FUNAI CIWP4206 A, CIWP4206 User Manual

OWNER'S MANUAL

CIWP4206 A

CIWP4206

42 INCH ANALOG / DIGITAL PLASMADISPLAYTV

TO RECEIVE DIGITAL/ANALOG SIGNAL,YOU MUST CONNECT ANTENNA.

HIGH-DEFINITIONTELEVISION

By changing the screen display mode from time to time, you can reduce burn-inon screen.

(Refer to “CHANGING THE SCREEN DISPLAY MODE” on page 21.)

IF YOU NEED ADDITIONAL ASSISTANCE WITH SET-UPOR OPERATING AFTER READING OWNER’S MANUAL, PLEASE CALL TOLL FREE1-800-474-0045,OR VISIT OUR WEB SITE AThttp://www.funai-corp.com

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERA-

TURE ACCOMPANYING THE APPLIANCE.

The important note is located on the rear of the cabinet.

IMPORTANT SAFETY INSTRUCTIONS

1.Read these instructions.

2.Keep these instructions.

3.Heed all warnings.

4.Follow all instructions.

5.Do not use this apparatus near water.

6.Clean only with dry cloth.

7.Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8.Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9.Do not defeat the safety purpose of the polarized or grounding-typeplug. A polarized plug has two blades with one wider than the other. Agrounding-typeplug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10.Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11.Only use attachments/accessories specified by the manufacturer.

12.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

PORTABLE CART WARNING

S3126A

13.Unplug this apparatus during lightning storms or when unused for long periods of time.

14.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as powersupply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15.Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.

To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

2

EN

PRECAUTIONS

•Place your TV in a room with adequate ventilation.

•Keep your TV set away from sources of direct heat, such as heat registers or direct sunlight.

•Do not place your TV on soft surfaces, such as rugs or blankets.

•Leave enough room for air to circulate around the bottom, top and back of the set.

FCC WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

Note to CATV system installer:

This reminder is provided to call the CATV system installer's attention to Article 820-40of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground should be connected to the grounding system of the building as close to the point of cable entry as practical.

The serial number of this product may be found on the back of the TV. No others have the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft.

Model No.		Date of Purchase
Serial No.		Dealer Phone No.
Dealer Purchase from		Dealer Address

A NOTE ABOUT RECYCLING:

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

When moving this TV

Due to the weight of this TV, two people should be used when moving it. Both people should make sure to grasp the top of the TV with one hand and the base of the TV with the other hand, as in the following illustration.

Optional Accessories

To mount the TV on a wall, the following accessory is needed:

VISIONMOUNT™ Flat Panel TV Wall Mount from SANUS SYSTEMS, for large flat panel televisions (32" to 60"). Refer to page 31 for mounting the TV.

NOTE:

• The wall mounts are not supplied with the TV.

# CAUTION

•This TV is for use only with the Sanus Systems Model VMPL. Wall Mount.

Use with other wall mounts may result in instability, causing possible injury.

•When mounting the TV with the Sanus Systems wall mount, make sure to mount it on the wood studs inside the wall, as failure to do so may result in instability, causing possible injury.

•Refer to the instruction manual included with the wall mount for details when securing the TV to the wall.

IMPORTANT SAFETY INSTRUCTIONS / PRECAUTIONS

3

EN

SUPPLIED ACCESSORIES

• Owner’s Manual	• Quick Set Up	• Power Cable
(1EMN22014A)	(1EMN22015A)	(WBC0192LW001)

• Remote control unit	• Batteries
(NF009UD)	(“AA” x 2)

•If you need to replace these accessories, please refer to the PART NO. with the illustrations and call our toll free customer support line found on the cover of this manual.

•Depending on your antenna system, you may need different types of Combiners (Mixers) or Separator (Splitters). Contact your local electronics store for these items.

FEATURES

• DTV/TV/CATV

You can use your remote control to select channels which are broadcast in conventional analog, standard definition, and high definition formats. Also, cable subscribers can access their cable TV channels.

• Program Information Display (DTV only)

You can display the title, contents and other information of the current DTV program on the screen.

•Autoscan

This TV can automatically scan and memorize the channels receivable in your residential area. This feature eliminates the need of a difficult setting procedure.

•V-CHIP

This feature allows you to block children’s access to inappropriate programs.

•Closed Caption Decoder

This TV contains the built-inClosed Caption Decoder that displays text across the screen. It allows you to read the dialogue of a TV program or other information in the ClosedCaption-supportedprograms.

•MTS/SAP Tuner

This feature allows you to select with the remote control your desired audio language.

•Auto Shut Off Function

If there is no signal input from the antenna terminal and no operation for 15 minutes, the unit will turn itself off automatically.

•Choices for On-ScreenMenu Language

Select your setup menu language: English, Spanish or French.

•Stereo Sound Function

•Full-FunctionRemote Control

•PLL Frequency Synthesized Tuning

•HDMI Input

This TV accepts 480i / 480p / 720p / 1080i video signals and 32kHz / 44.1kHz / 48kHz audio signals.

•Component VIDEO Input

This TV accepts 480i / 480p / 720p / 1080i video signals.

•S-VIDEOInput

•AV Input

•Analog Audio Output

•Digital Audio Output (Coaxial)

•Resume

This feature will automatically memorize settings if a power failure occurs.

4

EN

CONTENTS

IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 SUPPLIED ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

REMOTE CONTROL, FRONT AND REAR PANEL FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 INSTALLING THE BATTERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 BATTERY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 REMOTE CONTROL RANGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

PREPARATION FOR USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8

CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 ANTENNA CABLE CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 CONNECTION TO CABLE/SATELLITE BOX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 CONNECTING OTHER DEVICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 COMPONENT CABLE CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 S-VIDEOCABLE CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 VIDEO CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 DIGITAL AUDIO CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 ANALOG AUDIO CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 CONNECTING THE POWER CABLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

INITIAL SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

INITIAL SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

CHANNEL SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

AUTOSCAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	14
CHANNEL LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	15
MANUAL REGISTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	15
ANTENNA CONFIRMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	16
LANGUAGE SELECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	17
SETTING THE PANEL SAVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	17

WATCHING TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

CHANNEL SELECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	18
VOLUME ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	18
STILL MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	19
SELECTING AUDIO CHANNELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	19
ACCESSING EXTERNAL DEVICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	20
CHANGING THE SCREEN DISPLAY MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	21
SCREEN INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	22
SLEEP TIMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	23

OPTIONAL SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

SETUP SCREEN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 PICTURE ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 CLOSED CAPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 DTV CLOSED CAPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 CLOSED CAPTION STYLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 V-CHIP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28 HDMI AUDIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

ATTACHING A WALL MOUNT BRACKET (SOLD SEPARATELY) . . . . . . . . . . . . . . . . . . . . . .31

MISCELLANEOUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

TROUBLESHOOTING GUIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 GLOSSARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back cover

SYMBOLS USED IN THIS MANUAL

The following is the description for the symbols used in this manual.

TV	: Settings only for the analog mode
DTV	: Settings only for the digital mode

•If there is no symbol under the function heading, those are common settings for the analog mode and digital mode.

SUPPLIED ACCESSORIES / FEATURES / CONTENTS

5

EN

FUNCTIONS

REMOTE CONTROL, CONTROL AND REAR PANEL FUNCTION

SLEEP button (p23)						INPUT SELECT button (p20)
Press to activate the sleep timer.						Press to access connected external
		POWER		INPUT		devices like a DVD recorder or VCR.
POWER button (p13)			SLEEP SELECT
						AUDIO button (p19)
Press to turn the TV on and off.		1	2	3		Cycles through audio options.
Number buttons (p18)						• Analog mode (TV)
Press to select a channel.		4	5	6		Selects audio mode.
SETUP button (p23)				AUDIO		• Digital mode (DTV)
		7	8			Selects audio language.
Press to display on-screenmenu.				9
						STILL button (p19)
s / B/ K/ Lbuttons (p13)		-	0	STILL
						Press to pause screen image.
To move left / right / up / down through		SETUP		SCREEN		SCREEN MODE button (p21)
the items.				MODE
						Press to select screen aspect ratio.
ENTER button (p13)
						INFO button
Press to confirm your selection.			ENTER
		BACK		INFO		• Analog mode (TV) (p22)
						To display channel No., signal type
BACK button (p22)
						and TV setting.
Press to return to previous menu operation.			CH RETURN			• Digital mode (DTV) (p22)
VOL. X/Y buttons(p18)		VOL.	MUTE	CH		To display channel information, signal
						type and TV setting.
Press to adjust volume.						• External input mode (p20)
MUTE button (p18)						To display external input mode, signal
Press to turn sound on and off.						type and TV setting.
						CH K/L buttons(p18/p20)
CH RETURN button (p18)
						To select channels and external input
Press to return to previously viewed channel.
						mode.
INPUT SELECT/ENTER						Infrared Sensor Window
button (p20/p13)						Receives infrared rays transmit-
• To access connected external						ted from the remote control.
devices like a DVD recorder or
VCR.						STANDBY indicator
• To decide the command of
						Illuminates when TV is in stand-
setting when the menu is dis-
						by mode. Disappears when the
played.
						power is ON.
CHANNEL K/L buttons(p18)
						ON indicator
To select channels and move
						Lights up when the power is ON.
up/down through the menu items.
						POWER button (p13)
VOLUME X/Y buttons(p18)
						To turn TV on/off.
To adjust volume and move	SETUP	VOLUME CHANNEL	INPUT SELECT /	STANDBY ON	POWER
			ENTER
right(X)/left(Y) through the						SETUP button (p23)
menu items.						To display on-screenmenu.

NOTE:

•With buttons [VOL. X/Y] or[MUTE], you can only adjust the volume of the main unit. You cannot adjust the volume of the external devices with these buttons.

About Interference to Infrared Devices

Please note in advance that using other infrared devices (such as infrared cordless headphones) near the plasma display may cause infrared interference to occur.

