Fluke 164
2.7 GHz MultiFunction Counter
Fluke’s new MultiFunction
Counter is more than just a
high accuracy top-performance counter; it adds a
wideband DVM and
displays waveform information like an oscilloscope.
Three different
presentation modes let you
VIEW, MEASURE and
ANALYZE your signal.
These presentation modes
supply measuring data, as
seen from different
perspectives, giving more
insight and confidence.
• In the WAVEFORM Mode,
the bright LCD display
shows the input signal
and trigger level, so you
can see that what you are
measuring is correct. At
the same time you can
read off the measurement
which is displayed at up
to 10 digits resolution.
• The VALUES mode
displays up to 10 different
signal parameters
simultaneously, giving a
wealth of information
about the signal being
measured.
• The STATISTICS mode
gives statistical data over
any number of readings
up to 1 000 000, and
reveals trends, jitter, drift,
etc. It reduces random
errors by statistical
averaging, so enhancing
accuracy.
Best of all is the ease-of-operation of
this new instrument. Simple menu
selection and an intelligent AUTOSET
makes everyone an expert user and takes
all the hard work out of getting results.
With just a few keystrokes, the
MultiFunction Counter helps you to
measure more with better results, faster
and with less effort.
Now you can confidently VIEW,
MEASURE and ANALYZE parameters like:
Frequency, Period, Vmax, Vmin, Vpeakpeak, Pulse Width, Rise-/Fall Time, Duty
Cycle, Time Interval, Phase, Burst
Frequency, Vdc, true RMS Vac, Jitter and
Totalize of Counts.
The MultiFunction Counter delivers
high-resolution, high-accuracy readings of
up to 10 digits. Accuracy is enhanced by a
choice of high-stability oscillators,
including TCXO and an ovenized oscillator.
This is the ideal instrument for verification,
alignment, calibration and analysis when
you need accurate results. It is easier to
use than a traditional counter, and more
accurate than an oscilloscope is for timing
and frequency measurements.
• Total signal characterization, with up to
10 parameters displayed
simultaneously.
• 160 MHz / 2.7 GHz frequency counting.
• Up to 10-digits resolution.
• 1 ns single-shot time resolution.
0.01° phase resolution.
• See signals up to 50 MHz and read
voltages, including true-RMS.
• Confident triggering through visual
waveform verification.
• High-stability timebases, including
ovenized crystal oscillator.
• Easy to learn, easy to use, easy to get
results.
• AUTOSET for foolproof results.
• Handheld, rugged, battery operation:
Ideal for field use.
• 3 Years warranty, 40 000 hours MTBF.
• RS-232 interface for programmability
and downloading of data.
• Optional FlukeView®for Windows®to
analyze, document and store your
results.
View, Measure and Analyze with confidence
Technical Data
1
New technique captures
fast transitions more
effectively
Figure 1a shows the MultiFunction
Counter’s Transitional-Sampling™. From
the start trigger point, many time intervals
are measured at different trigger levels,
scanned over the entire waveform. This
technique concentrates sample data on
transitions, where high time resolution is
most needed. Vertical resolution is defined
by the 8-bit trigger level DACs, supplying
256 vertical steps.
Figure 1a. This drawing shows how the
MultiFunction Counter’s unique Transitionalsampling™ concentrates sample data on
transitions, obtaining a high time resolution of
<1ns in all time base positions (>1 GSa/s
effective sample rate).
Figure 1b. By comparison, this drawing shows
Time Sequential sampling, which is
traditionally used in DSOs. Only a few samples
are taken on transitions, creating the risk that
very narrow pulses will be missed.
Unique capabilities to
measure Low Duty Cycle
signals
Unlike DSOs, Transitional-Sampling™
resolution does not depend on time-base
settings, and captures down to 6 ns
narrow pulses with < 1ns time resolution
at all time-base settings. This offers a
unique capability to measure low duty
cycle signals. For example, figures 2a and
2b show a 1 µs radar pulse. Figure 2a
shows two cycles of the 1 ms pulse period,
while simultaneously the pulse width is
measured with 5 digits resolution.
Figure 2b views the pulse shape, while
the frequency (or another parameter) is
measured with very high accuracy.
WAVEFORM presentation mode
Figure 2a. Despite a 1÷1000 low duty cycle,
the MultiFunction Counter displays the pulse
width with high accuracy.
Figure 2b. This screen shows all the pulse
details yet is 1000 x faster than in figure 2a.
Simultaneously the frequency is measured
with 10 digits resolution.
