Funai MSD724G User Manual

24 inch DVD TRIPLE COMBO
Owner's Manual
I
I
I
Owner’s Manual
MSD724G
FEATURES
• Auto Channel Programming
• Timer Recording 1 year 8 events programmable Daily/Weekly recording
• One Touch Recording
• Auto Clock Setting
• Screen Saver
• Auto Power On and Off
• Parental Lock
• Resume Play (DVD)
• Closed Caption Decoder
• Virtual Surround
SUPPLIED ACCESSORIES
This unit comes with the following accessories. Please confirm that all the accessories are included.
P Remote Control
(NF104UD)
P AA batteries x 2
PLEASE READ BEFORE USING THIS EQUIPMENT
P Owner's Manual
(1EMN21760)
IF YOU NEED ADDITIONAL ASSISTANCE FOR SET-UP OR OPERATING AFTER READING OWNER’S MANUAL, PLEASE CALL
http://www.funai-corp.com
TOLL FREE 1-800-605-8610 OR VISIT OUR WEB SITE AT
RECAUTIONS
P
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The caution marking is located on the rear of the cabinet.
MPORTANT SAFEGUARDS
I
1. Read instructions - All the safety and operating instructions
should be read before the appliance is operated.
2. Retain Instructions - The safety and operating instructions
should be retained for future reference.
3. Heed Warnings - All warnings on the appliance and in the
operating instructions should be adhered to.
4. Follow Instructions - All operating and use instructions
should be followed.
5.
Cleaning - Unplug the unit from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION: A product that is meant for uninterrupted ser­vice and, that for some specific reason, such as the possibili­ty of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.
6. Attachments - Do not use attachments not recommended
by the unit manufacturer as they may cause hazards.
7. Water and Moisture - Do not use this unit near water - for
example, near a bath tub, wash bowl, kitchen sink, or laun­dry tub, in a wet basement, or near a swimming pool, and the like.
8. Accessories - Do not place this unit on an
PORTABLE CART WARNING
unstable cart, stand, tripod, bracket, or table. The unit may fall, causing serious injury to someone, and serious damage to the appli­ance. Use only with a cart, stand, tripod, bracket, or table recommended by the manu-
S3126A
facturer, or sold with the unit. Any mounting of the appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn. Ameubles - Cet appareil ne doit être placé
SYMBOLE D'AVERTISSEMENT POUR
LES COMPOSANTES
APPAREIL ET MEUBLE A ROULETTES
que sur un meuble (avec ou sans roulettes) recommandé par le fabricant. Si vous l’in­stallez sur un meuble à roulettes, déplacez les deux ensembles avec précaution. Un
S3126A
arrêt brusque, l’utilisation d’une force excessive et des sur­faces irrégulières risquent de déstabiliser l’ensemble et de le renverser.
9. Ventilation - Slots and openings in the cabinet and the back
or bottom are provided for ventilation and to ensure reliable operation of the unit and to protect it from overheating, and
10. Power Sources - This unit should be operated only from the
11. Grounding or Polarization - This unit is equipped with a
12. Power-Cord Protection - Power-supply cords should be
13. Outdoor Antenna grounding - If an outside antenna or
these openings must not be blocked or covered. The open­ings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface.This unit should never be placed near or over a radiator or heat register. This unit should not be placed in a built-in installation such as a book­case or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.
type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, con­sult your appliance dealer or local power company. For the units intended to operate from battery power, or other sources, refer to the operating instructions.
polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your elec­trician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.
cable system is connected to the unit, be sure the antenna or cable system is grounded so as to provide some protec­tion against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conduc­tors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)
THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.
FIGURE A
EXAMPLE OF ANTENNA GROUNDING
AS PER NATIONAL ELECTRICAL CODE
ELECTRIC SERVICE EQUIPMENT
NEC - NATIONAL ELECTRICAL CODE
S2898A
GROUND CLAMP
ANTENNA LEAD IN WIRE
ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)
GROUNDING CONDUCTORS (NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)
2
EN
14. Lightning - For added protection for this unit receiver during
a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and dis­connect the antenna or cable system. This will prevent dam­age to the unit due to lightning and power-line surges.
15. Power Lines - An outside antenna system should not be
located in the vicinity of overhead power lines or other elec­tric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
16. Overloading - Do not overload wall outlets and extension
cords as this can result in a risk of fire or electric shock.
17. Object and Liquid Entry - Never push objects of any kind
into this unit through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the unit.
18. Servicing - Do not attempt to service this unit yourself as
opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified ser­vice personnel.
19. Damage Requiring Service - Unplug this unit from the wall
outlet and refer servicing to qualified service personnel under the following conditions:
a. When the power-supply cord or plug is damaged or frayed. b. If liquid has been spilled, or objects have fallen into the unit. c. If the unit has been exposed to rain or water. d. If the unit does not operate normally by following the operat-
ing instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the unit to its normal operation.
e. If the unit has been dropped or damaged in any way.
f. When the unit exhibits a distinct change in performance, this
indicates a need for service.
20. Replacement Parts - When replacement parts are required,
be sure the service technician has used replacement parts specified by the manufacturer that have the same character­istics as the original part. Unauthorized substitutions may result in fire, electric shock, injury to persons or other haz­ards.
21. Safety Check - Upon completion of any service or repairs to
this unit, ask the service technician to perform routine safety checks to determine that the unit is in proper operating con­dition.
22. Heat - This unit product should be situated away from heat
sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.
IMPORTANT COPYRIGHT INFORMATION
Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This product incorporates copyright protection technology that is protected by U.S. patents and other intellec­tual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
PRECAUTIONS/ IMPORTANT SAFEGUARDS
RADIO-TV INTERFERENCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer­ence in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio commu­nications. However, there is no guarantee that interference will not occur in a particular installation. If this equip­ment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment and receiver.
3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4) Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
FCC WARNING-
This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the owner’s manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.
EN
3
LASER SAFETY
This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED.
DO NOT STARE INTO BEAM.
LOCATION: INSIDE, NEAR THE DECK MECHANISM.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE
LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU'AU FOND.
Note to CATV system installer:
This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides guide­lines for proper grounding and in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.
LOCATION
For safe operation and satisfactory performance of the unit, keep the following in mind when selecting a place for its installation:
• Shield it from direct sunlight and keep it away from sources of intense heat.
• Avoid dusty or humid places.
• Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes at the top and bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.
• Install unit in a horizontal position.
• Avoid locations subject to strong vibration.
• Do not place the unit near strong magnetic fields.
• Avoid moving unit to locations where temperature differences are extreme.
• Be sure to remove disc and unplug the AC power cord from the outlet before carrying the unit.
TO AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE
• Do not handle the power cord with wet hands.
• Do not pull on the power cord when disconnecting it from an AC wall outlet. Grasp it by the plug.
• If, by accident, water is spilled on your unit, unplug the power cord immediately and take the unit to our Authorized Service Center for servicing.
• Do not put your fingers or objects into the unit disc loading tray.
• Do not place anything directly on top of the unit.
MOISTURE WARNING
• Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, or after heating a cold room or under conditions of high humidity. If you play a videotape or DVD in a moist unit, it may damage the tape or DVD and the unit. When the condensation occurs inside the unit, turn the unit on and leave it at least 2 hours to dry out.
NOTE ABOUT RECYCLING
Batteries should never be thrown away or incinerated but disposed of in accordance with your local regula­tions concerning chemical wastes.
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
The serial number of this product may be found on the back of the unit. No other unit has the same serial number as yours.You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.
Date of Purchase Dealer Purchase from Dealer Address
Dealer Phone No. Model No. Serial No.
4
EN
ABLE OF CONTENTS
TV/VCR
T
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . .2
TABLE OF CONTENTS . . . . . . . . . . . . . . . . . . . .5
SYMBOLS USED IN THIS MANUAL . . . . . . . . . . . .5
PREPARATION FOR USE . . . . . . . . . . . . . . . . . .6
ANTENNA/CABLE CONNECTIONS . . . . . . . . . . . .6
CONNECTING TO AN EXTERNAL DEVICE (FRONT) CONNECTING TO A DIGITAL AUDIO DEVICE (REAR) INSTALLING THE BATTERIES IN REMOTE CONTROL
OPERATING CONTROLS AND FUNCTIONS . . .8
. .6
.7 .7
TV/VCR SECTION
TV OPERATION AND SETTINGS . . . . . . . . . . . .9
WATCHING A TV PROGRAM . . . . . . . . . . . . . . . . .9
SLEEP TIMER / PICTURE CONTROL . . . . . . . . . . .9
CLOCK SET UP . . . . . . . . . . . . . . . . . . . . . . . . . .10
DAYLIGHT-SAVING TIME . . . . . . . . . . . . . . . . . . .11
ON-SCREEN MENU LANGUAGE . . . . . . . . . . . . .11
CLOSED CAPTION SYSTEM . . . . . . . . . . . . . . . .11
V-CHIP SET UP . . . . . . . . . . . . . . . . . . . . . . . . . .12
CHANNEL SET UP . . . . . . . . . . . . . . . . . . . . . . . .13
ON-SCREEN DISPLAY . . . . . . . . . . . . . . . . . . .14
STATUS DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . .14
CHECKING THE STATUS . . . . . . . . . . . . . . . . . . .14
MTS (Multi-channel Television Sound) SYSTEM . .14
VIDEO CASSETTE . . . . . . . . . . . . . . . . . . . . . .15
PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
BASIC PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . .15
SPECIAL PLAYBACK . . . . . . . . . . . . . . . . . . . .16
RENTAL PLAYBACK . . . . . . . . . . . . . . . . . . . . . . .16
AUTO REPEAT PLAYBACK . . . . . . . . . . . . . . . . . .16
SEARCH FUNCTION . . . . . . . . . . . . . . . . . . . .16
ZERO RETURN . . . . . . . . . . . . . . . . . . . . . . . . . . .16
PICTURE SEARCH . . . . . . . . . . . . . . . . . . . . . . . .17
TIME SEARCH . . . . . . . . . . . . . . . . . . . . . . . . . . .17
INDEX SEARCH . . . . . . . . . . . . . . . . . . . . . . . . . .17
RECORDING . . . . . . . . . . . . . . . . . . . . . . . . . . .18
NORMAL RECORDING . . . . . . . . . . . . . . . . . . . . .18
OTR (One Touch Recording) . . . . . . . . . . . . . . . . .18
AUTOMATIC TIMER RECORDING . . . . . . . . . . . .19
AUTO RETURN . . . . . . . . . . . . . . . . . . . . . . . . . . .21
AUTO REWIND-EJECT . . . . . . . . . . . . . . . . . . . . .21
COPYING A VIDEO CASSETTE (from another source)
.21
DVD SECTION
ABOUT THE DISCS . . . . . . . . . . . . . . . . . . . . .22
PLAYABLE DISCS . . . . . . . . . . . . . . . . . . . . . . . . .22
UNPLAYABLE DISCS . . . . . . . . . . . . . . . . . . . . . .22
PLAYING A DISC . . . . . . . . . . . . . . . . . . . . . . .23
BASIC PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . .23
DISC MENU / TITLE MENU . . . . . . . . . . . . . . . . . .23
SPECIAL PLAYBACK FUNCTIONS & SETTINGS . . .
FUNCTION TABLE . . . . . . . . . . . . . . . . . . . . . . . .24
AUDIO MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
SUBTITLE LANGUAGE . . . . . . . . . . . . . . . . . . . . .25
ANGLE MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
ZOOM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
BLACK LEVEL MENU . . . . . . . . . . . . . . . . . . . . . .26
V. S.S. (Virtual Surround System) . . . . . . . . . . . . . .26
SEARCH MENU . . . . . . . . . . . . . . . . . . . . . . . . . .26
REPEAT PLAYBACK . . . . . . . . . . . . . . . . . . . . . . .27
PROGRAMMED PLAYBACK . . . . . . . . . . . . . . . . .28
RANDOM PLAYBACK . . . . . . . . . . . . . . . . . . . . . .28
ON-SCREEN INFORMATION . . . . . . . . . . . . . .28
CHANGING THE DVD SET UP ITEMS . . . . . . .29
CUSTOM MENU . . . . . . . . . . . . . . . . . . . . . . . . . .29
INITIALIZE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
TROUBLESHOOTING GUIDE . . . . . . . . . . . . . .32
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . .34
APPENDIX . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
CABLE CHANNEL DESIGNATIONS . . . . . . . . . . .35
LANGUAGE CODE LIST . . . . . . . . . . . . . . . . . . . .35
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . .36
24
ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . .37
WARRANTY . . . . . . . . . . . . . . . . . .BACK COVER
IMPORTANT SAFEGUARDS / TABLE OF CONTENTS
SYMBOLS USED IN THIS MANUAL
The following symbols below appear in some headings and notes in this manual, with the following meanings.
TV/VCR
TV/VCR
operation (in the TV/VCR mode).
Description refers to playback of DVD video discs (in the DVD mode).
Description refers to TV/VCR
QUICK
Description refers to playback of audio CDs (in the DVD mode).
Description refers to the items to be set by the QUICK mode (in the DVD mode).
5
EN
REPARATION FOR USE
ANT.
AUDIO OUT COAXIAL
ANT.
Cable
TV signal
Antenna
or
IN
OUT
L
VOLUME
K
L
CHANNEL
K
I
REC/OTR
E –
SEARCH –
D
H
PREV NEXT
G
B
PLAYC
STOPA OPEN/CLOSE
E
REW
FWD
D
B
PLAY
HEADPHONE
VIDEO
L – AUDIO – R
I
I
DVD
VCR/TV
SOURCE
I
STANDBY-ON
C A
STOP/EJECT
HEADPHONE
VIDEO
L – AUDIO – R
ex. VCR or video camera
, etc.
P
ANTENNA/CABLE CONNECTIONS
Plug the incoming cable into the ANT. jack on the rear of the unit. If your cable service supplies you with a converter box or if you use a satellite system, connect the box with this unit as shown below.
Rear of the unit
Incoming cable from home Antenna / Cable Company (No Cable Box)
Cable Box or Satellite Box*
OR
*NOTE
(DO NOT DISCONNECT FROM BOX)
Some cable TV systems use scrambled signals and require a special converter to
Incoming cable from Cable Company or Satellite Antenna
NOTE:
Before plugging the antenna into the ANT. jack of the unit, check that the pin is not bent. If it is bent, straighten the pin as illustrated, then plug the pin into the ANT. jack of the unit.
Bent pin
Cable
Plug
(Needs to be
straightened)
(Straight pin)
receive these channels. Consult your local cable company.
For your safety and to avoid damages to the unit, unplug the antenna cable from the ANT. jack before moving the unit.
CONNECTING TO AN EXTERNAL DEVICE (FRONT)
When you watch a program recorded on another source (VCR or video camera), use the AUDIO/VIDEO input jacks on the front of the unit. Connect the Audio/Video output jacks of another source to the AUDIO L/R and VIDEO jacks of this unit.
Then use [SELECT] or [CH.KK/ LL] until "AUX" appears on the screen.
AUX
NOTE:
When you connect a monaural VCR (another source) to this unit, connect the Audio output jack of the monaural VCR (another source) to the AUDIO L jack of this unit.The audio will output in both L and R channel equally.
6
EN
To the Audio output jacks Audio Cable (commercially available)
(IN)
(OUT)
Front of the unit
(IN)
To the Video output jack
(OUT)
Video Cable (commercially available)
To Coaxial digital Audio input jack
Audio coaxial digital cable (commercially available)
Dolby Digital
decoder
AUDIO OUT
COAXIAL
or
MD deck, DAT deck, etc.
To Coaxial digital Audio input jack
ANT.
AUDIO OUT COAXIAL
CONNECTING TO A DIGITAL AUDIO DEVICE (REAR)
21 3
You can connect this unit to a digital audio device to enjoy the digital audio of DVD. Connect to an amplifier equipped with digital input jacks, such as MD deck or DAT deck. To play a DVD disc in a Dolby Digital Multi­channel surround format in this unit, connect to a Dolby Digital decoder. Use an audio coaxial digital cable (commercially available) for the audio connections.
(OUT)
(IN)
(IN)
To AUDIO OUT COAXIAL jack (DVD AUDIO OUT only)
NOTES:
• The audio source on a disc in a Dolby Digital Multi-channel surround format cannot be recorded as digital sound by an MD or DAT deck.
• Be sure to turn off the power to all devices in the system before connecting another device.
• Refer to the Owner's Manuals for the devices to be connected to the unit.
• To connect to a MD or DAT deck, set "DOLBY DIGITAL" to "PCM" for the audio output in the setup mode, and to con­nect to a Dolby Digital decoder, set to "BITSTREAM" (Refer to "AUDIO SETTING" on page 30). Playing a unit using incorrect settings may generate noise distortion and may also damage the speakers.
PREPARATION FOR USE
INSTALLING THE BATTERIES IN REMOTE CONTROL
1) Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.
2) Insert 2 “AA” penlight batteries into the battery compartment in the direction indicated by the polarity (+/-) markings.
3) Replace the cover.
