ii900/ii910
Acoustic Imager
www.GlobalTestSupply.com
April 2019 Rev. 2, 5/23
©2019-2023 Fluke Corporation. All rights reserved. All product names are trademarks of their respective companies.
Users Manual
Find Quality Products Online at: sales@GlobalTestSupply.com
Each Fluke product is warranted to be free from defects in material and workmanship under normal use and service. The warranty period is two years and begins on the date of shipment. Parts, product repairs, and services are warranted for 90 days. This warranty extends only to the original buyer or end-user customer of a Fluke authorized reseller, and does not apply to fuses, disposable batteries, or to any product which, in Fluke's opinion, has been misused, altered, neglected, contaminated, or damaged by accident or abnormal conditions of operation or handling. Fluke warrants that software will operate substantially in accordance with its functional specifications for 90 days and that it has been properly recorded on non-defective media. Fluke does not warrant that software will be error free or operate without interruption.
Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authori ty to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price. Fluke reserves the right to invoice Buyer for importation costs of repair/replacement parts when product purchased in one country is submitted for repair in another country.
Fluke's warranty obligation is limited, at Fluke's option, to refund of the purchase price, free of charge repair, or replacement of a defective product which is returned to a Fluke authorized service center within the warranty period.
To obtain warranty service, contact your nearest Fluke authorized service center to obtain return authorization information, then send the product to that service center, with a description of the difficulty, postage and insurance prepaid (FOB Destination). Fluke assumes no risk for damage in
www.GlobalTestSupply.com
transit. Following warranty repair, the product will be returned to Buyer, transportation prepaid (FOB Destination). If Fluke determines that failure was caused by neglect, misuse, contamination, alteration, accident, or abnormal condition of operation or handling, including overvoltage failures caused by use outside the product’s specified rating, or normal wear and tear of mechanical components, Fluke will provide an estimate of repair costs and obtain authorization before commencing the work. Following repair, the product will be returned to the Buyer transportation prepaid and the Buyer will be billed for the repair and return transportation charges (FOB Shipping Point).
THIS WARRANTY IS BUYER'S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. FLUKE SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, ARISING FROM ANY CAUSE OR THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion or limitation of incidental or consequential damages, the limitations and exclusions of this warranty may not apply to every buyer. If any provision of this Warranty is held invalid or unenforceable by a court or other decision-maker of competent jurisdiction, such holding will not affect the validity or enforceability of any other provision.
11/99
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL USE OF A CONSUMER OR OTHER USES IN WHICH IT DOES NOT RECEIVE REMUNERATION TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM
.
Find Quality Products Online at: sales@GlobalTestSupply.com

Table of Contents

www.GlobalTestSupply.com
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Terms to Know. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Power On/Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features/Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Hand Strap/Neck Strap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Capture Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Capture Analysis Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
LeakQ™ Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
PDQ Mode™ (ii910) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
MecQ™ Mode (ii910) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Title Page
i
ii900/ii910
Users Manual
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Annotations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Text Note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Photo Note. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Tag Note. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Acoustics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Show PD Count: On or Off (ii910). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Show dB Scale: On or Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Min / Max dB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
High Frequency (ii910) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Single Source/Multiple Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
MecQ Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Palette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Markers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
File Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Date & Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Localization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Factory Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Operating Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Clear User Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Imager Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Test Microphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Save Diagnostic Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Basic Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
File Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Import Saved Images or Video Files with Fluke Connect Desktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Firmware Update. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
How to Clean the Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Acoustic Sensor Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Product Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
ii
Find Quality Products Online at: sales@GlobalTestSupply.com

Introduction

The Fluke ii900/ii910 is an Acoustic Imager (the Product or Imager) that detects and locates an acoustic signature. These
www.GlobalTestSupply.com
signatures can indicate leaks in compressed air, compressed gas, and vacuum systems.
In addition, the ii910 detects electrical discharges as well as leaks. Examples of these electrical discharges include partial discharge such as corona, surface tracking, and arcing. The ii910 also identifies and locates potential mechanical issues.
The Imager has an acoustic sensor-array that aligns a sound­source heatmap with the image. The visible-light camera provides a live-view image of the inspection area. Capture and save still image files and video files from the inspection for documentation and reports.
A rechargeable battery powers the Imager. The Imager includes an external battery charger with power adapter and country-specific cables.
The Imager has a USB-C port that connects to a PC for file download and firmware updates.
1
ii900/ii910
1
2
6
7
8
9
5
4
3
Mode d’emploi
Find Quality Products Online at: sales@GlobalTestSupply.com