VALUES presentation mode
Figure 2c. In the VALUES presentation mode,
all signal parameters can be shown
simultaneously, without the need for setting
changes per measurement. Any parameter
can be selected as “primary”, to be displayed
at the top of the screen in large numerals and
with full resolution.
Analyze with Statistics
A single keystroke gives statistical data
such as the Mean, Maximum, Minimum,
Max-Min and Standard Deviation of a
number of samples. By definition, the
Standard Deviation of Time Interval
samples gives the RMS jitter. The Max-Min
represents the peak-peak jitter. For FM
frequency measurements, the Max-Min
returns the peak-to-peak deviation of the
frequency, while MEAN gives the carrier
frequency.
STATISTICS presentation mode
Figure 2d shows how STATISTICS reveals
much more about the signal than a single
measurement ever could. E.g. jitter, drift,
wander or modulation.
VALUES presentation mode
2
®
Accurate Phase
Measurements
Figures 3a and 3b show how a MultiFunction Counter performs, where by
contrast both a Phasemeter and a scope or
DVM would be required.
Figure 3a. The signal on channel B represents
the output signal from a filter network, that is
delayed in phase with respect to the input
signal A.
Figure 3b. The Vp-p values of the output and
input signals indicate a ratio of
439mV ÷ 629mV = 0.7 i.e. at the frequency
where the output signal B is 3dB down versus
the input signal A. The frequency and the
phase delay are measured simultaneously
with high accuracy.
Advanced trigger features
The Model 164’s special trigger features
enable you to capture a particular signal
out of a stream of pulses, by ignoring
unwanted signals. An example would be
measurements on mechanical relays and
switches. Contact bounce at the beginning
of the signal does not normally allow a
traditional counter to measure the pulse
width digitally. Start and stop at the first
trigger event would result in an erroneous
measurement of only the first bouncing
contact closure. Trigger Hold-Off enables
the MultiFunction Counter to ignore “stoptriggering” over a pre-settable time of
200 ns to 1.6 s.
Figure 4. Despite contact bounce, the relay”ON” time is measured, thanks to the set 5 ms
trigger Hold-Off time. This allows accurate
adjustments of relays and switches.
Frequency Measurements
with Error-free triggering
Frequency measurements on basic signals
are best made with AUTO Trigger.
Figure 5a. The MultiFunction Counter gives
correct results even on a noisy signal. AUTO
Trigger centers the trigger level at 50% of
amplitude and adjusts the trigger hysteresis
band (noise immunity band) to 33% of the
input amplitude to provide optimal noise
immunity.
Figure 5b. By comparison, this figure shows
how too high a sensitivity in a traditional
counter could give erroneous results. Too high
a trigger sensitivity means that noise forces
the input signal to cross the trigger level (very
narrow hysteresis band) more than once per
input cycle and cause false counts.
3
Manual Trigger
Special applications with composite or
complex signals often require manual
trigger setting. The MultiFunction Counter
gives full control over triggering. The
trigger level can be set and is visible as
cursor-lines on the waveform, see figures
6a and 6b.
Figure 6a. Frequency measurement with
manual trigger level setting, where only the
last pulse in each pulse-burst triggers the
counter. This means you can measure the
repetition frequency of the burst reliably.
Figure 6b. When making a pulse width
measurement, for instance to check the
linearity of a DAC, the trigger level can be set
and monitored to accurately measure the pulse
width at each step on a stair case signal.
Automatic Burst
Measurements
Amongst frequency measurements,
measurements on bursts are the most
difficult ones to perform. One may want to
measure the pulse- or carrier frequency
inside the burst i.e. the “Burst frequency”,
or the “Burst repetition frequency”. The
MultiFunction Counter is unique in
offering fully automatic triggering on
burst signals.
Burst frequency
Burst frequency measurements require a
measurement that is synchronized with
the presence of the burst. Some counters
feature external arming and arming delay
to synchronize the start of a measurement
with an external signal. A requirement is
that the measuring time be set shorter
than the burst duration and that the
counter has a high resolution to obtain the
accuracy required. The MultiFunction
Counter measures Burst Frequencies fully
automatically.
Burst repetition frequency
Burst repetition frequency measurements
require that only one count per burst is
counted. Trigger Hold-Off can prevent a
counter from being triggered more than
once per burst. Figures 7a and 7b show
how the MultiFunction Counter
automatically measures both the Burst
Frequency (cycles inside the burst) and the
Burst Repetition Frequency. Thanks to the
high resolution, the readout is in 6 digits
despite the fact that the “narrow” burst of
106µs contains only 12 cycles.
