Data Sheet Fujitsu Display L20T-2 LED Display

Data Sheet

Fujitsu Display L20T-2 LED
Display

All-round display: 50.8 cm (20-inch) widescreen
Ease of use at a reasonable price

The L20T-2 LED comes in a 16:9 format with a trendy style. There is no compromise in

picture quality and energy efciency. It is the best choice to get high pixel density with
restricted desk space. It is easy-to-use and once it is installed you never have to adjust it
again - proven Fujitsu quality.

Widescreen display with LED backlit panel in optimum 16:9 movie
format

< 1W/inch typical power consumption and ENERGY STAR compliant

5 ms fast response time (typ.) - perfect for ofce and internet

1600 x 900 HD resolution for excellent entertainment experience

Due to integrated speakers no further accessories needed

Page 1 / 4 http://ts.fujitsu.com/displays

Data Sheet Fujitsu Display L20T-2 LED Display

Technical details

Special features

LED backlit panel, ECO Status LED: 3 colors for 3 modes

Stand details

Stand removable
Picture height over desk (min) 90 mm
Tilt angle -5° / +15°

Picture performance

Contrast - typical 1,000:1
Contrast - advanced 5,000,000:1
Response time typical 5 ms
Viewing angle (h/v) - typical 176°/170°
Color performance 16.7 million colors (Hi-FRC)
Brightness - typical 250 cd/m²

Size and resolution

Aspect ratio 16:9
Diagonal Size 50.8 cm (20-inch)
Resolution (native) 1600 x 900 pixel (recommended)
Resolution (interpolated) 1440 x 900 pixel, 1366 x 768 pixel, 1280 x 720 pixel, 1024 x 768 pixel, 800 x 600 pixel, 720 x 400 pixel, 640 x 480

pixel

Picture size 443 x 249 mm
Pixel Pitch 0.277 mm

Frequencies

Horizontal 30 kHz to 83 kHz
Vertical 55 - 76 Hz
Frequencies - bandwidth 137 Mhz

Connectivity

VGA/D-SUB 1 x D-SUB
Audio signal input 3.5 mm stereo phone jack
Audio sound output 2 x 1 W

OSD Languages and setting options

Languages Arabic, Czech, Danish, Dutch, English, Finnish, French, German, Italian, Norwegian, Polish, Portuguese, Russian,

Spanish, Swedish, Turkish

Brightness / Contrast Brightness, Contrast
Color 6500K, 7500K, 9300K, Native, sRGB, Custom Color
Image adjust H-Position, V-Position, Sharpness, Clock, Phase
Audio Mute, Volume
Information Resolution/mode, Signal input

Power consumption (typical, w/o sound)

Soft switch off 0.33 W
Power save mode 0.39 W
Operating with EPA settings 17.9 W
Operating maximum brightness 20.4 W

Electrical values

Rated voltage range 100 V - 240 V
Rated frequency range 50 Hz - 60 Hz
Protection class 1

Compliance

Europe CE, RoHS, WEEE, IT-Eco-Declaration
