Funai DCC1903 User Manual

WARNING:TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE

PORTABLE CART WARNING

S3126A

TO RAIN OR MOISTURE.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The caution marking is located on the rear of the cabinet.

1.Read instructions-All the safety and operating instructions

should be read before the appliance is operated.

2.Retain Instructions-The safety and operating instructions

should be retained for future reference.

3.Heed Warnings-All warnings on the appliance and in the

operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions

should be followed.

5.Cleaning-Unplug TV/VCR from the wall outlet before

cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6.Attachments-Do not use attachments not recommended by

the TV/VCR manufacturer as they may cause hazards.

7.Water and Moisture-Do not use this TV/VCR near water-

for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8.Accessories-Do not place this TV/VCR on an unstable cart,

stand, tripod, bracket, or table. The TV/VCR may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the TV/VCR. Any mounting of the appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

GEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMP ANYING THE APPLIANCE.

IMPORTANT SAFEGUARDS

Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

9.Ventilation-Slots and openings in the cabinet and the back

or bottom are provided for ventilation and to ensure reliable operation of the TV/VCR and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the TV/VCR on a bed, sofa, rug, or other similar surface. This TV/VCR should never be placed near or over a radiator or heat register. This TV/VCR should not be placed in a builtin installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10.Power Sources-This TV/VCR should be operated only

from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For TV/VCRs intended to operate from battery power, or other sources, refer to the operating instructions.

11.Grounding or Polarization-This TV/VCR is equipped

with a polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12.Power-Cord Protection-Power-supply cords should be

routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

THIS SYMBOL INDICATES THAT DAN-

- 2 - EN

9I03

EXAMPLE OF ANTENNA GROUNDING AS P ER

NATIONAL ELECT RICAL CODE

S2898A

FIGURE A

ELECTRIC SERVICE EQUIPMENT

NEC - NATIONAL ELECTRICAL CODE

GROUND

CLAMP

ANTENNA

LEAD IN WIRE

ANTENNA

DISCHARGE UNI T (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDI NG ELECTRODE SYSTEM (NEC ART 250, PART H)

13.Outdoor Antenna grounding-If an outside antenna or

cable system is connected to the TV/VCR, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14.Lightning-For added protection for this TV/VCR receiver

during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV/VCR due to lightning and power-line surges.

15.Power Lines-An outside antenna system should not be

located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16.Overloading-Do not overload wall outlets and extension

cords as this can result in a risk of fire or electric shock.

17.Object and Liquid Entry-Never push objects of any kind

into this TV/VCR through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the TV/VCR.

18.Servicing-Do not attempt to service this TV/VCR yourself

as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19.Damage Requiring Service-Unplug this TV/VCR from

the wall outlet and refer servicing to qualified service per-

sonnel under the following conditions: a. When the power-supply cord or plug is damaged or frayed. b. If liquid has been spilled, or objects have fallen into the

TV/VCR. c. If the TV/VCR has been exposed to rain or water. d. If the TV/VCR does not operate normally by following the

operating instructions. Adjust only those controls that are

covered by the operating instructions, as improper adjust-

ment of other controls may result in damage and will often

require extensive work by a qualified technician to restore

the TV/VCR to its normal operation. e. If the TV/VCR has been dropped or damaged in any way. f. When the TV/VCR exhibits a distinct change in perfor-

mance-this indicates a need for service.

20.Replacement Parts-When replacement parts are required,

be sure the service technician has used replacement parts

specified by the manufacturer that have the same character-

istics as the original part. Unauthorized substitutions may

result in fire, electric shock, injury to persons or other haz-

ards.

21.Safety Check-Upon completion of any service or repairs to

this TV/VCR, ask the service technician to perform routine

safety checks to determine that the TV/VCR is in proper

operating condition.

22.Heat-This TV/VCR product should be situated away from

heat sources such as radiators, heat registers, stoves, or

other products (including amplifiers) that produce heat.

Note to CATV system installer:

This reminder is provided to call the CATV system installer ’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

- 3 - EN

9I03

PRECAUTIONSPRECAUTIONS

LOCATION

For safe operation and satisfactory performance of your TV/VCR, keep the following in mind when selecting a place for its installation:

Shield it from direct sunlight and keep it away

•

from sources of intense heat. Avoid dusty or humid places.

•

Avoid places with insufficient ventilation for proper

•

heat dissipation. Do not block the ventilation holes at the top and bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

Install unit in a horizontal position.

•

Avoid locations subject to strong vibration.

•

Do not place the TV/VCR near strong magnetic fields.

•

Avoid moving TV/VCR to locations where temper-

•

ature differences are extreme.

AVOID THE HAZARDS OF

ELECTRICAL SHOCK AND FIRE

Do not handle the power cord with wet hands.

•

Do not pull on the power cord when disconnecting

•

it from an AC wall outlet. Grasp it by the plug. If, by accident, water is spilled on your unit, unplug

•

the power cord immediately and take the unit to our Authorized Service Center for servicing.

Do not put your fingers or objects into the

•

TV/VCR cassette holder. Do not place anything directly on top of the unit.

•

WARNING

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, or after heating a cold room or under conditions of high humidity. If a tape is played in a TV/VCR which has moisture, it may damage the tape and TV/VCR. Therefore when the condensation occurs inside the unit, turn the POWER button on and allow at least 2 hours for the unit to dry out.

CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

IMPORTANT COPYRIGHT INFORMATION

Unauthorized recording or use of broadcast television programming, video tape, film or other copyrighted material may violate applicable copyright laws. We assume no responsibility for the unauthorized duplication, use, or other acts which infringe upon the rights of copyright owners.

The serial number of this product may be found on the back of the unit. No other TV/VCR has the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase Dealer Purchase from Dealer Address Dealer Phone No. Model No. Serial No.

