EVS XTnano User Manual Version 11.02

OperatiOn Manual

Version 11.02 - July 2013



OPERATION MANUAL Nano 11.02

Copyright

EVS Broadcast Equipment S.A.– Copyright © 2010-2013. All rights reserved.

Disclaimer

The information in this manual is furnished for informational use only and subject to
change without notice. While every effort has been madeto ensurethat the information
contained in this usermanual is accurate, up-to-date andreliable, EVS Broadcast
Equipment cannot be held responsible for inaccuracies orerrors that may appear in this
publication.

Improvement Requests

Yourcomments will help us improve the quality of the user documentation. Do not
hesitate to send improvement requests, or report any erroror inaccuracy on this user
manual by e-mail to [e-mail].

Regional Contacts

The address and phone number of the EVS headquarters are usually mentioned in the
Help > About menu in the user interface.

You will find the full list of addresses andphonenumbers of local offices either at the end
of this usermanual (formanuals on hardwareproducts) or at the following pageon the
EVS website: http://www.evs.com/contacts.

User Manuals on EVS Website

The latest versionof the user manual, if any, and other user manuals on EVS products
can be found on the EVS downloadcenter, on the following webpage:

http://www.evs.com/downloadcenter.

I

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Table of Contents

TABLE OF CONTENTS II

WHAT'S NEW? V

1. OVERVIEW 1

2. WORKING INTERFACES 2

2.1. Overview 2

2.2. Remote Panel Controls 4

2.2.1. General Layout 4

2.2.2. LED Colors 6

2.2.3. Function Keys & Small Keys 7

2.2.4. Soft Keys andLCD Display 8

2.2.5. Jog Dial 9

2.2.6. Lever 9

2.2.7. Keyboard Locking 10

2.3. Remote Panel Operations 11

2.3.1. Main Menu 11

2.3.2. Function of the Small Keys 12

2.3.3. Function of the Operational Block 1 Keys 13

2.3.4. Function of the Operational Block 2 Keys 16

2.3.5. Rebooting the System from the Remote Panel 19

3. CONTROL MODES 20

3.1. Live, Search or Playback Mode 20

3.2. 1PGM+PRV Mode 21

3.2.1. 1PGM+PRV Mode 21

3.2.2. 1PGM+PRV Primary Menu Controls 22

3.2.3. 1PGM+PRV Secondary Menu Controls 23

3.2.4. Full Control and Lever Control 24

3.3. Multi PGM Mode 25

3.3.1. Multi PGM Overview 25

3.3.2. Multi PGM Primary Menu Controls 26

3.3.3. Multi PGM Secondary Menu Controls 28

3.4. Synchronization Mode (Switch To In) 29

3.5. Preference Mode (PREF) 29

3.6. Controlled and Primary Channels 30

II Table of Contents

OPERATION MANUAL Nano 11.02

4. CLIP MANAGEMENT 31

4.1. Introduction 31

4.1.1. Clip Structure 31

4.1.2. Clip Numbering Hierarchy 32

4.1.3. Clip Availability on Disks 34

4.2. Clip Functions onthe Remote Panel 34

4.2.1. Remote Panel Interface 34

4.2.2. Remote Panel Functions 35

4.3. Clip Functions onthe VGA 37

4.3.1. VGA Interface - Clip Screen 37

4.3.2. VGA Functions - Clip Screen 39

4.3.3. VGA Interface - VDR Panel 42

4.3.4. VGA Functions - VDR Panel 43

4.4. Operations onClips 45

4.4.1. Creating and Saving Clips 45

4.4.2. Recalling and Playing Back Clips 47

4.4.3. Deleting Clips 51

4.4.4. Copying andMoving Clips 53

4.4.5. Naming a Clip 55

4.4.6. Restriping Clips 55

4.4.7. Shortening a Clip 57

4.4.8. Changing the Primary Camera of a Clip 58

5. PLAYLIST MANAGEMENT 59

5.1. Introduction 59

5.2. Selecting Playlists 60

5.3. Playlist Functions on the Remote Panel 61

5.3.1. Edit and Playout Modes 61

5.3.2. Functions in Playlist Edit Mode 62

5.3.3. Functions in Playlist Playout Mode 64

5.4. Playlist Functions on the VGA 65

5.4.1. VGA Playlist Screen 65

5.4.2. VGA Playlist Bank Screen 66

5.4.3. Editing Functions in VGA Playlist Screen 66

5.5. Operations onPlaylists 67

5.5.1. Setting and LoadingPlaylists 67

5.5.2. Rolling a Playlist 69

5.5.3. Deleting Playlists 70

5.5.4. Copying Playlists 71

5.5.5. Naming a Playlist or Playlist Element 74

5.5.6. Consolidating a Playlist 75

5.5.7. Generating a Continuous TC in a Playlist 76

5.6. Operations onClips in Playlists 77

5.6.1. Adding Clips in a Playlist 77

Table of Contents III

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

5.6.2. Deleting andMoving Playlist Elements 79

5.6.3. Browsing Within a Playlist 80

5.6.4. Changing the Camera Angle of a Playlist Element 81

5.6.5. Adding Cuts in Playlist Elements 82

5.6.6. Trimming Clips into a Playlist 83

5.6.7. Sortingthe Playlist Elements by TC IN 83

5.7. Transition and Audio Operations 84

5.7.1. Overview on Transition Effects 84

5.7.2. Adding Transition Effects in a Playlist 87

5.7.3. Using the Replace Function 89

5.7.4. Adding an Auxiliary Audio Clip 92

IV Table of Contents

OPERATION MANUAL Nano 11.02

What's New?

This manual has not beensubject to changes associated to new features in release 11.02.
The whole operational manual has been restructured, and some topics have been

reviewed in respect of their structure or content. Such changes arehowever not related to
new features, and thereforenot highlighted with the New logo.

What's New? V

OPERATION MANUAL Nano 11.02

1. Overview

The aim of this manual is to familiarize the operatorwith the Multicam software for EVS
High Definition andStandardDefinition servers, and its Remote Panel, so as to learn as
quickly and efficiently as possible the basic operations.

The CLIP & PLAYLIST MANAGEMENT functions allow the operator to keep up to 5400
clips on a server and of course to replay all or some of them. A playlist consists of a list of
clips (90playlists can be defined) with videoand audio transitions.

1. Overview 1

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

2. Working Interfaces

2.1. Overview

Several User Interfaces

The EVS server can be operated from several user interfaces that can work
complementarily:

• VGA interface

• Remote Panel interface

• LSM.Connect application

• Xscreen application

Initial Configuration

Warning

Beforeyou start using Multicam with the Nano Remote Panel, you need to
ensure that the parameters are properly set for the configuration line you want to
run.
If clips are stored with certainparameters and the operator wishes to change the
parameter values afterwards, those clips and playlists will not change. It is thus
important to set the requested parameters first.

The Multicam Setup and Configuration modules of the VGA interface are used for
configurationand maintenance operations. A web-based user interface for distant
configurationis also available. A Technical and Operational Setup menus are also
available from the Remote Panel to configure the most important Multicam parameters.

The Multicam Setup window is used to select the configuration you want to run Multicam
with, since EVS disk recorders have the ability to run various configurations.

The Multicam Configuration window and included tabs allow users to define the channel
configurationassociated to a configurationline, audio and video parameters, andall
operational parameters.

You will find detailed information on Multicam configuration from the VGA and from the
Remote Panels in the EVS Server Configurationmanuals.

2 2. Working Interfaces

OPERATION MANUAL Nano 11.02

VGA Interface

When turning on the EVS mainframe, the first step is the PC boot sequence, then the
Multicam Setup window is displayed:

• If a default application has beenpreviously selected, this application will start
automatically after a few seconds if no key is hit.

• If a default application hasn't been defined or if the space baris hit, the system will
remain in the Multicam Setupwindow andwait for the operator's next command.

A configuration line called Sportlight will be available in the Application window for use
with the Nano Remote Panel.

When Multicam is started in the selected configuration, the operational windows allow
users to perform simple actions.

The Operational windows include the Keywordwindow, the Search Clip window, the Clip
window, and the Playlist/Timeline window. They are described in this manual, as well as
the possible actions from these windows.

Remote Panel Interface

The Remote Panel keys and main menuare describedin the following sections:

• See section "Remote Panel Controls" on page 4

• See section "Remote Panel Operations" on page 11

LSM Connect Application

The LSM Connect application is the Remote Panel companion. It allows users to quickly
edit clip metadata, and manage playlists. See the LSM Connect quick start guide for more
information on this application.

2. Working Interfaces 3

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

2.2. Remote Panel Controls

2.2.1. General Layout

The following diagram shows the Remote Panel alongwith a brief description of each
area.

Note

The operational buttons have primary and secondary functions and are divided
into upper and lower sections. By pressing the SHIFT button, you gain access
to the secondary functions.

4 2. Working Interfaces

OPERATION MANUAL Nano 11.02

Ref. Command Function

1. F-keys & small

Multi-purpose keys

buttons

2. Soft keys With LCD display, allows the operator to enter the
Multicam MENU system

3. Lever Initiates slow motionand playlist replay

4. Jog dial Used to accurately cue disk recorder

5. Operational block 1

PLST Initiates active playlist

LOOP Records the main output (PGM1) to the first input (CAM

A) of Multicam.

BROWSE Used to browse through clips, playlists, cue points

INSERT Used in playlist management to insert clips into a playlist

IN Sets Mark IN at the current position

GOTOIN Goes to the defined Mark IN

OUT Sets Mark OUT at the current position

GOTOOUT Goes to the defined Mark OUT

TAKE In PGM+PRV mode, pressing this button swaps

cameras onPGM andPRV monitors
In Multi-PGM mode, pressing this button toggles
between CAM selection andPGM selection modes.
In 2 PGM mode, whenboth PGMs are selected on the
Remote Panel, pressing this button swaps the content
loaded on PGM1 with the oneloadedon PGM2and vice­versa.
In Playlist Edit mode, pressing this button inserts the clip
loaded on the PRV channel into current playlist.

LEVER Changes the lever range to secondary mode (see setup

menu for range selection)

2. Working Interfaces 5

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Ref. Command Function

6. Operational Block 2

PLAY Initiates playback

NETWORK Not used on XTnano

LAST CUE Re-cues EVS server to previous cue point

GOTOTC Allows timecode entry, with «F» keys

FAST JOG Used with jogdial for rapid, manual re-cue. This mode is

automatically reset after PLAY/LIVE commands.

MARK Used to enter re-usablecue points (256cycling cues).

RECORD Initiates “E2E” mode

RETURN Inside a clip, allows the operator to returnto the same

picture inside the recordtrain, if it still exists.

PRV CTL Enables/disables the Preview Control mode.

PAGE Selects current clip page, from 1 to 10.

7. LCD Display Provides current status of system

2.2.2. LED Colors

A selected key lights red.
When a key lights green, it means a valuein relation with this key exists.
For example: F1 to F0 keys:

• A greenlight means a clip has been stored in relation with the key.

• A greenflashinglight means a clip is being created.

• A red light means the clip associated to the key is playing or is ready to play.

6 2. Working Interfaces

OPERATION MANUAL Nano 11.02

2.2.3. Function Keys & Small Keys

Key Function

Provides access to the secondary menu. Also used as CANCEL in some
messages when confirmation is required.
Note: SHIFT+MENU returns to Main menu

Enables use of the secondary key functions.
Note: This key remains active even if released, until another key has
been hit.

Stores or recalls clips, recalls playlists, and enters timecode information.

Is a multi-purpose key that clears clips or playlists, and clears IN and
OUT points.

Appends clips at the end of the current playlist and validates other options
andmessages.

2. Working Interfaces 7

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

2.2.4. Soft Keys and LCD Display

The soft keys have primary and secondary functions andare divided into upper and lower
sections.

The LCD display is divided into two menus.

• To access the secondary functions in the operational menu (A’ to D’), press the
SHIFT button.

• To access the secondary menu, press MENU from the remote controller. This menu
is used to define settings that do not require regular changes, without havingto return
to the Setup menu.

• To return to the Operational menu, press the MENU key again.

• To return to the Main menu in Multicam, press SHIFT+MENU.

8 2. Working Interfaces

OPERATION MANUAL Nano 11.02

2.2.5. Jog Dial

The jog dial allows the operatorto pass into Search mode andthus to choose exactly the
Short OUT or Short IN image.

Move the jog dial clockwise to search forward and move it counter-clockwise to search
backwards. One revolution of the jog dial will produce a jump of approximately 35frames.
When using the Fast mode, this numberis multiplied by a factor defined in the Setup
menu.

Note

The jog dial is also used to:

• Set parameters in the Setup menu.

• Browse inside the clip database, the cue points or the current playlist. Refer
to the explanation of the Browse function for more details.

The jog dial is active at all times when the system is in Play andRecordmodes.

2.2.6. Lever

The lever is used to start a play or to modify the slow motion speed. Its run can be of two
different types depending on the lever mode. In standard mode, the lever run goes from 0
up to 100%.

Different ranges are availableto play material from –400% to 400% using the 'Second
lever range' parameter in the Operational Setup menu (p.9.1 F5).

To access this second speed range, press SHIFT+Lever on the remote controller.

Note

When SD SUPER MOTION material is loaded on the primary channel, the lever
range has a larger, flat step at 33%.
In HD SUPER MOTION mode, the step is at 33% or 50% depending on the
camera.

The lever is also used to adjust speed, effect type, and duration in Playlist Edit mode.

2. Working Interfaces 9

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

2.2.7. Keyboard Locking

You can lock a remote keyboard at any time to protect it against accidental changes, for
example to prevent interruption of a play operation on an unattended device. Only the
locked device is affected, other remotes will stay fully operational.

How to Lock a Remote Panel

To lock a remote, press the CLEAR key. Then, within 2 seconds, press the MENU key
on the keyboard.

The following confirmation message is displayed:

███████████████████████████████████████
Do you really want to lock this remote?

[Menu] : Cancel
[Enter]: Confirm

███████████████████████████████████████

Press ENTER to confirm the locking of the remote.When a remote is locked:

◦ The CLEAR and MENU keys, used for unlocking, are flashing green.
◦ All other keys are continuously lightingred.
◦ The jog brake is activated.
◦ All keys, the lever and the jog beep if pressed or operated, except the CLEAR and

MENU keys, used for unlocking.

In addition, the following message is displayed in the middle of the current screen:

Msg: Clear+Menu to unlock the remote

How to Unlock a Remote Panel

To unlock the remote, press again the CLEAR key then, within 2 seconds, the MENU
key. The remote goes back to its operating mode.

10 2. Working Interfaces

OPERATION MANUAL Nano 11.02

2.3. Remote Panel Operations

2.3.1. Main Menu

Introduction

After the boot sequence of the Multicam system, the LCD screen of the Remote Panel
will display the Main menu:

2Rec 2PlayServerVer:11.00.xx
F1: 1 RemoteF6: Exit
F2: 2 RemotesF7: Clear all clips
F3: F8: Stop Record
F4: F9: Fill Playlist
F5: Char. On/OffF0: Technical setup

Setup

1PGM+PRV 2 PGM

The Main menuhas special function key operations as shown above, as well as the “soft”
keys options to enter 1PGM, 1PGM+PRV, or 2PGM modes (if available) and to enter the
Setup menuto configure your remote controller or to add special functions to your
application.

