	MCC4061E	GB	MICROWAVE OVEN	USER MANUAL	2
		DE	MIKROWELLENGERÄT	BENUTZERHANDBUCH	41
		FR	FOUR À MICRO-ONDES	GUIDE DE L’UTILISATEUR	83
		NL	MAGNETRONOVEN	GEBRUIKSAANWIJZING	127
		ES	HORNO MICROONDAS	MANUAL DE USUARIO	169
		PT	FORNO A MICRO-ONDAS	MANUAL DO UTILIZADO	210

2 Contents

FOR PERFECTRESULTS

Thank you for choosingthis AEG product.We havecreated it to give you impeccable performance for manyyears, with innovative technologies that help make life simpler – features you mightnot find on ordinary appliances. Pleasespenda few minutes reading to get the very best from it.

ACCESSORIESAND CONSUMABLES

In the AEG webshop,you’ll find everything you need to keepall your AEG appliances looking spotlessand working perfectly. Along witha wide range of accessories designed and built to the highqualitystandards you would expect, fromspecialist cookwareto cutlery baskets, frombottle holders to delicate laundry bags…

Visit the webshop at www.aeg-electrolux.com/shop

CONTENTS

3 Important safety instructions

7Appliance overview

8Before first use

10 Microwave cooking advice

12 Microwave operation

23 Recipes for glass tray

26 Automatic operation

28 Programme charts

34Care & cleaning

35Reduced power level

36What to do if . . .

36Specifications

37Installation

39Environmental information

40European guarantee

Important information concerningyoursafetyor the operation of your applianceis notedby thissymbol and/or mentions words suchas «Warning»,«Takecare». Be sureto follow all instructionscarefully.

This symbol indicatesfurtherinformationconcerningthe useof the appliance.

Theclover indicatesenergy-savingtipsandhintsfor environmentally friendly useof yourappliance.

In the eventof malfunctioning,pleasefollowthe instructions givenin thesection«Whatto do if...»

Important safety instructions	3

IMPORTANT SAFETY INSTRUCTIONS

Important safety instructions: Read carefully and keep for future reference

To avoid the danger of fire

The microwave oven should not be left unattended during operation. Power levels that are too high or cooking times that are too long may overheat foods resulting in a fire.

The electrical outlet must be readily accessible so that the unit can be unplugged easily in an emergency.

The AC power supply must be 230 V, 50 Hz, with a minimum 16 A distribution line fuse, or a minimum 16 A distribution circuit breaker.

It is recommended that a separate circuit serving only this appliance be provided. Do not store or use the oven outdoors.

If food being heated begins to smoke, DO NOT OPEN THE DOOR. Turn off and unplug the oven and wait until the food has stopped smoking. Opening the door while food is smoking may cause a fire.

Only use microwave-safe containers and utensils. See Page 11.

Do not leave the oven unattended when using disposable plastic, paper or other combustible food containers.

Clean the waveguide cover, the oven cavity and the turntable after use. These must be dry and free from grease. Built-up grease may overheat and begin to smoke or catch fire.

Do not place flammable materials near the oven or ventilation openings. Do not block the ventilation openings.

Remove a ll metallic s eals, wire t wists, e tc., from f ood and f ood packages. Arcing on metallic surfaces may cause a fire.

Do not use the microwave oven to heat oil for deep frying. The temperature cannot be controlled and the oil may catch fire.

To make popcorn, only use special microwave popcorn makers. Do not store food or any other items inside the oven.

Check the settings after you start the oven to ensure the oven is operating as desired. See the corresponding hints in the cookery book section.

To avoid the possibility of injury

Warning!

Do not operate the oven if it is damaged or malfunctioning. Check the following before use:

a)The door; make sure the door closes properly and ensure it is not misaligned or warped.

b)The hinges and door safety latches; check to make sure they are not broken or loose.

c)The door seals and sealing surfaces; ensure that they have not been damaged.

d)Inside the oven cavity or on the door; make sure there are no dents.

e)The power supply cord and plug; ensure that they are not damaged.

4 Important safety instructions

Never adjust, repair or modify the oven yourself. It is hazardous for anyone other than a competent person to carry out any service or repair operation which involves the removal of a cover which gives protection against exposure to microwave energy.

Do not operate the ovenwith the door open or alter the door safety latches in any way. Do not operate the ovenif there is an object between the door seals and sealing surfaces.

Do not allow grease or dirt to build up on the door seals and adjacent parts. Follow the instructions for “Care & Cleaning” on page 34. Failure to maintain the oven in a clean condition could lead to a deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.

Individuals with PACEMAKERS should check with their doctor or th e manufacturer of the pacemaker for precautions regarding microwave ovens.

To avoid the possibility of electric shock

Under no circumstances should you remove the outer cabinet.

Never spill or insert any objects into the door lock openings or ventilation openings. In the event of a spill, turn off and unplug the oven immediately and call your local AEG service agent.

Do not immerse the power supply cord or plug in water or any othe r liquid.

Do not allow the power supply cord to run over any hot or sharp surfaces, such as the hot air vent area at the top rear of the oven.

Do not attempt to replace the oven lamp yourself or allow anyone who is not authorised by AEG to do so. If the oven lamp fails, please consult your dealer or contact your local AEG service agent.

If the power supply cord of this appliance is damaged, it mustbe replaced with a special cord. The exchange must be made by an authorised AEG service agent.

To avoid the possibility of explosion and sudden boiling

Warning!

Liquids and other foods must not be heated in sealed containers since they are liable to explode.

Never use sealed containers. Removeseals and lidsbefore use. Sealed containers can explode due to a build up of pressure even after the oven has been turned off.

Take care when microwaving liquids. Use a wide-mouthed container to allow bubbles to escape.

Microwave heating of beverages can result in delayed eruptive boiling, therefore care has to be taken when handling the container.

To prevent sudden eruption ofboiling liquid and possible scalding:

1.Stir liquid prior to heating/reheating.

2.It is advisable to insert a glass rod or similar utensil into the liquid whilst reheating.

3.Let liquid stand for at least 20 seconds in the oven at the end of cooking time to prevent delayed eruptive boiling.

Do not cook eggs in their shells, and whole hard boiled eggs should not be heated in microwave ovens since they may explode even after microwave cooking has ended. To cook or reheat eggs which have not been scrambled or mixed, pierce the yolks and the whites, or the eggs may explode. Shell and slice hard boiled eggs before reheating them in the microwave oven.

