Epson C9300 User Manual

Download
Network Guide
NPD4503-00 EN
Epson Network Guide

Copyright and Trademarks

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation. No patent liability is assumed with respect to the use of the information contained herein. Neither is any liability assumed for damages resulting from the use of the information contained herein.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation’s operating and maintenance instructions.
Seiko Epson Corporation and its affiliates shall not be liable against any damages or problems arising from the use of any options or any consumable products other than those designated as Original Epson Products or Epson Approved Products by Seiko Epson Corporation.
Features Zoran Corporation Integrated Print System (IPS) for print language emulation.
NEST Office Kit Copyright © 1996, Novell, Inc. All rights reserved.
A part of the ICC Profile contained within this product was created by Gretag Macbeth ProfileMaker. Gretag Macbeth is the registered trademark of Gretag Macbeth Holding AG Logo. ProfileMaker is a trademark of LOGO GmbH.
IBM and PS/2 are registered trademarks of International Business Machines Corporation.
Microsoft
Apple Apple Chancery, Chicago, Geneva, Hoefler Text, Monaco and New York are trademarks or registered trademarks of Apple, Inc.
EPSON and EPSON ESC/P are registered trademarks and EPSON AcuLaser and EPSON ESC/P 2 are trademarks of Seiko Epson Corporation.
Monotype is a trademark of Monotype Imaging, Inc. registered in the United States Patent and Trademark Office and may be registered in certain jurisdictions.
The UFST printer devices.
MicroType significantly reduce font file sizes.
, Windows®, and Windows Vista® are registered trademarks of Microsoft Corporation.
®
, Macintosh®, Mac®, Mac OS®, AppleTalk®, and Bonjour® are registered trademarks of Apple, Inc.
®
(Universal Font Scaling Technology™) product is Monotype Imaging’s scalable font rendering subsystem for
®
font compression technology from Monotype Imaging works with the UFST® font rendering subsystem to
®
Monotype Imaging’s MicroType
CG Omega, CG Times, Garamond Antiqua, Garamond Halbfett, Garamond Kursiv, Garamond Halbfett Kursiv are trademarks of Monotype Imaging, Inc. and may be registered in certain jurisdictions.
font format is a MicroType-compressed font format.
®
Copyright and Trademarks 2
Epson Network Guide
Scalable type outlines are licensed from Monotype Imaging, Inc.
Albertus, Arial, Coronet, Gillsans, and Times New Roman are trademarks of The Monotype Corporation registered in the United States Patent and Trademark Office and may be registered in certain jurisdictions.
ITC Avant Garde Gothic, ITC Bookman, ITC Zapf-Chancery, and ITC ZapfDingbats are trademarks of International Typeface Corporation registered in the United States Patent and Trademark Office and may be registered in certain jurisdictions.
Clarendon, Helvetica, Palatino, Times and Univers are registered trademarks of Heidelberger Druckmaschinen AG, which may be registered in certain jurisdictions, exclusively licensed through Linotype Library GmbH, a wholly owned subsidiary of Heidelberger Druckmaschinen AG.
Wingdings is a registered trademark of Microsoft Corporation in the United States and other countries.
Marigold is a trademark of Arthur Baker and may be registered in some jurisdictions.
Antique Olive is a trademark of Marcel Olive and may be registered in certain jurisdictions.
HP and HP LaserJet are registered trademarks of the Hewlett-Packard Company.
PCL is a registered trademark of Hewlett-Packard Company.
Adobe, the Adobe logo and PostScript3 are trademarks of Adobe Systems Incorporated, which may be registered in certain jurisdictions.
CompactFlash is a trademark of SanDisk Corporation, registered in the United States and other countries.
This product includes software developed by the University of California, Berkeley, and its contributors.
This product includes RSA BSAFE RSA and BSAFE are registered trademarks or trademarks of EMC Corporation in the United States and other countries.
This product contains Runtime Modules of IBM Rational Rhapsody, Copyright IBM Corporation 2008. All Rights Reserved.
General Notice: Other product names used herein are for identification purposes only and may be trademarks of their respective owners. Epson disclaims any and all rights in those marks.
Copyright © 2011 Seiko Epson Corporation. All rights reserved.
Cryptographic software of EMC Corporation.
®
Copyright and Trademarks 3
Epson Network Guide

Contents

Safety Instructions
Warnings, Cautions, and Notes............................................................ 7
Chapter 1 Introduction
About Your Printer...................................................................... 8
About This Guide....................................................................... 8
Operating Environment.................................................................. 9
Laser printers....................................................................... 9
Inkjet printers/Large format inkjet printers............................................. 10
Features of the Network Interface......................................................... 10
Network Interface Operation............................................................. 11
Status light........................................................................ 11
Network connector................................................................. 12
About the Software..................................................................... 12
Terms and Concepts.................................................................... 13
Chapter 2 How To
Overview............................................................................. 14
Selecting a Printing Method.............................................................. 15
Printing from Windows............................................................. 15
Printing from Macintosh............................................................ 15
Features of the Printing Methods..................................................... 16
Installing Components on Your Computer................................................. 17
About Installing Components on Your Computer....................................... 17
Windows 7/Vista/Server 2008........................................................ 17
Windows XP...................................................................... 19
Windows Server 2003. .............................................................. 20
Windows 2000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Macintosh........................................................................ 23
Setting Up the Network Interface......................................................... 23
Connecting the Network Interface to the Network....................................... 23
Configuring the Network Interface (For Windows Users)................................. 24
Contents 4
Epson Network Guide
Configuring the Network Interface (For Macintosh Users)................................ 25
Installing the Printer Driver.............................................................. 27
About Installing the Printer Driver.................................................... 27
Windows 7/Vista/Server 2008........................................................ 27
Windows XP...................................................................... 31
Windows Server 2003. .............................................................. 36
Windows 2000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Macintosh........................................................................ 45
Chapter 3 Network Software
EpsonNet Config for Windows. .......................................................... 48
About EpsonNet Config............................................................. 48
System Requirements............................................................... 48
Installing EpsonNet Config.......................................................... 49
Accessing the EpsonNet Config User’s Guide........................................... 49
EpsonNet Config for Macintosh.......................................................... 50
About EpsonNet Config............................................................. 50
System Requirements............................................................... 50
Installing EpsonNet Config.......................................................... 50
Accessing the EpsonNet Config User’s Guide........................................... 51
EpsonNet Config with Web Browser...................................................... 51
About EpsonNet Config............................................................. 51
Configuring the Network Interface Using Web-Based EpsonNet Config..................... 52
Opening Screen.................................................................... 55
EpsonNet Print........................................................................ 58
About EpsonNet Print.............................................................. 58
System Requirements............................................................... 58
Installing EpsonNet Print............................................................ 59
For Windows 7/Vista/XP/Server 2008/Server 2003/2000/NT 4.0 Users. . . . . . . . . . . . . . . . . . . . . . 59
For Windows Me/98/95 Users........................................................ 66
Configuring the Printer Port......................................................... 71
Chapter 4 Troubleshooting
General Problems...................................................................... 74
Cannot configure the network interface or cannot print from the network................... 74
Cannot print even if you have assigned the IP address to the computer and the printer......... 74
Contents 5
Epson Network Guide
Unable to start EpsonNet Config...................................................... 74
The message “EpsonNet Config cannot be used because no network is installed.” appears when
you start EpsonNet Config......................................................... 75
The message “Could not complete communicating configuration data” appears when you send
settings to the network interface.................................................... 75
Unable to start EpsonNet Config with Web Browser...................................... 75
The Model Name and IP Address do not appear in the EpsonNet Config dialog box........... 76
An extra account is generated when using the dial-up network. ............................ 76
Printing a Network Status Sheet.......................................................... 76
Printing a Network Status Sheet (Large Format Inkjet Printers)................................ 77
Initializing Your Printer................................................................. 77
Reformatting the Hard Disk Drive........................................................ 78
Chapter 5 Tips for Administrator
Setting an IP Address on the Printer’s Control Panel......................................... 79
Network Menu.................................................................... 80
AUX Menu....................................................................... 81
Setting an IP Address on the Printer’s Control Panel (Large Format Inkjet Printers)............... 82
Network Setup Menu............................................................... 84
Instructions on Using a Dial-Up Router.................................................... 84
Function of Universal Plug and Play....................................................... 85
Secure Communication Using IPSec and Access Control...................................... 85
IPSec protocol..................................................................... 86
Access control..................................................................... 86
Appendix A Software License Terms
Open Source Software Licenses........................................................... 87
Bonjour.......................................................................... 87
Getopt........................................................................... 88
Arcfour........................................................................... 89
Other Software Licenses................................................................. 90
Info-ZIP copyright and license....................................................... 90
Index
Contents 6

Safety Instructions

Warnings, Cautions, and Notes

Warnings
w
must be followed carefully to avoid bodily injury.
Cautions
c
must be observed to avoid damage to your equipment.
Notes
contain important information and useful tips on the operation of your printer.
Epson Network Guide
Safety Instructions 7
Epson Network Guide
Chapter 1

Introduction

About Your Printer

Your printer has a built-in Ethernet interface and can connect anywhere on your network using 10Base-T, 100Base-TX, and 1000Base-T Ethernet. The built-in Ethernet interface, which is called the network interface in this manual, automatically selects the correct standard when it connects to a network. In addition, it supports and automatically selects the IEEE 802.2, IEEE 802.3, Ethernet II, and Ethernet SNAP network protocols.
Because the network interface supports multiple protocols and automatically detects protocols on your network, you can print from Microsoft
Windows® and Apple® Macintosh® applications.
®
Use the Software Disc to easily configure the network interface for use on the TCP/IP network and install the printer driver. You can use the printer on the TCP/IP network at once.
If you want to configure the network interface for protocols such as TCP/IP, AppleTalk SNMP, use EpsonNet Config, the configuration utility provided with your product, to quickly and easily configure the network interface to use those protocols.
Note:
The EpsonNet Config utility configures the network interface to work only with protocols that exist on your network. This does not imply that you can use all of the above-mentioned protocols on your network or operating system. The protocols that the network interface can use may vary depending on the operating system and the network configuration.

About This Guide

This Network Guide contains information about using the network interface on a network. It includes how to set up the network interface, install the configuration software, and modify network settings of your printer and computers.
, IPP, and
®
For information about your printer, see your User’s Guide.
Note:
❏ To read the online guide, you must have Adobe Reader or Adobe Acrobat Reader installed on your
computer.
Introduction 8
Epson Network Guide
❏ This guide is written for network administrators, and many of the steps included here require
detailed network knowledge and administrator rights.
❏ The term “network administrator” refers to the person responsible for maintaining the network.
“Administrator” is synonymous with “Supervisor” in this guide.
❏ The term “network interface” refers to the built-in Ethernet interface of the printer in this guide.
❏ Some screen shots in this guide may list a printer name other than your printer. This difference does
not alter the instructions.
❏ The supported operating systems are different depending on the printer. See your printer’s User’s
Guide for the supported operating systems.

Operating Environment

The network interface supports the following environments.

Laser printers

OS Protocol IPv4 IPv6
Windows 7
Windows Vista
Windows Server 2008
Windows XP (Home, Professional)
Windows Server 2003
Windows 2000 (Professional, Server)
Mac OS X 10.6
Mac OS X 10.5
Mac OS X 10.4 Epson AppleTalk - -
TCP/IP (Standard TCP/IP port) supported supported
TCP/IP (EpsonNet Print port) supported not supported
IPP supported supported
TCP/IP (Standard TCP/IP port) supported not supported
TCP/IP (EpsonNet Print port) supported not supported
IPP supported not supported
Epson TCP/IP supported supported
Bonjour supported supported
Epson TCP/IP supported not supported
Bonjour supported not supported
Introduction 9
Epson Network Guide
Note:
If you use the printer in a dial-up router environment, you must set an IP address for the printer. Make sure the IP address is suitable for the segment; incorrect IP address may generate unexpected dial-up.

