Emerson 5081-P-FF, 5081-P-FI User Manual

Model 5081-P-FF/FI

F

OUNDATION

®

Fieldbus Two-Wire pH/ORP

Transmitter

Instruction Sheet

PN 51A-5081P-FF-FI/rev.B
October 2007

ESSENTIAL INSTRUCTIONS

READ THIS PAGE BEFORE PROCEEDING!

Your purchase from Rosemount Analytical, Inc. has resulted in one of the finest instruments available for your
particular application. These instruments have been designed, and tested to meet many national and interna­tional standards. Experience indicates that its performance is directly related to the quality of the installation
and knowledge of the user in operating and maintaining the instrument. To ensure their continued operation to
the design specifications, personnel should read this manual thoroughly before proceeding with installation,
commissioning, operation, and maintenance of this instrument. If this equipment is used in a manner not speci­fied by the manufacturer, the protection provided by it against hazards may be impaired.

• Failure to follow the proper instructions may cause any one of the following situations to occur: Loss of life;
personal injury; property damage; damage to this instrument; and warranty invalidation.

• Ensure that you have received the correct model and options from your purchase order. Verify that this man­ual covers your model and options. If not, call 1-800-854-8257 or 949-757-8500 to request correct manual.

• For clarification of instructions, contact your Rosemount representative.

• Follow all warnings, cautions, and instructions marked on and supplied with the product.

• Use only qualified personnel to install, operate, update, program and maintain the product.

• Educate your personnel in the proper installation, operation, and maintenance of the product.

• Install equipment as specified in the Installation section of this manual. Follow appropriate local and national
codes. Only connect the product to electrical and pressure sources specified in this manual.

• Use only factory documented components for repair. Tampering or unauthorized substitution of parts and
procedures can affect the performance and cause unsafe operation of your process.

• All equipment doors must be closed and protective covers must be in place unless qualified personnel are
performing maintenance.

• If this equipment is used in a manner not specified by the manufacturer, the protection provided by it against
hazards may be impaired.

For additional information, please refer to the Instruction Manuals CD shipped with this
product, or visit our website at www.emersonprocess.com/raihome/liquid/.

MODEL 5081-P-FF/FI SPECIFICATIONS

SPECIFICATIONS - GENERAL

Case: Cast aluminum containing less than 6% magnesium.

NEMA 4X (IP65), NEMA 7 (explosion-proof)

Epoxy-polyester paint, Neoprene O-ring seals

Dimensions: 6.3 in. x 6.9 in. x 6.4 in. (160 mm x 175 mm x 161

mm); diameter 6.1 in (155 mm)

Conduit Openings: 3/4 in. FNPT

Reference Impedance: Transmitter accepts high impedance

(i.e. glass) reference electrodes as well as low impedance
(i.e. silver-silver chloride) reference electrodes.

Response Time: Display reaches 95% of final reading within 10

seconds.

Temperature Sensors: The following RTDs can be used with

the Model 5081-P pH/ORP transmitter:

3 and 4 wire Pt 100 RTDs

3 and 4 wire Pt 1000 RTDs

Transmitter can also be used with two-wire RTDs.

Temperature Range: 5°F to 248°F (-15°C to 130°C)

Local Display: Two line LCD; first line shows process variable

(pH or ORP), second line shows temperature and output sig­nal. When triggered, fault and warning messages alternate
with temperature and output readings.

Process variable: 7 segment LCD, 0.8 in. (20 mm) high

Temperature/output: 7 segment LCD, 0.3 in. (7 mm) high

Display board can be rotated 90 degrees clockwise or coun­terclockwise.

During calibration and programming, messages and prompts
appear in the temperature/output area.

Power Supply and Load Requirements:

A power supply volt-

age of 9-32 Vdc at 22 mA is required.

Security: User selected security code prevents accidental

changes to program settings.

Ambient Temperature: -4 to 149°F (-20 to 65°C)

Relative Humidity: 0 to 95% (with covers sealed)

Storage Temperature: -22 to 176°F (-30 to 80°C)

EMI/RFI: Meets the requirements of

EN-61326

Hazardous Area Classification:

Intrinsic Safety:

Class I, II, III, Div. 1
Groups A-G
T4 Tamb = 70°C

Exia Entity
Class I, Groups A-D
Class II, Groups E-G
Class III
T4 Tamb = 70°C

ATEX 0600 II 1 G

Baseefa02ATEX1284
EEx ia IIC T4
Tamb = -20°C to +65°C

Non-Incendive:

Class I, Div. 2, Groups A-D
Dust Ignition Proof
Class II & III, Div. 1, Groups E-G
NEMA 4X Enclosure

Class I, Div. 2, Groups A-D
Suitable for Class II, Div. 2, Groups E-G
T4 Tamb = 70°C

Explosion-Proof:

Class I, Div. 1, Groups B-D
Class II, Div. 1, Groups E-G
Class III, Div. 1

Class I, Groups B-D
Class II, Groups E-G
Class III
Tamb = 65°C max

SPECIFICATIONS - pH

pH Input Range: 0 to 14 pH

Temperature Input Range: 5°F to 248°F (-15°C to 130°C)

Accuracy at 25°C: ±0.01 pH

Repeatability at 25°C: ±0.01 pH

Resolution: 0.01 pH and 0.1°C or °F

Stability at 25°C: 0.25% per year
Diagnostics: The internal diagnostics can detect:

Calibration Error Low Temperature Error
High Temperature Error Sensor Failure
Line Failure CPU Failure
ROM Failure Input Warning
Glass Failure Glass Warning
Reference Failure Reference Warning

Once one of the above is diagnosed, the LCD will display a
message describing the failure/default detected.

Temperature Compensation: Automatic or manual between 5°F

to 248°F (-15°C to 130°C)

Solution Temperature Compensation: Transmitter will convert

pH measured at any temperature to the pH at 25°C.
Temperature coefficient is programmable between -0.044
pH/°C and 0.028 pH/°C

Calibration: Automatic two-point and manual two-point buffer

calibration. For automatic calibration, the transmitter recog­nizes NIST, DIN 19266 and 19267, JIS 8802, BSM, Merck,
and Ingold buffers.