Note
If 2 channels are available for the first Remote Panel, the B key will display 2
PGM.

Returning to the Main Menu

From any section of the application, except Playlist mode, press SHIFT+MENU on the
first Remote Control panel to return to the main menu.

Function Keys in the Main Menu

Select the correspondingFunction key (F_ key), and then press ENTER to validate the
selection.

Function Key Use

F1 to F4 If desired, the Multicam system can be run using 1 or 2 EVS

Remote Panels. Depending on the number of play channels
available in the current configuration, 1- or 2-Remote modes will
be available from the main menu.

F1: 1 Remote One Remote Panel is used in the configuration

F2: 2 Remotes Two Remote Panels areused in the configuration.

2. Working Interfaces 11

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Function Key Use

F3 Not used.

F4 Not used.

F5: Char. On/Off Enables or disables the on-screen display (Timecode, Clip ID…)

on the output monitors.

F6: Exit Exits the Multicam software and returns to the EVS Menu.

F7: Clear all clips Clears all clips. All clips will be lost. A confirmation of this

command is required.
For more informationto this action. "Deleting Clips" on page 51.
Note: This command is not similar to the Clear Video Disks from
the Maintenance menu. If you wish to refresh completely the
server, i.e. to clearall clips including the protected ones, you
need to use Clear Video Disks rather than Clearall clips.

F8: Stop Record Stops the record. The REC key will go off andthe F8 function

key is now used to restart the record.

F9: Fill Playlist «Dump» feature which allows all clips to be «dumped»at the end

of the current playlist. This allows the operator to save all
material to tape, as a backup feature after a show is complete.
You can select in the Setup menu which camera angles have to
be included in the Fill Playlist function.
Make sure that the playlist you have selected is an empty one.
This function will appendthe clips at the end of an existing
playlist.

F0: Technical
setup

Warning

In orderto guarantee the validity of data and clips previously saved, it is advised
to properly exit the application by pressing ALT+Q and ENTER from the
keyboard, or F6 and then ENTER from the Remote Panel. Do not turnoff the
system while the application is running.

Gives access to the technical setup menu.

2.3.2. Function of the Small Keys

MENU

This function allows the operator to gain access to the secondary menu.
SHIFT+MENU on the Remote gains access to the main menu.
Also usedas an ESCAPE key to cancel some options and messages.

12 2. Working Interfaces

OPERATION MANUAL Nano 11.02

CLEAR

This function clears the IN / OUT/ playlist / CLIPS / CUE points.

Note

• To clear one CUE point, recall the desired cue point and press
CLEAR+MARK key.

• To clear all cues: whencurrent picture is not a CUE point, press
CLEAR+MARK key. A messageappears to confirm the command.

ENTER

This function appends clip(s) at the endof the current playlist. This is also used to confirm
saving of clips, and validate various options and messages.

2.3.3. Function of the Operational Block 1 Keys

Loop

It enables the internal Loop mode. The button will flash red in this mode and “LOOP” will
appear on the OSD of the output monitors. When the user selects the Loop mode, the loop
has to be cabledfrom the HD/SD “clean” output of PGM1 to the Loop In connector.

The loopis performed on the audio andvideo components of the PGM1 output, or on the
video only, depending on the Internal Loop parameter of the Operational Setup menu,
(p.9.2 F6). In audio embedded, the audiois also looped, whatever the value defined for the
Internal Loop parameter.

To leave the loop mode, you need to press SHIFT+LOOP again.

Note

By default, users have to connect the clean SDI output to the Loop In connector
given that the OSD of the output monitors are not disabled. If users want to use
the output monitor with characters out, they have to start the Multicam
application with the followingparameter : /LOOP_SDI_MON.

This is very useful to “consolidate” effects and edits, or adding live sound or music or
voice to previously recordedmaterial when only the video is looped back into the server.

Note

When playing back at 200% in loop mode, then replaying the looped sequence
at 50%, you can obtain a “film effect”.

2. Working Interfaces 13

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

PLST

This function is not active if the current playlist is empty. If the current playlist is not
empty, pressing PLST once enters the Playlist Edit mode.

• Pressing PLST from the Playlist Edit mode enters the Playlist Playout mode.

• Pressing PLST from the Playlist Playout mode re-cues the playlist to its beginning.

• Pressing 3 times PLST will always cue up the playlist ready to roll.
To play back a playlist that has been cued, press the PLAY button and it will roll at the

preset speeds.

Insert

This function inserts a clip before or after (dependingon the Setup menu) the current
position inside the playlist.

Browse

When a clip is loaded on the primary channel, pressing the BROWSE key allows the
operator to browse inside all local clips of the database by turningthe jog dial.

When a cue point exists for the current picture on the primary channel (theCUE button
lights red), pressing the BROWSE key allows the operator to browse through all existing
cue points by turning the jog dial.

When the current picture on the primary channel is neither a clip nor a cue point, or if the
operator is in Playlist mode, pressing the BROWSE key allows him to browse inside the
clips of the current playlist by turning the jog dial.

Goto IN

When you are in CLIP mode, this key combination enables the operatorto go to IN / OUT
points of clips, instantly.

IN

This function defines the IN point of a clip. The key will light differently dependingon the
following situations:

• Green key The key lights green if an IN point exists but is not the image you see.

• Red key The key lights red if the on-air image is at this IN point. This point can be
entered while recording.

• Duringa Replace operation on a playlist, this key will flash red if trying to insert an IN
marker on a transition, as this is not allowed.

• Duringan Extend operationon a timeline, this key will flash reduntil you jog. At that
time, it will flash green until the operationis confirmed using the CAM D key.

14 2. Working Interfaces

OPERATION MANUAL Nano 11.02

Goto OUT

When you are in CLIP mode, this key combination enables the operatorto go to IN / OUT
points of clips, instantly.

OUT

This function defines the OUT point of a clip. This operates similarly to the IN button.

Modification of Clip IN / OUT Points

Select the clip that you wish to modify, use the jog dial to position the material at the new
IN or OUT point, andre-mark the IN or OUT point(s) as required.

Warning

When IN/OUT points are set and a clip is saved, the system automatically
write-protects a user definable length of material before andafter the IN/OUT
points respectively. These are referredto as the guardbands. Their duration can
be set with the Default clip duration parameter in the Operational Setupmenu
(p.2.2 F2) as required.

Lever

This function is used to perform slow motionfrom 0 to 100% and to playback material from
100to + 100% or from 200 to + 200% when Secondary Lever range is selected. The lever
has a continuous, linearrange, except when Super Motion material is loaded on the
primary channel. In this case, there is a “flat step”at 33% (SD SuperMotion) or 50% (HD
Super Motion) to help the operator locating easily the ideal playback speed.

Warning

When playing Super Motion material in slow motion, to obtain the smoothest
replay, it is important that the replay speed is exactly the ideal slow motion
speed, i.e. 33% for SD Super Motion or 50% for HD Super Motion. If the replay
speed is slightly off these ideal values, movements might appearstaggered.
These ideal speeds can also be called directly by pressing the PLAY button
when the current element is SuperMotion. ThePGM speed andVar Max modes
can also beused to facilitate this. See Chapter6 ‘PGM-PRV Mode’ on page26
for a description on these modes.

2. Working Interfaces 15

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

TAKE

• In PGM+PRV mode, pressing this button swaps cameras onPGM andPRV monitors

• In Multi-PGM mode, pressing this button toggles between CAM selection and PGM
selection modes.

• In 2 PGM mode, whenboth PGMs are selected on the Remote Panel, pressing this
button swaps the content loaded on PGM1 with the one loaded on PGM2 and vice­versa.

• In Playlist Edit mode, pressing this button inserts the clip loaded on the PRV channel
into current playlist.

2.3.4. Function of the Operational Block 2 Keys

Network

This function is not accessible on the XTnano.

PLAY

This function initiates a forward motion. It can also be usedto start playback of playlists
andclips (refer to PLST command).

When PgmSpd/Var Max is OFF, the default playback speed whenpressing the PLAY key
is 100% for standard pictures, 33% for Super Motion pictures with a TripleSpeed camera
(SD), and 50% for SuperMotion pictures with a Double Speed camera (HD),.

When PgmSpd/Var Max is ON, the value defined in the Operational Setup menu for the
PGM Speed/Var max parameter (p.9.1 F3) is used.

16 2. Working Interfaces

OPERATION MANUAL Nano 11.02

Goto TC

This function allows you to jumpto a given timecode in the loaded train or clip.

How to Go to a Given Timecode

To go to a given timecode, proceed as follows:

1. Press SHIFT+GOTO TC key on the Remote.
The GOTO TC window is displayed on the Remote Panel :

Go to TC xx:xx:xx:xx

Reset FromDate To Date
Return LTC

[Menu] : Cancel

[Enter] : Go to TC

2. To specify a date from which the search should be executed, press SHIFT+C, enter
the date in the format dd/mm/yy, using the F1 to F10 keys, and press ENTER on the
Remote.

3. To specify a date up to which the search shouldbe executed, press SHIFT+D and
enter the date in the format dd/mm/yy using the F1 to F10 keys and press ENTER on
the Remote.

4. To specify whether to go to a LTC, USER timecode or any of both (LTC/USER),
press C until the requested timecode type is displayed.

5. Enter the requested timecode using the function keys F1 to F10.
Eight digits: hh:mm:ss;ff (f=frame)are displayed on the LCD screenof the Remote.
◦ If you enter all 8 digits, Multicam will automatically goto the required timecode.
◦ If you enter less than 8 digits (when the last digits are zeros), press ENTER on the

Remote to validate the entry and reach the requested timecode.

Once you have entered the Goto TC, you can observe it has been correctly entered on
the display of the Remote LCD screen andon the output monitor. This Timecode
display appears in the centre of the LCD display, just above the menu options.

6. Press ENTER on the Remote.

If the timecode is from the LTC table, it will be displayed in white on the output monitor.
If the timecode is from the USER TC table, it will be displayed in yellow onthe output

monitor.
If nothing happens after confirming the TC entry with ENTER, this means that the field

corresponding to the selected Timecode does not exist on the disk any longer.
To exit the GOTO TC function at any time, press the MENU key.

2. Working Interfaces 17

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Last Cue

This function re-cues the EVS server to previous cue point relative to the current timecode
position. Each time the Last Cue button is pressed, the EVS server re-cues to the
previous cue, etc. Whenrecalling a cue point, the cue number appears in the upperleft
corner of the OSD if this option is enabled with the Cue number on OSD parameter in the
Operational Setup menu (p.1.1 F1)

Fast Jog

When selected, this option enables fast picture search: the actual speed of this fast jog is
adjustable in the Setup menu. Starting a play or returning to E2E mode resets the Fast Jog
mode.

Warning

The jog dial is active at all times when the system is in play & record. The brake
is automatically turned on when startinga playback with the PLAY key or with
the lever, or whenreturning to E2E mode with the RECORD button.

Mark

This function marks up to 256 cues that can be markedwhile recording or playing. The
cues are marked on the LIVE or PLAYBACK program depending on the valueset in the
Setup menu. When the operatorhas marked 256 cues, the next onewill overwrite the
oldest one.

Return

Inside a clip, press the RETURN key to remain on the same picture, but inside the record
train instead of the clip (if that picture still exists in the record train). This is useful when a
clip is too tight and you want to use material beyondthe current IN or OUT point.

RECORD

This key lights red when the system is recording. Pressing this key brings the system in
E/E (“live”) mode, and starts the record if necessary (depending on the settings of the
Setup menu). The E/E mode is actually playingpictures already recorded by the system,
andhas a delay of 3 frames compared to the live source, on all audio and video tracks.

Page

Use this key to select a new clips page. After pressing the SHIFT+PAGE key, you must
press a F_ key to select the corresponding page(1 to 10).

18 2. Working Interfaces

OPERATION MANUAL Nano 11.02

PRVCTL

This function enables/disables the Preview Control mode.

2.3.5. Rebooting the System from the Remote Panel

«Hard Reboot»

In the event that the system needs to be rebooted, the process can be accomplished from
the Remote Panel. Keep in mind that doing this while Multicam is running will of course
force the Multicam application to close abruptly, andup to 1 minute of the material being
recorded and not clipped could be lost.

To reboot, press the following key sequence,

Between step 3 and step 4, the RECORD button will flash GREEN and the PAGE button
will flash RED. Hitting the PAGE button will reboot the system. Hitting the RECORD
button will return to normal operation.

«Soft Reboot» from the Keyboard

It is also possible to run a «soft reboot» which will exit the software and returnthe user to
the EVS Menu. Here, the software can be selected and entered again without having to
reboot the entire system. When running the followingprocedure, the system will
automatically save all recorded material (record trains, clips, playlists) upon exit.

Hit ALT+Q on the keyboardor press F6 from the mainMenu, and confirm with ENTER or
cancel with ESC. You will exit the Multicam software and go back to the EVS Menu.

2. Working Interfaces 19

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

3. Control Modes

3.1. Live, Search or Playback Mode

Multicam can be set in three different basic modes, depending on commands used:

Live (E2E) Mode

This mode selected at start-up can also be selected by pushing the RECORD key.
Multicam records the input signal and plays it at the same time on the program output.

Search Mode

This mode is selected by moving the jog dial.
In this mode, the operator has the opportunity to search for an image, in order to define cue

points or clips. Moving the command knob clockwise will force Multicam to search
forward, moving the command knob counter-clockwise will force it to search backwards.
The most important thing to note is that Multicam never stops recording while searching.

Playback Mode

Moving the lever or pressing the PLAY key selects this last mode.
Multicam plays the incoming signal delayed, a clip or a playlist, in slow motion and of

course continues to recordthe incomingsignal on disks.
As soon as the lever is moved, Multicam starts playing back from the current picture. The

playback speedis defined by the lever position. This is used to start the playback of a
normal slow motion, as well as the playback of a clip or a playlist. During playback, the
system never stops recording

Note

Each operation on the Remote Panel with the control jog or lever will be
associated to the Search orPlayback mode respectively.

20 3. Control Modes

OPERATION MANUAL Nano 11.02

3.2. 1PGM+PRV Mode

3.2.1. 1PGM+PRV Mode

Introduction

Multicam has two modes for its basic operation, 1PRV+PGM and Multi PGM:

• The 1PGM+PRV mode is more powerful as it allows interaction between all outputs.

Synchronized replays can be rolled andchained between the cameras with either a
mix, a wipe, or a cut between them.

• The Multi PGM mode is more basic but gives the operator independent control of all

outputs. These outputs can be controlled together (such as jogging back to a certain
action on all outputs) or individually (eitherPGM 1 or2).

How to Enter the PGM+PRV Mode

To enter the 1PGM+PRV mode, press A from the Main menu. The Remote Panel will then
display the followingscreen:

*PGM1* CAM A PRV CAM B

Aud.Met. PgmSpd PostRoll

Mix Sw to IN Pref

P.1 B.1
PL 11: <
Msg

Rst Cam Sync Prv

Cam A Cam B

At least 2 playback channels must be available to run this configuration.
This mode allows the operator to make replays with/or without transition effects between

all outputs. A string of replays can be put together andplayed back at the operator’s
discretion.

