SPECIFICATIONS
Gateway M275 Convertible
Specifications are subject to change without notice or obligation.

Processor and Core Logic

Processor options One Intel® Pentium® -M CPU
To determine your Tablet PC’s processor speed, click/tap Start, My Computer, then tap/click View System Information. The processor speed is listed.
Processor packaging Intel micro-FCBGA
Level 2 cache 1 MB
Core logic Intel 85855GME + ICH4-M
Processor side bus speed
400 MHz front side bus
-OR-
800 MHz front side bus
Tablet Notebook
BIOS Phoenix BIOS
512 KB Flash ROM
SMBIOS 2.3 support
Advanced Configuration and Power Interface 1.0b (ACPI 1.0b) support
Wired for Management 2.0 (WfM 2.0)

System memory

Memory type 333 MHz DDR SDRAM
Memory expansion options
Two 200-pin industry standard DDR-SODIMM sockets
Accepts two PC1600 DDR SDRAM memory modules
1 GB maximum system memory
No on-board memory
To determine your notebook’s memory, click/tap Start, My Computer, then click/tap View System Information. The memory is listed.
www.gateway.com
1

Video

Graphics controller
Intel 85855GME (chipset integrated)
2D hardware acceleration
3D rendering acceleration
Video memory UMA (shared memory) architecture with Dynamic Video Memory
Te c h no l ogy ( DV MT)
LCD display panel 14.1-inch active matrix (TFT) LCD color display, tablet version
Maximum panel resolution: 1024
× 768
Maximum color depth: 32-bit (16.7 million colors)
LCD supported video modes XGA
LCD maximum refresh rate 60 Hz
Controls
External video
Brightness level selectable through FN keys (up, down)
Auto dim on battery
Auto bright on AC power
Supports dual display and extended desktop
Integrated TV encoder
External CRT resolutions Supports standard IBM VGA compatible modes
Maximum resolution: 1920
× 1200
Maximum color depth: 32-bit (16.7 million colors)
External CRT maximum refresh rate 75 Hz
TV out (S-Video) jack Supports NTSC/PAL connection to standard TV monitors with
S-Video jack on the optional port replicator
IEEE 1394
One 4-pin connector
100/200/400 mbps
Supports video and audio capture
Software included for motion and still-frame capture

Audio

Audio chipset Sigmatel® Soft Audio AC97 rev 2.3 codec (STAC9752)
Sound support
2
PCI interface audio
Multi-stream Direct Sound and Direct Sound 3D acceleration
SoundBlaster Pro, MIDI, Windows Sound System compatible, MP3, WMA
S/PDIF output for PCM or AC-3 content via Toslink jack on port replicator
PCI Power Management Interface (PPMI) 1.1 compliant
www.gateway.com
Digital DVD audio Provides full 5.1 channel Dolby Digital output (AC-3) from DVD
decoder through Toslink optical S/PDIF jack on the optional port replicator
Vol u m e c o n t r o ls
Volume control keys on keyboard
Software control provided through Windows
Internal speakers
Stereo speakers built into sides of notebook
1.5 W maximum output
Internal microphone Omni-directional, low impedance
Audio jacks
Stereo headphone output
Monophonic microphone input

Communications

Modem features
10/100 Mbps Ethernet interface features
Wireless Ethernet interface features (Factory installed option)
Integrated Agere AC 97 Soft V.92/56K data/fax modem
Uses the RJ-11 jack on the side of the notebook
Integrated IEEE 802.3 (10/100 BASE-TX) Ethernet interface
Uses the RJ-45 jack on the back of the notebook
Supports Wake on LAN from S3 power mode
Intel® PRO/Wireless IEEE 802.11b network card embedded in the notebook
-OR-
Intel® PRO/Wireless IEEE 802.11b/g network card embedded in the notebook
-OR-
Broadcom BCM94306 IEEE802.11g network card embedded in the convertible tablet PC
-OR-
Broadcom BCM94300 IEEE802.11a/g network card embedded in the convertible tablet PC
Antenna: Uses factory-installed internal antenna assembly
Operating channels: 11 selectable channels
Button toggle: Turns wireless Ethernet emitter on or off
Security: 128 and 64 bit WEP encryption
Operating Frequency
2.4 GHz Direct Sequence Spread Spectrum (IEEE 802.11b and IEEE 802.11g)
5.0 GHz (IEEE 802.11a)
Maximum Data Rate
54 Mbps (IEEE802.11g and IEEE 802.11a)
11 Mbps (IEEE802.11b)
www.gateway.com
3

Input/Output (I/O)

