CPX terminal
Description
Electronics
CMAX axis controller
Type
CPX−CMAX−C1−1
System description CMAX axis controller
Mounting, installation and diagnostics
Positioning system
Description
559 751 en 0908NH [727 403]
Contents and general safety instructions
Original . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
de |
Edition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . en 0908NH
Designation . . . . . . . . . . . . . . . . . . P.BE−CPX−CMAX−SYS−EN
Order no. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 559 751
© (Festo AG & Co. KG, D 73726 Esslingen, 2009)
Internet: http://www.festo.com
E−mail: service_international@festo.com
The copying, distribution and utilisation of this document as well as the communication of its contents to others with out expressed authorization is prohibited. Violations will give rise to compensation. All rights are reserved, in par ticular the right to carry out patent, registered design or ornamental design registration.
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
I |
Contents and general safety instructions
Interbus®, DeviceNet®, PROFIBUS®, CC−Link®, EtherNet/IP®, PROFINET®, Adobe Reader® und TORX® are registered trademarks of their respective trademark holders in certain countries.
II |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
Contents and general safety instructions
Intended use . . . |
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
VII |
|
Safety note . . . . . |
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
VIII |
|
Target group . . . |
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
X |
|
Service . |
. . . . . . . |
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
X |
Required software versions for the CPX nodes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
XI |
||
Important user instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
XII |
||
Notes on this description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
XIV |
||
Glossary |
. . . . . . . |
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
XVII |
1. |
CMAX system overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1−1 |
|
1.1 |
CMAX axis controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1−3 |
|
|
1.1.1 |
Connection and display components of the CMAX . . . . . . . . . . . . . |
1−3 |
|
1.1.2 |
CMAX function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1−4 |
|
1.1.3 |
CMAX in the CPX terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1−5 |
1.2 |
Structure of a positioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1−6 |
|
1.3 |
Parameterisation and commissioning options . . . . . . . . . . . . . . . . . . . . . . . . |
1−7 |
|
|
1.3.1 |
Festo Configuration Tool (FCT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1−7 |
|
1.3.2 |
FHPP communication profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1−8 |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
III |
Contents and general safety instructions
2. |
Fitting and pneumatic installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
2−1 |
|
2.1 |
General notes on mounting and installation . . . . . . . . . . . . . . . . . . . . . . . . . . |
2−3 |
|
2.2 |
Mounting/dismounting the CMAX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
2−4 |
|
2.3 |
Installation of the drive and position measuring system . . . . . . . . . . . . . . . . |
2−6 |
|
|
2.3.1 |
General mechanical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . |
2−7 |
|
2.3.2 |
Drive, shock absorbers and fixed stops . . . . . . . . . . . . . . . . . . . . . . |
2−8 |
|
2.3.3 |
Position measuring system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
2−10 |
|
2.3.4 |
Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
2−12 |
2.4 |
VPWP proportional directional control valve . . . . . . . . . . . . . . . . . . . . . . . . . |
2−17 |
|
|
2.4.1 |
Approved drive/valve combinations . . . . . . . . . . . . . . . . . . . . . . . . |
2−17 |
|
2.4.2 |
Mounting the VPWP proportional directional control valve . . . . . . |
2−19 |
2.5 |
Mounting the CASM sensor interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
2−22 |
|
2.6 |
Pneumatic installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
2−23 |
|
|
2.6.1 |
Compressed air supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
2−23 |
|
2.6.2 |
Filter regulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
2−24 |
|
2.6.3 |
Air reservoir (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
2−25 |
|
2.6.4 |
VPWP proportional directional control valve . . . . . . . . . . . . . . . . . . |
2−25 |
|
2.6.5 |
Tubing and fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
2−29 |
3. |
Electrical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
3−1 |
|
3.1 |
Earthing |
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
3−3 |
3.2 |
Axis interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
3−5 |
|
|
3.2.1 |
VPWP proportional directional control valve . . . . . . . . . . . . . . . . . . |
3−7 |
|
3.2.2 |
CASM sensor interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
3−9 |
3.3 |
Ensuring protection class IP65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
3−11 |
|
3.4 |
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
3−12 |
|
|
3.4.1 |