The LCD display is divided in two menus controlled by soft keys (A, B, C, D). To gain
access to the upper menu, press MENU from the Remote Panel.

3. Control Modes 21

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

3.2.2. 1PGM+PRV Primary Menu Controls

Introduction

The primary menu in 1PGM+PRV mode, illustrated below, gives access to the functions
detailed in the following paragraphs:

Rst Cam Sync Prv
Cam A Cam B

CAM A / B / C / D

Rst Cam Sync Prv
Cam A Cam B

If PRV CTL is 'OFF', select the camera to assign to the PGM output. This camera key
will be highlighted in the menu.

If PRV CTL is 'ON', select the camera to assign to the PRV output. This camera key will
be highlightedin the menu.

Rst Cam

Rst Cam Sync Prv
Cam A Cam B

This function restores the position of cameras on the active channels: CAM A on PGM1,
CAM B on PRV.

Note

When a clip/playlist is loaded on a channel, switching back to Live mode will
recall the record train, which was last used on that output. This avoids too
frequent uses of the RstCam function.

Sync Prv

Rst Cam Sync Prv
Cam A Cam B

This option allows the user to synchronize the PRV with the timecode and speed of the
PGM output. This function is not available with remote record trains.

22 3. Control Modes

OPERATION MANUAL Nano 11.02

3.2.3. 1PGM+PRV Secondary Menu Controls

Introduction

The secondary menu in 1PGM+PRV mode, illustrated below, gives access to the
functions detailed in the followingparagraphs:

Aud.Met. PgmSpd PostRoll
Mix. Sw to IN Pref

Mix / Wipe L>R / Wipe R>L / Wipe U>D / Wipe D>U / Cut

Aud.Met. PgmSpd PostRoll
Mix. Sw to IN Pref

These options determine the transition effect that will occur between the PGM and PRV
pictures. The mix, wipe andcut are on the same location. Pressing this button will browse
through these effects, showing the active one on the LCD menu. Please refer to Setup
menu to select the duration of the transition effect.

PgmSpd / VarMax

Aud.Met. PgmSpd PostRoll
Mix. Sw to IN Pref

Pressing PgmSpd once enables the Program Speedmode and highlights this function on
the LCD. Pressing the key once moreenables the VarMax modeand highlights this
function on the LCD. The PLAY key is flashing red while either of these modes is
enabled.

• Program Speed mode: In this mode, only two speed values are availablefrom the

lever: 0% when the lever is in the lower position, or the speeddefined in the
Operational Setup menu (p.9.1 F3) for any other position of the lever.

• VarMax mode: the speedrangedefined by the lever is limited between 0% and the

speed valuedefined in the Operational Setup menu (p.9.1 F3).

Sw To In

Aud.Met. PgmSpd PostRoll
Mix. Sw to IN Pref

When this function is enabled (highlighted), a camerachange will cause a jump to the
corresponding IN point if existing. It will switch in Sync if no IN point exists for the current
element, orif SwtoIN is 'OFF'.

See section "Synchronization Mode(Switch To In)" on page 29 for more information on
this option.

3. Control Modes 23

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Pref

Aud.Met. PgmSpd PostRoll
Mix. Sw to IN Pref

Selecting this function enables the Preference mode.
See section "Preference Mode (PREF)" on page 29 for more inforamtionon this option.

Aud.Met.

Aud.Met. PgmSpd PostRoll
Mix. Sw to IN Pref

This option enables/disables the display of audiometers for all channels using the OSD of
the output monitors.

Post-Roll

Aud.Met. PgmSpd PostRoll
Mix. Sw to IN Pref

When the post-roll modeis enabled, that function is highlighted on the LCD and a “P”
appears onthe OSD of the output monitors.

When the user exits Multicam with the post-roll mode on, this mode will still be enabled
when Multicam is restarted.

The post-roll mode works as follows depending on the element played:

• When a clip is played, it will not stop on the Short OUT point, but will continue to play

through the Short OUT point by the post-roll duration definedin the Setup Menu.

• When a record train is played, the same will happen if the Record trains OUTs

parameter is set to “Freeze” in the Operational Setup menu (p.2.3 F1).

• When a playlist is played, the post-roll will apply only to the last clip of the playlist.

3.2.4. Full Control and Lever Control

You control both PGM and PRV when the PRV CTL key is not active.
Once you select PRV CTL, you gain control on the PRV channel with the jog dial and

most keys, while the lever and the PLAY key control the PGM output. At this point,
selecting clips will call them up on the PRV channel.

Activating both the PRV CTL and the SW to IN functions allows the operator to auto-chain

cameras from the same IN point.

24 3. Control Modes

OPERATION MANUAL Nano 11.02

Let's say an IN point has been marked, and you activate the PRV CTL and sets to ON the

SW to IN option: Theslow motionof one camera can be started from this IN point. The
operator selects another camera in the PRV output and, via the TAKE button, can auto­chain cameras from the same IN point on the PGM output.

3.3. Multi PGM Mode

3.3.1. Multi PGM Overview

Introduction

Multicam has two modes for its basic operation, 1PRV+PGM and Multi PGM:

• The 1PGM+PRV mode is more powerful as it allows interaction between all outputs.

Synchronized replays can be rolled andchained between the cameras with either a
mix, a wipe, or a cut between them.

• The Multi PGM mode is more basic but gives the operator independent control of all

outputs. These outputs can be controlled together (such as jogging back to a certain
action on all outputs) or individually (eitherPGM 1 or2).

3. Control Modes 25

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

How to Enter the Multi-PGM Mode

To enter the Multi PGM mode, press B from the Main menu. This button is labeled
'1PGM', or '2PGM' according to your system configuration.

The Remote Panel will then display the following screen:

PGM1 CAM A *PGM2* CAM B

Aud.Met. PgmSpd PostRoll

Sw to IN Pref

P.1 B.1
PL 11: <
Msg:

Rst Cam Sync To

PGM 1 PGM 2

The LCD display is divided in two menus controlled by soft keys (A, B, C, D). To gain
access to the upper menu, press MENU from the Remote Panel.

3.3.2. Multi PGM Primary Menu Controls

Introduction

The primary menu in Multi PGM mode, illustrated below, gives access to the functions
detailed in the following paragraphs:

Rst Cam Sync To
PGM 1 PGM 2

Rst Cam

Rst Cam Sync To
PGM 1 PGM 2

This function restores the position of cameras on the active channels: CAMA on PGM1,
CAMB on PGM2, etc.

Note

When a clip/playlist is loaded on a channel, switching back to Live mode will
recall the record train, which was last used on that output. This avoids too
frequent uses of the RstCam function.

26 3. Control Modes

OPERATION MANUAL Nano 11.02

Sync To

Rst Cam Sync To
PGM 1 PGM 2

This button allows you to synchronize the selected PGM in use with another one. Press
this button and then select the PGM to be usedas a reference.

How to Assign a Camera to a Channel

In Multi PGM mode, to changethe current camera on each PGM, proceed as follows:

1. In the primary menu, select the PGM to which you want to change the current camera.

The TAKE key at the bottom of the remote is thenlighting red.

2. Press the TAKE key. It lights green and the menu on the LCD display changes to let

you select the desired camera.

Rst Cam Local
CAM A CAM B

3. Press the camerayou want to associate to the selected PGM.

4. Press TAKE again to return to the PGM selection menu.

Playlist Conditional Mode

This mode is only available in 2PGM mode. It allows the operator to loadand control
several playlists simultaneously from the same Remote Panel, orto load a playlist on one
channel while performing other operations on the other channel(s). To use this mode, the
Load Playlist parameter of the Operational Setup menu must be set to Conditional (p.3.3
F2).

To use this mode, select one channel (for example PGM1), andpress the PLST key one,
two or three times to enter the PLST EDIT or the PLST DIFF mode (refer to the “Playlist
Management” Section of this manual for details about these modes). You can notice that
the TAKE key lights green. Pressing the TAKE key will allow the operator to return to the
PGM selection menu, and select another PGM channel where he can start a replay, load a
clip oranother playlist, etc.

In this mode, if the operator selects a PGM channel where a playlist is loaded and presses
the TAKE key, he will enter again the PLST EDIT or PLST DIFF mode.

When playlists are loaded on all channels currently controlled by the operatorin Multi
PGM mode, the TAKE key lights red. If the TAKE key is pressed, the remote will enter a
specific PLST DIFF mode, where the operator can control several playlists
simultaneously, and browse them or roll them in sync. NEXT and SKIP functions are also
available and will apply on all controlled playlists. The TAKE button will not light red if one
of the controlled channels does not contain a playlist.

3. Control Modes 27

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Practical example

The operator builds a playlist with Fills and another playlist with Keys. He sets the Playlist
Load parameterto Conditional in the setup menu, thenenters the 2PGM mode, selects
the Fills playlist as current playlist, presses A to gain control on PGM1, presses PLST two
or threetimes to enter the PLST DIFF modeand cue upthe Fills playlist to its 1st clip.
Then he presses the TAKE key to returnto the PGM selection menu, selects the Keys
playlist as current playlist, presses B to gain control on PGM2, presses PLST two or three
times to enter the PLST DIFF modeand cue upthe Keys playlist to its 1st clip. Then he
presses the TAKE key to returnto the PGM selection menu, presses D to gain control on
both PGM channels, then presses TAKE to enter the PLST DIFF menu. He will see the
content of both playlists side by side on the LCD screen, and can browse them or play
them in Sync at any speed, and perform SKIP and NEXT commands as needed.

3.3.3. Multi PGM Secondary Menu Controls

The secondary menu can be called by pressing the MENU key andis similar to the
1PGM+PRV mode, except that the A function is empty since it is not possible to create a
transition between the channels in this mode.

See section "1PGM+PRV Secondary Menu Controls" on page 23 for a description of the
other functions of the secondary menu.

28 3. Control Modes

OPERATION MANUAL Nano 11.02

3.4. Synchronization Mode (Switch To In)

The Synchronization mode allows users to define how they jump from onecamera to the
other. The Synchronization mode is available in the secondary menu from the main LCD
display, using the B soft key.

If the Synchronization mode is OFF (SW to IN is not highlighted in the secondary menu), a
request for camera change will produce a jump at the same timecode on the requested
camera. This mode allows synchronous change of camera angle.

If the synchronization modeis ON, a request for a camera change(by pressing CAM A,
CAM B, CAM C, or CAM D in the Multicam menu)will leadto a jump to a predefined
CUE IN point.

If a CUE IN point has not been previously defined, Multicam acts as in SW to IN OFF
mode (even if SW to IN ON is shown) because the system has no reference to jump to.

3.5. Preference Mode (PREF)

The Preference mode allows users to show the preferential camera angle by default when
a clip is loaded. The Preference mode is available in the secondary menu from the main
LCD display, using the D soft key.

When this optionis ON and a clip is recalled, the preferred camera will be displayed on the
main output, even if another camera angle was previously loadedon that output.

The preferred camera is the one, which was onthe primary output channel when the clip
was created.

The second preferential camera (“secondary camera”) is the one that was loaded on the
next channel when the clip was created.

In the Clip screen, the first preferential camera is indicated by a star: 111B* and the
second preferential camera is indicated by 2 dashes: 111B=.

When the preference option is disabled, the PGM output stays on the camera currently
selected when the clip is called.

3. Control Modes 29

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

3.6. Controlled and Primary Channels

Controlled Channel

A channel is "controlled" whenthe operator can control it with the jog dial. In this case, the
words "FULL CTRL" are present on the top of the OSD of the output monitor of that
channel.

Primary Channel

The primary channel is the first controlled channel. It is identified by stars around its name
on the OSD of the output monitor and on the LCD display of the Remote Panel (ex:
*PGM1*).

Examples:

• In 1PGM+PRV mode with PRV CTRL OFF, the primary channel is PGM.

• In 1PGM+PRV mode with PRV CTRL ON, the primary channel is PRV.

30 3. Control Modes

OPERATION MANUAL Nano 11.02

4. Clip Management

4.1. Introduction

4.1.1. Clip Structure

Concepts

A clip is defined by Short IN andShort OUT points. When referring to Short IN and Short
OUT points, the operators usually use the terms IN point andOUT point.

When Short IN and Short OUT points are set, the system automatically write protects a
user definable length of material before andafter the Short IN/OUT points respectively,
these are referred to as the guardbands.

For this reason, the IN point before the guardbands and the OUT point after the guardband
arecalled Protect IN point and Protect OUT point.

Use of Guardbands

It is possible to trim a clip by redefining Short IN andShort OUT points.
If Short IN and Short OUT points are defined, only the fields between those two points will

be playedif the sequence is recalled(the same applies whenthe sequence is includedin a
playlist).

Fields between Protect IN andShort IN andfields between Short OUT and Protect OUT
(guardbands) can be reached with the jog. So the Short IN and Short OUT points can be
redefined.

4. Clip Management 31

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

General Principles

Protect IN & Protect OUT points of a clip cannot be replacedby new ones.
Short IN & Short OUT points of a clip can be replaced by new ones.
Short OUT point is excluded. The clip freezes on previous field whenplaying back (with

post-roll mode disabled).
(Short) IN & OUT are always on even fields. This is automatic.
The guardband beyond the Short OUT point is created with the material available when

the operator saves the clip by pressing the selected F_ key. Therefore, this guardband can
sometimes be shorter than the valuedefined in the Setup menu.

4.1.2. Clip Numbering Hierarchy

Introduction

Multicam can store up to 900(multiplied by the number of cameras) clips and 100 playlists
in its libraries. 900 clips with up to 6 cameraangles per clip result in 5400clips on a server.
This number is displayed in the upper right window of the VGA Setup screen (SHIFT+F2
from the PC keyboard).

32 4. Clip Management

OPERATION MANUAL Nano 11.02

Clip Hierarchy Diagram

The following diagram represents the hierarchy of the Multicam clip numberingsystem.
As an example, clip number “112” is used:

Clip LSM ID

The clip numberingsystem is as follows:

In the above example, the

• “5”refers to the clip page number (1 to 10).

• “4”refers to the clip bank (1 to 9)

• “7”refers to the clip number (1 to 10) inside the bank

• "B" refers to the cameraname.

4. Clip Management 33

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

4.1.3. Clip Availability on Disks

Various clip types can be distinguished depending on whether they are availableon the
disks or not. Depending on the clip availability on disks, you can perform specific actions
on the given clip or not.

Clip Available Actions

Clip on disk Clips which are protected on disks, and which have Short IN and

Short OUT points present on disks.
All the material is available on the disk.

Growing clip Clips which are protected on disks, and which have a Short IN

point, and possibly Short OUT point defined on disks.
Since the record process is still undergoing, some of the material is
already on the disk but not all of it.

4.2. Clip Functions on the Remote Panel

4.2.1. Remote Panel Interface

Overview

In Clip mode, the secondary menu of the Remote Panel is different from the RecordTrain
mode:

PGM1 112A *PRV1* 112B

Push Aux Clip PostRoll
>Archive Cam

P.1 B.1 Clips: Local Records: Local
PL 11: < >
Msg:

Rst Cam Sync Prv

Cam A Cam B

Press MENU to access the secondary menu.

