Furuno FS-1503 User Manual 2

SAFETY INSTRUCTIONS

DANGER

Never touch the SSB antenna, antenna coupler or lead-in insulator when the SSB radiotelephone is transmitting.

High voltage which will cause death or serious injury is present at the locations mentioned above when the SSB radiotelephone is transmitting.

Antenna

Indoor

Antenna Wire (High Voltage)

Antenna Coupler

Wire

Lead-in Insulator (High Voltage)

WARNING

Do not place liquid-filled containers on the top of the equipment.

Fire or electrical shock can result if a liquid spills into the equipment.

Immediately turn off the power at the switchboard if the equipment is emitting smoke or fire.

Continued use of the equipment can cause fire or electrical shock. Contact a FURUNO agent for service.

Make sure no rain or water splash leaks into the equipment.

Fire or electrical shock can result if water leaks in the equipment.

Keep heater away from equipment.

Do not open the equipment.

Hazardous voltage which can cause electrical shock exists inside the equipment. Only qualified personnel should work inside the equipment.

Immediately turn off the power at the switchboard if water leaks into the equipment or something is dropped in the equipment.

Continued use of the equipment can cause fire or electrical shock. Contact a FURUNO agent for service.

Do not disassemble or modify the equipment.

Fire, electrical shock or serious injury can result.

A heater can melt the equipment’s power cord, which can cause fire or electrical shock.

Use the proper fuse.

Fuse rating is shown on the equipment. Use of a wrong fuse can result in equipment damage.

Do not operate the equipment with wet hands.

Electrical shock can result.

CAUTION

A warning label is attached to the equipment. Do not remove the label. If the label is missing or illegible, contact a FURUNO agent or dealer.

To avoid electrical shock, do not remove cover. No user-serviceable parts inside.

WARNING

Name: Warning Label (1) Type: 86-003-1011-0 Code No.: 100-236-230

iiiiiiiiiiiii

INTRODUCTION.............................................................................................................iii

1. OPERATION

1.1 System Configuration.................................................................................................1-1

1.2 Transceiver Unit Description .....................................................................................1-2

1.3 Turning the Power On/Off..........................................................................................1-4

1.4 Adjusting the Backlighting.........................................................................................1-4

1.5 Turning the Loudspeaker On/Off ...............................................................................1-4

1.6 Turning the Squelch On/Off .......................................................................................1-4

1.7 Selecting Class of Emission, Turning AGC On/Off...................................................1-4

1.8 Selecting Frequency ...................................................................................................1-5

1.9 Displaying Station Name .........................................................................................1-10

1.10 Transmitting ...........................................................................................................1-1 0

1.11 Distress Call on 2182 kHz......................................................................................1-11

1.12 Receiving................................................................................................................1-13

1.13 Frequency Scan ......................................................................................................1-15

1.14 Frequency Sweep ...................................................................................................1-17

1.15 MIF Commands .....................................................................................................1-18

2. OPERATION OF OPTIONAL EQUIPMENT

2.1 T elex Communication ................................................................................................2-1

2.2 Remote Station RB-500 .............................................................................................2-2

2.3 Intercom .....................................................................................................................2-2

3. CHANGING SYSTEM SETTINGS

3.1 System Setup..............................................................................................................3-1

3.2 Customizing by User..................................................................................................3-1

3.3 Writing User Channels ...............................................................................................3-3

4. MAINTENANCE

4.1 W eekly Checks...........................................................................................................4-1

4.2 Diagnostic Test ...........................................................................................................4-2

4.3 LCD/Keyboard Test & ROM Version No. Confirmation...........................................4-3

4.4 Maintenance ...............................................................................................................4-4

5. TROUBLESHOOTING

5.1 Troubleshooting List ..................................................................................................5-1

5.2 Error Indication ..........................................................................................................5-3

5.3 Replacing Fuses .........................................................................................................5-3

SPECIFICATIONS..................................................................................................... SP-1

APPENDIX (Frequency Tables) .........................................................................A-1

TELEX CHANNELS......................................................................................................A-8

INDEX......................................................................................................................... Index-1

INTRODUCTION

FURUNO Electric Company thanks you for selecting the FS-1503 MF/HF SSB Radiotelephone. We are confident you will discover why FURUNO has become synonymous with quality and reliability. To get maximum performance from your unit, please carefully read and follow the recommended procedures for operation and maintenance.

The FS-1503 is an all-purpose radiotelephone system especially designed for marine mobile communication in the frequency range 1.6 to 27.5 MHz. All ITU channels are preprogrammed.

In addition, TX/RX frequencies can be preprogrammed into an E 199 frequency pairs.

Features

• Station name entry available (channels 0-1 – 0-65)

• 2182 key provides for immediate selection of 2182 kHz (at FULL power automatically)

• Scan and Sweep receiving functions

• Where permitted user may program both Rx and Tx frequencies or Rx frequencies

• PROM stores all ITU SSB and TELEX frequencies

• Optional dummy load (in the Antenna Coupler) permits checking of transmitter

• Effective noise blanker cancels pulse noise

• Advanced voice and/or level-detecting type squelch circuit filters out noise and/or level

• Remote Station RB-500 available (requires optional REMOTE-B Board)

• System diagnostics program

• DSC and NBDP connections (requires optional REMOTE-A Board)

PROM having a capacity of

iii

1. OPERATION

1.1 System Configuration

The basic FS-1503 consists of a T ransceiver Unit, an Antenna Coupler , and an MIC. The figure below shows the FS-1503 system and optional equipment.

FS-1503 SYSTEM CONFIGURATION

Antenna Coupler AT-1503

Transceiver Unit FS-1503

MIC (Handset optionally available)

PC-220 PR-270

24 VDC

Distributor

DB-500

Distributor

DB-120

AGC STATION

MODE

TUNE

2182

CURS

CLARI

SQL

SCAN

H/L

START

INT

ALM ENT

TEST

External

MIC

VOLUME RF GAIN FREQ/CH

OFF

SSB TRANSCEIVER FS-1503

SIMP

0246810

AGC NB

H3E

Speaker

13.6 V

NBDP Terminal

DP-5/6

* Optional pcb (REMOTE A or

100/110/200/220 VAC

13.6 VDC

REMOTE B) required.

Figure 1-1 FS-1503 system configuration

DSC Terminal

DSC-5/6

DSC Terminal

DSC-5/6

NBDP Terminal

DP-5/6

Remote Station

RB-500

Option

1-1

1.2 Transceiver Unit Description

Loudspeaker Operation Display

MIC

MIC Handset Jack

VOLUME control w/Power ON/OFF

Rotary controls

SSB TRANSCEIVER FS-1503

SIMP

0246810

VOLUME RF GAIN

OFF

Figure 1-2 Transceiver unit

RF GAIN control

AGC NB

H3E

FREQ/CH

FREQ/CH control

Keyboard

AGC STATION

MODE

CURS

TUNE

2182

SQL

H/L

INT

CLARI

SCAN

ALM ENT

TEST

START

STOP

VOLUME Turns the power on and off and adjusts the loudspeaker volume. RF GAIN Adjusts the receiver sensitivity. FREQ/CH Changes frequency digit selected by the cursor and switches user/ITU chan-

nel and band.

Keys

[MODE/1] Selects a class of emission and turns AGC on/off. Press the [MODE/1] key

repeatedly until the wanted class of emission appears. To turn AGC on or off, press the [MODE/1] key while pressing and holding down the [ENT] key.

[CURS/2] Each pressing switches between band and channel when entering channels, or

shifts among last four places when entering frequency . Pressing together with the [ENT] key displays station name or Rx frequency on the second line.

[CLARI/3] Adjusts the receiver frequency for fine tuning when the frequency is set in

terms of Channel No. Not active in direct frequency entry. The adjustable range is ±150 Hz in 10 Hz steps (±5 kHz in 100 Hz steps on H3E).

[TX] Selects a Tx frequency.

/4] Turns the internal or external loudspeaker on/off. The speaker mark appears

[

on the display when the speaker is off.

[SQL/5] Turns the squelch function on/of f. “SQ” appears on the display when the squelch

function is on.

1-2

[SCAN/6] Turns the scan/sweep function on or off. “SCAN” or “SWEEP” appears on

the display when the scan or sweep function is on. [RX] Selects an Rx frequency. [TUNE/7] Tunes the antenna coupler . “TUNE” appears during tuning, and “OK” appears

after tuning is successfully completed. [H/L /8] Alternately selects high or low output power.

/9] Adjusts backlighting of the keyboard and the display.

[ [CH] Enables entry of channel (by ten key). [2182] Selects 2182 kHz on H3E (J3E may be selected depending on system setting). [INT/0] Calls “remote station” (if connected). Press this key , enter station no. and then

press [ENT] key. [ALM] Releases the two-tone alarm for 45 seconds. To transmit the alarm, press the

[ENT] key while holding down the [ALM] key . To silence it, press the [ENT/

STOP] key or the [ALM] key . Never press [ALM] + [ENT] except when own

ship is in distress. [ENT] Concludes data entry. [0]...[9] Enter numeric data.

Indications

The operation display provides the operational status by various marks and indications. Shown below are the location and meaning of all available indications. They do not appear all at once but when the related parts appear with respect to the mode selected.

Clarifier ON

Transmit

ITU channel selected

ITU

Duplex

Simplex

Tx output (RF level)

Tx output (antenna current)

CLAR

DUP

SIMP

0246810

012345

MEMO

LSB

TR: Tx, Rx freq. R: Rx, freq.

* Tx/Rx CH only or Tx/Rx freq. only available thru system setting.

System setting mode User channel writing mode

Remote control ON

* Rx channel (Tx CH at Tx)

LOW TUNE

ANT

AGC NB SWEEP SCAN

REM

J3E

Intercom ON

COM

AGC ON

* Rx freq. or station name (Tx freq. at Tx)

Low output power

DUMMY

H3E TLX FAX

Noise Blanker ON

Dummy antenna in coupler ON

Antenna tuning in progress

Antenna tuning completed

Cursor Loudspeaker OFF Squelch ON

Scan ON

Class of Emission

Frequency Sweep ON

Figure 1-3 Indications

1-3

1.3 Turning the Power On/Off

The power switch is combined with the [VOLUME] control. Turn the [VOLUME] control clockwise until you hear a click. Further clockwise rotation of the control raises the loudspeaker volume. To turn off the power , turn the control fully counterclockwise until you hear the click.

1.4 Adjusting the Backlighting

The [ /9] key adjusts the backlighting for the operation display and the keyboard. Each time the key is pressed, the backlighting changes in the sequence of high, medium, low and off.

1.5 Turning the Loudspeaker On/Off

When you are using a handset and therefore do not require the internal or external loudspeaker, you can turn it off by pressing the loudspeaker [ /4] key. The “loudspeaker off mark” ( ) appears.

1.6 Turning the Squelch On/Off

The squelch mutes the audio output in the absence of an incoming signal. Each time [SQL/5] is pressed, the squelch is turned on or off. When radio noise is too jarring during stand-by condition, it may be muted by activating the squelch. “SQ” appears when the squelch function is active.

Note: The squelch is disabled on the class of emission TLX or FAX; “SQ” blinks.

1.7 Selecting Class of Emission, Turning AGC On/Off

Selecting class of emission

The [MODE/1] key selects the class of emission. Each time the key is pressed, the class of emission changes in the sequence of LSB, J3E, H3E, TLX (J2B) and FAX (F3C).

Indication Symbol Class of Emission LSB* J3E Single Sideband radiotelephony(LSB) J3E J3E Single Sideband radiotelephony(USB) H3E H3E Equivalent to AM radiotelephony. Only at 2182 kHz for

transmitting, any frequency for receiving. TLX* J2B Radio Telex FAX* F3C Reception of weather facsimile broadcast

* Available with system setting by FURUNO authorized service agent.

1-4

T urning AGC on/off

AGC is automatically turned on when frequency is changed, and “AGC” appears when AGC is active. To turn AGC on or off manually, press the [MODE/1] key while pressing and holding down the [ENT] key.

1.8 Selecting Frequency

Frequency can be selected by:

• Direct key entry (Free selection within marine bands for ship stations where a qualified Radio Operator is available.)

• Channel number entry

• [FREQ/CH] control

A receiving frequency can be selected by one of the above methods, but there is a restriction in selecting a transmitting frequency . This depends on how the equipment is programmed according to the national radio regulation.