About Pixel Defects

A plasma display is created by using a collection of miniature pixels. It is possible to display more than 99.99% of valid pixels, however a small fraction of pixels over the life of the product may not illuminate or may constantly be illuminated.

This is not to be considered a defect in the plasma panel.

6

Preventing Image Burn on the plasma display

Fixed images displayed on the plasma display for an extended period of several hours may cause uneven pixel aging causing damage to the plasma display. You should try to avoid displaying fixed images for extended periods on the plasma display.

Images of high luminance displayed on the plasma display for more than 60 seconds may cause lingering images to remain on the screen. These images will automatically disappear, but may take time depending on the luminance of the images and how long they were displayed on the screen.

EN

ANT. IN jack							AUDIO OUT jacks
Coaxial cable connection for your							Audio cable connection for external
antenna or cable box.						from underneath audio equipment. Use AUDIO IN jacks
DIGITAL AUDIO OUT						HDMI	of external equipment.
				ANT. IN

(COAXIAL) jack

AUDIO OUT

AUDIO

HDMI IN jack

Digital audio coaxial					L	L	HDMI cable connection for external
			DIGITAL			HDMI IN
cable connection for							video equipment (i.e.DVD recorder).
			(COAXIAL)
			AUDIO OUT		R	R
decoder or audio								AUDIO jacks (for DVI con-
receiver. Connect	by side	Rear of this TV
								nection)
cable to DIGITAL
	R							Audio cable connection for
AUDIO IN jack of
	AUDIO							external audio/video
external device.	L
								devices with DVI jack. Use
VIDEO2 and AUDIO	VIDEO2							AUDIO OUT jacks of exter-
								nal equipment when using
jacks
	S-VIDEO2							an HDMI-DVIconversion
Video and audio cable
								cable.
connection for external
								VIDEO1 and AUDIO
equipment.
S-VIDEO2jack			COMPONENT2		COMPONENT1			jacks
			Y		Y	VIDEO1		Video and audio cable
S-Videocable and audio		L	Pb	L	Pb	L		connection for external
(VIDEO2) cable connection for		AUDIO		AUDIO		AUDIO		equipment.
		R	Pr	R	Pr	R	S-VIDEO1
external video equipment.

	COMPONENT2 and AUDIO	from underneath	S-VIDEO1jack
			S-Videocable and audio
	jacks	COMPONENT1 and AUDIO
			(VIDEO1) cable connec-
	Component cable connection	jacks
			tion for external video
	for external audio/video	Component cable connection for
			equipment.
	devices. Use component and	external audio/video devices.
	audio out jacks of external	Use component and audio out
	device.	jacks of external device.

FUNCTIONS

INSTALLING THE BATTERIES

Install two AA batteries (included) matching the polarity (++ / – –)indicated inside battery compartment of the remote control.

[BATTERY PRECAUTIONS]

•Be sure to follow the correct polarity as indicated in the battery compartment. Reversed batteries may cause damage to the device.

•Do not mix different types of batteries together (e.g. Alkaline and Carbon-Zinc)or old batteries with fresh ones.

•If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from possible battery leakage.

•Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.

REMOTE CONTROL RANGE

Operate the remote control within a 30 degree angle on both sides of the infrared sensor on the main unit. You can operate the remote control from a distance of several yards away from the main unit.

			NOTE:
			• Other devices which use infrared beams,
	Within 30 degrees	Within 30 degrees	sunlight, fluorescent lights, etc., may affect
			the range and effectiveness of the remote
	Approximately 5.5 yds (5 m)	Approximately 5.5 yds (5 m)	control. Make sure the TV is positioned in a
			place which minimizes interference from
		Approximately	them.
		7.6 yds (7 m)	7

EN

PREPARATION FOR USE

CONNECTION

This section describes how to connect your TV to an antenna, cable box, etc.

MAKE SURE YOU HAVE AN ANTENNA.

As DTV is only available over the air, you need an antenna to receive a digital signal.

NOTE:

• Be sure your antenna or other source is connected properly before plugging in the power cord.

[ANTENNA CABLE CONNECTION]

1)When connecting your TV to an antenna

Connect the Coaxial cable on your home outlet to the ANT. IN jack of this TV.

2)When connecting TV to cable TV company (without box)

Connect the Coaxial cable on your home outlet to the ANT. IN jack of this TV.

Rear of this TV

VHF / UHF

antenna

		Coaxial cable
		(not included)
		or
	Cable TV	Coaxial cable
		(not included)
	company

ANT. IN

*Once connections are completed, turn on the TV and begin initial setup.

Channel scanning is necessary for the TV to memorize all available channels in your area. (Refer to “INITIAL SETUP” on page 13.)

NOTES:

•For your safety and to avoid damage to equipment, please unplug the coaxial cable from the ANT.IN jack before moving the unit.

•If you use an antenna in order to receive analog TV, the same antenna generally will work for DTV reception. Outdoor or attic antennas will be more effective than set-topversions.

•To easily switch between antenna and cable wires, you can purchase an “Antenna Selector” commercially available.

•If you connect a cable system directly, contact the CATV installer.

[CONNECTION TO CABLE/SATELLITE BOX]

1)Connect the coaxial cable on your home outlet to the input jack of the CABLE/SATELLITE box.

2)Use another coaxial cable to connect the ANT. IN jack of your TV to the output jack of the CABLE/SATELLITE box.

*Required cables in 2) and connecting methods differ depending on the CABLE/SATELLITE box. For more informa-

tion, please contact your cable/satellite provider.

Satellite

dish Cable box or Satellite box

		or
	Cable TV	Coaxial cable	Coaxial cable
		(not included)	(not included)
	company

Rear of this TV

ANT. IN

8

EN

CONNECTING OTHER DEVICES

[HDMI]

1)High Definition Multimedia Interface (HDMI) uses the latest technology to ensure the signal maintains the highest degree of integrity from source to TV. Both video and audio travel through a single cable.

HDMI cable (not included)

To HDMI IN jack

		ANT. IN		HDMI
	HDMI OUT		AUDIO OUT	AUDIO
			L	L
	To HDMI output jack	DIGITAL
	DVD Player with the HDMI output jack	AUDIO OUT	R	R
		(COAXIAL)

Rear of this TV

NOTES:

•This TV accepts 480i / 480p / 720p / 1080i video signals, and 32kHz / 44.1kHz / 48kHz audio signals.

•This TV accepts only 2 channel audio signal (LPCM).

•You need to select “PCM” for the digital audio output of the device you connect or the HDMI audio setting. Audio sometimes makes no sound if you select “Bitstream”, etc.

•This TV only accepts signals corresponding EIA861.

2)When your video device has a DVI output jack, connect the HDMI conversion cable (not included) from the DVI output jack.

Cable Box or Satellite Box with the DVI output jack

			HDMI-DVIconversion cable(not included)
	To DVI output jack			To HDMI IN jack
	DVI OUT
			ANT. IN	HDMI
				AUDIO OUT AUDIO
				L
	AUDIO OUT		DIGITAL	HDMI IN
	R	L
			AUDIO OUT	R
			(COAXIAL)
		To audio		To AUDIO Rear of this TV
		output jacks
				input jacks
			Audio cable (not included)

NOTES:

•This TV accepts 480i / 480p / 720p / 1080i video signals.

•An HDMI conversion cable requires a separate audio cable connection as well.

•Audio signals are converted from digital to analog if you make the connection in paragraph 2) above.

•DVI does not show image if the 480i does not accept EIA/CEA-861/861B.

“HDMI, the HDMI logo and High-DefinitionMultimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.”

PREPARATION FOR USE

9

EN

[COMPONENT CABLE CONNECTION]

Offers better picture quality for video devices connected to your TV.

Use a component video cable (not included) to connect your TV to external video devices equipped with component video jacks.

If you connect to your TV’s COMPONENT1 input jack, connect audio cables to the AUDIO L/R jacks of COMPONENT1.

If you connect to your TV’s COMPONENT2 input jack, connect audio cables to the AUDIO L/R jacks of COMPONENT2.

DVD Player with the component video output jacks

Component video cable (not included)

To component video

output jacks To COMPONENT1 input jacks

COMPONENT2	COMPONENT1
Y	Y	VIDEO1
L	Pb	L
AUDIO	AUDIO	AUDIO
R	Pr	R	S-VIDEO1

To audio	To AUDIO	Rear of this TV
output jacks	input jacks
Audio cable (not included)

NOTE:

• This TV accepts 480i / 480p / 720p / 1080i video signals.

[S-VIDEOCABLE CONNECTION]

Offers good picture quality for video devices connected to your TV.

Use an S-videocable (not included) to connect your TV to external video devices equipped withS-videoconnectors.

If you connect to your TV’s S-VIDEO1input jack, connect audio cables to the AUDIO L/R jacks of VIDEO1. If you connect to your TV’sS-VIDEO2input jack, connect audio cables to the AUDIO L/R jacks of VIDEO2.

Side of this TV

R	To AUDIO input jacks
AUDIO
L
VIDEO2	To S-VIDEO2input jack
S-VIDEO2

S-videocable (not included)

DVD/VCR with

the S-videooutput jack

							To S-VIDEO1
							input jack
VIDEO	S-VIDEO
OUT	OUT			COMPONENT2		COMPONENT1
				Y		Y	VIDEO1
AUDIO		To S-video	L	Pb	L	Pb	L
OUT		output jack	AUDIO		AUDIO		AUDIO
			R	Pr	R	Pr	R	S-VIDEO1

To audio	To AUDIO	Rear of this TV
	input jacks
output jacks

Audio cable (not included)

NOTE:

• If you connect to the S-VIDEOjack and the VIDEO jack at the same time, theS-Videoconnection will have priority.

10

EN

[VIDEO CONNECTION]

Offers standard picture quality for video devices connected to your TV.

When the audio jack of the video device is monaural, connect the audio cable to the audio L input jack.

