CD5220
Liquid Crystal
Customer Display
Users manual
CD5220 customer display
INDEX
1. FEATURES 2
2. TYPE CLASSIFICATION 3
3. GENERAL SPECIFICATION 4
4. INTERFACE SPECIFICATION 6
5. FUNCTION SELECTION 12
6. COMMAND 14
7. INSTALLATION GUIDE 23
CD5220 customer display
1. FEATURES
Data can be displayed on 15 columns x3 lines.
n
Blue-green fluorescent color and large character are easy to read.
n
The display panel is adjustable to provide the best view angle.
n
Provide 2 pole for bast position installation.
n
The DIP switch setting emulate commands mode
n
CD5220/UTC/AEDEX/ADM787/ADM788/EscPOS/DSP-800
n
emulation command set, selected by DIP switch or control utility
software.
User-defined characters can be downloaded. (for
n
CD5220/DSP-860/EPSON command mode)
A code-generated software is provided for customer, and download his
n
own character to the display (and save to EEPROM,EEPROM is
option).
International character set is selectable.
n
User-defined message can be downloaded to display. (DSP-800 only)
n
Display area can be controlled by window function. (EPSON only)
n
Provides an interface based on RS-232C or centronics ,And RS232C
n
baud rate 4800,9600 BPS select by DIP switch , (or setting by
software from 300 to 19200bps, EEPROM option)
Both printer and display can be connected to the same port .
n
CD5220 customer display
T
2. TYPE CLASSIFICATION
CD5220 -
I II III IV V VI
No Type name Type name Description
I Mode No. CD5220 CD5220 display
CD6220 CD6220 display
II Interface S Serial port(RS232c)
P Parallel port(Centronics)
III Base section
C Circular base
IV Power input
12 DC12V
24 DC24V
V Power N no adapter
adaptor 110 AC110V adapter
EU AC230V adapter with EU power core
UK AC230V adapter with EU power core
S
12 N PT
T Rectangle base
05 DC5V
B power bracket for PC
IV Pass through
function Without pass through function
PT With pass through function
CD5220 customer display
3. GENERAL SPECIFICATIONS
NO
1 Display method Vacuum fluorescent display
2 Number of
3 Display color blue green
4 Brightness 700 cd/m2 850 cd/m2
5 Character type 96 alphanumeric
6 Character font 5 x 7 dot matrix
7 Character size 9.2mm x 6.4mm 11.2mm x 6.4mm
8 Character pitch 8.3mm 9.9mm
9 Power supply 5VDC/12VDC/24VDC
10 Power consumption 5W/4.5W/4.5W
11 MTBF-power on
ITEM CD5220 CD6220
40 characters ( 20 columns x 2 lines)
character
13 kinds of international character set
1 kind of user define character
25000 hours 25000 hours
time
12 Dimensions panel 226/Wx92/Hx50/D
support
base rectangle base 、 217.5(w)x82(h)x106(d)mm
mm
231 mm,90 mm,231+90 mm
circular base 、 50(h)x70(r)mm
260/Wx100/Hx64/D mm
CD5220 customer display
NO
13 Viewing angle 8 - 35 degrees -5 ~ 35 degrees
14 Rotation angle Maximum 270 degrees
15 Weight 0.92 Kg 1.08 Kg
16 Environmental
17 Applicable
ITEM CD5220 CD6220
temperature Humidity
Condition
standards
Operating : 5 - 45 C -10 - 55 C
Storage 30%-85% 30%-85%
Table 3-1
FCC class A ” CE
CD5220 customer display
(b) Serial port (RS232C) communication flow
4. INTERFACE SPECIFICATIONS
4.1 Communication
4.1.1 Serial port (RS232C) communication
(a) The interface specification are based on EIA RS232C baud rate 9600 or
4800 bps ( select by DIP switch, refer Table 4-7) 8 data bits, none parity, 1
or more stop bits
1. Data flow : PC/host to display, display to printer, printer to
PC/host
2. Control flow : display to PC/host, printer to display, PC/host to
printer
(c) CD5220/CD6220 will inactive DTR or RTS signal to PC/host, the
following two condition.
