Epson 6100 User Manual

User’s Guide
1

Notations Used in This Guide

2
Attention
q
s
g
Procedure
[ (Name) ]
"(Menu Name)"
Indicates procedures which may result in damage or injury if sufficient care is not taken.
Indicates additional information and points which may be useful to know regarding a topic.
Indicates that an explanation of the underlined word or words in front of this symbol appears in the glossary of terms. See the "Glossary" section of the "Appendices". s p.68
Indicates operating methods and the order of operations. The procedure indicated should be carried out in the order of the numbered steps.
Indicates the name of the buttons on the remote control or the control panel. Example: [Esc] button
Indicates configuration menu items. Example: "Image" - "Brightness"

Contents

3
Projector Features......................................................................................4
Part Names and Functions ........................................................................5
Front/Top.............................................................................................................. 5
Rear (EMP-6100) ................................................................................................. 6
Rear (EMP-6000) ................................................................................................. 7
Control Panel .......................................................................................................8
Remote Control ....................................................................................................9
Base ...................................................................................................................10
Useful Functions
Changing the Projected Image................................................................12
Automatically Detect Incoming Signals and Change the Projected Image
(Source Search) .................................................................................................12
Changing Directly from the Remote Control ...................................................... 13
Functions for Enhancing Projection.......................................................14
Selecting the Projection Quality (Selecting Colour Mode) ................................. 14
Hiding the Image and Sound Temporarily (A/V Mute) ....................................... 15
Freezing the Image (Freeze).............................................................................. 15
Changing the Aspect Ratio
Pointer Function (Pointer) .................................................................................. 17
Enlarging Part of the Image (E-Zoom) ............................................................... 18
g (Resize) ............................................................... 16
Adjusting Colour for Several Projectors (Multi-Screen Colour
Adjustment)...............................................................................................19
Summary of Adjustment Procedure ................................................................... 19
Setting Screen ID ............................................................................................... 19
Image Correction Method................................................................................... 20
Security Functions ...................................................................................22
Managing Users (Password Protect) .................................................................22
Restricting Operation (Operation Lock).............................................................. 25
Anti-Theft Lock ...................................................................................................26
Configuration Menu
Using the Configuration Menu ................................................................28
List of Functions.......................................................................................29
Image Menu ....................................................................................................... 29
Signal Menu ....................................................................................................... 30
Settings Menu .................................................................................................... 31
Extended Menu ..................................................................................................33
Network Menu (EMP-6100 Only) .......................................................................35
Info Menu (Display Only).................................................................................... 38
Reset Menu........................................................................................................ 39
Troubleshooting
Using the Help .......................................................................................... 41
Problem Solving.......................................................................................42
Reading the Indicators ....................................................................................... 42
When the Indicators Provide No Help................................................................ 45
Appendices
Installation Methods ................................................................................ 53
Cleaning .................................................................................................... 54
Cleaning the Projector's Surface ....................................................................... 54
Cleaning the Lens Cover Glass ......................................................................... 54
Cleaning the Air Filter ........................................................................................ 54
Replacing Consumables ......................................................................... 56
Replacing the Remote Control Batteries ........................................................... 56
Replacing the Lamp ........................................................................................... 57
Replacing the Air Filter ...................................................................................... 60
Saving a User’s Logo............................................................................... 62
Screen Size and Distance........................................................................ 64
Connecting to External Equipment ........................................................ 65
Connecting to an External Monitor .................................................................... 65
Connecting to External Speakers (EMP-6100 Only) ......................................... 65
Connecting a LAN Cable (EMP-6100 Only)............................................ 66
Optional Accessories and Consumables .............................................. 67
Glossary....................................................................................................68
List of ESC/VP21 Commands.................................................................. 70
Command List.................................................................................................... 70
Cable Layouts.................................................................................................... 70
PJLink (EMP-6100 Only) .......................................................................... 71
List of Supported Monitor Displays ....................................................... 72
Specifications...........................................................................................73
Appearance...............................................................................................76
Index..........................................................................................................77

Projector Features

4
High reliability
f A highly efficient air filter is installed
Decreases the amount of dust that enters the projector.
f A message and an indicator inform you when it is time to replace
the air filter
The projector detects when the air filter is becoming clogged up and alerts you with a message and an indicator to give you advanced notice that the filter will soon need cleaning or replacing (EMP-6100 only). s p.44
f Easy to detach, instantly-removable filter
There is only one air filter and it can be removed and installed easily.
s p.60
Enhanced security functions
f Password Protect to restrict and manage users By setting a password you can restrict who can use the projector. s p.22
f Operation Lock restricts button operation on the control panel
You can use this to prevent people changing projector settings without permission at events, in schools, and so on. s p.25
f Equipped with various anti-theft devices
The projector is equipped with the following security devices. s p.26
• Security slot
• Security cable installation point
• Cable cover key installation hole
Control and monitor from a remote location by a LAN
f Control and monitor from a computer using EMP Monitor (EMP-
6100 only)
You can use the EMP Monitor software supplied with the projector to display and check the projector's status on a computer monitor and control it from a computer. s EMP Monitor Operation Guide
f Mail notification function when problems occur
When problems occur in the projector a mail notification is sent to a nominated e-mail address to inform the recipient of the projector's status.
s p.36
Multi-screen colour adjustment allows you to adjust the colour of several projectors
When several projectors are lined up and projecting images, you can adjust the colour tone of each image with multi-screen colour adjustment.
s p.19
Easy to handle
f Direct power On/Off
In places where power is managed centrally, such as in a conference room, the projector can be set to power on and off automatically when the power source to which the projector is connected is switched on or off.
f No cool down delay
You can disconnect the projector's power cable without having to wait for the projector to cool down first.
f High powered, 1.6 times zoom lens
The 1.6 times zoom allows for a wide range of installation positions to suit most room layouts, whether the projector is on a stand, a table, or ceiling mounted.

Part Names and Functions

5

Front/Top

How to open the zoom ring cover
*
A B
C
D
E
* Do not remove the zoom ring cover, and do not use the projector
when it is open. Otherwise dust can enter into the projector and shorten the optical engine's service life.
Name Function
J
I
H
G
F
Name Function
Lamp cover Open this cover when replacing the projector's
C
lamp. s p.57
Air exhaust vent
D
Status indicators The colour of the indicators and whether they
E
Front adjustable
F
feet
Remote receiver Receives signals from the remote control.
G
Air filter
H
(Air intake vent)
Zoom ring Adjusts the image size. s Quick Start Guide
I
Focus ring Adjusts the image focus. s Quick Start
J
Attention
Do not place objects that may become warped or otherwise affected by heat near the air exhaust vent and do not put your face or hands near the air exhaust vent while projection is in progress.
are flashing or lit indicates the status of the projector. s p.42
Turn to extend and adjust the position of the projected image when the projector is placed on a surface such as a desk. s Quick Start
Guide
s Quick Start Guide
This prevents dust and other foreign particles from getting inside the projector when air is drawn in. The projector displays a warning message when it is time to clean or replace the air filter. s p.54, 60
Guide
Speaker
A
Control panel s p.8
B
Part Names and Functions
6

Rear (EMP-6100)

A
B
A
B C
D E
LKJ I HG F
CDE
Name Function
Storage feet When storing the projector upright, make sure
that these feet are at the bottom.
Security slot (j) s p.26
S-Video port
Video port
Audio port L-Audio-R port
Rear foot
Power inlet Connects to the power cable. s Quick Start
For S-videog signals from video sources.
For composite videog signals from video sources.
These connect to the audio out port of equipment that is connected to the S-Video or Video port. s Quick Start Guide, p.31
Guide
Name Function
LAN port When a LAN cable is connected, you can
F
monitor and control the projector over a LAN.
s p.66
RS-232C port When controlling the projector from a
G
computer, connect it to the computer with an RS-232C cable. This port is for control use and should not normally be used. s p.70
Remote receiver Receives signals from the remote control.
H
s Quick Start Guide
Computer2 port For video signals from a computer and
I
component video sources.
Audio port Connect to the audio out port of the computer
connected to the Computer2 port. s Quick
Start Guide
Computer1 port For video signals from a computer and
J
component video sources.
Audio port Connect to the audio out port of the computer
connected to the Computer1 port. s Quick
Start Guide
Monitor Out port Outputs the computer image signal connected
K
to the Computer1 port to an external monitor. This is not available for component video signals or other signals being input to any port
other than Computer1 port. s p.65
Audio Out port Outputs the sound of the image currently being
L
projected to external speakers.
g signals from other video
g signals from other video
g
Part Names and Functions
7

Rear (EMP-6000)

A
B
Name Function
Storage feet When storing the projector upright, make sure
A
JI H G F
CDE
that these feet are at the bottom.
Name Function
RS-232C port When controlling the projector from a
F
computer, connect it to the computer with an RS-232C cable. This port is for control use and should not normally be used. s p.70
Remote receiver Receives signals from the remote control.
G
s Quick Start Guide
Computer2 port For video signals from a computer and
H
component video sources. s Quick Start Guide
Computer1 port For video signals from a computer and
I
component video sources. s Quick Start Guide
Monitor Out port Outputs the computer image signal connected
J
to the Computer1 port to an external monitor. This is not available for component video signals or other signals being input to any port
other than Computer1 port. s p.65
g signals from other video
g signals from other video
g
Security slot (j) s p.26
B
S-Video port
C
Video port
L-Audio-R port Connects to the audio out port of the
Rear foot
D
Power inlet Connects to the power cable. s Quick Start
E
For S-videog signals from video sources.
For composite videog signals from video sources.
equipment that is providing the image source to input the audio. s Quick Start Guide
Guide
Part Names and Functions
8

Control Panel

E
AH
G
B
F
F
G
C
H
D
Name Function
[Menu] button Displays and closes the configuration menu.
A
s p.28
E
Name Function
[a] [b] buttons Adjusts the sound volume.
If pressed when a configuration menu or a help screen is displayed, these buttons select menu items and setting values. s Quick Start Guide, p.28
[Help] button Displays and closes the help screen which
shows you how to deal with problems if they occur. s p.41
[Esc] button Stops the current function.
If pressed when a configuration menu is displayed, it moves to the previous menu level.
s p.28
[Enter] button If pressed during projection of computer signal
images, it automatically adjusts the tracking, synchronization, and position to project the optimum image. When a configuration menu or a help screen is displayed, it accepts and enters the current selection and moves to the next level. s p.28
[Power] button Turns the projector power on or off. s Quick
B
Start Guide
[Source Search]
C
button
[w] [v] buttons Corrects keystone distortion.
D
Changes to the next input source that is connected to the projector and is sending an image. s p.12
If pressed when a configuration menu or a help screen is displayed, these buttons select menu items and setting values. s Quick Start Guide, p.28
Part Names and Functions
9

Remote Control

A
B C
D E
F G H I
J
V
U T S
R Q P
O N M L
K
Name Function
[Pointer] button Press to activate the on screen pointer.
C
s p.17
[Comp1] button Displays images from the Computer1 port.
D
s p.13
[Comp2] button Displays images from the Computer2 port.
E
s p.13
[S-Video] button Displays images from the S-Video port.
F
s p.13
[Video] button Displays images from the Video port. s p.13
G
[Auto] button If pressed during projection of computer signal
H
images, it automatically adjusts the tracking, synchronization, and position to project the optimum image. s p.30
Numeric buttons Use these buttons when entering a password
I
or screen ID. s p.24, 19
[Search] button Changes to the next input source that is
J
connected to the projector and is sending an image. s p.12
[Volume] buttons (a) Decreases the volume.
K
(b) Increases the volume. s Quick Start Guide
Name Function
[E-Zoom] buttons
A
(z) (x)
[A/V Mute] button Turns the video and audio on or off. s p.15
B
(z) Enlarges the image without changing the projection size. (x) Reduces parts of images that have been enlarged using the [z] button. s p.18
[Resize] button
L
[Help] button Displays and closes the help screen which
M
[Color Mode]
N
button
The aspect ratiog changes each time the button is pressed. s p.16
shows you how to deal with problems if they occur. s p.41
Each time the button is pressed, the colour mode changes. s p.14
Part Names and Functions
10
Name Function
[Num] button Use this button when entering a password or
O
screen ID. s p.24, 19
[Freeze] button Images are paused or unpaused. s p.15
P
[Esc] button Stops the current function.
Q
If pressed when a configuration menu is displayed, it moves to the previous level.
s p.28
[Enter] button When a configuration menu or a help screen is
R
displayed, it accepts and enters the current selection and moves to the next level. s p.28
[h] button When a configuration menu or help screen is
S
displayed, it selects menu items and setting values. s p.28
[Menu] button Displays and closes the configuration menu.
T
s p.28
[Power] button Turns the projector power on or off. s Quick
U
Start Guide