Inkjet printers/Large format inkjet printers

OS Protocol IPv4 IPv6
Windows 7
Windows Vista
Windows XP (Home, Professional)
Mac OS X 10.6
Mac OS X 10.5
Mac OS X 10.4 Epson AppleTalk* - -
* IPP and AppleTalk are not supported on some models.
TCP/IP (Standard TCP/IP port) supported not supported
TCP/IP (EpsonNet Print port) supported not supported
IPP* supported not supported
Epson TCP/IP supported not supported
Bonjour supported not supported
Epson TCP/IP supported not supported
Bonjour supported not supported

Features of the Network Interface

❏ Connects your Epson printer using a built-in Ethernet interface, which is called the network
interface in this manual, to the network.
❏ Supports multiple protocols, such as TCP/IP, AppleTalk, and IPP.
❏ Supports 10Base-T, 100Base-TX, and 1000Base-T Ethernet.
❏ Supports DHCP.
❏ Supports Automatic Private IP Addressing (APIPA) that assigns an IP address automatically to
the network interface even if there is no DHCP server on the network.
❏ Supports the Dynamic DNS function.
❏ Supports SNMP and MIB.
❏ Supports SNTP (Simple Network Time Protocol).
Introduction 10
Epson Network Guide
❏ Supports Bonjour on Mac OS X 10.4 or later.

Network Interface Operation

Status light

The indicator lights provide you with important information on the operations of the network interface.
Laser printers
Status light Data light Network Status
Off Green Ready (10 M link)
Off Green (Flashing) Receiving packets (10 M link)
Orange Green Ready (100 M link)
Orange Green (Flashing) Receiving packets (100 M link)
Green Green Ready (1000 M link)
Green Green (Flashing) Receiving packets (1000 M link)
Off Off Deep sleep mode/Power off mode
Inkjet printers/Large format inkjet printers (Models that do not support 1000 Mbps communication)
Status light Data light Network Status
Green Yellow Ready (10 M link)
Green Yellow (Flashing) Receiving packets (10 M link)
Red Yellow Ready (100 M link)
Red Yellow (Flashing) Receiving packets (100 M link)
Introduction 11
Epson Network Guide
Large format inkjet printers (Models that support 1000 Mbps communication)
Status light Data light Network Status
Red Yellow Ready (100 M link)
Red Yellow (Flashing) Receiving packets (100 M link)
Green Yellow Ready (1000 M link)
Green Yellow (Flashing) Receiving packets (1000 M link)

Network connector

RJ-45 connector: This connector is used to connect an Ethernet cable to a network. You can use this cable for 10Base-T, 100Base-TX, and 1000Base-T Ethernet.
Caution:
c
You must use the following shielded twisted-pair cable to connect the network interface to a network.
❏ Category-5 or higher for the 10Base-T or 100Base-TX connection
❏ Category-5e or higher for the 1000Base-T connection

About the Software

The Software Disc provided with your printer includes the following network software.
Note:
The software provided varies depending on your printer model.
❏ EpsonNet Config for Windows is a Windows-based configuration utility for administrators that
allows you to configure the network interface for various protocols such as TCP/IP, MS Network, AppleTalk, IPP, and SNMP. See “EpsonNet Config for Windows” on page 48.
❏ EpsonNet Config for Macintosh is a Macintosh-based configuration utility for administrators
that allows you to configure the network interface for TCP/IP, AppleTalk, and IPP. See “EpsonNet Config for Macintosh” on page 50.
Introduction 12
Epson Network Guide
❏ EpsonNet Config with Web Browser is a Web-based configuration utility that allows you to
configure the network interface for TCP/IP, MS Network, AppleTalk, IPP, and SNMP. See “EpsonNet Config with Web Browser” on page 51.
❏ EpsonNet Print is a utility program that provides peer to peer printing to Epson printers on the
TCP/IP network. See “EpsonNet Print” on page 58.

Terms and Concepts

Configuration -- a prepared set of conditions for proper operation of a device. Configuring the network interface is to prepare it to work with protocols available on a network.
DHCP -- a dynamic host configuration protocol. It is a protocol that assigns dynamic IP addresses to devices on a network.
EtherTalk -- the communication protocol of AppleTalk governing Ethernet transmissions
ftp -- a TCP/IP application protocol for file transfer
lpd -- a TCP/IP remote printing protocol application
Print queue -- a location where a print job is stored as a file, until the network interface sends the job to the assigned printer
Protocol -- a rule that controls how data or information is exchanged through a network. Computers and software cannot communicate with each other using different protocols.
TCP/IP -- Transmission Control Protocol/Internet Protocol, a layer of protocols that provides communication between nodes on a network
SSL -- Secure Sockets Layer, a security protocol for transmitting data between a web server and a browser
Introduction 13
Epson Network Guide
Chapter 2

How To

Overview

This section describes the general procedure on how to set up the network interface for use on a network.
1. Check the network interface operation.
Check the functions and operations of the network interface, such as status lights and RJ-45 connector. See “Network Interface Operation” on page 11 for details.
2. Select a printing method.
Select a printing method appropriate for your network environment and operating system. If you are not sure, see “Printing from Windows” on page 15 or “Printing from Macintosh” on page 15 for details.
3. Install the necessary components on your computer.
Make sure the necessary components (such as TCP/IP) are installed on the computer, and network settings (such as IP address, subnet mask, etc.) of the computer is set. See “About Installing Components on Your Computer” on page 17 for details.
4. Connect the network interface to the network.
Connect the network interface to the network. See “Connecting the Network Interface to the Network” on page 23 for details.
5. Configure the network interface and install the printer driver.
See “Configuring the Network Interface (For Windows Users)” on page 24 or “Configuring the Network Interface (For Macintosh Users)” on page 25 for details.
6. If necessary, configure the network settings of the network interface using EpsonNet Config.
Configure the network interface for TCP/IP, AppleTalk, etc. using EpsonNet Config. For Windows users, see “About EpsonNet Config” on page 48. For Macintosh users, see “About EpsonNet Config” on page 50.
How To 14
Epson Network Guide

Selecting a Printing Method

Printing from Windows

Check if there is a Windows 7/Vista/XP/Server 2008/Server 2003/2000/NT print server on your network, and then use the suggestions below.
Note:
Only the recommended printing methods are introduced here. See “Features of the Printing Methods” on page 16 for information on additional methods.
If no Windows 7/Vista/XP/Server 2008/Server 2003/2000/NT print server exists
We recommend TCP/IP printing via LPR. See “Windows 7/Vista/Server 2008” on page 27, “Windows XP” on page 31, “Windows Server 2003” on page 36, or “Windows 2000” on page 41.
If a Windows 7/Vista/XP/Server 2008/Server 2003/2000/NT print server exists
On the server, set the printer to connect with LPR and turn it into a shared printer. Your clients can then print to this shared printer.

Printing from Macintosh

Mac OS X 10.5 or later
❏ Bonjour
❏ EPSON TCP/IP
Mac OS X 10.4
❏ Bonjour
❏ EPSON TCP/IP
❏ EPSON AppleTalk
How To 15
Epson Network Guide

Features of the Printing Methods

This section describes features of the printing methods available for you to choose.
LPR (TCP/IP) printing
Advantages
❏ No computer as a network interface is required.
❏ No special utility for Windows 7/Vista/XP/Server 2008/Server 2003/2000/NT is required.
❏ You can see the printer status using EPSON Status Monitor.
❏ For Windows 7/Vista/XP/Server 2008/Server 2003/2000/NT, you can create a print log using the
event viewer.
❏ You can print via a router.
Disadvantages
❏ You need to set up TCP/IP.
Internet printing
Advantages
❏ No proxy server (computer) is required.
❏ You can print to the printer over the Internet.
Disadvantages
❏ EPSON Status Monitor cannot be used.
❏ TCP/IP and DNS settings are required.
❏ For Windows 7/Vista/XP/Server 2008/Server 2003/2000, you cannot share the Internet printer.
How To 16
Epson Network Guide

Installing Components on Your Computer

About Installing Components on Your Computer

Before configuring the network interface and printing from the computer, you need to install the necessary components (such as TCP/IP) and assign an IP address and subnet mask for your computer, depending on the printing method you want to use. See the section in this chapter appropriate for your operating system.
Note:
❏ The Windows operating system CD-ROM may be required during the installation.
❏ When using TCP/IP or IPP for printing, you need to set the IP address, the subnet mask, and the
default gateway of the computer.

Windows 7/Vista/Server 2008

Use the following procedure to install the necessary components.
1. Click Start, click Control Panel, and then click View network status and tasks or double-click
Network and Sharing Center.
2. Click Local Area Connection (Windows 7), or View Status (Windows Vista/Server 2008), and
then click the Properties button.
Note:
If the User Account Control screen appears, click the Yes or Continue button.
How To 17
3. Check if the following necessary components are in the list.
Epson Network Guide
The following table lists the components required for configuring the network interface with EpsonNet Config.
EpsonNet Config’s setting screens Necessary components
TCP/IP, AppleTalk, IPP, SNMP (IP trap) Internet Protocol (TCP/IP)
The following table lists the components required for network printing.
Printing method Necessary components
LPR or Internet printing Internet Protocol (TCP/IP)
4. Double-click Internet Protocol Version 4 (TCP/IPv4) or Internet Protocol Version 6 (TCP/
IPv6) on the Local Area Connection Properties dialog box to open the properties dialog box. Set
the IP address, the subnet mask, etc. and then click OK.
5. Restart the computer.
The necessary components are now installed. Go to the section “Setting Up the Network Interface” on page 23.
How To 18
Epson Network Guide

Windows XP

For Windows XP, use the following procedure to install the necessary components.
1. Click Start, highlight Control Panel, and then click Network and Internet Connections.
Select Network Connections.
2. Under LAN or High-Speed Internet, click the Local Area Connection icon.
3. Under Network Tasks, click Change settings of this connection.
4. Check if the following necessary components are in the list.
The following table lists the components required for configuring the network interface with EpsonNet Config.
EpsonNet Config’s setting screens Necessary components
TCP/IP, AppleTalk, IPP, SNMP (IP trap) Internet Protocol (TCP/IP)
The following table lists the components required for network printing.
Printing method Necessary components
LPR or Internet printing Internet Protocol (TCP/IP)
How To 19
Epson Network Guide
5. Double-click Internet Protocol (TCP/IP) on the Local Area Connection Properties dialog box to
open the Internet Protocols (TCP/IP) Properties dialog box. Set the IP address, the subnet mask, etc. and then click OK.
6. Restart the computer.
The necessary components are now installed. Go to the section “Setting Up the Network Interface” on page 23.

Windows Server 2003

For Windows Server 2003, use the following procedure to install the necessary components.
1. Click Start, point to Control Panel, and then select Network Connections. Click Local Area
Connections.
2. Click the Properties button.
3. Check if the following necessary components are in the list.
The following table lists the components required for configuring the network interface with EpsonNet Config.
How To 20
Epson Network Guide
EpsonNet Config’s setting screens Necessary components
TCP/IP, AppleTalk, IPP, SNMP (IP trap) Internet Protocol (TCP/IP)
The following table lists the components required for network printing.
Printing method Necessary components
LPR or Internet printing Internet Protocol (TCP/IP)
4. Double-click Internet Protocol (TCP/IP) on the Local Area Connection Properties dialog box to
open the Internet Protocols (TCP/IP) Properties dialog box. Set the IP address, the subnet mask, etc. and then click OK.
5. Restart the computer.
The necessary components are now installed. Go to the section “Setting Up the Network Interface” on page 23.

