Ford C-Max 2015 User Manual

FORD C-MAX Owner's Manual

The information contained in this publication was correct at the time of going to print. In the interest of continuous development, we reserve the right to change specifications, design or equipment at any time without notice or obligation. No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted.

Part Number: CG3642en 02/2015 20150213081543

Introduction

About This Manual...........................................7

Symbols Glossary.............................................7

Data Recording..................................................9

Replacement Parts

Recommendation......................................10

Mobile Communications

Equipment.....................................................10

At a Glance

Front Exterior Overview.................................11

Rear Exterior Overview..................................12

Vehicle Interior Overview..............................13

Instrument Panel Overview - LHD............14

Instrument Panel Overview - RHD...........15

Child Safety

Installing Child Seats......................................17

Child Seat Positioning..................................20

Child Safety Locks - Vehicles With:

Mechanical Child Proof Locks...............24

Child Safety Locks - Vehicles With:

Remote Child Proof Locks......................24

Safety Belts

Fastening the Safety Belts..........................25

Safety Belt Height Adjustment.................25

Safety Belt Minder.........................................26

Supplementary Restraints

System

Principle of Operation...................................27

Driver Airbag.....................................................27

Passenger Airbag............................................27

Side Airbags.....................................................28

Side Curtain Airbags.....................................28

Keys and Remote Controls

General Information on Radio

Frequencies..................................................29

Remote Control - Vehicles With: Keyless

Entry................................................................29

Remote Control - Vehicles With: Remote

Flip Key............................................................31

Replacing a Lost Key or Remote

Control............................................................32

MyKey™

Principle of Operation...................................33

Creating a MyKey............................................34

Clearing All MyKeys.......................................34

Checking MyKey System Status...............36

Using MyKey With Remote Start

Systems.........................................................36

MyKey Troubleshooting...............................36

Locks

Locking and Unlocking.................................38

Sliding Door.....................................................40

Manual Liftgate - Compact MAV

(5-seater).....................................................40

Manual Liftgate - Grand MAV (5+2

seater).............................................................41

Power Liftgate.................................................42

Hands-Free Power Liftgate........................44

Keyless Entry....................................................45

Security

Passive Anti-Theft System........................48

Anti-Theft Alarm - Vehicles With:

Integral Battery...........................................48

Anti-Theft Alarm - Vehicles With: Interior

Sensor............................................................50

Anti-Theft Alarm - Vehicles With:

Perimeter Alarm.........................................52

Steering Wheel

Adjusting the Steering Wheel....................53

Audio Control...................................................53

Voice Control...................................................54

Cruise Control..................................................54

Information Display Control.......................55

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Table of Contents

Heated Steering Wheel................................55

Wipers and Washers

Windshield Wipers........................................56

Autowipers.......................................................56

Windshield Washers.....................................58

Rear Window Wiper and Washers...........58

Headlamp Washers......................................59

Lighting

General Information.....................................60

Lighting Control..............................................60

Autolamps.........................................................61

Instrument Lighting Dimmer......................61

Headlamp Exit Delay.....................................61

Daytime Running Lamps.............................62

Automatic High Beam Control..................62

Front Fog Lamps............................................63

Rear Fog Lamps..............................................63

Headlamp Leveling.......................................64

Cornering Lamps............................................65

Direction Indicators.......................................65

Interior Lamps.................................................65

Ambient Lighting...........................................66

Windows and Mirrors

Power Windows.............................................68

Global Opening and Closing......................69

Exterior Mirrors................................................70

Interior Mirror.....................................................71

Sun Visors..........................................................72

Sun Shades.......................................................72

Instrument Cluster

Gauges................................................................74

Warning Lamps and Indicators.................75

Audible Warnings and Indicators.............78

Information Displays

General Information.....................................80

Trip Computer.................................................83

Information Messages.................................83

Climate Control

Principle of Operation..................................92

Air Vents............................................................92

Manual Climate Control..............................93

Automatic Climate Control........................94

Hints on Controlling the Interior

Climate..........................................................96

Heated Windows and Mirrors...................99

Heated Windshield........................................99

Auxiliary Heater..............................................99

Cabin Air Filter...............................................103

Seats

Sitting in the Correct Position.................104

Head Restraints............................................104

Manual Seats.................................................105

Power Seats...................................................106

Rear Seats.......................................................107

Heated Seats...................................................115

Auxiliary Power Points

Auxiliary Power Points.................................116

Cigar Lighter....................................................116

Storage Compartments

Cup Holders......................................................117

Center Console................................................117

Overhead Console.........................................117

Starting and Stopping the

Engine

General Information.....................................118

Ignition Switch................................................118

Push Button Ignition Switch......................118

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Table of Contents

Steering Wheel Lock - Vehicles With:

Push Button Start......................................121

Steering Wheel Lock - Vehicles Without:

Push Button Start......................................121

Starting a Gasoline Engine.........................121

Starting a Diesel Engine.............................124

Diesel Particulate Filter..............................124

Switching Off the Engine...........................125

Engine Block Heater....................................125

Unique Driving Character-

istics

Auto-Start-Stop............................................127

Fuel and Refueling

Safety Precautions.......................................129

Fuel Quality - Gasoline...............................130

Fuel Quality - E85........................................130

Fuel Quality - Diesel......................................131

Fuel Filler Funnel Location.........................131

Running Out of Fuel......................................131

Catalytic Converter......................................132

Refueling..........................................................133

Fuel Consumption........................................134

Transmission

Manual Transmission..................................136

Automatic Transmission............................136

Brakes

General Information....................................139

Hints on Driving With Anti-Lock

Brakes...........................................................139

Parking Brake.................................................140

Hill Start Assist.............................................140

Traction Control

Principle of Operation.................................142

Using Traction Control................................142

Stability Control

Principle of Operation.................................143

Using Stability Control................................143

Parking Aids

Principle of Operation.................................144

Rear Parking Aid............................................144

Front Parking Aid..........................................145

Side Sensing System...................................147

Active Park Assist.........................................149

Rear View Camera........................................155

Cruise Control

Principle of Operation.................................158

Using Cruise Control....................................158

Using Adaptive Cruise Control................159

Driving Aids

Speed Limiter - Vehicles With: Cruise

Control.........................................................166

Speed Limiter - Vehicles With: Adaptive

Cruise Control............................................167

Driver Alert.......................................................167

Lane Keeping System.................................169

Blind Spot Information System...............173

Traffic Sign Recognition..............................177

Active City Stop.............................................178

Eco Mode.........................................................179

Collision Warning System.........................180

Load Carrying

General Information....................................184

Luggage Anchor Points..............................184

Rear Under Floor Storage..........................184

Luggage Covers.............................................185

Roof Racks and Load Carriers.................185

Dog Guard.......................................................185

Towing

Towing a Trailer.............................................188

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Table of Contents

Trailer Sway Control....................................189

Tow Ball...........................................................189

Towing Points................................................196

Towing the Vehicle on Four Wheels -

Manual Transmission..............................197

Towing the Vehicle on Four Wheels -

Automatic Transmission.......................198

Driving Hints

Breaking-In....................................................200

Reduced Engine Performance...............200

Economical Driving....................................200

Cold Weather Precautions........................201

Driving Through Water................................201

Floor Mats.......................................................201

Roadside Emergencies

Hazard Warning Flashers.........................203

First Aid Kit.....................................................203

Warning Triangle..........................................203

Fuel Shutoff...................................................203

Jump Starting the Vehicle........................204

Post-Crash Alert System..........................205

Fuses

Fuse Box Locations....................................206

Fuse Specification Chart - Vehicles Built

Up To: 22-06-2015..................................207

Fuse Specification Chart - Vehicles Built

From: 23-06-2015....................................217

Changing a Fuse...........................................226

Maintenance

General Information...................................228

Opening and Closing the Hood..............228

Under Hood Overview - 1.0L

EcoBoost™................................................230

Under Hood Overview - 1.5L

EcoBoost™.................................................231

Under Hood Overview - 1.6L Duratec-16V

Ti-VCT (Sigma)/1.6L Flex Fuel...........232

Under Hood Overview - 1.5L

Duratorq-TDCi Diesel.............................233

Under Hood Overview - 1.6L

Duratorq-TDCi (DV) Diesel..................234

Under Hood Overview - 2.0L

Duratorq-TDCi (DW) Diesel................235

Engine Oil Dipstick - 1.0L

EcoBoost™................................................236

Engine Oil Dipstick - 1.5L

EcoBoost™................................................236

Engine Oil Dipstick - 1.6L Duratec-16V

Ti-VCT (Sigma)/1.6L Flex Fuel..........236

Engine Oil Dipstick - 1.5L Duratorq-TDCi

Diesel/1.6L Duratorq-TDCi (DV)

Diesel...........................................................236

Engine Oil Dipstick - 2.0L Duratorq-TDCi

(DW) Diesel...............................................237

Engine Oil Check...........................................237

Engine Coolant Check................................237

Brake Fluid Check........................................238

Clutch Fluid Check......................................239

Washer Fluid Check....................................239

Changing the 12V Battery.........................239

Checking the Wiper Blades.......................241

Changing the Wiper Blades......................241

Removing a Headlamp..............................243

Changing a Bulb...........................................243

Bulb Specification Chart..........................250

Vehicle Care

Cleaning the Exterior...................................251

Cleaning the Interior....................................251

Repairing Minor Paint Damage...............252

Cleaning the Alloy Wheels.......................252

Wheels and Tires

Temporary Mobility Kit..............................253

Tire Care..........................................................257

Using Winter Tires........................................257

Using Snow Chains.....................................257

Tire Pressure Monitoring System..........258

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Table of Contents

Changing a Road Wheel...........................262

Tire Pressures...............................................269

Lug Nuts..........................................................274

Capacities and Specific-

ations

Vehicle Dimensions.....................................275

Towbar Dimensions....................................276

Vehicle Identification Plate.......................277

Vehicle Identification Number................278

Capacities and Specifications - 1.0L

EcoBoost™................................................279

Capacities and Specifications - 1.5L

EcoBoost™...............................................280

Capacities and Specifications - 1.6L

Duratec-16V Ti-VCT (Sigma)/1.6L Flex

Fuel................................................................281

Capacities and Specifications - 1.5L

Duratorq-TDCi Diesel.............................283

Capacities and Specifications - 1.6L

Duratorq-TDCi (DV) Diesel.................284

Capacities and Specifications - 2.0L

Duratorq-TDCi (DW) Diesel................286

Fuel Consumption Figures.......................287

Audio System

General Information...................................288

Audio Unit - Vehicles With: AM/FM/

CD.................................................................290

Audio Unit - Vehicles With: SYNC.........292

Audio Unit - Vehicles With: SYNC 2......294

Digital Radio..................................................295

Digital Radio - Vehicles With: SYNC

2.....................................................................296

Audio Input Jack...........................................297

USB Port.........................................................298

Media Hub......................................................298

Audio Troubleshooting..............................299

SYNC™

General Information..................................300

Using Voice Recognition............................301

Using SYNC™ With Your Phone...........304

SYNC™ Applications and Services.......315

Using SYNC™ With Your Media

Player............................................................322

SYNC™ Troubleshooting.........................330

SYNC™ 2

General Information...................................340

Settings............................................................347

Entertainment...............................................361

Phone...............................................................370

Information....................................................378

Climate............................................................382

Navigation......................................................384

SYNC™ Troubleshooting.........................394

Appendices

Electromagnetic Compatibility..............403

End User License Agreement.................404

Type Approvals............................................426

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Table of Contents

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

ABOUT THIS MANUAL

Thank you for choosing Ford. We recommend that you take some time to get to know your vehicle by reading this manual. The more that you know about it, the greater the safety and pleasure you will get from driving it.

WARNING

Driving while distracted can result in loss of vehicle control, crash and

injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle. We recommend against the use of any hand-held device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving.

Note: This manual describes product features and options available throughout the range of available models, sometimes even before they are generally available. It may describe options not fitted to the vehicle you have purchased.

Note: Some of the illustrations in this manual may show features as used in different models, so may appear different to you on your vehicle.

Note: Always use and operate your vehicle in line with all applicable laws and regulations.

Note: Pass on this manual when selling your vehicle. It is an integral part of your vehicle.

This manual may qualify the location of a component as left-hand side or right-hand side. The side is determined when facing forward in the seat.

Right-hand side.A Left-hand side.B

SYMBOLS GLOSSARY

These are some of the symbols you may see on your vehicle.

Safety alert

See Owner's Manual

Air conditioning system

Anti-lock braking system

Avoid smoking, flames or sparks

Battery

Battery acid

Brake fluid - non petroleum based

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Introduction

Brake system

Cabin air filter

Check fuel cap

Child safety door lock or unlock

Child seat lower anchor

Child seat tether anchor

Cruise control

Do not open when hot

Engine air filter

Engine coolant

Engine coolant temperature

Engine oil

Explosive gas

Fan warning

Fasten safety belt

Front airbag

Front fog lamps

Fuel pump reset

Fuse compartment

Hazard warning flashers

Heated rear window

Heated windshield

Interior luggage compartment release

Jack

Keep out of reach of children

Lighting control

Low tire pressure warning

Maintain correct fluid level

Note operating instructions

Panic alarm

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Introduction

Parking aid

Parking brake

Power steering fluid

Power windows front/rear

Power window lockout

Service engine soon

Side airbag

Shield the eyes

Stability control

Windshield wash and wipe

DATA RECORDING

A large number of electronic components of your vehicle contain data storage modules temporarily or permanently storing technical data about the condition of the vehicle, events and errors.

In general, this technical information documents the condition of parts, modules, systems or the environment:

• Operating conditions of system components (e.g. filling levels).

• Status messages of the vehicle and its individual components (e.g. number of wheel revolutions/rotational speed, deceleration, lateral acceleration).

• Malfunction and defects in important system components (e.g. lighting and brake system).

• Vehicle reactions in particular driving situations (e.g. inflation of an airbag, activation of the stability regulation system).

