Funai MGTD204 User Manual

COLOR TV/VCR/DVD TRIPLE COMBO

MGTD204

(20 inch)

OWNER’S MANUAL

As an ENERGY STAR

Partner, our company has determined that this product meets the E

NERGY STAR guidelines for

energy efficiency. E

NERGY STAR

is a U.S. registered mark.

If you need additional operating assistance after reading this owner’s manual or to order replacement accessories, please call

TOLL FREE : 1-800-605-8610. Or visit our WEB SITE at http://www.funai-corp.com

Please read before using this equipment

SUPPLIED ACCESSORIES

Batteries

Remote Control Unit

ACCESSORIES

2 AA Batteries

NE225UD

PA RT NO.

Owner’s Manual 1EMN20110

1.Read instructions-All the safety and operating instructions should be read before the appliance is operated.

2.Retain Instructions-The safety and operating instructions should be retained for future reference.

3.Heed Warnings-All warnings on the appliance and in the operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions should be followed.

5.Cleaning-Unplug TV/VCR/DVD from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6.Attachments-Do not use attachments not recommended by the TV/VCR/DVD manufacturer as they may cause hazards.

7.Water and Moisture-Do not use this TV/VCR/DVD near water-for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8.Accessories-Do not place this TV/VCR/DVD on an unstable cart, stand, tripod, bracket, or table. The TV/VCR/DVD may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the TV/VCR/DVD. Any mounting of the appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care.Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

9. Ventilation-Slots and openings in the cabinet and the back or bottom are provided for ventilation and to ensure reliable operation of the TV/VCR/DVD and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the TV/VCR/DVD on a bed, sofa, rug, or other similar surface. This TV/VCR/DVD should never be placed near or over a radiator or heat register. This TV/VCR/DVD should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10.Power Sources-This TV/VCR/DVD should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For TV/VCR/DVDs intended to operate from battery power, or other sources, refer to the operating instructions.

11.Grounding or Polarization-This TV/VCR/DVD is equipped with a polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12.Power-Cord Protection-Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

- 2 - EN

1B15

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

The caution marking is located on the rear of the cabinet.

IMPORTANT SAFEGUARDS

PORTABLE CART WARNING

S3126A

- 3 - EN

1B15

13.Outdoor Antenna grounding-If an outside antenna or cable system is connected to the TV/VCR/DVD, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14.Lightning-For added protection for this TV/VCR/DVD receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV/VCR/DVD due to lightning and power-line surges.

15.Power Lines-An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16.Overloading-Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

17.Object and Liquid Entry-Never push objects of any kind into this TV/VCR/DVD through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the TV/VCR/DVD.

18.Servicing-Do not attempt to service this TV/VCR/DVD yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19.Damage Requiring Service-Unplug this TV/VCR/DVD from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a. When the power-supply cord or plug is damaged or frayed. b. If liquid has been spilled, or objects have fallen into the

TV/VCR/DVD.

c. If the TV/VCR/DVD has been exposed to rain or water. d. If the TV/VCR/DVD does not operate normally by follow-

ing the operating instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the TV/VCR/DVD to its normal operation.

e. If the TV/VCR/DVD has been dropped or damaged in any

way.

f. When the TV/VCR/DVD exhibits a distinct change in per-

formance-this indicates a need for service.

20.Replacement Parts-When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, injury to persons or other hazards.

21.Safety Check-Upon completion of any service or repairs to this TV/VCR/DVD, ask the service technician to perform routine safety checks to determine that the TV/VCR/DVD is in proper operating condition.

22.Heat-This TV/VCR/DVD product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

S2898A

FIGURE A

ELECTRIC SERVICE EQUIPMENT

NEC - NATIONAL ELE CTRI CAL CO DE

GROUND

CLAMP

ANTENNA

L EAD IN WIRE

ANTENNA

DISCHARGE UNI T (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDI NG ELECTRODE SYSTEM (NEC ART 250, PART H)

- 4 - EN

1B15

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This product incorporates copyright protection tech-

nology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

LASER SAFETY

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

This Class B digital apparatus complies with Canadian ICES-003.

CAUTION: TO PREVENT ELECTRIC SHOCK,

MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

PRECAUTIONS

- 5 - EN

1C29

AV OID THE HAZARDS OF

ELECTRICAL SHOCK AND FIRE

LOCATION

For safe operation and satisfactory performance of your TV/VCR/DVD, keep the following in mind when selecting a place for its installation:

•

Shield it from direct sunlight and keep it away from sources of intense heat.

•

Avoid dusty or humid places.

•

Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes at the top or bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

•

Install unit in a horizontal position.

•

Avoid locations subject to strong vibration.

•

Do not place the TV/VCR/DVD near strong magnetic fields.

•

Avoid moving TV/VCR/DVD to locations where temperature differences are extreme.

•

Do not handle the power cord with wet hands.

•

Do not pull on the power cord when disconnecting it from an AC wall outlet. Grasp it by the plug.

•

If by accident, water is spilled on your unit, unplug the power cord immediately and take the unit to our Authorized Service Center for servicing.

•

Do not put your fingers or objects into the TV/VCR/DVD disc loading tray.

•

Do not place anything directly on top of the unit.

WARNING

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place or after heating a cold room or under conditions of high humidity. If a DVD is played in a TV/VCR/ DVD which has moisture, it may damage the DVD and TV/VCR/DVD. Therefore when the condensation occurs inside the unit, turn the POWER on and allow at least 2 hours for the unit to dry out.

The serial number of this product may be found on the back of the unit. No other TV/VCR/DVD has the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase Dealer Purchase from Dealer Address Dealer Phone No. Model No. Serial No.

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

The following symbols below appear in some headings and notes in this manual, with the following meanings

: Description refers to TV/VCR operation (in the

TV/VCR mode).

: Description refers to playback of DVD video discs

(in the DVD mode).

: Description refers to playback of audio CDs

(in the DVD mode).

: Description refers to playback of MP3 discs

(in the DVD mode).

: Description refers to the items to be set by the

QUICK mode (in the DVD mode).

QUICK

MP3

DVD-V

TV/VCR

SYMBOLS USED IN THIS MANUAL

- 6 - EN

1C29

TABLE OF CONTENTS

C IMPORTANT SAFEGUARDS . . . . .2

C PRECAUTIONS . . . . . . . . . . . . . . . .4

LOCATION . . . . . . . . . . . . . . . . . . .5

AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE .5

WARNING . . . . . . . . . . . . . . . . . . . .5

SYMBOLS USED IN THIS

MANUAL . . . . . . . . . . . . . . . . . . . . .5

C TABLE OF CONTENTS . . . . . . . . . .6

C FEATURES . . . . . . . . . . . . . . . . . . . .7

C OPERATING CONTROLS AND

FUNCTIONS . . . . . . . . . . . . . . . . . . .9

C PREPARATION FOR USE . . . . . . .11

ANTENNA/CABLE

CONNECTION . . . . . . . . . . . . . . . .11

CONNECTING TO EXTERNAL

INPUT JACKS . . . . . . . . . . . . . . . .12

INSTALLING THE BATTERIES . .12

EXTERNAL INPUT MODE . . . . . .12

CONNECTING TO A STEREO AMPLIFIER EQUIPPED WITH DIGITAL INPUT JACKS SUCH AS MD DECK OR DAT DECK (for DVD) .13

CONNECTING TO A DOLBY DIGITAL DECODER (for DVD) . .14

TV/VCR SECTION

C SET UP FOR USE . . . . . . . . . . . . .15

SELECTING THE LANGUAGE . .15 CLOCK SET UP

(AUTO / MANUAL) . . . . . . . . . . . .15

DAYLIGHT-SAVING TIME . . . . . .17

CHANNEL SET UP . . . . . . . . . . . .18

DELETING (OR ADDING)