Windows 2000

For Windows 2000, use the following procedure to install the necessary components.
1. Click Start, point to Settings, and then select Network and Dial-up Connections. The
Network and Dial-up Connections screen appears.
2. Right-click the desired network connection and then select Properties.
How To 21
3. Check if the following necessary components are in the list.
Epson Network Guide
The following table lists the components required for configuring the network interface with EpsonNet Config.
EpsonNet Config’s setting screens Necessary components
TCP/IP, AppleTalk, IPP, SNMP (IP trap) Internet Protocol (TCP/IP)
The following table lists the components required for network printing.
Printing method Necessary components
LPR or Internet printing Internet Protocol (TCP/IP)
4. If the necessary components are not in the list, click Install to install them, as described below.
Select Protocol and then click Add. In the Select Network Protocol dialog box, select Internet Protocol (TCP/IP) and then click OK.
5. Double-click Internet Protocol (TCP/IP) on the Configuration menu to open the TCP/IP
Properties dialog box. Set the IP address, the subnet mask, etc. and then click OK.
6. Restart the computer.
How To 22
Epson Network Guide
The necessary components are now installed. Go to the section “Setting Up the Network Interface” on page 23.

Macintosh

To assign an IP address, subnet mask, etc. to your Macintosh, follow the steps below.
Mac OS X
1. From the Apple menu, select System Preferences.
2. Open the Network control panel. Click the TCP/IP tab.
Note:
For Mac OS X 10.5 or later, select Ethernet as the connecting method on the Network control panel, select the method to assign the IP address from the Configure menu, and then assign the IP address.
3. Select Built-in Ethernet from the Show pull down menu.
4. Assign an IP address and other settings if necessary.
5. Click the Apply Now button to save any changes.
Go to the section “Setting Up the Network Interface” on page 23.

Setting Up the Network Interface

Connecting the Network Interface to the Network

Follow the instructions below to connect the network interface to the network.
1. Make sure that your printer is turned off.
2. Connect one end of the network cable to the RJ-45 connector on the network interface, and the
other end to the network.
How To 23
Epson Network Guide
Caution:
c
❏ You must use the following shielded twisted-pair cable to connect the network interface to
a network.
-- Category-5 or higher for the 10Base-T or 100Base-TX connection
-- Category-5e or higher for the 1000Base-T connection
❏ Do not connect the network interface and the computer directly. Be sure to use a HUB to
connect the network interface to the network.
Note:
You can use 10Base-T, 100Base-TX, and 1000Base-T Ethernet. When you print a lot of data, we recommend you use a higher-speed with light network traffic.
3. Turn on your printer. After the status lights go off, print a network status sheet.
Caution:
c
After turning off the printer, wait until the status lights go off before turning it back on; otherwise the network interface may not work correctly.
Note for Mac OS X 10.4 or later:
Since the printer supports Bonjour and is on by default, you can use the printer on a network just by connecting it to the network. If you want to disable the Bonjour setting, use the printer’s control panel. See “Setting an IP Address on the Printer’s Control Panel” on page 79 or “Setting an IP Address on the Printer’s Control Panel (Large Format Inkjet Printers)” on page 82 for details.
Now, you can configure the network interface to use on the TCP/IP network and also install the printer driver using the Software Disc shipped with your printer.
If you are using Windows, see “Configuring the Network Interface (For Windows Users)” on page 24.
If you are using Macintosh, see “Configuring the Network Interface (For Macintosh Users)” on page 25.

Configuring the Network Interface (For Windows Users)

Configure the network interface for use on the TCP/IP network and install the printer driver on your computer.
1. Insert the Software Disc into the CD-ROM drive.
How To 24
Epson Network Guide
2. The Epson Install Navi screen opens automatically.
If the Epson Install Navi screen does not appear, double-click EPSETUP.EXE on the CD-ROM.
3. Make sure that all applications are closed, and then click the Easy Install icon.
4. The software license agreement screen appears. Select the Agree radio button and then click the
Next button.
5. Select the Ethernet Network connection radio button and then click the Next button.
Note:
If your printer is connected to your computer with a USB cable, select the Local connection radio button. Then follow the on-screen instructions.
6. Make sure your printer is connected to the network (a hub or router) and click the Next button.
Note:
If the Windows Security Alert window appears, click the Allow access or Unblock button; otherwise the printer is not listed on the EpsonNet Setup screen.
7. The Software List screen appears. Select the optional software you want to install from the
Recommended pane, and then click Install.
8. EpsonNet Setup starts.
Follow the on-screen instructions to complete the installation.

Configuring the Network Interface (For Macintosh Users)

Configure the network interface for use on the TCP/IP network and install the printer driver on your computer.
1. Insert the Software Disc into the CD-ROM drive.
EPSON folder opens automatically.
2. Double-click the Install Navi icon in the EPSON folder.
The Epson Install Navi screen opens.
How To 25
Epson Network Guide
3. Enter your user name and password in the authentication screen.
4. Make sure that all applications are closed, and then click the Easy Install icon.
5. The software license agreement screen appears. Select the Agree radio button and then click the
Next button.
6. Select the Ethernet Network connection radio button and then click the Next button.
Note:
If your printer is connected to your computer with a USB cable, select the Local connection radio button. Then follow the on-screen instructions.
7. Make sure your printer is connected to the network (a hub or router) and click the Next button.
8. The Software List screen appears. Confirm the software you want to install, and then click
Install.
9. EpsonNet Setup starts. Follow the on-screen instructions to complete the installation.
Setting Up the Printer
Mac OS X 10.5 or later
1. Open System Preferences.
2. Open Print & Fax.
3. Click the + button to add a new printer.
4. Select the desired printer model that is connected with Bonjour.
Note:
If your printer is not displayed with the desired connection, click More Printers, select the desired connection from the drop down list, and then select the printer model.
5. Click Add.
Now you can use the printer on the TCP/IP network.
Note:
If your product supports the scanning function, see the product’s User’s Guide to make the settings.
How To 26
Mac OS X 10.4
1. Open the Applications folder.
2. Open the Utilities folder.
3. Open Printer Setup Utility and then click Add.
4. Select the printer model that is connected with Bonjour.
Note:
If your printer is not displayed with the desired connection, click More Printers, select the desired connection from the drop down list, and then select the printer model.
5. Click Add.
Now you can use the printer on the TCP/IP network.
Epson Network Guide
Note:
If your product supports the scanning function, see the product’s User’s Guide to make the settings.

Installing the Printer Driver

About Installing the Printer Driver

To print to the network printer, you need to install the printer driver on the computer. The following section explains how to instal the printer driver manually. See the section in this chapter appropriate for your operating system.

Windows 7/Vista/Server 2008

The printer driver installation procedure differs depending on the printing method you prefer.
LPR printing
Note:
If you are using EpsonNet Print, the setup procedure is different. See “About EpsonNet Print” on page 58 for details. Note that EpsonNet Print does not support IPv6 environment.
How To 27
Epson Network Guide
1. Click Start, Control Panel, and then View devices and printers (Windows 7) or Printers
(Windows Vista/Server 2008).
2. Click Add a printer to start the Add Printer wizard.
3. Click Add a local printer.
4. Select the Create a new port radio button, and then select Standard TCP/IP Port from the list.
Then click Next.
How To 28
Epson Network Guide
5. Enter the IP address of the network interface and then click Next.
6. If an error occurs, the following dialog box appears. Select the Standard radio button and then
select EPSON Network Printer. Click Next.
7. Click Finish.
8. See “Installing a printer driver” on page 30 to install the printer driver.
Internet printing
1. Click Start, Control Panel, and then Printers.
2. Click Add a printer to start the Add Printer wizard.
3. Click Add a network, wireless or Bluetooth printer.
How To 29
Epson Network Guide
4. Click The printer that I want isn’t listed.
5. Select the Add a printer using a TCP/IP address or hostname radio button and then click
Next.
6. Enter the URL of the target device to the Hostname or IP address box using the format below.
The URL should be the same as the URL you set on EpsonNet Config’s IPP configuration page.
http://IP address of network interface:631/Printer name
Example: http://192.168.100.201:631/EPSON_IPP_Printer
Note:
To check the IP address of the network interface, use EpsonNet Config. See “About EpsonNet Config” on page 48 for details.
7. Follow the on-screen instructions to set up the device. See “Installing a printer driver” on page 30
if necessary.
Installing a printer driver
1. Insert the Software Disc shipped with the device.
2. Close the Epson Install Navi screen if it appears.
3. On the Add Printer screen, click the Have Disk button. The Install From Disk dialog box appears.
4. Click Browse.
How To 30
Epson Network Guide
5. Select the CD-ROM drive for Drives, and double-click the WINX64 folder or the WINX86 folder
depending on your operating system. Click Open.
6. Click OK in the Install From Disk dialog box.
7. Select the model name of the device, and then click Next.
Note:
If the Add Printer wizard prompts you to select either Keep existing driver or Replace existing driver, be sure to select the Replace existing driver radio button.
8. Click Finish and follow the on-screen instructions to complete the setup.
Encrypting print data (Secure IPP printing)
Internet printing (IPP) enables you to encrypt data to print.
Required settings
Configure the following settings using EpsonNet Config with Web Browser. See “EpsonNet Config with Web Browser” on page 51 for details.
❏ Importing server certificate
❏ Selecting server certificate
❏ Setting encryption strength
❏ Setting printer port
Configuring the printer port
1. Select Connect to a printer on the Internet or on a home or office network: in the Internet printing
(IPP) wizard.
2. Enter the URL using the format below.
https://IP address of network interface:443/EPSON_IPP_Printer

Windows XP

The printer driver installation procedure differs depending on the printing method you prefer.
How To 31
Epson Network Guide
LPR printing
Note:
If you are using EpsonNet Print, the setup procedure is different. See “About EpsonNet Print” on page 58 for details.
1. Click Start, click Control Panel, click Printers and Other Hardware, and then click Printers
and Faxes.
2. Under Printer Tasks, click Add a printer to start the Add Printer wizard, and then click Next.
3. Click Local printer attached to this computer, clear the Automatically detect and install
my Plug and Play printer check box, and then click Next.
Note:
You must clear the Automatically detect and install my Plug and Play printer check box because the printer is attached directly to the network, not to a Windows XP computer.
How To 32
Epson Network Guide
4. Select the Create a new port radio button, and then select Standard TCP/IP Port from the list.
Then click Next.
5. Enter the IP address of the network interface and then click Next.
How To 33
Epson Network Guide
6. If an error occurs, the following dialog box appears. Select the Standard radio button and then
select EPSON Network Printer. Click Next.
7. Click Finish.
8. See “Installing a printer driver” on page 35 to install the printer driver.
Internet printing
1. Click Start, click Control Panel, click Printers and Other Hardware, and then click Printers
and Faxes.
2. Under Printer Tasks, click Add a printer to start the Add Printer wizard, and then click Next.
3. Click A network printer, or a printer attached to another computer, and then click Next.
4. Select the Connect to a printer on the Internet or on a home or office network radio button.
5. Enter the URL of the target printer using the format below. The URL should be the same as the
URL you set on EpsonNet Config’s IPP configuration page.
http://IP address of printer:631/Printer name
How To 34
Epson Network Guide
Example: http://192.168.100.201:631/EPSON_IPP_Printer
Note:
To check the IP address of the network interface, use EpsonNet Config. See “About EpsonNet Config” on page 48 for details.
6. Follow the on-screen instructions to set up the printer. See “Installing a printer driver” on
page 35 if necessary.
Installing a printer driver
1. Insert the Software Disc shipped with the printer.
2. Close the Epson Install Navi screen if it appears.
3. On the Add Printer screen, click the Have Disk button. The Install From Disk dialog box appears.
4. Click Browse.
5. Select the CD-ROM drive for Drives, and double-click the WINX64 or WINX86 folder. Click
Open.
6. Click OK in the Install From Disk dialog box.
7. Select the model name of the printer, and then click Next.
How To 35
Note:
If the Add Printer wizard prompts you to select either Keep existing driver or Replace existing driver, be sure to select the Replace existing driver radio button.
8. Click Finish and follow the on-screen instructions to complete the setup.
Encrypting print data (Secure IPP printing)
Internet printing (IPP) enables you to encrypt data to print.
Required settings
Configure the following settings using EpsonNet Config with Web Browser. See “EpsonNet Config with Web Browser” on page 51 for details.
❏ Importing server certificate
❏ Selecting server certificate
Epson Network Guide
❏ Setting encryption strength
❏ Setting printer port
Configuring the printer port
1. Select Connect to a printer on the Internet or on a home or office network: in the Internet printing
(IPP) wizard.
2. Enter the URL using the format below.
https://IP address of network interface:443/EPSON_IPP_Printer

