EMERSON AND THE G-CLEF LOGO ARE REGISTERED TRADEMARKS OF EMERSON RADIO CORP., PARSIPPANY, NEW JERSEY, U.S.A.

20” Digital / Analog

Television

Owner’s Manual

CR202EM9

WATCHING TVINTRODUCTION CONNECTION INITIAL SETTING

TO RECEIVE DIGITAL/ANALOG SIGNAL, YOU MUST CONNECT ANTENNA.

OPTIONAL SETTING

TROUBLESHOOTING

INFORMATION

IF YOU NEED ADDITIONAL ASSISTANCE WITH SETUP OR OPERATING AFTER READING OWNER’S MANUAL, PLEASE CALL TOLL FREE 1-800-256-2487, OR VISIT OUR WEB SITE AT www.EmersonAudioVideo.com

NTRODUCTION

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The important note is located on the rear of the cabinet.

Important Safeguards

1. READ INSTRUCTIONS - All the safety and operating instructions

should be read before the appliance is operated.

2. RETAIN INSTRUCTIONS - The safety and operating instructions

should be retained for future reference.

3. HEED WARNINGS - All warnings on the appliance and in the

operating instructions should be adhered to.

4. FOLLOW INSTRUCTIONS - All operating and use instructions

should be followed.

5. CLEANING - Unplug TV from the wall outlet before cleaning. Do

not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION: A product that is meant for uninterrupted service and, that for some speci c reason, such as the possibility of the loss of an authorization code for a CAT V converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6. ATTACHMENTS - Do not use attachments not recommended by

the TV manufacturer as they may cause hazards.

7. WATER AND MOISTURE - Do not use this TV near water, for

example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8. ACCESSORIES - Do not place this TV on

an unstable cart, stand, tripod, bracket, or table. The TV may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the

manufacturer, or sold with the TV. Any mounting of the appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn. AMEUBLES - Cet appareil ne doit être placé que sur un meuble (avec ou sans roulettes) recommandé par le fabricant. Si vous l’installez sur un meuble à roulettes, déplacez les deux ensembles avec précaution. Un arrêt brusque, l’utilisation d’une force excessive et des surfaces irrégulières risquent de déstabiliser l’ensemble et de le renverser.

9. VENTILATION - Slots and openings in the cabinet and the back

or bottom are provided for ventilation and to ensure reliable operation of the TV and to protect it from overheating, these openings must not be blocked or covered. The openings should never be blocked by placing the TV on a bed, sofa, rug, or other similar surface. This TV should never be placed near or over a radiator or heat register. This TV should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

PORTABLE CART WARNING

S3126A

SYMBOLE D'AVERTISSEMENT POUR

LES COMPOSANTES

APPAREIL ET MEUBLE A ROULETTES

S3126A

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

10. POWER SOURCES - This TV should be operated only from the type

of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For TVs intended to operate from battery power, or other sources, refer to the operating instructions.

11. GROUNDING OR POLARIZATION - This TV is equipped with a

polarized alternating-current line plug (a plug having one blade wider than the other). This plug will  t into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to  t, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12. POWER-CORD PROTECTION - Power-supply cords should be

routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

13. OUTDOOR ANTENNA GROUNDING - If an outside antenna or

cable system is connected to the TV, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

EXAMPLE OF ANTENNA GROUNDING AS PER

S2898A

14. LIGHTNING - For added protection for this TV receiver during a

FIGURE A

NATIONAL ELECTRICAL CODE

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

NEC - NATIONAL ELECTRICAL CODE POWER SERVICE GROUNDING

lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV due to lightning and power-line surges.

GROUND CLAMPS

ELECTRODE SYSTEM (NEC ART 250, PART H)

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

INTRODUCTION

15. POWER LINES - An outside antenna system should not be located

in the vicinity of overhead power lines or other electric light of power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16. OVERLOADING - Do not overload wall outlets and extension cords

as this can result in a risk of  re or electric shock.

17. OBJECT AND LIQUID ENTRY - Never push objects of any kind into

this TV through openings as they may touch dangerous voltage points or short out parts that could result in a  re or electric shock. Never spill liquid of any kind on the TV.

18. SERVICING - Do not attempt to service this TV yourself as opening

or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to quali ed service personnel.

19. DAMAGE REQUIRING SERVICE - Unplug this TV from the wall

outlet and refer servicing to quali ed service personnel under the following conditions:

a. When the power supply cord or plug is damaged or frayed. b. If liquid has been spilled, or objects have fallen into the TV.

Precautions

c. If the TV has been exposed to rain or water. d. If the TV does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and will often require extensive work by a

quali ed technician to restore the T V to its normal operation. e. If the TV has been dropped or damaged in any way. f. When the TV exhibits a distinct change in performance, this

indicates a need for service.

20. REPLACEMENT PARTS - When replacement parts are required, be

sure the service technician uses replacement parts speci ed by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in  re, electric shock, injury to persons or other hazards.

21. SAFETY CHECK - Upon completion of any service or repairs to this

TV, ask the service technician to perform routine safety checks to determine that the TV is in proper operating condition.

22. HEAT - This TV product should be situated away from heat sources

such as radiators, heat registers, stoves, or other products (including ampli ers) that produce heat.

Do not place the unit on the furniture that is capable of being tilted by a child and an adult leaning, pulling, standing or climbing on it. A falling unit can cause serious injury or even death.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA

BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

FCC WARNING This equipment may generate or use radio frequency energy. Changes or modifications to this equipment

may cause harmful interference unless the modifications are expressly approved in the manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

CONNECTION

INITIAL SETTING

WATCHING TV INFORMATION

OPTIONAL SETTING TROUBLESHOOTING

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Note to CATV system installer:

This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground should be connected to the grounding system of the building as close to the point of cable entry as practical.

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

NTRODUCTION

LOCATION

For safe operation and satisfactory performance of the unit, keep the following in mind when selecting a place for its installation:

• Shield it from direct sunlight and keep it away from sources of intense heat.

• Avoid dusty or humid places.

• Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes at the top and bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

• Install the unit in a horizontal position.