1. Printer inactive DTR or RTS signal.
2. The pass through buffer in CD5220/CD6220 is full ( 200bytes ) .
* If PC/host keep transmitting the data to printer when CD5220/CD6220
inactive DTR or RTS , data will be lost.
4.1.2 Parallel port (Centronic) communication
(a) data flow : PC/Host to display, display to printer
(b) control flow : printer to display , display to PC/Host
(c) When data has been transmitted to printer by parallel port interface, the
CD5220/CD6220 response the printer status to PC/Host, When printer
active the BUSY signal, CD5220/CD6220 will keep accept the data until the
CD5220 customer display
buffer is full, (the buffer size is 200 bytes), then active the BUSY signal to
PC/host.
4.2 Serial port interface for rectangle basic section
(a) Serial port interface connector position for rectangle basic section
CD5220 customer display
(b) Power input
Connector type : DC JACK (5.5/2.1)
(c) RS232C to PC/HOST connector pin assignment
Connector type : D-sub 25 pin (Female)
No Signal
1 FG - Frame ground
2 TXD From printer to PC/Host Printer status data
3 RXD From PC/Host to display Receive data
4 RTS From display to PC/Host Display/printer ready signal
5 CTS From PC/Host to printer PC/Host ready signal
6 DSR From PC/Host to printer PC/Host ready signal
7 GND
16 V+ Input(optional) If using power built-in
20 DTR From display to PC/Host Display/printer ready signal
direction Function description
- Signal ground
(d) RS232C to printer connector pin assignment
Connector type : D-sub 9 pin (Male)
No Signal
2 RXD From printer to PC/Host Printer status data
3 TXD From display to printer Transmit data
4 DTR From PC/Host to printer PC/Host ready signal
5 GND
6 DSR From printer to display Printer ready signal
7 RTS From PC/Host to printer PC/Host ready signal
8 CTS From printer to display Printer ready signal
direction Function description
Table 4-1
- Signal ground
Table 4-2
CD5220 customer display
4.1.3 Serial port interface for circular base
(a) Power connector of Power cable
Connector type : DC jack (5.5/2.1 )
(b) RS232C interface to PC/HOST cable,
PC/HOST side connector pin assignment
Connector type : D-sub 9 pin (Female)
No Signal
1 FG - Frame ground
2 TXD From printer to PC/Host
3 RXD From PC/Host to display
4 DSR From PC/Host to printer PC/Host ready signal
5 GND
6 DTR From display to PC/Host Display/printer ready signal
7 CTS From PC/Host to printer PC/Host ready signal
8 RTS From display to PC/Host Display/printer ready signal
direction Function description
- Signal ground
Printer status data
Receive data
(c) RS232C interface to printer cable,
printer side connector pin assignment
Connector type : D-sub 25 pin (Male)
No Signal
2 RXD From printer to PC/Host Printer status data
3 TXD From display to printer Transmit data
4 CTS From printer to display Printer ready signal
5 RTS From PC/Host to printer PC/Host ready signal
6 DTR From PC/Host to printer PC/Host ready signal
7 GND
20 DSR From printer to display Printer ready signal
direction Function description
Table 4-3
- Signal ground
Table 4-4
CD5220 customer display
4.3 Parallel port (Centronic) interface for circular base
(a) Power connector of Power cable
Connector type : DC jack (5.5/2.1 )
(b)Parallel interface to PC/HOST cable,
PC/HOST side connector pin assignment
Connector type : D-sub 25 pin (Male)
No Signal Name
1 /STB Input Strobe signal to read data
2-9
10
11
12
13 SELECT Output Always positive logic
15 /ERROR Output Always positive logic
Data0 -
Data7
/ACK Output Data request signal
BUSY Output BUSY state from the display
PE Output Always negative logic
Direction Function description
Input Parallel signal data
Table 4-5
(c) Parallel interface to Printer cable,
Printer side connector pin assignment
Connector type : D-sub 25 pin (Female)
No. Signal Name
1 /STB output strobe signal to write data
2-9 Data0-Data7
11
14 AUTFEED
16
17 SELE_IN output Always positive logic
BUSY input BUSY state from the printer
RESET output Always positive logic
Direction Function description
output parallel signal data
output Always positive logic
Table 4-6
CD5220 customer display
CD5220 customer display
5. FUNCTION SELECTION
5.1 Baud rate
SW number SW1 Function description Baud rate） bps
OFF 9600
ON 4800
notes: SW1 is ignores when baud rate is store to EEPROM (EEPROM type
only),
baud rate will be refer the EEPROM baud rate status.