• Environmental conditions (e.g. temperature).

These data are exclusively technical and help identification and correction of errors as well as optimisation of vehicle functions. Motion profiles indicating travelled routes cannot be created with these data.

If services are used (e.g. repair works, service processes, warranty cases, quality assurance), employees of the service network (including manufacturers) are able to read out this technical information from the event and error data storage modules using special diagnostic devices. If required, you will receive further information. After an error has been corrected, these data are deleted from the error storage module or they are constantly overwritten.

When using the vehicle, situations may occur in which these technical data related to other information (accident report, damages on the vehicle, witness statements etc.) may be associated with a specific person - possibly, with the assistance of an expert.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Introduction

Additional functions contractually agreed upon with the client (e.g. vehicle location in emergency cases) allow the transmission of particular vehicle data from the vehicle.

REPLACEMENT PARTS RECOMMENDATION

Your vehicle has been built to the highest standards using quality parts. We recommend that you demand the use of genuine Ford and Motorcraft parts whenever your vehicle requires scheduled maintenance or repair. You can clearly identify genuine Ford and Motorcraft parts by looking for the Ford, FoMoCo or Motorcraft branding on the parts or their packaging.

Scheduled Maintenance and Mechanical Repairs

One of the best ways for you to make sure that your vehicle provides years of service is to have it maintained in line with our recommendations using parts that conform to the specifications detailed in this Owner’s Manual. Genuine Ford and Motorcraft parts meet or exceed these specifications.

Collision Repairs

We hope that you never experience a collision, but accidents do happen. Genuine Ford replacement collision parts meet our stringent requirements for fit, finish, structural integrity, corrosion protection and dent resistance. During vehicle development we validate these parts deliver the intended level of protection as a whole system. A great way to know for sure you are getting this level of protection is to use genuine Ford replacement collision parts.

Warranty on Replacement Parts

Genuine Ford and Motorcraft replacement parts are the only replacement parts that benefit from a Ford Warranty. Damage caused to your vehicle as a result of the failure of non-Ford parts may not be covered by the Ford Warranty. For additional information, refer to the terms and conditions of the Ford Warranty.

MOBILE COMMUNICATIONS EQUIPMENT

Using mobile communications equipment is becoming increasingly important in the conduct of business and personal affairs. However, you must not compromise your own or others’ safety when using such equipment. Mobile communications can enhance personal safety and security when appropriately used, particularly in emergency situations. Safety must be paramount when using mobile communications equipment to avoid negating these benefits. Mobile communication equipment includes, but is not limited to, cellular phones, pagers, portable email devices, text messaging devices and portable two-way radios.

WARNING

Driving while distracted can result in loss of vehicle control, crash and

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Introduction

FRONT EXTERIOR OVERVIEW

Fuel tank. See Refueling (page 133).A Locks. See Locking and Unlocking (page 38).B Exterior mirrors. See Exterior Mirrors (page 70).C Wiper blades. See Changing the Wiper Blades (page 241).D Engine. See Maintenance (page 228).E Front towing point. See Towing Points (page 196).F Front exterior lamps. See Changing a Bulb (page 243).G Wheels and tires. Tire pressures. See Towing Points (page 196). See Changing

a Road Wheel (page 262).

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

At a Glance

REAR EXTERIOR OVERVIEW

Rear exterior lamps. See Changing a Bulb (page 243).A High mounted stop lamp. See Changing a Bulb (page 243).B Rear window wiper. See Changing the Wiper Blades (page 241).C Liftgate. See Power Liftgate (page 42).D Tire pressures. See Tire Pressures (page 269).E Wheels and tires. See Changing a Road Wheel (page 262).F

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

At a Glance

VEHICLE INTERIOR OVERVIEW

Gearshift lever. See Transmission (page 136).A Power window switches. See Power Windows (page 68).B Safety belts. See Fastening the Safety Belts (page 25).C Parking brake. See Parking Brake (page 140).D Head restraints. See Head Restraints (page 104).E Front seats. See Manual Seats (page 105).F Temporary mobility kit. See Temporary Mobility Kit (page 253).G Hood release lever. See Opening and Closing the Hood (page 228).H

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

At a Glance

INSTRUMENT PANEL OVERVIEW - LHD

Air vents. See Air Vents (page 92).A Direction indicator lever. See Direction Indicators (page 65).B Information display control. See Information Display Control (page 55).C Instrument cluster. See Instrument Cluster (page 74).D Audio control. See Audio Control (page 53).E Wiper lever. See Wipers and Washers (page 56).F Information and entertainment display. See SYNC™ 2 (page 340).G Audio unit. See Audio System (page 288).H Hazard flasher switch. See Hazard Warning Flashers (page 203).I Climate controls. See Climate Control (page 92).J Keyless start button. See Push Button Ignition Switch (page 118).K Horn.L Steering wheel adjustment. See Adjusting the Steering Wheel (page 53).M

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

At a Glance

Cruise control switches. See Using Cruise Control (page 158).N Lighting control. See Lighting (page 60).O

INSTRUMENT PANEL OVERVIEW - RHD

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

At a Glance

Keyless start button. See Push Button Ignition Switch (page 118).K Horn.L Steering wheel adjustment. See Adjusting the Steering Wheel (page 53).M Cruise control switches. See Using Cruise Control (page 158).N Lighting control. See Lighting (page 60).O

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

At a Glance

INSTALLING CHILD SEATS

WARNINGS

Use an approved child seat to secure children less than 59 in (150 cm) tall on the rear seat.

NEVER use a rearward facing child restraint on a seat protected by an

ACTIVE AIRBAG in front of it, DEATH OR SERIOUS INJURY to the CHILD can occur.

Read and follow the manufacturer’s

instructions when you are installing

a child seat.

Do not modify child seats in any way.

Do not hold a child on your lap when

your vehicle is moving.

WARNINGS

Do not leave children or pets unattended in your vehicle.

If your vehicle has been involved in a crash, have the child seats checked by an authorized dealer.

Note: Mandatory use of child seats varies from country to country.

Only child seats certified to ECE-R129, ECE-R44.03 or later have been tested and approved for use in your vehicle. A choice of child seats are available from authorized dealers.

Child Seats for Different Mass Groups

Use the correct child seat as follows:

Baby Safety Seat (Group 0+)

Secure children that weigh less than 29 lb (13 kg) in a rearward facing baby safety seat on the rear seat.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Child Safety

Child Safety Seat (Group 1)

Secure children that weigh between 29 lb (13 kg) and 40 lb (18 kg)in a child safety seat on the rear seat.

Booster Seats

WARNINGS

Do not install a booster seat or a booster cushion with only the lap strap of the safety belt.

Do not install a booster seat or a booster cushion with a safety belt that is slack or twisted.

Do not put the safety belt under your child’s arm or behind your child's back.

Do not use pillows, books or towels to boost your child’s height.

Make sure that your children sit in an upright position.

Note: Make sure the child seat rests tightly against the vehicle seat. If necessary, adjust the seat backrest to an upright position. It may also be necessary to lift or remove the head restraint. See Head Restraints (page

104).

Note: When using a child seat on a rear seat, adjust the front seat in a position to prevent contact with the rear passenger, child feet or child legs.

Booster Seat (Group 2)

Secure children that weigh more than 33 lb (15 kg) but are less than 59.06 in (150 cm) tall in a booster seat or a booster cushion.

We recommend that you use a booster seat that combines a cushion with a backrest instead of a booster cushion only. The raised seating position will allow you to position the shoulder strap of the adult safety belt over the center of your child’s shoulder and the lap strap tightly across your child's hips.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Child Safety

Booster Cushion (Group 3)

ISOFIX Anchor Points

WARNING

Use an anti-rotation device when

using the ISOFIX system. We

recommend the use of a top tether or support leg.

Note: When you are purchasing an ISOFIX seat, make sure that you know the correct mass group and ISOFIX size class for the intended seating locations. See Child Seat Positioning (page 20).

Your vehicle has ISOFIX anchor points that accommodate universally approved ISOFIX child seats.

The ISOFIX system has two rigid attachment arms on the child seat. These attach to anchor points on the second row seats, where the cushion and backrest meet. For child seats with a top tether, tether anchor points are on the rear of the second row seats.

Attaching a Child Seat With Top Tethers

WARNINGS

Do not attach the top tether strap to anything other than the correct top tether strap anchor point.

Make sure that the top tether strap is not slack or twisted and is properly located on the anchor point.

Follow the child seat manufacturer’s instructions for installing a child seat with a top tether.

Top Tether Anchor Points

Compact C-MAX

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Child Safety

WARNING

If your vehicle is equipped with the comfort seat system, slide the

second row seat forwards to gain access to the anchor points. After installing the ISOFIX seat, do not move the seat to the comfort position as it could interfere with the tether strap routing.

Grand C-MAX

The top tether anchor points are located on the back of the rear seat.

Attaching a Child Seat With a Support Leg

WARNINGS

Make sure the support leg is long

enough to reach the vehicle floor.

Make sure that the child seat

manufacturer lists your vehicle as

suitable for use with this type of child seat.

Follow the child seat manufacturer's instructions for installing a child seat with a support leg.

CHILD SEAT POSITIONING

WARNINGS

See an authorized dealer for the latest details relating to our recommended child seats.

Extreme Hazard! Never use a rearward facing child restraint on a

seat protected by an active airbag in front of it. Death or serious injury to the child can occur.

If you use a child seat that has a

support leg, make sure the support

leg rests securely on the floor.

If you use a child seat and a safety

belt, make sure that the safety belt

is not slack or twisted.

Make sure the child seat rests tightly

against the vehicle seat. If necessary,

adjust the seat backrest to an upright position. It may also be necessary to lift or remove the head restraint. See Head Restraints (page 104).

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Child Safety

WARNINGS

You must reinstall the head restraint following the removal of the child seat. See Head Restraints (page

104).

Note: When using a child seat on a front seat, always adjust the front passenger seat as far back as possible. If it proves difficult to tighten the lap section of the safety belt without slack remaining, adjust the seat backrest to the fully upright position and raise the height of the seat. See Seats (page 104).

Mass group categories

Seating positions

3210+0

46 - 79 lbs

(22 - 36 kg)

33 - 55 lbs

(15 - 25 kg)

20 - 40 lbs

(9 - 18 kg)

Up to 29

lbs (13 kg)

Up to 22

lbs (10 kg)

UF¹UF¹UF¹XX

Front passenger seat with airbag ON

U¹U¹U¹U¹U¹

Front passenger seat with airbag OFF

UUUUURear seats

X Not suitable for children in this mass group. U Suitable for universal category child seats approved for use in this mass group. U¹ Suitable for universal category child seats approved for use in this mass group. We

recommend that you secure children in a government approved child seat, on a rear seat. UF¹ Suitable for universal category forward facing child seats approved for use in this

mass group. We recommend that you secure children in a government approved child seat, on a rear seat.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Child Safety

ISOFIX Child Seats

Mass group categories

Seating positions

10+0

Rear-

ward

facing

Forward

facing

Rearward facing

20 - 40 lbs (9 - 18

kg)

Up to 29 lbs (13 kg)

No ISOFIX

Size class

Front passenger seat

Size type

C, D

A, B, B1

C, D, E

Size class

Rear outboard seat ISOFIX

IL2, IUF

Size type

No ISOFIX

Size class

Rear center seat

Size type

IL Suitable for use with particular ISOFIX child restraints systems in the semi-universal category. Refer to the child restraint system manufacturer vehicle recommendation list for additional information.

IUF Suitable for use with forward facing ISOFIX child restraints systems in the universal category.

The capital letters A to G define the ISOFIX size class for both universal and semi-universal

child restraints systems. You can see the identification letters on ISOFIX child restraints.

At the time of going to print, the recommended Group O+ ISOFIX baby safety seat is the

Britax Roemer Baby Safe.

At the time of going to print, the recommended Group 1 ISOFIX child seat is the Britax

Roemer Duo.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Child Safety

i-Size Child Seats

Rear center seatRear outboard seatsFront passenger seat

Xi-UXi-Size Child Restraint

Systems

i-U Suitable for use with forward and rearward facing i-Size child restraint systems. X Not suitable for use with i-Size child restraint systems.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Child Safety

CHILD SAFETY LOCKS VEHICLES WITH: MECHANICAL CHILD PROOF LOCKS

When these locks are set, the rear doors cannot be opened from the inside.

The childproof locks are located on the rear edge of each rear door and must be set separately for each door.

Left-Hand Side

Turn counterclockwise to lock and clockwise to unlock.

Right-Hand Side

Turn clockwise to lock and counterclockwise to unlock.

CHILD SAFETY LOCKS VEHICLES WITH: REMOTE CHILD PROOF LOCKS

Press the switch to turn them on.

Note: You cannot use the rear power window switches with the child safety locks on.

Press the switch again to turn them off.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Child Safety

FASTENING THE SAFETY BELTS

WARNINGS

You have not fastened the safety belt correctly if you do not hear a

distinct click. Failure to fasten the safety belt correctly could reduce its effectiveness and increase the risk of injury in a crash.

Make sure that your safety belt is

securely stored away and is not

outside your vehicle when closing the door. Failure of an occupant to be able to use a trapped safety belt increases the risk of serious personal injury or death.

Pull the safety belt out steadily. It may lock if you pull it sharply or if your vehicle is on a slope.

Insert the tongue into the buckle until you hear a distinct click.

To release the safety belt press the red button on the buckle. Hold the tongue and let the safety belt retract to its stowed position.

Using Safety Belts During Pregnancy

WARNING

Position the safety belt correctly for your safety and that of your unborn

child. Do not use only the lap strap or the shoulder strap. Failure to adjust the safety belt correctly could reduce its effectiveness and increase the risk of injury in a crash.

Pregnant women should always wear their safety belt. The lap belt portion of a combination lap and shoulder belt should be positioned low across the hips below the belly and worn as tight as comfort will allow. The shoulder belt portion of a combination lap and shoulder belt should be positioned to cross the middle of the shoulder and the center of the chest.