Figure 7a. An automatically measured burst
frequency of 113.449 kHz.
Figure 7b. The MultiFunction Counter
measures automatically and shows
simultaneously both the burst frequency and
the burst repetition frequency.
Figure 7c. The Burst settings, as automatically
derived from the input signal (in figures 4a
and 4b) by the green AUTO SET button.
INFO and Tutorial
By pressing the INFO key,
On-Line information is given on any
function or setting that is selected by the
On-Screen cursor. A built-in Tutorial gives
an overall explanation of the MultiFunction
Counter, eliminating the need to carry a
manual on-site.
Figure 8. The Sync Delay INFO screen,
showing a typical example of the information
given.
4
Specifications
®
Presentation Modes
Waveform: Displays recurrent signals and
trigger settings. Eliminates the need for a
separate oscilloscope to verify the input
signal and correct triggering. Displays
additionally one selected timer/counter
read-out with up to 10 digits resolution
plus the input signal’s Vp-p value.
Values: Up to 10 simultaneous readings of
frequency, time and voltage, just like on a
Counter, DVM and Phasemeter.
Statistics: Mean, Maximum, Minimum plus
Peak-to-Peak and Standard Deviation of a
selected number of samples; sample size:
2 to 106.
Timer/Counter Functions
Frequency limits: Minimum input
frequencies specified below are with
manual trigger setting and read-out in the
VALUES and STATISTICS presentation
modes. When using AUTO trigger or ACcoupled inputs, the minimum frequency is
20 Hz. Unless otherwise specified, the
maximum frequency is 50 MHz (60 MHz
typically) and the minimum pulse width is
6 ns, at set trigger level.
Frequency
Input A & B: 1µ Hz to 160 MHz (DC-
coupled)
20 Hz to 160 MHz
(AC-coupled)
Input C: 140 MHz to 2.7 GHz
(164H/164T only)
Resolution: 9 digits/s
Burst Repetition Rate and
Frequency in Burst
Frequency in Burst:
Input A & B: 1 Hz to 70 MHz
Input C: 140 MHz to 2.7 GHz
(164H/164T only)
Resolution: 9 digits/s burst time
Burst Repetition Rate:
Input A & B: up to 1 MHz
Input C: up to 20 kHz
(164H/164T only)
Resolution: 9 digits/s
Period
Input A & B: 6 ns to 106s
(1µ Hz to 160 MHz)
Input C: 770 ps to 14 ns
(140 MHz to 2.7 GHz),
(164H/164T only)
Resolution:
Single cycle: 1 ns (A, B)
Multiple cycles
averaged: 9 digits/s (A, B, C)
Frequency Ratio fl/f
2
fA/fB, fB/fA,
fC/fA, fC/fB:10
-9
to 10
9
Input A & B: 1µ Hz to 160 MHz
Input C: 140 MHz to 2.7 GHz
(164H/164T only)
RPM
Input A & B: 1x10
-5
RPM to 109RPM
(with 1 pulse/revolution)
Transducer
scaling factor: 1 to 106pulses/ rev
Time Interval
Input A & B: 0 ns to 107s
Resolution: 1 ns
Positive/Negative Pulse Width
Input A & B: 6 ns to 107s
Resolution: 1 ns
Rise/Fall Time
Input A & B: 6 ns to 107s
Resolution: 1 ns
Pulse amplitude: ≥ 500 mVp-p
Duty Cycle
Input A & B: 0.000 1 to
99.999 9%
Frequency Range: 10 mHz to 50 MHz
Resolution: 0.000 1% or (Input
Frequency / 1 GHz) x
100%, whichever is
greater
Phase
Input A & B: -180.00° to +360.00°
Frequency
Range: 10 mHz to 50 MHz
Resolution: 0.01° or (Input
Frequency / 1 GHz) x
360°, whichever is
greater
Totalize of counts, manual
and/or during set measuring
time
Range: 0 to 1014counts / up to
100 MHz
Manual mode: Counts pulses
simultaneously on
inputs A and B.
Pulse-count
displayed: A, B, A-B or A+B
Start/Stop: Run/Hold key
Timed mode: Counts pulses on A,
during set time:
200 ns to 15s
Pulse Width: ≥ 5 ns
Totalize of counts,
with external control signal
Input A & B: 0 to 1014counts / up to
100 MHz
Measurement
modes: Counts pulses on input
A, between start and
stop pulse on B or
during gate signal on B
Pulse Width: ≥ 5 ns
5
Measuring time and
synchronization
Measuring Time
Multiple cycles: Averaged during 200 ns
to 15s with 100 ns resolution. Used for
Frequency, RPM, Period Average and Ratio.