Side of this TV

To AUDIO input jacks

R

AUDIO

L

VIDEO2 To VIDEO2 input jack

S-VIDEO2

Camcorder	Video Game
	VCR

Video cable (not included)

			To VIDEO1
To video			input jack
output jack		COMPONENT2		COMPONENT1
AUDIO	VIDEO	Y		Y	VIDEO1
OUT	OUT
	L	Pb	L	Pb	L
	AUDIO		AUDIO		AUDIO
	R	Pr	R	Pr	R	S-VIDEO1
	To audio
	output jacks				To AUDIO	Rear of this TV
					input jacks

Audio cable (not included)

[DIGITAL AUDIO CONNECTION]

If you connect this TV to an external digital audio device, you can enjoy multi-channelaudio like 5.1ch digital broadcasting sound. Required digital audio coaxial cable not included.

Rear of this TV

MD deck, DAT deck, etc.	To coaxial digital	ANT. IN	HDMI
	audio input jack

	COAXIAL	AUDIO OUT	AUDIO
		L	L
	DIGITAL		HDMI IN
	AUDIO OUT	R	R
	(COAXIAL)

To DIGITAL AUDIO

OUT jack

Dolby Digital decoder	Digital audio coaxial cable
	(not included)

Manufactured under license from Dolby Laboratories. “Dolby” and the double-Dsymbol are trademarks of Dolby Laboratories.

PREPARATION FOR USE

11

EN

[ANALOG AUDIO CONNECTION]

If you connect this TV to an external analog audio device, you can enjoy stereophonic (2 channel) audio sound. Required audio cable not included.

	To audio input jacks	ANT. IN		HDMI
		AUDIO OUT		AUDIO
	AUDIO
			L	L
	IN
		DIGITAL		HDMI IN
		AUDIO	R	R
		(COAXIAL)
	Stereo system	To AUDIO		Rear of this TV
	Audio cable
		OUT jacks

(not included)

CONNECTING THE POWER CABLE

Connect the power cord (included) to the TV before connecting it to the power source.

A C I N

1

1Connect the power cable to this TV first.

2Connect the power cable to an AC outlet.

2

# CAUTION

•Do not connect the power cable to a power supply outside the indicated voltage of this TV (AC 120V). Connecting the power cable to a power supply outside of this range may result in fire or electrical shocks.

•Always use the power cable included with this TV. Do not use any other cable.

For safety, make sure to always connect the power cable to a three pronged AC outlet.

12

EN

INITIAL SETTINGS

INITIAL SETUP

This section will guide you through your TV’s initial set up which includes selecting a language for your on-screenmenu and AUTOSCAN, which automatically scans and memorizes viewable channels.

POWER	SLEEP	INPUT
		SELECT

4Select source of ANT. IN jack using [K/L], press

[ENTER].

InitialI i i l Setup

Make sure the antenna is connected to "ANT IN" jack.			Air
Select the destination of "ANT IN" jack.			Cable
Air
Cable	Or
	ANT IN
Select	BACK	Back	SETUP
	ENTER Enter		Exit

1	2	3
4	5	6	5 Autoscan will start automatically.
7	8	9	AUDIO
			STILL
-	0
SETUP			SCREEN
			MODE
		ENTER
BACK			INFO

1 After making					connections, turn
on your TV.
2 Press [POWER]				menu will appear.
• This operation					moments.
• If Initial Setup					appear, press
and hold					initial setup
will appear			3.
• If initial set					completed,
refer to						on page 17.
3 When you first					the following
screen is					to select the
on-screenmenu					the choices on
the right side
	InitialI i i l Setup
		Select the language for setup display.			English
		Elija idioma de preparación.			Español
		Sélectionner langue écran config.			Français
		Select ENTER Enter	SETUP
				Exit
The						4 will

be displayed in the selected language after you press [ENTER].

•When

memorized channel will be displayed.

NOTES:

•If you do not operate your TV for more than 45 seconds during the initial setup, the message boxes start to move to the lower left-handcorner of the screen to preventburn-in.This is to save your screen fromburn-in.Press any key except[POWER] to cancel it.

•The initial Autoscan function can be executed for either “Air” or “Cable” only once. When you change the connection (Air/Cable), set the “Autoscan” again. (Refer to page 14.)

•If you connect a cable system directly, contact the CATV installer.

•When the scanning is not completed, Helpful Hint will be displayed every time you turn on the power. If you have previously registered channels when this screen appears you can select a channel with [the Number buttons].

2-0

No channel is registered.

Press and hold "ENTER" key for 3 seconds.

Contact support hotline provided on manual or back of unit.

Sin canal registrado.

Mantenga oprimida la tecla "ENTER" durante 3 segundos.

Llame teléfono de apoyo en manual o atrás de TV.

Pas de chaîne consign.

Maintenir la touche "ENTER" pressée 3 secondes.

Contacter numero d'urgence dans manuel ou arrière appareil.

•Toll free customer support line can be found on the cover of this manual.

PREPARATION FOR USE / INITIAL SETTINGS

13

EN

CHANNEL SETTINGS

AUTOSCAN

With AUTOSCAN, your TV automatically scans and memorizes your area’s viewable channels. Activate AUTOSCAN when you turn on your TV for the first time, change broadcast sources (e.g. from antenna to CATV), or move your TV to a different broadcast area.

		STILL
-	0
SETUP		SCREEN
		MODE
	ENTER
BACK		INFO
	CH RETURN
VOL.	MUTE	CH

NOTE:

• Make sure the TV or cable.

1Display the setup screen.

•Press [SETUP].

The following setup screen appears.

2 Select	con-
firm.
• Using [K/L], select “Autoscan”.

Channell

Autoscan

Channel List

Manual Register

Antenna

3For TV channels, using [K/L], select “Air”. For CATV channels, select “Cable”.

Autoscan
Autoscan will rescan all channels.		Back
This may take a while to complete.		Air
Select the destination of "ANT IN" jack.		Cable
Air		Cable
		1hour
Cable	Or
	ANT IN

•Press

Scanning and memorizing the channels automatically starts.

Now the system is scanning for channels, please wait.

72%

	Analog channels		10ch
	Digital channels		6ch
	SETUP	Exit

• When completed, the lowest memorized channel in the broadcasting will be displayed.

NOTES:

•If you do not operate this TV for more than 45 seconds during initial setup, the message boxes start to move to the lower left-handcorner of the screen. This is to save your screen fromburn-in.Press any key except[POWER] to cancel it.

•If you connect a cable system directly, contact the CATV installer.

•If you press [POWER] or[SETUP] during Autoscan, this setting will be canceled.

•If there is no reception connected or a poor signal is detected, a Hint will appear on screen once scanning stops.

• Press

14

EN

CHANNEL LIST

This function lets you remove undesired channels from the Channel Registration List.

	STILL
-	0
SETUP	SCREEN
	MODE
	ENTER
BACK	INFO
	CH RETURN
1 Display the
• Press [SETUP]
The following	appears.

2 Select	con-
firm.
• Using [K/L]	List”.
Channell
Autoscan
Channel List
Manual Register
Antenna

• Press

3Select the channel you want to remove.

• Using [K/L], select the channel.

Channell Listi

Highlight channels for			DTV	6
Ch Up/Down key selection.			DTV	8
				9
				27
			DTV	48
				58
			DTV	67
Ch Select		Watch/Skip	BACK
	ENTER		Back

• Press selected for removal. You will not be able to select the channel again using [CH K/L].

•To reactivate the removed channel, highlight it and press [ENTER].

•When you remove a major channel, you remove its minor channels, too.

NOTE:

•The channel with “DTV” indicated on the display is ATSC, otherwise the channel is NTSC.

4 To exit the setup, press[SETUP].

MANUAL REGISTER

This function lets you manually add channels not memorized due to poor broadcast strength during AUTOSCAN.

1	2		3
4	5		6
			AUDIO
7	8		9
			STILL
-	0
SETUP			SCREEN
			MODE	SETTINGS
		ENTER
BACK			INFO
1 Display the				CHANNEL
• Press [SETUP]
The following			appears.

2 Select	-
firm.
• Using [K/L]	Register”.

A

Channel List

Manual Register

Antenna

• Press

3Select the channel you want to add.

•Using [the Number buttons], select your desired channel.

11

Manuall Registeri

		For Analog channels,	Register
		select a channel to register
		using number keys.
		For Digital channels,
		you must perform Autoscan function.
		BACK	Back
		Ch Change

• Select

4To exit the setup, press [SETUP].

NOTES:

•If set up completes successfully, “Registered to the Channel List” is displayed.

•If Video 1 is being used, set up will not be completed successfully and “Unavailable” will be displayed on the screen.

15

EN

ANTENNA CONFIRMATION

Displays signal strength for each channel.

POWER	SLEEP	INPUT
		SELECT

1	2	3
4	5	6
7	8	9	AUDIO
			STILL
-	0
SETUP			SCREEN
			MODE
		ENTER
BACK			INFO
	CH RETURN
VOL.		MUTE	CH

1 Display the
• Press [SETUP]
The following	appears.

2 Select	con-
firm.

• Using [K/L], select “Antenna”.

Channell

Autoscan

Channel List

Manual Register

Antenna

•Press

•Using [the Number buttons]or [CHK/L], select the channel for which you want to check signal strength.

		11
Antenna
		Back
Now	70 Peak	80
CH	Ch Change

16

•If the channel is set to external input, you cannot confirm the antenna situation.

	Video1
Antenna
	Back
Indicator is available
for antenna signal only.
CH	Ch Change

3 To e

EN

LANGUAGE SELECTION

You can choose English, Spanish, or French as your on screen language.

		STILL
-	0
SETUP		SCREEN
		MODE
	ENTER
BACK		INFO
	CH RETURN
VOL.	MUTE	CH

1 Display the
• Press [SETUP]
The following	appears.

2 Select	to con-
firm.

•Using [K/L], select “English”, “Español” or “Français”.