Important safety instructions	5

Pierce the skin of such foods as potatoes, sausages and fruit before cooking, or they may explode.

To avoid the possibility of burns

Use pot holders or oven gloves when removing food from the oven to prevent burns. Always open containers, popcornmakers, oven cooking bags,etc., away fromhet face andhands to avoidsteam burns.

To avoid burns, always test food temperature and stir before serving and pay special attention to the temperature of food and drink given to babies, children or the elderly.

Temperature of the container is not a true indication of the temperature ofthe food or drink; always check the food temperature.

Always stand back from the oven door when opening, to avoid bu rns from escap ing steam and heat.

Slice stuffed baked foods after heating to release steam and avoidburns. Keep children away from the door to prevent them burning themselves.

Do not touch the oven door, outer cabinet, rear cabinet, oven cavity, ventilation openings, accessories and dishes during GRILL mode, CONVECTION mode, DUAL mode, AUTO COOK and AUTO COOK FROM FROZEN operation as they will become hot. Before cleaning make sure they are not hot.

To avoid misuse by children

Warning!

Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.

This appliance is not int ended fo r use by pers ons (includin g children) with reduc ed physical, se nsory or m ental ca pabilities, or la ck of e xperience and knowle dge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance. Do not lean or swing on the oven door. Do not play with the oven or use it as a toy.

Children should be ta ught all important safety instructions: use of pot holders, careful removal of food coverings; paying special attention to packaging (e.g. self-heating materials) designed to make food crisp, as they may be extra hot.

Other warnings

Never modify the oven in any way.

Do not move the oven while it is in operation.

This oven is for home food preparation only and may only be used for cooking food. It is not suitable for commercial or laboratory use.

To promote trouble-free use of your oven and avoid damage

Never operate the oven when it is empty except where recommended in the operation manual, see Pages 17 - 18. Doing so may damage the oven.

When u sing a browning dish or self -heating m aterial, al ways pla ce a h eat-resistant insulator such as a porcelain plate under it to prevent damage to the turntable due to heat stress. The preheating time specified in the dish’s instructions must not be exceeded.

Do not use metal utensils, which reflect microwaves and may cause electrical arcing. Do not put cans in the oven.

6 Important safety instructions

Use only the turntable designed for this oven.

Do not place anything on the outer cabinet during operation.

Do not use plastic containers for microwaving if the oven is still hot from using the GRILL mode,CONVECTIONmode, DUAL mode,AUTO COOKand AUTO COOK FROM FROZEN, because they may melt. Plastic containers must not eb used during above modesunless the container manufacturer says they are suitable.

Important:

If you are unsure how to c onnect yo ur oven, pl ease cons ult an aut horised, qualified electrician.

Neither the manufacturer nor the dealer can accept any liability for damage to the oven or pers onal injur y r esulting from failure t o observe the corre ct electrical connection procedure.

Water vapour or drops may occasionally form on the oven walls or around the door seals a nd se aling surfaces. This i s a normal occ urrence a nd is not an indication of microwave leakage or a malfunction.

Appliance overview	7

APPLIANCE OVERVIEW

Microwave oven & accessories

1	2	3	4	1
				5
11

6

			1	9	8	7		1
1	Fixing points (4 points)							12
2	Grill heating element
3	Convection heating element			14
4	Oven lamp
5	Control panel
6	Shelf runners			15
7	Waveguide cover							13
8	Oven cavity
9	Coupling
10	Door seals and sealing surfaces
11	Door opening handle
12	Air-vent openings							16
13	Outer cabinet
14	Power cord							17
15	Power supply cord support clip
Check to make sure the following accessories are supplied:								Coupling
16	Turntable	19	High rack
17	Turntable support	20	Rack for glass tray			These racks are used for cooking in
18	Low Rack	21	Glass tray
						Convection, Dual or Grill mode.
• Place the turntable support into the coupling in the								19
centre of the oven floor, ensuring you place it TOP side							18
up, (TOP is engraved on one side). It should be able to
freely rotate around the coupling.
• Place the turntable on to the turntable support.								20
• Place the high/low racks onto the turntable if necessary
• Slide the glass tray into the shelf runners. You may cook
dishes directly in the tray or set the rack inside the tray
when roasting in order to catch drippings.(See page 22.)								21

8Appliance overview & Before first use

IMPORTANT:

•Always operate the oven with the turntable and support fitted correctly. Thispromotes thorough even cooking. A badly fitted turntable may rattle, may not rotate properly and damage the oven.

•The turntable rotates clockwise or counter clockwise.

The rotary direction may change each time youstart the oven. This doesnot affect cooking performance.

•When you order accessories, please mention two

details: part name and model name to your dealer orAEG service agent.

	Control panel
	Digital display and indicators:
		COOKING indicator	3	4
		START indicator
			2	5
	3	GRILL indicator
			1	6
		CONVECTION indicator
		MICROWAVE indicator		7
		INFORMATION indicator	19	8
	Operating buttons:
		INFORMATION button		9
	8	LANGUAGE button
	9	COOKING MODE knob
		for microwave cooking
		for microwave cooking with GRILL		10
		for microwave cooking with CONVECTION
		for GRILL		11
		for CONVECTION		12
				13
	10	TIMER/WEIGHT knob
	11	AUTO COOK button	18	14
	12	COOK FROM FROZEN button
			17
	13	AUTO DEFROST button
	14	MICROWAVE POWER LEVEL button	16	15
	15	START/QUICK button
	16	STOP button
	17	CONVECTION button
	18	TIMER button
		LESS/MORE buttons

BEFORE FIRST USE

1.Plug in the oven. Nothing will appear in the display at this time.

2.Open the door.

The oven display will show “SELECT LANGUAGE” in 6 languages.

3.Close the door.

The oven display will show .

	Before first use	9
NOTE:	If you do nothing for 3 minutes, the power will go off automatically. Nothing
	will appear on the display at this time. To restore power, openthe door.

4. Heat the oven without food (see page 17 - 18).

COOKING HINTS:

The oven has an ‘Information Display System’ which offers you step by step instructions to easily guide you through each feature, and enable you to gain information in your desired language. The oven has an INFORMATION button for getting instructions for each button. Indicators will appear in the display, after pressing a button, to inform you of the next operation step.