Base

A
D
C
B
Remote control
V
light-emitting area
Outputs remote control signals. s Quick Start Guide
Name Function
Front adjustable
A
feet
Security cable
B
installation point
Suspension
C
bracket fixing points (4 points)
Handle Use this handle when carrying the projector.
D
Turn to extend and adjust the position of the projected image when the projector is placed on a surface such as a desk.
Pass a commercially available anti-theft wire lock through here when you want to secure the projector to a fixed object. s p.26
Attach the optional ceiling mount here when suspending the projector from a ceiling.
s p.53, 67

Useful Functions

This chapter explains useful functions for giving presentations and so on, and the security functions.
Changing the Projected Image .......................... 12
• Automatically Detect Incoming Signals and Change
the Projected Image (Source Search) ..............................12
• Changing Directly from the Remote Control.................13
Functions for Enhancing Projection................. 14
• Selecting the Projection Quality
(Selecting Colour Mode)...................................................14
• Hiding the Image and Sound Temporarily
(A/V Mute) .........................................................................15
• Freezing the Image (Freeze).............................................15
• Changing the Aspect Ratio
• Pointer Function (Pointer) ...............................................17
• Enlarging Part of the Image (E-Zoom)...........................18
g (Resize)..............................16
Adjusting Colour for Several Projectors
(Multi-Screen Colour Adjustment).....................19
• Summary of Adjustment Procedure............................... 19
• Setting Screen ID.............................................................. 19
• Image Correction Method ............................................... 20
Security Functions..............................................22
• Managing Users (Password Protect)............................... 22
Type of Password Protect .............................................................. 22
Setting Password Protect................................................................ 23
Entering the password.................................................................... 24
• Restricting Operation (Operation Lock)........................ 25
• Anti-Theft Lock ................................................................ 26
Installing the wire lock................................................................... 26
Cable cover locking method (EMP-6100 only) ............................. 26

Changing the Projected Image

12
You can change the projected image in the following two ways.
• Changing by Source Search The projector automatically detects signals being input from connected equipment, and the image being input from the equipment is projected.
• Changing directly You can use the remote control buttons to change to the target input port.

Automatically Detect Incoming Signals and Change the Projected Image (Source Search)

You can project the target image quickly as input ports with no image signal being input are ignored when you change by pressing the [Source Search] button.
Computer1 VideoS-VideoComputer2
q
Using the remote control Using the control panel
When two or more pieces of equipment are connected, press the [Source Search] button until the target image is projected.
The following screen showing the status of image signals is displayed when only the image that the projector is currently displaying is available, or when no image signal can be found. You can select the input port where the connected equipment you want to use is projecting. If no operation is performed after about 10 seconds, the screen closes.
The input port where no image signal is being input is skipped.
Procedure
When your video equipment is connected, start playback before beginning this operataion.
Changing the Projected Image

Changing Directly from the Remote Control

You can change directly to the target image by pressing the following buttons on the remote control.
Remote control
13
Changes to images from the Computer1 port.
Changes to images from the S-Video port.
Changes to images from the Computer2 port.
Changes to images from the Video port.

Functions for Enhancing Projection

14

Selecting the Projection Quality (Selecting Colour Mode)

You can easily obtain the optimum image quality simply by selecting the setting that best corresponds to your surroundings when projecting. The brightness of the image varies depending on the mode selected.
Mode Application
Photo (When computer images are input)
Ideal for projecting still pictures, such as photos, in a bright room. The images are vivid and brought into contrast.
Sports (When component video, S-video, or composite
video images are input) Ideal for watching TV programmes in a bright room.
The images are vivid and brought to life. Presentation Ideal for giving presentations in a bright room. Theatre Ideal for watching films in a dark room. Gives
images a natural tone. Game Ideal for playing video games in a bright room.
Excels at emphasizing dark gradations. sRGBg Ideal for images that conform to the sRGB colour
standard. Blackboard Even if you are projecting onto a blackboard
(greenboard), this setting gives your images a natural
tint, just like when projecting onto a screen.
Procedure
Remote control
Each time you press the button, the colour mode name is displayed on the screen and the colour mode changes.
If you press the button while the colour mode name is displayed on the screen, it changes to the next colour mode.
q
The colour mode can also be set using "Color Mode" in the "Image" menu from the configuration menu.
s
p.29
Functions for Enhancing Projection
15

Hiding the Image and Sound Temporarily (A/V Mute)

You can use this when you want to focus the audience's attention on what you are saying, or if you do not want to show details such as when you are changing between files during presentations from a computer.
Procedure
Remote control
Each time you press the button, A/V Mute turns on or off.
• If you use this function when projecting moving images,
q
the images and sound continue to be played back by the source, and you cannot return to the point where A/V Mute was activated.
• You can choose to display black, blue, or logo as the A/V Mute display using the "Extended"-"Display"-"A/V
s
Mute" setting from the configuration menu.
p.33

Freezing the Image (Freeze)

When the moving image on the screen is frozen, the image continues to project, so you can project a moving image one frame at a time like a still photo. Also, you can perform operations such as changing between files during presentations from a computer without projecting any images if the freeze function is activated beforehand.
Procedure
Remote control
Each time you press the button, Freeze turns on or off.
• Audio does not stop.
q
• The image source continues to playback the moving images even while the screen is frozen, and so it is not possible to resume projection from the point where it was paused.
• If the [Freeze] button is pressed while the configuration menu or a help screen is displayed, the menu or help screen being displayed is cleared.
• Freeze still works while E-Zoom is being used.
Functions for Enhancing Projection
16
Changing the Aspect Ratiog (Resize)
When video equipment is connected, images that have been recorded in digital video or onto DVDs can be viewed in 16:9 wide-screen format. You can change the aspect ratio for images in squeeze modeg as follows.
16:94:3 16.9 (below)16.9 (above)
Procedure
Remote control
If you press the button while the aspect name is displayed on the screen, it changes to the next aspect mode.
The colour mode can also be set using "Resize" in the
q
"Signal" menu from the configuration menu.
s
p.30
Each time you press the button, the aspect name is displayed on the screen and the aspect changes.
Functions for Enhancing Projection
17

Pointer Function (Pointer)

This allows you to move a pointer icon on the projected image, and helps you draw attention to the area you are talking about.
Procedure
A
Display the pointer.
Remote control
B
q
Move the pointer icon.
Remote control
Pointer icon
You can choose from three different kinds of pointer icon (
··
from the configuration menu.
) in "Pointer Shape" in the "Settings" menu
s
p.31
Each time you press the button, the pointer appears or disappears.
Functions for Enhancing Projection
18

Enlarging Part of the Image (E-Zoom)

This is useful when you want to expand images to see them in greater detail, such as graphs and tables.
Procedure
A
Start E-Zoom.
Remote control
B
C
Move the cross to the area of the image that you want to enlarge.
Remote control
Cross
Enlarge.
Remote control
q
Each time the button is pressed, the area is expanded. You can expand quickly by holding the button down. You can reduce the enlarged image by pressing the [x] button. Press the [Esc] button to cancel.
• The enlargement ratio appears on the screen. The selected area can be enlarged to between 1 to 4 times in 25 incremental steps.
h
• Tilt the [
] button to scroll the image.

Adjusting Colour for Several Projectors (Multi-Screen Colour Adjustment)

19
When several projectors are lined up and projecting images, you can adjust the brightness and colour tone of each projector's image with multi-screen colour adjustment so that the colours of images from each projector match closely. In some cases the brightness and colour tone may not match completely even after adjustment.

Summary of Adjustment Procedure

Make adjustments according to the following procedure.
1. Setting screen ID
Before setting up the projectors, set one screen ID for each. When making adjustments for two or more projectors using the remote control, you can operate them individually by setting individual screen IDs for each projector.
2. Making image corrections
After the projectors are setup, you can adjust the image for each projector. Using Image Correction you can adjust from black to white in five stages called levels 1 to 5, and in each level 1 to 5 you can adjust the following two points.
• Adjusting brightness Adjust each image by levels 1 to 5 so that they are all equal.
• Adjusting colour Adjust each image by levels 1 to 5 so that the colours match using "Color Correct. (G/R)" and "Color Correct. (B/Y)".

Setting Screen ID

For instance, after setting one projector as screen ID3, when you press button [3] while holding down the [Num] button, even if there is more than one projector setup, you can operate just the one set as screen ID3.
Procedure
A
Press the [Menu] button and select "Extended" ­"Multi-screen" - "Screen ID" from the configuration menu. s "Using the Configuration Menu" p.28
Using the remote control Using the control panel
Check the buttons you can use and the operations they perform in the guide under the menu.
Adjusting Colour for Several Projectors (Multi-Screen Colour Adjustment)
20
B
C
q
Choose the ID you want to set and press the [Enter] button.
Press the [Menu] button to close the configuration menu.
• Point the remote control at the remote receiver on the projector you want to operate, press the numeric button corresponding to the screen ID set while holding down the [Num] button, and then you can operate only the projector specified with the ID number.
• You can operate all projectors regardless of the screen ID settings by pointing the remote control at the remote receiver on the projector, and pressing the [0] button while holding down the [Num] button.
• The screen IDs set here are only effective during "Image Correction" for "Multi-screen".
• If a projector that is not the object of operation reacts to the remote control, point the remote control at the remote receiver on that projector and press the number set as that projector's screen ID while holding down the [Num] button.

Image Correction Method

After setting up the projectors, adjust the brightness and tone for each image.
Procedure
A
B
C
Press the [Menu] button and select "Extended" ­"Multi-screen" - "Image Correction" from the configuration menu. s "Using the Configuration Menu" p.28
Select the level to be adjusted in "Adjustment Level".
• Each time a level is selected, the pattern of the level selected is displayed.
• You can start adjusting from any level, usually you can make it darker or lighter by adjusting 1 to 5 or 5 to 1.
Adjust the brightness with "Brightness Correct.".
• When you select level 5, it adjusts to the darkest image from several projectors.
• When you select level 1, it adjusts to the brightest image from several projectors.
• When you select level 2 to 4, it adjusts to the mid-range brightness image from several projectors.
• Each time the [Enter] button is pressed the image displayed changes between the pattern display and the actual image, and you can check the adjustment results and make corrections in the actual image.
Adjusting Colour for Several Projectors (Multi-Screen Colour Adjustment)
21
D
E F
Adjusting "Color Correct. (G/R)" and "Color Correct. (B/Y)".
Each time the [Enter] button is pressed the image displayed changes between the pattern display and the actual image, and you can check the adjustment results and make corrections in the actual image.
Repeat procedures 2 to 4 until adjustments are finished.
When all adjustments are finished, press the [Menu] button to close the configuration menu.

Security Functions

22
The projector has the following enhanced security functions.
• Password Protect You can limit who can use the projector.
• Operation Lock You can prevent people changing the settings on the projector without permission.
• Security Lock The projector is equipped with various types of anti-theft security devices.

