Fluke 1586A/2DS, 1586A/1HC, 1586A/1DS, 1586A/2HC, 1586A/1HC/C User manual

1586A

SUPER-DAQ Precision Temperature Scanner

June 2013

© 2013 Fluke Corporation. All rights reserved. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.

Users Manual

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

LIMITED WARRANTY AND LIMITATION OF LIABILITY

Each Fluke product is warranted to be free from defects in material and workmanship under normal use and
service. The warranty period is one year and begins on the date of shipment. Parts, product repairs, and
services are warranted for 90 days. This warranty extends only to the original buyer or end-user customer of
a Fluke authorized reseller, and does not apply to fuses, disposable batteries, or to any product which, in
Fluke's opinion, has been misused, altered, neglected, contaminated, or damaged by accident or abnormal
conditions of operation or handling. Fluke warrants that software will operate substantially in accordance
with its functional specifications for 90 days and that it has been properly recorded on non-defective media.
Fluke does not warrant that software will be error free or operate without interruption.

Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers
only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is
available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the
applicable international price. Fluke reserves the right to invoice Buyer for importation costs of
repair/replacement parts when product purchased in one country is submitted for repair in another country.

Fluke's warranty obligation is limited, at Fluke's option, to refund of the purchase price, free of charge repair,
or replacement of a defective product which is returned to a Fluke authorized service center within the
warranty period.

To obtain warranty service, contact your nearest Fluke authorized service center to obtain return
authorization information, then send the product to that service center, with a description of the difficulty,
postage and insurance prepaid (FOB Destination). Fluke assumes no risk for damage in transit. Following
warranty repair, the product will be returned to Buyer, transportation prepaid (FOB Destination). If Fluke
determines that failure was caused by neglect, misuse, contamination, alteration, accident, or abnormal
condition of operation or handling, including overvoltage failures caused by use outside the product’s
specified rating, or normal wear and tear of mechanical components, Fluke will provide an estimate of repair
costs and obtain authorization before commencing the work. Following repair, the product will be returned to
the Buyer transportation prepaid and the Buyer will be billed for the repair and return transportation charges
(FOB Shipping Point).

THIS WARRANTY IS BUYER'S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. FLUKE SHALL NOT BE LIABLE
FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OR LOSSES,
INCLUDING LOSS OF DATA, ARISING FROM ANY CAUSE OR THEORY.

Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion or
limitation of incidental or consequential damages, the limitations and exclusions of this warranty may not
apply to every buyer. If any provision of this Warranty is held invalid or unenforceable by a court or other
decision-maker of competent jurisdiction, such holding will not affect the validity or enforceability of any other
provision.

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Table of Contents

Chapter Title Page

1 Product Overview and Specifications ............................................... 1-1

Introduction ........................................................................................................ 1-3

Product Overview .............................................................................................. 1-3

Front and Rear-Panel Overview ......................................................................... 1-5

Safety Information ............................................................................................. 1-9

Screen Capture Feature ...................................................................................... 1-11

About this Manual ............................................................................................. 1-12

The Product Manual Set .................................................................................... 1-12

How to Contact Fluke Calibration ..................................................................... 1-13

Calibration and Repair Information ................................................................... 1-13

General Specifications ....................................................................................... 1-13

Measurement Specifications .............................................................................. 1-15

PRT/RTD ....................................................................................................... 1-15

PRT/RTD Resistance Accuracy ................................................................ 1-15

PRT/RTD Temperature Accuracy ............................................................. 1-16

PRT/RTD Measurement Characteristics ................................................... 1-16

Thermistor ..................................................................................................... 1-16

Thermistor Resistance Accuracy ............................................................... 1-16

Thermistor Temperature Accuracy ........................................................... 1-17

Thermistor Measurement Characteristics .................................................. 1-17

Thermocouple ................................................................................................ 1-18

Thermocouple Voltage Accuracy .............................................................. 1-18

Thermocouple Reference Junction Accuracy ........................................... 1-18

Thermocouple Temperature Accuracy ...................................................... 1-18

Thermocouple Measurement Characteristics ............................................ 1-19

DC Voltage .................................................................................................... 1-20

DC Voltage Accuracy ............................................................................... 1-20

DC Voltage Input Characteristics ............................................................. 1-20

DC Current .................................................................................................... 1-20

DC Current Accuracy ................................................................................ 1-20

DC Current Input Characteristics .............................................................. 1-21

Resistance ...................................................................................................... 1-21

Resistance Accuracy ................................................................................. 1-21

Resistance Input Characteristics ............................................................... 1-21

i

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Digital I/O ...................................................................................................... 1-22

Totalizer ......................................................................................................... 1-22

Trigger ........................................................................................................... 1-22

Alarm Output ................................................................................................. 1-22

1586-2588 DAQ-STAQ Input Module Specifications ...................................... 1-22

General .......................................................................................................... 1-22

1586-2586 High-Capacity Input Module Specifications ................................... 1-22

General .......................................................................................................... 1-22

2 Initial Setup and Configuration .......................................................... 2-1

Introduction ........................................................................................................ 2-3

Set the Regional Voltage ................................................................................... 2-3

Connect to Mains Power .................................................................................... 2-4

Set the Handle Position ...................................................................................... 2-5

Power On and Standby ...................................................................................... 2-6

Warm-Up the Product ........................................................................................ 2-7

Configure the Product ........................................................................................ 2-7

Input Module and Relay Card Installation ......................................................... 2-8

Install a DAQ-STAQ Multiplexer Connection Module ..................................... 2-11

Set Up Security .................................................................................................. 2-13

3 Input and Channel Configuration ....................................................... 3-1

Introduction ........................................................................................................ 3-3

Input Wiring ....................................................................................................... 3-3

The 1586-2586 High Capacity Input Module ................................................ 3-3

The 1586-2588 DAQ-STAQ Multiplexer Connector Module ...................... 3-4

Wiring Safety and Considerations ................................................................. 3-5

3-Wire and 4-Wire Sense Input Configuration .............................................. 3-6

Input Types and Wiring Diagrams ................................................................ 3-7

Input Wiring Instructions .............................................................................. 3-8

Channel Configuration ....................................................................................... 3-10

About Channel Numbers ............................................................................... 3-10

Basic Channel Operations ............................................................................. 3-12

Open the Channel Setup Menu ................................................................. 3-12

Set Channels to ON or OFF ...................................................................... 3-13

Verify a Channel ....................................................................................... 3-14

Zero a Channel .......................................................................................... 3-14

Copy a Channel ......................................................................................... 3-15

Save or Load a Channel Configuration (Setup File) ................................. 3-16

Reset the Channel and Test Configuration ................................................ 3-18

Analog Channel Configuration (Ch001, Ch101 to Ch222) ........................... 3-18

Current and Voltage Channels .................................................................. 3-19

Resistance Channels .................................................................................. 3-20

Thermocouple Channels ............................................................................ 3-21

Thermistor Channels ................................................................................. 3-22

PRT Channels............................................................................................ 3-23

Digital I/O (DIO) Channel Configuration (Ch401) ....................................... 3-24

Totalizer Channel Configuration (Ch402) ..................................................... 3-25

Read Mode ................................................................................................ 3-25

Debounce .................................................................................................. 3-25

Math Channel Configuration (Ch501 to

Ch520) ........................................... 3-27

Mx+B, Alarms, and Channel Options ................................................................ 3-30

Mx+B Scaling ................................................................................................ 3-30

HI and LO Channel Alarms ........................................................................... 3-31

ii

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Contents (continued)

Channel Delay ............................................................................................... 3-33

Rate of Change .............................................................................................. 3-33

Display As ..................................................................................................... 3-34

Open Detect ................................................................................................... 3-34

Probe Library ..................................................................................................... 3-34

4 Scan/Monitor, Record, and Data ........................................................ 4-1

Introduction ........................................................................................................ 4-3

Scan .................................................................................................................... 4-3

About Scan Timing and Sampling ................................................................. 4-5

Configure a Scan ........................................................................................... 4-6

Trigger Type.............................................................................................. 4-7

Auto Recording ......................................................................................... 4-8

File Destination ......................................................................................... 4-8

Sample Rate .............................................................................................. 4-8

Data Security ............................................................................................. 4-9

Temperature Unit ...................................................................................... 4-10

Align Channels .......................................................................................... 4-10

Automatic Power Loss Scan Resume ........................................................ 4-11

Basic Scan Procedures ................................................................................... 4-11

Start a Scan ................................................................................................ 4-11

View Scan Data and Statistics ................................................................... 4-12

Graph the Measurements ........................................................................... 4-14

Monitor .............................................................................................................. 4-15

Automated Test .................................................................................................. 4-16

Overview ....................................................................................................... 4-16

Configure an Automated Test........................................................................ 4-17

Connect to An External Source ..................................................................... 4-18

Record ................................................................................................................ 4-19

Record Measurement Data ............................................................................ 4-19

Memory Consumption for Recorded Data .................................................... 4-20

Open and View Measurement Data on a PC ................................................. 4-20

How to Read the Setup CSV File .................................................................. 4-22

How to Read the Data CSV File .................................................................... 4-24

5 Measure/DMM Operation .................................................................... 5-1

Introduction ........................................................................................................ 5-3

About the Measure Function .............................................................................. 5-3

About the DMM Function ................................................................................. 5-3

Input Type Selection and Range Adjustment .................................................... 5-4

Relative Measurements ...................................................................................... 5-4

Graph the Measurements ................................................................................... 5-5

Measurement Statistics ...................................................................................... 5-6

6 Maintenance and Care ........................................................................ 6-1

Introduction ........................................................................................................ 6-3

Clean the Product ............................................................................................... 6-3

Replace the Fuse ................................................................................................ 6-3

Memory Reset and Factory Reset ...................................................................... 6-4

User-Replaceable Parts and Accessories ........................................................... 6-5

7 Error Messages and Troubleshooting ............................................... 7-1

Introduction ........................................................................................................ 7-3

iii

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Error Messages .................................................................................................. 7-3

Troubleshooting ................................................................................................. 7-20

iv

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

List of Tables

Table Title Page

1-1. Front-Panel Features .............................................................................................. 1-5

1-2. Rear-Panel Features ............................................................................................... 1-7

1-3. Symbols .................................................................................................................. 1-9

2-1. Fuses ....................................................................................................................... 2-3

2-2. Instrument Setup Menu .......................................................................................... 2-7

3-1. Types of Inputs ....................................................................................................... 3-8

3-2. Channel Types and Numbers ................................................................................. 3-10

3-3. Channel Setup Menu .............................................................................................. 3-12

3-4. Current and Voltage Channel Configuration .......................................................... 3-19

3-5. Resistance Channel Configuration ......................................................................... 3-20

3-6. Thermocouple Channel Configuration ................................................................... 3-21

3-7. Thermistor Channel Setup ...................................................................................... 3-22

3-8. PRT Channel Setup ................................................................................................ 3-23

3-9. Totalizer Channel Configuration ............................................................................ 3-26

3-10. Math Channel Formulas ......................................................................................... 3-27

3-11. Math Channel Configuration .................................................................................. 3-29

4-1. The Scan Menu ...................................................................................................... 4-4

4-2. Scan Sample Rates ................................................................................................. 4-9

4-3. Scan Statistics ......................................................................................................... 4-13

4-4. Automated Test Setup ............................................................................................ 4-17

4-5. Scan Data Memory Usage ...................................................................................... 4-20

5-1. Statistics ................................................................................................................. 5-6

6-1. Fuses ....................................................................................................................... 6-3

6-2. Comparison of the Memory Clear Functions ......................................................... 6-4

6-3. User-Replaceable Parts and Accessories ................................................................ 6-5

7-1. Error Messages ....................................................................................................... 7-3

7-2. Troublehooting Chart ............................................................................................. 7-20

v

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

List of Figures

Figure Title Page

1-1. Screen Capture ....................................................................................................... 1-11