• Avoid locations subject to strong vibration.

• Do not place the unit near strong magnetic fields.

• Avoid moving the unit to locations where temperature differences are extreme.

• Be sure to unplug the AC power cord from the outlet before carrying the unit.

TO AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE

• Do not handle the power cord with wet hands.

• Do not pull on the power cord when disconnecting it from an AC outlet. Grasp it by the plug.

• If, by accident, water is spilled on the unit, unplug the power cord immediately and take the unit to our Authorized Service Center for servicing.

• Do not place anything directly on top of the unit.

The serial number of this product may be found on the back of the unit. No others have the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft.

date of purchase

dealer phone No.

serial No.

dealer purchase from

model No.

dealer address

Note about recycling:

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

Supplied Accessories5

owner’s manual (1EMN23060A)

• If you need to replace these accessories, please refer to the part No. with the illustrations and call our toll free customer support line found on the cover of this manual.

• Depending on your antenna system, you may need different types of combiners (mixers) or separators (splitters). Contact your local electronics store for these items.

remote control (NE616UE)

POWER

–

/ENT

VOL VOL

INPUT SELECT

DTV

INFO

AUDIO

321

654

CHANNEL RECALL

100

MUTE

SLEEP

* Batteries (AA x 2) for remote control

not included.

Symbols Used in this Manual5

The following is the description for the symbols used in this manual. Description refers to:

DTV

: Digital TV operation

• If neither symbol appears under the function heading, operation is applicable to both.

: Analog TV operation

INTRODUCTION

Features5

• DTV/TV/CATV

- You can use your remote control to select

channels which are broadcast in digital format and conventional analog format. Also, cable subscribers can access their cable TV channels.

• Information Display (DTV only)

- You can display the title, contents and other

information of the current DTV program on the TV screen.

• Auto Channel Scan

- This unit automatically scans and memorizes

channels available in your area, eliminating difficult setup procedures.

• V-chip

- This feature allows you to block children’s access to

inappropriate programs.

• Closed Caption Decoder

- Built-in closed caption decoder displays text for

closed caption supported programming.

• Auto Shut Off Function

- If there is no signal input from the antenna terminal

and no operation for 15 minutes, the unit will turn itself off automatically.

• Sleep Timer

- This feature will automatically turn off the power of the unit at a specific time.

• Choices for On-screen Language

- Select your on-screen language: English, Spanish or French.

• Stereo Sound Function

• PLL Frequency Synthesized Tuning

- Provides free and easy channel selection and lets you tune directly to any channel using the channel number buttons on the remote control.

• S-video Input

• AV Input

• Digital Audio Coaxial Output

Contents5

INTRODUCTION

Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Supplied Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Symbols Used in this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Remote Control Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Installing the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

CONNECTION

Basic Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

External Device Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

INITIAL SETTING

Initial Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Auto Channel Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Language Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

WATCHING TV

Channel Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Volume Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Switching Each Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Screen Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

TV Screen Display Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Sleep Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

OPTIONAL SETTING

Channel Add/Delete . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Picture Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Closed Caption. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

DTV Closed Caption. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

DTVCC Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

V-chip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

TROUBLESHOOTING

Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

INFORMATION

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Cable Channel Designations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

General Speci cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Electrical Speci cation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Other Speci cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

CONNECTION

INITIAL SETTING

WATCHING TV INFORMATION

OPTIONAL SETTING TROUBLESHOOTING

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back cover

All rights reserved. No part of this manual may be reproduced, copied, transmitted, disseminated, transcribed, downloaded or stored in any storage medium, in any form or for any purpose without the express prior written consent of Funai. Furthermore, any unauthorized commercial distribution of this manual or any revision hereto is strictly prohibited.

Information in this document is subject to change without notice. Funai reserves the right to change the content herein without the obligation to notify any person or organization of such changes.

with the design is a registered trademark of Funai Electric Co., Ltd and may not be used in any way without the express written consent of Funai. All other trademarks used herein remain the exclusive property of their respective owners. Nothing contained in this manual should be construed as granting, by implication or otherwise, any license or right to use any of the trademarks displayed herein. Misuse of any trademarks or any other content in this manual is strictly prohibited. Funai shall aggressively enforce its intellectual property rights to the fullest extent of the law.

NTRODUCTION

Remote Control Function5

DTV

AUDIO

321

654

100

SLEEP

INFO

CHANNEL

RECALL

MUTE

1 7

POWER

–

/ENT

3 4

VOL VOL

INPUT

SELECT

1. POWER button (p10) Press to turn the unit on and off.

2. Number buttons (p12)

• Press to select channels.

-/ENT button

• Press to shift the minor channel

8 9

from the major channel.

+100 button

• Press to select 100 or higher channels. (CATV)

• Press to search if there are minor

channels on the currently selected major channel. (DTV)

3. CH K / L buttons (p12)

Press to select channels and the

external input mode or move up/down through the main menu items.

4. VOL X / Y buttons (p12)

Press to adjust the volume or move

right(X)/left(Y) through the main menu items.

5. MENU button (p10)

Press to display the main menu.

6. INPUT SELECT button (p13)

Press to access a connected

external device like a DVD player or a VCR.

7. DTV/TV button (p13) Press to switch between the digital

mode (DTV) and analog mode (TV).

8. INFO button (p13) Digital Mode (DTV)

• Press to display the channel number and the program information.

Analog Mode (TV)

• Press to display the channel number.

External Input Mode

• Press to display the currently

selected external input mode.

9. AUDIO button (p13)

Digital Mode (DTV only) Press to select the audio

language.

10. CHANNEL RECALL button (p12)

Press to return to previous channel.

11. MUTE button (p12)

Press to turn the sound on and off.

12. SLEEP button (p14)

Press to activate the sleep timer.

Installing the Batteries

Install the batteries (AA x 2) matching the polarity indicated inside battery compartment of the remote control.

213

Battery Precautions:

• Be sure to follow the correct polarity as indicated in the battery compartment. Reversed batteries may cause damage to the device.

• Do not mix different types of batteries together (e.g., Alkaline and Carbon-Zinc) or old batteries with fresh ones.

• If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from possible battery leakage.