[BATTERY PRECAUTIONS]
Be sure to follow the correct polarity as indicat-
• ed in the battery compartment. Reversed batter­ies may cause damage to the device.
Do not mix different types of batteries together
• (e.g. Alkaline and Carbon-Zinc) or old batteries with fresh ones.
If the device is not to be used for a long period
• of time, remove the batteries to prevent damage or injury from possible battery leakage.
Do not try to recharge batteries not intended to
• be recharged; they can overheat and rupture.
7
EN
PERATING CONTROLS AND FUNCTIONS
L
VOLUME
K
L
CHANNEL
K
I
REC/OTR
E –
SEARCH –
D
H
PREV NEXT
G
B
PLAY
C
STOPA OPEN/CLOSE
E
REW
FWD
D
B
PLAY
HEADPHONE
VIDEO
L – AUDIO – R
I
I
DVD
VCR/TV
SOURCE
I
STANDBY-ON
C A
STOP/EJECT
1 4 5 6 10
7
1514983 3 411 12 13 2120191817162
DVD buttons TV/VCR buttons
O
- FRONT PANEL -
- REMOTE CONTROL -
17 18 19 20 21
[REMOTE CONTROL] 22 23 24 25 26 27 28 29
30 31 32 33 34 35 36
22 23
24
25 26
27 28
29
30 31
32
33
STANDBY-ON
PICTURE/
SLEEP
1
7 8 9
DISPLAY
TV/VCR Audio
SPEED
REW
SLOW
PAUSE TITLE
CLEAR
MODE
2
5
0
PLAY
STOP
REC
SELECT
3
CH.
64
VOL.
+100
+10
SET-UP MUTE
FWD
DISC MENU
ENTER
RETURN
34 35
36
37
38 39
40 41
42 43
44 45
37
[FRONT PANEL]
yy
01
STANDBY-ON Button
02
VOLUME K/ LButtons
03
H PREV / NEXT G Buttons SEARCH E / D Buttons
04
PLAY B Button
05
STOP C Button
06
OPEN/CLOSE A Button
07
Disc loading tray
08
DVD Indicator
09
SOURCE Button
10
VCR/TV Indicator
11
CHANNEL K/ LButtons
12
Recording Indicator
13
REC/OTR Button
14
REW E Button
15
FWD D Button
16
STOP/EJECT C A Button
[TV/VCR P.15 / DVD P.23] [DVD P.23]
[TV/VCR P.9]
[TV/VCR P.18] [TV/VCR P.15] [TV/VCR P.15]
[TV/VCR P.9 / DVD P.23]
[P.9]
[DVD P.26]
[DVD P.23]
[DVD P.23]
[TV/VCR P.9]
[TV/VCR P.15]
38 39 40
41 42 43 44 45
NOTES:
• We do not recommend the use of universal remote con­trols as it may not control all the functions. Note that the code number given by universal remote controls may not program with this unit. For more details, contact the manufacturer of the universal remote control.
• Unless stated, all operations described are based on remote control use. Some operations can be carried out using the menu bar on the TV screen.
Remote sensor window HEADPHONE Jack VIDEO input Jack
[P.6]
AUDIO L/R input Jacks Cassette compartment
STANDBY-ON yyButton
[TV/VCR P.9 / DVD P.23]
PICTURE/SLEEP Button Number Buttons DISPLAY Button SPEED Button TV/VCR Audio Button PLAY B Button REW E Button SKIP H Button PAUSE F Button TITLE Button CLEAR Button MODE Button REC Button SELECT Button CH.K/ LButtons VOL.X/YButtons MUTE Button SET-UP Button FWD D Button SKIP G Button STOP C Button DISC MENU Button ENTER Button
K /L
/{ / B Buttons
RETURN Button
[TV/VCR P.9 / DVD P.26]
[TV/VCR P.14 / DVD P.28]
[TV/VCR P.18]
[TV/VCR P.14]
[TV/VCR P.15 / DVD P.23]
[TV/VCR P.15 / DVD P.23]
[DVD P.26]
[TV/VCR P.15 / DVD P.23]
[DVD P.23]
[TV/VCR P.9 / DVD P.26]
[DVD P.24]
[TV/VCR P.16]
[TV/VCR P.9]
[TV/VCR P.9]
[TV/VCR P.9]
[TV/VCR P.9]
[TV/VCR P.10 / DVD P.29]
[TV/VCR P.15 / DVD P.23]
[DVD P.26]
[TV/VCR P.15 / DVD P.23]
[DVD P.23]
[TV/VCR P.10 / DVD P.23]
[TV/VCR P.9 / DVD P.23]
[TV/VCR P.10 / DVD P.25]
[P.6]
[TV/VCR P.9]
8
EN
TV/VCR SECTION
TV/VCRTV/VCR
V OPERATION AND SETTINGS
T
WATCHING A TV PROGRAM
1 After antenna or cable connection is
completed, connect the power cord into a standard AC outlet.
2 Press [STANDBY-ON 3 Use [CH.
select your desired channel number.
To use the number buttons
•Single digit channels: (Ex. 02, 03, 04 and so on) Press [0] first to select a single digit channel.
•Two digit channels: (Ex. 12, 38, 95 ...) Press two digits directly.
•Three digit channels: (Ex. 115, 125 ...) Press
4 Use [VOL.
Press mute the sound. Press it again to restore the previous sound level.
NOTE:
•Even if you turn off the unit in the DVD mode, the unit will be in the TV/VCR mode when you turn it on again.
TO WATCH CABLE OR SATELLITE CHANNEL
If the unit is connected to a cable box or satellite box, use ing to the output channel setting of the device and select desired channel on that device.
TO WATCH EXTERNAL INPUT
When an external equipment is connected to the front AUDIO/ VIDEO input jacks, press [SELECT] or [CH. K / L] repeat- edly until "AUX" appears on the screen.
NOTE:
• If there is no signal input from the antenna terminal and no operation for 15 minutes, the unit will turn itself off automatically.
K/ L
[+100] first, then press the last two digits.
X/ Y
[MUTE] to instantly
[CH. K / L] to select CH3 or CH4 accord-
yy
] to turn on the unit.
] or the Number buttons to
] to adjust the volume.
VOLUME 20
C C C C C C C C C C C C C C C C
AUX
SLEEP TIMER / PICTURE CONTROL
You can set Sleep Timer and picture adjustment with
• The menu changes as described below every time
you press [PICTURE / SLEEP].
Sleep Timer
[PICTURE / SLEEP].
BRIGHT
TINTSHARPNESS
SLEEP TIMER SETTING
The Sleep Timer function is used to turn off the unit without pressing desired time.
[STANDBY-ON yy] after a
TV/VCRTV/VCR
CONTRAST
COLOR
1 Press [PICTURE / SLEEP] to
display the Sleep Timer menu.
SLEEP 0 MINUTE
2 Within 5 seconds, set your desired sleep time
using
[s / B].
[B]...Increase by 30 min. (Up to 120 min.) [s]...Decrease by 30 min.
NOTE:
•To cancel the Sleep Timer, use [CLEAR] or [s / B] to set the time to "0".
3 To confirm the remainder time to shutdown,
press
[PICTURE / SLEEP].
PICTURE CONTROL
1 Press [PICTURE / SLEEP]
repeatedly until desired control is displayed.
BRIGHT
PP PP PP PP PP PP PP CC PP PP PP PP PP PP PP
2 Use [s / B] to adjust to your desired level within
5 seconds.
BRIGHT CONTRAST COLOR TINT SHARPNESS
• Even if any power failure occurs, the unit will retain its memory for this feature.
to decrease brightness to decrease contrast to pale to purple to soft
to increase brightness to increase contrast to brilliant to green to clear
TV/VCR SECTION
+
OPERATING CONTROLS AND FUNCTIONS / TV OPERATION AND SETTINGS
9
EN
TV/VCR SECTION
TV OPERATION AND SETTINGS
CLOCK SET UP
Set the unit clock correctly for VCR timer recording. We suggest that you should set the clock manually when you first set up the unit, then set the auto clock setting to "ON" to cor­rect the time periodically.
NOTE:
• If you cannot receive a station with time signals, auto clock setting is not available. Use manual setting only.
MANUAL CLOCK SETTING
In the example below, the clock is to be set to:
DATE: May 5th, 2006 SETTING TIME: 5:40PM
1 Press [SET-UP].
Use
[KK/ LL] to point to
"SETTING CLOCK", then press
[ENTER].
2 Use [
• If there is no local PBS station in
3 Use [
KK/ LL
] to point to
"MANUAL CLOCK SET", then press
[ENTER].
your area or on your cable sys­tem, select "AUTO CLOCK" and press to turn "OFF" the function before this step.
KK/ LL
] to set your
desired month, day, year, hour and minute.
Use
[s / B] to move to
another item.
TV/VCRTV/VCR
- TV/VCR SETUP -
TIMER PROGRAMMING
B SETTING CLOCK
CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH
– SETTING CLOCK –
AUTO CLOCK [ON]
AUTO CLOCK CH SEARCH
AUTO CLOCK CH [ 02 ]
B MANUAL CLOCK SET
D.S.T. [OFF]
[ENTER]
– MANUAL CLOCK SET –
MONTH DAY YEAR
0 5 / 0 5 FRI 2 0 0 6
HOUR MINUTE
0 5 : 4 0 PM
4 Press [SET-UP].
Although seconds are not displayed, they begin counting from 00 when you press [SET-UP]. Use this feature to synchronize the clock with the correct time.
NOTE:
• When unplugging the AC cord or if there is a power failure for more than 3 seconds, you may have to reset the clock.
TO CHANGE CLOCK SETTING
5:40 PM
1 Follow steps 1 to 2 above. 2 Select the item you want to change using [ 3 Enter correct numbers using [
KK/ LL
BB
].
].
4 Press [SET-UP] to start the clock.
AUTOMATIC CLOCK SETTING
NOTES:
• If a cable converter box is being used, make sure it is turned on.
•You must use the remote control for the clock setting.
• If the unit is connected directly to a cable converter box or satellite box, the local PBS station must be selected on the cable box itself and the unit must be set to the output channel of the cable converter box or satellite box (usually channel 3 or 4), to enable to set up or correct the clock automatically.
1 Press [SET-UP].
[KK/ LL] select "SETTING
Using CLOCK", then press
[ENTER].
2 Press [ENTER] to select "ON".
3 Press [
• The unit begins searching for the station which contains the auto clock set signal. The search for a signal may take up to 20 seconds per channel.
LL
] to select
"AUTO CLOCK CH SEARCH". Then press
[ENTER].
- TV/VCR SETUP -
TIMER PROGRAMMING
B SETTING CLOCK
CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH
– SETTING CLOCK –
INDEX SEARCH
B AUTO CLOCK [ON]
AUTO CLOCK CH SEARCH
AUTO CLOCK CH [ 02 ]
MANUAL CLOCK SET
– SETTING CLOCK –
AUTO CLOCK [ON]
B AUTO CLOCK CH SEARCH
AUTO CLOCK CH [ 02 ]
MANUAL CLOCK SET
D.S.T. [OFF]
– AUTO CLOCK CH SEARCH –
08 10 13
• When the search has finished, "_ _" appears at the lower left of the screen.
_ _
NOTES:
• During AUTO CLOCK CH SEARCH, the picture may be distorted.
• If no number appears on the TV screen, there are no stations in your area which contain the Auto Clock signal. Auto Clock Setting is not possible. Please use Manual Clock Setting on this page.
4 Write down the numbers that appear on the
screen. They are the auto clock stations in your area.
5 Press [RETURN] to go back to
"SETTING CLOCK" menu. Press [LL] to select
"AUTO CLOCK CH". Use
[s / B] until you locate an
auto clock station number.
– SETTING CLOCK –
AUTO CLOCK [ON]
AUTO CLOCK CH SEARCH
B AUTO CLOCK CH [ 08 ]
MANUAL CLOCK SET
D.S.T. [OFF]
6 Press [SET-UP] to exit the menu.
NOTE:
• Once the unit is turned off, it will periodically check and set the correct date and time.
10
EN
DAYLIGHT-SAVING TIME
TV/VCRTV/VCR
Select this feature and the unit clock will automatically advance one hour in April, then reverse one hour in October.
First Sunday of April : At 2 AM, the clock imme­diately changes to 3 AM. Any timer programming you have set to occur between 2 AM and 3 AM will be canceled.
Last Sunday of October : At 2 AM, the clock immediately changes to 1 AM.
1 Press [SET-UP].
[KK/ LL] to point to
Use "SETTING CLOCK", then press
[ENTER].
2 Use [
KK/ LL
] to point to "D.S.T.".
- TV/VCR SETUP -
TIMER PROGRAMMING
B SETTING CLOCK
CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH
– SETTING CLOCK –
AUTO CLOCK [ON]
AUTO CLOCK CH SEARCH
AUTO CLOCK CH [ 02 ]
MANUAL CLOCK SET
B D.S.T. [ON]
3 Press [ENTER] to select "ON".
NOTE:
•To cancel the setting, select "OFF".
4 Press [SET-UP] to exit the menu.
ON-SCREEN MENU LANGUAGE
You can select the language of on-screen menu among English, Spanish and French.
1 Press [SET-UP].
Use
[KK/ LL] to point to
"LANGUAGE".
TV/VCRTV/VCR
- TV/VCR SETUP -
TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP
B LANGUAGE [ENGLISH]
CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH
2 Press [ENTER] repeatedly to select "ENGLISH",
"ESPAÑOL" or "FRANÇAIS".
3 Press [SET-UP] to exit the menu.
NOTES:
• This function effects only the language on the screen menu and not the audio source.
• If for some reason the menu is already in Spanish or French, press [SET-UP], using [KK/ LL] point to "IDIOMA [ESPAÑOL]" or "LANGAGE [FRANÇAIS]", then press guage, then press
[ENTER] repeatedly to select desired lan-
[SET-UP].
CLOSED CAPTION SYSTEM
You can view specially labeled (cc) TV programs, movies, news and pre-recorded tapes with either a dialogue caption or text display.
1 Press [SET-UP].
Use
[KK/ LL] to point to
"CAPTION".
2 Press [ENTER] repeatedly to
select your desired caption mode.
CAPTION mode: You can watch dramas, movies and news while captioning the dialogues and the contents of news.
TEXT mode: You can watch half screen text informa-
tion if you want.
*"CAPTION2" is usually used for a second language (if
available).
Press [SET-UP] to exit the menu.
3
NOTES:
•Even if any power failure, the unit will retain its mem­ory for this feature.
• Some programs are not broadcasted with closed captions. The unit is designed to provide error-free closed captions with high quality antenna, cable and VCR signals. Conversely, poor quality signals are likely to result in caption errors or no captions at all.
• Common signal conditions which may cause caption errors are listed below:
- Electric motor brush noise
- Weak snowy reception on TV screen
- Multiplex signal reception displaying picture ghosts or airplane flutter
• If the unit displays a black box on the TV screen, this means that the unit is set to the TEXT mode. To clear screen, select "CAP­TION1", "CAPTION2" or "OFF".
TO CANCEL THE CLOSED CAPTION SYSTEM
1 Press [SET-UP]. Use [
"CAPTION".
KK/ LL
] to point to
TV/VCRTV/VCR
- TV/VCR SETUP -
TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH]
B CAPTION [OFF]
ZERO RETURN TIME SEARCH
- TV/VCR SETUP -
INDEX SEARCH TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH]
B CAPTION [CAPTION1]
ZERO RETURN TIME SEARCH INDEX SEARCH
2 Press [ENTER] repeatedly to select "OFF".
3 Press [SET-UP] to exit the menu.
TV/VCR SECTION
TV OPERATION AND SETTINGS
11
EN
TV/VCR SECTION
TV OPERATION AND SETTINGS
V-CHIP SET UP
This feature enables parents to prevent their children from watching inappropriate material on TV. When you try to access a blocked program, “PROTECTED PROGRAM by ...” mes­sage appears on the TV screen.
NOTE:
•To change the rating, the TV must be turned to an unprotect­ed program. If the screen on the right is displayed, change the channel to a station that is not protected.
TV/VCRTV/VCR
PROTECTED PROGRAM
by TV-Y
A
TV RATING SET UP
4 Use [
KK/ LL
] to select a rating
that you wish to block. Press [ENTER] repeatedly to
set it to "BLOCK" or "VIEW".
B TV–Y [VIEW]
TV–Y7 ( ) [VIEW] TV–G [VIEW] TV–PG ( ) [VIEW] TV–14 ( ) [VIEW] TV–MA( ) [VIEW]
Selection Rating Category Explanations
TV-Y Appropriate for all children TV-Y7
Appropriate for children seven and older TV-G General Audience TV-PG Parental Guidance suggested TV-14 Unsuitable for children under 14 TV-MA Mature audience only
1 Press [SET-UP].
Use
[KK/ LL] to select
"V-CHIP SET UP", then press [ENTER].
2 Use the Number buttons to
enter the access code.
- TV/VCR SETUP -
TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP
B V-CHIP SET UP
LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH
ACCESS CODE
•For the first time set-up or in the event the unit has lost power, enter the default code of 0000.
