Page 1
PowerLite® 4200W
MULTIMEDIA PROJECTOR
Brilliant widescreen performance. Easy installation.
The PowerLite 4200W offers a flexible widescreen solution that’s easily installed in any classroom or
boardroom. WXGA (1280 x 800) resolution means you get 30 percent more image area than with
standard 4:3 projectors, so it’s easy to display content from the latest widescreen computers and
HD devices. This powerful performer ensures amazing presentations with 4500 lumens of color light
output and white light output.
added peace of mind. It even includes a closed captioning decoder, so there are no added costs
to accommodate those with hearing impairments. The PowerLite 4200W is ideal for both executive
boardrooms and educational institutions, with the value, power and performance for all your
presentation needs.
Brilliant widescreen performance — WXGA resolution (16:10), 4500 lumens color
and white light output
Network-ready — RJ-45 LAN connection with monitor and control capabilities
Easy installation — horizontal/vertical lens shift, centered lens design, 1.8x zoom lens
and Quick Corner
®
allow for flexible room placement and easy image adjustments at setup
1
And, it offers one-touch filter removal and easy side lamp access for
1
Page 2
PowerLite® 4200W
MULTIMEDIA PROJECTOR
The best-selling projectors in the world.
Epson understands business and education and has a solution no matter what your situation. Built with
image quality and reliability in mind, Epson projectors enhance communication and inspire collaboration,
while offering a low total cost of ownership. From long-throw projectors to ultra-short-throw
and all-in-one solutions, Epson has the model made for you.
Brilliant image quality
3LCD technology — for quality and
color that’s beyond amazing
• 3 chips for full-time, vibrant color
• 25% less electricity required per lumen of brightness
when compared to 1-chip DLP projectors
• Over 20 years of road-tested reliability built
into every projector
Screen
Lens
Mirror
Mirror
Prism
Green
3LCD chips
Blue
2
Dichroic mirror
Red
Mirror
Lamp
Dichroic mirror
Advanced sharpness
Another feature Epson has transferred over from its
industry-leading home cinema projectors—advanced sharpness
for video. Depending on the content, users can adjust any of
the following attributes of the image: thin line enhancement,
thick line enhancement, vertical line enhancement or
horizontal line enhancement.
Amazing color light output
Rich color and detail are critical for
presentations — that’s why it’s important to
understand that color light output is an es-
sential ingredient in achieving optimum
performance. The PowerLite 4200W delivers 4500 lumens of
color light output and 4500 lumens of white light output
bright, vibrant colorful images.
4500
4500
1
for
C2FineTM technology delivers a higher
contrast ratio
C2Fine offers smooth, uniform images with exceptional
contrast for better image quality. Based on this new
phase-compensation technology, light leakage is eliminated,
and when combined with auto iris, it allows for contrast ratios
of up to 1000:1.
With C2Fine
Without C2Fine
Image quality and detail
Resolution defines the level of detail and depth you’ll see in a
projected image. It’s measured as the number of pixels wide by
the number of pixels high. The more pixels, the better the
image quality. With WXGA (1280 x 800), the PowerLite 4200W
offers higher quality and is ideal for widescreen (16:10) displays.
For more information on Epson’s environmental
programs, go to eco.epson.com
TM
• Energy-efficient 3LCD light engine
• Designed to be recycled
Eco Features
3
SM
• Epson America, Inc. is a SmartWaySM
Transport Partner
4
Page 3
Easy and flexible installations
Centered lens design
The PowerLite 4200W makes installation easy to plan with
lens-to-screen alignment. Installers can position the ceiling
mount, screen and projector independently of one another,
knowing that the center of the screen will align with the lens at
the center of the projector.
Epson lens shift technology
In addition to added reliability and amazing color performance,
Epson’s industry-leading 3LCD technology enables this
projector to achieve a wide range of lens shift capabilities
allowing you to install around obstacles. This lens shift
technology enables an incredible range of ±60 percent on the
vertical axis and ±10 percent on the horizontal axis.
Off-axis, flexible installation
The PowerLite 4200W also features a ±30-degree tilt operation
for off-axis positioning flexibility. As a result, this projector can
be used for a wide range of applications, such as projecting on
angled surfaces. Epson technology keeps the projector running
without compromising performance or causing overheating.
Keystone correction
Adjusts up to ±40 degrees vertically and ±20 degrees
horizontally to easily achieve a perfect square image.
Quick Corner
This innovative feature allows you to move any of the four
corners of an image independently at setup, using the remote
control, for a perfectly rectangular picture.
