OWNER’S
MANUAL
If you need additional assistance for set-up or operating
after reading owner’s manual, please call
TOLL FREE : 1-800-287-4871
Please read before using this equipment.
DVD PLAYER
PORTABLE CART WARNING
(Symbol provided by RETAC)
S3125A
CDVL100D
WARNING
:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
:
IMPORTANT SAFEGUARDS
1) Read Instructions - All the safety and operating instructions
should be read before the product is operated.
2) Retain Instructions - The safety and operating instructions
should be retained for future reference.
3) Heed Warnings - All warnings on the product and in the operating instructions should be adhered to.
4) Follow Instructions - All operating and use instructions should
be followed.
5) Cleaning - Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
6) Attachments - Do not use attachments not recommended by
the product manufacturer as they may cause hazards.
7) Water and Moisture - Do not use this product near water - for
example, near a bath tub, wash bowl, kitchen sink, or laundry
tub; in a wet basement; or near a swimming pool; and the like.
8) Accessories - Do not place this product on an unstable cart,
stand, tripod, bracket, or table. The product may fall, causing
serious injury to a child or adult, and serious damage to the
product. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the product.
Any mounting of the product should follow the manufacturer’s
instructions, and should use a mounting accessory recommended by the manufacturer.
9) A product and cart combination should be
moved with care. Quick stops, excessive
force, and uneven surfaces may cause the
product and cart combination to overturn.
10)Ventilation - Slots and openings in the cabinet are provided for ventilation and to
ensure reliable operation of the product and
to protect it from overheating, and these
openings must not be blocked or covered.
The openings should never be blocked by placing the product
on a bed, sofa, rug, or other similar surface. This product
should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to.
11)
Power Sources - This product should be operated only from the type
of power source indicated on the marking label. If you are not sure
of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from
battery power, or other sources, refer to the operating instructions.
12)
Grounding or Polarization - This product may be equipped with
a polarized alternating-current line plug (a plug having one blade
wider than the other). This plug will fit into the power outlet only
one way. This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the plug should
still fail to fit, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the polarized plug.
13)
Power-Cord Protection - Power-supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.
14)Lightning - For added protection for this product during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect
the antenna or cable system. This will prevent damage to the
product due to lightning and power-line surges.
15)Power lines - An outside antenna system should not be located in the vicinity of overhead power lines or other electric light
or power circuits, or where it can fall into such power lines or
circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching such power lines
or circuits as contact with them might be fatal.
16)Overloading - Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a risk of
fire or electric shock.
17)Object and Liquid Entry - Never push objects of any kind into
this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.
18)
Servicing - Do not attempt to service this product yourself as
opening or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service personnel.
19)Damage Requiring Service - Unplug this product from the wall
outlet and refer servicing to qualified service personnel under
the following conditions:
a) When the power-supply cord or plug is damaged,
b)
If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper adjust-
ment of other controls may result in damage and will often
require extensive work by a qualified technician to restore
the product to its normal operation,
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance
- this indicates a need for service.
20)Replacement Parts - When replacement parts are required, be
sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as
the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.
21)
Safety Check - Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
22)Heat - The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
PRECAUTIONS
LASER SAFETY
This player employs a laser. Only a qualified service person should remove the cover or attempt to service this
device, due to possible eye injury.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO
NOT STARE INTO BEAM.
LOCATION: INSIDE, ON THE DECK MECHANISM.
FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly
approved in the instruction manual.The user could lose the authority to operate this equipment if an
unauthorized change or modification is made.
RADIO-TV INTERFERENCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment and receiver.
3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4) Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
A NOTE ABOUT RECYCLING
This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in
accordance with your local recycling regulations.
Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.
About Copyright
Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.
This product incorporates copyright protection technology that is protected by method claims of certain U.S.
patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of
this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home
and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
–2–
EN
TABLE OF CONTENTS
■
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
LASER SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
About Copyright. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
■
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Supplied Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Symbols Used in this Manual. . . . . . . . . . . . . . . . . . . . . 4
■
ABOUT THE DISCS . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Playable Discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Disc Types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
■
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
■
FUNCTIONAL OVERVIEW . . . . . . . . . . . . . . . . . . . . . . 6
FRONT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
REAR VIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . 6
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Displays During Operation . . . . . . . . . . . . . . . . . . . . . . . 7
Loading the Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . 7
■
HOOK UPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting to a TV using a VIDEO OUT Jack
or a S-VIDEO OUT Jack . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting to an Amplifier Equipped with Digital Input
Jacks such as MD deck or DAT deck . . . . . . . . . . . . . . . 8
Connecting to a Dolby Digital decoder . . . . . . . . . . . . . . 8
Connecting to a TV or a Stereo TV that has Component
VIDEO In Jacks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
■
PLAYING A DISC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Basic Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
General Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Disc Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Title Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
CALLING UP A MENU SCREEN DURING
PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Step by Step Playback. . . . . . . . . . . . . . . . . . . . . . . . . . 9
Resume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Fast Forward / Reverse Search . . . . . . . . . . . . . . . . . . 10
Slow Forward / Slow Reverse . . . . . . . . . . . . . . . . . . . 10
Zoom. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Track . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Title / Chapter Search . . . . . . . . . . . . . . . . . . . . . . . . . 10
Time Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Repeat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
REPEAT TITLE / CHAPTER. . . . . . . . . . . . . . . . . . . 10
REPEAT TRACK . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
REPEAT A-B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Program (CD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Random Playback (CD) . . . . . . . . . . . . . . . . . . . . . . . . 11
MP3 Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
On-Screen Information. . . . . . . . . . . . . . . . . . . . . . . . . 11
Track Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Random Playback (MP3) . . . . . . . . . . . . . . . . . . . . . . . 12
Programm (MP3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Audio Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Stereo Sound Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Subtitle Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Camera Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Changing the On-Screen Display . . . . . . . . . . . . . . . . . 12
Parental Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
PARENTAL LEVEL . . . . . . . . . . . . . . . . . . . . . . . . . . 13
IF YOU FORGET THE PASSWORD . . . . . . . . . . . . . 13
CONTROL LEVELS . . . . . . . . . . . . . . . . . . . . . . . . . 13
Marker Setup Screen. . . . . . . . . . . . . . . . . . . . . . . . . . 13
■
DVD SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Audio Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Black Level Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Virtual Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Display Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Language Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
■
TROUBLESHOOTING GUIDE. . . . . . . . . . . . . . . . . . . 15
■
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
■
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
–3–
EN
INTRODUCTION
1
Supplied Accessories Symbols Used in this Manual
• Remote control
• Two AA batteries
• Owner’s Manual
• VIDEO/AUDIO cables
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of
Dolby Laboratories.
The following symbols appear below in some headings and
notes in this manual, with the following meanings!
DVD-V
: Description refers to playback of DVD video discs.
CD
: Description refers to playback of audio CDs.