Before You Start

Table 1 is a list of items included with the Imager. Use the part
numbers to order additional accessories.
Table 1. Standard Equipment
www.GlobalTestSupply.com
Item Model Number Description Part Number
ii900 or ii910 Acoustic Imager NA BP291 Rechargeable Lithium-ion Battery Pack (x2) 3894688 ESBC290-1 External Battery Charger/Power Supply with Country-Specific Adapters 5385738 TiX5XX-NECK Neck Strap 4574715 ii900 Hand Strap Hand Strap 5075994 USB-C Cable 3.0 USB-C Cable, 1 m (3.3 ft) 5079197 Array Cover Acoustic Sensor Cover 5075982 CXT1000 Protective/Carry Case 4628917
C/D
2
A
B
E
F
G
H
I
Acoustic Imager
Find Quality Products Online at: sales@GlobalTestSupply.com
Before You Start

Terms to Know

Use this section to familiarize yourself with these terms that are unique to this Imager and sound pressure measurements.
Decibel (dB) Sound Pressure Level (SPL). The unit of measurement for changes in sound pressure. Decibel indicates the level of the sound (against the reference level of sound in air) and is expressed in terms of dB SPL.
Distance to target. The distance between the leak source and the acoustic sensor is critical. The decibel level that the Imager can measure decreases with the square of this distance.
www.GlobalTestSupply.com
Sound Frequency / Acoustic Frequency / Frequency Band.
The frequency corresponds to the number of sound vibrations/ second and is expressed as Hertz (Hz) or thousands of Hertz (kHz).
Frequency Range
Audible (up to 20 kHz). The range that human ear can perceive sounds.
Ultrasonic (above 20 kHz). Certain issues (leaks, electrical discharges, mechanical failures) generate sound signatures in ultrasonic ranges. The human ear cannot perceive the ultrasonic range that the Imager can detect.
Frequency Selection / Frequency Filtering / Selected Frequency Band. Select a frequency band for measurement and
visualization of sound. When a frequency band is selected, any sound outside of that range is filtered and not shown or considered.
Background Noise. The noise that exists in the surroundings that the microphone sensors detect along with the sound sources of possible leaks. Generally, background noise is higher in lower frequencies. In noisy environments, select higher frequencies to help discriminate the leak sounds.
Frequency / Spectrum Graph. A graphic chart on the display shows the level of sound detected in all frequency ranges.
Frequency Spike. Spike in the frequency / spectrum graph that indicates a significant source of sound in this specific frequency. If this spike is within the frequency selection, the Imager visualizes the source on the display.
Field-of-View (FOV). What is detected by the Imager at a particular position and orientation in space.
Sound Reflections. Sound signals reflect, particularly on smooth and flat surfaces. In certain conditions, the Imager shows on the display a hot spot from the source of noise and one or more hot spots from reflections.
LeakQ™. LeakQ is a capture mode that estimates the size of a leak. LeakQ Scale is a scale from 0 to 10 that is an indication of the leak size. The Imager calculates a value based on the measured dB SPL level and the distance value. The distance value is automatically determined or you input a value with the display keyboard.
3
ii900/ii910
Mode d’emploi
Find Quality Products Online at: sales@GlobalTestSupply.com
PDQ Mode™. PDQ Mode is a capture mode that detects and locates potential partial discharges. The PDQ Mode indicates a possible type of Partial Discharge (External, Internal, Tracking, or Other), Pulse count indication/minute, and Phase-resolved Partial Discharge Plot (PRPD plot).
Partial Discharge (PD). PD is a localized dielectric breakdown that does not completely bridge the electrical insulation between two conductors under high voltage.
PD types are classified into three main types:
External discharge, or corona discharge, is the ionization of a fluid, gas, or air surrounding a conductor that is electrically
www.GlobalTestSupply.com
charged at high voltage.
Internal discharge occurs in voids or cavities within solid or liquid dielectrics.
Surface discharge tracks across the surface of different insulation materials.
MecQ™. MecQ is a capture mode that detects and locates potential anomalies in mechanical components as an early identification of possible mechanical deterioration that requires further inspection.