3 Use [
KK/ LL
] to select "TV RATING", "MPAA
RATING" or "CHANGE CODE", then press [ENTER]. Refer to the pages below to set up each item.
– V-CHIP SET UP –
B TV RATING
MPAA RATING CHANGE CODE
P 12 P 13 P 13
A
B C
_ _ _ _
NOTES:
• When you select a rating and set it to "BLOCK", the higher ratings will be blocked automatically. The lower ratings will be avail­able for viewing.
TV–Y [VIEW] TV–Y7 ( ) [VIEW]
B TV–G [BLOCK]
TV–PG (DLSV) [BLOCK] TV–14 (DLSV) [BLOCK] TV–MA ( LSV) [BLOCK]
• When you set the lowest rating to "VIEW", all other ratings will be automatically avail­able for viewing.
5 The TV-Y7, TV-PG, TV-14 and
TV-MA ratings have the option of sub rating categories. Use
[KK/ LL] to select a rating
with sub-ratings, then press [ENTER] twice.
6 Use [
KK/ LL
] to select a sub-
rating, then press
[ENTER] to
set it to "BLOCK" or "VIEW".
NOTE:
•The blocked sub-ratings will appear next to the rating cate­gory in the "TV RATING" menu.
Selection Rating Category Explanations TV-Y7
FV Fantasy Violence
TV-PG, TV-14, TV-MA
D
Suggestive Dialog (TV-PG, TV-14 only) L Coarse Language S Sexual Situation V Violence
TV–Y [VIEW]
B TV–Y7 ( ) [VIEW]
TV–G [VIEW] TV–PG ( ) [VIEW] TV–14 ( ) [VIEW] TV–MA( ) [VIEW]
TV–PG [BLOCK]
B D[BLOCK]
L[BLOCK] S[BLOCK] V[BLOCK]
TV–Y [VIEW] TV–Y7 ( ) [VIEW] TV–G [VIEW]
B TV–PG (DLSV) [BLOCK]
TV–14 (DLSV) [BLOCK] TV–MA ( LSV) [BLOCK]
12
EN
7 Press [SET-UP] to exit the menu.
B
TV/VCRTV/VCR
MPAA RATING SET UP
4 Use [
KK/ LL
] to point to your
desired item, then press [ENTER] to select "BLOCK" or "VIEW".
G[VIEW] PG [VIEW] PG–13 [VIEW]
B R[BLOCK]
NC–17 [BLOCK] X[BLOCK]
C
CHANGE ACCESS CODE
4 Use the Number buttons to
enter your desired access code in the "NEW CODE", then enter the same code in the "CONFIRM CODE". When
Selection Rating Category Explanations
G General Audience PG Parental Guidance suggested. PG-13 Unsuitable for children under 13 R Restricted; under 17 requires acco-
mpanying parent or adult guardian NC-17 No one under 17 admitted X Mature audience only
5 Press [SET-UP] to exit the menu.
completed, the menu will return to "V-CHIP SET UP".
5 Press [SET-UP] to exit the menu.
NOTE:
•Your personal access code will be erased and will return to the default (0000) when a power failure occurs or when you turn off the power using a wall switch. If you forget the code, unplug the power cord for 10 seconds to restore the access code to 0000.
CHANNEL SET UP
Channel presetting is necessary at the start or in case you moved the TV to a different area.
NEW CODE
X X X X
CONFIRM CODE
_ _ _ _
TV/VCR SECTION
AUTO CHANNEL PROGRAMMING
1 Press [SET-UP].
[KK/ LL] to point to
Use "CHANNEL SET UP", then
press
[ENTER].
2 Use [
KK / LL
] to point to "AUTO
CH PROGRAMMING", then press
[ENTER].
The tuner scans and memorizes all the active channels in your area.
- TV/VCR SETUP -
TIMER PROGRAMMING SETTING CLOCK
B CHANNEL SET UP
USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH
– CHANNEL SET UP –
ADD / DELETE CH (CATV)
B AUTO CH PROGRAMMING
3 When the scanning is comple-
ted, the lowest memorized channel is displayed.
If "NO TV SIGNALS" appears on the TV screen, check the antenna connection and try again.
NOTES:
• The unit may recognize CATV channels to be TV channels if reception condition is poor. In this case, check the antenna connection and try "AUTO CH PROGRAMMING" again.
Auto channel programming is NOT necessary
when connected to a cable box or satellite box. Just select the channel for cable box or satellite input (ex. CH3 or CH4) on the unit, then select your desired channel on the cable box or satellite box.
NO TV SIGNALS
<EXAMPLE>
CH 15
ADDING/DELETING CHANNELS
You can add channels that was not memorized due to the bad reception status and also delete chan­nels you no longer receive or seldom watch.
1 Press [SET-UP].
Use
[KK/ LL] to point to
"CHANNEL SET UP", then press
[ENTER].
2 Use [
KK/ LL
] to point to
"ADD/DELETE CH", then press
[ENTER].
- TV/VCR SETUP -
TIMER PROGRAMMING SETTING CLOCK
B CHANNEL SET UP
USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH
– CHANNEL SET UP –
B ADD / DELETE CH (CATV)
AUTO CH PROGRAMMING
3 Use the Number buttons or
[CH.KK/ LL] to select your
desired channel number. (You can also use
[KK/ LL] to
ADD / DELETE
08
enter it.)
• Refer to page 9 on how to use
(Example: CH8)
the Number buttons.
4 Press [ENTER] repeatedly. The channel number
changes to time you press the button.
•To delete another channel, repeat steps 3 to 4.
red (deleted) or blue (added) every
5 Press [SET-UP] to exit the menu.
NOTE:
•To confirm that channel(s) has(have) been deleted or added, select it (them) using [CH.KK/ LL].
TV OPERATION AND SETTINGS
13
EN
TV/VCRTV/VCR
TV/VCR SECTION
N-SCREEN DISPLAY
O
STATUS DISPLAY
On screen display examples are shown below.
PLAY B 12:00AM
1
2
HIFI CH 123
STEREO/SAP
SP COUNT 0:00:00
3
1. VCR status
Displays the current VCR motion: PLAY / STOP / REC / OTR / PAUSE / FF / REW
2. VCR sound mode status (during playback)
Displays "HIFI" when the tape is recorded in Hi-Fi stereo mode.
3. Tape speed (during recording)
Displays the tape speed: SP / SLP
4. Clock
5. Channel number
(in TV mode) Displays the current channel number. "AUX" is displayed in external input mode.
6. MTS status (in TV mode)
Displays the current sound status of the broad­cast: STEREO / SAP
7. Tape counter (during playback or recording)
Shows the elapsed recording or playback time. (Not available for a blank tape or blank portions on the tape.) You can reset the counter by press­ing
[CLEAR].
4
5 6
7
CHECKING THE STATUS
While receiving a broadcast or playing a VHS tape, you can check the status dis­played on the screen by pressing
[DISPLAY].You
can also check the status of the preset MTS (Multi­Channel Television sound). The display will change as shown below each time you press
WHEN THE CLOSED CAPTION IS OFF
The display switches among VCR counter and clock.
Display OFF
COUNTER display CLOCK display
STOP
SPSPCOUNT 0:12:34
After 5 seconds
COUNT 0:12:34
WHEN THE CLOSED CAPTION IS ON
The display switches among VCR counter and clock.
Display OFF CLOCK/COUNTER
display
STOP
SP COUNT 0:12:34
5:40PM
CH2
*The display will disappear after 5 seconds
TV/VCRTV/VCR
[DISPLAY].
STOP
5:40PM
CH2
After 5 seconds
5:40PM
CH2
MTS (Multi-channel Television Sound) SYSTEM
MTS allows for reception of sound other than the main audio program.You can listen or record monaural audio sound, stereo sound or Secondary Audio Program (SAP).
WHEN RECEIVING AN MTS BROADCAST
Press [TV/VCR Audio] repeatedly to select a sound mode when you watch or record a TV program.
• The mode changes according to the broadcast among "STEREO",
"SAP" and "MONO" every time
you press the button.
NOTES:
• The initial setting is "STEREO". The unit records auto­matically MTS broadcasts in Hi-Fi stereo sound unless you select "SAP" beforehand.
• If you select "SAP" when second audio is not available, the unit will record in normal audio.
• This setting returns to the initial value when you turn off the unit or unplug the power cord.
14
EN
STEREO
TV/VCRTV/VCR
WHEN PLAYING CASSETTES
Press [TV/VCR Audio] repeatedly to select "HIFI" or "MONO".
• This setting is saved until the cassette is ejected.
NOTE:
• The initial setting is "HIFI". When you play non-HIFI tapes, the unit will play only in the monaural mode even if the setting is "HIFI".
WHEN IN THE EXTERNAL INPUT ("AUX")MODE
Any output mode setting does not affect the audio output and the current audio output mode does not appear on the TV screen.
IDEO CASSETTE
TV/VCRTV/VCR
V
This unit will operate with any cassette that has the
mark. For best results, we recommend the use of high-quality tapes. Do not use poor quality or damaged tapes.
SELECTING TAPE SPEEDS
Before recording, select the tape speed from : SP mode
(Standard Play) or SLP mode (Super Long
Play).You can also play a tape recorded in (Long Play).
Tape Speed Recording/Playback time
T120 T160T60Type of tape
2 hours 2-2/3 hours1 hourSP mode 6 hours 8 hours3 hoursSLP mode
LAYBACK
P
LP mode
BASIC PLAYBACK
1 Insert a pre-recorded tape so that the
unit turns on automatically (Auto Power On).
2 Select TV/VCR mode by pressing [SELECT].
NOTE:
• If the erase-prevention tab has been removed, the unit will change the VCR mode and starts playback automatically.
3 To start playback,
press
[PLAY BB].
NOTE:
•Even in the DVD mode, you can start the VCR play­back if you press [PLAY BB] on the front panel (of the TV/VCR side).
4 To stop the playback,
press
[STOP CC].
5 To rewind the tape,
press
[REWE].
To forward the tape, press
[FWDD].
To stop winding, press
[STOP CC].
PLAY
STOP
REW
FF
B
E
D
ERASE PREVENTION
Break off the tab on the back edge of the cassette to prevent accidental eras­ing of recording.
Ta b
Cover the hole with plastic tape to record on the tape again.
Plastic Tape
NOTES:
• In the TV/VCR mode, if the cassette without tab is insert­ed, playback will start automatically.
• If you press [REC/OTR] or [REC] when a cassette with­out tab is inserted, the unit will eject it automatically.
TRACKING ADJUSTMENT
•Tracking adjustment will be set automatically when
you start playback (Digital tracking function).
• If noise lines (black and white streaks) appear on
the playback picture, use streaks disappear (Manual tracking adjustment). This is available in Pause/Still/Slow mode, too.
•To release manual tracking mode, stop the tape
once and start playback again.
[CH.KK/ LL] until the
STILL PICTURE
• During playback, press [PAUSE F] to freeze the
picture. You can advance the picture frame by frame by pressing
•To release the Still mode, press
[PAUSE F] repeatedly.
[PLAY BB].
SLOW MOTION
• During playback, press [PAUSE F] then press
[FWDD].
•To release the Slow mode, press
NOTE:
• If the unit keeps the slow mode or still mode for more
than 5 minutes, it will automatically enter the stop mode.
[PLAY BB].
TV/VCR SECTION
ON-SCREEN DISPLAY / VIDEO CASSETTE / PLAYBACK
6 To eject the tape from the unit,
press
[STOP/EJECT C A]
on the front panel.
EJECT
A
15
EN
TV/VCRTV/VCR
TV/VCRTV/VCR
TV/VCRTV/VCR
TV/VCR SECTION
PECIAL PLAYBACK
S
RENTAL PLAYBACK
This function enables you to improve the picture quality when playing back worn cassettes such as rented tapes.
1 Press [SET-UP].
Use
[KK/ LL] to point to
"USER’S SET UP", then press [ENTER].
2 Use [
KK/ LL
] to point to
"RENTAL". Press
[ENTER] to select "ON".
- TV/VCR SETUP -
TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP
B USER’S SET UP
V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH
USER’S SET UP
B RENTAL [ON]
REPEAT PLAY [OFF] AUTO RETURN [OFF]
NOTE:
•To cancel the setting, select "OFF" at this step.
3 Press [SET-UP] to exit the menu.
4 Press [PLAY B] to start
playback.
NOTE:
• This setting will not change even if you turn off the unit.
RENTAL PLAY B
AUTO REPEAT PLAYBACK
This function allows you to repeat a tape indefinitely.
1 Press [SET-UP].
Use
[KK/ LL] to point to
"USER’S SET UP", then press [ENTER].
2 Use [
KK/ LL
] to point to "REPEAT PLAY".
Press
[ENTER] repeatedly
until your desired selection "ALL" or "BLANK" appears.
ALL: Repeat playback from the
beginning to the end of the tape.
- TV/VCR SETUP -
TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP
B USER’S SET UP
V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH
USER’S SET UP
RENTAL [OFF]
B REPEAT PLAY [ALL]
AUTO RETURN [OFF]
BLANK: Repeat playback from the beginning to a part,
which is blank for more than 10 seconds.
OFF: Cancel repeat playback.
3 Press [SET-UP] to exit the menu.
4 Press [PLAY B] to start the
Repeat Play.
NOTES:
• If the rental mode is set to "ON", “RENTAL PLAY B display has priority.
• This setting will not change even if you turn off the unit.
REPEAT PLAY B
S
ZERO RETURN
This function allows you to search easily a beginning point that you want to review by rewinding or fast forwarding.
NOTE:
• Zero Return WILL NOT work on a blank tape or a blank portion of a tape.
1 Rewind or forward the tape to the beginning
point at which you want to review.
2 Press [CLEAR] repeatedly to
set the counter to "0:00:00".
3 Press [PLAY B] for playback or [REC] for
recording. Press completed.
16
EN
EARCH FUNCTION
[STOP CC] when playback or recording is
COUNT 0:00:00
4 Press [SET-UP].
Use
[KK/ LL] to point to "ZERO
RETURN", then press [ENTER].
The unit will begin rewinding
- TV/VCR SETUP -
TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF]
B ZERO RETURN
TIME SEARCH INDEX SEARCH
and the counter will appear on the TV screen. The tape will automatically stop when the
counter returns to 0:00:00 (approx.).
TV/VCRTV/VCR
TV/VCRTV/VCR
Pro.1 Pro.2 Pro.3 Pro.4 Pro.5 Pro.6 Pro.7
4321123
End of
the tape
Beginning of
the tape
CURRENT PLAYBACK PROGRAM
INDEX MARK
PICTURE SEARCH
TV/VCRTV/VCR
This function is useful in finding or skipping over a particular scene on a tape. In this mode, the sound will be muted.
1 During playback, press [REW
EE
] or [FWD DD]
to view at a high speed (in forward/reverse).
2 Press [REW
EE
] or [FWD DD] again to view at
super high speed (in LP/SLP modes only).
NOTE:
•Tapes recorded in the SP or LP mode will normally display a noise bar on the TV screen and the picture may revert to black and white.
3 Press [PLAY
BB
] to return to normal playback.
TIME SEARCH
This function allows you to quickly advance the tape to your desired posi­tion simply by entering the exact amount of playback time you want to skip.
In the example below: To watch a program before/ after 2 hour 50 minutes from the present position, in either direction.
1 Press [SET-UP].
Use
[KK/ LL] to point to "TIME
SEARCH", then press [ENTER].
2 Use [
3 Use [
KK/ LL
] until your desired
time appears. To cancel the Time Search at this point, press
[SET-UP].
NOTE:
• Time Search can be set up to a maximum of 9 hours 50 minutes (9:50) by 10 minutes at a time.
ss/ BB
] to rewind or fast forward to the
specified point. The time counts down during the search. When
the counter reaches "0:00:00", the tape will start playback automatically.
- TV/VCR SETUP -
TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN
B TIME SEARCH
INDEX SEARCH
TIME SEARCH
2 : 50
INDEX SEARCH
This function allows you to index the starting point to make it easy to reach the point in either fast forward or rewind mode.
•Every time you start recording
, an index is marked
automatically. The index mark also works as the starting point of Timer recording and OTR.
• The index mark will not be recorded if
[PAUSE FF]
is used during recording.
• The time gap between making the index marks on the tape should be greater than 1 minute for SP recording, 2 minutes for LP recording and 3 min­utes for SLP recording.
• In some cases, the index mark at the beginning of video tape cannot be detected.
Example: You are watching program number 4 and
want to fast forward to program number 7. Skip three programs.
1 Press [SET-UP].
Use
[KK/ LL] to point to
"INDEX SEARCH", then press [ENTER].
2 Use [
KK/ LL
] until the number
of programs that you want to
- TV/VCR SETUP -
TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH
B INDEX SEARCH
INDEX SEARCH
0 3
skip appears.
3 Use [
ss/ BB
]. The unit begins rewinding or fast
forwarding to the beginning of desired program.
4 When the search is completed, the unit will start
playback automatically.
• The numbers of Index Search can be set up to
20.
• This function is not available during recording.
