Furuno FS-5070 User Manual 2

OPERATOR'S MANUAL

SSB RADIOTELEPHONE

FS-1570 FS-2570

MODEL

FS-5070

www.furuno.co.jp

9‑52Ashihara‑cho,

Fax:

A:NOV

2006

C2:JUL.17,2008

Pub.No.

OME‑56560‑C2

00016050112

**00016050112

(

TATA

)

FS‑1570/2570/5070

00016050112

**00016050112

Nishinomiya,662‑8580,JAPAN

Telephone: +81‑(0)798‑65‑2111

+81‑(0)798‑65‑4200

Thepaperusedinthismanual iselementalchlorinefree.

・FURUNOAuthorizedDistributor/Dealer

Allrightsreserved.

PrintedinJapan

*00016050112*

IMPORTANT NOTICE

• This manual is intended for use by native speakers of English.

• No part of this manual may be copied or reproduced without written permission.

• If this manual is lost or worn, contact your dealer about replacement.

• The contents of this manual and equipment specifications are subject to change

without notice.

• The example screens (or illustrations) shown in this manual may not match the

screens you see on your display. The screen you see depends on your system configuration and equipment settings.

• Store this manual in a convenient place for future reference.

• FURUNO will assume no responsibility for the damage caused by improper use or

modification of the equipment (including software) by an unauthorized agent or a third party.

• Dispose of the equipment according to local regulations.

SAFETY INSTRUCTIONS

The user and installer must read the appropriate safety instructions before attempting to install or operate the equipment.

Indicates a hazardous situation which, if not avoided, will result in

DANGER WARNING

CAUTION

death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

Warning, Caution

DANGER

Never touch the SSB antenna, antenna coupler or lead-in insulator when the SSB radiotelephone is transmitting.

High voltage which will cause death or serious injury is present at the locations shown in the illustration below when the SSB radiotelephone is transmitting.

Antenna

Antenna Wire (High Voltage)

Antenna Coupler

Indoor

WARNING

Do not open the equipment.

Only qualified personnel should work inside the equipment.

Immediately turn off the power at the switchboard if water leaks into the equipment or something is dropped into the equipment.

Continued use of the equipment can cause fire or electrical shock. Contact a FURUNO agent for service.

Do not disassemble or modify the equipment.

Fire, electrical shock or serious injury can result.

Wire

Lead-in Insulator (High Voltage)

Prohibitive Action

Immediately turn off the power at the switchboard if the equipment is emitting smoke or fire.

Continued use of the equipment can cause fire or electrical shock. Contact a FURUNO agent for service.

Do not operate the equipment with wet hands.

Electrical shock can result.

Turn off the power immediately if you feel the equipment is behaving abnormally.

Turn off the power at the switchboard if the equipment becomes abnormally warm or is emitting odd noises. Contact a FURUNO dealer or agent for advice.

Make sure no rain or water splash leaks into the equipment.

Fire or electrical shock can result if water leaks in the equipment.

Use the proper fuse.

Use of the wrong fuse can cause fire

or electrical shock.

Mandatory Action

WARNING

Do not place liquid-filled containers on the top of the equipment.

Fire or electrical shock can result if a liquid spills into the equipment.

WARNING

CAUTION

Do not operate the [DISTRESS] button except in case of a life-endangering situation on your vessel.

If the distress alert is accidentally transmitted, contact the nearest coast station and inform them of the accidental transmission, providing the following data:

Operating the [DISTRESS] button transmits the distress alert. Accidental transmission may prevent search and rescue operations for actual emergency. If the distress alert is accidentally

a) Ship's name b) Ship's call sign and DSC number c) Position at time of transmission d) Time of transmission

transmitted, contact the nearest station to cancel the alert.

Do not apply strong pressure to the LCD, which is made of glass.

Injury can result if the LCD breaks.

WARNING LABEL(S)

Do not remove any safety label. If a label is missing or damaged, contact a FURUNO agent or dealer about replacement.

DANGER

Hazardous voltage.

Can shock

burn

or cause death.

Do not touch antenna

wire

insulator and

terminal.

Name: Danger Label

Type:

05-062-0213-0

Code No.:

100-199-230

WARNING

To avoid electrical shock, do not remove cover. No user-serviceable parts inside.

ANTENNA COUPLER

Name: Warning Label (1) Type: 86-003-1011 Code No.: 100-236-231

TRANSCEIVER UNIT

iii

DISTRESS ALERT MESSAGE PROCEDURE

Below is the procedure for transmitting a distress alert via radiotelephone. Transmit the distress alert when a life-endangering situation occurs on your vessel.

1. Open the DISTRESS button cover and press the DISTRESS button more than four seconds to show the following display, then release the DISTRESS button.

Distress button pressed!

NATURE: UNDESIGNATED

POS:

12°34.0000 N 123

TELEPHONE

DSC FREQ : 2187.5kHz

45.0000E AT 12:34

KEEP PRESSED FOR 2S

2. After the distress message has been transmitted, the following displays appear in order.

2182.0 kHz

Wait for distress acknowledgement.

NATURE: UNDESIGNATED POS:

12 34.5678N 123 45.6789E AT 12:34

TELEPHONE DSC FREQ :

TIME TO GO: 2M10S

2. 4. 6. 8. 12. 16. M RESENDING

When distress message is acknowledged by coast station (usually within 1 min to 2 min 45 seconds)

Distress acknowledge message received.

CANCEL: STOP ALARM

NATURE: UNDESIGNATED POS:

12 34.5678N DIST: 0nm 123 45.6789E AT 12:34

TELEPHONE

2182.0 kHz

3. The audio alarm sounds; press the CANCEL key to silence the alarm.

4. Communicate with the coast station via radiotelephone as below.

Say MAYDAY three times. Say “This is …” name of your vessel and your message sign three times. Give nature of distress and assistance needed. Give description of your vessel (type, number of persons onboard, etc.) and any other

information which may aid in rescue.

Note: If the distress message is not acknowledged by coast station, it will be transmitted

again after 3 min 30 seconds to 4 min 30 seconds.