English

• Press

3 To exit the setup, press[SETUP].

SETTING THE PANEL SAVER

Panel saver prevents the display from being etched by an unchanging image. You can specify a setting for it.

		STILL
-	0
SETUP		SCREEN
		MODE
	ENTER
BACK		INFO	SETTINGS
	CH RETURN
VOL.	MUTE	CH
			CHANNEL
1 Display the
• Press [SETUP]
The following		appears.

2 Select

confirm.

•Using [K/L], select “Panel Saver” and press[ENTER] to confirm.

Detailil

			Closed Caption
			V–chip
			HDMI Audio		Auto
					Off
			Panel Saver

3 Switch

•Using [K/L], select “Strong”, “Weak” or “Off” and press[ENTER] to confirm.

Panell Saver

						Strong
				This function is useful for
				burn-inreduction of the display		Weak
				panel by shifting the picture		Off
				element.
				Select the level for effect.

NOTE:

•"Weak" moves 1 pixel every 5 minutes and "Strong" moves 1 pixel every minute. This prevents burn-in.

4 To exit the setup, press[SETUP].

17

EN

WATCHING TV

CHANNEL SELECTION

Select channels by pressing [CH K/L] found on remote control or on the TV’s control panel, or by pressing[the Number buttons] found on the remote control.

POWER	SLEEP	INPUT
		SELECT

1 2 3

NTSC	18:00	ATSC
	CH4-1	No signal	No signal
	18:30
	CH4-1	CH4-2	CH4-3
CH4	19:00
	CH4-1	No signal	CH4-3
	19:30
	CH4-1	CH4-2	No signal

20:00

4 5 6

AUDIO

7 8 9

STILL

- 0

: change automatically

: change manually by pressing[CH /] on your remote control

SETUP	SCREEN
	MODE

			ENTER
		BACK		INFO
			CH RETURN
		VOL.	MUTE	CH
[CH K/L]
• Use [CH K/				channel.
• Same operation				with [CHANNEL
K/L] on the				main unit.
[the Number
• Press the				[the Number
buttons] to				want to watch,
then press
- When				12
1	2
- When selecting				channel 12-1
Be sure to press [–] before entering the minor
channel number.
1	2	-	1	ENTER

•If the channel broadcasts NTSC and ATSC both and you don't press [–],you will receive the NTSC channel only. The moment you press[–],the lowest memorized digital channel will be displayed.

•Press [CH RETURN] to return to the previously viewed channel.

NOTE:

•In DTV broadcasting, one channel sometimes broadcasts multiple programs depending on the air time. In this case, the main channel is called major channel and the minor channel is called minor channel.

About minor channel broadcasting:

There may be different programs being broadcast on minor channels through a single channel from ATSC. You can watch each minor channel program being broadcast by selecting one of the minor channels.

NOTE:

•“No Signal” will appear on the screen after the minor channel broadcast is over.

You will need to change the channel to continue watching another TV program.

VOLUME ADJUSTMENT

This section describes how to adjust the volume. The mute function, which turns the sound off and on, will also be described.

BACK		INFO
	CH RETURN
VOL.	MUTE	CH

[VOL. X/Y]
• Use [VOL. X					audio volume.
• The same					with [VOLUME
X/Y] on the					main unit.
• The volume					at the bottom
of the screen					the volume.
	Volume
• The							dis-
appear in a

[MUTE]

• Press [MUTE] to turn off and on the sound.

Mute

• “Mute”

few sec-

onds.

•Press [MUTE]again or [VOL.X/Y]([VOLUME

X/Y]) to release the Mute status.

18

EN

STILL MODE

You can freeze the image shown on the screen.

1	2	3
4	5	6
		AUDIO
7	8	9
		STILL
-	0
SETUP		SCREEN
		MODE

1 Pause the image
• When you	image shown on
the screen is
Still
• The audio is	keeps on reading
out.
• If the digital	protected, the
image will	the audio will be
muted.
• The Still	after 5
minutes.
2 Canceling Still
• The Still	by pressing
any button	working.

NOTE:

• Press any key except [POWER] to cancel still mode.

SELECTING AUDIO CHANNELS

This section describes how to switch the audio in the analog mode and how to switch the audio language in the digital mode.

		AUDIO
7	8	9
		STILL
-	0
SETUP		SCREEN
		MODE
TV
When you press		currently selected
audio mode will		the screen
		6

SAP / STEREO

Press [AUDIO] to cycle through available audio channels.

When the broadcasting has all audio...

SAP /STEREO SAP /MONO

SAP / STEREO

When the broadcasting has stereo audio and

monaural audio...

MONO /STEREOMONO / STEREO

When the broadcasting has SAP and monaural

audio...

	SAP / MONO				SAP / MONO	TV
						WATCHING
	When the broadcasting is having only monaural
	audio...
			MONO
		(cannot be switched.)
	STEREO : Outputs stereo-audio
	SAP	: Outputs second audio program
	MONO	: Outputs mono-audio

DTV

When you press [AUDIO], the currently selected language and the number of available languages will be displayed on the screen.

available audio

Spanish 2/3

•Available languages differ depending on the broadcast.

•The information display will automatically disappear in one minute.

NOTE:

• Pressing [AUDIO] does not control external audio source.

19

EN

ACCESSING EXTERNAL DEVICES

Use your remote control to access DVD recorders, home audio systems and other external devices when they are connected to your television.

POWER	SLEEP	INPUT
		SELECT

1	2	3
4	5	6
7	8	9	AUDIO
			STILL
-	0
SETUP			SCREEN
			MODE
		ENTER
BACK			INFO
	CH RETURN
VOL.		MUTE	CH
Use your remote			external com-
ponent.
• When you			or [CHL]
on the remote			mode will be
switched as

Video2

Component1

Component2

HDMI

•Pressing [CH K] on the remote control reverses direction.

•To use the VIDEO1 or S-VIDEO1input jack on the TV, select “Video1”.

•To use the VIDEO2 or S-VIDEO2input jack on the TV, select “Video2”.

•To use the COMPONENT1 input jacks on the TV, select “Component1”.

•To use the COMPONENT2 input jacks on the TV, select “Component2”.

•To use the HDMI IN jack on the TV,

20	select “HDMI”.

•When you press [INFO], the current external input mode, the type of resolutions for video signal, TV aspect ratio, CC and TV rating will be displayed at thetop-rightof the screen.

•The information display will automatically disappear in 1 minute.

1) When using VIDEO1 or S-VIDEO1input jack

Video1

480ii SD

TV-PGDLSVCC

Video2

480ii SD

TV-PGDLSVCC

Component1

1080ii HD

NONE

Component2

1080ii HD

NONE

HDMI

1080ii HD 16:9:9

NONE

EN

CHANGING THE SCREEN DISPLAY MODE

Each of 4 display modes can be selected in either 4:3 or 16:9 aspect ratios.

		AUDIO
7	8	9
		STILL
-	0
SETUP		SCREEN
		MODE
		ENTER
BACK		INFO

1Press [SCREEN MODE], to switch the TV aspect ratio.

2Press [SCREEN MODE] repeatedly until the normal screen displays.

NOTES:

•Some programs may not offer all display mode options.

•By changing the screen display mode from time to time, you can reduce burn-inon screen.

When the broadcast is sending 4:3 video	When the broadcast is sending 16:9 video
signal...	signal...

Sidebar

(normal)

Full	Full	Zoom
	(normal)

WATCHING TV

Wide

Cinema

[Sidebar]

Sidebar displays a 4:3 picture at its standard 4:3 size. Sidebars will be displayed on the right and left edges of the screen.

[Full]

Full displays a 4:3 picture at a 16:9 size, with horizontal elongation necessary to fill the screen.

[Cinema]

Cinema displays a 4:3 picture at a 16:9 size, with less horizontal elongation necessary to fill the screen because a little bit of the top and bottom edge of the screen will be cut off.

[Wide]

Wide displays the center of the picture as original size and the outer sides of the picture will be elongated. The size of the picture will depend on the original signal.

Expand

Cinema

[Full]

A picture is displayed at 16:9 size as it is.

[Zoom]

Zoom displays a 16:9 picture without changing its horizontal and vertical ratio, at its maximum size.

[Cinema]

Cinema displays a 16:9 picture with vertical elongation.

[Expand]

Expand displays a 16:9 picture with horizontal elongation.

21

EN

SCREEN INFORMATION

You can display the currently selected channel or other information such as the audio mode on the screen.

7	8	9	AUDIO
			STILL
-	0
SETUP			SCREEN
			MODE
		ENTER
BACK			INFO
	CH RETURN
VOL.		MUTE	CH

TV
In the analog			channel and the
audio mode are
1 Display the				the audio
mode.
• Press [INFO]			control.
The current				audio mode, type
of resolutions				TV aspect ratio,
CC and TV				at the top-right
of the screen
				6
				SAP / STEREO
				480ii SD 4:3:3
				TV-PGDLSVCC
• To					[INFO]
again

DTV

In the digital mode, the detailed information for the current channel such as the Program guide is displayed.

1Display the detailed information for the channel.

•Press [INFO] on the remote control.

The currently selected program details are displayed on the screen.

•The following information is displayed.

(1)Program title

(2)Broadcast station

(3)Program guide (max. 4 lines displayed)

(4)Channel number

(5)Audio language (“Other” is displayed when the audio language cannot be acquired, or the acquired languages are other than English, Spanish or French.)

(6)Effective scanning lines and scan mode

(7)Program definition

(8)Program aspect ratio

(9)Program rating

(10)CC (Not available if the CC set to “Off”)

(1)		(2)				(4)
Buffy Vampirei Slayerl		HDTV
						6-1				(5)
A quarter-centuryago,which may now qualify as the				English 1/2
good old days of newspapering,run-of-papersales
				1080ii HD 16:9:9
accounted for 80 percent of the industry's advertising
revenues.Department stores and supermarket were				TV-PGDLSVCC						(6), (7), (8)
(3)				(9)		(10)

than 4 lines,

the program

•The following screen is displayed when connecting to external devices:

e.g.) When using VIDEO1 input jack for connection

Video1

480ii SD

TV-PGDLSVCC

22

EN

SLEEP TIMER

The Sleep Timer can be set to automatically turn off your television after an incremental period of time.