TV/VCR SECTION
SPECIAL PLAYBACK / SEARCH FUNCTION
TO CANCEL DURING TIME SEARCH
Press [STOP/EJECT C A] on the unit or [STOP CC].
TO CANCEL DURING INDEX SEARCH
Press [STOP/EJECT C A] on the unit or [STOP CC].
17
EN
TV/VCRTV/VCR
TV/VCRTV/VCR
Time(s) Display Recording length
1 time (normal recording) 2 times 0:30 30 minutes 3 times 1:00 60 minutes
↓↓
17 times 8:00 480 minutes
TV/VCR SECTION
ECORDING
R
NOTES:
• Insert a cassette tape with its erase-prevention tab in place.
• This unit cannot record the contents from the built-in DVD.
•You can ONLY watch the same TV program that is being recorded.
NORMAL RECORDING
1 Use [CH.
buttons
be recorded.
NOTE:
• If the unit is connected to a cable box or satellite box, the unit must be on CH3 or CH4. Select the channel to be recorded on the cable box or satellite box.
KK/ LL
] or the Number
to select the channel to
CH 10
2 Press [SPEED] to select the
desired tape speed (SP/ SLP).
(Refer to "SELECTING TAPE SPEEDS" on page 15.)
3 Press [REC] to start recording.
4 Press [PAUSE
rarily stop recording unwanted scenes. Press
[PAUSE FF] again or
[REC] to resume recording.
NOTE:
• If the recording is paused for more than 5 minutes, the unit will automatically switch to the recording mode to prevent tape damage.
5 Press [STOP
FF
] to tempo-
CC
] to stop recording.
SP
REC
SP
PAUSE
SP
OTR (One Touch Recording)
This function enables you to start record­ing for specified length simply by press­ing
[REC/OTR] on the unit.
1 Use [CH.
select the channel to be recorded.
NOTE:
• If the unit is connected to a cable box or satellite box, the unit must be on CH3 or CH4. Select the channel to be recorded on the cable box or satellite box.
KK/ LL
] or the Number buttons to
2 Press [SPEED] to select the desired tape speed
(SP/SLP).
(Refer to "SELECTING TAPE SPEEDS" on page 15.)
3 Press [REC/OTR] on the unit
repeatedly until your desired length appears on the screen. The recording time will increase by 30 minutes up to 8 hours.
Recording starts immediately when you press [REC/OTR].
NOTE:
• If you press [REC/OTR] when "8:00" is displayed, the unit returns to the normal recording mode.
NOTES:
•Even if you press [STANDBY-ON yy] during OTR, the unit continues recording.
cannot start OTR with the remote control.
•You
• In the SLP mode, maximum recording time, assum­ing the tape starts at the beginning, is 8 hours using T-160 (or 6 hours using T-120).
• If the tape runs out before the end time, the unit will switch to the stop mode immediately, eject the tape and turn itself off.
•To show the remaining time of OTR, press on the remote control to display "OTR" on the TV screen. (It will show up momentarily then disappear.)
OTR (2 : 30)
SP
[DISPLAY]
18
EN
TO CANCEL OTR IN PROGRESS
Press [STOP/EJECT C A] on the unit or [STOP CC].
AUTOMATIC TIMER RECORDING
TV/VCRTV/VCR
You can set 8 programs to record on specific days, daily or weekly within 1 year period.
In the example below, the timer is being set to record:
DATE: July 3rd, 2006 SETTING TIME: from 7:30PM to 8:50PM CHANNEL: CH61 TAPE SPEED: SP
1 Press [SET-UP].
Use
[KK/ LL] to select
"TIMER PROGRAMMING", then press
NOTE:
• If you have not yet set the clock, "MANUAL CLOCK SET" menu appears. Set to the present time and date (refer to "MANUAL CLOCK SETTING" on page
10) then start setting the timer recording.
2 Use [
desired program position, then press
3 Use [
channel number appears, then press
NOTE:
•If the unit is connected to a cable box or satellite box, the unit must be on CH3 or CH4. Select the channel to be recorded on the cable box or satellite box.
[ENTER].
KK/ LL
] to select the
[BB].
KK/ LL
] until the desired
[BB].
- TV/VCR SETUP -
B TIMER PROGRAMMING
SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH
– TIMER PROGRAMMING –
CH DATE BEGIN END
- - -/- - - - - -:- - -:- - - -
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
– TIMER PROGRAMMING –
- - -/- - - - - -:- - -:- - - -
CH DATE BEGIN END
61 -/- - - - - -:- - -:- - - -
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
4 Set the starting date.
For once recording :
Press [KK] until the desired date appears. Then press
[BB].
For every day recording :
To record the same channel at the same time every day.
Press [LL] until "EVRY DAY" appears, then press
[BB].
For weekly recording :
To record the same channel at the same time every week.
Press [LL] until "EVRY" and your desired day of the week (Ex. Every Monday) appear, then press
[BB].
– TIMER PROGRAMMING –
CH DATE BEGIN END
61 7/03 MON -:- - -:- - - -
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
– TIMER PROGRAMMING –
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
CH DATE BEGIN END
61 EVRY DAY -:- - -:- - - -
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
– TIMER PROGRAMMING –
CH DATE BEGIN END
61 EVRY MON -:- - -:- - - -
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
5 Use [
KK/ LL
] to set the desired
begin/end hour and minute. Press
[BB] to move to next item.
6 Use [
KK/ LL
] until the desired
tape speed appears.
(Refer to "SELECTING TAPE SPEEDS" on page 15.)
– TIMER PROGRAMMING –
CH DATE BEGIN END
61 7/03 MON 7:30
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
– TIMER PROGRAMMING –
CH DATE BEGIN END
61 7/03 MON 7:30
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
P
P
M
8:50
M
8:50
7 Press [ENTER] to complete setting.
To set another program, repeat steps 2 to 7.
•To correct the program while setting, press
to go back one step and use [KK/ LL] to enter the correct numbers.
• Press
8 Press [STANDBY-ON
[SET-UP] to exit the menu.
yy
] to set automatic timer
recording. The recording indicator lights up.
NOTES:
You MUST turn off the unit to activate automatic
timer recording.
• If power is not turned off and you continue watching TV, "TIMER REC STANDBY" starts flashing on the TV screen 2 min­utes before the programmed start time.
• Make sure a cassette with erase-prevention tab is
inserted before turning off the unit. If the cassette does not have the tab, it will be ejected when you press [STANDBY-ON yy] to turn off.
TIMER REC STANDBY
9 At the programmed start time, the unit begins
recording.
NOTES:
• The recording starts without turning on the TV screen.
During recording, you can watch only currently
being recorded TV program or DVD playback.
Press [STANDBY-ON yy] and [SELECT] to select the desired mode.
• If the tape runs out before the end time, the recording stops immediately and the cassette will be ejected.
TO CONFIRM THE PROGRAM
1 Press [STANDBY-ON
(The Recording indicator turns off.)
yy
] to turn on the unit.
2 Press [SET-UP].
Use
[KK/ LL] to select "TIMER PROGRAMMING",
then press
[ENTER].
3 Confirm the details of programs that appear on
the TV screen.
4 Press [SET-UP] to exit the menu.
P
P
M
[ss]
M
- -
SP
TV/VCR SECTION
RECORDING
19
EN
TV/VCR SECTION
9:00AM 10:00AM 12:00PM
Program 1 10:00AM-11:00AM Program 2 9:00AM-10:00AM Program 3 9:30AM-12:00PM
11:00AM
Recording Sequence
*Recording period is SHADED
RECORDING
ABOUT OVERLAP OF PROGRAMS
When programs overlap, a program may not be recorded.
• The program with an earlier start has priority.
• Once the earliest program finishes, the overlapping pro­grams will begin recording in sequence.
• When the starting time is the same, the program set on the highest position in the program list has priority.
• The illustration below demonstrates the sequence of recordings.
TIMER PROGRAM EXTENSION
You can shift the time schedule of an automatic timer recording after programming or during recording.
1 Press [STANDBY-ON
yy
] to turn on the unit.
2 Press [SET-UP].
Use
[KK/ LL] to select "TIMER PROGRAMMING",
then press
[ENTER].
TO CORRECT A PROGRAM AFTERWARD
1 Press [STANDBY-ON
yy
] to turn on the unit.
2 Repeat steps 1 to 2 of "AUTOMATIC TIMER
RECORDING" on page 19.
3 Press [
BB
] (or press [ss] to go back one step)
until the part you want to correct begins flashing, then use Press
4 Press [STANDBY-ON
[KK/ LL] to make the changes.
[ENTER] to confirm.
yy
] to set automatic timer
recording.
TO CANCEL A PROGRAM
1 Press [STANDBY-ON
yy
] to turn on the unit.
2 If recording is in progress, press
[STOP/EJECT C A] on the unit.
3 Press [SET-UP].
Use
[KK/ LL] to select "TIMER PROGRAMMING",
then press
4 Use [
cancel and press
[ENTER].
KK/ LL
] to select a program you want to
[CLEAR].
5 Press [SET-UP] to exit the menu.
3 Press [REC] and use
[KK/ LL] to select the desired program.
4 Press [REC] repeatedly until your desired
– TIMER PROGRAMMING –
CH DATE BEGIN END
61 7/03 MON 7:30
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
begin/end time appears. Each press will shift forward the begin/end time for recording by 10 minutes.
NOTES:
• When the recording is already in progress, each press
will shift forward the end time only.
• If you want to cancel while setting, press
on the remote control. The recording time returns to the original time.
• When you shift forward the time schedule during
recording, the recording speed will be automatically set to the SLP mode.
5 Press [ENTER] to complete the setting. Then
press
[SET-UP] to exit the menu.
20
EN
P
M
8:50
[PAUSE FF]
P
M
SP
AUTO RETURN
TV/VCRTV/VCR
HEADPHONE
VIDEO
L – AUDIO – R
VIDEO
IN
OUT
AUDIO
IN
OUT
L
R
TV/VCRTV/VCR
TV/VCRTV/VCR
This function allows you to automatically search the beginning of the recorded program(s) after timer recording finishes.
1 Press [SET-UP].
Use
[KK/ LL] to point to
"USER’S SET UP", then press
2 Use [
"AUTO RETURN", then press [ENTER] to select "ON".
KK/ LL
[ENTER].
] to point to
- TV/VCR SETUP -
TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP
B USER’S SET UP
V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH
USER’S SET UP
RENTAL [OFF] REPEAT PLAY [OFF]
B AUTO RETURN [ON]
3 When all the timer recordings are completed, the
unit will rewind to the beginning of the recorded program(s) and then turn itself off.
NOTE:
• If you turn off the unit while rewinding the tape, the AUTO RETURN will stop.
TO CANCEL THE AUTO RETURN MODE
Repeat steps 1 to 2 and press [ENTER] to select "OFF".
• Even if any power failure occurs, the unit will retain its memory for this feature.
COPYING A VIDEO CASSETTE
(from another source)
You can make copies of video tapes for your enjoyment.
You CANNOT copy a DVD to a videotape.
WARNING: Unauthorized recordings of copyrighted video tapes may be an infringement of copyright laws.
Connect the unit and a source (for playing) device as shown the following diagram.
[This unit]
Audio/Video cables (not supplied)
[Ex: Jacks of source device]
1 Insert a pre-recorded video cassette into the
source device (VCR, camcorder, etc.).
TV/VCR SECTION
RECORDING
AUTO REWIND-EJECT
• When the end of a tape is reached during recording, playback, or fast­forward, the tape will automatically rewind to the beginning. After rewinding finishes, the unit will eject the tape and turn itself off.
• This function is operative when REPEAT PLAY is set to "OFF".
• The tape will not auto-rewind during timer record­ing or One Touch Recording (OTR).
2 Insert a video cassette to record into this unit’s
cassette compartment.
3 Press [SPEED] to select the
desired recording speed (SP/SLP).
4 Press [SELECT] until "AUX"
appears on the screen.
5 Press [REC/OTR] on the unit.
SP
AUX
III
6 Begin playback of the tape
in the source device.
NOTE:
•For best results during copying, use the front panel con­trols whenever possible. The remote control might affect the operation of the source device.
7 To stop copying, press [STOP/EJECT C A] on
the unit, then stop the playback on the source device.
21
EN
DVD-Video
* 1,2,4,6,
10,11
* 4,6,10
* 4,5,6,9,10
* 1,3,4,5,
6,7,9,10
DVD-RW
DVD-R
* 1,3,4,5,6,8,9,10
DVD+RW
DVD+R
Audio CD
CD-RW
CD-R
Digital
video
(MPEG2)
-
-
-
Digital
audio
Region
code
Mark (logo)
Playable
discs
Recorded
signals
Disc size
Disc types
12 cm
or
8 cm
12 cm
or
8 cm
Example
Title 1 Title 2
Chapter 1 Chapter 2 Chapter 1
Chapter 2
Chapter 3 Chapter 4
Example
Tra c k 1
Tra c k 2
Tra c k 5
Tra c k 6
Tra c k 3
Tra c k 4
or
is a trademark of DVD Format/Logo Licensing Corporation.
DVD SECTION
BOUT THE DISCS
A
PLAYABLE DISCS
If you cannot play back a disc which bears one of the marks above, check the following notes.
*1: This unit conforms to the NTSC color system. Discs recorded in other color systems such as PAL cannot
be played back. *2: Certain DVD-Video discs do not operate as described in this manual due to the intentions of the disc's producers. *3: Discs recorded in the VR (Video Recording) format cannot be played back. *4: Scratched or stained discs may not be played back. *5: Some discs cannot be played back because of incompatible recording conditions, characteristics of the
recorder or special properties of discs. *6: You can play back discs which bear the marks above. If you use nonstandardized discs, this unit may
not play them back. Even if they are played back, the sound or video quality will be compromised. *7: You may play back the unfinalized DVD-R/RW disc recorded in the video format on our brand's DVD
recorder. However, depending on the recording status of a disc, the disc may not be played back at all
or normally (the picture or sound may not be smooth, etc.). In this case, you need to finalize the disc
with the DVD recorder. Refer to the manual accompanying the DVD recorder. *8: Only the discs recorded in the video format and finalized can be played back.
Unfinalized discs cannot be played back. Depending on the recording status of a disc, the disc may not
be played back at all or normally (the picture or sound may not be smooth, etc.). *9: If there is too much recording space left on a disc (the used portion is less than 55mm across), it may
not play back properly.
*10: Do not glue paper or put stickers on to the disc. These may damage the disc and the unit may not read
it correctly.
*11: The number inside the symbol refers to a region of the world and a disc encoded in a specific region
format can only be played back on unit with the same region code.
UNPLAYABLE DISCS
NEVER play back the following discs. Otherwise, malfunction may result!
DVD-RAM / CD-i / Photo CD / Video CD / DVD-Audio / DVD with region codes other than 1 or ALL / DTS-CD / DVD-ROM for personal computers / CD-ROM for personal computers / MP3
The sound MAY NOT be heard: Super Audio CD
NOTE:
Only the sound recorded on the normal CD layer can be delivered. The sound recorded on the high density Super Audio CD layer cannot be delivered.
Any other discs without compatibility indications
22
EN
LAYING A DISC
Press 'PLAY' to play from here. To play the beginning, press 'STOP' first and then 'PLAY'.
Resume ON
P
BASIC PLAYBACK 1 Press [STANDBY-ON
on the unit.
2 Press [OPEN/CLOSE
yy
] to turn
AA
] on the unit.
3 Place the disc in the tray, with
the label facing up.
4 Press [PLAY
• The tray will close automatically and playback will start. When you play back a DVD which features a title menu, it may appear on the screen.
NOTES:
• Closing the disc tray manually or by pressing
[OPEN/CLOSE AA] also starts playback.
• With DVDs that use titles for playback program signals, playback may start from the second title or it may skip these titles.
5 To freeze the picture, press [PAUSE
playback.
NOTE:
• The sound will be muted in pause mode.
6 Press [STOP
playback temporarily.
• Press [PLAY BB] to resume
the playback.
• To cancel resume and stop the disc,
[STOP CC] again.
NOTES:
• The resume information stays on even if the unit is turned off.
•A "prohibited icon" may appear at the top-right on the TV screen during operation. This means that the operation is not available on the disc.
BB
].
CC
] to stop
FF
] during
FAST FORWARD / FAST REVERSE
• During playback, press and hold
[FWD DD] for fast forward or [REW EE] for fast reverse.
•Every time you press and hold the button, playback speeds up and the level of the speed appears on the screen.
NOTES:
•For DVDs, fast forward/reverse speed is different depending on the disc. Approximate speed is 1 (×2), 2 (×8), 3 (×20), 4 (×50) and 5 (×100).
•For Audio CDs approximate speed is 1 ( and 3 (×30).
• When you use buttons on the front panel, use
[SEARCH EE/ DD].
•To return to normal playback, press [PLAY BB].
×2), 2 (×8)
SLOW FORWARD / SLOW REVERSE
• During playback, press [PAUSE FF].
• Press and hold ward or
•Every time you press and hold the button, playback is slowed down and the level of the speed appears on the screen.