Determining the current consumption . . . . . . . . . . . . . . . . . . . . . . . |
3−13 |
|
3.4.2 |
Power supply concept, formation of power zones . . . . . . . . . . . . . |
3−14 |
3.4.3Disconnecting the load voltage in connection with a brake or
clamping unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3−18
IV |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
Contents and general safety instructions
4. |
Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−1 |
|
4.1 |
Overview/procedure for commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−3 |
|
|
4.1.1 |
Instructions for commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−4 |
|
4.1.2 |
Installing the Festo Configuration Tool and FCT CMAX plug−in . . . . |
4−5 |
4.2 |
Preparations for commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−8 |
|
|
4.2.1 |
Checking the axis string . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−8 |
|
4.2.2 |
Switching on the power supply, switch−on behaviour . . . . . . . . . . . |
4−8 |
|
4.2.3 |
Establishing a connection to the PC . . . . . . . . . . . . . . . . . . . . . . . . . |
4−11 |
4.3 |
Commissioning with the FCT (overview) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−12 |
|
|
4.3.1 |
Overview of commissioning steps . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−12 |
4.4 |
Operation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−14 |
|
|
4.4.1 |
CMAX control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−14 |
|
4.4.2 |
General operation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−14 |
4.5 |
Structure of the cyclical I/O data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−16 |
|
|
4.5.1 |
Defining the operating mode with CCON . . . . . . . . . . . . . . . . . . . . . |
4−17 |
|
4.5.2 |
Controlling the CMAX in record select operating mode . . . . . . . . . |
4−19 |
|
4.5.3 |
Controlling the CMAX in direct operating mode . . . . . . . . . . . . . . . |
4−20 |
|
4.5.4 |
Execute record (record select mode) . . . . . . . . . . . . . . . . . . . . . . . . |
4−22 |
|
4.5.5 |
Direct mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−29 |
|
4.5.6 |
Acknowledge error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−37 |
4.6 |
Flow charts for programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−38 |
|
|
4.6.1 |
Establish ready status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−38 |
|
4.6.2 |
Start record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−41 |
|
4.6.3 |
Acknowledge malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−42 |
|
4.6.4 |
Switch operating mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4−43 |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
V |
Contents and general safety instructions
5. |
Diagnostics and error handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5−1 |
|
5.1 |
Summary of diagnostics options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5−3 |
|
5.2 |
Malfunctions and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5−4 |
|
|
5.2.1 |
Error numbers on the CPX terminal . . . . . . . . . . . . . . . . . . . . . . . . . |
5−6 |
|
5.2.2 |
Malfunction groups: Classification according to the cause . . . . . . |
5−6 |
5.2.3Error level and reset type: Classification according to effect and
|
|
acknowledgement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5−7 |
|
5.2.4 |
Error numbers and warning numbers . . . . . . . . . . . . . . . . . . . . . . . |
5−8 |
5.3 |
Diagnostics via LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5−29 |
|
|
5.3.1 |
CMAX−specific LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5−30 |
|
5.3.2 |
Axis−specific LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5−31 |
|
5.3.3 |
LEDs on the VPWP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5−32 |
|
5.3.4 |
LEDs on the sensor interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5−33 |
|
5.3.5 |
LEDs on the displacement encoder (DGCI only) . . . . . . . . . . . . . . . |
5−34 |
5.4 |
Diagnostics via the display/7−segment display . . . . . . . . . . . . . . . . . . . . . . . |
5−35 |
|
|
5.4.1 |
Error status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5−35 |
|
5.4.2 |
Status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5−36 |
5.5 |
Diagnostic functions with the CPX−MMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5−39 |
|
|
5.5.1 |
Error display ([Diagnostics] menu) . . . . . . . . . . . . . . . . . . . . . . . . . . |
5−39 |
|
5.5.2 |
Information on the CMAX ([Module data] menu) . . . . . . . . . . . . . . . |
5−40 |
A. |
Technical appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
A−1 |
|
A.1 |
CMAX technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
A−3 |
|
A.2 |
Replacing components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
A−6 |
|
A.3 |
Additional pneumatic circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
A−7 |
|
A.4 |
Index . . |
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
A−8 |
VI |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
Contents and general safety instructions
The CPX−CMAX−C1−1 axis controller documented in this description is intended exclusively for use in Festo CPX terminals for installation in a machine or an automation system.