• Do not try to recharge batteries; they can overheat and rupture.

INTRODUCTION

Control Panel5

1. Infrared Sensor Window

Receives infrared rays transmitted from the remote

control.

2. POWER button (p10) Press to turn the unit on and off.

3. CHANNEL K / L buttons (p12) Press to select channels or move up/down through

the main menu items.

4. VOLUME X / Y buttons (p12) Press to adjust the volume or move right(X)/left(Y)

through the main menu items.

5. MENU button (p10) Press to display the main menu.

6. HEADPHONE jack

Headphone connection for personal listening.

7. AUDIO input jacks (p9) RCA audio cable connection for an external device.

VIDEO

AUDIO RL

MENU VOLUME CHANNEL

HEADPHONE

POWER

8. VIDEO input jack (p9) RCA video cable connection for an external device.

1 2 3 4 5 6 7 8

CONNECTION

INITIAL SETTING

WATCHING TV INFORMATION

OPTIONAL SETTING TROUBLESHOOTING

Rear Panel5

1. ANT. IN jack (p8) RF coaxial cable connection for your antenna or

cable/satellite box.

2. COAXIAL (digital audio) output jack (p9) Digital audio coaxial cable connection for a decoder or

an audio receiver.

Use digital audio input jack of an external device.

3. S-VIDEO input jack (p9) S-video cable connection for an external device.

4. AUDIO input jacks (p9) RCA audio cable connection for an external device.

5. VIDEO input jack (p9) RCA video cable connection for an external device.

6. AC Power cord

Connect to a standard AC outlet to supply power to

this unit.

VIDEO

ANT. INCOAXIALS-VIDEO

2 3 4 5

ONNECTION

Cables not included.

Please purchase the necessary cables at your local store.

Basic Connection

This section describes how to connect the unit to an antenna, cable/satellite box, etc.

Note:

• Be sure your antenna or other device is connected properly before plugging in the power cord.

[Antenna Cable Connection]

When connecting the unit to an antenna or cable TV company (without cable/satellite box) Connect the RF coaxial cable on your home outlet to the antenna input jack of this unit.

e.g.)

VHF / UHF

antenna

RF coaxial cable

ANT. IN

cable TV

company

* Once connections are completed, turn on the unit and begin initial setup.

Channel scanning is necessary for the unit to memorize all available channels in your area. (Refer to “Initial Setup” on page 10.)

rear of this unit

Note:

• For your safety and to avoid damage to device, please unplug the RF coaxial cable from the antenna input jack before moving the unit.

• If you use an antenna to receive analog TV, it should also work for DTV reception. Outdoor or attic antennas will be more effective than settop versions.

• To easily switch your reception source between antenna and cable, install an antenna selector.

• If you connect to the cable system directly, contact the CATV installer.

[Connection to Cable Box or Satellite Box]

Connect the RF coaxial cable on your home outlet to the input jack of the cable/satellite box. Use another RF coaxial cable to connect the antenna input jack of the unit to the output jack of the cable/satellite box.

e.g.)

satellite

dish

cable/satellite box

rear of this unit

cable TV

company

* Required cables and connecting methods differ depending on the cable/satellite box.

For more information, please contact your cable/satellite provider.

RF coaxial cable RF coaxial cable

RF OUTANT. IN

ANT. IN

Cables not included.

Please purchase the necessary cables at your local store.

External Device Connection

[S-video or Video Cable Connection (Rear)]

S-video connection offers good picture quality for video devices connected to the unit. Video connection offers standard picture quality for video devices connected to the unit. Make the connection as illustrated below. When the audio jack of the video device is monaural, connect the RCA audio cable to the audio L input jack.

CONNECTION

RCA audio cable

e.g.)

DVD player with the S-video output jack

AUDIO OUT

S-VIDEO

OUT

VIDEO

OUT

rear of this unit

VIDEO

ANT. INCOAXIALS-VIDEO

S-video cable

e.g.)

VCR

AUDIO OUT

RCA video cable

VIDEO

OUT

rear of this unit

VIDEO

ANT. INCOAXIALS-VIDEO

RCA audio cable

• To use the S-video or video input jack on the rear of this unit, press [INPUT SELECT] to select “VIDEO1”.

[Video Cable Connection (Front)]

Video connection offers standard picture quality for video devices connected to the unit. Make the connection as illustrated below. When the audio jack of the video device is monaural, connect the RCA audio cable to the audio L input jack.

e.g.)

AUDIO OUT

VIDEO

OUT

front of this unit

VIDEO

AUDIO RL

HEADPHONE

INITIAL SETTING

WATCHING TVINTRODUCTION

OPTIONAL SETTING

TROUBLESHOOTING

MENU VOLUME

camcorder video game

RCA video cable

RCA audio cable

• To use the video input jack on the front of this unit, press [INPUT SELECT] to select “VIDEO2”.

Note:

• If you connect to the S-video jack and the video jack at the same time, the S-video connection will have priority.

[Digital Audio Output Connection (for digital broadcasting only)]

If you connect this unit to an external digital audio device, you can enjoy multi-channel audio like 5.1ch digital broadcasting sound.

e.g.)

Dolby Digital decoder

DIGITAL AUDIO

COAXIAL IN

digital audio coaxial cable

rear of this unit

VIDEO

ANT. INCOAXIALS-VIDEO

INFORMATION

NITIAL SETTING

These operations are accessible by remote control. Some may also be accessible by controls on the main unit.

Initial Setup

This section will guide you through the unit’s initial setting which includes selecting a language for your on-screen menu and “AUTO PRESET CH”, which automatically scans and memorizes viewable channels.

Before you begin:

Make sure if the unit is connected to antenna or cable.

After making all the necessary connections, press

[POWER] to turn on the unit.

POWER

• This operation may take a few moments.

Use [CH K / L] or [VOL X] to select the on-screen

language from the choices on the left side of the TV screen. (ENGLISH / ESPAÑOL / FRANÇAIS)

VOL

• Press [CH K] for English.

• Press [CH L] for Spanish.

• Press [VOL X] for French.