Windows Server 2003

The printer driver installation procedure differs depending on the printing method you prefer.
LPR printing
Note:
If you are using EpsonNet Print, the setup procedure is different. See “About EpsonNet Print” on page 58 for details.
How To 36
Epson Network Guide
1. Click Start, and then select Printers and Faxes.
2. Double-click the Add Printer icon to start the Add Printer wizard, and then click Next.
3. Click Local printer attached to this computer, clear the Automatically detect and install
my Plug and Play printer check box, and then click Next.
Note:
You must clear the Automatically detect and install my Plug and Play printer check box because the printer is attached directly to the network, not to a computer.
4. Select the Create a new port radio button, and then select Standard TCP/IP Port from the list.
Click Next.
How To 37
Epson Network Guide
5. When Add Standard TCP/IP Printer Port Wizard dialog box appears, click Next.
6. Enter the IP address of the network interface and then click Next.
7. If an error occurs, the following dialog box appears. Select the Standard radio button and then
select EPSON Network Printer. Click Next.
8. Click Finish.
9. See “Installing a printer driver” on page 39 to install the printer driver.
How To 38
Epson Network Guide
Internet printing
1. Click Start, and then select Printers and Faxes.
2. Double-click the Add Printer icon to start the Add Printer wizard, and then click Next.
3. Select A network printer, or a printer attached to another computer, and then click Next.
4. Select the Connect to a printer on the Internet or on a home or office network radio button.
5. Enter the URL of the target printer using the format below. The URL must be the same URL you set
on EpsonNet Config’s IPP configuration page.
http://IP address of printer:631/Printer name
Example: http://192.168.100.201:631/EPSON_IPP_Printer
Note:
To check the IP address of the network interface, use EpsonNet Config. See “About EpsonNet Config” on page 48 for details.
6. Follow the on-screen instructions to set up the printer. See “Installing a printer driver” on
page 39 if necessary.
Installing a printer driver
1. Insert the Software Disc shipped with the printer.
How To 39
Epson Network Guide
2. Close the Epson Install Navi screen if it appears.
3. On the Add Printer screen, click the Have Disk button. The Install From Disk dialog box appears.
4. Click Browse.
5. Select the CD-ROM drive for Drives, and double-click the WINX64 or WINX86 folder. Click
Open.
6. Click OK in the Install From Disk dialog box.
7. Select the model name of the printer, and then click Next.
Note:
If the Add Printer wizard prompts you to select either Keep existing driver or Replace existing driver, be sure to select the Replace existing driver radio button.
8. Click Finish and then follow the on-screen instructions to complete the setup.
Encrypting print data (Secure IPP printing)
Internet printing (IPP) enables you to encrypt data to print.
Required settings
Configure the following settings using EpsonNet Config with Web Browser. See “EpsonNet Config with Web Browser” on page 51 for details.
❏ Importing server certificate
❏ Selecting server certificate
❏ Setting encryption strength
❏ Setting printer port
Configuring the printer port
1. Select Connect to a printer on the Internet or on a home or office network: in the Internet printing
(IPP) wizard.
2. Enter the URL using the format below.
https://IP address of network interface:443/EPSON_IPP_Printer
How To 40
Epson Network Guide

Windows 2000

The printer driver installation procedure differs depending on the printing method you prefer.
LPR printing
Note:
If you are using EpsonNet Print, the setup procedure is different. See “About EpsonNet Print” on page 58 for details.
1. Click Start, point to Settings, and then select Printers.
2. Double-click Add Printer to start the Add Printer wizard, and then click Next.
3. Click Local printer, clear the Automatically detect and install my Plug and Play printer
check box, and then click Next.
Note:
You must clear the Automatically detect and install my Plug and Play printer check box because the printer is attached directly to the network, not to a Windows 2000 computer.
How To 41
Epson Network Guide
4. Select the Create a new port radio button, and then select Standard TCP/IP Port from the list.
Then click Next.
5. Enter the IP address of the network interface and then click Next.
How To 42
Epson Network Guide
6. If an error occurs, the following dialog box appears. Select the Standard radio button and then
select EPSON Network Printer. Click Next.
7. Click Finish.
8. See “Installing a printer driver” on page 44 to install the printer driver.
Internet printing
1. Click Start, point to Settings, and then select Printers.
2. Double-click Add Printer to start the Add Printer wizard, and then click Next.
3. Select the Network printer radio button and then click Next.
4. Select the Connect to a printer on the Internet or on your intranet radio button.
5. Enter the URL of the target printer using the format below. The URL should be the same as the
URL you set on EpsonNet Config’s IPP configuration page.
http://IP address of printer:631/Printer name
Example: http://192.168.100.201:631/EPSON_IPP_Printer
Note:
To check the IP address of the network interface, use EpsonNet Config. See “About EpsonNet Config” on page 48 for details.
How To 43
Epson Network Guide
6. Follow the on-screen instructions to set up the printer. See “Installing a printer driver” on
page 44 if necessary.
Installing a printer driver
1. Insert the Software Disc shipped with the printer.
2. Close the Epson Install Navi screen if it appears.
3. On the Add Printer screen, click the Have Disk button. The Install From Disk dialog box appears.
4. Click Browse.
5. Select the CD-ROM drive for Drives, and double-click the WINX64 or WINX86 folder. Click
Open.
6. Click OK in the Install From Disk dialog box.
7. Select the model name of the printer, and then click Next.
Note:
If the Add Printer wizard prompts you to select either Keep existing driver or Replace existing driver, be sure to select the Replace existing driver radio button.
8. Click Finish and follow the on-screen instructions to complete the setup.
Encrypting print data (Secure IPP printing)
Internet printing (IPP) enables you to encrypt data to print.
Required settings
Configure the following settings using EpsonNet Config with Web Browser. See “EpsonNet Config with Web Browser” on page 51 for details.
❏ Importing server certificate
❏ Selecting server certificate
❏ Setting encryption strength
❏ Setting printer port
How To 44
Epson Network Guide
Configuring the printer port
1. Select Connect to a printer on the Internet or on a home or office network: in the Internet printing
(IPP) wizard.
2. Enter the URL using the format below.
https://IP address of network interface:443/EPSON_IPP_Printer

Macintosh

Follow the steps below to set a printer.
Note:
Make sure that the printer driver is installed on your Macintosh before following the steps below. See the manual shipped with your printer for instruction on how to install the printer driver.
Mac OS X 10.5 or later
Bonjour printing
1. Open System Preferences.
2. Open Print & Fax.
3. Click the + button to add a new printer.
4. Select the desired printer model that is connected with Bonjour.
5. Click Add.
TCP/IP printing
1. Open System Preferences.
2. Open Print & Fax.
3. Click the + button to add a new printer.
4. Select the desired printer model.
How To 45
Epson Network Guide
5. If the desired printer model does not appear in the list, click More Printers, select EPSON TCP/IP
from the drop down list, and then select the printer model.
6. Click Add.
Mac OS X 10.4
Bonjour printing
1. Open the Applications folder.
2. Open the Utilities folder.
3. Open Printer Setup Utility and then click Add.
4. Select the printer model that is connected with Bonjour.
5. Click Add.
TCP/IP printing
1. Open the Applications folder.
2. Open the Utilities folder.
3. Open Printer Setup Utility and then click Add.
4. Click More Printers, select EPSON TCP/IP from the drop down list, and then select the printer
model.
5. Click Add.
AppleTalk printing
1. Open the Applications folder.
2. Open the Utilities folder.
3. Open Printer Setup Utility and then click Add.
4. Click More Printers, select EPSON Apple Talk from the drop down list, select the zone from the
drop down list, and then select the printer model.
How To 46
5. Click Add.
Epson Network Guide
How To 47
Epson Network Guide
Chapter 3

Network Software

This chapter explains how to use the network software provided with your printer.
Note:
The software provided varies depending on your printer model.

EpsonNet Config for Windows

About EpsonNet Config

EpsonNet Config is a Windows-based configuration software for administrators to configure the network interface for TCP/IP.
Note:
Be sure to use EpsonNet Config included on the Software Disc shipped with this product.
Note for Windows 98/Me/NT 4.0 users:
EpsonNet Config on the Software Disc shipped with this product does not support Windows 98, Me, and NT 4.0. To configure the network interface, use the previous version of the software (EpsonNet Config Ver.2). You can download EpsonNet Config Ver.2 from the Epson Web site. http://support.epson.net/netconfig_down.html

System Requirements

The following table lists the system requirements of EpsonNet Config.
Operating systems Windows 7
Windows Vista
Windows XP Professional/Home Edition
Windows Server 2008/Windows Server 2008 R2
Windows Server 2003/Windows Server 2003 R2
Windows 2000 Server/Professional
Memory 150 MB or more
Network Software 48
Epson Network Guide
Hard disk drive space 50 MB

Installing EpsonNet Config

Follow the steps below to install EpsonNet Config on your computer to configure the network interface.
Note:
❏ Log on to the operating system with an administrator account to install EpsonNet Config.
❏ If you add or delete protocols or services from your operating system after installing EpsonNet Config,
EpsonNet Config may not work correctly. If this happens, uninstall EpsonNet Config and then install it again.
1. Make sure all the applications are closed, then insert the Software Disc in the CD-ROM drive.
2. The Software Installation screen opens automatically.
If the Software Installation screen does not appear, double-click EPSETUP.EXE on the CD-ROM.
3. Click User Installation if it appears.
4. Click the Install Network Utility button.
5. Click the icon located next to EpsonNet Config Ver.3.
6. Follow the on-screen instructions to complete the installation.
Note:
If the Windows Security Alert window appears after you start EpsonNet Config, click the Allow access or Unblock button; otherwise the devices are not listed on the screen of EpsonNet Config.

Accessing the EpsonNet Config User’s Guide

The EpsonNet Config User’s Guide contains detailed information on EpsonNet Config. Follow the steps below to access the EpsonNet Config User’s Guide.
1. Click Start, point to Programs (for Windows 2000 users) or All Programs (for Windows 7,
Vista, XP, Server 2008, and Server 2003 users), select EpsonNet, and then select EpsonNet Config V3.
Network Software 49
Epson Network Guide
2. Click EpsonNet Config User’s Guide.
The EpsonNet Config User’s Guide appears. By clicking the links on the front page or contents page, you can get information on using EpsonNet Config.