In connection with a CPX terminal with suitable CPX bus nodes or CPX−FEC, as well as with enabled drives with a displacement encoder as well as a VPWP proportional direc tional control valve, CMAX serves as a position controller with position and force control for pneumatic drives.
The CPX terminal may only be used with the CMAX as follows:
As intended for the industrial environment
In its original condition without unauthorised modifica tions. Only the conversions or modifications described in the documentation supplied with the product are per mitted.
In perfect technical condition.
Only in combination with approved components (valves, drive/displacement encoder combinations, see section 1.2).
The limit values specified for pressures, temperatures, electri cal data, torques etc. should be observed.
Please comply with regulations of the trade associations, the German Technical Control Board (TÜV), the VDE or the relevant national regulations.
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
VII |
Contents and general safety instructions
Protection against dangerous movements
Warning
High acceleration forces at the connected actuators! Unexpected motions can cause collisions and severe injuries.
Dangerous movements can occur due to the faulty control ling of connected actuators, e.g. due to:
Dirty or faulty wiring/cabling
Component operating errors
Measured value and signal generator errors
Faulty or non−EMC−compliant components
Errors in the higher−order control system.
Simply switching off the compressed air supply or load voltage are not suitable locking procedures. In the event of a fault, this could lead to unintentional movement of the drive.
·Before mounting, installation and maintenance work, put the system into a safe state (e.g. by putting the drive in a safe position and deactivating the controller).
Always make sure that the compressed air and power supplies are switched off and locked before working in the machine area.
·Make sure that no persons are in the operating range of the drive or any other connected actuators.
·Do not switch on the compressed air until the system is correctly installed and parameterised.
VIII |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
Contents and general safety instructions
·The holding brakes controlled by the drive controller are not appropriate for personal protection by themselves. Lock vertical axes additionally to keep them from falling down or sinking when the compressed air and load volt age are switched off, e.g. by means of:
mechanical locking of the vertical axis
external braking/safety catch/clamping device
sufficient counterbalance of the axis.
·If used in safety applications, additional measures are necessary, e.g. in Europe the standards listed under the EU machine guidelines must be observed. Without addi tional measures in accordance with statutory minimum requirements, the product is not suitable for use in safety−related sections of control systems.
Protection from pressurised tubing
Caution
Danger of injury through inappropriate handling of pres surised tubing!
Uncontrolled movements of the connected actuators and uncontrolled movements of loose tubing can cause injury to human beings or damage to property.
·Do not connect, disconnect or open pressurised lines.
·The lines must always be exhausted before removal (release compressed air).
·Use suitable protective equipment (e.g. safety goggles, safety shoes, etc.).
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
IX |
Contents and general safety instructions
This manual is intended exclusively for technicians trained in control and automation technology, who have experience in installing, commissioning, programming and diagnosing posi tioning systems.
Please consult your local Festo Service agent if you have any technical problems.
X |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
Contents and general safety instructions
Particular software versions for the CPX node are required for operating the CMAX (versions as of August 2009):
CPX node |
Required version 1) |
Use |
Special features 2) |
CPX−FEC |
From Revision 18 (R18) |
On request |
Max. 8 CMAX modules |
|
|
|
|
CPX−FB6 (Interbus) |
From Revision 22 (R22) |
On request |
Max. 1 CMAX module |
|
|
|
|
CPX−FB11 (DeviceNet) |
From Revision 20 (R20) |
Suitable |
Max. 8 CMAX modules |
|
|
|
|
CPX−FB13 (PROFIBUS−DP) |
From Revision 23 (R23) |
Suitable |
Max. 8 CMAX modules |
|
|
|
Acyclic services, DPV1 |
|
|
|
(then max. |
|
|
|
7 CMAX modules) |
|
|
|
|
CPX−FB14 (CANopen) |
From Revision 20 (R20) |
On request |
Max. 3 CMAX modules |
|
|
|
|
CPX−FB23 (CC link) |
From Revision 19 (R19) |
On request |
Max. 8 CMAX modules |
|
|
|
|
CPX−FB32 (Ethernet/IP) |
From Revision 14 (R14) |
On request |
Max. 8 CMAX modules |
|
|
|
|
CPX−FB33 (PROFINET, M12) |
From Revision 7 (R7) |
On request |
Max. 8 CMAX modules |
|
|
|
|
CPX−FB34 (PROFINET, RJ45) |
From Revision 7 (R7) |
On request |
Max. 8 CMAX modules |
|
|
|
|
CPX−FB38 (EtherCAT) |
All |
On request |
Max. 8 CMAX modules |
|
|
|
|
CPX−CEC |
In preparation |
On request |
Max. 8 CMAX modules |
|
|
|
|
1) Revisions version (Rev...) see name plate. Older revisions are not suitable for use with CMAX and cannot lead to the intended behaviour.