Frequencies are indicated by: Voice frequencies: Designated by the CARRIER frequency. Assigned frequencies are 1.4 kHz

higher than the carrier frequencies.

Telex, DSC: Designated by the CENTER frequencies.

qerFXT noitceleS

noitceleseerFON

UTIc slennah

resUc slennahybdetacidni,SEY

gnitteS

ehtnislennahcllA

ybdetacidniXIDNEPPA

.ycneuqerfdnaHC

ybteserP.emannoitats/HC

.tnegaONURUF

1-5

Direct frequency entry

Rx frequency may can be entered manually. (Tx frequency may also be entered where permitted.)

Rx frequency

To set for a receive frequency of 1636.4 kHz, for example; Press [RX], [1], [6], [3], [6], [4], [ENT] in this order . Entry of the decimal point is not required.

Tx frequency

To set for a transmit frequency of 2061.4 kHz, for example; Press [TX], [2], [0], [6], [1], [4], [ENT].

DUP

0246810

RX freq (Tx freq shown at Tx)

AGC NB

J3E

Figure 1-4 Sample frequency display

• The [CURS/2] key shifts the cursor among last 4 places (J3E) or two places to left of decimal and one place to right of decimal (H3E).

• To modify a value at a particular digit (Rx frequency only), use the [FREQ/CH] control; it changes the value above the cursor.

Paired Rx/Tx frequency

To set for 2161 kHz simplex channel, for instance, press as below; [TX]*, [RX]*, [2], [1], [6], [1], [0], [ENT]

Do not forget to enter the last zero in the above example. The last numeral repr esents the 1/10 decimal place. Simply hitting [TX], [RX], [2], [1], [6], [1], [ENT] will set 216.1 kHz.

* Order of pressing may be reversed, that is, you may press [RX] first.

1-6

User channels

You can recall user channels through the keyboard by channel numbers. Once a channel is selected with the keyboard, the channel can be changed with the [FREQ/CH] control.

For how to write user channels, see Chapter 3. 199 user channels ( 0-01 to 0-99 and 1-00 to 1-

99) can be programmed in addition to ITU channels.

To call the channel 1-20, for example: Tx only

Press [TX], [CH], [1], [2], [0], [ENT] RX only

Press [RX], [CH], [1], [2], [0], [ENT] TX and RX paired

Press [CH], [1], [2], [0], [ENT] Note: The standard sets provide readout of Rx CH No. and Rx frequency in kHz. When trans-

mitting, Tx CH and Tx freq. are displayed. Pressing the [ENT] key displays both Tx and Rx frequencies.

Rx band

SIMP 0246810

—

LOW

AGC NB SWEEP

Rx CH

Frequency

J3E

Figure 1-5 Sample user channel (Rx)

• The [CURS/2] key shifts the cursor to band or channel number.

• To change channel number use the [FREQ/CH] control; it changes the number above the cursor, a band or channel designator.

• The [ENT] key temporarily displays both Tx and Rx frequencies.

1-7

ITU telephony channels (SSB)

To recall ITU SSB channel 412, for example, select J3E with the [MODE/1] key. Press [CH], [4], [1], [2], [ENT], and a combination of Tx frequency of 4098 kHz and Rx

frequency of 4390 kHz is selected. To select only Rx or Tx frequency, hit [RX] or [TX] first.

Rx frequency

ITU

DUP

0246810

Rx band

Rx CH No.

AGC NB

J3E

When receiving

Tx frequency

ITU

DUP

0246810

Tx Band

AGC NB

Tx CH No.

J3E

When transmitting

Figure 1-6 Sample displays of ITU telephony channel

• The [CURS/2] key shifts the cursor to band or channel number.

• To change channel number use the [FREQ/CH] control; it changes the number above the

cursor, a band or channel designator.

• The [ENT] key temporarily displays both Tx and Rx frequencies.

1-8

ITU TELEX channels

T o select the ITU TELEX channel 4012, for example, first select TLX with the [MODE/1] key . This radiotelephone is furnished with J2B class of emission. The J2B is compatible with F1B which may be used on other parties. You do not have to worry about F1B or J2B; you can just select TELEX mode for narrow-band direct-printing.

Press [CH], [4], [0], [1], [2], [ENT], and a combination of TX frequency of 4178.0 kHz and RX frequency of 4215.5 kHz is selected with the display as below. To select only RX or TX frequency, hit [RX] or [TX] to begin.

Rx freq ITU Tx CH No.

ITU

DUP

Rx band

ITU Rx CH No.

0246810

AGC

Tx freq

ITU

DUP

0246810

TLX

When receiving

Identify frequencies by referring to the APPENDIX. Entering 412 reads 4012 as above. Tx and Rx frequencies can be read temporarily.

Tx Band

AGC

TLX

When transmitting

Figure 1-7 Sample display of ITU telex channel

• The [CURS/2] key shifts the cursor to band or channel number.

• To change channel number use the [FREQ/CH] control; it changes the number above the

cursor, a band or channel designator.

• The [ENT] key temporarily displays both Tx and Rx frequencies.

• Y ou can recall an ITU channel by entering 3 or 4 digits. T o recall ITU telex channel 4012 by

three digits, for example, select “TLX” then enter 412 (instead of 4012).

• Tx frequency/Rx frequency or Tx CH/Rx CH indication can be selected through the system

settings. Ask your dealer.

1-9

1.9 Displaying Station Name

User channels 0-01 to 0-65 can be registered with a name, and it or the Rx frequency can be displayed on the second line of the display. This function is available when a system setting is set to display both channel and frequency. See page 3-3 for how to register station name.

1. Press [ENT] and [CURS/2] keys together. Each time those keys are pressed together, Rx

frequency or station name is displayed on the second line of the display.

2. When station name is displayed, you may press the [ENT] key to display Tx and Rx fre-

quency temporarily.

RX freq

Station

CH No. (Example)

DUP

0246810

Press ENT + CURS

AGC

TLX

DUP

6810

AGC

TLX

Note: If no station name is registered,

Rx frequency is soon displayed.

Figure 1-8 How to display Rx frequency and station name alternately

1.10 Transmitting

After selecting class of emission and frequency, you can transmit by pressing the PTT (pressto-talk) switch on the microphone (handset). (“T” appears when the PTT switch is pressed. Output power can be evaluated on the operation display . Do not transmit any signal other than

emergency during the silence period, 00 to 03 min, and 30 to 33 min of every hour.

Tuning the antenna

Maximum transmission power is achieved only when the antenna impedance and transmitter impedance match each other . Because the antenna impedance changes with frequency a means must be provided to match (tune) the antenna impedance with the transmitter impedance. This is done with the antenna coupler. The antenna coupler automatically tunes the transmitter to a wide range of different antenna length (6 – 15 m). To initiate the automatic tuning, do the following:

1. Press the PTT switch on the microphone (handset), or the [TUNE/7] key.

2. “TUNE” appears on the display.

3. Tuning will be completed within 2 to 15 seconds for a newly selected frequency, or less than

0.5 seconds for a once tuned frequency. (A built-in memory remembers coil and capacitor settings.)

4. When the tuning process is successfully completed “OK” appears.

1-10

Using the microphone

Hold the microphone close to your mouth, press the PTT switch and speak clearly.

Monitoring transceiver output power

The meter shows TX filter output level.

0246810

J3E

Figure 1-9 Meter

Reducing transmitter power

T o conserve energy and to minimize possible interference to other stations, reduce the transmission power . This should be done when using the transceiver in a harbor , near the shore or close to communication partner (other ship). Each pressing of the [H/L /8] key selects high or low output power. “LOW” appears on the display when low output power is selected. The output power on 2182 kHz (distress and calling) is the rated maximum regardless of the position of the [H/L /8] key.

1.11 Distress Call on 2182 kHz

The frequency 2182 kHz is an International radiotelephony distress, urgency and safety frequency for ship stations, public and private coast stations, and survival craft stations. It is also used for call and reply by ship stations on a primary basis and by public coast stations on a secondary basis.

Distress or emergency call is generally initiated by a radiotelephone alarm signal on 2182 kHz. Watch keeping receivers on other parties will hear your call.

1. Press the [2182] key . 2182 kHz and the class of emission H3E is automatically selected (J3E

may be selected depending on system setting).

When the [2182] key is pressed, the following parameters are set automatically:

AGC: ON Output power: Maximum Loudspeaker: ON Squelch: OFF

1-11

2. While pressing and holding down the [ALM] key, press

the [ENT] key. The alarm signal, modulated at 1300 Hz and 2200 Hz tones alternately, is emitted at full power for 45 sec.

AGC STATION

MODE

CURS

CLARI

The alarm can be monitored from the loudspeaker. The

SQL

SCAN

alarm may be canceled at any time by pressing the [ENT] key for immediate speech transmission.

3. Distress calls and Distress message

(1) Speak slowly and distinctly, “MAYDAY, MAY-

DA Y, MA YDA Y, pronounced as the French expression “m’aider”.

TUNE

2182

H/L

INT

START

ALM ENT

TEST

(2) This is; (3) The name of your vessel and call sign three times.

Then, continue with the distress message, which con-

PRESS BOTH to emit 2-two tone alarm signal.

sists of:

(1) The distress signal MAYDAY;

Figure 1-10 Keyboard

(2) The name of the mobile station in distress; (3) Particulars of its position (in latitude and longitude) (4) The nature of the distress; (5) The kind of assistance desired; (6) Any other information which might facilitate rescue, for length, color, and type of

vessels, number of persons on board.

STOP

4. Indicate the end of message by saying “Over.”

5. When you receive no answer to a distress message, repeat at intervals over again the radio-

telephone alarm signal, the distress call and the distress message.

Distress frequencies

All distress frequencies including 2182 kHz are shown below:

Telephony SSB (kHz, Carrier) DSC (kHz, Center) Telex (kHz, Center)

2 182 2 187.5 2 174.5 4 125 <ITU 421> 4 207.5 4 177.5 6 215 <ITU 606> 6 312 6 268

8 291 <ITU 833> 8 414.5 8 376.5 12 290 <ITU 1221> 12 577 12 520 16 420 <ITU 1621> 16 804.5 16 695

For other Telex frequencies, refer to APPENDIX.

1-12

1.12 Receiving

You can select a receiving frequency by one of the following methods:

- Direct frequency entry, or

- Channel number entry

Adjusting RF gain

In normal use the [RF GAIN] control should be set for maximum. If the audio on the received channel is unclear or interfered with other signals, adjust (usually reduce) the control to improve clarity.

Clarifier adjustment

If reception is unclear, try to clarify the signal as follows. For manual entry of frequency, simply turn the [FREQ/CH] control for fine tuning.

1. Press the [CLARI/3] key. (If a frequency is selected by CH No., the cursor which was located at the channel number, moves under the 10 Hz place and “CLAR” appears on the display.)

2. Turn the [FREQ/CH] control to fine tune the receiver on the wanted frequency.

3. To terminate this operation, press the [CLARI/3] key again. The cursor returns to the channel number.

S-meter

During reception, the meter works as a Sensitivity Meter indicating the relative signal strength coming into the receiver front end. While in transmission, it indicates output level at the transceiver .

0246810

Figure 1-11 S-meter

Note: S-meter will not work with AGC off.

Monitoring traffic on intended transmit frequency

When a semi-duplex (two-frequency simplex) channel is selected, it is recommended to monitor it if there is no existing traffic on the frequency you are going to use. To do this, press the [RX] key followed by the [ENT] key. The transceiver unit monitors traffic on the selected frequency for three sec. If you want to monitor continuously, press the [TX] key followed by the [ENT] key.

1-13

Receiving AM broadcasting stations

1. Press the [MODE/1] key repeatedly to select H3E.

2. To tune in a 15,260 kHz shortwave station, for instance, press as below:

[RX], [1], [5], [2], [6], [0], [0], [ENT]. Be sure to enter the last zero.

Squelch control

Squelch is used to mute the receiver audio output when the receiver input is less than a preset value or dominant noise is higher than a preset (1000 Hz) frequency. To switch the squelch function ON, press the [SQL/5] key. Make sure the label “SQ” appears on the display. To pick up a weak signal at high audio frequencies, you should remove the squelch function notwithstanding a possible increase of background noise. To do this, press the [SQL/5] key again. Make sure the label “SQ” goes off.