Also used for Totalize of pulses with timed
stop.
Single cycle: Used for Single Period A &
B, Time Interval, Pulse Width and Rise/Fall
times.
Display time: Measuring time or 200 ms
whichever is greater.
HOLD / RUN: HOLD freezes last result.
RESTART starts new measurement.
Additional Trigger Control
Normally, measurements are immediately
started/stopped by the first input event
that meets the trigger conditions. Arming,
Arming Delay and Hold-Off are additional
trigger control features that enable the
counter to measure at a specific point in a
stream of pulses on input A, by ignoring
triggering during a set delay time and/or
as long as an additional trigger condition
on input B has not been fulfilled.
Arming ON: Start triggering is enabled
directly after an external arming signal has
triggered the arming input B. Applies to
Frequency, Period or Pulse Width
measurements.
Start Arming Delay: 200 ns to 5s. After
arming, an additional delay is inserted
before the instrument can be starttriggered for a new measurement.
Trigger Hold-Off: 200 ns to 5s. Stop
triggering is inhibited during the set trigger
Hold-Off time. Applies to Time Interval,
Pulse Width, and Rise/Fall Time
measurements.
Voltage Functions
Tolerances: Uncertainties specified apply
from 10% to 100% of full range - and
from18°C to 28°C, after 30 minutes warmup time. Add (specified uncertainty) x
0.1/ °C at < 18°C or > 28°C. Confidence
level corresponds to 2σ for a normal
Gaussian distribution ( > 95%).
Peak Voltage
(V max, V min, V p-p)
Voltage range
A & B: 500 mV, 5.00V, 50.0V
Frequency Range: 20 Hz to 50 MHz
Uncertainty:
20 Hz to 2 kHz 2% + 0.2% of range
2 kHz to 5 MHz 4% + 0.2% of range
5 MHz to 20 MHz 10% + 1% of range
20 MHz to 50 MHz 25% + 1% of range
DC Voltage
Voltage Range
A & B: 500 mV, 5.00V, 50.0V
Uncertainty: 2% + 0.2% of range
AC or AC+DC True-rms Voltage
Voltage Range
A & B: 300 mV, 3.00V, 30.0V
Peak voltages: 500 mV, 5.00V, 50.0V
Frequency Range: 1 Hz to 10 MHz
Uncertainty (sine):
20 Hz to 50 Hz 2% + 0.2% of range
(DC + AC), 4% + 0.2%
of range (AC coupled)
50 Hz to 2 kHz 2% + 0.2% of range
2 kHz to 5 MHz 4% + 0.2% of range
(4% + 2% of range in
300 mV range)
5 MHz to 10 MHz 10%+1% of range
(10% + 2% of range in
300 mV range)
Crest Factor: Any signal tolerated within
Vp limits. Instrument calibrated for
sinewaves. For other signals, with crest
factors up to 3.0, add 2% + 2% of range
(typically).
Multiple Parameter Display
Automatic waveform characterization with
simultaneous display of all parameters,
relevant for selected signal type:
Signal type Parameters displayed
simultaneously
SINE like Frequency, Period, Vmax,
signals: Vmin, Vp-p
PULSE like Frequency, Period,
signals: Positive Pulse Width,
Negative Pulse Width,
Rise Time, Fall Time, Duty
Cycle, Vmax, Vmin, Vp-p.
BURST Burst Frequency, Burst
Repetition Rate, Vmax,
Vmin, Vp-p.
Waveform Display Function
Displays the waveform of recurrent input
signals. Eliminates for most signals the
need for a separate oscilloscope to verify
the input signal and correct triggering.
Uses the same inputs A & B as for Timer/
Counter and Volt modes. For viewing
complex signal patterns, dynamically
changing signals or low amplitude signals,
a fully featured oscilloscope can be
expected to give a better signal
representation.
Transitional Sampling™ (HF):
(Vertical Sampling) The waveform is
captured by measuring Time vs. Voltage
samples. Measured time intervals start at
the set start trigger point and stop at
consecutive stop trigger points, scanned
over the entire signal.
Bandwidth: 50 MHz
(-3 dB on Vp-p display)
Rise time: 3.5 ns.