SAFETY BELT HEIGHT ADJUSTMENT

WARNING

Position the safety belt height

adjusters so that the belt rests

across the middle of your shoulder. Failure to adjust the safety belt correctly could reduce the effectiveness of the safety belt and increase the risk of injury in a crash.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Safety Belts

To adjust the shoulder belt height, squeeze the button and slide the height adjuster up or down. Release the button and pull down on the height adjuster to make sure it is locked in place.

SAFETY BELT MINDER

WARNING

The system will only provide protection when you use the safety belt correctly.

The warning lamp illuminates and an audible warning will sound when the following conditions have been met:

• The front safety belts have not been fastened.

• Your vehicle exceeds a relatively low speed.

It will also illuminate and sound if a front safety belt is unfastened when your vehicle is moving.

If you do not fasten your safety belt the warning switches off automatically after approximately five minutes.

Turning the Safety Belt Minder Off

Contact an authorized dealer.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Safety Belts

PRINCIPLE OF OPERATION

WARNINGS

Extreme Hazard! Never use a rearward facing child restraint on a

seat protected by an active airbag in front of it. Death or serious injury to the child can occur.

Do not modify the front of your

vehicle in any way. This could

adversely affect deployment of the airbags. Failure to adhere to this warning could result in serious personal injury or death.

Wear a safety belt and keep

sufficient distance between yourself

and the steering wheel. Only when you use the safety belt correctly, can it hold you in a position that allows the airbag to achieve its optimum effect. See Sitting in the Correct Position (page 104). Failure to adhere to this warning could result in serious personal injury or death.

Repairs to the steering wheel,

steering column, seats, airbags and

safety belts must be carried out by an authorized dealer. Failure to adhere to this warning could result in serious personal injury or death.

Keep the areas in front of the airbags

free from obstruction. Do not affix

anything to or over the airbag covers. In the event of a crash, hard objects could cause serious personal injury or death.

Do not puncture the seat with sharp

objects. This could damage and

adversely affect deployment of the airbags. Failure to adhere to this warning could result in serious personal injury or death.

Use seat covers designed for seats

with side airbags. Have these fitted

by an authorized dealer. Failure to adhere to this warning could result in serious personal injury or death.

Note: You will hear a loud bang and see a cloud of harmless powdery residue if an airbag deploys. This is normal.

Note: Only wipe airbag covers with a damp cloth.

DRIVER AIRBAG

The airbag will deploy during significant frontal collisions or collisions that are up to 30 degrees from the left or the right. The airbag will inflate within a few thousandths of a second and deflate on contact with the occupant, thus cushioning forward body movement. During minor frontal collisions, overturns, rear collisions and side collisions, the airbag will not deploy.

PASSENGER AIRBAG

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Supplementary Restraints System

The passenger airbag will deploy during significant frontal or near-frontal collisions. The airbag will inflate within a few thousandths of a second and deflate on contact with the occupant, thus cushioning forward body movement. During minor frontal collisions, overturns, rear collisions and side collisions, the front passenger airbag will not deploy.

SIDE AIRBAGS

WARNING

Use seat covers designed for seats with side airbags. Have these fitted by an authorized dealer.

The airbags are located inside the seatback of the front seats. There is a label attached to the side of the seatback to indicate this.

The airbag will deploy during significant lateral collisions. It might also deploy during significant frontal collisions. The airbag will not deploy in minor lateral and frontal collisions, rear collisions, or overturns.

SIDE CURTAIN AIRBAGS

The airbags are located over the front and rear side windows.

The airbag will deploy during significant lateral collisions. It will also deploy during significant frontal angled collisions. The curtain airbag will not deploy in minor lateral and frontal collisions, rear collisions, or overturns.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Supplementary Restraints System

GENERAL INFORMATION ON RADIO FREQUENCIES

Note: Changes or modifications not

expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

The typical operating range for your transmitter is approximately 33 ft (10 m).

A decrease in operating range could be caused by:

• weather conditions

• nearby radio towers

• structures around your vehicle

• other vehicles parked next to your

vehicle.

The radio frequency used by your remote control can also be used by other radio transmitters, for example amateur radios, medical equipment, wireless headphones, wireless remote controls, cell phones, battery chargers and alarm systems. If the frequencies are jammed, you will not be able to use your remote control. You can lock and unlock the doors with the key.

Note: Make sure your vehicle is locked before leaving it unattended.

Note: If you are in range, the remote control will operate if you press any button unintentionally.

Note: The remote control contains sensitive electrical components. Exposure to moisture or impact may cause permanent damage.

REMOTE CONTROL - VEHICLES WITH: KEYLESS ENTRY

Intelligent Access Key

Key Blade

The intelligent access key also contains a removable key blade that you can use to unlock your vehicle.

To release the key blade:

1. Press and hold the buttons on the edges to release the cover. Carefully remove the cover.

2. Remove the key blade.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Keys and Remote Controls

Programming a New Remote Control

To program an additional remote control See Security (page 48).

Changing the Remote Control Battery

Make sure that you dispose of old batteries in an

environmentally friendly way. Seek advice from your local authority regarding recycling.

1. Press and hold the buttons on the

edges to release the cover. Carefully remove the cover.

2. Remove the key blade.

3. Use a suitable tool, for example a screwdriver, to carefully seperate the two halves of the remote control.

4. Twist the screwdriver in the position shown to separate the two halves of the remote control.

Note: Do not touch the battery contacts or the printed circuit board with the screwdriver.

5. Carefully prise out the battery with the screwdriver.

6. Install a new battery (3V CR 2032) with the + facing downwards.

7. Assemble the two halves of the remote control.

8. Reinstall the key blade.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Keys and Remote Controls

Note: Do not wipe off any grease on the

battery terminals or on the back surface of the circuit board.

Note: Replacing the battery does not delete the transmitter from the vehicle. The transmitter should operate normally.

Locating Your Vehicle

Press the lock button on the key twice within three seconds. The horn may sound and the direction indicators flash.

The horn may sound twice and the direction indicators do not flash if:

• Locking was not successful.

• Any door or the liftgate is open.

• The hood is open on vehicles with an

anti-theft alarm or remote start.

REMOTE CONTROL - VEHICLES WITH: REMOTE FLIP KEY

Programming a New Remote Control

Contact an authorized dealer.

Reprogramming the Unlocking Function

Note: When you press the unlock button,

either all the doors are unlocked or only the driver door is unlocked. Pressing the unlock button again unlocks all the doors.

Press and hold the unlock and lock buttons on the remote control simultaneously for at least four seconds with the ignition off. The direction indicators flash twice to confirm the change.

To return to the original unlocking function, repeat the process.

Changing the Remote Control Battery

The remote control uses one coin-type three-volt lithium battery CR2032 or equivalent.

Make sure that you dispose of old batteries in an

environmentally friendly way. Seek advice from your local authority about recycling old batteries.

1. Insert a suitable tool, for example a

screwdriver, in the position shown and gently push the clip.

2. Press the clip down to release the

battery cover.

3. Carefully remove the battery cover.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Keys and Remote Controls

Note: Do not touch the battery contacts or

the printed circuit board with the screwdriver.

4. Turn the remote control over to remove the battery.

5. Install a new battery with the + facing upward.

6. Reinstall the battery cover.

Note: Do not wipe off any grease on the battery terminals or on the back surface of the circuit board.

Note: You do not need to reprogram the remote control after you have replaced its battery, it should operate normally.

Locating Your Vehicle

Press the lock button on the key twice within three seconds. The direction indicators flash.

The direction indicators do not flash if:

• Locking was not successful.

• Any door or the liftgate is open.

• The hood is open on vehicles with an

anti-theft alarm.

REPLACING A LOST KEY OR REMOTE CONTROL

You can purchase replacement keys or remote controls from an authorized dealer. Authorized dealers can program remote controls for your vehicle. See Replacing a Lost Key or Remote Control (page 32).

To re-program the passive anti-theft system see an authorized dealer.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Keys and Remote Controls

PRINCIPLE OF OPERATION

The system allows you to program keys with restricted driving modes to promote good driving habits. You can use all but one of the keys programmed to your vehicle with these restricted modes.

Any keys that have not been programmed are referred to as an administrator key or admin key. These can be used to:

• Create a MyKey.

• Program configurable MyKey settings.

• Clear all MyKey features.

When you have programmed a MyKey, you can access the following information using the information display:

• How many admin keys and MyKeys are programmed to your vehicle.

• The total distance your vehicle has traveled using a MyKey.

Note: All MyKeys are programmed to the same settings. You cannot program them individually.

Note: For vehicles with push-button start, when both a MyKey and an admin remote transmitter are present, the admin remote transmitter will be recognized by the vehicle while switching the ignition on to start the vehicle.

Non-Configurable Settings

The following settings cannot be changed:

• Safety belt minder. You cannot disable this feature. The audio system will mute when this feature is activated.

• Low fuel level warning. When the fuel level is low, warnings will be shown in the display followed by an audible tone.

• Driver assist features, for example traction control, navigation and parking aids. These systems turn on automatically whenever you switch the ignition on.

Configurable Settings

You can configure MyKey settings when you first create a MyKey. You can also change the settings afterward with an admin key.

The following settings can be configured using an admin key:

• Various vehicle speed limits can be set. Warnings will be shown in the display followed by an audible tone when your vehicle reaches the set speed. You cannot override the set speed by fully depressing the accelerator pedal.

WARNING

Do not set MyKey maximum speed limit to a limit that will prevent the

driver from maintaining a safe speed considering posted speed limits and prevailing road conditions. The driver is always responsible to drive in accordance with local laws and prevailing conditions. Failure to do so could result in accident or injury.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

MyKey™

• Various vehicle speed reminders can be set. Warnings will be shown in the display followed by an audible tone when the set vehicle speed is exceeded.

• Audio system maximum volume of 45%. A message will be shown in the display when you attempt to exceed the limited volume. Automatic volume control will be disabled.

• Always on setting. When this is selected you will not be able to disable emergency assistance or the do not disturb feature.

Note: If a MyKey and an admin key are present, your vehicle will recognize the admin key only.

CREATING A MYKEY

Vehicles without Keyless Starting

1. Insert the key you want to program into the ignition.

2. Switch the ignition on.

3. Access the main menu using the information display. Select MyKey and press OK or the right arrow button.

4. Select Create MyKey and press OK.

5. When prompted, press and hold OK until you see a message informing you to label this key as a MyKey. The key will be restricted the next time you use it.

Note: Make sure you label the MyKey so you can distinguish it from the admin keys.

Vehicles with Keyless Starting

1. Switch the ignition on using an admin key.

2. Access the main menu using the information display. Select MyKey and press OK or the right arrow button.

3. Place the key into the backup position. The location of your backup position is in another chapter. See Starting and Stopping the Engine (page 118).

4. Select Create MyKey and press OK.

5. When prompted, press and hold OK until you see a message informing you to label this key as a MyKey. The key will be restricted the next time you use it.

Note: Make sure you label the MyKey so you can distinguish it from the admin keys.

CLEARING ALL MYKEYS

You can clear or change your MyKey settings using the information display control on the steering wheel. See Information Displays (page 80).

Switch the ignition on using an admin key or fob.

To clear all MyKeys of all MyKey settings, press the left arrow button to access the main menu and scroll to:

Action and DescriptionMessage

Press the OK button.Settings

Press the OK button.MyKey

Press and hold the OK button until the following message displays.

Clear MyKey

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

MyKey™

Action and DescriptionMessage

All MyKeys

Cleared

Note: When you clear your MyKeys, you remove all restrictions and return all MyKeys to their original admin key status.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

MyKey™

CHECKING MYKEY SYSTEM STATUS

You can find information about your programmed MyKeys by using the information display.

MyKey Distance

Tracks the distance when drivers use a MyKey. The only way to delete the accumulated distance is by using an admin key to clear all MyKeys. If the distance does not accumulate as expected, then the intended user is not using the MyKey, or an admin key user recently cleared and then recreated a MyKey.

Number of MyKeys

Indicates the number of MyKeys programmed to your vehicle. Use this feature to detect how many MyKeys you have for your vehicle and determine when all MyKeys have been deleted.

Number of Admin Keys

Indicates how many admin keys are programmed to your vehicle. Use this feature to determine how many admin keys you have for your vehicle, and detect if an additional MyKey has been programmed.

USING MYKEY WITH REMOTE START SYSTEMS

MyKey is not compatible with non Ford-approved, aftermarket remote start systems. If you choose to install a remote start system, see an authorized dealer for a Ford-approved remote start system.

MYKEY TROUBLESHOOTING

Potential CausesCondition

The key used to start the vehicle is not an admin key.I cannot create a MyKey. The key used to start the vehicle is the only key. There always has to be at least one admin key. Vehicles with keyless start: The keyless start transmitter is not placed in the backup position. See Starting and Stopping the Engine (page 118). The passive anti-theft system is disabled.

The key used to start the vehicle is not an admin key.I cannot program the

configurable settings. There are no MyKeys programmed to your vehicle. See

Creating a MyKey (page 34).

The key used to start the vehicle is not an admin key.I cannot clear the MyKeys. There are no MyKeys programmed to your vehicle. See Creating a MyKey (page 34).

Purchase a new key from an authorized dealer.I lost the only admin key.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

MyKey™

Potential CausesCondition

Program a spare key. See Passive Anti-Theft System (page 48).

I lost a key.

The MyKey is not being used by the intended user.The MyKey distance does

not accumulate. The MyKeys have been cleared. See Clearing All MyKeys

(page 34).

An admin transmitter is present at vehicle start.No MyKey functions with the

keyless entry transmitter. No MyKeys are created. See Creating a MyKey (page

34).

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

MyKey™

LOCKING AND UNLOCKING

Power Door Locks

The power door lock control is on the driver door.

Unlock.A Lock.B

Remote Control

You can use the remote control at any time while your vehicle is switched off.

Unlocking the Doors

Press the button to unlock all doors. The direction indicators will flash.