Noise blanker (NB)

The noise blanker clips inputs of noise resulting from an engine ignition or motor brush sparks. It can be enabled or disabled through the system settings.

1-14

1.13 Frequency Scan

Channel scan

Scan is the function where the receiver watches 10/group user or ITU channels in succession at predetermined intervals. The scan-stop signal level and scan-stop time can be changed on system codes 9951 and 9952, respectively . AGC is automatically turned on when scanning is activated.

1. Recall user or ITU channel.

User channels

User channels are divided into 20 groups in the scan mode as below.

puorGnacS

190-0ot10-0 291-0ot01-0 392-0ot02-0 493-0ot03-0 594-0ot04-0 695-0ot05-0 796-0ot06-0 897-0ot07-0 998-0ot08-0

0199-0ot09-0 1190-1ot00-1 2191-1ot01-1 3192-1ot02-1 4193-1ot03-1 5194-1ot04-1 6195-1ot05-1 7196-1ot06-1

resU.oNlennahC

8197-1ot07-1 9198-1ot08-1 0299-1ot09-1

Figure 1-12 Scan groups

1-15

ITU channels

T o select the scan group (band or channel, including user channels), shift the cursor to either the position of the band or channel number by pressing the [CURS/2] key. (Band scan is useful to watch frequencies on the same channel in different bands.)

2. Press the [SCAN/6] key, and “SCAN” appears. The receiver starts scanning, stopping at a channel where the signal is stronger than the scan-stop level. The receiver will restart scanning when the traffic goes out of that channel or designated time elapses, depending on system setting 9952.

For example, the scan group is “channel” and scan starts at ITU 1203, as shown in Figure 1-

12.

DUP

ITU

0246810

AGC NB SWEEP SCAN

J3E

Figure 1-12 Sample “scan” screen

3. To stop scanning, press the [SCAN/6] key . “SCAN” disappears from the operation display.

1-16

1.14 Frequency Sweep

Sweep is the function where the receiver searches for a signal within a selected frequency coverage. AGC is automatically turned on in frequency sweep.

The defaults of respective parameters are as follows: Sweep stop signal level: 3

Sweep stop time: 2 sec Sweep width: 100 kHz Step frequency: 1 kHz

These can be adjusted on system codes 9951 through 9954. Note: Sweep width is the frequency width to sweep on both sides of the selected frequency.

Sweep step is the frequency interval at which the receiver sweeps the sweep width. Procedure

1. Select the sweep center by key operation.

2. Press the [SCAN/6] key . “SWEEP” appears and the receiver starts sweeping. T o stop sweeping, press the [SCAN/6] key.

1-17

1.15 MIF Commands

The FS-1503 can be remotely controlled by the FURUNO external device, for example, NBDP Terminal, DSC Terminal, Remote Station, with MIF commands. The table below shows the applicable MIF commands.

Table 1-1 MIF commands applicable to the FS-1503

dnammoCnoitarepO

SRD .zHk2812s'3051revoytiroirpsahdnammocsihT.draobyekskcoL

RRD.draobyekskcolnU SZF.ytiroirpsahgnitteszHk2812s'3051-SF.draobyekskcoL RZF.draobyekskcolnU

xME ,E3J:1,BSL:0(noissimefossalcgnitonedtigidelgniS=x.noissimefossalC

.)XAF:6,XLT:5,E3H:2

xxxxxxxTF.zH01otzHM01morfycneuqerftigid-7=x.ycneuqerfxT

xxxxxxxRF.zH01otzHM01morfycneuqerftigid-7=x.ycneuqerfxR

xxxxTS .lennahcresusaycneuqerfxT/xRdnanoissimefossalctessretsigeR

.lennahcresutigid-4=x

xxxxHC.lennahcdnadnabtigid-4=x.lennahcresusteS

xxxxCR.evobasaemaS

xxxxxIHC dnabtigid-2fodesopmocrebmunlennahcdnadnabtigid-5=xlennahcUTIsteS

.lennahctigid-3dna

xxxxxICR.evobasaemaS SGA.CGAsetavitcA RGA.CGAsetavitcaeD

xxFR.NIMNIAGFR:00,.XAMNIAGFR:FF=x.NIAGFRsteS SQS.hcleuqssetavitcA RQS.hcleuqssetavitcaeD SCS.gninnacsstratS RCS.gninnacsspotS xOPHGIH:3,WOL:2,1,0=x.rewoptuptuosteS

UT.rorregninut:?,lufsseccusgninut:*.relpuocannetnasenuT

SxCI.rebmungnillaC=x.mocretninosllaC RxCI.rebmungnillaC=x.mocretninollacspotS

DIAC.denrutersi3051SFDI#.emantnempiuqesmrifnoC

MEAC.denrutersiME#.noissimefossalcsmrifnoC TFAC.denrutersixxxxxxxTF#.ycneuqerfxTsmrifnoC RFAC.denrutersixxxxxxxRF#.ycneuqerfxRsmrifnoC

HCAC.denrutersixxxxxIHC#,xxxxHC#.lennahcsmrifnoC CRAC.denrutersixxxxxICR#,xxxxCR#.lennahcsmrifnoC GAACFFO:RGA#,NO:SGA#.etatsCGAsmrifnoC

FRAC.denrutersi)FF-00=xx(xxFR#.etatsNIAGFRsmrifnoC LSAC.denrutersi)FF-00=xx(xxLS#.levellangissmrifnoC QSACFFO:RQS#,NO:SQS#.etatshcleuqssmrifnoC OPAC.denrutersixOP#.rewoptuptuoxTsmrifnoC

1-18

2. OPERATION OF OPTIONAL EQUIPMENT

2.1 Telex Communication

T elex communication is performed with a Narrow-band direct-printing (NBDP) Terminal connected with an SSB transceiver. The recommended terminal for the FS-1503 is the FURUNO DP-5/DP-6. Other makes can also be connected with the FS-1503, provided they comply with the interfacing requirements. Telex operation requires the REMOTE-A Board (option). Note that an Rx narrow filter (option) is also available.

FURUNO NBDP Terminal DP-5/DP-6

No special operation is required; class of emission and frequencies are automatically set on the DP-5/DP-6.

Other makes of NBDP Terminal:

1. Select “TLX” with the [MODE/1] key.

2. Select a desired frequency.

3. Tune the antenna coupler by pressing the [TUNE/7] key. Distress frequencies for telephony and telegraphy are as below. For other traffic frequen-

cies, refer to APPENDIX.

BSSynohpeleT

)reirraC,zHk(

28125.78125.4712

52145.70245.7714

512621360.86260.

19285.41485.6738 09221

024615.40861

CSD

)retneC,zHk(

775210.025210.

xeleT

596610.

)retneC,zHk(

2-1

2.2 Remote Station RB-500 (requires optional Remote-B Board)

Priority

The Remote Station RB-500 usually has higher priority than the FS-1503. This means that operation of the FS-1503 is disabled when the handset of the RB-500 is picked up. The indication “REM” appears on the FS-1503 display when the remote station is in operation and the PTT switch on the microphone of the FS-1503 is inoperative.

Communication on 2182 kHz

When 2182 kHz is selected on the FS-1503, the FS-1503 takes priority.

2.3 Intercom

The intercom provides communications between the FS-1503 and the RB-500 Remote Station (option). They must be wire-connected. When intercom mode is in use, there is no radio transmission.

Calling RB-500

1. Press the [INT/0] key. “COM” appears on the FS-1503 display panel.

2. Press [1]*, [ENT] keys. Calling beeps sound at the FS-1503. The buzzer stops when the handset of the RB-500 is picked up. * Designated number of the RB-500 if more than one is installed.

3. Press the PTT switch to talk. Release the switch to listen.

Call from RB-500

When the FS-1503 is called from the RB-500, the FS-1503 releases a buzzer . Press the [INT/0] key to silence the buzzer . Press the PTT switch to talk. Release the switch to listen. Note that the loudspeaker on the FS-1503 is automatically turned on when a call from the RB-500 is received, regardless of setting.

Terminating the intercom

Press the [INT/0] key to terminate the intercom function. “COM” disappears.

2-2

3. CHANGING SYSTEM SETTINGS

3.1 System Setup

1. While pressing and holding down the [CH] key, turn on the power. Release the [CH] key when “MEMO” appears on the display.

System code

Setting value

MEMO

Figure 3-1 System setting selection screen

2. Turn the [FREQ/CH] control to select a desired code number.

3. Press the [CH] key, enter desired setting by a numeric key, then press the [ENT] key.

4. To change setting for another code, repeat steps 2 and 3.

5. Reset the power.

3.2 Customizing by User

The operator can customize several system settings. The table below shows the system codes and their function, setting range and factory setting.

Note: FURUNO Electric Company will assume no responsibility for the inconvenience or disturbance to communications due to inadequate or unlawful presetting of this equipment.

Code Function, Setting 9942 Key beep ON/OFF

A beep sounds when a keying sequence is correctly executed. You may turn the beep on or off. Factory setting: ON

9943 Noise blanker ON/OFF

The noise blanker cancels unwanted noise. Factory setting: ON

3-1

9951 Scan/sweep-stop signal level

When the receiver detects a signal whose level is stronger than the preset level it stops scanning and receives the signal. The setting on system code 9955 is available only when “0” (SQ working condition) is selected here.

Setting range: 0 (Squelch working condition is effective as set on code

9955), 1-10 (S-meter level); Factory setting: 3

9952 Scan/sweep-stop time

When a signal is detected, the receiver stops scanning/sweeping and dwells on this channel frequency. When “0” (RX) is selected, the receiver keeps receiving until the traffic goes out of this channel frequency. Define the dwell time between 1 and 99 sec.

Setting range: 0 (RX), 1-99 sec; Factory setting: 2 9953 Sweep width setting range: 0.01-30000.00 kHz; Factory setting: 100.0 9954 Sweep step frequency

Setting range: 0.01-30000.00 kHz; Factory setting: 1.00 9955 Squelch activation

“Squelch activation” is the method by which the squelch is activated.

Setting range: 0, 1, 2, 3; Factory setting: 3

0: Voice

The squelch is opened by signal frequency less than 1000 Hz (factory set-

ting). This frequency can be changed between 500 – 2000 Hz on system

code 9958. The loudspeaker reproduces a sound when the signal is lower

than the preset frequency.

Squelch OPEN:

Audio signal is detected and a sound is reproduced through the loudspeaker.

Squelch CLOSED:

No input signal but only noise is coming into the receiver. The receiver is

muted.

1: Level

The squelch is activated depending on “signal strength”. The factory setting

is “5”. You can change the level between 0 - 10 on system code 9956.

2: And

The squelch opens when both “voice” and “signal strength” meet the set-

ting.

3: Or

The squelch opens by either “voice” or “signal strength”, whichever meets

the setting. 9956 Squelch level. Setting range: 0-10; Factory setting: 5

3-2

9957 Squelch delay - a delay until the squelch mutes (closes) the receiver after

the signal has gone.

(Ex) 9957: 1000 ms

Squelch closes 1000 ms after the signal has gone.

Setting range: 500-4000 ms; Factory setting: 1000 ms 9958 Squelch activating frequency

Setting range: 500-2000 Hz; Factory setting: 1000 Hz

3.3 Writing User Channels

The user channels may write user Tx channels. (Rx channels may also be written where permitted.)

1. Turn on the power while pressing the [CH] key. Release the key when MEMO appears.

2. Rotate the [FREQ/CH] control clockwise to display desired channel no. “R” appears (Rx

frequency writing mode).

4. Press the [MODE/1] key to select class of emission.

5. Press the [CH] key. Key in Rx frequency with the numeric keys (0-9) and press the [ENT]

key. If you are only writing Rx frequency go to step 8.

6. Rotate the [FREQ/CH] control clockwise. “T” appears (Tx frequency writing mode).

7. Enter Tx frequency like you entered Rx frequency.

8. Rotate the [FREQ/CH] control clockwise. If no station name have been written you will see

seven dashes. If station name cannot be entered for a particular station, the next channel number appears.

9. Press the [CH] key to enter station name or write over existing name. The cursor appears. A

station name may consist of seven characters, hyphens, alphabet, numerics and spaces are available.

10.Operate the [FREQ/CH] control to display character desired and press the [ENT] key. To

enter a space or shift the cursor press the [ENT] key . To erase station name, press [CH], [0] and [ENT]. When seven characters are entered, the cursor disappears.