CHANNEL(S) . . . . . . . . . . . . . . . . .18

C TV OPERATION . . . . . . . . . . . . . . .19

WATCHING A TV PROGRAM . . .19

DEGAUSSING . . . . . . . . . . . . . . . .19

PICTURE CONTROL . . . . . . . . . . .19

CLOSED CAPTION SYSTEM . . . .20

V-CHIP SET UP . . . . . . . . . . . . . . .21

C MTS (Multi-Channel Television

sound) SYSTEM . . . . . . . . . . . . . . .23

CHECKING THE SELECTED

MTS MODE . . . . . . . . . . . . . . . . . .23

MTS RECORDING/MONITOR

MODE . . . . . . . . . . . . . . . . . . . . . .23

SELECTING THE MTS SYSTEM .24

C VIDEO CASSETTE . . . . . . . . . . . . .25

C PLAYBACK . . . . . . . . . . . . . . . . . . .26

NORMAL PLAYBACK . . . . . . . . .26

TRACKING ADJUSTMENT . . . . .26

SLOW MOTION . . . . . . . . . . . . . .26

STILL PICTURE . . . . . . . . . . . . . .26

VERTICAL HOLD CONTROL . . .26

C SPECIAL PLAYBACK . . . . . . . . . .27

RENTAL PLAYBACK . . . . . . . . . .27

AUTO REPEAT PLAYBACK . . . . .27

C SEARCH . . . . . . . . . . . . . . . . . . . . .28

ZERO RETURN . . . . . . . . . . . . . . .28

PICTURE SEARCH . . . . . . . . . . . .28

TIME SEARCH . . . . . . . . . . . . . . .28

INDEX SEARCH . . . . . . . . . . . . . .29

C SPECIAL FEATURES . . . . . . . . . .29

REAL TIME TAPE COUNTER . . .29

AUTO REWIND-EJECT . . . . . . . .29

C RECORDING . . . . . . . . . . . . . . . . .30

NORMAL RECORDING . . . . . . . .30

SKIPPING UNWANTED SCENES

DURING RECORDING . . . . . . . . .30

OTR (One Touch Recording) . . . . . .31

COPYING A VIDEO CASSETTE (Requires a VCR or camcorder) . . .31

C TIMER . . . . . . . . . . . . . . . . . . . . . .32

AUTOMATIC

TIMER RECORDING . . . . . . . . . .32

TIMER PROGRAM EXTENSION .33 HINTS FOR AUTOMATIC TIMER

RECORDING . . . . . . . . . . . . . . . . .34

AUTO RETURN . . . . . . . . . . . . . . .34

SLEEP TIMER . . . . . . . . . . . . . . . .34

C ON SCREEN DISPLAY . . . . . . . . .35

C CABLE CHANNEL

DESIGNATIONS . . . . . . . . . . . . . .35

VD SECTION

C ABOUT THE DISCS . . . . . . . . . . . .36

PLAYABLE DISCS . . . . . . . . . . . .36

DISC TYPES . . . . . . . . . . . . . . . . .36

C PLAYING A DISC . . . . . . . . . . . . . .37

BASIC PLAYBACK . . . . . . . . . . . .37

GENERAL FEATURES . . . . . . . . .37

DISC MENU . . . . . . . . . . . . . . . . .37

TITLE MENU . . . . . . . . . . . . . . . . .37

RESUME . . . . . . . . . . . . . . . . . . . .38

PAUSE . . . . . . . . . . . . . . . . . . . . . .38

STEP BY STEP PLAYBACK . . . . .38

FAST FORWARD/REVERSE

SEARCH . . . . . . . . . . . . . . . . . . . .38

SLOW FORWARD / SLOW

REVERSE . . . . . . . . . . . . . . . . . . . .38

C SEARCH FUNCTION . . . . . . . . . . .39

TRACK SEARCH . . . . . . . . . . . . .39

TITLE / CHAPTER SEARCH . . . .39

TIME SEARCH . . . . . . . . . . . . . . .39

MARKER SETUP SCREEN . . . . . .39

SPECIAL PLAYBACK FUNCTION . . .40

REPEAT . . . . . . . . . . . . . . . . . . . . .40

PROGRAM . . . . . . . . . . . . . . . . . . .40

RANDOM PLAYBACK . . . . . . . . .40

C PLAYING A MP3 DISC . . . . . . . . . .41

MP3 PLAYBACK . . . . . . . . . . . . . .41

REPEAT . . . . . . . . . . . . . . . . . . . . .41

PROGRAM . . . . . . . . . . . . . . . . . . .41

RANDOM PLAYBACK . . . . . . . . .41

C CHANGING THE SETTINGS . . . .42

SUBTITLE LANGUAGE . . . . . . . .42

AUDIO LANGUAGE . . . . . . . . . . .42

STEREO SOUND MODE . . . . . . . .42

CAMERA ANGLE . . . . . . . . . . . . .42

BLACK LEVEL SETTING . . . . . . .42

VIRTUAL SURROUND . . . . . . . . .42

THE ON-SCREEN INFORMATION . . .43

C CHANGING THE DVD SETUP

ITEMS . . . . . . . . . . . . . . . . . . . . . . .44

LANGUAGE SETTING . . . . . . . . .44

DISPLAY SETTING . . . . . . . . . . . .45

AUDIO SETTINGS . . . . . . . . . . . .45

PARENTAL CONTROL . . . . . . . . .46

INITIALIZE . . . . . . . . . . . . . . . . . .46

C TROUBLESHOOTING GUIDE . . .47

C MAINTENANCE . . . . . . . . . . . . . . .50

DISC HANDLING . . . . . . . . . . . . .50

C SPECIFICATIONS . . . . . . . . . . . . .51

C WARRANTY . . . . . . . . . . .Back Cover

- 7 - EN

1C29

•

Hi-Fi system–The Hi-Fi stereo recording system

offers you excellent sound quality with a dynamic range of 80dB, frequency response from 20Hz to 20kHz and 0.005% wow and flutter.

•

Rotary 4-head Record/Playback System–Four

heads ensure excellent picture quality and special effects playback.

•

Index Search–Fast-forwards to start of next

recording.

•

Slow Motion–View recorded program at slower

than normal speed.

•

Infrared remote control

•

Trilingual on screen TV/VCR setup display selectable in English, Spanish or French

•

Real time counter–This shows the elapsed record-

ing or playback time in hours, minutes and seconds. The “–” indication will appear when the tape is rewound further than the tape counter position “0:00:00”.

•

181 channel capability PLL frequency synthesizer tuner with direct station call

(A converter may

be necessary to view scrambled cable channels.)

•

Auto Clock Setting–Allows you to set the clock

function from a PBS broadcast station.

•

Closed caption system–You may view specially

labeled (cc) TV programs, movies, news, prerecorded tapes, etc. with either a dialogue caption or text display added to the program.

•

Auto power on and off system–Automatically

turns on the TV/VCR/DVD when you insert the cassette, turns off after auto-rewind and ejects when the beginning of the tape is reached.

•

Auto rewind when the end of a tape is reached

(This function doesn’t occur when using timer recording.)

•

Smooth mode change–TV/VCR mode and DVD

mode automatically changes without control.

•

2 Step picture search operation–You can view a

video program at a high speed or super high speed in either a forward or reverse direction in LP and SLP mode. For SP mode, only high speed is available.

FEATURES

TV/VCR Mode

- 8 - EN

1C29

¡Dolby Digital sound

This TV/VCR/DVD can handle Dolby Digital surround sound having 5.1 channels when connected to a Dolby Digital decoder.

¡Still/fast/slow/step playback

Various playback modes are available including still pictures, fast forward/reverse, slow motion and step frames.

¡Random playback for audio CD and MP3

This TV/VCR/DVD can shuffle the order of tracks to play them in random order.

¡Program playback for audio CD and MP3

You can program the order of tracks to play them in any desired order.

¡DVD menus in a desired language

You can display DVD menus in a desired language, if available on a DVD.

¡Screen saver/Auto power-off functions

The screen saver program starts when there is no input from the TV/VCR/DVD for 5 minutes in the stop mode. When the screen saver program is activated for 15 minutes, the power automatically turns off.

¡Subtitles in a desired language

You can select a desired language for the display subtitles, if that language is available on a disc.

¡Selecting a camera angle

You can select the desired camera angle, if a disc contains sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound mode, if different languages and modes are available on a disc.

¡Parental lock

You can set the control level to limit playback of discs which may not be suitable for children.

¡Automatic detection of discs

This TV/VCR/DVD automatically detects if the loaded disc is DVD, audio CD or MP3 on disc.

¡Playback MP3 disc ¡On-screen display

Information about the current operation can be displayed on a TV screen, allowing you to confirm the currently active functions (such as program playback), on the TV screen using the remote control.

¡Search

Chapter search / Title search / Track search / Time search

¡Repeat

Chapter / Title / Track / Group / All / A-B

¡Marker

The part designated by user can be called back.

¡Resume Play

User can resume to playback from the part at which the play was stopped.

¡Virtual Surround ¡Bit rate indication

¡DRC (Dynamic range control)

You can control the range of sound volume.

NOTE:

•

We do not recommend the use of universal remote controls. Not all of the functions may be controlled with a universal remote control.

If you decide to use a universal remote control with this TV/VCR/DVD, please be aware that the code number given may not operate this TV/VCR/DVD. In this case, please call the manufacturer of the universal remote control.

DVD Mode

- 9 - EN

1C29

OPERATING CONTROLS AND FUNCTIONS

5.STOP Button

[TV/VCR P.26 / DVD P.37]

Stops operation of the disc. (or front panel) Stops operation of the disc or tape contents. (remote control)

OPEN/CLOSE Button

[DVD P.37]

Press to insert discs into or remove them from the tray.