MP3
: Description refers to playback of MP3 discs.
QUICK
: Description refers to the items to be set in the QUICK
mode.
ABOUT THE DISCS
Playable Discs
The following discs can be played back on this DVD player.
¡
DVD video
¡
DVD+R/RW*
¡
CD-R/RW*
*Depending on the types or the writing method of the medium some discs can not be played.
• Some DVD-R/RW, DVD+R/RW, or CD-R/RW discs made on personal computers, or on DVD recorders may not be played
back properly due to the factors such as scratches, dirt or special properties of the disc.
• Discs made on personal computers may not be played back properly due to the different environment or the settings of the
application you use. We recommend always to use the standardized, rightly formatted discs. (Please contact the sales
agency for more detail).
This player conforms to the NTSC color system.You cannot play discs recorded in other color systems such as PAL or SECAM.
• Some discs include region codes as shown below.
¡
DVD-R/RW*
¡
Audio CD
¡
MP3*
• The number inside the symbol refers to a region of the world, and a disc encoded in a specific region format can only be
played back on DVD player with the same region code.
For Customer Use:
Read carefully the information located at the bottom of your DVD player and enter below the Serial No.Retain this information for future reference.
Model No. DVD player
Serial No. __________________________
The following discs cannot be played back on this DVD player.
¡
DVD with region codes other than 1 or ALL.
¡
DVD-ROM
¡
DVD-RAM (Never play back, otherwise malfunction may result.)
¡
CD-ROM
¡
VSD
¡
CDV (Only plays back the audio part.)
¡
CD-G (Only plays back the sound.)
¡
CD-I (Never play back, otherwise malfunction may result.)
¡
SACD
¡
Photo CD (Never play back, otherwise malfunction may result.)
¡
Video CD (Never play back, otherwise malfunction may result.)
Any other discs without compatibility indications.
–4–
EN
ABOUT THE DISCS
Example
Track 1 Track 2 Track 3 Track 4 Track 5 Track 6
Example
Title 1 Title 2
Chapter 1 Chapter 2 Chapter 1 Chapter 2Chapter 3 Chapter 4
Example
Group 1 Group 2
Track 1 Track 2 Track 1 Track 2Track 3 Track 4
Disc Types
[DVD]
Data on a DVD is divided into sections called "titles", and then
into subsections called "chapters", each of which is given a title
or chapter number. Playback conditions are preset on some
DVD video discs, and these playback conditions take priority
over user operations on this player. If a function you selected do
not run as desired, refer to the manual accompanying the disc.
[Audio CD]
Data on an audio CD is divided into sections called “tracks”,
each of which is given a track number.
[MP3]
Data on a MP3 is divided into sections called "groups", and
then into subsections called "tracks", each of which is given
a group or track number.
FEATURES
¡Dolby Digital sound
This player can handle Dolby Digital surround sound having 5.1 channels when connected to a Dolby Digital
decoder.
¡Still/fast/slow/step playback
¡Random playback for audio CD and MP3
¡Program playback for audio CD and MP3
¡DVD menus in a desired language
¡Screen saver/Auto power-off functions
The screen saver program starts when there is no input from
the player for five minutes in the stop mode. When the
screen saver program is activated for 30 minutes, the power
is automatically turned off.
¡Subtitles in a desired language
¡Selecting a camera angle
¡Choices for audio language and sound mode
¡Parental lock
¡Automatic detection of discs
This player automatically detects if a loaded disc is DVD,
audio CD or MP3 on disc.
¡Playing an MP3 disc
¡Direct Search
¡On-screen display
Information about the current operation can be displayed
on a TV screen, allowing you to confirm the currently
active functions (such as program playback), on the TV
screen using the remote control.
¡Search
Chapter search / Title search / Track search / Time search
¡Repeat
Chapter / Title / Track / Group / All / A-B
¡Zoom
¡Marker
The part designated by user can be called back.
¡Resume Play
¡Virtual Surround
¡Component Video Out Jacks
Jacks located on the back of the DVD Player which are
used to send high-quality video to a TV via Component
Video In Jacks.
¡Dimmer
¡Bit rate indication
¡DRC (Dynamic range control)
You can control the range of sound volume.
¡Black Level Setting
–5–
EN
AUDIO OUT
DIGITAL AUDIO OUT
PCM / BITSTREAM
YCr
COMPONENT
VIDEO OUT
CbLRCOAXIAL
VIDEO
OUT
S-VIDEO OUT
10
111213 15
14
RETURN
ZOOM
MODE
MENU
SKIPPAUSEA-B
REPEAT
ANGLE
AUDIO
SUB
TITLE
CLEAR
TITLE
STOP
PLAY
FWDREV
SETUP
ENTER
OPEN/
CLOSE
SEARCH
MODE
DISPLAY
123
456
789
0 +10
POWER
1
2
3
4
5
6
7
8
9
10
11
14
12
13
15
18
19
17
16
21
20
22
23
24
25
FUNCTIONAL OVERVIEW
FRONT PANEL
2 435
REAR VIEW
1. POWER
to switch the player to ON or OFF
2. Disc tray
3. OPEN/CLOSE
to open/close the disc tray
4. PLAY
to start or resume disc playback
5. STOP
to stop playback
6. SKIP G / SEARCH
gg
goes to next chapter or track during playback; press and
hold for 1.5 seconds for a forward search
7. SKIP H / SEARCH
hh
goes to previous chapter or track during playback; press
and hold for 1.5 seconds for a reverse search
8. PAUSE
to pause the current disc operation
9. Display
REMOTE CONTROL
1. DISPLAY
to access or remove the display screen during DVD or
Audio CD playback
2. POWER
switch DVD player ON or OFF
3. AUDIO
to choose audio languages or sound modes
4. SUBTITLE
subtitle language DVD selector
5. ANGLE
6. REPEAT
7. REPEAT A-B
8. CLEAR
select DVD camera angle
repeat chapter, track, title, all.
repeat a specific segment
to reset the setting
[Fig. 3]
19 87 6
10. MAIN (AC Power Cord)
connect to a standard AC outlet
11. COAXIAL (Digital audio out)
connect to AUDIO inputs of a digital (coaxial) audio
equipment
12. AUDIO OUT (Left/Right)
connect to AUDIO inputs of an amplifier, receiver or
stereo system
13. VIDEO OUT
connect to the Video Input of a TV.
14. COMPONENT VIDEO OUT
connect to a TV with Component video in jacks.
15. S-VIDEO OUT
connect to a TV with S-Video inputs
Caution: Do not touch the inner pins of the jacks on the
rear panel. Electrostatic discharge may cause permanent
damage to the player.