Power On/Off

To turn on the Imager, push and hold O >2 s. To turn off the Imager, push
O. Tap OK to continue.

Battery

XW Warning
To prevent personal injury and for safe operation of the Product:
Do not put battery cells and battery packs near heat or fire.
Do not put in sunlight.
Do not disassemble or crush battery cells and battery packs.
Remove batteries to prevent battery leakage and damage to the Product if it is not used for an extended period.
Connect the battery charger to the mains power outlet before the Product.
Use only Fluke approved power adapters to charge the battery.
Keep cells and battery packs clean and dry. Clean dirty connectors with a dry, clean cloth.
W Caution
To prevent damage to the battery:
Do not expose battery to heat sources or high­temperature environments such as an unattended vehicle in the sun.
Do not store the battery on the charger for more than 24 hours as reduced battery life may result.
Charge the battery for a two-hour minimum at six-month intervals for maximum battery life. Without use, the battery will self-discharge in approximately six months.
Always operate in the specified temperature range.
Do not incinerate the Product and/or battery.
A Li-ion battery powers the Imager. The Imager includes two batteries for a quick-change during operation.
The battery charges on the charging base. The power supply powers the charging base. Country-specific adapters are included.
4
Acoustic Imager
A
BC
Find Quality Products Online at: sales@GlobalTestSupply.com
Before You Start
The battery is tested in accordance with and complies to:
UN Manual of Tests and Criteria Part III Subsection 38.3 (ST/SG/AC.10/11/Rev.5) – also known as the UN T19.T8 tests
EN55022 and EN55024
•FCC part 15B
UL2054/cUL60950-1
IEC62133
•ROHS
www.GlobalTestSupply.com
The battery has an indicator with four LEDs (25 %, 50 %, 75 %, and 100 % charge) and a test button. To check the battery charge,
. The LEDs light to show the battery charge level. If all four
push LEDs are on, the battery charge is at 100 % of available capacity.
To charge the battery:
1. Connect the ac power supply to the ac wall outlet and connect the dc output to the charger base. See Figure 1.
2. Put one or two batteries into bay of charger base.
3. Charge battery.
4. Remove battery and push
to check the status.
Note
The charger base automatically charges one battery at a time.
To install the battery:
1. Open the battery door. See Figure 1.
2. Insert the battery with the contact side first.
3. Replace the battery door. Make sure that the battery tab does not interfere with the lock and the door is firmly closed.
Figure 1. Battery
25%
50%
75%
+
100%
C
D
T
-
5
ii900/ii910
1
2 3 4
5
8 7 6
Mode d’emploi
Find Quality Products Online at: sales@GlobalTestSupply.com

Features/Buttons

Table 2 is a list of the Imager features.
Table 2. Feature/Control Descriptions
www.GlobalTestSupply.com
Button Function Button Function
A
B
C
D
Power On/Off Hand Strap Touchscreen Display Capture Button for Image or Start/Stop Video
6
E
F
G
H
Acoustic Sensor Battery Compartment USB-C Connector Neck Strap Anchor
Find Quality Products Online at: sales@GlobalTestSupply.com

Hand Strap/Neck Strap

The Imager includes a hand strap and a neck strap that makes it easy to hold and operate as you take measurements. See Figure 2 for information about setup.
Figure 2. Hand Strap/Neck Strap
www.GlobalTestSupply.com
Acoustic Imager
Hand Strap/Neck Strap
Table 3. Touchscreen
3
1
2

Display

The color display is a touchscreen that shows the test area as a visual image combined with a sound image. See Table 3.
With the touchscreen you are able to set up and adjust all the test parameters. For more information, see Basic Operation.
9
8
7
6
Item Description
A
B
C
D
E
F
G
H
I
Tool Menu Zoom Capture Mode Frequency Range of Spectrum Palette of dB SPL Scale Profile Selection (when enabled) Folder Selection Time/Date Stamp Battery Status
5
4
7
ii900/ii910
Mode d’emploi
Find Quality Products Online at: sales@GlobalTestSupply.com

Menus

To view the tool menu, tap your finger on the display. This action reveals the menu for parameter settings. Tap anywhere on the display outside the menu to hide the menu.