Selecting the language

Press LANGUAGE button	LANGUAGE
once	ENGLISH
twice	DEUTSCH
3 times	NEDERLANDS
4 times	FRANÇAIS
5 times	ITALIAN
6 times	ESPAÑOL

The oven comes set for English. You can change the language. To change, press the LANGUAGE button until th desired language is displayed. Then press the START/QUICK button.

Example: To select Italian:

1. Choose the desired language by pressing the LANGUAGE button.

x5

2. Press the START/QUICK button the start the setting.

x1

3. Check the display:

Note: The selected language will be memorised even if the electrical power supply is interrupted.

Using the STOP button

Use the STOP button to:

1.Erase a mistake during programming.

2.Stop the oven temporarily during cooking.

3.Cancel a programme during cooking, press the STOP button twice.

10 Microwave cooking advice

MICROWAVE COOKING ADVICE

Microwave cooking

To cook/defrost food ina microwave oven, the microwaveenergymust be able to pass through the container to penetrate the food. Therefore it is important to choose suitable cookware.

Round/oval dishes are preferable to square/oblong ones as the food inthe corners tends to overcook.

It is important to turn,rearrange orstir food to ensure even heating.

Standing time is necessary after cooking as itenables the heatto disperseequally throughout the food.

	Food characteristics
Composition	Foodshigh infat orsugar (eg.. Christmas pudding, mince pies)requirelessheating time.Care
	shouldbe takenas overheating canlead to fire.
Density	Fooddensitywill affect the amount of cooking time neededLight. porousfoods,such as
	cakesor bread,cookmore quickly than heavy, dense foods,suchas roastsandcasseroles.
Quantity	Thecooking timemust beincreased asthe amount of food placed in theovenincreases.
	E.g. four potatoes will take longer tocookthan two.
Size	Small foodsand small pieces cookfaster than largeones,as microwaves canpenetrate from
	all sides to the centre.For even cooking make all the pieces thesame size.
Shape	Foodswhichare irregular in shape, suchchickenas breasts ordrumsticks,take longer tocook
	in the thicker parts. Roundshapes cookmore evenlythan squareshapeswhenmicrowave
	cooking.
Temperature	Theinitial temperatureof food affectsthe amount of cooking timneeded. Chilledfoods will
of food	takelongertocookthan food at room temperatureCut. into foodswith fillings,ge..jam
	doughnuts, to release heat or teams.
	Cooking techniques
Arrange	Placethethickest parts of food towardsthe outside of theishd. E.g. Chickendrumsticks.
Cover	Use vented microwave clingfilm ora suitable lid.
Pierce	Foodswith a shell,skin or membrane must be piercedin severalplaces beforecooking or
	reheating as steam will build up and maycause foodto explode,e.g.Potatoes,Fish, Chicken,
	Sausages.
	Important: Eggs should not be heated using microwave poweras theymay explode, even
	after cooking has ended,e.g. poached,hard boiled.
Stir, turnand	Foreven cookingit is essential to tir,s turn and arrangere fooduring cookingAlways. stir and
rearrange	rearrange fromthe outside towardsthe centre.
Stand	Standingtime is necessary aftercookingto enablethe heatto disperseequallythroughout
	the food.
Shield	Someareasoffoodbeingdefrosted maybecome warm. Warmareascanbe shielded with
	small pieces of foil, which reflect microwaves, e.g. legsand wingson a chicken.

Microwave cooking advice	11

Microwave safe cookware

Cookware	Microwave		Comments
	safe
Aluminium foil /	/	Small pieces of aluminium foilcanbe usedto shieldfood from
foil containers		overheating. Keepfoil at least 2 cmfromtheoven walls, as arcing
		may occur. Foil containersare notrecommendedunlessspecifiedby
		the manufacturer,e.g. Microfoil ®, followinstructionscarefully.
Browning dishes		Always followthe manufacturersinstructionsDo. not exceed
	/	heating times given. Be very carefulas these dishesbecome veryhot.
Chinaand ceramics		Porcelain, pottery,glazed earthenware andbone chinaareusually
		suitable, except forthose with metallicdecoration.
Glassware eg. . Pyrex ®		Care should betaken if using fineglasswareas itcanbreak or crack if
		heated suddenly.
Metal		It is notrecommendedto use metal cookware whenusing micro-
		wave power as it will arc, which canleadto fire.
Plastic / polystyrene		Care mustbe taken as some containers warp,melt ordiscolour at
e.g. fast food containers		hightemperatures.
Clingfilm		Should not touch the foodand must bepierced to letthe steam escape.
Freezer/ roasting bags		Must bepierced toletsteam escape.Ensurebags aresuitable for
		microwave use.Donotuse plasticor metal ties,as theymaymeltor
		catch fire due to the metal arcing.
Paper - platescups		Onlyusefor warming orto absorb moistureCare.must be taken as
andkitchen paper		overheatingmay cause fire.
Straw and wooden		Always attend theovenwhen using thesmaterialsas overheating
containers		maycausefire.
Recycled paper		Maycontain extracts of metal whichwillcause‘arcing’ and maylead
andnewspaper		to fire.
Suitable ovenware
Ovenware material			Micro-	Convec-	Grill	Combination
			wave	tion
Ovenproof glass and ceramic dishes (without any			X	X	X	X
metal parts, e.g. Pyrex, oven-to-tableware, glass tray)
Non ovenproof glassand porcelain (e.g table crockery 1)			X	-	-	-
Glass ceramic and vitroceramic made of fire /			X	X	X	X
frostproof material (e,g. Arcoflam)
Ovenproof earthware 2)			X	X	-	X
Plastic heat-resistant up to 200 0C 3)			X	X 3)	-	X 3)
Paper, cardboard			X	-	-	-
Cling film			X	-	-	-
Microwaveable roasting bag 4)			X	X	-	X 4)
Metal roasting pans, e.g. enamel or cast-iron dishes			-	X	X	-
Black-lacqued or silcone-coated baking tins			-	X	-	-
X = suitable	- = non suitable

1)excluding silver, gold, platinum or metal decoration.

2)does not include glaze containing metal.

3)please note the maximum temperature stated by the manufacturer.

4)convection + microwave combined function.

