GF14
Accessories
Accessories
FRY_P_0012_ 11_14_Accessories.pdf
GF14
Accessories
# PART # DESCRIPTION QTY Note
1 8030015 Basket, Full 1
1a 8030099 Basket, Full Size 1
2 8030032 Basket Support Rack, J2X 1
2a 8030132 Rack, Full-Vat Basket Support 1
2b 8030037 Basket rack, fine mesh GF14 1
2c 8030136 Basket Support Screen, Full Vat 1
3 8030197 Fryer’s Friend 1
4 8030271 Basket, Twin Size 1
5 8065518 Cover, Frypot, Full Vat 1
5a 9107014 Cover, Spreader Cabinet 1 [1]
6 8100070 Coupling, Gas Line Female Quick Disconnect 0.75-inch 1
6a 8100073 Coupling, Gas Line Female Quick Disconnect 1-inch 1
7 8100072 Quick-Disconnect Fitting, Male, 0.75-inch 1
7a 8100074 Quick-Disconnect Fitting, 1-Inch Male 1
8 8100083 Hose, Flexible Gas, 0.75-inch x 36-inch 1
8a 8100084 Hose, Flexible Gas, 0.75-inch x 48-inch 1
8b 8100088 Gas Line, 1-Inch Dormont Flexible, 36-Inch 1
8c 8100085 Gas Line, 1-Inch Dormont Flexible, 48-Inch 1
9 8261095 Anchor Strap Kit 1 [2]
10 8260900 Kit, Chain Restraint 1 [3]
11 8121226SP Drain Extension, 1.25-inch, Full-vat 1
11a 8121226 Drain Extension 1.25-inch 1 [1]
12 8103169 Leg 4
13 8100750 Caster, 90° rigid 1
13a 8100356 Caster, 5” 1 [4]
13b 8100357 Caster, 5” 1 [5]
14 1064386SP Toggle switch 1
15 8102793 Hanger, Wireform Basket 1
15a 8090171 Thumbscrew, 0.25-20 x 1.375-inch 1
15b 8090921 Spacer, Basket Hanger 1 [6]
16 8030188 Sediment tray, GF14 1
16a 8030103 Valve, Manual Gas Shut Off 0.75” 1
PART NOTES:
[1] - manufactured date code before 1/1/08
[2] - for use only on fryers equipped with legs
[3] - for use only on fryers equipped with casters
[4] - without brake
[5] - with brake
[6] - spacer
Accessories
FRY_P_0012_ 11_14_Accessories.pdf
1
2
4
5
7
9
10
11
4
5
9
12
13
15
GF14
Burners (Post June 08 and current)
Burners (Post June 08 and current)
FRY_P_0012_ 11_14_Burners (Post June 08 and current).pdf
GF14
Burners (Post June 08 and current)
# PART # DESCRIPTION QTY Note
1 2000176 Bracket, Front Manifold Mounting 1
2 2000177 Hanger, Rear Manifold 1
3 2000749 Guard, Thermopile 1
3a 8101873 Pilot, Powerpile 1
4 8071603 Valve, Honeywell Millivolt Gas, Natural 1
4a 8071604 Valve, Honeywell Millivolt Gas, Propane 1
4b 8100975 Gas Valve Knob 1
5 8100691 Tube, 0.125-inch Vent 1
6 8100703 Pilot Tubing, Gas Valve to Pilot 1
7 8101862 Burner Manifold, J2X 1
8 8261139 Conversion Kits, GF14 Conversion Kit, Natural to LP 1
8a 8261140 Conversion Kits, GF14 Conversion Kit, LP to Natural 1
8b 8261143 Conversion Kit, Natural to Propane 1
8c 8261144 Conversion Kit, Propane to Natural 1
9 8102071 Pilot Assembly Pilot Assembly, Natural 1
9a 8100149 Right Angle Orifice, .024-inch 1
9b 8100426 Pilot, Natural Gas 1
9c 8102070 Pilot Assembly (Includes bracket, hood, and thermopile),
Propane Gas
9d 8100148 Right Angle Orifice, .013-inch 1