5.2 International character set
SW number Function description
SW2 SW3 SW4 SW5 International
character set(code
20H-7FH)
OFF OFF OFF OFF U.S.A. PC-437
ON OFF OFF OFF FRANCE PC-850(multilingual)
OFF ON OFF OFF GERMANY PC-850(multilingual)
ON ON OFF OFF U.K. PC-850(multilingual)
OFF OFF ON OFF DENMARK I PC-850(multilingual)
ON OFF ON OFF SWEDEN PC-850(multilingual)
OFF ON ON OFF ITALY PC-850(multilingual)
ON ON ON OFF SPAIN PC-850(multilingual)
OFF OFF OFF ON JAPAN Katakana
ON OFF OFF ON NORWAY PC-850(multilingual)
OFF ON OFF ON DENMARK II PC-850(multilingual)
ON ON OFF ON
OFF OFF ON ON
ON OFF ON ON
OFF ON ON ON
ON ON ON ON
Table 5-1
Code table
(code 80H-FFH)
(USA,standard Europe)
SLAVONIC
RUSSIA
Factory define
Factory define
User define pattern
CD5220 customer display
Table 5-2
5.3 Command type select
SW number Function description Software defined
SW6 SW7 SW8 Command type Hex code
OFF OFF OFF CD5220 07
ON OFF OFF UTC/S 06
OFF ON OFF UTC/P 05
ON ON OFF AEDEX 04
OFF OFF ON ADM 787 03
ON OFF ON ADM 788 02
OFF ON ON ESC/pos 01
ON ON ON DSP800 00
Table 5-3
CD5220 customer display
6. COMMAND
6.1 CD5220 standard mode command list
Command Code description(hex) Function description
ESC DC1 1B 11 overwrite mode
ESC DC2 1B 12 vertical scroll mode
ESC DC3 1B 13 horizontal scroll mode
ESC Q
A ..........CR
ESC Q
B ..........CR
ESC Q
D ..........CR
ESC [ D 1B 5B 44 move cursor left
BS 08 move cursor left
ESC [ C 1B 5B 43 move cursor right
HT 09 move cursor right
ESC [ A 1B 5B 41 move cursor up
ESC [ B 1B 5B 42 move cursor down
LF 0A move cursor down
ESC [ H 1B 5B 48 move cursor to home position
HOM 0B move cursor to home position
ESC [ L 1B 5B 4C move cursor to left-most
CR 0D move cursor to left-most
ESC [ R 1B 5B 52 move cursor to right-most
ESC [ K 1B 5B 4B move curso r to bottom position
ESC l x y 1B 6C x y
ESC @ 1B 40 initialize display
ESC W s x1 x2 y 1B 57 1 x1 x2 y
1B 51 41 [n ]x20 0D set the string display mode,
write string to upper line
1B 51 42 [n ]x20 0D set the string display mode,
write string to lower line
1B 51 44 [n ]xm 0D
m<40
1<=x<=20,y=1,2
1<=x1<=x2<=20 y=1,2
upper line message scroll
continuously
position
position
position
move cursor to specified
position
set or cancel the window range
at horizontal scroll mode
CD5220 customer display
ESC & s n m
5
select/cancel download
select peripheral device, Display
Command Code description
(hex)
CLR 0C clear display screen , and clear
CAN 18 clear cursor line, and clear
ESC * n 1B 2A n
1<=n<=4
1B 26 1 n m
[a (p1..pa)]x
(m-n+1)
ESC ? 1B 3F delete download characters.
ESC % 1B 25
ESC _ n 1B 5F n
ESC f n 1B 66 n select international fonts set
ESC c n 1B 63 n select fonts ,ASCII code or JIS
ESC = n 1B 3D n
ESC s 1 1B 73 01 store the use define character
ESC d 1 1B 64 01 store the use define character
(REMARK)* While using command "ESC QA" or "ESC QB", these two commands could
using combine with terminal printer -- TP 2688.or TP3688
* If using commands "ESC QA" or "ESC QB ,others commands can not be used except
using command "CLR" or "CAN" to change operating mode.