Keyboard
Pointing device
U.S. English keyboard
Full-sized 86-key keyboard
19 mm × 19 mm key pitch
3.0 mm keystroke
Gateway EZ-Pad™ touchpad
2-buttons plus rocker switch
Multifunction buttons Four “hot keys” that launch Web browser, e-mail, help application,
and My Computer
LCD panel buttons Four buttons that are used to control the convertible tablet PC when
in tablet mode
Screen rotation
Tablet input panel
Brightness boost/dim
Windows security
Microphone Integrated monophonic microphone
LED status indicators
Input/Output (I/O) ports
Hard drive access
DVD or DVD/CD-RW drive access
Memory card access
Battery status
Power/Suspend
Caps lock
Scroll lock
PA D l o c k
Two USB 2.0 (4-pin)
IEEE 1394 (4-pin)
V.92, 56K Modem (RJ-11)
10/100 Ethernet (RJ-45)
External monitor (VGA)
Stereo headphone output
Monophonic microphone input
PC Card socket (one Type II)
Docking port
DC input
PCMCIA
4
Accepts one Type II device
Ricoh R5C593 controller
NOTE: This notebook does not support Zoomed Video.
www.gateway.com

Docking Solution

Type Port replicator
Docking supported
Hot dock
Warm dock
Cold dock
Input/Output (I/O ports)
Two PS/2
Three USB 2.0 (4-pin)
S-Video TV out
External monitor (VGA)
Parallel
High-speed serial
Ethernet (RJ-45)
S/PDIF digital audio out
Monophonic microphone input
Stereo headphone output
Analog audio line input (stereo)
Docking port
DC input
Security Kensington lock loop

Storage

Hard drive controller Supports up to Ultra DMA 100 and up to PIO mode 4
Hard drive
Super I/O controller
User removable
2.5-inch diameter
9.5 mm height
To find the hard drive capacity, click/tap Start, then click/tap My
Computer. Right-click/Button-tap the drive letter, then click/tap Properties. The drive’s capacity and available space appears. If the
drive has multiple partitions (for example, C: and D:), add the capacities of each partition to determine the drive’s total capacity.
NS PC87391 LPC super I/O controller
IEEE 1284 compliant parallel port
Memory card reader Supports the following card types:
Memory Stick
MultiMediaCard
Secure Digital
SmartMedia
®
www.gateway.com
5
Modular bay One modular bay is available on the notebook for an optical drive.
Available drives include:
DVD
Combination DVD/CD-RW
To determine the type of optical drive in a bay, examine the drive tray’s plastic cover. A DVD logo indicates a DVD drive, and a DVD logo in combination with a CD-R/RW logo indicates a DVD drive that also is a recordable/rewritable CD drive.

Power

Intelligent charger Supports dynamic charge current to achieve the best charge
performance
AC adapter
19 VDC, 3.16A, 60 W output
Automatically adjusts for 100 to 240 VAC, 50 to 60 Hz power sources
Three-wire design
Battery type
Battery capacity
Removable 8-cell Lithium Ion battery pack
Embedded controller inside to support smart battery
3.6 Ah
14.8 V nominal
53.28 Wh
Battery life varies depending on configuration, programs, power management settings, and features used. Recharge time varies, depending on usage.
Power management
Advanced Configuration and Power Interface 1.0b or later (ACPI 1.0b or later) support
SMBIOS 2.3
PC 2001 compliant
Controls
Keyboard-activated pop-up display gives battery charge as a percentage remaining
Icon on taskbar shows battery charge as a percentage remaining
Power switch Supports Power On/Off, Suspend/Resume, or Hibernate
Reset hole Resets whole system if notebook cannot recover by power switch
Lid switch System power on with lid raise, LCD On/Off, Suspend/Resume, or
Hibernate
6
www.gateway.com

Security

Passwords
Physical
Power-on password (2-level password support)
Hard drive password
System memory compartment screws
Hard drive kit screw
Kensington® security slot on notebook sides

System software

Operating system Microsoft® Windows® XP Professional Tablet PC Edition
System management
SMBIOS 2.3 BIOS support
Advanced Configuration and Power Interface 1.0b (ACPI 1.0b) support
Support for Wake on LAN from S3 power mode
Support for Intel® LANDesk® Client manager 6.0
Wired for Management 2.0 (WfM 2.0) enabled
System compatibility
PC2001 specification
Advanced Configuration and Power Interface 1.0b (ACPI 1.0b) or later
SMBIOS 2.3
Windows Hardware Quality Labs (WHQL) certified
Quick boot Supported

Physical specifications

Dimensions ~1.2 × 12.6 × 11.1 in. (H × W × D)
~31 × 320 × 282 mm (H × W × D)
System weight ~5.7 lbs.
~2.6 kg
Includes DVD drive and 8-cell battery
AC adapter weight ~0.9 lbs
~0.41 kg
Includes cord
www.gateway.com
7

Environment

Operating temperature 41°F to 95°F (5°C to 35°C)
Storage temperature -4
Operating humidity 20% to 80% relative humidity; no condensation
Storage humidity 10% to 90% relative humidity; no condensation
Operating altitude, maximum 8,000 feet at 59
Storage altitude, maximum 12,000 feet (3,658 m)
°F to 140°F (-20°C to 60°C)
°F (2,438 meters at 15°C)
MAN SYS M275 SPEC R2 6/04