- 4 - EN

9I03

TABLE OF CONTENTS

C IMPORTANT SAFEGUARDS . . . . . . . . . . . . .2

C PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . .4

LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

AVOID THE HAZARDS OF ELECTRICAL

SHOCK AND FIRE . . . . . . . . . . . . . . . . . . . . . .4

WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

C FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

C SUPPLIED ACCESSORIES . . . . . . . . . . . . . . .6

C VIDEO CASSETTE . . . . . . . . . . . . . . . . . . . . .7

C OPERATING CONTROLS AND FUNCTIONS 8

C PREPARATION FOR USE . . . . . . . . . . . . . . .10

ANTENNA/CABLE CONNECTIONS . . . . . . .10

INSTALLING THE BATTERIES . . . . . . . . . . .11

EXTERNAL INPUT MODE . . . . . . . . . . . . . .11

C SET UP FOR USE . . . . . . . . . . . . . . . . . . . . .12

CHANNEL SET UP FOR THE FIRST TIME .12

DELETING (OR ADDING) CHANNEL . . . . .12

CHANNEL SET UP AGAIN . . . . . . . . . . . . . .13

SELECTING THE LANGUAGE . . . . . . . . . . .13

DAYLIGHT-SAVING TIME . . . . . . . . . . . . . .13

CLOCK SET UP (AUTO / MANUAL) . . . . . .14

C ON SCREEN DISPLAY . . . . . . . . . . . . . . . . .16

C SPECIAL FEATURES . . . . . . . . . . . . . . . . . .16

DEGAUSSING . . . . . . . . . . . . . . . . . . . . . . . .16

REAL TIME TAPE COUNTER . . . . . . . . . . . .16

AUTO REWIND-EJECT . . . . . . . . . . . . . . . . .16

C TV OPERATION . . . . . . . . . . . . . . . . . . . . . . .17

WATCHING ATV PROGRAM . . . . . . . . . . . .17

GAME MODE . . . . . . . . . . . . . . . . . . . . . . . . .17

PICTURE CONTROL . . . . . . . . . . . . . . . . . . .17

CLOSED CAPTION SYSTEM . . . . . . . . . . . .18

V-CHIP SET UP . . . . . . . . . . . . . . . . . . . . . . . .19

C PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . .21

NORMAL PLAYBACK . . . . . . . . . . . . . . . . . .21

TRACKING ADJUSTMENT . . . . . . . . . . . . . .21

PICTURE SEARCH . . . . . . . . . . . . . . . . . . . .21

STILL PICTURE . . . . . . . . . . . . . . . . . . . . . . .21

NOISE CANCEL (in the Still mode) . . . . . . . .21

VERTICALHOLD CONTROL . . . . . . . . . . . .21

C SPECIAL PLAYBACK . . . . . . . . . . . . . . . . . .22

RENTAL PLAYBACK . . . . . . . . . . . . . . . . . . .22

AUTO REPEAT PLAYBACK . . . . . . . . . . . . .22

C SEARCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

ZERO RETURN . . . . . . . . . . . . . . . . . . . . . . .23

TIME SEARCH . . . . . . . . . . . . . . . . . . . . . . . .23

C RECORDING . . . . . . . . . . . . . . . . . . . . . . . . .24

NORMAL RECORDING . . . . . . . . . . . . . . . . .24

SKIPPING UNWANTED SCENES DURING

RECORDING . . . . . . . . . . . . . . . . . . . . . . . . .24

OTR (One Touch Recording) . . . . . . . . . . . . . .25

COPYING A VIDEO CASSETTE

(Requires a VCR or camcorder) . . . . . . . . . . . .25

C TIMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

AUTOMATIC TIMER RECORDING . . . . . . .26

TIMER PROGRAM EXTENSION . . . . . . . . .27

HINTS FOR AUTOMATIC TIMER

RECORDING . . . . . . . . . . . . . . . . . . . . . . . . .28

AUTO RETURN . . . . . . . . . . . . . . . . . . . . . . .28

WAKE UP TIMER . . . . . . . . . . . . . . . . . . . . . .28

SLEEP TIMER . . . . . . . . . . . . . . . . . . . . . . . . .29

C MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . .29

C TROUBLESHOOTING GUIDE . . . . . . . . . . .30

C SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . .31

C CABLE CHANNEL DESIGNATIONS . . . . . .31

C WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . .32

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

- 5 - EN

9I03

FEATURES

Owner’s Manual

Infrared remote control

•

Bilingual on screen menu display selectable in

•

English or French Real time counter–This shows the elapsed record-

•

ing or playback time in hours, minutes, and seconds. The “–” indication will appear when the tape is rewound further than the tape counter position “0:00:00”.

181 channel capability PLL frequency synthesiz-

•

er tuner with direct station call–

be necessary to view scrambled cable channels.)

Auto Clock Setting–Allows you to set the clock

•

function from a PBS broadcast station.

Closed caption system–You may view specially

•

labeled (cc) TV programs, movies, news, prerecorded tapes, etc. with either a dialogue caption or text display added to the program.

Game mode–Automatically sets external input

•

mode and allows TV/VCR display to be suitable for use with TV games.

Auto power on and off system–Automatically

•

turns on the TV/VCR when you insert the cassette, turns off after auto-rewind, and ejects when the beginning of the tape is reached.

Auto rewind when the end of a tape is

•

reached–

timer recording.

2 Step picture search operation–You can view a

•

video program at a high speed or super high speed in either a forward or reverse direction in LP and SLP mode. For SP mode only high speed.

Three different playback tape speeds : SP/LP/SLP

•

Two different recording tape speeds : SP/SLP

•

Auto Head Cleaner–Automatically cleans video

•

heads as you insert or remove a cassette.

This function doesn’t occur when using

(A converter may

Zero Return–The tape returns to counter of

•

0:00:00 by rewinding or fast forwarding.

Still–“Freeze” the picture at any time, for close

•

viewing of a particular scene. Only tapes recorded in SLP mode will show a fairly clear picture.

Digital Auto Tracking (DTR)–Automatically

•

adjusts the tracking for each tape you play.

Rental play mode–Improves playback picture

•

quality from worn tapes, such as rental tapes.

Auto repeat–Allows you to repeat the playing of a

•

tape indefinitely without pressing the PLAY button.

Time search–Let you set the TV/VCR to advance

•

the tape by entering the desired playback time you want to skip.

OTR (One Touch Recording)–Instant timed

•

recording from 30 to 480 minutes is possible at the push of the REC/OTR button.