Effective
sampling rate: 1 GSa/s at >20ns/div
3 GSa/s at ≤20ns/div
Glitch detect: ≥6 ns repetitive pulses.
Always active
independently from
time-base setting.
Time Sequential Sampling (LF)
(Horizontal Sampling)
Frequency Range: 1 Hz to 2 kHz
Sampling Rate: Up to 40 kS/s
AUTO Sampling: Automatic selection
between HF Transitional Sampling™ and
LF Time Sequential, based on detected
input signal frequency and pulse width.
Vertical deflection
Display Modes: One or two input
channels, automatic
selection depending on
selected measure
function
Frequency
response: 1 Hz to 50 MHz
(-3dB in Vp-p display)
AC coupled: 20 Hz to 50 MHz
(-3dB in Vp-p display)
Coupling: AC/DC
Rise time: 3.5 ns (transitional
sampling mode)
Display Voltage
Range: 100 mV to 50V.
Sensitivity: 20 mV/div to 10V/div,
auto scaling
Accuracy: 2% + 25 mV
Divisions: 8
6
Horizontal deflection
Time Coefficients: 5 ns/div to 0.2 s/div,
AUTO or manual scaling
Accuracy: 1 ns + 1 pixel
(transitional sampling)
25 µs + 1 pixel
(time sequential
sampling)
Divisions: 8 div + 2 div pre-trigger
data (transitional
sampling mode only)
Max. display
length: 5 input signal cycles
Waveform Triggering
Sources: Input A or B, automatic
selection, depending on
selected MEASURE
FUNCTION
Trigger
sensitivity: 60 mVp-p to 10 MHz
90 mVp-p to 50 MHz
120 mVp-p to 75 MHz
Trigger level
and slope: AUTO SET or manual
Inputs and Outputs
Input A & B
Frequency Range: Frequency limits for
MEASURE FUNCTIONS and WAVEFORM
display are separately specified; see
Timer/Counter, Voltage and Waveform
Functions.
Low Pass Filter: ≤ 100 kHz
Impedance: 1 MΩ / 15 pF
Trigger Level
Range: ±500 mV, ±5.00V or
±50.0V
Resolution: 1, 10 or 100 mV
Uncertainty: ± 1% + resolution
Setting: AUTO, Manual
Read-out: Digital read-out,
or with trigger lines on
WAVEFORM display.
Trigger sensitivity, manual trigger
setting:
± 0.5V/± 5V
range: 20 mVrms sine
(DC to 50 MHz)
40 mVrms sine
(50 MHz to 160 MHz)
± 50V range: 200 mVrms sine
(DC to 50 MHz)
400 mVrms sine
(50 MHz to 160 MHz)
AUTO Trigger:
Level: Automatically set at 50% of input
signal’s Vp-p value, or at 10% and 90% of
Vp-p for Rise/Fall Time measurements
Trigger hysteresis: In Frequency and
Period Average modes, hysteresis is
automatically set to approx. 33% of input
signal’s Vp-p value to provide optimal
noise immunity. For all other functions, the
hysteresis is equal to the specified trigger
sensitivity (manual setting) up to 120 MHz.
Above 120 MHz the trigger hysteresis
increases to 100 mV (0.5V/5V range), and
to 1V (50V range).
Min. Frequency: 20 Hz.
Maximum input voltage:
No instrument
damage: 240Vrms up to 1 kHz,
decreasing linearly to
6Vrms at 10 MHz.
Safe for user: 100Vrms (models
163/164 only), 30Vrms
(models 164H/164T).
Floating voltage: All inputs: 300Vrms to
ground, (models
163/164 only), 30Vrms
(models 164H/164T)
Input C
(models 164H/164T only)
Frequency Range: 140 MHz to 2.7 GHz
Prescaler Factor: 64
Operating Input Voltage:
140 to 300 MHz: 20 mVrms to 5Vrms
0.3 to 2.1 GHz: 10 mVrms to 5Vrms
2.1 to 2.4 GHz: 20 mVrms to 5Vrms
2.4 to 2.7 GHz: 70 mVrms to 5Vrms
Impedance: 50Ω nominal, AC
coupled, VSWR <2:1
Maximum Voltage
Without Damage: 12Vrms, during 60s,
PIN-diode protected
Ext. Reference Input
Frequency: 10 MHz
Voltage Range: 500 mVrms to 12Vrms
Impedance: Approx. 500Ω, AC
coupled
Test signals output
Reference
frequency: 10 MHz square-wave
Probe
Compensation: 2 kHz square-wave
Gate Monitor: Gate open: low,
gate closed: high
Test Signal Source:
Square-waves,
selectable: 1 Hz, 50 Hz, 100 Hz,
1 kHz, 10 kHz, 100 kHz,
1 MHz and 5 MHz
Low- and highduty cycle pulses: 1 kHz/0.2 µs and 1 kHz/
999.9 µs.