•To return to normal playback, press [PLAY BB].
[REW EE] for slow reverse.
NOTES:
• Slow forward / reverse speed varies with the disc. Approximate speed is 1 (1/16), 2 (1/8) and 3 (1/2).
• When you use buttons on the main unit, use
[SEARCH EE/ DD].
[FWD DD] for slow for-
DISC MENU / TITLE MENU
DVD may contain menus to navigate the disc and access special features.
D1
DVD SECTION
1
ABOUT THE DISCS / PLAYING A DISC
STEP BY STEP PLAYBACK
• During playback, press [PAUSE F].
You can advance the picture frame by frame by pressing
•To return to normal playback, press
[PAUSE F] repeatedly.
[PLAY BB].
1 Press [DISC MENU] or [TITLE].
• The DVD main menu / the title menu will appear.
• You can call up the menu even during playback.
2 Use [
KK/ LL
/ ss/ BB] to select an item, and press
[ENTER].
NOTES:
• If disc menu is available on the disc, audio language, subtitle options, chapters for the title and other options will appear for selection.
• Contents of menu and corresponding menu opera­tions may vary between discs. Refer to the manual accompanying the disc for details.
23
EN
(If available)
CD
Press [MODE]
AUDIO MENU (p25)
V. S.S. MENU (p26)
SEARCH MENU (p26)
REPEAT MENU (p27)
A-B REPEAT MENU (p27)
MENU OFF
AUDIO STREAM 1 ... AUDIO STREAM 8
ANGLE 1
....
ANGLE 8
OFF SUBTITLE STREAM 1
....
SUBTITLE STREAM 32
OFF ON
OFF 1 2
CHAPTER SEARCH TITLE SEARCH TIME SEARCH MARKER SEARCH
OFF CHAPTER TITLE
OFF A­A-B
OFF ZOOM 1 (×1.3) ZOOM 2 (×2.0) ZOOM 3 (×4.0)
STEREO L-ch R-ch
OFF 1 2
TRACK SEARCH TIME SEARCH MARKER SEARCH
OFF TRACK ALL
OFF A­A-B
DVD-V
Press [MODE]
AUDIO MENU (p25)
SUBTITLE MENU (p25)
ANGLE MENU (p25)
ZOOM MENU (p25)
BLACK LEVEL MENU (p26)
V. S.S. MENU (p26)
SEARCH MENU (p26)
REPEAT MENU (p27)
A-B REPEAT MENU (p27)
MENU OFF
DVD SECTION
PECIAL PLAYBACK FUNCTIONS & SETTINGS
S
FUNCTION TABLE
Setting menu switches as below every time you press See the reference page for how to set each menu. Some functions are not available in specific
modes, but this is not a malfunction.
[MODE] during playback.
24
EN
AUDIO MENU
1.ENG Dolby D 3/2.1ch 48k/3
STEREO (AUDIO)
1.ENG/6
(SUBTITLE)
1 / 8 (ANGLE)
AUDIO LANGUAGE
You can select audio language during DVD playback (if multi languages are available).
1 Press [MODE] during playback.
ANGLE MENU
Some DVD discs contain scenes which have been shot from various angles and you can change them as you like.
1 During playback, press
[MODE] repeatedly until ANGLE menu appears.
2 Use [
KK/ LL
] to select your desired language.
NOTES:
• This function may not work on some DVDs with mul­tiple audio languages. In this case, set it on the disc menu. (Operation varies depending on discs. Refer to the manual of the disc.)
• When "NOT AVAILABLE" appears on the TV screen, it means this function is not available on the disc.
3 Press [RETURN] to exit the menu.
STEREO SOUND MODE
You can select sound output mode.
1 Press [MODE] during
playback.
2 Use [
KK/ LL
] to select the sound mode.
• STEREO: stereo sound with left and right channels L-ch: left channel sound only R-ch: right channel sound only
3 Press [RETURN] to exit the menu.
SUBTITLE LANGUAGE
You can select a language for subtitles during DVD playback (if available).
1 During playback, press
[MODE] repeatedly until SUBTITLE menu appears.
2 Use [
KK/ LL
] to select your desired subtitle lan-
guage. To cancel subtitles, select "OFF".
3 Press [RETURN] to exit the menu.
NOTES:
• This function may not work on some DVDs with mul­tiple subtitle languages. In this case, set it on the disc menu. (Operation varies depending on discs. Refer to the manual of the disc.)
• If the selected language does not have 3-letter code, "---" will be displayed on the screen. (Refer to "LANGUAGE CODE LIST" on page 35.)
NOT AVAILABLE (AUDIO
2 Use [
KK/ LL
] to select your desired angle.
DVD SECTION
3 Press [RETURN] to exit the menu.
NOTE:
• If multiple angle function is not available, this menu does not appear on the screen.
)
ZOOM
The Zoom function allows you to enlarge the video image and to pan through the enlarged image.
1 During playback, press
OFF (ZOOM)
[MODE] repeatedly until ZOOM menu appears.
2 Press [ENTER] repeatedly to select the required
zoom factor.
OFF ZOOM1(×1.3) ZOOM2(×2.0) ZOOM3(×4.0)
ZOOM2OFF (ZOOM) ZOOM1 ZOOM3
SPECIAL PLAYBACK FUNCTIONS & SETTINGS
3 Use [
KK/ LL
/ ss/ BB] to move the zoomed picture
across the screen.
4 Press [RETURN] to exit.
• The zoomed position guide appears on the right corner of the TV screen in the zoom mode.
NOTES:
• Zooming function does not work while disc menu is shown.
• Zooming function is not available on some discs.
•It may take several seconds to slide the zoomed picture.
• The picture may be distorted if you operate other functions (ex. pause, fast forward etc.) repeatedly in the zoom mode.
•To cancel the zoom mode, repeat steps 1-2 and
[ENTER] until "OFF" appears.
press
25
EN
OFF (BLACK LEVEL)
OFF (V.S.S.)
DVD SECTION
_/2 (SEARCH)
SPECIAL PLAYBACK FUNCTIONS & SETTINGS
BLACK LEVEL MENU
You can adjust the Black Level to make the black parts of the picture brighter.
1 During playback, press
[MODE] repeatedly until BLACK LEVEL menu appears.
2 Use [
• ON: Makes the dark parts brighter.
KK/ LL
] to select "ON" or "OFF".
OFF: Shows the original picture as recorded.
(Initial setting)
3 Press [RETURN] to exit the menu.
NOTE:
• The setting will be saved even if the unit is turned off.
V.S.S. (Virtual Surround System)
You can enjoy surround-sound effect over two speakers on this unit.
1 During playback, press
[MODE] repeatedly until V. S.S. menu appears.
SEARCH MENU
You can begin playback at a specific track, title, chapter or from a specific point on a disc.
TRACK SEARCH
1 During playback, press [MODE]
repeatedly until SEARCH menu appears.
__/12 (SEARCH)
2 Within 60 seconds, use the Number buttons to
select the desired track number. Playback will start from the selected track.
NOTES:
•For single digit press [0] first, if the total track of the disc is 10 tracks or more.
• During playback or pause, you can also select tracks by skipping with PREV] on the front panel), or entering the desired track number with the Number buttons.
[H / G] (or [NEXT G ] or [H
3 Press [RETURN] to exit the menu.
CHAPTER SEARCH
1 During playback, press
[MODE] repeatedly until SEARCH menu appears.
_ _/21 (SEARCH)
2 Use [
• 1: Natural effect
KK/ LL
] to select the desired sound effect.
2: Emphasized effect OFF: No effect (Initial setting)
3 Press [RETURN] to exit the menu.
NOTES:
• When playing back 96kHz with Virtual Surround func­tion, the sound will be down sampled at 48kHz and output as digital audio.
(for CD play only)
• Virtual Surround System will be effective only when you set the sound mode to "STEREO". (Refer to "STEREO SOUND MODE" on page 25.)
2 Use the Number buttons to enter the desired
chapter number. Playback will start at the selected chapter.
• Press
• For single digit press
[CLEAR] to erase the incorrect input.
[0] first, if the total number of
chapters of the disc is 10 or more.
3 Press [RETURN] to exit the menu.
TITLE SEARCH
1 During playback, press [MODE] repeatedly until
SEARCH menu appears.
2 Use [
KK/ LL
] to display
TITLE SEARCH menu.
3 Use the Number buttons to enter the desired title
number. Playback will start at the selected title.
• Press
• For single digit press
[CLEAR] to erase the incorrect input.
[0] first, if the total number of
titles of the disc is 10 or more.
4 Press [RETURN] to exit the menu.
26
EN
TIME SEARCH
1 During playback, press [MODE] repeatedly until
SEARCH menu appears.
TOTAL
2 Use [
KK/ LL
] repeatedly to
display TIME SEARCH menu.
0:0 _:_ _ 0:04:23
REPEAT PLAYBACK
REPEAT TRACK
1 During playback, press
[MODE] repeatedly until REPEAT menu appears.
OFF (REPEAT)
3 Within 60 seconds, use the Number buttons to
enter a desired disc time. Playback will start at the specified time.
• Press
[CLEAR] to erase the incorrect input.
• When there is no need to enter a number, "0" appears automatically.
4 Press [RETURN] to exit.
MARKER SEARCH
You can set markers to memorize your favorite places on a disc.
1 During playback, press [MODE] repeatedly until
SEARCH menu appears.
2 Use [
3 Use [
KK/ LL
] repeatedly to
display MARKER SEARCH menu.
ss/ BB
] to select a marker number among
10
1 23456789
_ _ _ _:_ _:_ _
<Example: CD>
AC
1 to 10.
4 When the track (or title) reaches your desired
point, press
• The track (or title) number and elapsed playing time will appear on the TV screen.
[ENTER] to set a marker.
1 00:15:30
23456789
10
AC
5 You can play from the desired point by selecting
the marker number by using pressing
[ENTER].
[ss/ BB] and then
6 To clear a marker, select the marker number and
press
[CLEAR].To clear all markers at once,
select "AC" with
[ss/ BB] and press [ENTER].
NOTE:
• The following operation will also erase all markers: – Opening the disc tray – Turning off the power – Pressing
[SELECT]
7 Press [RETURN] to exit the menu.
2 Use [
KK/ LL
] to select your desired repeat mode.
• OFF: Repeat function off TRACK: Current track repeat ALL: All track repeat
NOTE:
• Repeat Track setting will be cleared when moving to other track.
3 Press [RETURN] to exit the menu.
REPEAT TITLE / CHAPTER
1 During playback, press
[MODE] repeatedly until REPEAT menu appears.
2 Use [
• OFF: Repeat function off
KK/ LL
] to select your desired repeat mode.
CHAPTER: Current chapter repeat TITLE: Current title repeat
NOTES:
• Repeat Title/Chapter is not available in some scenes.
• The REPEAT setting will be cleared when moving to other title or chapter.
OFF (REPEAT)
3 Press [RETURN] to exit the menu.
REPEAT A-B
OFF (A-B REPEAT)
1 Press [MODE] repeatedly until
A-B REPEAT menu appears.
2 Press [ENTER] at your desired
starting point (A). To cancel it, press
[CLEAR].
3 Press [ENTER] again at your
desired ending point (B). The repeat sequence begins.
ABBA
A- (A-B REPEAT)
ABBA
A-B (A-B REPEAT)
ABBA
4 To e xit the sequence, follow step1 and press
[ENTER] repeatedly until "OFF" appears and press
[RETURN] to exit the menu.
NOTES:
• The A-B repeat section can be set only within the cur­rent title (for DVDs) or current track (for Audio CDs).
• A-B repeat is not available with some scenes in DVD.
• A-B repeat playback is not available during other repeat playback.
DVD SECTION
SPECIAL PLAYBACK FUNCTIONS & SETTINGS
27
EN
PLAY
CD-DA TOTAL 0:45:55
RANDOM PROGRAM
- - no indication - -
RANDOM
9/49 0:00:00 -0:03:30
1/3 0:00:00 - 1:23:45
TL1
4/12 0:03:21 - 0:02:15
T
4/12 0:13:45 - 0:45:40
T
DVD SECTION
SPECIAL PLAYBACK FUNCTIONS & SETTINGS
PROGRAMMED PLAYBACK
You can determine the playing order of tracks.
1 In the stop mode, press [MODE].
• The PROGRAM screen appears.
2 Use [
KK/ LL
] to select a track,
then press
[ENTER].
NOTES:
• Up to 99 tracks can be entered. [CLEAR] to erase the
• Press
most recently entered track.
• If you enter more than 8 tracks, you can change pages
of the program list with
•To erase all tracks in the program at once, select "ALL
CLEAR" at the bottom of the track list.
[H / G].
PROGRAM
ENTER
PLAY
CLEAR
PROGRAM
ENTER
PLAY
CLEAR
CD-DA
1 3:40 2 4:30 3 5:00 4 3:10 5 5:10 6 1:30 7 2:30
1/4
1 3:40
CD-DA
1 3:40 1 3:40 2 4:30 3 5:00 4 3:10 5 5:10 6 1:30 7 2:30
1/4
6 1:30
TOTAL 0:00:00
1/1
TOTAL 0:14:25
3 5:00 10 1:30 12 2:45 6 1:30
1/1
3 Repeat step 2 until you select all the tracks you
want to play in the program.
4 Press [PLAY
BB
] to play the programmed tracks.
5 Press [STOP
CC
] to temporarily stop the playback.
You can resume the playback by pressing [PLAY BB]. Press
[STOPCC] twice to cancel the pro-
grammed playback.
NOTE:
• REPEAT setting is available during programmed playback. (Refer to "REPEAT TRACK" on page 27.)
RANDOM PLAYBACK
This function shuffles the playing order of tracks.
1 In the stop mode, press
[MODE] twice.
• The RANDOM screen appears.
2 Press [PLAY
NOTE:
• REPEAT setting is available during random playback. (Refer to "REPEAT TRACK" on page 27.)
3 Press [STOP
BB
] to start random playback.
CC
] to stop random playback.
N-SCREEN INFORMATION
O
You can check the information about the current disc by pressing [DISPLAY].
For DVD-Videos
1 Press [DISPLAY] during playback to show cur-
rent Chapter.
• The elapsed and remaining playing time of the current chapter will be displayed.
2 Press [DISPLAY] again to show current Title.
• The elapsed and remaining playing time of the current title will be displayed.
For Audio CDs
1 Press [DISPLAY] during playback to show the
current Track.
• The elapsed and remaining playing time of the current track will be displayed.
2 Press [DISPLAY] again to show current Total
Tr ac k .
• The elapsed and remaining playing time of the total track will be displayed.
Press [DISPLAY] again.
3
• The bit rate and the current repeat setting will be displayed.
• If you are playing a dual layered disc, the layer
4
28
EN
number will also be displayed. (L0: Layer 0 is playing. L1: Layer 1 is playing).
Press [DISPLAY] again to exit.
3 Press [DISPLAY] again to exit.
PROGRAM B
When in the PROGRAM mode or RANDOM mode.
HANGING THE DVD SET UP ITEMS
SETUP CUSTOM
LANGUAGE DISPLAY AUDIO PARENTAL OTHERS
C
You can change the DVD player’s settings by pressing [SET-UP] in DVD mode. The set up items are shown in the diagram below.
Press [SET-UP] twice
CUSTOMQUICK INITIALIZE
TV MODE
DOLBY DIGITAL
CUSTOM MENU
1 In the stop mode, press
[SET-UP] twice to display the DVD SETUP menu.
NOTES:
• Pressing [SET-UP] once will show TV/VCR SETUP menu partly.
• If the menu does not appear, press [STOP CC] first. Make sure the unit is in DVD mode before setting.
2 Use [
KK/ LL
[ENTER].
] to select "CUSTOM", then press
SETUP
QUICK CUSTOM INITIALIZE
SELECT:K/ EXIT:SETUP CANCEL:RETURN
LANGUAGE (p29)
DISPLAY (p30)
AUDIO (p30)
PARENTAL (p30)
OTHERS (p31)
L SET:ENTER
AUDIO SUBTITLE DISC MENU
TV MODE STILL MODE
DRC DOWN SAMPLING DOLBY DIGITAL
PARENTAL LEVEL PASSWORD CHANGE
ANGLE ICON AUTO POWER OFF
A
LANGUAGE SETTING
4 Use [
KK/ LL
] to select the
desired item, then press [ENTER].
SETUP LANGUAGE
AUDIO ORIGINAL
SUBTITLE
OFF
DISC MENU
ENGLISH
• AUDIO: Sets the audio language.
• SUBTITLE: Sets the subtitle language.
• DISC MENU: Sets the language for DVD menu.
5 Use [
KK/ LL
] to select your desired language
from the list, then press
[ENTER].
DVD SECTION
3 Use [
KK/ LL
] to select the
desired item, then press [ENTER]. Refer to the pages below for continuation to set up each item.
• LANGUAGE setting: P29
• DISPLAY setting: P30
• AUDIO setting: P30
• PARENTAL setting: P30
• OTHERS setting: P31
6 Press [SET-UP] to exit the menu.
NOTES:
• If your desired language is not on the list, select "OTHER" and enter the code of the language.