Use [CH K / L] to select “AUTO PRESET CH(TV/DTV)”

for TV channels or “AUTO PRESET CH(CATV)“ for CATV channels, then press [VOL X].

VOL

• Scanning and memorizing the channels automatically

start.

• When the scanning and memorizing are completed,

the lowest memorized channel in the broadcasting will be displayed.

SELECT LANGUAGE ENGLISH NEXT:PRESS CH

ESPAÑOL DESPUÉS:PRESIONE CH

FRANÇAIS APRÈS:PRESSEZ VOL

- INITIAL SETUP -

1. PLEASE CONNECT ANTENNA OR CABLE OR SATELLITE TO THIS UNIT.

2. SET UP THE ITEMS WITH , AND BUTTONS.

AUTO PRESET CH (TV/DTV) AUTO PRESET CH (CATV)

AUTO PRESET CH(TV/DTV)

CH 25

Note:

• If you connect the cable system directly, contact the CATV installer.

• If you press [POWER] or [MENU] during “AUTO PRESET CH”, this setting will be canceled.

• The initial auto channel scan function can be executed for either TV/DTV or CATV only once. If you want to scan both TV/DTV and CATV, you need to select “CHANNEL SETUP” in the main menu to scan and memorize other channels after initial presetting is completed. (Refer to page 11.)

• You can cancel or exit the initial “AUTO PRESET CH” menu by pressing [MENU].

• When no channel can be received by “AUTO PRESET CH”, “NO TV SIGNALS” is displayed on the TV screen.

• If there is no signal input from the antenna terminal and no operation for more than 5 seconds, “HELPFUL HINTS” appears. Follow the instructions listed on the TV screen.

- HELPFUL HINTS PLEASE CHECK TO SEE IF

1. THE ANTENNA / CABLE / SATELLITE IS PROPERLY CONNECTED. DID YOU PERFORM

2. “AUTO PRESET CH”? PLEASE REFER TO FRONT

3. PAGE OF THE OWNER’S MANUAL OR REAR PANEL FOR SUPPORT LINE INFORMATION.

Main Menu

This section describes the overview of the main menu displayed when you press [MENU]. For more details, see the reference page for each item. The main menu consists of the function setting items below.

Press [MENU]. e.g.) digital TV mode

- TV SETUP -

PICTURE CHANNEL SETUP

• PICTURE

You can adjust the picture quality.

(Refer to “Picture Adjustment” on page 16.)

• CHANNEL SETUP

You can automatically scan the viewable channels and

remove those that are undesired. (Refer to “Auto Channel Scan” on page 11.)

• V-CHIP SETUP

You can set the viewing limitations. (Refer to “V-chip” on page 19.)

• LANGUAGE

You can change the language (English, Spanish,

French) displayed on the main menu.

(Refer to “Language Selection” on page 11.)

• CAPTION

You can change the display format for closed caption,

which displays the dialogue of a TV program or other information across the TV screen.

(Refer to “Closed Caption” on page 16.)

• DTV SETUP

You can set the screen display or caption in the DTV

mode.

(Refer to “DTV Closed Caption” on page 17.)

V-CHIP SETUP LANGUAGE [ENGLISH] CAPTION [OFF] DTV SETUP

Auto Channel Scan

If you switch wires (e.g., between antenna and CATV) or if you move the unit to a di erent area after the initial setting, or if you recover the DTV channel you deleted, you will need to perform auto channel scan.

Before you begin:

Make sure if the unit is connected to antenna or cable.

Press [MENU] to display the main menu.

Use [CH K / L] to select “CHANNEL SETUP”,

then press [VOL X].

e.g.) digital TV mode

VOL

Use [CH K / L] to select your desired preset type,

then press [VOL X].

e.g.) digital TV mode

- TV SETUP -

PICTURE CHANNEL SETUP V-CHIP SETUP LANGUAGE [ENGLISH] CAPTION [OFF] DTV SETUP

- CHANNEL SETUP -

ADD/DELETE(DTV) AUTO PRESET CH(DTV) AUTO PRESET CH(TV/DTV) AUTO PRESET CH(CATV) ! CATV takes approx. 50min.

Note:

• If you connect the cable system directly, contact the CAT V installer.

• If you press [POWER] or [MENU] during “AUTO PRESET CH”, the setting will be canceled.

• When no channel can be received by “AUTO PRESET CH”, “NO TV SIGNALS” is displayed on the TV screen.

• Channel setting will be saved even if the power fails.

• If you have Spanish or French menus and need English, press [MENU]. Use [CH K / L] to select “IDIOMA” or “LANGAGE”. Press [VOL X] to select “ENGLISH”. Press [MENU] to remove the main menu.

• With regard only to the digital channel, even after the scanning is complete if you unplug the AC power cord before turning off the unit by pressing [POWER], the channel setting may be lost.

Language Selection

You can choose English, Spanish, or French as your on-screen language.

Press [MENU] to display the main menu.

Use [CH K / L] to select “LANGUAGE”,

then press [VOL X] repeatedly to change the setting. e.g.) digital TV mode

- TV SETUP -

PICTURE CHANNEL SETUP V-CHIP SETUP

LANGUAGE [ENGLISH] CAPTION [OFF] DTV SETUP

INITIAL SETTING

WATCHING TVINTRODUCTION CONNECTION

OPTIONAL SETTING

TROUBLESHOOTING

VOL

• When aerial antenna is connected, select “AUTO PRESET CH (TV)”, “AUTO PRESET CH (DTV)” or “AUTO PRESET CH (TV/DTV)”.

• When connected to CATV, select “AUTO PRESET CH (CATV)”.

• Scanning and memorizing the channels automatically start.

e.g.) digital TV mode

D25

AUTO PRESET CH(DTV)

• When the scanning and memorizing are completed, the lowest memorized channel will be displayed.

• When you selected “AUTO PRESET CH (TV/DTV)”, the lowest memorized analog channel will be displayed when the scanning and memorizing are completed. If there is no analog channel, the lowest memorized digital channel will be displayed.

VOL

Press [MENU] to exit.