12 Microwave operation

MICROWAVE OPERATION

Microwave cooking

Your oven can be programmed for up to 90 minutes. The input unit of cookingtime varies from 10 seconds to five minutes. It depends on het total length of cooking time as shown in the table.

Cooking time	Increasing unit
0-5 minutes	10seconds
5-10minutes	30 seconds
10-30 minutes	1 minute
30-90 minutes	5 minutes

Manual defrosting

For manual defrosting (withoutoperating the Auto defrost feature), use 270 W.The defrost symbol appears in the window displaywhenever the power level is selected.

Microwave power levels

Your oven has 5 power levels. To hoosec the power level for cooking, followthe advice given in the recipe section. Generallythe following recommendationsapply:

Power	Suggested use
setting
900 W/	Used for fast cooking orreheatinge.g. soup, casseroles, canned food,hotbeverages, vegetables,
HIGH	fish, etc.
630 W	Used for longer cooking of dense foods such asroast joints, meatloafand platedmeals, also for
	sensitive dishes such as cheesesauce and sponge cakes.At thisreducedsetting, thesaucewill
	not boil overand food will cookevenlywithout overcookingat thesides.
450 W	For dense foodswhich require along cookingtimewhencookedconventionally,eg. beef dishes,
	it is advisable touse this power settingto ensurethemeatwillbe tender.
270 W/	To defrost,select this power setting,to ensure that the dish defrostsevenly.This
DEFROST	setting is also ideal forimmeringsrice, pasta, dumplingsand cookingeggcustard.
90 W	For gentle defrosting,e.g. cream gateaux or pastry.

W = WATT

Microwave operation	13

Example: To heat soup for 2 minutes and30 seconds on 630W microwave power. 1. Rotate the COOKING MODE dial to the microwave setting.

2. Enter desired cooking time by rotating the TIMER/WEIGHT knob clockwise.

3.Press the MICROWAVE POWER LEVEL button twice for 630 W microwave power.

x2

4. Press the START/QUICK button once to start cooking

x1

5. Check the display:

Important:

If the power level is not selected, HIGH/900 W isautomaticallyset.

NOTES:

1.When the door is opened during the cooking process, the cooking time on the digital display stops automatically. The cooking time starts to count down again when the door is closed and the START/QUICK button is pressed.

2.If you wish to know the power level during cooking, press the MICROWAVE POWER LEVEL button. As long as your finger is pressing the MICROWAVE POWER LEVEL button, the power level will be displayed.

3.You can rotate the TIMER/WEIGHT knob clockwise or counter-clockwise. If you rotate the dial counter-clockwise, the cooking time will decrease from 90 minutes by degrees.

Kitchen timer

1. Press the TIMER button once.

x1

2. Enter the time by rotating the TIMER/WEIGHT knob clockwise.

3. Press the START/QUICK button to start.

x1

4. The oven will count down.

14 Microwave operation

START/QUICK function

The START/QUICK button allows you to operate the two following functions:

a.30 seconds cooking

You can cook on your desired cooking mode for 30 seconds without entering the cooking time.

Example: To cook for 30 seconds on 630 W microwave power.

1.Select the cooking mode by rotating the COOKING MODE dial to (Microwave).

2.Change the power by pressing the MICROWAVE POWER LEVEL button.

3.Press the START/QUICK button once to begin cooking.

4.Check the display:

NOTES:

x2

x1

1.You can use this function for manual cooking only.

2.When the COOKING MODE dial is on microwave ( ) and you press the START/QUICK button, the microwave power is always 900 W.

When the COOKING MODE dial is on dual (	or	) and you press		the
START/QUICK button, the microwave power is always 270 W.
When the COOKING MODE dial is on convection or dual 1 (			or	) and you

press the START/QUICK button, the convection temperature is always 250 °C.

3.To avoid misuse by children the add 30 seconds function can be used only within 3 minutes after the preceding operation, ie closing the door, pressing the STOP button or end of cooking.

b.Extend the cooking time

You can extend the cooking time in multiples of 30 seconds if the START/QUICK button is pressed while the oven is in operation.

NOTE: You can use this function for manual cooking only.

Microwave operation	15

Less or More buttons

The LESS ( ▼ ) and MORE ( ▲ ) buttons allow you to decrease or increase programmed setting times easily, (for a less well or more well cooked result), when cooking in progress.

a)Choosing Autocook with Less/More:

Press the LESS ( ▼ ) and MORE ( ▲ ) button after entering weight and before pressing the START/QUICK button. (See cooking for menus that use Less and More.)

Example: To cook 0,2 kg French Fried Potatoes using AUTO COOK FROM FROZEN with the LESS ( ▼ ) button.

1.Choose the AUTO COOK FROM FROZEN menu for French Fried Potatoes by pressing the button four times.

2.Enter the amount (0,2 kg).

3.Choose the “thin” French Fried Potatoes by pressing the LESS ( ▼ ) button once.

4.Press the START/QUICK button.

5.Check the display.

NOTES:

To cancel LESS or MORE press the same button again.

To change MORE to LESS simply press the less ( ▼ ) button. To change LESS to MORE simply press the MORE ( ▲ ) button.

x4

x1

x1

b)Changing the heating time while the oven is operating:

During the manual cooking progress, the cooking time can be decreased or increased in 1 minute steps each time the LESS ( ▼ ) and MORE ( ▲ ) buttons are pressed.

NOTE: You can use this function for manual cooking only.

16 Microwave operation

To check settings while the oven is operating

You can check the power level and the actual oven temperatures ie: when preheating.

TO CHECK THE POWER LEVEL:

To check the microwave power level during cooking press the MICROWAVE POWER LEVEL button.

The oven continues to count down, although the display shows the power level.

As long as your finger is pressing the button, the power level will be displayed.

TO CHECK THE CONVECTION TEMPERATURE:

To check the convection temperature during cooking press the CONVECTION button. When the oven is pre-heating, you can check the actual oven temperature.

As long as your finger is pressing the button, the convection temperature in ° C will be displayed.

Information button

Each button carries useful information. If you wish to get the information, press the INFORMATION button before pressing the desired button.

Example:

To get information about AUTO COOK menu number 2, Roast chicken: 1. Choose the INFORMATION button function.

x1

2. Press the AUTO COOK button 2 times to select Roast Chicken.

x2

3. Check the display:

NOTE:

1.The information message will be repeated twice, and then the display will show the time of day, if set.