For IC-302 (option) operation

1. Open the DISTRESS button cover and press the DISTRESS button more than four seconds.

2. After the distress message has been transmitted, the length of the beep changes from short to long.

3. Release the DISTRESS button.

4. Do step 4 shown in the Distress Alert Message Procedure above with the radiotelephone.

CANCELING DISTRESS ALERT

You can cancel the distress call while it is being sent or while waiting for its acknowledgement as follows.

1. Press the CANCEL key. When the following message appears, do the following.

Distress Proc. is Paused.

NATURE: UNDESIGNATED POS:

12 34.5678N

RESUME RESEND CANCEL

123 45.6789E

DSC FREQ : TIME TO GO : 0S

2. Rotate the ENTER knob to choose CANCEL at the screen, and then push the ENTER

2187.5 kHz

knob.

Warning: Distress Cancel Step

NATURE: UNDESIGNATED POS:

12 34.5678N

YES NO

123 45.6789E

DSC FREQ :

TIME TO GO : 0S

2187.5 kHz

3. Rotate the ENTER knob to choose YES, and then push the ENTER knob to show the following screen.

Distress Cancellation Proc. Select frequency and push ENTER.

NATURE: UNDESIGNATED

POS:

12 34.5678N

Cancel: Back to pause menu.

123 45.6789E

2M-2187.5 kHz 8M-8414.5kHz

4M-4207.5kHz 12M-12577.0kHz 6M-6312.0kHz 16M-16804.5kHz

The cancellation message is transmitted over the same frequency used to transmit the distress call.

Now Transmitting Distress Cancellation Message

NATURE: UNDESIGNATED POS:

12 34.5678N 123 45.6789E

2M-2187.5 kHz 8M-8414.5kHz

4M-4207.5kHz 12M-12577.0kHz 6M-6312.0kHz 16M-16804.5kHz

CANCELLING DISTRESS ALERT

4. Communicate, via radiotelephone, with the coast station.

Send cancel msg. by voice on 2182.0 kHz.

NATURE: UNDESIGNATED

POS:

12 34.5678N

Push any key: Go next step.

123 45.6789E

*2M-2187.5 kHz 8M-8414.5kHz

4M-4207.5kHz 12M-12577.0kHz

6M-6312.0kHz 16M-16804.5kHz

Asterisk marks the frequency over which the cancellation call was transmitted..

5. Press any key. If you used other frequencies to send the distress call, cancel distress call on those frequencies by repeating steps 3 to 5.

When all cancellation is completed, the RT display appears.

FOREWORD ...................................................................................................... xii

SYSTEM CONFIGURATIONS ........................................................................... xiv

1. OPERATIONAL OVERVIEW......................................................................... 1-1

1.1 Controls..................................................................................................................... 1-1

1.2 Turning the Power On/Off .......................................................................................... 1-2

1.3 Radiotelephone (RT) Screen .....................................................................................1-2

1.4 DSC Standby Screen................................................................................................. 1-3

1.5 Control Unit Dimmer, Contrast ................................................................................... 1-4

1.6 Loudspeaker.............................................................................................................. 1-4

1.7 Setting Scan Frequencies.......................................................................................... 1-4

1.8 Setting for Auto Acknowledgement ............................................................................ 1-5

1.9 System Characteristics .............................................................................................. 1-5

1.9.1 Equipment priority ........................................................................................... 1-5

1.9.2 Controls become inoperative........................................................................... 1-5

1.9.3 Controls become operative.............................................................................. 1-5

1.9.4 Automatic setting of working frequency ........................................................... 1-6

1.10 Intercom ....................................................................................................................1-6

2. SSB RADIOTELEPHONE ............................................................................. 2-1

2.1 Choosing Class of Emission ...................................................................................... 2-1

2.2 Choosing Channel, Frequency ..................................................................................2-2

2.3 Transmitting............................................................................................................... 2-3

2.3.1 Transmitting procedure.................................................................................... 2-3

2.3.2 Reducing transmitter power............................................................................. 2-4

2.3.3 Condition of the transmitting unit ..................................................................... 2-4

2.4 Receiving................................................................................................................... 2-5

2.4.1 RF gain (sensitivity) adjustment....................................................................... 2-5

2.4.2 S-meter ........................................................................................................... 2-5

2.4.3 Receiving AM broadcasting stations................................................................ 2-6

2.4.4 Squelch function.............................................................................................. 2-6

2.4.5 Noise blanker .................................................................................................. 2-6

2.5 When Automatic Tuning Fails .................................................................................... 2-7

2.6 User Channels........................................................................................................... 2-8

3. DSC OVERVIEW ........................................................................................... 3-1

3.1 What is DSC?............................................................................................................ 3-1

3.2 DSC Message ...........................................................................................................3-1

3.3 Audio Alarms ............................................................................................................. 3-3

3.4 Interpreting Call Displays........................................................................................... 3-4

3.4.1 Receive calls................................................................................................... 3-4

vii

TABLE OF CONTENTS

3.4.2 Send calls ....................................................................................................... 3-5

4. DISTRESS OPERATIONS ............................................................................4-1

4.1 Sending Distress Alert............................................................................................... 4-1

4.1.1 Sending distress alert by DISTRESS button, nature of distress not specified . 4-2

4.1.2 Sending distress alert by DISTRESS button, nature of distress specified ....... 4-4

4.2 Receiving a Distress Alert.......................................................................................... 4-7

4.2.1 Distress alert received on MF band................................................................. 4-7

4.2.2 Distress alert received on HF band ................................................................4-10

4.3 Sending Distress Relay on Behalf of a Ship in Distress............................................4-14

4.3.1 Sending distress relay to coast station...........................................................4-14

4.3.2 Sending distress relay to area ships ..............................................................4-18

4.4 Receiving Distress Relay from Coast Station............................................................4-21

4.5 Cancelling Distress Call ...........................................................................................4-21

5. RoutINE MESSAGE CALLING, RECEIVING ...............................................5-1

5.1 Individual Call............................................................................................................ 5-1

5.1.1 Sending an individual call................................................................................ 5-1

5.1.2 Receiving an individual call............................................................................. 5-7

5.2 Group Call................................................................................................................5-12

5.2.1 Sending a group call ......................................................................................5-12

5.2.2 Receiving a group call....................................................................................5-14

5.3 Geographical Area Call ............................................................................................5-15