EpsonNet Config for Macintosh

About EpsonNet Config

EpsonNet Config for Macintosh is a Macintosh-based configuration software for administrators that allows you to configure the network interface for TCP/IP.
Note:
Be sure to use EpsonNet Config included on the Software Disc shipped with this product.
Note for Mac OS 9 users:
E ps o nN e t Co n f ig o n th e S of t w ar e D is c s hi p p ed wi th t hi s p ro d u ct do es n ot s u pp o r t M a c OS 9. To c on f i gu re the network interface, use the previous version of the software (EpsonNet Config Ver.2). You can download EpsonNet Config Ver.2 from the Epson Web site. http://support.epson.net/netconfig_down.html

System Requirements

The following table lists the system requirements of EpsonNet Config.
Operating systems Mac OS 10.3.9 or higher
Java 1.4 or later is installed
Models PowerPC Macintosh/Intel Macintosh
Memory 150 MB or more
Hard disk drive space 50 MB

Installing EpsonNet Config

Follow the steps below to install EpsonNet Config to configure the network interface.
Network Software 50
Epson Network Guide
1. Make sure all the applications are closed, then insert the Software Disc in the CD-ROM drive.
EPSON folder opens automatically.
2. Select the Mac OS X icon in the EPSON folder, and then double-click it.
3. Click the Install Network Utility button.
4. Click the icon located next to EpsonNet Config Ver.3.
5. Follow the on-screen instructions to complete the installation.

Accessing the EpsonNet Config User’s Guide

The EpsonNet Config User’s Guide contains detailed information on EpsonNet Config. Follow the steps below to access the EpsonNet Config User’s Guide.
1. Double-click the Macintosh HD icon.
2. In the Applications folder, double-click the EpsonNet folder, and then double-click the
EpsonNet Config V3 folder. Finally, double-click the EpsonNet Config icon.
EpsonNet Config starts.
3. From the Help menu, select EpsonNet Config Help.
The EpsonNet Config User’s Guide appears. By clicking the links on the front page or contents page, you can get information on using EpsonNet Config.

EpsonNet Config with Web Browser

About EpsonNet Config

EpsonNet Config with Web Browser is a Web-based utility designed to configure the printer for use on a network.
Network Software 51
Epson Network Guide
By typing the IP address of the network interface for the URL in your browser, you can start EpsonNet Config to allow you to configure the network interface for TCP/IP, NetWare, MS Network, AppleTalk, IPP, and SNMP.
Supported Web browser
❏ Microsoft Internet Explorer version 6.0 or later
❏ Apple Safari version 5.0 or later
❏ Mozilla Firefox version 3.6 or later
❏ Opera version 10.63 or later
❏ Google Chrome version 8.0 or later
About Web browser setting
When running EpsonNet Config with Web Browser, be sure not to use a proxy server to access the Internet. If the Access the Internet using a proxy server check box is selected, you cannot use EpsonNet Config with Web Browser. Use the following steps to clear the Access the Internet using a proxy server check box.
1. Right-click the Internet Explorer icon on the desktop, and then select Properties.
2. Click the Connection tab.
3. Clear the Access the Internet using a proxy server check box.

Configuring the Network Interface Using Web-Based EpsonNet Config

After you have assigned an IP address to the network interface using EpsonNet EasyInstall, EpsonNet Config for Windows or Macintosh, or the arp/ping command, you can configure the network interface using Web-based EpsonNet Config.
Note:
❏ A Web browser must be installed on your computer.
❏ TCP/IP must be correctly set for the computer and the network interface.
❏ Do not run both EpsonNet Config for Windows or Macintosh and Web-based EpsonNet Config at
the same time.
Network Software 52
Epson Network Guide
❏ Your browser may restrict some characters you can use. For details, see your browser or operating
system documentation.
Follow the steps below to change the IP address using EpsonNet Config.
1. Turn on your printer.
2. Run EpsonNet Config using one of the following ways.
❏ Run EpsonNet Config for Windows or Macintosh. Select the printer you want to configure
from the list and then click Launch Browser.
❏ Open your browser, and then type in the IP address of the network interface directly. Do not
run EpsonNet Config for Windows or Macintosh.
http://IP address of network interface/
Example: http://192.168.100.201/
Note:
To check the IP address of the network interface, use EpsonNet Config. See “About EpsonNet Config” on page 48 for Windows users, or see “About EpsonNet Config” on page 50 for Macintosh users for details.
3. Click TCP/IP under Network on the Configuration menu to display the TCP/IP setting screen.
Note:
If you want to configure a protocol other than TCP/IP, configure the desired settings on Configuration - Network screen.
4. Select a method for acquiring the IP address. When you select Auto, DHCP becomes available and
assigns an IP address automatically. If you want to set the IP address manually, select Manual.
Note:
❏ The network administrator must check any changes made to the IP address settings.
❏ When Auto is selected, DHCP becomes available. To use the DHCP server, make sure it is
installed on your computer and correctly configured. See your operating system’s online help for detailed instructions.
❏ If Set Using Automatic Private IP Addressing (APIPA) is enabled, a private IP address is
automatically assigned to the network interface even when there are no DHCP servers on your system or your network.
Network Software 53
Epson Network Guide
❏ If the Dynamic DNS function is not supported, we recommend that you select Manual and then
enter an IP address. This is because if you select Auto, the IP address of the network interface changes every time you turn on the printer so that you need to change the printer port setting accordingly.
5. To assign an IP address manually, enter the IP address, the subnet mask, and the default gateway.
Be sure the IP address does not conflict with any other devices on the network.
Note:
If there is a server or a router functioning as a gateway, enter the IP address of the server or the router for the gateway address. If there is no gateway, leave the default values there.
6. If you want to get a private address between 169.254.1.1 and 169.254.254.254 automatically when
an IP address cannot be obtained by the DHCP server, leave it at Enable for Set Using Automatic Private IP Addressing (APIPA); otherwise, select Disable.
7. When setting an IP address using the ping command, select Enable for Set Using PING. Select
Disable when setting an IP address with EpsonNet Config; this prevents any unexpected change of the IP address.
8. Select Enable for Acquire DNS Server Address Automatically if you want to acquire the DNS
server address using the DHCP server.
If you want to enter the DNS server address manually, select Disable and then enter the IP address of the DNS server.
9. Select Enable for Acquire Host Name and Domain Name Automatically if you want to
acquire the host name and the domain name using the DHCP server.
If you want to specify manually, enter the host name and the domain name in the text boxes.
10. Select Enable for Register Network Interface Address to DNS Server if you want to register
the host name and domain name to the DNS server through the DHCP server that supports Dynamic DNS.
If you want to register the host name and the domain name directly to the DNS server, select Enable for Register Network Interface Address Directly to DNS Server.
11. Select Enable or Disable for Use Universal Plug and Play. Select Enable if you want to use the
Universal Plug and Play function on Windows Me or future operating systems.
Network Software 54
Epson Network Guide
12. Change the default Universal Plug and Play device name, if desired. This device name is used for
Windows that supports the Universal Plug and Play function.
13. Mac OS X only:
Select Enable or Disable for Use Bonjour. If you select Enable, enter the Bonjour Name and the Bonjour Printer Name. If your network environment supports DHCP, you can use the printer on the network just by enabling this setting.
14. Click Submit and then enter the password to update the settings.
Note:
If you have set the Administrator Name on the Administrator screen, enter the administrator name for the user name.
15. If the message “Configuration change is complete!” appears on your screen, the update is
complete. Do not exit the Web browser and do not send a job to the printer until this message appears. Follow the on-screen instructions to reset the printer.
Note:
❏ Since the new IP address becomes available after the printer is reset, you need to restart EpsonNet
Config by entering the new IP address.
❏ Only changes on the page where you press the Submit button take effect.

Opening Screen

Any user can access the following screen by typing the IP address of the network interface for the URL in your browser.
Note:
❏ The item appears only if your printer supports the function, and the name of the item may vary
depending on the model.
❏ See the EpsonNet Config with Web Browser help for details about each item.
Index
Home Links to the opening screen.
Favorite Links to a Web site previously defined by the administrator.
Help Links to Help.
Network Software 55
Menu
Epson Network Guide
About Links to the copyright and version information for EpsonNet Config.
EPSON Logo Links to the Epson Web site (http://www.epson.com).
Information - Printer
Device Displays the printer device information.
Consumables Displays the consumables information.
Confirmation Confirms and executes the Information Sheet, Reserve Job, and Form Overlay.
Input Displays the paper type information.
Print Displays the print information.
Emulation Displays the information for each type of emulation.
Interface Displays the printer interface information.
Energy Saver Displays the information for power saving settings.
Information - Network
General Displays the network interface information.
NetWare Displays information about NetWare.
TCP/IP Displays information about TCP/IP.
AppleTalk Displays information about AppleTalk.
MS Network Displays information about Microsoft Network.
IPP Displays information about IPP.
SNMP Displays information about SNMP.
Access Control Displays information about Access Control.
Timeout Displays information about Timeout.
Time Displays information about Time.
EDM Displays the EDM Agent information.
Configuration - Printer
Input Change the input settings.
*
Network Software 56
Print Change the print settings.
Emulation Change the emulation settings.
Interface Change the printer interface settings.
Energy Saver Changes the power saving settings.
Configuration - Network
NetWare Configure the applicable settings for NetWare.
TCP/IP Configure the desired settings/method for TCP/IP.
AppleTalk Configure the desired settings for AppleTalk.
MS Network Configure the desired settings for Microsoft Network.
IPP Configure the desired settings for IPP.
SNMP Configure the desired settings for SNMP.
Epson Network Guide
Access Control Configure the desired settings for Access Control.
Timeout Configure the desired settings for Timeout.
Time Configure the desired settings for Time.
Configuration - Security Screens
Port Control Select either Enable or Disable for each of the LPR, RAW, FTP, and IPP ports.
SSL/TLS Communication Settings
CA Certificate Import or delete CA certificates.
Server Certificate Manage server certificates.
Configuration - Optional
Administrator Type the name of the administrator and a link to a favorite Web site.
Reset Resets the printer and returns to the default settings.
Password Set the password to protect settings.
* Large format inkjet printers do not support this function.
Configure the desired settings for SSL/TLS communication.
*
Network Software 57
Epson Network Guide

EpsonNet Print

About EpsonNet Print

EpsonNet Print is a utility program that provides peer to peer printing to Epson printers on the TCP/ IP network.
By using EpsonNet Print, you can find a printer located in the same segment or beyond a router. You can select LPR standard printing, LPR enhanced printing, or High-speed printing.
Note:
EpsonNet Print does not support IPv6 environment.

System Requirements

The following table lists the system requirements of EpsonNet Print.
Operating systems Windows 7
Windows Vista (with Service Pack 2 or higher)
Windows XP Home Edition/Professional (with Service Pack 3 or higher)
Windows Me, 98, 98 Second Edition
Windows 95 OSR2 (with Internet Explorer version 5.0 or higher)
Windows Server 2008 (with Service Pack 2 or higher)
Windows Server 2008 R2
Windows Server 2003 (with Service Pack 2 or higher)
Windows 2000 (with Service Pack 4 or higher)
Windows NT 4.0 (with Service Pack 6 or higher)
CPU Pentium II 400 MHz or better recommended
Memory 64 MB or more
Hard disk space 20 MB or more
Display
800 × 600 screen resolution, 256 color or more
Network Software 58
Epson Network Guide

Installing EpsonNet Print

Follow the steps below to install EpsonNet Print. Be sure to install it on a computer connected to the network.
1. Make sure all the applications are closed, then insert the Software Disc into the CD-ROM drive.
2. The Epson Install Navi screen opens automatically.
If the Epson Install Navi screen does not appear, double-click EPSETUP.EXE on the CD-ROM.
3. Click the Software List icon.
4. Select EpsonNet Print and then click the Next button.
5. Follow the on-screen instructions to complete the installation.
Your computer is now set up to print using LPR via EpsonNet Print. See the next section to set up your printer.