2-1. Fuse Replacement and Line-Voltage Selection...................................................... 2-3

2-2. Mains Power Cord Connection .............................................................................. 2-4

2-3. Handle Positions and Boot Removal ...................................................................... 2-5

2-4. Main Power Switch and Standby Key .................................................................... 2-6

2-5. Module Indicator Example ..................................................................................... 2-9

2-6. Relay Card Installation ........................................................................................... 2-10

2-7. DAQ-STAQ Multiplexer Installation ..................................................................... 2-12

3-1. 2-Wire, 3-Wire, and 4-Wire Input Module Connections ....................................... 3-3

3-2. 2-Wire, 3-Wire, and 4-Wire Multiplexer Connections .......................................... 3-4

3-3. 3-Wire and 4-Wire Channel Reservation ............................................................... 3-7

3-4. Module Indicator (Input Module Installed Shown) ................................................ 3-9

3-5. Example Channel Assignment ............................................................................... 3-11

3-6. Channel Status Indicators ....................................................................................... 3-13

3-7. Zero Function ......................................................................................................... 3-15

3-8. DIO Connector ....................................................................................................... 3-24

3-9. Totalizer Input (TOT) ............................................................................................ 3-25

3-10. Rear-Panel Alarm Outputs ..................................................................................... 3-32

3-11. Alarm Output Example .......................................................................................... 3-32

3-12. The Probe Library .................................................................................................. 3-34

4-1. Scan Data ............................................................................................................... 4-4

4-2. Illustration of a Scan Sweep ................................................................................... 4-6

4-3. Test Setup Menu Example ..................................................................................... 4-7

4-4. Scan Data ............................................................................................................... 4-13

4-5. Graph Feature ......................................................................................................... 4-14

4-6. Monitor Menu ........................................................................................................ 4-15

4-7. External Temperature Control Source .................................................................... 4-16

4-8. Scan Data File Name Convention .......................................................................... 4-21

4-9. Setup.csv and Dat00001.csv Files .......................................................................... 4-22

5-1. Example Voltage Front-Panel Connection ............................................................. 5-3

5-2. Input Function Selection ........................................................................................ 5-4

5-3. Relative Measurement ............................................................................................ 5-5

5-4. Graph Function ....................................................................................................... 5-5

5-5. DMM Statistics ...................................................................................................... 5-6

6-1. Fuse Replacement .................................................................................................. 6-4

vii

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 1

Product Overview and Specifications

Title Page

Introduction ........................................................................................................ 1-3

Product Overview .............................................................................................. 1-3

Front and Rear-Panel Overview ......................................................................... 1-5

Safety Information ............................................................................................. 1-9

Screen Capture Feature ...................................................................................... 1-11

About this Manual ............................................................................................. 1-12

The Product Manual Set .................................................................................... 1-12

How to Contact Fluke Calibration ..................................................................... 1-13

Calibration and Repair Information ................................................................... 1-13

General Specifications ....................................................................................... 1-13

Measurement Specifications .............................................................................. 1-15

PRT/RTD ....................................................................................................... 1-15

PRT/RTD Resistance Accuracy ................................................................ 1-15

PRT/RTD Temperature Accuracy ............................................................. 1-16

PRT/RTD Measurement Characteristics ................................................... 1-16

Thermistor ..................................................................................................... 1-16

Thermistor Resistance Accuracy ............................................................... 1-16

Thermistor Temperature Accuracy ........................................................... 1-17

Thermistor Measurement Characteristics .................................................. 1-17

Thermocouple ................................................................................................ 1-18

Thermocouple Voltage Accuracy .............................................................. 1-18

Thermocouple Reference Junction Accuracy ........................................... 1-18

Thermocouple Temperature Accuracy ...................................................... 1-18

Thermocouple Measurement Characteristics ............................................ 1-19

DC Voltage .................................................................................................... 1-20

DC Voltage Accuracy ............................................................................... 1-20

DC Voltage Input Characteristics ............................................................. 1-20

DC Current .................................................................................................... 1-20

DC Current Accuracy ................................................................................ 1-20

DC Current Input Characteristics .............................................................. 1-21

Resistance ...................................................................................................... 1-21

Resistance Accuracy ................................................................................. 1-21

Resistance Input Characteristics ............................................................... 1-21

Digital I/O ...................................................................................................... 1-22

Totalizer ......................................................................................................... 1-22

Trigger ........................................................................................................... 1-22

Alarm Output ................................................................................................. 1-22

1586-2588 DAQ-STAQ Input Module Specifications ...................................... 1-22

1-1

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

General .......................................................................................................... 1-22

1586-2586 High-Capacity Input Module Specifications ................................... 1-22

General .......................................................................................................... 1-22

1-2

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Product Overview and Specifications

Introduction 1

Introduction

This chapter supplies information about the Product, the manual set, safety information,
contact information, and specifications.

Product Overview

The Fluke Calibration 1586A SUPER-DAQ Precision Temperature Scanner (the Product
or Instrument) is a 45 analog channel bench-top measurement instrument that measures
and records temperature, resistance, dc volts, and dc current (see Table 1-1). See the
Specifications section for information on the types and ranges of the measurement inputs
the Product can accept.

Features of the Product include:

Temperature Accuracy – Measures temperature with uncertainty as low as 0.01 °C

•

with a PRT, 0.003 °C with a thermistor, or 0.2 °C with a thermocouple. PRT
accuracy is enhanced by 4-wire sensing that cancels out lead-wire resistance,
bidirectional source current that cancels thermoelectric EMF in the PRT, and ITS-90
characterization that accurately relates resistance to temperature.

•

Scan – Sequentially scan up to 45 analog channels per scan sweep. In addition, the

Product also has 20 math channels, one DIO channel, and one TOT channel that can
be included in scan. A scan can be manually controlled from the front panel or
triggered with a variety of triggers such a timer, an alarm, an external source, or a
remote SCPI command.

While a scan is in progress, all channel values can be viewed on the display in a
spreadsheet format along with statistics such as average, standard deviation,
minimum, maximum, peak-to-peak, and rate-of-change. With the Graph feature,
channel measurement data for up to four channels can be plotted and viewed on the
display. Users can toggle the data mode with a softkey to view live data or historical
data.

•

Monitor – View the measurement value or the statistics of a single channel. Monitor

is an independent feature that can be used while a scan is in progress or inactive.
Much like the Scan feature, the statistics of the single measurement can be viewed on
the display or be shown in a graph.

Digital Multimeter Functionality (DMM) – Function that presents the user with

•

familiar DMM features and controls like a standard bench DMM. The DMM can
show 6 ½ digits on the display. To visualize trend data, the DMM provides additional
functionality to graph and see measurement statistics.

1-3

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

• Data Storage - Store up to 20 MB of data and channel setup files directly to the

internal non-volatile memory or an external USB drive. Data can also be transferred
to a PC with a USB drive or LAN TCP/IP interface at the rear of the unit with SCPI
interface command sets.

•

Alarms – Each channel can be assigned two independent alarms to indicate when

either an upper (HI) or lower (LO) range has been exceeded. The alarms can be
configured to output a digital signal from the rear-panel alarm output for control of
external devices.

Digital I/O (DIO) – The Product is equipped with a digital 8-bit transistor-transistor

•

logic (TTL) port that can sense and output. When the DIO channel is included in the
scan list, the value of this port is recorded in the scan data record on each scan with a
value range of 0 to 255 based on the port state when it is read.

•

Totalizer – The Product is equipped with a unidirectional, resettable totalizer with an

input count capability of 1,048,575 (20 bits). Counter increment is accomplished
through a change to a digital signal or contact closure to the totalizer input terminals
on the rear of the Instrument.

Remote Operation – Remotely operate the Product with remote SCPI commands

•

from application software over a rear-panel USB or LAN TCP/IP connection.

•

Automated Sensor Test – Automatically sets the temperature of a Fluke

Calibration dry-well calibrator or temperature bath connected to the rear-panel
RS-232 port. Monitors temperature stability, and measures the readings of
temperature sensors and a reference thermometer when the temperature is stable.

DAQ-STAQ Accessory – Multiplexer module provides quick and convenient

•

connection of temperature sensors with Fluke's patented spring-loaded DWF
terminals.

1-4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Product Overview and Specifications

Front and Rear-Panel Overview 1

Front and Rear-Panel Overview

Table 1-1 identifies and describes the front-panel features and Table 1-2 identifies and
describes the rear-panel features.

Table 1-1. Front-Panel Features

9

8

7

6

10

11

X

12

345 2

13

14

15

16

17

18

19

20

1

hcn001.eps

Item Name Function

Puts the Product in the standby mode. In standby, the display is off and



Standby Key

the keys are disabled. Standby mode also disables remote operation.
See “Power ON and Standby” in Chapter 2.

Function softkeys to open submenus and set selections. The function of

Function Softkeys



the softkey changes with each menu and is shown above the softkey
on the display.

Scroll menus, increase or decrease values, and highlight selections.

Arrow Keys



The keys also let the user cycle through measurement values in data
menus and also change the view of graphs.

1-5

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Table 1-1. Front-Panel Features (cont.)

Item Name Function

Red LED that illuminates when the USB drive is recognized and flashes

USB Data Transfer



Indicator

red when data is transferred to or from the USB drive.

Caution

To prevent data loss, do not remove the USB drive when

Front-Panel USB Port



Current Input Terminal



the LED is flashing.

USB port to insert a USB drive.

Input terminal to make current measurements up to 100 mA. The
current input is connected to a thermal over-current protection circuit
that disconnects the input when an overcurrent occurs and reconnects
the input when the condition is removed.

V, Ω, mA Input



Terminals

4WΩ Sense Terminals



Channel Status



Indicator

 Menu Name Name of the menu.

 Hazardous Voltage



Indicator

 Date and Time

 Module Indicator

 Scan/Monitor

Input terminals that connect to test leads to measure dc volts,
dc milliamps, resistance, and temperature.

Sense input terminals to make 3-wire and 4-wire compensated
resistance measurements.

Square green box that shows when a channel is set to ON. When a
channel is set to ON, it is referred to as “active”.

Warns the user of hazardous voltage on an input. Shows when voltage
is >30 V dc.

Shows the current date and time that is set in the Instrument Setup
menu. This date and time is used for timestamps when data is logged.

Visually shows how many and which slots the Input Modules are
connected to. See “Input Module and Relay Card Installation” in
Chapter 2.

Scan all active channels. The Scan function samples all active
channels directed by the test setup file. The Monitor function shows
measurement data of a single channel. See Chapter 4 for more
information and operation instructions.

1-6

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Product Overview and Specifications

Front and Rear-Panel Overview 1

Table 1-1. Front-Panel Features (cont.)

Item Name Function

Starts and stops data recording. When recording, the key illuminates and
“RECORDING” shows on the top of the display. Recording can be set to

 Record

 Memory

 Measure/DMM

 Instrument Setup

 Channel Setup

 Numeric Keypad

automatically start and stop with a scan. In addition to recording scan data,
measurements made with the front-panel DMM can also be recorded. See
Chapter 4 for more information and operation instructions.

Manage setup files, scan data files, and DMM data files on either the
internal memory or USB drive.

Operate the single-channel measurement function or digital multimeter
(DMM) function that lets the user quickly configure and make
measurements with the front-panel inputs. See Chapter 5 for DMM
operation instructions.

Configure the Product. Menu contains many user-configurable settings to
customize the Product. See “Configure the Product” in Chapter 2.

Configure and verify channels. Channel Setup is the default menu that
shows on the display when the Product is powered on. See Chapter 3 for
instructions on how to wire and configure a channel.

Use to input numerical values when prompted. Push and hold the PRINT
or “0” key to take a screenshot of the display. Push and hold the LOCK key
to lock the front panel to prevent changes and UNLOCK to unlock.

Table 1-2. Rear-Panel Features

1

2

3

12345678 123456

4

5

6

7

9

8

10

Item Name Function

11

12

hcn002.eps

Line Voltage



Selector and Fuse

Regional voltage selector. See “Set the Regional Voltage” in Chapter 2.