1 Year, 8 events (including Daily and Weekly

•

Timer Recording)–

record up to 8 programs at different times on different channels up to 1 year in advance. The Daily timer allows recordings to be made of daily broadcasts, and the Weekly timer allows recording to be made once a week up to the end of the tape.

Auto return–After timer recording is finished, the

•

TV/VCR can return to the beginning of the recording.

Wake up/Sleep timer–Allows you to have the

•

TV/VCR automatically turn on or off at a desired time.

Timer Program Extension–Allow you to shift the

•

time schedule for automatic timer recording.

V-CHIP–Enables parents to prevent their children

•

from watching inappropriate material on TV.

The built-in timer allows you to

SUPPLIED ACCESSORIES

Remote Control Unit

PART NO. (N0150UD or N0107UD)

Depending on your antenna system, you may need different types of Combiners (Mixer) or Separators

•

(Splitter). Contact your local electronics store for these items. We do not recommend the use of universal remote controls. Not all of the functions may be controlled with

•

a universal remote control. If you decide to use a universal remote control with this unit, please be aware that the code number given may not operate this unit. In this case, please call the manufacturer of the universal remote control.

2 AA Batteries Rod Antenna

(13 inch model only)

PART NO. (0EMN00673 or 0EMN01755 or 0EMN01599)

- 6 - EN

Owner’s Manual

PART NO. (0EMN02176)

9I03

VIDEO CASSETTE

This TV/VCR will operate with any cassette that has the mark. For best results, we recommend the use of high-quality tapes. Do not use poor quality or damaged tapes.

PRECAUTIONS

Avoid moisture. Moisture condensation may occur

•

on the tape if it is moved from a cold place to a warm place or visa versa. Before using a tape with these conditions, to avoid damage of the tape and your TV/VCR, wait until the tape has warmed to room temperature and the moisture has evaporated.

Avoid extreme heat, high humidity and magnetic

•

fields. Do not tamper with the cassette mechanism.

•

Do not touch the tape with your fingers.

•

TWO DIFFERENT TAPE SPEEDS

Before recording, select the tape speed from : SP mode (Standard Play) or SLP mode (Super Long

Play). The table below shows the maximum recording/play-

back time using T60, T120 or T160 tapes in each mode.

Tape Speed Recording/Playback Time

Type of tape

SP mode 1 hour 2 hours 2-2/3 hours SLP mode 3 hours 6 hours 8 hours

Note: You can play back a tape recorded in LP mode (Long Play).

T60 T120 T160

INSERTING A CASSETTE

Insert the cassette in the direction as shown. Push in gently, but continuously, on the center-back of the cassette until it is drawn into the TV/VCR. The TV/VCR will automatically turn on.

Window

CORRECT

WRONG

REMOVING A CASSETTE

1)In the Stop mode, press the EJECT button on the remote control or press the STOP/EJECT button on the TV/VCR. The cassette will eject.

2)Pull the cassette out of the cassette compartment.

3)Store the cassette in its case as shown.

ERASE PREVENTION

You can prevent accidental erasing of recording by breaking off the tab on the back edge of the cassette.

Tab

If you decide to record on the tape again, cover the hole with plastic tape.

Plastic Tape

- 7 - EN

9I03

OPERATING CONTROLS AND FUNCTIONS

AUDIO

EARPHONE

VIDEO

STOP/EJECT REW

PLAY

F.FWD REC/OTRCHANNEL

VOLUME

POWER

1 92 3 4 5 6 78131011 1412

POWER

WAKE-UP

/SLEEP

123

456

789

+100

EJECT

CHANNEL

RETURN

REW

PLAY

STOP

F.FWD

GAME

RECORD

PAUSE/STILL

SPEED

TIME SEARCH

CHANNEL

T-PROG.

CLEAR

COUNTER

RESET

DISPLAY MUTE

VOLUME

11 18

19 20

22 21

This manual covers 13" and 19". The operation of the two models are exactly the same except the appearance. 19" model is illustrated in this manual.

NOTE:

We do not recommend the use of universal remote controls. Not all of the functions may be controlled with

•

a universal remote control. If you decide to use a universal remote control with this unit, please be aware that the code number given

may not operate this unit. In this case, please call the manufacturer of the universal remote control.

- TV/VCR FRONT P ANEL -

- REMOTE CONTROL -

1 VIDEO input jack– Connect to the video output

jack of your video camera or another VCR.

2 AUDIO input jack– Connect to the audio output

jack of your audio equipment, video camera or another VCR.

3 POWER button– Press to turn TV/VCR on and

off. Press to activate timer recording.

4 VOLUME

XX/ YY

buttons– Adjust the volume

level.

5 CHANNEL K / L buttons– Press to select the

desired channels for viewing or recording. You may display the main menu on the TV screen

by pressing repeatedly this button on the TV/VCR.

TRACKING function– Press to minimize video

‘noise’ (lines or dots on screen) during playback mode. (See page 21.)

6 Remote Sensor Window– Receives the infrared

signals from the remote control.

7 STOP button– Press to stop the tape motion.

EJECT button– Press in the Stop mode to remove

tape from TV/VCR.

L button–

Press to select setting modes from the on screen

•

menu. Press to enter digits when setting program.

•

(for example: setting clock or timer program)

- 8 - EN

9I03

- REAR VIEW -

ANT.

2726

8 REW button– Press to rewind the tape, or to view

the picture rapidly in reverse during playback mode. (Rewind Search)

s button–

Press to select a mode from a particular menu.

•

(for example: LANGUAGE or USER’S SET UP)

9 PLAY button– Press to begin playback.

K button–

Press to select setting modes from the on screen

•

menu. Press to enter digits when setting program.

•

(for example: setting clock or timer program)

10 F.FWD button– Press to rapidly advance the tape,

or to view the picture rapidly in forward during playback mode. (Forward Search)

B button–

When setting program (for example: setting clock

•

or timer program), press to determine your selection and proceed to the next step you want to input.

Press to determine setting modes from on screen

•

menu. Press to select a mode from a particular menu.

•

(for example: LANGUAGE or USER’S SET UP)

REC button– Press for manual recording.

OTR button–Activates One Touch Recording.