34 4. Clip Management

OPERATION MANUAL Nano 11.02

Secondary Menu Without Keyword File Defined

1 2 3

111A

Push Aux Clip PostRoll

>Archive Search Cam

In this mode of the secondary menu, clips can still be directly recalled using the F1-F10
keys of the Remote Panel.

4.2.2. Remote Panel Functions

Secondary Menu in Clip Mode

Push

Push Aux Clip PostRoll
>Archive Cam

The Push function allows you to easily send a copy of a clip to another machine on the
network, via the GigE network.

• If one or two default targets (push machines) are defined in the setup, the clip will be

automatically sent to these machines.

• If no default target is defined, the list of machines available on the network will appear.

As soon as the operator selects one of them, the clip is pushed.

In both cases, a message appears for a few seconds on the LCD to confirm that the clip is
being pushed and indicate the clip location where it will be stored on the receiving
machine.

If the Receive Page(s) defined on the destination machineis (are) full, the operator who
tries pushing the clip is notified. While this message is being displayed, the operator can
press the MENU key at any time to return to the normal menu. Depending on the
CAM/CLIP mode selected by the D key, only the camera angles loaded on the controlled
channels are pushed (CAM mode), or all cameraangles of the clip arepushed at once
(CLIP mode).

4. Clip Management 35

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

>Archive

Push Aux Clip PostRoll
>Archive Cam

The Archive function allows the operator to flag a clip to place it in the archive queue of the
Xtract

This function is blinking when the clip is flagged for archiving, but has not yet been
archived. It is permanently highlighted when the archiving of the clip is completed.

Depending on the modeselected with the D key (CLIP/CAM), the >ARCHIVE flag is
assigned only to the camera angles of the clip loadedon the controlled channels (CAM
mode), or to all camera angles of the clip (CLIP mode).

Aux Clip

Push Aux Clip PostRoll
>Archive Cam

This function allows assigning a clip as auxiliary audio clip to the current playlist. Press
CLEAR+Aux Clip (CLEAR+SHIFT+B) to remove the current auxiliary clip. "Playlist
Management" on page59 for more details.

PostRoll

Push Aux Clip PostRoll
>Archive Cam

This function enables/disables the post-roll mode. "1PGM+PRV Secondary Menu
Controls" on page23 for more explanations about this mode.

Clip/Cam

Push Aux Clip PostRoll
>Archive Cam

Pressing the D key will toggle between CAM and CLIP modes onthe remote. Please note
that this mode on the remote and on the VGA screens is never synchronized.

• In CAM mode, the Push, and Archive functions will apply only to the cameraangles of

the clip loaded on the controlled channels.

• In CLIP mode, these functions will apply on all camera angles of the clip.

36 4. Clip Management

OPERATION MANUAL Nano 11.02

4.3. Clip Functions on the VGA

4.3.1. VGA Interface - Clip Screen

Standard View

The navigation through the Clip screen, and the various functions available on this screen,
can be performed using the tablet and stylus, or the keyboardshortcuts.

4. Clip Management 37

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Extended View

The extended view shows cameras A to F instead of A to D. Only 1 bank can be viewed at
a time. The switch between standard and extended view is done by pressing F5 on the
keyboard or by clicking on the “F5:VIEW” areaon the screen.

Title Bar

The Title bar contains the status information:

• Name of the EVS server.

• Total number of clips (1camera anglecounting for 1 clip in this count).

• Total duration of all clips.

• Remaining capacity on the server (all record trains together; valid for local server

only).

Clip Information Area

The next area is the Clip InformationArea which displays the clips of the selected page
andbank(s). Two clip banks are displayed at a time.

38 4. Clip Management

OPERATION MANUAL Nano 11.02

For each clip and camera angle, the following information is available:

Field Description

Clip ID Uniqueidentifier of the clip on the server. Ex: 111A

Clip “rank” Clip rank depending on the channel on which it has been created:

Clip name Name of the clip, either automatically assigned or defined by the

Archive Status • If the clip ID is blinking green, the clip is flagged for archiving, but

The clip ID is followed by the “Creating”messagewhen the clip is in
the process of being created, copiedor moved to this location.

• Primary (“*” next to the clip ID)

• Secondary (“=” next to the clip ID)
The clip rank informationis highlighted in blue if the clip is protected.

user.

not yet archived

• If the clip ID is permanently highlighted in green, the archiving of

the clip has been completed

4.3.2. VGA Functions - Clip Screen

Function Bar

The second line of the Clip screendisplays the available functions. Each function can be
called by the correspondingF_ key of the keyboard, or by clicking with stylus & tablet on
the corresponding area on this line.

Function Key Description

Name F1 This function is used to name a clip.

Clip/Cam F2 This function toggles betweenCLIP mode and CAM

mode.

• In CLIP mode, actions on a clip will use all available
cameras for this clip.

• In CAM mode, actions on a clip will only use the
selected camera for this clip.

Otherfunctions such as Name, Delete, Copy, Set TC,
>Archive depend on this mode selection.

Call F3 The operatorcan gain immediate access to a local or

network clip by typing its ID number.

Pref F4 This optionchanges the primary camera of a clip.

View F5 This option changes the standard display to the extended

display and vice versa.

Playlist F0 The Playlist screen can be accessed by selecting F10 on

the keyboard.

4. Clip Management 39

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Clip Management Area

Name Capture Field

This is the only capture area of the screen. It is used to enter the name to assign to a
clip/playlist, or to enter the ID of a clip to recall.

Mode Field

It indicates if the clip screen is currently in CLIP orCAM mode. In CLIP mode, actions on
a clip will use all available cameras for this clip. In CAM mode, actions on a clip will only
use the selected camera for this clip. Default value is CAM mode.

Clip Control Area

It is dedicated to play-out control.

Command Description

ALT+P:►/■ Plays at 100% speed except for super motionclips which are

playedback at 33% speed; and pause playback on the current
picture.

ALT+R:RECUE Jumps to the Short IN point.Primary.

ALT+T: SET TC Restripes the timecode of the current clip.

40 4. Clip Management

OPERATION MANUAL Nano 11.02

Command Description

ALT+Z:>ARCHIVE Allows the operatorto flag a clip to place it in the archive queue of

PGM X Located in the bottom right corner of the clip screen, this field is

the Xtract defined in the Operational Setup menu (p.7.1 F1) or in
the Setup screen.
When a clip is flagged for archiving, but has not yet been
archived, its ID will be blinking green in the Clip screen. It is
permanently highlighted green when the archiving of the clip is
completed.
Depending on the modeselected with the F2 key (CLIP/CAM),
the >ARCHIVE flag is assigned only to the camera angle of the
clip selected with the green cursor (CAM mode), or to all camera
angles of the clip (CLIP mode).

only visible if the Call channel VGA function has beenenabled in
the Operational Setup menu (p.9.2 F4) or in the Setup Screen,
andis only effective in CAM mode, not in CLIP mode. It allows
the operator to select on which channel clips called using the
keyboard/tablet and VGA should be loaded.
Press ALT+F1 on the keyboardto select PGM1, ALT+F2 for
PGM2/PRV. This function is useful to load clips on channels that
cannot be controlled by anEVS Remote Panel, or to allow an AP
to browse clips on a play channel not used by the main operator.
Note that if that channel is in PLST EDIT mode with a PRV, the
clip will automatically cue up on the PRV.

4. Clip Management 41

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

4.3.3. VGA Interface - VDR Panel

VDR Panel

The VGA VDR Panel is accessed from any VGA screen by pressing SHIFT+F9 on the
keyboard. The lower section of the VDR Panel is similar to the clip screen, with the same
functions. The upper section of the VDR Panel features two windows that can each take
control of one channel of the server.

Pressing SHIFT+F9 in the VDR Panel returns the VGA to the Clip screen mode.

Upper Section

The two windows of the upper section can be assigned to a different channel of the server.
When entering the VDR Panel for the first time after starting the application, the control of
both windows is disabled.

Press CTRL+F1 to gain control of the left window, orCTRL+F2 to gain control on the right
window. The framearound the corresponding window becomes green. Note that only one
window can beactive at a time. Inside the active window, letters/numbers highlighted in
green indicate the keyboard shortcut to the corresponding function: press ALT+the
highlighted letter/number. All functions are also available by clicking with the stylus.

Warning

The control of a channel from the VDR Panel is concurrent to any other
controller that might be assigned to that channel: EVS Remote Panel or external
protocol. A command sent from the VDR Panel to a channel will overwrite
whatever the channel was doing at that time.

42 4. Clip Management

OPERATION MANUAL Nano 11.02

The name of the channel currently assigned to each window is displayed on the top of
each of them. To assign a new channel to this window, press ALT+H. A new window
appears onthe otherside to allow the selection of a new channel.

Use the UPARROW andDOWNARROW keys to select the channel and press
ENTER, or directly press ALT+the number of the channel as highlighted in green. The
Play channels already assigned appear in grey and cannot be selected. Select “0 –
Disable Window” if you don’t want to assign any channel to the window. Depending
whether a Play or Record channel is assigned to the VDR Panel window, its content is
automatically updated.

Lower Section

The browsing of clips, the viewing modes (normal or extended), the way clips arerecalled,
moved andcopied, etc. in the VDR Panel is strictly the same as in the Clip screen. The
Connect window is calledwith F9, and allows to connect to other servers on the network.

4.3.4. VGA Functions - VDR Panel

In the Player Window

The following information are available in this screen:

• ID of the current element (clip ortrain)

• Current timecode

• Name of the current element

• List of available camera angles (green) and selected cameraangle (red)

4. Clip Management 43

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

The following functions are availableto play and browse the current element:

Command Description

ALT+P Play from / Pause on the current picture

ALT+Y Play the current clip in endless loop mode. The play will start from

the current picture until the Short OUT point of the clip, then will
automatically loopback to the Short IN point and keep playing, and
so on…

ALT+V PlayVar at the speed specified in the adjacent field. To edit the Var

speed, press ALT+% (without SHIFT key), type the desired value
andpress ENTER to confirm.

< / > Move 1 field backward / forward

SHIFT+< / > Move 1 second backward / forward

CTRL+< / > Fast Rewind+Fast Forward. The browsing will continue after the

keys are released.

ALT+< / > Goto IN / OUT

ALT+G Goto timecode

After loadingthe desired clip, the following edition functions are available:

Command Description

ALT+N Renames the clip. Type the desired nameand press ENTER to

confirm or ESC to cancel.

ALT+I / ALT+O Marks a new Short IN / Short OUT point on the current picture. The

cursor is automatically placed in the adjacent field, so that the
operator can manually enter the timecode of the desired Short IN /
Short OUT point if needed. Press ENTER to confirm, or ESC to
cancel.

In the Recorder Window

44 4. Clip Management

OPERATION MANUAL Nano 11.02

The VDR Panel Recorder can be used to start/stop the record, and to create clips from the
local recordtrains. For example, it allows the creation of clips on a server that has no Play
channel.

Press ALT+R to start or stop the record on the recordchannel assigned to the window.
No confirmation is required.

Warning

In Sportlight mode, all recorders will be stopped at once to keep the
synchronization between all recordchannels.

4.4. Operations on Clips

4.4.1. Creating and Saving Clips

Introduction

A clip is created by defining and IN and OUT point on a record train, and saving the A/V
material between IN and OUT as a clip, hence preventing it to be deleted by the loop
recording.

When you save your clip, clips are created automatically on the following cameras:

• on the primary channel.

• on all cameras associated to a player channels.

• on all cameras for which the Automake Clip option is set to Yes in Multicam
Configurationwindow, Operation tab, Clips section.

A clip can be createdwith only an IN or only an OUT point. Thesystem will automatically
adjust the clip duration according to the default duration definedin the Setup menu (p.2.2
F2).

The auto-save process automatically saves clips and playlists at least every minute.
Exiting the software(ALT+Q) will also save the clips and playlists.

In the Remote Panel Interface

To create a new clip, proceed as follows:

1. Press the RECORD key to select the Live mode if you are not yet in this mode.

2. Use the jogdial to define the clip Short IN point then press the IN key to mark it

3. You can use the jog dial to define the clip Short OUT point then press the OUT key to
mark it.

Note

You can mark an IN or an OUT point on a paused record train andgo back to live
without losing the point marked by pressing SHIFT+Return.

4. Clip Management 45

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

4. Press SHIFT+Page+F_ key to select the page where the clip will be stored (page 1
contains clips 110to 199, page 2 contains clip 210 to 299, and so on).

5. Press SHIFT+F_ key to select the bank wherethe clip will be stored (use F1 to F9
keys as F10 is reserved for the playlist bank available on each page).

6. Press F_ key to select the location of the clip.

The clip is created in the specified location. The primary timecode of the clip is the primary
timecode defined on the trainwhere and when the clip has been created.

Note
Press the F0 key on the Remote Panel to save ALL clips and playlists.

Example

To create a clip in location 213 (page2, bank 1, location3):

1. Press SHIFT+Page+F2 to select page 2.

2. Press SHIFT+F1 to select bank 1.

3. Press F3 to select location 3 on the selected page.

In the VGAInterface

To create a new clip in a player window of the VDR Panel, proceed as follows:

1. Load a record train on the player.

2. Browse the record train to reach the desired Short IN or Short OUT point.

In a Player or in a Recorder window of the VDR Panel:

3. Press ALT+I or ALT+O to mark the Short IN or Short OUT point on the current
picture.

4. The cursor is automatically placed in the adjacent field, so you can manually enter, if
you know it, the timecode of the desired Short IN or Short OUT point . Press ENTER
to confirm or ESC to cancel.

5. You can repeat this operation to define the complementary Short IN or Short OUT
point.

6. Press ALT+A-F to select and deselect the recordtrain(s) from which the clip(s) will be
created. The letters highlighted in RED mean that a clip will be created from the
corresponding record train and the letters highlighted in GREEN mean that the
corresponding record train is available but will not be used to create a clip.

7. You can specify the name of the clip before saving it. Press ALT+N thenenter the
desired name and confirm it with ENTER.

8. In a Recorderwindow, you can restripe the timecode of the IN point to a new value.
Press ALT+T, enter the desired value and confirm with ENTER. When creating the
clip, this timecodewill replace the original one of the Short IN point.

46 4. Clip Management

OPERATION MANUAL Nano 11.02

9. Press ALT+S to open the 'Save as' window. If needed, you can name or rename the
clip. Press ENTER to save the clip to the current cursor location in the lower section
of the VDR Panel or ALT+U to save it in the first availableclip location in the current
server (that is the first available location where no camera angleis already present).

You can also, from this window, browse the database, select a different page and
bank, and even connect to another machine on the network using the Connect
window.

4.4.2. Recalling and Playing Back Clips

In the Remote Panel Interface

How to Recall a Clip

To recall a clip, proceed as follows:

1. Select the page where the clip is storedby pressing the SHIFT+Page key and the
function key correspondingto the given page.

2. Select the bank wherethe clip is stored by pressing the SHIFT+F1 to F9 key
corresponding to the requested bank.

The clip banks 1 through 9 respectively correspond to the F1 to F9 keys within each
clip page (1 to 10).

3. Select the position where the clip is stored in the bank by pressing the F1 to F9 key
corresponding to the clip position.