ENGLISH

ESPAÑOL

FRANÇAIS

INFORMATION

ATCHING TV

Channel Selection

5 Volume Adjustment

Select channels by using [CH K /L] or [the Number buttons].

This section describes how to adjust the volume. The mute function, which turns the sound off and on, is also described.

• To select the memorized channels, use [CH K / L] or [the Number buttons].

• To select the non-memorized channels, use [the Number buttons].

To Use [the Number buttons]

- When selecting analog channel 12

DTV

- When selecting digital channel 12-1

Be sure to press [–/ENT] before entering the minor channel number.

21 1

• Press [CHANNEL RECALL] to return to the previously viewed channel.

• When you select a channel larger than 100, press [+100] first. Then use [the Number buttons] to press the lower 2-digit numbers.

About digital TV broadcasting:

With its high definition broadcast, digital broadcasting far surpasses analog broadcasting in both its picture and sound quality.

What is the minor channel?

By using high compression technology, digital broadcasting offers a service that enables multiple signals to send simultaneously. Therefore, you can select more than one program per major channel since digital broadcasting technology distinguishes between multiple channels broadcast by a single network.

NTSC (analog mode)

CH4

: change automatically : change manually by using [CH / ]

Although, you cannot watch the high definition TV (HDTV) program, the unit converts the HDTV signal down to the standard definition TV signal.

–

/ENT

[Air Time]

18:00

18:30

19:00

19:30

20:00

20:30

major channel

ATSC (digital mode)

CH4

No signal No signal

CH4

(high denition TV)

CH4

CH4-1

CH4

No signal

CH4-1CH4 CH4-2

minor channel

Note:

• “NO SIGNAL” will appear on the TV screen after the minor channel broadcast is over.

No signal

CH4-2

Use

[VOL X / Y] to adjust the audio volume

VOL VOL

VOLUME 20

• The volume bar will be displayed at the bottom of the TV screen when adjusting the volume.

• The volume bar display will automatically disappear in a few seconds.

Press [MUTE] to turn off and on the sound.

• “MUTE” is displayed on the TV screen.

Press [MUTE] again or use [VOL X / Y] to recover the original volume.

MUTE

MUTE 20

INTRODUCTION

Switching Each Mode

You can easily switch with the remote control to the DTV (ATSC) and T V (NTSC) or to access an external device when they are connected to the unit.

Press [DTV/TV] repeatedly to change the analog TV or the digital TV.

DTV

ANALOG MODE

DIGITAL MODE

Note:

• When you switch the analog mode to the digital mode, it may take a while until the digital channel selection is completed. The following TV screen is displayed while switching the mode.

NOW SCANNING

Press [INPUT SELECT] repeatedly to cycle through the input modes.

ANALOG MODE

DTV

In the digital mode, the detailed broadcasting information for the current channel such as program title, the program guides are displayed.

Press [INFO] repeatedly to cycle through the available display modes.

OFF

INFOINFO

BROADCASTING INFORMATION

[Broadcasting Information]

• The following information is displayed.

1 channel number 2 broadcast station 3 program title 4 audio language

Press [AUDIO] repeatedly to cycle through the available audio languages. (“OTHER” is displayed when the audio language cannot be acquired, or the acquired languages are other than English, Spanish or French.)

2 3 4

PROGRAM GUIDE

KABC CH 25-03 A Day of Memories ENGLISH 1/3

CONNECTION INITIAL SETTING OPTIONAL SETTING

WATCHING TV

DIGITAL MODE

INPUT

SELECT

VIDEO1

VIDEO2

• To use the video or S-video input jack on the rear of the unit, select “VIDEO1”.

• To use the video input jack on the front of the unit, select “VIDEO2”.

Screen Information

You can display the currently selected channel or other information such as the audio mode on the TV screen.

In the analog mode, the current channel number is displayed.

Press [INFO].

CH 25

INFOINFO

• The current channel number is displayed at the topright corner of the TV screen.

• To clear the display, press [INFO] again.

[Program Guide]

• The program guide added to broadcasting information is displayed.

KABC CH 25-03 A Day of Memories ENGLISH 1/3 A quarter-century ago, which may now

program guide

qualify as the good old days of newspapering, run-of-paper sales accounted for 80 percent of the industry’s advertising revenues. Next - Push Vol Y Key Back - Push Vol X Key

Note:

• When the program guide consists of more than 6 lines, use [VOL X/Y] to scroll.

• “No description provided” is displayed when the program guide is not provided.

• While the program guide is displayed, the closed caption function is interrupted.

• In external input mode, the following screen is displayed;

e.g.) When an external device is connected to S-video input

jack.

VIDEO 1

• Available languages differ depending on the broadcast.

• The information display will automatically disappear in a

• Pressing [AUDIO] does not control external audio source.

few seconds when the closed caption is on.

TROUBLESHOOTING

INFORMATION

ATCHING TV

TV Screen Display Mode

DTV

2 types of display modes can be selected in the digital mode when the broadcasting station is sending 16:9 video signal.

Sleep Timer

The sleep timer can be set to automatically turn o the unit after an incremental period of time.

Press [MENU] to display the main menu.

Use [CH K / L] to select “DTV SETUP”, then press

[VOL X]. e.g.) digital TV mode

VOL

Use [CH K / L] to select “DTV DISPLAY”, then use

[VOL X / Y] to switch the desired TV aspect ratio.

VOL VOL

- TV SETUP -

PICTURE CHANNEL SETUP V-CHIP SETUP LANGUAGE [ENGLISH] CAPTION [OFF] DTV SETUP

- DTV SETUP -

DTV DISPLAY [LETTERBOX] DTVCC

Press [SLEEP] to set the sleep timer.

SLEEP

• Sleep timer display appears on the TV screen.

Press [SLEEP] repeatedly to change the amount of

time until shut off.

SLEEP

• You can set the unit to turn off after a set period of time (from 30 to 120 minutes).

• Each press of [SLEEP] will increase the time by 30

minutes.

• After set up, the sleep timer display can be called up

for checking by pressing [SLEEP].

To Cancel the Sleep Timer

Press [SLEEP] repeatedly until “SLEEP OFF“ is displayed on the TV screen.