(only on the TV/VCR)

12 RECORD indicator– Flashes during recording.

Lights up in the Stand-by mode for Timer Recording.

13 EARPHONE jack– Connects to earphones (not

supplied) for personal listening. The size of jack is 1/8” monaural (3.5mm).

14 Cassette compartment 15 Number buttons– Press to select desired channels

for viewing or recording. To select channels from 1 to 9, first press the 0 button and then 1 to 9.

+100 button– When selecting cable channels

which are higher than 99, press this button first, then press the last two digits. (To select channel 125, first press the “+100” button then press “2” and “5”).

16 MENU button– Press to display the main menu on

the TV screen.

17 DISPLAY button– Display the counter or the cur-

rent channel number and current time on the TV screen. (See page 16.)

18 SPEED button– Press to choose the desired

recording speed:SP/SLP.

19 T-PROG. CLEAR button– Press to cancel a setting

of timer program. (See page 27.)

COUNTER RESET button– Press to reset counter

to 0:00:00.

20 GAME button– Sets the game mode and external

input mode at the same time. (See page 17.)

21 TIME SEARCH button– Press to activate Time

Search mode.

22 PAUSE/STILL button– Press to temporarily stop

the tape during the recording or to view a still picture during playback.

23 MUTE button– Mutes the sound. Press it again to

resume sound.

24 CHANNEL RETURN button– Press to go back to

the previously viewed channel. For example, pressing this button once will change channel display from 3 (present channel) to 10 (previously viewed channel), and pressing it a second time will return from 10 to 3.

25 WAKE-UP/SLEEP button– Sets the Wake up or

Sleep Timer. (See page 28 and 29.)

26 Power cord– Connect to a standard AC outlet

(120V/60Hz).

27 ANT. terminal– Connect to an antenna or cable

system.

- 9 - EN

9I03

PREPARATION FOR USE

ANT.

ANTENNA/CABLE

CONNECTIONS

VHF/UHF COMBINED ANTENNA

The VHF/UHF Rod Antenna (supplied with 13 inch model only) is detachable. Insert the stem of the antenna into the hole on the upper-back portion of the TV/VCR.Connect the VHF/UHF Rod Antenna or VHF/UHF Combination Antenna to the ANT. terminal of the TV/VCR as shown in the diagram below. For the best reception, fully extend the VHF/UHF Rod Antenna and make the necessary adjustments. (Avoid touching the top section when adjusting.)

NOTE:

Before plugging the Rod antenna into antenna terminal, check that the pin is not bent. If it is bent, straighten the pin as illustrated, then plug the pin into antenna terminal.

Bent pin

Cable Plug

(Needs to be straightened)

Rod Antenna (Supplied with 13” model)

(Straight pin)

VHF/UHF Antenna (Not supplied)

VHF/UHF SEPARATE ANTENNAS

In some areas it will be necessary to use an outdoor antenna.

VHF Antenna (Not supplied)

UHF Antenna

VHF/UHF Combiner (Not supplied)

Flat twin-lead cable

(Not supplied)

CABLE WITHOUT CONVERTER/ DESCRAMBLER BOX

Use this connection if your cable system connects directly to your TV/VCR without a converter box.

By using this connection you can:

1) Use the TV/VCR remote to select channels.

2) Program one or more unscrambled channels for

Automatic Timer Recording.

NOTE: This unit will ONL same channel.

From Cable System

Y record and view the

NOTE:

The connection of an indoor antenna may not always give acceptable TV reception.

Antenna/Cable Connections Continued on the Next Page.

75-ohm Coaxial Cable (Not supplied)

- 10 - EN

9I03

CABLE WITH CONVERTER/

ANT.

OUT

ANT.

DESCRAMBLER BOX OR SATELLITE BOX

If your cable service supplies you with a converter box or if you use a satellite system, you can use the basic connection shown here.

By using this connection you can also record scrambled channels. However, channel selection must be made with the converter box or satellite box. This means that channels cannot be changed using the TV/VCR Remote Control. Unattended timer recording is limited to one channel at a time.

Satellite Box or Cable Box (Not supplied)

From Cable System or Satellite Dish

INSTALLING THE BATTERIES

1)Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.

2)Insert 2 “AA” penlight batteries into the battery compartment in the direction indicated by the polarity (+/-) markings.

3)Replace the cover.

75-ohm Coaxial Cable (Not supplied)

TO RECORD A SCRAMBLED/UNSCRAMBLED CHANNEL

1. Set the TV/VCR channel selector to the output channel of the Cable Converter Box or Satellite Box. (Ex. CH3)

2.Select the channel to record from your Cable

Converter Box or Satellite Box.

EXTERNAL INPUT MODE

When using an external input signal (another VCR or camcorder), connect the player’s audio/video output cables to the AUDIO IN/ VIDEO IN jacks of your TV/VCR. Then press the CHANNEL K or L button until “AUX” appears on the screen.

AUX

- 11 - EN

9I03

SET UP FOR USE

You can program the tuner to scan all the channels you receive in your area. NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just

select the TV/VCR channel selector to the output channel of the cable box or satellite box (Ex CH3). Then select the channel to be viewed on the Cable Box or Satellite Box.

CHANNEL SET UP FOR THE

FIRST TIME

1 Plug in the TV/VCR power cord

Plug the TV/VCR power cord into a standard AC outlet.

NOTE:

If some digits appear in the corner of

•

the screen, press the POWER button without unplugging the power cord.

2 Turn on the TV/VCR

Press the POWER button to turn on the TV/VCR.

3 Select “ENGLISH” or “FRANÇAIS”

Select “ENGLISH” or “FRANÇAIS”=French using the F.FWD/B or REW/s button. “[ ]” indicate the selected language.

4 Begin auto preset

Press the PLAY/K or STOP/L but- ton to point to “AUTO PRESET”.

Then press the F.FWD/B button. The tuner scans and memorizes all

active channels in your area.

NOTES:

The TV/VCR distinguishes between standard TV

•

channels and cable channels. If you want to play or record a video tape

•

BEFORE MENU button on the remote control. To preset the tuner again, see “CHANNEL SET UP AGAIN” on page 13.