2.If you want to cancel the information press the STOP button.

Microwave operation	17

Grill cooking

The grill heating element at the top of the ovencavity has one powersetting only. Example: To cook cheese on toast for 5 minutes (place toast on the high rack.)

1. Rotate the COOKING MODE dial to the GRILL setting.

2. Enter the desired cooking time by rotating the TIMER/WEIGHT knob clockwise.

3. Press the START/QUICK button to start cooking.

x1

4. Check the display:

Important:

1.The high or the low rack is recommended for grilling.

2.You may detect smoke or a burning smell when using the grill for the first time, this is normal and does not indicate a fault with the oven. To avoid this problem, when using the oven for the first time, operate the grill without food for 20 minutes.

3.After cooking the display may show ‘NOW COOLING”.

WARNING: The oven cavity, door, outer cabinet, turntable, racks and dishes will become very hot, always use thick oven gloves when removing the food or turntable from the oven to prevent burns.

Heating without food

You may detect smoke or a burning smell when using the grill and convection for the first time. This is normal and not a sign that the oven is out of order.

To avoid this problem, when first using the oven, heat the oven without food for 20 minutes on grill and then at convection 250 °C.

IMPORTANT: During operation, to allow smokeor smells to disperse open a window or switch the kitchen ventilation on. Make sure there is no food in theoven.

1. Rotate the COOKING MODE dial to the GRILL or CONVECTION setting.

18Microwave operation

2.Enter the required heating time.(20 min.)

3.Start cooking by pressing the START/QUICK button.

x1

The oven will count down. When the oven has finished cooking, openthe door to cool the oven cavity.

WARNING: The oven door, outer cabinet & oven cavity will become hot. Take care to avoid burns when cooling the oven down after operation.

Convection cooking

Your oven can be used as a con ventional oven using th e convection facility and 10 pre-set oven temperatures.

Press Convection button	1	2	3	4	5	6	7	8	9	10
Oven Temp (˚C)	250	230	220	200	190	180	160	130	100	40

Example 1: To cook with preheating.

To pre-heat to 180 °C and c ook for 20 minutes at 180 °C.

1.Select the cooking mode by rotating the cooking mode dial to .

2.Enter the desired preheat temperature by pressing the CONVECTION

button six times. The display will show 180 °C.

x6

3. Press the START/QUICK button to start pre-heating.

x1

4. Check the display:

When the pre-heated temperature has been reached the audible signal sounds, the display will show 180 °C, open the door and place the food inside the oven. Close the door.

Microwave operation	19

5. Use the TIMER/WEIGHT knob to input the cooking time (20 mins).

6. Press the START/QUICK button.

x1

7. Check the display:

Notes:

1.When the oven is preheating, the turntable should be in the oven.

2.After preheating, if you want to cook at a different temperature press the CONVECTION button until the desired setting appears on the display. In the example above, to change the temperature you would press the CONVECTION button after entering the cooking time.

3.When the oven reaches the programmed preheating temperature, it will automatically hold at the pre-heated temperature for 30 minutes. After 30 minutes

the display may show o r “NOW COOLING”. The selected convection programme will be cancelled.

4.After cooking the oven will automatically cool and the display may show “NOW COOLING”.

5.To get the best results when following pack instructions for convection, please follow the instructions for “conventional oven”.

Example 2: To cook without preheating. To cook at 250 °C for 20 minutes. 1. Select the cooking mode by rotating the cooking mode dial to .

2. Use the TIMER/WEIGHT knob to input the cooking time (20 mins).

3. Select the desired cooking temperature (250 °C).

x1

4. Press the START/QUICK button.

x1

5. Check the display:

20Microwave operation

NOTES:

1.After cooking the oven will automatically cool and the display may show “NOW COOLING”.

2.To change the convection temperature, press the CONVECTION button until the desired temperature appears on the display.

3.You may detect smoke or a burning smell when using convection for the first time. This is normal and is not a sign that the oven is out of order. (Please see Heating Without Food on pages 17 - 18).

WARNING: The oven cavity, door, outer cabinet, turntable, racks and dishes will become very hot, always use thick oven gloves when removing the food or turntable from the oven to prevent burns.

Dual cooking

Your oven has 2 DUAL cooking modes combining 1) Convection & microwave, 2) Grill with microwave.

To select the DUAL cooking mode rotate the COOKING MODE dial to the desired setting, then choose the cooking time. Generally, dual cooking time shortens the total cooking time.

Cooking mode	Cooking method	Initial microwave power
Dual1	Convection250 °C	270 W
Dual 2	Grill	270 W

NOTES: The power settings are variable:

DUAL 1 : The oven temperature can be changed from 40 °C to 250 °C in ten levels. Microwave power levels can be changed from 90 W - 630 W in four levels.

DUAL 2 : Microwave power levels can be changed from 90 W - 900 W in five levels.

Example 1: To cook for 20 minutes on DUAL 1 using 90 W microwave power and 200 °C convection.

1. Select the cooking mode by rotating the cooking mode dial to .

2. Enter the desired cooking time (20 minutes).

3. Press the microwave POWER LEVEL button twice (90 W).

x2

Microwave operation	21

4. Press CONVECTION button four times (200 °C).

x4

5. Press the START/QUICK button.

x1

6. Check the display:

Example 2:

To cook for 20 minutes on DUAL 2 using 90 W microwave power and GRILL.

1. Select the cooking mode by rotating the cooking mode dial to .

2. Enter the desired cooking time (20 minutes).

3. Press the MICROWAVE POWER LEVEL button twice (90 W).

x2

4. Press the START/QUICK button.

x1

5. Check the display:

NOTE: After cooking, the oven will automatically cool and the display may show “NOW COOLING”.

WARNING: The oven cavity, door, outer cabinet, turntable, racks and dishes will become very hot, always use thick oven gloves when removing the food or turntable from the oven to prevent burns.

Important:

After GRILL, DUAL, CONVECTION, AUTO COOK, AUTO COOK FROM FROZEN, the cooling fan will run and “NOW COOLING” may appear on the display. Also, when you press the STOP button and open the door during these cooking modes, the

cooling fan will run; you may, therefore, feel air blowing from the ventilation openings.