9. PAUSE
pause playback temporarily / frame-by-frame playback
10. REV
hh
to view DVD picture in fast reverse motion
11. PLAY
to start a DVD disc playback
12. SETUP
to access or remove the DVD setup menu
13. MODE
to set up programmed or random playback (Audio CD)
to set the black level and virtual surround during DVD
playback
14. ZOOM
enlarge DVD video image
15. TITLE
to display title menu of a disc
16. ENTER
acknowledge menu selection
17. RETURN
to return previous or remove setup menu
18. Arrow (sB
KK LL
)
(left/right/up/down) select an item in the menu
19. MENU
to display the menu of the DVD disc
20. STOP
to stop a DVD disc playback
21. FWD
gg
to view DVD picture in fast forward motion
22. SKIP H,G
to skip chapter/tracks
23. 0-9 numerical buttons
select numbered items in a menu
+10
use this button to enter number 10 and above
24. OPEN/CLOSE
to open/close the disc tray
25. SEARCH MODE
to locate a desired point
–
6 –
[Fig. 1]
[Fig. 2]
EN
FUNCTIONAL OVERVIEW
AUDIO OUT
DIGITAL AUDIO OUT
PCM / BITSTREAM
YCr
COMPONENT
VIDEO OUT
CbLRCOAXIAL VIDEO
OUT
S-VIDEO OUT
A/V-compatible
or
wide screen TV
Stereo system
or
To Right (red) and
Left (white) AUDIO
OUT jacks
To VIDEO INPUT jack
To Right (red) and Left (white)
ANALOG AUDIO INPUT jacks
To VIDEO OUT jack
To S-VIDEO
INPUT jack
To S-VIDEO
OUT jack
Display
Stays on when repeat
Stays on when
the repeat function is on.
Stays on when
the A-B repeat
function is on.
title function is on.
Stays on when repeat chapter function is on.
Stays on when repeat track function is on.
Lights up when a DVD
is inserted on the tray.
Lights up when a CD is
inserted on the tray.
Stays on when the inserted
disc is being played back.
Displays During Operation
Lights up when the
inserted disc comes
to a pause.
Displays how long a current title or track has been
played back. When a chapter or track has switched,
the number of a new title, chapter or track is displayed.
Loading the Batteries
[Fig. 4]
1. Open the battery compartment cover.
Power on
No disc inserted or
playing DVD Menu
2. Insert two AA batteries, with each one
oriented correctly.
Tray open
Tray closed
3. Close the cover.
Loading the Disc
NOTES
Power off
• Do not mix alkaline and manganese batteries.
• Do not mix old and new batteries.
HOOK UPS
CAUTION:
• Be sure to turn off the Player and equipment to be connected before connecting.
• Read through the operation manual for the equipment to be connected.
• Be sure that the colors of the jacks and plugs match up when using VIDEO/AUDIO cables.
• Be sure to keep the Player connection cables separate from the TV antenna cable when you install the Player, because it
may cause electrical interference when you are watching television programs.
Connecting to a TV using a VIDEO OUT Jack or a S-VIDEO OUT Jack
Use an S-Video cable (commercially available) in place of the yellow video cable to enjoy pictures at higher quality.
A/V-compatible or
wide screen TV
To Right (red) and
AUDIO OUT jacks
To Right (red) and Left (white)
AUDIO INPUT jacks
To VIDEO INPUT jack
Left (white)
To VIDEO OUT jack
or
To S-VIDEO OUT jackTo S-VIDEO INPUT jack
AUDIO OUT
DIGITAL AUDIO OUT
PCM / BITSTREAM
–7–
YCr
COMPONENT
L
VIDEO OUT
S-VIDEO OUT
Cb
RCOAXIAL VIDEO
OUT
[Fig. 5]
[Fig. 6]
EN
HOOK UPS
AUDIO OUT
DIGITAL AUDIO OUT
PCM / BITSTREAM
YCr
COMPONENT
VIDEO OUT
CbLRCOAXIAL VIDEO
OUT
S-VIDEO OUT
To COAXIAL DIGITAL
AUDIO OUT jack
To VIDEO INPUT jackTo VIDEO OUT jack
To S-VIDEO
INPUT jack
To S-VIDEO
OUT jack
To COAXIAL DIGITAL
AUDIO INPUT jack
A/V-compatible
or
wide screen TV
Amplifier equipped with digital
input jacks, MD deck,
DAT deck, etc.
or
AUDIO OUT
DIGITAL AUDIO OUT
PCM / BITSTREAM
YCr
COMPONENT
VIDEO OUT
CbLRCOAXIAL VIDEO
OUT
S-VIDEO OUT
To COAXIAL
DIGITAL AUDIO
OUT jack
To VIDEO INPUT jackTo VIDEO OUT jack
To S-VIDEO
INPUT jack
To S-VIDEO
OUT jack
To COAXIAL DIGITAL
AUDIO INPUT jack
A/V-compatible
or
wide screen TV
Front
speaker
(left)
Center speaker
Front
speaker
(right)
Surround
speaker
(left)
Surround
speaker
(right)
Subwoofer
Dolby Digital
decoder
or
NOTES:
• Connect the DVD player directly to a TV. If the A/V cables are connected to a VCR, pictures may be distorted due to the
copy protection system.
• Be sure to turn off the power to all components in the system before connecting another component.
• Refer to the Owner's Manuals for your TV, stereo system and any other components to be connected to the DVD player.
Connecting to an Amplifier Equipped with Digital Input Jacks such as MD deck or DAT deck
Use an audio coaxial digital cables (not included) for the audio connections. Connecting to an amplifier equipped with digital
input jacks such as MD Deck or Dat Deck.
NOTES:
[Fig. 7]
• The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital sound by an MD
or DAT deck.
• Set Dolby Digital to off for audio output in the setup mode. Playing a DVD using incorrect settings may generate noise distortion, and may also damage the speakers.(See page 13 to set ON for Dolby Digital)
Connecting to a Dolby Digital decoder
If using this DVD player to playback a DVD in a 5.1 channel Dolby Digital surround, the DVD player outputs a Dolby Digital
data stream from its COAXIAL DIGITAL AUDIO OUT jack. By hooking the player up to a Dolby Digital decoder, you can enjoy
a more convincing, realistic ambience with powerful and high-quality surround sound of a professional standard such as can
be heard in movie theaters.
Use an audio coaxial digital cables (not included) for the audio connections.
[Fig. 8]
NOTES:
•
If output Dolby Digital audio, connect to a Dolby Digital decoder, and set Dolby Digital to on for audio output in the setup mode.
• Unless connected to a Dolby Digital decoder, set Dolby Digital to off for audio output in the setup mode. Playing a DVD
using incorrect settings may generate noise distortion, and may also damage the speakers.