* If using commands "ESC QD ,upper line message move continuously, till receive a new
command, and clear upper line and move cursor to upper line left-most position.
Set international font set( Table 6-2) Select code table(Table
6-3)
n international font set n international font set n international font set
A
U.S.A. N
[a(p1..pa)]x (m-n+1)
20<n<=m<=FF
n=0,1
n=1,2,3,31,32,33
Table 6-1
NORWAY
Function description
string mode
string mode
brightness adjustment
define download characters.
a=1-
p1..p5 =row1..row5
character set.
set cursor ON/OFF
code
or Printer
into EEPROM
from EEPROM
A compliance with ASCII code
CD5220 customer display
G
GERMANY
I
J
U
F
S
6.2 UTC standard mode command list
ITALY
JAPAN
U.K.
FRANCE
SPAIN
Command Code description
BS 08 back space
HT 09 horizontal tab
LF 0A line feed
CR 0D carriage return
DLE 0F display position
DC1 11 over write display mode
DC2 12 vertical scroll mode
DC3 13 cursor on
DC4 14 cursor off
ESC d 1B 64 change to UTC enhanced mode
US 1F clear display
6.3 UTC enhanced mode command list
Command Code description
ESC u A ....CR 1B 75 41 [ data x
ESC u B ....CR 1B 75 42 [ data x
ESC u D ....CR 1B 75 44 [ data x
ESC u E ....CR 1B 75 45 hh ’ : mm 0D
ESC u F ....CR 1B 75 46 [ data x
ESC u H ....CR 1B 75 48 n m 0D
W
(hex)
(hex)
40]0D
40]0D
40]0D
h,m=’ 0-’ 9
40]0D
20h<=n,m
D
E
L
R
SWEDEN
DENMARK I
DENMARK II
SLAVONIC
RUSSIA
reserved
Table 6-4
J
compliance with JIS code
R
compliance with RUSSIA code
L
Function description
Function description
upper line display
bottom line display
upper line message scroll
continuously
display time
upper line message scroll once
pass
change attention code
CD5220 customer display
ESC u I ....CR 1B 75 49 [ data x
40]0D
ESC RS CR 1B 0F 0D change to UTC standard mode
Table 6-5
two line display
CD5220 customer display
21 23 35 hh ’: mm 0D
6.4 AEDEX mode command list
Command Code description
! # 1 ....CR 21 23 31 [data x 40]0D upper line display
! # 2 ....CR 21 23 32 [data x 40]0D bottom line display
! # 4 ....CR 21 23 34 [data x 40]0D upper line message scroll
! # 5 ....CR
! # 6 ....CR 21 23 36 [data x 40]0D upper line message scroll once
! # 8 ....CR 21 23 38 n m 0D
! # 9 ....CR 21 23 39 [data x 40]0D two line display
6.5 ADM787/788 mode command list
Command Code description
CLR 0C clear display
CR 0D carriage return
SLE1 0E clear up line and move cursor to
SLE2 0F clear low line and move cursor
DC0 10 n set period to upper line last n
DC1 11 n set line blanking ,
DC2 12 n clear line blanking ,
SF1 1E clear field 1 and move cursor to
SF2 1F clear field 2 and move cursor to
Function description
(hex)
continuously
display time
h,m=’ 0- ’ 9
pass
change attention code
20h<=n,m
Table 6-6
Function description
(hex)
upper line left most end
to lower line left most end
position 31H<=n<=37H
n=’ 1 up line, n=’ 2 low line
n=’1 up line, n=’ 2 low line
field 1 fast position
field 2 fast position
Table 6-7
04 01 26 n p1...p5 17,
04 01 3F n 17
6.6 DSP-800 mode command list
Command Code description
EOT SOH I n ETB 04 01 49 n 17 select international character
EOT SOH P n ETB 04 01 50 n 17
EOT SOH C n m
ETB
EOT SOH S n ETB 04 01 53 n 17
EOT SOH D n m
ETB
EOT SOH A n
ETB
EOT SOH F n ETB 04 01 46 n 17
EOT SOH & n
[px5] ETB
EOT SOH ? n ETB
EOT SOH = n ETB 04 01 3D n 17
EOT SOH % ETB 04 01 25 17 initialize display
EOT SOH @ ETB 04 01 40 17 execute self-test
REMARK)
(
About the command display the saved data(Table 6-9)
*
CD5220 customer display
Function descriptions
(hex)
set.
