CueSpider / CueSpider Lite OutstationETC

CueSystem Series

GENERAL INFORMATION

CueSystem is a highly flexible cue light system using dedicated
hardware and software along with standard Ethernet protocols
to control a network of outstations. This highly-customizable
backstage communication network provides an immediate visual
communication system complete with advanced features such as text
based cue information and outstation acknowledgement providing
peace of mind in show critical applications.

Each outstation is equipped with an information screen and two
signal lights. When the red “standby” light is illuminated, it can
double as a feedback button, allowing operators to confirm that
they are in place and ready. For more complex shows, a dedicated
PC software application provides familiar cue recording and playback
funcionality that can be uploaded to a dedicated rack-mount or
desktop playback unit. Prefer a hands-on approach? CueSpiders can
also be operated manually or on the fly via the desktop or rack­mount desks, available in 4-, 8- and 12-way configurations.

For applications where daisy-chaining of outstations is not required,
CueSpider Lite provides all features of CueSpider but without the
EtherCON output.

APPLICATIONS

• Professional theatre

• Touring productions

• School auditoriums/theatre

• Community theatre

• Houses of worship

• TV studio

FEATURES

• Rugged metal enclosure with multiple mounting points

• Standard Power over Ethernet (PoE) connectivity

• CueSpider is a class 3 PoE device allowing up to six units to
be daisy-chained when used with a PoE+ switch (three units
maximum with standard PoE switch)*

• Convection cooled product for silent auditorium use

• Red standby LED doubles as acknowledge button to provide
feedback to stage manager that user is ready

• 3-line OLED display providing outstation name, current and
next cue active text information from controller

• Seamless, real-time synchronization with PC application for
additional live monitoring, patching and recording/playback
of cues

* Feature not available on CueSpider Lite

ORDERING INFORMATION

CueSpider Outstation

MODEL DESCRIPTION

CSNOSS CueSpider Outstation

CSNOSSL CueSpider Lite Outstation

The CueSystem PC Application is downloadable free of charge from
the ETC website. Visit etcconnect.com/cuesystem to download the
installer.

REGULATORY AND COMPLIANCE

REGULATORY AND COMPLIANCE

• cETLus Listed

• Conforms to UL STD. 62368-1

• Certified to CSA STD. C22.2 #62368-1

• CE Compliant

1 of 4

CUESYSTEM SYSTEM DIAGRAM

CueSpider / CueSpider Lite OutstationETC

CueSystem Series

CueSystem Desk

Laptop

CueSystem

Playback Unit

Ethernet

connectivity

CueSpider Outstations