Capture Mode

When you push the Capture button, you save an image of the scene in the selected mode.
To select the capture mode:
1. Open the tool menu.
www.GlobalTestSupply.com
2. Tap the Capture Mode icon to open the Capture Mode menu.
3. Tap on the option to select. The icon on the tool menu and the display change to show the
selected mode.
4. Tap anywhere on the display outside the tool menu to hide the menu.


Image mode captures a still photo of the scene with overlapping sound image and saves it in a .PNG or .JPG format. The Image mode is the best method for the initial scan of the scene for any type of issue. If an issue is detected, then you have options for advanced analysis modes. See Capture Analysis Modes.
1. Press the Capture button to save the still photo. After the image is saved, a small image (thumbnail) shows on
the screen.
2. Tap to add notes, photo notes, or tags to the image. See
Memory for more information.

Video

Video mode captures a video of the scene with overlapping sound image and saves it in an .MP4 format.
1. Press the Capture button to start recording. The elapsed time shows as the Imager records.
2. Press the Capture button again to stop recording and save the video.
After the video is saved, a small image (thumbnail) shows on the screen.
3. Tap to add notes, photo notes, or tags to the image. See
Memory for more information.
8
Acoustic Imager
Find Quality Products Online at: sales@GlobalTestSupply.com
Menus

Capture Analysis Modes

LeakQ™ mode. The Imager is able to capture the leak data for later use to evaluate the type of leak (quick connect, threaded coupling, hose, open end) and estimate the size of the leak.
PDQ Mode™ (ii910 only). The Imager is able to detect, locate, and capture potential partial discharges and evaluate the type of partial discharge (external, internal, surface, or other). The data includes information for later use to create pulse phase diagrams.
MecQ™ mode (ii910 only). The Imager is able to detect, locate, and capture a picture of components that may have mechanical deterioration and require further attention.
www.GlobalTestSupply.com
To select the capture analysis mode:
1. Open the tool menu.
2. Tap the Capture Mode icon to open the Capture Mode menu.
3. Tap for the LeakQ mode. The icon on the tool menu and the display change to show the
selected mode.
ii910 only:
4. Tap for the PDQ Mode.
5. Tap for the MecQ mode.
Online tools and calculators are available to create reports with (data) captures that use the LeakQ, PDQ, and MecQ modes.
The capture analysis modes show on the display when the on-device option is turned on. When on, a portion of the analysis shows on-screen at the time of capture (see Settings and
Operating Conditions).

LeakQ™ Mode

LeakQ mode automatically determines the distance to the target (a leak that shows inside the circle on the display). When a leak is detected and the Imager can determine the distance, the LeakQ value on the display gives an indication of the size of the leak. The value is based on the measured dB SPL value and the distance.
If a leak shows inside the circle on the display:
Values for DISTANCE and LeakQ Scale show on the display.
or
NO TARGET FOUND shows on the display when no leak is detected inside the circle.
If the Imager cannot automatically determine the distance, this pop-up message shows on the display:
UNABLE TO ESTIMA TE DISTANCE
If the Imager is unable to determine the distance, or you want to override the estimated distance, you can input the distance manually.
To input the distance manually:
1. Tap on the message to open a numeric screen and enter
the distance. The Imager uses the entered distance to calculate the
LeakQ values.
Note
Stabilize the Imager for a few moments as it calculates the values.
2. Press the Capture button to make a more precise
calculation.
9
ii900/ii910
Mode d’emploi
Find Quality Products Online at: sales@GlobalTestSupply.com
3. If the measured distance requires additional adjustment, tap the Distance box to update.
4. Press Capture button or Save in the menu. The Imager saves the still photo of the scene with
overlapping sound image and values in .PNG or .JPG format. You can add notes, photo notes, or tags to the image. See Memory for more information.
Note
For best results:
www.GlobalTestSupply.com
• Move the Imager around the leak to find the highest LeakQ value. This will best reflect the actual leak size.
• Obstacles within the circle may influence the calculated distance and LeakQ value.
• High background noise will influence the calculated distance and LeakQ value.