1-7

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Table 1-2. Rear-Panel Features (cont.)

Item Name Function

Main Power Switch



Mains Power



Connector

Chassis Ground



Temperature



Source Control

Serial USB Port



LAN Connection



Totalizer Input



DIO (Digital I/O



Input Ports)

Digital External



Alarm Trigger
Outputs

Supplies and disconnects mains power to the unit.

Mains power cord receptacle.

Terminal that is internally grounded to the chassis. If the Product is the
location of the ground reference point in a system, this binding post can be
used to connect other instruments to earth ground.

RS-232 connector used to control a Fluke Calibration dry-well or
temperature bath for automated tests on temperature instruments. See
“Automated Test” in Chapter 4.

USB port used for remote operation. See the 1586A Remote Programmers
Guide.

Network port used for remote operation. See the 1586A Remote
Programmers Guide.

Input terminal for the Totalizer feature. See “Totalizer Channel
Configuration” in Chapter 3.

Eight digital ports used to sense and output a digital, 8-bit transistor­transistor logic (TTL) value that can be displayed as the 8-bit TTL value
and be recorded as the decimal equivalent.

Six digital outputs that can be used to trigger a digital external alarm if a
channel exceeds the set alarm limits. See “HI and LO Channel Alarms” in
Chapter 3.

 Trigger Input

 Input Module Slots

Input terminal to trigger a scan when the External trigger type is used. See
Scan Test Setup” in Chapter 4.

Slots that accept up to two High-Capacity Input Modules or DAQ-STAQ
Multiplexer Connection Modules. See “Input Module and Relay Card
Installation” and “Install a DAQ-STAQ Multiplexer Connection Module” in
Chapter 2.

1-8

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Product Overview and Specifications

Safety Information 1

Safety Information

A Warning identifies conditions and procedures that are dangerous to the user. A
Caution identifies conditions and procedures that can cause damage to the Product or

the equipment under test.

See Table 1-3 for a list of symbols used in this manual and on the Product.

Table 1-3. Symbols

Symbol Description Symbol Description









CAT II

CAT III

CAT IV





Note:

[1] - This equipment is not intended for measurements in CAT II, CAT III, or CAT IV environments. These definitions are

included because the test leads supplied with the product include these ratings.

Risk of danger. Important
information. See manual.

Hazardous voltage. Voltage
>30 V dc or ac peak might be
present.

Earth ground.

Recycle.

Measurement Category II is applicable to test and measuring circuits connected directly to

[1]

utilization points (socket outlets and similar points) of the low-voltage MAINS installation.

Measurement Category III is applicable to test and measuring circuits connected to the

[1]

distribution part of the building’s low-voltage MAINS installation.

Measurement Category IV is applicable to test and measuring circuits connected at the source

[1]

of the building’s low-voltage MAINS installation.

This product complies with the WEEE Directive (2002/96/EC) marking requirements. The
affixed label indicates that you must not discard this electrical/electronic product in domestic
household waste. Product Category: With reference to the equipment types in the WEEE
Directive Annex I, this product is classed as category 9 "Monitoring and Control
Instrumentation” product. Do not dispose of this product as unsorted municipal waste. Go to
Fluke’s website for recycling information.

Product conforms with the requirements of the applicable EC directives.









DC (Direct Current)

AC or DC (Alternating or Direct Current)

Digital signal.

Power ON / OFF

Warning

To prevent possible electrical shock, fire, or personal injury:

• Read all safety information before you use the Product.

• Carefully read all instructions.

1-9

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

• Use the Product only as specified, or the protection supplied

by the Product can be compromised.

• Examine the case before you use the Product. Look for cracks

or missing plastic. Carefully look at the insulation around the
terminals.

• Do not use the Product if it operates incorrectly.

• Do not use and disable the Product if it is damaged.

• Use only the mains power cord and connector approved for

the voltage and plug configuration in your country and rated
for the Product.

• Replace the mains power cord if the insulation is damaged or

if the insulation shows signs of wear.

• Make sure the ground conductor in the mains power cord is

connected to a protective earth ground. Disruption of the
protective earth could put voltage on the chassis that could
cause death.

• Do not put the Product where access to the mains power cord

is blocked.

• Use only correct measurement category (CAT), voltage, and

amperage rated probes, test leads, and adapters for the
measurement.

• Use only cables with correct voltage ratings.

• Do not use test leads if they are damaged. Examine the test

leads for damaged insulation and measure a known voltage.

• Do not exceed the Measurement Category (CAT) rating of the

lowest rated individual component of a Product, probe, or
accessory.

• Keep fingers behind the finger guards on the probes.

• Do not apply more than the rated voltage, between the

terminals or between each terminal and earth ground.

• Do not touch voltages >30 V ac rms, 42 V ac peak, or 60 V dc.

• Limit operation to the specified measurement category,

voltage, or amperage ratings.

• Measure a known voltage first to make sure that the Product

operates correctly.

1-10

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Product Overview and Specifications

Screen Capture Feature 1

• Consider all accessible channels to be hazardous live and an

electric shock hazard if any channel is connected to a
hazardous voltage source.

• Do not remove, touch, or change the internal wiring of

hazardous inputs until the input source is turned off.

• Remove inputs from hazardous voltage sources before an

input module is opened.

• Use the correct terminals, function, and range for

measurements.

• Use this Product indoors only.

• Do not use the Product around explosive gas, vapor, or in

damp or wet environments.

Screen Capture Feature

The Product can take a screenshot of the display and save it directly to the USB drive.

To take a screenshot of the display (see Figure 1-1):

1. Insert a USB drive in the front panel and wait for the USB Data Transfer Indicator to

show solid red.

2. Push and hold the PRINT or “0” key on the numeric keypad for 3 seconds and then

release. The display shows “File Saved”.

3. Remove the USB from the front panel and connect it to a USB drive on a PC.

4. Open the USB drive and navigate to the image folder with this path:

\\fluke\1586A\[Product Serial Number]\Image

PRINT

3 seconds

Figure 1-1. Screen Capture

=

hcn024.eps

1-11

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

About this Manual

This manual has seven chapters:

•

Chapter 1 supplies product information, safety information, contact information, and

product specifications.

•

Chapter 2 supplies information and instructions on how to set up and configure the

Product for first time use.

•

Chapter 3 supplies instructions on how to wire inputs to the Input Module then

configure the associated channel.

•

Chapter 4 supplies information and instructions on how to do a scan, monitor a

channel, and record measurement data.

•

Chapter 5 supplies instructions on how to operate the DMM function of the Product.

•

Chapter 6 supplies information on how to clean the Product and replace the fuse in

the rear of the Product.

•

Chapter 7 supplies information on error messages and how to troubleshoot the

Product.

The Product Manual Set

The Product manual set includes:

• This 1586A Users Manual that contains feature information, operation instructions,

and basic user maintenance and troubleshooting information. The Users Manual is
translated into many languages.

• The 1586A Safety Information is printed and contains important safety information for

this Product. The Safety Information is translated into many languages.

• The 1586A Remote Programmers Guide contains information on how to remotely

operate the Product. The Programmers Guide alphabetically lists all commands and
provides example code for different applications.

• The 1586A Calibration Manual contains calibration and adjustment procedures to keep

the Product within specifications.

• The 1586A Product CD contains the all the manuals in the manual set.

1-12

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Product Overview and Specifications

How to Contact Fluke Calibration 1

General Specifications

Mains Voltage

100 V Setting ...................................................... 90 V to 110 V

120 V Setting ...................................................... 108 V to 132 V

220 V Setting ...................................................... 198 V to 242 V

240 V Setting ...................................................... 216 V to 264 V

Frequency .............................................................. 47 Hz to 440 Hz

Power Consumption ............................................. 36 VA peak (24 W average)

Environment Temperature

Operating ............................................................ 0 °C to 50 °C

Full accuracy ....................................................... 18 °C to 28 °C

Storage ............................................................... −20 °C to 70 °C

Warm-up ............................................................. 1 hour to full accuracy specifications

Relative Humidity (non-condensing)

Operating ............................................................ 0 °C to 30 °C <80 %

30 °C to 50 °C <50 %

Storage ............................................................... −20 °C to 70 °C <95 %

1-13



Find Quality Products Online at: [e-mail]



www.GlobalTestSupply.com

1586A

Users Manual

Altitude

Operating ............................................................ 2,000 m

Storage ............................................................... 12,000 m

Vibration and Shock ............................................. Complies with MIL-PRF-28800F Class 3

Channel Capacity

Total analog channels ........................................ 45

Voltage/resistance channels ............................... 41

Current channels ................................................ 5

Digital I/O ............................................................ 8 bits

Totalizer .............................................................. 1

Alarm outputs...................................................... 6

Trigger input ........................................................ 1

Input Protection .................................................... 50 V all functions, terminals and ranges

Math Channels

Number of channels............................................ 20

Operations .......................................................... sum, difference, multiply, divide, polynomial, power, square root,

Triggers .................................................................. interval, external (trigger input), alarm, remote (bus), manual,

Memory

Scan data RAM................................................... 75,000 readings with timestamp

Data/Setup flash memory ................................... 20 MB

USB Host Port

Connector type ................................................... Type A

Function .............................................................. Memory

File system .......................................................... FAT32

Memory capacity................................................. 32 GB

USB Device Port

Connector type ................................................... Type B

Class ................................................................... Instrument

Function .............................................................. Control and data transfer

Command protocol ............................................. SCPI

LAN

Function .............................................................. Control and data transfer

Network protocols ............................................... Ethernet 10/100, TCP/IP

Command protocol ............................................. SCPI

RS-232

Connector ........................................................... D-sub 9 pin (DE-9)

Baud rates .......................................................... 1200, 2400, 4800, 9600, 19200, 38400

Function .............................................................. Temperature source control output

Dimensions

Height ................................................................. 150 mm

Width ................................................................... 245 mm

Depth .................................................................. 385 mm

Weight ................................................................. 6 kg (typical configuration)

Shipping Weight.................................................. 9.5 kg (typical configuration)

Conformity ............................................................. CE, CSA, IEC 61010 3

reciprocal, exponential, logarithm, absolute value, average, maximum,
minimum

automated test

rd

ed.

1-14

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Product Overview and Specifications

Measurement Specifications 1

Measurement Specifications

Accuracy specifications generally apply with medium and slow sample rates (unless otherwise noted), after a warm-up
time of 1 hour, and within an environment temperature range of 18 °C to 28 °C, and may depend on the channel. The
confidence level for accuracy specifications is 95 % within 1 year of calibration.

Scan rate

Fast ..................................................................... 10 channels per second max (0.1 seconds per channel)

Medium ............................................................... 1 channel per second (1 second per channel)

Slow .................................................................... 4 seconds per channel

Display Resolution ................................................ 4 ½ to 6 ½ digits, depending on function and Sample Rate (see

PRT/RTD

Temperature Range .............................................. −200 °C to 1200 °C (depending on the sensor)

Resistance Range ................................................. 0 Ω to 4 kΩ

Offset Compensation

0 Ω to 400 Ω, 4-wire........................................ automatic current reversal

400 Ω to 4000 Ω or 3-wire .............................. none

Source Current Reversal Interval (0 Ω to 400 Ω range)

Fast sample rate ............................................. 2 ms

Medium sample rate ....................................... 250 ms

Slow sample rate ............................................ 250 ms

Maximum Lead Resistance (4-wire Ω) ................ 2.5 % of range per lead for 400 Ω and 4 kΩ ranges.