9e 8100427 Pilot, Propane Gas 1
9f 1069922 Pilot Assembly (Includes bracket, hood, and thermopile),
Propane Gas, Australian
10 9001032 Pilot Mounting Bracket, J2X 1
11 9101082 Deflector, side, GF14 1
12 2301177 Deflector, side, GF40 1
13 2301206 Deflector, rear, GF40 1
14 9102113 Target, rear, GF14 1
15 8230496 Manifold, Burner 1
16 8261388 GF14, Natural 1.655mm (Altitutde 0-1999 feet (0-609
meters))
17 8261354 GF 14, Propane 1.05 mm (Altitude 0-1999 feet (0-609
meters))
18 8261357 Orifice, 1.45 mm (for natural gas, 0-1999 feet/0-609 meters) 10
19 8261387 Orifice, 0.86 mm (for Propane gas, 0-1999 feet/0-609 meters) 10
20 8102804 GF14, Natural Gas 1.60 mm (Altitude 2000-3999 (610-1219
meters))
21 8120907 GF14, Natural Gas 1.55 mm (Altitude 4000-5999 feet (1220-
1829 meters))
22 8121204 GF14, Natural Gas 1.50 mm (Altitude 6000-7999 feet (1830-
2438 meters))
23 8261357 Orifice, 1.45 mm (for natural gas, 0-1999 feet/0-609 meters) 10
24 8261386 Orifice, 1.40 mm (for natural gas, 2000-3999 feet/610-1219
meters)
25 8100135 GF 14, Propane 1.02 mm (Altitude 2000-3999 (610-1219
meters))
26 8261391 GF 14, Propane 0.99 mm (Altitude 4000-5999 feet (1220-
1829 meters))
27 8120906 GF 14, Propane 0.95 mm (Altitude 6000-7999 feet (1830-
2438 meters))
1
1
10
10
1
1
1
10
1
10
1
Burners (Post June 08 and current)
FRY_P_0012_ 11_14_Burners (Post June 08 and current).pdf
GF14
Burners (Post June 08 and current)
# PART # DESCRIPTION QTY Note
28 8120915 GF 14, Propane 0.93 mm (Altitude 8000-8999 feet (2439-
2743 meters))
29 8120910 GF 14, Propane 0.90 mm (Altitude 9000-9999 feet (2743-
3048 meters))
30 8261386 Orifice, 1.40 mm (for natural gas, 2000-3999 feet/610-1219
meters)
31 8100361 Orifice, 1.36 mm (for natural gas, 4000-5999 feet/1220-1829
meters)
32 8100131 Burner Orifice Burner Orifice, #56, 1.30 mm, Natural, J1C &
J1X
33 8100951 Orifice, 1.25 mm (for natural gas, 8000-8999 feet/2439-2743
meters)
34 8100323 Orifice, 1.20 mm (for natural gas, 9000-9999 feet/2744-3048
meters)
35 8100952 Orifice, 0.82 mm (for Propane gas, 2000-3999/610-1219
meters)
36 8261352 Orifice, 0.81 mm (for Propane gas, 4000-5999 feet/1220-
1829 meters)
37 8120914 Orifice, 0.78 mm (for Propane gas, 6000-7999 feet/1830-
2438 meters)
38 8121302 Orifice, 0.76 mm (for Propane gas, 8000-8999 feet/2439-
2743 meters)
39 8120444 Orifice, 0.74 mm (for Propane gas, 9000-9999 feet/2743-
3048 meters)
1
1
10
1
1
1
1
1
10
1
1
1
Burners (Post June 08 and current)
FRY_P_0012_ 11_14_Burners (Post June 08 and current).pdf
1
2
3
4
5
6
7
9
9
10
11
12
13
14
14
15
12
16
17
18
19
18
20
21
22
23
GF14
Burners and Gas Supply Components (Pre June 08)
Burners and Gas Supply Components (Pre June 08)
FRY_P_0012_ 11_14_Burners and Gas Supply Components (Pre June 08).pdf
GF14