11. Turn off the power to register channels.

3-3

4. MAINTENANCE

WARNING

Do not open the equipment.

Improper handling can result in electrical shock. Only qualified personnel should work inside the equipment.

Do not disassemble or modify the equipment.

Fire, electrical shock or serious injury can result.

4.1 Weekly Checks

Check the radiotelephone at appropriate intervals as required by Administration.

Aural testing

1. Press the [ALM] key to generate the alarm. Confirm that the two-tone alarm is released for

more than 30 seconds. You will hear the audio from the loudspeaker. This process helps to verify that the radiotelephone alarm generator is in the working condition without transmitting an actual radio signal.

2. To terminate test, press the [ALM] key again or [ENT] (STOP) key.

Testing the transmitter with a dummy antenna

This requires the optional dummy load (in the antenna coupler).

1. While pressing and holding down the [ALM] key, press the [INT/0] key. The dummy an-

tenna in the antenna coupler is connected to the FS-1503 instead of the antenna. “DUMMY” appears and the test signal at test frequency (for example, 2191 kHz), modulated by two tones (1300 Hz and 2200 Hz), is generated across the dummy load for 45 seconds.

2. To stop the emission, press the [ALM] key . The dummy load is disconnected and the trans-

ceiver restores the previous frequency setting.

4-1

4.2 Diagnostic Test

This test checks the transceiver for proper operation. It should be conducted regularly to ensure proper operation. If a DSC or NBDP terminal is connected, the test should be conducted together with them. Before starting the test, set the RF GAIN control to maximum (fully clockwise).

1. While pressing and holding down the [TX] key, turn on the power. All LCD segments ap-

pear.

2. Release the [TX] key. The FS-1503 starts diagnostics and the following indications appear:

Receiver section tested successfully.

Transmitter Exciter stage is tested successfully .

Transmitter Power Amplifier stage and Antenna Coupler are tested successfully.Test available with dummy load and by setting system setting 9917 to 1.

Figure 4-1 Sequence of diagnostic test

If a fault is detected, “no Good” appears instead of “Good” and the associated indication blinks after completion of this test.

3. Turn off the transceiver on completion of tests. Turn it on again for normal operation.

4-2

4.3 LCD/Keyboard Test & ROM Version No. Confirmation

1. While pressing and holding down the [ENT] key, turn on the power. All LCD segments

appear.

2. Release the [ENT] key.

3. Press keys one by one. Check if the indication on the operation display is correct as shown

below:

Table 4-1 Key and corresponding indication

Key

Indication

Key

Indication

Key

Indication

Key

Indication

MODE/1 CURS/2 CLARI/3 TX

/4 SQL/5 SCAN/6 RX

TUNE/7 H/L /8 /9 CH

2182 INT/0 ALM ENT

Example: The [CURS/2] key is pressed. The following appears. In a few seconds, 7 characters x 2 lines readout changes to all

PRIVUSA WXITU

DUP SIMP 0246810

012345

CLAR

SRF ANT

ATT PRE AGC NB SWEEP SCAN

MEMO REM COM DW DUMMY TONE

LOW TUNE

Program No. (Last two digits are version no.)

LSB J3E R3E CW H3E TLX FAX

Figure 4-2 LCD segments

3. Turn off the transceiver on completion of tests. Turn it on again for normal operation.

4-3

4.4 Maintenance

This radiotelephone equipment is designed and manufactured to provide years of intended performance. For this, a regular maintenance program should be established and should at least include the items listed in the table below:

Table 4-2 Maintenance

Item Check Point Remedy/Remarks

Whip antenna Check for physical damage, corrosion

and water leakage.

Wire antenna Check that antenna is properly spanned

and separated sufficiently apart from metallic structures.

Insulators for antenna installation

Antenna coupler

Check for salt water accumulation on insulators.

Check that connection at lead-in insulator is tight and rust-free.

Check contact at * Antenna terminal * Ground connection * Coaxial cable * Control cable(terminal board)

Check that coupler lid and cable glands are firmly secured.

Replace damaged parts.

If necessary, re-span the antenna.

Replace damaged insulators. Remove salt water deposits. Clean with fresh water, then dry. Remove rust, then tighten bolts and lock nuts. Cover metallic surface with sealing compound.

Tighten loosened connections.

Fasten lid firmly and evenly to prevent water leakage.

Check for physical damage, corrosion and salt water deposits.

Transceiver Check contact at

* Antenna cable * Ground connection * Power cable * Control cable

Confirm that there are no objects on the top of the cabinet.

Power supply Check that supply voltage at transmission

is within the rated range. (10.8-15.6 VDC at the power connector)

(Continued on next page)

Replace if damaged.

Tighten loosened connections; remove foreign material from connectors.

Remove objects to prevent overheating.

If not within the range, call for service. Low voltage may cause erratic operation.

4-4

Table 4-2 Maintenance (con’t)

Item Check Point Remedy/Remarks

Power cable Check for loosened or corroded connection

at power terminals.

Battery Check that the battery is fully charged. If discharged, charge. Feeder (coax

cable, control cable)

PCB connection

Microphone Check that jumper cables between boards

Check for physical damage. Replace if damaged.

Check that jumper cables between boards are firmly connected.

are firmly connected.

Clean and tighten.

Reconnect loosened connections of jumper cables.

Fasten if loosened.

4-5

5. TROUBLESHOOTING

WARNING

Do not open the equipment.

Improper handling can result in electrical shock. Only qualified personnel should work inside the equipment.

Do not disassemble or modify the equipment.

Fire, electrical shock or serious injury can result.

5.1 Troubleshooting List

The troubleshooting list below gives common symptoms of equipment malfunction and means to restore normal operation. If you cannot restore normal operation, please do not check inside any unit. Any repair is best left to a qualified radiotelephone technician. Improper handling or adjustment may cause more serious damage.

Table 5-1 Troubleshooting list

elbuorTesuaCelbaborPydemeR

denrutebtonnacrewoP

.no

.thgilspmalontub

dnuosontubnosirewoP

.rekaepsduolmorf

.ffo

.slanimret

sraeppatuodaerycneuqerF

.nosihcleuqS

ebyamdraobhctiwssniamehT

.tupniegatlovrevoCD

.V51nahtsseleb

evahyamyrettabehT

tatcatnocroopro,degrahcsid

.ffoebyamyek]9/[ehT.yek]9/[ehtetarepO

.ffosiyek]4/[ehT

.wolootebyamemuloV

.hctiwssniamehtnonruT

dluohstI.egatlovylppuskcehC

nethgitdnayrettabegrahceR

.snoitcennoclanimret

.yek]4/[ehtsserP

.lortnoc]EMULOV[ehttsujdA

"QS"fiyek]5/LQS[ehtsserP

.yalpsidehtnosraeppa

(Continued on next page)

.niaGFRdecudeR

.esiwkcolc

5-1

lortnoc]NIAGFR[ehtnruT

Table 5-1 Troubleshooting list (con’t)

elbuorTesuaCelbaborPydemeR

noitalucitrarooPyamnoissimefossalcgnorW

,elpmaxeroF(.esunieb

).zHk2812

.denutedrevieceR

decudersirewoptuptuO

noitacidni"WOL"(wolot

)sknilb

.detpeccatonsitupniyeKfolortnocrednusi3051-SF

.tnempiuqelanretxe

t’nacrelpuocannetnA

.annetnaenut

.htgnel

.dnuorgotdetrohsro

elbanutfotuosiannetnA

.edomE3Hnilangisgniviecer

noylnodesuebdluohsE3H

decuderyllacitamotuasirewoP

gnitaehrevotsniagatcetorpot

.noissimsnartsuounitnocoteud

detcennocsidebyamannetnA

.sretem51

.ylreporpgnikrowsi

nehwsraeppa"MER"

lanretxeybdellortnoc

.noitarepolanretxefo

emasnoissimefossalctceleS

.langisgnimocnifotahtsa

lennahcUTIromotsuCnI

]3/IRALC[ehtsserp,edom

ycneuqerfenutenifnehtyek

.lortnocHC/QERFehtyb

otsnrutertinuehtlitnutiaW

naffikcehC.noitidnoclamron

noitarepodnepsuS.tnempiuqe

.noitcennocannetnakcehC

ot6sihtgneldednemmoceR

.detcennocsid

anienuttonnaC

.noitatstsacdaorb

.noitats

EDOMfognittesgnorW

riaffosinoitatsehT.

nahtsselsiycneuqerF

.zHM83ot6.1ottes

.relpuocehtfognidnuorgrooP

rodenesoolelbacnoitcennoC

tigidehttalaremuntsalgnissiM

ehtnienutotgniyrtnehw1fo

siLIFTNArevewoh,zHM6.1

.elbackcehC

.E3HtceleS

.dnuorgrelpuockcehC

rofzHk0469nienutoT

,]6[,]9[,]XR[sserp,ecnatsni

tonoD.]TNE[,]0[,]0[,]4[

esiwrehto;]0[tsalehtssim

.zHk0.469teslliwuoy

.ycneuqerfrehtonatceleS

03ot1.0otLIFTNAteS

.)LIF/APniteS(zHM

5-2

5.2 Errow Indication

When the FS-1503 detects a fault in the synthesizer unit (frequency unlocked),the frequency or channel number blinks.

5.3 Replacing Fuses

To protect the unit from overcurrent and equipment fault,two 30 A are provided in snap-in holders on the power cable. If a fuse blows,find out the cause before replacing it. If it blows again after replacement,request service.

WARNING

Use the proper fuse.

Fuse rating is shown on the equipment. Use of a wrong fuse can cause equipment damage and void the warranty.

5-3

SPECIFICATIONS

GENERAL

Communication System Simplex, semi-duplex Frequency Range 1.6 to 27.5 MHz (transmit),

0.1 to 29.9 MHz (receive) Frequency Resolution Transmit: 100 Hz Receive: 10 Hz Class of Emission J3E SSB, suppressed carrier, signal channel containing ana-

logue information

H3E SSB, full carrier, signal channel containing analogue infor

mation, telephony; when 2182 kHz is first selected, H3E is set.

J2B for DSC, NBDP; SSB, suppressed carrier, signal channel

containing quantized or digital information with the use of a modulating sub-carrier, telegraphy for automatic reception

F3C weather facsimile, reception only

Frequency Error ±10 Hz (Both Transmitter and Receiver) Number of Channels Custom channels: 199 max. Programmed by FURUNO autho-

rized service representatives (user may program Rx channels). ITU SSB/TELEX Channels as listed in the APPENDIX.

2182 kHz (single action)

Environmental Transceiver unit: -20°C to +55°C

Antenna coupler: -30°C to +70°C Relative humidity 93% at 40°C

Power Supply 13.6 VDC (+15%, -15%)

Receive: 1.5 A Transmit (max.): 30 A

Radiotelephone Alarm Signal Generator

Two tones of 2200 Hz and 1300 Hz transmitted alternately.

TRANSMITTER

Output Impedance 50 ohms Output Power

J3E/H3E: 1.6 to 23 MHz, 150 W pep, 23 to 27.5 MHz, 75 W pep

J2B: 1.6 to 23 MHz, 100 W; 23 to 27.5 MHz, 50 W pep Tune 10 W approx. Power Reduction 60 W approx. Controls Output HI/LOW, test (option)/send of two-tone alarm generator

SP-1

ANTENNA COUPLER

Power Capability 150 W pep Tuning System CPU controlled fully automatic tuning system Frequency Range 1.6 to 27.5 MHz Input Impedance 50 ohms (viewed from transceiver) Antenna Required 6 to 15 meters wire or whip Tuning Power 10 to 20 W pep VSWR Less than 1.5 Tuning Time Within 2 to 15 seconds, Within 0.5 seconds for an ever tuned

frequency Dummy Load (option) 10 ohms + 250 pF for check of Two-tone alarm generator at

2191 kHz (frequency changeable) Power Requirement 12.0 VDC, 0.6 A (supplied from transceiver) Construction Waterproof plastic cabinet, stainless steel mount

RECEIVER

Receiving System Double-conversion superheterodyne

IF: 54.455 MHz and 455 kHz. Sensitivity Input level to produce SINAD 20 dB

J3E J2B

1.6 - 4 MHz Below +16 dBµV Below +6 dBµV across 10 Ω + 250 pF

4-27.5 MHz Below +3 dBµV Below -7 dBµV across 50 Ω

Pass Band 350 - 2700 Hz -6 dB Cross Modulation Unwanted signal +90 dBµV ±20 kHz from +60 dBµV wanted

signal Audio Output 1 W (8 Ω internal loudspeaker), 3.5 W (4Ω optional external

loudspeaker)

0 dBm/600Ω line output (for NBDP, DSC, RB-500) Other Features RF Gain: Adjustable

Squelch: ON/OFF, Activated by voice/signal strength

Dimmer: OFF/Low/Medium/High

Loudspeaker: ON/OFF (Handset always alive)

AGC: ON/OFF

Noise blanker: ON/OFF (thru system setting)

SP-2

APPENDIX

CUSTOM CHANNELS/FREQUENCIES

Where permitted user may program both Tx and Rx frequencies or Rx frequencies; Tx frequencies to be programmed by FURUNO dealer .