PDQ Mode™ (ii910)

PDQ Mode™ captures data from a Partial Discharge (PD) that enables further analysis such as type of discharge and severity. The PD must be inside the circle on the display.
When a PD is detected, the PD Count value on the display gives an indication of the pulses generated by that partial discharge.
The value is based on the pulses of the acoustic interference generated by the PD:
Values for estimated DISTANCE show on the display.
or
NO TARGET FOUND shows on the display when no PD is detected inside the circle.
If the Imager cannot automatically determine the distance, this pop-up message shows on the display:
UNABLE TO ESTIMAT E DISTANCE
If the Imager is unable to determine the distance, or you want to override the estimated distance, you can input the distance manually. See LeakQ™ Mode.
Note
PD Count value is not directly related to the distance.
The Imager saves the still photo of the scene with overlapping sound image and values in .PNG or .JPG format. You can add notes, photo notes, or tags to the image. See Memory for more information.

MecQ™ Mode (ii910)

MecQ™ mode detects and locates potential anomalies in mechanical components as an early identification of possible mechanical deterioration that requires further inspection.
10
Acoustic Imager
Find Quality Products Online at: sales@GlobalTestSupply.com
Menus

Memory

The Memory menu shows an overview of all saved files with a thumbnail image. Each thumbnail includes an icon to indicate the file type:
Video
LeakQ
www.GlobalTestSupply.com
PDQ Mode
MecQ
To view a file, tap on the thumbnail once to open the file on the display.
To delete a single image file:
1. Tap on the image once to open the file on the display.
2. Tap
To delete multiple image files:
1. Tap and hold an image file.
2. Tap all files to delete.
t to delete the file.
The mode changes to multi-file selection.

Annotations

You have 2 methods to access the annotation menu:
after a capture (image or video), tap on the small thumbnail that shows on the bottom left corner
tap on any capture (image or video) to go to the Memory Menu
The annotation menu on the left side of the screen shows the types of notes. Each note is identified with an icon. These icons include a yellow dot when annotation data is available.

Text Note

You can add additional information to files with Text Note. To add a text note:
1. Tap on the image thumbnail to open the file on the display.
2. Tap
3. Tap
To Delete a text note:
1. Tap on the image file to open the file on the display.
2. Tap
3. Tap t to delete the note.
n to edit a note.
x or the Close Keyboard icon.
n to edit a note.
3. Tap An icon also identifies the annotation type. When the file includes
an annotation, the icon changes to include a yellow dot.
t (see top right of the display) to delete multiple files.
11
ii900/ii910
Mode d’emploi
Find Quality Products Online at: sales@GlobalTestSupply.com

Photo Note

A Photo Note is an additional photo attached to the file. Examples include a photo of a label or location that adds additional information about the file.
To add a Photo Note:
1. Tap on the image file to open the file on the display.
2. Tap
3. Tap
www.GlobalTestSupply.com
4. Push the Capture button to take the photo.
5. Tap To delete a Photo Note:
1. Tap on the image file to open the file on the display.
2. Tap
3. Tap on the Photo Note icon you want to delete.
4. Tap
C to open the Photo Notes menu.
+ to open the Camera view.
The Imager adds the photo as a note.
< to close the Photo Notes menu.
C to open the Photo Notes menu.
t to delete the Photo Note.