2) Depending on the CPX node functions used, the address range and therefore the maximum number of modules can be further restricted, if necessary.
Tab. 0/1: Overview CPX nodes
Please also observe the notes on the software version in the documentation for the CPX node.
To commission the CMAX, you will require the Festo configur ation tool with a CMAX plug−in. You can find this on the Festo website at:
èwww.festo.com ˛ Downloads ˛ Download Area: Software, drivers and firmware ˛ Enter search term: CMAX
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
XI |
Contents and general safety instructions
Danger categories
This manual contains instructions on the possible dangers which can occur if the product is not used correctly. These instructions are marked (Warning, Caution, etc), printed on a shaded background and marked additionally with a picto gram. A distinction is made between the following danger warnings:
Warning
... means that failure to observe this instruction may result in serious personal injury or material damage.
Caution
... means that failure to observe this instruction may result in personal injury or material damage.
Note
... means that failure to observe this instruction may result in material damage.
The following pictogram marks passages in the text which describe activities with electrostatically sensitive devices:
Electrostatically sensitive devices: Inappropriate handling can result in damage to components.
XII |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
Contents and general safety instructions
Identification of specific information
The following pictograms designate texts that contain special information.
Pictograms
Information:
Recommendations, tips and references to other sources of information
Accessories:
Information about necessary or useful accessories for the
Festo product.
Environment:
Information on the environmentally friendly use of Festo products.
Text designations
·Bullet points indicate activities that may be carried out in any order.
1.Numerals denote activities which must be carried out in the specified sequence.
Arrowheads indicate general lists.
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
XIII |
Contents and general safety instructions
This description refers to the following versions:
CPX−CMAX−C1−1 axis controller starting from software version V 1.0
This description contains special information on the mode of operation, mounting, installation and commissioning of the CMAX axis controller with the modules and components on the axis string (see Tab. 0/2).
Information about the activation, programming and diagnosis of a CMAX with the used CPX node can be found in the •CMAX communication profile" description.
Special information about the configuration for certain CPX nodes can be found in the corresponding supplementary description. See Tab. 0/3.
General basic information on the mode of operation, mount ing, installing and commissioning CPX terminals can be found in the CPX system description, type P.BE−CPX−SYS−... .