CH NO Ship Receive (kHz) Ship Transmit (kHz) Remarks (Station name)

A-1

MF band working carrier frequencies - ref. US CFR 47 Part 80.371

Region

East Coast 2490.0 2031.5 Gulf Coast 2466.0 2009.0

West Coast 2450.0 2003.0 2550.0 2158.0

Ship Receive

(kHz)

2514.0 2118.0 2530.0 2134.0

2522.0 2126.0 2538.0 2142.0

2538.0 2142.0 2550.0 2158.0

2558.0 2166.0 2558.0 2166.0

2590.0 2198.0 2598.0 2206.0

2450.0 2366.0 2450.0 2366.0

2482.0 2382.0 2482.0 2382.0

2566.0 2390.0 2572.0 2430.0

2400.0 2400.0 2506.0 2458.0

2506.0 2406.0 Great Lakes

2442.0 2009.0 2582.0 2206.0

2566.0 2009.0 Alaska 2309.0 2131.0

2566.0 2031.5 2312.0 2134.0

2522.0 2126.0 2400.0 2240.0

2598.0 2206.0 Hawaii 2530.0 2134.0

2466.0 2382.0 Caribbean 2506.0 2009.0

2482.0 2430.0 2585.0 2086.0

Ship Transmit

(kHz)

Region

Guam 2506.0 2009.0

Ship Receive

(kHz)

2514.0 2118.0

2530.0 2134.0

Ship Transmit

(kHz)

Above is not factory programmed, should be programmed by Furuno representatives.

1 Unlimited use December 15 to April 1 2 2206 kHz for distress only. 3 Limited to pep of 150 W.

NOTE: 1 to 3 indicate the outline only. Refer to the relative documentation for full detail. For other coast stations, consult with your dealers.

A-2

MF band SSB working carrier frequencies

CH NO

241 1635 2060 271 1725 2069 242 1638 2063 272 1728 2072 243 1641 2066 273 1731 2075 244 1644 2069 274 1734 2078 245 1647 2072 275 1737 2081 246 1650 2075 276 1740 2084 247 1653 2078 277 1743 2087 248 1656 2081 278 1746 2090 249 1659 2084 279 1749 2093 250 1662 2087 280 1752 2096 251 1665 2090 281 1755 2099 252 1668 2093 282 1758 2102 253 1671 2096 283 1761 2105 254 1674 2099 284 1764 2108 255 1677 2102 285 1767 2111 256 1680 2105 286 1770 2114 257 1683 2108 287 1773 2117 258 1686 2111 288 1776 2120 259 1689 2114 289 1779 2123 260 1692 2117 290 1782 2126 261 1695 2120 291 1785 2129 262 1698 2123 292 1788 2132 263 1701 2126 293 1791 2135 264 1704 2129 294 1794 2138 265 1707 2132 295 1797 2060 266 1710 2135 267 1713 2138 268 1716 2060 269 1719 2063 270 1722 2066

Ship Receive

(kHz)

Ship Transmit

(kHz)

CH NO

Ship Receive

(kHz)

Ship Transmit

(kHz)

Change of system setting required to use above channels. Ask a FURUNO dealer. Above is factory programmed. A channel can be recalled by hitting the keys [CH], [2], [4], [1], [ENT] for channel 241 as an example. The channel number and Rx frequencies appear on the display. The channel number is displayed in 4 digits, such as 2041. (Additional zero is inserted automatically.) The Tx frequency and Rx frequency are checked by pressing the [ENT] key.

A-3

4/6 MHz ITU SSB carrier frequencies (ITU RR APPENDIX 16)

The following frequencies are factory programmed.

)E3J(BSSzHM4)E3J(BSSzHM6

ONHCUTIXRpihSXTpihSONHCUTIXRpihSXTpihS 1047534560410610560026 2040634860420640563026 3043634170430670566026 4046634470440601569026 5049634770450631562126 6042734080460661565126 7045734380470691568126 8048734680480622561226 9041834980490642264226 0144834290401672267226 1147834590411603260326 21409348904 31439341014 41469344014 51499347014 61420440114 71450443114 81480446114 91411449114 02441442214 12471445214 22402448214 32432441314 42462444314 52492447314 62423440414 72453443414 82415341534 92445344534 03464146414 13494149414

)10(23400040004 )20(33430043004 )30(43460046004 )40(53490049004 )50(63421042104 )60(73451045104 )70(83481048104 )80(93412041204 )90(04442044204 )01(14472047204 )11(24403040304 )21(34433043304 )31(44463046304 )41(54493049304 )51(64424042404 )61(74454045404 )71(84484048404 )81(94415041504 )91(05445044504 )02(15475047504 )12(25406040604

.]TNE[

.elpmaxenasa104

ehtgnittihybdellacerebnaclennahcA

HCrof]TNE[,]1[,]0[,]4[,]HC[syek

ehtnoraeppaycneuqerfxRdnarebmunlennahC

sahcusstigid4nideyalpsidsiONHCehT.yalpsid

sserp,ycneuqerfxRdnaycneuqerfxTeesoT.1004

-3esU.)1-CnoitceSRR(sONUTIera)(nisONHC

.snoitcelesrofsrotangiseds'ONURUFtigid

A-4

8 MHz ITU SSB carrier frequencies (ITU RR APPENDIX 16)

The following frequencies are factory programmed.

8 MHz SSB (J3E) 8 MHz SSB (J3E)

ITU CH NO Ship RX Ship TX (ITU CH NO) Ship RX Ship TX

801 8719 8195 840 (01) 8101 8101 802 8722 8198 841 (02) 8104 8104 803 8725 8201 842 (03) 8107 8107 804 8728 8204 843 (04) 8110 8110 805 8731 8207 844 (05) 8113 8113 806 8734 8210 845 (06) 8116 8116 807 8737 8213 846 (07) 8119 8119 808 8740 8216 847 (08) 8122 8122 809 8743 8219 848 (09) 8125 8125 810 8746 8222 849 (10) 8128 8128 811 8749 8225 850 (11) 8131 8131 812 8752 8228 851 (12) 8134 8134 813 8755 8231 852 (13) 8137 8137 814 8758 8234 853 (14) 8140 8140 815 8761 8237 854 (15) 8143 8143 816 8764 8240 855 (16) 8146 8146 817 8767 8243 856 (17) 8149 8149 818 8770 8246 857 (18) 8152 8152 819 8773 8249 858 (19) 8155 8155 820 8776 8252 859 (20) 8158 8158 821 8779 8255 860 (21) 8161 8161 822 8782 8258 823 8785 8261 CH NOs in ( ) are ITU NOs (RR Section C-1). 824 8788 8264 825 8791 8267 826 8794 8270 827 8797 8273 828 8800 8276 829 8803 8279 830 8806 8282 831 8809 8285 832 8812 8288 833 8291 8291 834 8707 8707 835 8710 8710 836 8713 8713 837 8716 8716 838 8294 8294 839 8297 8297

A channel can be recalled by hitting the keys [CH], [8], [0], [1], [ENT] for channel 801 as an example. CH NO and Rx frequency appear on the display. The channel number is displayed in 4 digits, such as 8001. (Additional zero is inserted automatically.) The Tx frequency and Rx frequency are checked by pressing the [ENT] key.

Use 3-digit Furuno’s designators for selection in this radiotelephone.

A-5

12/16 MHz ITU SSB carrier frequencies (ITU RR APPENDIX 16)

12 MHz SSB (J3E) 16 MHz SSB (J3E) 16 MHz SSB (J3E)

CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX

1201 13077 12230 1601 17242 16360 1651 17392 16510 1202 13080 12233 1602 17245 16363 1652 17395 16513

1203 13083 12236 1603 17248 16366 1653 17398 16516 1204 13086 12239 1604 17251 16369 1654 17401 16519 1205 13089 12242 1605 17254 16372 1655 17404 16522 1206 13092 12245 1606 17257 16375 1656 17407 16525 1207 13095 12248 1607 17260 16378 1657 16528 16528 1208 13098 12251 1608 17263 16381 1658 16531 16531 1209 13101 12254 1609 17266 16384 1659 16534 16534 1210 13104 12257 1610 17269 16387 1660 16537 16537 1211 13107 12260 1611 17272 16390 1661 16540 16540

1212 13110 12263 1612 17275 16393 1662 16543 16543 1213 13113 12266 1613 17278 16396 1663 16546 16546 1214 13116 12269 1614 17281 16399 1215 13119 12272 1615 17284 16402 1216 13122 12275 1616 17287 16405 1217 13125 12278 1617 17290 16408 1218 13128 12281 1618 17293 16411 1219 13131 12284 1619 17296 16414 1220 13134 12287 1620 17299 16417 1221 13137 12290 1621 17302 16420

1222 13140 12293 1622 17305 16423 1223 13143 12296 1623 17308 16426 1224 13146 12299 1624 17311 16429 1225 13149 12302 1625 17314 16432 1226 13152 12305 1626 17317 16435 1227 13155 12308 1627 17320 16438 1228 13158 12311 1628 17323 16441 1229 13161 12314 1629 17326 16444 1230 13164 12317 1630 17329 16447 1231 13167 12320 1631 17332 16450

1232 13170 12323 1632 17335 16453 1233 13173 12326 1633 17338 16456 1234 13176 12329 1634 17341 16459 1235 13179 12332 1635 17344 16462 1236 13182 12335 1636 17347 16465 A channel can be recalled by hitting 1237 13185 12338 1637 17350 16468 1238 13188 12341 1638 17353 16471 1239 13191 12344 1639 17356 16474 1240 13194 12347 1640 17359 16477 1241 13197 12350 1641 17362 16480

1242 12353 12353 1642 17365 16483 1243 12356 12356 1643 17368 16486 1244 12359 12359 1644 17371 16489 1245 12362 12362 1645 17374 16492 1246 12365 12365 1646 17377 16495

1647 17380 16498 1648 17383 16501 1649 17386 16504 1650 17389 16507

Above is factory programmed.

the keys [CH], [1], [2], [0], [1], [ENT] for channel 1201 as an example. CH NO and Rx frequency appear on the display. The CH NO is displayed in 5 digits, such as 12001. (Additional zero is inserted automatically.)

The Tx and Rx frequencies are checked by pressing the [ENT] key.

A-6

18/19, 22, 25/26 MHz ITU SSB carrier frequencies (ITU RR APPENDIX 16)

The following frequencies are factory programmed.

18/19 MHz SSB (J3E) 22 MHz SSB (J3E) 22 MHz SSB (J3E)

CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX

1801 19755 18780 2201 22696 22000 2251 22846 22150 1802 19758 18783 2202 22699 22003 2252 22849 22153 1803 19761 18786 2203 22702 22006 2253 22852 22156 1804 19764 18789 2204 22705 22009 2254 22159 22159

1805 19767 18792 2205 22708 22012 2255 22162 22162 1806 19770 18795 2206 22711 22015 2256 22165 22165 1807 19773 18798 2207 22714 22018 2257 22168 22168 1808 19776 18801 2208 22717 22021 2258 22171 22171 1809 19779 18804 2209 22720 22024 2259 22174 22174

1810 19782 18807 2210 22723 22027 2260 22177 22177 1811 19785 18810 2211 22726 22030 1812 19788 18813 2212 22729 22033 1813 19791 18816 2213 22732 22036 1814 19794 18819 2214 22735 22039

1815 19797 18822 2215 22738 22042 1816 18825 18825 2216 22741 22045 1817 18828 18828 2217 22744 22048 1818 18831 18831 2218 22747 22051 25/26 MHz SSB (J3E) 1819 18834 18834 2219 22750 22054 CH NO Ship RX Ship TX

1820 18837 18837 2220 22753 22057 2501 26145 25070 1821 18840 18840 2221 22756 22060 2502 26148 25073 1822 18843 18843 2222 22759 22063 2503 26151 25076

2223 22762 22066 2504 26154 25079 2224 22765 22069 2505 26157 25082

2225 22768 22072 2506 26160 25085 2226 22771 22075 2507 26163 25088 2227 22774 22078 2508 26166 25091 2228 22777 22081 2509 26169 25094

2229 22780 22084 2510 26172 25097 A channel can be recalled by hitting the keys [CH], [1], [8], [0], [1], [ENT] for channel 1801 as an example. CH NO and Rx frequency appear on the display. The CH NO displayed in 5 digits, such as 18001. (Additional zero is inserted automatically.)