The TV/VCR may recognize TV channels to be

•

CATV channels by the receiving conditions. In this case, try auto preset again in the fine receiving conditions.

presetting the tuner, you must press the

– SET UP –

B LANGUAGE

[ENGLISH] FRANÇAIS

AUTO PRESET

– SET UP –

LANGUAGE [ENGLISH] FRANÇAIS

B AUTO PRESET

DELETING (OR ADDING)

CHANNEL

The channels you no longer receive or seldom watch can be deleted from the memory. (Of course, you can add the deleted channel into the memory again.)

1 Select “CHANNEL SET UP”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L but- ton to point to “CHANNEL SET UP”.

Then, press the F.FWD/B button.

2 Select “ADD/DELETE CH”

Press the PLAY/K or STOP/L but- ton to point to “ADD/DELETE CH”.

Press the F.FWD/B button.

3 Enter the desired channel number

Press the PLAY/K or STOP/L but- ton until your desired channel number appears. (You can also use the number buttons or the CHANNEL K/L button to enter it.) (Example: CH8)

4 Delete (or add) it from (into) memory

Press the F.FWD/B or REW/s button. The channel number changes to light red. The channel is deleted from memory.

To delete another channel, repeat steps [3] and [4].

•

If you press the F.FWD/B or REW/s button

•

again, the channel is memorized again.

Added channel: Light blue . Deleted channel: Light red.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK

B CHANNEL SET UP

USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

– CHANNEL SET UP –

B ADD / DELETE CH (TV)

AUTO PRESET

ADD / DELETE

5 After scanning

The tuner stops on the lowest memorized channel. If you want to recall the selected channels, you can

select the desired channel directly with the remote control number buttons or

CHANNEL

K or L button.

5 Exit the channel setup mode

Press the MENU button on the remote control to returns to TV mode.

NOTE: To confirm that channel(s) has been deleted or added, press the CHANNEL K or L button.

- 12 - EN

9I03

CHANNEL SET UP AGAIN

DAYLIGHT-SAVING TIME

Make sure ...

Press the POWER button to turn on the TV/VCR.

•

1 Select “CHANNEL SET UP”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L but- ton to point to “CHANNEL SET UP”.

Then, press the F.FWD/B button.

2 Begin auto preset

Press the PLAY/K or STOP/L but- ton to point to “AUTO PRESET”.

Then, press the F.FWD/B button. The tuner scans and memorizes all

the active channels in your area.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK

B CHANNEL SET UP

USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

– CHANNEL SET UP –

ADD / DELETE CH (TV)

B AUTO PRESET

3 After scanning

The tuner stops on the lowest memorized channel.

SELECTING THE LANGUAGE

Make sure ...

Press the POWER button to turn on the TV/VCR.

•

NOTE: This function effects only the language on the screen menu and not the audio source.

Select this feature and the TV/VCR’s clock automatically will advance one hour in April, then reverse one hour in October.

When Daylight-Saving Time is ON, the clock will change automatically as follows:

First Sunday of April : At 2 AM the clock imme-

•

diately changes to 3 AM. Any timer programming you have set to occur between 2 AM and 3 AM will not record.

Last Sunday of October : At 2 AM the clock

•

immediately changes to 1 AM.

Make sure ...

Press the POWER button to turn on the TV/VCR.

•

1 Select “SETTING CLOCK”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L but- ton to point to “SETTING CLOCK”.

Then, press the F.FWD/B button.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

2 Set “D.S.T.”(Daylight-Saving Time) to [ON]

Press the PLAY/K or STOP/L but- ton to point to “D.S.T.”.

Then, press the F.FWD/B or REW/s button until [ON] appears.

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH AUTO CLOCK CH [ 02 ] MANUAL CLOCK SET

B D.S.T. [ON]

1 Select “LANGUAGE”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L but- ton to point to “LANGUAGE”.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP

B LANGUAGE [ENGLISH]

CAPTION [OFF] ZERO RETURN TIME SEARCH

2 Select “ENGLISH” or “FRANÇAIS”

Select “ENGLISH” or “FRANÇAIS”= French using the F.FWD/B or REW/s button.

3 Exit the Language mode

Press the MENU button on the remote control to return to TV mode.

NOTE: If for some reason the menu is in French, press the MENU button on the remote control, press the PLAY/K button to point to “LANGAGE [FRANÇAIS]”, then press the F.FWD/B button, then press the MENU button on the remote control.

3 Exit the Daylight-Saving Time mode

Press the MENU button on the remote control to return to TV mode.

TO CANCEL THE DAYLIGHT-SAVING TIME

Repeat steps [1] to [2], select [OFF] using the F.FWD/B or REW/s button. then, press the MENU button on the remote control to return to TV mode.

- 13 - EN

9I03

CLOCK SET UP

(AUTO / MANUAL)

The TV/VCR clock must be set correctly before VCR timer recording is possible. It is suggested that the clock be set manually when first setting up the TV/VCR. Then, set to [on] the auto clock setting which will periodically correct the setting if necessary.

NOTE: If you cannot receive a station with time signals, auto clock setting cannot be performed. Use manual setting only.

6 Select the hour

Press the PLAY/K or STOP/L but- ton until your desired hour appears. (Example: 5, PM)

Then, press the F.FWD/B button.

7 Select the minute

Press the PLAY/K or STOP/L but- ton until the desired minute appears. (Example: 40)

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 TUE 2 0 0 3

HOUR MINUTE

0 5 : – – PM

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 TUE 2 0 0 3

HOUR MINUTE

0 5 : 4 0 PM

MANUAL CLOCK SETTING

Make sure ...

The TV/VCR is turned on.

•

In the example below, the clock is to be set to:

DATE May 6th, 2003 SETTING TIME 5:40PM

1 Select “SETTING CLOCK”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L button to point to “SETTING

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

CLOCK”. Then, press the F.FWD/B button.

2 Select “MANUAL CLOCK SET”

Press the PLAY/K or STOP/L button to point to “MANUAL CLOCK SET”.

Then, press the F.FWD/B button.

3 Select the month

Press the PLAY/K or STOP/L button until your desired month appears. (Example: May → 05)

Then, press the F.FWD/B button.