Managing Users (Password Protect)

When Password Protect is activated, people who do not know the password cannot use the projector to project images even if the projector power is on. Furthermore, the user's logo that is displayed when you turn on the projector cannot be changed. This acts as an anti-theft device as the projector cannot be used even if it is stolen. At the time of purchase, Password Protect is not activated.
f Type of Password Protect
The following four kinds of password protect settings can be made according to how the projector is being used.
1. "Power On Protect"
When "Power On Protect" is "On", the password must be entered whenever the projector is turned on after it has been disconnected from the power supply it was connected to the last time the password was entered. If the correct password is not entered, projection does not start.
2. "Password Timer"
When "Password Timer" is set to "On" and a time limit is set, the projector requests the password after the time limit has passed.
3. "User's Logo Protect"
When "User's Logo Protect" is set to "On" the user's logo cannot be changed and the following setting changes for user's logo are prohibited.
• Capturing a user's logo
• Settings for "Display Background", "Startup Screen", and "A/V Mute" from "Display" on the configuration menu.
4. "Network Protect" (EMP-6100 only)
When "Network Protect" is set to "On" setting changes for "Network" in the configuration menu are prohibited.
Security Functions
23
f Setting Password Protect
Use the following procedure to set Password Protect.
Procedure
A
q
Hold down the [Freeze] button for about five seconds.
The password protect setting menu is displayed.
Remote control
• If Password Protect is already activated, you must enter the password. If the password is entered correctly, the password protect
s
setting menu is displayed.
p.24
• When the password is set, stick the password protect sticker in a visible position on the projector as a further theft deterrent (EMP-6100 only).
"Entering the password"
C
D
E
Turn on "Password Timer".
If you do not use this setting, go to step 4. (1) Select "Password Timer", and then press the [Enter] button. (2) Select "On", and then press the [Enter] button. (3) Press the [Esc] button. (4) Select "Timer", and then press the [Enter] button. (5) While holding down the [Num] button, use the numeric buttons
to enter the setting time within a range of 1 to 9999 hours and then press the [Enter] button. If you make a mistake entering the time, press the [Esc] button and re-enter the time. The time counter begins when you close the password protect setting menu. The count is only done while the lamp is lit, and not while it is turned off. The time already counted is displayed in "Time-elapsed".
Turn on "User's Logo Protect".
(1) Select "User's Logo Protect", and then press the [Enter] button. (2) Select "On", and then press the [Enter] button. (3) Press the [Esc] button.
Turn on "Network Protect" (EMP-6100 only).
(1) Select "Network Protect", and then press the [Enter] button. (2) Select "On", and then press the [Enter] button. (3) Press the [Esc] button.
B
Turn on "Power On Protect".
(1) Select "Power On Protect", and then press the [Enter] button. (2) Select "On", and then press the [Enter] button. (3) Press the [Esc] button.
Security Functions
24
F
Set the password.
(1) Select "Password", and then press the [Enter] button. (2) The message "Change the password?" is displayed, select
"Yes" and then press the [Enter] button. The default setting for the password is "0000". Change this to your own desired password. If you select "No", the screen shown in step 1 is displayed again.
(3) While holding down the [Num] button, enter a four digit
number using the numeric buttons. The number entered is displayed as "****". When you enter the fourth digit, the confirmation screen is displayed.
Remote control
Keep
pressed
Numeric buttons
(4) Re-enter the password.
The message "Password accepted." is displayed. If you enter the password incorrectly, a message is displayed prompting you to re-enter the password.
f Entering the password
When the password entry screen is displayed, enter the password using the numeric buttons on the remote control.
Procedure
While holding down the [Num] button, enter the password by pressing the numeric buttons.
When you enter the correct password, projection begins.
Attention
• If an incorrect password is entered three times in succession, the message "The projector's operation will be locked." is displayed for about five minutes, and then the projector switches to standby mode. If this happens, disconnect the power plug from the electrical outlet and then reinsert it and turn the projector's power back on. The projector displays the password entry screen again so that you can enter the correct password.
• If you have forgottten the password, make a note of the "Request Code: xxxxx" number that appears on the screen and contact the nearest address provided in the World-Wide Warranty Terms.
s
Inquiries
• If you continue to repeat the above operation and input the wrong password thirty times in succession, the following message is displayed and the projector does not accept any more password entries. "The projector's operation will be locked. Contact Epson
s
as described in your documentation."
Inquiries
Security Functions

Restricting Operation (Operation Lock)

Do one of the following to lock the operation buttons on the control panel.
•Full lock All of the buttons on the control panel are locked. You cannot perform any operations from the control panel, including turning the power on or off.
• Partial lock All of the buttons on the control panel, except for the [Power] button, are locked.
This is useful at events or shows when you want to deactivate all buttons and only project, or at schools when you want to limit button operation. The projector can still be operated using the remote control.
Procedure
B
25
Check the buttons you can use and the operations they perform in the guide under the menu.
Select either "Full Lock" or "Partial Lock".
A
Press the [Menu] button and select "Settings" ­"Operation Lock". s "Using the Configuration Menu" p.28
Using the remote control Using the control panel
C
q
Select "Yes" when the confirmation message is displayed.
The control panel buttons are locked according to the setting you chose.
You can release the control panel lock by one of the following two methods.
• From the remote control, select "Off" in "Settings"­"Operation Lock" from the configuration menu.
• Press and hold down the [Enter] button on the control panel for about seven seconds, a message is displayed and the lock is released.
Security Functions
26

Anti-Theft Lock

As the projector is often setup on ceiling mounts and left in rooms unattended, it is possible that someone may try and take the projector, so the projector includes the following security devices.
Security slot
The security slot is compatible with the Microsaver Security System manufactured by Kensington. You can find details about the Microsaver Security System on the Kensington homepage http://www.kensington.
com/.
Security cable installation point
A commercially available theft-prevention wire lock can be passed through the installation point to secure the projector to a desk or pillar.
Cable cover padlock hole (EMP-6100 only)
Lock the cable cover using a commercially available padlock, because the power cable and connection cables cannot be unplugged from the projector once the cable cover is locked, the projector cannot easily be removed.
f Installing the wire lock
Pass an anti-theft wire lock through the installation point. See the documentation supplied with the wire lock for locking instructions.
f Cable cover locking method (EMP-6100 only)
After fitting the cable cover, lock it using a commercially available padlock.

Configuration Menu

This chapter explains how to use the configuration menu and its functions.
Using the Configuration Menu .......................... 28
List of Functions................................................. 29
• Image Menu.......................................................................29
• Signal Menu.......................................................................30
• Settings Menu ....................................................................31
• Extended Menu .................................................................33
• Network Menu (EMP-6100 Only) ...................................35
• Info Menu (Display Only).................................................38
• Reset Menu ........................................................................39

Using the Configuration Menu

28
A
Selecting from the top menu
Top menu
Guide
B
Selecting from the sub menu
Sub menu (Settings)
C
Changing the selected item
D
Exit
Buttons used
Using the control panel
Using the remote control
Select the setting to change

List of Functions

Image Menu

Items that can be set vary depending on the image signal currently being projected as shown in the following screen shots. Setting details are saved for each image signal.
29
Computer image
Sub Menu Function
Color Mode You can select the quality of the image to suit your surroundings. s p.14 Brightness You can adjust the image brightness. Contrastg You can adjust the difference between light and shade in the images. Color Saturation You can adjust the colour saturation for the images. Tint (Adjustment is only possible when NTSC signals are being input if you use composite video/S-video.)
You can adjust the image tint. Sharpness You can adjust the image sharpness. Color Adjustment You can make adjustments by choosing one of the following.
Abs. Color Temp.: You can adjust the overall tint of images. You can adjust tints in 10 stages from 5000 K to 10000 K. When a high value is
selected the image becomes tinged with blue, when a low value is selected the image becomes tinged with red.
Red, Green, Blue: You can adjust the saturation of each colour individually.
(This item cannot be selected if "sRGB Reset You can reset all adjustment values for the "Image" menu functions to their default settings. To return all menu items to their default settings, see
s p.39
g" is selected as the "Color Mode" setting in the "Image" menu.)
Component videog/Composite videog/S-videog
List of Functions

Signal Menu

Items that can be set vary depending on the image signal currently being projected as shown in the following screen shots. Setting details are saved for each image signal.
30
Computer image
Sub Menu Function
Auto Setup You can select whether, when the input signal changes, the image is automatically adjusted to the optimum state (On) or not (Off). s p.48 Trackingg You can adjust computer images when vertical stripes appear in the images. s p.48 Sync.g You can adjust computer images when flickering, fuzziness, or interference appears in the images. s p.48 Position You can adjust the display position up, down, left, and right when a part of the image is missing so that all of the image is projected. Progressiveg (Component video can only be adjusted when 525i/625i signals are being input)
Off: IP conversion is carried out for each field in the screen. This is ideal for viewing images with a large amount of movement.
On: interlace Computer1 Input You can select the input signal from Computer1 port or Computer2 port.
Computer2 Input
Video Signal If set to "Auto", video signals are recognized automatically. If interference appears in the image or a problem occurs such as no image is being
Resize You can set the aspect ratiog for projected images. s p.16 Reset You can reset all adjustment values on the "Signal" menu to their default settings, except for "Computer1 Input" and "Computer2 Input".
If set to "Auto" the input signal is set automatically according to the connected equipment.
If colours do not appear correctly when set to "Auto", select the appropriate signal according to the connected equipment.
projected when set to "Auto", select the appropriate signal according to the connected equipment.
To return all menu items to their default settings, see s p.39
g (i) signals are converted into progressiveg (p) signals. This is ideal for viewing still images.
Component videog Composite videog/S-videog
List of Functions

Settings Menu

Sub Menu Function
Keystone You can correct vertical keystone distortion in images. sQuick Start Guide Operation Lock You can use this to restrict operation of the projector's control panel. s p.25 Pointer Shape You can select the shape of the pointer. s p.17
Pointer 1: Pointer 2: Pointer 3:
Brightness Control You can set the lamp brightness to one of two settings.
Select "Low" if the images being projected are too bright such as when projecting images in a dark room or onto a small screen. When "Low" is
selected, the amount of electricity consumed is changed as follows, and fan rotation noise during projection is reduced.
Electrical consumption: about a 46 W decrease Vo l u m e You can adjust the volume. RCA Audio Input
(EMP-6100 only)
You can select whether to use the RCA audio port (L-Audio-R) as audio input for either the
equipment connected to the Video port or the equipment connected to the S-Video port.
For example, the illustration on the right shows how the image port and the audio port are
combined when "S-Video" is selected.
31
When you select "S-Video"
Remote Receiver You can limit the reception of the operation signal from the remote control.
When you want to prohibit operation by remote control, or if the remote receiver has a fluorescent light too close to it , you can make settings to
deactivate the remote receiver you do not want used or that is experiencing interference.
List of Functions
Sub Menu Function
Test Pattern When the projector is setup, a test pattern is displayed so that you can adjust the projection without connecting other equipment. While displaying
the test pattern, you can perform Zoom, Focus, and Keystone adjustments.
To cancel the test pattern, press the [Esc] button on the remote control or the control panel. Reset You can reset all adjustment values for the "Settings" menu, except for "RCA Audio Input (EMP-6100 only)", to their default settings.
To return all menu items to their default settings, see s p.39
32
List of Functions

Extended Menu

Sub Menu Function
Display You can make settings related to the projector's display.
Messages: You can set whether to display (On) or not display (Off) the source name when you change the input source, the colour mode name when
you change the colour mode, a message when no image signal is input, and so on.
Display Background
Startup Screen
*1
: You can set the screen displayed during A/V Mute as "Black", "Blue", or "Logo".
User's Logo
*1
A/V Mute
You can change the user's logo that is displayed as a background and displayed during A/V Mute. s p.62 Projection You can set from the following according to the way the projector is setup. s p.53
"Front" "Front/Ceiling" "Rear" "Rear/Ceiling"
You can change the setting as follows by pressing down the [A/V Mute] button on the remote control for about five seconds.
"Front" W "Front/Ceiling"
"Rear" W "Rear/Ceiling"
Operation Direct Power On: You can set whether Direct Power On is enabled (On) or disabled (Off).
When it is set to "On" and the projector power cable is connected to an electrical outlet, be aware that sudden surges of electricity when power comes back on after a power outage may cause the projector to turn on automatically.
Sleep Mode: You can set whether projection stops automatically (On) or not (Off) when no operations are carried out for about 30 minutes while no
image signals are being input.
High Altitude Mode: Set to "On" when using the projector above an altitude of 1500 m.
Standby Mode You can use network monitoring and control functions while the projector is in standby mode when this is set to "Network On".
Depending on the model, you can use the following methods to monitor and control the state of the projector.
EMP-6100: You can use SNMP
EMP-6000: You can download the EMP Monitor software
*1
*1
: You can set the screen status for when no image signal is available to "Black", "Blue", or "Logo".
: You can set if the startup screen (the image projected when starting the projector) is displayed or not.
g or EMP Monitor software supplied with this product.
*2
from the your local Epson homepage.
33
List of Functions
Sub Menu Function
Air Filter Setting You can set information regarding the replacement time for the air filter.
Alarm Timer: You can set whether you are informed (On) or not (Off) when it is time to replace the air filter.
Make sure you set this to "On" if you are using the smoke type air filter.
Timer: You can set whether or not to display a message indicating length of use.
The projector automatically detects the type of air filter installed and sets the appropriate time for filter replacement. However, you can set the
message to warn you earlier depending on the projector's environment to give you more notice that maintenance will soon be required. Multi-screen You can adjust the hue and brightness of each projected image when multiple projectors are lined up and projecting. s p.19
Screen ID: When performing "Image Correction" for "Multi-screen" by using one remote control for multiple projector's, you can define which
projector to use when individual IDs are set. The IDs set here are only effective during "Image Correction" for "Multi-screen".
Image Correction: You can make the following adjustments.
Adjustment Level: You can adjust from black to white in five stages called levels 1 to 5, and in each level 1 to 5 you can adjust "Brightness Correct." and "Color Correct.". Brightness Correct.: Corrects the difference in the brightness of each product. Color Correct. (G/R) / Color Correct. (B/Y) :Corrects the difference in the colour of each product.
Language You can set the language for message displays.
Reset You can reset "Display*1", "Operation*3", and "Air Filter Setting" in the "Extended" menu to their default settings.
To return all menu items to their default settings, see s p.39
*1 When "User's Logo Protect" is set to "On" in "Password Protect", settings relating to user's logo cannot be changed. You can make changes after setting "User's
Logo Protect" to "Off". s p.23
*2 To download EMP Monitor software, go to http://www.epson.com
that uses a computer to monitor and control the state of one or more projectors on a network. You will need a serial W IP conversion adapter and cable to connect an EMP-6000 to a network so that you can monitor it with EMP Monitor. You can check product information and operation compatibility at the homepage address mentioned above.
*3 Except for "High Altitude Mode".
, select your local Epson Web site and then select the support section. EMP Monitor is software
34
List of Functions

