Instruction Manual
PT-85 Blowback Socom
P25 Blowback Tactical
PT-85 Blowback Tactical
READ THIS INSTRUCTION MANUAL COMPLETELY.
This airgun is not a toy. Treat it with the same respect you would a firearm. Always carefully follow the safety directions found in this instruction manual and keep this manual in a safe place for future use.
Not a toy. Adult supervision required. Misuse or careless use may cause serious injury or death. May be dangerous up to 224 yards (205 metERs).
This is a high powered airgun intended for use by those 16 years of age or older. Read all instructions before using. The purchaser and user should conform to all laws governing use and ownership of airguns.
! WARNING Lead airgun ammunition contains a chemical known to the state of California to cause cancer and birth defects (or other reproductive harm). Do not inhale dust or put pellets in mouth. Wash hands after handling.
SAFETY RULES:
•Do not install a magazine which contains ammunition into the gun until you are ready to shoot. If you do install a magazine which contains ammunition into the gun and then decide not to shoot, either manually remove the magazine from the gun or shoot the remaining ammunition at a safe target.
•An unloaded, non-pressurized gun with an “ACTIVATED” safety is safest.
•Accidents happen fast, and accidentally injuring or killing someone is a terrible thing. Please shoot safety.
•Whenever you handle a GAMO pistol, make sure the safety is “ACTIVATED” and there is no ammunition in the magazine.
•Always use eye protection.
•Always use hearing protection.
•Think first, shoot second.
•Always point the gun in a safe direction. Never point your air pistol at people or animals even if it is not loaded.
•Always keep your fingers away from the trigger until you are ready to shoot.
•Always be certain of what is behind your target. Make sure your target does not conceal a person or some object which could be harmed by the pellets.
•Do not shoot at targets which allow ricochets or deflections.
•Do not shoot into or at water.
•Never use drugs or alcohol while handling this product.
•The air pistol and pellets should be kept in separate and secured places.
•Do not walk, run, jump or climb when carrying a loaded air pistol. A loaded air pistol should never be carried inside a vehicle.
•Never modify or alter your GAMO air pistol. Modification of the pistol may cause it to malfunction and tampering with the gun may make it unsafe.
DO NOT BRANDISH OR DISPLAY THIS AIRGUN IN PUBLIC. IT MAY CONFUSE PEOPLE AND MAY BE A CRIME. POLICE AND OTHERS MAY THINK THIS AIRGUN IS A FIREARM. DO NOT CHANGE THE COLORATION AND MARKINGS TO MAKE IT LOOK MORE LIKE A FIREARM. THAT IS DANGEROUS AND MAY BE A CRIME.
DESCRIPTION:
P-25 Blowback Tactical
|
1. |
|
4. |
2. |
10. |
|
||
|
|
3.
9. 11.
8.
7.
DESCRIPTION:
1. Safety |
4. Rear Sight |
7. Magazine |
6. |
|
|
|
|
||||
2. Slide |
5. CO2 Compartment |
8. Trigger |
5. |
||
3. Quad Rail |
6. Magazine Slot |
9. Muzzle Blast Compensator |
|
|
|
DESCRIPTION:
PT-85 Blowback Tactical
10.
4.
12.
2.
1.
11.
9.
3.
DESCRIPTION:
1. Safety |
4. Rear Sight |
7. Magazine Release Button |
10. 13MM RGB Dot Sight |
2. Slide |
5. CO2 Compartment |
8. Trigger |
11. Tactical Flashlight |
3. Quad Rail |
6. Magazine Slot |
9. Muzzle Blast Compensator |
12. Laser Sight |
8.
7.
6.5.
SAFETY:
|
SAFE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
FIRE |
|
|
|
|||||||||
|
• Activated |
|
|
|
|
|
|
|
|
|
• Deactivated |
|
|
|
|||||||
|
Safety |
|
|
|
|
|
|
|
|
|
Safety |
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
REPLACING THE CO2 BOTTLE: |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
1 |
|
|
|
|
2 |
|
|
|
4 |
|
|
|
|
5 |
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
Replace the |
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
3 |
12 gr CO2 capsule |
3.1 |
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
Use only 12 gram CO2 cylinders. Any attempt to use others types of gas cylinders could be extremely dangerous and could result in serious injury or death. Gases other than CO2 could result in an explosion or rupture the airgun.
! WARNING Keep hands and face away from the CO2 cylinder. Escaping CO2 gas can cause frostbite if allowed to come in contact with skin.
! WARNING
If you are not going to use the pistol for a long period of time, we recommend removing the CO2 bottle.
When replacing the CO2 bottle, it is possible that some residual gas is left. In order to avoid accidents, make sure that the pistol is unloaded and the safety is “ACTIVATED” when removing or placing a CO2 bottle. Never use force to insert a CO2 bottle.
Keep the CO2 bottles away from heat and flames. Temperatures over 50º C (120º F) can cause explosion and injury. Never throw a CO2 bottle into a fire.
Always wear eye protection when handling CO2 bottles, since there is a risk of injury to the eyes. Do not remove a CO2 bottle until it is completely empty. Failure to observe this recommendation can result in a dangerous escape of residual gas.
LOADING THE PELLETS:
2
1
3 |
4 |
! WARNING When preparing to store the pistol, point the barrel at the ground and make sure that the magazine is empty and that there are no pellets in the barrel. In this way you will avoid possible accidents when using the pistol again.
! WARNING When there is an obstruction in the barrel, never shoot another pellet. Always make sure that the Safety is activated before clearing an obstruction.
NOTE: Always discard defective ammunition. We recommend GAMO ammunition for GAMO CO2 pistols. Never reuse pellets
UNLOADING THE PELLETS:
Keep the air pistol pointed in a SAFE DIRECTION. Remove the magazine. Fire at a SAFE target. Repeat until you are sure the air pistol no longer fires ammunition.You may also unload your air pistol by following the directions listed under “Removing Jammed Ammunition”.
REMOVING JAMMED Ammunition:
Keep the air pistol pointed in a safe direction. Remove the magazine. Remove the CO2 cylinder. Insert a .177 caliber ramrod into the muzzle end and carefully push the jammed BB or pellet into the breech area and remove. If you are not able to unjam your air pistol, take not further action. Call GAMO at (954) 581-5822 and ask for the customer service department. NOTE: The barrel could be damaged and the warranty will be void if the proper sized ramrod is NOT used.
Make sure that the Safety is activated and the CO2 bottle has been removed before proceeding with the removal of ammunition. Before removing the CO2 bottle, make sure that it is empty of CO2.