A
B C D E
(Refer to "LANGUAGE CODE LIST" on page 35.)
• This feature may not be valid due to default setting of the disc. In this case, press language. (Refer to "AUDIO MENU" on page 25.)
• If you select a language that is not supported by the disc, subtitle will be "OFF" automatically and the default language of the disc will be selected.
•To change the language for the on-screen menus, call up the TV/VCR SETUP menu by pressing [SET-UP] once and set the language. (Refer to "ON­SCREEN MENU LANGUAGE" on page 11.)
SETUP LANGUAGE
LANGUAGE CODE
Please enter a 4-digit language code.
[MODE] to select the
ON-SCREEN INFORMATION / CHANGING THE DVD SET UP ITEMS
29
EN
DRC DOWN SAMPLING DOLBY DIGITAL
SETUP AUDIO
ON ON BITSTREAM
DVD SECTION
SETUP PARENTAL
PASSWORD
Please enter a 4-digit password.
PARENTAL LEVEL ALL PASSWORD CHANGE
SETUP PARENTAL
CHANGING THE DVD SET UP ITEMS
B
DISPLAY SETTING
4 Use [
• TV MODE:
KK/ LL
then press
] to select an item, [ENTER].
QUICK
SETUP DISPLAY
TV MODE STILL MODE AUTO
4:3 LETTER BOX
You can change certain aspects of the DVD display screens and on-screen messages on the TV screen.
• 4:3 LETTER BOX (default): To show black bars on top and bottom of the screen.
SETUP DISPLAY
TV MODE
4:3 LETTER BOX 4:3 PAN & SCAN
• 4:3 PAN & SCAN: To show a full height picture with both sides trimmed.
NOTE:
•You can access this setting directly by selecting "QUICK" at step 2 on page 29.
• STILL MODE: This function allows you to adjust picture resolution and quality in the still mode.
•AUTO (default): Automatically select the best
SETUP DISPLAY
STILL MODE
AUTO FIELD FRAME
resolution setting (FRAME or FIELD) based on the data characteristics of the pictures.
• FIELD: Select "FIELD" when the pictures are still unstable even if "AUTO" is selected. FIELD stabilizes the pictures, although the picture quality may become coarse due to the limited amount of data.
• FRAME: Select "FRAME" to display relatively motionless pictures in higher resolution. FRAME improves the picture quality, although it may unstabilize the pictures due to simultaneous output of two field data.
5 Press [SET-UP] to exit the menu.
C
AUDIO SETTING
Choose the appropriate Audio settings for your equipment as it only affects during the playback of DVD discs.
4 Use [
KK/ LL
then press
] to select an item,
[ENTER] repeated-
ly until your desired setting appears.
• DRC (Dynamic Range Control):
• ON :To compress the range of soft to loud sound. (default)
• OFF : Output the original sound.
• DOWN SAMPLING:
• ON : Output in 48kHz. (default)
• OFF : Output the original sound.
NOTE:
• When playing a disc with copyright protection, the sound will be output at 48kHz even if the setting is "OFF".
• DOLBY DIGITAL:
QUICK
• BITSTREAM: Output a Dolby Digital signal. (default)
• PCM: Convert the Dolby Digital to PCM. (2 channel stereo)
NOTES:
•You can access this setting directly by selecting "QUICK" at step 2 on page 29.
• Set to "BITSTREAM" when the unit is connected to a Dolby Digital Decoder.
5 Press [SET-UP] to exit the menu.
D
PARENTAL SETTING
This feature allows you to set the rating level of your DVD discs. Playback will stop if the disc ratings exceed the level you set.
PARENTAL LEVEL
4 Enter four-digit password with
the Number buttons, then press
[ENTER].
NOTE:
• Enter any 4 digits (except for 4737) to set the pass­word for the first time, and record it for your memory.
30
EN
5 Use [
KK/ LL
] to select
"PARENTAL LEVEL", then press
[ENTER].
6 Use [
PARENTAL LEVEL
ALL
8 [ADULT] 7 [NC-17] 6 [R]
SETUP PARENTAL SETUP OTHERS
ANGLE ICON AUTO POWER OFFONON
SETUP
QUICK CUSTOM INITIALIZE
SETUP INITIALIZE
Initialize? NO YES
SETUP PARENTAL
PASSWORD Enter current password.
PARENTAL LEVEL ALL PASSWORD CHANGE
SETUP PARENTAL
SETUP PARENTAL
PASSWORD Please enter a 4-digit password.
Don't forget the password. Press 'ENTER' to activate password.
1
2 3 4
KK/ LL
] to select the
desired level, then press [ENTER].
7 Press [SET-UP] to exit the menu.
CONTROL LEVELS
ALL: All parental locks are canceled. 8 [ADULT]: DVD software of any grade
• (adult/general/children) can be played back.
7 to 2: Only DVD software intended for general use and children can be played back.
1 [KID SAFE]: Only DVD software intended for children can be played back, with those intended for adult and general use prohibited.
NOTE:
• With some DVDs, it may be difficult to find if they are compatible with parental lock. Be sure to check if the parental lock function operates in the way that you have set.
PASSWORD CHANGE
4 Enter current password with
the Number buttons, then press
[ENTER].
5 Use [
KK/ LL
] to select
"PASSWORD CHANGE", then press
[ENTER].
E
OTHERS SETTING
4 Use [
KK/ LL
then press
] to select an item, [ENTER] repeated-
ly to set the feature "ON" or "OFF".
• ANGLE ICON:
• ON: To show the angle icon when multiple camera angles are available during DVD playback. (default)
• OFF: To keep angle icon from the display.
• AUTO POWER OFF:
• ON: To activate screen saver program and turn off the unit automatically. (default)
• OFF: To deactivate Auto Power Off function.
NOTE:
• The screen saver program starts when there is no input from the unit for 5 minutes in the stop mode. After the screen saver program is activated for 15 minutes, the power is automatically turned off.
5 Press [SET-UP] to exit the menu.
INITIALIZE
This allows you to return all items of SETUP menu (except for
setting
and menu language) to their default settings.
PARENTAL
DVD SECTION
CHANGING THE DVD SET UP ITEMS
6 Enter four-digit password with
the Number buttons, then press
[ENTER].
7 Press [SET-UP] to exit the menu.
NOTE:
• If you forget the current password, enter 4737 first, then enter your new password. The former password will be cleared and parental level will be set to "ALL" (default).
1 In the stop mode, press [SET-UP] twice to
display the DVD SETUP menu.
2 Use [
KK/ LL
] to select
"INITIALIZE", then press [ENTER].
3 Use [
KK/ LL
then press
] to select "YES",
[ENTER] twice.
• To cancel the initialization, select "NO".
4 Press [SET-UP] to exit the menu.
31
EN
ROUBLESHOOTING GUIDE
T
If the unit does not perform properly when operated as instructed in this Owner’s Manual, check the following
guide for the possible remedy of a problem before contacting the Customer Service. Sometimes a perfor­mance problem can be easily solved by checking seemingly apparent but often overlooked possibilities. It could save your time and money.
SYMPTOM POSSIBLE REMEDY
General
No power
No operation by remote control
TV/VCR mode
Poor or no picture
Poor or no picture in playback
Poor or no sound
Cannot go into recording mode
Timer recording does not work or results in failure
Picture or color fades in and out when copying a videotape
Make sure the power plug is connected to an AC outlet.
• (In case of power failure) Check the breaker.
• Check if the batteries are weak or inserted incorrectly.
• Replace weak batteries and insert with their polarities (+/­signs) as indicated.
Aim the remote control at the remote sensor and operate
• within 23 feet (7 m) of the unit.
Remove all obstacles to clear the path of the infrared signal.
• Refer to the infrared signal.
• Select the correct mode to operate by pressing
The operable range from the unit is 10 feet (3m) within 15˚.
• Check if antenna or cable is connected properly.
• Check for the broken pin or wire of antenna cable.
• Check for source of reception disturbance.
[SELECT] to select the correct mode.
Press
• Perform channel scanning to memorize available TV channels.
Tr y another channel. If OK, then possible station problem.
• Adjust picture control (COLOR/CONTRAST/BRIGHT etc.).
• Check for magnetism from nearby appliances and try
• degaussing.
Adjust tracking control.
Tr y video head cleaning.
The videotape may be old or worn. Replace with new one.
• Adjust volume control using
Tr y another channel. If OK, then possible station problem.
• Check if the unit is in Still mode or Slow motion playback.
• If so, press
Make sure the cassette has an erase-prevention tab. If neces-
• sary, cover the hole with plastic tape.
Make sure the begin/end time is set correctly.
• Make sure the power is off to activate timer recording.
• Check if the unit’s clock is set to current time and date.
The program may contain copy protection signals that restricts
• copying.
The timer setting overlapped with another setting has priority.
• Check if the tape reached the end during recording.
• Check if the power failure during recording.
You cannot copy a copyrighted videotape. You are experienc-
• ing copy guard protection.
[PLAY B] to return to normal playback.
[VOL.X/ Y].
[SELECT].
PAG E
9
-­7
--
--
34
9
-­6
--
-­9
13
-­9
--
15 34
--
--
--
15
15
19 19 10
--
20
--
--
21
32
EN
SYMPTOM POSSIBLE REMEDY
TV/VCR mode DVD mode
Misspelling in captions
Te xt is not shown in its entirety or a delay occurs from what is being said
Captions scrambled with white boxes
No captions in a program which must contain closed caption
No captions in a pre-recorded videotape with indicated closed captions included
Black box in the TV screen No picture
Disc cannot be played
No sound
No DTS audio is output
Distorted picture
Audio or subtitle language does not match the setting
The camera angle cannot be changed
Audio or subtitle language can­not be changed
"Prohibited icon" appears on the screen
CD/DVD sound dropout No CD/DVD reproduction DVD picture poor
Error committed by the closed captioning production company.
• Possible in a live broadcast. Not in case of a prerecorded pro-
• gram.
A few seconds of delay is common for live broadcast.
• If a dialogue exceeds the display capacity (220 words per minute), selective editing is used so that the captions remain up-to-date with the current TV screen dialogue.
Caused by interferences of building, power lines, thunder-
• storms, etc.
The broadcast may use a time compression process to speed
• up the program. The decoder cannot read the compressed information and captions will be lost.
Possibility of a illegal copy or an erroneous copying process
• accidentally performed by the fabricator.
You are in TEXT mode. Select CAPTION mode or "OFF"
• This unit cannot play DVD-RAM/CD-i/Photo CD/Video CD/
• DVD with region codes other than "1" and "ALL".
Clean the disc.
• Place the disc correctly, with the label side up.
• Cancel the parental setting or change the control level.
• Correct the audio output settings.
• Confirm the power and audio settings of external audio com-
• ponent.
This unit does not support DTS audio. This is not a malfunc-
• tion.
During the playback of a 2-layered disc, pictures may stop for
• a moment. This happens while the 1st layer is being switched to the 2nd layer. This is not a malfunction.
This happens right after fast forwarding or rewinding.
• The selected language is not available for audio or subtitle on
• the DVD.
The DVD does not contain sequences recorded from different
• camera angles.
The DVD does not contain audio source or subtitles in the
• selected language.
That operation is not available by the unit or the disc.
Scratched disc. Replace with an unscratched one.
PAG E
--
--
--
--
--
--
11 22
34 23 30
30
--
--
--
-­29
25
29
23
--
TROUBLESHOOTING GUIDE
NOTE:
• Some functions are not available in specific modes, but this is not a malfunction. Read the description in this Owner’s Manual for details on correct operations.
• Playback from a desired track and random playback are not available during playback.
33
EN
AINTENANCE
M
DEGAUSSING
A degaussing circuit in this unit clears up color errors on the TV screen. Color errors occur when there is any excess magnetism close to the unit. This circuit is designed to operate once when the unit is first plugged in.
errors on the screen, unplug the unit for approx­imately 30 minutes.
the degaussing circuit will operate to clear errors. Ta ke this step any time the TV screen is accidental­ly magnetized or when you move the unit.
If you see minor color
When you plug the unit again,
AUTO HEAD CLEANING
•Automatically cleans video heads as you insert or remove a cassette, so you can see a clearer pic­ture.
• Playback picture may become blurred or interrupt­ed while the TV program reception is clear. Dirt accumulated on the video heads after long peri­ods of use or the usage of rental or worn tapes can cause this problem. If a streaky or snowy picture appears during play­back, the video heads in your unit may need to be cleaned.
1. Please visit your local Audio/Video store and pur-
chase a good quality VHS Video Head Cleaner.
2. If a Video Head Cleaner does not solve the prob-
lem, please call our help line mentioned on the front page, to locate an Authorized Service Center.
NOTES:
• Remember to read the instructions included with the video head cleaner before use.
• Clean video heads only when problems occur.
CABINET CLEANING
• Wipe the front panel and other exterior surfaces of the unit with a soft cloth immersed in lukewarm water and wrung dry.
•Never use a solvent or alcohol. Do not spray insecticide liquid near the unit. Such chemicals may cause damage and discoloration to the exposed surfaces.
SERVICING
• Should your unit become inoperative, do not try to correct the problem by yourself. There are no user-serviceable parts inside. Turn off, unplug the power cord and
tioned on the front page,
Service Center.
please call our help line men-
to locate an Authorized
IR SIGNAL CHECK
Use the AM radio or the digital camera to check if the remote control properly sends out the infrared signal. It will help to define the cause of malfunction.
Using AM radio
•Tune the AM radio to no broadcasting band. Press any button on remote control toward the radio. If the radio receives the signal from remote control properly, the sound will flutter.
Using digital camera (including built-in camera of cellular phone)
• Press and hold any button on remote control toward a digital camera. The remote control is working if you confirm infrared light through the digital camera.
IF THE LASER OPTICAL PICKUP UNIT IS
DIRTY
• If the unit still does not perform properly when it is operated, while referring to the relevant sections and to “TROUBLESHOOTING GUIDE” in this Owner’s Manual, the laser optical pickup unit may be dirty. Consult your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.
34
EN
DISC HANDLING
• Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.
• Always store the disc in its protective case when it is not used.
•To clean-off, use a soft cloth.
• Do not use a hard cloth since this will mar the disc.
• Wipe the disc in a straight line from center to edge.
•Never wipe with a circular motion.
• Do not use detergent or abrasive clean­ing agents.
PPENDIX
TV Display
TV Display
TV Display
TV Display
TV Display
TV Display
TV Display
TV Display
CATV channel
TV Display
W+80 W+81 W+82 W+83 W+84
W+65 W+66 W+67 W+68 W+69 W+70 W+71 W+72 W+73 W+74 W+75 W+76 W+77 W+78 W+79
W+55 W+56 W+57 W+58 A-4 A-3 A-2 A-1 W+59 W+60 W+61 W+62 W+63 W+64
W+40 W+41 W+42 W+43 W+44 W+45 W+46 W+47 W+48 W+49 W+50 W+51 W+52 W+53 W+54
W+25 W+26 W+27 W+28 W+29 W+30 W+31 W+32 W+33 W+34 W+35 W+36 W+37 W+38 W+39
W+10 W+11 W+12 W+13 W+14 W+15 W+16 W+17 W+18 W+19 W+20 W+21 W+22 W+23 W+24
A-5
RSTUVWW+1 W+2 W+3 W+4 W+5 W+6 W+7 W+8 W+9
CDE FGH I JK LMNOPQ
5A 2 3 4 5 6 7 8 9 10 11 12 13 A B
123456789101112131415
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
31 32 33 34 35 36 37 38 39 40 41 42 43 44 45
46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75
76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105
106 107 108 109 110 111 112 113 114 115 116 117 118 119 120
121 122 123 124 125
CATV channel
CATV channel
CATV channel
CATV channel
CATV channel
CATV channel
CATV channel
CATV channel
A
CABLE CHANNEL DESIGNATIONS
If you subscribe to cable TV, the channels are displayed as 1-125. Cable companies often designate channels with letters or letter-number combinations. Please check with your local cable company. The following is a chart of common cable channel designations.