Connecting to a TV or a Stereo TV that has Component VIDEO In Jacks
AUDIO OUT
YCr
COMPONENT
VIDEO OUT
S-VIDEO OUT
CbLRCOAXIAL VIDEO
OUT
–8–
To COMPONENT
VIDEO OUT jack
To COMPONENT
VIDEO INPUT jack
A/V-compatible
wide screen TV
To Right (red) and
Left (white)
Stereo system
HOW TO CONNECT TO A TV WITHOUT AUDIO/VIDEO INPUT JACKS
If your TV does not have RCA type audio and video input jacks it is still possible to connect this DVD player to your TV’s 75-ohm coaxial antenna terminal using a commercially available Stereo Audio/Video RF Modulator. Connect the audio and video outputs of the DVD
AUDIO OUT jacks
To Right (red) and Left (white)
ANALOG AUDIO INPUT jacks
player to the audio and video inputs on the RF Modulator, and then connect the coaxial output of the RF Modulator (usually marked
“TO TV”) to the 75 ohm coaxial antenna terminal on your TV. Follow the instruction supplied with the RF Modulator for more details.
If your TV’s 75 ohm coaxial antenna terminal is already occupied by an antenna or cable box connection, remove that cable from your
TV’s antenna terminal and reconnect it to the coaxial antenna input terminal of the RF Modulator (usually marked “ANT IN”), then connect the RF modulator to your TV’s antenna terminal as described above.
NOTE
•
The picture quality from DVD discs will not be as good if the DVD player is connected to the TV’s antenna terminal through an RF Modulator.
DIGITAL AUDIO OUT
PCM / BITSTREAM
or
[Fig. 9]
EN
PLAYING A DISC
Basic Playback Disc Menus
CDDVD-V
Getting started
• Turn on the power of the TV, amplifier and any other components which are connected to the DVD.
• Make sure the TV and audio receiver (commercially available) are set to the correct channel.
1
Press POWER.
•“P-ON” will appear briefly on the display panel.
2
Press OPEN/CLOSE to open disc
loading tray.
3
Place the chosen disc in the tray,
with the label facing up.
4
Press
PLAY.
• The tray will close automatically, and
playback will then start from the first chapter or track of
the disc. If the playback does not start automatically,
press PLAY.
• When you playback the DVD which a title menu is
recorded, it may appear on the screen. In this case,
refer to “TITLE MENU”.
5
Press STOP to stop playback.
NOTES:
• A “prohibited icon” may appear at the topright on the TV screen during operation,
warning that a prohibited operation has
been encountered by the DVD player or
the disc.
• With DVDs that use some titles for playback program
signals, playback may start from the second title, or it
may skip these titles.
• During the playback of two layered disc, pictures may
stop for a moment. This happens when the 1st layer
switches to the 2nd layer. This is not a malfunction.
General Features
DVD may contain menus to navigate the disc and access
special features. Press the appropriate numerical key or use
Arrow ( L / K / B / s ) to highlight your selection in the DVD
main menu and press ENTER to confirm.
NOTE:
• Unless stated, all operations described are based on
remote control use. Some operations can be carried
out using the menu bar on the TV screen.
Pause
DVD-V
1
Press MENU.
• The DVD main menu will appear.
2
If the feature is not available, symbol may
appear on the TV screen.
3
If disc menu is available on the disc, audio language, subtitle options, chapters for the title and
other options will appear for selection.
4
Press
Arrow ( L / K / B / s ) to select an item, and
ENTER to confirm selection.
Title Menu
DVD-V
1
Press TITLE.
• The title menu will appear.
2
If the feature is not available, symbol may
appear on the TV screen.
3
Press
Arrow ( L / K / B / s ) to select an item, and
ENTER to confirm selection.
• Playback will begin at the selected Title.
CALLING UP A MENU SCREEN DURING PLAYBACK
DVD-V
• Press MENU to call up the DVD main menu.
• Press
NOTE:
TITLE to call up the title menu.
• Contents of menus and corresponding menu operations may vary between discs. Refer to the manual
accompanying the disc for details.
Step by Step Playback
DVD-V
1
During playback, press PAUSE.
• Playback will pause and sound will be muted.
2
The disc goes forward by one frame each time
PAUSE is pressed.
3
To exit step by step playback, press
PLAY.
1
During playback, press PAUSE.
• Playback will pause and sound will be muted.
2
To continue playback, press PLAY.
CDDVD-V
Resume
CDDVD-V
1
During playback, press STOP.
• Resume message will appear on the TV screen.
2
Press PLAY, playback will resume from the point
at which playback was stopped.
• To cancel resume, press STOP twice.
–9–
EN
PLAYING A DISC
/2
Fast Forward / Reverse Search
MP3CDDVD-V
1
During playback, press
ly to select the required forward or reverse speed: x2, x8,
x50, x100.
• If you are using SKIP G / SEARCH
panel, press and hold it for more than 1.5 sec (the
longer you hold it, the faster the speed will be)
you reach the desired speed, release the button.
• For audio CDs, the speed is fixed at
• For MP3, the speed is fixed at
2
To return to normal playback, press PLAY.
FWDggor
x8.
REVhhrepeated-
gg
on the front
. When
x16.
2
Within 30 seconds, select a desired track number using
numerical buttons. For single digits press “0” first.
• Playback will start at the selected track.
Using the SKIP
During playback, press
Press it repeatedly to skip subsequent tracks. Press
to go back to the beginning of the current track. Press it repeatedly to go to the previous tracks
•
Track number will appear briefly on the DVD display panel.
• If SKIP is pressed while the playback is paused, the
playback will be paused again after skipping to the next
track.
HH GG
SKIP
GG
to move to the next track.
.
SKIP
HH
NOTE:
•
SKIP HGare not available when playback is stopped.
Slow Forward / Slow Reverse
DVD-V
1
During playback, press PAUSE.
2
Press
FWDggor REVhh.
•
Slow motion playback will begin and sound will be muted.
3
Press FWDggor REV
hh
repeatedly to select
the required speed: 1/16, 1/8, 1/2 of the normal
playback.
• If you are using SKIP H / SEARCH
panel, press and hold it for more than 1.5 sec (the
longer you hold it, the slower the speed will be)
hh
on the front
. When
you reach the desired speed, release the button.
4
To return to normal playback, press PLAY.
Zoom
DVD-V
The Zoom function allows you to enlarge the video image
and to pan through the enlarged image.
1
Press ZOOM during playback.
• Playback will continue.
2
Press ZOOM repeatedly to select the required
zoom factor: x2, x4 or OFF.
3
Use
Arrow ( L / K / B / s ) to move the zoomed
picture across the screen.
4
To exit zoom mode, press
NOTES:
• Zooming function does not work while disc menu is
shown.
• x4 zoom is not available on some discs.
ZOOM to OFF.
Track
CD
There are three ways to begin playback on an Audio CD at a
specific Track.
Using the Numerical buttons
1
Press numerical buttons to enter the desired
Track number.
• Playback will start at the selected track.
• For single digit tracks (1-9), press a single number (eg.
track 3, press 3).