5.3.1 Sending a geographical area call...................................................................5-16

5.3.2 Receiving a geographical area call ................................................................5-17

5.4 Neutral Craft Call......................................................................................................5-19

5.4.1 Sending a neutral craft call.............................................................................5-19

5.4.2 Receiving a neutral craft call ..........................................................................5-20

5.5 Medical Transport Call..............................................................................................5-21

5.5.1 Sending a medical transport call ....................................................................5-21

5.5.2 Receiving a medical transport call..................................................................5-23

5.6 Receiving a Polling Request.....................................................................................5-24

5.6.1 Automatic reply..............................................................................................5-24

5.6.3 Manual reply ..................................................................................................5-25

5.7 Position Call .............................................................................................................5-26

5.7.1 Requesting other ship’s position ....................................................................5-26

5.7.2 Position call: other ship requests your position...............................................5-28

5.8 PSTN Call ................................................................................................................5-30

5.8.1 Sending a PSTN call, receiving acknowledge back (ACK BQ).......................5-30

5.8.2 Receiving a PSTN call, sending acknowledge back (ACK BQ) ......................5-33

5.8.3 PSTN call disconnection, receiving charge information

(ship disconnects line)....................................................................................5-35

5.8.4 PSTN call disconnection, receiving charge information

(coast station disconnects line) ......................................................................5-36

5.9 Log File ....................................................................................................................5-36

5.9.1 Opening a log file...........................................................................................5-36

5.9.2 Deleting log files ............................................................................................5-37

viii

TABLE OF CONTENTS

6. MENU OPERATION ......................................................................................6-1

6.1 Adjusting Handset Volume......................................................................................... 6-1

6.2 Noise Blanker ............................................................................................................ 6-2

6.3 Squelch Frequency.................................................................................................... 6-2

6.4 User Channels........................................................................................................... 6-2

6.4.1 Registering user channels............................................................................... 6-2

6.4.2 Deleting user channels.................................................................................... 6-4

6.5 Preparing TX Message .............................................................................................. 6-4

6.5.1 Preparing individual calls................................................................................. 6-4

6.5.2 Preparing group calls ...................................................................................... 6-7

6.5.3 Preparing PSTN calls ...................................................................................... 6-9

6.5.4 Preparing test call..........................................................................................6-10

6.5.5 Sending prepared messages......................................................................... 6-11

6.5.6 Deleting send message................................................................................. 6-11

6.5.7 Printing List of Send Message Files ..............................................................6-12

6.6 Manual Entry of Position and Time .......................................................................... 6-12

6.7 Date and Time Setting ............................................................................................. 6-14

6.8 Memory Clear.......................................................................................................... 6-14

6.9 Setting Alarms ......................................................................................................... 6-16

6.10 Sound Setting .......................................................................................................... 6-17

6.11 Setting the AUTO ACK Details ................................................................................. 6-18

6.12 Printing Messages................................................................................................... 6-19

6.13 Setting Scan Frequencies........................................................................................ 6-20

6.14 Key Assignment....................................................................................................... 6-22

6.15 Special Messages.................................................................................................... 6-22

6.16 FAX Enable/Disable................................................................................................. 6-23

6.17 Speaker Setting in Off Hook..................................................................................... 6-23

6.18 Operation Timer Off .................................................................................................6-23

7. NBDP SYSTEM OVERVIEW......................................................................... 7-1

7.1 Turning on the NBDP System .................................................................................... 7-1

7.2 Description of Equipment........................................................................................... 7-2

7.2.1 Terminal unit.................................................................................................... 7-2

7.2.2 Keyboard......................................................................................................... 7-3

7.3 Function Keys, Menu Operation................................................................................. 7-4

7.3.1 Menu conventions ........................................................................................... 7-4

7.3.2 Menu overview................................................................................................ 7-5

7.3.3 Function key description.................................................................................. 7-6

8. NBDP PREPARATIONS................................................................................ 8-1

8.1 Registering Answerback Code & ID Codes................................................................ 8-1

8.1.1 Registering answerback code .........................................................................8-1

8.1.2 Registering ID codes....................................................................................... 8-2

8.2 Station List................................................................................................................. 8-3

8.2.1 Registering stations......................................................................................... 8-3

8.2.2 Editing/Deleting stations.................................................................................. 8-4

8.3 Timer Programming ................................................................................................... 8-5

8.3.1 Registering timer programs ............................................................................. 8-5

TABLE OF CONTENTS

8.3.2 Editing/Deleting timer programs...................................................................... 8-6

8.4 User Channels .......................................................................................................... 8-6

8.4.1 Registering user channels............................................................................... 8-6

8.4.2 Editing/Deleting user channels........................................................................ 8-7

8.5 Scan Channel Groups............................................................................................... 8-7

8.5.1 Registering scan channel groups.................................................................... 8-7

8.5.2 Editing/Deleting scan channel groups ............................................................. 8-8

9. NBDP FILE OPERATIONS ...........................................................................9-1

9.1 Opening and Closing Files ........................................................................................ 9-1

9.2 Creating Files............................................................................................................ 9-1

9.3 Saving a File ............................................................................................................. 9-2

9.3.1 Formatting floppy disks ................................................................................... 9-2

9.3.2 Saving a file .................................................................................................... 9-3

9.4 Editing Files............................................................................................................... 9-3

9.4.1 Cutting and pasting text .................................................................................. 9-3

9.4.2 Copying and pasting text................................................................................. 9-4

9.4.3 Select all......................................................................................................... 9-5

9.4.4 Searching text................................................................................................. 9-5

9.4.5 Replacing text................................................................................................. 9-6

9.4.6 Goto line ......................................................................................................... 9-6

9.4.7 Goto top, Goto bottom .................................................................................... 9-6

9.5 Opening Files............................................................................................................ 9-7

9.5.1 Opening a file.................................................................................................. 9-7

9.5.2 Switching between files................................................................................... 9-7

9.6 Renaming Files ......................................................................................................... 9-7

9.7 Saving a File Under a New Name ............................................................................. 9-8

9.8 Deleting Files ............................................................................................................ 9-8

9.9 Real Time Printing..................................................................................................... 9-8

9.10 Printing Files ............................................................................................................. 9-8

10. NBDP TRANSMITTING, RECEIVING .................................................. 10-1

10.1 Manual Calling .........................................................................................................10-1