Network Menu (EMP-6100 Only)

When "Network Protect" is set to "On" in "Password Protect", a message is displayed and the settings cannot be changed. You can make changes after setting "Network Protect" to "Off". s p.23
Sub Menu Function
Wired LAN DHCP: You can set whether to use DHCP (On) or not (Off).
If this is set to "On" you cannot set any more addresses.
IP Address: You can input the IP address assigned to the projector.
You can input a number from 0 to 255 in each field of the address. However, the following IP addresses cannot be used.
0.0.0.0, 0.x.x.x, 127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from 0 to 255)
Subnet Mask: You can input the subnet mask for the projector.
You can input a number from 0 to 255 in each field of the address. However, the following subnet masks cannot be used.
0.0.0.0, 255.255.255.255
Gateway Address: You can input the IP address for the gateway for the projector.
You can input a number from 0 to 255 in each field of the address. However, the following gateway addresses cannot be used.
0.0.0.0, 127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from 0 to 255)
MAC Address: You can display the MAC address for the projector.
PJLink Password You can input the authentication password when accessing the projector by using the PJLink compatible application software.*1 s p.71
You can use numbers and letters and it can be up to 32 characters in length.
Web Control Password
You can input the authentication password when setting and controlling the projector using Web control.*1 You can use numbers and letters and it
can be up to 8 characters in length.
Web control is a computer function that allows you to control the projector by using a computer's Web browser when starting up EMP Monitor.
s EMP Monitor Operation Guide
*1
*1
*1
35
List of Functions
Sub Menu Function
SNMPg Set the SNMP.
Trap IP Address 1/Trap IP Address 2: You can register up to two for the SNMP trap notification destination.
The IP address registered in "Trap IP Address 2" is used when the IP address registered in "Trap IP Address 1" cannot be accessed.
Community Name: Enter the community name for SNMP. You can enter up to 8 numbers and letters.
You have to install the SNMP program on your computer to monitor the projector using SNMP. SNMP should be managed by a network expert.
Mail When this is set, if the projector enters an abnormal/warning state you are notified by e-mail.
Mail Notification: You can set whether to be notified by mail (On) or not (Off).
SMTP Server: You can input the IP address for the SMTP server for the projector.
You can input a number from 0 to 255 in each field of the address. However, the following IP addresses cannot be used.
127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from 0 to 255)
Port Number: You can input the port number for the SMTP server.
The initial value is 25. You can input numbers between 1 to 65535.
Address 1 Setting/Address 2 Setting/Address 3 Setting: You can input the mail address
when an abnormality or a warning occurs. You can input up to three destinations. You can use numbers and letters for the mail address and it can be up to 32 characters in length.
Projector Name You can display an individual name to identify the projector on the network.
Reset You can reset all adjustment values for the "Network" menu functions to their default settings.
To return all menu items to their default settings, see s p.39
*1 When inputting numbers and passwords, the following soft keyboards are displayed. Tilt the remote control [h] button to move the cursor to the target key, and
press the [Enter] button to input. After inputting, press [Finish] on the keyboard to confirm your input. Press [Cancel] on the keyboard to cancel your input.
*1
36
*2
*1
*1
and the contents of the message to receive notification
Each time this key is selected, it sets and changes between upper case and lower case letters.
Each time this key is selected, it sets and changes the symbol keys for the section enclosed by the frame.
List of Functions
*2 When the mail notification function is set to "On" and the projector enters an abnormal/warning state, the following mail is sent.
Subject: EPSON Projector First line: The projector name of the projector where the abnormality occurs Second line: The IP address set for the projector where the abnormality occurs Third line and on: Details of the abnormality
The details of the abnormality are described one by one, one line at a time. The following table explains the details shown in the message. For details on dealing with abnormalities/warnings, see "Reading the Indicators" (s p.42).
Internal error An internal error has occurred. Fan related error A fan error has occurred. Sensor error A sensor error has occurred. Lamp cover is open. The lamp cover is open. Lamp timer failure Lamp failure has occurred. Lamp out A lamp error has occurred.
Internal temperature error
High-speed cooling in progress
Lamp replacement notification
Air Filter Replace It is time to replace the air filter. No Air Filter There is no air filter installed. Low Air Flow A low air flow error has occurred. Air Flow Sensor Error An air flow sensor error has occurred.
No-signal
The (+) or (-) at the beginning of the sentence (+): An error has occurred in the projector (-): An error in the projector has been dealt with
37
Message Cause
A high temperature error has occurred. (Overheating)
A high temperature warning has occurred.
It is time to replace the lamp.
No Signal No image signal is being input to the projector. Check the connection status for the projector and that the power supply for the connected equipment is turned on.
List of Functions

Info Menu (Display Only)

Lets you check the status of the image signals being projected and the status of the projector. Items displayed vary depending on the image signal currently being projected as shown in the following screen shots.
Computer image/Component videog Composite videog/S-videog
Sub Menu Function
Lamp Hours You can display the cumulative lamp operating time*.
When it reaches the lamp warning time, the characters are displayed in yellow.
Air Filter You can display the type of air filter and the cumulative use time*.
If the "Alarm Timer" is set to "On" in "Air Filter Setting" from the "Extended" menu, when it reaches the air filter replacement time, the characters
are displayed in yellow.
Source You can display the input port name for the connected equipment currently being projected.
Input Signal You can display the content of "Computer1" or "Computer2" set in the "Signal" menu according to the "Source".
Resolution You can display the input resolution.
Video Signal You can display the content of "Video Signal" set in the "Signal" menu. Refresh Rateg You can display the refresh rate. Sync.g Info You can display the image signal information.
This information may be needed if service is required.
* The cumulative use time is displayed as "0H" for the first 10 hours.
38
List of Functions

Reset Menu

Sub Menu Function
Reset All You can reset all items in the configuration menus to their default settings.
The following items are not reset to their defaults: "Computer1 Input", "Computer2 Input", "User's Logo", "Multi-screen", all items for "Network"
menus (EMP-6100 only), "Air Filter Usage Time", "Lamp Hours", and "Language". Reset Air Filter Time You can clear the cumulative air filter use time, and return it to "0H". Reset when you replace the air filter. Reset Lamp Hours You can clear the cumulative lamp hours use time, and return it to "0H". Reset when you replace the lamp.
39

Troubleshooting

This chapter describes how to identify problems and what to do if a problem is found.
Using the Help..................................................... 41
Problem Solving ................................................. 42
• Reading the Indicators......................................................42
t Power indicator lights red ..........................................................43
i · o · n Indicator is lit or flashing orange .................................44
• When the Indicators Provide No Help ............................45
Problems relating to images ...........................................................46
Problems when projection starts.....................................................50
Other problems ...............................................................................50

Using the Help

41
If a problem occurs with the projector, Help uses on-screen displays to assist you in solving the problem.
Procedure
A
B
Press the [Help] button.
The help screen is displayed.
Using the remote control Using the control panel
Select a menu item.
C
D
Confirm the selection.
Using the control panelUsing the remote control
Use the same operations as procedures 2 and 3 to proceed through the menu to more detailed items.
Press the [Help] button to exit Help.
Using the remote control Using the control panel
q
If Help does not provide a solution to the problem, refer to "Problem Solving" (
s
p.42).

Problem Solving

If you are having a problem with the projector, first check the projector's indicators and refer to "Reading the Indicators" below. If the indicators do not show clearly what the problem might be, refer to "When the Indicators Provide No Help". s p.45

Reading the Indicators

The projector is provided with the following four indicators that indicate the operating status of the projector.
Indicates the operating status.
Orange : Standby condition
When the [Power] button is pressed in this condition, projection starts.
Green : Warm-up in progress
Warm-up time is about 30 seconds. After warm-up is complete, the indicator stops flashing.
Green : Projection in progress
Indicates the projection lamp status.
Indicates the internal temperature status.
Indicates the air filter status.
42
Refer to the following table to see what the indicators mean and how to remedy problems that they indicate. If all indicators are off, check that the power cable is connected correctly and that the power is being supplied normally. Sometimes, when the power cable is unplugged, the t indicator remains lit for a short period, this is not a fault.
Problem Solving
43
f t Power indicator lights red
Status Cause Remedy or Status
RedRedRed
RedRed
RedRed
RedRed
Internal Error Stop using the projector, disconnect the power cable from the electrical outlet, and contact your local dealer or the
Fan Error Sensor Error
High Temp Error (overheating)
Lamp Error Lamp Failure Lamp Cover Open
Abnormal
: Lit : Flashing: : Off
nearest address provided in the World-Wide Warranty Terms. s Inquiries
Stop using the projector, disconnect the power cable from the electrical outlet, and contact your local dealer or the nearest address provided in the World-Wide Warranty Terms. s Inquiries
The lamp turns off automatically and projection stops. Wait for about five minutes. After about five minutes the projector switches to standby mode, so check the following two points.
• Check that the air filter and air exhaust vent are clear, and that the projector is not positioned against a wall.
• If the air filter is clogged, clean or replace it. s p.54, 60 If the error continues after checking the points above, stop using the projector, disconnect the power cable from the electrical outlet, and contact your local dealer or the nearest address provided in the World-Wide Warranty Terms.
s Inquiries When using at an altitude of 1500 m or more, set "High Altitude Mode" to "On". s p.33
Check the following two points.
• Take out the lamp and check if it is cracked. s p.57
• Clean the air filter. s p.54
If it is not cracked _ Re-fit the lamp and turn on the power.
If the error continues _ Replace the lamp with a new lamp and turn on the power.
If the error continues _ Stop using the projector, disconnect the power cable from the electrical outlet, and
contact your local dealer or the nearest address provided in the World-Wide Warranty Terms. s Inquiries
If it is cracked _ Replace it with a new lamp, or contact your local dealer for further advice. If replacing the lamp
yourself, be careful to avoid pieces of broken glass (you cannot continue projecting until the lamp is replaced).
Check that the lamp cover and the lamp are securely installed. s p.57 If the lamp cover or the lamp is not securely installed, the lamp does not switch on.
When using at an altitude of 1500 m or more, set "High Altitude Mode" to "On". s p.33
Problem Solving
44
f i · o · n Indicator is lit or flashing orange
Status Cause Remedy or Status
OrangeRed
Orange
Orange
Orange
High Temp Warning (This is not an abnormality. However, if the temperature rises too high again, projection stops automatically.)
• Check that the air filter and air exhaust vent are clear, and that the projector is not positioned against a wall.
• If the air filter is clogged, clean or replace it. s p.54, 60
Replace Lamp Replace it with a new lamp. s p.57
If you continue to use the lamp after the replacement period has passed, the possibility that the lamp may explode increases. Replace it with a new lamp as soon as possible.
No Air Filter Check that the air filter is securely installed. s p.60 Air Flow Sensor Err.
(EMP-6100 only)
Low Air Flow (EMP-6100 only)
Replace Air Filter If the message "Clean or replace the air filter." is displayed, clean the air filter.
Check that the air filter is securely installed. s p.60 If the error continues when an air filter is installed, the air filter sensor is malfunctioning. Stop using the projector, disconnect the power cable from the electrical outlet, and contact your local dealer or the nearest address provided in the World-Wide Warranty Terms. s Inquiries
If the message "The air filter is clogged. Clean or replace the air filter." is displayed, check the following two points.
• Check that the air filter and air exhaust vent are clear, and that the projector is not positioned against a wall.
• If the air filter is clogged, clean or replace it. s p.54, 60 Replace the air filter if the force of the air flow through the air filter decreases even after repeated cleaning. s p.60 If the error continues after checking the points above, stop using the projector, disconnect the power cable from the electrical outlet, and contact your local dealer or the nearest address provided in the World-Wide Warranty Terms.
s Inquiries
If the air filter has become brown because of tobacco smoke and so on, and you cannot clean it well, replace it with a new air filter. * The indicator and the message telling you when to replace the air filter are only displayed when "Alarm Timer" is
set to "On" in the "Air Filter Setting" menu from the "Extended" menu. s p.34
Warning
: Lit : Flashing : Off : Varies according to the projector status
q
• If the projector is not operating properly, even though the indicators are all showing normal, refer to "When the Indicators Provide No
s
Help" (
p.45).
• If an indicator is displaying a status not described in the tables, contact your local dealer or the nearest address provided in the World-Wide Warranty Terms.
Problem Solving
45