Note: You can unlock the driver's door with the key. Use the key when the remote control is not functioning.

Note: When you lock your vehicle for several weeks, the remote control will be switched off. Your vehicle must be unlocked and started. Unlocking and starting your vehicle once will enable the remote control.

Reprogramming the Unlocking Function

You can reprogram the unlocking function so that only the driver door is unlocked. See Remote Control (page 29).

Locking the Doors

Press the button to lock all the doors. The direction indicators will flash.

Note: If any door or the luggage compartment is not closed, or if the hood is not closed on vehicles that have an anti-theft alarm or remote start, the direction indicators will not flash.

Double Locking the Doors

WARNING

Do not use double locking when passengers or animals are inside your

vehicle. You will not be able to unlock the doors from the inside if you have double locked them.

Double locking is a theft protection feature that prevents someone from opening the doors from the inside. You can only double lock the doors if they are all closed.

Press the button twice within three seconds.

Automatic Relocking

The doors will automatically relock if you do not open a door within 45 seconds of unlocking the doors with the remote control. The door locks and the alarm will return to their previous state.

Locking and Unlocking the Doors from Inside

Use the lock and unlock buttons located on the driver door.

Locking and Unlocking the Doors with the Key

Locking with the Key

Turn the top of the key toward the front of your vehicle.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Locks

Double Locking with the Key

Turn the key to the lock position twice within three seconds.

Unlocking with the Key

Turn the top of the key toward the rear of your vehicle.

Note: If the child safety locks are on and you pull the interior handle, you will only turn off the emergency locking, not the child safety lock. You can only open the doors using the external door handle.

Locking and Unlocking the Doors Individually with the Key

Locking

If the central locking function fails to operate, lock the doors individually using the key in the position shown.

Left-Hand Side

Turn clockwise to lock.

Right-Hand Side

Turn counterclockwise to lock.

Unlocking

If the central locking function fails to operate, unlock the driver door and then unlock all other doors individually by pulling the interior door handles.

Note: If the doors have been unlocked using this method, the doors must be locked individually until the central locking function has been repaired.

Opening the Liftgate

With the Remote Control

Press the button twice within three seconds.

From Outside Your Vehicle

Press the release button above the license plate to unlatch the liftgate. Your vehicle must be unlocked or have an intelligent access transmitter within 3 ft (1 m) of the liftgate.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Locks

SLIDING DOOR

When the rear doors are fully open, make sure that you do not step on the cable or mechanism at the base of the door aperture.

MANUAL LIFTGATE COMPACT MAV (5-SEATER)

WARNINGS

It is extremely dangerous to ride in a cargo area, inside or outside of a

vehicle. In a crash, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts. Make sure everyone in your vehicle is in a seat and properly using a safety belt. Failure to follow this warning could result in serious personal injury or death.

WARNINGS

Make sure to close and latch the liftgate to prevent drawing exhaust

fumes into your vehicle. This will also prevent passengers and cargo from falling out. If you must drive with the liftgate open, keep the vents or windows open so outside air comes into your vehicle. Failure to follow this warning could result in serious personal injury.

Note: Be careful when opening or closing the liftgate in a garage or other enclosed area to avoid damaging the liftgate.

Note: Do not hang anything, for example a bike rack, from the glass or liftgate. This could damage the liftgate and its components.

Note: Do not leave the liftgate open while driving. This could damage the liftgate and its components.

Opening the Liftgate

Manually

Press the release button above the license plate to unlatch the liftgate.

With the Remote Control

Press the button twice within three seconds.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Locks

Closing the Liftgate

A handle is located inside the liftgate to help with closing.

MANUAL LIFTGATE - GRAND MAV (5+2 SEATER)

WARNINGS

It is extremely dangerous to ride in a cargo area, inside or outside of a

vehicle. In a crash, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts. Be sure everyone in your vehicle is in a seat and using a safety belt properly. Failure to follow this warning could result in serious personal injury or death.

Make sure to close and latch the

liftgate to prevent drawing exhaust

Note: Be careful when opening or closing the liftgate in a garage or other enclosed area to avoid damaging the liftgate.

Note: Do not hang anything, for example a bike rack, from the glass or liftgate. This could damage the liftgate and its components.

Note: Do not leave the liftgate open while driving. This could damage the liftgate and its components.

Opening the Liftgate

Manually

Press the button located in the top of the liftgate pull cup handle to unlatch the liftgate, and then pull on the outside handle.

With the Remote Control

Press the button twice within three seconds.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Locks

Closing the Liftgate

A handle is located inside the liftgate to help with closing.

POWER LIFTGATE

WARNINGS

It is extremely dangerous to ride in a cargo area, inside or outside of a

Make sure to close and latch the

liftgate to prevent drawing exhaust

Keep keys out of reach of children.

Do not allow children to operate or

play near an open or moving power liftgate. You should supervise the operation of the power liftgate at all times.

Note: Make sure that you close the liftgate before operating or moving the vehicle, especially in an enclosure, like a garage or a parking structure. You could damage the liftgate or its components.

Note: Do not hang anything, for example a bike rack, from the spoiler, glass or liftgate. This could damage the liftgate and its components.

The liftgate only operates with the transmission in park (P).

One warning tone sounds as the liftgate begins to power close. Three short chimes indicate a problem with the open or close request, caused by:

• The ignition is on and the transmission is not in park (P).

• The battery voltage is below the minimum operating voltage.

• The vehicle speed is at or above 3 mph (5 km/h).

If the liftgate starts to close after it has fully opened, this indicates there may be excessive weight on the liftgate or a possible gas strut failure. A repetitive chime sounds and the liftgate closes under control. Remove any excessive weight from the liftgate. If the liftgate continues to close after opening, have the system checked by an authorized dealer.

Opening and Closing the Liftgate

WARNING

Make sure all persons are clear of the power liftgate area before using the power liftgate control.

Note: Be careful when opening or closing the liftgate in a garage or other enclosed area to avoid damaging the liftgate.

Note: Do not leave the liftgate open while driving. This could damage the liftgate and its components.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Locks

From the Instrument Panel

Press the button on the instrument panel.

With the Remote Control

Press the button twice within three seconds.

With the Outside Control Button

Opening the Liftgate

1. Unlock the liftgate with the remote control or power door unlock control. If an intelligent access key is within 3 ft (1 m) of the liftgate, the liftgate unlocks when you press the liftgate release button.

2. Press the control button located in the top of the liftgate pull-cup handle.

Note: Allow the power system to open the liftgate. Manually pushing or pulling the liftgate may activate the system’s obstacle detection feature and stop the power operation or reverse its direction. Manually interfering with the liftgate motion may also replicate a gas strut failure.

Closing the Liftgate

WARNING

Keep clear of the liftgate when activating the rear switch.

Press and release the button.

Stopping the Liftgate Movement

You can stop the liftgate movement by doing any of the following:

• Pressing the liftgate control button.

• Pressing the liftgate button on the

remote control twice.

• Pressing the liftgate button on the instrument panel.

• Pressing the exterior liftgate release button.

• Activating the obstacle detection feature.

• Moving your foot under and away from the center rear bumper in a single-kick motion.

This method only works for vehicles with

the hands-free liftgate feature.

Setting the Liftgate Open Height

1. Open the liftgate.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Locks

2. Stop the liftgate movement by pressing the control button on the liftgate when it reaches the desired height.

Note: Once the liftgate has stopped moving, you can also manually move it to the desired height.

3. Press and hold the liftgate control button on the liftgate until you hear a chime, indicating programming is complete.

Note: You can only use the liftgate control button to program the height.

Note: You cannot program the height if the liftgate position is too low.

The new open liftgate height is recalled when the power liftgate is opened. To change the programmed height, repeat the above procedure. Once you open the power liftgate, you can manually move it to a different height.

Note: The system recalls the new programmed height until you reprogram it, even if you disconnect the battery.

When operating the power liftgate after you have programmed a lower height than full-open, you can fully open the liftgate by manually pushing it upward to the maximum open position.

Obstacle Detection

When Closing

The system stops when it detects an obstacle. Two short tones sound and the system reverses to open. Once you remove the obstacle, you can power close the liftgate.

Note: Entering your vehicle while the liftgate is closing can cause your vehicle to bounce and activate obstacle detection. To prevent this, let the power liftgate close completely before you enter your vehicle. Before driving off, check the instrument cluster for a liftgate or door ajar message or warning indicator. Failure to do this could result in unintentionally leaving the liftgate open while driving.

When Opening

The system stops when it detects an obstacle and two short tones sound. Once you remove the obstacle, you can continue to operate the liftgate.

HANDS-FREE POWER LIFTGATE

WARNINGS

It is extremely dangerous to ride in a cargo area, inside or outside of a

Make sure to close and latch the

liftgate to prevent drawing exhaust

Keep keys out of reach of children.

Do not allow children to play near an

open or moving power liftgate.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Locks

Note: Do not hang anything, for example

a bike rack, from the glass or liftgate. This could damage the liftgate and its components.

Note: Be careful when opening or closing the liftgate in a garage or other enclosed area to avoid damaging the liftgate.

Note: Stand clear of the liftgate area once the power liftgate begins to open or close.

Opening and Closing the Liftgate

The intelligent access key must be within 3 ft (1 m) of your vehicle.

1. Move your foot under and away from the rear bumper detection area in a single-kick motion. Do not move your foot sideways or the sensors may not detect the motion.

2. The liftgate opens or closes automatically.

Note: Allow the power system to open or close the liftgate. Manually pushing or pulling the liftgate may activate the obstacle detection feature and stop the power operation.

Note: Splashing water may cause the hands-free liftgate to open. Keep the intelligent access key away from the rear bumper detection area while washing your vehicle.

Note: Switching the ignition on or off while the liftgate is closing may cause the liftgate to reverse to the fully open position.

Note: You can also open or close the power liftgate using the remote control or power liftgate control buttons. See Power Liftgate (page 42).

Setting the Liftgate Open Height

See Power Liftgate (page 42).

KEYLESS ENTRY

General Information

The system will not function if:

• Your vehicle battery has no charge.

• The passive key battery has no charge.

• The passive key frequencies are

jammed.

Note: If the system does not function, you will need to use the key blade to lock and unlock your vehicle.

The system allows you to operate your vehicle without the use of a key or remote control.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Locks

Passive locking and unlocking requires a valid passive key to be located within one of the three external detection ranges. These are located approximately five feet (1.5 meters) from the front door handles and the liftgate.

Note: The system may not function if the passive key is close to metal objects or electronic devices, for example keys or a cell phone.

Passive Key

Your vehicle can be locked and unlocked using the passive key. You can also use the passive key as a remote control to lock and unlock your vehicle. See Locking and

Unlocking (page 38).

Locking Your Vehicle

Note: Your vehicle does not automatically

lock. If you do not touch a locking sensor your vehicle will remain unlocked.

Locking buttons are located on each of the front doors.

For central locking and to arm the alarm, press a locking button once.

For double locking and to arm the alarm, press a locking button twice within three seconds.

Note: When locking your vehicle, do not grip the door handle.

Note: Keep the door handle surface clean to make sure the system operates correctly.

Note: Your vehicle will remain locked for approximately one second. When the delay period is over, you can open the doors again, provided the passive key is within the respective detection range.

Two short flashes of the direction indicators confirms that all the doors and the liftgate have been locked and that the alarm has been armed.

Liftgate

The liftgate cannot be closed and will reopen if the passive key is located inside the luggage compartment with the doors locked.

Note: If a second valid passive key is located within the liftgate detection range, the liftgate can be closed.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Locks

Unlocking Your Vehicle

Pull an exterior door handle to unlock and open the door. Do not touch the lock sensor on the front of the handle.

One long flash of the direction indicators confirms that all the doors and the liftgate have been unlocked and that the alarm has been disarmed.

Note: A valid passive key must be located within the detection range of that door.

Unlocking Only the Driver's Door

You can program the system so that only the driver door is unlocked. See Locking and Unlocking (page 38).

If the unlocking function is reprogrammed so that only the driver door is unlocked the following will occur:

• If the driver’s door is the first door which is opened, the other doors will remain locked. All the other doors can be unlocked from inside your vehicle by pressing the unlock button located on the driver's and front passenger's door. Doors can be unlocked individually by pulling the interior door handles on those doors.

• If the front passenger's door is the first door which is opened, all the doors and the liftgate will be unlocked.

Disabled Keys

Any keys left inside your vehicle interior when it is locked will be disabled.

You cannot use a disabled key to switch the ignition on or start the engine.

You must enable all passive keys again in order to use them. To enable all your passive keys, unlock your vehicle using a passive key that has not been disabled or the remote control unlocking function. All passive keys will then be enabled if you switch the ignition on or you start your vehicle with a valid key.

Note: You can still start your vehicle when the passive key is in the back-up position. See Push Button Ignition Switch (page

118).

Locking and Unlocking the Doors with the Key Blade

1. Carefully remove the cover.

2. Remove the key blade and insert it into the lock.

Note: Only the driver's door handle has a lock cylinder.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Locks

PASSIVE ANTI-THEFT SYSTEM

Principle of Operation

The system prevents someone from starting the engine with an incorrectly coded key.

Note: Do not leave correctly coded keys in the vehicle. Always take your keys and lock all doors when leaving the vehicle.

Coded Keys

If you lose a key, you can obtain a replacement from an authorized dealer. If possible, provide them with the key number from the tag provided with the original keys. You can also obtain extra keys from an authorized dealer.

Note: Have all of your remaining keys erased and recoded if you lose a key. Have replacement keys coded together with recoding your remaining keys. See an authorized dealer for further information.

Note: Do not shield your keys with metal objects. This may prevent the receiver from recognizing a coded key.

Arming the Engine Immobilizer

When you switch the ignition off the engine immobilizer will arm automatically after a short time.

Disarming the Engine Immobilizer

When you switch the ignition on the engine immobilizer will disarm automatically if a correctly coded key is used.