For Windows 7/Vista/XP/Server 2008/Server 2003/2000/NT 4.0 Users

Follow the steps below to add a port using the Add Printer Wizard.
❏ If you want to add a port for a printer with its IP address assigned automatically by the DHCP
server or router, see “Adding a port for a printer assigned with a dynamic IP address” on page 59.
❏ If you want to add a port for a printer with its IP address assigned manually, see “Adding a port for
a printer assigned with a static IP address” on page 63.
Note:
❏ Be sure that the computer is connected to the network and TCP/IP is correctly set.
❏ A valid IP address must be assigned to the printer.
Adding a port for a printer assigned with a dynamic IP address
1. For Windows 7/Vista/Server 2008: Click Start, Control Panel, and then View devices and
printers (Windows 7), or Printers (Windows Vista/Server 2008). Click Add a printer to start the
Add Printer Wizard.
Network Software 59
Epson Network Guide
For Windows XP: Click Start and then Printers and Faxes. Under Printer Tasks, click Add a printer to start the Add Printer Wizard. Click Next.
For Windows Server 2003: Click Start and then Printers and Faxes. Double-click Add Printer in the Printers folder to start the Add Printer Wizard. Click Next.
For Windows 2000: Click Start, point to Settings, and then select Printers. Double-click Add Printer in the Printers folder to start the Add Printer Wizard. Click Next.
For Windows NT 4.0: Click Start, point to Settings, and then select Printers. Double-click the Add Printers icon. Click Next.
2. For Windows 7/Vista/Server 2008: Click Add a local printer. Select the Create a new port
radio button, and then select EpsonNet Print Port from the list. Click Next.
Note:
If the Windows Security Alert screen appears, click the Allow access or Unblock button, and then click the Search Again button to search the printers.
For Windows XP/Server 2003: Click Local printer attached to this computer, clear the Automatically detect and install my Plug and Play printer check box, and then click Next.
Select the Create a new port radio button, and then select EpsonNet Print Port from the list. Click Next.
Note:
If the Windows Security Alert screen appears, click the Unblock button, and then click the Search Again button to search the printers.
For Windows 2000: Click Local printer, clear the
Automatically detect and install my Plug and Play printer check box, and then click Next. Select the Create a new port radio button, and then select EpsonNet Print Port from the list. Click Next.
For Windows NT 4.0: Select the My Computer radio button, and then click Next. Click the Add Port button in the Add Printer Wizard dialog box. Select EpsonNet Print Port from the Available Printer Port list, and then click the New Port button.
Network Software 60
Epson Network Guide
3. Select the target printer, and then click Next.
Note:
❏ If the target printer is not in the list, click the Search Again button to search the printers using
new parameters.
❏ Each column can be sorted in ascending or descending order by clicking the column header.
However, Manual Setting is always displayed on the top of the list regardless of sorting.
❏ If you want to search printers in other segments, click the N/W Settings button. Select the
Specific Network Segments check box, and then enter the network address and subnet mask of
the network segment for the search. Then click the Add button. You can also specify the time before declaring communication error.
Network Software 61
Epson Network Guide
4. Confirm the information about the printer’s port you want to configure, and then click Finish.
Items Explanations
Port Type The following items are listed in the pull-down menu, and you can select the port
type you need.
IP Address (Auto): Configure the port automatically. If the IP address of the printer is acquired automatically and the computer and the printer are in the same segment, you can select this port type.
IP Address (Manual): Use the printer’s IP Address for the port name.
HostName (DNS): Use the printer’s host name registered in the DNS server for the
port name.
MS Network: Use the NetBIOS name registered in the printer for the port name.
The port Information The following items are displayed:
- Port Name (If the port type is changed, the port name and the host name or IP address are also changed.)
- Printer Model
- Host Name or IP Address
- Protocol
Finish button Register the port information to the system and close the Add EpsonNet Print Port
Wizard.
Back button Go back to the printer list window.
Cancel button Close the Add EpsonNet Print Port Wizard.
The new printer port is created in your computer. To install the printer driver, see “Installing the Printer Driver” on page 65.
Network Software 62
Epson Network Guide
Adding a port for a printer assigned with a static IP address
1. For Windows 7/Vista/Server 2008: Click Start, Control Panel, and then View devices and printers (Windows 7), or Printers (Windows Vista/Server 2008). Click Add a printer to start the
Add Printer Wizard.
For Windows XP: Click Start and then Printers and Faxes. Under Printer Tasks, click Add a printer to start the Add Printer Wizard. Click Next.
For Windows Server 2003: Click Start and then Printers and Faxes. Double-click Add Printer in the Printers folder to start the Add Printer Wizard. Click Next.
For Windows 2000: Click Start, point to Settings, and then select Printers. Double-click Add Printer in the Printers folder to start the Add Printer Wizard. Click Next.
For Windows NT 4.0: Click Start, point to Settings, and then select Printers. Double-click the Add Printers icon. Click Next.
2. For Windows 7/Vista/Server 2008: Click Add a local printer. Select the Create a new port radio button, and then select EpsonNet Print Port from the list. Click Next.
Note:
If the Windows Security Alert screen appears, click the Allow access or Unblock button, and then click the Search Again button to search the printers.
For Windows XP/Server 2003: Click Local printer attached to this computer, clear the Automatically detect and install my Plug and Play printer check box, and then click Next.
Select the Create a new port radio button, and then select EpsonNet Print Port
from the list.
Click Next.
Note:
If the Windows Security Alert screen appears, click the Unblock button, and then click the Search Again button to search the printers.
For Windows 2000: Click Local printer, clear the Automatically detect and install my Plug and Play printer check box, and then click Next. Select the Create a new port radio button, and then select EpsonNet Print Port from the list. Click Next.
For Windows NT 4.0: Select the My Computer radio button, and then click Next. Click the Add Port button in the Add Printer wizard dialog box. Select EpsonNet Print Port from the Available Printer Port list, and then click the New Port button.
Network Software 63
Epson Network Guide
3. Select Manual Setting from the list, and then click Next.
4. Enter the printer’s name and the port name is automatically entered to the Port Name edit box. Then click Next.
Network Software 64
Epson Network Guide
5. Confirm the information about the printer’s port you want to configure, and then click Finish.
Items Explanations
The port Information The following items are displayed:
- Port Name
- Host Name or IP Address
- Protocol
Finish button Register the port information to the system and close the Add EpsonNet Print Port
Wizard.
Back button Go back to the printer list window.
Cancel button Close the Add EpsonNet Print Port Wizard.
The new printer port is created in your computer. To install the printer driver, see “Installing the Printer Driver” on page 65.
Installing the Printer Driver
Install the printer driver that comes with your printer.
Note:
Some buttons in these steps may be slightly different depending on your operating system.
1. Insert the Software Disc shipped with the printer.
2. Close the Epson Install Navi screen if it appears.
Network Software 65
Epson Network Guide
3. On the Add Printer screen, click the Have Disk button. The Install From Disk dialog box appears.
4. Click Browse.
5. Select the CD-ROM drive for Drives, and double-click the appropriate folder for your operating system. Click OK.
6. Click OK in the Install From Disk dialog box.
7. Select the model name of the printer, and then click Next.
Note:
If the Add Printer Wizard asks you to select either Keep existing driver or Replace existing driver, be sure to select the Replace existing driver radio button. Click Next.
8. Click Finish and follow the on-screen instructions to complete the setup.
The printer is now ready for peer-to-peer printing. To configure the printer port, see “Configuring the Printer Port” on page 71.

For Windows Me/98/95 Users

Follow the steps below to add a port using the Add Printer Wizard.
❏ If you want to add a port for the printer with its IP address assigned automatically from the DHCP
server or router, see “Adding a port for a printer assigned with a dynamic IP address” on page 66.
❏ If you want to add a port for the printer with its IP address assigned manually, see “Adding a port
for a printer assigned with a static IP address” on page 69.
Note:
❏ Be sure that the computer is connected to the network and TCP/IP is correctly set.
❏ Be sure that the target Epson printer driver is installed on the computer.
❏ A valid IP address must be assigned to the printer.
Adding a port for a printer assigned with a dynamic IP address
Install the printer driver before adding a port for the printer. See the manual shipped with your printer for instructions on how to install the printer driver.
Network Software 66
Epson Network Guide
1. Click Start, point to Settings, and then select Printers.
2. Right-click the target printer icon, and then select Properties.
3. Click the Details tab, and then click the Add Port button. Select the Other radio button, and then select EpsonNet Print Port. Click OK.
4. Select the target printer, and then click Next.
Note:
❏ If the target printer is not in the list, click the Search Again button to search the printers using
new parameters.
❏ Each column can be sorted in ascending or descending order by clicking the column header.
However, Manual Setting is always displayed on the top of the list regardless of sorting.
Network Software 67
Epson Network Guide
❏ If you want to search printers in other segments, click the N/W Settings button. Select the
Specific Network Segments check box, and then enter the network address and subnet mask of
the network segment for the search. Then click the Add button. You can also specify the time before declaring communication error.
5. Confirm the information about the printer’s port you want to configure, and then click Finish.
Network Software 68
Epson Network Guide
Items Explanations
Port Type The following items are listed in the pull-down menu, and you can select the port
type you need.
IP Address (Auto): Configure the port automatically. If the IP address of the printer is acquired automatically and the computer and the printer are in the same segment, you can select this port type.
IP Address (Manual): Use the printer’s IP Address for the port name.
HostName (DNS): Use the printer’s host name registered in the DNS server for the
port name.
MS Network: Use the NetBIOS name registered in the printer for the port name.
The port Information The following items are displayed:
- Port Name (If the port type is changed, the port name and the host name or IP address are also changed.)
- Printer Model
- Host Name or IP Address
- Protocol
Finish button Register the port information to the system and close the Add EpsonNet Print Port
Wizard.
Back button Go back to the printer list window.
Cancel button Close the Add EpsonNet Print Port Wizard.
The printer is now ready for peer-to-peer printing. To configure the printer port, see “Configuring the Printer Port” on page 71.
Adding a port for a printer assigned with a static IP address
Install the printer driver before adding a port for the printer. See the manual shipped with your printer for instructions on how to install the printer driver.
1. Click Start, point to Settings, and then select Printers.
2. Right-click the target printer icon, and then select Properties.
3. Click the Details tab, and then click the Add Port button. Select the Other radio button, and then select EpsonNet Print Port. Click OK.
Network Software 69
Epson Network Guide
4. Select Manual Setting from the list, and then click Next.
5. Enter the printer’s name and the port name is automatically entered to the Port Name edit box. Then click Next.
Network Software 70
Epson Network Guide
6. Confirm the information about the printer’s port you want to configure, and then click Finish.
Items Explanations
The port Information The following items are displayed:
- Port Name
- Host Name or IP Address
- Protocol
Finish button Register the port information to the system and close the Add EpsonNet Print Port
Wizard.
Back button Go back to the printer list window.
Cancel button Close the Add EpsonNet Print Port Wizard.
The printer is now ready for peer-to-peer printing. To configure the printer port, see “Configuring the Printer Port” on page 71.