Tag Note

A Tag Note is a set of predefined fields attached to a file. These fields store data about the file that is useful for comparison and evaluation.
To add a Tag Note:
1. Tap on the image thumbnail to open the file on the display.
2. Tap
3. Tap on the tag category you want to add: a. General
b. Leaks
to open the Tag Note menu.
• Asset name: Open text field
• Asset ID: Open text field or enter with QR Code scan (see step 4).
• Asset Type: Pre-defined list of asset types.
• Inspection Status: As found; As left (Default: Undetermined).
• Action required: Yes, No (Default: Undetermined).
• Priority: High; Medium, Low (Default: Undetermined).
• Type of Leak: Based on outcome of on-device analysis. Option for end-user to modify.
• Type of Gas: Pre-defined list of gas types.
• Pressure of Line/Pressure unit system: Open numeric entry.
12
Acoustic Imager
Find Quality Products Online at: sales@GlobalTestSupply.com
Menus
c. Electrical (ii910)
• Discharge Type: pre-defined partial discharge type by on-device data analysis and highest likelihood. Option for end-user to modify.
• Voltage / Frequency: Open numeric entry.
• Ambient Temp: Open numeric entry.
• Relative Humidity (%): Open numeric entry.
• Weather Notes: Open text field.
d. Mechanical (ii910)
www.GlobalTestSupply.com
For QR code-based Asset ID recognition:
4. Tap to use the camera to capture and read QR code.
5. Tap to close the Tag Note menu.
• Component Type: Pre-defined list of mechanical components.
• Speed (RPM): Open numeric entry.
• Severity: High, Medium, Low (Default: Undeterminded).
Inspection Status: Asset Inspection Status helps you to select and assign the status of inspection:
Action required: Yes, No (Default: Undetermined).
Action priority: High , Mediu m , Low (Default: Undetermined).
Action notes: Open text field.

Acoustics

The Acoustics menu shows all the available settings for adjustment.

Show PD Count: On or Off (ii910 PDQ Mode only)

The PD Count (Partial discharge pulse count) value is an indication of the number of pulses/minute that the Imager dete cts.

Show dB Scale: On or Off

You can choose to show or hide the dB scale. Turn off the dB scale to see a larger visual area on the display.

Min / Max dB

The minimum/maximum decibel (dB) settings determine the sound level (intensity) that shows on the SoundMap. Decibel level thresholds help you to visualize leaks in challenging conditions, for example, very small leaks or a lot of background noise in the same frequency range as a leak. For more information, see Profiles.
Auto: Automatically adjusts the Color Palette Scale to the minimum/maximum decibel value for the received sound pressure.
Manual: The Color Palette Scale is a user-defined minimum/ maximum decibel value. Levels above the maximum value show on the display with the same color as the maximum value. Levels below the minimum value do not show on the display.
When Manual is selected, use the +/- to adjust. Or, tap on the dB SPL scale and use the slider to manually adjust the minimum and maximum in decibel values of the Color Palette Scale.

High Frequency (ii910)

Toggle between the standard frequency range up to 52 kHz and the expanded frequency range up to 100 kHz.
13
ii900/ii910
Mode d’emploi
Find Quality Products Online at: sales@GlobalTestSupply.com

Single Source/Multiple Sources

The Single Source mode shows less noise and reflection on the display. Smaller leaks or partial discharges do not show when they are close together with larger leaks or PD in the same field of view.
The Multiple Sources mode will not mask smaller leaks or partial discharges when they are in presence of larger leaks or PD. When in Multiple Sources mode, several markers show on the display to indicate the peak dB level of any detected source of sound.
Note
The central marker does not show on the display in the
www.GlobalTestSupply.com
Multiple Sources mode. The Multiple Sources mode is not available in MecQ mode.

Profiles

Profiles allow you to reuse the manual settings such as Frequency band, Max dB scale and Min dB scale, and Palette.
On: A preset profile is active. The icon in the center bottom of the display allows you to select a profile or save the current settings as a profile.
Off: Turn off the preset profile.
Note
When you turn on and turn off the Imager, the settings for Frequency Band, Max dB, Min dB, and Palette reset to the values in the selected profile, not the current settings when the unit is turned off. If no profile is selected when the Imager is turned off, the Imager uses the factory-default profile.

MecQ Mode (ii910 MecQ Mode only)

MecQ offers three modes to identify potential mechanical areas of interest:
Mode 1: 30 kHz mode (default). This mode automatically activates the 30 kHz frequency band.
Mode 2: User selection mode. In this mode you can select any frequency range between 2 and 100 kHz
Mode 3: Fixed Multi mode. This mode automatically activates five predefined frequency bands.

Palette

Select the palette for the acoustic image. The color palettes offer an equal, linear presentation of colors for the best presentation of data detail. Or you can switch the live visual camera to greyscale mode.

Markers

When the Centerpoint Marker is On, the dB level of the Centerpoint shows on the display as value on the center of the display.
Note
The display shows the dB value of the selected frequencies as received in the center of the Field-of­View. This is not the dB value of the sound source.

Settings

The Settings menu shows all the available settings for adjustment.