10.2 ARQ Mode Operation...............................................................................................10-3

10.3 FEC Mode Operation ...............................................................................................10-5

10.4 Choosing Receive Mode ..........................................................................................10-5

10.5 Communication Example..........................................................................................10-6

10.6 Timer Operation .......................................................................................................10-8

10.6.1 Enabling timer operation ................................................................................10-8

10.6.2 Stopping timer operation ................................................................................10-9

10.7 Scanning ..................................................................................................................10-9

10.8 Communication Buffer............................................................................................10-10

10.9 Preparing Macrofiles for Automatic Telex................................................................10-10

10.9.1 Automatic telex overview .............................................................................10-10

10.9.2 Preparations ................................................................................................ 10-11

10.9.3 Commands ..................................................................................................10-12

10.9.4 Store-and-forward method ...........................................................................10-13

10.10 Automatic Telex using Macrofile ........................................................................10-17

TABLE OF CONTENTS

11. MAINTENANCE & TROUBLESHOOTING .......................................... 11-1

11.1 Radiotelephone Test ................................................................................................ 11-1

11.2 Maintenance ............................................................................................................ 11-2

11.3 Simple Troubleshooting ........................................................................................... 11-3

11.4 Error Messages ....................................................................................................... 11-4

11.5 Replacement of Fuses............................................................................................. 11-5

11.6 Test Call................................................................................................................... 11-6

11.7 NBDP Terminal Unit Maintenance............................................................................ 11-8

11.7.1 Cleaning the equipment ................................................................................ 11-8

11.7.2 Connectors and earth connection.................................................................. 11-8

11.7.3 Floppy disk drive ........................................................................................... 11-8

11.7.4 Diagnostics ................................................................................................... 11-8

APPENDIX ......................................................................................................AP-1

Menu Tree ...................................................................................................................... AP-1

NBDP terminal unit (telex) ...................................................................................... AP-2

Frequency Tables............................................................................................................ AP-3

Digital Interface (IEC 61162-1)...................................................................................... AP-17

Parts List....................................................................................................................... AP-22

Parts Location............................................................................................................... AP-26

INDEX............................................................................................................... IN-1

DECLARATION OF CONFORMITY

FOREWORD

Thank you for purchasing the FS-1570/2570/5070 SSB Radiotelephone. We are confident you will discover why FURUNO has become synonymous with quality and reliability.

Dedicated in the design and manufacture of marine electronics equipment for 60 years, FURUNO Electric Company has gained an unrivaled reputation as a world leader in the industry. This is the result of our technical excellence as well as our worldwide distribution and service network.

Please carefully read and follow the safety information and operating and maintenance instructions set forth in this manual before attempting to operate the equipment and conduct any maintenance. Your unit will perform to the utmost of its ability only if it is operated and maintained in accordance with the correct procedures.

Features

The FS-1570/2570/5070 is an MF/HF SSB Radiotelephone with a built-in DSC/Watch Receiver, all contained in a surprisingly compact cabinet. An NBDP (Narrow Band Direct Printing) Terminal Unit is optionally available.

Data is displayed on a large, easy-to-read backlit LCD. Operation is simplified by the use of few keys and easy-to-follow menus.

The built-in DSC/watch receiver produces and receives digital selective calls for quick and efficient establishment of distress, urgency, safety and routine communications with other ships and coast stations that install any MF/HF DSC facilities.

The main features are

General

Fully meets the following regulations: IMO A.806(19), IMO A.694(17), IMO A. 813(19), MSC 68(68) Annex 3, IEC 61097-3 Annex A, IEC 61162-1 (2000), IEC 60945 (2002), EN 300 373-1 (2002), ETS 300 067A1(1998), EN 300 338(2004), EN 301 033 (2005), ITU-R M.493-11, M.541-9, M.476-5, M.491-1, M.492-6, M.625-3, M.1173-3.

Automatic entry of position with manual override Optional printer can automatically print out DSC and NBDP received messages and test

results.

SSB

• Receiving voice communication, telex and AM.

• Facsimile signal receiving

• Simplified setting of channel and frequency.

xii

FOREWORD

DSC/watch receiver

• Distress, urgency, safety and routine calling

• Scanning of DSC frequencies for distress and general calls on MF/HF

• File editing capability for readiness in case of emergency

• PSTN (Public Switched Telephone Network) capability standard

• Log stores 50 each of latest ordinary, distress and transmitted messages, in separate

memory blocks.

NBDP (with optional NBDP Terminal Unit IB-583)

• Automatic error-free telex communications and distress message in compliance with

GMDSS requirements

• LCD monitor and keyboard comply with ITU regulations

• Pop-up menus for user-friendly operation

• Memory for 256 operator-customized channels

• Real time message printing with Printer PP-510

Program Number

FS-1570/2570/5070

PC board Program No. Ver. No. Remarks

MAIN 0550225 01 Main program

PANEL 0550222 01 Program for the control display

DSP (DSC) 0550207 01 MODEM Program for DSC

NBDP 0550208 01 MODEM Program for NBDP

Terminal Unit IB-581 (optional unit, for FS-1570/2570 only)

PC Board Program No. Ver. No Remarks

TERMINAL 0550210 1.22

Terminal Unit IB-583 (optional unit)

Program Program No. Ver. No Remarks

TERMINAL 0550209 1.22

About the TFT LCD: The TFT LCD is constructed using the latest LCD techniques, and displays99.99% of its pixels. The remaining 0.01%of the pixels may drop out or blink, however this is not an indication of malfunction.

xiii

SYSTEM CONFIGURATIONS

FS-1570

Standard configuration is shown with solid line.

DSC DISTRESS SAFETY FREQUENCY

# = 2.6 m whip antenna

PREAMP UNIT

FAX-5

ANTENNA COUPLER

AT-1560-15

EPFS (GNSS)

INCOMING INDICATOR IC-303-DSC

MIF EQUIPMENT

DISTRESS ALERT UNIT

IC-302-DSC

BK INTERFACE

BK-300

CONTROLLER 1

TRANSCEIVER UNIT

FS-1570T

CONTROLLER 2

AC/DC POWER

SUPPLY UNIT

PR-300

LOUDSPEAKER SEM-21Q

CONTROL

UNIT

FS-2571C

NBDP

TERMINAL UNIT

IB-583/IB-581

24VDC

CONTROL UNIT

FS-2571C

HANDSET

HS-2003

PRINTER

PP-510

INTERFACE

IF-8500*

* = Required for NBDP Terminal and DSC to share printer.