When the Indicators Provide No Help

If any of the following problems occur and the indicators do not offer a solution, refer to the pages given for each problem.
Problems relating to images
f No images appear s p.46
Projection does not start, the projection area is completely black, the projection area is completely blue, and so on.
f Moving images are not displayed s p.46
Moving images being projected from a computer appear black and nothing is projected.
f Projection stops automatically s p.46 f The message "Not supported." is displayed s p.47 f The message "No Signal." is displayed s p.47 f Images are fuzzy or out of focus s p.47 f Interference or distortion appears in images s p.48
Problems such as interference, distortion, or black & white checked patterns appear.
f The image is truncated (large) or small, or the aspect is not
suitable s p.48
Only part of the image is displayed, or the height and width ratios of the image are not correct, and so on.
f Image colours are not right s p.49
The whole image appears purplish or greenish, images are black & white, colours appear dull, and so on. (Computer monitors and LCD screens have different colour reproduction performance, so that the colours projected by the projector and the colours appearing on the monitor may not necessarily match, but this is not a sign of a problem.)
f Images appear dark s p.49 f Nothing appears on the external monitor s p.49
Other problems
f No sound can be heard or the
sound is faint s p.50
f The remote control does not work
s p.50
f Mail is not received even if an
abnormality occurs in the projector (EMP-6100 only) s p.51
Problems when projection starts
f Power does not turn on s p.50
Problem Solving
f Problems relating to images
f No images appear
Check Remedy
Did you press the [Power] button? Press the [Power] button to turn the power on. Are the indicators switched off? The power cable is not connected correctly or power is not being supplied normally.
Connect the projector's power cable correctly. sQuick Start Guide Check that your electrical outlet or power source is functioning correctly.
Is A/V Mute active? Press the [A/V Mute] button on the remote control to cancel A/V Mute. s p.15 Are the configuration menu settings correct? Reset all of the settings. s"Reset"-"Reset All" p.39 Is the projected image completely black? Some input images, such as screen savers, may be completely black.
Only when projecting computer images
Is the image signal format setting correct? Change the setting according to the signal for the connected equipment. s"Signal"-"Video Signal" p.30
Only when projecting images from a video source
f Moving images are not displayed
Check Remedy
Is the computer's image signal being output to the LCD and the monitor?
Only when projecting images from a laptop
computer or a computer with a built-in LCD screen
Change the image signal to external output only. s Check your computer's documentation.
46
f Projection stops automatically
Check Remedy
Is "Sleep Mode" set to "On"? Press the [Power] button to turn the power on. If you do not want to use "Sleep Mode", change the setting to
"Off". s"Extended"-"Operation"-"Sleep Mode" p.33
Is an air filter installed? A message is displayed if the projector is used without an air filter, and the power turns off automatically
after about one minute. Install an air filter and then turn the projector on. s p.60
Problem Solving
f The message "Not supported." is displayed
Check Remedy
Is the image signal format setting correct? Change the setting according to the signal for the connected equipment. s"Signal"-"Video Signal" p.30
Only when projecting images from a video source
Do the image signal resolution and the refresh rate correspond to the mode?
Only when projecting computer images
Refer to the computer's documentation for how to change the image signal resolution and the refresh rate output from the computer. s "List of Supported Monitor Displays" p.72
f The message "No Signal." is displayed
Check Remedy
Are the cables connected correctly? Check that all the cables required for projection are securely connected. sQuick Start Guide Is the correct input port selected? Change the image by pressing the [Source Search] button on the remote control or the control panel.
s p.12
Is the power for the computer or video source turned on? Turn the power on for the equipment. Are the image signals being output to the projector? If the image signals are only being output to the computer's LCD monitor or to the accessory monitor, you
Only when projecting images from a laptop
computer or a computer with a built-in LCD screen
need to change the output to an external destination as well as the computer's own monitor. For some computer models, when the image signals are output externally, they no longer appear on the LCD monitor or accessory monitor. sComputer's documentation, under a title such as "External output" or "Connecting an external monitor" If the connection is made while the power of the projector or computer is already turned on, the function [Fn] key that changes the computer's image signal to external output may not work. Turn the power for the computer and the projector off and then back on again.
47
f Images are fuzzy or out of focus
Check Remedy
Is the focus adjusted correctly? Turn the focus ring to adjust the focus. sQuick Start Guide Is the projector at the correct distance? The recommended projection distance ranges from 83 to 1469 cm (2.7 to 48.2 ft).
Setup within this range. s p.64
Is the Keystone adjustment value too large? Lower the projection angle to reduce the amount of keystone correction. sQuick Start Guide Has condensation formed on the lens? If the projector is suddenly taken from a cold environment to a warm environment, or if sudden ambient
temperature changes occur, condensation may form on the surface of the lens, and this may cause the images to appear fuzzy. Set the projector up in the room about one hour before it is used. If condensation forms on the lens, turn the projector off and wait for the condensation to disappear.
Problem Solving
f Interference or distortion appear in images
Check Remedy
Is the image signal format setting correct? Change the setting according to the signal for the connected equipment. s"Signal"-"Video Signal" p.30
Only when projecting images from a video source
Are the cables connected correctly? Check that all the cables required for projection are securely connected. sQuick Start Guide Is an extension cable being used? If an extension cable is used, electrical interference may affect the signals. Use the cables supplied with the
projector to check if the cables you are using may be causing the problem.
Is the correct resolution selected? Set the computer so that the signals being output are compatible with the projector.
Only when projecting computer images
Are the "Sync.g" and "Trackingg" settings adjusted correctly?
Only when projecting computer images
s "List of Supported Monitor Displays" p.72 sComputer documentation
Press the [Auto] button on the remote control or the [Enter] button on the control panel to perform automatic adjustment. If the images are not adjusted correctly after using automatic adjustment, you can make the adjustments using "Sync." and "Tracking" from the configuration menu. s"Signal"-"Tracking", "Sync."
p.30
f The image is truncated (large) or small, or the aspect is not suitable
Check Remedy
Is a wide panel computer image being projected? Press the [Resize] button on the remote control to change the aspect mode in the order of "Normal", "4:3",
Only when projecting computer images
Is the image still being enlarged by E-Zoom? Press the [Esc] button on the remote control to cancel E-Zoom. s p.18 Is "Position" adjusted correctly? Press the [Auto] button on the remote control or the [Enter] button on the control panel to perform automatic
Is the computer set for dual display? If dual display is activated in the "Display Properties" of the computer's control panel, only about half of the
Only when projecting computer images
Is the correct resolution selected? Set the computer so that the signals being output are compatible with the projector.
Only when projecting computer images
and "16:9". Change the aspect mode according to the resolution.
adjustment of the computer image being projected. If the images are not adjusted correctly after using automatic adjustment, you can make the adjustments using "Position" from the configuration menu. Apart from computer image signals, you can adjust other signals while projecting by adjusting "Position" from the configuration menu. s"Signal"-"Position" p.30
image on the computer screen is projected. To display the entire image on the computer screen, turn off the dual display setting. sComputer video driver documentation
s "List of Supported Monitor Displays" p.72 sComputer documentation
48
Problem Solving
f Image colours are not right
Check Remedy
Do the input signal settings match the signals from the connected device?
Is the image brightness adjusted correctly? Adjust the "Brightness" setting from the configuration menu. s"Image"-"Brightness" p.29 Are the cables connected correctly? Check that all the cables required for projection are securely connected. sQuick Start Guide Is the contrastg setting adjusted correctly? Adjust the "Contrast" setting from the configuration menu. s"Image"-"Contrast" p.29 Is the colour adjusted correctly? Adjust the "Color Adjustment" setting from the configuration menu. s"Image"-"Color Adjustment" p.29 Are the colour saturation and tint adjusted correctly? Adjust the "Color Saturation" and "Tint" settings from the configuration menu. s"Image"-"Color
Only when projecting images from a video source
Change the following settings according to the signal for the connected equipment. When projecting images from equipment connected to Computer1 or Computer2 port s"Signal"- "Computer1/2 Input" p.30 When projecting images from equipment connected to Video or S-Video port s"Signal"-"Video Signal"
p.30
Saturation", "Tint" p.29
f Images appear dark
Check Remedy
Are the image brightness and luminance adjusted correctly? Adjust the "Brightness" and "Brightness Control" settings from the configuration menu.
s"Image"-"Brightness" p.29 s"Settings"-"Brightness Control" p.31
Is the contrastg setting adjusted correctly? Adjust the "Contrast" setting from the configuration menu. s"Image"-"Contrast" p.29 Is the lamp due for replacement? When the lamp is nearly ready for replacement, the images become darker and the colour quality becomes
poorer. When this happens, replace the lamp with a new lamp. s p.57
49
f Nothing appears on the external monitor
Check Remedy
Are images from a port other than the Computer1 port being projected?
The only images that can be displayed on an external monitor are computer images from Computer1 port.
s p.65
Problem Solving
f Problems when projection starts
f Power does not turn on
Check Remedy
Did you press the [Power] button? Press the [Power] button to turn the power on. Are the indicators switched off? The power cable is not connected correctly or power is not being supplied normally.
Connect the projector's power cable correctly. sQuick Start Guide Check that your electrical outlet or power source is functioning correctly
Do the indicators turn on and off when the power cable is touched?
Is the operation lock set to "Full Lock"? Press and hold down the [Enter] button on the control panel for about seven seconds, a message is displayed
Is the correct setting for the remote receiver selected? Check "Remote Receiver" from the configuration menu. s"Settings"-"Remote Receiver" p.31 Was the power cable plugged back in immediately after
Direct Power Off, or is the breaker turned off?
There is probably a poor contact in the power cable, or the power cable may be defective. Reinsert the power cable. If this does not solve the problem, stop using the projector, disconnect the power cable from the electrical outlet, and contact your local dealer or the nearest address provided in the World-Wide Warranty Ter ms . s Inquiries
and the lock is released. s p.25
When the operation to the left is performed when "Direct Power On" is set to "On", the power may not turn back on. Press the [Power] button to turn the power back on.
50
f Other problems
f No sound can be heard or the sound is faint
Check Remedy
Is the audio source connected correctly? Check that the cable is connected to the Audio port. Is the volume adjusted to the minimum setting? Adjust the volume so that sound can be heard. sQuick Start Guide Is A/V Mute active? Press the [A/V Mute] button on the remote control to cancel A/V Mute. s p.15 Is the audio source setting correct? Check the "RCA Audio Input" setting on the configuration menu. s p.31
Only when video equipment is connected to
the EMP-6100
f The remote control does not work
Check Remedy
Is the remote control light-emitting area pointing towards the remote receiver on the projector when it is operated?
Is the remote control too far from the projector? The operating range for the remote control is about 6 m. sQuick Start Guide
Point the remote control towards the remote receiver. The operating angle for the remote control is about 30° horizontally, and about 15° vertically. sQuick Start
Guide
Problem Solving
Check Remedy
Is direct sunlight or strong light from fluorescent lamps shining onto the remote receiver?
Is the correct setting for the remote receiver selected? Check the "Remote Receiver" from the configuration menu. s"Settings"-"Remote Receiver" p.31 Are the batteries dead or have the batteries been inserted
correctly? Was a remote control button pressed for more than 30
seconds?
Set the projector up in a location where strong light does not shine onto the remote receiver. Or, set the remote receiver to "Off" in "Remote Receiver" from the configuration menu. s"Settings"-"Remote Receiver" p.31
Make sure the batteries are inserted correctly or replace the batteries with new ones if necessary. s p.56
If any of the buttons on the remote control are pressed down for more than 30 seconds, the remote control stops sending signals (remote control's sleep mode). This feature is to prevent the batteries running down if the remote control buttons are held down accidentally such as when it is stored in a bag or if an object is placed on top of it. When the button is released, normal remote control operation resumes.
f Mail is not received even if an abnormality occurs in the projector (EMP-6100 only)
Check Remedy
Is the LAN cable connected correctly? Check that the LAN cable is connected correctly. Reconnect it if it is not connected or it is not connected
correctly. s p.66
Is "Mail" set correctly in the configuration menu? Mail notification of abnormalities is sent according to the "Mail" settings in the configuration menu.
Check if it is set correctly. s"Network"-"Mail" p.36
Is "Standby Mode" set to "Network On"? To use the mail notification function when the projector is in standby, set "Network On" in "Standby Mode"
from the configuration menu. s"Extended"-"Standby Mode" p.33
Did a fatal abnormality occur and the projector come to a sudden stop?
Is power being supplied to the projector? Check that your electrical outlet or power source is functioning correctly.
When it comes to a sudden stop, mail cannot be sent. If the abnormal state continues, contact your local dealer or the nearest address provided in the World-Wide Warranty Terms. s Inquiries
51