Measurement Characteristics tables below to find the display
resolution of temperature readings)

PRT/RTD Resistance Accuracy

Accuracy is given as ± (% of measurement + ohms). Basic accuracy is for 4-wire PRT/RTD using medium or slow sample
rate. When using 3-wire PRT/RTD add 0.013 Ω to the accuracy specification for internal resistance mismatch and voltage
offset if using Channel 1, or add 0.05 Ω if using channels x01 through x20. When using Fast sample rate add the number
given in the table to the accuracy specification. The 4 kΩ range accuracy specification can be decreased by 0.06 Ω if
using Slow sample rate. If the environment temperature is outside the specified range, multiply the temperature coefficient
numbers by the temperature deviation and add to the accuracy specification.

Range DAQ-STAQ Module High-Capacity Module Fast Sample Rate

0 Ω to 400 Ω 0.002 % + 0.002 Ω 0.003 % + 0.003 Ω add 0.003 Ω 0.0001 % + 0.0008 Ω

400 Ω to 4 kΩ 0.004 % + 0.1 Ω

0.006 % + 0.1 Ω

add 0.08 Ω 0.0001 % + 0.008 Ω

T.C./ °C Outside 18 °C to

28 °C

1-15

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

PRT/RTD Temperature Accuracy

Accuracy is for 4-wire 100 Ω nominal PRT/RTD, using medium or slow sample rate. When using 3-wire PRT/RTD add

0.039 °C to the accuracy specification for internal resistance mismatch and voltage offset if using Channel 1, or add

0.15 °C if using channels x01 through x20. When using the Fast sample rate, add the number given in the table to the
accuracy specification. If the environment temperature is outside the specified range, multiply the temperature coefficient
number by the temperature deviation and add to the accuracy specification. Linear interpolation may be used between
points in the table. Specifications do not include sensor accuracy. The practical range of temperature measurement
depends on the sensor and characterization.

Temperature DAQ-STAQ Module High-Capacity Module Fast Sample Rate

−200 °C 0.006 °C 0.01 °C add 0.01 °C 0.0019 °C

0 °C 0.01 °C 0.015 °C add 0.01 °C 0.0023 °C

300 °C 0.018 °C 0.03 °C add 0.01 °C 0.0028 °C

600 °C 0.026 °C 0.045 °C add 0.01 °C 0.0034 °C

T.C./ °C Outside 18 °C

to 28 °C

PRT/RTD Measurement Characteristics

Temperature Display Resolution

Range

0 Ω to 400 Ω

400 Ω to 4 kΩ

Slow / Medium

Sample Rate

0.001 °C 0.01 °C

0.001 °C 0.01 °C

Sample Rate

Fast

Source Current

±1 mA

0.1 mA

Thermistor

Temperature Range .............................................. −200 °C to 400 °C (depending on the sensor)

Resistance Range ................................................. 0 Ω to 1 MΩ

Thermistor Resistance Accuracy

Accuracy is given as ± (% of measurement + Ω). The basic accuracy specification is for 4-wire thermistor, slow sample
rate. When using medium or fast sample rate, add the number given in the table to the accuracy specification. If the
environment temperature is outside the specified range, multiply the temperature coefficient numbers by the temperature
deviation and add to the accuracy specification. For 2-wire thermistor add 0.02 Ω internal resistance if using Channel 1 or

1.5 Ω if using channels x01 through x20, and add external lead wire resistance.

Range

0 Ω to 2.2 kΩ 0.004 % + 0.2 Ω add 0.3 Ω add 1 Ω 0.0005 % + 0.05 Ω

2.1 kΩ to 98 kΩ 0.004 % + 0.5 Ω add 0.5 Ω add 1.3 Ω 0.0005 % + 0.1 Ω

95 kΩ to 1 MΩ 0.015 % + 5 Ω add 5 Ω add 13 Ω 0.001 % + 2 Ω

Slow

Sample Rate

Medium

Sample Rate

Rate

Fast

Sample Rate

T.C./ °C Outside

18 °C to 28 °C

1-16

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Product Overview and Specifications

A

Measurement Specifications 1

Thermistor Temperature Accuracy

Accuracy specifications are for 4-wire thermistor. When using 2-wire thermistor, add the number given in the table to the
specification for internal resistance. If the environment temperature is outside the specified range, increase the accuracy
specification by 25 % for every 1 °C outside the specified environment temperature range. Specifications do not include
sensor accuracy. The practical range of temperature measurement depends on the sensor.

ccuracy 2.2 kΩ Thermistor

Temperature

−40 °C 0.001 °C 0.001 °C 0.01 °C add 0.001 °C

0 °C 0.003 °C 0.004 °C 0.01 °C add 0.004 °C

25 °C 0.006 °C 0.011 °C 0.02 °C add 0.016 °C

50 °C 0.008 °C 0.018 °C 0.04 °C add 0.05 °C

100 °C 0.047 °C 0.114 °C 0.28 °C add 0.34 °C

150 °C 0.23 °C 0.56 °C 1.34 °C add 1.7 °C

Slow

Sample Rate

Medium

Sample Rate

Fast

Sample Rate

2-wire

Accuracy 5 kΩ Thermistor

Temperature

−40 °C 0.003 °C 0.004 °C 0.01 °C add 0.001 °C

0 °C 0.002 °C 0.002 °C 0.01 °C add 0.002 °C

25 °C 0.004 °C 0.006 °C 0.01 °C add 0.007 °C

50 °C 0.005 °C 0.009 °C 0.02 °C add 0.022 °C

100 °C 0.022 °C 0.052 °C 0.13 °C add 0.16 °C

150 °C 0.096 °C 0.24 °C 0.57 °C add 0.7 °C

Slow

Sample Rate

Medium

Sample Rate

Fast

Sample Rate

Accuracy 10 kΩ Thermistor

Temperature

−40 °C 0.003 °C 0.004 °C 0.01 °C add 0.001 °C

0 °C 0.002 °C 0.002 °C 0.01 °C add 0.002 °C

25 °C 0.003 °C 0.004 °C 0.01 °C add 0.004 °C

50 °C 0.005 °C 0.009 °C 0.02 °C add 0.011 °C

100 °C 0.011 °C 0.024 °C 0.06 °C add 0.067 °C

150 °C 0.04 °C 0.098 °C 0.24 °C add 0.29 °C

Slow

Sample Rate

Medium

Sample Rate

Fast

Sample Rate

Thermistor Measurement Characteristics

Temperature Display Resolution

Range

0 Ω to 2.2 kΩ

2.1 kΩ to 98 kΩ

95 kΩ to 1 MΩ

Slow / Medium

Sample Rate

0.0001 °C 0.001 °C

0.0001 °C 0.001 °C

0.0001 °C 0.001 °C

Sample Rate

Fast

Source Current

2-wire

2-wire

10 μA

10 μA

1 μA

1-17

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Thermocouple

Temperature Range .............................................. −270 °C to 2315 °C (depending on the sensor)

Voltage Range ....................................................... −15 mV to 100 mV

Thermocouple Voltage Accuracy

Accuracy is given as ± (|% of measurement| + μV). Basic accuracy specification is for medium or slow sample rate. When
using a fast sample rate add the number given in the table to the accuracy specification. If the environment temperature is
outside the specified range, multiply the temperature coefficient numbers by the temperature deviation and add to the
accuracy specification.

Range

−15 mV to 100 mV

Accuracy

Channel 1

0.004 % + 4 μV add 2 μV add 1 μV

Ch. x01 – x20

Fast

Sample Rate

T.C./ °C Outside

18 °C to 28 °C

0.0005 % + 0.0005 mV

Thermocouple Reference Junction Accuracy

Module CJC Accuracy

DAQ-STAQ Module 0.25 °C 0.02 °C

High-Capacity Module 0.6 °C 0.05 °C

T.C./ °C Outside

18 °C to 28 °C

Thermocouple Temperature Accuracy

Accuracy specifications apply using medium or slow sample rate. When using fast sample rate, increase the accuracy
specification by 25 %. If the environment temperature is outside the specified range, increase the accuracy specification
by 12 % for every 1 °C outside the specified environment temperature range. Accuracy with fixed/external CJC does not
include the accuracy of the reference junction temperature. Linear interpolation may be used between points in the table.
Specifications do not include sensor accuracy. The practical range of temperature measurement depends on the sensor.

Accuracy

Type

(Range)

K

−270 °C to
1372 °C

T

−270 °C to

400 °C

R

−50 °C to
1768 °C

S

−50 °C to
1768 °C

J

−210 °C to
1200 °C

N

−270 °C to
1300 °C

Temperature

−200 °C
0 °C

1000 °C

−200 °C
0 °C

200 °C
400 °C

0 °C

300 °C
1200 °C
1600 °C

0 °C

300 °C
1200 °C
1600 °C

−200 °C

0 °C

1000 °C

−200 °C

0 °C

500 °C
1000 °C

Fixed / External CJC Internal CJC

Channel 1 Ch. x01 – x20 DAQ-STAQ Module

0.28 °C

0.10 °C

0.14 °C

0.27 °C

0.10 °C

0.08 °C

0.08 °C

0.76 °C

0.42 °C

0.33 °C

0.34 °C

0.74 °C

0.45 °C

0.37 °C

0.39 °C

0.20 °C

0.08 °C

0.11 °C

0.42 °C

0.15 °C

0.12 °C

0.14 °C

0.41 °C

0.15 °C

0.20 °C

0.40 °C

0.15 °C

0.12 °C

0.11 °C

1.13 °C

0.63 °C

0.47 °C

0.49 °C

1.11 °C

0.67 °C

0.54 °C

0.56 °C

0.29 °C

0.12 °C

0.14 °C

0.62 °C

0.23 °C

0.17 °C

0.19 °C

0.76 °C

0.29 °C

0.32 °C

0.76 °C

0.30 °C

0.23 °C

0.20 °C

1.16 °C

0.64 °C

0.48 °C

0.50 °C

1.14 °C

0.68 °C

0.55 °C

0.57 °C

0.65 °C

0.28 °C

0.25 °C

0.90 °C

0.34 °C

0.24 °C

0.26 °C

High-Capacity

Module

1.60 °C

0.62 °C

0.64 °C

1.60 °C

0.65 °C

0.47 °C

0.41 °C

1.28 °C

0.71 °C

0.52 °C

0.54 °C

1.26 °C

0.76 °C

0.60 °C

0.63 °C

1.41 °C

0.61 °C

0.53 °C

1.69 °C

0.64 °C

0.44 °C

0.45 °C

1-18

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Product Overview and Specifications

Measurement Specifications 1

Accuracy

Type

(Range)

E

−270 °C to
1000 °C

B

100 °C to

1820 °C

C

0 °C to

2315 °C

D

0 °C to

2315 °C

G

0 °C to

2315 °C

L

−200 °C to

900 °C

M

−50 °C to
1410 °C

U

−200 °C to
600 °C

W

0 °C to

2315 °C

Temperature

−200 °C
0 °C

300 °C
700 °C

300 °C

600 °C
1200 °C
1600 °C

600 °C
1200 °C
2000 °C

600 °C
1200 °C
2000 °C

600 °C
1200 °C
2000 °C

−200 °C

0 °C

800 °C

0 °C

500 °C
1000 °C

−200 °C

0 °C

400 °C

600 °C
1200 °C
2000 °C

Fixed / External CJC Internal CJC

Channel 1 Ch. x01 – x20 DAQ-STAQ Module

0.17 °C

0.07 °C

0.06 °C

0.08 °C

1.32 °C

0.68 °C

0.41 °C

0.38 °C

0.23 °C

0.28 °C

0.44 °C

0.22 °C

0.26 °C

0.39 °C

0.24 °C

0.22 °C

0.33 °C

0.13 °C

0.08 °C

0.09 °C

0.11 °C

0.10 °C

0.10 °C

0.25 °C

0.10 °C

0.08 °C

0.24 °C

0.22 °C

0.33 °C

0.25 °C

0.10 °C

0.09 °C

0.10 °C

1.97 °C

1.02 °C

0.60 °C

0.55 °C

0.33 °C

0.40 °C

0.60 °C

0.32 °C

0.36 °C

0.53 °C

0.36 °C

0.32 °C

0.46 °C

0.19 °C

0.12 °C

0.12 °C

0.16 °C

0.15 °C

0.14 °C

0.37 °C

0.15 °C

0.11 °C

0.36 °C

0.32 °C

0.46 °C

0.64 °C

0.27 °C

0.21 °C

0.21 °C

1.97 °C

1.02 °C

0.60 °C

0.55 °C

0.37 °C

0.45 °C

0.66 °C

0.34 °C

0.39 °C

0.56 °C

0.36 °C

0.32 °C

0.46 °C

0.45 °C

0.28 °C

0.23 °C

0.30 °C

0.25 °C

0.21 °C

0.71 °C

0.30 °C

0.20 °C

0.36 °C

0.32 °C

0.46 °C

High-Capacity

Module

1.42 °C

0.61 °C

0.46 °C

0.45 °C

1.97 °C

1.02 °C

0.60 °C

0.55 °C

0.54 °C

0.63 °C

0.91 °C

0.44 °C

0.49 °C

0.69 °C

0.36 °C

0.33 °C

0.46 °C

0.99 °C

0.62 °C

0.48 °C

0.64 °C

0.51 °C

0.41 °C

1.48 °C

0.63 °C

0.40 °C

0.36 °C

0.33 °C

0.46 °C

Thermocouple Measurement Characteristics

Range

−270 °C to 2315 °C 0.01 °C 0.1 °C

Slow / Medium

Sample Rate

Temperature Display Resolution

Fast

Sample Rate

1-19

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

DC Voltage

Maximum Input ...................................................... 50 V on any range