HANDSET

HS-2003

POWER STATUS

MONITOR

PSM-01

24VDC

Preamp Unit Antenna Coupler Other Units

xiv

24VDC

Exposed to weather Exposed to weather

Protected from weather

100-115/200-230VAC

, 50/60Hz

FS-2570

Standard configuration is shown with solid line.

SYSTEM CONFIGURATIONS

DSC DISTRESS SAFETY FREQUENCY

# = 2.6 m whip antenna

DISTRESS ALERT UNIT

PREAMP UNIT

FAX-5

EPFS (GNSS)

INCOMING INDICATOR

IC-303-DSC

MIF EQUIPMENT

IC-302-DSC

DSC ROUTINE FREQUENCY

PREAMP UNIT

FAX-5

W/R BOARD

CONTROLLER 1

TRANSCEIVER UNIT

FS-2570T

ANTENNA COUPLER

AT-1560-25

TERMINAL UNIT

IB-583/IB-581

LOUDSPEAKER SEM-21Q

CONTROL

UNIT

FS-2571C

NBDP

DC24V

HANDSET

HS-2003

PRINTER

PP-510

INTERFACE

IF-8500*

* = Required for NBDP Terminal and DSC to share printer.

24VDC

BK INTERFACE

Unit

Preamp Unit Antenna Coupler Other Units

BK-300

Category Exposed to weather Exposed to weather

Protected from weather

CONTROLLER 2

AC/DC POWER

SUPPLY UNIT

PR-850A

24VDC

CONTROL UNIT

FS-2571C

100-115/200-230VAC 1

, 50/60Hz

HANDSET

HS-2003

POWER STATUS

MONITOR

PSM-01

SYSTEM CONFIGURATIONS

FS-5070

Standard configuration is shown with solid line.

DSC DISTRESS SAFETY FREQUENCY

DSC ROUTINE FREQUENCY

# = 2.6 m whip antenna

PREAMP UNIT

EPFS (GNSS)

INCOMING INDICATOR IC-303-DSC

MIF EQUIPMENT

DISTRESS ALERT UNIT

IC-302-DSC

BK INTERFACE

BK-300

FAX-5

PREAMP UNIT

FAX-5

W/R BOARD

CONTROLLER 1

TRANSCEIVER UNIT

FS-5070T

CONTROLLER 2

ANTENNA COUPLER

AT-5000

CONTROL

FS-2571C

NBDP

TERMINAL UNIT

IB-583

24VDC

CONTROL UNIT

LOUDSPEAKER SEM-21Q

UNIT

FS-2571C

HANDSET

HS-2003

PRINTER

PP-510

INTERFACE

IF-8500*

* = Required for NBDP Terminal and DSC to share printer.

HANDSET

HS-2003

24VDC

Unit

Preamp Unit Antenna Coupler Other Units

Category Exposed to weather Exposed to weather

Protected from weather

24VDC

AC/DC POWER

SUPPLY UNIT

PR-850A

100-115/200-230VAC 1φ, 50/60Hz

POWER STATUS

MONITOR

PSM-01

xvi

1. OPERATIONAL OVERVIEW

1.1 Controls

Description of controls

Control Function

PWR/VOL knob

DISTRESS button

CALL key Transmits DSC messages. ENTER knob

CANCEL key

1/ RT/CH key

2/DSC key Composes DSC TX message. 3/TEST key Executes daily test and TX self-check. 4/IntCom key Turns on/off the intercom with other Control Unit FS-2571C. 5/ ACK/SQ key

6/SCAN key

• Turns the power on/off.

• Adjusts volume.

Press and hold down the button more than four (4) seconds to transmit the distress alert.

Rotate to choose menu items; push to register selection.

• Cancels wrong data.

• Restores previous menu.

• Silences audio alarm.

• Cancels transmission, printing.

• Erases error message.

Switches to the radiotelephone (RT) screen. Press and hold down more than five (5) seconds to set SSB: 2182.0 kHz/J3E.

DSC: Switches automatic and manual acknowledge alternately. Radiotelephone: Turns squelch on and off.

• Displays DSC screen.

• Starts/stops scanning of DSC routine frequencies, on the DSC standby

screen.

1-1

1. OPERATIONAL OVERVIEW

7/ key

8/PRINT key Prints communications log files, current screen (except DSC standby

9/ key */FILE/CURSOR

key

0/LOG/TUNE key

#/SETUP key Opens the main menu. ALARM lamp

OVEN lamp Lights (in green) when mains switchboard is on.

Turns loudspeaker on/off.

(Note that this key does not silence the distress or urgency alarm.)

screen and radiotelephone screen) and test results. Adjusts panel dimmer and LCD contrast.

• Opens the send message file list from the DSC standby screen, to send

stored message.

• Shifts cursor.

• Long press: Tunes antenna in radiotelephone operation.

• Momentary press: Displays message logs.

• Flashes in red for distress and urgency messages.

• Flashes in green for safety and routine messages.

1.2 Turning the Power On/Off

Turn the PWR/VOL knob clockwise at the right-hand side of the control unit to power the system. The RT screen appears.

Rotate the PWR/VOL knob counterclockwise to turn the system off.

In the dual control unit system, the control unit connected to the CONTROLLER 1 port on the transceiver unit has priority and it controls the power for both the No.1 and No. 2 control units. The power switch of the No. 2 control unit powers on/off the No. 2 control unit only.

Note: Turn on power at switchboard more than five minutes before turning on this equipment.

1.3 Radiotelephone (RT) Screen

Turn the power on, or press the 1/ RT/CH key to show the radiotelephone screen. This is where you set up the transceiver unit, and communicate by voice or telex.

UTC 00:00 EPFS 23:59

1-2

CH: 200 Tx: 2182.0 kHz Rx: 2182.00 kHz

SSB SIMP HIGH FAST NB SQ

SEN

MMSI xxxxxxxxx POS 35 00.0000N 135 00.0000E

Radiotelephone (RT) screen

10.0A

1. OPERATIONAL OVERVIEW

Indication Meaning CH Channel Tx

TX frequency (Tx: while transmitting)

Rx RX frequency

Blinks when there are messages not read yet.