LANGUAGE CODE LIST
Language Code
Abkhazian 4748 Afar 4747 Afrikaans 4752 Albanian 6563 Amharic 4759 Arabic 4764 Armenian 5471 Assamese 4765 Aymara 4771 Azerbaijani 4772 Bashkir 4847 Basque 5167 Bengali;Bangla 4860 Bhutani 5072 Bihari 4854 Bislama 4855 Breton 4864 Bulgarian 4853 Burmese 5971 Byelorussian 4851
Cambodian 5759 Catalan 4947 Chinese [CHI] 7254 Corsican 4961 Croatian 5464 Czech [CZE] 4965 Danish [DAN] 5047 Dutch [DUT] 6058 English [ENG] 5160 Esperanto 5161 Estonian 5166
Faroese 5261 Fiji 5256 Finnish [FIN] 5255 French [FRE] 5264 Frisian 5271 Galician 5358 Georgian 5747
A-B
C-E
F-H
Language Code
German [GER] 5051 Greek [GRE] 5158 Greenlandic 5758 Guarani 5360 Gujarati 5367 Hausa 5447 Hebrew 5569 Hindi 5455 Hungarian [HUN] 5467
Icelandic [ICE] 5565 Indonesian 5560 Interlingua 5547 Interlingue 5551 Inupiak 5557 Irish [IRI] 5347 Italian [ITA] 5566 Japanese [JPN] 5647 Javanese 5669 Kannada 5760 Kashmiri 5765 Kazakh 5757 Kinyarwanda 6469 Kirghiz 5771 Kirundi 6460 Korean [KOR] 5761 Kurdish 5767
Laothian 5861 Latin 5847 Latvian;Lettish 5868 Lingala 5860 Lithuanian 5866 Macedonian 5957 Malagasy 5953 Malay 5965 Malayalam 5958 Maltese 5966 Maori 5955 Marathi 5964 Moldavian 5961
I-K
L-N
Language Code
Mongolian 5960 Nauru 6047 Nepali 6051 Norwegian [NOR] 6061
Occitan 6149 Oriya 6164 Oromo(Afan) 6159 Panjabi 6247 Pashto;Pushto 6265 Persian 5247 Polish [POL] 6258 Por tuguese [POR] 6266 Quechua 6367 Rhaeto-Romance 6459 Romanian [RUM] 6461 Russian [RUS] 6467
Samoan 6559 Sangho 6553 Sanskrit 6547 Scots Gaelic 5350 Serbian 6564 Serbo-Croatian 6554 Sesotho 6566 Setswana 6660 Shona 6560 Sindhi 6550 Singhalese 6555 Siswat 6565 Slovak 6557 Slovenian 6558
O-R
S
If you choose a language that has a 3 letter language code, the code will be displayed every time you change the AUDIO or SUBTITLE language setting. If you choose any other languages, '---' will be displayed instead. (3 letter language code is written in bracket.)
Language Code
Somali 6561 Spanish [SPA] 5165 Sundanese 6567 Swahili 6569 Swedish [SWE] 6568
Tagalog 6658 Tajik 6653 Tamil 6647 Tatar 6666 Telugu 6651 Thai 6654 Tibetan 4861 Tigrinya 6655 Tonga 6661 Tsonga 6665 Tu rkish [TUR] 6664 Tu rkmen 6657 Tw i 6669
Ukrainian 6757 Urdu 6764 Uzbek 6772 Vietnamese 6855 Volapuk 6861 Welsh 4971 Wolof 6961 Xhosa 7054 Yiddish 5655 Yo r uba 7161 Zulu 7267
MAINTENANCE / APPENDIX
T
U-Z
35
EN
PECIFICATIONS
S
GENERAL SPECIFICATIONS
TV/VCR
CRT: 24 inch in-line gun,
90˚ deflection tube Television system: NTSC-M Closed caption system: §15.119/FCC Video Heads: Rotary four-head Tape width: 1/2 inch Tape speed
SP: 33.40 mm/sec. LP: 16.67 mm/sec. SLP: 11.12 mm/sec.
Tuner channel
TV VHF Low: #2~#6 TV VHF High: #7~#13 TV UHF: #14~#69 CATV VHF: 5A MID band: A5~A1, A~I SUPER band: J~W HYPER band: W+1~W+84
DVD
Product type: DVD Player Discs: Output signal format: NTSC color
DVD video, Audio CD
ELECTRICAL SPECIFICATIONS
Sound output:
2 speakers, 1W, 8 ohm
OTHER SPECIFICATIONS
Te r minals
Antenna input: VHF/UHF/CATV
75 ohm unbalanced
(F-type) Video input: RCA connector Audio L/R input: RCA connector Headphone: 1/8" stereo (3.5 mm) Coaxial digital audio output: One pin jack,
500 m Vpp (75 ohm)
Remote control: Digital encoded
infrared light system
Operating temperature: 5°C to 40°C
(41°F~104°F)
Power requirements: AC 120 V, 60 Hz Power consumption 120 W
(Maximum): Picture tube: 24" Dimensions: H: 22-11/16" (576 mm)
W
: 24-1/16" (612 mm)
D: 19" (482 mm)
Weight: 64.6 lbs. (29.3 kg)
× 1 × 2
•Designs and specifications are subject to change without notice.
• If there is a discrepancy between languages, the default language will be English.
36
EN
ANT.
AUDIO OUT COAXIAL
ANT.
IN
OUT
NDICE DE CONTENIDO
Í
PREPARATIVOS PARA EL USO . . . . . . . . . . . .37
CONEXIONES DE ANTENA/CABLE . . . . . . . . . . .37
CONEXIÓN A UN DISPOSITIVO EXTERNO
(FRONTAL) . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
CONEXIÓN A UN DISPOSITIVO DE AUDIO DIGITAL
(TRASERA) . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
SECCIÓN TV/VCR
FUNCIONAMIENTO Y AJUSTES DEL
TELEVISOR . . . . . . . . . . . . . . . . . . . . . . . . . .39
PARA VER UN PROGRAMA DE TELEVISIÓN . . . .39
AJUSTE DEL RELOJ . . . . . . . . . . . . . . . . . . . . . .39
AJUSTE DE CANAL . . . . . . . . . . . . . . . . . . . . . . .40
IDIOMA DE MENÚ DE PANTALLA . . . . . . . . . . . . .40
REPARATIVOS PARA EL USO
P
REPRODUCCIÓN . . . . . . . . . . . . . . . . . . . . . . .41
REPRODUCCIÓN BÁSICA . . . . . . . . . . . . . . . . . .41
GRABACIÓN . . . . . . . . . . . . . . . . . . . . . . . . . . .41
GRABACIÓN NORMAL . . . . . . . . . . . . . . . . . . . . .41
GRABACIÓN CON TEMPORIZADOR
AUTOMÁTICO . . . . . . . . . . . . . . . . . . . . . . . . . .42
SECCIÓN DVD
REPRODUCCIÓN BÁSICA . . . . . . . . . . . . . . . . . .43
MENÚ DE DISCO/MENÚ DE TÍTULO . . . . . . . . . .43
CONEXIONES DE ANTENA/CABLE
Enchufe el cable entrante en la toma ANT., en la parte trasera de la unidad. Si su servicio de cable le suministra una caja convertidora o si usted utiliza un sistema de satélite, conecte la caja con esta unidad, como se indica a continuación.
Cable
Señal de TV
Antena
o
Cable entrante desde antena casera/empresa de cable (sin caja de cable)
Caja de cable o caja de satélite*
O
Cable entrante desde empresa de cable o antena de satélite
NOTA:
Antes de enchufar la antena en la toma ANT. de la unidad, compruebe que la patilla no está doblada. Si está doblada, enderece la patilla como se indica en la ilustración y enchufe la patilla a la toma ANT. de la unidad.
Patilla doblada
Cable
Enchufe
(Debe ser
enderezada)
Parte trasera de la unidad
*NOTA
(NO DESCONECTAR DE LA CAJA)
Algunos sistemas de TV por cable utilizan señales cifradas y requieren un convertidor especial para recibir estos canales. Consulte con su empresa de cable local.
(Patilla recta)
ÍNDICE DE CONTENIDO / PREPARATIVOS PARA EL USO
Para su seguridad y para evitar daños en la unidad, desenchufe el cable de la antena de la toma ANT. antes de mover la unidad.
37
ES
L
VOLUME
K
L
CHANNEL
K
I
REC/OTR
E –
SEARCH –
D
H
PREV NEXT
G
B
PLAYC
STOPA OPEN/CLOSE
E
REW
FWD
D
B
PLAY
HEADPHONE
VIDEO
L – AUDIO – R
I
I
DVD
VCR/TV
SOURCE
I
STANDBY-ON
C A
STOP/EJECT
HEADPHONE
VIDEO
L – AUDIO – R
ANT.
AUDIO OUT COAXIAL
AUDIO OUT
COAXIAL
PREPARATIVOS PARA EL USO
CONEXIÓN A UN DISPOSITIVO EXTERNO (FRONTAL)
Cuando vea un programa grabado en otra fuente (videograbadora o videocámara), utilice las tomas de entrada AUDIO/VIDEO en la parte frontal de la unidad.
AUX
Conecte las tomas de salida de Audio/Video de otra fuente a las tomas AUDIO L/R y VIDEO de esta unidad.
A continuación, utilice [SELECT] o [CH.KK/ LL] hasta que aparezca "AUX" en la pantalla.
Por ejemplo, videograbadora o videocámara, etc.
(SALIDA)
(SALIDA)
A las tomas de salida de audio Cable de audio
(disponible en el mercado)
A la toma de salida de vídeo Cable de vídeo (disponible en el mercado)
(ENTRADA)
(ENTRADA)
Parte frontal de la unidad
NOTA:
Cuando conecte una VIDEOGRABADORA monoaural (otra fuente) a esta unidad, conecte la toma de salida de audio de la videograbadora monoaural (otra fuente) a la toma AUDIO L de esta unidad. El sonido saldrá igualmente por ambos canales L y R (izquierdo y derecho).
CONEXIÓN A UN DISPOSITIVO DE AUDIO DIGITAL (TRASERA)
Puede conectar esta unidad a un dispositivo de audio digital para disfrutar del sonido digital de DVD. Conecte a un amplificador equipado con tomas de entrada digital, tales como una platina MD o DAT. Para reproducir un disco DVD en un formato ambiental multicanal Dolby Digital en esta unidad, conéctela a un decodificador Dolby Digital. Utilice un cable coaxial digital de audio (disponible en el mercado) para las conexiones de audio.
A la toma AUDIO OUT COAXIAL (Solamente DVD AUDIO OUT)
Decodificador
Dolby Digital
Platina MD, platina DAT, etc.
A la toma de entrada de audio coaxial digital
(ENTRADA)
A la toma de entrada de audio coaxial digital
(SALIDA)
Cable de audio coaxial digital (disponible en el mercado)
o
(ENTRADA)
NOTAS:
• La fuente de audio de un disco en formato ambiental multicanal Dolby Digital no puede ser grabado como sonido digital por una platina MD o DAT.
• Asegúrese de apagar todos los dispositivos del sistema antes de conectar otro dispositivo.
• Consulte los manuales del usuario de los dispositivos que van a conectarse a la unidad.
• Para conectar a una platina MD o DAT, ajuste "DOLBY DIGITAL" en "PCM" para la salida de audio en el modo de ajuste, y para conectar a un decodificador Dolby Digital, ajuste en "BITSTREAM" (consulte "AUDIO SETTING" en página 30). Utilizar una unidad con unos ajustes incorrectos puede generar distorsión de ruido y puede asimismo dañar los altavoces.
38
ES
SECCIÓN TV/VCR
TV/VCRTV/VCR
TV/VCRTV/VCR
UNCIONAMIENTO Y AJUSTES DEL TELEVISOR
F
PARA VER UN PROGRAMA DE TELEVISIÓN
1 Después de finalizar la conexión de la
antena o del cable, conecte el cable de alimentación a una toma estándar de CA.
2 Presione [
STANDBY-ON
yy
] para encender la
unidad.
3 Utilice [CH.
K/ L
] o los botones numéricos
para seleccionar el número de canal deseado.
Para utilizar los botones numéricos
•Canales de un dígito: (Ej.: 02, 03, 04, etc.) Presione primero [0] para seleccionar un canal de un dígito.
•Canales de dos dígitos: (Ej.: 12, 38, 95 ...) Presione dos dígitos directamente.
•Canales de tres dígitos: (Ej. 115, 125 ...) Presione primero dos dígitos.
[+100], y luego presione los últimos
4 Utilice [VOL. X / Y] para ajustar el volumen.
Presione silenciar al instante el sonido. Presione de nuevo para restaurar el nivel de sonido anterior.
NOTA:
• Incluso aunque apague la unidad en el modo DVD, la unidad estará en el modo TV/VCR cuando vuelva a encenderse.
PARA VER UN CANAL DE CABLE O SATÉLITE
Si la unidad está conectada a una caja de cable o de satélite, utilice CA3 o CA4 según el ajuste de canal de salida del dispositivo y seleccionar el canal deseado en dicho dispositivo.
PARA VER UNA ENTRADA EXTERNA
Cuando un equipo externo esté conectado a las tomas de entrada frontales AUDIO/VIDEO, presione [SELECT] o [CH. K / L] repetidamente hasta que aparezca "AUX" en la pantalla.
NOTA:
• Si no hay entrada de señal del terminal de antena ni se hace funcionar durante 15 minutos, el TV se apagará automáticamente.
[MUTE] para
[CH. K / L] para seleccionar
VOLUMEN 20
C C C C C C C C C C C C C C C C
AUX
AJUSTE DEL RELOJ
Ajuste correctamente el reloj de la unidad para grabación con temporizador para videograbadora. Se sugiere ajustar el reloj manualmente cuando se configure por primera vez la unidad, y luego fijar el ajuste automático del reloj en "ON" para corregir la hora periódicamente.
NOTA:
• Si no pude recibir una emisora con las señales horarias, el ajuste automático del reloj no estará disponible. Utilice únicamente el ajuste manual.
AJUSTE MANUAL DEL RELOJ
En el siguiente ejemplo, el reloj está ajustado en:
FECHA: 5 de mayo de 2006 HORA DE AJUSTE: 5:40PM
1 Presione [SET-UP].
Utilice
[KK/ LL] para ir hasta
"AJUSTE RELOJ", y presione [ENTER].
2 Utilice [
"AJUSTE MANUAL RELOJ", y presione
• Si no hay ninguna emisora local PBS en su zona o en su sistema de cable, seleccione "RELOJ AUT." y presione [ENTER] para desactivar la función antes de este paso.
3 Utilice [
datos deseados de mes, día, año, hora y minuto.
Utilice otro elemento.
KK/ LL
] para ir hasta
[ENTER].
KK/ LL
] para ajustar los
[s / B] para pasar a
- TV/VCR PREP. -
COMO PROGRAMAR
B AJUSTE RELOJ
AJUSTE DE CANAL AJUSTE DE USER AJUSTE DE V-CHIP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH
– AJUSTE RELOJ –
RELOJ AUT. [ON]
BUSQ. AUTO RELOJ CA.
CAN. RELOJ AUT. [ 02 ]
B AJUSTE MANUAL RELOJ
HORA VER. [OFF]
– AJUSTE MANUAL RELOJ –
MES DIA AÑO
0 5 / 0 5 VIE 2 0 0 6
HORA MINUTO
0 5 : 4 0 PM
4 Presione [SET-UP].
Aunque los segundos no se muestran, se comienzan a contar desde 00 cuando se presiona
[SET-UP]. Utilice esta función para
sincronizar el reloj con la hora correcta.
NOTA:
• Cuando desenchufe el cable de CA o si hay un corte del suministro eléctrico durante más de 3 segundos, es posible que tenga que reajustar el reloj.
5:40 PM
SECCIÓN TV/VCR
FUNCIONAMIENTO Y AJUSTES DEL TELEVISOR
39
ES
TV/VCRTV/VCR
TV/VCRTV/VCR
SECCIÓN TV/VCR
FUNCIONAMIENTO Y AJUSTES DEL TELEVISOR
AJUSTE DE CANAL
Es necesario preseleccionar el canal al principio o en caso de haber movido el televisor a una zona distinta.
AUTOPROGRAMACIÓN DEL CANAL
1 Presione [SET-UP].
[KK/ LL] para ir hasta
Utilice "AJUSTE DE CANAL", y presione
2 Utilice [
"AUTOPROGRAMACIÓN DE CA.", y presione
El sintonizador explora y memoriza todos los canales activos de su zona.
[ENTER].
KK / LL
] para ir hasta
[ENTER].
- TV/VCR PREP. -
COMO PROGRAMAR AJUSTE RELOJ
B AJUSTE DE CANAL
AJUSTE DE USER AJUSTE DE V-CHIP IDIOMA [ TÍTULO [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH
– AJUSTE DE CANAL –
AGREGAR / BORRAR (CATV)
B
AUTOPROGRAMACIÓN DE CA.
3 Cuando la exploración ha
finalizado, se muestra el canal memorizado más bajo.
Si en la pantalla del televisor aparece "NO HAY SEÑAL DE TV", compruebe la conexión de la antena y vuelva a intentar.
NOTAS:
• La unidad puede reconocer canales de CATV como canales de TV si el estado de la recepción es deficiente. En tal caso, compruebe la conexión de la antena y vuelva a intentar "AUTOPROGRAMACIÓN DE CA.".
La autoprogramación del canal NO es necesaria
cuando está conectado a una caja de cable o de satélite. Simplemente seleccione el canal para entrada de caja de cable o de satélite (ej. CA 3 o CA 4) en la unidad, y seleccione el canal deseado en la caja de cable o de satélite.
<EJEMPLO>
NO HAY SEÑAL DE TV
ESPAÑOL
]
CA 15
IDIOMA DE MENÚ DE PANTALLA
Puede seleccionar el idioma del menú de pantalla entre inglés, español y francés.
1 Presione [SET-UP].
Utilice
[KK/ LL] para ir hasta
"IDIOMA".
