Five Piece Introductory Bit Set
Application: Fundamental bit set for novice woodworkers
• This four-piece set transforms to five pieces by using a bearing to convert the beading bit into a rounding over bit.
• Includes a flush trim, straight, Roman ogee and beading bit.
• All bits have 1/4" shanks.
• Cuts all composition materials, plywoods, hardwoods, and softwoods.
• Use on hand-held and table-mounted portable routers.
Router Bit Sets
222
New
Shadow
# 42-104
# 04-108
Bit Type Item Overall Bearing Carbide Number Large Shank Overall
Number Dia. Dia. Height of Flutes Radius Dia. Length
Item Number 88-104 Bearing Flush Trim Bit 42-104 1/2" 1/2" 1" 2 1/4" 2-13/16" Double Flute Straight Bit 04-108 1/4" 1" 2 1/4" 2-1/2" Roman Ogee Bit 38-100 1-1/16" 3/8" 1/2" 5/32" 1/4" 2-3/16" Beading Bit 36-114 1-1/4" 3/8" 5/8" 3/8" 1/4" 2-3/16" Rounding Over Bit* 34-114 1-1/4" 3/8" 5/8" 3/8" 1/4" 2-3/16"
* Use included bearing #62-104 to convert 36-114 Beading Bit into 34-114 Rounding Over Bit.
Five Piece Introductory Bit Set
Application: Fundamental bit set for novice woodworkers
• Freud’s new Five Piece Introductory Set provides an economical yet very useful introduction to the wide world of possibilities offered by your 1⁄2" collet router.
• Includes a flush trim, straight, Roman ogee, and rounding over bit.
Box
# 91-103
• All bits have 1⁄2" shanks.
• Set comes in Freud’s unique shadow box case, this set hangs on the wall or mounts on the bench to keep bits handy and safe.
• Cuts all composition materials, plywoods, hardwoods, and softwoods.
• Use on hand-held and table-mounted portable routers.
# 36-114# 38-100
# 34-114*
Bit Type Item Overall Bearing Carbide Number Large Shank Overall
NEW
Item Number 91-103
Bearing Flush Trim Bit 42-110 1/2" 1/2" 1" 2 1⁄2" 3-1/4"
ROUTER BITS & SETS
Double Flute Straight Bit 12-100 1/4" 3/4" 2 1⁄2" 2-3/8" Roman Ogee Bit 38-104 1-1/16" 3/8" 1/2" 5/32" 1⁄2" 2-3/8" Rounding Over Bit 34-124 1-1/4" 1/2" 5/8" 3/8" 1⁄2" 2-5/8" *Beading Bit 36-124 1-1/4" 3/8" 5/8" 3/8" 1⁄2" 2-5/8"
* Use included bearing #62-104 to convert 34-124 Beading Bit into 36-124 Rounding Over Bit.
# 42-110
# 12-100
# 34-124
Number Dia. Dia. Height of Flutes Radius Dia. Length
Red Item Numbers Indicate 1/2" ShankSee individual bit for scale profile
# 36-124*# 38-104