POWER	SLEEP	INPUT
		SELECT

1	2	3
4	5	6
		AUDIO
7	8	9
		STILL
-	0
SETUP		SCREEN
		MODE
		ENTER
1 Press [SLEEP]		control to set the
Sleep Timer.
• The setting		Timer is shown on
the screen.
Sleep
2 You can set		after a set period
of time (from		After set up, you
can display the		before shut off by
pressing [SLEEP]
• To cancel the		[SLEEP]
repeatedly		displayed.

Sleep

•The Sleep Timer setting display will automatically disappear in a few seconds.

NOTE:

•When you disconnect your TV from its power source or when a power failure occurs, the sleep timer setting will be canceled.

OPTIONAL SETTINGS

SETUP SCREEN

This section describes the overview of the setup screen displayed when you press [SETUP].

For more details, see the reference page for each item.

The setup screen consists of the function setting items below.

•

To exit settings.

	•
	You can adjust the picture quality (Picture Mode,
	Brightness, Contrast, Color, Tint, Sharpness,
	Color Temp.).			SETTINGS
	(Refer to “PICTURE ADJUSTMENT” on page 24.)
	•
	You can automatically scan the viewable channels
	and remove those that are undesired.			OPTIONAL/
	and font styles. (Refer to “CLOSED CAPTION” on
	(Refer to “AUTOSCAN” on page 14.)
	•
	You can change closed captioning display formats
	page 25.)			TV
	Block children’s access to inappropriate program-
				WATCHING
	ming. (Refer to “V-CHIP”on page 28.)
	And select HDMI Audio if your TV is connected to
	a digital external device like a DVD recorder.
	(Refer to “HDMI AUDIO” on page 30.)
	•

You can change the language (English, Spanish, French) displayed on the setup screen.

(Refer to “LANGUAGE SELECTION” on page 17.)

NOTES:

•To cancel the setup screen, press [SETUP].

•If you do not operate this TV for more than 45 seconds during initial setup, the message boxes start to move to the lower left-handcorner of the screen. This is to save your screen fromburn-in.Press any key except[POWER] to cancel it.

23

EN

PICTURE ADJUSTMENT

You can select from four default picture color settings. You can also adjust brightness, contrast, color, tint, sharpness and color temperature settings.

SETUP	SCREEN
	MODE
	ENTER
BACK	INFO

1 Display the
• Press [SETUP]
The following	appears.

Contrast

Using [s/ B], adjust to increase or decrease contrast.

s: To decrease contrast B: To increase contrast

Contrast 60

Using [s/ B], adjust to be brilliant or pale color. s: To pale

B: To brilliant

Using [s/ B], adjust to obtain natural skin tones. s: To red

B: To green

Tint	R2

		Using [s/ B], adjust the detail of the picture.
2 Select		s: To soft
	con-	B: To clear
firm.		Sharpness 0
• Using [K/L]	item and
press [ENTER]

Picturei		Using [K/L], select “Reset”.
Picture Mode	Dynamic	You can reset setting of the Picture Mode you select.
Brightness	30
Contrast	60	Reset Settingsi
Color	36	This function resets the	Cancel
Tint	0	"Dynamic" setting for Picture Mode	Reset
	0
Sharpness		to factory default.
Reset Settings
Color Temp.	Neutral

3 Adjust

Color

• Using [K/L], select the picture quality you want

to adjust.

Using

selec-

Picture Mode

tion, then press [ENTER]. (Cool, Neutral and Warm)

Using [K/L], adjust Picture Mode from the

Picturei

Picture Mode

selection, then press [ENTER]. (Standard,

Brightness

Dynamic, Movie and News)

Contrast

Color

Tint

Picturei

Sharpness

Cool

Picture Mode

Standard

Reset Settings

Neutral

Brightness

Dynamic

Color Temp.

Warm

Contrast

Movie

Color

News

Tint

• The

is

Sharpness

Reset Settings

displayed on the screen.

Color Temp.

NOTE:

Using

of

• To move to the normal screen, press [SETUP].

the picture are as bright as you prefer.

4 To exit the setup, press[SETUP].

s: To decrease brightness

B: To increase brightness

Brightness 30

Adjust

Move

ENTER Enter

24

EN

CLOSED CAPTION

You can view closed captioning (cc) for TV programs, movies, news, and prerecorded tapes. Closed captions refer to text of dialogue or descriptions displayed on-screenfor the hearing impaired.

	STILL
-	0
SETUP	SCREEN
	MODE
	ENTER
BACK	INFO
	CH RETURN
1 Display the
• Press [SETUP]
The following	appears.

2 Select	confirm.
• Using [K/L]	Caption” and press
[ENTER] to
Detailil
Closed Caption
V–chip
HDMI Audio	Auto
Panel Saver	Off

3 Select	[ENTER] to
confirm.
Closedl Captioni
Conventional CC	Off
DTV CC	Off
CC Style

4 Select the Closed Caption mode.

Closedl Captioni
Conventional CC	Off
DTV CC	CC1
CC Style	CC2
	CC3
	CC4
	Text1
	Text2
	Text3
	Text4
• Using	caption,
then

	[Caption Mode]
	CC1 and Text1:
	are the primary caption and text services.
	The captioning or text is displayed in the same
	language as the program’s dialogue
	(up to 4 lines of script on the screen, where it
	does not obstruct relevant parts of the picture).
	CC3 and Text3:
	serve as the preferred data channels.
	The captioning or text is often a secondary lan-
	guage translation, simplified English or displayed
	at a slower rate.
	CC2, CC4, Text2 and Text4:
	are rarely available and broadcasters use them
	only in special conditions, such as when CC1
	and CC3 are not available or Text1 and Text3 are
	not available.	SETTINGS
	• There are three display modes according to
	programs:
	Paint-on mode: Displays input characters on the
	screen immediately.
	Pop-on mode : Once characters are stored in	OPTIONAL
	memory, they are displayed all
	at once.
	Roll-up mode : Displays the characters continu-
	ously by scrolling (max. 4 lines).

5To exit the setup, press [SETUP].

NOTES:

•Closed captions must be broadcast or included in your recorded content to appear on your TV.

•If the closed caption is not broadcasted, nothing is displayed.

•The closed caption is not displayed when you use HDMI connection.

•When your TV receives a special effects playback signal (i.e., Search, Slow and Still) from a VCR’s video output channel (CH3 or CH4), the TV may not display the correct caption or text.

•Captions and texts may not match the TV voice exactly.

•Interference may cause the closed caption system not to function properly.

•The caption or text characters will not be displayed while the menu display or functions display is shown.

•If a black box appears on the screen, this means that the TV is set to TEXT mode. To clear screen, select CAPTION “CC1”, “CC2” , “CC3”, “CC4”or “Off”.

25

EN

DTV CLOSED CAPTION			CLOSED CAPTION STYLE
DTV			DTV

Apart from closed captions, DTV has its own closed captions called DTV CC. Use this menu to change the settings for DTV CC.

1Display the setup screen.

•Press [SETUP].

The following setup screen appears.

2 Select

confirm.

1Display the setup screen.

•Press [SETUP].

The following setup screen appears.

2 Select

.

•Using [K/L], select “Closed Caption” and press[ENTER] to confirm.

• Using [K/L], select “Closed Caption” and press			Detailil
			Closed Caption
[ENTER] to confirm.			HDMI Audio		Auto
			V–chip
			Panel Saver		Off

Detailil

Closed Caption
V–chip
HDMI Audio	Auto
Panel Saver	Off

3 Select

.

Closedl Captioni

Conventional CC

Off

3 Select

confirm.

DTV CC

Off

CC Style

Closedl

Captioni

Conventional CC

Off

DTV CC

Off

CC Style

4 Switch

CC Stylele

User Setting

Off

4 Switch

Font Style

Font0

Font Size

Middle

Font Color

White

Font Opacity

Solid

Closedl

Captioni

Back Color

Black

Conventional CC

Back Opacity

Solid

DTV CC

Off

Edge Color

Black

CC Style

Service1

Edge Type

None

Service2

Service3

• Using

Service4

Service5

Style.

Service6

• Using

Closed

5 Use “User Setting”.

• The “User Setting” function lets you change CC

Caption, then press [ENTER].

Off:

style.

Select if you do not want DTV CC. This is the

• Using [K/L], select “User Setting”.

default.

• Press [ENTER] and set “User Setting” to “On”.

Service 1 to Service 6:

CC Stylele

Select one of these before changing any other

User Setting

On

item in the Closed Caption menu. Choose

Font Style

Off

Font Size

Service 1 under normal circumstances.

Font Color

Font Opacity

Back Color

5 To exit the setup, press[SETUP].

Back Opacity

Edge Color

Edge Type

26

EN

6Set each item.

•When “User Setting” is set to “On”, you can set the following items.

•CC style set by “User Setting” will be displayed.

•Using [K/L], select the item you want to set.

•You can switch the setting for each item with

[K/L].

Picture display

[Font Opacity]

Font opacity of the displayed caption can be switched as below.

			CC Stylele		Closed Caption
			User Setting
			Font Style
			Font Size
			Font Color
			Font Opacity	Solid
			Back Color	Flash
			Back Opacity	Translucent
			Edge Color	Transparent
			Edge Type

[Back

Background

caption can

ABCDEFGHIJKL

be switched as below.

Edge

CC Stylele

Closed Caption

User Setting

(Edge Color and Edge Type)

Font Style

White

Font

Font Size

Black

(Font Style, Font Size, Font Color and Font Opacity)

Font Color

Red

Font Opacity

Green

Blue

Back

Back Color

Back Opacity

Yellow

(Back Color and Back Opacity)

Edge Color

Magenta

• The setting description for each item is shown

Edge Type

Cyan

[Back

below.