- TV/VCR PREP. -
COMO PROGRAMAR AJUSTE RELOJ AJUSTE DE CANAL AJUSTE DE USER AJUSTE DE V-CHIP
ESPAÑOL
B IDIOMA [
TÍTULO [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH
2 Presione [ENTER] repetidamente para
seleccionar "ENGLISH", "ESPAÑOL" o "FRANÇAIS".
3 Presione [SET-UP] para salir del menú.
NOTAS:
• Esta función afecta solamente al idioma del menú de pantalla y no a la fuente de sonido.
• Si por alguna razón el menú ya está en inglés o en francés, presione [SET-UP] y mediante [KK/ LL] vaya a "LANGUAGE [ENGLISH]" o "LANGAGE [FRANÇAIS]", y presione [ENTER] repetidamente para seleccionar el idioma deseado, y presione [SET-UP].
]
40
ES
TV/VCRTV/VCR
TV/VCRTV/VCR
EPRODUCCIÓN
R
RABACIÓN
G
REPRODUCCIÓN BÁSICA
1 Inserte una cinta pregrabada para
2 Seleccione el modo TV/VCR
3 Para iniciar la reproducción,
4
5
6
AJUSTE DE SEGUIMIENTO
El ajuste de seguimiento se establecerá automáticamente al iniciar la reproducción (función de seguimiento digital).
Si aparecen líneas de ruido (rayas negras y blancas) en la imagen de reproducción, utilice desaparezcan (ajuste de seguimiento manual). Esto también está disponible en el modo Pausa/Imagen fija/Cámara lenta.
Para desactivar el modo de seguimiento manual, pare la cinta una vez e inicie de nuevo la reproducción.
IMAGEN FIJA
• Durante la reproducción, presione [PAUSE F]
para congelar la imagen. Puede avanzar la imagen fotograma a fotograma presionando repetidamente
Para desactivar el modo de imagen fija, presione [PLAY BB].
CÁMARA LENTA
• Durante la reproducción, presione [PAUSE F] y, a
continuación presione
Para desactivar el modo de cámara lenta, presione [PLAY BB].
NOTA:
Si la unidad se mantiene en el modo cámara lenta o imagen fija durante más de 5 minutos, entrará automáticamente en el modo de parada.
encender la unidad automáticamente (Auto Power On/Actividad automática).
presionando
NOTA:
Si se ha quitado la lengüeta de protección contra borrado, la unidad cambiará en el modo VCR y empezará la reproducción automáticamente.
presione
NOTA:
Incluso en el modo DVD, puede iniciar la reproducción en videograbadora si presiona [PLAY BB] en el panel frontal (del lateral de TV/VCR).
Para interrumpir la reproducción, presione
Para rebobinar la cinta, presione [REWE]. Para hacer avanzar la cinta, presione Para interrumpir el movimiento de la cinta, presione
Para expulsar la cinta de la unidad, presione panel frontal.
[SELECT].
[PLAY BB].
[STOP CC].
[FWDD].
[STOP CC].
[STOP/EJECT
B
REPRODUCIR
PARAR
E
REBOBINAR
D
AV RAPIDO
A
EXPULSAR
C A
] en el
[CH.KK/ LL] hasta que las rayas
[PAUSE F].
[FWDD ].
NOTAS:
• Inserte una cinta de casete con la lengüeta de protección contra borrado sin quitar.
• Esta unidad no puede grabar el contenido del DVD incorporado.
• SOLAMENTE podrá ver el mismo programa de televisión que se esté grabando.
GRABACIÓN NORMAL
1 Utilice [CH.
botones numéricos
seleccionar el canal donde se va a grabar.
NOTA:
• Si la unidad está conectada a una caja de cable o de satélite, deberá estar en CA3 o CA4. Seleccione en la caja de cable o de satélite el canal donde se va a grabar.
KK/ LL
] o los
para
2 Presione [SPEED] para
seleccionar la velocidad de cinta deseada (SP/SLP). (Consulte "SELECTING TAPE SPEEDS" en página 15.)
SP
3 Presione [REC] para iniciar la
grabación.
4 Presione [PAUSE
interrumpir temporalmente la grabación de escenas no deseadas. Presione nuevo o la grabación.
NOTA:
• Si la grabación se mantiene en pausa durante más de 5 minutos, la unidad pasará automáticamente al modo de grabación para que la cinta no sufra daños.
[PAUSE FF] de
[REC] para reanudar
5 Presione [STOP
grabación.
FF
] para
CC
] para interrumpir la
GRABAR
SP
PAUSA
SP
CA 10
SECCIÓN TV/VCR
REPRODUCCIÓN / GRABACIÓN
41
ES
TV/VCRTV/VCR
SECCIÓN TV/VCR
GRABACIÓN
GRABACIÓN CON TEMPORIZADOR AUTOMÁTICO
Puede ajustar ocho programas para grabar en días concretos, diariamente o semanalmente, dentro de un periodo de un año.
En el siguiente ejemplo, el temporizador está ajustado para grabar:
FECHA: 3 de julio de 2006 HORA DE AJUSTE: de7:30PM a 8:50PM CANAL: CA61 VELOCIDAD DE CINTA: SP
1 Presione [SET-UP].
Utilice "COMO PROGRAMAR", y presione
NOTA:
• Si todavía no ha ajustado el reloj, aparece el menú
2 Utilice [
la posición del programa deseado y presione
3 Utilice [
aparezca el número del canal deseado y presione
NOTA:
4 Ajuste la fecha de inicio.
Para una única grabación :
Presione [KK] hasta que aparezca la fecha deseada. A continuación, presione
Para una grabación cada día
Para grabar el mismo canal a la misma hora cada día.
Presione [LL] hasta que aparezca "CADA DIA", y presione
Para una grabación semanal
Para grabar el mismo canal a la misma hora cada semana.
Presione [LL] hasta que aparezca "CADA" y su día deseado de la semana (por ejemplo, "Cada lunes"), y presione
42
ES
- TV/VCR PREP. -
B COMO PROGRAMAR
[KK/ LL] para seleccionar
[ENTER].
AJUSTE RELOJ AJUSTE DE CANAL AJUSTE DE USER AJUSTE DE V-CHIP IDIOMA [ESPAÑOL] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH
"AJUSTE MANUAL RELOJ". Ajuste la hora y la fecha actuales (consulte "AJUSTE MANUAL DEL RELOJ" en página 39) e inicie el ajuste de la grabación con temporizador.
KK/ LL
] para seleccionar
[BB].
KK/ LL
] hasta que
[BB].
Si la unidad está conectada a una caja de cable o de
– COMO PROGRAMAR –
CA FECHA IN ICIO FINAL
- - -/- - - - - -:- - -:- - - -
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
– COMO PROGRAMAR –
CA FECHA IN ICIO FINAL
61 -/- - - - - -:- - -:- - - -
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
satélite, deberá estar en CA3 o CA4. Seleccione en la caja de cable o de satélite el canal donde se va a grabar.
– COMO PROGRAMAR –
CA FECHA IN ICIO FINAL
61 7/03 LUN -:- - -:- - - -
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
[BB].
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
– COMO PROGRAMAR –
:
CA FECHA IN ICIO FINAL
61 CADA DIA -:- - -:- - - -
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
[BB].
– COMO PROGRAMAR –
:
CA FECHA IN ICIO FINAL
61 CADA LUN -:- - -:- - - -
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
[BB].
5
Utilice [KK/ LL] para ajustar la hora y el minuto de inicio/fin deseados. Presione
[BB] para pasar al
siguiente elemento.
6
Utilice [KK/ LL] hasta que aparezca la velocidad de cinta deseada.
(Consulte "SELECTING TAPE SPEEDS" en página 15.)
– COMO PROGRAMAR –
CA FECHA IN ICIO FINAL
61 7/03 LUN 7:30
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
– COMO PROGRAMAR –
CA FECHA IN ICIO FINAL
61 7/03 LUN 7:30
B
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
- - -/- - - - - -:- - -:- - - -
7 Presione [ENTER] para finalizar el ajuste.
Para ajustar otro programa, repita los pasos 2 a 7.
•Para corregir el programa durante el ajuste, presione
[ss] para retroceder un paso y utilice
[KK/ LL] para introducir los números correctos.
• Presione
8 Presione [STANDBY-ON
[SET-UP] para salir del menú.
yy
] para ajustar la
grabación con temporizador automático. El indicador de grabación se enciende.
NOTAS:
DEBE apagar la unidad para activar la grabación
con temporizador automático.
Si no se apaga la unidad y sigue usted viendo la televisión, "PRG. ESTAR LISTO" empieza a parpadear en la pantalla del televisor 2 minutos antes de la hora de inicio programada.
Asegúrese de insertar una cinta con lengüeta de protección contra borrado antes de apagar la unidad. Si la cinta no tiene la lengüeta, será expulsada cuando se presione [STANDBY-ON yy] para apagar.
PRG. ESTAR LISTO
9 En la hora de inicio programada, la unidad
empieza a grabar.
NOTAS:
• La grabación comienza sin encenderse la pantalla
del televisor.
Durante la grabación, puede ver solamente el
programa de televisión que se esté grabando actualmente o una reproducción de DVD.
Presione [STANDBY-ON yy] y [SELECT] para seleccionar el modo deseado.
Si la cinta se acaba antes de la hora de finalización, la grabación
se interrumpe inmediatamente y la cinta es expulsada.
PARA CONFIRMAR EL PROGRAMA
1 Presione [STANDBY-ON
unidad. (El indicador de grabación se apaga.)
yy
] para encender la
2 Presione [SET-UP].
Utilice
[KK/ LL] para seleccionar "COMO
PROGRAMAR", y presione
[ENTER].
3 Confirme los detalles de los programas que
aparecen en la pantalla del televisor.
4 Presione [SET-UP] para salir del menú.
P
P
M
M
8:50
- -
P
P
M
M
8:50
SP
SECCIÓN DVD
Presione 'PLAY' para reproducir desde aquí. Para reproducir desde el inicio, primero presione 'STOP' y luego 'PLAY'.
REANUDACIÓN ACTIVADA
REPRODUCCIÓN BÁSICA
1 Presione [STANDBY-ON
2 Presione [OPEN/CLOSE
3 Coloque el disco en la
4 Presione [PLAY
• La bandeja se cerrará automáticamente y se
5 Para congelar la imagen, presione [PAUSE
6 Presione [STOP
• Presione
• Para cancelar la reanudación y parar el disco,
REPRODUCCIÓN PASO A PASO
• Durante la reproducción, presione
•Para volver a la reproducción normal, presione
yy
]
para encender la unidad.
AA
] en la unidad.
bandeja, con la etiqueta hacia arriba.
BB
].
empezará la reproducción. Cuando reproduzca un DVD que incluya un menú de títulos, este menú puede aparecer en pantalla.
NOTAS:
• Cerrar la bandeja del disco manualmente o presionando [OPEN/CLOSE AA] también inicia la reproducción.
• Con discos DVD que utilicen títulos para señales de programa de reproducción, la reproducción puede comenzar desde el segundo título o puede omitir dichos títulos.
FF
]
durante la reproducción.
NOTA:
• El sonido se silenciará en modo de pausa.
CC
] para
interrumpir temporalmente la reproducción.
[PLAY BB] para
reanudar la reproducción.
presione
[STOP CC] de nuevo.
NOTAS:
• La información de reanudación se conserva aunque se apague la unidad.
• Puede aparecer un "icono prohibido" en la zona superior derecha de la pantalla del televisor durante la operación. Esto significa que la operación no está disponible en el disco.
[PAUSE F]. Puede avanzar la imagen fotograma a fotograma presionando repetidamente
[PAUSE F].
[PLAY BB].
AVANCE RÁPIDO / RETROCESO RÁPIDO
• Durante la reproducción, mantenga presionado rápido o
• Cada vez que mantenga
[FWD DD] para avance
[REW EE] para retroceso rápido.
D1
presionado el botón, la reproducción se acelera y el nivel de velocidad aparece en la pantalla.
NOTAS:
En los discos DVD, la velocidad de avance/retroceso rápido es diferente según el disco. La velocidad aproximada es 1 (×2), 2 (×8), 3 (×20), 4 (×50) y 5 (×100).
• En discos de CD de audio la velocidad aproximada es 1 (×2), 2 (×8) y 3 (×30).
• Cuando utilice los botones del panel frontal, utilice [SEARCH EE/ DD].
Para volver a la reproducción normal, presione [PLAY BB].
AVANCE LENTO / RETROCESO LENTO
Durante la reproducción, presione [PAUSE FF].
• Mantenga presionado [FWD DD] para
avance lento o
[REW EE] para retroceso lento.
• Cada vez que mantenga presionado el botón, la reproducción se ralentiza y el nivel de velocidad aparece en la pantalla.
NOTAS:
• La velocidad de avance/retroceso lento varía según el disco. La velocidad aproximada es 1 (1/16), 2 (1/8) y 3 (1/2).
• Cuando utilice los botones de la unidad principal, utilice [SEARCH EE/ DD].
•Para volver a la reproducción normal, presione
[PLAY BB].
MENÚ DE DISCO/MENÚ DE TÍTULO
Un DVD puede contener menús para explorar el disco y acceder a funciones especiales.
1 Presione [DISC MENU] o [TITLE].
Aparecerá el menú principal/menú de título del DVD.
Puede activar el menú incluso durante la reproducción.
2 Utilice [
KK/ LL
/ ss/ BB] para seleccionar un
elemento y presione
[ENTER].
NOTAS:
• SI el disco tiene un menú de disco, aparecerán distintas opciones de selección: idioma de sonido, subtítulos, capítulos del título y otras.
• El contenido del menú y las correspondientes operaciones de menú pueden variar según los discos. Para más detalles, consulte el manual que acompaña el disco.
SECCIÓN DVD
1
43
ES
LIMITED WARRANTY
FUNAI CORP. will repair this product, free of charge in the USA in the event of defect in materials or work­manship as follows:
DURATION:
PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year
LABOR: FUNAI CORP. will provide the labor without charge for a period of ninety (90) days from the
LIMITS AND EXCLUSIONS:
This warranty is extended only to the original retail purchaser. A purchase receipt or other proof of origi­nal retail purchase will be required together with the product to obtain service under this warranty.
This warranty shall not be extended to any other person or transferee. This warranty is void and of no effect if any serial numbers on the product are altered, replaced, defaced,
missing or if service was attempted by an unauthorized service center. This limited warranty does not apply to any product not purchased and used in the United States.
This warranty only covers failures due to defects in material or workmanship which occurs during normal use. It does not cover damage which occurs in shipment, or failures which are caused by repairs, alter­ations or product not supplied by FUNAI CORP. or damage which results from accident, misuse, abuse, mishandling, misapplication, alteration, faulty installation, improper maintenance, commercial use such as hotel, rental or office use of this product or damage which results from fire, flood, lightning or other acts of God.
THIS WARRANTY DOES NOT COVER PACKING MATERIALS, ANY ACCESSORIES (EXCEPT REMOTE CONTROL), ANY COSMETIC PARTS, COMPLETE ASSEMBLY PARTS, DEMO OR FLOOR MODELS.
FUNAI CORP. AND ITS REPRESENTATIVES OR AGENTS SHALL IN NO EVENT BE LIABLE FOR ANY GENERAL, INDIRECT OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR OCCASIONED BY THE USE OF OR THE INABILITY TO USE THIS PRODUCT. THIS WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED AND OF ALL OTHER LIABILITIES ON THE PA RT OF FUNAI, ALL OTHER WARRANTIES INCLUDING THE WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED BY A FUNAI AND ITS REPRESENTATIVES IN THE UNITED STATES. ALL WARRANTY INSPECTIONS AND REPAIRS MUST BE PERFORMED BY AN AUTHORIZED SERVICE CENTER. THIS WARRANTY IS ONLY VALID WHEN THE UNIT IS CARRIED-IN TO AN AUTHORIZED SERVICE CENTER.
IMPORTANT:
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS.YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE. IF, AT ANY TIME DURING THE WARRANTY PERIOD, YOU ARE UNABLE TO OBTAIN SATISFACTION WITH THE REPAIR OF THIS PRODUCT, PLEASE CONTACT FUNAI CORP.
ATTENTION:
FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY DESIGN OF THIS PRODUCT WITHOUT PRIOR NOTICE.
WARRANTY STATEMENT REGARDING NON AUTHORIZED REPAIRS:
To obtain warranty service, you must take the product, or deliver the product freight prepaid, in either its original packaging or packaging affording an equal degree of protection, to any AUTHORIZED SER­VICE CENTER. FUNAI CORP. will not reimburse you for any service done by unauthorized service providers without prior written approval.
from the date of original retail purchase. Two (2) years for Picture Tube. Certain parts are excluded from this warranty.
date of original retail purchase.
To locate your nearest AUTHORIZED SERVICE CENTER or for general service inquiries, please contact us at :
FUNAI CORPORATION
Customer Service
Tel :1-800-605-8610
http://www.funai-corp.com
19900 Van Ness Avenue, Torrance, CA 90501
Printed in Malaysia 1EMN21760
T2223UD
★★★★★
Loading...