File Format

set image format (JPG or PNG)
set video format (MP4 format)
14
Acoustic Imager
Find Quality Products Online at: sales@GlobalTestSupply.com
Menus

Date & Time

set date and format
set time and format

Display

turn on or turn off the display logo

Localization

select language
set decimal separator to point or comma
set units of measurement
www.GlobalTestSupply.com

Factory Settings

Startup Profile, see Profiles
Reset to Factory Defaults
Clear User Data (clear all images, videos, and other user data)

Operating Conditions

Set LeakQ Operating Conditions
1. Input the data relevant to your system and operating
conditions.
2. Select the LeakQ metrics (rate/costs or LeakQ scale) to
display.
Set PDQ Mode network operating frequency (ii910) . Se
lect your network operating Frequency.
1
2. Select the PDQ indicators to display: Discharge Type, PD Count, Real time PRPD Plot.

Imager Info

firmware version
hardware version
device registration Use a mobile phone to scan the QR code and register your
device to receive important product updates. The serial number and model number are automatically found during the registration process.

Test Microphones

verify the correct operation of the microphones

Save Diagnostic Information

use at request of Fluke Customer Service to save diagnostic information
Note
The diagnostic info file is saved in the Imager memory at /User Data/DiagnosticInfo/.
15
ii900/ii910
1
2
3
4
Mode d’emploi
Find Quality Products Online at: sales@GlobalTestSupply.com

Basic Operation

The Imager works much like a point-and-shoot camera.
W Caution
Do not place hand on or obstruct the acoustic sensor. Always use the sensor cover when the Product is not in use.
1. Remove the sensor cover before use.
2. Push and hold
3. Aim the Imager at the test area.
www.GlobalTestSupply.com
Ideal distance is 1 m to 8 m (3 ft to 26 ft). With good line-of-sight, >8 m to 21 m (>26 ft to 70 ft).
4. Select a band on the frequency spectrum on the right side of the display. See Table 4.
5. Change the width of the band by sliding the edges or move by sliding the middle of the band.
6. The optimum band depends on the environment and application. As an example for finding air or gas leaks, start with a band at 35 kHz and width that spans 5 kHz.
High frequency peaks within the selected band may be caused by sources other than a leak or partial discharge. In this case, move the band to another frequency range.
If a strong source of sound is off the field-of-view, the display shows a circular pattern (flower) of hot spots on the SoundMap. In this case, scan around for the source of sound.
O >2 s.
Note
Table 4. Frequency Band Adjustment
Item Description
A
Frequency Band Move within the Spectrum: Touch center of box until
B
arrows show. Slide the box up and down to move the frequency range.
Adjust high end: Touch upper edge of box until
C
arrows show. Slide edge up to change high end of the frequency range.
Adjust low end: Touch lower edge of box until
D
arrows show. Slide edge down to change low end of the frequency range.
Maximum Frequency Range:
ii900...........52 kHz
ii910...........100 kHz
16
Acoustic Imager
Find Quality Products Online at: sales@GlobalTestSupply.com

File Transfer

7. When the area of interest clearly shows, push the Capture
button. The Imager saves the image to memory.
Tip: Sound signals reflect, particularly on smooth and flat surfaces. In certain conditions, the Imager shows a steady spot on the source of noise and one or more steady spots from the reflections. Move the Imager around to help discriminate the sound source from the reflections. The sound source remains in the same location, while reflections will move.
Use folders to organize your files. New file captures save to the folder name that shows on the display. You have the option to review files by folder name or timestamp.
www.GlobalTestSupply.com
To select a folder or create a new folder name:
1. Tap on the folder name that shows at the bottom of the
display. A list of folder names pops up with the option, Create Folder.
2. When you select Create Folder, use the keyboard to input a
new file name.
For more information about how to view the images in memory, see Memory.
File Transfer
To transfer saved files from the Imager to a PC:
1. Use the provided USB cable to connect the Imager to the PC.
A USB drive is added to the list of drives on your PC.
2. Open the added USB drive to view the saved images or video
files.
3. Copy the files you want to the local PC drive.
4. When transfer is complete, remove the USB drive from your PC.
The Fluke Connect Desktop application is another method you can use to download images or video files. See Import Saved Images
or Video Files with Fluke Connect Desktop.