SPECIFICATIONS - ORP

ORP Input Range: -1400 to 1400 mV

Temperature Input Range: 5°F to 248°F (-15°C to 130°C)

Output Scale Expansion: Continuously expandable between -

1400 and 1400 mV

Accuracy at 25°C: ±1 mV

Repeatability at 25°C: ±1 mV

Resolution: 1 mV and 0.1°C or °F

Stability at 25°C: 0.25% per year

2

Sira MC070112/00

3

MODEL 5081-P-FF/FI WIRING

SENSOR WIRING AND SET-UP

Wire sensor per Figure 1. Refer to the sensor instruction
manual for more details.

If your sensor has an integral preamplifier or you are using
a remote preamplifier, you will need to change the pream­plifier location in the program menu. Please see Figure 14.
Select “trAnS” for integral preamplifier or “SnSr” for J-box
or sensor preamplifier.

WIRING THROUGH A JUNCTION BOX WITH
REMOTE PREAMPLIFIER

Wire sensor as shown in Figure 5. Refer to the sensor
instruction manual for more details.

WIRING THROUGH A JUNCTION BOX

Sensors with integral preamplifiers can be wired to the ana­lyzer through a remote junction box (PN 23550-00). Wire
the extension cable and sensor cable point-to-point. Refer
to the sensor instruction manual for more details.

POWER WIRING

For general purpose areas, wire power as shown in
Figure 1. For hazardous areas, please see hazardous
area installation drawings.

FIGURE 1. Model 5081-P-FF/FI Wiring Details

(9 - 32 VDC)

NOTE: REF wire covered with

sleeving. To prevent
depletion of KCL if
other wires touched,
remove sleeving
before wiring to TB-7.

4

MODEL 5081-P-FF/FI WIRING

FIGURE 2. Exploded View of Model 5081-P-FF/FI

FIGURE 3. Wiring Diagram — Sensor with Preamplifier

DWG. NO. REV.

45081P30 A

5

WIRING THROUGH A JUNCTION BOX WITH REMOTE PREAMPLIFIER

MODEL 5081-P-FF/FI WIRING

FIGURE 4. Wiring diagram — sensor Model 381+ with preamplifier

Wire sensor as shown in Figure 5. Refer to the sensor instruction manual for more details.

FIGURE 5. Wiring Through a Junction Box with Remote Preamplifier

DWG. NO. REV.

45081P28 A

DWG. NO. REV.

45081P29 A

MODEL 5081-P-FF/FI INSTALLATION

6

INSTALLATION

UNPACKING AND INSPECTION

Inspect the shipping container. If it is damaged, contact the
shipper immediately for instructions. Save the box. If there
is no apparent damage, unpack the container. Be sure all
items shown on the packing list are present. If items are
missing, notify Rosemount Analytical immediately.

ROTATING THE DISPLAY

The 5081-P-FF/FI display can be rotated 90° left or right.
Disengage the cover lock and remove the front cover.
Remove the three screws holding the PCB stack and gen­tly lift the display board. Do not disengage the ribbon cable
between the display board and the CPU board. Rotate the
display. The black infrared sensor will be at the top of the
display.

INSTALLATION

See Figure 6.

1. Although the analyzer is suitable for outdoor use, do not
install it in direct sunlight or in areas of extreme temper­atures.

2. Install the analyzer in an area where vibrations and elec­tromagnetic and radio frequency interference are mini­mized or absent.

3. Keep the analyzer and sensor wiring at least one foot
from high voltage conductors. Be sure there is easy
access to the analyzer.

4. The conduit connections on the sides of the 5081-P
housing should be sealed to prevent moisture from
entering the enclosure.

5. The transmitter must not be mounted with both conduit
openings at the top.

MILLIMETER

INCH

FIGURE 6. Mounting Model 5081-P-FF/FI

7

FIGURE 8. FM Intrinsically Safe Installation Label

8

FIGURE 7. FMRC Explosion-Proof Installation

MODEL 5081-P-FF/FI HAZARDOUS AREA INSTALLATION

HAZARDOUS AREA INSTALLATION

9

FIGURE 9. FM Intrinsically Safe Installation (1 of 2)

10

FIGURE 9. FM Intrinsically Safe Installation (2 of 2)

11

FIGURE 10. CSA Intrinsically Safe Installation Label

12

FIGURE 11. CSA Intrinsically Safe Installation (1 of 2)

FIGURE 11. CSA Intrinsically Safe Installation (2 of 2)

13

FIGURE 12. ATEX Intrinsically Safe Installation Label

14

FIGURE 13. ATEX Intrinsically Safe Installation (1 of 2)

15

FIGURE 14. ATEX Intrinsically Safe Installation (2 of 2)

16

17

9241503-01

B

CHK

DATE

BY

REVISIONS

DESCRIPTION

A

QTY

2400 Barranca Pkwy

Uniloc Division

Irvine, CA 92606

Rosemount Analytica l,

REV

REV

REV

FM A

CERTIFIED BY

THIS DOCUMENT IS

REV

REV

REV

W/O AGENCY APPROVAL

REVISIONS NOT PERMITTED

DESCRIPTION

REV

5081-P-FI

LABEL, I.S. FM

DWG NO

12

SHEET OF

9241503-01

2:1

ECO

LTR

A

REV

5-6-04 8933

RELEASE DATE ECO NO

Uniloc

TITLE

BILL OF MATERIAL

DATE

5/3/04

PART NO

±.02

ITEM

B. JOHNSON

APPROVALS

DRAWN

B

SIZE

SCALE

5/6/04J. FLOCK

5/6/04

J. FLOCK

SOLID EDGE

THIS DWG CREATED IN

PROJECT

ENGR APVD

CHECKED

2.56

1/2

-

+

2.180

±.015

.120

Ø .125

FM

APPROVED

R

°C

±.01 5

2X.650

±.02

ANGLES

TOLERANCES

DIMENSIONS ARE IN INCHES

.030

.010

REMOVE BURRS & SHARP EDGES .020 MAX

-

+

-

+

UNLESS OTHERWISE SPECIFIED

.XX

.XXX

1

4

NOMINAL SURFACE FINISH 125

MACHINED FILLET RADII .020 MAX

MATERIAL

FINISH

1.30

Tamb= 70

.125

EXPLOSION PROOF

PER DWG. 1400296

CLASS II, DIV. 1, GRPS. E,F & G

CLASS I, DIV.1, GRPS. B,C & D

ROSEMOUNT ANALYTICAL

GRPS. A,B,C,D,E,F & G

CLASS I, II & III, DIV. 1,

HAZARDOUS AREA WHEN

INTRINSICALLY SAFE FOR

5081-P-FI-67

MODEL

DUST IGNITION PROOF

NON-INCENDIVE

CONNECTED PER DWG. 14002 87

OR SUITABILITY FOR DIV. 2.