If Recall Clip Toggle option is enabledin the Operational Setup menu (p.9.1 F6) or in
the Multicam Configuration window (Operation tab, EVS controller section), pressing
several times on the same F_ key will call successively all cameraangles of that clip.

How to Play Back a Clip

To play back a clip, doone of the following depending on the desired playback speed:

• Press the PLAY key to play back the selected clip at the default playback speed.

• Use the lever to play back the selected clip at a speed varying from 0% to 100%.

4. Clip Management 47

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Playback Speed Options

• To play back a selected clip, with the lever, at a speed varying from 0% to a given
maximum speed, you needto do the following:

◦ Define the requested maximum speed in the PGM Speed/Var max parameter

(p.9.1 F3) in the Operational Setup menu.

◦ Select (highlight) the VarMax option in the secondary menu in PGM/PRV mode.

• To play back a selected clip, with the lever, at a given predefined speed, you need to
do the following:

◦ Define the requested maximum speed in the PGM Speed/Var max parameter

(p.9.1 F3) in the Operational Setup menu.

◦ Select (highlight) the PGMSpd option in the secondary menu in PGM/PRV mode.

Options for Camera Angle Selection

• If PREF is 'ON', the preferred camera angle of the clip appears on the primary
channel, the secondary camera angle on the next controlled channel, and the other
camera angles on the next channels in alphabetical order.

◦ Example: If the preferredcamera anglefor clip 124 is camera C, when loading the

clip, 124C is loadedon the primary channel, whatever the camera present on that
channel before loading the clip.

• If PREF is 'OFF', the camera angle will be the same as the onealready present on
each controlled channel. If that camera angle does not exist, the first available camera
angle of the clip is used.

◦ Example: If camera B is the current camera on the primary channel, whencalling

clip 124, it is 124B that appears onthe primary channel, even if it is not the
preferred camera angle.

• When the operator is controlling only one channel (such as with PRV CTL), the clip
appears at that location only. In the case of a clip containing a single camera angle (so
only an 'A', 'B', 'C', or 'D' clip), whenin full control of all outputs, the clip recalled will
appear on the primary channel.

Growing Clips

You can recall and play back growing clips, or clips that are in the process of being
created on a disk.

• As long as the OUT point of a growing clip is not available on the EVS server, the LED
corresponding to the growing clip locationblinks green when it is called and red when
it is loaded on the Remote Panel. The clip LED will nolongerblink as soon as both IN
andOUT points are available on the EVS server.

• If the play reaches the end of the availablematerial, it freezes until new material is
available for play back. As soon as new material is available, the play resumes.

• When the OUT point of the clip is known, the remaining time is displayed, otherwise
the remaining time display is '--:--:--:--' until the entire clip is copied.

48 4. Clip Management

OPERATION MANUAL Nano 11.02

In the VGAInterface

Introduction

In the Clip window, use the keyboard keys to move through pages/banks, as well as
select and recall clips. The main commands are detailed in the table below:

Moving Around Pages and Banks

In order to ... Proceed as follows:

Highlight clips in the displayed banks Press the Up, Down, Left or Right

Display other banks Press ALT+Up/Down Arrow key to

Arrow keys.
The highlighted clip or clip position is
surrounded by green arrows.

scroll vertically between banks.
Press ALT+Left/Right Arrow key to
scroll horizontally betweenpages.

Go to bank 1 of current page Press the HOME key.

Go to bank 10 (playlist) of current page Press the END key.

Return to the local clips and playlists (if Clip
window connected to a remote machine)

Press ALT+L

How to Cue and Play Back a Clip via the Clip Window

To cue up anhighlighted clip, press ENTER.
The clip will be cued up on the on the primary channel controlled by the 1st Remote Panel

andon the VGA Call Channel defined in the setup.
If the channel where the clip is supposedto be loadedis in Plst Edit modewith a PRV

channel attached, the clip will automatically cue up on the PRV channel.

To recall a clip on the server you are connected to, proceed as follows:

1. Enter the 3 or 4 digits of the clip ID (for example111 or 111A).

2. The entry appears in the Name field.

3. Press F3:
◦ If you entered only 3 digits, the clip primary camera is selected.
◦ If you entered 4 digits, the clip givencamera angleis selected.
◦ If no clip matches the entry, no selection is done.

4. Press ALT+P to play back the selected clip.

Note

Press ESC at any time to clear the Name field.

4. Clip Management 49

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

How to Load a Record Train in the VDRPanel

1. Press ALT+L to go in LIVE mode (or click on the LIVE function).

2. Press ALT+the letter of the desired record train (A/B/C/D/E/F), or click on it.

3. The letters corresponding to the available record trains arehighlighted in green, and
the letter of the current record train in red.

How to Load a Clip in the VDRPanel

1. Use the arrow keys to move the cursor inside the lower section of the VDR Panel to
the desiredclip.

2. Press ENTER, or click on the desired clip with the stylus, or type the desiredclip ID
andpress F3.

3. To select a different camera angle inside a clip, press ALT+the letter of the desired
camera (A/B/C/D/E/F), orclick on it.

4. Available cameraangles are highlighted in green, the current camera angle in red.

With a Tablet and a Stylus

To select a different page or bank using the stylus, click on the desiredpage/bank number
on the bottom line of the screen. You can also move to the adjacent page/bank by clicking
on the red arrows on the top, bottom and sides of the screen:

• Left/Right Arrow: go to previous/next page

• Up/Down Arrow: go to previous/next bank

If a clip is present in a certainlocation, it will be highlighted in blue. Once selected, it will
be highlightedin orange.

To cue up a clip on the primary channel controlled by the first remote, or on the VGA Call
Channel defined in the setup, simply click on it with the stylus (that is press lightly the tip
of the stylus onto the tablet). If the channel where the clip is supposed to be loaded is in
Plst Edit modewith a PRV channel attached, the clip will automatically cue up on the
PRV channel.

50 4. Clip Management

OPERATION MANUAL Nano 11.02

4.4.3. Deleting Clips

Introduction

You can delete any clip available on disks as well as growing clips, but:

• Loaded clips cannot be deleted.

• Clip that are on air cannot be deleted.

In these cases, a warning message is displayed.
Additionally, the deletion must be confirmed in the warning message box that appears:

• When the clip is protected.

• When the Confirm del clp/plst parameter is set in the Operational Setup menu (p.5.1
F3).

Note

When a clip is deleted, all playlists are scanned and that clip is removedfrom all
of them.

In the Remote Panel Interface

Deleting a Single Clip

Note

The F_key corresponding to the clip location on the Remote Panel must be
green to be able to delete it.

To delete a clip, proceed as follows:

1. Select the page and bank where the clip that you want to delete is stored.

2. Press CLEAR, then press the F_ key corresponding to the clip.

Warning

In most cases, no confirmation is required and the clip will be instantly deleted.

3. If a confirmation message appears, press ENTER to confirm the selected clip
deletion.

4. Clip Management 51

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Deleting All Unprotected Clips in a Bank

To delete all unprotected clips stored on a givenbank, proceedas follows:

1. Select the page where the bank that you wish to clearof all unprotected clips is
stored.

2. Press CLEAR, SHIFT , then the F_ key corresponding to the bank.

The following confirmation message is displayed:

Caution:

This will delete all unprotected clips
stored on bank X

[Menu] : Cancel[Enter] : Confirm

3. Press ENTER to confirm the unprotected clips deletion on the selected bank.

Deleting All Unprotected Clips

You can delete all unprotected clips in one operation using the Clear All Clips command.
The following clips will not be deleted:

• Clips stored on protected pages as defined in the Setup menu.

• Clips protected by another protocol.

• Clips included in playlists.

To clear all unprotected clips, proceed as follows:

1. Press SHIFT+MENU to go to the mainmenu.

2. Press F7 (Clear All Clips command).

3. When the confirmation message is displayed, press ENTER to confirm the
unprotected clips deletion.

4. A message is displayedon the video monitorto notify the operation completion.

Warning

The Clear All Clips commandis different from the Clear Video Disks
command available in the Maintenance menu of EVS software.

• The Clear All Clips commanddeletes only the unprotected clips.

• The Clear Video Disks command in the Maintenance menu
definitively deletes all video and audio data from the disks, including
any clip stored in protected pages.

52 4. Clip Management

OPERATION MANUAL Nano 11.02

In the VGAInterface

To delete a clip, proceed as follows:

1. Move the cursor to the clip to delete.

2. Press CTRL+DEL or click on the corresponding area in the Clip Management area.
◦ In 'CAM' mode, only the cameraselected is deleted.
◦ In 'CLIP' mode, all cameras of the clip are deleted.

4.4.4. Copying and Moving Clips

Principles

• Copying a clip gives a new clip which is totally independent from the original. It can
thereforebe trimmed, named, deleted, etc. without affecting the original.

• Copying clips locally ona server does not duplicate the video and audio material on
the drives: it simply creates a separate reference to the same material. This means
that the available storage capacity will not decrease whenmaking copies of clips on a
server. It also means that deletedcopies of clips will not increase the available
capacity of the server, as the material will not be deleted as longas one instance of
the clip remains.

• When moving a clip using the Move function, the reference to this clip in playlists will
automatically be updated. This is very useful whenyou wish to re-organize yourclips
across different pages and banks, since playlists are not affected. If you copy the
clips andthendelete the originals instead of using the Move function, the reference to
the original clips will be removed from the playlists when deleting these clips.

In the Remote Panel Interface

To copy or move a clip, proceed as follows.

1. Select the original clip. It can be a local or a growing clip.

2. Select an empty location.

The following Copy/Move menu is displayed:

Copy Clip113 to Clip 141
Cam A B

[Menu]: Cancel
[Enter]: Confirm

COPY MOVE SHORT CLIP

4. Clip Management 53

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

3. Select the COPY or MOVE function by pressing the A or B key. The selected function
will be highlighted on the Remote Panel and the message will be updated accordingly
on the OSD.

4. Press the D key in the Copy/Move menu to select:
◦ 'CLIP' mode: all cameraangles of the clips will be copied or moved.
◦ 'CAM' mode: only the cameraangles of the clip loaded on the controlled channels

will be copied or moved.

5. Press ENTER to confirm or MENU to cancel.

In the VGAInterface

Copying andmoving clips is performed using the CUT, COPY and PASTE functions
available in the Clip Management area.

How to Copy a Clip

To copy or move a clip, proceed as follows.

1. Move the cursor to the clip to copy.

2. For a copy, press CTRL+C (COPY function)or for a move, press CTRL+X (CUT
function) or click on the corresponding area in the Clip Management area. During a
move operation, the original clip is deleted.

3. The clip is copied to the clipboard .The clipboard area displays its content: clip number
andthe selected cameras.

◦ In 'CLIP' mode: all camera angles of the clips will be copied.
◦ In 'CAM' mode: only the selected camera angle will be copied.

4. Move the cursor to the clip/playlist location where the content of the clipboard should
be copied.

5. Press CTRL+SHIFT+V (SHORT PASTE function)or click on the corresponding area
in the Clip Management area.

◦ In 'CLIP' mode: only the available camera locations inside the destinationclip are

copied. If some camera angles already exist for the destination clip, they are not
be overwritten by the corresponding camera in the clipboard.

◦ In 'CAM' mode: the selected camera angle is copied.

6. During a move operation, the original clip is deleted.

Note

A “Cut & Paste” of a clip is equivalent to a “Move Clip”, meaning that any
reference to that clip inside playlists will be updated to the new location of that
clip. This is not the case when doing a “Copy & Paste”, then deletingmanually
the original clip.

54 4. Clip Management

OPERATION MANUAL Nano 11.02

How to Copy a Clip in the VDR Panel Player

To copy a clip from the VDR Panel Player, proceed as follows:

1. Load the original clip

2. Press ALT+S to save the current clip to another location. This creates a copy of the
clip.

3. Save the clip to the current cursorlocation by pressing ENTER, or to the first available
clip locationon the current serverby pressing ALT+U.

4. You can also rename the clip during this operation.

Note

The Cut / Copy / Paste functions are available at any time to move and copy
clips in the lowersection of the VDR Panel, even when one of the upper
windows is active.

4.4.5. Naming a Clip

You can name a clip in the VGA interface.
To name a clip, proceed as follows:

1. In the Clip screen, select the clip to name in one of the following ways:

2. Click on the clip with the stylus

3. Position the green arrows around the desired clip with the keyboard.

4. Type in the desired name with the keyboard. All characters available from the
keyboard are accepted, including blanks.

5. Press F1:
◦ In CAM mode, only the camera where the cursor is located is named.
◦ In CLIP mode, all cameras of the clip where the cursoris located are named.

The entry in the Name field is not cleared by pressing F1 and remains for future use. Press
BACKSPACE to delete the last character in the Name field, or press ESC to clear the
whole field.

4.4.6. Restriping Clips

Limitation of the Remote Panel Interface

The function to restripe the timecodeof a clip via the Remote Panel is restricted as
follows and you should use the VGA interface to changethese parameters:

• You can modify only the primary timecode.

• You cannot modify the date of the clip.

• You cannot modify the type of the primary timecode.

4. Clip Management 55

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

In the Remote Panel Interface

To restripe the timecode of a clip, proceed as follows:

1. Recall the clip by pressing the corresponding F_ key.

2. Move the jog dial to reach the picture whereyou want to define a new timecode.

3. Press the MENU key to access the secondary menu.

4. Press SHIFT+C to call the Set TC function.

5. Enter the new timecode for the current picture.

6. In 59.94Hz modes (NTSC), press SHIFT+MENU to select between 'Drop Frame'
and'Non DropFrame' modes.

7. Press the D key to select 'CAM' or 'CLIP' mode.
◦ In 'CAM' mode, only the timecode of the cameraangle loaded on the primary

channel will be changed.

◦ In 'CLIP' mode, the timecode of all camera angles of the clip will be changed.

8. Press ENTER to confirm or MENU to cancel.

The primary timecode of the entire clip is updated according to the new timecode valueso
that the timecode remains continuous over the whole clip.

Next time this function is called, the value previously used will be set as default.

In the VGAInterface

To restripe the timecode of a clip, proceed as follows:

1. Move the cursor on the desiredclip and press ENTER or click on it with the stylus to
recall it.

2. Press ALT-T on the keyboardto call the SET TC function. The following Set
Timecode screen is displayed:

56 4. Clip Management

OPERATION MANUAL Nano 11.02

3. To modify oneof the following timecodes:
◦ The LTC timecode and date: Type in the new timecode for the Short IN point and

date of the clip in the Set TC field following the LTC field.

◦ The user-defined timecode and date: Type in the new timecodefor the Short IN

point and date of the clip in the Set TC field following the USER field.

◦ The primary TC for this clip: Press the A or B key corresponding to the requested

primary TC.

4. In 59.94Hz modes (NTSC), press the SPACEBAR to select between 'Drop Frame'
and'Non DropFrame' modes.

5. Press F2 to select 'CAM' or 'CLIP' mode.
◦ In 'CAM' mode, only the timecode of the cameraangle loaded on the primary

channel will be changed.

◦ In 'CLIP' mode, the timecode of all camera angles of the clip will be changed.