Burners and Gas Supply Components (Pre June 08)
# PART # DESCRIPTION QTY Note
1 2000749 Guard, Thermopile 1
2 8060225SP Deflector Assembly 1
3 8071603 Valve, Honeywell Millivolt Gas, Natural 1
3a 8071604 Valve, Honeywell Millivolt Gas, Propane 1
3b 8100975 Gas Valve Knob 1
3c 8261143 Conversion Kit, Natural to Propane 1
3d 8261144 Conversion Kit, Propane to Natural 1
3e 8100426 Pilot, Natural Gas 1
3f 8100427 Pilot, Propane Gas 1
3g 8101873 Pilot, Powerpile 1
4 8090092 Screw, 5-40 x 0.25-inch Slotted Pan Head 1
4a 8090115 Screw. #10-32 x 0.25-inch Truss Head 1 [1]
5 8090785 Screw, #14 x 0.75-inch Slotted Hex Washer Head 1
6 8090951 Clamp, Hose 1
7 8261357 Orifice, 1.45 mm (for natural gas, 0-1999 feet/0-609 meters) 10
7a 8261386 Orifice, 1.40 mm (for natural gas, 2000-3999 feet/610-1219
meters)
7b 8100361 Orifice, 1.36 mm (for natural gas, 4000-5999 feet/1220-1829
meters)
7c 8100131 Burner Orifice Burner Orifice, #56, 1.30 mm, Natural, J1C &
J1X
7d 8100951 Orifice, 1.25 mm (for natural gas, 8000-8999 feet/2439-2743
meters)
7e 8100323 Orifice, 1.20 mm (for natural gas, 9000-9999 feet/2744-3048
meters)
7f 8261387 Orifice, 0.86 mm (for Propane gas, 0-1999 feet/0-609 meters) 10
7g 8100952 Orifice, 0.82 mm (for Propane gas, 2000-3999/610-1219
meters)
7h 8261352 Orifice, 0.81 mm (for Propane gas, 4000-5999 feet/1220-
1829 meters)
7i 8120914 Orifice, 0.78 mm (for Propane gas, 6000-7999 feet/1830-
2438 meters)
7j 8121302 Orifice, 0.76 mm (for Propane gas, 8000-8999 feet/2439-
2743 meters)
7k 8120444 Orifice, 0.74 mm (for Propane gas, 9000-9999 feet/2743-
3048 meters)
8 8100691 Tube, 0.125-inch Vent 1
9 8100705 Gas Line, Pilot Supply - 0.25 x 20” 1
10 Pilot Assembly 1 [2]
10a 8101830 Natural Gas w/.024-inch Right Angle Orifice 1
10b 8100149 Right Angle Orifice, .024-inch 1
10c 8101773 Pilot Assembly, Propane 1
10d 8100148 Right Angle Orifice, .013-inch 1
11 8130031 Bushing, 0.75-inch NPT to 0.5-inch Reducer 10
12 8130062 Elbow, 0.5” BM x 90° 10
13 8130068 Elbow, 0.75-inch NPT x 0.5-inch NPT x 90º 10
14 8130087 Nipple, 0.5-inch NPT x 1.5-inch (3.8 cm) 10
15 8130108 Nipple, 0.5-inch x 24.50-inch BM NPT 1
16 8130154 Plug, 0.125-inch NPT Hex Head Pipe 1
10
1
1
1
1
1
10
1
1
1
Burners and Gas Supply Components (Pre June 08)
FRY_P_0012_ 11_14_Burners and Gas Supply Components (Pre June 08).pdf
GF14
Burners and Gas Supply Components (Pre June 08)
# PART # DESCRIPTION QTY Note
17 8130165 Elbow, 0.5-inch X 90° NPT Street 1
18 8130173 Union, 0.5-inch NPT 10
19 8130247 Nipple, 0.5 x 3.5” NPT BM 10
20 8130265 Nipple, 0.5-inch x 2.50-inch NPT BM 1
21 8130320 Nipple, 0.5-inch NPT x 8-inch 10
22 8230496 Manifold, Burner 1
23 8230574 Shield, Open Burner Heat 1
PART NOTES:
[1] - attaches Item 10 to Item 22
[2] - Includes bracket, hood, and thermopile.