4 Select the day

Press the PLAY/K or STOP/L but- ton until your desired day appears. (Example: 6th → 06)

Then, press the F.FWD/B button.

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH AUTO CLOCK CH [ 02 ]

B MANUAL CLOCK SET

D.S.T. [OFF]

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / – – – – – – – – –

HOUR MINUTE

– – : – – – –

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 – – – – – – –

HOUR MINUTE

– – : – – – –

8 Star t the clock

5:40 PM

Press the MENU button on the remote control.

Although seconds are not displayed, they begin counting from 00 when you press the MENU button on the remote control. Use this feature to synchronize the clock with the correct time.

NOTE:

When unplugging the AC cord or if there is a power failure for more than 3 seconds, you may have to reset the clock.

TO CHANGE CLOCK SETTING

If you want to change the clock,

1)Follow steps [1] and [2].

2)Select where you want to change using the F.FWD/B or REW/s button.

3)Enter correct numbers using the PLAY/K or STOP/L button.

4)Press the MENU button on the remote control to start the clock.

PLEASE NOTE:

If there is no local PBS station in your area or on your cable system, select “AUTO CLOCK” and press the F.FWD/B or REW/s button to turn [OFF] this function. Then you can manually adjust the clock.

5 Select the year

Press the PLAY/K or STOP/L but- ton until your desired year appears. (Example: 2003)

Then, press the F.FWD/B button.

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 TUE 2 0 0 3

HOUR MINUTE

– – : – – – –

- 14 - EN

9I03

AUTOMATIC CLOCK SETTING

Make sure ...

The TV/VCR is turned on.

•

Confirm the TV/VCR is receiving a RF (Radio

•

Frequency) signal from either an antenna or cable system connection using the ANT IN jack on the rear of the TV/VCR.

NOTE:

If a cable converter box is being used, make sure it

•

is powered on. You must use the TV/VCR remote control to per-

•

form the clock setting procedure. If the TV/VCR is connected directly to a cable con-

•

verter box or satellite box, the local PBS station must be selected on the cable box itself, and the TV/VCR must be set to the output channel of the cable converter box or satellite box (usually channel 3 or 4), to be able to set up or correct the clock automatically

1 Select “SETTING CLOCK”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L but- ton to select “SETTING CLOCK”.

Press the F.FWD/B button to enter “SETTING CLOCK” menu.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

Clock signal. Auto Clock Setting is not possible. Please use Manual Clock Setting on page 14.

Press the MENU button to exit the screen. NOTE: During Auto Clock CH Search, the picture

may be distorted. This is normal.

4 Enter the channel number that contains the

Automatic Clock Setting Signal

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L button to select “SETTING CLOCK”.

Press the F.FWD/B button to enter

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

“SETTING CLOCK” menu. Press the STOP/L button to select

“AUTO CLOCK CH”. Press the F.FWD/B or REW/s

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH

B AUTO CLOCK CH [ 45]

MANUAL CLOCK SET D.S.T. [OFF]

buttons until you locate Auto Clock Set station number. See item 3 above.

Press the MENU button to exit the screen.

5 Turn off the TV/VCR

Once the TV/VCR is turned off , it will periodically check and set the correct date and time.

2 Set “AUTO CLOCK” to [ON]

Press the F.FWD/B button until AUTO CLOCK [ON] appears.

– SETTING CLOCK –

B AUTO CLOCK [ON]

AUTO CLOCK CH SEARCH AUTO CLOCK CH [ 02 ] MANUAL CLOCK SET D.S.T. [OFF]

3 Begin “AUTO CLOCK CH SEARCH”

Press the STOP/L button to select “AUTO CLOCK CH SEARCH”.

Press the F.FWD/B button.

The TV/VCR is now searching

•

for the station which contain the auto clock set signal. The search for a signal may take up to 20 seconds per channel.

“_ _” appears at the lower left of

•

the screen when the search has ended.

Auto Clock station- write down

•

the number(s) that appear on the screen. These are the auto clock station(s) in your area. See item 4 below.

If no number(s) appear on the TV screen, there are

•

no stations in your area which contain the Auto

– SETTING CLOCK –

AUTO CLOCK [ON]

B AUTO CLOCK CH SEARCH

AUTO CLOCK CH [ 02 ] MANUAL CLOCK SET D.S.T. [OFF]

– AUTO CLOCK CH SEARCH –

08 10 13

_ _

- 15 - EN

9I03

ON SCREEN DISPLAY

To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows:

When the Closed Caption mode is OFF:

Counter mode: After 5 seconds, only

•

the counter remains. To clear it, press the DISPLAY button.

Clock mode: After 5 seconds, only

•

the clock and the channel number remain. To clear them, press the DISPLAY button.

OFF mode Counter mode Clock mode

When the Closed Caption mode is ON:

The On Screen Display disappear after 5 seconds.

•

This is true even if the MUTE button is pressed, or

•

the PAUSE/STILL button is pressed while recording.

STOP STOP

SP SPCOUNT 0:12:34

5:40PM

CH2

After 5 seconds After 5 seconds

5:40PM

CH2

COUNT 0:12:34

Counter remains

OFF mode Clock/Counter mode

Clock & Channel remains

STOP 5:40 PM

SP COUNT 0:12:34

CH2

SPECIAL FEATURES

DEGAUSSING

Magnetism from nearby appliances might affect the color of the TV picture.

If this happens, move this unit away from the appliance. If the color is still not correct, disconnect power cord from AC outlet then reconnect it after 30 minutes.

REAL TIME TAPE COUNTER

This shows the elapsed recording or playback time in hours, minutes, and seconds. (The displayed time will not change on a blank tape or blank portions on the tape.)The “–” indication will appear when the tape has rewound further than “0:00:00” on the tape counter.

AUTO REWIND-EJECT

When the end of a tape is reached during record-

•

ing, playback, or fast-forward, the tape will automatically rewind to the beginning. After rewinding finishes, the TV/VCR will eject the tape and turn itself to off.

This function is operative when Repeat Play is set

•

to the [OFF] position. The tape will not auto-rewind during timer record-

•

ing or One Touch Recording.

- 16 - EN

9I03

TV OPERATION

WATCHING A TV PROGRAM

1 Turn on the TV/VCR

Press the POWER button to turn on the TV/VCR.