move cursor to specified
n=31-58
04 01 43 n m 17
31<= n<=m<=58
n=31-35
04 01 44 n m 17
n=31-4F m=31-33
04 01 41 n 17
n=31-34
00<=n<=FF
20<=n
20<=n
n=’1 ,’ 2
Table 6-8
position.
clear display range from n
position to m position and
move cursor to n position.
save the current displaying data
to n layer for demo display.
display the saved data
brightness adjustment.
blink display screen.
define download characters
delete download characters.
select peripheral device.
n=’1,printer n=’ 2,display
n lay select
bit 0=1 lay 1 bit 3=1 lay 4
n lay select
m show mode
bit 0=1 show mode 1
CD5220 customer display
bit 1=1 lay 2 bit 4=0 lay 5
bit 2=1 lay 3
bit 1=1 show mode 2
CD5220 customer display
select international character
5
select/cancel download
6. 7 EPSON Esc/pos command list
Command Code description(hex) Function description
HT 09 move cursor right.
BS 08 move cursor left.
US LF 1F 0A move cursor up.
LF 0A move cursor down.
US CR 1F 0D move cursor to right-most
CR 0D move cursor to left-most
HOM 0B move cursor to home position.
US B 1F 42 move cursor to bottom position.
US $ x y 1F 24 x y
x=1-20,y=01,02
CLR 0C clear display screen.
CAN 18 clear cursor line.
US X n 1F 58 n
01<=n<=04
US E n 1F 45 n n=00-ff blink display screen.
ESC @ 1B 40 initialize display.
ESC t n 1B 74 n n=00-0f select character code table.
ESC R n 1B 52 n n=00-0f
US r n 1F 72 n n=00,01 select/cancel reverse character.
US MD1 1F 01 specify overwrite mode.
US MD2 1F 02 specify vertical scroll mode.
US MD3 1F 03 specify horizontal scroll mode.
ESC & s n m
[a(p1..pa)]x m-n
ESC ? 1B 3F delete download characters.
ESC % 1B 25
1B 26 1 n m
[a(p1..pa)]x m-n
20<n<=m<=ff
position.
position.
move cursor to specified
position.
brightness adjustment.
set.
define download characters.
20<n<=m<=ff a=1-
p1..p5 =row1..row5
character set.
CD5220 customer display
specify/cancel the window
set starting/ending position of
Command Code description(hex)
ESC W n s x1 y1
x2 y2
ESC = n 1B 3D n
US : 1F 3A
US ^ n m 1F 5E n m
US @ 1F 40 execute self-test.
US T h m 1F 54 h m
US U 1F 55 display time continuously
ESC s 1 1F 73 01 store define download character
ESC d 1 1F 64 01 Restore user define character
1B 57 n s x1 y1 x2 y2
n=1,2,3,4
s=0,1
n=1,31 ,select printer
n=2,32 ,select display
00<=(n, m)<=ff
0<=h<=17 , 0<=m<=3b
Function description
range.
1<=x1<=x2<=20
1<=y1<=y2<=2
select peripheral device.
macro definition.
execute and quit macro.
display time
to EEPROM
from EEPROM
11 Table 6-10
Set international font set for ESC/pos Select code table for ESC/pos
n International font n International font
0
U.S.A.
1
FRANCE
2
GERMANY
3
U.K.
4
DENMARK I
5
SWEDEN
6
ITALY
Table 6-11 Table 6-12
7
SPAIN
8
JAPAN
9
NORWAY
10
DENMARK II
11
SLAVONIC
12
RUSSIA
15
reserved
n
0
1
2
3
4
5
6
7
-FFH)
-French)
CD5220 customer display
7. INSTALLATION GUIDE
Loading...