Burners and Gas Supply Components (Pre June 08)
FRY_P_0012_ 11_14_Burners and Gas Supply Components (Pre June 08).pdf
1
2
3
4
7
8
9
10
11
GF14
Cabinetry (Post June 08 and current)
Cabinetry (Post June 08 and current)
FRY_P_0012_ 11_14_Cabinetry (Post June 08 and current).pdf
GF14
Cabinetry (Post June 08 and current)
# PART # DESCRIPTION QTY Note
1 2006903 Back GF14 1
1a 2006904 Back GF40 1
2 8160656 Insulation, back 1
3 2016917 Side, left, stainless 1
4 2026917 Side, right, stainless 1
5 2126893 Side, Right, painted 1
6 2116893 Side, Left, painted 1
7 2307192 Hinge, Door Lower 1
8 9004813 Brace, Cabinet Top Single 1
9 1069539 Door assembly 1
9a 2304960 Handle, Eurolook Door 1
10 1064067 Pin Assy, Door 1
11 8241946 Topcap 1
12 8101105 Magnet, Door 1
13 9103557 Fryer’s Friend 27” 1
Cabinetry (Post June 08 and current)
FRY_P_0012_ 11_14_Cabinetry (Post June 08 and current).pdf
1
2
2
3
5
6
7
7
7
8
8
9
10
11
12
13
8
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
GF14
Cabinetry Components (Pre June 08)
Cabinetry Components (Pre June 08)
FRY_P_0012_ 11_14_Cabinetry Components (Pre June 08).pdf
GF14
Cabinetry Components (Pre June 08)
# PART # DESCRIPTION QTY Note
1 8068396 Door Assembly 1
2 8261351 Nut Retainer, 0.25-20 Std. Fluecap 10 [1]
3 8261362 Nut, 0.25-20 Hex 10
4 8090171 Thumbscrew, 0.25-20 x 1.375-inch 1
5 8090191 Washer, Lock 0.25 Spring ZP 1
6 8090193 Washer, Flat 0.25 Nylon 1
7 8261371 Screw, 8 x 0.5-inch Hex Head ZP 25
8 8261374 Screw, 10 x 0.5-inch Hex Head 25
9 8090413 Spacer, Door Post (0.25-inch ID x 4mm nylon washer) 1 [2]
10 8090563 Bolt, 0.25-20 X 0.75-inch Carriage 1
11 8100356 Caster, 5” 1 [3]
12 8100357 Caster, 5” 1 [4]
13 8101105 Magnet, Door 1
14 8101403 Hanger, Wireform Basket 1
14a 8030028 Hanger AL (obsolete) 1
15 8101508 Hinge, Universal Door 1
16 8240330 Panel, GF14/GF40 Control 1
17 9000943 Bracket, Drain Extension 1
18 9001129 Support, Gas Line 1
19 9001501 Mount, Thermostat 1
20 9004274 Brace, GF40 Cabinet Top 1
21 9005764 Base, One-Piece GF40 Cabinet 1
22 9006983SP Back, Cabinet, Enameled Steel 1
22a 9106983SP Back, Cabinet, Stainless Steel 1
23 9017311SP Side, Left Cabinet, Enameled Steel 1
23a 9117311SP Side, Left Cabinet, Stainless Steel 1
24 9027311SP Side, Right Cabinet, Enameled Steel 1
24a 9127311SP Side, Right Cabinet, Stainless Steel 1
25 9103557 Fryer’s Friend 27” 1
26 9105038 Cap, Flue 1
27 8101422 Handle, Wireform Door 1
28 8261379 Screw, #10 X 0.5-inch Phillips Truss Head 10
PART NOTES:
[1] - for use on standard fluecap
[2] - 0.25-inch ID x 4mm nylon washer
[3] - without brake
[4] - with brake
Cabinetry Components (Pre June 08)
FRY_P_0012_ 11_14_Cabinetry Components (Pre June 08).pdf
4, 22, 23
5
6
7
8
9
10
11
12
13
14
15
14
15
16
16
17
18
19
20
21
24, 25, 26
12
GF14
Frypot and Related Components (Pre June 08)
Frypot and Related Components (Pre June 08)