DR/DS DR: Distress received, DS: Distress sent

Speaker on/off

SSB/TLX/AM Class of Emission SIMP/SDUP/DUP Communication mode (SIMP: simplex, SDUP: semi-duplex,

DUP: full-duplex HIGH/MID/LOW1/LOW2 Output power (LOW2: FS-5070 only, minimum output power) FAST/SLOW/OFF (AGC)

Auto gain control (FAST: high-speed, SLOW: low-speed, OFF: no

adjustment) NB Noise blanker SQ Squelch SEN Receiving sensitivity S S-meter, displays the strength of received signal. IA/IC/VC/RF Transceiver unit status (IA: antenna current, IC: collector current, VC:

collector voltage, RF: PA output) MMSI Own ship’s ID (nine digits) POS Own ship’s position EPFS/MAN Own ship’s position data source

EPFS: GPS navigator

MAN: manual (See section 6.6.)

1.4 DSC Standby Screen

The DSC standby screen may be displayed by pressing the 6/SCAN key. This screen scans and receives the distress and routine frequencies, and sends the acknowledgement for the received message automatically.

Acknowledge status (AUTO ACK or MANUAL ACK)

Shown with nine digits.

WATCH KEEPING

DISTRESS WR1

2187.5

16804.5 12577.0

ROUTINE TRX

2177.0

16903.0 12657.0

35°00.0000N UTC 00:00 135°00.0000E MAN 23:59

Position and time. "EPFS" shown when these are input automatically.

TRX: transceiver unit WR2: The optional antenna for the routine frequency

4207.5

4219.5

AUTO ACK

MMSI xxxxxxxxx

6312.0

8414.5

6331.0

8436.5

DSC standby screen

Maximum six distress and routine frequencies scanned in clockwise direction, and frequency currently being scanned is highlighted. One cycle is completed in less than two seconds.

1-3

1. OPERATIONAL OVERVIEW

1.5 Control Unit Dimmer, Contrast

You can adjust the dimmer and contrast of the control unit.

1. Press the 9/

key to show the dimmer/contrast adjustment window.

DIMMER (1~8)

CONTRAST (40~63)

EXIT:[CANCEL]

2. Rotate the ENTER knob to choose DIMMER or CONTRAST, whichever you want to adjust, and then push the ENTER knob.

DIMMER (1-8)

Dimmer adjustment window Contrast adjustment window

CONTRAST (40-63)

3. Rotate the ENTER knob to adjust and then push the ENTER knob.

4. To quit, push the CANCEL key.

1.6 Loudspeaker

The alarm beeps (other than distress communication) can be turned on or off.

1. Press the 7/

generated for routine messages. SPEAKER ON or SPEAKER OFF appears with each press.

2. Rotate the PWR/VOL knob to adjust volume of loudspeaker (cw: volume up, ccw:

volume down).

key to alternately disable or enable the loudspeaker and the alarm

1.7 Setting Scan Frequencies

The DSC screen scans multiple routine frequencies according to operator-set interval. For how to set frequency to scan, see section 6.13. Note that voice and telex communication are not available when scanning. (However, they are available when the system is equipped with the optional watch receiver.)

1. Press the 6/SCAN key to show the DSC screen. Scanning starts.

2. Press the 6/SCAN key again when the desired frequency is chosen to stop the cursor. You can scan only the frequency chosen by cursor.

3. Rotate the ENTER knob to move the cursor.

4. Press the 6/SCAN key to restart the scanning.

1-4

1. OPERATIONAL OVERVIEW

1.8 Setting for Auto Acknowledgement

Individual, position, polling and test calls can be acknowledged automatically or manually.

Press the 5/ACK/SQ key to switch the acknowledge mode between automatic and manual alternately. The message AUTO ACK or MANUAL ACK appears on the DSC standby screen with each press of the key.

Note: When own ship’s communication is high priority, set to MANUAL ACK.

The auto acknowledgement is not sent in the following cases:

• The category of a received message is DISTRESS, URGENCY or SAFETY.

• The communication mode is NBDP-FEC, NBDP-ARQ or DATA.

• Com Freq is NO INFO.

• ECC is NG (No Good).

• The handset is off hook.

1.9 System Characteristics

1.9.1 Equipment priority

Equipment priority order is as below.

1. Control unit sending distress alert

2. Control unit 1 – routine use

3. Control unit 2 – routine use

4. NBDP

1.9.2 Controls become inoperative

Controls become inoperative in the following conditions:

• When the other control unit goes OFF HOOK on RT mode in the two control units system.

• When the other control unit switches to the DSC mode in the two controls system.

• NBDP is scanning or communicating.

• Distress alert or distress relay is transmitted.

• Call other than distress is transmitted (transmission time about 8 sec.) If it becomes

necessary to unlock the keyboard before the message is transmitted, press the CANCEL key to cancel the call.

1.9.3 Controls become operative

Controls become operative in the following conditions:

• DISTRESS button is pressed.

• Control unit having higher priority is operated.

1-5

1. OPERATIONAL OVERVIEW

• The other control unit in two controls unit system goes ON HOOK.

• NBDP stops scanning or communicating.

1.9.4 Automatic setting of working frequency

The radiotelephone automatically sets working frequency in the following conditions:

• ABLE ACK is sent in response to individual call.

• Your ship receives ABLE ACK in response to own ship-initiated individual call.

• *Your ship receives ABLE ACK with COM. Frequency automatically changes in response to

own ship-initiated individual call.

• Your ship sends geographical area call.

• Your ship sends distress relay.

• Your ship sends distress alert.

• *Your ship receives group call.

• *Your ship receives geographic area call.

• *Your ship receives distress alert.

*: When receiving a call with different frequency from the setting, the following window appears.

Change COM Frequency Agree Disagree Count down xx sec. Pause

After 10 seconds passed or when "Agree" is chosen, the working frequency is changed with the message shown below.

Accept New Working Freq

CANCEL: CLOSE WINDOW

Choose "Pause".

Change COM Frequency Agree Disagree Count down has been paused.

