Ferguson satellite receivers support recording on external hard disk drives (HDDs) and
flash memories (pendrives). In all instances, the correct operation of the recording
function depends on the type of connected memory! You must read the following
limitations.
REMEMBER:
1. In order to use an external USB memory, the memory must support the USB
2.0 standard. To ensure stable recording and playback, you must use amemory with a recording speed of 9.0 MB/s or greater. Slower hard disk
drives and flash memories may not function properly, have problems with
recording (image jitter), or not function at all!!!
2. Only disks with one basic NTFS or FAT32 partition (we recommend using the
NTFS format) will function properly. If you do not have such a format, prepare
the disk on your computer before connecting it to the receiver.
3. Highly fragmented or used memories may also not operate smoothly or
correctly.
4. External hard disk drives should be autonomously powered, since the built-in
USB port is unable to provide sufficient power.
CAUSION
1. Under no circumstances should you disconnect the USB device from the receiver during
recording or playback. Disconnecting during operation may cause damage to the receiver and/or
flash memory, and to the recorded data.
2. Do not touch the working device (and in particular the USB connector) with wet hands. Risk
of electric shock and permanent damage to the receiver!
We request that you read the instruction manual and recommendations set forward therein.
Also remember to correctly position the satellite antenna!
In order to avoid an electric shock, never open the housing. Damage to the
warranty seal shall void the warranty.
Disconnect the device from the mains during thunderstorms or when it is not to
be used for an extended period of time. Please remember that the warranty does
not cover damage to the equipment caused by a lightning strike.
Do not expose the device to direct sunlight. Place it away from sources of heat
and humidity. Do not cover ventilation ducts, in order to ensure the correct
circulation of air.
Place the device horizontally on a flat, even and stable surface.
If you move the device from a room that is warm to one that is cold (or vice
versa), wait at min. 1 hour before connecting it to the mains. Otherwise,
problems may arise.
The device should be placed away from vases, bottles, aquariums and other water
containers in order to avoid damage. Do not touch the mains plug with your bare
hands.
Do not place any objects on the housing of the device. This may cause
overheating and reception problems.
Before commencing maintenance or installation work, disconnect the receiver from the mains.
Do not clean the receiver with alcohol or liquids containing ammonia. If necessary, clean it with
a soft, lint-free cloth wetted with a gentle solution of water and soap.
•Do not connect any cables when the mains plug is in the socket.
•Check the condition of your cables. Damaged cables may cause a fire.
•Please disconnect the receiver from the mains before connecting any cables.
DOWNLOADABLE SOFTWARE
Ferguson has taken every effort to provide users with software updates in order to ensure that
the parameters of the satellite television receiver are up to date. Ferguson reserves itself the
right to amend, change or modify the software used in the satellite television receiver as it shall
choose and without prior notification. The latest version of the software is available on the
website
http://www.ferguson-digital.eu
5
ABOUT THE INSTRUCTION MANUAL
Ferguson has made every effort to provide the most current information about its products.
Ferguson does not grant any guarantee as to the contents of the present instruction manual and
disclaims any implied guarantees concerning market value or suitability for specific purposes.
The information contained herein is an instruction intended to enable the correct usage and
maintenance of the receiver.
Ferguson reserves itself the right to introduce amendments, changes or translations of the
instruction manual without prior notification thereof. For this reason, we recommend you
regularly visit our website in order to obtain the latest information.
MARKINGS AND SIGNS APPLIED TO THE RECEIVER
Digital signal transmission logo.
This logo informs that the receiver conforms to the Digital Video Broadcasting
standards.
Risk of electric shock - do not open.
This notice warns the user not to open the receiver housing. The housing may be
opened solely by authorised service technicians.
CE logo.
The logo informs that the receiver conforms to the terms and conditions of
Directive 89/336/EEC concerning observance by Member States of provisions
regulating electromagnetic compatibility, and to the terms and conditions of
Directives 73/23/EEC and 93/68/EEC concerning observance by Member States of
provisions regulating low voltage electricity and safety with relation to the
handling and operation of electrical equipment.
Double insulation logo.
This logo informs that the receiver is an electrically safe device, provided that it is
used in accordance with the recommendations set forward in the chapter
concerning safety.
Take an active part in protecting the natural environment!
•Your device is made from materials that can be processed or recycled.
•To this end, you should deliver it to a designated collection point.
6
BASIC INFORMATION ABOUT THE RECEIVER
1. Main features
✔Receives cable TV channels in High Definition
✔PAL upscaling up to 720p & 1080i resolution
✔Dolby Digital surround audio pass - through (HDMI, optic)
✔Card reader, CONAX CAS5/7 embedded
✔Software upgrade via USB port
✔Supports timers
✔Favorite channel groups, TV and radio
✔Electronic Program Guide (EPG)
✔Supports Teletext and Subtitles
✔User friendly, Multilanguage menu
✔Simple Installation wizard
✔NIT- Search
✔Logical Channel Numbers Support
✔OTA (DVB- System Software Updates)
✔Modern design and small dimensions
✔MPEG-2, MPEG-4, MPEG-4 AVC/H.264 support
✔Software upgrade via Internet
2. Contents of box
Unpack the receiver and check whether all of the following elements are present
✔1 x remote control unit
✔1 x instruction manual
✔1 x cable television receiver
3. Important instructions concerning handling of the receiver
The screen menu (OSD) simplifies operation of the receiver and has made it possible to reduce
the number of keys on the remote control. All of the functions are displayed on the screen and
may be controlled by means of a small number of keys. Common functions have been
connected in one "MENU". The selected function is coloured. Depending on the selected option,
various "function keys" are displayed: red, yellow, green, blue and white in the form of graphics
and descriptions. The colours represent various functions in individual "Menus". The selected
function is activated by pressing a key on the remote control unit. The so-called function keys
are active only when in the appropriate field there is information about it. The user interface
makes it possible to navigate within a menu and between functions in a number of different
ways. Certain buttons on the remote control allow direct access to functions. The buttons are
multi-functional, i.e. their functions depend on previously activated elements.