If you are unable to start your vehicle with a correctly coded key, have your vehicle checked by an authorized dealer.

ANTI-THEFT ALARM VEHICLES WITH: INTEGRAL BATTERY

Alarm System

WARNING

Do not arm the alarm with full guard if passengers, animals or other moving objects are inside your

vehicle.

Perimeter Alarm

The perimeter alarm is a deterrent against unauthorized access to your vehicle through the doors and the hood.

Interior Sensors

Note: Do not cover up the interior lamp unit

sensors.

The sensors act as a deterrent against unauthorized access by sensing any movement within your vehicle.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Security

Battery Back-up Sounder

The battery back-up sounder is an additional alarm system, which sounds a siren if your vehicle battery or the battery back-up sounder is disconnected. When you lock your vehicle the system is armed. The sounder has its own battery and will sound an alarm siren even if someone disconnects your vehicle battery or the battery back-up sounder itself.

Triggering the Alarm

Once armed, the alarm is triggered in any of the following ways:

• If someone opens a door, the liftgate or the hood without a valid key or remote control.

• If someone removes the audio or navigation system.

• If you switch your vehicle on without a correctly coded key.

• If the interior sensors detect movement within your vehicle.

• On vehicles with a battery back-up sounder, if someone disconnects your vehicle battery or the battery back-up sounder itself.

If the alarm is triggered, the alarm horn will sound for 30 seconds and the hazard warning flasher will flash for five minutes.

Any further attempts to perform one of the above sounds the alarm again.

Full and Reduced Guard

Full Guard

Full guard is the standard setting. In full guard, the interior sensors are on

when you arm the alarm.

Reduced Guard

In reduced guard, the interior sensors are off when you arm the alarm.

Selecting Full or Reduced Guard

You can select full or reduced guard using the information display. See General

Information (page 80).

Ask on Exit (If Equipped)

You can set the information display to ask you each time which level of guard you wish to set.

Using the information display controls, scroll to:

Action and DescriptionMessage

Press the OK button.Settings

Press the OK button.Vehicle settings

Press the OK button.Alarm

Press the OK button.Ask on exit

Appears in the information display each time you switch your vehicle off.

Reduced

If you wish to arm the alarm with reduced guard, press the OK button when this message appears.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Security

Action and DescriptionMessage

If you wish to arm the alarm with full guard, leave your vehicle without pressing the OK button.

Note: Selecting reduced guard does not set the alarm permanently to reduced guard. It sets it to reduced guard only for the current locking cycle.

Arming the Alarm

To arm the alarm, lock your vehicle. See

Locks (page 38).

Disarming the Alarm

Vehicles Without Keyless Entry

Perimeter Alarm

Disarm and silence the alarm by unlocking the doors with the key and switching your vehicle on with a correctly coded key or unlocking the doors with the remote control.

Category One Alarm

Disarm and silence the alarm by unlocking the doors with the key and switching your vehicle on with a correctly coded key within 12 seconds or unlocking the doors with the remote control.

Vehicles with Keyless Entry

Note: A valid passive key must be located

within the detection range of that door for keyless entry. See Keyless Entry (page 45).

Perimeter Alarm

Disarm and silence the alarm by unlocking the doors and switching your vehicle on or unlocking the doors with the remote control.

Category One Alarm

Disarm and silence the alarm by unlocking the doors and switching your vehicle on within 12 seconds or unlocking the doors or the liftgate with the remote control.

ANTI-THEFT ALARM VEHICLES WITH: INTERIOR SENSOR

Alarm System

WARNING

Do not arm the alarm with full guard if passengers, animals or other moving objects are inside your

vehicle.

Perimeter Alarm

The perimeter alarm is a deterrent against unauthorized access to your vehicle through the doors and the hood. It also protects the audio unit.

Interior Sensors

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Security

Note: Do not cover up the interior lamp unit

sensors.

The sensors act as a deterrent against unauthorized intrusion by sensing any movement inside your vehicle.

Triggering the Alarm

Once armed, the alarm is triggered in any of the following ways:

• If someone opens a door, the liftgate or the hood without a valid key or remote control.

• If someone removes the audio unit or navigation system.

• If you switch your vehicle on without a correctly coded key.

• If the interior sensors detect movement within your vehicle.

If the alarm is triggered, the alarm horn will sound for 30 seconds and the hazard warning flasher will flash for five minutes.

Any further attempts to perform one of the above will trigger the alarm again.

Full and Reduced Guard

Full Guard

Full guard is the standard setting. In full guard, the interior sensors are on

when you arm the alarm.

Reduced Guard

In reduced guard, the interior sensors are off when you arm the alarm.

Selecting Full or Reduced Guard

You can select full or reduced guard using the information display. See General

Information (page 80).

Ask on Exit (If Equipped)

You can set the information display to ask you each time which level of guard you wish to set.

Using the information display controls, scroll to:

Action and DescriptionMessage

Press the OK button.Settings

Press the OK button.Vehicle settings

Press the OK button.Alarm

Press the OK button.Ask on exit

Appears in the information display each time you switch your vehicle off.

Reduced guard

If you wish to arm the alarm with reduced guard, press the OK button when this message appears. If you wish to arm the alarm with full guard, leave your vehicle without pressing the OK button.

Note: Selecting reduced guard does not set the alarm permanently to reduced guard. It sets it to reduced guard only for the current locking cycle.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Security

Arming the Alarm

To arm the alarm, lock your vehicle. See

Locks (page 38).

Disarming the Alarm

Vehicles Without Keyless Entry

Disarm and silence the alarm by unlocking the doors with the key and switching your vehicle on with a correctly coded key or unlocking the doors with the remote control.

Vehicles with Keyless Entry

Note: A valid passive key must be located

within the detection range of that door for keyless entry. See Keyless Entry (page 45).

Disarm and silence the alarm by unlocking the doors and switching your vehicle on or unlocking the doors with the remote control.

ANTI-THEFT ALARM VEHICLES WITH: PERIMETER ALARM

The perimeter alarm is a deterrent against unauthorized access to your vehicle through the doors and the hood. It also protects the audio unit.

If the alarm is triggered, the alarm horn will sound and the hazard warning flasher will flash.

Take all remote controls to an authorized dealer if there is any potential alarm problem with your vehicle.

Arming the Alarm

To arm the alarm, lock your vehicle. See

Locks (page 38).

Disarming the Alarm

Vehicles Without Keyless Entry

Disarm and silence the alarm by unlocking the doors with the key and switching your vehicle on with a correctly coded key or unlocking the doors with the remote control.

Vehicles With Keyless Entry

Note: A valid passive key must be located

within the detection range of that door for keyless entry. See Keyless Entry (page 45).

Disarm and silence the alarm by unlocking the doors and switching your vehicle on or unlocking the doors with the remote control.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Security

ADJUSTING THE STEERING WHEEL

WARNING

Do not adjust the steering wheel when your vehicle is moving.

Note: Make sure that you are sitting in the correct position. See Sitting in the Correct Position (page 104).

1. Unlock the steering column.

2. Adjust the steering wheel to the desired position.

3. Lock the steering column.

AUDIO CONTROL

Select the required source on the audio unit.

You can operate the following functions with the control:

Type One

Volume up.A Seek up or next.B Volume down.C Seek down or previous.D

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Steering Wheel

Type Two

Volume up.A Seek up or next.B Volume down.C Seek down or previous.D Press to select source.E

Seek, Next or Previous

Press the seek button to:

• Tune the radio to the next or previous stored preset.

• Play the next or the previous track.

Press and hold the seek button to:

• Tune the radio to the next station up or down the frequency band.

• Seek through a track.

VOICE CONTROL

Press the button to select or deselect voice control. See Using Voice Recognition (page 301).

CRUISE CONTROL

Type 1

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Steering Wheel

Type 2

See Cruise Control (page 158).

INFORMATION DISPLAY CONTROL

See General Information (page 80).

HEATED STEERING WHEEL

Press the button to switch the system on. The LED on the switch illuminates when the system is on.

Note: The system only operates when the engine is running.

Press the button to switch the system off. The system automatically controls the

temperature to avoid overheating. Under high interior temperature conditions,

there may be no perceived warming. This is normal and is not a sign of a system fault.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Steering Wheel

WINDSHIELD WIPERS

Note: Fully defrost the windshield before

you switch the windshield wipers on. Note: Make sure you switch the windshield

wipers and vehicle power off before using an automatic car wash.

Note: If streaks or smears appear on the windshield, clean the windshield and the wiper blades. See Checking the Wiper Blades (page 241). If that does not resolve the issue, install new wiper blades. See Changing the Wiper Blades (page 241).

Note: Do not operate the wipers on a dry windshield. This may scratch the glass, damage the wiper blades or cause the wiper motor to burn out. Always use the windshield washers before wiping a dry windshield.

Single wipe.A Intermittent wipe.B Normal wipe.C High-speed wipe.D

Note: Move to position O marked on the wiper lever to switch off.

Intermittent Wipe

Short-wipe interval.A Intermittent wipe.B Long-wipe interval.C

Push the wiper lever up to switch the wipers on, and then use the rotary control to adjust the intermittent wipe interval.

Speed Dependent Wipers (If Equipped)

When your vehicle speed increases, the interval between wipes decreases.

AUTOWIPERS

Note: Fully defrost the windshield before

switching on the windshield wipers. Note: Check your wipers before you enter

a car wash to make sure you switched them off.

The autowipers feature uses a rain sensor. You can find it in the area around the interior mirror. The rain sensor monitors the amount of moisture on the windshield and automatically turns on the wipers. It adjusts the wiper speed by the amount of moisture that the sensor detects on the windshield.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Wipers and Washers

Highest sensitivity.A On.B Lowest sensitivity.C

Switch the autowipers on by moving the wiper lever up to the first position.

Switch the autowipers off by moving the wiper lever down.

Use the rotary control to adjust the sensitivity of the rain sensor:

• Rotate the control down to low sensitivity, and the wipers turn on when the rain sensor detects a large amount of moisture on the windshield.

• When you move the wiper lever up

to the first position and the autowiper system is on, the autowiper sensitivity setting adjusts the wiper speed according to the moisture on the windshield only.

• When you lower the sensitivity, the

wipers remain in their ready position only. They do not wipe the windshield automatically unless the sensor detects moisture.

• Move the wiper lever position up to

the second position to wipe the windshield on-demand.

• Rotate the control up to high sensitivity, and the wipers turn on when the rain sensor detects a small amount of moisture on the windshield.

• When you set the wiper control to

a higher sensitivity, the wipers wipe the windshield once.

• Remember to move the wiper lever

position up to the second position to wipe the windshield on-demand.

The autowipers feature is active and ready when the wiper lever is in the first position and selected in the information display. You can change the autowipers feature to intermittent wipers through the information display. See General Information (page 80).

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Wipers and Washers

Note: Check your wiper function in the

information display. See General Information (page 80). The autowipers

feature functions only when you select the menu choice in the information display and you move the wiper lever up to the first position. The autowipers feature then remains on in the information display menu until you change it to intermittent wipe.

Note: If you switch autolamps on in conjunction with autowipers, your low beam headlamps turn on automatically when the rain sensor activates the windshield wipers continuously. See Autolamps (page 61).

Keep the outside of the windshield clean. The rain sensor is very sensitive. If the area around the mirror is dirty, then the wipers may operate if dirt, mist or insects hit the windshield.

Wet or winter driving conditions with ice, snow or salty road mist can cause inconsistent and unexpected wiping or smearing. In these conditions, you can do the following to help keep your windshield clear:

• Lower the sensitivity of the autowipers to reduce the amount of smearing.

• Switch to normal or high-speed wipe by moving the wiper lever up.

• Switch the autowipers off and switch intermittent mode on through the information display. See General Information (page 80).

• Switch the autowipers off by moving the wiper lever down.

Note: Clean the windshield and wiper blades if they begin to leave streaks or smears. If that does not resolve the issue, install new wiper blades. See Changing the Wiper Blades (page 241).

WINDSHIELD WASHERS

Note: Do not operate the washers when

the washer reservoir is empty. This may cause the washer pump to overheat.

To operate the washers and spray the windshield, pull the lever toward you. When you release the lever, the wipers will operate for a short time.

REAR WINDOW WIPER AND WASHERS

Rear Window Wiper

Note: Make sure you switch the rear

window wiper and ignition off before using an automatic car wash.

Intermittent wipe.A Low speed wipe.B Off.C

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Wipers and Washers

Press the top of the button to switch intermittent wipe on. Press the top of the button again to switch low speed wipe on. Press the bottom of the button to switch the rear window wiper off.

When you switch on the front wipers and move the gearshift lever to reverse (R), rear intermittent wipe automatically turns on.

Rear Window Washer

Push the lever away from you to operate the rear window washer. When you release the lever, wiping continues for a short period of time.

HEADLAMP WASHERS

When the headlamps are on, the headlamp washers will operate with the windshield washers.

Note: The headlamp washers will not operate every time you use the windshield washers. This is to prevent the washer fluid reservoir from emptying quickly.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Wipers and Washers

GENERAL INFORMATION

Condensation in Lamp Assemblies

Exterior lamps have vents to accommodate normal changes in air pressure.

Condensation can be a natural by-product of this design. When moist air enters the lamp assembly through the vents, there is a possibility that condensation can occur when the temperature is cold. When normal condensation occurs, a fine mist can form on the interior of the lens. The fine mist eventually clears and exits through the vents during normal operation.

Clearing time may take as long as 48 hours under dry weather conditions.

Examples of acceptable condensation are:

• The presence of a fine mist (no streaks, drip marks or large droplets).

• A fine mist covers less than 50% of the lens.

Examples of unacceptable condensation are:

• A water puddle inside the lamp.

• Streaks, drip marks or large droplets

present on the interior of the lens.

If you see any unacceptable condensation, have your vehicle checked by an authorized dealer.

LIGHTING CONTROL

OffA Parking lamps, instrument panel

lamps, license plate lamps and tail lamps

HeadlampsC

High Beams

Push the lever away from you to switch the high beam on.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Lighting

Push the lever forward again or pull the lever toward you to switch the high beams off.