Configuring the Printer Port

Follow the steps below to configure the printer port. The printing speed differs depending on your selection.
1. For Windows 7/Vista/Server 2008: Click Start, Control Panel, and then View devices and printers (Windows 7) or Printers (Windows Vista/Server 2008).
Network Software 71
For Windows XP/Server 2003:
Click Start and then Printers and Faxes.
For Windows Me/98/95/2000/NT 4.0:
Click Start, point to Settings, and then select Printers.
2. Right-click the target printer, and then click Properties.
3. For Windows Vista/XP/Server 2008/Server 2003/2000/NT 4.0: Click the Ports tab, and then click the Configure Port button.
For Windows Me/98/95:
Click the Details tab, and then click the Port Settings button.
4. Make the appropriate settings for the desired port.
Epson Network Guide
LPR enhanced printing:
Select the LPR Printing radio button, and then specify the queue name (up to 32 characters). LPR enhanced printing sends a print job to the target network printer without spooling all of the print data. LPR enhanced printing is faster than LPR standard printing.
LPR standard printing:
Select the Confirm file size check box, and then specify the queue name (up to 32 characters). Print data is spooled by the computer before being sent to the target network printer.
Note:
When the print data size is 20 MB or more, we recommend that you use LPR enhanced printing.
Network Software 72
Epson Network Guide
High-speed printing:
Select the High-Speed Printing (RAW) radio button. The Epson high-speed printing port sends a print job to the target network printer without spooling all of the print data. High-Speed printing is faster than the other two printing methods.
5. Click OK.
If you select the High-Speed Printing (RAW) radio button and if the printer does not support High-Speed printing, or if you fail to connect to the printer, an error message appears. Follow the message to remedy the problem.
Network Software 73
Epson Network Guide
Chapter 4

Troubleshooting

General Problems

Cannot configure the network interface or cannot print from the network.

Cause What to do
The printer settings or network settings may be wrong.
First, check to see if you can print a status sheet, as described in “Printing a Network Status Sheet” on page 76. If you can print a status sheet, check the network settings; otherwise, set the interface mode of the printer’s control panel to Auto or Option.

Cannot print even if you have assigned the IP address to the computer and the printer.

Cause What to do
You have assigned an IP address to the computer manually, but you assigned the IP address to the printer by Automatic Private IP Addressing (APIPA).
Assign the printer’s IP address so that it belongs to the same segment of the computer. Use EpsonNet Config and the printer’s control panel.

Unable to start EpsonNet Config.

Cause What to do
You have added or deleted protocols after installing EpsonNet Config.
Uninstall EpsonNet Config and then reinstall it. See “Installing EpsonNet Config” on page 49.
Troubleshooting 74
Epson Network Guide
The message “EpsonNet Config cannot be used because no network is installed.” appears when you start EpsonNet Config.
Cause What to do
Both TCP/IP and IPX/SPX are not installed on the computer.
TCP/IP is installed on the computer, but its IP address is not set correctly.
Install the TCP/IP or IPX/SPX protocol.
Set a correct IP address for the computer.
The message “Could not complete communicating configuration data” appears when you send settings to the network interface.
Cause What to do
This may happen when using a dial-up router.
Run Command Prompt from the computer on which EpsonNet Config is installed, and then enter the following command:
Format: >ROUTE_ADD_the IP address of the network interface_ the IP address of the computer (the under bar represents one space)
Example: >ROUTE ADD 192.168.192.168 22.33.44.55.

Unable to start EpsonNet Config with Web Browser.

Cause What to do
You have not set the IP address for the network interface.
Set the IP address for the network interface using EpsonNet Config for Windows or Macintosh, the printer’s control panel. You can check the IP address on a status sheet. See the EpsonNet Config User’s Guide.
Troubleshooting 75
Epson Network Guide

The Model Name and IP Address do not appear in the EpsonNet Config dialog box.

Cause What to do
If the valid IP address is not set, the items indicated in the dialog box mentioned above may not appear.
Set a valid IP address.
Refresh the status by selecting Refresh from the View menu.
In cre ase the len gth o f ti me b efo re a tim eout . To do t his , se lec t Options from the Tool menu, and then select Timeout. Note that doing so can cause EpsonNet Config to run more slowly.

An extra account is generated when using the dial-up network.

Cause What to do
NetWare is set to Enable even though you are not using NetWare.
How to acquire an IP address.
To acquire your IP address, you need to apply to the NIC (Network Information Center) in your country.
Set NetWare to Disable on the NetWare screen of EpsonNet Config with Web Browser.

Printing a Network Status Sheet

Before you start configuring the network interface, be sure to print a network status sheet that contains important information such as the current configuration and the MAC address of the network interface.
To print a network status sheet, follow the steps below.
Note:
You cannot print a status sheet using the steps below if your printer does not have an LCD panel. See the User’s Guide on how to print the status sheet.
1. Press the Right button on the printer’s control panel once to enter the SelecType mode. The LCD panel displays Information Menu.
2. Press the Right button.
3. Press the Down button until Network Status Sheet appears on the LCD panel.
Troubleshooting 76
Epson Network Guide
4. Finally, press the Right button to print a network status sheet.
Note:
❏ You cannot print a status sheet in the following cases: the printer has started printing, it is offline, or it
is not ready to print.
❏ See the User’s Guide for more information on the printer’s control panel.

Printing a Network Status Sheet (Large Format Inkjet Printers)

Before you start configuring the network interface, be sure to print a network status sheet that contains important information such as the current configuration and the MAC address of the network interface. To print a network status sheet, follow the steps below.
Note:
You cannot print a status sheet using the steps below if your printer does not have an LCD panel. See the User’s Guide on how to print the status sheet.
1. Press the Right button on the printer’s control panel once to enter the Menu mode.
2. Press the Up or Down button until TEST PRINT appears. Then press the Enter button.
3. Press the Down button until NETWORK STATUS SHEET appears on the LCD panel. Then press the Enter button.
4. Finally, press the Enter button to print a network status sheet.
Note:
❏ You cannot print a status sheet in the following cases: the printer has started printing, it is offline, or it
is not ready to print.
❏ See the User’s Guide for more information on the printer’s control panel.

Initializing Your Printer

To initialize your printer, turn on the printer while pressing the Cancel Job button on the printer’s control panel.
Troubleshooting 77
Note:
Some printer models do not support this function.
Caution:
c
Note that all changes made to the printer and network settings are cleared when you initialize the printer using this method. Therefore, do not initialize your printer except in the case you forget the EpsonNet Config password.

Reformatting the Hard Disk Drive

To reformat the Hard Disk Drive, follow the instructions below.
Note:
Some printer models do not support this function.
Epson Network Guide
1. Make sure the printer is turned off.
2. Hold down the Down button while you turn on the printer.
3. When you see the message Support Mode on the LCD panel, select HDD Format in the support menu.
Note:
❏ After reformatting the Hard Disk Drive, the printer will automatically reboot.
❏ When you want to erase only the fonts installed from the Adobe PostScript 3 (PS3), follow steps 1
through 3 above. Select PS3 HDD Init when the Adobe PostScript 3 ROM is installed.
❏ When installing a Hard Disk Drive from a different printer, reformat it with this function.
Troubleshooting 78
Epson Network Guide
Chapter 5

Tips for Administrator

Setting an IP Address on the Printer’s Control Panel

After connecting the printer to the network, you need to set the IP address for the network interface.
To set the IP address, subnet mask, and default gateway from the control panel, follow the steps below.
Note:
If you are using a printer model that does not have an LCD panel, you cannot use the steps below.
1. Turn on your printer.
2. Press the Right button on the printer’s control panel once to enter the SelecType mode. The LCD panel displays Information Menu.
3. Press the Up or Down button until Network Menu appears. Then press the Right button.
4. Check that Network I/F = On appears.
If Network I/F = Off appears instead, press the Right button and then the Up or Down button to change to Network I/F = On. Then press the Right button, turn off the printer for more than five seconds, and turn it back on.
5. Press the Up or Down button until Get IP Address = Auto appears. Press the Right button and then the Up or Down button to change to Get IP Address = Panel. Then press the Right button. You can use the following methods to get an IP address.
❏ Choose Panel when setting the IP address, subnet mask, and default gateway using the
printer’s control panel.
❏ Choose Auto when getting the IP address from a DHCP server. The IP address is automatically
obtained from the DHCP server whenever the printer is reset or turned on.
❏ Choose PING when setting the IP address using the arp/ping command. The network interface
uses the IP address set by the arp/ping command. The settings become available when the printer is reset or turned off and then back on.
Tips for Administrator 79
Epson Network Guide
Note:
❏ To use Auto, a DHCP server must be correctly configured on the network. See the online help of
your operating system for detailed instructions.
❏ Choose PING only when setting the IP address using the arp/ping command.
6. Press the Up or Down button until IP = xxx.xxx.xxx.xxx appears. Press the Right button.
7. Press the Up or Down button until the desired value appears. Then press the Right button to set the value.
Note:
Repeat steps 7 and 8 to set the IP address, subnet mask, and default gateway.
8. Press the Start button to exit the control panel menus.
9. Turn off your printer and then turn it back on. Be sure to wait until the initialization is complete.
Print a network status sheet to confirm the new IP address.
Note:
❏ You must first set the IP address before using EpsonNet Config with Web Browser.
❏ See the User’s Guide for more information about settings on the printer’s control panel.

Network Menu

These items are used to make network settings on the printer’s control panel.
Item Settings
Network I/F On, Off
Get IPAddress Panel, Auto, PING
IP 0.0.0.1 to 255.255.255.254
SM 0.0.0.0 to 255.255.255.255
GW 0.0.0.0 to 255.255.255.255
AppleTalk On, Off
MS Network On, Off
Tips for Administrator 80
Epson Network Guide
Item Settings
WSD On, Off
LLTD On, Off
Bonjour On, Off
IPv6 On, Off
IPSec On, Off
Pre-Shared Key Enter the pre-shared key (up to 20 characters).
Link Speed Auto, 100 Full, 100 Half, 10 Full, 10 Half
Buffer Size Normal, Maximum, Minimum
Note:
❏ To activate the Network Menu settings, you must turn off the printer for more than five seconds and
then turn it back on. Or, you can perform a Reset All operation, as explained in “Reset Menu” in the User’s Guide.
❏ Resetting the printer erases all print jobs. Make sure the Ready light is not flashing when you reset the
printer.

AUX Menu

This menu allows you to control the optional interface settings from the printer’s control panel.
Note:
The AUX Menu appears only when an optional interface is installed.
Item Settings
AUX I/F On, Off
Get IPAddress* Panel, Auto, PING
IP* 0.0.0.0 to 255.255.255.254
SM* 0.0.0.0 to 255.255.255.255
GW* 0.0.0.0 to 255.255.255.255
NetWare* On, Off
AppleTalk* On, Off
Tips for Administrator 81
Epson Network Guide
Item Settings
MS Network* On, Off
Bonjour* On, Off
AUX Init* -
Buffer Size* Normal, Maximum, Minimum
* Available only when On is selected as the AUX I/F setting.
AUX I/F
Allows you to activate or deactivate the AUX interface when an optional interface card is installed.
Buffer Size
Determines the amount of memory to be used for receiving data and printing data. If Maximum is selected, more memory is allocated for receiving data. If Minimum is selected, more memory is allocated for printing data.
Note:
❏ To activate Buffer Size settings, you must turn off the printer for more than five seconds then turn it
back on. Or, you can perform a Reset All operation, as explained in “Reset Menu” in the User’s Guide.
❏ Resetting the printer erases all print jobs. Make sure the Ready light is not flashing when you reset the
printer.