Choose "Agree".

1.10 Intercom

The built-in intercom permits voice communications between two control units.

1. Off hook the handset at the radiotelephone screen.

2. Press the IntCom key to show INTERCOM on the display. The called party’s control unit

rings.

3. When the called party picks up their handset, start communications.

4. Hang up the handset to turn the intercom off. The indication INTERCOM disappears

from the screen.

1-6

2. SSB RADIOTELEPHONE

You can use the SSB communication in the RT (radiotelephone) mode. Press the RT/CH key to show the RT screen.

2.1 Choosing Class of Emission

There are three emission modes, SSB, TLX and AM.

•SSB: Single Sideband

•TLX: Telex (see chapter 7 to 10.)

•AM: AM (You cannot transmit in the AM mode.)

At the radiotelephone screen, choose class of emission as follows:

1. Rotate the ENTER knob to highlight the emission mode (default: SSB) and then push the ENTER knob. When rotating the ENTER knob clockwise, the cursor moves from “CH” to downward.

CH: 200 Tx: 2182.0 kHz Rx: 2182.00 kHz

Emission mode

2. Rotate the ENTER knob to choose mode desired and then push the ENTER knob. AGC is automatically selected according to emission mode.

• SSB : AGC FAST

•TLX: AGC OFF

•AM: AGC SLOW

However, you may change it as below.

4. Rotate the ENTER knob to choose AGC mode and then push the ENTER knob.

CH: 200

SSB SIMP HIGH FAST NB SQ

SSB

TLX

MMSI xxxxxxxxx

POS

35 00.0000N 135 00.0000E

10.0A

UTC 00:00 EPFS 23:59

AGC mode

Tx: 2182.0 kHz Rx: 2182.00 kHz

SSB SIMP HIGH FAST NB SQ

MMSI xxxxxxxxx

POS

35 00.0000N 135 00.0000E

10.0A

OFF

FAST

SLOW

FAST

UTC 00:00 EPFS 23:59

5. Rotate the ENTER knob to choose OFF, SLOW or FAST as appropriate and then push the ENTER knob.

2-1

2. SSB RADIOTELEPHONE

2.2 Choosing Channel, Frequency

Choose the channel or transmitting frequency to use for the SSB. This setting can be done both when the handset is on and off hook.

Note: To set the SSB radiotelephone to 2182 kHz/J3E, press the RT/CH key more than five

seconds.

Choosing channel

1. Rotate the ENTER knob to choose CH and then push the ENTER knob. You can show the channel window by pushing also 1/CH key.

CH: 200

Tx: 2182.0 kHz Rx: 2182.00 kHz

SSB SIMP HIGH FAST NB SQ

MMSI xxxxxxxxx

POS

35 00.0000N 135 00.0000E

200

10.0A

UTC 00:00 EPFS 23:59

2. Channel can be entered directly with the numeric keys, or by using the ENTER knob. See below for details.

Entering band and band channel with the numeric keys: Use the numeric keys to enter band and band channel and then push the ENTER knob.

Choosing band and band channel with the ENTER knob:

After showing the window, use the FILE/CURSOR key to place the cursor in the band or band channel position, whichever you want to change.

200

Cursor position for Cursor position for selection of band channel

200

selection of band

3. Rotate the ENTER knob to set band (or channel) desired.

2 4 6 8 12 16 18 22 25 01 02----- 029

ITU band User band

Setting Range ITU Band: 2/4/6/8/12/16/18/22/25 User Band: 001-029 (First zero is necessary) ITU Channel: XX01 - XX236 (rendering on band or mode) User Channel: XXX01 - XXX99

4. Push the ENTER knob. The Tx and Rx frequencies of the channel entered appear.

2-2

2. SSB RADIOTELEPHONE

Choosing frequency

1. Rotate the ENTER knob to choose Tx or Rx as appropriate and then push the ENTER knob.

CH: 200 Tx: 2182.0 kHz

2182.00

Rx: 2182.00 kHz

SSB SIMP HIGH FAST NB SQ

MMSI xxxxxxxxx 35 00.0000N 135 00.0000E

2. Enter frequency by one of the methods below.

Entering frequency with the numeric keys:

Use the numeric keys to enter frequency and then push the ENTER knob. For example, to enter 2161 kHz, key in 2, 1, 6, 1, 0. (Keying in 2-1-6-1 will set 216.1 kHz.) Be sure to include zero for 100 Hz place.

10.0A

UTC 00:00 EPFS 23:59

Choosing frequency with the ENTER knob (for RX only):

3. Use the FILE/CURSOR key to choose digit to change.

4. Rotate the ENTER knob to set digit.

5. Push the ENTER knob.

Note: When Tx and Rx frequencies are different, enter Tx and Rx in that order:

Tx: Tx/Rx frequencies Rx: Rx frequency only

2.3 Transmitting

After selecting class of emission and frequency, you can transmit by pressing the PTT switch. Tx is shown on the display.

2.3.1 Transmitting procedure

Maximum transmission power is achieved only when the antenna impedance and transmitter impedance match each other. Because the antenna impedance changes with frequency, antenna impedance matching with the transmitter impedance is done with the antenna coupler. The antenna coupler automatically tunes the transmitter to a wide range of different antenna lengths, from 7 to 18 (FS-1570/2570) or 10 to 18 (FS-5070) meters.

To initiate the automatic tuning, do the following:

1. Press the PTT switch on the handset or the LOG/TUNE key more than one second on the control unit. Tuning is automatically adjusted at first transmission after frequency is changed. “TUNING” appears when the LOG/TUNE key is pressed more than one second; “Tx” pops out when the PTT switch is pressed. Tuning will be completed within 2 to 5 seconds for a newly selected frequency, or less than 0.5 seconds for a once-tuned frequency. When the tuning process is successfully

2-3

2. SSB RADIOTELEPHONE

completed, TUNE: OK appears. If tuning fails, TUNE: NG appears.

2. Hold the handset close to your mouth, press the PTT switch and speak clearly.

Note: When tuning is initiated in the two control units system, the display of the idle control

unit shows “OCCUPIED(ANOTHER CONTROLLER).” In this case, only the DISTRESS button is operative on the idle control unit. Further, if a control unit is in use when the other control is tuned, the display of the activated control unit shows “OCCUPIED” plus the reason why cannot use: ANOTHER CONTROLLER or NBDP to inform you that tuning is not operated.