Output levels: Fixed TTL:
low = <0.4V,
high = >1.8V into 50Ω
RS232 Data input/output
Connector: Isolated optical connector, for
use with optional optical-to-RS232
adapter PM9080/001
Input: Full programmability via LEARN
data strings and RECALL of up to 10
complete instrument settings.
Output: Measurement data, see also
FlukeView®.
FlukeView
®
SW 160/011 Optional FlukeView®;
MultiFunction Counter software for
Windows
®
Documenting: Transfers waveforms and
measurement data from MultiFunction
Counter to a PC with the optional opticalto-RS232 adapter PM9080/001. Print out
complete screens directly or store graphical
data in a popular file format to import into
word processor or spreadsheet programs.
Archiving: Waveform storage and retrieval
with text annotations like measurement
conditions and instrument set up.
Analysis: Log and graph readings to
monitor and analyze signal variations and
related events, reveal relationships and
conditions that could otherwise remain
hidden.
®
7
Auxiliary Functions
Statistics
Statistical functions: Maximum, Minimum,
Mean, Standard Deviation and Peak-toPeak Deviation (= Max-Min) of a selected
number of samples, (not available in
Totalize modes).
Error reduction: Random uncertainties for
instance from noise and jitter can normally
be reduced by √N, by averaging a number
of measurement readings.
N (Sample Size): 2 to 1 000 000
Mathematics
Mathematics: Display = (K x measure-
ment result) + L.
Constants K and L: 0 to ±10
±20
, key-board
entry in 12 digits
resolution
Tutorial and INFO
Built-in Tutorial and context-sensitive INFO
explain settings and operation
Save / Recall
Instrument
set-ups: 10
Screen images: 1 (WAVEFORM, VALUES
or STATISTICS)
General
Quality and maintenance
Quality control: ISO 9001 quality system
Warrantee: 3 years parts and labor
MTBF 40 000 hours
Calibration: Closed Case Calibration,
recommended interval:
12 month
Display
Super Twisted Liquid Crystal with Cold
Cathode Fluorescent backlight
Size: 84 x 84 mm,
4.7” diagonal
Resolution: 240 x 240 pixels
Brightness: selectable,
max. 50 cd/m
2
Contrast ratio: adjustable,
max. 1:15
(typical at 20°C)
Environmental Data
Temperature:
Operating: 0°C to 50°C
Storage: -20°C to 70°C
Humidity:
Operating: 20°C to 30°C, < 90%
RH non-condensing
30°C to 50°C, < 70% RH
non-condensing
Storage: < 95% RH
Altitude:
Operating: < 3000 m (10 000 ft)
Storage: < 12000 m (40 000 ft)
Vibration: Up to 3G at 55 Hz, per
MIL-T-28800E, Class 3
Shock: Half-sine shock pulse
30G, per MIL-T-28800E,
Class 3
EMC: Emission: EN 55011 ISM
Group 1, Class A.
Susceptibility: EN 50082-2
Safety
Safe Operation: 100Vrms to 10 kHz
(model 164 only),
30Vrms (models
164H/164T).
Floating voltage: All inputs: 300Vrms to
ground, (model 164
only), 30Vrms (models
164H/164T).
Compliance: EN 61010-1:1993,
Cat. ll CE
CSA CAN /
CSA - C22.2
No.1010.1 - 92
AC/DC adapter: UL: UL1310 Class 2
C22.2 No. 223
Power Supply
Line voltage
adapter: 90 to 130Vrms or
190 to 255Vrms,
45 Hz to 440 Hz, 16 VA
Internal Ni-Cd
Battery: Type PM 9086, 4.8V
Typical operating
time: Pulse output and
external reference input
switched OFF, lowest
backlight brightness
level and full battery
capacity.