[Font Style]		Background	caption can
		be switched as below.
Closed Captioning font style can be changed as
below.		CC Stylele	Closed Caption
CC Stylele		User Setting
	Closed Caption	Font Style
User Setting		Font Size
Font Style		Font Color
Font Size		Font Opacity
Font Color		Back Color	Solid
Font Opacity		Back Opacity	Flash
Back Color		Edge Color	Translucent
Back Opacity		Edge Type	Transparent
Edge Color
Edge Type		[Edge

[Font	Edge				be
Font size of the displayed caption can be	switched as below.
switched as below.
		CC Stylele	Closed Caption

CC Stylele		User Setting
	Closed Caption	Font Style	White
User Setting		Font Size	Black
Font Style		Font Color	Red
Font Size	Large	Font Opacity	Green
Font Color	Middle	Back Color	Blue
Font Opacity	Small	Back Opacity	Yellow
Back Color		Edge Color	Magenta
Back Opacity		Edge Type	Cyan

Edge Color

Edge Type

[Edge

[Font

Edge

be

Font color of the displayed caption can be

switched as below.

switched as below.

CC Stylele

Closed Caption

User Setting

CC Stylele

Closed Caption

Font Style

User Setting

Font Size

Font Style

White

Font Color

None

	Font Size	Black	Font Opacity	Raised
			Back Color
	Font Color	Red		Depressed
			Back Opacity
	Font Opacity	Green		Uniform
	Back Color	Blue	Edge Color	L.Shadow
			Edge Type	R.Shadow
	Back Opacity	Yellow

Edge Color	Magenta
Edge Type	Cyan

7 To e

OPTIONAL SETTINGS

27

EN

V-CHIP

You can block certain programming inappropriate for children. This block can be released by entering a

3Enter the password.

•Use [the Number buttons]and enter the 4-digit number.

password.		V-Chipip
POWER		INPUT
		SLEEP SELECT
		Enter password.
1	2	3
		PIN Code	BACK
4	5		Back
		6

		AUDIO
7	8	9
		STILL
-	0
SETUP		SCREEN
		MODE

•When you have not set up your password, enter 0000.

•When the password is correct, the following “V-Chip”screen is displayed.

			V-Chipip
	ENTER		MPAA Rating
BACK		INFO	TV Rating
			New Password

1 Display the

A MPAA Rating

B TV Rating

C New Password

	• Press [SETUP]		See the following description for setting each
	The following	appears.
			item.

		A MPAA Rating
		4 Display the “MPAA Rating” screen.
		• Using [K/L], select “MPAA Rating”.
2	Select	V-Chipip
		MPAA Rating
	• Using [K/L]	TV Rating
		New Password

Closed Caption
V–chip
HDMI Audio	Auto
Panel Saver	Off	• Press
		V-Chipip
			X
			NC-17
• Press			R
			PG-13
The			PG
			G
			NR
V-Chipip				BACK
		Select	ENTER View/Block	Back

Enter password.

				PIN Code	BACK
					Back

28

EN

5Set “MPAA Rating”.

•Using [K/L], select the rating.

•Press [ENTER] and set to “View” or “Block”.

V-Chipip

	X
	NC-17
	R
	PG-13
	PG
	G
	NR
Select		View/Block	BACK
	ENTER		Back

6 To e

<Selection>	<Rating Category Explanations>
X :	Mature audience only
NC-17 :	No one under 17 admitted
R :	Restricted; under 17 requires
	accompanying parent or adult
	guardian
PG-13 :	Unsuitable for children under 13
PG :	Parental Guidance suggested
G :	General Audience
NR :	No Rating

NOTES:

•When you select a rating and set it to “Block”, the higher ratings will be blocked automatically. The lower ratings will be available for viewing.

•When you set “X” to “View”, all ratings turn to “View” automatically.

B TV Rating

4 Display the “TV Rating” screen.

• Using [K/L], select “TV Rating”.

V-Chipip

MPAA Rating

TV Rating

New Password

• Press

V-Chipip

	FV V	S	L	D
TV-MA
TV-14
TV-PG
TV-G
TV-Y7
TV-Y
Select	ENTER View/Block		BACK	Back

5Set “TV Rating”.

•Using [K/L], select the rating.

•Press [ENTER] and set to “View” or “Block” for the rating without sub categories.

V-Chipip

	FV V	S	L	D
TV-MA
TV-14
TV-PG
TV-G
TV-Y7
TV-Y
Select	ENTER View/Block		BACK	Back

• For

press . Then press [ENTER] and set to “View” or “Block”.

V-Chipip

	FV V	S	L	D
TV-MA
TV-14
TV-PG
TV-G
TV-Y7
TV-Y
Select	ENTER View/Block		BACK	Back

6 To e

<Selection>	<Rating Category Explanations>
TV-MA :	Mature audience only
TV-14 :	Unsuitable for children under 14
TV-PG :	Parental Guidance suggested
TV-G :	General Audience
TV-Y7 :	Appropriate for children 7 and
	older
TV-Y :	Appropriate for all children

<Selection>	<Rating Sub Category Explanations>
FV :	Fantasy Violence
V :	Violence
S :	Sexual Situation
L :	Coarse Language
D :	Suggestive Dialogue

NOTES:

•When you select a rating and set it to “Block”, the higher ratings will be blocked automatically. The lower ratings will be available for viewing.

•When you set “TV-MA”to “View”, all ratings turn to “View” automatically.

OPTIONAL SETTINGS

29

EN

C New Password

4 Display the “New Password” screen.

• Using [K/L], select “New Password”.

V-Chipip

MPAA Rating

TV Rating

New Password

• Press

5Change the password.

•Use [the Number buttons] on the remote control and enter the NEW4-digitpassword.

•Enter password again in “Confirm password” space.

V-Chipip

Enter password.

Confirm password.

				PIN Code	BACK
					Back

6To e

NOTES:

•Make sure to enter the exact same new password as the “Confirm password.”. If they are different, the space is cleared for reentering.

•Your password will be erased and return to the default (0000) when a power failure occurs or when you turn off the power using a wall switch. If you forget the password, unplug the power cord for 10 seconds to restore the password to 0000.

HDMI AUDIO

Set the method of sound input for HDMI jack.

	STILL
-	0
SETUP	SCREEN
	MODE
	ENTER
BACK	INFO

1 Display the
• Press [SETUP]
The following	displayed.

2 Select	confirm.
• Using [K/L]	and press
[ENTER] to
Detailil
Closed Caption
V–chip
HDMI Audio	Auto
Panel Saver	Off

3 Switch

•Using [K/L], select the desired HDMI Audio, then press[ENTER].

Detailil

		Closed Caption
		V–chip
		HDMI Audio	Auto
		Panel Saver	Digital
			Analog

•	digital
	device with HDMI jack and analog device for
	audio sources. Digital audio input signal has
	priority in this setting.

• Select “Digital” if you connected to digital device with HDMI jack for digital audio input signal.

• Select “Analog” if you connected to analog device with analog jacks for analog audio input signal.

4 To exit the setup, press[SETUP].

30

EN

ATTACHING A WALL MOUNT BRACKET (SOLD SEPARATELY)

The following is a description of the method for attaching a wall mount to the TV.

When performing this operation, refer to the instruction manual included with the wall mount kit.

# CAUTION

•Any damage caused by incorrectly attempting to mount the TV is not covered under the terms of the manufacturer’s warranty.

•This TV is for use only with the Sanus Systems Model VMPL. Wall Mount. Use with other wall mounts may result in instability causing possible injury.

2

Rear of this TV

1

1

Stands

1Turn the TV over and place it screen-firstonto a table which has a soft cloth draped over it. Place the TV in a way so that the stands hang over the edge of the table.

NOTES:

•Make sure to use a table which can support the weight of the TV and is larger than the TV.

•Make sure the table is in a stable location.

2Remove the stands from the TV.

Unscrew the M5 screws indicated by 1 , and remove the left and right stands.

NOTE:

•The screws and stands you have removed are necessary for reattachment at a later date. Make sure to keep them in a safe place.

3Attach the left and right TV rails to the TV using the M8 screws included with the wall mount kit. 2 indicates the position of the screw holes on

the TV.

NOTES:

•Only use the screw holes indicated by 2 for mounting the TV.

•For instructions on how to attach the TV rails, refer to the instruction manual included with the mount wall kit.

4 Attach the TV to the wall.

NOTE:

•Refer to the instruction manual included with the mount wall when securing the TV to the wall.

*If you want to attach the stands of this TV again, insert the stand slowly as illustrated below and drive screws in the 4 threaded holes ( 1 ).

1

OPTIONAL SETTINGS / ATTACHING A WALL MOUNT BRACKET (SOLD SEPARATELY)

31

EN

MISCELLANEOUS

TROUBLESHOOTING GUIDE

Before calling for service, please refer to the following information.

Symptom		Remedy
No power		• Be sure the power cord is connected to outlet.
		• If a power failure occurs, unplug the power cord for 30 minutes
		to allow the unit to reset itself.
No picture or sound		• Check if the power is on.
		• Check the outlet connection.
		• Check the antenna or cable connection to the main unit.
		• When the outside antenna is used, check the wire condition and
		connection.
		• View other TV channels. The problem might be limited to the
		broadcasting station.
		• Turn off the power and wait for about 1 minute, then turn it on
		again.
No color		• Check the antenna or cable connection to the main unit.
		• When the outside antenna is used, check the wire condition and
		connection.
		• View other TV channels. The problem might be limited to the
		broadcasting station.
		• Adjust the Color in the setup screen.
Sound OK, picture poor		• Check the antenna or cable connection to the main unit.
		• When the outside antenna is used, check the wire condition and
		connection.
		• Electrical interference from nearby appliances may affect picture
		quality.
		• Adjust Contrast and Brightness in the setup screen.
		• View other TV channels. The problem might be limited to the
		broadcasting station.
Picture distorted		• When the outside antenna is used, check the wire condition and
		connection.
		• View other TV channels. The problem might be limited to the
		broadcasting station.
Weak picture		• Check the antenna or cable connection to the main unit.
		• When the outside antenna is used, check the wire condition and
		connection.
		• Adjust Contrast and Brightness in the setup screen.
		• View other TV channels. The problem might be limited to the
		broadcasting station.
Lines or streaks in picture		• When the outside antenna is used, check the wire condition and
		connection.
		• Electrical interference from nearby appliances may affect picture
		quality.
		• View other TV channels. The problem might be limited to the
		broadcasting station.
Picture blurred		• When the outside antenna is used, check the wire condition and
		connection.
		• View other TV channels. The problem might be limited to the
		broadcasting station.