22 Microwave operation

Cooking charts

Baking using the glass tray with the convection function

Menu	Time	Mode		Position
Quiche	Preheat	200	˚C	Cook base for 15‘00, directly in glass tray, lower
	1) 20’00	200	˚C	position, rotate after 1)
	2) 12’00	200	˚C
Banana Loaf Cake	Preheat	180	˚C	Place loaf tin in glass tray, lower position
	60’00	180	˚C
Apricot & Pecan Loaf	Preheat	180	˚C	Place loaf tin in glass tray, lower position
	35’00	90 W & 180 ˚C
Cherry & Almond Cake	Preheat	180	˚C	Place loaf tin in glass tray, lower position
	40’00	90 W & 180 ˚C
Cheese Cake	Preheat	160	˚C	Place on the rack in glass tray, lower position
	54’00	160	˚C
Frozen Pizza	Preheat	220	˚C	Place on the rack in glass tray, lower position
	12’00	220	˚C
Garlic Baguette	Preheat	200	˚C	Place directly in glass tray, lower position
	15’00	90 W & 200 ˚C
Frozen Lasagne	Preheat	200	˚C	Place directly in glass tray, lower position
	25’00	270	W & 200 ˚C
Small Pastries (from dough)	Preheat	160 ˚C		Place directly in glass tray lower position
(e.g. Croissants)	35’00	160	˚C
Using the glass tray with the grill function

Menu		Time		Mode	Position
Gratin	1) 6’00		900	W	Place dish in glass tray, lower position
	2)	14’00	450	W & grill	Rotate after 2)
	3)	5’00	450	W & grill
Kebabs	1) 10’00		270	W & grill	Place on the rack in glass tray, upper position
	2)	10’00	270	W & grill
Onion Soup	1) 8’00		900	W	Place the soup bowls into the glass tray, lower
	2)	7’30	270	W & grill	position, add cheese & croutons after 1)
Chicken Noodle Casserole	1) 3’00		900	W	Place dish in glass tray, lower position
	2)	10’00	450	W & grill
Steak	1) 9’00		Grill		Place on the rack in glass tray, lower position
	2)	4’00	Grill
Thick sausages	1) 14’00		Grill		Place on the rack in glass tray, lower position
	2)	5’00	Grill		Turnover after 1)
Thin sausages	1) 12’00		Grill		Place on the rack in glass tray, lower position
	2)	6’00	Grill		Turnover after 1)
Toast	1) 4’30		Grill		Place on the rack in glass tray, lower position
	2)	1’30	Grill		Turnover after 1)
Cheese on Toast	1) Preheat 2’00		Grill		Place on the rack in glass tray, lower position
	2)	5’00	Grill		turn over and add cheese after 2)
	3)	4’30	Grill
Mackeral	1) 6’00		90 W & Grill		Place on the rack in glass tray, lower position
	2)	6’00	90 W & Grill		Turnover after 1)
Sardines	1) 5’00		90 W & Grill		Place on the rack in glass tray, lower position
	2)	3’00	90 W & Grill		Turnover after 1)
The above infomation should be used as a guideline.
Adjust cooking times/power levels as required to give the best result.
The times given are for guidance only,as they aredependent upon the typeandquality ofthe meat.
Grilling isideal for flat, pieces of meat andfish.
Unless otherwise stated,the settings given in the table are for use in a coldoven.
Flat foods should be turned only once. Thickerpieces should beturned more often.
Fish are best place head to tailon the wiretray.

Recipes for glass tray	23

RECIPES FOR GLASS TRAY & CONVECTION

Banana loaf

Preheat the oven.

1.Grease and line loaf tin.

2.Cream butter and sugar together.

3.Add egg and coffee essence and beat again.

4.Peel and mash bananas and add to the mix, beat well.

5.Mix in the flour, bicarbonate of soda baking powder and milk until smooth.

6.Place in tin and smooth the surface.

7.Place loaf tin in glass tray, lower position.

60 min.

180 ˚C

8.Stand for 5 mins in tin bef ore turning onto a cooling rack.

120 g	butter
170 g	castersugar
1 tsp	coffee esence
2	ripe bananas
225 g	flour
1 tsp	bicarbonate of soda
1/4 tsp	baking powder
1	medium egg
100 ml	milk

Apricot & pecan loaf

Preheat the oven.

1.Grease and line loaf tin.

2.Mix the salt, baking powder, cinnamon and flour.

3.Add the rest of the ingredients, except the fruit and nuts, mix well.

4.Fold in the fruit and nuts.

5.Place in tin and smooth the surface.

6.Place loaf tin in glass tray, lower position.

35 min.

90 W / 180 ˚C

Baked cheesecake

1.Line the base of the springform tin with greaseproof paper.

2.Melt the butter, add the sugar and crushed biscuits.

3.Push into base of the tin, then chill until set.

4.Put all the filling ingredients in a bowl and whisk until smooth.

5.Pour the filling onto the chilled base.

6.Place tin in glass tray, lower position. 54 min. 160 ˚C

7.Allow to cool, decorate with fruit to serve.

	pinch of salt
11/2 tsp	baking powder
2 tsp	cinnamon
110 g	plain flour
110 g	wholemeal flour
110 g	butter
175 g	soft brown sugar
2	beaten eggs
3 tbsp	milk
175 g	ready to eat apricots, chopped
175 g	toasted pecans, chopped

	Base:
100 g	butter
4 tsp	brown sugar
200 g	plain flour
110 g	crusheddigestive biscuits
	Filling:
450 g	softcheese
150 g	double cream
100 g	castersugar
2	egg yolk
1	juice and zestof lemon

24 Recipes for glass tray

Cherry almond cake

1.Grease and line the springform.

2.Cream the margarine and sugar until light and fluffy.

3.Beat in the eggs one at a time.

4.Fold in the flour and baking powder, stir in the cherries, ground almonds, almond essence and milk.

5.Spoon in the mixture and smooth the surface.

6.Place tin in glass tray, lower position.

40 min.

90 W / 180 ˚C

175 g	margarine
175 g	castersugar
3	medium eggs
175 g	plain flour
1 tsp	baking powder
100 g	glace cherries
75 g	groundalmonds
1 tsp	almond essence
1 tbsp	milk

Red onion quiche

Preheat the oven.

1.Roll out the pastry and line the square dish.

2.Prick the pastry all over with a fo rk.

3.Line the pastry with baking paper.