Common Mode Rejection ..................................... 140 dB at 50 Hz or 60 Hz (1 kΩ unbalance in LOW lead) ±50 V peak

Normal Mode Rejection ........................................ 55 dB for power line frequency ±0.1 %, ±120 % of range peak

A/D Linearity .......................................................... 2 ppm of measurement + 1 ppm of range

Input Bias Current ................................................. 30 pA at 25 °C

maximum

maximum

DC Voltage Accuracy

Accuracy is given as ± (% measurement + % of range). Basic accuracy specification is for Channel 1, medium or slow
sample rate. For channels x01 through x20 or when using Fast sample rate, add the numbers given in the table to the
accuracy specification. If the environment temperature is outside the specified range, multiply the temperature coefficient
numbers by the temperature deviation and add to the accuracy specification.

Range

±100 mV

±1 V

±10 V 0.0024 % + 0.0005 % − add 0.0008 % of range 0.0005 % + 0.0001 %

±50 V 0.0038 % + 0.0012 % − add 0.0008 % of range 0.0005 % + 0.0001 %

Accuracy

Channel 1

0.0037 % + 0.0035 %

0.0025 % + 0.0007 %

Ch. x01 – x20

add 2 μV

add 2 μV

add 0.0008 % of range

add 0.0008 % of range

Fast

Sample Rate

T.C./ °C Outside

18 °C to 28 °C

0.0005 % + 0.0005 %

0.0005 % + 0.0001 %

DC Voltage Input Characteristics

Range

±100 mV

±1 V

±10 V

±50 V

[1] - Input beyond ±12 V is clamped. The clamp current is up to 3 mA.

Slow / Medium Fast

0.1 μV 1 μV

1 μV 10 μV

10 μV 100 μV

100 μV

Resolution

1 mV

Input Impedance

[1]

10 GΩ

10 GΩ

10 GΩ

10 MΩ ±1 %

[1]

[1]

DC Current

Input Protection .................................................... 0.15 A resettable PTC

DC Current Accuracy

Accuracy is given as ± (% measurement + % of range). Basic accuracy specification is for medium or slow sample rate.
When using a fast sample rate, add the number given in the table to the accuracy specification. If the environment
temperature is outside the specified range, multiply the temperature coefficient numbers by the temperature deviation and
add to the accuracy specification.

Range Accuracy Fast Sample Rate

±100 μA

±1 mA 0.015 % + 0.0011 % add 0.0008 % of range 0.002 % + 0.001 %

±10 mA 0.015 % + 0.0035 % add 0.0008 % of range 0.002 % + 0.001 %

±100 mA 0.015 % + 0.0035 % add 0.0008 % of range 0.002 % + 0.001 %

0.015 % + 0.0035 %

add 0.0008 % of range

T.C./ °C Outside

18 °C to 28 °C

0.002 % + 0.001 %

1-20

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Product Overview and Specifications

Measurement Specifications 1

DC Current Input Characteristics

Range

±100 μA

±1 mA 1 nA 10 nA <1 mV

±10 mA 10 nA 100 nA <1 mV

±100 mA 100 nA

Slow / Medium Fast

0.1 nA 1 nA <1 mV

Resolution

1 μA

Burden Voltage

<1 mV

Resistance

Max. Lead Resistance (4-wire ohms) .................. 10 Ω per lead for 100 Ω and 1 kΩ ranges. 1 kΩ per lead on all other

ranges.

Resistance Accuracy

Accuracy is given as ± (% measurement + % of range). Basic accuracy specification is for 4-wire resistance, medium or
slow sample rate. For 2-wire resistance add 0.02 Ω internal resistance if using Channel 1, or 1.5 Ω if using channels x01
through x20, and add external lead wire resistance. When using Fast sample rate, add the numbers given in the table to
the accuracy specification. If the environment temperature is outside the specified range, multiply the Temperature
Coefficient numbers by the temperature deviation and add to the accuracy specification.

Range Accuracy Fast Sample Rate

100 Ω

1 kΩ

10 kΩ

100 kΩ

1 MΩ

10 MΩ

100 MΩ

0.004 % + 0.0035 % add 0.001 % of range 0.0001 % + 0.0005 %

0.003 % + 0.001 % add 0.001 % of range 0.0001 % + 0.0001 %

0.004 % + 0.001 % add 0.001 % of range 0.0001 % + 0.0001 %

0.004 % + 0.001 % add 0.001 % of range 0.0001 % + 0.0001 %

0.004 % + 0.001 %

0.015 % + 0.001 %

0.8 % + 0.01 % add 0.01 % of range 0.05 % + 0.002 %

add 0.002 % of reading plus

0.0008 % of range

add 0.002 % of reading plus

0.0008 % of range

T.C./ °C Outside

18 °C to 28 °C

0.0005 % + 0.0002 %

0.001 % + 0.0004 %

Resistance Input Characteristics

Range

100 Ω 0.1 mΩ 1 mΩ

1 kΩ 1 mΩ 10 mΩ

10 kΩ 10 mΩ 100 mΩ 100 μA (6 V)

100 kΩ 100 mΩ 1 Ω 100 μA (12 V)

1 MΩ 1 Ω 10 Ω 10 μA (12 V)

10 MΩ 10 Ω 100 Ω 1 μA (12 V)

100 MΩ 100 Ω 1 kΩ 0.1 μA (12 V)

Slow / Medium Fast

Resolution

Source Current

(open-circuit voltage)

1 mA (4 V)

1 mA (4 V)

1-21

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Digital I/O

Absolute Voltage Range ......................................... -4 V to 30 V

Input Minimum Logic High ...................................... 2.0 V

Input Maximum Logic Low ...................................... 0.7 V

Output Type ............................................................ open drain active low

Output Logic Low (<1 mA) ...................................... 0 V to 0.7 V

Maximum Sink Current ........................................... 50 mA

Output Resistance .................................................. 47 Ω

Totalizer

Absolute Voltage Range ......................................... -4 V to 30 V

Minimum Logic High ............................................... 2.0 V

Maximum Logic Low ............................................... 0.7 V

Minimum Pulse Width ............................................. 50 μs

Maximum Frequency .............................................. 10 kHz

Debounce Time ....................................................... 1.7 ms

Maximum Count ...................................................... 1048575 (20 bits)

Trigger

Absolute Voltage Range ......................................... -4 V to 30 V

Minimum Logic High ............................................... 2.0 V

Maximum Logic Low ............................................... 0.7 V

Minimum Pulse Width ............................................. 50 μs

Maximum Latency ................................................... 100 ms

Alarm Output

Absolute Voltage Range ......................................... -4 V to 30 V

Output Type ............................................................ open drain active low

Output Logic Low (<1 mA) ...................................... 0 V to 0.7 V

Maximum Sink Current ........................................... 50 mA

Output Resistance .................................................. 47 Ω

1586-2588 DAQ-STAQ Input Module Specifications

General

Maximum Input ....................................................... 50 V

Offset Voltage ......................................................... <2 μV

3-Wire Internal Resistance Mismatch ..................... <50 mΩ

Basic CJC Accuracy ............................................... 0.25 °C

1586-2586 High-Capacity Input Module Specifications

General

Maximum Input ....................................................... 50 V

Offset Voltage ......................................................... <2 μV

3-Wire Internal Resistance Mismatch ..................... <50 mΩ

Basic CJC Accuracy ............................................... 0.6 °C

1-22

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2

Initial Setup and Configuration

Title Page

Introduction ........................................................................................................ 2-3

Set the Regional Voltage ................................................................................... 2-3

Connect to Mains Power .................................................................................... 2-4

Set the Handle Position ...................................................................................... 2-5

Power On and Standby ...................................................................................... 2-6

Warm-Up the Product ........................................................................................ 2-7

Configure the Product ........................................................................................ 2-7

Input Module and Relay Card Installation ......................................................... 2-8

Install a DAQ-STAQ Multiplexer Connection Module ..................................... 2-11

Set Up Security .................................................................................................. 2-13

2-1

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Initial Setup and Configuration

Introduction 2

Introduction

This chapter supplies information and instructions on how to set up and configure the
Product for first time use.

Set the Regional Voltage

The Product is equipped with a voltage selector that must be set for the region of use
before the mains power cord is connected. The selector can be set to 100 V, 120 V,
220 V, or 240 V. See Figure 2-1 for an illustration on how to set the voltage selector.

See Chapter 6 for instructions on how to change the fuse. Each voltage selection requires
a specific fuse. See Table 2-1.

Table 2-1. Fuses

Voltage Selector Fuse Fluke Part Number

100 V 0.25 A, 250 V (slow blow) 166306

120 V 0.25 A, 250 V (slow blow) 166306

220 V 0.125 A, 250 V (slow blow) 166488

240 V 0.125 A, 250 V (slow blow) 166488

Caution

To prevent damage to the Product, make sure the regional
voltage selector is in the correct position for the region of use
before mains power is connected.

1 2

Figure 2-1. Fuse Replacement and Line-Voltage Selection

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

hcn027.eps

2-3

1586A

Users Manual

Connect to Mains Power

Use the mains power cord to connect the Product to a 100 V ac, 120 V ac, or 230 V ac
nominal outlet as shown in Figure 2-2.

Warning

To prevent possible electrical shock, fire, or personal injury:

• Use only the mains power cord and connector approved for

the voltage and plug configuration in your country and rated
for the Product.

• Replace the mains power cord if the insulation is damaged

or if the insulation shows signs of wear.

• Make sure the ground conductor in the mains power cord is

connected to a protective earth ground. Disruption of the
protective earth could put voltage on the chassis that could
cause death.

• Do not put the Product where access to the mains power

cord is blocked.

Caution

To prevent damage to the Product, make sure the regional
voltage selector is in the correct position for the region of use
before mains power is connected.

Figure 2-2. Mains Power Cord Connection

hcn058.eps

2-4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Initial Setup and Configuration

Set the Handle Position 2

Set the Handle Position

The handle is used to easily transport the Product but can also be used as a stand.
Figure 2-3 shows the various handle positions and also shows how to remove and install
the handle and the protective rubber boots.