7.Disc loading tray

8.DVD Indicator

Illuminates during DVD mode.

SOURCE Button

Press to change to TV/VCR mode, external input mode or DVD mode.

10.TV/VCR Indicator

Illuminates during TV/VCR mode.

11.

CHANNEL(CH.) K/L Buttons

Press to select memorized channel.

12.

Recording Indicator

Flashes during recording. Illuminates in the Standby mode for Timer Recording.

13. REC/OTR Button (Front Panel)

[TV/VCR P.30, 31]

Press to start manual recording. Press repeatedly to start One Touch Recording.

RECORD Button (Remote Control)

[TV/VCR P.30]

Press to start manual recording.

14. REW Button (for TV/VCR)

[TV/VCR P.26]

Press to rewind the tape, or to view the picture rapidly in reverse during playback mode. (Rewind Search)

15.

F.FWD Button (for TV/VCR)

[TV/VCR P.26]

Press to rapidly advance the tape, or to view the picture rapidly in forward during playback mode. (Forward Search)

16.

STOP/EJECT Button

[TV/VCR P.28]

Press to stop the tape motion. Press in the Stop mode to remove tape from the TV/VCR/DVD.

17.

Remote sensor window

18. HEADPHONE Jack

To connect headphone (not supplied) for personal listening.

19.

VIDEO input Jack

Connect to the video output jack of a video camera or VCR.

- REMOTE CONTROL -

[Fig. 2]

POWER Button

[TV/VCR P.15 / DVD P.37]

Press to turn the power on and off.

2.VOLUME(VOL.) X/Y Buttons

Press to control the volume level for the DVD and TV.

3.PREV/NEXT (SEARCH) Buttons (for DVD)

[P.38]

Press once to skip chapters or tracks to a desired point. Press and hold to change forward or reverse playback speed.

PLAY Button

[TV/VCR P.26 / DVD P.37]

Starts playback of the disc or tape contents.

- TV/VCR/DVD FRONT PANEL - [Fig.1]

DVD buttonsDVD buttons TV/VCR buttonsTV/VCR buttons

PLAY NEXT OPEN/CLOSE SOURCE PLAY

•

REC/OTR

STOP/EJECT

h - SEARCH - g

POWER PICTURE SELECTSLEEP

24 25

123

456

789

PAUSE

SPEED C.RESET

(DVD) 3

(TV/VCR) 14

RECORD

DISPLAY

27 28

29 30

CLEAR

MODE

31 32

4 5 6 107 1514983 3 41213 212019181711 16

45 44

+100

0 +10

CH.

VOL.

MUTEV.SURR

43 42

PLAY

STOP

DISC

3 (DVD)

15 (TV/VCR)

5 41

ENTER

REPEATSEARCH MODE

RETURNTITLESETUP

ANGLESUBTITLEAUDIO

40 39 38

36 35

DVD TV/VCR

- 10 - EN

1C29

ANT.

AUDIO OUT

COAXIAL

20. AUDIO L/R input Jacks

Connect to the audio output jacks of a video camera or VCR.

21.

Cassette compartment

22. PICTURE Button

Press to adjust the picture.

23.

Number Buttons TV/VCR Mode:

[P.18]

Press two digits to directly access the desired channel. Remember to press a “0” before a single digit channel.

+100 Button–

Press to select cable channels which are equal or greater than number 100.

DVD Mode:

Press to enter the desired number.

+10 Button–

Press to enter the desired numbers which are equal or greater than number 10.

24.

PAUSE Button

[TV/VCR P.26 / DVD P.38]

Pauses the current disc or tape operation.

25.

SPEED Button

[TV/VCR P.30]

Press to choose the desired recording speed: SP/SLP.

26.

C.RESET Button

[TV/VCR P.28]

Press to reset counter to 0:00:00. Press to cancel a setting of timer program. (See page 33.)

27.

DISPLAY Button TV/VCR Mode:

Display the counter or the current channel number and current time on the TV screen.

DVD Mode:

[P.43]

Displays the current status on the TV screen for checking purposes.

28.

SETUP Button

[TV/VCR P.15] [DVD P.44-46]

Press to enter or exit the TV menu or DVD setup mode.

29.

TITLE Button

[DVD P.37]

Displays the title menu.

30.

CLEAR Button

Resets a setting.

31.

MODE Button

[DVD P.40]

Activates program playback or random playback mode.

32. SEARCH MODE Button

[DVD P.39]

Press to locate a desired point.

33.

AUDIO Button

[DVD P.42]

Press to select a desired audio language or sound mode.

34.

SUBTITLE Button

[DVD P.42]

Press to select a desired subtitle language.

35.

REPEAT Button

[DVD P.40]

Repeats playback of the current disc, title, chapter, group or track.

36.

ANGLE Button (DVD mode)

[DVD P.42]

Press to change the camera angle to see the sequence being played back from a different angle (if available).

37. A-B REPEAT Button

[DVD P.40]

Repeats playback of a selected section.

38.

RETURN Button

Returns to the previous operation in the DVD setup mode.

39.

ENTER Button

Press to accept a setting.

40.

Arrow Buttons TV/VCR Mode:

Press to select a setting mode from the menu on the TV screen. Press to select or adjust from a particular menu.

DVD Mode:

Use when making settings while watching the display on a TV screen.

41.

DISC MENU Button

[DVD P.37]

Displays the menus in the DVD.

42.

V. SURR (VIRTUAL SURROUND) Button

[DVD P.42]

Sets virtual surround on/off.

43.

MUTE Button

Mutes the sound. Press it again to resume sound.

44.

SLEEP Button

[TV/VCR P.34]

Sets the Sleep Timer.

45.

SELECT Button

Press to switch TV/VCR and DVD mode. You can see the mode (TV/VCR or DVD) on the front panel indicator.

- TV/VCR/DVD REAR PANEL - [Fig.3]

- 11 - EN

1C29

CABLE WITH CONVERTER/ DESCRAMBLER BOX OR SATELLITE BOX

If your cable service supplies you with a converter box or if you use a satellite system, you can use the basic connection shown in the illustration.

By using this connection you can also record scrambled channels. However, channel selection must be made with the converter box or satellite box. This means that channels cannot be changed using the TV/VCR/DVD remote control. Unattended timer recording is limited to one channel at a time.

PREPARATION FOR USE

CABLE WITHOUT CONVERTER/ DESCRAMBLER BOX

Use this connection if your cable system connects directly to your TV/VCR/DVD without a converter box.

By using this connection you can:

1) Use the TV/VCR/DVD remote control to select channels.

2) Program one or more unscrambled channels for Automatic Timer Recording.

NOTE: This TV/VCR/DVD will ONL

Y record and

view the same channel.

VHF/UHF SEPARATE ANTENNAS

In some areas it will be necessary to use an outdoor antenna.

Antenna/Cable Connections Continued on the Next Page.

ANT.

AUDIO OUT

COAXIAL

ANT.

OUT

VHF/UHF Antenna (Not supplied)

VHF/UHF Combiner (Not supplied)

Flat twin-lead cable

UHF Antenna (Not supplied)

VHF Antenna (Not supplied)

From Cable System

75-ohm Coaxial Cable (Not supplied)

Satellite Box or Cable Box (Not supplied)

From Cable System or Satellite Dish

46. ANT. in Jack

Connect to an antenna, cable system or satellite system.

47.

Power cord

Connect to a standard AC outlet (120V/60Hz).

NOTE: Remove the power cord from the hook to

avoid breaking a wire before you connect to a standard AC outlet.

48.

COAXIAL digital audio out Jack

Connect to the digital input of an external amplifier or (decoder for DVD audio only).

[Fig. 4]

ANTENNA/CABLE CONNECTION

- 12 - EN

1C29

TO RECORD A SCRAMBLED/UNSCRAMBLED CHANNEL

1. Set the TV/VCR/DVD channel selector to the output channel of the Cable Converter Box or Satellite Box. (Ex. CH3)

2.Select the channel to record from your Cable

Converter Box or Satellite Box.

INSTALLING THE BATTERIES

1)Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.

2)Insert 2 “AA” penlight batteries into the battery compartment in the direction indicated by the polarity (+/-) markings.

3)Replace the cover.

EXTERNAL INPUT MODE

When using an external input signal (another VCR or video camera), connect the player’s audio/video output cables to the AUDIO L/R IN/ VIDEO IN jacks of your TV/VCR/DVD. Then press the CHANNEL button K or L until “AUX” appears on the screen.

AUX

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

CONNECTING TO EXTERNAL

INPUT JACKS

When you watch a program recorded on another source (VCR or video camera), use the audio/video input jacks on the front of the TV/VCR/DVD.

Connect the audio/video output jacks of another source to the AUDIO L/R and VIDEO jacks of this TV/VCR/DVD.

