Epson F2100 User Manual

Epson® SureColor® F2100 Series

2 Remove all the packaging materials and tape. Check carefully for all the

tape inside and outside the printer and platen.

Start Here

WARNING: The printer weighs about 185 pounds (84 kilograms) and

Read these instructions before using your product.

requires three people to lift and move it. Make sure to grip the printer where
indicated by the gray stickers as shown in the illustration. When moving the
printer, do not tilt it more than 10 degrees.

Choose a Location for the Printer

Choose a location for the printer that is near a wall outlet where the plug can
be easily unplugged. Avoid places subject to rapid changes in temperature and
humidity. Also keep the printer away from direct sunlight, strong light, or heat
sources.

Make sure to place the printer on a flat, stable surface with enough space on
all sides (see illustrations below). The surface supporting the printer should
be wider than the space between the rubber feet on the bottom of the printer,
at least 2 feet (60 cm) off the ground, and capable of supporting at least 220
pounds (100 kg).

23 in.

(58.5 cm)

28 in.

(71.1 cm)

5.90 in.
(15 cm)

47.24 in.
(120 cm)

19.68 in.
(50 cm)

1.26 in.

(3.2 cm)

2.55 in.

(6.5 cm)

29.53 in.
(75 cm)

23.62–31.50 in.
(60–80 cm)

2.95 in.

(7.5 cm)

78.74 in.
(200 cm)

Stickers

3 Remove the carriage lock and store it in a safe place.

Note: Do not throw the carriage lock away; you will need it if you transport

the printer.

4 Open the printer cover and press down on the parts as shown to make

sure they are secure. Then close the printer cover.

Unpack

1 Make sure you have these items:

Printer

Medium platen

and hoop

Ink/cleaning

cartridges

Maintenance kit

Tweezers

Platen hoop

hooks

Waste ink bottle

Waste ink

bottle holder

Grip pad

Waste ink tube

Caution

label

Assemble the Printer

1 Remove the plugs from the waste ink outlets on the back of the printer

and store them in a safe place.

Note: Do not throw the plugs away; you will need them if you transport the

printer.

2 Connect the waste ink tube. Make sure that the longer end of the tube

is connected to the waste ink outlet on the left side and the shorter end
is connected to the waste ink outlet on the right side.

Ink charging unit

Note: See the online User’s Guide for information on installing the grip

pad, using the grip pad tool, installing the platen hoop hooks, and using the
maintenance kit and tweezers.

Grip pad tool

Power cord

Limited

warranty

Tube/cable clamps

Note: Make sure the tubes point downward and are not twisted to ensure

proper ink drainage.

3 Attach two tube clamps to the left and right sides on the back of the

printer and route the waste ink tube through the clamps as shown.

4 Remove the outer and inner caps from the waste ink bottle and store

them in a safe place.

Note: Do not throw the caps away; you will need them when disposing of the

waste ink.

5 Place the caution label for your language over the English label, if

necessary. Then, insert the waste ink bottle into the waste ink bottle
holder. The bottle and holder should be placed in an area lower than the
printer so that the waste ink can flow straight down.

Install Ink Cartridges

1 Remove the ink cartridges from their

packages. Gently shake each ink cartridge
for about 15 seconds; white ink cartridges need to be shaken on both
sides. You do not need to shake the cleaning cartridge.

Color ink cartridges White ink cartridges

Caution: Do not touch the green chip on top of the cartridge.

2 Open the ink covers and install each cartridge into the correct slot for its

color.

6 Insert the waste ink tube into the waste ink bottle. The tube should

curve toward the bottle and straight down as shown.

Left ink bay

Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 Slot 7

WH WH Y M C BK CL*

Right ink bay

*Cleaning cartridge

3 Close the ink covers.

4 Press the button on the control panel.
5 Follow the prompts to select Language, Date & Time, and unit of

measurement.

Make sure that the tube sits above the yellow line indicated on the
outside of the bottle. If the tube is too long, cut the end to the
appropriate length.

7 Connect the power cord. (Do not connect the printer to your

computer yet.)

6 Select White Ink/Color Ink and press the OK button.
7 Select Yes and press the OK button.
8 Press the OK button at each of the confirmation prompts.
9 Open the printer cover. Remove the ink charging cover and set it aside.

Press the OK button.