4.Bake in lower position 15 min. 200 ˚C

5.Remove from the oven and allow to cool.

6.Cook the onions in the butter for 5 min. 900 W

drain off the butter then cool.

7.Beat the eggs, cream, milk, mustard, salt and pepper together.

8.Add the onions and cheese, mix well.

9.Pour mixture into the pastry case and cook.

1. 20 min.	200	˚C, rotate, then
2. 12 min.	200	˚C

500 g	shortcrust pastry
45 g	butter
300 g	redonions,sliced
3	eggs
150 ml	double cream
50 ml	milk
100 g	gratedgouda
1/4 tsp	dijon mustard
	black pepper
1/4 tsp	salt

Recipes for glass tray	25

RECIPES FOR GLASS TRAY & GRILL

Onion soup
1.	Slice the onions, place in a bowl with the		20 g	butter
	stock, salt and pepper, cook for
			250 g	onions
	8 min.	900 W	500 ml	stock
2.	Put the soup in to 4 soup bowls.
				salt & pepper
3.	Cut the toast into cubes and put o n top of
			2	slices of toast
	the soup and place the cheese on the toast.		80 g	emmental cheese

4.Place soup bowls in the glass tray, lower position and cook

71/2 min.

270 W / GRILL

Gratin

1.Grease a gratin dish.

2.Put a layer of potatoes, a layer of onions and 1/2 the cheese in to the dish.

3.Repeat, finishing with a top layer of potato.

4.Mix together cream and eggs, add salt & pepper. Pour over the potatoes.

5.Sprinkle the remaining cheese over the top.

6.Place dish in the glass tray, lower position, cook

1.	6 min.	900 W
2.	14 min.	450 W / GRILL, rotate, then
3.	5 min.	450 W / GRILL

450 g potatoes,sliced thinly

150 g sliced onon

250 g gratedgouda

salt & pepper

250 ml cream

3 eggs

Chicken noodle casserole

1.Place butter, onion, pepper and mushroom in a bowl and cook

2min. 900 W

2.Blend the flour with the milk until smooth, add the stock, sweetcorn, salt & pepper, mix well.

3.Add the chicken and noodles to the sauce.

4.Sprinkle the cheese over the top.

5.Place dish in the glass tray, lower position, cook

1.3 min. 900 W

2. 10 min.

450 W / GRILL

30 g	butter
100 g	sliced mushrooms
100 g	diced onion
100 g	diced peppers
25 g	plain flour
175 ml	milk
300 ml	stock
150 g	sweetcorn
	salt & black pepper
250 g	diced, cooked chicken
150 g	cooked noodles
75 g	freshlygratedgoudacheese

26 Recipes for glass tray & Automatic operation

Grilled sardines/mackeral

1.Mix all ingredients for marinade and spread on the fish, chill for one hour.

2.Place on the rack in the glass tray, lower position.

Cook Sardines:

1.5 min. 90 W / GRILL, turn over

2.3 min. 90 W / GRILL

Cook Mackeral:

1. 6 min.	90 W / GRILL, turn over
2. 6 min.	90 W / GRILL

6headlesssardines/mackeral Marinade:

4 tbsp	olive oil
1 tsp	garlic puree
1 tbsp	balsamic vinegar
1 tsp	lemon juice
	salt & pepper
1 tbsp	fennel

AUTOMATIC OPERATION

The AUTOMATIC OPERATIONS automatically work out the correct cooking mode and cooking time. You can choose from 5 AUTO COOK menus, 4 AUTO COOK FROM FROZEN menus and 7 AUTO DEFROST menus.

Warning:

For AUTO COOK and AUTO COOK FROM FROZEN:

The oven cavity, door, outer cabinet, turntable, racks and dishes will become very hot. Use thick oven gloves when removing food or the turntable from the oven to prevent burns.

What you need to know when using this automatic function:

1. Enter the menu by pressing the AUTO COOK, AUTO COOK FROM
FROZEN or AUTO DEFROST button until the desired menu number
appears in the display. (See pages 28 - 31.)	x1

2.The weight or quantity of the food can be input by rotating the TIMER/WEIGHT knob until the desired weight/quantity is displayed.

• Enter the weight of the food only. Do not include the weight of the container.

• For food weighing more or less than weights/quantities given in the cooking chart, cook using manual programmes.

3. The programmed cooking times are average times. If you want to alter cooking times pre-programmed in the automatic operations, use the LESS ( ▼ ) or MORE ( ▲ ) buttons. See page 15 for de tails. For best results, follow cooking chart instructions.

Automatic operation	27

4. To start cooking press START/QUICK button.

x1

When action is required (e.g. to turn food over) the oven stops and the audible signals sound, the display shows the necessary action. To continue cooking, press the START/QUICK button.

The final temperature will vary according to the initial temperature. Check food is piping hot after cooking. If necessary, you can extend the cooking time and change the power level.

Example: To cook 300 g of Rice using AUTO COOK (AC-1).

1. Press the AUTO COOK button once to select Rice.

x1

2. Enter the weight by rotating the TIMER/WEIGHT knob until the desired weight is displayed.

3. Press the START/QUICK button to start cooking.

x1

4. Check the display:

28 Programme charts

PROGRAMME CHARTS

Auto cook chart

Menu No.				Weight (increasing			Procedure
				unit) / Utensils
AC-1				0,1 - 0,3 kg (100 g)		•	Place in a big bowl and add boiling water.
Rice				Big bowl & lid		•	Cover with a lid.
						•	Place the dish in the centre of the turntable.
						•	When the audible signals sound, stir and recover.
		Rice		Boiling Water
						•	When the audible signals sound again, stir and
		100 g		250 ml
							recover, replace into the oven and press start.
		200 g		450 ml
		300 g		650 ml		•	Stand for approx. 10 mins after cooking.
AC-2				0,9 - 2,0 kg (100 g)		• Mix the ingredients and spread on the chicken.
Roast Chicken				Low rack		•	Pierce the skin of the chicken.
						• Put chicken breast side down in a flan dish.
						• Place on the low rack and cook.
	Ingredients for 1,2 kg Roast chicken:					• When audible signals sound, turn over.
						•	After cooking, let the food stand for approx. 3
	Salt and Pepper, 1 tsp sweet paprika, 2 tbsp oil
							min in the oven, remove and put on a plate for
							serving.
AC-3				0,6 - 2,0 kg (100 g)		• Lean pork is recommended.
Roast Pork				Low rack		• Mix all ingredients and spread them onto the
							pork.
	Ingredients for 1 kg rolled lean pork:					• Place the pork in a flan dish and cook.
	1 garlic clove, crushed, 2 tbsp oil, 1 tbsp sweet					• When audible signal sounds, turn over.
	paprika, a little cumin powder, 1 tsp salt					• After cooking, let the food stand wrapped in
							aluminium foil for approx. 10 minutes.
AC-4				0,5 - 2,0 kg (100 g)		•	See recipes for “Gratin” on page 31.
Gratin				Gratin dish		* Total weight of allingredients.
				Low rack
AC-5				0,5 - 1,5 kg (100 g)		•	Prepare the cake referring to page 32-33.
Cake				Baking tin, Saucer		• Put a saucer upside down on the low rack and
				Low rack			place the baking tin on it.
						•	Let the cake stand for approximately 10 min after
							baking.
						• Remove the cake from the baking tin.