1

Viewing Position

2

Alternate Viewing Position

Carrying Position

3

5

To Remove, Pull End From Unit

4

6

Boot Removal

Removal Position (to Remove,
Pull Ends Out)

Figure 2-3. Handle Positions and Boot Removal

Hcn003.eps

2-5

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Power On and Standby

As shown in Figure 2-4, the Product has a main power switch located on the rear panel
that supplies power to the unit, and a Standby key () on the front panel that puts the
Product in a standby mode. Push the (I) side of the main power switch to power on the
Product. As the Product powers on, a startup screen is shown on the display while the
Product performs a self-check. This self-check can take up to 2 minutes to complete and
if the Product detects any errors, an error message is shown on the display that contains
the error description along with an error code to help troubleshoot the problem (see
“Error Messages” in Chapter 7).

Once the Product is powered on, use the Standby key () to put the Product in
standby. When in standby, the display, keys, and functions are disabled while the internal
components remain powered on and warmed up (see “Warm-Up the Product”).

Standby Key

Figure 2-4. Main Power Switch and Standby Key

Main Power
Switch

hcn052.eps

2-6

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Initial Setup and Configuration

Warm-Up the Product 2

Warm-Up the Product

It is recommended that the Product be warmed up before use to stabilize the
environmentally controlled components. This will ensure the best performance to the
specification listed in Chapter 1. Sufficient warm-up times are as follows:

• If the Product has been powered off for 30 minutes or more, let it warm-up for 1 hour

or more.

• If the Product has been powered off for less than 30 minutes, let it warm-up for a

minimum of two times the length of time it was powered off. For example, if Product
has been turned off for 10 minutes, let it warm-up for 20 minutes.

Configure the Product

Use the Instrument Setup menu to configure the Product. To open the Instrument Setup
menu, push
the menu softkeys shown on the display to edit the settings.

Table 2-2 shows the menu items and selections available in the Instrument Setup menu.

 on the front panel. To change a setting, highlight the setting then use

Table 2-2. Instrument Setup Menu

Menu Item Description Selections Available

Language

Firmware

Date

Time

Decimal
Format

Display
Brightness

Keypad Beep

Changes the display language.

Note

If the incorrect language is set by accident, push
then push . This temporarily resets the language to
English.

Shows the firmware version installed, model number, and
serial number

Changes the date and date format shown on the top-right
corner of the display. This date is also used for
timestamps in the data log.

Changes the time and time format shown on the top-right
corner of the display. This time is also used for
timestamps in the data log.

Changes the decimal format to show a comma or
decimal.

Changes the display brightness level. High, Med, or Low

Turn on or turn off the key beep that sounds when a key
is pushed.



English

中文

Français
Deutsch
Portugués

--

MM-DD-YYYY

YYYY-MM-DD

DD/MM/YYYY

12H or 24H

Period (0.000) or
Comma (0,000)

ON or OFF

Español

Русский

日本語

한국어

2-7

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Table 2-2. Instrument Setup Menu (cont.)

Menu Item Description Selections Available

Screen Saver Change the wait time or disable the screensaver.

Calibration
Date

Password
Management

Resume Scan

Remote Port

Relay Counter

Shows the date that the Product was last calibrated. See
the 1586A Calibration Manual for more information.

Change the Admin and User profile passwords.

Sets the Product to automatically turn on and resume
scanning and recording after a power loss.

Configure the LAN Ethernet or serial USB communication
settings.

Shows how many times the channel relays have been
scanned along with the name, serial number, and
calibration date of the Input Module.

Input Module and Relay Card Installation

Before an Input Module can be inserted into the rear panel, a relay card must be installed.
Standard product configurations include at least one slot preconfigured with a relay card.
Use the procedure below and refer to Figure 2-6 as necessary to install the relay card:

1. Power off the Product with the main power switch.

Never, 15 Min, 30 Min, or
60 Min

--

See “Set Up Security” in this
chapter for more information.

See “Automatic Power Loss
Scan Resume” in Chapter 4
for more information.

See the 1586A Remote
Programmers Guide for more
information.

--

2. Remove the four screws that secures the plastic frame to the rear panel.

3. Remove the plastic frame.

4. Slide the aluminum slot protector out of the Product.

5. Carefully align the rails of the relay card into the slot guides.

6. Slowly push the relay card into the Product until the card is fully seated.

Caution

Do not force the relay card into the slot. The card should easily
move when the rails of the relay card are properly aligned in the
slot guides.

7. Install the plastic frame and secure it to the rear panel with four screws.

2-8

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Initial Setup and Configuration

Input Module and Relay Card Installation 2

To install the Input Module:

1. Power off the Product with the main power switch.

2. Slide an Input Module into the slot the relay card was installed.

3. Power on the Product with the main power switch.

4. Verify that the module indicator appears green on the main screen (see Figure 2-5).

Note

If the module indicator is not green, the Product did not recognize the Input
Module or relay card. Refer to the troubleshooting section in Chapter 7.

Channel List

Slot 1

Slot 2

Figure 2-5. Module Indicator Example

Module Installed

Empty

hcn016.eps

2-9

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

1

2

3

4

Figure 2-6. Relay Card Installation

hcn018.eps

2-10

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Initial Setup and Configuration

Install a DAQ-STAQ Multiplexer Connection Module 2

Install a DAQ-STAQ Multiplexer Connection Module

In order to use an additional DAQ-STAQ Multiplexer Connection Module (the
Multiplexer), an interface relay card must be installed. Use the procedure below and refer
to Figure 2-7 as necessary.

To install an interface relay card:

1. Turn off the Product.

2. Remove the four screws that secures the plastic frame to the rear panel.

3. Remove the plastic frame.

4. Slide the aluminum slot protector out of the Product.

5. Carefully align the rail of the relay card into the slot guides.

6. Slowly push the relay card into the Product until the card is fully seated.

Caution

Do not force the card into the slot. The card should easily move
when the rails of the relay card are properly inserted in the slot
guides.

7. Install the plastic frame and secure it to the rear panel with four screws.

8. Connect the Product to a DAQ-STAQ Multiplexer with two signal cables.

9. Turn on the Product.

10. Verify that the module indicator appears green on the main screen (see Figure 2-5).

Note

If the module indicator is not green, the Product did not recognize the
module. Refer to the troubleshooting section in Chapter 7.

To remove an interface relay card:

1. Complete steps 1 through 3 of the installation procedure.

2. Pull out the interface relay card.

3. Slide the aluminum slot protector into the Product.

4. Install the plastic frame and secure it to the rear panel with four screws.

2-11

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Figure 2-7. DAQ-STAQ Multiplexer Installation

hcn032.eps

2-12

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Initial Setup and Configuration

Set Up Security 2

Set Up Security

The Product has one administration (Admin) and five User profiles. The Admin profile is
used for three purposes:

• To protect the Product from accidental or unintentional changes to the calibration

coefficients. The Admin profile is the only profile that can open the Calibration menu
to calibrate the Product. Refer to the 1586A Calibration Manual for calibration and
adjustment instructions.

• To clear the memory or reset the Product to factory defaults. See Chapter 6.

• To change passwords of the User profiles.

The User profiles sole purpose is to produce secure data files that are traceable back to
the user who performed the test (commonly referred to as test traceability). See Chapter 4
for more information.

Note

The user profile names are fixed and cannot be changed.

The Product ships from the factory with a default Admin password of “1586”. To change
the Admin or User profile password:

1. Push .

2. Highlight

3. Enter the default password of

previously changed) then push .

4. Select an

5. Enter a new password then push .

6. Enter the password again to confirm then push .

Password Management then push .

1586 (or the current Admin password if it was

Admin or User profile then push .

2-13

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

2-14

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 3

Input and Channel Configuration

Title Page

Introduction ........................................................................................................ 3-3

Input Wiring ....................................................................................................... 3-3

The 1586-2586 High Capacity Input Module ................................................ 3-3

The 1586-2588 DAQ-STAQ Multiplexer Connector Module ...................... 3-4

Wiring Safety and Considerations ................................................................. 3-5

3-Wire and 4-Wire Sense Input Configuration .............................................. 3-6

Input Types and Wiring Diagrams ................................................................ 3-7

Input Wiring Instructions .............................................................................. 3-8

Channel Configuration ....................................................................................... 3-10

About Channel Numbers ............................................................................... 3-10

Basic Channel Operations ............................................................................. 3-12

Open the Channel Setup Menu ................................................................. 3-12

Set Channels to ON or OFF ...................................................................... 3-13

Verify a Channel ....................................................................................... 3-14

Zero a Channel .......................................................................................... 3-14

Copy a Channel ......................................................................................... 3-15

Save or Load a Channel Configuration (Setup File) ................................. 3-16

Reset the Channel and Test Configuration ................................................ 3-18

Analog Channel Configuration (Ch001, Ch101 to Ch222) ........................... 3-18

Current and Voltage Channels .................................................................. 3-19

Resistance Channels .................................................................................. 3-20

Thermocouple Channels ............................................................................ 3-21

Thermistor Channels ................................................................................. 3-22

PRT Channels............................................................................................ 3-23

Digital I/O (DIO) Channel Configuration (Ch401) ....................................... 3-24

Totalizer Channel Configuration (Ch402) ..................................................... 3-25

Read Mode ................................................................................................ 3-25

Debounce .................................................................................................. 3-25

Math Channel Configuration (Ch501 to Ch520) ........................................... 3-27

Mx+B, Alarms, and Channel Options ................................................................ 3-30

Mx+B Scaling ................................................................................................ 3-30

HI and LO Channel Alarms ........................................................................... 3-31

Channel Delay ............................................................................................... 3-33

Rate of Change .............................................................................................. 3-33

Display As ..................................................................................................... 3-34

Open Detect ................................................................................................... 3-34

Probe Library ..................................................................................................... 3-34

3-1

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

3-2

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Input and Channel Configuration

Introduction 3

Introduction

This chapter supplies instructions on how to wire inputs to the Input Module then
configure the associated channel.

Input Wiring

The 1586-2586 High Capacity Input Module

The 1586-2586 High Capacity Input Module (the Input Module) is used to wire inputs of
various types to the Product (see Figure 3-1). Each Input Module has 20 analog channels
(ChX01 through ChX20) that can be configured to measure temperature, resistance, and
dc volts and two low-burden current channels (ChX21 and ChX22) that measure
dc current without the use of an external shunt resistor.

Note

To expand the functionality of the Product, current sources can also be connected
to channels ChX01 through ChX20 by the use of an accessory shunt resistor. See
Chapter 6 for part number and ordering information.

2-Wire Connection

Note: For 3-Wire connections, leave the H sense open.

Figure 3-1. 2-Wire, 3-Wire, and 4-Wire Input Module Connections

3-Wire or 4-Wire Connection

2-Wire

Connection

3-Wire or

4-Wire Connection

hcn012.eps

3-3

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

The 1586-2588 DAQ-STAQ Multiplexer Connector Module

The 1586-2588 DAQ-STAQ Multiplexer Connector Module (the Multiplexer) is an
external, bench-top accessory that is used to quickly wire inputs of various types to the
Product (see Figure 3-2). Each Multiplexer has 20 analog channels (ChX01 through
ChX20) that can be configured to measure temperature, resistance, and dc volts.

3-Wire

4-Wire

2-Wire

Thermocouple

Figure 3-2. 2-Wire, 3-Wire, and 4-Wire Multiplexer Connections

hcn040.eps

3-4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Input and Channel Configuration

Input Wiring 3

Wiring Safety and Considerations

Warning

To prevent possible electrical shock, fire, or personal injury:

• Consider all accessible channels to be hazardous live and an

electric shock hazard if any channel is connected to a
hazardous voltage source.

• Do not remove, touch, or change the internal wiring of

hazardous inputs until the input source is turned off.

• Remove inputs from hazardous voltage sources before an

input module is opened.

• Use the correct terminals, function, and range for

measurements.

• Make sure proper insulation is maintained between channel

wiring terminations and that no loose strands are outside of
the terminal block connections.

Caution

To prevent damage to the Product, do not exceed the specified
input voltage levels.

Shielded wires and sensors (such as thermocouples) should be used in environments
where "noisy" voltage sources are present. When shielded wiring is used, the shield is
normally connected to the L (low) input terminals for each channel. Alternate
configurations should be examined for each equipment application.