To play track 26, press +10, 2, 6 on the numerical button.
•
Using the SEARCH MODE
1
Press SEARCH MODE.
• The track search display appears.
Title / Chapter Search
DVD-V
1
Press SEARCH MODE once for the Chapter search,
twice for the Title search during playback.
2
Enter the desired chapter/title number using
numerical buttons.
Time Search
CDDVD-V
1
During playback, press SEARCH MODE three times
(CD: twice) to display the Time Search on the TV
screen.
2
Within 30 seconds, enter a desired disc time using
numerical buttons.
• Playback will start at the specified time.
3
Press CLEAR to erase the incorrect input.
Repeat
• REPEAT are available only during playback.
REPEAT TITLE / CHAPTER
DVD-V
To activate the repeat function, press REPEAT during playback.
• The repeat mode changes as described below every time
you press the button.
CHAPTER TITLE OFF
(current chapter repeat) (current title repeat)
NOTES:
• Repeat Title/Chapter is not available with some scenes.
• The REPEAT setting will be cleared when moving to
other title or chapter.
(repeat off)
–10–
EN
3
PLAYING A DISC
PLAY
CD [AUDIO] Total 00:45:55
RANDOM PROGRAM
no indication
RANDOM
PLAY
ENTER
DISC NAME
FIRST PLAY
FILE LIST
folder name
FOLDER
MP3
folder name
folder name
folder name
folder name
folder name
FIRST PLAY
1/2
REPEAT TRACK
CD
To activate the repeat function, press REPEAT during playback.
• The repeat mode changes as described below every time
you press the button.
TRACK ALL OFF
(current track repeat) (entire disc repeat)
(repeat off)
Random Playback
CD
This shuffles the playing order of tracks instead of playback
in the sequence.
1
In stop mode, press
MODE twice.
•
RANDOM screen appears
2
Press PLAY to start ran-
.
dom playback.
NOTES:
•
The REPEAT setting will be cleared when moving to other track
•
Repeat playback does not function during repeat A-B playback.
REPEAT A-B
CDDVD-V
1
Press REPEAT A-B at your chosen starting point.
• A- appears briefly on the TV screen.
2
Press REPEAT A-B again at your chosen end point.
• A-B appears briefly on the TV screen, and the repeat
sequence begins.
3
To exit the sequence, press REPEAT A-B.
NOTES:
• The repeat A-B section can only be set within the current
title (for DVDs), or current track (for audio CDs).
• Repeat A-B is not available with some scenes in DVD.
•
To cancel the A point which was set, press CLEAR.
• Repeat A-B playback does not function during title, chapter, track or all repeat playback.
Program
CD
You may determine the order in which tracks will play.
1
In stop mode press MODE.
• The PROGRAM screen
will appear.
2
Press ▲ or ▼ to select a
track, then press
• Press CLEAR to erase
the The most recently
entered program.
3
Press PLAY to play the
programmed tracks.
NOTES:
•
While the program is being played back, the STOP works as follows.
•
Press STOP once and then PLAY again, playback will restart
from the point where STOP was pressed. (Program continued)
•
Press STOP twice and then PLAY again, playback will restart
from the track in the usual way. (Program cleared)
• Up to 99 programs can be entered.
• If you like to repeat the current track in the program, press
REPEAT repeatedly until TRACK appears during playback. If you like to repeat the entire program press
REPEAT repeatedly until ALL appears during playback.
ENTER.
NOTES:
• If you like to repeat the cur-
.
rent track in the random
selection, press REPEAT repeatedly until TRACK
appears during playback. If you like to repeat the entire random selection press REPEAT repeatedly until ALL
appears during playback.
MP3 Playback
When a CD with MP3 files is inserted in the DVD player, the
MP3 menu will appear on the TV screen, and number of
tracks is displayed on the front panel.
1
In stop mode, press K or L to select the desired
group or track.
• If a group is selected, press
the track selection
screen. Press K or L to
choose a track, then
press PLAY or ENTER.
• If a track is selected,
press PLAY or ENTER to
start playing tracks.
Starting from the one
you’ve just chosen the
subsequent tracks will be
played.
• Choose FIRST PLAY to start playback from the beginning of the listed tracks.
TITLE to return to the first item.
• Press
2
Press STOP to stop playback.
B
or ENTER to go on to
NOTES:
• Folders are known as Groups; files are known as Tracks.
• MP3 files are accompanied by icon.
• Maximum of 255 folders can be recognized.
• Maximum of 256 files can be recognized.
• Up to 8 hierarchies can be created.
This player recommends the use of files recorded at the below specifications
:
• Sampling frequency: 44.1kHz or 48kHz
• Constant bit rate: 112kbps ~ 320kbps.
On-Screen Information
You can check the MP3 files during playback.
1
Press DISPLAY.
• The name of the file currently in play will be displayed.
2
Press DISPLAY again to show the track number,
MP3
MP3
the elapsed time, the repeat status, and the playback status at the top of the screen.
• will be displayed when the repeat play has been
selected.
–11–
T - indicates Track repeat
G - indicates Group (folder) repeat
A - indicates Disc repeat
3
Press DISPLAY again to exit.
EN
PLAYING A DISC
9/49 0:00:00 -0:00:00
Track Selection
MP3
1
Press SEARCH MODE during playback.
• The FILE LIST will appear.
2
Select a desired track using Arrow (L/K/B/s).
• Press Bwhen you want to go to the next hierarchy.
s
• Press
hierarchy.
3
Press PLAY to start playing
when you want to go back to the previous
NOTES:
•
Press SEARCH MODE to EXIT.
• Some selections may take a while to be recognized.
Random Playback
MP3
1
Press MODE twice while playback is stopped.
2
Press
PLAY to play the tracks in random order.
Program
MP3
This feature allows you to program a mp3 disc to play in a
desired sequence.
1
Press MODE when playback is stopped.
• The PROGRAM screen will appear.
2
Press K or L to select a track, then press ENTER,
to save it in a program.
• Press CLEAR to erase the incorrect input.
3
Press PLAY to start programmed playback.
Audio Language
DVD-V
The DVD player allows you to select a language during DVD
disc (if multi language available) playback.
1
Press AUDIO during playback.
2
Press
AUDIO repeatedly to select your desired
language.
Stereo Sound Mode
CD
1
Press AUDIO repeatedly during playback to select
between STEREO, L-CH or R-CH.
STEREO - both right and left channels are active (stereo)
L-CH - only left channel is active
R-CH - only right channel is active
NOTE:
• If the Virtual Surround setting is ON, the sound mode will
be fixed to STEREO, and can not be changed.
Subtitle Language
DVD-V
The DVD player allows you to select a language for subtitle
during DVD disc (if available) playback.
1
Press SUBTITLE during playback.
2
Press
SUBTITLE repeatedly to select your desired
subtitle language.