MAY IMPAIR INTRINSIC SAFETY

GRPS. E, F & G

CLASS II AND III, DI V. 1,

WARNING: COMPONENT SUBSTITUTION

CLASS I, DIV. 2, GRPS. A,B,C & D

T4

NEMA 4X ENCLOSURE.

CLASS III, DIV. 1

9241503-01/A

R .25

4X

2X FULL R

This document contains information proprietary to

to those who may compete with Rosemount Analytical.

Rosemount Analytical, and is not to be made available

.140

STEEL .015+/-.005 THICK. MATERIAL TO

BE ANNEALED & PASSIVATED. MAXIMUM

HARDNESS BRINELL 190.

3. ARTWORK IS SHEET 2 OF 2.

4 FINISH:SILKSCREEN BLACK EPOXY PAINT (BAKED).

2. NO CHANGE WITHOUT FM APPROVAL.

1 MATERIAL: AISI 300 SERIES STAINLESS

NOTES: UNLESS OTHERWISE SPECIFIED

18

D

1

1400296

CHK

DATE

C

B

REV

REV

REV

REV

REV

REV

FM A

CERTIFIED BY

THIS DOCUMENT IS

W/O AGENCY APPROVA L

REVISIONS NOT PERMITTED

A

06-01

REV

QTY

Rosemount Analytical Division

2400 Barranca Pkwy

Emerson Process Management,

Irvine, CA 92606

A

1

1

SHEET OF

1

DESCRIPTION

BILL OF MATERIAL

REVISION

DESCRIPTION BY

2

ECO

LTR

SAFE AREASAFE AREA

POWER SUPPLY

17.5 VDC MAX

3

Emerson

TITLE

DATE

5/3/04

PART NO.

B. JOHNSON

APPROVALS

ITEM

DRAWN

-

+

ANGLES

TOLERANCES

DIMENSIONS ARE IN INCHES

NOMINAL SURFACE FINISH 125

MACHINED FILLET RADII .020 MAX

.030

.010

+

-

+

­REMOVE BURRS & SHARP EDGES .020 MAX

UNLESS OTHERWISE SPECIFIED

.XX

.XXX

1400296

NONE

DWG NO.

D

EXP PROOF 5081-P-FI

SIZE

SCHEM, SYSTEM FMRC

5/6/04

J. FLOCK

CHECKED

MATERIAL

SCALE TYPE

5/6/04

J. FLOCK

PROJECT

ENGR APVD

2

SOLID EDGE

THIS DWG CREATED IN

3

FINISH

A

ECO NO. REV

4

3

1

/

E

D

O

N

D

A

E

V

R

E

S

E

R

2

1

V

5

+

1

1

V

5

-

C

P

^

R

0

1

0

O
/

N

7

I

H

p

R

O

F

P

D

D

R

R

9

O

E

A

/

U

T

H

G

p

A
R

E
B

5

D

L

N

8

T

O

G

S

S
U

M

G

N

I

N

I

R

-

7

F

I

E
R

W

D

R

A

-

U

F

G

E

6

R

N

I
D

T

R

5

E

S

N

E

D

T

R

4

1

5

4

1

H

/

E

T

/

D

F

F

O

H

T

A

C

D

E

V

R

E

S

E

R

1

6

(

-

H

)

T

/

F

F

(

+

)

12

11

10

15

16

14

13

RIGID METAL CONDUIT

AND AP PROVED SEALS

3

9

8

7

WIRING LABEL

P

N

9

2

4

1

5

1

8

-

0

0

/

S

B

E

R

V

N

T

R

D

T

R

3

E

D

1

R

E

S

E

R

V

E

D

2

6

5

4

3

R

E

S

12

5081-P-FI-67

v

CLASS I, DIV 1, GPS B-D

CLASS III, DIV 1

CLASS II, DIV 1, GPS E-G

HAZARDOUS AREA

70 C MAX

4

RELEASE DATE

5-6-04 8933

5

6

7

RIGID METAL CONDUIT

AND AP PROVED SEALS

3

pH SENSOR

OPTIONAL PREAMP/J-BOX

8

2. SEAL REQUIRED AT EACH CONDUIT ENTRANCE.

RECOMMENDED SENSORS:

320B

320HP

328A

330B

370

371

381+

385+

389

396

396P

396R

396PVP

396RVP

396VP

397

398

398R

398RVP

398VP

399

Rosemount Analytical, and is not to be made available

This document contains information proprietary to

to those who may compete with Rosemount Analytical.

D

399VP

C

B

3 USE ONLY APPROVED CONDUIT SEALS AND FITTINGS.

A

6

7

8

1. INSTALLATION MUST CONFORM TO THE NEC.

NOTES: UNLESS OTHERWISE SPECIFIED

D

19

1

1400287

CHK

DATE

BYDESCRIPTION

C

APPARATUS

ASSOCIATED

ANY FM APPROVED

ANY FM APPROVED

APPARATUS

ASSOCIATED

APPARATUS

ASSOCIATED

ANY FM APPROVED

B

APPARATUS

ASSOCIATED

ANY FM APPROVED

A

10-96

B

QTY

Rosemount Analytical,

Uniloc Division

2400 Barranca Pkwy

Irvine, CA 92606

REV

2

1

SHEET OF

1

DESCRIPTION

BILL OF MATERIAL

REVISION

2

ECO

LTR

TERMINATOR

NON-HAZARDOUS LOCATIONS

ANY FM APPROVED

TERMINATOR

ANY FM APPROVED

ANY FM APPROVED

TERMINATOR

TERMINATOR

ANY FM APPROVED

3

ANY FM APPROVED

INTRINSICALLY SAFE

APPARATUS

TERMINATOR

ANY FM APPROVED

ANY FM APPROVED

INTRINSICALLY SAFE

APPARATUS

ANY FM APPROVED

TERMINATOR

APPARATUS

ANY FM APPROVED

TERMINATOR

ANY FM APPROVED

INTRINSICALLY SAFE

ANY FM APPROVED

INTRINSICALLY SAFE

APPARATUS

ANY FM APPROVED

Uniloc

SCHEMATIC, INSTALLATION

TITLE

DATE

5/3/04

5/6/04

PART NO.