6. Press ENTER to confirm or ESC to cancel.

The timecode of the entireclip is updated according to the new timecode valueso that the
timecode remains continuous overthe whole clip.

4.4.7. Shortening a Clip

You can shorten a clip using the Remote Panel.
To shorten a clip, proceed as follows:

1. Recall the desired clip by pressing the corresponding F_ key.

2. Move the jog dial to browse the clip and reach to the desired Short IN point.

3. Press the IN key to mark a new Short IN point. This new Short IN point is instantly
saved.

4. Move the jog dial to reach the desired Short OUT point.

5. Press the OUT key to mark a new Short OUT point. This new Short OUT point is
instantly saved.

Move the lever or press the PLAY key to play the clip. The replay will stop at the new
Short OUT point (or after the Short OUT point if the post-roll mode is enabled).

Note

You can use Goto IN and Goto OUT functions to jump immediately onto Short
IN or Short OUT points respectively.

4. Clip Management 57

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

4.4.8. Changing the Primary Camera of a Clip

You can change the primary camera of a clip in the VGA interface.
To change the primary camera of a clip, proceed as follows:

1. In the Clip screen, move the cursor to the desired camera.

2. Press F4 on the keyboard or click with the stylus on the corresponding area in the
Function bar.

◦ This camera becomes the new primary camera.
◦ If the selected camera is a secondary camera (indicatedby “=”), it becomes the

primary camera and the previous primary camera becomes the secondary
camera.

58 4. Clip Management

OPERATION MANUAL Nano 11.02

5. Playlist Management

5.1. Introduction

Playlist Creation

Playlists can be created on the server via the Nano Remote Panel and/or the Multicam
user interface.

Limitation on Playlist and Timeline Elements

• A playlist can include up to 1000 elements.

• Up to 16000 playlist elements can be saved ona server.

• The temporary playlist elements, available for undoand redoactions, are stored on the
server and are purged each time the Multicam application is closed.

Playlist Location

All playlists created are automatically stored on the banks dedicated to playlists and
timelines on the server, i.e. the bank 10 of each page.

Playlists on page 10 arenot available from the EVS Remote Panel. These playlists are
reserved for external protocols (Odetics, Louth VDCP, EVS AVSP).

5. PlaylistManagement 59

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

5.2. Selecting Playlists

Playlist LSM ID

The playlist numbering system is as follows:

In the above example, the

• “5”refers to the clip page number (1 to 10).

• The bank page is not specified as the playlists are always stored on bank 10 of a
page.

• “7”refers to the playlist position (1 to 10) inside bank 10.

Note

The playlist bank of page 10 is not availablefrom the EVS remote, since it is
actually reserved for the EVS AVSP protocol (for Air Box and Air Edit).

How to Recall a Playlist

To recall a playlist, proceed as follows:

1. Select the page where the playlist is storedby pressing the SHIFT+Page key and the
function key correspondingto the given page.

2. Select the bank wherethe playlist is stored by pressing the SHIFT+F10 key
corresponding to the playlist bank.

3. Select the position where the playlist is stored in the bank by pressing the F1 to F9
key corresponding to the playlist position.

60 5. PlaylistManagement

OPERATION MANUAL Nano 11.02

5.3. Playlist Functions on the Remote Panel

5.3.1. Edit and Playout Modes

Introduction

Two modes are availableon the Remote Panel to access and manipulate the playlists:
The Playlist Edit modeand the Playlist Playout mode:

• The Playlist Edit modeis used to modify the playlist.

• The Playlist Playout mode is used to roll the playlist on air.
Editing the playlist in Playlist Playout mode is not possible.

Accessing the Playlist Edit Mode

When you load a playlist pressing the PLST key on the Remote Panel, you directly enter
the Playlist Edit mode. The first frame of the element highlighted in the playlist appears on
the PGM. At the start, full control will beon the PGM side; scrolling through the playlist
can be done here.

Note

From the Playlist Playout mode, you need to press the EDIT function (D button)
or move the jogdial to returnto the Playlist Edit mode from where you can edit
the playlist.

The main menuin the Playlist Edit mode available is the following:

Effect Edit All

Insert Speed FX Dur Delete

A secondary menu is also available when you select MENU from the main menu in the
Playlist Edit mode. All commands are not always available in the secondary menu:

OtherAng Add cut

Replace Redo Undo

In Playlist Edit mode, the duration displayed in the top right corner of the LCD screen is
the playlist total duration, from the beginningto the end.

5. PlaylistManagement 61

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Accessing the Playlist Playout Mode

When you load a playlist pressing the PLST key on the Remote Panel, you need to press
PLST a second time to enter the Playlist Playout mode.

The first frame of the playlist element following the one on the PGM will be displayed on
the PRV side. This allows the operator to play only parts of the playlist, starting from the
current position.

The menu available from the Playlist Playout mode on the Remote Panel display is the
following:

FilmFX NEXT SKIP EDIT

Note

A thirdselection of the PLST button cues the playlist to the beginning,
displayingthe first playlist element on the PGM side and the following clip on the
PRV.

5.3.2. Functions in Playlist Edit Mode

Main Menu Functions

Edit All

If you want to edit all clips of the playlist at the same time, select Edit All (SHIFT+D)
before you perform the requested editingaction with oneof the following playlist
commands: Speed, Effect, FX Dur.

Insert

The Insert function (A key) allows the operator to insert a clip into the playlist. The same
operation can beachieved using the TAKE key.

Speed

The Speed function (B key) allows definingthe speed at which one or all clips of a playlist
will be played. Select the playback speedof the clip with the lever, then press ENTER to
validate. Values are‘Unknown’ and from 0 to 100%.

Operators have access to the secondary lever control like whenclips are replayed. While
editingthe speedof a clip, pressing SHIFT+Lever on the Remote allows to access the
secondary lever speed defined in the menu.

62 5. PlaylistManagement

OPERATION MANUAL Nano 11.02

FX Dur

The FX Dur function (C key) sets the duration of the transition effect. The default value
that initially appears is determined by the value set in the Setup menu. The effect duration
will affect the transition at the beginningof the selected clip. Use the lever to to adjust the
value, then press ENTER to confirm.

Effect

The Effect function (SHIFT+C key) is used to select the type of transition effect
(Mix/Wipe/Cut/Fade). Move the lever to set the type of effect, when Effect is highlighted.
Press ENTER to validate.

Delete

The Delete function allows the operator to quickly edit a playlist by removing the selected
clip. The clip that has been «cut» can thenbe inserted into another location. This clip is
displayed on the second PRV output. To insert it at another position in the playlist, simply
go to that position using the jogdial and press the Insert key (or TAKE).

Secondary Menu Functions

Replace

The Replace function makes it possible to replace a portion of a playlist by the same A/V
material to which effects have beenadded(externally or internally). This consolidates the
effects within the playlist.

Undo/Redo

The last modifications of a playlist can be undone/redone for as long as the operator does
not exit the Playlist mode (e.g.: returning to Live).

Pressing the Undo command (D key) will undo the last modification. Up to 9 modifications
can be undone. Once a modification has been undone, it is possible to redoit by pressing
the Redo key (C key).

OtherAng

The OtherAng (Other Angle)function (SHIFT+C key) allows the operator to replace the
current playlist element by another playlist element showinga different angle of the
recorded material.

When the OtherAng option is selected, Multicam loads the local and network trains that
includethe TC IN of the playlist element to replace. The trains are loaded on the PRV
channel, at the current TC of the loaded element. Thejog is used to shift from one record
train to the other.

Once the requested record train is displayed on the PRV channel, pressing ENTER
replaces the current playlist element by the one created from the selected angle.

5. PlaylistManagement 63

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Add cut

The Add cut function (SHIFT+D key) allows the operator to split an existing clip into two
independent clips at a selected point. Both resulting clips are duplicates of the original one
with additional short-in and short-out points addedat the split point.

5.3.3. Functions in Playlist Playout Mode

Once the playlist is cued and ready to roll, the menubelow is displayed on the Remote
LCD. This menu gives the operatorthe ability to manipulate the playlist while it is playing.
The duration displayed in the top right corner of the LCD screen in Playlist Playout mode
is the remaining durationuntil the end of the playlist.

PL11 LSM 04 Albert LOC LEFT=00:00:02:22

111A Clipname01200:00:29UnkW00:10
112B/03Clipname45600:53:29 UnkM00:10
112B Clipname89100:53:29 UnkM00:10

Film FX Next Skip Edit

Film FX

Selecting this function will create a film style effect during the playout of the playlist by
repeating one field every two fields. Please note that the audio is also affected by this
effect, making it unusable and therefore, muted. This mode is deactivated when exiting a
playlist.

Next

While the playlist is rolling on air, selecting the Next function will start the transition of the
next clip with the transition effect listed onthe playlist. This can be used if a clip is running
too long and it is necessary to shorten up the playing time.

Skip

While the playlist is rolling, the next clip in the sequence is always displayed on the PRV
screen. The Skip function allows the operator to discard clips before they go on-air. The
clip that will be «skipped» is the one displayedon the PRV screen. This function does not
remove the clip from the playlist, but it simply allows it to be skipped during playback.

Edit

Selecting the Edit function gets the user back to the Playlist Edit mode.

64 5. PlaylistManagement

OPERATION MANUAL Nano 11.02

5.4. Playlist Functions on the VGA

5.4.1. VGA Playlist Screen

Introduction

Pressing F10 on the keyboard calls the VGA Playlist screen. The Playlist screen displays
information on the clips included in the current or loaded playlist. Several transport
functions are available from this screen. "Clip Functions on the VGA" on page37 for more
information.

Display Depending on the Load Playlist Setting

When the Load Playlist parameter is set to ‘Conditional’ in the Operational Setup menu on
the Remote Panel (P3.3 F2), the information displayed on the VGA Playlist Screen will
differ depending on whether a playlist is loaded on the PGM1or not:

If a playlist is loaded on the PGM1:

• All the information displayed on the Playlist Screenrefers to the loadedplaylist.

• The PLAY, SKIP, NEXT and RECUE commands are displayed on the blue-

highlighted section at the bottom of the page.

5. PlaylistManagement 65

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

If no playlist is loaded on the PGM1:

• The information displayedon the Playlist screen refers to the current playlist, except

the remaining time, which is not displayed.

• The PLAY, SKIP, NEXT and RECUE commands are NOT displayed on the blue-

highlighted section at the bottom of the page.

5.4.2. VGA Playlist Bank Screen

Pressing END on the keyboard when the Clip screen is displayed allows the users to
access the VGA Playlist Bank screenon the given page. This gives an overview on the
playlists and timelines stored on the bank.

For each playlist the following information is displayed:

Field Description

Playlist ID Unique identifier of the playlist on the server.

Ex: PL16

Playlist Name Name of the playlist. It cannot exceed 12

characters.
Ex: ”game edit

X clips Number of available clips in the playlist

(unavailable network clips are not taken into
account).
Ex: 98 clips

Dur: --:--:--:-- Total playback duration with available clips.

Ex: 00:04:34:12

Aux Clip Aux Clip ID and name of the audio auxiliary clip.

5.4.3. Editing Functions in VGA Playlist Screen

To use the following commands, you must be in Playlist Edit or Playlist Playout mode:

• To enter the Playlist Edit mode, press the PLST key on the EVS Remote. The screen

of the Remote Panel displays the information about the previous, current and next
three clips of the playlist.

• To enter the Playlist Playout mode, press the PLST key again.

66 5. PlaylistManagement

OPERATION MANUAL Nano 11.02

The following operations can be performed from the VGA playlist screen:

Criteria Description

Naming a
playlist or the
current clip

PLAY/pause Press ALT+P to start the playback / pause of the playlist from the

RECUE Press ALT+R to recue to the beginning of the playlist and pause.

NEXT Press ALT+N while the playlist is playing to force immediately the

SKIP Press ALT+S while the playlist is playing to skip the next clip. The

For more information, see section "Naming a Playlist or Playlist
Element" on page 74.

current position.

transition to the next clip in the playlist.

current clip will play until the defined OUT point, thanthe playlist will
skip the next one and play the one after instead.

5.5. Operations on Playlists

5.5.1. Setting and Loading Playlists

Introduction

A distinction is made betweensetting and loading a playlist:

• When you load a playlist, you actually load it on a given playerchannel either to edit it

or to play it out.

• When you set the current playlist, you access the playlist location on the server but

you do not load it on a player channel. Thus you can insert clips directly in the current
playlist without having to load it onto a channel.

Note

At Multicam startup, the current playlist is automatically playlist 11,that is the
playlist 1 on bank 10 of page 1.

5. PlaylistManagement 67

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

How to Set the Current Playlist

In the Remote Panel Interface

To set the current playlist, proceed as follows:

1. Press SHIFT+Page+F_ key to select the page in which the desired playlist is located.

2. Press SHIFT+F10 to select the playlist bank.

3. Press F_ key to select the desired playlist.

4. Press ENTER to confirm.
To load the current playlist, continueas follows:

5. Press PLST to load the current playlist on a player channel (it cannot be empty).
To exit the playlist mode:

6. Press the RECORD key to returnto E2E mode.
Notes:

• If the new playlist is not empty, it is automatically loaded on the PGM (in PGM/PRV

mode) and it becomes the current playlist.

• If the new playlist is empty, the system will ask you whetheryou want to copy the

current playlist at this new location.

Note

Page 1 contains playlists 10 to 19, Page 2 contains playlists 20 to 29, andso on.

In the VGAInterface

To set the current playlist, proceed as follows:

1. From the clip screen, press END to access the playlist bank.

2. Press DOWNARROW to select the playlist that you want to define as the current

playlist.

3. Press ENTER on the selected playlist to set it as the current playlist.

68 5. PlaylistManagement

OPERATION MANUAL Nano 11.02

How to Recall and Load a Playlist

You can only recall and load a playlist if this is not empty.
To load a playlist on a playerchannel, proceed as follows:

1. Access the desired playlist bank by pressing F10 from the requested page.

2. Select the playlist to load with the F1-F10 keys.

The selected playlist becomes current and is displayedon the LCD display.

3. Press PLST key onthe Remote Panel to loadthe current playlist.
If the new playlist is not empty, it is automatically loaded on the PGM (in PGM/PRV

mode) and it becomes the current playlist.
If the new playlist is empty, the system will ask you whetheryou want to copy the current

playlist at this new location.

5.5.2. Rolling a Playlist

How to Roll a Playlist

After recalling a playlist, you will roll the playlist using the pre-defined speed of each clip.
Use the PLAY key to start rolling the playlist.

Playlist Speed

• As soon as the lever is used to start the playback or during playback, the pre-set

speed for the current clip is canceled and set by the lever position only.

• The playlist will return to pre-set speedmode as soon as anotherclip with a pre-set

speed is found.

• If the speed for a Super Motion clip is set to “UNK”, pressing the PLAY key on that

clip will start the playback of the playlist at 33%.

Note

When using the PLAY key to start the playlist, it is recommended to set the
lever at the top position (100%). If the lever is in low position and the operator
touches it by mistake while the playlist is rolling, the playlist could freeze on-air.

5. PlaylistManagement 69

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

5.5.3. Deleting Playlists

Note

Deleting a playlist deletes all the playlist elements from the playlist as well as
the playlist definition in the database.