XIV |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
Contents and general safety instructions
|
This description contains information on the following |
|
modules and components of the positioning system: |
Module/component type |
Description |
CMAX−C1−1 |
CMAX axis controller with 7−segment display as well as an axis |
|
interface to the VPWP. |
|
The CMAX is a CPX module (technology module) in a CPX terminal. |
|
VPWP−... |
VPWP proportional directional control valve with connections to the |
|
|
CMAX and to the displacement encoder or sensor interface. |
|
|
The position measuring system or sensor interface is connected to |
|
|
the VPWP. |
|
|
Additional digital output with a load voltage supply for activating a |
|
|
brake or clamping unit. |
|
|
|
|
|
Sensor interfaces with a connection to the VPWP, for connecting |
|
|
special position measuring systems to the axis string: |
|
CASM−S−D2−R3 |
analogue, absolute displacement encoders (potentiometers) |
|
CASM−S−D3−R7 |
digital, incremental displacement encoders |
|
|
|
|
|
Enabled drives with position measuring systems: 1) |
|
DGCI−... |
Linear drive with permanently integrated position measuring |
|
|
system. |
|
|
(digital, absolute) |
|
DGP(L)−... with |
Linear drive with external position measuring system |
|
MLO−POT−...−TLF |
(potentiometer, absolute) |
|
DNCI−... |
Standard cylinder with integrated position measuring system |
|
|
(encoder, incremental) |
|
DNC−... with |
Standard cylinder with external position measuring system |
|
MLO−POT−...−LWG |
(potentiometer, absolute) |
|
DNCM−... |
Standard cylinder with external position measuring system |
|
|
(potentiometer, absolute) |
|
DSMI−... |
Semi−rotary drive with integrated position measuring system |
|
||
|
|
(potentiometer, absolute) |
|
|
1) Support for other drives in preparation
Tab. 0/2: Overview of positioning system modules and components
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
XV |
Contents and general safety instructions
Manual for CMAX axis controller
Type |
Title |
Contents |
|
|
|
Electronics de |
•CMAX axis controller |
Mounting, installation, commissioning and diagnosis |
scription |
system description" |
of the CMAX axis controller |
|
P.BE−CPX−CMAX−SYS−... |
|
|
|
|
Communica |
•CMAX communication |
Activation, programming and diagnosis of a CMAX |
tion profile de |
profile" |
with the used CPX node |
scription |
P.BE−CPX−CMAX−CONTROL−... |
|
|
|
|
Online help |
Help for the Festo configur |
Configuration and commissioning of the CMAX axis |
|
ation tool with CMAX plug−in |
controller with the FCT |
|
|
èwww.festo.com ˛ Downloads ˛ Download |
|
|
Area: Software, drivers and firmware ˛ Enter |
|
|
search term: CMAX |
|
|
|
Operating in |
Operating instructions for the used components |
|
structions |
|
|
|
|
|
Tab. 0/3: Documentation for the positioning system with CMAX
XVI |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
Contents and general safety instructions
|
|
|
The following product−specific terms and abbreviations are |
|
|
|
|
used in this description: |
|
|
Term/abbreviation |
|
Meaning |
|
|
|
|
||
|
|
|
|
|
|
0xA0 (A0h) |
|
Hexadecimal numbers are marked by a prefixed •0x" or by a subscript |
|
|
|
|
•h.". |
|
|
|
|
|
|
|
Absolute position |
|
A position measuring system with fixed (absolute) assignment of |
|
|
measuring system |
|
the measured value (position, angle, etc.) and measured variable, |
|
|
|
|
for •digital" or •potentiometer" CMAX. |
|
|
|
|
|
|
|
Adaptation |
|
CMAX function to improve non−optimal switch−on behaviour automati |
|
|
|
|
cally during operation |
|
|
|
|
|
|
|
Axis string |
|
Totality of all modules and cables which are connected via the axis inter |
|
|
|
|
face to the CMAX |
|
|
|
|
|
|
|
Bus node |
|
Establish the connection to specific fieldbuses. Transmit control signals |
|
|
|
|
to the connected modules and monitor their operation (as CPX module: |
|
|
|
|
CPX bus node). |
|
|
|
|
|
|
|
Control interface |
|
Connection for all modules and cables in the axis string. |
|
|
|
|
|
|
|
CPX modules |
|
Collective term for the various modules which can be integrated in a CPX |
|
|
|
|
terminal. |
|
|
|
|
|
|
|
CPX node |
|
Collective term for all CPX bus nodes or the CPX−FEC |
|
|
|
|
|
|
|
CPX terminal |
|
Complete system consisting of CPX modules with or without pneumatics. |
|
|
|
|
|
|
|
Drive |
|
In this description, the term •drive" represents linear drives (DGCI, DGP), |
|
|
|
|
standard cylinders, positioning drives (DNC, DNCI, DNCM) or swivel |
|
|
|
|
modules (DSMI). |
|
|
|
|
|
|
|
Festo Configuration Tool |
|
Software with standardised project and data management for supported |
|
|
(FCT) |
|
device types. The special requirements of a device type are supported |
|