• The selected language will be displayed on the display
bar at the top of the screen.
3
To turn off subtitles, press SUBTITLE repeatedly
until OFF appears.
NOTES:
•
Pressing AUDIO may not work on some DVDs with multiple
audio languages (e.g. DVDs which allow audio language setting on the disc menu).
• Some discs allow audio language setting/subtitle language
setting on the disc menu. (Operation varies between discs,
so refer to the manual accompanying the disc.)
•
If the desired language is not shown after pressing SUBTITLE
several times, the disc does not have subtitles in that language.
• If you choose a Language that has a 3 letter language
code, the code will be displayed every time you change the
Subtitle language setting. If you choose any other languages, ‘---’ will be displayed instead. (Refer to page 14.)
Camera Angle
DVD-V
Some DVD discs contain scenes which have been shot simultaneously from various angles. You can change the camera angle
when the ( ) icon appears on the screen.
1
Press ANGLE during playback.
• The selected angle will be displayed on the display bar
at the top of the screen.
2
Press ANGLE repeatedly to select your desired angle
Changing the On-Screen Display
DVD-V
You can check information about the current disc by pressing
DISPLAY on the remote control.
1
Press DISPLAY during play-
back to show current
Chapter.
• The elapsed and remaining playing time of the current
chapter will be displayed.
2
Press DISPLAY again to show current Title.
• The elapsed and remaining playing time of the current
title will be displayed.
3
Press DISPLAY the third time.
• The BIT RATE, layer number (if available) and the current repeat setting will be displayed.
4
Press DISPLAY the fourth time to remove the display.
CD
1
Press DISPLAY during playback, the current Track
will be displayed on the TV screen.
• The elapsed and remaining playing time of the current
track will be displayed.
2
Press DISPLAY again to show current Total Track.
• The elapsed and remaining playing time of the current
total track will be displayed.
3
Press DISPLAY the third time to remove the display.
.
–12–
EN
PLAYING A DISC
ON
OFF
PARENTAL
PARENTAL LEVEL ALL
AUDIO
DRC OFF
DOLBY DIGITAL ON
DOWN SAMPLING ON
Parental Control
DVD-V
Parental Control limits the disc viewing that exceed your set-
tings. (with a password or playback will stop.)
This feature allows you to prevent discs with alternative
scenes from being played by your children.
PARENTAL LEVEL
Parental Level allows you to set the rating level of your DVD discs.
Playback will stop if the disc’s ratings exceed the level you set.
1
Press SETUP in STOP mode.
2
Press B to select
3
Press s or B to select
PARENTAL, then press ENTER.
4
Enter your four-digit password
then press
5
Press K or L to select
PARENTAL LEVEL, then press ENTER.
•
To change the password, press K or L to select CHANGE, then
press ENTER. Enter the four-digit pass-word, then press ENTER.
6
Press K or L to select the desired level, then
press ENTER.
7
Press SETUP to exit.
NOTES:
• When doing this for the first time, enter any 4 digits. (except
for 4737) That number will be used as the password from
the second time onward.
• With some DVDs, it may be difficult to find if they are compatible with parental lock. Be sure to check if the parental
lock function operates in the way that you have set.
• Record the password in case you forget it.
IF YOU FORGET THE PASSWORD
1
Press 4, 7, 3, 7 at step 3.
•
Password will be cleared and parental level will be set to ALL.
2
Proceed the above steps 3-5 again.
CUSTOM, then press ENTER.
ENTER.
CONTROL LEVELS
• ALL
All parental lock is cancelled.
• Level 8
DVD software of any grade (adult/general/children) can
be played back.
• Levels 7 to 2
Only DVD software intended for general use and children can be played back.
• Level 1
Only DVD software intended for children can be played back,
with those intended for adult and general use prohibited.
Marker Setup Screen
CDDVD-V
Use markers to memorise your favourite places on a disc.
1
Press SEARCH MODE four times (CD: three times)
during playback.
•
The display screen and Markers will appear on the TV screen.
2
Press s or B to select 1, 2, 3, 4, 5, 6, 7, 8, 9, or 10
and ensure that “- :- - :- -” appears in the display.
3
When reaches the desired point, press ENTER.
• The Title or Track and elapsed playing time will appear
in the TV screen.
4
To return to the Marker later, press SEARCH
MODE
four times
and
s or B to choose the desired marker, then
press
ENTER.
NOTES:
• Opening the disc tray or turning off the power or select
AC at step and press ENTER will erase all Markers.
• To clear a marker, using s or B, position the cursor on
to the marker number to be cleared and press CLEAR.
• You can mark up to 10 points.
5
Press SEARCH MODE or RETURN to exit.
(CD: three times)
2
during playback
DVD SETUP
Audio Setting
Choose the appropriate Audio settings for your equipment as it
only affect during the playback of DVD discs of the DVD player.
1
Press SETUP in STOP mode.
2
Press B to select
• CUSTOM mode will appear.
3
Press s or B to select AUDIO, then ENTER to confirm.
4
Press K or L to select the
below items, then press
ENTER.
DRC (Dynamic Range Control) :
• To compress the range of sound
volume.
• The default setting is OFF.
DOLBY DIGITAL :
Set to ON when the player is connected to Dolby Digital
Decoder.
(ON : Output by Dolby Digital)
(OFF : Convert the Dolby Digital to PCM)
• The default setting is ON.
DOWN SAMPLING :
• Set to ON when outputting in 48kHz.
• The default setting is ON.
When playing disc with copyright Protection
• If you select OFF, copyright protection will be activated
and sound will be down sampled at 48kHz.
5
Press SETUP to exit.
CUSTOM, then press ENTER.
QUICK
Black Level Setting
Adjust the Black Level Settings to make the black parts of
the picture as bright as you preferred.
1
Press MODE during playback.
2
Press ENTER to switch ON/OFF
ON : Makes the dark parts brighter.
OFF : Shows the original picture as recorded.
3
Press MODE twice or RETURN to exit.
.
Virtual Surround
You can enjoy stereophonic visual space on your existing
stereo system.
1
Press MODE twice (CD/MP3: once) during playback
2
ENTER to set it 1(Natural effect),
Press
2(Emphasized effect) or OFF.
3
Press
MODE or RETURN to exit.
NOTE (for CD play only):
• Vir tual Surround will not be effective if the sound mode
is set to something other than STEREO.
–13–
DVD-V
MP3CDDVD-V
.
EN
DVD SETUP
Display Setting
DVD-V
You can change certain aspects of the DVD display screens, on-screen
messages and the display panel on the front of the DVD player.
1
Press SETUP in STOP mode.
2
Press B to select
• CUSTOM mode will appear.
3
Press s or B to select DISPLAY, then ENTER to confirm.
4
Press K or L to select the below
items, then press
TV ASPECT :
• Press K or L for an item
selection, then press ENTER.