SLEEP OFF

SLEEP 120 MIN.

ZOOMLETTERBOX

[LETTERBOX] Display the digital-supported program in full-screen. Black borders will spread in the upper and lower

screen.

[ZOOM] Enlarge and display the center area of the digital-

supported program.

The right and left side of image will be cut off.

Press [MENU] to exit.

Note:

• You may not switch the display mode depending on the program.

Note:

• The sleep timer setting display will automatically disappear in a few seconds.

• When you disconnect the unit from the AC outlet or when a power failure occurs, the sleep timer setting will be canceled.

PTIONAL SETTING

Channel Add/Delete

The channel add/delete function lets you add the channel that was not added by the auto channel scan due to the reception status at the initial setting. You can also delete the unnecessary channels.

Press [MENU] to display the main menu.

Use [CH K / L] to select “CHANNEL SETUP”,

then press [VOL X].

e.g.) digital TV mode

VOL

Use [CH K / L] to select “ADD/DELETE(DTV)” or

“ADD/DELETE”, then press [VOL X].

e.g.) digital TV mode

VOL

- TV SETUP -

PICTURE CHANNEL SETUP V-CHIP SETUP LANGUAGE [ENGLISH] CAPTION [OFF] DTV SETUP

- CHANNEL SETUP -

ADD/DELETE(DTV) AUTO PRESET CH(DTV) AUTO PRESET CH(TV/DTV) AUTO PRESET CH(CATV) ! CATV takes approx. 50min.

Press [MENU] to exit.

Note:

• ”ADD/DELETE(DTV)” or “ADD/DELETE” menu will disappear automatically in a few seconds.

• In the digital mode (DTV), you can add or delete channels only for major channel.

• Once you delete a DTV channel, you cannot recover the channel without performing auto channel scan again. (Refer to “Auto Channel Scan” on page 11.)

WATCHING TVINTRODUCTION CONNECTION INITIAL SETTING

OPTIONAL SETTING

TROUBLESHOOTING

Select the channel you want to add or delete.

(Refer to “Channel Selection“ on page 12.)

e.g.) digital TV mode

D25

ADD/DELETE : DTV

Use [VOL X / Y] to select “ADD” or “DELETE”.

VOL VOL

• To add or delete another channels, repeat steps 4 to 5.

• Color of channel number displayed at the right top of the TV screen indicates;

- Blue: The selected channel will be added.

- Red: The selected channel will be deleted.

INFORMATION

PTIONAL SETTING

Picture Adjustment

You can adjust brightness, contrast, color, tint and sharpness.

Closed Caption

You can view closed captioning (cc) for TV programs, movies and news. Closed caption refer to text of dialogue or descriptions displayed on-screen for the hearing impaired.

Press [MENU] to display the main menu.

Use [CH K / L] to select “PICTURE”, then press [VOL X].

e.g.) digital TV mode

VOL

Use [CH K / L] to select the picture quality type you

want to adjust.

- TV SETUP -

PICTURE CHANNEL SETUP V-CHIP SETUP LANGUAGE [ENGLISH] CAPTION [OFF] DTV SETUP

BRIGHT

CONTRAST

COLOR

TINT

Use [VOL X / Y] to adjust the quality.

VOL VOL

Selection

BRIGHT to decrease brightness to increase brightness

CONTRAST to decrease contrast to increase contrast

COLOR to decrease color to brighten color

TINT to add red to add green

SHARPNESS to make soft to make clear

Press [MENU] to exit.

[VOL Y] [VOL X]

SHARPNESS

Note:

• The picture adjustment setting display will automatically disappear in a few seconds.

Press [MENU] to display the main menu.

Use [CH K / L] to select “CAPTION”,

then use [VOL X / Y] to change the setting.

e.g.) digital TV mode

- TV SETUP -

PICTURE CHANNEL SETUP V-CHIP SETUP LANGUAGE [ENGLISH] CAPTION [OFF] DTV SETUP

OFF

CAPTION1

CAPTION2

CAPTION3

CAPTION4

VOL VOL

TEXT1

TEXT2

TEXT3

[Caption Mode]

CAPTION1 (C1) and TEXT1 (T1);

are the primary caption and text services.

The captioning or text is displayed in the same language as the program’s dialogue

(up to 4 lines of script on the TV screen, where it does

not obstruct relevant parts of the picture).

CAPTION3 (C3) and TEXT3 (T3);

serve as the preferred data channels. The captioning or text is often a secondary language.

CAPTION2 (C2), CAPTION4 (C4), TEXT2 (T2) and TEXT4 (T4);

are rarely available and broadcasters use them only

in special conditions, such as when “CAPTION1” and “CAPTION3” or “TEXT1” and “TEXT3” are not available.

• There are 3 display modes according to programs: Paint-on mode: Displays input characters on the TV

screen immediately.

Pop-on mode: Once characters are stored in

memory, they are displayed all at once.

Roll-up mode: Displays the characters continuously

by scrolling (max. 4 lines).

TEXT4

DTV Closed Caption

DTV

In addition to the basic closed caption described on page 16, DTV has its own closed caption called DTVCC. Use this menu to change the settings for DTVCC.

Press [MENU] to exit.

Note:

• To show the closed caption on your TV screen, broadcast signal must contain the closed caption data.

• Not all T V programs and commercials have the closed caption or all types of the closed caption.

• Captions and texts may not match the TV voice exactly.

• Changing channels may delay the closed caption for a few seconds.

• Adjusting or muting the volume may delay the closed caption for a few seconds.

• Abbreviations, symbols and other grammatical shortcuts may be used in order to keep pace with the on-screen action. This is not a problem with the unit.

• The caption or text characters will not be displayed while the main menu or functions display is shown.

• If a black box appears on the TV screen, this means that the closed caption is set to the text mode. To clear the box, select “C1”, “C2”, “C3”, “C4” or “OFF”.

• If the unit receives poor quality television signals, the captions may contain errors, or there might be no captions at all. Some possible causes of poor quality signals are:

- Automobile ignition noise

- Electric motor noise

- Weak signal reception

- Multiplex signal reception (ghosts or screen flutter)

• The unit retains the closed caption setting if the power fails.