B. JOHNSON

J. FLOCK

APPROVALS

ITEM

DRAWN

CHECKED

1/2

-

+

ANGLES

TOLERANCES

DIMENSIONS ARE IN INCHES

NOMINAL SURFACE FINISH 125

MACHINED FILLET RA DII .020 MAX

.030

.010

REMOVE BURRS & SHARP EDGES .020 MAX

+

-

-

+

UNLESS OTHERWISE SPECIFIED

TERMINATOR

.XX

.XXX

MATERIAL

TYPE

1400287

FM APPROVALS

5081-P-FI XMTR

NONE

D

SIZE

SCALE

5/6/04

2

J. FLOCK

SOLID EDGE

THIS DWG CREATED IN

ENGR APVD

PROJECT

3

FINISH

B

REVECO NO.

8933

4

GROUPS A, B, C, D, E, F, G;

DIVISION 1,

NI CLASS I,

IS CLASS I, II, III,

HAZARDOUS (CLASSIFIED)LOCATIONS

SUITABLE CLASS III,

DIVISION 2

DIVISION 2,

SUITABLE CLASS II,

GROUPS A,B,C,D;

GROUPS F & G;

DIVISION 2,

4

RELEASE DATE

5-6-04

15

16

14

5

MODEL

5081-P-FI

FISCO

13

12

11

10

9

8

XMTR

7

6

5

4

3

21

XMTR

MODEL

5081-P-FI

15

16

14

13

12

11

10

9

8

7

6

5

4

3

21

MODEL

5081-P-FI

XMTR

15

16

14

13

12

11

10

9

8

7

6

5

4

3

21

MODEL

5081-P-FI

XMTR

6

15

16

14

13

12

11

10

9

8

7

6

5

4

3

21

5

6

10 7 5 4TB1-

FM INTRINSIC SAFETY INSTALLATION

PREAMP

(NOTE 2)

PREAMP

(NOTE 2)

OF NOTE 1

THAT MEETS REQUIREMENTS

FM APPROVED PREAMP

OF NOTE 1

THAT MEETS REQUIREMENTS

7

+PH

SENSOR

FOR USE IN

INFRARED RED

(RMT PN 23572-00)

CLASS I AREA ONLY

REMOTE CONTROL UNIT

+PH

FM APPROVED PREAMP

TC

SENSOR

SEE NOTE 1

10 COND, 2 SHIELDS 24 A WG

PN 23646-01 PREPPED

PN 9200273 (UNPREPPED)

RECOMMENDED CABLE

+PH

SENSOR

PH

WITH

SENSOR

SUITABILITY FOR DIVISION 2.

SUBSTITUTION OF COMPONENTS MAY IMPAIR INTRINSIC SAFETY OR

DISCONNECT POWER BEFORE SERVICING.

TO PREVENT IGNITION OF FLAMMABLE OR COMBUSTIBLE ATMOSPHERES,

WARNING-

WARNING-

4 WIRES SHIELDED

22 AWG. SEE NOTE 1

RECOMMENDED CABLE

7

BFM

8

Rosemount Analytical, and is not to be made available

This document contains information proprietary to

REV

REV

REV

REV

REV

REV

to those who may compete with Rosemount Analytical.

CERTIFIED BY

THIS DOCUMENT IS

W/O AGENCY APPROVAL

REVISIONS NOT PERMITTED

D

C

B

A

8

NOTES ON SHEET 2 OF 2

NOTES: UNLESS OTHERWISE SPECIFIED

20

1400287

D

C

B

A

B

08-94

REV

1

2

13.02 Vdc

TB1-1 THRU 12

MODEL 5081- P-FI

TABLE II

Vt

OUTPUT

PARAMETERS

La

3.1

(mH)

43

Ca

(uF)

TABLE I

0.96

OUTPUT PARAMETERS

SHEET 2 OF 2

1

TYPE

1400287

DWG NO.

D

SCALE: NONE

SIZE

2

10

10

Li (uH)

147 mW

105.64 mA

Pt

It

5

5

Ci (nF)

2.52

5.32

Pmax (W)

3

380

360

Imax (mA)

12.3

5.99

25

21.69

TABLE III

17.5

17.5

Vmax (Vdc)

5081-P-FI FISCO PARAMETERS

SUPPLY / SIGNAL TERMINALS TB 1-15, 16

IIB/

IIC/

C,D,E,F,G

GROUPS

A,B,C,D,E,F,G

4

C

D

A, B

GROUPS

GAS

5

6

7

TUS MUST BE FACTORY MUTUAL RESEARCH APPROVED

Ca, Ct OR Co

La, Lt OR Lo; OR Lc/Rc (La/Ra OR Lo/Ro) AND Li/Ri (La/Ra OR Lo/Ro)

5081-P-FI

5081-P-FI

MODEL NO.

5

6

7

8

Rosemount Analytical, and is not to be made available

This document contains information proprietary to

to those who may compete with Rosemount Analytical.

D

10. THE CONFIGURATION OF ASSOCIATED APPARA

11. NO REVISION TO DRAWING WITHOUT PRIOR FACTORY MUTUAL RESEARCH APPROVAL.

C

WHEN INSTALLING THIS EQUIPMENT.

MORE THAN 250 Vrms OR Vdc.

9. CONTROL EQUIPMENT CONNECTED TO ASSOCIATED APPARATUS MUST NOT USE OR GENERATE

UNDER THE ASSOCIATED CONCEPT.

8. ASSOCIATED APPARATUS MANUFACTURER'S INSTALLATION DRAWING MUST BE FOL LOWED

WITH ASSOCIATED APPARATUS WHEN THE FOLLOWING IS TRUE:

7. THE ENTITY CONCEPT ALLOWS INTERCONNECTION OF INTRINSICALLY SAFE APPARATUS

Imax OR Ii Isc, It OR Io;

Vmax OR Ui Voc, Vt OR Uo;

FIELD DEVICE INPUT ASSOCIATED APPARATUS OUTPUT

3Li+ 3Lcable.