2.3.2 Reducing transmitter power

To minimize possible interference to other stations, reduce the transmission power. This should be done when using the transceiver in a harbor, near the shore or close to communication partner (other ship).

1. Rotate the ENTER knob to choose HIGH, MID, LOW (1) or LOW2 (shown on FS-5070) in the equipment states area and then push the ENTER knob.

CH: 200 Tx: 2182.0 kHz Rx: 2182.00 kHz

SSB SIMP HIGH FAST NB SQ

MMSI xxxxxxxxx

POS

35 00.0000N 135 00.0000E

(The above figure shows FS-5070.)

HIGH

MID

10.0A

LOW1 LOW2

UTC 00:00 EPFS 23:59

HIGH

MID

LOW1*

LOW2

FS-1570 FS-2570 FS-5070

150Wpep 250Wpep 500Wpep

100Wpep 125Wpep 350Wpep

68Wpep 90Wpep 200Wpep

110Wpep

*: For FS-1570/2570, "LOW"

(Power: ITU401CH)

2. Rotate the ENTER knob to choose a power as appropriate and then push the ENTER

knob.

Note: Power amplifier temperature is monitored, and when its temperature rises above a

certain temperature output power is automatically reduced. For FS-5070, when the over current is detected, output power is automatically reduced.

2.3.3 Condition of the transmitting unit

While transmitting, you may display RF (PA output), IA (antenna current), IC (collector current) or VC (collector voltage), at the lower left-hand side of the radiotelephone screen.

1. Rotate the ENTER knob to choose RF, IA, IC or VC (whichever is displayed) in the equipment states area, and push the ENTER knob.

CH: 200 Tx: 2182.0 kHz

Rx: 2182.00 kHz

SSB SIMP HIGH FAST NB SQ

MMSI xxxxxxxxx

POS

35 00.0000N 135 00.0000E

10.0A

UTC 00:00 EPFS 23:59

Equipment states area

2. Rotate the ENTER knob to choose option desired and then push the ENTER knob.

2-4

2. SSB RADIOTELEPHONE

Checking the transmitting power

During transmission, the IA bar deflects according to the current being fed to the antenna feeder from the antenna coupler. The unit of readout is amperes. The antenna current varies with the effective antenna impedance. The reading differs by the frequency and antenna length. The output power is proportional to the square of an antenna current.

CH: 200 Tx: 2182.0 kHz Rx: 2182.00 kHz

SSB SIMP HIGH FAST NB SQ

MMSI xxxxxxxxx

POS

35 00.0000N 135 00.0000E

2.1A

UTC 00:00 EPFS 23:59

Antenna Current

2.4 Receiving

Check if the emission mode and receiving frequency are set properly. If necessary, set them again referring to section 2.1 and 2.2.

2.4.1 RF gain (sensitivity) adjustment

In normal use the sensitivity should be set for maximum. If the audio on the received channel is unclear or interfered with other signals, adjust (usually reduce) sensitivity to improve clarity.

1. Rotate the ENTER knob to choose SEN in the equipment states area and then push the ENTER knob.

SEN

2. Rotate the ENTER to adjust and then push the ENTER knob.

2.4.2 S-meter

The S-meter shows relative signal strength coming into the receiver front end. Note that the S-meter does not function when the AGC is turned off.

CH: 200 Tx: 2182.0 kHz Rx: 2182.00 kHz

Equipment states area

2-5

SSB SIMP HIGH FAST NB SQ

MMSI xxxxxxxxx

POS

35 00.0000N 135 00.0000E

10.0A

UTC 00:00 EPFS 23:59

S-meter

2. SSB RADIOTELEPHONE

2.4.3 Receiving AM broadcasting stations

1. Press the RT key to show the radiotelephone screen.

2. Rotate the ENTER knob to choose emission mode and then push the ENTER knob.

CH: 200 Tx: 2182.0 kHz Rx: 2182.00 kHz

Emission mode

3. Rotate the ENTER knob to choose AM and then push the ENTER knob.

4. Rotate the ENTER knob to choose Rx and then push the ENTER knob.

CH: 200

SSB SIMP HIGH FAST NB SQ

SSB

TLX

MMSI xxxxxxxxx 35 00.0000N 135 00.0000E

10.0A

UTC 00:00 EPFS 23:59

AGC mode

Tx: 2182.0 kHz

2182.00

Rx: 2182.00 kHz

SSB SIMP HIGH FAST NB SQ

MMSI xxxxxxxxx

POS

35 00.0000N 135 00.0000E

10.0A

UTC 00:00 EPFS 23:59

5. Key in RX frequency with the numeric keys and then push the ENTER knob.

2.4.4 Squelch function

Squelch on/off

The squelch mutes the audio output in the absence of an incoming signal. Press the ACK/SQ key to turn on and off the squelch alternately. When radio noise is too jarring during stand-by condition, it may be muted by activating the squelch. “SQ” in the equipment states area is hatched when the squelch function is active.

Squelch frequency

To adjust the squelch frequency, see section 6.3.

2.4.5 Noise blanker

The noise blanker functions to remove pulse noise. To turn it on or off, see section 6.2.

2-6

+ 189 hidden pages

Furuno FS-5070 User Manual 2

Specifications and Main Features

Frequently Asked Questions

User Manual

IMPORTANT NOTICE

SAFETY INSTRUCTIONS

DISTRESS ALERT MESSAGE PROCEDURE

CANCELING DISTRESS ALERT

TABLE OF CONTENTS

FOREWORD

SYSTEM CONFIGURATIONS

1. OPERATIONAL OVERVIEW

1.1 Controls

1.2 Turning the Power On/Off

1.3 Radiotelephone (RT) Screen

1.4 DSC Standby Screen

1.5 Control Unit Dimmer, Contrast

1.6 Loudspeaker

1.7 Setting Scan Frequencies

1.8 Setting for Auto Acknowledgement

1.9 System Characteristics

1.10 Intercom

2. SSB RADIOTELEPHONE

2.1 Choosing Class of Emission

2.2 Choosing Channel, Frequency

2.3 Transmitting

2.4 Receiving