Page 4
Convenient control, monitoring and communication
Monitor and control
• Easy Management® software included — remotely
access, monitor and control Epson projectors over the
network; includes e-mail notifications
• Network-ready for monitor and control — RJ-45 LAN
connection
• Direct power On/Off — power the projector on and off with
the flip of a switch
Low cost of ownership
Protect your investment — long-life
electrostatic air filter
This innovative filter was designed to protect the optical engine,
lamp and electronics from small dust particles that can enter
any projector. It has a recommended 3000-hour filter cleaning
6
schedule
due in part to its pleated,
expanded design.
With one air intake and
one exhaust path, the
PowerLite 4200W offers
efficient airflow systems
for optimum cooling of
key components and a
reduction in dust-related
problems.
and can capture particles as small as three microns,
Web-based remote control
This utility allows users to control one projector at a time
through the LAN network. Projector control is used in the
room in which the projector is located,
taking the place of the remote control
for some basic commands, including
power on and off, volume control,
source changes and more.
Long-life lamp that’s easy to replace
This high-efficiency lamp lasts up to 2000 hours in Normal
7
Mode and up to 3000 hours in ECO Mode.
quickly and easily,
without having
to uninstall the
projector from
the ceiling.
It can be replaced
PowerLite 4200W Product SpecificationPowerLite 4200W Product Specification
Page 5
Full-featured performance
DICOM simulation mode
DICOM (Digital Imaging and Communication in Medicine) is a
standard for handling, storing, printing and transmitting medical
imaging information. The projector’s DICOM Simulation
Mode enables users to reproduce images with an advanced
grayscale level that simulates DICOM Part 14. This mode is
ideal for viewing grayscale medical images, such as X-rays, for
training and educational purposes.
Normal Mode
5
DICOM Simulation Mode
Built-in closed captioning
• Accommodates those with hearing impairments
• Delivers important content when audio
broadcasting is not preferred
• Helps save money — no need to pay for an
additional decoder and its installation
• Effective and easy to use — easily enable or disable
through the projector remote or menu
>>> Phase one projected to be early.
Test patterns
The PowerLite 4200W also features four test patterns for
precise setup, including detecting distortion, checking linearity,
color reproduction and bleeding, and DICOM simulation mode.
Standard
Color Bars
Cross-Hatch
Grayscale
5.96"
12.26"
18.50"
PowerLite 4200W Product Specification
Page 6
®
PowerLite
4200W
Multimedia Projector
Product Name Product Code UPC
PowerLite 4200W V11H348020 0 10343 88097 9
Genuine Epson Lamp V13H010L63 0 10343 88123 5
Replacement Air Filter V13H134A17 0 10343 86897 7
Specifications
Projection System
High-aperture Epson 3LCD, 3-chip technology
Projection Method
Front/rear/ceiling mount
Driving Method
Epson Poly-silicon TFT Active Matrix
Pixel Number
1,024,000 pixel x 3 LCDs (1280 x 800)
Native Resolution
1280 x 800 (WXGA)
Aspect Ratio
Supports 4:3, 16:9, 16:10
Pixel Arrangement
Cross stripe
Color Light Output
4500 lumens
White Light Output
4500 lumens (ISO 21118 standard)
Contrast Ratio (High Brightness,
Dynamic Mode)
1000:1
Brightness Uniformity (typical)
89%
Color Reproduction
16.7 million colors
Size (projected distance)
30" – 300"
Lens Shift
Vertical: ±60 degrees
Horizontal: ±10 degrees
Keystone Correction
Vertical: ±40 degrees
Horizontal: ±20 degrees
Lamp Type
330 W UHE
Lamp Life
2000 hours (Normal Mode)
3000 hours (ECO Mode)
1
1
7
Effective Scanning
Frequency Range
Pixel Clock
13.5 MHz – 162 MHz (up to UXGA 60 Hz)
Horizontal
15 kHz – 92 kHz
Vertical
50 Hz – 85 Hz
Video I/O
Display Performance
NTSC: 560 line
PAL: 560 line (depends on observation of the
multi-burst pattern)
Input Signal
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/
PAL60/SECAM 480i/576i/480p/576p/720p/
1080i/1080p
Pixel works: video chip
3D Y/C separation, noise reduction
motion compensated
Interlace-Progressive conversion
(2 – 2, 3 – 2 film detection)
Interfaces
Computer: D-sub 15 pin x 1
Composite video: BNC x 1
Video: 5-BNC x 1
Network: RJ-45 x 1,100 Mbps
Serial: RS-232c
Projection Lens
Type
Manual focus/zoom
F-number
1.65 – 2.55
Focal Length
21.28 mm – 37.94 mm