The Tx and Rx frequencies are checked by pressing the [ENT] key.

2230 22783 22087 2511 25100 25100

2231 22786 22090 2512 25103 25103

2232 22789 22093 2513 25106 25106

2233 22792 22096 2514 25109 25109

2234 22795 22099 2515 25112 25112

2235 22798 22102 2516 25115 25115

2236 22801 22105 2517 25118 25118

2237 22804 22108

2238 22807 22111

2239 22810 22114

2240 22813 22117

2241 22816 22120

2242 22819 22123

2243 22822 22126

2244 22825 22129

2245 22828 22132

2246 22831 22135

2247 22834 22138

2248 22837 22141

2249 22840 22144

2250 22843 22147

A-7

TELEX CHANNELS

MF BAND Telex FREQUENCY TABLE

The following frequencies are factory programmed.

CH NO.

201 2142.0 1607.0 202 2142.5 1607.5

203 2143.0 1608.0 204 2143.5 1608.5 205 2144.0 1609.0

206 2144.5 1609.5 207 2145.0 1610.0 208 2145.5 1610.5 209 2146.0 1611.0 210 2146.5 1611.5

211 2147.0 1612.0 212 2147.5 1612.5 213 2148.0 1613.0 214 2148.5 1613.5

215 2149.0 1614.0

216 2149.5 1614.5 217 2150.0 1615.0 218 2150.5 1615.5

219 2151.0 1616.0 220 2151.5 1616.5

Ship Receive

(NBDP, DSC)

Ship Transmit

(NBDP, DSC)

NBDP/DSC

221 2152.0 1617.0 222 2152.5 1617.5

223 2153.0 1618.0 224 2153.5 1618.5 225 2154.0 1619.0

226 2154.5 1619.5 227 2155.0 1620.0 228 2155.5 1620.5 229 2156.0 1621.0 230 2156.5 1621.5

231 2157.0 1622.0 232 2157.5 1622.5 233 2158.0 1623.0 234 2158.5 1623.5

235 2159.0 1624.0

236 2159.5 1624.5

For Europe MF frequencies selection of ITU+MF on system setting necessary. A channel can be recalled by hitting the keys [CH], [2], [0], [1], [ENT] for channel 201 as an example. CH NO and Rx frequency appear on the display. The channel number is displayed in 4 digits, such as 2001. (Additional zero is inserted automatically.) The Rx and Tx frequencies are checked by pressing the [ENT] key.

DSC

A-8

4/6 MHz BAND ITU NBDP (Telex) FREQUENCY TABLE

(ITU RR APPENDIX 32)

4 MHz TELEX 6 MHz TELEX 6 MHz TELEX

CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX

4001 4210.5 4172.5 6001 6314.5 6263.0 6041 6303.5 6303.5 4002 4211.0 4173.0 6002 6315.0 6263.5 6042 6304.0 6304.0

4003 4211.5 4173.5 6003 6315.5 6264.0 6043 6304.5 6304.5 4004 4212.0 4174.0 6004 6316.0 6264.5 6044 6305.0 6305.0

4005 4212.5 4174.5 6005 6316.5 6265.0 6045 6305.5 6305.5 4006 4213.0 4175.0 6006 6317.0 6265.5 6046 6306.0 6306.0

4007 4213.5 4175.5 6007 6317.5 6266.0 6047 6306.5 6306.5 4008 4214.0 4176.0 6008 6318.0 6266.5 6048 6307.0 6307.0

4009 4214.5 4176.5 6009 6318.5 6267.0 6049 6307.5 6307.5 4010 4215.0 4177.0 6010 6319.0 6267.5 6050 6308.0 6308.0 4011 4177.5 4177.5 6011 6268.0 6268.0 6051 6308.5 6308.5

4012 4215.5 4178.0 6012 6319.5 6268.5 6052 6309.0 6309.0 4013 4216.0 4178.5 6013 6320.0 6269.0 6053 6309.5 6309.5

4014 4216.5 4179.0 6014 6320.5 6269.5 6054 6310.0 6310.0 4015 4217.0 4179.5 6015 6321.0 6270.0 6055 6310.5 6310.5 4016 4217.5 4180.0 6016 6321.5 6270.5 6056 6311.0 6311.0

4017 4218.0 4180.5 6017 6322.0 6271.0 6057 6311.5 6311.5 4018 4218.5 4181.0 6018 6322.5 6271.5 6058 6312.0 6312.0

4019 4219.0 4181.5 6019 6323.0 6272.0 6059 6331.0 6312.5 4020 4202.5 4202.5 6020 6323.5 6272.5 6060 6331.5 6313.0 4021 4203.0 4203.0 6021 6324.0 6273.0 6061 6332.0 6313.5

4022 4203.5 4203.5 6022 6324.5 6273.5 4023 4204.0 4204.0 6023 6325.0 6274.0

4024 4204.5 4204.5 6024 6325.5 6274.5 4025 4205.0 4205.0 6025 6326.0 6275.0 4026 4205.5 4205.5 6026 6326.5 6275.5

4027 4206.0 4206.0 6027 6327.0 6281.0 4028 4206.5 4206.5 6028 6327.5 6281.5

4029 4207.0 4207.0 6029 6328.0 6282.0 4030 4207.5 4207.5 6030 6328.5 6282.5 4031 4219.5 4208.0 6031 6329.0 6283.0

4032 4220.0 4208.5 6032 6329.5 6283.5 4033 4220.5 4209.0 6033 6330.0 6284.0

6034 6330.5 6284.5

6035 6300.5 6300.5

6036 6301.0 6301.0

6037 6301.5 6301.5

6038 6302.0 6302.0

6039 6302.5 6302.5

6040 6303.0 6303.0 Above is factory programmed.

A-9

8 MHz BAND ITU NBDP (Telex) FREQUENCY TABLE

(ITU RR APPENDIX 32)

8 MHz TELEX 8 MHz TELEX

CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX

8001 8376.5 8376.5 8046 8399.0 8399.0 8002 8417.0 8377.0 8047 8399.5 8399.5

8003 8417.5 8377.5 8048 8400.0 8400.0 8004 8418.0 8378.0 8049 8400.5 8400.5 8005 8418.5 8378.5 8050 8401.0 8401.0 8006 8419.0 8379.0 8051 8401.5 8401.5

8007 8419.5 8379.5 8052 8402.0 8402.0 8008 8420.0 8380.0 8053 8402.5 8402.5 8009 8420.5 8380.5 8054 8403.0 8403.0 8010 8421.0 8381.0 8055 8403.5 8403.5 8011 8421.5 8381.5 8056 8404.0 8404.0

8012 8422.0 8382.0 8057 8404.5 8404.5 8013 8422.5 8382.5 8058 8405.0 8405.0 8014 8423.0 8383.0 8059 8405.5 8405.5 8015 8423.5 8383.5 8060 8406.0 8406.0 8016 8424.0 8384.0 8061 8406.5 8406.5

8017 8424.5 8384.5 8062 8407.0 8407.0 8018 8425.0 8385.0 8063 8407.5 8407.5 8019 8425.5 8385.5 8064 8408.0 8408.0 8020 8426.0 8386.0 8065 8408.5 8408.5 8021 8426.5 8386.5 8066 8409.0 8409.0

8022 8427.0 8387.0 8067 8409.5 8409.5 8023 8427.5 8387.5 8068 8410.0 8410.0 8024 8428.0 8388.0 8069 8410.5 8410.5 8025 8428.5 8388.5 8070 8411.0 8411.0 8026 8429.0 8389.0 8071 8411.5 8411.5

8027 8429.5 8389.5 8072 8412.0 8412.0 8028 8430.0 8390.0 8073 8412.5 8412.5 8029 8430.5 8390.5 8074 8413.0 8413.0 8030 8431.0 8391.0 8075 8413.5 8413.5 8031 8431.5 8391.5 8076 8414.0 8414.0

8032 8432.0 8392.0 8077 8414.5 8414.5 8033 8432.5 8392.5 8078 8436.5 8415.0 8034 8433.0 8393.0 8079 8437.0 8415.5 8035 8433.5 8393.5 8080 8437.5 8416.0 8036 8434.0 8394.0

8037 8434.5 8394.5 8038 8435.0 8395.0 8039 8435.5 8395.5 8040 8436.0 8396.0 8041 8396.5 8396.5

8042 8397.0 8397.0 8043 8397.5 8397.5 8044 8398.0 8398.0 8045 8398.5 8398.5

Above is factory programmed.

A-10

12 MHz BAND ITU NBDP (Telex) FREQUENCY TABLE

The following frequencies are factory programmed.

12 MHz TELEX 12 MHz TELEX 12 MHz TELEX

CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX

12001 12579.5 12477.0 12056 12607.0 12504.5 12111 12634.0 12532.0 12002 12580.0 12477.5 12057 12607.5 12505.0 12112 12634.5 12532.5 12003 12580.5 12478.0 12058 12608.0 12505.5 12113 12635.0 12533.0 12004 12581.0 12478.5 12059 12608.5 12506.0 12114 12635.5 12533.5 12005 12581.5 12479.0 12060 12609.0 12506.5 12115 12636.0 12534.0 12006 12582.0 12479.5 12061 12609.5 12507.0 12116 12636.5 12534.5 12007 12582.5 12480.0 12062 12610.0 12507.5 12117 12637.0 12535.0 12008 12583.0 12480.5 12063 12610.5 12508.0 12118 12637.5 12535.5 12009 12583.5 12481.0 12064 12611.0 12508.5 12119 12638.0 12536.0 12010 12584.0 12481.5 12065 12611.5 12509.0 12120 12638.5 12536.5 12011 12584.5 12482.0 12066 12612.0 12509.5 12121 12639.0 12537.0 12012 12585.0 12482.5 12067 12612.5 12510.0 12122 12639.5 12537.5 12013 12585.5 12483.0 12068 12613.0 12510.5 12123 12640.0 12538.0 12014 12586.0 12483.5 12069 12613.5 12511.0 12124 12640.5 12538.5 12015 12586.5 12484.0 12070 12614.0 12511.5 12125 12641.0 12539.0 12016 12587.0 12484.5 12071 12614.5 12512.0 12126 12641.5 12539.5 12017 12587.5 12485.0 12072 12615.0 12512.5 12127 12642.0 12540.0 12018 12588.0 12485.5 12073 12615.5 12513.0 12128 12642.5 12540.5 12019 12588.5 12486.0 12074 12616.0 12513.5 12129 12643.0 12541.0 12020 12589.0 12486.5 12075 12616.5 12514.0 12130 12643.5 12541.5 12021 12589.5 12487.0 12076 12617.0 12514.5 12131 12644.0 12542.0 12022 12590.0 12487.5 12077 12617.5 12515.0 12132 12644.5 12542.5 12023 12590.5 12488.0 12078 12618.0 12515.5 12133 12645.0 12543.0 12024 12591.0 12488.5 12079 12618.5 12516.0 12134 12645.5 12543.5 12025 12591.5 12489.0 12080 12619.0 12516.5 12135 12646.0 12544.0 12026 12592.0 12489.5 12081 12619.5 12517.0 12136 12646.5 12544.5 12027 12592.5 12490.0 12082 12620.0 12517.5 12137 12647.0 12545.0 12028 12593.0 12490.5 12083 12620.5 12518.0 12138 12647.5 12545.5 12029 12593.5 12491.0 12084 12621.0 12518.5 12139 12648.0 12546.0 12030 12594.0 12491.5 12085 12621.5 12519.0 12140 12648.5 12546.5 12031 12594.5 12492.0 12086 12622.0 12519.5 12141 12649.0 12547.0 12032 12595.0 12492.5 12087 12520.0 12520.0 12142 12649.5 12547.5 12033 12595.5 12493.0 12088 12622.5 12520.5 12143 12650.0 12548.0 12034 12596.0 12493.5 12089 12623.0 12521.0 12144 12650.5 12548.5 12035 12596.5 12494.0 12090 12623.5 12521.5 12145 12651.0 12549.0 12036 12597.0 12494.5 12091 12624.0 12522.0 12146 12651.5 12549.5 12037 12597.5 12495.0 12092 12624.5 12522.5 12147 12652.0 12555.0 12038 12598.0 12495.5 12093 12625.0 12523.0 12148 12652.5 12555.5 12039 12598.5 12496.0 12094 12625.5 12523.5 12149 12653.0 12556.0 12040 12599.0 12496.5 12095 12626.0 12524.0 12150 12653.5 12556.5 12041 12599.5 12497.0 12096 12626.5 12524.5 12151 12654.0 12557.0 12042 12600.0 12497.5 12097 12627.0 12525.0 12152 12654.5 12557.5 12043 12600.5 12498.0 12098 12627.5 12525.5 12153 12655.0 12558.0 12044 12601.0 12498.5 12099 12628.0 12526.0 12154 12655.5 12558.5 12045 12601.5 12499.0 12100 12628.5 12526.5 12155 12656.0 12559.0 12046 12602.0 12499.5 12101 12629.0 12527.0 12156 12656.5 12559.5 12047 12602.5 12500.0 12102 12629.5 12527.5 12157 12560.0 12560.0 12048 12603.0 12500.5 12103 12630.0 12528.0 12158 12560.5 12560.5 12049 12603.5 12501.0 12104 12630.5 12528.5 12159 12561.0 12561.0 12050 12604.0 12501.5 12105 12631.0 12529.0 12160 12561.5 12561.5 12051 12604.5 12502.0 12106 12631.5 12529.5 12161 12562.0 12562.0 12052 12605.0 12502.5 12107 12632.0 12530.0 12162 12562.5 12562.5 12053 12605.5 12503.0 12108 12632.5 12530.5 12163 12563.0 12563.0 12054 12606.0 12503.5 12109 12633.0 12531.0 12164 12563.5 12563.5 12055 12606.5 12504.0 12110 12633.5 12531.5 12165 12564.0 12564.0