NOTE:
7
Please keep in mind that new software may change the functionality of the receiver.
Photographs and descriptions included in the instruction manual are for informational
purposes only. If you should notice an error, please report it - we shall make every
effort to have it rectified.4. Remote control
Due to the standardization of Ferguson equipment, the majority of these devices use the same
remote control unit, i.e. RCU-500. This means that not all keys are used by this equipment
model!!
POWERTurns the receiver on and sets it in standby mode.
MUTESwitches the sound on and off.
BACKReturns to the previously displayed channel.
EPGDisplays the electronic programme guide.
MENU Displays the main menu on-screen.
OPTUsed to switch between the resolution selected in the menu and the default
USB/PVRDisplays the USB menu, if a USB memory device has been connected.
FAVDisplays a selection of favorite channel lists.
VOL+ VOL–Used to change the volume level (lower, higher).
CH+ CH– Switches to the next or previous channel.
INFODisplays information about the current programme.
EXITReturns to the previous submenu, or exits the menu.
TEXTSwitches on the teletext on-screen, if this is available.
AUDIOSwitching between soundtrack versions, if these are available.
SUBTITLESwitches the on-screen captions on and off, if these are available.
FINDA quick search for channels according to successive name letters.
EDITNot used.
TV/STBUsed for controlling the SCART bush. Cyclic selection of signal sources.
FORMATChanges the image resolution. The following resolutions are available: 480i, 480p,
REV, PLAY,
PAUSE, FF,
STOP, REC
resolution of 576i. Allows the user to restore proper functioning of the receiver
following the selection of a resolution not supported by the television.
Buttons used to operate the recording, playback and time shift mode functions.
SATNo function attached to this button
TV/RADIOSwitching between the list of television and radio programmes.
8
4.1 Installation of batteries
Remove the cover of the battery compartment on the rear panel of the remote control unit;
slide it downwards and put it aside. Insert two AAA (R03) batteries into the compartment,
observing the indicated polarity. Do not mix old and new batteries, or batteries of
different types. Replace the battery compartment cover. Slide it upwards until it locks in place.
5. Front panel
POWER:Turns the receiver on and sets it in standby mode.
:Switches to the next/previous channel, moves the cursor up/down in the Menu.
:Used to select the desired volume level (lower, higher) and move the cursor
left/right in the Menu.
OK:Selects options in the Menu or displays the channel list.
MENU:Displays the main Menu on-screen.
EXIT:Switching off; exits the selected option.
USB:Port for connecting an external USB memory device.
CA:Socket for a subscriber's card – always insert with the chip facing down!
9
6. Rear panel
LOOP OUT:Output of the signal from the converter to another satellite receiver.
CABLE IN: Input of the concentric cable
HDMI:Digital image and sound output.
LAN:The Ethernet port used for communication over the LAN
network/Internet.
AUDIO (L/R):Analogue stereo audio output, 2 x RCA.
COAXIAL: Digital coaxial audio output.
COMPONENT (YpbPr):Component video output 3 x RCA (YpbPr).
OPTICAL:Digital optical audio output.
TV:SCART output, for connection to a television.
RS232:RS232 port for communication with a PC computer.
ON/OFF:Power on/off switch.
7. Connecting the cable receiver
The following illustrations show cable connections for a television and other devices connected
with the receiver. If you require any assistance in connecting individual devices, contact your
local technician. Before connecting or altering cabling, disconnect the receiver from the
mains !!!
7.1 Connection by means of an HDMI cable (recommended)
1. Connect the antenna to the Cable IN socket of the receiver.
2. Connect the HDMI to the receiver out and the television in.
Connection by means of an HDMI cable allows you to obtain the highest image quality.
10
If you have an amplifier with an HDMI out and in, which supports sound sent over HDMI,
connect the devices by two HDMI cables. As in the following figure: one cable to theamplifier,
and the other from the amplifier to the television set.
7.2 Connection by means of the YPrPb (component) sockets
1. Connect the antenna to the Cable IN socket of the receiver.
2.Connect the video and audio by means of five cinch cables to the television set.
Three cables, coloured green, blue and red, are used to send the three colour
components. The two remaining cable, red and white, are used to connect sound (right
and left channel).
7.3 Connection by means of SCART cables
1. Connect the antenna to the Cable IN socket of the receiver.
2.Connect the television to the port in accordance with the description. We recommend
using shielded SCART cables.
11
7.4 Connection of an audio system
1. Digital sound (including surround sound, if broadcast) may be obtained through two
sockets: electrical (SPDIF) or optical (OPTICAL). The following figure presents the SPDIF
connection.
2.Stereo sound may be obtained by connecting cinch cables (white and red) for the left and
right channels
7.5 Connection of an external memory
1. The receiver supports all types of hard disk drives in housings that are equipped with an
independent power supply. The sole condition is that the hard disk has to have a single
basic partition that is formatted in the NTSF (recommended) or FAT32 system.
2.We recommend that you regularly archive data on your PC computer. A large number of
files with recordings may slow down cooperation with the receiver (slow loading of the file
list).
3.Connect the memory through the USB port located on the front panel under a tab.
12
Loading...
+ 26 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