2 Select the channel number

Press the CHANNEL K or L button to select your desired channel number or press the number buttons on the remote control.

Remember: If the TV/VCR is connected to a cable box or satellite box, the TV/VCR must be on CH3 or CH4, then the channel to be viewed must be selected on the cable box or satellite box.

3 Adjust sound

Press the VOLUME XXor YYbutton to adjust the volume.

VOLUME 20

C C C C C C C C C C C C

GAME MODE

This function enables you to decrease the TV screen contrast and making it suitable for use with a TV GAME.

NOTE: This function can not be set during recording.

Press the GAME button on the remote control. “GAME” appears on the screen.

When you press the GAME button;

The TV/VCR comes on automatically if it is off.

•

The TV/VCR will be in external input mode auto-

•

matically.

GAME

PICTURE CONTROL

The TV/VCR’s picture controls – BRIGHT, CONTRAST, COLOR, TINT and SHARPNESS – are

preset to factory specifications. Although they are usually the best, you may need to make some further adjustments for a natural looking image.

NOTES:

Procedures must be followed within 5 seconds or

•

the Picture Control mode will be cancelled. When setting the Picture Control, the Game mode

•

will be cancelled.

Make sure ...

TV/VCR power must be turned on.

•

1 Select “PICTURE CONTROL”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L but- ton to point to ”PICTURE CONTROL”.

Then, press the F.FWD/B button.

2 Select item you want to adjust

Press the PLAY/K or STOP/L but- ton until desired control is displayed.

BRIGHT CONTRAST COLOR TINT SHARPNESS

3 Adjust the picture control

Press the F.FWD/B or REW/s button to adjust to your desired level.

– M E N U –

TIMER PROGRAMMING

B PICTURE CONTROL

SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

BRIGHT

PP PP PP PP PP PP PP CC PP PP PP PP PP PP PP

–

TO CANCEL THE GAME MODE

Press the GAME button or CHANNEL K or L but- ton on the remote control.

REW/s F.FWD/B

BRIGHT to decrease to increase

brightness brightness

CONTRAST to decrease to increase

contrast contrast

COLOR to pale to brilliant TINT to purple to green

SHARPNESS to soft to clear

If there is a power failure of any kind, the unit will

•

retain its memory for this feature.

- 17 - EN

9I03

CLOSED CAPTION SYSTEM

You can view specially labeled (cc) TV programs, movies, news, pre-recorded tapes with either a dialogue caption or text display.

CAPTION mode: By choosing the caption mode, you

can watch dramas, movies and news while captioning the dialogues and the contents of news.

TEXT mode: By choosing the text mode, you can

watch half screen text information if you want.

1-2: You may get these captions or text information

by selecting either “1” or “2”. Caption “2” is used, usually for a second language if available.

1 Select “CAPTION”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L but- ton to point to “CAPTION”.

2 Select your desired caption menu

Press the F.FWD/B or REW/s button until your desired caption menu appears.

([CAPTION1], [CAPTION2], [TEXT1] or [TEXT2])

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [OFF]

ZERO RETURN TIME SEARCH

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [CAPTION1]

ZERO RETURN TIME SEARCH

NOTE:

Not all programs are broadcast with closed captions. Your television is designed to provide error free closed captions from high quality antenna, cable and VCR signals. Conversely, poor quality signals are likely to result in caption errors or no captions at all. Common signal conditions which may cause captions errors are listed below:

Automobile ignition noise

•

Electric motor brush noise

•

Weak snowy reception on TV screen

•

Multiplex signal reception displaying picture

•

ghosts or airplane flutter. Playback of poorly recorded or worn VCR tapes.

•

NOTE:

If the TV/VCR displays a black box on the TV screen, this means that the TV/VCR is set to the TEXT mode. To clear screen, select [CAPTION1], [CAPTION2] or [OFF].

Make sure ...

TV/VCR power must be turned on.

•

3 Exit the caption setting mode

Press the MENU button on the remote control to return to TV mode.

TO CANCEL THE CLOSED CAPTION SYSTEM

Repeat steps [1] and [2], select [OFF] using the F.FWD/B or REW/s button. Press the MENU button on the remote control to return to TV mode.

WHEN THE CLOSED CAPTION MODE IS ON

The On-Screen Display will disappear after 5 seconds.

This is also true when the MUTE button is pressed,

•

and when the PAUSE/STILL button is pressed while recording.

If there is a power failure of any kind, the unit will

•

retain its memory for this feature.

- 18 - EN

9I03

V-CHIP SET UP

V-CHIP enables parents to prevent their children from watching inappropriate material on TV.

V-CHIP reads the ratings for programming (except for news and sports programs, unedited movies on premium cable channels, and Emergency Broadcast System signals), then denies access to programming if the program’s rating meets the limitations you select. In this case, “PROTECTED PROGRAM by ...” message appears on the TV screen.

To block ratings, follow the steps below.

Programming may be rated by the Motion Picture

•

Association of America (MPAA) or according to the Television Parental Guidelines. In order to block any inappropriate programming, set your limits in both places (MPAA RATING and TV RATING).

TV RATING SET UP

Make sure ...

TV/VCR power must be turned on.

•

1 Select “V-CHIP SET UP”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L but- ton to point to “V-CHIP SET UP”.

Then, press the F.FWD/B button.

2 Select “TV RATING”

Press the PLAY/K or STOP/L but- ton to point to “TV RATING”.

Then, press the F.FWD/B button.

3 Select your desired item

Press the PLAY/K or STOP/L but- ton to point to your desired item.

Then, press the F.FWD/B button to select [BLOCK] or [VIEW].

When you select the rating category and turn it

•

[BLOCK], the higher rating will turn [BLOCK] automatically. Also, the lower rating will turn [VIEW] automatically.