Appendices

This chapter provides information on maintenance procedures to ensure the best level of performance from the projector for a long time to come.
Installation Methods ........................................... 53
Cleaning............................................................... 54
• Cleaning the Projector's Surface .....................................54
• Cleaning the Lens Cover Glass ........................................54
• Cleaning the Air Filter......................................................54
Replacing Consumables .................................... 56
• Replacing the Remote Control Batteries ........................56
• Replacing the Lamp ..........................................................57
Lamp replacement period...............................................................57
How to replace the lamp.................................................................57
Resetting the lamp operating time..................................................59
• Replacing the Air Filter ....................................................60
Air filter replacement period ..........................................................60
How to replace the air filter............................................................60
Resetting the air filter operating time............................................. 61
Saving a User’s Logo ......................................... 62
Screen Size and Distance .................................. 64
Connecting to External Equipment................... 65
Connecting a LAN Cable (EMP-6100 Only).......66
Optional Accessories and Consumables .........67
Optional accessories....................................................................... 67
Consumables .................................................................................. 67
Glossary...............................................................68
List of ESC/VP21 Commands.............................70
• Command List .................................................................. 70
• Cable Layouts ................................................................... 70
Serial connection............................................................................ 70
PJLink (EMP-6100 Only) .....................................71
List of Supported Monitor Displays ..................72
Computer image............................................................................. 72
Component video ........................................................................... 72
Composite video/S-video............................................................... 72
Specifications......................................................73
Appearance..........................................................76
Index.....................................................................77
• Connecting to an External Monitor ................................65
• Connecting to External Speakers (EMP-6100 Only) .....65

Installation Methods

53
The projector supports the following four different projection methods.
Attention
• A special method of installation is required when suspending the projector from the ceiling (ceiling mount). If it is not installed correctly, it could fall causing an accident and injury.
• If you use adhesives on the ceiling mount to prevent the screws from loosening, or if you use things such as lubricants or oils on the projector, the projector case may crack causing it to fall from its ceiling mount. This could cause serious injury to anyone under the ceiling mount and could damage the projector. When installing or adjusting the ceiling mount, do not use adhesives to prevent the screws from loosening and do not use oils or lubricants and so on.
• Do not use the projector on its side. This may cause malfunctions to occur.
• Project images from in front of the screen (Front projection)
• Suspend the projector from the ceiling and project images from in front of the screen. (Front/Ceiling projection)
• Project images from behind a translucent screen (Rear projection)
• Suspend the projector from the ceiling and project images from behind a translucent screen. (Rear/Ceiling projection)
q
• An optional ceiling mount is required when suspending
s
the projector from the ceiling.
• You can change the setting as follows by pressing down the [A/V Mute] button on the remote control for about five seconds.
W
"Front" Set "Rear" or "Rear/Ceiling" from the configuration menu.
"Front/Ceiling"
s
p.33
p.67

Cleaning

54
You should clean the projector if it becomes dirty or if the quality of projected images starts to deteriorate.

Cleaning the Projector's Surface

Clean the projector's surface by wiping it gently with a soft cloth. If the projector is particularly dirty, moisten the cloth with water containing a small amount of neutral detergent, and then firmly wring the cloth dry before using it to wipe the projector's surface.
Attention
Do not use volatile substances such as wax, alcohol, or thinner to clean the projector's surface. The quality of the case may change or become discoloured.

Cleaning the Lens Cover Glass

Use a commercially available cloth for cleaning glasses to gently wipe the lens cover glass.

Cleaning the Air Filter

Clean the air filter when the following message is displayed.
• "The air filter is clogged. Clean or replace the air filter."
• "Clean or replace the air filter."
However, if the air filter has turned brown because it has been stained by tobacco smoke and so on, it cannot be cleaned. In this case, replace it with a new air filter. s "How to replace the air filter" p.60
Attention
• If dust collects on the air filter it can cause the internal temperature of the projector to rise, and this can lead to problems with operation and shorten the optical engine's service life. Clean the air filter immediately when the message is displayed.
• If you continue to use the air filter after it has turned brown and been stained with tobacco resin, the optical engine deteriorates quickly and the luminance intensity falls.
Attention
Do not rub the lens cover glass with harsh materials or subject the lens to shocks, as it can easily become damaged.
Cleaning
55
Procedure
A
B
Open the air filter cover.
While pushing the air filter catches, pull the cover down.
Use a vacuum cleaner to remove dust from the air filter.
q
• After cleaning the air filter, make sure you set "Reset Air
s
Filter Time" from the configuration menu.
• If a message is frequently displayed, even after cleaning, it is time to replace the air filter. Replace it with a new air
s
filter.
p.60
p.39

Replacing Consumables

56
This section explains how to replace the remote control batteries, the lamp, and the air filter.

Replacing the Remote Control Batteries

If delays in the responsiveness of the remote control occur or if it does not operate after it has been used for some time, it probably means that the batteries are becoming flat. When this happens, replace them with new batteries. Have two spare AAA-size alkali batteries ready to use when required.
Attention
Make sure you read the Safety Instructions/World-Wide Warranty Terms before handling the batteries.
Procedure
A
Remove the battery cover.
While pushing the battery compartment cover catch, lift the cover up.
s
Safety Instructions
B
C
Replace the old batteries with new batteries.
Attention
Check the positions of the (+) and (-) marks inside the battery holder to ensure the batteries are inserted the correct way.
Replace the battery cover.
Press the battery compartment cover until it clicks into place.
Catch
Replacing Consumables

Replacing the Lamp

f Lamp replacement period
It is time to replace the lamp when:
• The message "Replace the lamp." is displayed when you start projecting.
A message is displayed.
• The lamp indicator flashes orange.
Attention
• The lamp replacement message is set to appear after the following time periods in order to maintain the initial brightness and quality
s
of the projected images.
·When used continually at high brightness: About 1900 hours
·When used continually at low brightness: About 2900 hours
• If you continue to use the lamp after the replacement period has passed, the possibility that the lamp may explode increases. When the lamp replacement message appears, replace the lamp with a new one as soon as possible, even if it is still working.
• Depending on the characteristics of the lamp and the way it has been used, the lamp may become darker or stop working before the lamp warning message appears. You should always have a spare lamp ready incase it is needed.
f How to replace the lamp
"Brightness Control" p.31
57
Flashing orange
• The projected image gets darker or starts to deteriorate
Attention
• When replacing the lamp because it has stopped illuminating, there is a possibility that the lamp may be broken. If replacing the lamp of a projector which has been installed on the ceiling, you should always assume that the lamp is broken, and you should stand to the side of the lamp cover, not underneath it. Remove the lamp cover gently. Small pieces of glass may fall out when the lamp cover is opened. If pieces of glass get into your eyes or mouth, seek medical advice immediately.
• Wait until the lamp has cooled down sufficiently before removing the lamp cover. If the lamp is still hot, burns or other injuries may result. It takes about one hour after the power has been turned off for the lamp to be cool enough.
Replacing Consumables
58
Procedure
A
B
After you turn off the projector's power and the confirmation buzzer beeps twice, disconnect the power cable.
Wait until the lamp has cooled down, then remove the lamp cover from the surface of the projector.
Open the lamp cover by inserting the screwdriver supplied with the new lamp into the lamp cover side switch, and remove the lamp cover without removing the screwdriver.
C
D
Loosen the two lamp fixing screws.
Take out the old lamp.
If the lamp is cracked, replace it with a new lamp, or contact your local dealer for further advice. If replacing the lamp yourself, be careful to avoid pieces of broken glass.
Replacing Consumables
59
E
F
Install the new lamp.
Insert the new lamp so that the lamp fits in place correctly and, once it is fully inserted, tighten the two screws.
Replace the lamp cover.
Attention
• Make sure you install the lamp securely. If the lamp cover is removed, the lamp turns off automatically as a safety precaution. If the lamp or the lamp cover is not installed correctly, the lamp does not turn on.
• This product includes a lamp component that contains mercury (Hg). Please consult your local regulations regarding disposal or recycling. Do not dispose of it with normal household waste.
f Resetting the lamp operating time
The projector records how long the lamp is turned on and a message and indicator notify you when it is time to replace the lamp. After replacing the lamp, make sure you reset the lamp hours from the configuration menu. s p.39
Only reset the lamp operating time after the lamp has been
q
replaced, otherwise the lamp replacement period is not indicated correctly.
Replacing Consumables
60

Replacing the Air Filter

f Air filter replacement period
It is time to replace the air filter when:
• The air filter has been turned brown by such things as tobacco resin.
• When the message "The air filter is clogged. Clean or replace the air filter." is frequently displayed, even though the air filter has been cleaned.
f How to replace the air filter
The air filter can be replaced even when the projector is suspended from a ceiling.
Procedure
A
After you turn off the projector's power and the confirmation buzzer beeps twice, disconnect the power cable.
B
C
Open the air filter cover.
While pushing the air filter cover catches, pull the cover down.
Remove the air filter.
Grip the raised part at the centre of the air filter and pull it straight out.
Replacing Consumables
61
D
E
Install the new air filter.
Close the air filter cover.
Press the cover until it clicks into place.
Set so that the projected ridge points to the front of the projector.
• Make sure you install an air filter. A message is displayed
q
f Resetting the air filter operating time
The projector keeps a running total of the time the air filter is used and a message and indicator notify you when it is time to replace the air filter. After replacing the air filter, make sure you reset the air filter time from the configuration menu. s p.39
q
if the projector is used without an air filter, and the power turns off automatically after about one minute.
• Dispose of used air filters properly in accordance with your local regulations. Material quality of the frame section: PP Material quality of the filter section: PP·PET
• Do not reset the air filter operating time except after replacing or cleaning the air filter.
• If "Alarm Timer" is set to "Off" in "Air Filter Setting" from the configuration menu, the projector does not inform you when it is time to replace the air filter even if the air filter replacement time is reached.

Saving a User’s Logo

62
You can save the image that is currently being projected as a user's logo.
When a user's logo is saved, the previous user's logo is
q
Procedure
A
erased.
Project the image you want to use as the user's logo, and then press the [Menu] button.
Using the remote control Using the control panel
B
q
From the configuration menu, select "Extended" ­"User's Logo". s "Using the Configuration Menu"
p.28
Check the buttons you can use and the operations they perform in the guide under the menu.
• If "User's Logo Protect" from "Password Protect" is set to "On", a message is displayed and the user's logo cannot be changed. You can make changes after setting
s
"User's Logo Protect" to "Off".
• If "User's Logo" is selected when Keystone, E-Zoom, Resize, and Progressive are being performed, the function currently being performed is cancelled.
p.23
C
q
When "Choose this image as the User's Logo?" is displayed, select "Yes".
When you press the [Enter] button on the remote control or the control panel, the screen size may change according to the signal as it changes to the resolution of the image signal.
Saving a User’s Logo
63
D
The image is recorded and a selection marquee box is displayed. Move the box to select the part of the image to use as the user's logo.
Using the remote control Using the control panel
E F
G
q
When "Select this image?" is displayed, select "Yes".
Select the zoom factor from the zoom setting screen.
When the message "Save this image as the User's Logo?" is displayed, select "Yes".
The image is saved. After the image has been saved, the message "Completed" is displayed.
• Saving the user's logo may take about 15 seconds. Do not use the projector or any connected equipment while it is saving, otherwise malfunctions may occur.
• Once a user's logo has been saved, the logo cannot be returned to the factory default.
q
You can save at up to 400 ^ 300 dots in size.