Important: Chilledfoods arecooked from5 oC, frozen foodsare cookedfrom-18oC.

Programme charts	29

Auto cook from frozen chart

Menu No.		Weight (increasing	Procedure
		unit) / Utensils
ACF-1 Cook		0,3 - 1,0 kg* (100 g)	• Transfer meal to suitable microwave proof dish.
Frozen Ready Meals		Bowl & lid	• Cover with a lid.
(Stirrable)			• Cook without cover if manufacturer instructs.
			• When the audible signal sounds, stir and re-cover.
			• After cooking, stir and stand for approx. 2 min.
ACF-2 Cook		0,1 - 0,8 kg (100 g)	• Add 1tbsp water per 100 g and salt as desired.
Frozen Vegetables		Bowl & lid	(For mushrooms no additional water is necessary.)
			• Cover with a lid.
			• When audible signal sounds, stir and re-cover.
			• After cooking, let stand for approx. 2 min.
			NOTE: If frozen vegetables are compacted
			together, cook manually.
ACF-3 Cook		0,2 - 0,6 kg (100 g)	• Remove the gratin from package. If the
Frozen Gratin		Shallow, oval gratin dish	container is not suitable for microwave ovens,
		and microwave cling film or	transfer gratin to a suitable microwave proof
		original container and	dish.
		microwave cling film	• Cover with microwave cling film.

•If the container is suitable for microwave ovens, remove original paper cover and cover with microwave cling film.

•After cooking, let stand for approx. 5 min.

ACF-4 Cook	0,20 - 0,40 kg (50 g)	• Place the frozenfrench fried potatoes in a flan
Frozen French Fried	Flan dish	dish.
Potato	High rack	• Place the dish on the high rack and cook.
(Oven chips)		• When the audible signal sounds, turn over.
		• After cooking, remove from the dish and put on a
		plate for serving. (No standing time necessary.)
		IMPORTANT: For thin type of French fried
		potatoes, cook with the LESS ( ▼ )
		button. The dish gets very hot during
		cooking. To avoid burning yourself,
		please use oven gloves to remove the
		flan dish from the oven.

Important: Chilled foods arecookedfrom 5oC, frozen foods are cooked from 18- oC.

30 Programme charts

Auto defrost chart

Menu No.	Weight (increasing	Procedure
	unit) / Utensils
AD-1 Defrost	0,2 - 1,0 kg (100 g)	• Place the food in a flan dish in the centre of the
Steaks, Chops	Flan Dish	turntable.
	(See note on page 31.)	• When the audible signal sounds, turn the food
		over, rearrange and separate. Shield thin parts and
		warm spots with aluminium foil.

•After defrosting, wrap in aluminium foil for 10-15 min, until thoroughly defrosted.

AD-2 Defrost	0,6 - 2,0 kg (100 g)	• Place the meat in a flan dish in the centre of the
Meat Joint	Flan Dish	turntable.
	(See note on page 31.)	• When the audible signal sounds, turn the food
		over. Shield the defrosted parts with aluminium foil.
		• If audible signal sounds, turn the food over and
		shield again.
		• After defrosting, wrap in aluminium foil and stand
		for 15-30 min, until thoroughly defrosted.

AD-3 Defrost	0,2 - 1,0 kg (100 g)	• Place the block of minced meat in a flan dish in
Minced Meat	Flan dish	the centre of the oven.
	(See note on page 31.)	• When the audible signalsounds, turn the food over.
		Remove the defrosted parts if possible.

•After defrosting, cover in aluminium foil and stand for 5-10 min, until thoroughly defrosted.

AD-4 Defrost	0,20 - 1,00 kg (50 g)	• Place the food in a flan dish in the centre of the
Chicken Legs	Flan Dish	turntable.
	(See note on page 31.)	• When the audible signal sounds, turn the food
		over, rearrange and separate. Shield thin parts and
		warm spots with aluminium foil.

•After defrosting, cover with aluminium foil and stand for 10-15 min, until thoroughly defrosted.

AD-5 Defrost		0,9 - 2,0 kg (100 g)	• Place poultry in a flan dish in the centre of the
Poultry		Flan Dish	turntable.
		(See note on page 31.)	• When audible signal sounds, turnover and shield
			thin parts and warm spots with small pieces of
			aluminium foil.

•After defrosting, rinse with cold water, cover with aluminium foil and stand for 15-30 min until thoroughly defrosted.

•Finally clean the poultry under running water.

AD-6 Defrost	0,1 - 1,4 kg (100 g)	• Remove all packaging fromthe cake.
Cake	Plate	• Place directly on the turntable, or on a plate in
		the middle of the turntable.
		• After defrosting, cut the cake into similar sized
		pieces keeping space between each piece and let
		stand for 15-30 min, until thoroughly defrosted.
AD-7 Defrost	0,1 - 1,0 kg (100 g)	• Distribute on a flan dish in the centre of the
Bread	Plate	turntable. For 1,0 kg distribute directly on the
	(Only sliced bread is	turntable.
	recommended for this	• When the audible signal sounds turn over,
	programme.)	rearrange, and remove defrosted slices.
		• After defrosting cover in aluminium foil and stand
		for 5-10 min, until thoroughly defrosted.

Important: Chilled foods arecookedfrom 5oC, frozen foods are cooked from 18- oC.