A-11

12/16 MHz BAND ITU NBDP (Telex) FREQUENCY TABLE

The following frequencies are factory programmed.

12 MHz TELEX 16 MHz TELEX 16 MHz TELEX

CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX

12166 12564.5 12564.5 16001 16807.0 16683.5 16056 16834.0 16711.0 12167 12565.0 12565.0 16002 16807.5 16684.0 16057 16834.5 16711.5 12168 12565.5 12565.5 16003 16808.0 16684.5 16058 16835.0 16712.0 12169 12566.0 12566.0 16004 16808.5 16685.0 16059 16835.5 16712.5 12170 12566.5 12566.5 16005 16809.0 16685.5 16060 16836.0 16713.0 12171 12567.0 12567.0 16006 16809.5 16686.0 16061 16836.5 16713.5 12172 12567.5 12567.5 16007 16810.0 16686.5 16062 16837.0 16714.0 12173 12568.0 12568.0 16008 16810.5 16687.0 16063 16837.5 16714.5 12174 12568.5 12568.5 16009 16811.0 16687.5 16064 16838.0 16715.0 12175 12569.0 12569.0 16010 16811.5 16688.0 16065 16838.5 16715.5 12176 12569.5 12569.5 16011 16812.0 16688.5 16066 16839.0 16716.0 12177 12570.0 12570.0 16012 16812.5 16689.0 16067 16839.5 16716.5 12178 12570.5 12570.5 16013 16813.0 16689.5 16068 16840.0 16717.0 12179 12571.0 12571.0 16014 16813.5 16690.0 16069 16840.5 16717.5 12180 12571.5 12571.5 16015 16814.0 16690.5 16070 16841.0 16718.0 12181 12572.0 12572.0 16016 16814.5 16691.0 16071 16841.5 16718.5 12182 12572.5 12572.5 16017 16815.0 16691.5 16072 16842.0 16719.0 12183 12573.0 12573.0 16018 16815.5 16692.0 16073 16842.5 16719.5 12184 12573.5 12573.5 16019 16816.0 16692.5 16074 16843.0 16720.0 12185 12574.0 12574.0 16020 16816.5 16693.0 16075 16843.5 16720.5 12186 12574.5 12574.5 16021 16817.0 16693.5 16076 16844.0 16721.0 12187 12575.0 12575.0 16022 16817.5 16694.0 16077 16844.5 16721.5 12188 12575.5 12575.5 16023 16818.0 16694.5 16078 16845.0 16722.0 12189 12576.0 12576.0 16024 16695.0 16695.0 16079 16845.5 16722.5 12190 12576.5 12576.5 16025 16818.5 16695.5 16080 16846.0 16723.0 12191 12577.0 12577.0 16026 16819.0 16696.0 16081 16846.5 16723.5 12192 12577.5 12577.5 16027 16819.5 16696.5 16082 16847.0 16724.0 12193 12578.0 12578.0 16028 16820.0 16697.0 16083 16847.5 16724.5 12194 12578.5 12578.5 16029 16820.5 16697.5 16084 16848.0 16725.0

16030 16821.0 16698.0 16085 16848.5 16725.5 16031 16821.5 16698.5 16086 16849.0 16726.0 16032 16822.0 16699.0 16087 16849.5 16726.5 16033 16822.5 16699.5 16088 16850.0 16727.0 16034 16823.0 16700.0 16089 16850.5 16727.5 16035 16823.5 16700.5 16090 16851.0 16728.0 16036 16824.0 16701.0 16091 16851.5 16728.5 16037 16824.5 16701.5 16092 16852.0 16729.0 16038 16825.0 16702.0 16093 16852.5 16729.5 16039 16825.5 16702.5 16094 16853.0 16730.0 16040 16826.0 16703.0 16095 16853.5 16730.5 16041 16826.5 16703.5 16096 16854.0 16731.0 16042 16827.0 16704.0 16097 16854.5 16731.5 16043 16827.5 16704.5 16098 16855.0 16732.0 16044 16828.0 16705.0 16099 16855.5 16732.5 16045 16828.5 16705.5 16100 16856.0 16733.0 16046 16829.0 16706.0 16101 16856.5 16733.5 16047 16829.5 16706.5 16102 16857.0 16739.0 16048 16830.0 16707.0 16103 16857.5 16739.5 16049 16830.5 16707.5 16104 16858.0 16740.0 16050 16831.0 16708.0 16105 16858.5 16740.5 16051 16831.5 16708.5 16106 16859.0 16741.0 16052 16832.0 16709.0 16107 16859.5 16741.5 16053 16832.5 16709.5 16108 16860.0 16742.0 16054 16833.0 16710.0 16109 16860.5 16742.5 16055 16833.5 16710.5 16110 16861.0 16743.0

A-12

16 MHz BAND ITU NBDP (Telex) FREQUENCY TABLE

The following frequencies are factory programmed.

16 MHz TELEX 16 MHz TELEX 16 MHz TELEX

CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX

16111 16861.5 16743.5 16166 16889.0 16771.0 16221 16798.5 16798.5 16112 16862.0 16744.0 16167 16889.5 16771.5 16222 16799.0 16799.0 16113 16862.5 16744.5 16168 16890.0 16772.0 16223 16799.5 16799.5 16114 16863.0 16745.0 16169 16890.5 16772.5 16224 16800.0 16800.0 16115 16863.5 16745.5 16170 16891.0 16773.0 16225 16800.5 16800.5 16116 16864.0 16746.0 16171 16891.5 16773.5 16226 16801.0 16801.0 16117 16864.5 16746.5 16172 16892.0 16774.0 16227 16801.5 16801.5 16118 16865.0 16747.0 16173 16892.5 16774.5 16228 16802.0 16802.0 16119 16865.5 16747.5 16174 16893.0 16775.0 16229 16802.5 16802.5 16120 16866.0 16748.0 16175 16893.5 16775.5 16230 16803.0 16803.0 16121 16866.5 16748.5 16176 16894.0 16776.0 16231 16803.5 16803.5 16122 16867.0 16749.0 16177 16894.5 16776.5 16232 16804.0 16804.0 16123 16867.5 16749.5 16178 16895.0 16777.0 16233 16804.5 16804.5 16124 16868.0 16750.0 16179 16895.5 16777.5 16234 16805.0 16805.0 16125 16868.5 16750.5 16180 16896.0 16778.0 16235 16805.5 16805.5 16126 16869.0 16751.0 16181 16896.5 16778.5 16236 16806.0 16806.0 16127 16869.5 16751.5 16182 16897.0 16779.0 16128 16870.0 16752.0 16183 16897.5 16779.5 16129 16870.5 16752.5 16184 16898.0 16780.0 16130 16871.0 16753.0 16185 16898.5 16780.5 16131 16871.5 16753.5 16186 16899.0 16781.0 16132 16872.0 16754.0 16187 16899.5 16781.5 16133 16872.5 16754.5 16188 16900.0 16782.0 16134 16873.0 16755.0 16189 16900.5 16782.5 16135 16873.5 16755.5 16190 16901.0 16783.0 16136 16874.0 16756.0 16191 16901.5 16783.5 16137 16874.5 16756.5 16192 16902.0 16784.0 16138 16875.0 16757.0 16193 16902.5 16784.5 16139 16875.5 16757.5 16194 16785.0 16785.0 16140 16876.0 16758.0 16195 16785.5 16785.5 16141 16876.5 16758.5 16196 16786.0 16786.0 16142 16877.0 16759.0 16197 16786.5 16786.5 16143 16877.5 16759.5 16198 16787.0 16787.0 16144 16878.0 16760.0 16199 16787.5 16787.5 16145 16878.5 16760.5 16200 16788.0 16788.0 16146 16879.0 16761.0 16201 16788.5 16788.5 16147 16879.5 16761.5 16202 16789.0 16789.0 16148 16880.0 16762.0 16203 16789.5 16789.5 16149 16880.5 16762.5 16204 16790.0 16790.0 16150 16881.0 16763.0 16205 16790.5 16790.5 16151 16881.5 16763.5 16206 16791.0 16791.0 16152 16882.0 16764.0 16207 16791.5 16791.5 16153 16882.5 16764.5 16208 16792.0 16792.0 16154 16883.0 16765.0 16209 16792.5 16792.5 16155 16883.5 16765.5 16210 16793.0 16793.0 16156 16884.0 16766.0 16211 16793.5 16793.5 16157 16884.5 16766.5 16212 16794.0 16794.0 16158 16885.0 16767.0 16213 16794.5 16794.5 16159 16885.5 16767.5 16214 16795.0 16795.0 16160 16886.0 16768.0 16215 16795.5 16795.5 16161 16886.5 16768.5 16216 16796.0 16796.0 16162 16887.0 16769.0 16217 16796.5 16796.5 16163 16887.5 16769.5 16218 16797.0 16797.0 16164 16888.0 16770.0 16219 16797.5 16797.5 16165 16888.5 16770.5 16220 16798.0 16798.0

A-13

18/19 MHz BAND ITU NBDP (Telex) FREQUENCY TABLE

The following frequencies are factory programmed.