Screen Size and Distance

See the following table to choose the best position for your projector. The values are only a guide.
Units: cm (in.) Units: cm (ft) Units: cm (in.)
Projection Distance
4:3 Screen Size
(Zoom Adjustment Wide) to (Zoom Adjustment Tele)
30" 61 ^ 46 (24.0 ^ 18.1) 83 to 139 (2.7 to 4.6) 4 (1.6) 40" 81 ^ 61 (31.9 ^ 24.0) 114 to 189 (3.7 to 6.2) 6 (2.2) 50" 100 ^ 76 (39.4 ^ 30.0) 144 to 238 (4.7 to 7.8) 7 (2.7) 60" 120 ^ 90 (47.2 ^ 35.4) 174 to 287 (5.7 to 9.4) 8 (3.3)
80" 160 ^ 120 (63.0 ^ 47.2) 235 to 386 (7.7 to 12.6) 11 (4.4) 100" 200 ^ 150 (78.7 ^ 59.1) 296 to 484 (9.7 to 15.9) 14 (5.5) 120" 240 ^ 180 (94.4 ^ 70.8) 357 to 583 (11.7 to 19.1) 17 (6.5) 150" 300 ^ 230 (118.1 ^ 90.6) 449 to 730 (14.7 to 24.0) 21 (8.2) 200" 410 ^ 300 (161.4 ^ 118.1) 601 to 977 (19.7 to 32.0) 28 (10.9) 300" 610 ^ 460 (240.2 ^ 181.1) 906 to 1469 (29.7 to 48.2) 42 (16.4)
Minimum Maximum
U
Distance from the Centre of the
Lens to the Base of the Screen
64
V
90°
Screen
Centre of lens
90°
Centre of lens
Screen

Connecting to External Equipment

65

Connecting to an External Monitor

Computer images being input to the Computer1 port can be displayed on an external monitor and the screen at the same time when connected to the projector. This means that you can check projected images on an external monitor when giving presentations even if you cannot see the screen. Connect to an external monitor using the cable supplied with the monitor.
Monitor port

Connecting to External Speakers (EMP-6100 Only)

You can connect speakers with built-in amplifiers to the projector's Audio Out port to enjoy a fuller quality of sound. Connect with a commercially available audio cable (pin plug W 3.5 mm stereo mini plug and so on). Use an audio cable compatible with the connector on the external speakers.
To external speakers
q
Cable supplied with monitor To Monitor Out port (black)
• Component video signals and equipment connected to the Computer2 port, Video port, and S-Video port cannot be output to an external monitor.
• The setting gauge for Keystone, the configuration and help screen, and so on are not output to an external monitor.
q
Audio cable
To Audio Out port
(commercially available)
When an audio cable plug is inserted in the Audio Out port, the audio changes to the external destination, and audio is no longer emitted from the projector's built-in speaker.

Connecting a LAN Cable (EMP-6100 Only)

Connect with a commercially available 100baseTX or 10baseT type LAN cable.
To LAN port
66
LAN cable
(commercially available)
To LAN port
Attention
To prevent malfunctions, use a category 5 shielded LAN cable.

Optional Accessories and Consumables

67
The following list of optional accessories is current as of July, 2006. Details of accessories are subject to change without notice and availability may vary depending on the country of purchase.
f Optional accessories
60" portable screen ELPSC07 80" portable screen ELPSC08 100" screen ELPSC10
Portable roll-type screens (Aspect ratio
50" portable screen ELPSC06
A compact screen that can be carried easily (Aspect ratio 4:3)
HD-15 cable ELPKC02 (1.8 m - for mini D-Sub 15-pin/mini D-Sub 15-pin)
This is the same as the computer cable supplied with the projector.
HD-15 cable ELPKC09 (3 m - for mini D-Sub 15-pin/mini D-Sub 15-pin) HD-15 PC cable ELPKC10 (20 m - for mini D-Sub 15-pin/mini D-Sub 15-pin)
Use one of these longer cables if the computer cable supplied with the projector is too short.
Component video cable ELPKC19 (3 m - for mini D-Sub 15-pin/RCA male ^ 3)
Use to connect a component video
g4:3)
g source.
Ceiling mount* ELPMB07 Ceiling mount (for use as ceiling plate)
Use when installing the projector on a ceiling.
* A special method of installation is required to suspend the projector from a
ceiling. Contact your local dealer or the nearest address provided in the Wor ld - Wide Warranty Terms if you want to use this installation method. s Inquiries
*
ELPMB21
f Consumables
Lamp unit ELPLP37
Use as a replacement for used lamps.
Air filter (high efficient) ELPAF11
(Use to filter general dust, clouds of dust, and chalk dust)
Air filter (smoke) ELPAF12
(Use to filter cigarette smoke) Use as a replacement for used air filters. Choose one of the two types depending on the projector's environment.
Ceiling plate* ELPFC03 Ceiling pipe 370 mm (silver) Ceiling pipe 570 mm (silver) Ceiling pipe 770 mm (silver) Suspension adapter 450 mm (cable cover attachment for ELPMB21) ELPFP11 Suspension adapter 700 mm (cable cover attachment for ELPMB21) ELPFP12
Use when installing the projector on a high ceiling.
*
ELPFP04
*
ELPFP05
*
ELPFP06
*
*

Glossary

This section explains easily terms that are used with the projector and difficult terms that are not explained in the text of this guide. For details, refer to other commercially available publications.
Aspect ratio The ratio between an image's length and its height. HDTV images have an aspect ratio of 16:9 and appear elongated. The aspect ratio for
standard images is 4:3.
Component video A video signal which has the luminance component and colour component separated to provide better image quality.
Refers to images that consist of three independent signals: Y (luminance signal), Pb and Pr (colour difference signals).
Composite video Video signals that have the video brightness signals and colour signals mixed together. The type of signals commonly used by household
video equipment (NTSC, PAL, and SECAM formats). The carrier signal Y (luminance signal) and chroma (colour) signal that are contained in the colour bar are overlapped to form a single signal.
Contrast The relative brightness of the light and dark areas of an image can be increased or decreased to make text and graphics stand out more
clearly, or to make them appear softer. Adjusting this particular property of an image is called "contrast adjustment".
Dolby Digital A sound format developed by Dolby Laboratories. Normal stereo is a 2-channel format that uses two speakers. Dolby Digital is a 6-
channel (5.1-channel) system which adds to this a centre speaker, two rear speakers, and a sub-woofer.
HDTV An abbreviation for High-Definition Television that refers to high-definition systems which satisfy the following conditions.
• Vertical resolution of 750p or 1125i or greater (p =progressive
• Screen aspect ratio
• Dolby Digital
Interlace A method of image scanning whereby the image data is divided into fine horizontal lines that are displayed in sequence starting from left
to right and then from top to bottom. The even-numbered lines and odd-numbered lines are displayed alternately.
Progressive A method of image scanning whereby the image data from a single image is scanned sequentially from top to bottom to create a single
image.
Refresh rate The light-emitting element of a display maintains the same luminosity and colour for an extremely short time. Because of this, the image
must be scanned many times per second to refresh the light-emitting element. The number of refresh operations per second is called the Refresh rate and is expressed in hertz (Hz).
SDTV An abbreviation for Standard Definition Television that refers to standard television systems which do not satisfy the conditions for
HDTV
SNMP An abbreviation for Simple Network Management Protocol, which is the protocol for monitoring and controlling devices such as routers
and computers connected to a TCP/IP network.
Squeeze mode In this mode, wide-screen images in 16:9 mode are compressed in the horizontal direction so that they are stored on the recording
medium as 4:3 images. When these images are played back by the projector in squeeze mode, they are restored to their original 16:9 format.
sRGB An international standard for colour intervals that was formulated so that colours that are reproduced by video equipment can be handled
easily by computer operating systems (OS) and the Internet. If the connected source has an sRGB mode, set both the projector and the connected signal source to sRGB.
g High-Definition Television.
g of 16:9
g audio reception and playback (or output)
g, i =interlaceg)
68
Glossary
SVGA A type of video signal with a resolution of 800 (horizontal) ^ 600 (vertical) dots that is used by IBM PC/AT-compatible computers. S-video A video signal which has the luminance component and colour component separated to provide better image quality.
Refers to images that consist of two independent signals: Y (luminance signal) and C (colour signal).
SXGA A type of video signal with a resolution of 1280 (horizontal) ^ 1024 (vertical) dots that is used by IBM PC/AT-compatible computers. Synchronization The signals output from computers have a specific frequency. If the projector frequency does not match this frequency, the resulting
images are not of a good quality. The process of matching the phases of these signals (the relative position of the crests and the troughs in the signal) is called Synchronization. If the signals are not synchronized, flickering, blurriness, and horizontal interference occur.
Tracking The signals output from computers have a specific frequency. If the projector frequency does not match this frequency, the resulting
images are not of a good quality. The process of matching the frequency of these signals (the number of crests in the signal) is called Tracking. If tracking is not carried out correctly, wide vertical stripes appear in the signal.
VGA A type of video signal with a resolution of 640 (horizontal) ^ 480 (vertical) dots that is used by IBM PC/AT-compatible computers. XGA A type of video signal with a resolution of 1024 (horizontal) ^ 768 (vertical) dots that is used by IBM PC/AT-compatible computers.
69

List of ESC/VP21 Commands

70

Command List

When the power ON command is transmitted to the projector, the power turns on and it enters warm-up mode. When the projector's power has turned on, a colon ":" (3Ah) is returned. When a command is input, the projector executes the command and returns a ":", and then accepts the next command. If the command being processed terminates abnormally, an error message is output and a ":" is returned.
Item Command
Power ON/OFF ON PWR ON
OFF PWR OFF
Signal selection Video SOURCE 41
S-Video SOURCE 42
A/V Mute ON/OFF ON MUTE ON
OFF MUTE OFF
A/V Mute selection Black MSEL 00
Blue MSEL 01 Logo MSEL 02
Command
Item
Signal selection Computer (Auto) SOURCE 1F SOURCE 2F
Computer SOURCE 11 SOURCE 21 Component Video SOURCE 14 SOURCE 24
Computer1
Port
Computer2
Port

Cable Layouts

f Serial connection
• Connector shape : D-Sub 9-pin (male)
• Projector input connector : RS-232C
<At the projector> <At the computer>
<At the projector> (PC serial cable) <At the computer>
GND 5 5 GND
RD 2 3 TD TD 3 2 RD
DTR 4 6 DSR
DSR 6 4 DTR
Signal Function
GND Signal wire ground
TD Transmit data
RD Receive data
DSR Data set ready
DTR Data terminal ready
* Add a Carriage Return (CR) code (0Dh) to the end of each command and
transmit.

PJLink (EMP-6100 Only)

PJLink Class 1 was established by the JBMIA (Japan Business Machine and Information System Industries Association) as a standard protocol for controlling network-compatible projector's as part of their efforts to standardize projector control protocols. The projector complies with the PJLink Class 1 standard established by the JBMIA. It complies with all commands except for the following commands defined by PJLink Class 1, and agreement was confirmed by the PJLink standard adaptability verification.
f Non-compatible commands
Function PJLink Command
Mute settings Image muting set AV MT 1 1
Image muting cancel AV M T 1 0 Audio muting set AV M T 2 1 Audio muting cancel AV M T 2 0
Mute status queries Normal (only images muted) AV M T = 1 1
Normal (only audio muted) AV M T = 2 1
71
f Input names defined by PJLink and corresponding projector
connectors
Input Connector PJLink Command
Computer1 INPT 11 Computer2 INPT 12 Video INPT 21 S-Video INPT 22
f Manufacturer name displayed for "Manufacture name information
query"
EPSON
f
Model name displayed for "Product name information query"
EMP-6100

List of Supported Monitor Displays

72
f Computer image
Number of
Signal
VGAEGA 640 ^ 350 1024 ^ 560
VGAg 60/72/75/85, iMac
SVGAg 56/60/72/75/85, iMac
XGAg 60/70/75/85, iMac
SXGAg 70/75/85 1152 ^ 864 1024 ^ 768
SXGA 60/75/85 1280 ^ 960 1024 ^ 768 SXGA 60/75/85 1280 ^ 1024 960 ^ 768
UXGA 60 1600 ^ 1200 1024 ^ 768 MAC13" 640 ^ 480 1024 ^ 768 MAC16" 832 ^ 624 1024 ^ 768 MAC19" 1024 ^ 768 1024 ^ 768 MAC19" 60 1024 ^ 768 1024 ^ 768 MAC21" 1152 ^ 870 1016 ^ 768
SDTVg (525i) 60 720 ^ 480 1024 ^ 768
SDTV (625i) 50 720 ^ 576 1024 ^ 768 SDTV (525p) 60 720 ^ 480 1024 ^ 768 SDTV (625p) 50 720 ^ 576 1024 ^ 768
HDTVg (750p) 50/60 1280 ^ 720 1024 ^ 576
HDTV (1125i) 50/60 1920 ^ 1080 1024 ^ 576
Refresh Rateg
(Hz)
*
*
Resolution
(dots)
640 ^ 480 1024 ^ 768
*
800 ^ 600 1024 ^ 768
1024 ^ 768 1024 ^ 768
Pixels Used
When Display
is Resized
(dots)
f Component video
Signal
SDTVg (525i) 60 1024 ^ 768 1024 ^ 576
SDTV (625i) 50 1024 ^ 768 1024 ^ 576 SDTV (525p) 60 1024 ^ 768 1024 ^ 576 SDTV (625p) 50 1024 ^ 768 1024 ^ 576
HDTVg (750p)
16:9
HDTV (1125i)
16:9
Refresh Rateg
(Hz)
50/60 1024 ^ 768 1024 ^ 576
50/60 1024 ^ 768 1024 ^ 576
Aspect Ratiog
Resolutions (dots)
Aspect Ratio
4:3
f Composite video/S-video
Signal
TV (NTSC) 60 1024 ^ 768 1024 ^ 576
TV
(PAL, SECAM)
Refresh Rateg
(Hz)
50 1024 ^ 768 1024 ^ 576
Aspect Ratiog
Resolutions (dots)
Aspect Ratio
4:3
16:9
16:9
* Connection is not possible if the equipment does not have a VGA output port.
Even when signals other than those mentioned above are input, it is likely that the image can be projected. However, not all functions may be supported.