Pmax OR Pi Po;

3Ci+ 3Ccable;

CLASS III ENVIRONMENTS.

LESS THAN 1.0 Ohm.

5. DUST-TIGHT CONDUIT SEAL MUST BE USED WHEN INSTALLED IN CLASS II AND

6. RESISTANCE BETWEEN INTRINSICALLY SAFE GROUND AND EARTH GROUND MUST BE

4. SENSORS WITHOUT PREAMPS SHALL MEET THE REQUIREMENTS OF SIMPLE APPARATUS AS

B

"INSTALLATION OF INTRINSICALLY SAFE SYSTEMS FOR HAZARDOUS

THAT DOES NOT DISSIPATE MORE THAN 1.3W. SEE TABLES I AND II.

THEY CAN NOT GENERATE NO R STORE MORE THAN 1.5V, 0.1A OR A PASSIVE COMPONENT

(CLASSIFIED) LOCATIONS" (EXCEPT CHAPTER 5 FOR FISCO INSTA LLATIONS) AND

THE NATIONAL ELECTRICAL CODE (ANSI/NFPA 70) SECTIONS 504 AND 505.

23546-00 REMOTE PREAMPLIFIER.

CIRCUIRTY. A WEATHER RESISTANT ENCLOSURE MUST HOUSE THE TYPE

DEFINED IN ANSI/ISA RP12.6 AND THE NEC, ANSI/NFPA 70.

3. INSTALLATION SHOULD BE IN ACCORDANCE WITH ANSI/ISA RP12.06

2. PREAMPLIFIER TYPE 23546-00, 23538-00 OR 23561-00 MAY BE UTILIZED INSTEAD

OF THE MODEL 5081-P-FI TRANSMITTER INTEGRAL PREAMPLIFIER

1. THE MODEL 5081-P-FI TRANSMITTER INCLUDES INTEGRAL PREAMPLIFIER

WHERE Ca Ci (SENSOR) + Ccable;

THE CAPACITANCE AND INDUCTANCE OF THE LOAD CONNECTED TO THE

THE OUTPUT PARAMETERS SPECIFIED IN TABLE II ARE VALID FOR EITHER

PREAMPLIFIER.

CIRCUITRY. AN EXTERNAL PREAMPLIFIER MAY BE ALSO USED.

SENSOR TERMINALS MUST NOT EXCEED THE VALUES SPECIFIED IN TABLE I

A

8

La Li (SENSOR) + Lcable.

NOTES: UNLESS OTHERWISE SPECIFIED

21

9241504-01

B

CHK

DATE

BY

10-96

21

A

A

REV

REV

REV

REV

REV

REV

QTY

Uniloc Division

2400 Barranca Pkw y

Rosemount Analytical,

Irvine, CA 92606

REV

SHEET OF

CERTIFIED BY

CSA

THIS DOCUMENT IS

W/O AGENCY APPROVAL

REVISIONS NOT PERMITTED

REVISIONS

REV

ECO NORELEASE DATE

DESCRIPTION

ECO

LTR

A

8925

5-6-04

DESCRIPTION

LABEL, I.S. CSA

Uniloc

TITLE

9241504-01

2:1

DWG NO

5081-P-FI

B

SIZE

SCALE

BILL OF MATERIAL

DATE

5/3/04

5/6/04

5/6/04

PART NO

B. JOHNSON

J. FLOCK

J. FLOCK

APPROVALS

SOLID EDGE

±.02

ITEM

DRAWN

THIS DWG CREATED IN

PROJECT

CHECKED

ENGR APVD

2.56

1/2

-

4 FINISH:SILKSCREEN BLACK EPOXY PAINT (BAKED).

±.00 5

±.01 5

2.180

.120

+

ANGLES

TOLERANCES

DIMENSIONS ARE IN INCHES

.030

.010

REMOVE BURRS & SHARP EDGES .020 MAX

-

+

-

+

UNLESS OTHERWISE SP ECIFIED

.XX

.XXX

1

4

NOMINAL SURFACE FINISH 125

MACHINED FILLET RADII .020 MAX

MATERIAL

FINISH

This document contains information proprietary to

Rosemount Analytical, and is not to be made available

Ø .125

LR34186

ENCLOSURE 4

R

SA

R

±.015

.650

±.02

1.30

Tamb= 70°C

ROSEMOUNT ANALYTICAL

Exia ENTITY

INTRINSICALLY SAFE FOR

5081-P-FI-69

MODEL

CLASS I, GRPS A, B, C & D

CLASS II, GRPS E, F & G

T4 Tamb = 70°C

CLASS III

WARNING: COMPONENT SUBSTITUTION

PER DWG. 1400288

MAY IMPAIR INTRINSIC SAFETY.

HAZARDOUS AREA WHEN CONNECTED

CLASS II, DIV. 2, GRPS E, F & G

SUITABLE FOR

CLASS I, DIV. 2, GRPS A,B,C & D

UNLESS AREA IS KNOWN TO BE NON-

HAZARDOUS.

TION OF COMPONENTS MAY IMPAIR

DISCONNECT WHILE CIRCUIT IS LIVE

WARNING-EXPLOSION HAZARD-SUBSTITU-

WARNING-EXPLOSION HAZARD-DO NOT

T4

SUITABILITY FOR CLASS I, DIV 2.

CLASS I, GRPS B,C & D

CLASS II, GRPS E, F & G

CLASS III

SEAL REQUIRED TO BE INSTALLED

WITHIN 50 mm OF THE ENCLOSURE.

ARE LIVE.

KEEP COVER TIGHT WHILE CIRCUITS

Tamb ABOVE 60°C USE 75°C MINIMUM

RATED WIRING

Tamb = 65°C MAX

9241504-01/A

.125

R .25

4X

±.005

.140

2X FULL R

3. ARTWORK IS SHEET 2 OF 2.

2. NO CHANGE WITHOUT CSA APPROVAL.

1 MATERIAL: AISI 300 SERIES STAINLESS

to those who may compete with Rosemount Analytical.

STEEL .015+/-.005 THICK. MATERIAL TO

HARDNESS BRINELL 190.