3-5

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

3-Wire and 4-Wire Sense Input Configuration

For improved resistance measurement accuracy, the Product can connect to 3-wire (PRT
only) and 4-wire instruments with sense connections.

Sense connections cancel out the resistance of the test lead or wire and significantly
improves the accuracy of the measurement. As shown in Table 3-1, many thermistors,
platinum-resistance thermometers (PRTs) and resistors use a 3-wire or 4-wire sense
connection to eliminate lead wire resistance errors.

For 2-wire measurements, the wires can be connected to either the source or sense
channels ChX01 through ChX20. For 3-wire or 4-wire resistance measurements, the
source wires must be connected to channels ChX01 through ChX10 and the sense wires
to the set of terminals directly across from where the source is connected (channels
ChX11 through ChX20).

Note

The Product will not show or let the user select a 3-wire or 4-wire input on
channels ChX11 through ChX20.

Figure 3-3 shows an example of a 4-wire input (PRT) with sense wires connected to the
Input Module, then how it would look in the Channel Setup menu once it is properly
configured.

To use the sense connections, the channel connected to the source wires must be
configured as a 3-wire or 4-wire input as described in “Channel Configuration
Procedures” on page 3-10. When a channel is configured as a 3-wire or 4-wire input, the
Product automatically reserves the sense channel across from the source that prevents the
channel from being independently configured, as shown in Figure 3-3.

3-6

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Input and Channel Configuration

Input Wiring 3

Sense wires connected
directly across from source
on Channel 116.

Source on Channel 106.
Note: For 3-Wire
connections, leave the
H sense open.

Figure 3-3. 3-Wire and 4-Wire Channel Reservation

Input Types and Wiring Diagrams

Table 3-1 lists the type of input types the Product can measure and the wiring polarity
that should be used to wire it to the Input Module.

3-Wire or 4-Wire Function

Channel Reserved

hcn014.eps

3-7

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Type of Input Range and Types

Table 3-1. Types of Inputs

Channel

Configuration

Reference

Wiring Polarity

DC Voltage Range: 0 V to 50 V Page 3-19

DC Current

Resistance (Ω)

Platinum
Resistance
Thermometer
(PRT)

[1]

Range: 0 mA to 100 mA Page 3-19

[3]

2-Wire or 4-Wire

Range: 0 Ω to 100 MΩ

Page 3-20

2-Wire, 3-Wire or 4-Wire

Types: ITS90, CVD,

Page 3-23

PT385, PT392

2-Wire or 4-Wire

Thermistor

Types: R(T)

[2]

, 2.252

Page 3-22

kΩ, 5 kΩ, 10 kΩ

Types: B, C, D, E, G, J,

Thermocouple

K, L, M, N, R, S, T, U,

W, POLY

[2]

Page 3-21

Source

Source

H

L

V

H

L

V

2-Wire

H

L

R

3-Wire

H

R

L

H

Sense

L

4-Wire

H

R

L

H

Sense

L

H

L

3-8

Note

[1] − Each Input Module has two terminal sets (mA 21 and mA 22) that are dedicated to current measurements.

[2] – Custom characterized.

[3] − 100 M

Ω is for Ch001 only. Other analog channels are 10 MΩ Max.

Input Wiring Instructions

Use the procedure below and refer to Figure 3-1 for instructions on how to wire a 2-wire,
3-wire, or 4-wire input to the Input Module.

Warning

To prevent possible electrical shock, fire, or personal injury,
read the Wiring Safety and Considerations section on page 3-5.

1. Power off the Product with the main power switch.

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Input and Channel Configuration

Input Wiring 3

2. Squeeze together the release tabs located on both sides of the Input Module then pull

the module out of the Product.

3. Use a straight-head screw driver to rotate the cover locks to the unlock position then

open the cover.

 Caution

To prevent damage to the module, never turn the cover locks
more than quarter of a turn.

4. Connect the positive source wire to the H terminal and the negative source wire to the

L terminal. For 3-wire and 4-wire sense connections, connect the sense wires to the
terminals directly across from the source wires. See “Sense Input Configuration” on
page 3-6.

5. Route the wires through the strain-relief pins then out the back of the Input Module.

If necessary, the rubber wire compressor used to secure the wires can be removed for
more room.

6. Close the Input Module cover and rotate the cover locks to the locked position.

7. Align the Input Module on the guide rails and carefully slide the module into the

connector at the rear of the Product until it latches in place.

8. Power on the Product with the main power switch. After powered on, the Product

tests the connection to the Input Module. If the Input Module is recognized, the
module indicator changes to green and shows all channels available on the left side of
the Channel Setup menu as shown in Figure 3-4. If the module indicator does not
turn green, refer to the troubleshooting information in Chapter 4.

9. Configure the channel. For instructions on how to configure the various input types,

see “Channel Configuration” on page 3-10.

Channel List

Slot 1

Slot 2

Figure 3-4. Module Indicator (Input Module Installed Shown)

Module Installed

Empty

hcn016.eps

3-9

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Channel Configuration

This section contains instructions on how to configure the channels after the inputs are
connected to the Input Module.

About Channel Numbers

A channel number (Ch) is a numerical identification associated with a set of terminals on
the Input Module. The channel number of the input is determined by the slot number the
Input Module is in (1 or 2) followed by the number of the terminal the input is connected
to (1 to 22) as illustrated in Figure 3-5. The front-panel inputs are permanently assigned
to channel Ch001. Here are some examples on how to determine the channel number of
an input:

• A voltage source is connected to input terminal 4 (04) in the Input Module and then

slid into slot 1. The channel is Ch104.

• A thermistor source is connected to input terminal 8 (08) in the Input Module and then

slid into slot 2. The channel is Ch208.

• A voltage source is connected to the front-panel terminals. The channel is Ch001.

Table 3-2 shows channel types and channel numbers.

Table 3-2. Channel Types and Numbers

Channel Type

Input Channel (front panel) Ch001

Input Channel (rear panel, slot 1) Ch101 to Ch122

Input Channel (rear panel, slot 2) Ch201 to Ch222

Digital I/O Channel Ch401

Totalizer Channel Ch402

Math Channel Ch501 to Ch520

Channel Numbers

and Range

Reference

See “Analog Channel Configuration (Ch001,
Ch102 to Ch222)” on page 3-18.

See “Digital I/O Channel Configuration
(Ch401)” on page 3-24.

See “Totalizer Channel Configuration
(Ch402)” on page 3-25.

See “Math Channel Configuration (Ch501 to
Ch520)” on page 3-26.

3-10

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Input and Channel Configuration

C

Channel Configuration 3

Slot: Channel 101 - 122

Slot: Channel 201 - 222

Rear View

12345678 123 456

01234567 012345

Front View

T-D AQ PR E

1586 A

Channel 001

Channel: 106

Rear-Panel Slot

Figure 3-5. Example Channel Assignment

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Input Module
Terminal Number

hcn026.eps

3-11

1586A

Users Manual

Basic Channel Operations

Use the instructions in this section to perform basic channel operations.

Open the Channel Setup Menu

The Channel Setup menu lets the user manage channels, verify inputs, and also set up
tests. To open the menu, push

To select channels, use the  and  arrow keys. To quickly move up and down the list
of channels, use the  and  arrow keys.

The Channel Setup menu cannot be accessed while a scan is in progress.

on the front panel.

Note

Table 3-3. Channel Setup Menu

3

4

5

Item Function

Module indicator that has two bars to show which Input Modules are connected and registered.



The top indicator is slot 1 and the bottom indicator is slot 2. When a module is in a slot, the
indicator is green. When a slot is empty, the indicator is white.

Channel status. When ON, the channel can be configured and the channel status indicator to the



left of the channel is green. When OFF, the channel information is not shown and the channel
status indicator is white.

List of available channels. Channels show in the list only when an Input Module relay card is
installed in a slot or a DAQ-STAQ Multiplexer is connected. For example, Ch201 through Ch222
will not show in the channel list until an Input Module relay card is installed into slot 2.



2

1

hcn017.eps

Note

Ch001 is always the front-panel terminals and always shows in the channel list.

3-12

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Input and Channel Configuration

Channel Configuration 3

Table 3-3. Channel Setup Menu (cont.)

Item Function

Channel status indicator. When a channel is set to ON, the channel status indicator is green. When



OFF, the channel status indicator is white.

Channel selection indicator. When a channel is selected, the channel information shows on the



screen. Use  and  to move up or down one channel at a time. Use  or  to jump to the next
module number (for example, to jump from channel Ch101 to channel Ch201).

Set Channels to ON or OFF

To scan, monitor, or record an input, the associated channel must be set to ON and
configured. When a channel is set to ON, it is referred to as “active”. The channel
indicator appears green when set to ON and white when set to OFF as shown in
Figure 3-6. To set a channel to ON, push

 then push . Push  again to set

the channel to OFF.

Channel Status Indicators

Green = ON

White = OFF

hcn006.eps

Figure 3-6. Channel Status Indicators

When a channel is set to ON, the channel loads the previous channel configuration. If the
channel was not previously configured, the default channel settings are loaded. To change
the or edit the channel:

1. Push

.

2. Push  or  to highlight a channel.

3. Push  to edit the channel.

4. Set the

Channel Status to ON if necessary.

3-13

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

The display opens a channel configuration sequence that prompts the user to select key
parameters for the specific channel type. These sequences are shown and described in the
analog channel configuration section that starts on page 3-18.

Note

If the configuration sequence is skipped or stopped before the sequence is
complete, the default channel settings are used for the skipped steps. Some
channel settings are not able to be configured or changed outside of the
setup sequence.

Use the  or  to select the settings and input values with the numeric keypad. Once a
parameter is set, push  to save the setting.

Verify a Channel

After a channel is set to ON and configured, a direct measurement can be made to verify
that the channel is configured properly.

To verify a channel:

1. Turn on the input source that is connected to the Product.

2. Push .

3. Push  or  to highlight a channel.

4. Set the channel to

5. Push  to edit the channel.

6. Push  to open the Verify Channel menu.

7. Evaluate the measurement and zero the channel if necessary. See “Zero a Channel”.

Zero a Channel

In certain applications, it may be necessary to zero the channel in order to make
measurements without unwanted offsets or noise levels. The zero channel function is
located in the Verify Channel menu that is accessed by a softkey in the Channel Setup
menu. The Product uses the Mx+B offset value to zero a channel. To do this, the Product
calculates the offset required to convert the measurement to a zero value, sets Mx+B to
ON, and loads the calculated offset value into the Mx+B settings. To clear the zero, the
offset value can be manually set back to the original value (usually “0”) or Mx+B can be
set to OFF if it was off before the channel was zeroed. Zero offset values can be viewed
in the setup file associated with the scan data file (see Chapter 4).

When a zero is performed, the Product will overwrite any custom offset
values in the Mx+B settings. If a channel has a custom Mx+B offset, make
note of the offset value before the channel is zeroed so it can be referred to
later if necessary.

To zero a channel:

ON.

Note

1. Turn on the input source that is connected to the Product.

3-14

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Input and Channel Configuration

Channel Configuration 3

2. Push .

3. Push  or  to highlight a channel.

4. Push  to edit the channel.

5. Push  to open the Verify Channel menu.

6. Push  to zero the channel. A confirmation message appears, select

continue or
is selected, the Product sets the Mx+B to

Cancel to disregard the changes and return to previous menu. After OK

ON and loads the calculated offset into the

OK to

Mx+B offset setting. To clear the zero function, set the Mx+B back to the original
values. See “Mx+B Scaling” on page 3-30 for instructions.

Mx+B Indicator

Relative Measurement Value

Baseline Measurement

Copy a Channel

The Product has a copy and paste function to help duplicate channels. When a channel is
duplicated, all of the channel configuration settings are copied and pasted to a new
channel number. The copy channel softkey in located in the Channel Setup menu.

When a channel is copied to another channel, the channel configuration of
the target channel is overwritten without a notification. Confirm the
channel selections before OK is pushed to prevent accidental overwrites.