• Select 4:3 LETTER BOX for a
black bars appears on top and bottom of the screen.
• Select 4:3 PAN & SCAN for a full height picture with
both sides trimmed.
• Select 16:9 WIDE if a wide-screen TV is connected to
the DVD player.
• The default setting is 4:3 LETTER BOX.
PANEL DISPLAY :
• Press K or L for an item select BRIGHT, DIMMER
and AUTO, then press ENTER.
• This adjust the brightness of the display panel with the
factory default BRIGHT.
•
When AUTO is selected, the display dims only during playback.
ANGLE ICON :
•
Press ENTER repeatedly to turn Angle icon ON or OFF.
• The default setting is ON.
AUTO POWER OFF :
•
Press ENTER repeatedly to turn Auto Power off ON or OFF.
• The default setting is ON and it will turn the DVD player
to off automatically after 35 minutes of no use.
5
Press SETUP to exit.
CUSTOM, then press ENTER.
ENTER.
QUICK
DISPLAY
TV ASPECT
4:3 LETTER BOX
PANEL DISPLAY BRIGHT
ANGLE ICON ON
AUTO POWER OFF ON
Language Setting
DVD-V
Language options are not available with some discs.
1
Press SETUP in STOP mode.
2
Press B to select
• CUSTOM mode will appear.
3
Press s or B to select LANGUAGE, then ENTER
to confirm.
4
Press
K or L to select the
below items, then press
ENTER.
AUDIO :
• Sets the audio language.
SUBTITLE :
• Sets the subtitle language.
DISC MENU :
• Sets the language for DVD Menu.
PLAYER MENU :
• Sets the language for the On-Screen display.
5
Press K or L to select a setting, then press
ENTER.
•
If OTHER is selected in the AUDIO, SUBTITLE or DISC
MENU screen, press four-digit number to enter the code for
the desired language. (Refer to the language code list below).
•
Only the languages supported by the disc can be selected.
6
Press SETUP to exit.
NOTE:
• Language Setting for Audio and Subtitle is not available
with some discs. Then use AUDIO and SUBTITLE. Details
are on pages 12.
CUSTOM, then press ENTER.
LANGUAGE
AUDIO ORIGINAL
SUBTITLE OFF
DISC MENU ENGLISH
PLAYER MENU ENGLISH
QUICK
NOTES:
•
Be sure to press the SETUP button, or the setting will not work.
• You can also choose the item by pressing the numbers.
Language Code Language Code Language Code Language Code
Abkhazian 4748
Afar 4747
Afrikaans 4752
Albanian 6563
Amharic 4759
Arabic 4764
Armenian 5471
Assamese 4765
Aymara 4771
Azerbaijani 4772
Bashkir 4847
Basque 5167
Bengali;Bangla 4860
Bhutani 5072
Bihari 4854
Bislama 4855
Breton 4864
Bulgarian 4853
Burmese 5971
Byelorussian 4851
Cambodian 5759
Catalan 4947
Chinese [CHI] 7254
Corsican 4961
Croatian 5464
Czech 4965
Danish [DAN] 5047
Dutch [DUT] 6058
English [ENG] 5160
Esperanto 5161
Estonian 5166
Faroese 5261
Fiji 5256
Finnish [FIN] 5255
French [FRE] 5264
A-B
C-E
F-H
Frisian 5271
Galician 5358
Georgian 5747
German [GER] 5051
Greek [GRE] 5158
Greenlandic 5758
Guarani 5360
Gujarati 5367
Hausa 5447
Hebrew 5569
Hindi 5455
Hungarian [HUN] 5467
Icelandic [ICE] 5565
Indonesian 5560
Interlingua 5547
Interlingue 5551
Inupiak 5557
Irish [IRI] 5347
Italian [ITA] 5566
Japanese [JPN] 5647
Javanese 5669
Kannada 5760
Kashmiri 5765
Kazakh 5757
Kinyarwanda 6469
Kirghiz 5771
Kirundi 6460
Korean [KOR] 5761
Kurdish 5767
Laothian 5861
Latin 5847
Latvian;Lettish 5868
Lingala 5860
Lithuanian 5866
Macedonian 5957
Malagasy 5953
I-K
L-N
Malay 5965
Malayalam 5958
Maltese 5966
Maori 5955
Marathi 5964
Moldavian 5961
Mongolian 5960
Nauru 6047
Nepali 6051
Norwegian [NOR] 6061
Occitan 6149
Oriya 6164
Oromo(Afan) 6159
Panjabi 6247
Pashto;Pushto 6265
Persian 5247
Polish 6258
Portuguese [POR] 6266
Quechua 6367
Rhaeto-Romance 6459
Romanian [RUM] 6461
Russian [RUS] 6467
Samoan 6559
Sangho 6553
Sanskrit 6547
Scots Gaelic 5350
Serbian 6564
Serbo-Croatian 6554
Sesotho 6566
Setswana 6660
Shona 6560
Sindhi 6550
Singhalese 6555
Siswat 6565
Slovak 6557
Slovenian 6558
O-R
S
Somali 6561
Spanish [SPA] 5165
Sundanese 6567
Swahili 6569
Swedish [SWE] 6568
Tagalog 6658
Tajik 6653
Tamil 6647
Tatar 6666
Telugu 6651
Thai 6654
Tibetan 4861
Tigrinya 6655
Tonga 6661
Tsonga 6665
Turkish [TUR] 6664
Turkmen 6657
Twi 6669
Ukrainian 6757
Urdu 6764
Uzbek 6772
Vietnamese 6855
Volapuk 6861
Welsh 4971
Wolof 6961
Xhosa 7054
Yiddish 5655
Yoruba 7161
Zulu 7267
T
U-Z
If you choose a Language that has a 3 letter language code, the code will be displayed every time you change
the Audio or Subtitle language setting on page 12. If you choose any other languages, ‘---’ will be displayed
instead. (3 letter language code is written in bracket.)
–14–
EN
TROUBLESHOOTING GUIDE
If the DVD player does not perform properly when operated as instructed in this Owner's Manual, check the player, consulting
the following checklist.
Problem Solution
No power –Check if the AC power cord is properly connected.
No picture –Check if the TV is switched on.
–Check the video connection
Distorted picture –Sometimes a small amount of picture distortion may appear.
This is not a malfunction.
Completely distorted picture or –Connect DVD player directly to the TV.
black/white picture with DVD –Make sure the disc is compatible with the DVD player.
No sound or distorted sound –Adjust the volume.
–Check that the speakers are connected correctly.
No audio at digital output –Check the digital connections.
–Check if the audio format of the selected audio language matches
your receiver capabilities.
No DTS audio is output –This player does not support DTS audio. This is not a malfunction.