32

EN

Symptom		Remedy
Ghosts in picture		• Check the antenna or cable connection to the main unit.
		• When the outside antenna is used, check the wire condition and
		connection.
		• Electrical interference from nearby appliances may affect picture
		quality.
		• View other TV channels. The problem might be limited to the
		broadcasting station.
Bars on screen		• When the outside antenna is used, check the wire condition and
		connection.
		• Electrical interference from nearby appliances may affect picture
		quality.
Picture rolls vertically		• When the outside antenna is used, check the wire condition and
		connection.
		• Electrical interference from nearby appliances may affect picture
		quality.
		• View other TV channels. The problem might be limited to the
		broadcasting station.
Different color marks on screen		• Move your TV away from nearby electric appliances. Turn off the
		power and wait 30 minutes before turning it back on.
		• View other TV channels. The problem might be limited to the
		broadcasting station.
Poor reception on some channels		• Check the antenna or cable connection to the main unit.
		• When the outside antenna is used, check the wire condition and
		connection.
		• Electrical interference from nearby appliances may affect picture
		quality.
		• View other TV channels. The problem might be limited to the
		broadcasting station.
Picture OK, sound poor		• Electrical interference from nearby appliances may affect picture
		quality.
		• View other TV channels. The problem might be limited to the
		broadcasting station.

MISCELLANEOUS

Burn-inon screen	• Do not continuously display images such as video games, com-
	puter graphics, stock market quotations or other fixed patterns.
	Those images may cause screen burn-in.
	If burn-inoccurs, display a movie or TV show to reduce the
	problem.
	These images can cause permanent damage to your screen.
	Burn-incaused by misuse is not covered by your warranty.
No reception of digital signals	• Make sure Autoscan has been completed (Refer to “AUTOSCAN” on
	page 14). Autoscan must be completed when you set up your TV for
	the first time or move it to a location where previously unavailable
	channels are broadcast.
	• The selected channel may not be broadcasting.
	• When Autoscan is interrupted, some channels will not be
	received. Make sure to complete Autoscan in the setup screen.
Channel changes automatically	• Many digital channels have alternate channel numbers. TV changes the
	numbers automatically to the ones signifying the broadcasting stations.
	These are the numbers used for analog broadcasts.
Remote Control doesn’t work	• Check the antenna or cable connection to the main unit.
	• Check the batteries of the remote control.
	• Check if there is an obstacle between the sensor and the
	remote control.
	• Test the signal output. If OK, there might be remote sensor trou-
	ble. (Refer to “IR SIGNAL CHECK” on page 36.)

33

EN

Problems with Closed Caption Feature

Misspelled captions are displayed.	• Closed captioning production companies may broadcast pro-
	grams without correcting the misspelling in a live broadcast.
Captions are not entirely displayed, or	• Captions that are delayed a few seconds behind the actual dialogue
captions are delayed behind the dia-	are common for live broadcasts. Most captioning production compa-
logue.	nies can display a dialogue to a maximum of 220 words per minute. If
	a dialogue exceeds that rate, selective editing is used to ensure that
	the captions remain up-to-datewith the current TV screen dialogue.
Captions are displayed as a white	• Interference from buildings or weather conditions may cause
box.	captioning to be incomplete.
No caption is displayed in the Closed	• Broadcasting station may shorten the program to insert adver-
Caption-supportedprogram.	tisement. The closed caption decoder cannot read the informa-
	tion of the shortened program.
No caption is displayed when playing	• The videotape may be illegally copied, or the caption signal
the videotape containing captions.	might not have been read during copying.
Black box is displayed in the screen.	• “Text” mode is selected for caption. Select “CC1”, “CC2”, “CC3”,
	“CC4” or “Off”.

34

EN

•IGNITION NOISE:

Black spots or horizontal streaks may appear, picture may flutter or drift. Usually caused by interference from automobile ignition systems, neon lamps, electrical drills and other electrical appliances.

•GHOSTS:

Ghosts are caused by the television signal following two paths. One is the direct path and the other is reflected from tall buildings, hills or some other objects. Changing the direction or position of the antenna may improve reception. Ghosting may also be caused by defects in the antenna system such as unshielded leads or connecting several sets to the same antenna without using multiple antenna couplers.

Ghosting occurring when the TV is connected to a cable TV system may indicate a bad cable wire or loose connection. Confirm that the cable wire is properly connected.

•SNOW:

If your receiver is located in the fringe area of a television station where the signal is weak, your picture may be marred by the appearance of small dots. When the signal is extremely weak, it may be necessary to install a special antenna to improve the picture.

Snowing occurring when the TV is connected to a cable TV system may indicate a bad cable wire or loose connection. Confirm that the cable wire is properly connected.

•RADIO FREQUENCY INTERFERENCE:

The interference produces moving ripples or diagonal streaks, and in some cases, causes loss of contrast in the picture.

•PREVENTION OF AN OBSTACLE TO RADIO RECEIVERS:

This TV has been designed pursuant to the FCC class B Rules. This is to prevent a problem to Radio receivers. lf this TV causes a problem to Radio receivers, then take the following steps:

-Keep the monitor away from Radio.

-Adjust Radio antennas in order for the TV not to receive interference.

-The antenna cable of Radio should be kept away from the TV.

-Use a coaxial cable for antenna.

You can check if this TV influences Radio receivers by turning off all other equipment other than the TV.

If you find a problem receiving Radio when using the TV, check the instructions mentioned above.

Vertical stripes appear,	•The plasma display panel is lighting the phosphors by the discharge of
depending on the screen	internal radiation. Depending on the screen contents, in rare cases this
contents.	may cause vertical stripes to appear because of failure to light. Please
	note that this is not a malfunction.

MISCELLANEOUS

35

EN

GLOSSARY

ATSC

Acronym that stands for Advanced Television Systems Committee and the name of the digital broadcasting standards.

Aspect ratio

The width of a TV screen relative to its height. Conventional TVs are 4:3 (in other words, the screen is almost square); widescreen models are 16:9 (the screen is almost twice as wide as its height).

Component video

This is a video signal format that conveys each of three principal colors of light (red, blue and green) through different signal lines. This allows the viewers to experience picture colors as original as it is. There are several signal formats, including Y / Pb / Pr and Y / Cb / Cr.

Dolby Digital

The system developed by Dolby Laboratories to compress digital sound. It offers stereo sound (2ch) or multi-channelaudio.

HDMI (High-Definition

Multimedia Interface)

Interface that supports all uncompressed, digital audio/video formats including set-topbox, DVD player or digital television, over a single cable.

High Definition TV (HDTV)

Ultimate digital format that produces high resolution and high picture quality.

LPCM

(Linear Pulse Code Modulation)

LPCM is a format that can have up to 8 channels of audio. It is mainly used in music production. The format samples and captures analog signals and transforms them into digital signals without compressing the sound data.

NTSC

Acronym that stands for National Television Systems Committee and the name of the current analog broadcasting standards.

Password

A stored 4-digitnumber that allows access to parental control features.

SAP

(Secondary Audio Program)

Second-audiochannel delivered separately frommain-audiochannel. This audio channel is used as an alternate in bilingual broadcasting.

Standard Definition TV (SDTV)

Standard digital format that is similar to the NTSC picture quality.

S-Video

Offers higher quality images by delivering each signal, color (c) and luminance (y) independently of each other through separate cables.

MAINTENANCE

CABINET CLEANING

•Always unplug the TV from the AC outlet before cleaning.

•Clean the case of the TV with a soft cloth which has been wet and wrung dry.

•If the screen is dirty or dusty, wipe it clean with a soft cloth.

NOTES:

•Never use a solvent, alcohol or any other abrasive liquid to clean the TV.

•Always make sure the area around vents on the TV is clear and clean. Failure to do this may result in fire or cause the TV to fail prematurely.

SERVICING

Should your unit become inoperative, do not try to correct the problem yourself. There are no user serviceable parts inside. Turn off the TV, unplug the power cord and call our toll free customer support line found on the cover of this manual to locate an authorized service center.

IR SIGNAL CHECK

If the remote control isn’t working properly, you can use an AM radio or digital camera (including a cellular phone with built-incamera) to see if it is sending out an infrared signal.

• With an AM radio:

Tune the AM radio station to a non-broadcastingfrequency. Point the remote control towards it, push any button and listen. If the sound from the radio flutters, it is receiving the remote control’s infrared signal.

•With a digital camera (including builtin cell phone cameras):

Point a digital camera towards the remote control. Push any button on the remote control and look through the digital camera. If the infrared light appears through the camera, the remote control is working.