18/19 MHz TELEX 18/19 MHz TELEX

CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX

18001 19681.0 18870.5 18051 18895.5 18895.5 18002 19681.5 18871.0 18052 18896.0 18896.0

18003 19682.0 18871.5 18053 18896.5 18896.5 18004 19682.5 18872.0 18054 18897.0 18897.0 18005 19683.0 18872.5 18055 18897.5 18897.5 18006 19683.5 18873.0 18056 18898.0 18898.0

18007 19684.0 18873.5 18057 18898.5 18898.5 18008 19684.5 18874.0 18058 18899.0 18899.0 18009 19685.0 18874.5 18059 18899.5 18899.5 18010 19685.5 18875.0 18011 19686.0 18875.5

18012 19686.5 18876.0 18013 19687.0 18876.5 18014 19687.5 18877.0 18015 19688.0 18877.5 18016 19688.5 18878.0

18017 19689.0 18878.5 18018 19689.5 18879.0 18019 19690.0 18879.5 18020 19690.5 18880.0 18021 19691.0 18880.5

18022 19691.5 18881.0 18023 19692.0 18881.5 18024 19692.5 18882.0 18025 19693.0 18882.5 18026 19693.5 18883.0

18027 19694.0 18883.5 18028 19694.5 18884.0 18029 19695.0 18884.5 18030 19695.5 18885.0 18031 19696.0 18885.5

18032 19696.5 18886.0 18033 19697.0 18886.5 18034 19697.5 18887.0 18035 19698.0 18887.5 18036 19698.5 18888.0

18037 19699.0 18888.5 18038 19699.5 18889.0 18039 19700.0 18889.5 18040 19700.5 18890.0 18041 19701.0 18890.5

18042 19701.5 18891.0 18043 19702.0 18891.5 18044 19702.5 18892.0 18045 19703.0 18892.5 18046 18893.0 18893.0

18047 18893.5 18893.5 18048 18894.0 18894.0 18049 18894.5 18894.5 18050 18895.0 18895.0

A-14

22 MHz BAND ITU NBDP (Telex) FREQUENCY TABLE

The following frequencies are factory programmed.

22 MHz TELEX 22 MHz TELEX 22 MHz TELEX

CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX

22001 22376.5 22284.5 22051 22401.5 22309.5 22101 22426.5 22334.5 22002 22377.0 22285.0 22052 22402.0 22310.0 22102 22427.0 22335.0

22003 22377.5 22285.5 22053 22402.5 22310.5 22103 22427.5 22335.5 22004 22378.0 22286.0 22054 22403.0 22311.0 22104 22428.0 22336.0 22005 22378.5 22286.5 22055 22403.5 22311.5 22105 22428.5 22336.5 22006 22379.0 22287.0 22056 22404.0 22312.0 22106 22429.0 22337.0

22007 22379.5 22287.5 22057 22404.5 22312.5 22107 22429.5 22337.5 22008 22380.0 22288.0 22058 22405.0 22313.0 22108 22430.0 22338.0 22009 22380.5 22288.5 22059 22405.5 22313.5 22109 22430.5 22338.5 22010 22381.0 22289.0 22060 22406.0 22314.0 22110 22431.0 22339.0 22011 22381.5 22289.5 22061 22406.5 22314.5 22111 22431.5 22339.5

22012 22382.0 22290.0 22062 22407.0 22315.0 22112 22432.0 22340.0 22013 22382.5 22290.5 22063 22407.5 22315.5 22113 22432.5 22340.5 22014 22383.0 22291.0 22064 22408.0 22316.0 22114 22433.0 22341.0 22015 22383.5 22291.5 22065 22408.5 22316.5 22115 22433.5 22341.5 22016 22384.0 22292.0 22066 22409.0 22317.0 22116 22434.0 22342.0

22017 22384.5 22292.5 22067 22409.5 22317.5 22117 22434.5 22342.5 22018 22385.0 22293.0 22068 22410.0 22318.0 22118 22435.0 22343.0 22019 22385.5 22293.5 22069 22410.5 22318.5 22119 22435.5 22343.5 22020 22386.0 22294.0 22070 22411.0 22319.0 22120 22436.0 22344.0 22021 22386.5 22294.5 22071 22411.5 22319.5 22121 22436.5 22344.5

22022 22387.0 22295.0 22072 22412.0 22320.0 22122 22437.0 22345.0 22023 22387.5 22295.5 22073 22412.5 22320.5 22123 22437.5 22345.5 22024 22388.0 22296.0 22074 22413.0 22321.0 22124 22438.0 22346.0 22025 22388.5 22296.5 22075 22413.5 22321.5 22125 22438.5 22346.5 22026 22389.0 22297.0 22076 22414.0 22322.0 22126 22439.0 22347.0

22027 22389.5 22297.5 22077 22414.5 22322.5 22127 22439.5 22347.5 22028 22390.0 22298.0 22078 22415.0 22323.0 22128 22440.0 22348.0 22029 22390.5 22298.5 22079 22415.5 22323.5 22129 22440.5 22348.5 22030 22391.0 22299.0 22080 22416.0 22324.0 22130 22441.0 22349.0 22031 22391.5 22299.5 22081 22416.5 22324.5 22131 22441.5 22349.5

22032 22392.0 22300.0 22082 22417.0 22325.0 22132 22442.0 22350.0 22033 22392.5 22300.5 22083 22417.5 22325.5 22133 22442.5 22350.5 22034 22393.0 22301.0 22084 22418.0 22326.0 22134 22443.0 22351.0 22035 22393.5 22301.5 22085 22418.5 22326.5 22135 22443.5 22351.5 22036 22394.0 22302.0 22086 22419.0 22327.0 22136 22352.0 22352.0

22037 22394.5 22302.5 22087 22419.5 22327.5 22137 22352.5 22352.5 22038 22395.0 22303.0 22088 22420.0 22328.0 22138 22353.0 22353.0 22039 22395.5 22303.5 22089 22420.5 22328.5 22139 22353.5 22353.5 22040 22396.0 22304.0 22090 22421.0 22329.0 22140 22354.0 22354.0 22041 22396.5 22304.5 22091 22421.5 22329.5 22141 22354.5 22354.5

22042 22397.0 22305.0 22092 22422.0 22330.0 22142 22355.0 22355.0 22043 22397.5 22305.5 22093 22422.5 22330.5 22143 22355.5 22355.5 22044 22398.0 22306.0 22094 22423.0 22331.0 22144 22356.0 22356.0 22045 22398.5 22306.5 22095 22423.5 22331.5 22145 22356.5 22356.5 22046 22399.0 22307.0 22096 22424.0 22332.0 22146 22357.0 22357.0

22047 22399.5 22307.5 22097 22424.5 22332.5 22147 22357.5 22357.5 22048 22400.0 22308.0 22098 22425.0 22333.0 22148 22358.0 22358.0 22049 22400.5 22308.5 22099 22425.5 22333.5 22149 22358.5 22358.5 22050 22401.0 22309.0 22100 22426.0 22334.0 22150 22359.0 22359.0

A-15

22, 25/26 MHz BAND ITU NBDP (Telex) FREQUENCY TABLE

The following frequencies are factory programmed.

22 MHz TELEX 25/26 MHz TELEX 25/26 MHz TELEX

CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX CH NO. SHIP RX SHIP TX

22151 22359.5 22359.5 25001 26101.0 25173.0 25051 25198.0 25198.0 22152 22360.0 22360.0 25002 26101.5 25173.5 25052 25198.5 25198.5

22153 22360.5 22360.5 25003 26102.0 25174.0 25053 25199.0 25199.0 22154 22361.0 22361.0 25004 26102.5 25174.5 25054 25199.5 25199.5 22155 22361.5 22361.5 25005 26103.0 25175.0 25055 25200.0 25200.0 22156 22362.0 22362.0 25006 26103.5 25175.5 25056 25200.5 25200.5

22157 22362.5 22362.5 25007 26104.0 25176.0 25057 25201.0 25201.0 22158 22363.0 22363.0 25008 26104.5 25176.5 25058 25201.5 25201.5 22159 22363.5 22363.5 25009 26105.0 25177.0 25059 25202.0 25202.0 22160 22364.0 22364.0 25010 26105.5 25177.5 25060 25202.5 25202.5 22161 22364.5 22364.5 25011 26106.0 25178.0 25061 25203.0 25203.0

22162 22365.0 22365.0 25012 26106.5 25178.5 25062 25203.5 25203.5 22163 22365.5 22365.5 25013 26107.0 25179.0 25063 25204.0 25204.0 22164 22366.0 22366.0 25014 26107.5 25179.5 25064 25204.5 25204.5 22165 22366.5 22366.5 25015 26108.0 25180.0 25065 25205.0 25205.0 22166 22367.0 22367.0 25016 26108.5 25180.5 25066 25205.5 25205.5

22167 22367.5 22367.5 25017 26109.0 25181.0 25067 25206.0 25206.0 22168 22368.0 22368.0 25018 26109.5 25181.5 25068 25206.5 25206.5 22169 22368.5 22368.5 25019 26110.0 25182.0 25069 25207.0 25207.0 22170 22369.0 22369.0 25020 26110.5 25182.5 25070 25207.5 25207.5 22171 22369.5 22369.5 25021 26111.0 25183.0 25071 25208.0 25208.0

22172 22370.0 22370.0 25022 26111.5 25183.5 25072 26121.0 25208.5 22173 22370.5 22370.5 25023 26112.0 25184.0 25073 26121.5 25209.0 22174 22371.0 22371.0 25024 26112.5 25184.5 25074 26122.0 25209.5 22175 22371.5 22371.5 25025 26113.0 25185.0 22176 22372.0 22372.0 25026 26113.5 25185.5

22177 22372.5 22372.5 25027 26114.0 25186.0 22178 22373.0 22373.0 25028 26114.5 25186.5 22179 22373.5 22373.5 25029 26115.0 25187.0 22180 22374.0 22374.0 25030 26115.5 25187.5 22181 22374.5 22374.5 25031 26116.0 25188.0

22182 22375.0 22375.0 25032 26116.5 25188.5 22183 22375.5 22375.5 25033 26117.0 25189.0

25034 26117.5 25189.5 25035 26118.0 25190.0 25036 26118.5 25190.5

25037 26119.0 25191.0 25038 26119.5 25191.5 25039 26120.0 25192.0 25040 26120.5 25192.5 25041 25193.0 25193.0

25042 25193.5 25193.5 25043 25194.0 25194.0 25044 25194.5 25194.5 25045 25195.0 25195.0 25046 25195.5 25195.5

25047 25196.0 25196.0 25048 25196.5 25196.5 25049 25197.0 25197.0 25050 25197.5 25197.5

A-16

INDEX

2182 key 1-11

AGC 1-5 AM broadcasting stations 1-14 Antenna tuning 1-10

Backlighting 1-4

CLARI/3 key 1-13 Clarifier 1-13 Class of emission 1-4 Control description 1-2

Diagnostic test 4-2 Distress call 1-11 Dummy antenna 4-1

NBDP Terminal 2-1

Power on/off 1-4

Receiving 1-13 Remote Station 2-2 RF GAIN 1-13 RF gain 1-13 ROM version no. 4-3

S-meter 1-13 Scanning 1-15 Specifications iv SQL/5 key 1-4 Squelch 1-4 Station name 1-10 Sweep 1-17 System configuration 1-1 System settings 3-1

Error indication 5-3

Frequency selection

custom channels 1-7 direct frequency entry 1-6 ITU telephony channels 1-8 ITU Telex channels 1-9

Fuse replacement 5-3

Indications 1-3 Intercom 2-2

Keyboard test 4-3

LCD test 4-3 Loudspeaker on/off 1-4

Transmitter output 1-11 Transmitter test 4-1 Transmitting 1-10 Troubleshooting 5-1

User channels 3-3

VOLUME control 1-4

Weekly checks 4-1

Maintenance 4-4 Microphone usage 1-11 MIF commands 1-18

Index-1

Furuno FS-1503 User Manual 2

Specifications and Main Features

Frequently Asked Questions

User Manual

SAFETY INSTRUCTIONS

TABLE OF CONTENTS

INTRODUCTION

1. OPERATION

1.1 System Configuration

1.2 Transceiver Unit Description

1.3 Turning the Power On/Off

1.4 Adjusting the Backlighting

1.5 Turning the Loudspeaker On/Off

1.6 Turning the Squelch On/Off

1.7 Selecting Class of Emission, Turning AGC On/Off

1.8 Selecting Frequency

1.9 Displaying Station Name

1.10 Transmitting

1.11 Distress Call on 2182 kHz

1.12 Receiving

1.13 Frequency Scan

1.14 Frequency Sweep

1.15 MIF Commands

2. OPERATION OF OPTIONAL EQUIPMENT

2.1 Telex Communication

2.2 Remote Station RB-500 (requires optional Remote-B Board)

2.3 Intercom

3. CHANGING SYSTEM SETTINGS

3.1 System Setup

3.2 Customizing by User

3.3 Writing User Channels

4. MAINTENANCE

4.1 Weekly Checks

4.2 Diagnostic Test

4.3 LCD/Keyboard Test & ROM Version No. Confirmation

4.4 Maintenance

5. TROUBLESHOOTING

5.1 Troubleshooting List

5.3 Replacing Fuses

SPECIFICATIONS

APPENDIX

TELEX CHANNELS

INDEX