No sound and picture –Check that the VIDEO/AUDIO cable is connected to the correct
device (See Connecting to a TV)
Picture freezes momentarily –Check the disc for fingerprints/scratches and
during playback clean with a soft cloth wiping from center to edge.
Disc can’t be played –Ensure the disc label is facing up.
–Check if the disc is defective by trying another disc.
No return to start-up screen when –Reset the player by switching the player off, then on again.
disc is removed
The player does not respond to –
the remote control –Reduce the distance to the player.
Buttons do not work or player stops –To completely reset the player, unplug the AC
responding cord from the AC outlet for 5-10 seconds.
Player does not respond to some –Operations may not be permitted by the disc.
operating commands during playback. Refer to the instructions of the disc.
DVD player cannot read –Use a commonly available cleaning CD/DVD to
CDs/DVDs clean the lens before sending the DVD player for repair.
Aim the remote control directly at the sensor on the front of the player.
–Replace the batteries in the remote control.
–Re-insert the batteries with their polarities (+/– signs) as indicated.
NOTES:
Some functions are not available in specific modes, but this is not a malfunction. Read the description in this Owner’s Manual
for details on correct operations.
• Playback from a desired track and random playback are not available during program playback.
–15–
EN
SPECIFICATIONS
OUTPUT SIGNAL FORMAT
NTSC color
POWER SOURCE
120 V AC +/- 10%, 60 Hz +/- 0.5%
POWER CONSUMPTION
11 W (standby: 4.8W)
OPERATING TEMPERATURE
5°C to 40°C
DIMENSIONS
W 435mm
H 75mm
D 211mm
WEIGHT
Approx 1.8kg
• Designs and specifications are subject to change
without notice.
• If there is a discrepancy between languages, the
default language will be English.
MAINTENANCE
Servicing
• Should your DVD player become inoperative, do not try to correct the problem by yourself. There are no user-serviceable parts inside. Turn off, unplug the power cord, and please call our help line at 1-800-287-4871, to locate an
Authorized Service Center.
Cleaning the Cabinet
• Use a soft cloth slightly moistened with a mild detergent solution. Do not use a solution containing alcohol, spirits,
ammonia or abrasives.
Cleaning Discs
• When a disc becomes dir ty, clean it with a cleaning cloth. Wipe the disc from the center out. Do not wipe in a circular
motion.
• Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, adrasive cleaning agents or
antistatic spray intended for analogue records.
Cleaning the disc lens
• If the player still does not perform properly when it is operated while referring to the relevant sections and to “TROUBLESHOOTING GUIDE” in this Owner’s Manual, the laser optical pickup unit may be dirty. Consult your dealer or an
Authorized Service Center for inspection and cleaning of the laser optical pickup unit.
Disc Handling
• Use discs which have the following logos on them. (Optical audio digital discs.)
Recordable
• Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.
• Always store the disc in its protective case when it is not used.
Make your contribution to the environment!!!
• Used up batteries do not belong in the dust bin.
• You can dispose of them at a collection point for used up batteries or special waste.
Contact your council for details.
ReWritable
–16–
EN
MEMO
–17–
EN
MEMO
–18–
EN
MEMO
–19–
EN
SYLVANIA HOME ENTERTAINMENT WARRANTY
We appreciate your purchase of a SYLVANIA Home Entertainment product. We take pride in the
quality of our products and have manufactured your new Home Entertainment unit to exacting quality
standards. We feel confident that in normal use, it will provide you with satisfactory performance.
However, should you experience difficulty, you are protected under the provisions of this warranty.
SYLVANIA Home Entertainment products are warranted against manufacturing defects in materials and
workmanship in normal use for the following period from the date of purchase by the original user, and
is conditional upon the unit being installed and used as directed in the instruction manual.
Product Parts and Labour
D.V.D. Players 1 year
Remote Control 90 days
SYLVANIA’s obligation under this warranty shall be limited to the repair, including all necessary parts
and the cost of the labour connected therewith, or at our option the exchange of any Home Entertainment
product which shows evidence of a manufacturing defect within the warranty period.
Replacement parts, furnished in connection with this warranty shall be warranted for a period equal to
the unexpired portion of the original equipment warranty.
CUSTOMER OBLIGATIONS
This warranty applies to the product from the original date of purchase at retail. Therefore, the owner
must provide a copy of the original, dated bill of sale. No warranty service will be performed without a
bill of sale. Transportation to and from the service depot is the responsibility of the owner.
WARRANTY EXCLUSIONS
This warranty is extended to SYLVANIA Home Entertainment products purchased and used in Canada.
This warranty shall not apply to appearance or accessory items including but not limited to: antenna,
cabinet, cabinet parts, knobs, batteries, connecting cables, cassette tapes, compact discs. This
warranty shall, in addition, not apply to damages due to handling, transportation, unpacking, set-up,
installation, customer adjustments that are covered in the instruction book, repair or replacement of parts
supplied by other than the SYLVANIA authorized service depot, any malfunction or failure caused by or
resulting from abnormal environmental conditions, improper unauthorized service, improper
maintenance, modifications or repair by the consumer, abuse, misuse, neglect, accident, fire, flood, or
other Acts of God, and incorrect line voltage.
This Home Entertainment product is only warranted to the original retail purchaser. This warranty
becomes void in the event of commercial or rental use. This warranty becomes void in the event serial
numbers are altered, defaced or removed.
SYLVANIA reserves the right to make changes in design or to make additions to or improvements upon
this product without incurring any obligation to install the same on products previously manufactured.
The foregoing is in lieu of all other warranties expressed or implied and SYLVANIA neither assumes nor
authorizes any person to assume for it any other obligation or liability in connection with the sale or
service of this product. In no event shall SYLVANIA or its SYLVANIA dealers be liable for special or
consequential damage arising from the use of this product, or for any delay in the performance of this
warranty due to cause beyond our control.
The purchaser may have other rights under existing provincial or federal laws, and where any terms of
this warranty are prohibited by such laws, they are deemed null and void, but the remainder of the
warranty shall remain in effect.
HOW TO OBTAIN SERVICE
Should this product require service, you may obtain specific information on how to obtain service by
contacting the SYLVANIA Dealer from whom this product was purchased, or by contacting us
directly:
SYLVANIA SERVICE
300 Alden Road
Markham, Ontario
L3R 4C1
PHONE: (905) 940-5089 FAX: (905) 940-2303
1-800-287-4871
Printed in China
E5702CD
0VMN03356
★★★★★
documentation manual, user maintenance, brochure, user reference, pdf manual
This file has been downloaded from:
User Manual and User Guide for many equipments like mobile phones, photo cameras, monther board, monitors, software, tv, dvd, and othes..
Manual users, user manuals, user guide manual, owners manual, instruction manual, manual owner, manual owner's, manual guide,
manual operation, operating manual, user's manual, operating instructions, manual operators, manual operator, manual product,
Loading...