• When the unit receives special effects playback signal (i.e., Search, Slow and Still) from a VCR’s video output channel (CH3 or CH4), the unit may not display the correct caption or text.

Press [MENU] to display the main menu.

Use [CH K / L] to select “DTV SETUP“,

then press [VOL X] . e.g.) digital TV mode

VOL

Use [CH K / L] to select “DTVCC“, then press [VOL X] .

- TV SETUP -

PICTURE CHANNEL SETUP V-CHIP SETUP LANGUAGE [ENGLISH] CAPTION [OFF] DTV SETUP

e.g.) digital TV mode

VOL

Use [CH K / L] to select “CAPTION SERVICE“, then use

- DTV SETUP -

DTV DISPLAY [LETTERBOX] DTVCC

[VOL X / Y] to change the setting.

VOL VOL

- DTVCC CAPTION SERVICE [OFF] USER SETTING [OFF] CAPTION SIZE [MIDDLE] FONT STYLE [STYLE1/8] CHARACTER EDGE [NONE] FORE OPACITY [SOLID] FORE COLOR [WHITE] BACK OPACITY [SOLID] BACK COLOR [BLACK]

OFF

CAPTION SERVICE

SERVICE1~6

Select if you do not want DTVCC. This is the default.

Select one of these before changing any other item in “CAPTION” menu. Choose “SERVICE1/6” under normal circumstances.

WATCHING TVINTRODUCTION CONNECTION INITIAL SETTING

OPTIONAL SETTING

TROUBLESHOOTING

INFORMATION

Press [MENU] to exit.

Note:

• “CAPTION SERVICE” that you can switch differs depending on the broadcast description.

PTIONAL SETTING

DTVCC Style

DTV

You can change the style of DTV CC such as font, color or size, etc.

Press [MENU] to display the main menu.

Use [CH K / L] to select “DTV SETUP”,

then press [VOL X].

e.g.) digital TV mode

VOL

Use [CH K / L] to select “DTVCC“, then press [VOL X].

- TV SETUP -

PICTURE CHANNEL SETUP V-CHIP SETUP LANGUAGE [ENGLISH] CAPTION [OFF] DTV SETUP

e.g.) digital TV mode

VOL

Use [CH K / L] to select “USER SETTING“,

- DTV SETUP -

DTV DISPLAY [LETTERBOX] DTVCC

then use [VOL X / Y] to set to “ON”.

• Items in the dotted box are available only when “USER SETTING“ is “ON“.

VOL VOL

Use [CH K / L ] to select an item, then use [VOL X / Y]

- DTVCC CAPTION SERVICE [SERVICE1/6] USER SETTING [ON] CAPTION SIZE [MIDDLE] FONT STYLE [STYLE1/8] CHARACTER EDGE [NONE] FORE OPACITY [SOLID] FORE COLOR [WHITE] BACK OPACITY [SOLID] BACK COLOR [BLACK]

to change the setting for the item.

• CAPTION SIZE

Closed captioning font size can be changed as below.

• FONT STYLE

Font style of the displayed caption can be switched as

below.

• CHARACTER EDGE

Edge type of the displayed caption can be switched

as below.

• FORE COLOR, BACK COLOR

Font and background color of the displayed caption

can be switched as below.

• FORE OPACITY, BACK OPACITY

Text and background opacity of the displayed caption

can be switched as below.

CAPTION SIZE MIDDLE, LARGE, SMALL

STYLE1/8

STYLE2/8 Monospaced with serifs

STYLE3/8

FONT STYLE

CHARACTER EDGE

FORE OPACITY SOLID, TRANSLUCENT, FLASH

FORE COLOR

BACK OPACITY SOLID, TRANSLUCENT, FLASH

BACK COLOR

Press [MENU] to exit.

STYLE4/8 Monospaced with serifs

STYLE5/8

STYLE6/8 Casual font type STYLE7/8 Cursive font type STYLE8/8 Small capitals NONE, RAISED, DEPRESSED, UNIFORM,

SHADOW LEFT, SHADOW RIGHT

WHITE, BLACK, RED, GREEN, BLUE, YELLOW, MAGENTA, CYAN, TRANSPARENT

BLACK, RED, GREEN, BLUE, YELLOW, MAGENTA, CYAN, TRANSPARENT, WHITE

Proportional font used in the menu screen

Proportionally spaced with serifs

Proportionally spaced without serifs

VOL VOL

V-chip

V-chip reads the ratings for programs, then denies access to the programs which exceed the rating level you set. With this function, you can block certain programming inappropriate for children.

Press [MENU] to display the main menu.

Use [CH K / L] to select “V-CHIP SETUP“,

then press [VOL X].

e.g.) digital TV mode

VOL

- TV SETUP -

PICTURE CHANNEL SETUP V-CHIP SETUP LANGUAGE [ENGLISH] CAPTION [OFF] DTV SETUP

Use [the Number buttons] to enter the 4-digit

numbers for your password.

321

654

PASSWORD

- - -

• When you have not set up your password, enter 0000.

• When the password is correct, the following “V-CHIP SETUP” menu is displayed.

See the following description for setting each item.

e.g.) digital TV mode

...

“A. TV Rating” D page 20

...

“B. MPAA Rating”D page 21

...

“C. Change Password”

D page 21

- V - CHIP SETUP -

TV RATING MPAA RATING DOWNLOADABLE RATING CHANGE PASSWORD

Note:

• “DOWNLOADABLE RATING“ will be available when the unit receives a digital broadcast using the new rating system.

• When you select a rating and set it to “BLOCK”, the higher ratings will be blocked automatically. The lower ratings will be available for viewing.

• When you set the highest rating to “VIEW”, all ratings turn to “VIEW” automatically.

• If the “PROTECTED PROGRAM” message appears during your TV viewing, change to a channel that is not blocked. Then, you can access “V-CHIP SETUP” menu and change the setting to allow all TV viewing.

• To block any inappropriate programming, set your limits in both “TV RATING” and “MPAA RATING”.