In the Remote Panel Interface

To delete a playlist, proceed as follows:

1. Press SHIFT+Page+F_ key to select the page in which the playlist to delete is

located.

2. Press SHIFT+F10 to select the playlist bank.

3. Press CLEAR+F_ key to delete the corresponding playlist.

4. According to the value of the Confirm del clp/plst parameter in the Operational

Setup menu(p.5.1 F3), you will be asked or not to confirm the deletion action.

5. The empty playlist location remains available.
To delete all playlists stored on a same bank, proceed as follows:

1. Press SHIFT+Page+F_ key to select the page in which the playlists to delete are

located.

2. Press CLEAR+SHIFT+F10 to delete all playlists stored in the corresponding bank.

The following confirmation message is displayed:

Caution:

This will delete all playlists/
timelines stored on bank 0

[Menu] : Cancel [Enter] : Confirm

3. Press ENTER to confirm the deletion. All playlists andtimelines on the selected bank

will be deleted.

In the VGAInterface

To delete a playlist, proceed as follows:

1. In the Clip window, go to the requested playlist bank by pressing ALT+Down Arrow

in the requested page.

2. Highlight the requested playlist and press CTRL+DEL to delete the playlist entry.

70 5. PlaylistManagement

OPERATION MANUAL Nano 11.02

5.5.4. Copying Playlists

Introduction

From the VGA Clip screen, you can copy or move playlists, through cut, copy and paste
commands, in the same way as you do with clips.

From the Remote Panel, you can only copy playlists.
The copy process is seamless to the user as long or short copies of a playlist are

performed as a background process. If the destination playlist is recalled and the on-air
playlist element has not yet been transferredto the local machine, the on-air element
playedout is the original one. The on-air element will be automatically copied locally when
the playlist will be removedfrom the playout channel.

You can only copy and move playlists locally.

Copy Options

When you copy a playlist, you have different options:

• The EDL copy copies only the playlist definition while the playlist elements remain at

their original location.

• The EDL+Clips copy copies the playlist definition and the playlist elements to the

destination. In this case, you must also choose one of the following:
◦ The short copy that copies only the material included betweenthe IN and OUT

points of the playlist elements with the clip guardbands as defined on the
destination system.

◦ The long copy that copies the complete original clips. This makes a difference

when the playlist elements have been trimmed compared to the original clip.

EDL+Clips copy processes cannot be queued. If the operator tries startinga new copy
process while the previous one is still running, a message will ask him whether he wants
to stop the previous process to start the new one, orcancel his new request.

5. PlaylistManagement 71

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Available Copy Actions

The following table provides an overview on the copy actions available from the Remote
Panel and from the VGA interface. The playlists are copied to an empty playlist position:

Remote Panel VGA Interface

EDL Copy

Yes

EDL+Clips Copy (short or long) No

• To play back a selected clip, with the lever, at a speed varying from 0% to a given

maximum speed, you needto do the following:
◦ Define the requested maximum speed in the PGM Speed/Var max parameter

(p.9.1 F3) in the Operational Setup menu.

◦ Select (highlight) the VarMax option in the secondary menu in PGM/PRV mode.

Yes

In the Remote Panel Interface

To copy a playlist, proceed as follows:

1. Go to the source playlist bank.

2. Select the original playlist to copy by pressing the corresponding F_ key.

3. Go to the destination playlist bank.

4. Select an empty playlist location.

A new menu appears on the LCD display of the Remote Panel, with the corresponding
message on the OSD of the output monitors, asking whetheryou want to copy the
original playlist to the new location or whether you simply want to select a new, empty
playlist (default choice):

Select New Playlist 13 ?

[Menu]: Cancel
[Enter]: Confirm

COPY NEWPLST

5. Press COPY (A key) to select the copy option. The menu becomes:

Copy Playlist 11/03
to Playlist 13 ?

[Menu]: Cancel
[Enter]: Confirm

COPY PLST+CLP NEWPLST

72 5. PlaylistManagement

OPERATION MANUAL Nano 11.02

6. Specify whetherto copy the EDL with or without the clips:

◦ Press ENTER to copy only the EDL without copyingthe elements contained in

the original playlist. The copy is done instantly since there is no material to
transfer.

◦ Press PLST+CLP (B key) to copy the EDL together with the playlist elements.

The display becomes:

Copy Playlist and all net. clips
to Playlist 13 ?

[Menu]: Cancel
[Enter]: Confirm

COPY PLST+CLP SHORT NEWPLST

7. Press the C key to specify whether to perform a SHORT ora LONG copy.

◦ SHORT mode (default): only the section of the elements between the Short IN

andShort OUT as defined in the playlist will be copied, increased by the duration
of the guardbands, as defined on the destination system.

◦ LONG mode: the entire original clips, including their guardbands, will be copied on

the destination system.

8. Press ENTER to confirm the copy or MENU to cancel.
The F_ key of the destination playlist will flash until all clips have been copied. This

playlist can be recalledduringthat process for browsing, editing, orplayback.

In the VGAInterface

To copy a playlist, proceed as follows:

1. Press the END key to open the playlist bank.

2. Select the playlist to copy.

3. Press CTRL+C to copy the playlist or CTRL+X to move it.

4. Go to the empty playlist location on the same server where you want to copy the

playlist.

5. Press CTRL+V to paste the playlist. The EDL of the playlist is copied to the

requested location.

Merging Playlists

From the VGA Interface, it is possible to merge two playlists by copyinga playlist and
pasting it to an existing playlist. The copied playlist will be added at the end of the
destination playlist.

5. PlaylistManagement 73

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

5.5.5. Naming a Playlist or Playlist Element

Introduction

You can name or rename a playlist or one of its elements only from the VGA interface.

Note

When entering a name, use BACKSPACE to delete the last character or ESC
to clear the entire field.

How to Name a Playlist

From the Playlist Bank Window

To name a playlist from the VGA Playlist Bank window, proceed as follows:

1. From the Clip screen, press END to go to the Playlist Bank screenof the requested

page.

2. Use the DOWNARROW to select the playlist to name.

3. Enter the desired nameon the keyboard. It appears in the Name field at the bottom of

the screen.

4. Press F1 to assign the new name to the selected playlist. The playlist name appears

in the title bar next to the playlist number.

From the Playlist Window

To name the current playlist from the VGA Playlist window, proceedas follows:

1. Press F10 to open the VGA Playlist screen. The current playlist is displayed.

2. Enter the desired nameon the keyboard. It appears in the Name field at the bottom of

the screen.

3. Press SHIFT+F1 to assign the new name to the current playlist. The playlist name

appears in the title bar next to the playlist number.

74 5. PlaylistManagement

OPERATION MANUAL Nano 11.02

How to Name a Playlist Element

To name the current element in the loaded playlist from the VGA Playlist window, proceed
as follows:

Note

This function is only available when the playlist is the current one in Playlist Edit
mode (PLST EDIT) orPlaylist Playout mode (PLST DIFF) on the Remote
Panel.

1. Press F10 to open the VGA Playlist screen. The loadedplaylist is displayed and the

current playlist element on the Remote Panel is selected.

2. Enter the desired namefor the element on the keyboard. It appears in the Name field

at the bottom of the screen.

3. Press F1 to assign the new name to the current element. The name for the current

element appears in the Name columnof the selected element.

Note

Naming the current element of the loaded playlist will affect the original clips.

5.5.6. Consolidating a Playlist

Introduction

Using the internal loop, you can recorda playlist back to the server as a big clip if you
want, for example, to record the playlist effects (split screen, target tracking, painting,
etc.) as regular video inside the server.

You can only consolidate a playlist from the Remote Panel.
Depending on the Internal Loop parameter in the Operational Setup menu (p.9.2 F6),

both video and audio can be loopedback into the system, or only the videotrack is looped
andthe system keeps recording the live audio at the same time.

5. PlaylistManagement 75

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

How to Loop Back a Playlist into the Server

To consolidate a playlist using the internal Loop mode, proceed as follows:

1. Add the requested effects to the playlist.

2. Recue the playlist.

3. Activate the Loop mode via the SHIFT+Loop key.

4. Roll the playlist.
The playlist will be recorded onto the disks (Channel 1 – CAM A) as a continuous

video/audio stream.
When you exit the playlist mode, go back to LIVE record andsimply jogback, you will see

the playlist recordedwith all its transitions and at the speed they were played.

5.5.7. Generating a Continuous TC in a Playlist

Introduction

From the VGA interface, you can regenerate a continuous timecodefor the wholeplaylist
or for each clip of a playlist. This can be useful when:

• You do not want to have a playlist with disrupted timecodes from the various playlist

elements.

• You want to change the timecode type in the VITC or LTC timecode.

Settings for Continuous Timecode in Playlists

The following table describes the various parameters that should be defined when
regenerating the timecode in a playlist:

Parameter Description

Continuous in … Specifies whether the TC should be continuous

for the whole playlist or for each playlist element.

From … Specifies the initial TC valueto be used for the

timecode regeneration

Possible
Values

PLST, CLIP

Timecode,
LTC TC, User
TC

In … Specifies the TC type in which the timecode

should be regenerated

76 5. PlaylistManagement

LTC or VITC
in SD
HANC VITC,
HANC LTC,
or both

OPERATION MANUAL Nano 11.02

How to Activate the Continuous Timecode Regeneration

To activate the continuous timecode regeneration, proceed as follows:

1. In the Playlist page (F10), press TAB several times until the ON/OFF field after

‘Regeneration of TC’ is green highlighted.

2. Press the right arrow key to toggle the function to ON.

3. Press TAB again to highlight the 'continuous in PLST' text segment, and, with the

right arrow, select whether the regeneration will be applied on the playlist (PLST) or on
the playlist clips (CLIPS).

4. Press TAB to highlight the 'from 00:00:00:00' segment, and type the start TC to be

used for the regeneration.

5. Press TAB again to highlight on the timecode type, and toggle to the requested

timecode type with the right arrow.

The continuous timecode regenerationfunction is now active. However, the timecodewill
effectively be regeneratedwhen you replay the playlist after activating a loop.

To deactivate the function, press the left arrow on the field to toggle the function to ‘OFF’.

How to Regenerate the Timecode in a Playlist

To regenerate the timecode in a given playlist, proceed as follows:

1. Activate the TC Regeneration and define the related settings on the Playlist page

(F10), in the blue-highlighted area at the bottom of the page. This feature is definedfor
each playlist individually:

2. Activate the internal loop using the SHIFT+Loop keys

3. Roll the playlist.
This will record the playlist back into the recorder channel 1 (CAM A) with the regenerated

timecode.

5.6. Operations on Clips in Playlists

5.6.1. Adding Clips in a Playlist

Introduction

You can add clips to a playlist in different ways, but always from the Remote Panel:

• Adding clips at the end of the current playlist without entering the Playlist Edit mode.

• Inserting clips before or after the clip selected in the loaded playlist.

5. PlaylistManagement 77

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

How to Add Clips at the End of the Current Playlist

You can create a playlist very quickly. The experienced operator can include a clip at the
endof the playlist containing an action that happened seconds before the playlist is played
on air. To add clips quickly at the end of the current playlist, you do not have to enter the
Edit mode.

To add clips to the current playlist, proceedas follows:

1. Activate a playlist as the current playlist.

2. Recall the first clip for your playlist.

3. Press ENTER on the Remote Panel.
The clip is added at the end of the current playlist.

4. Repeat as many times as necessary until the last clip is entered.

How to Insert Clips into a Playlist

The following rules apply to the procedure below:

• You need to be in PGM/PRV modeto be able to use the TAKE key on the Remote

Panel to insert a clip.

• Depending on what is selected for the Insert in playlist parameter in the Operational

Setup menu(p.3.1 F6), the clip will be inserted beforeor after this selected position.

To insert a clip into a playlist, proceedas follows:

1. Using the Playlist Edit mode or the Browse mode, scroll to the location where the clip

must be inserted.

2. Call the selected clip. It appears on the PRV output.

3. Do one of the following to insert the selected clip in the playlist, at the position shown

on the PGM output:
◦ Press the A key (Insert function) on the Remote Panel
◦ Press the TAKE key on the Remote Panel

◦ Press the SHIFT+INSERT keys on the Remote Panel
A confirmation message will appearif that option has been enabled in the Setup menu.
After the clip has been inserted, you can press PLST to returnto the playlist at the current

position.

78 5. PlaylistManagement

OPERATION MANUAL Nano 11.02

Inserting Growing Clips into Playlists

Growing clips can be inserted in playlists in the same way as other clips. However, their
display has the following characteristics:

Display:

• They will be displayed with the ‘Creating’ messagein the playlist on the VGA.

• The growing clips ID will be blinkingon the mini playlist display and on the playlist

screen on the Remote Panel, as well as on the OSD.
Remaining time:

• The remaining time in playlists containing growing clips with only an IN point is

displayed as --:--:-- on the screens (OSD, VGA, Remote Panel screen) wherethis

information is shown.

5.6.2. Deleting and Moving Playlist Elements

Introduction

Just as you can add clips into a playlist only with the Remote Panel, deleting clips from a
playlist or moving clips within a playlist arealso performed via the Remote Panel.

How to Delete an Element from a Playlist

To delete a playlist element in a playlist, proceedas follows:

1. While you are in Playlist Edit mode, scroll within the playlist to the element that needs

to be deleted.

If the Browse mode is active, the first frame will appear on the display as each clip is

scrolled through.

2. Select Delete from the Playlist Edit menu.
The selected element will be removed from the playlist. A confirmation message will

appear if the Confirm Ins/Del clips parameter has been enabled in the Operational Setup
menu (p.3.2 F1).

5. PlaylistManagement 79

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

How to Move an Element within a Playlist

Note

You can only move elements within a playlist if you are in PGM/PRV mode.

To move a playlist element within a playlist using the Remote Panel, proceed as follows:

1. While you are in Playlist Edit mode, scroll within the playlist to the clip that needs to

be moved.

2. Select Delete from the Playlist Edit menu. The clip is sent to the clipboard and loaded

on the PRV channel.

3. Scroll to the location in the playlist where you want to insert the clip.
Remember that the position where the clip is inserted will depend on the valueof the

Insert in playlist parameter in the Operational Setup menu (p3.1 F6), that is to say before
or after the selected playlist element.

4. Press TAKE or Insert on the Remote Panel to insert the clip from the clipboard at the

requested location.
The playlist element is inserted at the requested location.
If the playlist element has been trimmed before being moved, the element will be

reinsertedin the new position with the new guardbands.

5.6.3. Browsing Within a Playlist

Introduction

You can browse within a playlist in different ways in the Remote Panel:

• Browse through the content of each clip in the playlist.

• Browse quickly by jumping to the first field of each clip in the playlist.

Browsing Through a Playlist

When you load a playlist, the default playlist mode allows you to scroll up and down
through all the playlist elements.

80 5. PlaylistManagement

OPERATION MANUAL Nano 11.02

Browsing Quickly Through a Playlist

When you are neither in Playlist nor in Clip mode, press the Browse key on the Remote
Panel to enter the current playlist in Browse mode.

In this mode, you can quickly jump to the first field of each clip inside the playlist by
moving the jog dial. To return to the normal Playlist Edit mode, press the Browse key
again.