To duplicate a channel with copy and paste:

1. Push

2. Push  or  to highlight a channel.

.

Zero Function Softkey

Figure 3-7. Zero Function

Note

hcn060.eps

3-15

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

3. Set the channel to ON if necessary.

4. Push  to open the Copy Channel menu.

5. Use  or  to highlight a channel then push  to select the channels to paste to.

6. Push  to paste the channels.

Save or Load a Channel Configuration (Setup File)

The channel and test configuration can be saved to a file referred to as the Setup file.
When the Setup file is saved, the Product saves the present configuration of each channel
(including Mx+B and Alarms) in their current state (ON or OFF). Setup files can be
loaded at a later time or transferred to another Product with a USB drive. Setup files are
managed and loaded from the internal memory in the Memory menu.

Notes

• Setup files cannot be directly saved to or loaded from the USB drive.

To save Setup files to a USB drive, save the file to the internal
memory, then copy it to the USB drive. To load a Setup file from a
USB drive, copy the file to internal memory then load the file. See the
instructions below.

• The Product will not load a Setup file if the present configuration does

not match the configuration in the Setup file. This is caused by missing
Input Modules. Match the configuration and try to load the Setup file
again.

To save a Setup File:

1. Push

2. Push .

3. Follow the on-screen directions to name the file then push  to save.

To save a Setup file to a USB drive:

1. Save the current Setup file to internal memory.

2. Insert a USB drive into the front-panel USB port.

3. Push .

4. Push  to select

.

Note

Wait about 15 seconds to let the Product recognize the USB drive. The LED
illuminates solid red when the USB drive is recognized and ready.

Internal Files.

3-16

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Input and Channel Configuration

Channel Configuration 3

5. Choose Setup Files then push .

6. Use the  and  keys to select the file to be copied.

7. Push  to manage the file.

8. Push  to copy to the USB drive.

Note

Do not remove the USB drive until you see a file transfer complete
message.

To load a Setup File:

1. Push .

2. Push  to select internal files.

3. Select

Setup Files then push .

4. Use  and  to highlight the Setup File.

5. Push  to load and use the Setup File.

To load a Setup File from a USB drive:

1. Insert a USB drive into the front-panel USB port.

Note

Wait 15 seconds to let the Product recognize the USB drive.

2. Push .

3. Push  to select

4. Choose

Setup Files then push .

USB Files.

5. Use the  and  keys to select the file to be copied.

6. Push  to manage the file.

7. Push  to copy to the internal memory.

Note

Do not remove the USB drive until you see a file transfer complete
message.

3-17

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Reset the Channel and Test Configuration

To reset the entire channel configuration and test setup:

Note

All channels are set to the default settings when reset and cannot be
restored unless the configuration was saved.

1. Push and hold

2. Push  to confirm to reset channel setup, or push  to cancel.

Analog Channel Configuration (Ch001, Ch101 to Ch222)

After an analog input is connected to the Input Module and/or the front-panel connectors,
the channel must be configured for the type of input that is connected. Analog inputs are
channels Ch101 to Ch122 and Ch201 to Ch222. Use the procedure below and the tables
in this section to set up channels for specific input types.

Please read the considerations below to help with channel configuration:

• For new channels that have not been previously set up, the user is prompted to

configure the channel when it is set to ON for the first time. Push the cancel softkey
() while in the setup sequence to: (1) accept the default settings for new channels
or (2) use the previous configuration for channels previously configured.

• A channel can be configured with the Edit Channel softkey in the Channel Setup

menu.

• Each channel has independent channel options such as Channel Delay, Rate of

Change, Display As reading type, and thermocouple open-circuit detect that can be
accessed with the Channel Options softkey in the Edit Channel menu. The channel
options listed vary based on the on the input type.

• After a channel is configured, it is important to verify the channel with the Verify

Channel softkey on the Channel Setup menu. This ensures that the channel was
configured properly before data is collected from a scan. See “Verify a Channel” on
page 3-14.

for 3 seconds.

3-18

To configure an analog channel:

1. Push

2. Set the channel to ON (see “Set Channels to ON or OFF” on page 3-12). When the

3. Use the information in the tables in this section to configure the channel. Push  or

.

channel is set to ON, a channel configuration sequence shows on the display that
steps the user through an initial configuration sequence as shown in Table 3-5. If the
channel was previously configured, push  to cancel the configuration sequence
to use the last channel configuration.

 to highlight the channel setting then push  to edit the setting.

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Input and Channel Configuration

Channel Configuration 3

4. After the channel is configured, verify that the channel is configured properly and

reading the input. For instructions, see “Verify a Channel” on page 3-14.

Current and Voltage Channels

Refer to Table 3-4 to configure a dc voltage or current channel.

Note

Ch001 can be set up for all measurements. ChX21 and ChX22 are the only
channels that can be set up for current measurements. To expand the
functionality of the Product, current sources can also be connected to
ChX01 through ChX20 by the use of an accessory shunt resistor. See
Chapter 2 for part number and ordering information.

Table 3-4. Current and Voltage Channel Configuration

1

2

3

4

5

hcn050.eps

Item Function

 DC voltage or DC current function selection.

For voltage, set the voltage range to: Auto, 100 mV, 1 V, 10 V, or 50 V.



For current, set the current range to: Auto, 100 μA, 1 mA, 10mA, or 100 mA.

 Input a custom alpha-numeric label to help identify the channel (optional).

 Set an alarm for this channel (optional). See “HI and LO Channel Alarms” on page 3-31.

 Apply Mx+B scaling to the measurement (optional). See “Mx+B Scaling” on page 3-30.

3-19

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Resistance Channels

Refer to Table 3-5 to configure a resistance channel.

Table 3-5. Resistance Channel Configuration

1

2

3

4

5

6

hcn008.eps

Item Function

 Resistance function selection.

Set up the channel for a 2-wire or 4-wire resistance measurement connection. See “Sense Input



Configuration” on page 3-6.

 Set the range to: Auto, 100 Ω, 1 kΩ, 10 kΩ, 100 kΩ, 1 MΩ or 10 MΩ. Ch001 can be set to 100 MΩ.

 Input a custom alpha-numeric label to help identify the channel (optional).

 Set an alarm for this channel (optional). See “HI and LO Channel Alarms” on page 3-31.

 Apply Mx+B scaling to the measurement (optional). See “Mx+B Scaling” on page 3-30.

3-20

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Input and Channel Configuration

Channel Configuration 3

Thermocouple Channels

Refer to Table 3-6 to configure a thermocouple channel. Thermocouple types R and S
have optional correction polynomial coefficients to be entered. The correction equation is
as follows:

32

3210 tCtCtCCV +++=Δ

where t is the temperature in °C and ΔV is the correction in millivolts. If the correction is
not used, leave the coefficients set to 0.

Table 3-6. Thermocouple Channel Configuration

1

2

6

Item Function

 Thermocouple function selection.

 Select the thermocouple type.

 Input a custom alpha-numeric label to help identify the channel (optional).

 Set an alarm for this channel (optional). See “HI and LO Channel Alarms” on page 3-31.

 Apply Mx+B scaling to the measurement (optional). See “Mx+B Scaling” on page 3-30.

 Load a thermocouple from the Probe Library. See “Probe Library” on page 3-34.

3

4

5

hcn009.eps

3-21

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Thermistor Channels

Refer to Table 3-7 to configure a thermistor channel. The R(T) polynomial type requires
polynomial coefficients to be entered. The thermistor characterization polynomial is as
follows:

x

1

15.273

+=t

yR exp=

Where t is the temperature in °C and R is the resistance in Ω. Any coefficients that are
not used must be set to 0.

32

3210 xBxBxBBy +++=

Table 3-7. Thermistor Channel Setup

1

2

3

7

4

5

6

hcn010.eps

Item Function

 Thermistor function selection.

 Select the thermistor type. Types available: R(T), 2.252 kΩ, 5 kΩ, and 10 kΩ.

Set up the channel for a 2-wire measurement connection. See “Sense Input Configuration” on



page 3-6.

 Input a custom alpha-numeric label to help identify the channel (optional).

 Set an alarm for this channel (optional). See “HI and LO Channel Alarms” on page 3-31.

 Apply Mx+B scaling to the measurement (optional). See “Mx+B Scaling” on page 3-30.

 Load a thermistor from the Probe Library. See “Probe Library” on page 3-34.

3-22

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Input and Channel Configuration

Channel Configuration 3

PRT Channels

Refer to Table 3-8 to configure a Platinum Resistance Thermometer (PRT) channel.
ITS-90 type requires deviation function coefficients to be entered. Coefficient "A" should
be set to the value of “a7” or “a8” as shown on the PRT calibration certificate. Likewise,
"B" is for “b7” or “b8” and "C" is for “c7”. If a coefficient is not available, it must be set
to “0”.

Table 3-8. PRT Channel Setup

1

2

3

8

Item Function

 PRT function selection.

 Select the PRT type. Types available: ITS90, CVD, PT-385, and PT-392.

 Set the PRT resistance value at 0 °C (CVD, PT-385, or PT-392) or 0.01 °C (ITS-90).

Set up the channel for a 2-wire, 3-wire, or 4-wire measurement connection. See “Sense Input



Configuration” on page 3-6.

4

5

6

7

hcn011.eps

 Input a custom alpha-numeric label to help identify the channel (optional).

 Set an alarm for this channel (optional). See “HI and LO Channel Alarms” on page 3-31.

 Apply Mx+B scaling to the measurement (optional). See “Mx+B Scaling” on page 3-30.

 Load a PRT from the Probe Library. See “Probe Library” on page 3-34.

3-23

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1586A

Users Manual

Digital I/O (DIO) Channel Configuration (Ch401)

The Product can sense and output a digital, 8-bit transistor-transistor logic (TTL) value
that can be displayed as the 8-bit TTL value and be recorded as the decimal equivalent.
This is accomplished with the rear-panel digital I/O connectors (DIO) that are shown in
Figure 3-8.

When a DIO input is sensed, the Product displays the status of the digital I/O as 8-bit
TTL value and records the decimal equivalent. The 8-bit TTL value can also be seen
when a channel is monitored. The default value is a high state that shows as “11111111”
until the Product senses a low state or is used as an output. A few examples of some 8-bit
TTL values and their decimal equivalents are shown below:

• 11111111 is represented by decimal 255

• 00001111 is represented by decimal 15

• 00010001 is represented by decimal 17

• 10000101 is represented by decimal 133

Notes

For input and output specifications such as input and output voltages, see
“Digital I/O” in Chapter 1.

The DIO channel will be read-only when it is set to ON (active).

With a remote command, the Product can output an 8-bit TTL value. See the
1586A Remote Programmers Guide for more information.

Terminal

TOT

1
2
3
4
5
6
7

8

GND

Function

Totalizer Input

Input/Output Line 1

Input/Output Line 2

Input/Output Line 3

Input/Output Line 4

Input/Output Line 5

Input/Output Line 6

Input/Output Line 7

Input/Output Line 8

Ground Terminal

Figure 3-8. DIO Connector

Set up the DIO channel as follows:

1. Connect the equipment to the DIO input terminal then insert it into the rear-panel

digital I/O (DIO) port.

2. Push

.

hcn019.eps

3-24

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Input and Channel Configuration

Channel Configuration 3

3. Set channel 401 to ON (see “Set Channels to ON or OFF” on page 3-13).

4. Assign a label to the channel if desired.

5. To measure the DIO, monitor channel Ch401 in the Scan/Monitor menu. The

8-bit TTL value is shown on the display and the decimal equivalent will be recorded
to the data file.

Totalizer Channel Configuration (Ch402)

The Product is equipped with a unidirectional, resettable totalizer with an input count
capability of 0 to 1048575 (20 bits). When a digital input is connected to the TOT input
on the rear panel and Ch402 is set to on, the Product counts each time the dc voltage of