• The V-chip setting will be retained after a power failure (except the access code reverts to 0000).

WATCHING TVINTRODUCTION CONNECTION INITIAL SETTING

A B

OPTIONAL SETTING

TROUBLESHOOTING

INFORMATION

PTIONAL SETTING

A. TV Rating

Use [CH K / L] to select “TV RATING“,

then press [VOL X]. e.g.) digital TV mode

Use [CH K / L ] to select the desired rating,

VOL

- V - CHIP SETUP -

TV RATING MPAA RATING DOWNLOADABLE RATING CHANGE PASSWORD

then press [VOL X] repeatedly to switch between “VIEW” and “BLOCK”.

VOL

Rating Category

TV-Y Appropriate for all children lower

TV-Y7

TV-G General audience TV-PG Parental guidance suggested TV-14 TV-MA Mature audience only higher

Appropriate for all children 7 and older

Unsuitable for children under 14

TV-Y [VIEW] TV-Y7 ( ) [VIEW] TV-G [VIEW] TV-PG ( ) [VIEW] TV-14 ( ) [VIEW] TV-MA ( ) [VIEW]

[To Set the Sub Ratings]

As for TV-Y7, TV-PG, TV-14 or TV-MA, you can further set the sub ratings to block specific elements of programming. To set the sub ratings, follow the steps below.

Use [CH K / L ] to select the desired main rating,

then press [VOL X] twice to show its sub ratings.

VOL

Use [CH K / L ], then press [VOL X] repeatedly to

change the setting.

TV-Y [VIEW] TV-Y7 (DLSV) [VIEW] TV-G [VIEW] TV-PG (DLSV) [BLOCK] TV-14 (DLSV) [BLOCK] TV-MA (DLSV) [BLOCK]

e.g.) TV-PG

VOL

Sub Rating Category Rating FV Fantasy Violence TV-Y7 V Violence S Sexual Situation L Coarse Language D Suggestive Dialogue TV-PG, TV-14

TV-PG [BLOCK]

D [BLOCK] L [BLOCK] S [BLOCK] V [BLOCK]

TV-PG TV-14 TV-MA

Press [MENU] to exit.

Note:

• Blocked sub ratings will appear beside the main rating category in “TV RATING” menu.

• You cannot block a sub rating (D, L, S or V) if the main rating is set to “VIEW”.

• Changing the category to “BLOCK” or “VIEW” automatically changes all its sub ratings to the same (“BLOCK” or “VIEW”).

B. MPAA Rating

MPAA Rating is the rating system created by MPAA (Motion Picture Association of America).

C. Change Password

Although the default code “0000” is supplied with the unit, you can set your own password.

Use [CH K / L] to select “MPAA RATING”,

then press [VOL X]. e.g.) digital TV mode

VOL

Use [CH K / L], then press [VOL X] repeatedly to

- V - CHIP SETUP -

TV RATING MPAA RATING DOWNLOADABLE RATING CHANGE PASSWORD

change the setting.

VOL

Rating Category G PG PG-13

NC-17 X

Press [MENU] to exit.

General audience

Parental guidance suggested

Unsuitable for children under 13

Restricted; under 17 requires accompanying parent or adult guardian

No one under 17 admitted

Mature audience only

G [VIEW] PG [VIEW] PG-13 [VIEW] R [BLOCK] NC-17 [BLOCK] X [BLOCK]

Use [CH K / L] to select “CHANGE PASSWORD”,

then press [VOL X]. e.g.) digital TV mode

VOL

Press [the Number buttons] on the remote control to

- V - CHIP SETUP -

TV RATING MPAA RATING DOWNLOADABLE RATING CHANGE PASSWORD

enter the new 4-digit password.

• Enter password again in “CONFIRM PASSWORD” space.

Press [MENU] to exit.

321

654

NEW PASSWORD

_ _ _ _

CONFIRM PASSWORD

_ _ _ _

Note:

• Make sure new password and confirm password must be exactly the same. If they are different, the space is cleared for reentering.

• Your password will be erased and return to the default (0000) when a power failure occurs. If you forget the password, unplug the power cord for 10 seconds to restore the password to 0000.

WATCHING TVINTRODUCTION CONNECTION INITIAL SETTING

OPTIONAL SETTING

TROUBLESHOOTING

INFORMATION

ROUBLESHOOTING

Troubleshooting Guide

If the unit does not perform properly when operated as instructed in this owner’s manual, check the following chart once before calling for service.

Symptom Remedy

No power • Be sure the power cord is plugged in.

No picture or sound • Check if the power is on.

No color • Check the antenna or cable connection to the main unit.

Sound OK, picture poor • Check the antenna or cable connection to the main unit.

Picture distorted • When the outside antenna is used, check the wire condition and connection.

Weak picture • Check the antenna or cable connection to the main unit.

Lines or streaks in picture • When the outside antenna is used, check the wire condition and connection.

Picture blurred • When the outside antenna is used, check the wire condition and connection.

Ghosts in picture • Check the antenna or cable connection to the main unit.

Bars on TV screen • When the outside antenna is used, check the wire condition and connection.

Picture rolls vertically • When the outside antenna is used, check the wire condition and connection.

Different color marks on TV screen

Poor reception on some channels

Picture OK, sound poor • View other TV channels. The problem might be limited to the broadcasting station. No reception of digital signals • Make sure auto channel scan has been completed. (Refer to “Auto Channel Scan”

• If a power failure occurs, unplug the power cord for 30 minutes to allow the unit to reset itself.

• Check the outlet connection.

• Check the antenna or cable connection to the main unit.

• When the outside antenna is used, check the wire condition and connection.

• View other TV channels. The problem might be limited to the broadcasting station.

• Turn off the power and wait for about 1 minute, then turn it on again.

• When the outside antenna is used, check the wire condition and connection.

• View other TV channels. The problem might be limited to the broadcasting station.

• Adjust “COLOR” in “PICTURE” menu.

• When the outside antenna is used, check the wire condition and connection.

• Electrical interference from nearby appliances may affect picture quality.

• Adjust “CONTRAST” and “BRIGHT” in “PICTURE” menu.