Model 164: 2 1/4 hours
Model 164T: 1 3/4 hours
Model 164H: 1 1/2 hours
Charging Time: 3h typical,
when instrument OFF
Alternate Battery: 4 alkaline, C cells
(user supplied)
External DC
Supply: 10V to 20V DC, 10W
typical, 6W charging
only
Input Connector: 5 mm power jack,
DIN 45323
Mechanical Data
Dimensions: 60 x 130 x 260 mm
(H x W x L) (2.4 x 5.1 x 10.2 in),
excl. holster
65 x 140 x 275 mm
(2.5 x 5.5 x 10.8 in),
incl. holster
Weight: 1.5 kg (3.3 lb),
excl. holster;
1.8 kg (4.0 lb),
incl. holster
Transport
weight: 3.4 kg (7.5 lb).
®8®
Uncertainty Timer/Counter
Measurement
Uncertainty examples in table 1 and table
2 are a simplified way to quickly obtain
the magnitude of accuracy for commonly
made measurements. The figures are
overall figures, taking into account all
instrument error-contributors, such as
quantization error, trigger errors, reference
crystal oscillator ageing, temperature drift
and one year calibration interval.
Reference is made to the Users Manual, for
exact calculations of the measurement’s
uncertainties (random, systematic and total
values), taking into account specific
manual settings, ambient temperature and
input signal characteristics such as slewrate and noise.
Frequency measurements on Sinewave
signals
Table 1 shows the uncertainty for
measurements on undistorted 1Vrms
sinewave input signals, with instrument
settings obtained through AUTOSET and
making use of the internal time-base
reference at room temperature.
Conditions that lead to a better accuracy
(reduced uncertainty) are: steeper trigger
transitions (for instance through higher
input amplitude and higher input
frequency), use of STATISTICS to average
the result of a number of readings, the use
of a more accurate external time-base
reference and a shorter calibration interval
than 12 months. In LF Frequency
measurements, the internal trigger
uncertainty is the dominant error
contributor, whereas for HF Frequency
measurements the internal time-base
uncertainty dominates.
Frequency and timing measurements on
Pulse input signals
Table 2 shows the uncertainty for
measurements on undistorted 1Vp-p pulse
signals with 10 ns rise/fall times (except
for rise/fall-time measurements, where
noted differently), with instrument settings
obtained through AUTOSET and making
use of the internal time-base at room
temperature.
Conditions that lead to a better accuracy
(reduced uncertainty) are: steeper trigger
transitions (for instance through shorter
rise/fall time and higher input amplitude),
use of STATISTICS to average the result of
a number of readings, the use of a more
accurate external time-base reference and
a shorter calibration interval than 12
months. For short duration Time
measurements, the 1 ns resolution is the
dominant error-contributor, whereas for
long duration Time measurements, the
internal time-base uncertainty dominates.
Type Standard TCXO Oven
Model 164 164T 164H
24h < 1.5 x 10
-9
(1styear)
Aging Rate per: Month < 5 x 10
-7
<1 x 10
-7
< 3 x 10
-8
Year < 5 x 10
-6
< 1 x 10-
6
< 1 x 10
-7
(after 1styear)
Temperature 0 to 50°C < 5 x 10
-6
< 1 x 10
-6
< 2 x 10
-7
Stability: 10 to 40°C < 1 x 10
-7
(after 15 min. and 18 to 28°C < 2 x 10
-6
< 5 x 10
-8
referenced to 23°C)
Factory adjustment uncertainty < 5 x 10
-6
< 1 x 10
-6
< 1 x 10
-7
at 23° C
Internal Time Base Stability
Model 164 164T 164H
Mode and input signal Absolute Absolute Absolute
uncertainty uncertainty uncertainty
Frequency & Period average:
(Period = 1÷Frequency)
≤100 Hz 1 mHz 1 mHz 1 mHz
1 kHz 5 mHz 1 mHz 1 mHz
10 kHz 50 mHz 10 mHz 1 mHz
100 kHz...2.7 GHz 5x10-6x Freq. 1x10-6x Freq. 1x10-7x Freq.
Phase:
≤100 kHz 0.1° 0.1° 0.1°
1 MHz 0.5° 0.5° 0.5°
10 MHz 5°5°5°
Frequency Ratio f1/ f2:
f2: 100 Hz 0.1 0.1 0.1
10 kHz 0.001 0.001 0.001
1 MHz 0.00001 0.00001 0.00001
100 MHz 0.0000001 0.0000001 0.0000001
Model 164 164T 164H
Mode and input signal Absolute Absolute Absolute
uncertainty uncertainty uncertainty
Frequency & Period average:
(Period = 1÷Frequency)