|
|
|
with the necessary descriptions and dialogues by means of plug−ins. |
|
|
|
|
|
|
|
Festo Handling and Posi |
|
Fieldbus data profile for Festo position controllers |
|
|
tioning Profile (FHPP) |
|
|
|
|
|
|
|
|
|
Festo Parameter |
|
FHPP−specific parameter access |
|
|
Channel (FPC) |
|
|
|
|
|
|
|
|
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
XVII |
Contents and general safety instructions
Term/abbreviation |
Meaning |
|
|
Functions |
Special functions in the different operating modes. e.g.: |
|
Jog mode |
|
Homing |
|
|
Homing |
By means of homing, the reference position and thereby the origin of the |
|
dimension reference system of the axis are defined. |
|
|
I |
Digital input. |
|
From the point of view of the master controller, the CMAX status outputs |
|
are module input data. See section 4.5. |
|
|
I/Os |
Digital inputs and outputs. |
|
|
Identification |
System function where specific characteristics of the connected axis are |
|
determined by means of an identification run, e.g. break−away forces, |
|
frictional behaviour, dynamics (maximum accelerations and speeds), etc. |
|
|
Incremental position |
A position measuring system in which the measured variable refers to a |
measuring system |
reference point and is determined by counting equally large measure |
|
ment steps (increments) with the CMAX •encoder". |
|
|
Jog mode |
Manual travel in positive or negative direction. |
|
Function for setting positions by approaching the target position, |
|
e. g. by teaching records. |
|
|
Logic 0 |
Input or output provides 0 V (also LOW, FALSE or logical 0). |
|
|
Logic 1 |
Input or output provides 24 V (also HIGH, TRUE or logical 1). |
|
|
O |
Digital output |
|
From the point of view of the master controller, the CMAX control inputs |
|
are module output data. See section 4.5. |
|
|
OB |
Output byte |
|
|
Operating mode |
Type of CMAX control, function or setpoint specification |
|
|
Parameter |
Various settings which must be defined for system operation and be |
|
saved in CMAX. |
|
|
PLC/IPC |
Programmable logic controller; for short: Controller |
|
(also IPC: industrial PC). |
|
|
PNU |
Parameter number each parameter has a number and subindex. |
|
|
Position control |
Control mode where a defined position is approached and held with |
|
control. |
|
|
XVIII |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
Contents and general safety instructions
Term/abbreviation |
Meaning |
|
|
Pressure/force control |
Control mode where a defined force is applied via pressure control. In the |
|
following, the term •force control" will be used. |
|
|
Project zero point (PZ) |
Dimension reference point for all positions in positioning tasks (project |
|
zero point). The project zero point forms the basis for all absolute posi |
|
tion specifications (e.g. in the position set table or in direct mode). The |
|
point of reference for the project zero point is the axis zero point. |
|
|
Record |
Positioning command defined in the position set table, consisting of |
|
target position, positioning mode, speed, acceleration, ... |
|
|
Reference point (REF) |
Point of reference for the incremental displacement encoder. |
|
The reference point defines a known position within the drive’s travel. |
|
|
Software end position |
Programmable stroke limit (point of reference = axis zero point) |
|
Upper software end position |
|
Max. limit position in the positive direction (increasing actual values). |
|
Lower software end position |
|
Min. limit position in negative direction (decreasing actual values). |
|
|
Tab. 0/4: Terms and abbreviations
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
XIX |
Contents and general safety instructions
XX |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
Chapter 1
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
1−1 |
1. CMAX system overview
1. |
CMAX system overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1−1 |
|
1.1 |
CMAX axis controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1−3 |
|
|
1.1.1 |
Connection and display components of the CMAX . . . . . . . . . . . . . |
1−3 |
|
1.1.2 |
CMAX function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1−4 |
|
1.1.3 |
CMAX in the CPX terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1−5 |
1.2 |
Structure of a positioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1−6 |
|
1.3 |
Parameterisation and commissioning options . . . . . . . . . . . . . . . . . . . . . . . . |
1−7 |
|
|
1.3.1 |
Festo Configuration Tool (FCT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1−7 |
|
1.3.2 |
FHPP communication profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1−8 |
1−2 |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
1. CMAX system overview