When you turn “TV-Y” to [VIEW], the all ratings

•

will turn to [VIEW] automatically.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK CHANNEL SET UP USER’S SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

– V-CHIP SET UP –

B TV RATING

MPAA RATING

B TV–Y [VIEW]

TV–Y7 ( ) [VIEW] TV–G [VIEW] TV–PG( ) [VIEW] TV–14 ( ) [VIEW] TV–MA( ) [VIEW]

Selection Rating Category Explanations

TV-Y Appropriate for all children TV-Y7 Appropriate for children seven and older TV -G General Audience TV-PG Parental Guidance suggested. TV-14 Unsuitable for children under 14

TV-MA Mature audience only

When you select TV-Y7, TV-PG, TV-14, or TV-MA and you press the F.FWD/B button, the sub-ratings will appear on the TV screen.

If you select the rating category (example: TV-PG) and turn it [BLOCK] or [VIEW], the sub-ratings (example: V for Violence) will turn [BLOCK] or [VIEW] automatically.

You can set the sub-ratings to [BLOCK] or [VIEW] individually when the rating category is set to [BLOCK].

To set the sub-ratings individually, follow the steps below.

When you select [TV-Y7]:

•

Press the STOP/L or PLAY/K button to select “FV” (Fantasy Violence).

TV–Y7 [BLOCK]

B FV [BLOCK]

Then, press the F.FWD/B button to select [BLOCK] or [VIEW].

When you select [TV-PG], [TV-14] or [TV-MA]:

•

Press the STOP/L or PLAY/K button to select “D”(Suggestive Dialog), “L”(Coarse Language), “S”(Sexual Situation), or

TV–PG [BLOCK]

B D [BLOCK]

L [BLOCK] S [BLOCK] V [BLOCK]

“V”(Violence). Then, press the F.FWD/B button to select [BLOCK] or [VIEW].

Note: When you select [TV-MA], “D” does not appear on the TV screen.

The sub-ratings which set to

•

[BLOCK] appears next to the rating category in the TV RATING menu.

B TV–Y [VIEW]

TV–Y7 ( ) [VIEW] TV–G [VIEW] TV–PG (DLSV) [BLOCK] TV–14 (DLSV ) [BLOCK] TV–MA ( LSV) [BLOCK]

4 Exit the V-Chip setting mode

Press the MENU button on the remote control to return to original mode.

- 19 - EN

9I03

MPAA RATING SET UP

Make sure ...

TV/VCR power must be turned on.

•

1 Select “V-CHIP SET UP”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L but- ton to point to “V-CHIP SET UP”.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK CHANNEL SET UP USER’S SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

Then, press the F.FWD/B button.

2 Select “MPAA RATING”

Press the PLAY/K or STOP/L but-

– V-CHIP SET UP –

TV RATING

B MPAA RATING

ton to point to “MPAA RATING”. Then, press the F.FWD/B button.

3 Select your desired item

Press the PLAY/K or STOP/L but- ton to point to your desired item.

Then, press the F.FWD/B button to select [BLOCK] or [VIEW].

Selection Rating Category Explanations

G General Audience PG Parental Guidance suggested. PG-13 Unsuitable for children under 13 R Restricted; under 17 requires accompa-

nying parent or adult guardian

NC-17 No one under 17 admitted X Mature audience only

When you select the rating category and turn it

•

[BLOCK], the higher rating will turn [BLOCK] automatically. Also, the lower rating will turn [VIEW] automatically.

When you turn “G” to [VIEW], the all ratings will

•

turn to [VIEW] automatically.

G [VIEW] PG [VIEW] PG–13 [VIEW]

B R [BLOCK]

NC–17 [BLOCK] X [BLOCK]

4 Exit the V-Chip setting mode

Press the MENU button on the remote control to return to original mode.

- 20 - EN

9I03

PLAYBACK

NORMAL PLAYBACK

Make sure ...

TV/VCR power must be turned on.

•

1 Inser t a prerecorded tape

If the erase-protection tab has been removed, the TV/VCR will start playback automatically.

2 To begin playback

Press the PLAY button.

3 To stop playback

Press the STOP button when playback is completed.

PLAY

STOP

TRACKING ADJUSTMENT

Tracking adjustment will be set automatically

•

(Digital Tracking function) when you start playback.

However when playing pre-recorded tapes or tapes

•

recorded on units other than your own, noise lines (black and white streaks) may appear on the playback picture. If this occurs, you can adjust the tracking control manually by pressing the CHANNEL K or L button until the streaks disappear. To return to the DTR function, stop the tape once and start playback again.

2)Press it again and the TV/VCR will now search in super high speed. (in the LP / SLP modes only)

NOTE: Tapes recorded in the SP or LP mode will display a noise bar on the TV screen and the picture may revert to Black and White. This is normal.

3)Press the PLAY button to return to normal speed.

STILL PICTURE

You can view a still picture on the TV screen during playback (the Still mode). Press the PAUSE/STILL button during playback. Only tapes recorded in the SLP mode will show the least amount of lines.Press the PLAY button to return to playback.

NOTES:

Usually there will be video “noise” lines (black

•

and white streaks or dots) on the screen. This is normal.

If the tape was originally recorded in SP or LP mode, the still picture will be black and white in addition to the “noise” lines.

This is not a fault of the machine, but is a byproduct of the technology involved in producing a TV/VCR with 2 video heads.

If it is left in the Pause mode for more than five

•

minutes, the TV/VCR will automatically switch to the Stop mode.

NOISE CANCEL (in the Still mode)

This feature allows you to reposition or reduce the noise lines of a still picture.Press the PAUSE/STILL button so that the noise lines change position on the screen so you can see the picture in its entirety without distracting noise lines.

NOTE: This feature can be activated ONLY when viewing a tape recorded in the SLP mode. If the tape was originally recorded in the SP or LP mode, the still picture may revert to black and white in addition to the “noise bars”. This is normal.

PICTURE SEARCH

This feature is very useful in finding or skipping over a particular scene on a tape. In this mode, the sound will be muted.

1)You may view a video tape at a high speed in either a forward or reverse direction by pressing the F.FWD or REW button during playback.

(in the SP / LP / SLP modes)

VERTICALHOLD CONTROL

In the Pause/Still mode only, when the picture begins to vibrate vertically, stabilize the picture by pressing the CHANNEL K or L button.

NOTE:

If there are video noise lines on the screen, reposition or reduce them. Refer to “NOISE CANCEL”.

- 21 - EN

9I03

+ 48 hidden pages