BE ANNEALED & PASSIVATED. MAXIMUM

NOTES: UNLESS OTHERWISE SPECIFIED

22

D

1

1400288

CHK

DATE

YB

C

B

A

REV

QTY

2400 Barranca Pk wy

Rosemount Analytical,

Uniloc Division

Irvine, CA 92606

A

2

1

SHEET OF

1

UNSPECIF IED

17.5 VDC MAX

POWER SUPPLY

N
O

I

T
PIR

REVISION

C
S
E
D

2

ECO

LTR

UNC LAS SI F IED ARE A

CSA APPROVED

SUITABLE FOR FISCO

SEE NOTE 8 AND TABLE III

ASSOC IATED APP ARATUS

UNSPECIF IED

17.5 VDC MAX

POWER SUPPLY

CSA APPROVED

SUITABLE FOR FISCO

SEE NOTE 8 AND TABLE III

ASSOC IATED APP ARATUS

UNSPECIF IED

17.5 VDC MAX

POWER SUPPLY

CSA APPROVED

SUITABLE FOR FISCO

SEE NOTE 8 AND TABLE III

ASSOC IATED APP ARATUS

3

UNSPECIF IED

17.5 VDC MAX

POWER SUPPLY

CSA APPROVED

SUITABLE FOR FISCO

SEE NOTE 8 AND TABLE III

ASSOC IATED APP ARATUS

DESCRIPTION

BILL OF MATERIAL

Uniloc

SCHEMATIC, INSTALLATION

TITLE

DATE

5-3-04

5/6/04

PART NO.

B. JOHNSON

J. FLOCK

APPROVALS

ITEM

DRAWN

CHECKED

-

+

ANGLES

TOLERANCES

DIMENSION S ARE IN INC HES

NOMINAL SURFACE FIN ISH 125

MACHINED FILLET RADII .020 MAX

.030

.010

+

-

+

­REMOVE BURRS & SHARP EDGES .020 MAX

UNLESS OTHERWISE SPECIFIED

.XX

.XXX

MATERIAL

E
P
Y
T

1400288

5081-P-FI XMTR CSA

NONE

DWG NO.

EL
A

D

CS

SIZE

5/6/04

2

J. FLOCK

SOLID EDGE

THIS DWG CREATED IN

PROJECT

ENGR APVD

3

FINISH

A

ECO NO. REV

8925

4

HAZARDOUS AREA

NI CLASS I, DIV 2

IS CLASS I, GRPS A-D

CLASS III

CLASS II, DIV 2

CLASS II, GRPS E-G

GRPS A-D

GRPS E-G

4

5-6-04

RELEASE DATE

15

16

14

13

12

5

MODEL

11

10

9

8

XMTR

7

5081-P-FI

6

5

4

3

12

XMTR

MODEL

5081-P-FI

15

16

14

13

12

11

10

9

8

7

6

5

4

3

12

XMTR

MODEL

5081-P-FI

15

16

14

13

12

11

10

9

8

7

6

5

4

3

12

XMTR

MODEL

5081-P-FI

6

PREAMP

(NOTE 3)

PREAMP

THAT MEETS REQUIRE MENTS

CSA APPROVED PREAMP

OF NOTE 2

(NOTE 3)

THAT MEETS REQUIREMENTS

OF NOTE 2

CSA APPROVED PREAMP

+PH

7

FISCO

8

Rosemount Analytical, and is not to be made available

This document contains information proprietary to

to those who may compete with Rosemount Analytical.

SENSOR

FOR USE IN

INFRARED RED

(RMT PN 235 72-00)

CLASS I AREA ONLY

REMOTE CONTROL UNIT

A

REV

REV

CSA INTRINSIC SAFETY INSTALLATION

REV

CSA

CERTIFIED BY

THIS DOCUMENT IS

D

REV

REV

REV

W/O AGENCY APPROVAL

REVISIONS NOT PERMITTED

C

+PH

SENSOR

10 COND, 2 SHIELDS 24 AWG

RECOMMENDED CABLE

PN 23646-01 PREPPED

SEE NOTE 1

PN 9200273 (UNPREPPED)

+PH

SENSOR

B

15

16

14

13

12

11

10

9

8

7

6

5

4

3

12

5

6

TB1-

4

5 710

TO PREVENT IGN ITION OF FLAMMABLE OR COMBUSTIBLE ATMOSPHE RES,

DISCONNECT POWER BEFORE SERVI CING.

SUBSTITUTION OF COMPONENTS MAY IM PAIR INTRI NSIC SAFETY OR

SUITABILITY FOR DIVISION 2.

WARNING-

WARNING-

PH

TC

WITH

SENSOR

4 WIRES SHIE LDED

RECOMMENDED CABLE

22 AWG. SEE NOTE 1

7

8

NOTES ON SHEE T 2 OF 2

NOTES: UNLESS OTHERWISE SPECIFICED

A

23

9241502-01

B

CHK

DATE

BY

THIS DOCUMENT IS

CERTIFIED BY

A

REV

REV

Baseefa

REV

REV

REV

REV

21

A

QTY

Uniloc Division

2400 Barranca Pkw y

Rosemount Analytical,

Irvine, CA 92606

W/O AGENCY APPROVAL

REVISIONS NOT PERMITTED

Related Drawi ng

the Authorized Person

without the approval of

Baseefa Certified Product

No modifications permitted

REV

SHEET OF

REVISIONS

REV

ECO NORELEASE DATE

DESCRIPTION

ECO

LTR

A

8925

5-6-04

±.015

.120

±.02

2.56

PROJECT

1

5081-P-FI

5/6/04

J. FLOCK

ENGR APVD

9241502-01

DWG NO

B

SIZE

SCALE

SOLID EDGE

THIS DWG CREATED IN

4

FINISH

2:1

DESCRIPTION

LABEL, I.S. BAS/ATEX

Uniloc

TITLE

BILL OF MATERIAL

DATE

5/3/04

5/6/04

PART NO

ITEM

±.005

2.180

4 FINISH:SILKSCREEN BLACK EPOXY PAINT (BAKED).

TOLERANCES

UNLESS OTHERWISE SP ECIFIED

.030
+

.XX

1/2

-

+

ANGLES

-

.010

+

.XXX

B. JOHNSON

J. FLOCK

APPROVALS

DRAWN

CHECKED

DIMENSIONS ARE IN INCHES

NOMINAL SURFACE FINISH 125

MACHINED FILLET RADII .020 MAX

REMOVE BURRS & SHARP EDGES .020 MAX

-

MATERIAL

This document contains information proprietary to

Rosemount Analytical, and is not to be made available

Ø .125

II 1 G

RR

EEx ia IIC T4

MODEL 5081-P-FI-73

1180

BAS02ATEX1284

Tamb = -20°C TO +65°C

ROSEMOUNT ANALYTICAL

FISCO SUPPLY

µ

Ii = 380 mA

Pi = 5.32 W

Ci= 0 F

Ui = 17.5 VDC

µ

µ

SIGNAL INPUT

Li= 0 H

µ

9241502-01/A

Li= 0 H

Io = 173 mA

Po = 231 mW

Uo = 13.1 V

Ci= 0.010 F

±.015

.650

±.02

1.30

.125

R .25

4X

±.00 5

.140

to those who may compete with Rosemount Analytical.