FRY_P_0012_ 11_14_Frypot and Related Components (Pre June 08).pdf
GF14
Frypot and Related Components (Pre June 08)
# PART # DESCRIPTION QTY Note
1 1061679SP Frypot with Flue and Insulation - Stainless Steel 1
2 8064199SP Frypot with Flue and Insulation - Cold-Rolled Steel 1
3 8064308SP Complete Front Combustion Chamber 1 [1]
4 9006969 Baffle, Front Insulation 1
5 8065566 Panel Assembly, Rear Combustion Chamber 1
6 8065567SP Flue Assembly with Insulation, Complete 1
6a 8160174 Insulation, Flue Back 1
6b 8160175 Insulation, Flue Front 1
7 8065778SP Box Assembly, Flue Deflector 1
8 8261362 Nut, 0.25-20 Hex 10
9 8090170 Screw, #14 X 0.75-inch Slotted Pan Head 1
10 8090173 Clip, Tinnerman 1
11 8261371 Screw, 8 x 0.5-inch Hex Head ZP 25
12 8090410 Screw, #8 X 0.5-inch Phillips Head Drill Point 1
13 8100500 Spacer, .25-inch x .9375-inch 1
14 8120248 Insulation, Kaowool M-Board 14.50 X15.93 X 0.25-inch 1
15 8120249 Insulation, Spinglas 16.75 X 19.38 X 1.00-inch 1
16 8120269 Insulation, Kaowool Blanket 14.00 X 14.00 X 0.50-inch 1
17 8233470SP Replacement Frypot without Insulation - Stainless Steel 1
17a 8231233SP Replacement Frypot without Insulation - Cold-Rolled Steel 1
18 9006441 Side, Combustion Chamber 1
19 8067546 Thermostat Assembly, High Limit 1
20 8261809 Thermostat, Sunne Operating 1
20a 8160578 O-Ring, Thermostat Shaft 1
20b 8160139 Knob, thermostat 1
21 8101569 Valve, 1.25-inch, Non-filter, Full-vat Drain 1
22 8120246 Insulation, Spinglas 15.00 X 16.37 X 1.00-inch 1
23 8120245 Insulation, Kaowool M-Board 15.00 X 16.37 X 0.25-inch 1
24 9001090 Cover, Pilot Viewport 1
25 8100647 Holder, Security Screw 1
26 8090409 Screw, #10 X 0.5-inch Round Head One-way Security 1
PART NOTES:
[1] - Items 4 and 22 through 26
Frypot and Related Components (Pre June 08)
FRY_P_0012_ 11_14_Frypot and Related Components (Pre June 08).pdf
12
4
11
12
13
GF14
Frypots (Post June 08 and current)
Frypots (Post June 08 and current)
FRY_P_0012_ 11_14_Frypots (Post June 08 and current).pdf
GF14
Frypots (Post June 08 and current)
# PART # DESCRIPTION QTY Note
1 8231024 Flue assembly 1
1a 9103557 Fryer’s Friend 27” 1
2 8236655 Frypot, Standard 1
2a 8234493 Frypot, Sysco-branded fryers 1
3 8067972 Operating thermostat 1 [1]
4 1060770 Thermostat 1
5 8261177 Thermostat, High-Limit 425°F/218°C 1
6 8262014 Operating thermostat 1
7 8160139 Knob, thermostat 1
8 9102113 Target, rear, GF14 1
9 8101569 Valve, 1.25-inch, Non-filter, Full-vat Drain 1
10 8260861 Insulation kit 1
11 8065567 Flue 1
11a 9103557 Fryer’s Friend 27” 1
12 8236667 Frypot 1
13 8261177 Thermostat, High-Limit 425°F/218°C 1
14 8262014 Operating thermostat 1
15 8160139 Knob, thermostat 1
16 8101569 Valve, 1.25-inch, Non-filter, Full-vat Drain 1
17 8260861 Insulation kit 1
PART NOTES:
[1] - Sysco fryer
Frypots (Post June 08 and current)
FRY_P_0012_ 11_14_Frypots (Post June 08 and current).pdf
Loading...