Then press the CHANNEL button K or L until “AUX” appears on the screen.

NOTE:

•

When you connect a monaural VCR (another source) to this TV/VCR/DVD, connect the Audio output jack of the monaural VCR (another source) to the AUDIO L jack of this TV/VCR/DVD. The audio will output in both L and R channel equally.

[Another source]

To the audio output jacks

Audio/Video cable (not supplied)

etc.

To the video output jack

[Front of the TV/VCR/DVD]

[Fig. 5]

- 13 - EN

1C29

CONNECTING TO A STEREO AMPLIFIER EQUIPPED WITH DIGI-

TAL INPUT JACKS SUCH AS MD DECK OR DAT DECK (for DVD)

Use an audio coaxial digital cable available at retail for the audio connections. Connecting to an amplifier equipped with digital input jacks such as MD Deck or DAT Deck.

NOTES:

•

The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital sound by an MD or DAT deck.

•

Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner's Manuals for the components to be connected to the TV/VCR/DVD.

•

Set Dolby Digital to OFF for audio output in the setup mode. Playing a TV/VCR/DVD using incorrect settings may generate noise distortion and may also damage the speakers.

ANT.

AUDIO OUT

COAXIAL

Amplifier equipped with digital

input jacks, MD deck,

DAT deck, etc.

To COAXIAL DIGITAL AUDIO INPUT jack

To DIGITAL AUDIO OUT COAXIAL jack

(only DVD AUDIO OUT)

[Fig. 6]

- 14 - EN

1C29

ANT.

AUDIO OUT COAXIAL

Front speaker

(left)

Center

speaker

Front speaker

(right)

Surround

speaker

(left)

Surround

speaker

(right)

Subwoofer

To DIGITAL AUDIO OUT COAXIAL jack

To COAXIAL DIGITAL AUDIO INPUT jack

Dolby Digital

decoder

[Fig. 7]

CONNECTING TO A DOLBY DIGITAL DECODER (for DVD)

If using this TV/VCR/DVD to play a DVD disc in a 5.1 channel Dolby Digital surround format, the TV/VCR/DVD outputs a DOLBY DIGITAL Data stream from its COAXIAL digital audio out jack. By hooking the TV/VCR/DVD up to a Dolby Digital decoder, you can enjoy a more convincing, realistic ambience with powerful and high-quality surround sound as enjoyed in movie theaters.

Use audio coaxial digital cables available at retail for the audio connections.

NOTES:

•

Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner's Manuals for the components to be connected to the TV/VCR/DVD.

•

If connected to a Dolby Digital decoder, set DOLBY DIGITAL to ON for audio output in the setup mode. (See page 45 to set DOLBY DIGITAL to ON.)

•

Unless connected to a Dolby Digital decoder, set DOLBY DIGITAL to OFF for audio output in the setup mode. Playing a TV/VCR/DVD using incorrect settings may generate noise distortion and may also damage the speakers.

Manufactured under license from Dolby Laboratories.“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

1 Plug in the TV/VCR/DVD power cord

Plug the TV/VCR/DVD power cord into a standard AC outlet.

NOTE:

•

If any digits appear in the corner of the screen, press the POWER button without unplugging the power cord.

Make sure ...

•

Press the SOURCE or SELECT button to select TV/ VCR mode or make sure TV/ VCR lights on.

•

Press the POWER button to turn on the TV/VCR/DVD.

NOTE: This function effects only the language on the screen menu and not the audio source.

2 Select “LANGUAGE”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “LANGUAGE”.

3 Select “ENGLISH”, “ESPAÑOL” or “FRANÇAIS”

Select “ENGLISH”, “ESPAÑOL”= Spanish or “FRANÇAIS”= French using the ENTER button.

4 Exit the Language mode

Press the SETUP button on the remote control to return to TV mode.

NOTE: If for some reason the menu is in Spanish or French, press the SETUP button on the remote control, press the Arrow button K or L to point to “IDIOMA [ESPAÑOL]” or “LANGAGE [FRANÇAIS]”, then press the ENTER button, then press the SETUP button on the remote control.

- 15 - EN

1C29

SET UP FOR USE

TV/VCR SECTION

SELECTING THE LANGUAGE

The TV/VCR/DVD clock must be set correctly before VCR timer recording is possible. It is suggested that the clock be set manually when first setting up the TV/VCR/DVD, then set to [ON] the auto clock setting which will periodically correct the setting if necessary.

NOTE: If you cannot receive a station with time signals, auto clock setting cannot be performed. Use manual setting only.

MANUAL CLOCK SETTING

Make sure ...

•

The TV/VCR/DVD is turned on.

In the example below, the clock is to be set to:

DATE May 6th, 2004 SETTING TIME 5:40PM

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “SETTING CLOCK”. Then press the ENTER button.

2 Select “MANUAL CLOCK SET”

Press the Arrow button K or L to point to “MANUAL CLOCK SET”. Then press the ENTER button.

3 Select the month

Press the Arrow button K or L until your desired month appears.

(Example: May → 05) Then press the Arrow button B.

(Or press the Arrow button s to go back one step.)

4 Select the day

Press the Arrow button K or L until your desired day appears.

(Example: 6th → 06) Then press the Arrow button B.

CLOCK SET UP

(AUTO / MANUAL)

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / – – – – – – – – –

HOUR MINUTE

– – : – – – –

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 – – – – – – –

HOUR MINUTE

– – : – – – –

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH AUTO CLOCK CH [ 02 ]

B MANUAL CLOCK SET

D.S.T. [OFF]

TV/VCR

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP

B LANGUAGE [ENGLISH]

CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

- 16 - EN

1C29

5 Select the year

Press the Arrow button K or L until your desired year appears.

(Example: 2004) Then press the Arrow button B.

6 Select the hour

Press the Arrow button K or L until your desired hour appears.

(Example: 5, PM) Then press the Arrow button B.

7 Select the minute

Press the Arrow button K or L until the desired minute appears.

(Example: 40)

8 Start the clock

Press the SETUP button on the remote control.

Although seconds are not displayed, they begin counting from 00 when you press the SETUP button on the remote control. Use this feature to synchronize the clock with the correct time.

NOTE:

When unplugging the AC cord or if there is a power failure for more than 3 seconds, you may have to reset the clock.

TO CHANGE CLOCK SETTING

If you want to change the clock,

1)Follow steps [1] to [2].

2)Select where you want to change using the Arrow button B.

3)Enter correct numbers using the Arrow button K or L.

4)Press the SETUP button on the remote control to start the clock.

PLEASE NOTE:

If there is no local PBS station in your area or on your cable system, select “AUTO CLOCK” and press the ENTER button to turn [OFF] this function. Then you can manually adjust the clock.

AUTOMATIC CLOCK SETTING

Make sure ...

•

The TV/VCR/DVD is turned on.

•

Confirm the TV/VCR/DVD is receiving a RF (Radio Frequency) signal from either an antenna or cable system connection using the ANT. terminal on the rear of the TV/VCR/DVD.

NOTE:

•

If a cable converter box is being used, make sure it is powered on.

•

You must use the TV/VCR/DVD remote control to perform the clock setting procedure.

•

If the TV/VCR/DVD is connected directly to a cable converter box or satellite box, the local PBS station must be selected on the cable box itself and the TV/VCR/DVD must be set to the output channel of the cable converter box or satellite box (usually channel 3 or 4), to be able to set up or correct the clock automatically.

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control. Press the Arrow button K or L to select “SETTING CLOCK”. Press the ENTER button to enter “SETTING CLOCK” menu.

2 Set “AUTO CLOCK” to [ON]

Press the Arrow button B until “AUTO CLOCK [ON]” appears.

3 Begin “AUTO CLOCK CH SEARCH”

Press the Arrow button L to select “AUTO CLOCK CH SEARCH”. Press the ENTER button.

•

The TV/VCR/DVD is now searching for the station which contain the auto clock set signal. The search for a signal may take up to 20 seconds per channel.

•

“_ _” appears at the lower left of the screen when the search has ended.

•

Auto Clock station- write down the number(s) that appear on the screen. These are the auto clock station(s) in your area. See step [4] on page 17.

•

If no number(s) appear on the TV screen, there are no stations in your area which contain the Auto Clock signal. Auto Clock Setting is not possible. Please use Manual Clock Setting on page 15.

Press the SETUP button to exit the screen.

