Installation instructions
and User guide
Ceramic glass cooktops
CT2802, CT560C, CT5602F and CT6551S models
NZ AU
Contents
1
Safety and warnings
Installation instructions
Introduction
Using your cooktop
Cookware and cooking tips
Care and cleaning
Frequently asked questions
Warranty and service
6
8
10
12
13
14
15
Important!
SAVE THESE INSTRUCTIONS
The models shown in this User Guide may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please go to our website www.fisherpaykel.com or contact your local Fisher & Paykel dealer.
2
Safety and warnings
WARNING!
Electrical Shock Hazard
Before carrying out any work on the electrical section of the appliance, it must be disconnected from the mains electricity supply.
Connection to a good earth wiring system is absolutely essential.
Failure to follow this advice may result in death or electrical shock.
WARNING!
Cut Hazard
Beware of sharp edges when handling appliances. Failure to use caution could result in injury or cuts.
Important safety precautions
Installation
Read these instructions carefully before installing or using this product. Please make this information available to the person responsible for installing the product as it could reduce your installation costs. This appliance must be installed in accordance with these installation instructions. This appliance is to be installed only by an authorised person. Incorrect installation, for which the manufacturer accepts no responsibility, may cause personal injury or damage. Always disconnect the cooktop from mains power supply before carrying out any maintenance or repairs.
Safety and warnings
This product should not be sealed into the bench with silicone or glue. Doing so will make future servicing difficult. Fisher & Paykel will not be liable for costs associated with releasing such a product, nor for repairing damage that may be incurred in doing this. When this product is installed it shall not be used as a space heater, especially if installed in marine craft or caravans. No combustible material or products should be placed on this product at any time.
Before you install the appliance, ensure that
the benchtop is square and level and no structural members interfere with space requirements. there is a minimum of 60 mm between the cutout and the rear or side wall. if the cutout is less than 100 mm from the wall, some form of protection against heat is used, such
as ceramic tiles. if the appliance is a CT2802 model, the power supply cable is rated for use at 100OC. a suitable disconnection switch is incorporated in the permanent wiring, mounted and positioned
to comply with local wiring rules and regulations. A means of disconnection with at least a 3 mm
air gap contact separation in all poles must be incorporated into the fixed wiring in accordance
with the wiring rules, unless the local wiring rules allow for the following variation of these
requirements: A means of disconnection from the supply having an air gap separation in all
active (phase) conductors must be incorporated into the fixed wiring. the interconnection cord between the cooktop and the oven or control box will not be accessible
via cupboard doors after installation. This applies to any extension cord as well, even if they are
double-insulated. you consult local building authorities and by-laws if in doubt regarding installation. the appliance is rated 5.9 kW at 220-240 V (CT560C,CT5602F,CT6551S models) or 3.0 kW at
220-240V (CT2802 models).
3
When you install the appliance, ensure that you comply with the following requirements:
If prolonged use is anticipated, or the cooktop is mounted above a drawer space, a thermal
protection barrier between is recommended AND Where the base of this product is accessible after installation, a thermal protection barrier MUST
be installed to prevent contact. If a thermal protection barrier is installed below the cooktop, this barrier must be made of heat
resistant material capable of withstanding sustained exposure to temperatures up to 70
be at least 30 mm and no greater than 75 mm below the base of the cooktop and have FOUR
ventilation holes or TWO similiar holes for CT2802 models (min 50 mm – max 70 mm diameter,
see Fig. 1 for details). These ventilation holes must be open to free air.
We recommend that the thermal protection barrier be removable, so that the cooktop can be
easily secured with the supplied clamps. Use easy-to-clean finishes for the wall surfaces surrounding the cooktop, so that cooking fume
staining resulting from using the cooktop is easy to remove.
o
C,
4
Safety and warnings
Electrical Shock Hazard
Do not attempt to use this appliance if the ceramic glass surface is cracked. If the surface becomes cracked, switch the appliance and the power supply o immediately. Switch the cooktop o at the wall before cleaning or maintenance.
Failure to do so may result in death or electrical shock
Hot Surface Hazard
During use, accessible parts of this appliance will become hot enough to cause burns. Avoid body or clothing contact with the ceramic glass until it is cool. Keep children away. Handles of saucepans may be hot to touch. Check saucepan handles do not overhang other elements that are on. Keep handles out of reach of children.
Failure to do so may result in serious injury.
WARNING!
WARNING!
WARNING!
Cut Hazard
When the safety cover is retracted, the blade in the scraper is razor-sharp. Use with extreme care and always store safely and out of reach of children.
Failure to use caution could result in injury or cuts.