The following connection and display components can be found on the CMAX:
1 |
Status LED |
|
|
5 |
|
||
|
|||
|
See section 5.3 |
|
|
|
|
|
|
2 |
X: Axis interface |
|
|
4 |
|
||
|
(connection for |
|
VPWP)
3Inscription labels (accessories)
43−character display See section 5.4
5 Name plate |
3 |
(on side surface) |
|
1
Dx X
Dy Y
2
Fig. 1/1: Connection and display components of the CMAX
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
1−3 |
1. CMAX system overview
|
The CMAX axis controller, together with a VPWP proportional |
|
directional control valve and a drive with a position measur |
|
ing system, forms a positioning system for pneumatic axes |
|
(see section 1.2). |
|
The positioning system permits: |
|
Travel at selectable speed in any positions (position con |
|
trol) |
|
The approach of a position and applying a defined force |
|
(force control). |
|
Mode of operation |
CMAX functions |
The CMAX takes over the following functions: |
|
Parameter storage (hardware configuration, records, con |
|
troller settings, etc.) |
|
It ascertains system characteristic values of the con |
|
nected components (identification). |
|
Specifies setpoint values (position or force) |
|
Tracks setpoint and actual values (position or force con |
|
trol) by appropriately activating the proportional direc |
|
tional control valve. |
Mode of operation |
The CMAX, valve, drive and displacement encoder are |
|
connected to form a closed−loop control circuit. |
1−4 |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
1. CMAX system overview
The CMAX is integrated in a CPX terminal as a CPX module and is controlled by the CPX node via the internal bus using 8 bytes of module output and 8 bytes module input data. See section 4.5.
Information about the control and parameterisation of the CMAX via the CPX node can be found in the •CMAX communi cation profile" description, P.BE−CPX−CMAX−CONTROL−... .
The descriptions are also available as PDF files: èwww.festo.com ˛ Downloads ˛ Manual
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
1−5 |
1. CMAX system overview
1CPX terminal with CMAX
2VPWP proportional directional control valve
3A sensor interface with displacement encoder cable (optional, depending on the displacement encoder used)
4Drive with position measuring system (in this example a DNCI)
5 Pneumatic tubing
6 Axis string
A positioning system typically consists of the following com ponents (see Fig. 1/2):
1 |
|
|
2 |
|
|
|
|
3 |
|
|
|
4 |
|||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
6 |
5 |
Fig. 1/2: Structure of positioning system
Specific information on the structure is provided in chapters 2 and 3.
1−6 |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
1. CMAX system overview
Tab. 1/1 provides an overview of the commissioning, parameterising and teaching options.
Operated via |
Properties |
For details, see |
|
|
|
|
|
FCT CMAX plug−in |
Easy commissioning thanks to special dialogues |
Chapter 4, |
|
|
|
and functions. |
help for FCT CMAX |
|
Direct •on−site" operation with drive monitoring |
plug−in |
|
|
|
is possible |
|
|
PC must be connected on site with the diagnostic |
|
|
|
|
interface of the CPX terminal. |
|
|
|
|
|
Master controller, |
|
Parameterisation of several positioning |
•CMAX communication |
CPX node |
|
systems is possible. |
profile" description, |
(CPX bus node or |
Commissioning and teaching require additional |
P.BE−CPX−CMAX−CON |
|
CPX−FEC) |
|
measures for the necessary drive monitoring. |
TROL−... |
|
|
Additional programming required. |
|
|
|
|
|
Tab. 1/1: Commissioning, parameterising and teaching options
The Festo Configuration Tool (abbreviated as FCT) is the soft ware platform for configuring and commissioning various Festo components and devices.
The CMAX plug−in for the FCT helps to carry out all the steps necessary for commissioning a CMAX.
An overview for commissioning with the FCT can be found in chapter 4.
The help for the FCT contains the complete information on operating the Festo Configuration Tool. The device−specific plug−ins each have their own help files.
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
1−7 |
1. CMAX system overview
Festo has developed an optimised data profile, the •Festo Handling and Positioning Profile (FHPP)", tailored to handling and positioning functions.
The FHPP allows the various Festo fieldbus systems and con trollers to be uniformly controlled and programmed.
It also uniformly defines the following for the user:
Operating modes
I/O data structure
Parameters
Sequence control.
Basic information can be found in section 4.5.
More detailed information about FHPP can be found in the •CMAX communication profile" description.
1−8 |
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH |