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 THU 2 0 0 4

HOUR MINUTE

0 5 : – – PM

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 THU 2 0 0 4

HOUR MINUTE

0 5 : 4 0 PM

5:40 PM

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 THU 2 0 0 4

HOUR MINUTE

– – : – – – –

– SETTING CLOCK –

B AUTO CLOCK [ON]

AUTO CLOCK CH SEARCH AUTO CLOCK CH [ 02 ] MANUAL CLOCK SET D.S.T. [OFF]

– SETTING CLOCK –

AUTO CLOCK [ON]

B AUTO CLOCK CH SEARCH

AUTO CLOCK CH [ 02 ] MANUAL CLOCK SET D.S.T. [OFF]

– AUTO CLOCK CH SEARCH –

08 10 13

_ _

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

- 17 - EN

1C29

DAYLIGHT-SAVING TIME

Select this feature and the TV/VCR/DVD’s clock automatically will advance one hour in April, then reverse one hour in October.

When Daylight-Saving Time is ON, the clock will change automatically as follows:

•

First Sunday of April : At 2 AM the clock imme-

diately changes to 3 AM. Any timer programming you have set to occur between 2 AM and 3 AM will not record.

•

Last Sunday of October : At 2 AM the clock

immediately changes to 1 AM.

Make sure ...

•

Press the POWER button to turn on the TV/VCR/DVD.

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “SETTING CLOCK”.

Then press the ENTER button.

2 Set “D.S.T.” (Daylight-Saving Time) to [ON]

Press the Arrow button K or L to point to “D.S.T.”.

Then press the ENTER button until [ON] appears.

3 Exit the Daylight-Saving Time mode

Press the SETUP button on the remote control to return to TV mode.

TO CANCEL THE DAYLIGHT-SAVING TIME

Repeat steps [1] to [2], select [OFF] using the ENTER button.

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH AUTO CLOCK CH [ 02 ] MANUAL CLOCK SET

B D.S.T. [ON]

NOTE: During Auto Clock CH Search, the picture may be distorted, this is normal.

4 Enter the channel number that contains the

Automatic Clock Setting Signal

Press the SETUP button on the remote control. Press the Arrow button K or L to

select “SETTING CLOCK”. Press the ENTER button to enter

“SETTING CLOCK” menu. Press the Arrow button L to select

“AUTO CLOCK CH”. Press the ENTER button or the

Arrow button s or B until you locate Auto Clock Set station number. See step [3] on page 16.

Press the SETUP button to exit the screen.

5 Turn off the TV/VCR/DVD

Once the TV/VCR/DVD is turned off , it will periodically check and set the correct date and time.

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH

B AUTO CLOCK CH [ 45]

MANUAL CLOCK SET D.S.T. [OFF]

TV/VCR

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

- 18 - EN

1C29

CHANNEL SET UP

Make sure ...

•

Press the POWER button to turn on the TV/VCR/DVD.

1 Select “CHANNEL SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “CHANNEL SET UP”.

Then press the ENTER button.

2 Begin auto ch programming

Press the Arrow button K or L to point to “AUTO CH PROGRAMMING”.

Then press the ENTER button. The tuner scans and memorizes all

the active channels in your area.

3 After scanning

The tuner stops on the lowest memorized channel.

•

When AUTO CH PROGRAMMING is activated where there is no TV signal input, “NO TV SIGNALS” will appear on the display after the completion of the channel scanning.

•

The TV/VCR/DVD may recognize TV channels to be CATV channels by the receiving conditions. In this case, try auto ch programming again in the fine receiving conditions.

– CHANNEL SET UP –

ADD / DELETE CH (CATV)

B AUTO CH PROGRAMMING

The channels you no longer receive or seldom watch can be deleted from the memory. (Of course, you can add the deleted channel into the memory again.)

1 Select “CHANNEL SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “CHANNEL SET UP”.

Then press the ENTER button.

2 Select “ADD/DELETE CH”

Press the Arrow button K or L to point to “ADD/DELETE CH”.

Press the ENTER button.

3 Enter the desired channel number

Press the Arrow button K or L until your desired channel number appears. (You can also use the number buttons or the CHANNEL button K or L to enter it.)

•

You must precede single-digit channel numbers with a zero (Example: 02 ... 09).

•

When selecting cable channels which are higher than 99, press the +100 button first then press the last two digits. (Example: to select channel 125, first press the +100 button then press “2” and “5”).

4 Delete (or add) it from (or into) memory

Press the ENTER button. The channel number changes to light red. The channel is deleted from memory.

•

To delete another channel, repeat steps [3] to [4].

•

If you press the ENTER button again, the channel is memorized again.

5 Exit the channel setup mode

Press the SETUP button on the remote control to return to TV mode.

NOTE: To confirm that channel(s) has been deleted or added, press the CHANNEL button K or L.

DELETING (OR ADDING)

CHANNEL(S)

Added channel: Light blue. Deleted channel: Light red.

– CHANNEL SET UP –

B ADD / DELETE CH (CATV)

AUTO CH PROGRAMMING

ADD / DELETE

You can program the tuner to scan all the channels you receive in your area.

NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just select the TV/VCR/DVD channel selector to the output channel of the cable box or satellite box (Ex CH3), then select the channel to be viewed on the Cable Box or Satellite Box.

TV/VCR

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK

B CHANNEL SET UP

USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK

B CHANNEL SET UP

USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

(Example: CH8)

- 19 - EN

1C29

TV OPERATION

DEGAUSSING

Magnetism from nearby appliances and speakers might affect the color of the TV picture.

If this happens, move this TV/VCR/DVD away from the appliance. If the color is still not correct, unplug the power cord, then plug it in again 30 minutes later or so.

TV/VCR

WATCHING A TV PROGRAM

1 Turn on the TV/VCR/DVD

Press the POWER button to turn on the TV/VCR/DVD.

2 Select the channel number

Press the CHANNEL button K or L to select your desired channel number or press the number on the remote control.

Note for using the Number button on the remote control:

¡You must precede single-digit channel numbers

with a zero (for example: 02, 03, 04 and so on).

¡When selecting cable channels which are higher

than 99, press +100 first, then press the last two digits. (Example: to select channel 125, first press “+100” then press “2” and “5”.)

Remember: If the TV/VCR/DVD is connected to a cable box or satellite box, the TV/VCR/DVD must be on CH3 or CH4, then the channel to be viewed must be selected on the cable box or satellite box.

3 Adjust sound

Press the VOLUME button XXor

to adjust the volume.

NOTES:

•

If you press the CHANNEL button K or L in the DVD mode, you can change the TV channels.

Even if you turn off the TV/VCR/DVD in the DVD mode, when you turn it on again, it will go into the TV/VCR mode.

TV/VCR

PICTURE CONTROL

The TV/VCR/DVD’s picture controls – BRIGHT, CONTRAST, COLOR, TINT and SHARPNESS –

are preset to factory specifications. Although they are usually the best, you may need to make some further adjustments for a more natural looking image.

NOTES:

•

Procedures must be followed within 5 seconds or the Picture Control mode will be cancelled.

•

When setting the Picture Control, the Game mode will be cancelled.

Make sure ...

•

TV/VCR/DVD power must be turned on.

1 Select “PICTURE CONTROL”

Press the PICTURE button on the remote control.

2 Select item you want to adjust

Press the Arrow button K or L until desired control is displayed.

BRIGHT CONTRAST COLOR TINT SHARPNESS

3 Adjust the picture control

Press the Arrow button s or B to adjust to your desired level.

TV/VCR

•

If there is a power failure of any kind, the TV/VCR/DVD will retain its memory for this feature.

VOLUME 20

C C C C C C C C C C C C

BRIGHT

–

PP PP PP PP PP PP PP CC PP PP PP PP PP PP PP

Arrow Button { Arrow Button B

BRIGHT

CONTRAST

COLOR

TINT

SHAPNESS

to decrease brightness

to decrease contrast

to pale to brilliant

to purple

to soft

to increase brightness

to increase contrast

to green

to clear

- 20 - EN

1C29

CLOSED CAPTION SYSTEM

You can view specially labeled (cc) TV programs, movies, news and pre-recorded tapes with either a dialogue caption or text display.

CAPTION mode: By choosing the caption mode, you

can watch dramas, movies and news while captioning the dialogues and the contents of news.

TEXT mode: By choosing the text mode, you can

watch half screen text information if you want.

1-2: You may get these captions or text information

by selecting either “1” or “2”. Caption “2” is used, usually for a second language if available.

NOTE:

Not all programs are broadcast with closed captions. Your TV/VCR/DVD is designed to provide error free closed captions from high quality antenna, cable and VCR signals. Conversely, poor quality signals are likely to result in caption errors or no captions at all. Common signal conditions which may cause caption errors are listed below:

•

Automobile ignition noise

•

Electric motor brush noise

•

Weak snowy reception on TV screen

•

Multiplex signal reception displaying picture ghosts or airplane flutter.

•

Playback of poorly recorded or worn VCR tapes.

NOTE:

If the TV/VCR/DVD displays a black box on the TV screen, this means that the TV/VCR/DVD is set to the TEXT mode. To clear screen, select [CAPTION1], [CAPTION2] or [OFF].

Make sure ...

•

TV/VCR/DVD’s power must be turned on.

TV/VCR

1 Select “CAPTION”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “CAPTION”.

2 Select your desired caption menu

Press the ENTER button until your desired caption menu appears.

([CAPTION1], [CAPTION2], [TEXT1] or [TEXT2])

3 Exit the caption setting mode

Press the SETUP button on the remote control to return to TV mode.

TO CANCEL THE CLOSED CAPTION SYSTEM

Repeat steps [1] to [2], select [OFF] using the ENTER button. Press the SETUP button on the remote control to return to TV mode.

WHEN THE CLOSED CAPTION MODE IS ON

The On-Screen Display will disappear after 5 seconds.

•

It will also disappear when the MUTE button is pressed or when the PAUSE button is pressed while recording.

•

If there is a power failure of any kind, the TV/VCR/DVD will retain its memory for this feature.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [OFF]

ZERO RETURN TIME SEARCH INDEX SEARCH

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [CAPTION1]

ZERO RETURN TIME SEARCH INDEX SEARCH

- 21 - EN

1C29

5 Exit the V-Chip setting mode

Press the SETUP button on the remote control to exit the screen.

V-CHIP SET UP

Make sure ...

•

TV/VCR/DVD is turned on.

1 Select “V-CHIP SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to select “V-CHIP SET UP”.

Then press the ENTER button.

2 Enter Access code

Use the number buttons on the remote control to enter the access code.

•

For the first time set-up or in the event the TV/VCR/DVD has lost power, enter the default code of the numbers: 0000.

3 Select “TV RATING”

Press the Arrow button K or L to select “TV RATING”.

Then press the ENTER button.

4 Blocking TV programs

Press the Arrow button K or L to select “TV rating” that you wish to block.

Press the ENTER button to turn it [BLOCK].

•

When you select the rating category and turn it [BLOCK], the higher rating will turn [BLOCK] automatically. Also, the lower rating will turn [VIEW] automatically.

•

When you turn “TV-Y” to [VIEW], all ratings will turn to [VIEW] automatically.

TV/VCR

ACCESS CODE

_ _ _ _

V-CHIP SET UP

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

INDEX SEARCH

– V-CHIP SET UP –

B TV RATING

MPAA RATING CHANGE CODE

B TV–Y [VIEW]

TV–Y7 ( ) [VIEW] TV–G [VIEW] TV–PG ( ) [VIEW] TV–14 ( ) [VIEW] TV–MA( ) [VIEW]

Selection Rating Category Explanations

TV-Y Appropriate for all children TV-Y7 Appropriate for children seven and older TV-G General Audience TV-PG Parental Guidance suggested. TV-14 Unsuitable for children under 14

TV-MA Mature audience only

V-CHIP SET UP SUB RATINGS

When you select the ratings of TV-Y7,TV-PG,TV-14 or TV-MA you will have the option of selecting sub rating categories.

1 Select “V-CHIP SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to select “V-CHIP SET UP”. Then press the ENTER button.

2 Enter Access code

Use the number buttons on the remote control to enter the access code. (Default code is 0000.)

3 Select “TV RATING”

Press the Arrow button K or L to select “TV RATING”.

Then press the ENTER button.

4 Selecting “Sub-Ratings”

Press the Arrow button L or K to select the sub-rating you wish to block. Then, press the ENTER button twice.

•

When you select [TV-Y7]:

Press the Arrow button L or K to select “FV” (Fantasy Violence). Then press the ENTER button to select [BLOCK] or [VIEW].

•

When you select [TV-PG], [TV14] or [TV-MA]:

Press the Arrow button L or K to select “D”(Suggestive Dialog), “L”(Coarse Language), “S”(Sexual Situation) or “V”(Violence). Then press the ENTER button to select [BLOCK] or [VIEW].

Note: When you select [TV-MA], “D” does not appear on the TV screen.

•

The sub-ratings which are set to [BLOCK] appears next to the rating category in the TV rating menu.

5 Exit the V-Chip setting mode

Press the SETUP button on the remote control to enter the setting and exit the screen.

– V-CHIP SET UP –

B TV RATING

MPAA RATING CHANGE CODE

TV–Y7 [BLOCK]

B FV [BLOCK]

TV–PG [BLOCK]

B D [BLOCK]

L [BLOCK] S [BLOCK] V [BLOCK]

TV–Y [VIEW] TV–Y7 ( ) [VIEW] TV–G [VIEW]

B TV–PG (DLSV ) [BLOCK]

TV–14 (DLSV) [BLOCK] TV–MA ( LSV) [BLOCK]

ACCESS CODE

_ _ _ _

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

- 22 - EN

1C29

CHANGING V-CHIP BLOCKED PROGRAMMING

Note: To change the rating, the TV must be turned to a station that is not protected. If the (PROTECTED) appears on the screen, please change the channel to a station that is not protected.

1)Follow steps [1] to [2].

2)Press the Arrow button K or L to select “TV RATING”. Then press the ENTER button. Select a TV rating to be unblocked by pressing the Arrow button K or L.

Then press the ENTER button to unblock the rating.

3)Press the SETUP button on the remote control to exit the screen.

MPAA RATING SET UP

1 Select “V-CHIP SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to select “V-CHIP SET UP”. Then press the ENTER button.

2 Enter Access code

Use the number buttons on the remote control to enter the access code.

3 Select “MPAA RATING”

Press the Arrow button K or L to point to “MPAA RATING”.

Then press the ENTER button.

4 Select your desired item

Press the Arrow button K or L to point to your desired item.

Then press the ENTER button to select [BLOCK] or [VIEW].

•

When you select the rating category and turn it [BLOCK], the higher rating will turn [BLOCK] automatically. Also, the lower rating will turn [VIEW] automatically.

•

When you turn “G” to [VIEW], all ratings will turn to [VIEW] automatically.

Selection Rating Category Explanations

G General Audience PG Parental Guidance suggested. PG-13 Unsuitable for children under 13 R Restricted; under 17 requires accompa-

nying parent or adult guardian

NC-17 No one under 17 admitted X Mature audience only

– V-CHIP SET UP –

TV RATING

B MPAA RATING

CHANGE CODE

G [VIEW] PG [VIEW] PG–13 [VIEW]

B R [BLOCK]

NC–17 [BLOCK] X [BLOCK]

ACCESS CODE

_ _ _ _

5 Exit the V-Chip setting mode

Press the SETUP button on the remote control to exit the screen.

CHANGE ACCESS CODE

To change access code, follow the steps below.

1 Select “V-CHIP SET UP”

Press the SETUP button on the remote control. Press the Arrow button K or L to select “V-CHIP

SET UP”. Then press the ENTER button.

2 Enter Access code

Use the number buttons on the remote control to enter the access code.

The default code is 0000.

3 Select “CHANGE CODE”

Press the Arrow button K or L to select “CHANGE CODE”. Then press the ENTER button.

4 Enter New code

Use the number buttons to enter your desired access code in the NEW CODE space. Then enter the same code in the CONFIRM CODE space. V-CHIP SET UP screen appear on the screen.

•

If you enter wrong code, repeat step [4], making sure you enter the same new code exactly in the confirm code space.

5 Exit the V-Chip setting mode

Press the SETUP button on the remote control to exit the screen.

Note: If you unplug the power cord or a power failure occurs, the changed access code will be lost and will return to default (0000). Change your access code again as necessary.

ACCESS CODE

_ _ _ _

NEW CODE

X X X X

CONFIRM CODE

_ _ _ _

– V-CHIP SET UP –

TV RATING MPAA RATING

B CHANGE CODE

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

- 23 - EN

1C29

MTS (Multi-Channel Television sound) SYSTEM

You can record or listen to a program in MTS stereo.

CHECKING THE SELECTED MTS MODE

When you play a VHS tape, or receive a broadcast on the TV/VCR/DVD tuner channel you are watching, the status shown below will appear when you press the DISPLAY button on the remote control.

PLAY

12:00AM

HIFI CH 123

STEREO/SAP

SP COUNT 0:00:00

1) When a program is broadcast in stereo, STEREO appears on the TV screen.

2) When a program is broadcast in second audio, SAP appears on the TV screen.

3) When a program broadcast both in stereo and second audio, STEREO and SAP appear on the TV screen.

NOTE: Although a program may be broadcast in

both stereo and second audio, you cannot record in both stereo and second audio at the same time.

4) While the TV/VCR/DVD is set in HIFI stereo mode and playback mode. HIFI appears on the TV screen. While the TV/VCR/DVD is set in monaural (MONO) mode, HIFI disappears from the TV screen.

NOTE: If you play non-HIFI tapes while the

TV/VCR/DVD is set in HIFI, HIFI will disappear from the TV screen and the TV/VCR/DVD will play automatically in monaural.

MTS RECORDING/MONITOR MODE

Type of broadcast Display on STEREO/SAP Hi-Fi audio track (2-channel) Normal audio

the TV screen SELECTION L-channel R-channel track

Regular -None- -Invalid- Mono Mono Mono

(monaural audio)

Stereo broadcast STEREO -Invalid- L R L+R

Bilingual broadcast SAP STEREO* Main audio Main audio Main audio

program program program

SAP* Sub audio Sub audio Sub audio

program program program

Stereo & Bilingual STEREO STEREO* L R L+R

broadcast SAP

SAP* sub audio sub audio sub audio

program program program

*You must select the recording mode in TV AUDIO [STEREO] or [SAP] when you record a broadcast.

SAP

Second Audio Program, which means your program, can also be received in a second language or sometimes a radio station.

HIFI

High Fidelity which produces better sound than standard stereo TV/VCR/DVDs.

TV/VCR

- 24 - EN

1C29

SELECTING THE MTS SYSTEM

Make sure ...

•

TV/VCR/DVD power must be turned on.

TO SELECT HIFI MODE

Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “USER’S SET UP”. Then press the ENTER button.

2 Select “VCR AUDIO”

Press the Arrow button K or L to point to “VCR AUDIO”.

3 Select [HIFI]

Press the ENTER button until [HIFI] appears.

4 To return to TV mode

Press the SETUP button on the remote control to return to TV mode.

NOTES:

•

Normally “HIFI” should be selected for playback with HIFI sound.

•

When you play non-HIFI tapes, the TV/VCR/DVD will play automatically in the monaural mode.

•

The TV/VCR/DVD records automatically MTS broadcasts in HIFI stereo sound unless you select SAP mode recording before you begin recording.

TO SELECT STEREO, SAP, OR MONO

Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “USER’S SET UP”.

2 Select “TV AUDIO”

Press the Arrow button K or L to point to “TV AUDIO”.

3 Select [STEREO], [SAP] or [MONO]

Press the ENTER button until [STEREO], [SAP] or [MONO] appears.

4 To return to TV mode

Press the SETUP button on the remote control to return to TV mode.

NOTES:

•

You must select the recording mode, either TV AUDIO [STEREO] or [SAP] when you record a broadcast. Refer to

“MTS RECORDING/MONITOR

MODE”.

•

If you select second audio when second audio is not available, the TV/VCR/DVD will record normal audio.

•

The TV/VCR/DVD records automatically MTS broadcasts in HIFI stereo sound unless you select SAP mode recording before you begin recording.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– USER’S SET UP –

RENTAL [OFF] REPEAT PLAY [OFF] AUTO RETURN [OFF]

B VCR AUDIO [HIFI]

TV AUDIO [STEREO]

– USER’S SET UP –

RENTAL [OFF] REPEAT PLAY [OFF] AUTO RETURN [OFF] VCR AUDIO [HIFI]

B TV AUDIO [STEREO]

– USER’S SET UP –

RENTAL [OFF] REPEAT PLAY [OFF] AUTO RETURN [OFF]

B VCR AUDIO [HIFI]

TV AUDIO [STEREO]

TO SELECT MONO MODE

You can change the selection to “MONO” if you want to listen to HIFI tapes in normal audio playback.

Press the SETUP button on the remote control. Press the Arrow button K or L to point to “USER’S

SET UP”. Then press the ENTER button.

2) Press the Arrow button K or L to point to “VCR AUDIO”.

3) Press the ENTER button until [MONO] appears.

4) Press the SETUP button on the remote control to

return to TV mode.

TV/VCR

- 25 - EN

1C29

VIDEO CASSETTE

This TV/VCR/DVD will operate with any cassette that has the mark. For best results, we recommend the use of high-quality tapes. Do not use poor quality or damaged tapes.

REMOVING A CASSETTE

1)In the Stop mode, press the STOP/EJECT button on the TV/VCR/DVD. The cassette will eject.

2)Pull the cassette out of the cassette compartment.

3)Store the cassette in its case as shown.

NOTE:

• In DVD mode, Whether the cassette is with tab or

without tab you insert, it doesn’t start playing until you press the PLAY button. In TV/VCR mode, if the cassette without tab is inserted, playback will automatically start.

PRECAUTIONS

•

Avoid moisture. Moisture condensation may occur on the tape if it is moved from a cold place to a warm place or visa versa. Before using a tape with these conditions, to avoid damage of the tape and your TV/VCR/DVD, wait until the tape has warmed to room temperature and the moisture has evaporated.

•

Avoid extreme heat, high humidity and magnetic fields.

•

Do not tamper with the cassette mechanism.

•

Do not touch the tape with your fingers.

INSERTING A CASSETTE

Insert the cassette in the direction as shown. Push in gently, but continuously, on the center-back of the cassette until it is drawn into the TV/VCR/DVD. The TV/VCR/DVD will automatically turn on.

TWO DIFFERENT TAPE SPEEDS

Before recording, select the tape speed from : SP mode (Standard Play) or SLP mode (Super Long

Play). The table below shows the maximum recording/play-

back time using T60, T120 or T160 tapes in each mode.

Note: You can play back a tape recorded in LP mode (Long Play).

Tape Speed Recording/Playback Time

Type of tape

T60 T120 T160 SP mode 1 hour 2 hours 2-2/3 hours SLP mode 3 hours 6 hours 8 hours

ERASE PREVENTION

You can prevent accidental erasing of recording by breaking off the tab on the back edge of the cassette.

If you decide to record on the tape again, cover the hole with plastic tape.

CORRECT

Window

WRONG

Ta b

Plastic Tape

- 26 - EN

1C29

PLAYBACK

NORMAL PLAYBACK

Make sure ...

•

TV/VCR/DVD power must be turned on.

1 Insert a prerecorded tape

If the erase-protection tab has been removed, the TV/VCR/DVD will start playback automatically.

2 To begin playback

Press the PLAY button.

3 To stop playback

Press the STOP button when playback is completed.

NOTES:

•

If you press the PLAY button (of the TV/VCR side) in the DVD mode, you can start the VCR playback.

•

If you press the SOURCE or SELECT button during the VCR playback, it will stop and the mode will change to the DVD mode. In addition, the same function operates with the DVD side PLAY button or the OPEN/CLOSE button.

TV/VCR

TRACKING ADJUSTMENT

•

Tracking adjustment will be set automatically (Digital Tracking function) when you start playback.

•

However when playing pre-recorded tapes or tapes recorded on other VCR, noise lines (black and white streaks) may appear on the playback picture. If this occurs, you can adjust the tracking control manually by pressing the CHANNEL button K or L until the streaks disappear. To return to the DTR function, stop the tape once and start playback again.

•

You can reduce the noise lines by pressing the CHANNEL button K or L in slow mode too. Tracking adjustment in Slow mode will not be set automatically.

TV/VCR

STILL PICTURE

You can view a still picture on the TV screen during playback (the Still mode). Press the PAUSE button during playback. Only tapes recorded in the SLP mode will show the least amount of lines. Press the PLAY button to return to playback.

NOTES:

•

You can advance the picture one frame at a time by pressing the PAUSE button during the Still mode.

•

If it is left in the Pause mode for more than 5 minutes, the TV/VCR/DVD will automatically switch to the Stop mode.

TV/VCR

VERTICAL HOLD CONTROL

In the Pause/Still mode only, when the picture begins to vibrate vertically, stabilize the picture by pressing the CHANNEL button K or L.

NOTE:

If there are video noise lines on the screen, see Tracking Adjustment section.

TV/VCR

SLOW MOTION

Press the PAUSE button, then press the F.FWD g button to start the playback in slow motion. The TV/VCR/DVD mutes the sound during slow motion. Press the PLAY button to return to normal playback. NOTE: If it is left in the Slow mode for more than 5 minutes, the TV/VCR/DVD will automatically go into the Stop mode.

TV/VCR

PLAY

STOP

- 27 - EN

1C29

SPECIAL PLAYBACK

This function enables you to improve the picture quality when playing back worn cassettes such as rented tapes.

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “USER’S SET UP”.

Then press the ENTER button.

2 Set “RENTAL” to [ON]

Press the Arrow button K or L to point to “RENTAL”.

Press the ENTER button until [ON] appears.

3 Exit the Rental setting

Press the SETUP button on the remote control to return to the TV mode.

4 Start playback

Press the PLAY button to start playback. “RENTAL PLAY B” appears.

•

Once you select the Rental mode, it stays in effect even after you turn off the TV/VCR/DVD.

TO CANCEL THE RENTAL MODE

Repeat steps [1] to [2], select [OFF] using the ENTER button on the remote control. Press the SETUP button on the remote control to return to TV mode.

If there is a power failure of any kind, the TV/VCR/DVD will retain its memory for this feature.

TV/VCR

Make sure ...

•

TV/VCR/DVD’s power must be turned on.

•

Insert a prerecorded tape.

RENTAL PLAYBACK

The TV/VCR/DVD has the auto repeat function that allows you to repeat a tape indefinitely without touching the PLAY button.

ALL REPEAT: Repeat playback from the beginning

to the end of the tape.

BLANK REPEAT: Repeat playback from the begin-

ning to a blank part, which is blank for more than 10 seconds.

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “USER’S SET UP”.

Then press the ENTER button.

2 Select “ALL” or “BLANK”

Press the Arrow button K or L to point to “REPEAT PLAY”.

Press the ENTER button repeatedly until your desired selection [ALL] or [BLANK] appears.

3 Exit the Repeat Play setting

Press the SETUP button on the remote control to return to the TV mode.

4 Start playback

Press the PLAY button to start the Repeat Play. “REPEAT PLAY B” appears.

•

Once you select the Repeat Play mode, it stays in effect even after you turn off the TV/VCR/DVD.

•

If the Rental mode is set [ON], the “RENTAL PLAY B” display has priority.

TO CANCEL THE REPEAT PLAY MODE

Repeat steps [1] to [2], select [OFF] using the ENTER button on the remote control. Press the SETUP button on the remote control to return to TV mode.

If there is a power failure of any kind, the TV/VCR/DVD will retain its memory for this feature.

TV/VCR

AUTO REPEAT PLAYBACK

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

–

USER’S SET UP

–

B RENTAL [ON]

REPEAT PLAY [OFF] AUTO RETURN [OFF] VCR AUDIO [HIFI] TV AUDIO [STEREO]

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

–

USER’S SET UP

–

RENTAL [OFF]

B REPEAT PLAY [ALL]

AUTO RETURN [OFF] VCR AUDIO [HIFI] TV AUDIO [STEREO]

- 28 - EN

1C29

Make sure ...

•

TV/VCR/DVD power must be turned on.

•

Insert a tape.

This function allows you to search easily a beginning point that you want to review by rewinding or fast forwarding.

NOTE: Zero Return WILL

NOT work on a blank tape or a

blank portion of a tape.

1 Stop a tape at your desired point

Rewind or fast forward the tape to the beginning point at which you want to review.

2 Reset the counter to 0:00:00

Press the C.RESET button repeatedly.

3 Begin recording or playback

Press the RECORD or PLAY button. Press the STOP button when recording or playback is completed.

4 To activate “ZERO RETURN” mode

Press the SETUP button on the remote control. Press the Arrow button K or L to point to “ZERO RETURN”. Then press the ENTER button. The counter will appear on the TV screen. The tape will automatically stop when the counter returns to 0:00:00.

TV/VCR

ZERO RETURN

The Time Search function makes it possible to quickly advance the tape to your desired position simply by entering the exact amount of playback time you want to skip.

NOTES:

•

Time Search can be set up to a maximum of 9 hours 50 minutes (9:50) by 10 minutes at a time.

•

This function will not operate in recording mode.

•

This function is not operative when a cassette tape is not inserted in the TV/VCR/DVD.

In the example below: To watch a program before/ after 2 hour 50 minutes from the present position, in either direction.

TV/VCR

TIME SEARCH

1 Insert a tape

2 Select “TIME SEARCH” mode

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “TIME SEARCH”.

Then press the ENTER button.

3 Enter your desired time

Press the Arrow button K or L until your desired time appears. (Example: “2:50” stands for 2 hours 50 minutes)

If you wish to cancel the Time Search at this point, press the SETUP button on the remote control.

4 Begin Time Search

By pressing the Arrow button s or B, the TV/VCR/DVD will rewind or fast forward to the specified point.

The time counts down as the searching progresses. When 0:00 is reached, the tape will start playback automatically.

TO CANCEL THE TIME SEARCH at this point

Press the STOP/EJECT button on the TV/VCR/DVD or the STOP button on the remote control. This will delete the selected time.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF]

B ZERO RETURN

TIME SEARCH INDEX SEARCH

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN

B TIME SEARCH

INDEX SEARCH

TIME SEARCH

2 : 50

PICTURE SEARCH

This feature is very useful in finding or skipping over a particular scene on a tape. In this mode, the sound will be muted.

1)You may view a video tape at a high speed in either a forward or reverse direction by pressing the

F.FWD

or REW

button

during play-

back. (in the SP / LP / SLP modes)

NOTE:

•

If you press the F.FWD

or REW

button on the front panel in the DVD mode, the VCR forward or reverse will start. Please press the STOP / EJECT button once to stop it, twice to eject it.

Press it again and the TV/VCR/DVD will now search in super high speed. (in the LP / SLP modes only)

NOTE:

•

Tapes recorded in the SP or LP mode will display a noise bar on the TV screen and the picture may revert to Black and White. This is normal.

3)Press the PLAY button to return to normal speed.

TV/VCR

- 29 - EN

1C29

INDEX SEARCH

This feature provides a method of indexing the starting point so that it can be easily returned to in either fast forward or rewind mode.

•

The index mark will be made automatically when the RECORD button is pressed. It will also be marked at the starting point of Timer recording and OTR.

•

The index mark will not be recorded if the PAUSE button is pressed and released during recording.

•

The time gap between making the index marks on the tape should be greater than 1 minute for SP recording, 2 minutes for LP recording and 3 minutes for SLP recording.

•

In some cases, the index mark at the beginning of video tape cannot be detected.

Example: You are watching program number 4 and

want to fast forward to program number 7. You must skip three programs.

TV/VCR

1 Select “INDEX SEARCH”

Press the SETUP button on the remote control. Press the Arrow button K or L to point to “INDEX SEARCH”. Then press the ENTER button.

2 Enter your desired number

Press the Arrow button K or L until the number of programs that you want to skip appears. (Example: “03” for 3 programs)

•

The Index Search mode will be canceled if the procedures are not activated in 30 seconds.

3 Begin Index Search

Press the Arrow button s or B. The TV/VCR/DVD begins rewinding or fast forwarding to the beginning of desired program.

NOTE: Every time an index signal is skipped, the number in the program indicator decreases by one.

4 After Index Search

When the preset program is reached, the TV/VCR/DVD will start playback automatically.

•

A video cassette must be inserted in the TV/VCR/DVD for this function to work.

•

The number of Index Searches can be set up to 20.

•

This function will not operate in the recording mode.

•

When you want to cancel the Index Search while in progress, press the STOP button.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

B INDEX SEARCH

INDEX SEARCH

0 3

SPECIAL FEATURES

REAL TIME TAPE COUNTER

This shows the elapsed recording or playback time in hours, minutes, and seconds. (The displayed time will not change on a blank tape or blank portions on the tape.)The “–” indication will appear when the tape has rewound further than “0:00:00” on the tape counter.

TV/VCR

AUTO REWIND-EJECT

•

When the end of a tape is reached during recording, playback, or fast-forward, the tape will automatically rewind to the beginning. After rewinding finishes, the TV/VCR/DVD will eject the tape and turn itself off.

•

This function is operative when Repeat Play is set to the [OFF] position.

•

The tape will not auto-rewind during timer recording or One Touch Recording.

TV/VCR

CURRENT PLAYBACK PROGRAM

Beginning of tape

Pro.1 Pro.2 Pro.3 Pro.4 Pro.5 Pro.6 Pro.7

4321123

INDEX MARK

End of tape

- 30 - EN

1C29

RECORDING

Make sure ...

•

TV/VCR/DVD power must be turned on.

•

Insert a cassette tape with its erase prevention tab in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.)

NOTES:

•

This TV/VCR/DVD will ONLY record and view the same channel.

•

This TV/VCR/DVD cannot record the contents from the built-in DVD.

You can ONL

Y watch the same TV program that is

being recorded.

1 Select the channel to be recorded

Press the number buttons on the remote control or the CHANNEL button K or L.

Remember: If the TV/VCR/DVD is connected to a cable box or satellite box, the TV/VCR/DVD must be on CH3 or CH4, then the channel to be recorded must be selected on the cable box or satellite box.

2 Select the tape speed

Press the SPEED button to select the desired tape speed (SP/ SLP).

3 Begin recording

Press the RECORD button.

4 Stop recording

Press the STOP button when recording is completed.

TV/VCR

NORMAL RECORDING

Press the PAUSE button to temporarily stop recording.

Press the PAUSE or RECORD button to resume recording.

NOTES:

•

After 5 minutes, the TV/VCR/DVD will automatically switch to the Recording mode to prevent tape damage.

•

If “CLOSED CAPTION (ON)” is selected, the OnScreen Display will appear for 5 seconds, then disappear.

TV/VCR

SKIPPING UNWANTED

SCENES DURING RECORDING

CH 10

REC

PAUSE

+ 75 hidden pages

Funai MGTD204 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
