CONTENTS 1
Introduction
Safety Instructions 2
First Use 2
Controls
Ignition 3
Adjusting the Flame 3
Flame Failure 3
If the Cooktop does not Light 4
Cleaning
Cleaning your Cooktop 4
Utensils
Cookware 5
Efficient Cooking 5
Saucepans 5
Wok 5
Coffee Pot Support 5
Frequently Asked Questions 6
Warranty
Fisher & Paykel Manufacturer's Warranty 7
Product Details 8
Customer Care 9
INTRODUCTION
CONGRATULATIONS
Congratulations on the purchase of your new Gas Cooktop.
We strongly recommend that you read these Use and Care Instructions carefully to take full
advantage of the features offered by this product. This books covers operational instructions
for the CG602 and GC9002 Series Gas Cooktops.
SAFETY INSTRUCTIONS
1. Household appliances are not intended to be played with by children.
2. Children or persons with a disability that may limit their ability to use the appliance, should
have a competent person instruct them in its use. This person should be satisfied that they
can then use the appliance without danger to themselves or their surroundings.
WARNINGS
1. Do not spray aerosols in the vicinity of this appliance while it is in operation.
2. Where this appliance is installed in Marine Craft or in caravans, it shall not be used as a
space heater.
3. If the electrical supply cord is damaged it must only be replaced by an authorised person.
FIRST USE
Before using your Gas Cooktop, clean it with warm soapy water to remove dust.
Check that the electricity is switched on in order for the electronic ignition to work.
2
CONTROLS 3
IGNITION
ADJUSTING THE FLAME
FLAME FAILURE
Adjust
OFF
Choose the control knob for the burner you want to
use. Press down and turn the knob counter clockwise
to the High symbol.
All the ignitors will spark until the gas ignites on the
selected burner (see Figure 1).
The flame can be adjusted anywhere between the
High and Low symbol, do not regulate the flame
between High and Off.
Flame Failure is a safety device fitted to some models
(listed below). A metal probe behind the burner
generates electricity when a flame is present. After 5
seconds the metal probe gets hot enough to hold a
valve open and maintain the gas supply. If the flame
is blown out then the gas to the burner is cut off.
To operate the Flame Failure you need to hold the
burner knob down for 5 seconds after the burner has
ignited. Letting go too soon will extinguish the flame.
The Flame Failure models are
CG602F/CG602WF/CG602WFC & GC9002 series. If
you are unsure if you have a Flame Failure model, you
can look at the back of the burners and check there
are two probes (spark electrode and flame failure
probe), indicating a flame failure model.
Figure 1