20 Hz to 2.7 GHz 5x10-6x Freq. 1x10-6x Freq. 1x10-7x Freq.
Period Single:
≤1 µs 1 ns 1 ns 1 ns
1 ms 5 ns 1.5 ns 1 ns
1 s 5 µs 1 µs 100 ns
Time Interval, Pulse width:
≤1 µs 1.5 ns 1.5 ns 1.5 ns
1 ms 5 ns 2 ns 1.5 ns
1 s 5 µs 1 µs 100 ns
Rise / Fall time, @ 100kHz:
≤10 ns 2 ns 2 ns 2 ns
100 ns 5 ns 5 ns 5 ns
1 µs 50 ns 50 ns 50 ns
Duty Cycle:
≤100 Hz 0.0001 % 0.0001 % 0.0001 %
10 kHz 0.0015 % 0.0015 % 0.0015 %
1 MHz 0.15 % 0.15 % 0.15 %
Table 1: Uncertainty on Sinewave signals.
Table 2: Uncertainty on
Pulse input signals.
9
Fluke 164 50 MHz / 160 MHz
MultiFunction Counter with
Standard Time Base
Fluke 164T 50 MHz / 2.7 GHz
MultiFunction Counter with
TCXO Time Base
Fluke 164H 50 MHz / 2.7 GHz
MultiFunction Counter with
High Stability Oven Time
Base
Included Accessories
Operators Manual
Calibration certificate
PM 9086 Ni-Cd Battery Pack
PM 9083 Protective Holster
PM 9651/00X AC/DC Power Adapter/
Battery Charger
For other country versions than country of
ordering, please contact your Fluke
representative.
Optional Accessories
Probes; safety designed for isolated
measurements on inputs A & B:
PM 8918/101 Probe 1:1, 1 MΩ,
12 MHz BW, (1.5 m, 5 ft)
PM 8918/002 Probe Set (2 pcs)
10:1,10 MΩ, 100 MHz BW,
(1.5 m, 5 ft)
PM 8918/202 Probe Set (2 pcs)
10:1, 10 MΩ, 75 MHz BW,
(2.5 m, 8 ft)
80i-110s Clamp-on AC/DC current
probe, DC to 100 kHz,
100 mV/A (max. 10A) or
10 mV/A (max. 100 A)
Probes; optimized for HFmeasurements:
PM 9020/001 Probe 10:1, 10 MΩ,
200 MHz BW, (1.5 m, 5 ft).
Recommended for pulse
response testing on
input A & B.
PM 9639/011 Probe 10:1, 500Ω,
1GHz (-3dB) 2.3 GHz (-6dB),
(1.5 m, 5 ft). Recommended
for frequency measurements
on input C.
50Ω BNC-BNC cables; safety designed
for isolated measurements on
inputs A & B:
PM 9091/001 cable set (3 x 1.5 m)
PM 9092/001 cable set (3 x 0.5 m)
50Ω BNC-BNC regular cables:
PM 9588/01 50Ω BNC-BNC cable set
(5 x 0.2 m, 4 x 0.4 m,
3 x 0.6 m, 3 x 2 m).
Other Accessories:
C 95 Soft carrying case
C 97B Protective hard carrying
case
PM 9080/001 Optically isolated RS-232
adapter/cable
PM 9585/01 50Ω Feedthrough
Termination, 1W
SW 160/011 FlukeView
®
; MultiFunction
Counter software for
Windows
®
PM 9086/011 Spare Ni-Cd Battery Pack
Selection guide
Models 164 164T 164H
Function/Frequency range:
160 MHz Frequency Counter
50 MHz Waveform, Timing and Vp-p modes
•••
100 MHz Totalize of Counts
V dc and 10 MHz true RMS Volt modes
2.7 GHz Frequency- and Period modes
••
Timebase stability / Accuracy per month• 5 x 10
-7
1 x 10-75 x 10
-8
per year• 5 x 10
-6
1 x 10-65 x 10
-7
Optional PC-support: RS232 adapter
°°°Optional FlukeView® for Windows® •
Ordering Information
®
10
Fluke Corporation
P.O. Box 9090, Everett, WA USA
98206
Fluke Europe B.V.
P.O. Box 1186, 5602 BD Eindhoven
The Netherlands
For more information call:
In the U.S.A. (425) 347-6100 or
fax (425) 356-5116
In Europe (31 40) 2 678 200 or
fax (31 40) 2 678 222
In Canada
1-800-FLUKE-FAX
From other countries
+1 (425) 356-5174 or
fax +1 (425) 356-5116
©
Copyright 1999 Fluke Corporation. All rights
reserved.
Specifications subject to change without notice.
Loading...
