S TANDAR D K E YB OAR D
C OMPACT K E YB OAR D
FK B 1406 S E R IE S
F E AT UR E S
• C ompact s iz e : 216 mm(8.504 in.) (W ) ? 76 mm(3.07 in.) (D)x 10.2mm (0.412 in.) (H)
• K ey pitch: 15 mm (0. 59 in. )
• E xcellent operation
—1. 5 mm(0.059 in.) keystroke, 60 g operating force (2. 112 oz .), 20 g ( 0.704 oz . )tactile respons e
—S oft tactile feedback
• High quality and reliability
• E valuation kit a vailable
MA IN A P P L IC AT IONS
• Internet Telephones
• Handheld P C
• P roces s C ontrol and Ins trumentation
C ONS TR UC TIO N
• K eyboa rd unit (without enclos ure and microcontroller)
DISCONTINUED
1
S PE C IF ICAT IONS
FK B 1406 S E R IE S
Ite m
Mechanica l Number of K eys 64
(U S)
K ey S witch T ype Membrane s witch
K eytop style R ectangula r cylindrical
Operating F orce 60 gf ? 20 gf ( 2.112? 0. 704 oz. )
S troke 1. 5 mm ? 0. 3 mm (0.059 in. ? 0. 011 in.)
Tactile 20 gf typ. (0 .70 4 oz. ), soft type
Operating Life 5 M operations min.
Weight 109 g (3. 9 oz)
E lectrical Interfac e R ow a nd column matrix
C ontac t R es is tanc e 1 K ohms
Ins ulation R es istance 50 M ohms minimum
Die lectric S trength 250 V DC , 1 minute
C ontact B ounce 10 msec ma ximum
E nvironment Operating Temperature 0 to 50 C
S torage Tempera ture –20 to 60 C
Humidity 90% R H max. at +40 C max. invers ely proportional cha nge to 50% R H
at 60 C
S peci c ation
PAR T NUMB E R
N860-1406-T 001
DISCONTINUED
2
K E Y B OA R D L AY OU T
)
±0.0 20
(2 .972
±0.5
75. 5
)
DISCONTINUED
Membra ne
S heet
0.0 20
±0.5
9. 7
(0. 382±
FK B 1406 S E R IE S
±0.5
(8 .504
±0.0 20
)
(1. 50)[0 .060 ]
216 .0
K eyca p
8. 0 (0.31 5)
0. 50
A
A: Boss for M2x5. 7 s crew ( 2 plac es)
7. 21
(0. 284)
S upport panel (aluminum 0 .5t)
K eyswitch panel
(0. 020)
OP E R AT ING F OR C E A ND TR AV E L C HA R AC TE R IS TIC S
(gf)
100
50
F OR C E
0
0.5 1.0 1.5 (mm)
S TR O KE
3
FK B1406 S E R IE S
E urope
F ujitsu C omponents Europe B.V.
Diamantlaa n 25
213 2 WV Hoofddorp
Netherlands
Tel: (31-23) 5560 910
F ax: (31-23) 5560 950
E mail: info.marketing@fceu.fujitsu.com
Web: www.fceu.fujitsu.com
Asia Pacifi c
F ujitsu C omponents Asia Ltd.
102 E Pasir Panjang Road
#04-01 C itilink Warehouse Complex
S ingapore 118 529
Tel: (65) 375-8560
F ax: (65) 273-3021
E mail: fcal@fcal.fujitsu.com
www.fcal.fujitsu.com
F ujits u Components
International
Headquarter
Offic es
J apan
F ujitsu C omponent Limited
G otanda-C huo Building
3-5, Higashigotanda 2-chome, Shinagawa-ku
Tokyo 141, Japan
Tel: (81-3) 5449-7010
F ax: (81-3) 5449-2626
E mail: promothq@ft.ed.fujitsu.com
Web: www.fcl.fujitsu.com
Nor th and S outh America
F ujitsu C omponents America, Inc.
250 E . Caribbean Drive
S unnyvale, CA 9408 9 U.S.A.
Tel: (1-408) 745-4900
F ax: (1-408) 745-4970
E mail: marcom@fcai.fujitsu.com
Web: www.fcai.fujitsu.com
© 20 01 Fujitsu C omponents America, Inc. All company and product names are tra demarks or registered trademarks of their res pective owners. R ev. 09/2001