2X FULL R

3. ARTWORK IS SHEET 2 OF 2.

2. NO CHANGE WITHOUT BASEEFA APPROVAL.

1 MATERIAL: AISI 300 SERIES STAINLESS

BE ANNEALED & PASSIVATED. MAXIMUM

HARDNESS BRINELL 190.

STEEL .015+/-.005 THICK. MATERIAL TO

NOTES: UNLESS OTHERWISE SPECIFIED

24

D

1

REVISION

2

1400293

CHK

DATE

YBN

OI
T
P

IR
C

SE
D

C

B

A

REV

CERTIFIED BY

THIS DOCUMENT IS

Baseefa

UNSPECIFIED

17.5 VDC MAX

POWER SUPPLY

UNSPECIFIED

17.5 VDC MAX

POWER SUPPLY

UNSPECIFIED

17.5 VDC MAX

POWER SUPPLY

UNSPECIF IED

REV

REV

REV

REV

REV

W/O AGENCY APPROVAL

REVISIONS NOT PERMITTED

17.5 VDC MAX

POWER SUPPLY

A

10-96

REV

QTY

Rosemount Analytical,

2400 Barranca Pkwy

Irvine, CA 92606

Uniloc Division

DESCRIPTION

BILL OF MATERIAL

Uniloc

TITLE

DATE

5/3/04

A

2

1

SHEET OF

1

TYPE

1400293

ATEX Z ONE 0

5081-P-FI XMTR

NONE

DWG NO.

SCHEMATIC, INSTALLATION

D

SIZE

SCALE

5/6/04

5/6/04

2

PART NO.

ECO

LTR

UNCLASSIF IED ARE A

3

SAFETY BARRIER

(SEE NOTES 1 & 7)

(ZONE 0)

4

SAFETY BARRIER

(SEE NOTES 1 & 7)

SAFETY BARRIER

(SEE NOTES 1 & 7)

SAFETY BARRIER

(SEE NOTES 1 & 7)

ITEM

+

-

ANGLES

TOLERANCES

.030

.010

+

-

+

-

UNLESS OTHERWISE SPECIFIED

.XX

.XXX

J. FLOCK

B. JOHNSON

J. FLOCK

APPROVALS

DRAWN

DIMENSIONS ARE IN INCHES

NOMINAL SURFACE FINI SH 125

MACHINED FILLET RADII .020 MAX

REMOVE BURRS & SHARP EDGES .020 MAX

SOLID EDGE

THIS DWG CREATED IN

PROJECT

ENGR APVD

CHECKED

3

MATERIAL

FINISH

A

ECO NO. REV

8925

4

RELEASE DATE

5-6-04

1180

II 1 G

Baseefa02ATEX1284

EEx ia IIC T4

HAZARDOUS AREA

5

15

16

14

13

12

11

10

9

8

XMTR

MODEL

7

5081-P-FI

6

5

4

3

6

12

XMTR

MODEL

5081-P-FI

15

16

14

13

12

11

10

9

8

7

6

5

4

3

12

XMTR

MODEL

5081-P-FI

15

16

14

13

12

11

10

9

8

7

6

5

4

3

12

XMTR

MODEL

5081-P-FI

15

16

14

13

12

11

10

9

8

7

6

5

4

3

12

5

6

TB1-

4

5 710

TO PREVENT IGNITION OF FLAMMABLE OR COMBUSTIBLE ATMOSPHERES,

SUBSTITUTION OF COMPONENTS MAY IMPAIR INTRINSIC SAFETY.

DISCONNECT POWER BEFORE SERVICING.

7

FISCO

+PH

SENSOR

ZONE 0

INFRARED

FOR USE IN

(RMT PN 23 572-00)

8

REMOTE CONTROL UNIT

PREAMP

(NOTE 4)

PREAMP

ATEX APPROVED PREAMP

OF NOTE 3

THAT MEETS REQUIREMENTS

(NOTE 4)

WARNING-

ATEX AP PROVED PREAMP

THAT MEETS REQUIRE MENTS

OF NOTE 3

+PH

SENSOR

RECOMMENDED CABLE

PN 9200273 (UNPREPPED)

PN 23646-01 PREPPED

10 COND, 2 SHIELDS 24 AWG

SEE NOTE 2

+PH

SENSOR

PH

TC

WITH

SENSOR

WARNING-

4 WIRES SHIELDED

RECOMMENDE D CABLE

22 AWG. SEE NOTE 2

7

8

NOTES ON SHEET 2 OF 2

ATEX INTRINSIC SAFETY INSTALLATION

Rosemount Analytical, and is not to be made available

This document contains information proprietary to

to those who may compete with Rosemount Analytical.

D

C

B

A

NOTES: UNLESS OTHERWISE SPECIFIED

25

MODEL 5081-P-FF/FI INFRARED REMOTE CONTROLLER

INFRARED REMOTE CONTROLLER (IRC) - KEY FUNCTIONS

The infrared remote controller is used to calibrate and program the transmitter and to display diagnostic mes­sages. See figure below for a description of the function of the keys.

Hold the IRC within 6 feet of the transmitter, and not more than 15 degrees from the center of the display window.

Infrared Remote Controller.

RESET - Press RESET to end the cur-

rent operation and return to the main
display. Changes will NOT be saved.

RESET does NOT return the transmit­ter to factory default settings.

CAL - Press CAL to access the calibra-

tion menu.

