Esotec Adria, Garda Operating Manual

Instruction manual

G

B

Solar pump set
„Garda“ and „Adria“.

hese instructions relate ONLY to this product and contain important informa-

T

ion for using the product for the first time. Please keep these instructions for

t

ater reference and should always accompany the product in the event of trans-

l
ference to a new user.

1. Introduction

ear Costumer, thank you for purchasing the solar pump kit.

D
With this solar pump kit you purchased a product manufactured according to the cur-

ent state of technology.

r

his product fulfils all requirements of the valid European and national regula-

T

ions. The conformity was proved. The relevant declarations and documentati-

t
on are deposited with the manufacturer.

o maintain this state and guarantee a safe operation, you as the user will have to fol-

T

ow this operating manual!

l

2. Safety Instructions

In case of damages caused by not following

­his operating manual, the warranty rights

t
will expire! We exclude liability for any
consequential damages!

We exclude liability for property or

!

ue to safety and admission reasons (CE) it is not allowed to arbitrarily reconstruct

D
and/or change the solar pump kit.

herefore, please keep to the operating manual.

T
The accident prevention rules of the association of the industrial trade cooperative
association for electric plants and working material are to be considered in industrial
environments.

3. Appropriate Use

- The pumping system is designed for the outdoor use in garden ponds.

- Direct solar radiation is required for the correct function.

- The pumping system is characterized by its easy assembly. Tools are not requi­red for the assembly.

- The pump must not be used for the raising of drinking water.

- In order to safely interrupt the pumping it is required to interrupt the cable connec­tion between solar module and pump.

4. Assembly and Initiation

The pumping system consists of the following parts:

1 piece 25 Wp solar module (Adria set 2 pcs.), 1 piece water pump in the plastic hou­sing with a 5 m connecting cable.

1. Completely unroll the connecting cable on the pump.

2. Put the pump in the pond on some stones. Avoid a location directly on the ground
of the pond because a lot of dirt is here sucked in by the pump which will then be
polluted very fast.

3. Now connect the plug of the pump with the socket of the solar module and screw
the cap.

Position the solar module in a sunny, shadow-free place facing south.

Note: The plug is reverse-protected. Do not apply force when inserting the plug. The
glass of the solar modules is sensitive to breakage.

Attention: Risk of injury! A broken module may not be repaired and has to be dispo­sed of environmentally sound.

Note: For further assembly instructions, please see the instruction of the water pump.

­ersonal damages caused by inappropriate

p
handling or not following the safety instructions.

- In these cases any guarantee rights will expire.

5. Service and Maintenance

In order to preserve the performance of the pump, it is required to wash out the pump
and its parts with warm water depending on the pollution of the water.

or directions for the service and maintenance of the pump storage, please see the

F
instruction of the pump storage.

Occasionally wipe the solar module clean with a soft and slightly moistened cloth.

Note: Before carrying out operations on the pump, interrupt the plug connection bet­ween pump and solar module in order to avoid any unintentional starting during the

perations.

o

6. Technical Data

Solar pumping system Garda Adria

System voltage: 18 VDC 18 VDC

-

Solar module

- Nominal power: 25 Wp 2 x 25 Wp
Nominal voltage: 17,28 V 17,28 V

­ Nominal current: 1,45 A 1,45 A

-

- Open-circuit voltage: 20,8 V 20,8 V

- Short-circuit current: 1,71 A 1,71 A

- Projection system: IP 65 IP 65
Temperature range: -30°C to +75°C -30°C to +75°C

-

- Dimensions: 620x354x25 mm 620x354x25 mm

ater pump:

W

Operating voltage: 12 bis 18 V DC 12 bis 18 V DC

­ Max. delivery height: ap. 2 m ap. 3 m

-

- Max. delivery rate: ap. 2480 l/h ap. 3400 l/h
Protection system: IP 68 IP 68

­ Temperature range: +4 to +40°C +4 to +40°C

-

Manufacturer item no: 101762 101766

ccessories for pump systems with esotec item no.:

A

5 m extender cable: 101736 101736

attery box: 12 Ah: 101720 24 Ah: 101729

B

25 W solar module
with Y-connector cable: 130059 130059

Note: Protect the pump from frost!

In cold winter months, it is required to take the pump out of the water and store it in
a warm place. The solar module may be left outside during the winter.

Accessories accumulator storage:

Accumulator storages in different sizes are available for those pumping systems. Just
ask your dealer!

24 Ah: 101729

7. Safety Instructions:

DANGER for children! Keep children away from swallowable small parts (ascending

pipe and sprinklers) and the packaging material. Danger of suffocation!

WARNING: risk of stumbling! Lay the connecting cable so that it will not become a
trip hazard!

CAUTION Material damage! When setting up the solar module without module brak­ket, please pay attention to an adequate stability. The solar module may be damaged
in case of tipping or in case of an impact of a foreign object.

Disposal instruction for electric appliances:

Dear customer, if you want to get rid of the article, please dispo­se it according to the current regulations. The municipal authori-

ty will provide you with information.

Manufacturer, spare parts, service:

esotec GmbH

Gewerbegebiet Weberschlag 9
D-92729 Weiherhammer
Tel.-Nr: [phone]
Fax.-Nr: [phone]
e-mail:[e-mail]
Internet: www.esotec.de

Copyright esotec GmbH