Headlamp Flasher

Slightly pull the lever toward you and release it to flash the headlamps.

AUTOLAMPS

The headlamps will switch on and off automatically in low light situations or during poor weather.

Note: It may be necessary to switch your headlamps on manually in severe weather conditions.

Note: If you have autolamps on, you can only switch the high beam on once autolamps has switched the headlamps on.

Note: If you switch autolamps on in conjunction with autowipers, low beam headlamps will illuminate automatically when the rain sensor activates the windshield wipers continuously.

INSTRUMENT LIGHTING DIMMER

HEADLAMP EXIT DELAY

After you switch the ignition off, you can switch the headlamps on by pulling the direction indicator lever toward you. You will hear a short tone. The headlamps will switch off automatically after three minutes with any door open or 30 seconds after the last door has been closed. You can cancel this feature by pulling the direction indicator toward you again or switching the ignition on.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Lighting

DAYTIME RUNNING LAMPS

WARNING

Always remember to switch your headlamps on in low light situations

or during inclement weather. The system does not activate the tail lamps and may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.

To switch the system on:

1. Switch the ignition on.

2. Switch the lighting control to the off or

autolamp position.

AUTOMATIC HIGH BEAM CONTROL

WARNINGS

The system does not relieve you of

your responsibility to drive with due

care and attention. A manual override may be necessary if the system fails to switch the high beam on or off.

A manual override may be required

when approaching other road users

such as cyclists.

Do not use the system in fog.

In cold and severe weather

conditions the system may not

function. A manual override may be necessary in these cases.

The system may not deactivate the

high beam if the lights of oncoming

vehicles are hidden by obstacles (for example guard rails).

WARNINGS

Check and replace wiper blades regularly to ensure the camera

sensor has a clear view through the windscreen. Replacement wiper blades must be the correct length.

Note: Keep the windscreen free from obstructions such as bird droppings, insects and snow or ice.

Note: Reflective road signs may be detected as oncoming traffic and the headlamps will be switched to low beam.

Note: Always fit Ford Original Parts when replacing headlamp bulbs. Other bulbs may reduce system performance.

The system will automatically switch on high beams if it is dark enough and no other traffic is present. If it detects an approaching vehicle’s headlamps or tail lamps, or street lighting ahead the system will switch off high beam before it can distract other road users. Low beam will remain on.

A camera sensor is centrally mounted behind the windshield of your vehicle. This monitors conditions continuously to decide when to switch the high beams on and off.

Once the system is active the high beam will switch on if:

• It is dark enough to require the use of

high beams and

• there is no traffic or street lighting

ahead and

• vehicle speed is greater than 25 mph

(40 km/h).

The high beam will switch off if:

• The rear fog lamps are switched on.

• The ambient light is high enough that

high beam is not required.

• An approaching vehicle's headlamps

or tail lamps are detected.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Lighting

• Street lighting is detected.

• Vehicle speed falls below 19 mph

(30 km/h).

• The camera sensor is too hot or becomes blocked.

Activating the System

Switch the system on using the information display. See Information Displays (page

80). Turn the switch to the autolamps

position. See Autolamps (page 61).

The indicator will illuminate to confirm when the system is ready to assist.

Manually Overriding the System

Push or pull the lever to switch between high and low beam.

FRONT FOG LAMPS

Press the control to switch the fog lamps on or off.

You can switch the fog lamps on when the lighting control is in any position except off.

REAR FOG LAMPS

WARNINGS

Only use the rear fog lamps when visibility is restricted to less than 164 feet (50 meters).

Do not use the rear fog lamps when it is raining or snowing and visibility is more than 164 feet (50 meters).

Press the control to switch the fog lamps on or off.

You can switch the fog lamps on when either the front fog lamps or low beam headlamps are on.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Lighting

HEADLAMP LEVELING

Note: Vehicles with Xenon headlamps have

automatic headlamp leveling.

Raised headlamp beamsA Lowered headlamp beamsB

Adjust the level of the headlamps according to the load you are carrying in your vehicle.

Recommended Headlamp Leveling Switch Positions

Switch position

Load in luggage

compartment

Load

Second row seatsFront seats

0--1-2

0 (0.5)

--1-2

1 (0.5)

31-2

3 (0.5)

Max

31-2

4 (1.5)

Max

-1

See Vehicle Identification Plate (page 277).

Vehicles with active suspension.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Lighting

CORNERING LAMPS

Headlamp beamA Cornering lamp beamB

The cornering lamps illuminate the inside of a corner when you are turning.

DIRECTION INDICATORS

Push the lever up or down to use the direction indicators.

Note: Tap the lever up or down to make the direction indicators flash three times to indicate a lane change.

INTERIOR LAMPS

The lamps turn on when:

• You open any door.

• You press a remote control button.

• You press the buttons on the map

lamps.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Lighting

Front Interior Lamps (If Equipped)

Note: Press the door function switch to

switch off interior lights when you open any door. The indicator lamp illuminates amber when the door function is off. When the door function is off and you open a door, the courtesy and door lamps stay off. Press the switch again to switch the door function back on. The indicator lamp illuminates white when the door function is on. When the door function is on and you open a door, the courtesy and door lamps switch on.

Center Mounted Lamp

Left-hand side map lamp.A Right-hand side map lamp.B Door function switch.C All lamps on switch.D

Side Mounted Lamp

Map lamp.A Door function switch.B All lamps on switch.C

AMBIENT LIGHTING

The ambient lighting system illuminates the interior with a choice of several colors. The ambient lighting control is located in the overhead console.

Color paletteA Control knobB Search modeC

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Lighting

Rotate B past the first detent to switch on and adjust to the desired brightness.

Press A to cycle through the color choices. Press C to switch on all interior lamps and

the ambient lighting. Press C again to switch off the interior lamps and return the ambient lighting to the previously selected color.

The ambient lighting will switch on when the following conditions have been met:

• you switch the ignition on

• you switch the headlamps on

The ambient lighting will remain on until you switch the ignition off and one of the following conditions have been met:

• you lock your vehicle

• the accessory delay timer expires.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Lighting

POWER WINDOWS

WARNINGS

Do not leave children unattended in your vehicle and do not let them play with the power windows. They may

seriously injure themselves.

When closing the power windows, you should verify they are free of

obstructions and make sure that children and pets are not in the proximity of the window openings.

Press the control to open the window. Lift the control to close the window.

Note: You may hear a pulsing noise when just one of the windows is open. Lower the opposite window slightly to reduce this noise.

One-Touch Down (If Equipped)

Press the control fully and release it. Press again or lift it to stop the window.

One-Touch Up (If Equipped)

Lift the control fully and release it. Press or lift it again to stop the window.

Window Lock

Press the control to lock or unlock the rear window controls. It lights when the rear window controls lock.

Bounce-Back (If Equipped)

The window stops automatically while closing. It reverses some distance if there is an obstacle in the way.

Overriding the Bounce-Back Feature

WARNING

When you override the bounce-back feature the window will not reverse

if it detects an obstacle. Take care when closing the windows to avoid personal injury or damage to your vehicle.

Proceed as follows to override this protection feature when there is a resistance, for example in winter:

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Windows and Mirrors

1. Close the window twice until it reaches the point of resistance and let it reverse.

2. Close the window a third time to the point of resistance. You disabled the bounce-back feature and you can now close the window manually. The window travels past the point of resistance and you can close it fully.

Contact an authorized dealer as soon as possible if the window does not close after the third attempt.

Resetting the Bounce-Back Feature

WARNING

The bounce-back feature remains turned off until you reset the memory.

If you have disconnected the battery, you must reset the bounce-back memory separately for each window.

1. Lift and hold the control until the window is fully closed.

2. Release the control.

3. Lift and hold the control again for a few seconds.

4. Release the control.

5. Lift and hold the control again for a few seconds.

6. Release the control.

7. Press and hold the control until the window is fully open.

8. Lift and hold the control until the window is fully closed.

9. Release the control.

10. Open the window and then try to

close it automatically.

11. Repeat the procedure if the window

does not close automatically.

Accessory Delay (If Equipped)

You can use the window controls for several minutes after switching off the ignition or until opening either front door.

GLOBAL OPENING AND CLOSING

You can also operate the power windows with the ignition off using the global opening and global closing function.

Note: Global opening will only operate for a short period of time after you have unlocked your vehicle using the remote control.

Note: Global closing will only operate if you have set the memory correctly for each window. See Power Windows (page 68).

Global Opening (If Equipped)

To open all the windows:

1. Press and release the remote control unlock button.

2. Press and hold the remote control unlock button for at least three seconds.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Windows and Mirrors

Press the lock or unlock button to stop the opening function.

Global Closing (If Equipped)

Vehicles Without Keyless Entry

WARNING

Take care when using global closing. In an emergency, press the lock or unlock button immediately to stop.

To close all the windows, press and hold the remote control lock button for at least three seconds. Press the lock or unlock button to stop the closing function. The bounce-back function is also on during global closing.

Vehicles With Keyless Entry

WARNING

Take care when using global closing. In an emergency, touch a door handle lock sensor to stop.

Note: Global closing can be switched on using the driver’s door handle. Global opening and closing can also be switched on using the buttons on the passive key.

To close all the windows, press and hold the driver’s door handle for at least three seconds. The bounce-back function is also on during global closing.

EXTERIOR MIRRORS

Power Exterior Mirrors

WARNING

Do not adjust the mirrors when your vehicle is moving.

Left-hand mirrorA OffB Right-hand mirrorC

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Windows and Mirrors

Press the arrows to adjust the mirror.

Fold-Away Exterior Mirrors

Push the mirror toward the door window glass. Make sure that you fully engage the mirror in its support when returning it to its original position.

Power-Folding Mirrors

When you switch the ignition on, you can use the power-folding feature. Press the control to fold or unfold the mirrors.

Note: You can operate the mirrors (mirror tilting and folding) for several minutes after switching off the ignition. When you open a door, the power-folding feature automatically turns off.

Press the button again to stop and reverse the direction of movement.

Note: Continuous folding and unfolding of the mirrors will cause them to overheat and shut down for a short time. This is to avoid permanent damage.

Heated Exterior Mirrors (If Equipped)

See Heated Windows and Mirrors (page

99).

Blind Spot Monitor (If Equipped)

See Blind Spot Information System (page 173).

INTERIOR MIRROR

WARNING

Do not adjust the mirror when your vehicle is moving.

Note: Do not clean the housing or glass of any mirror with harsh abrasives, fuel or other petroleum or ammonia-based cleaning products.

You can adjust the interior mirror to your preference. Some mirrors also have a second pivot point. This lets you move the mirror head up or down and from side to side.

Pull the tab below the mirror toward you to reduce glare at night.

Auto-Dimming Mirror (If Equipped)

Note: Do not block the sensors on the front

and back of the mirror. Mirror performance may be affected. A rear center passenger or raised rear center head restraint may also block light from reaching the sensor.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Windows and Mirrors

The mirror will dim automatically to reduce glare when bright lights are detected from behind your vehicle. It will automatically return to normal reflection when you select reverse gear to make sure you have a clear view when backing up.

SUN VISORS

Rotate the sun visor toward the side window and extend it rearward for extra shade.

Illuminated Vanity Mirror (If Equipped)

Lift the cover to switch the lamp on.

SUN SHADES

WARNINGS

Do not let children play with the sun shade or leave them unattended in the vehicle. They may seriously hurt

themselves.

When closing the sun shade, you should verify that it is free of

obstructions and make sure that children and pets are not in the proximity of the sunshade.

The control is located in the overhead console.

The sun shade has a one-touch open and close feature. To stop motion during one-touch operation, press the control a second time.

Opening and Closing the Sun Shade

Fully press and release the front of the control to open the sun shade.

Fully press and release the rear of the control to close the sun shade.

Bounce-Back

The sun shade will stop automatically while closing. It will reverse some distance if there is an obstacle in the way.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Windows and Mirrors

Sun Shade Relearning

WARNING

The bounce-back function is not active during this procedure. Make sure that there are no obstacles in

the way of the moving sun shade.

Note: You must start the relearning process within 30 seconds of switching the ignition on.

In case the sun shade no longer opens or closes properly, follow this relearning procedure:

1. Press the front of the control to the first action point twice and release it within two seconds.

2. Press the rear of the control to the first action point twice and release it within two seconds.

3. Press and hold the front of the control to the first action point, until the sun shade fully opens.

4. Press and hold the rear of the control to the first action point, until the sun shade fully closes.

If you do not complete Step 2 within 15 seconds of Step 1, the relearning function end. Switch the ignition off, wait for another 30 seconds and then switch the ignition back on again. Start the procedure again from the beginning.

Confirm that relearning was successful by opening and closing the sun shade.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Windows and Mirrors

GAUGES

Information display.A Speedometer.B Engine coolant temperature gauge.C Fuel gauge.D Tachometer.E

Information Display

Odometer

Records the total distance traveled by your vehicle.

Outside Air Temperature

Shows the outside air temperature.

Trip Computer

See Trip Computer (page 83).

Vehicle Settings and Personalization

See General Information (page 80).

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Instrument Cluster

Engine Coolant Temperature Gauge

WARNING

Never remove the coolant reservoir cap while the engine is running or hot.

At normal operating temperature the indicator will remain in the center section.

Note: Do not restart the engine until the cause of overheating has been determined and resolved.

If the needle enters the red section, the engine is overheating. Stop the engine, switch the ignition off and determine the cause once the engine has cooled down. See Engine Coolant Check (page 237).

Fuel Gauge

Switch the ignition on. The fuel gauge will indicate approximately how much fuel is left in the fuel tank. The arrow adjacent to the fuel pump symbol indicates on which side of your vehicle the fuel filler door is located.

WARNING LAMPS AND INDICATORS

The following warning lamps and indicators alert you to a vehicle condition that may become serious. Some lamps illuminate when you start your vehicle to make sure they work. If any lamps remain on after starting your vehicle, refer to the respective system warning lamp for further information.