Setting an IP Address on the Printer’s Control Panel (Large Format Inkjet Printers)

After connecting the printer to the network, you need to set the IP address for the network interface.
To set the IP address, subnet mask, and default gateway from the control panel, follow the steps below.
1. Turn on your printer.
2. Press the Right button on the printer’s control panel once to display MENU.
3. Press the Down button until NETWORK SETUP appears. Then press the Right button.
Tips for Administrator 82
Epson Network Guide
4. Select NETWORK SETUP, then press the Right button.
5. Select ENABLE, then press the Enter button to enable the network settings menu.
6. Press the Left button to display the NETWORK SETUP menu.
7. Press the Down button to select IP ADDRESS SETTING, then press the Right button. You can use the following methods to get an IP address.
❏ Choose Auto when getting the IP address from a DHCP server. The IP address is automatically
obtained from the DHCP server whenever the printer is reset or turned on.
❏ Choose Panel when setting the IP address, subnet mask, and default gateway using the
printer’s control panel.
Note:
❏ To use Auto, a DHCP server must be correctly configured on the network. See the online help of
your operating system for detailed instructions.
❏ Choose PING only when setting the IP address using the arp/ping command.
8. Select PANEL, then press the Enter button. Press the Left button to return to the NETWORK SETUP menu.
9. Press the Down button to select IP, SM, or GW, then press the Right button.
10. Press the Up or Down button on the IP ADDRESS screen until the desired value appears. Then press the Right button.
11. Press the Up or Down button on the SUBNET MASK screen until the desired value appears. Then press the Enter button.
12. Press the Up or Down button on the DEFAULT GATEWAY screen until the desired value appears. Then press the Enter button to set the values.
13. Press the Left button twice to exit the control panel menus.
14. Turn off your printer and then turn it back on. Be sure to wait until the initialization is complete.
Print a network status sheet to confirm the new IP address.
Tips for Administrator 83
Note:
❏ You must first set the IP address before using EpsonNet Config with Web Browser.
❏ See the User’s Guide for more information about settings on the printer’s control panel.

Network Setup Menu

These items are used to make network settings on the printer’s control panel.
Note:
The available settings vary depending on your printer model.
Item Settings
NETWORK SETUP Disable, Enable
IP ADDRESS SETTING* Auto, Panel, PING
Epson Network Guide
IP* 0.0.0.0 to 255.255.255.254
SM* 0.0.0.0 to 255.255.255.255
GW* 0.0.0.0 to 255.255.255.255
AppleTalk* On, Off
MS Network* On, Off
Bonjour* On, Off
WSD* On, Off
INIT NETWORK SETTING*
* Available only when Enable is selected for NETWORK SETUP.
EXECUTE

Instructions on Using a Dial-Up Router

This section describes instructions on using a dial-up router.
I f D HC P i s u se d t o a ss ig n a n I P address of the printer and the Dynamic DNS function is not supported, you need to change the printer port setting every time you turn on the printer. Therefore, we recommend that you set a valid IP address for the network interface by using the one of the following methods.
Tips for Administrator 84
Epson Network Guide
❏ Set the IP address for the network interface manually. Use EpsonNet Config. See the EpsonNet
Config User’s Guide for details.
❏ Specify the network interface by using the bind of DHCP function.
❏ Set the exclusive address of the DHCP function.
Note:
See the manual of the Dial-Up router for more information on scope range, bind, exclusive address of the DHCP function.

Function of Universal Plug and Play

When you connect your printer to the network, the printer is automatically assigned with an IP address, and the printer’s icon appears in the My Network Places folder. By double-clicking the printer’s icon, you can access EpsonNet Config with Web Browser for basic information about the printer, such as manufacturer, model name, location, and administrator’s name.
Right-click the printer’s icon in the My Network Places folder and select Properties. You can check the brief information of the network interface.
To use this function, the Universal Plug and Play must be installed on Windows Me or future operating systems. For information on how to install Universal Plug and Play, see the Windows Me online help.
Note:
Before using the Universal Plug and Play function, you must enable the Universal Plug and Play function in EpsonNet Config. See the EpsonNet Config User’s Guide or “Configuring the Network Interface Using Web-Based EpsonNet Config” on page 52.

Secure Communication Using IPSec and Access Control

This product supports secure data communication using the IPSec protocol and the access control function.
IPSec Access control
Data format Encrypted data Unencrypted data
Tips for Administrator 85
IPSec Access control
Epson Network Guide
Supported operating systems
Windows 7/Windows Vista All operating systems supported by
this product

IPSec protocol

IPSec is a protocol that is suitable for securing IP communication by encrypting the data or by authenticating client users in a network. To use this function, make the necessary settings on your printer using EpsonNet Config with Web Browser. Security settings on the client computers on the network are also required. For details on the settings, r ef er t o th e Ep so nNe t Co nfi g w ith Web Bro ws er help.

Access control

Access control function allows you to restrict network access to the printer.
❏ Restrict access to the printer from specified client users only
❏ Restrict data communication to the printer to specified purposes only (such as accessing
administrative information by the administrators)
To use this function, make the necessary settings on your printer using EpsonNet Config with Web Browser. For details on the settings, refer to the EpsonNet Config with Web Browser help.
Tips for Administrator 86
Appendix A

Software License Terms

Open Source Software Licenses

Bonjour

This product contains the Apache Software.
Copyright © 2009 SEIKO EPSON CORPORATION
Licensed under the Apache License, Version 2.0 (the “License”); you may not use this file except in compliance with the License.
Epson Network Guide
You may obtain a copy of the License at http://www.apache.org/licenses/LICENSE-2.0
Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an “AS IS” BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.
This product contains the Linux Name Service Switch code.
The Linux Name Service Switch code, contributed by National ICT Australia Ltd (NICTA) is licensed under the NICTA Public Source License version 1.0
NICTA Public Software Licence
Version 1.0
Copyright 2004 National ICT Australia Ltd
All rights reserved.
Software License Terms 87
Epson Network Guide
EXCEPT AS EXPRESSLY STATED IN THIS LICENCE AND TO THE FULL EXTENT PERMITTED BY APPLICABLE LAW, THE SOFTWARE IS PROVIDED “AS IS” AND NICTA MAKES NO REPRESENTATIONS, WARRANTIES OR CONDITIONS OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, ANY REPRESENTATIONS, WARRANTIES OR CONDITIONS REGARDING THE CONTENTS OR ACCURACY OF THE SOFTWARE, OR OF TITLE, MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, NONINFRINGEMENT, THE ABSENCE OF LATENT OR OTHER DEFECTS, OR THE PRESENCE OR ABSENCE OF ERRORS, WHETHER OR NOT DISCOVERABLE.
TO THE FULL EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT WILL NICTA BE LIABLE ON ANY LEGAL THEORY (INCLUDING, WITHOUT LIMITATION, NEGLIGENCE) FOR ANY LOSS OR DAMAGE WHATSOEVER, INCLUDING (WITHOUT LIMITATION) LOSS OF PRODUCTION OR OPERATION TIME, LOSS, DAMAGE OR CORRUPTION OF DATA OR RECORDS; OR LOSS OF ANTICIPATED SAVINGS, OPPORTUNITY, REVENUE, PROFIT OR GOODWILL, OR OTHER ECONOMIC LOSS; OR ANY SPECIAL, INCIDENTAL, INDIRECT, CONSEQUENTIAL, PUNITIVE OR EXEMPLARY DAMAGES ARISING OUT OF OR IN CONNECTION WITH THIS LICENCE, THE SOFTWARE OR THE USE OF THE SOFTWARE, EVEN IF NICTA HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
If applicable legislation implies warranties or conditions, or imposes obligations or liability on NICTA in respect of the Software that cannot be wholly or partly excluded, restricted or modified, NICTA’s liability is limited, to the full extent permitted by the applicable legislation, at its option, to:
a. in the case of goods, any one or more of the following:
i. the replacement of the goods or the supply of equivalent goods;
ii. the repair of the goods;
iii. the payment of the cost of replacing the goods or of acquiring equivalent goods;
iv. the payment of the cost of having the goods repaired; or
b. in the case of services:
i. the supplying of the services again; or
ii. the payment of the cost of having the services supplied again.

Getopt

Copyright (c) 1987, 1993, 1994 The Regents of the University of California. All rights reserved.
Software License Terms 88
Epson Network Guide
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
3. Neither the name of the University nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE REGENTS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE REGENTS OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Arcfour

Copyright (c) April 29, 1997 Kalle Kaukonen. All Rights Reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that this copyright notice and disclaimer are retained.
Software License Terms 89
Epson Network Guide
THIS SOFTWARE IS PROVIDED BY KALLE KAUKONEN AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL KALLE KAUKONEN OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Other Software Licenses

Info-ZIP copyright and license

This is version 2007-Mar-4 of the Info-ZIP license. The definitive version of this document should be available at ftp://ftp.info-zip.org/pub/infozip/license.html indefinitely and a copy at http:// www.info-zip.org/pub/infozip/license.html.
Copyright © 1990-2007 Info-ZIP. All rights reserved.
For the purposes of this copyright and license, “Info-ZIP” is defined as the following set of individuals:
Mark Adler, John Bush, Karl Davis, Harald Denker, Jean-Michel Dubois, Jean-loup Gailly, Hunter Goatley, Ed Gordon, Ian Gorman, Chris Herborth, Dirk Haase, Greg Hartwig, Robert Heath, Jonathan Hudson, Paul Kienitz, David Kirschbaum, Johnny Lee, Onno van der Linden, Igor Mandrichenko, Steve P. Miller, Sergio Monesi, Keith Owens, George Petrov, Greg Roelofs, Kai Uwe Rommel, Steve Salisbury, Dave Smith, Steven M. Schweda, Christian Spieler, Cosmin Truta, Antoine Verheijen, Paul von Behren, Rich Wales, Mike White.
Permission is granted to anyone to use this software for any purpose, including commercial applications, and to alter it and redistribute it freely, subject to the above disclaimer and the following restrictions:
1. Redistributions of source code (in whole or in part) must retain the above copyright notice, definition, disclaimer, and this list of conditions.
Software License Terms 90
Epson Network Guide
2. Redistributions in binary form (compiled executables and libraries) must reproduce the above copyright notice, definition, disclaimer, and this list of conditions in documentation and/or other materials provided with the distribution. The sole exception to this condition is redistribution of a standard UnZipSFX binary (including SFXWiz) as part of a self-extracting archive; that is permitted without inclusion of this license, as long as the normal SFX banner has not been removed from the binary or disabled.
3. Altered versions--including, but not limited to, ports to new operating systems, existing ports with new graphical interfaces, versions with modified or added functionality, and dynamic, shared, or static library versions not from Info-ZIP--must be plainly marked as such and must not be misrepresented as being the original source or, if binaries, compiled from the original source. Such altered versions also must not be misrepresented as being Info-ZIP releases--including, but not limited to, labeling of the altered versions with the names “Info-ZIP” (or any variation thereof, including, but not limited to, different capitalizations), “Pocket UnZip,” “WiZ” or “MacZip” without the explicit permission of Info-ZIP. Such altered versions are further prohibited from misrepresentative use of the Zip-Bugs or Info-ZIP e-mail addresses or the Info-ZIP URL(s), such as to imply Info-ZIP will provide support for the altered versions.
4. Info-ZIP retains the right to use the names “Info-ZIP,” “Zip,” “UnZip,” “UnZipSFX,” “WiZ,” “Pocket UnZip,” “Pocket Zip,” and “MacZip” for its own source and binary releases.
Software License Terms 91

Index

Epson Network Guide
D
Dial-up router......................................................................84
E
EpsonNet Config (Macintosh)..........................................50
EpsonNet Config (Web Browser).....................................51
EpsonNet Config (Windows)............................................48
EpsonNet Print....................................................................58
I
Initializing the printer.........................................................77
Installation
EpsonNet Config (Macintosh).......................................50
EpsonNet Config (Windows).........................................49
EpsonNet Print.................................................................59
IP address................................................................76, 79 , 82
N
U
Using the printer with
Macintosh.........................................................................45
Windows 2000..................................................................41
Windows 7........................................................................27
Windows Server 2003......................................................36
Windows Server 2008......................................................27
Windows Vista.................................................................27
Windows XP.....................................................................31
Network status sheet...........................................................76
O
Operating environment........................................................9
P
Protocols.................................................................................9
R
RJ-45 connector...................................................................12
S
Setting the IP address............................................52, 79 , 82
Index 92