PROG - Press PROG to access the pro­gram menu.

DIAG - Press DIAG to read diagnostic
messages.

HOLD - Press HOLD to access the
prompts used for turning on or off the
hold function.

ARROW KEYS - Use



and



keys to
increase or decrease a number or to
scroll through items in a list. Use the



or



keys to move the cursor across a
number. A flashing word or numeral
shows the position of the cursor.

ENTER - Press ENTER to move from a
submenu to the first prompt under the
submenu. Pressing ENTER also stores
changes in memory and advances to the
next prompt.

NEXT - Press NEXT to advance to the
next submenu or to leave a message
screen.

EXIT - Press EXIT to end the current
operation. Changes are NOT saved.

REMOTE CONTROL

INTRINSICALLY SAFE EQUIPMENT
HAZARDOUS AREA LOCATIONS:
CLASS I, DIV 1, GP A, B, C, D
CLASS I, DIV 2, GP A, B, C, D
T3C Tamb = 40°C T3 Tamb = 80°C

1.5Vdc AAA BATTERIES
EVEREADY E92/1212
DURACELL MN2400/PC2400

IS/I/1/A,B,C & D
NI/I/2/A,B,C & D
T4 Tamb = 40°C
T3A Tamb = 80°C

Baseefa02ATEX0198
II 1G EExia IIC T4 1180

1.5Vdc AAA BATTERIES
EVEREADY E92/1212
DURACELL MN2400/PC2400
ROSEMOUNT ANALYTICAL 92606 USA

WARNING:
TO PREVENT IGNITION
CHANGE BATTERIES IN
A NONHAZARDOUS AREA

ONLY

IRC - INFRARED REMOTE CONTROL

LR 34186
Exia

SUBSTITUTION OF

COMPONENTS MAY

IMPAIR INTRINSIC SAFETY

PN 23572-00

YEAR

26

MODEL 5081-P-FF/FI START-UP - pH

START-UP CONFIGURATION AND CALIBRATION — pH

To perform a two-point buffer calibration, follow these steps:

1. Place the pH sensor in the first buffer solution.

2. On the remote, press CAL, ENTER, ENTER.

3. Use the arrow buttons to select the correct buffer value. Press ENTER.

4. Rinse the sensor and place it in the second buffer solution. Press ENTER.

5. Use the arrow buttons to select the correct buffer value. Press ENTER.

MENU

Sub-menu

PROMPT

Diag Message

FIGURE 14. Menu Tree for pH

PROGRAM

CALIBRATE

GIMP 1000

5081-P-FF

SoFt

InPut 58.9

FAULtS

nonE

rIMP 10

dIAGnOStIC

tEMP

bUFFEr

dISPLAY

ISOPOtntAL

LinE FrEq PAMP=trAnS

CALIbrAtE

Std

tEMP AdJ

tEMP 25.0

tAUtO On

tMAn 25.0

tYPE PH

tEMP C

OUtPUt Cur

COdE 000

bAUtO On

bUFFEr Std

StAbiLiSE

tIME 10

deLtA 00.02

tCOEF 00.00

ISO 07.00

Snr 07.00

LinE 60

dEFAULt

FActOrY

YESNO

rOFFSt 060

dIAG OFF

IMPtC ON

GWH 1000

GFH 1500

GWL 020

GFL 010

CAL 000

rEF LO

rFH 140

rWH 040

rWL 000

rFL 000

CAL bF1

bF 1

bF1 4.01

CAL bF2

bF 2

bF2 10.01

DIAGNOSE

Std 7.00

SLOPE 59.01

SLOPE OFFSt

HArd

27

MODEL 5081-P-FF/FI START-UP - ORP

START-UP CONFIGURATION AND CALIBRATION — ORP

To perform a one point standardization, follow these steps.

1. Place the ORP sensor in the ORP buffer solution.

2. On the Remote press CAL, ENTER, ENTER

3. Use the arrow buttons to adjust the value. Press ENTER

4. Press RESET

MENU

Sub-menu

PROMPT

Diag Message

FIGURE 15. Menu Tree for ORP

PROGRAM

CALIBRATE

OFFSt 120

5081-P-FF

FAULtS

nonE

dIAGnOStIC

dISPLAY

LinE FrEq

Std

tEMP ADj

tEMP 25.0

tYPE ORP

tEMP C

OUtPUt CUr

COdE 000

LinE 60

rOFFSt 060

dIAG OFF

IMPtC OFF

rEF LO

rFH 140

rWH 040

rWL 000

rFL 000

Std 1000

DIAGNOSE

rIMP 10 SoFt 00.02 HArd 01

PAMP=trAnS

2511

mV

MODEL 5081-P-FF/FI MENU MNEMONICS

5081-P DISPLAY MANUAL TEXT MEANING

DBMJcsBuF CALIbrAtE Calibration menu

Tue Std Standardize sensor

cG2!0!cG3 bF1 / bF2 Buffer 1 / Buffer 2

TMPQF SLOPE Sensor slope

Ipme HoLd Set hold

GBVMu FAULt Set fault

eQo dPn Set output dampening

eJBHopTujd dIAGnoStic Diagnostic submenu

sPGGTu rOFFSt Reference offset

JNQuD IMPtC Glass impedance temperature compensation

HGI GFH Glass fault high

HXKI GWH Glass warning high

HGM GFL Glass fault low

HXKM GWL Glass warning low

DBM CAL [Factory use only]

sFG rEF Set high/low impedance reference

sGI rFH Reference fault high

sxkI rWH Reference warning high

sGm rFL Reference fault low

sxkM rWL Reference warning low

uFNQ tEMP Temperature units

uBVuP tAUtO Automatic temperature compensation

uNBo tMAn Manual temperature compensation

uZQF tYPE Measurement type (pH/ORP)

ejTQMBZ diSPLAY Display submenu

PROGRAM MENU MNEMONICS

Credit Cards for U.S. Purchases Only.

The right people,
the right answers,
right now.

ON-LINE ORDERING NOW AVAILABLE ON OUR WEB SITE

http://www.raihome.com

Specifications subject to change without notice.

Emerson Process Management

Liquid Division

2400 Barranca Parkway
Irvine, CA 92606 USA
Tel: [phone]
Fax: [phone]

http://www.raihome.com

© Rosemount Analytical Inc. 2007