Note: Some warning indicators appear in the information display and operate the same as a warning lamp but do not illuminate when you start your vehicle.

Anti-Lock Braking System Warning Lamp

If it illuminates when you are driving, this indicates a

malfunction. You will continue to have the normal braking system (without anti-lock braking system) unless the brake system warning lamp is also illuminated. Have your vehicle checked by an authorized dealer.

Automatic High Beam Lamp (If

Equipped)

It will illuminate when this

feature is on. See Automatic

High Beam Control (page 62).

Battery Warning Lamp

If it illuminates when driving, this

indicates a malfunction. Switch

off all unnecessary electrical equipment. Have your vehicle checked by an authorized dealer immediately.

Blind Spot Monitor Indicator (If

Equipped)

It will illuminate when you switch

this feature off or in conjunction

with a message. See Blind Spot

Information System (page 173). See Information Messages (page 83).

Brake System Warning Lamp

It will illuminate when you

engage the parking brake with

the ignition on.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Instrument Cluster

If it illuminates when you are driving, check that the parking brake is not engaged. If the parking brake is not engaged, this indicates low brake fluid level or a brake system malfunction. Have your vehicle checked by an authorized dealer immediately.

WARNING

Driving your vehicle with the warning lamp on is dangerous. A significant

decrease in braking performance may occur. It will take you longer to stop your vehicle. Have your vehicle checked by an authorized dealer immediately. Driving extended distances with the parking brake engaged can cause brake failure and the risk of personal injury.

Cruise Control Indicator (If Equipped)

It will illuminate when you switch this feature on. See Using

Cruise Control (page 158).

Direction Indicator

Illuminates when the left or right direction indicator or the hazard

warning flasher is turned on. If the indicators stay on or flash faster, check for a burnt out bulb. See Changing a Bulb (page 243).

Door Ajar

Displays when the vehicle is on

and any door is not completely

closed.

Engine Oil Warning Lamp

WARNING

If it illuminates when you are driving do not continue your journey, even if the oil level is correct. Have your

vehicle checked.

If it illuminates with the engine running or when you are driving,

this indicates a malfunction. Stop your vehicle as soon as it is safe to do so and switch the engine off. Check the engine oil level. See Engine Oil Check (page 237).

Engine Warning Lamps

Malfunction Indicator Lamp

All Vehicles

If it illuminates when the engine is running, this indicates a malfunction. The engine will continue to run but it may have limited power. If it flashes when you are driving, reduce the speed of your vehicle immediately. If it continues to flash, avoid heavy acceleration or deceleration. Have your vehicle checked by an authorized dealer immediately.

WARNING

Have this checked immediately.

Fasten Safety Belt Warning Lamp

It will illuminate and a chime will

sound to remind you to fasten

your safety belt. See Safety

Belt Minder (page 26).

Front Airbag Warning Lamp

If the warning lamp does not

illuminate during start up,

remains on or flashes, the system may be disabled.

Have your vehicle checked by an authorized dealer.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Instrument Cluster

Front Fog Lamps Indicator

It will illuminate when you switch the front fog lamps on.

Frost Warning Lamp

WARNING

Even if the temperature rises to above 39°F (4°C) there is no guarantee that the road is free of

hazards caused by inclement weather.

It will illuminate when the outside air temperature is 39°F (4°C) or below.

Glow Plug Indicator

See Starting a Diesel Engine (page 124).

High Beam Indicator

It will illuminate when you switch the high beam headlamps on. It will flash when you use the

headlamp flasher.

Information Indicator

It will illuminate when a new message is stored in the

information display. It will be red or amber in color depending on the severity of the message and will remain on until the cause of the message has been rectified. See Information Messages (page 83).

Liftgate Ajar

Lights when the liftgate is not

completely closed.

Low Fuel Level Warning Lamp

If it illuminates when you are driving, refuel as soon as possible.

Low Washer Fluid

Lights when the windshield washer fluid is low.

Headlamp and Parking Lamp Indicator

It will illuminate when you switch the headlamps or parking lamps on.

Rear Fog Lamps Indicator

It will illuminate when you switch the rear fog lamps on.

Shift Indicator

It will illuminate to inform you that shifting to a higher or lower gear as indicated may give better fuel economy and lower CO2 emissions. It will not illuminate during periods of high acceleration, braking or when

the clutch pedal is pressed.

Stability Control Off Indicator

It will illuminate when you switch the system off. It will go out

when you switch the system back on or when you switch the ignition off.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Instrument Cluster

Stability Control Warning Lamp

It will flash when the system is active. If it remains illuminated

or does not illuminate when you switch the ignition on, this indicates a malfunction. During a malfunction the system will switch off. Have your vehicle checked by an authorized dealer immediately.

Start-Stop Active Indicator

It will illuminate when the

automatic engine stop occurs.

See Auto-Start-Stop (page

127). See Information Messages (page

83).

Start-Stop Unavailable Indicator

It will illuminate when automatic

engine stop is not available. See

Auto-Start-Stop (page 127). See Information Messages (page 83).

AUDIBLE WARNINGS AND INDICATORS

Automatic Transmission

Sounds when you open the driver's door and do not move the transmission selector lever to position P.

Key Outside Car

Vehicles With Keyless System

Sounds when you close the door, the engine is running and the system does not detect a passive key inside your vehicle.

Headlamps On

Sounds when you remove the key from the ignition and open the driver's door and you have left the headlamps or parking lamps on.

Fuel Gauge

Switch the ignition on. The fuel gauge will indicate approximately how much fuel is left in the fuel tank. The fuel gauge may vary slightly when your vehicle is moving or on a gradient. The arrow adjacent to the fuel pump symbol indicates on which side of your vehicle the fuel filler door is located.

Low Fuel Reminder

Vehicles with Trip Computer

A low fuel level reminder displays and sounds when the distance to empty reaches 75 mi (120 km) for MyKey and 50 mi (80 km) for all other keys.

Note: The low fuel reminder can appear at different fuel gauge positions depending on fuel economy conditions. This variation is normal.

Vehicles without Trip Computer

A low fuel level reminder displays and sounds when the fuel gauge needle is at 1/16th.

Safety Belt Minder

WARNINGS

The safety belt minder remains in stand-by mode when the front safety belts have been fastened. It will

sound if either safety belt is unfastened.

Do not sit on top of a fastened safety belt to prevent the safety belt minder

from coming on. The occupant protection system will only provide optimum protection when you use the safety belt properly.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Instrument Cluster

Sounds when your vehicle speed exceeds the pre-determined limit and the front safety belts are unfastened. The chime will stop after a period of time.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Instrument Cluster

GENERAL INFORMATION

WARNING

Driving while distracted can result in loss of vehicle control, crash and

You can control various systems on your vehicle using the information display controls on the steering wheel.

The information display shows the corresponding information.

Information Display Controls

• Press the up and down arrow buttons to scroll through and highlight the options within a menu.

• Press the right arrow button to enter a submenu.

• Press the left arrow button to exit a submenu.

• Press the OK button to choose and confirm settings or messages.

Menu Structure - Information Display

You can access the menu using the information display control.

Note: It may describe options not fitted to the vehicle you have purchased.

Trip computer 1 and 2

Option to display all the values on screen.

Speed

Trip odometer

Ford EcoModeAverage fuel

Gear shifting

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Information Displays

Trip computer 1 and 2

Anticipation

Speed

Ford EcoMode

Instant fuel

Dist to empty

Trip timer

Average speed

Option to select for navigation display.

See Trip Computer (page 83).

Information

Driver alert

Traffic signs

MyKey

System check

Settings

Traction ctrlDriver assist

BLIS

City Stop

Forward alert

Cross traffic alrt

AdaptiveCruise control

Normal

Driver alert

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Information Displays

Settings

Hill start assist

Tyre monitor

Traffic signs

Lane keeping

Aux heaterVehicle settings

Heater clockPark heater

Time 1

Time 2

Once

Heat now

Full guardAlarm

Reduced

Ask on exit

Park slot foundChimes

Information

Warning

Traffic (R/L)Lighting

Auto highbeam

Rain light

Hdlamp delay

Rain sensingWipers

Hold OK to create.Create MyKeyMyKey

Always on or user selectable.Traction ctrl

Always on or user selectable.ESC

User selectable or off.Max speed

User selectable or off.Speed warning

Volume limit

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Information Displays

Settings

Always on or user selectable.Do not disturb

Hold OK to clear all MyKeys.Clear all

Choose your applicable setting.LanguageDisplay

Vehicle graphic

Choose your applicable setting.Measure unit

Choose your applicable setting.Temp unit

System Check

All active warnings will display first if applicable. The system check menu may appear different based upon equipment options and current vehicle status. Use the up and down arrow buttons to scroll through the list. See Information

Messages (page 83).

TRIP COMPUTER

Resetting the Trip Computer

Press and hold OK on the current screen to reset the respective trip, distance, time and average fuel consumption information.

All Values

Indicates all the respective trip, distance, time and average fuel consumption information.

Average Fuel Consumption

Indicates the average fuel consumption since the function was last reset.

Distance to Empty

Indicates the approximate distance your vehicle will travel on the fuel remaining in the tank. Changes in driving pattern may cause the value to vary.

Outside Air Temperature

Shows the outside air temperature.

Trip Odometer

Registers the distance traveled of individual journeys.

Trip Timer

Registers the elapsed time of individual journeys or the total time since the function was last reset.

INFORMATION MESSAGES

Note: Depending on your vehicle options

and instrument cluster type, not all of the messages will display or be available.

Note: The information display may abbreviate or shorten certain messages.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Information Displays

Press the OK button to acknowledge and remove some messages from the information display.

The information display will automatically remove other messages after a short period of time.

You need to confirm certain messages before you can access the menus.

Message Indicator (If Equipped)

The message indicator illuminates to supplement some messages.

The indicator will be red or amber depending on the severity of the condition and it remains on until the condition is resolved.

A system-specific symbol with a message indicator may supplement some messages.

Active City Stop

ActionMessage

See Active City Stop (page 178).Active City Stop Auto braking

See Active City Stop (page 178).

Active City Stop Sensor blocked Clean screen

See Active City Stop (page 178).Active City Stop not available

Airbag

ActionMessage

Displays when the system requires service due to a

malfunction. Contact an authorized dealer.

Airbag fault Service now

Alarm

ActionMessage

Displays when the alarm has been triggered due to

unauthorized entry. See Anti-Theft Alarm (page 52).

Alarm activated Check Vehicle

Displays when the system requires service due to a

malfunction. Contact an authorized dealer.

Alarm fault Service required

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Information Displays

Battery and Charging System

ActionMessage

Stop your vehicle as soon as it is safe to do so and

switch off the ignition. Contact an authorized dealer.

Electrical system overvoltage

Stop safely

Displays to warn of a low battery condition. Turn off

all unneeded electrical accessories. Contact an

authorized dealer.

Battery low See manual

Blind Spot Information and Cross Traffic Alert System

ActionMessage

Displayed when the blind spot information system and

cross traffic alert system sensors are blocked. See

Blind Spot Information System (page 173).

BLIS Low visibility See manual

Displayed when a fault with the system has occurred.

Contact an authorized dealer as soon as possible.

BLIS: right sensor fault Service

required

Displayed when a fault with the system has occurred.

Contact an authorized dealer as soon as possible.

BLIS: left sensor fault Service

required

Displayed when the system is not available due to trailer use. See Blind Spot Information System

(page 173).

BLIS not available Trailer

attached

Displayed when the system detects a vehicle. See

Blind Spot Information System (page 173).

Cross traffic Vehicle coming

from right

Displayed when the system detects a vehicle. See

Blind Spot Information System (page 173).

Cross traffic Vehicle coming

from left

Displayed when the blind spot information system and

cross traffic alert system sensors are blocked. See

Blind Spot Information System (page 173).

Cross traffic Sensor blocked See

manual

Displays when the system requires service due to a

malfunction. Contact an authorized dealer.

Cross traffic malfunction

Service required

Displayed when the system is not available due to trailer use. See Blind Spot Information System

(page 173).

Cross traffic disabled Trailer

attached

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Information Displays

Child Safety Locks

ActionMessage

Retry to activate or deactivate the system. If the issue persists

contact an authorized dealer.

Child lock fault Service

required

Engine

ActionMessage

Engine service is required. Contact an authorized

dealer.

Engine fault Service now

Displays when the engine temperature is too high. Stop the vehicle in a safe place and allow the engine to cool.

If the problem persists, contact an authorized dealer.

See Engine Coolant Check (page 237).

High engine temperature Stop

safely

Displays when the engine has reduced power in order

to help reduce high coolant temperature.

Power reduced to lower engine

temperature

Hill Start Assist

ActionMessage

Displays when hill start assist is not available. Contact an authorized dealer. See Hill Start Assist (page 140).

Hill start assist not available

Keyless Vehicle

ActionMessage

Displays to remind you that the key is in the trunk. See

Push Button Ignition Switch (page 118).

Ford KeyFree Key inside vehicle

Displayed if the key is not detected by the system. See

Push Button Ignition Switch (page 118).

Ford KeyFree No key detected

Displayed as a reminder to turn off the vehicle. See

Push Button Ignition Switch (page 118).

Ford KeyFree Switch ignition off

Press POWER

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Information Displays

ActionMessage

Displayed as a reminder to press the brake while

starting the vehicle.

Press brake to start

Displayed when a valid key is not detected within the

vehicle. See Push Button Ignition Switch (page 118).

Ford KeyFree Key not inside car

Displays when the key battery is low. Change the

battery as soon as possible. See Remote Control

(page 31).

Key Battery low Replace soon

Lane Keeping Aid

ActionMessage

Displays when the system has detected a condition that requires service. Have your vehicle checked by an authorized dealer.

Lane keeping sys malfunction Service required

Lighting

ActionMessage

Displays when the brake lamp bulb has burned out.

Contact an authorized dealer.