Specifications

73
Product name Multimedia Projector
EMP-6100
Dimensions 465 (W) ^ 146 (H) ^ 340 (D) mm (not including feet) Panel size 0.8" Display method Polysilicon TFT active matrix Resolution 786432 pixels XGAg(1024 (W) ^ 768 (H) dots) ^ 3 Focus adjustment Manual Zoom adjustment Manual (approx. 1 to 1.6) Lamp UHE lamp, 230 W, Model No.: ELPLP37 Max. audio output 5W monaural 1W monaural Speaker 1 Power supply 100 to 240 V AC ±10%, 50/60 Hz 3.7 to 1.6 A Power
consumption
Operating altitude Altitude 0 to 3000 m (0 to 9843 ft) Operating temperature 0 to +40°C* (No condensation) Storage temperature -10 to +60°C (No condensation) Weight Approx 7 Kg Connectors Computer1 port 1 Mini D-Sub15-pin (female) blue
* At an altitude of 1500 to 3000 m, and when "Brightness Control" is set to "High", the operating temperature
is 0 to +35°C.
100 to 120 V area Operating: 330 W
Standby power consumption (network invalid): 0.4 W
Standby power consumption (network valid): 10 W
230 V area Operating: 310 W
Standby power consumption (network invalid): 0.7 W
Standby power consumption (network valid): 9 W
Audio port 1 Stereo mini jack ­Computer2 port 1 Mini D-Sub15-pin (female) blue Audio port 1 Stereo mini jack ­S-Video port 1 Mini DIN 4-pin Audio port 1 Stereo mini jack ­Video port 1 RCA pin jack Audio port 1 RCA pin jack RS-232C port 1 Mini D-Sub 9-pin (male) LAN Port 1 RJ45 ­Monitor Out port 1 Mini D-Sub15-pin (female) black Audio Out port 1 Stereo mini jack -
Multimedia Projector
EMP-6000
Pixelworks DNX used in this projector.
Angle of tilt
If you use the projector tilted at an angle of more than 30° it could be damaged and cause an accident.
TM
ICs are
0 to 30°0 to 30°
Specifications
74
Safety standards
USA UL60950-1
Canada CSA C22.2 No.60950-1
EU The Low Voltage Directive (73/23/EEC) IEC/EN60950-1
EMC standards
USA FCC Part 15B Class B (DoC)
Canada ICES-003 Class B
EU The EMC Directive (89/336/EEC) EN55022, Class B EN55024 IEC/EN61000-3-2 IEC/EN61000-3-3
Australia/New Zealand AS/NZS CISPR 22:2002 Class B
Specifications
DECLARATION of CONFORMITY
According to 47CFR, Part 2 and 15
Class B Personal Computers and Peripherals; and/or
CPU Boards and Power Supplies used with Class B
Personal Computers
We : Epson America, Inc. Located at : 3840 Kilroy Airport Way
MS: 3-13 Long Beach, CA 90806
Tel : 562-290-5254
Declare under sole responsibility that the product identified herein, complies with 47CFR Part 2 and 15 of the FCC rules as a Class B digital device. Each product marketed, is identical to the representative unit tested and found to be compliant with the standards. Records maintained continue to reflect the equipment being produced can be expected to be within the variation accepted, due to quantity production and testing on a statistical basis as required by 47CFR 2.909. Operation is subject to the following two conditions :
Trade Name : EPSON
Type of Product : Projector
75
FCC Compliance Statement
For United States Users
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio and television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures.
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING
The connection of a non-shielded equipment interface cable to this equipment will invalidate the FCC Certification or Declaration of this device and may cause interference levels which exceed the limits established by the FCC for this equipment. It is the responsibility of the user to obtain and use a shielded equipment interface cable with this device. If this equipment has more than one interface connector, do not leave cables connected to unused interfaces. Changes or modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment.
Model : EMP-6100/EMP-6000

Appearance

76
4-M4X9
Centre of lens
18
128
32
18
95.9
26
156
465
* Distance from centre of lens to suspension bracket fixing point
136
*
23
120
94
187.1
72.9
340
Units: mm

Index

77
A
A/V mute ....................................................... 15, 33
Abs. color temp ................................................... 29
Address 1/2/3 setting .......................................... 36
Adjustment level .................................................. 20
Air exhaust vent .................................................... 5
Air filter ...................................................... 5, 38, 67
Air filter replacement period ................................ 60
Air filter setting .................................................... 34
Air intake vent ....................................................... 5
Alarm timer .......................................................... 34
Angle of tilt .......................................................... 73
Appearance ......................................................... 76
Aspect ratio ................................................... 16, 30
Audio out port ........................................................ 6
Audio port .............................................................. 6
Auto setup ........................................................... 30
B
Blackboard .......................................................... 14
Brightness ........................................................... 29
Brightness control ............................................... 31
C
Cable cover lock .................................................. 26
Cleaning the air filter ........................................... 54
Cleaning the lens cover glass ............................. 54
Cleaning the projector’s surface .......................... 54
Color adjustment ................................................. 29
Color mode .......................................................... 29
Color saturation ................................................... 29
Colour mode ........................................................ 14
Community name ................................................ 36
Computer1 input .................................................. 30
Computer1 port ................................................. 6, 7
Computer2 input .................................................. 30
Computer2 port ................................................. 6, 7
Configuration menu .............................................28
Connecting a LAN cable ......................................66
Consumables .......................................................67
Contrast ...............................................................29
Control panel .........................................................8
Cross ...................................................................18
D
DHCP ..................................................................35
Direct power on ...................................................33
Display .................................................................33
Display background .............................................33
E
ESC/VP21 ...........................................................70
Extended menu ...................................................33
External monitor ..................................................65
External speakers ................................................65
E-zoom ................................................................18
F
Filter indicator ......................................................42
Focus ring ..............................................................5
Freeze .................................................................15
Front ....................................................................33
Front adjustable feet ..............................................5
Full lock ...............................................................25
G
Game ...................................................................14
Gateway address .................................................35
Glossary ..............................................................68
H
Handle .................................................................10
Help function ....................................................... 41
High altitude mode .............................................. 33
How to replace the lamp ..................................... 57
I
Image correction ........................................... 20, 34
Image menu ........................................................ 29
Indicators ............................................................ 42
Info menu ............................................................ 38
Input signal .......................................................... 38
IP address ........................................................... 35
K
Keystone ............................................................. 31
L
Lamp cover ........................................................... 5
Lamp hours ......................................................... 38
Lamp indicator .................................................... 42
Lamp replacement period ................................... 57
LAN port ................................................................ 6
Language ............................................................ 34
Low ..................................................................... 31
M
MAC address ...................................................... 35
Mail ..................................................................... 36
Mail notification ................................................... 36
Menu ................................................................... 28
Message ............................................................. 33
Monitor out port ................................................. 6, 7
Multi-screen ........................................................ 34
Multi-screen adjustment ...................................... 19
Index
78
N
Network menu ..................................................... 35
Network protect ................................................... 22
Numeric buttons .................................................... 9
O
Operating temperature ........................................ 73
Operation ............................................................ 33
Operation lock ............................................... 25, 31
Optional accessories ........................................... 67
P
Part names and functions ..................................... 5
Partial lock ........................................................... 25
Password protect ................................................ 22
Password protect sticker ..................................... 23
Password timer ................................................... 22
Photo ................................................................... 14
PJLink ................................................................. 71
PJLink password ................................................. 35
Pointer ................................................................. 17
Pointer shape ...................................................... 31
Port number ........................................................ 36
Position ............................................................... 30
Power indicator ................................................... 42
Power inlet ........................................................ 6, 7
Power on protect ................................................. 22
Presentation ........................................................ 14
Problem solving ................................................... 42
Progressive ......................................................... 30
Projection ............................................................ 33
Projection distance .............................................. 64
Projector name .................................................... 36
R
RCA audio input .................................................. 31
Rear .....................................................................33
Rear foot ............................................................6, 7
Refresh rate .........................................................38
Remote control ......................................................9
Remote control light-emitting area .......................10
Remote receiver ......................................5, 6, 7, 31
Replacing batteries ..............................................56
Replacing the air filter ..........................................60
Request code ......................................................24
Reset all ...............................................................39
Reset menu .........................................................39
Resetting the air filter operating time .............39, 61
Resetting the lamp operating time .................39, 59
Resize ......................................................16, 30, 72
Resolution ......................................................38, 72
RS-232C port .....................................................6, 7
S
Screen ID .............................................................34
Screen size ..........................................................64
Security cable installation point ...........................10
Security slot .......................................................6, 7
Settings menu ......................................................31
Sharpness ...........................................................29
Signal menu .........................................................30
Sleep mode .........................................................33
SMTP server ........................................................36
SNMP ..................................................................36
Soft keyboard ......................................................36
Source .................................................................38
Source search .............................................8, 9, 12
Speaker .................................................................5
Specifications ......................................................73
Sports ..................................................................14
sRGB ...................................................................14
Standby mode .....................................................33
Startup screen .....................................................33
Storage feet .......................................................6, 7
Storage temperature ............................................73
Sub menu ............................................................ 28
Subnet mask ....................................................... 35
Supported monitor displays ................................ 72
Suspension bracket fixing points .................. 10, 76
S-video port ....................................................... 6, 7
Sync. ................................................................... 30
Sync. info ............................................................ 38
T
Temp indicator .................................................... 42
Test pattern ......................................................... 32
Theatre ................................................................ 14
Timer ................................................................... 34
Tint ...................................................................... 29
Top menu ............................................................ 28
Tracking .............................................................. 30
Trap IP address .................................................. 36
U
User’s logo .......................................................... 62
User’s logo protect .............................................. 22
V
Video port .......................................................... 6, 7
Video signal .................................................. 30, 38
Volume ........................................................ 8, 9, 31
W
Warning mail ....................................................... 37
Web control password ........................................ 35
Wide-screen projection ....................................... 16
Wired LAN ........................................................... 35
Z
Zoom ring .............................................................. 5
79
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation. No patent liability is assumed with respect to the use of the information contained herein. Neither is any liability assumed for damages resulting from the use of the information contained herein.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation's operating and maintenance instructions.
Seiko Epson Corporation shall not be liable against any damages or problems arising from the use of any options or any consumable products other than those designated as Original Epson Products or Epson Approved Products by Seiko Epson Corporation.
General Notice: Macintosh, Mac, and iMac are registered trademarks of Apple Computer, Inc. IBM is a registered trademark of International Business Machines Corporation. Windows, Windows NT and VGA are trademarks or registered trademarks of Microsoft Corporation in the United States of America. Dolby is a trademark of Dolby Laboratories. Pixelworks and DNX are trademarks of Pixelworks, Inc.
Other product names used herein are also for identification purposes only and may be trademarks of their respective owners. Epson disclaims any and all rights in those marks. This product uses open source software.
The contents of this guide may be changed or updated without further notice.
Illustrations in this guide and the actual projector may differ.
ZSEIKO EPSON CORPORATION 2006. All rights reserved.
Loading...