Import Saved Images or Video Files with Fluke Connect Desktop

Fluke Connect Desktop is an application installed on a local PC. To import saved images or video files:
1. Start the Fluke Connect Destop application on your PC.
2. Turn off the Imager.
3. Connect the Imager to the PC with a USB/USB-C cable.
4. Turn on the Imager.
5. Open Fluke Connect Desktop on the PC. The Fluke ii900 Series shows in the TOOLS tab.
6. Select DOWNLOAD.
7. Use DOWNLOAD ALL or SELECT FILES to transfer all or a selection of files to Fluke Connect Desktop.
8. Select the destination folder and select OK.
9. Confirm deletion of downloaded files from the Imager or select CANCEL to proceed and keep the files in the Imager.
Downloaded files are now available in the MEASUREMENTS tab.
17
ii900/ii910
Mode d’emploi
Find Quality Products Online at: sales@GlobalTestSupply.com

Firmware Update

Firmware updates are available for the Imager. Connect the Imager to Fluke Connect Desktop to find the most current firmware version.
To update with Fluke Connect Desktop:
1. Use the provided USB cable to connect the Imager to a PC with the current version of Fluke Connect Desktop software installed.
Fluke Connect Desktop software detects the connected Imager, checks the firmware version, and updates the Imager
www.GlobalTestSupply.com
if a newer firmware version is available. Fluke Connect Desktop requires an Internet connection to
download a new firmware version. The Imager shows a popup message to confirm the update.
2. Tap YES to confirm and start the firmware update. The Imager shows a popup message to restart the Imager.
3. Tap YES to restart the Imager.
To update with a .swu file:
1. Download the firmware update (.swu file) from the website to a PC.
2. Use the provided USB cable to connect the Imager to the PC with the new firmware update file. A USB drive is added to the list of drives on your PC.
3. Copy the firmware update file (.swu) from the PC to the root folder (/User Data/) of the added USB drive.
4. When the file copy is complete, safely remove the USB cable from your PC. The Imager shows a popup message to inform you that a firmware update is found.
5. Tap YES to confirm and start the firmware update. The Imager shows a popup message to restart the Imager.
6. Tap YES to restart the Imager.

Maintenance

The Imager does not require routine maintenance.
W Caution
The optical surfaces of the lens are equipped with high-quality optical layers. Avoid any contact with these surfaces and protect these surfaces against dirt and damage.

How to Clean the Case

Clean the case with a clean, damp cloth. Do not use abrasives, isopropyl alcohol, or solvents to clean the case or lens/window.

Acoustic Sensor Care

W Caution
The Imager has highly-sensitive acoustic sensors. Do not expose the sensors to water or fluids, dust, and other contaminates. Accumulation of these in the sensor will affect the performance.
Always keep the Acoustic Sensor protected with the provided cover when the Imager is not in use. Avoid grease or liquids on the microphones. If the microphones are dirty or clogged, carefully clean with low air pressure from a compressed air duster at 25 cm to 30 cm (10 in to 12 in) distance. Avoid too much air pressure.
18
Acoustic Imager
Find Quality Products Online at: sales@GlobalTestSupply.com
Maintenance
To check the microphones:
1. Go to Settings menu.
2. Select Test Microphones. If you see a warning message for service:
1. Clean the microphones with an air duster.
2. Test the microphones again. If the message continues,
contact a Fluke Service Center.

Environmental

www.GlobalTestSupply.com
This Imager has electronic printed circuit boards. These components must be disposed of specifically when the device is at the end of its use.
The manufacturer offers to take back the Imager from the customer to ensure that the device is disposed of in an environmentally-friendly manner when it is at the end of its use.

Product Disposal

Dispose of the Product in a professional and environmentally sound manner:
Delete personal data on the Product before disposal.
Remove batteries that are not integrated into the electrical system before disposal and dispose of batteries separately.
If this Product has an integral battery, put the entire Product in the electrical waste.

Service

Fluke recommends that you service the Imager at two-year intervals (depending on operating conditions) to maintain optimum performance.
Contact your equipment distrib u to r o r au th o r i ze d Fl uk e Service Center for any equipment performance failure or to schedule regular maintenance service.
19
Loading...