36

EN

SPECIFICATIONS

GENERAL SPECIFICATIONS

Television System: ATSC NTSC-M

TV Standard

Closed Caption

System: §15.119/FCC (Analog CC) §15.122/FCC (Digital CC)

Channel Coverage (ATSC/NTSC)

VHF:	2 ~ 13
UHF:	14 ~ 69
CATV:	2 ~ 13, A ~ W,
	W+1 ~ W+94,
	A-5~A-1,5A
Tuning System:	Channel frequency
	synthesized tuning system
Channel Access:	Direct access keyboard,
	Programmable scan,
	and Up/down
Terminals
Antenna Input:	VHF/UHF/CATV
	75 ohm unbalanced
	(F-type)
S-VideoInput:	Mini DIN 4-pinjack x 2
Video Input:	RCA jack x 2
Audio Input:	RCA jack (L/R) x 4

Component Video/Audio Input:

2 pin jacks (Y) / 1Vpp

4 pin jacks (Pb/Pr) / 700mVpp

4 RCA jacks (L/R)

HDMI / Audio Input:

HDMI jack

2 RCA jacks (L/R)

Coaxial Digital Audio Output:

1 pin jack, 500mVpp

Analog Audio Output:

2 RCA jacks (L/R)

Stereo Sound System Speaker

ELECTRICAL SPECIFICATION

Sound Output: 5W, 8 ohm x 4

OTHER SPECIFICATIONS

Remote Control:	Digital encoded
	infrared light system
Operating
Temperature:	5°C to 40°C
	(41°F to 104°F)
Power Requirements: AC120V, 60Hz
Power Consumption
(Maximum):	400W
Plasma panel:	42" XGA panel
Dimensions:
	H : 30-11/16"	(780mm)
	W: 41-1/2"	(1054mm)
	D : 13"	(330mm)
Weight:	92.4 lbs. (42.0kg)

MISCELLANEOUS / SPECIFICATIONS

•Designs and specifications are subject to change without notice and without our legal obligation.

•If there is a discrepancy between languages, the default language will be English.

37

EN

LIMITED WARRANTY

FUNAI CORP. will repair this product, free of charge in CANADA in the event of defect in materials or workmanship as follows:

DURATION :

PARTS : FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the date of original retail purchase. Certain parts and LCD imageburn-inare not covered under this warranty.

LABOR : FUNAI CORP. will provide the labor without charge for a period of ninety (90) days from the date of original retail purchase.

LIMITS AND EXCLUSIONS :

THIS WARRANTY IS EXTENDED ONLY TO THE ORIGINAL RETAIL PURCHASER. A PURCHASE RECEIPT OR OTHER PROOF OF ORIGINAL RETAIL PURCHASE WILL BE REQUIRED TOGETHER WITH THE PRODUCT TO OBTAIN SERVICE UNDER THIS WARRANTY.

This warranty shall not be extended to any other person or transferee.

This warranty is void and of no effect if any serial numbers on the product are altered, replaced, defaced, missing or if service was attempted by an unauthorized service center. This limited warranty does not apply to any product not purchased and used in CANADA.

This warranty only covers failures due to defects in material or workmanship which occurs during normal use. It does not cover damage which occurs in shipment, or failures which are caused by repairs, alterations or product not supplied by FUNAI CORP., or damage which results from accident, misuse, abuse, mishandling, misapplication, alteration, faulty installation, improper maintenance, commercial use such as hotel, rental or office use of this product or damage which results from fire, flood, lightning or other acts of God.

THIS WARRANTY DOES NOT COVER PACKING MATERIALS, ANY ACCESSORIES (EXCEPT REMOTE CONTROL), ANY COSMETIC PARTS, COMPLETE ASSEMBLY PARTS, DEMO OR FLOOR MODELS.

FUNAI CORP. AND ITS REPRESENTATIVES OR AGENTS SHALL IN NO EVENT BE LIABLE FOR ANY GENERAL, INDIRECT OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR OCCASIONED BY THE USE OF OR THE INABILITY TO USE THIS PRODUCT. THIS WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND OF ALL OTHER LIABILITIES ON THE PART OF FUNAI, ALL OTHER WARRANTIES INCLUDING THE WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED BY FUNAI AND ITS REPRESENTATIVES IN CANADA.

ALL WARRANTY INSPECTIONS AND REPAIRS MUST BE PERFORMED BY AN AUTHORIZED SERVICE CENTER.

THIS WARRANTY IS ONLY VALID WHEN THE UNIT IS CARRIED-INTO AN AUTHORIZED SERVICE CENTER.

THE PRODUCT MUST BE ACCOMPANIED BY A COPY OF THE ORIGINAL RETAIL PURCHASE RECEIPT. IF NO PROOF OF PURCHASE IS ATTACHED, THE WARRANTY WILL NOT BE HONORED AND REPAIRS COSTS WILL BE CHARGED.

ATTENTION :

FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY DESIGN OF THIS PRODUCT WITHOUT PRIOR NOTICE.

WARRANTY STATEMENT REGARDING NON AUTHORIZED REPAIRS:

To obtain warranty service, you must take the product, or deliver the product freight prepaid, in either its original packaging or packaging affording an equal degree of protection, to any AUTHORIZED SERVICE CENTER. FUNAI CORP. will not reimburse you for any service done by unauthorized service providers without prior written approval.

To locate your nearest AUTHORIZED SERVICE CENTER or for general service inquiries, please contact to us at:

FUNAI CORPORATION

Customer Service

Tel: [phone]

http://www.funai-corp.com

19900 Van Ness Avenue, Torrance, CA 90501

Printed in Malaysia	L0703CD / L0701CB
	1EMN22014A

QUICK SET UP

GUIDE D’INSTALLATION RAPIDE

Some cables here are not included with the plasma display TV.

Certains des câbles présentés ici ne sont pas fournis avec le téléviseur écran plasma.

5 Plasma Display TV rear side

Arrière du téléviseur écran plasma

S-VIDEO(OR VIDEO) CONNECTION

CONNEXION S-VIDÉO(OU VIDÉO)

			R						5S-VIDEO(OR VIDEO) CONNECTION
			AUDIO
			L
			VIDEO2
			S-VIDEO2
2AUDIO OUTPUT CONNECTION										CONNEXION S-VIDÉO(OU VIDÉO)
CONEXION DE SORTIE AUDIO
	ANT. IN		HDMI		COMPONENT2		COMPONENT1			Power cord is included.
		AUDIO OUT	AUDIO		Y		Y	VIDEO1
		L	L	L	Pb	L	Pb	L		Le cordon d’alimentation
	DIGITAL		HDMI IN	AUDIO		AUDIO		AUDIO		est fourni.
	AUDIO OUT	R	R	R	Pr	R	Pr	R	S-VIDEO1
	(COAXIAL)
1ANTENNA	3HDMI CONNECTION				4COMPONENT CONNECTION

ANTENNE

CONNEXION HDMI

CONNEXION À COMPOSANTES

1ANTENNAANTENNE

VHF / UHF antenna

Antenne VHF / UHF

OR

Plasma Display TV rear side

OU

Cable TV company

Compagnie du câble TV

OR

OU

Satellite dish

			Arrière du téléviseur écran plasma
		OR	ANT. IN		HDMI
		OU
	IN			AUDIO OUT	AUDIO
	OUT	Cable box or		L	L
			DIGITAL		HDMI IN
		Satellite box
			AUDIO OUT	R	R
	Décodeur de câblodistribution		(COAXIAL)
		ou décodeur satellite

Antenne parabolique

	AUDIO OUTPUT CONNECTION
	2CONEXION DE SORTIE AUDIO
	Analog Audio Output Connection	Plasma Display TV rear side
	CONNEXION DE SORTIE AUDIO/VIDÉO ANALOGIQUE
		Arrière du téléviseur écran plasma
		ANT. IN		HDMI
	AUDIO IN		AUDIO OUT	AUDIO
	VIDEO AUX TV
	L		L	L
	R	DIGITAL		HDMI IN
		AUDIO OUT	R	R

(COAXIAL)

Stereo system

Chaîne stéréo

Digital Audio Output Connection		Plasma Display TV rear side
CONEXION DE SORTIE AUDIO NUMÉRIQUE		Arrière du téléviseur écran plasma
		ANT. IN		HDMI
	AUDIO IN		AUDIO OUT	AUDIO
VIDEO	AUX TV
DIGITAL	L		L	L
AUDIO IN
(COAXIAL)		DIGITAL		HDMI IN
	R
		AUDIO OUT	R	R
		(COAXIAL)

Dolby Digital decoder

Décodeur Dolby Digital

	HDMI CONNECTION
	3CONNEXION HDMI
	DVR or DVD Player With HDMI Out Jack	Plasma Display TV rear side
	DVR ou Lecteur DVD avec prise de sortie HDMI
		Arrière du téléviseur écran plasma
		ANT. IN		HDMI
			AUDIO OUT	AUDIO
		HDMI OUT	L	L
		DIGITAL		HDMI IN
		AUDIO OUT	R	R
		(COAXIAL)

4COMPONENT CONNECTION

CONNEXION À COMPOSANTES

DVD Player With Component Video Out Jack

Lecteur DVD avec prises de sortie vidéo à composantes

Plasma Display TV rear side

Arrière du téléviseur écran plasma

					COMPONENT2		COMPONENT1
					Y		Y
	AUD IO		C O MPONE N T
	OUT		VIDEO OUT	L		L
R	L	Y	Cb/Pb Cr/Pr		Pb		Pb
				AUDIO		AUDIO
				R	Pr	R	Pr

5S-VIDEO(OR VIDEO) CONNECTION

CONNEXION S-VIDÉO(OU VIDÉO)

Camcorder

CAMÉSCOPE

Plasma Display TV (side view)

Côte du téléviseur écran plasma

R

AUDIO

L

VIDEO2

R L VIDEO S–VIDEO

	OR	S-VIDEO2
	OU

DVD Player	VCR		Plasma Display TV rear side
			Arrière du téléviseur écran plasma
LECTEUR DVD	MAGNÉTOSCOPE
			VIDEO1
	VIDEO	AUDIO	L
			AUDIO
	OUT	OUT
	VIDEO S–VIDEO	R	L
			R	S-VIDEO1

OR

OU

FOR MORE INFORMATION

POUR PLUS D’INFORMATIONS

1. Owner’s Manual Mode d’emploi

2.http://www.funai-corp.com

3.1-800-474-0045

	1EMN22015A
Printed in Malaysia	L0703CD / L0701CB