Zoom Ratio
Optical zoom 1.0 – 1.8
Throw Ratio Range
1.29 – 2.34
Other Features
Operating Temperature
32 ˚ to 104 ˚F (0 ˚ to 40 ˚C)
Power Supply Voltage
100 – 240 V ±10%, 50/60 Hz AC
Power Consumption
464 W (Normal Mode)
383 W (ECO Mode)
11 W Standby (Communication on)
0.47 W Standby (Communication off)
Fan Noise
38 dB (Normal Mode)
32 dB (ECO Mode)
Security
Security cable hole, lens lock,
Kensington® lock provision
Dimensions (W x D x H)
Including Feet (with standard lens)
18.50" x 12.26" x 5.96"
Excluding Feet, Lens
18.5" x 12.26" x 5.31"
Weight 15 lb
Remote Control
Features
Power, source search selection, computer,
video, A/V mute, freeze, user ID, auto, aspect,
color mode, num, page up and down, E-zoom,
volume, help, menu, enter, esc and
pointer functions
Operating Angle
Right/left:
Front: ± 60 degrees
Rear: ± 30 degrees
Upper/lower:
Front: ± 20 degrees
Rear: +10 to +45 degrees
Operating Distance
49 ft
Support
The Epson Connection
Pre-sales support
U.S. and Canada 800-463-7766
Internet website www.epson.com
Service Programs
Two-year limited warranty, Epson Road
Service program, PrivateLine
dedicated toll-free support (U.S. and
Canada only) and 90-day limited
lamp warranty
What’s In The Box
PowerLite 4200W projector, power cable,
computer cable (VGA), projector remote control
with batteries, user manual CD, EasyMP®
software CD, Quick Setup Sheet, PrivateLine
support card, registration card, password
protection sticker and lens lock screw
SM
®
Accessory Part Numbers
Genuine Epson lamp V13H010L63
Replacement air filter V13H134A17
Replacement remote control 1485872
Advanced projector ceiling mount
with precision gear ELPMBPRG
Adjustable suspended
ceiling channel kit ELPMBP01
False ceiling plate kit ELPMBP02
Structural round ceiling plate ELPMBP03
Adjustable extension column
(pipe) 8" – 11" ELPMBC01
Kensington security lock ELPSL01
50-inch portable screen
(4:3 aspect ratio) ELPSC06
60-inch portable pop-up screen
(4:3 aspect ratio) ELPSC07
80-inch portable pop-up screen
(4:3 aspect ratio) ELPSC08
Duet™ portable projector screen
(4:3/16:9 combination) ELPSC80
Component to VGA video cable ELPKC19
S-video cable ELPSV01
Distribution amplifier ELPDA01
Remote control (ELPST16) V12H007T16
Image presentation
camera (ELPDC05) V12H162020
Packaging Specifications
PowerLite 4200W
Dimensions 21.9" x 18.4" x 11.1" (W x D x H)
Weight 21.3 lb
Genuine Epson Lamp
Dimensions 6.3" x 5.6" x 5.6" (W x D x H)
Weight 0.8 lb
Master Carton
Dimensions 28.4" x 13.1" x 6.8" (W x D x H)
Weight 9 lb
Units Per Master Carton 10
Replacement Air Filter
Dimensions 11.3" x 3.7" x 1.9" (W x D x H)
Weight 0.21 lb
Master Carton
Dimensions 19.2" x 11.8" x 4.8" (W x D x H)
Weight 3.09 lb
Units Per Master Carton 10
1 White and color light output will vary depending on mode selected. White light output measured using ISO 21118 standard.
2 Data source: ProjectorCentral.com Jan 2010. Average of 910 shipping models for which the manufacturers provided lumens and total power data, all resolutions
and brightness levels.
3 See our website for convenient and reasonable recycling options at www.epson.com/recycle
4 SmartWay is an innovative partnership of the U.S. Environmental Protection Agency that reduces greenhouse gases and other air pollutants and improves fuel efficiency.
5 This projector does not meet the DICOM standard Part 14 and should not be used as a medical diagnostic device.
6 Recommended based on normal room conditions. Cleaning requirements may vary depending on use, environment and other conditions.
Cleaning intervals may be adjusted to accommodate the environment in which the projector is used.
7 Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Specifications subject to change. Epson, Easy Management, EasyMP and Quick Corner are registered trademarks, Epson Exceed Your Vision is a registered logomark and Better Products for a Better
Future and C
SmartWay is a service mark of the U.S. Environmental Protection Agency. All other product and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims
any and all rights in these marks. Copyright 2010 Epson America, Inc. CPD-33436 12/10
2
Fine are trademarks of Seiko Epson Corporation. PowerLite and PrivateLine are registered trademarks, Duet is a trademark and Epson Connection is a service mark of Epson America, Inc.
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
www.epson.com
www.epson.ca
Loading...