When you are in Playlist Edit mode, you can of course also activate the Browse mode by
pressing the Browse key.

PL11 LSM01 Paola LOC TDUR=00:00:02:22

111A/04Clipname01200:00:29Unk W00:10
112B Clipname45600:53:29 Unk W00:10
112B/02 Clipname89100:53:29 Unk W00:10

Insert Speed FX Dur Delete

Effect Edit All

5.6.4. Changing the Camera Angle of a Playlist Element

From the Remote Panel, you can change the camera angle of a playlist element if the
material is still available in a local or distant record train.

To change the camera angle of a playlist element, proceed as follows:

1. When you are in Playlist Edit mode, scroll within the playlist to the playlist element.

2. Press MENU to access the secondary menu:

OtherAng

Replace

3. Press SHIFT+C to search and load the local and distant record trains that include the

same TC IN as the playlist element.

The first record train is loaded on the PRV channel, at the current TC of the loaded
element.

4. Press Browse and use the jog to move within one record trainto browse its content.

5. Once you have loaded the requested camera angle on the PRV channel, press

ENTER.

This will replace the current playlist element by a new clip having the same TC IN and TC
OUT. The new clip is stored on the playlist receive page.

The effects, the split audio and the swap points defined on the initial playlist element are
preserved.

5. PlaylistManagement 81

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

5.6.5. Adding Cuts in Playlist Elements

Description

The Add Cut command is only availablefrom the Remote Panel. This command
duplicates a playlist or timeline element (clip, record train...) and adjusts the SHORT IN
andSHORT OUT points of these new duplicated elements:

• On both these elements, the guardbands and other effects are kept unchanged as in

the original one.

• In the first duplicatedelement, the SHORT IN point is left unchanged while the

SHORT OUT point is adjusted to the cut point.

• In the second duplicated element, the SHORT OUT point is left unchanged while the

SHORT INpoint is adjusted to the cut point as illustrated hereunder.

Multicam Behavior

When adding a cut to a clip, Multicam will behave as follows:

• The transition appliedat the cut point is a cut (for both audio and video).

• The speed of the cut elements is the same as the original element, even if it is

“Unknown”.

• The stop and start modes of the cut elements are auto.

• Any loop definedon the playlist that includes the original element conserves and

includes the cut elements.

• Any tag defined and active on the original element at the cut point is recreated at the

short-in of the second cut element.

82 5. PlaylistManagement

OPERATION MANUAL Nano 11.02

The adding cut is not possible in the following cases:

• Within a video effect.

• Within anaudio effect beginning or finishingthe original element.

5.6.6. Trimming Clips into a Playlist

Introduction

Every playlist element can be trimmed independently of all other instances of the same
clip number. Trim actions are only available in the Remote Panel.

How to Trim Clips in a Playlist

To trim clips in a playlist, proceedas follows:

1. Browse to the desired element in the playlist.

2. Re-mark a new Short IN or Short OUT.

If the clip duration is too short, clear the IN or OUT point by selecting CLEAR and
then set the new IN or OUT point at the desired position.

Note

Clearing restores the existing IN or OUT point to the end of the guardbands of
the clip.

5.6.7. Sorting the Playlist Elements by TC IN

Introduction

From the VGA Interface, it is possible to sort (reorder)the playlist elements by TC IN. The
sort is done on the TC displayed in the TC IN column, whatever the type of TC displayed
(User TC or LTC).

Note

This operation will change the order of the playlist elements, and reset the
transitions to the default transitions defined on the Remote Panel.

5. PlaylistManagement 83

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

How to Sort Playlist Elements by TC IN

To reorder the playlists elements by TC IN in a playlist, proceed as follows:

1. Open the playlist in the VGA Playlist screen.

2. Press the TAB key until you highlight the Sort by TC IN field in the Playlist

management area at the bottom of the screen.

3. Press ENTER to validate.

4. Press ENTER again to confirm the operation.
The playlist elements are reordered by TC IN.
You can undo the operation using the Undo command available in Playlist Edit mode on

the Remote Panel.

5.7. Transition and Audio Operations

5.7.1. Overview on Transition Effects

Introduction

You can apply effects on the audio and video transitions of a clip in a playlist. For each
transition, you define the effect type and duration. You can only apply transition effects
using the Remote Panel.

The following drawings show that the transition effects are applied on the material
included in the playlist element, not on the guardbands:

Normal Playlist with Cuts Illustration

84 5. PlaylistManagement

OPERATION MANUAL Nano 11.02

Playlist with 1:00 sec Effect Duration Illustration

In an LSM playlist, the video andaudio effects end at the OUT point of a clip, so the
duration of clips is shortened by the length of the effect.

Available Video Transition Effects

The following video transition effects can bedefined. By default, the audio transition is
always a mix when the split audio mode is disabled.

Effect Type Description

Cut No transition effect is applied between both elements.

Mix Dissolve effect between both elements.

Wipe The last frame of the previous element is gradually replaced

by the first frames of the next element.
The wipe effect is shown as a vertical linemoving across the
video. The direction of the wipe effect (left to right, right to
left) is defined in the Wipe type parameterin the Operational
Setup menu(p.3.1 F4).

Fade from color (<) A fade out effect from a defined color is applied on the first

frame of the clip (on which the effect is defined). The
previous clip ends in cut mode.
In the drawing below, the previous clip is displayed in red, the
next clip is green, and the fade in black:

5. PlaylistManagement 85

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Effect Type Description

Fade to color (>) A fadein effect to a defined color is applied on the previous

clip upto the transition in cut mode to the next clip (on which
the effect is defined).
In the drawing below, the previous clip is displayed in red, the
next clip is green, and the fade in black:

Fade to/from color (V
fade)

Note

The color of the fade effects is definedwith the Fadeto/from color parameter in
the Playlist settings of the Operational Setup menu (p.3.3 F1).

A fadein effect to a defined color is applied on the previous
clip upto its OUT point and a fade out effect from the same
color is applied on the next clip (on which the effect is
defined) from its IN point. The effect durationmust be a
multiple of 2 frames.
In the drawing below, the previous clip is displayed in red, the
next clip is green, and the fade in black:

Associations of Audio and Video Transition Types

The following table shows the possible associations of audio andvideo transition effects
when the Audio effect duration parameteris not locked to the video in the Operational
Setup menu(p.3.1. F3):

Audio Effect Cut Mix

Video Effect

Cut √ √

Mix √

Wipe Left ->
Right

Wipe Right ->
Left

Fade from color √

Fade to color √

V Fade (to/from
Black)

86 5. PlaylistManagement

√

√

Fade from

Mute

Fade to

Mute

V Fade

to/from

Mute

√

OPERATION MANUAL Nano 11.02

Default Values

Default Duration for Video and Audio Transition

It is possible to set a default value for the duration of the video and audio transitions in the
Setup Menu. Once this is defined, each time a clip is entered or inserted into a playlist,
transitions areappliedwith the default values.

The Video effect durationparameter is available in the Operational Setup menu (p.3.1 F1),
andranges up to 20:00 secs.

The Audio effect durationparameter is available in the Operational Setup menu (p.3.1 F3).
When the split audio is disabled, the value for this setting is ‘Lock to video’, and the Audio
effect duration is the same as the Video effect duration.

Default Transition Effect

A default mix transition effect (audio and video) is applied to each new clip inserted into
the playlist. However, you can change the type of transition effect in the main menu of the
Playlist Edit mode.

5.7.2. Adding Transition Effects in a Playlist

Transition Effects Commands

The functions related to transition effects areavailable from the main menu of the Playlist
Edit mode, and the effects applied are also displayed on the Remote Panel display:

5. PlaylistManagement 87

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

How to Add a Transition Effect

You can add transitions on one or all elements of a playlist as follows, or more precisely
modify the default effect applied (mix):

1. Select the playlist location and press PLST to open it in Playlist Edit mode. The main

menu appears:

Effect Edit All

Insert Speed FX Dur Delete

2. Browse to the playlist element at the beginningof which you want to modify the effect

or press Edit All (SHIFT+D) to modify the effect on all playlist elements.

3. To modify the effect, press Effect (SHIFT+C) and move the lever until the requested

effect is displayedon the LCD display.
The effect type is displayed as a letter/symbol in the information corresponding to the

loaded element (see highlighted letter):

111A/04 Clipname012 00:00:29 Unk W00:10

The following effect types areavailable:

Command Description

C Cut

M Mix

W Wipe

> Fade to color

< Fade from color

V Fade to/from color

4. To modify the default duration for the transition effect, press FX Dur (C) and move the

lever until the requested duration is displayed in the last field of the corresponding
element:

111A/04 Clipname012 00:00:29 Unk W00:20

5. Press ENTER to validate the modifications in effect type and/orduration.

88 5. PlaylistManagement

OPERATION MANUAL Nano 11.02

5.7.3. Using the Replace Function

Introduction

The purpose of the Replace function is to consolidate the effects defined on a playlist as
follows:

The operator loops a section or an entire playlist back to themselves and, duringthe
playback, add some effects externally (graphic insertion for instance) or internally
(changing the speed).

While the operator plays the playlist back, and inserts the requested effects, the playback
result is re-injected into the playlist from a predefined IN frame. The OUT point of the
replaced section is predefinedor manually defined in the record process.

The Replace function is only available on the Remote Panel.

Note

The Replace function is not allowed on playlists containing growing clips.

Accessing the Replace Function

Press MENU in Playlist Edit mode to open the secondary menu with the Replace
function. Select Replace in this menu to access the Replace function :

Clr Unav OtherAng
Replace Redo Undo

Replace Edit Mode

This mode allows to specify the following information for the Replace:

• IN point and OUT point, for the section to replace in the playlist. The OUT point can

also be defined during the Replace itself.

• Loop mode parameters.
In the Replace Edit mode, the playlist is considered as one entity on which you can mark

oneIN point and one OUT point (pressing the IN and OUT points does not retrim the
current playlist clip).

Those IN andOUT points will be used to determine what portion of the playlist will be
replaced.

5. PlaylistManagement 89

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

Replace Playback Mode

In this mode, you play the playlist back and insert the new section between the defined IN
andOUT points.

After you have selected the required settings for the Replace function, the Replace
Playback mode is automatically activated: the playlist is cuedbefore the IN point (to
create guardbands), ready to be initiated.

The playlist is played at the speed defined in the playlist but the lever can also be used to
vary the playback speed.

When the Protect OUT point of the clip is reached, a clip containing the IN and OUT
points with the guardbands is created on the Receive page defined in the Setup menu.
The loopis stopped and the user switches back to match Frame Edit mode.

Methods

You can perform a Replace action in two ways:

• By defining an IN and OUT points in the Replace Edit mode.

• By defining only anIN point in the Replace Edit mode, and defining the OUT point

while you perform the Replace in the Replace Playback mode.

Warning

The IN and OUT points cannot bemarked on a transition (including split audio
transitions andswap zones) or on a split zone (the key will flash red whenit is
the case).

How to Perform a Replace

First define the Replace function in the Replace Edit mode. Then execute the Replace
function in the Replace Playback mode.

To perform a Replace, proceedas follows:

1. Open the playlist in which you want to replace a section in Playlist Edit mode.

2. In Playlist Edit mode, press Menu on the Remote Panel to access the secondary

menu.

3. Press the A key to enter the Replace Edit mode.

4. Use the jogdial to reach the desired IN point for the Replace section and press the IN

key to mark it.
When the IN point has been marked, the display switches to:

Cam A +2fields

Replace Int.Loop Ext.Loop

5. If you want to specify the OUT point for the Replace section at this stage, jog to the

requested point and press the OUT key. Otherwise, you can define the OUT point
while you perform the Replace.

The Int.Loop (B) and Ext.Loop (C) keys areblinking.

90 5. PlaylistManagement

OPERATION MANUAL Nano 11.02

6. If you want to specify the OUT point for the Replace section at this stage, jog to the

requested point and press the OUT key. Otherwise, you can define the OUT point
while you perform the Replace.

7. Press the B or C key to select whether you will use the internal loop or external loop to

perform the Replace.
◦ The playlist is cued before the IN point (to create guardbands), ready to be

initiated.

◦ A message appears on Remote: “Start Replace: lever or play

button”.

8. Push the lever or pressthe Play key on the Remote Panel to shift to the Replace

Playback mode and start the Replace process.

9. If you have not defined the OUT point for the Replace in step 5, press the OUT key

when you reach the desired OUT point.
While the Replace is being performed, the following messages are displayed on the

OSD:

“Replace in Progress”

“Clipping guardbands”

“Replace by clip xxx”

On the Remote Panel, a confirmation message pops up:

Replace in/out by clip xxx ?

MENU: Cancel – ENTER: OK

10. Press ENTER on the Remote Panel to validate the Replace:

◦ The material between the IN and OUT points is replaced with the newly created

clip.
◦ The playlist returns to Playlist Edit mode, positioned at the end of the inserted clip.
◦ Press the MENU key on the Remote Panel to cancel the Replace.

Loop Mode in the Replace Function

When the IN point has been marked, the display switches to:

Cam A +2fields

Replace Int.Loop Ext.Loop

• The Int.Loop and Ext.Loop keys are blinking.

• Beforeentering the Replace Playback mode, choose between Internal Loop or
External Loop.

• The Internal Loop is the same loop as the existing loop process.

5. PlaylistManagement 91

EVS Broadcast Equipment S.A. Issue 11.02.A July2013

• The External Loop allows you to select onwhich channel you will physically re-record
the output of yourPGM. The link is physical: it is necessary to make the video link
manually with a router or video/audio cables; it is not done inside the server.

Additional parameters are available for the external loop:

• With the Cam A function (SHIFT+C), you can select the camerathe PGM will be
recorded to for the external LOOP process. Press SHIFT+C until the desired camera
is selected.

• With the +2fields function (SHIFT+D), you can select by how much the video coming
back to yourrecord channel will be delayed. If you are using a DVE, it could introduce
a delay. This system is based on the assumptionthat audioand video are in sync
when they hit the record channel. The delay value cannot benegative.

Select SHIFT+D to highlight the delay value; the display allows you to add frames or
fields of delay to the delay value. Press either MENU or SHIFT+D to leave this mode.

5.7.4. Adding an Auxiliary Audio Clip

Introduction

This option allows adding a new stereoaudio track (e.g. sport comments, music, jingles,
ambient sound) to the original video clips. This is only available from the Remote Panel.

This stereoaudio track is available on the PVW output and on analogue outputs 7/8 or on
digital outputs 15/16. Theselection of the track output is done with the Audio slow motion
parameter in the Operational Setup menu (p.8.1 F1).

The original audio tracks are still availableon outputs 1/2 (3/4). Theauxiliary audio clip
selected is always played back with normal speed (100%), whateverthe selected
playback speedfor the video.

When the playback of the playlist is not started from the beginning, the system calculates
the offset between the current position and the beginningof the playlist, andapplies the
same offset to the Aux. Clip, so that it can remain synchronizedwith the playlist.

If the duration of the Aux Clip is longer than the playlist duration, the auxiliary audio clip
keeps playing even after the videohas stopped. Otherwise, the audio clip ends itself
before the end of the playlist, whenthe audio clip reaches its OUT point.

92 5. PlaylistManagement