Brake lamp Bulb fault

Displays when the rear fog lamp bulb has burned out.

Contact an authorized dealer.

Rear fog lamp Bulb fault

Displays when the low beam headlamp bulb has

burned out. Contact an authorized dealer.

Low beam Bulb fault

Displays when an electrical system problem occurs

with the headlamp system. Contact an authorized

dealer.

Headlamp fault Service required

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Information Displays

Maintenance

ActionMessage

Displays when the engine oil life is depleted and

requires a change. See Engine Oil Check (page 237).

Oil change required

Indicates the brake fluid level is low and the brake

system should be inspected immediately. See Brake

Fluid Check (page 238).

Brake fluid level low Service

now

MyKey

ActionMessage

Displays when MyKey is active.MyKey active Drive Safely

Displays when a MyKey is in use and the MyKey speed

limit is on and the vehicle speed is approaching 80

mph (130 km/h).

MyKey Vehicle near top speed

Displays when a MyKey is in use and the MyKey speed

limit is reached.

MyKey Vehicle at top speed

Displays when MyKey is active.MyKey Check speed Drive safely

Displays when a MyKey is in use and Belt-Minder is

activated.

MyKey Buckle up to unmute

audio

Displays when a MyKey is in use and park aid is activ-

ated.

MyKey Park aid cannot be

deactivated

Displays when trying to create a MyKey with a key

already designated as a MyKey.

MyKey Key is already MyKey

Displays when programming a MyKey.MyKey ESC cannot be deactiv-

ated

Occupant Protection

ActionMessage

Displays when the system has detected a condition that requires service. Have your vehicle checked by an authorized dealer as soon as possible.

Service Beltminder

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Information Displays

Park Aid

ActionMessage

Displays when the system has detected a condition

that requires service. Contact an authorized dealer.

See Principle of Operation (page 144).

Parking aid malfunction Service

required

Park Brake

ActionMessage

Displays when the parking brake is set, the engine is

running and the vehicle is driven more than 3 mph (5

km/h). If the warning stays on after the parking brake

is released, contact an authorized dealer.

Park brake applied

Power Steering

ActionMessage

The power steering system is not working. Stop the

vehicle in a safe place. Contact an authorized dealer.

Steering loss Stop safely

The power steering system is not working. Stop the

vehicle in a safe place. Contact an authorized dealer.

Steering assist malfunction

Service required

The power steering system has detected a condition

within the power steering system or passive entry or

passive start system requires service. Contact an

authorized dealer.

Steering malfunction Service

now

Starting System

ActionMessage

Displays when starting the vehicle as a reminder to

apply the brake.

Press brake to start

Displays when the vehicle fails to start.Cranking time exceeded

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Information Displays

Start-Stop

ActionMessage

Switch the ignition off before leaving your vehicle if the system has shut down the engine. See Auto-Start-Stop (page 127).

Auto StartStop Switch ignition off

The engine needs to be restarted, press the clutch pedal to start. See Auto-Start-Stop (page 127).

Auto StartStop Press a pedal to start engine

Select neutral for the system to restart the engine. See Auto-Start-Stop (page 127).

Auto StartStop Select neutral to start engine

The system is not functioning. A manual restart is required. See Auto-Start-Stop (page 127).

Auto StartStop Manual restart required

The engine needs to be restarted manually, but the transmission is not in P. See Auto-Start-Stop (page 127).

Auto StartStop Shift to P, then Restart Engine

The engine needs to be restarted, press the brake pedal to start. See Auto-Start-Stop (page 127).

Auto StartStop Press Brake to Start Engine

Transmission

ActionMessage

See an authorized dealer.Transmission malfunction

Service now

The transmission is overheating and needs to cool.

Stop in a safe place as soon as it’s possible.

Transmission overheating Stop

safely

Transmission is getting hot. Stop to let it cool or speed

up.

Transmission overheating Stop

safely

Displays as a reminder to shift into park.Transmission not in Park Select

Displays to request the operator to apply the brake as

needed by the transmission.

Press brake to unlock selector

lever

Displays when the transmission shift lever is unlocked

and free to select gears.

Selector lever unlocked

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Information Displays

Tyre Pressure Monitoring System

ActionMessage

Displays when one or more tires on your vehicle have

low tire pressure. See Tire Pressure Monitoring

System (page 258).

Check tyre pressures

Displays when the tire pressure monitoring system is

malfunctioning. If the warning stays on or continues

to come on, contact an authorized dealer. See Tire

Pressure Monitoring System (page 258).

Tyre monitor malfunction

Service required

Displayed when a tire pressure sensor is malfunc-

tioning, or your spare tire is in use. More information

on how the system operates under these conditions

is available. See Tire Pressure Monitoring System

(page 258). If the warning stays on or continues to come

on, contact an authorized dealer as soon as possible.

Tyre sensors not detected

Check handbook

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Information Displays

PRINCIPLE OF OPERATION

Outside Air

Keep the air intakes in front of the windshield free from obstruction (such as snow or leaves) to allow the climate control system to function effectively.

Recirculated Air

WARNING

Prolonged use of recirculated air may cause the windows to mist up. If the windows mist up, follow the settings

for demisting the windshield.

The air currently in the passenger compartment recirculates. Outside air does not enter your vehicle.

Heating

Heating performance depends on the temperature of the engine coolant.

General Information on Controlling the Interior Climate

Fully close all the windows.

Warming the Interior

Direct the air toward your feet. In cold or humid weather conditions, direct some of the air toward the windshield and the door windows.

Cooling the Interior

Direct the air toward your face.

Air Conditioning

The system directs air through the evaporator for cooling. The evaporator extracts humidity from the air to help keep the windows free of mist. The system directs the resulting condensation to the outside of your vehicle, which may cause a small pool to form under your vehicle. This is normal.

Note: The air conditioning operates only when the temperature is above 39°F (4°C).

Note: When you use air conditioning, your vehicle uses more fuel.

AIR VENTS

Center Air Vents

To close the air vent, turn the thumbwheel above the vent fully downward.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Climate Control

Side Air Vents

To close the air vent, turn the thumbwheel to the left of the vent fully downward.

MANUAL CLIMATE CONTROL

Fan speed control: Adjust the volume of air circulated in the vehicle.A A/C: Press the button to turn the air conditioning on or off. Use air conditioning

with recirculated air to improve cooling performance and efficiency.

Heated windshield (if equipped): Press the button to clear the heated windshield of thin ice and fog. See Heated Windshield (page 99).

Air distribution control: Adjust the control to turn airflow from the windshield, instrument panel, or footwell vents on or off. You can distribute air through any combination of these vents.

Heated rear window: Press the button to switch the heated rear window on and off. See Heated Windows and Mirrors (page 99).

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Climate Control

Recirculated air: Press the button to switch between outside air and

recirculated air. The air currently in the passenger compartment recirculates. This can reduce the time needed to cool the interior and reduce unwanted odors from entering your vehicle.

Temperature control: Control the temperature of the air circulated in your vehicle.

MAX Defrost: Adjust the control to switch on defrost. Outside air flows through the windshield vents, air conditioning automatically turns on, and fan automatically adjusts to the highest speed. You can also use this setting to defrost and clear the windshield of a thin covering of ice.

MAX A/C: Adjust the control for maximum cooling. Recirculated air flows through the instrument panel vents, air conditioning automatically turns on and the fan automatically adjusts to the highest speed.

Heated seats (if equipped): Press the button to switch the heated seats on and off. See Heated Seats (page 115).

Power: Press the button to switch the system on and off. When the system is off, it prevents outside air from entering the vehicle.

AUTOMATIC CLIMATE CONTROL

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Climate Control

AUTO: Press the button to turn on automatic operation. Select the desired

temperature using the temperature control. The system adjusts fan speed, air distribution, air conditioning operation, and selects outside air or recirculated air to heat or cool the vehicle in order to maintain the desired temperature. You can also use the AUTO button to turn off dual zone operation by pressing and holding the button for more than two seconds.

Heated windshield (if equipped): Press the button to clear the heated windshield of thin ice and fog. See Heated Windshield (page 99).

Fan speed control: Adjust the volume of air circulated in the vehicle.C Air distribution control: Adjust the control to turn airflow from the windshield,

instrument panel, or footwell vents on or off. You can distribute air through any combination of these vents.

Climate control display: The display shows the set temperatures and the fan speed.

Heated rear window: Press the button to switch the heated rear window on and off. See Heated Windows and Mirrors (page 99).

A/C: Press the button to turn air conditioning compressor on or off. Use air conditioning with recirculated air to improve cooling performance and efficiency.

Note: In certain conditions (for example, maximum defrost), the air conditioning compressor may continue to operate even though the air conditioning is switched off.

Recirculated air: Press the button to switch between outside air and recirculated air. When you select recirculated air, the air currently in the passenger compartment recirculates. This may reduce the time needed to cool the interior (when used with A/C) and may reduce unwanted odors from entering your vehicle.

Note: Recirculated air may turn off automatically (or be prevented from turning on) in all airflow modes except MAX A/C to reduce risk of fogging. Recirculated air may also turn on and off automatically in Panel or Panel and Floor airflow modes during hot weather in order to improve cooling efficiency.

Heated seats (if equipped): Press the button to switch the heated seats on and off. See Heated Seats (page 115).

MAX A/C: Press the button to maximize cooling. Recirculated air flows through the instrument panel vents, air conditioning automatically turns on, and the fan automatically adjusts to the highest speed.

MAX Defrost: Press the button to switch on defrost. Outside air flows through the windshield vents, air conditioning automatically turns on, and fan automatically adjusts to the highest speed. You can also use this setting to defrost and clear the windshield of a thin covering of ice. The heated rear window also automatically turns on when you select maximum defrost.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Climate Control

Note: To prevent window fogging, you cannot select recirculated air when

maximum defrost is on. Power: Press the button to switch the system on and off. When the system is

off, it prevents outside air from entering the vehicle.

Note: If you press a fan speed or airflow direction button, it will turn off the automatic operation function. Press the AUTO button to return to auto mode.

Note: Prolonged use of recirculated air may cause the windows to fog up. If the system detects high humidity inside your vehicle, recirculated air will automatically turn off. The system will not automatically turn recirculated air back on.

Temperature Control

You can set the temperature between 60°F (15.5°C) and 85°F (29.5°C). In position LO, the system switches to permanent cooling. In position HI, the system switches to permanent heating.

Note: If you select either position LO or HI, the system does not regulate a stable temperature.

Mono Mode

In this mode, the temperature settings for both the driver side and passenger side are linked. If you adjust the setting using the rotary control on the driver side, the system adjusts the temperature to the same setting on the passenger side.

Switching Mono Mode Off

Select a temperature for the passenger side using the rotary control on the passenger side. Mono mode automatically switches off. The temperature on the driver side remains unchanged. You can now adjust the driver side and passenger side temperatures independently. The temperature settings for each side are shown in the display.

Note: The maximum temperature difference between driver and passenger side is 39.2°F (4°C).

Switching Mono Mode Back On

Press and hold the AUTO button. The passenger side temperature is adjusted to the driver side temperature setting.

HINTS ON CONTROLLING THE INTERIOR CLIMATE

General Hints

Note: Prolonged use of recirculated air may

cause the windows to fog up. Note: To reduce humidity build-up inside

your vehicle, do not drive with the system switched off or with recirculated air always switched on.

Note: Do not place objects under the front seats as this may interfere with the airflow to the rear seats.

Note: Remove any snow, ice or leaves from the air intake area at the base of the windshield.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Climate Control

Note: To improve air conditioning when

starting your vehicle, drive with the windows open until you feel cold air through the vents.

Manual Climate Control

Note: To reduce fogging of the windshield

during humid weather, adjust the air distribution control to the windshield air vents position.

Automatic Climate Control

Note: Do not adjust the settings when your

vehicle interior is extremely hot or cold. The system automatically adjusts to the previously stored settings. For the system to function efficiently, the instrument panel and side air vents should be fully open.

Note: At low ambient temperatures with AUTO selected, the air stream is directed toward the windshield and side windows for as long as the engine remains cold.

Note: When the system is in AUTO mode, and the interior and exterior temperatures are high, the system automatically selects recirculated air to maximize cooling of the interior. When the selected air temperature is reached, the system automatically selects outside air.

Heating the Interior Quickly

Vehicle with automatic climate controlVehicle with manual climate control

Press the AUTO button.Adjust the fan speed to the highest

speed setting.

Adjust the temperature control to the desired setting.

Adjust the temperature control to the highest setting.

Adjust the air distribution control to the footwell air vents position.

Recommended Settings for Heating

Vehicle with automatic climate controlVehicle with manual climate control

Press the AUTO button.Adjust the fan speed to the second

speed setting.

Adjust the temperature control to the desired setting.

Adjust the temperature control to the midway point of the hot settings.

Adjust the air distribution control to the footwell air vents position.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Climate Control

Cooling the Interior Quickly

Vehicle with automatic climate controlVehicle with manual climate control

Press the MAX A/C button.Adjust the temperature control to the

MAX A/C position.

Adjust the fan speed to the highest setting.

Drive with the windows open until you feel cold air through the vents.

Recommended Settings for Cooling

Vehicle with automatic climate controlVehicle with manual climate control

Press the AUTO button.Adjust the fan speed to the second

speed setting.

Adjust the temperature control to the desired setting.

Adjust the temperature control to the midway point of the cold settings.

Adjust the air distribution control to the instrument panel air vents position.

Side Window Defogging in Cold Weather

Vehicle with automatic climate controlVehicle with manual climate control

Press the windshield defrosting and defogging button.

Select the windshield air vents using the air distribution buttons.

Adjust the temperature control to the desired setting.

Press the A/C button.2

Adjust the temperature control to the desired setting.

Adjust the fan speed to the highest setting.

C-MAX (CEU) Vehicles Built From: 16-03-2015 Vehicles Built Up To: 19-07-2015, CG3642en enGBR, Edition date: 02/2015, First Printing

Climate Control
