ITEM #
MODEL #
EMPower
Mixed (1/3 Ribbed) Gas Griddle
Top - 48"
EMPower
Mixed (1/3 Ribbed) Gas Griddle Top - 48"
169118 (ARG48FR)EMPower Restaurant Range
griddle, 48" wide, gas,
104,000 BTU, 1/3 ribbed top,
4" adjustable, removable
legs
NAME #
SIS #
AIA #
Main Features
•Four individually controlled high efficiency 7 ,6 kW
burners.
•Thick 25 mm highly polished mild steel griddle plate
maintains selected temperatures and assures quick
recovery.
•Stainless steel grease trough, one piece rolled front.
•Two large 3.8 lt removable grease collector drawers.
•Insulated cooktop to conserve energy .
•Flame failure device to protect against accidental
extinguishing of the flame.
•All major compartments located in front of unit for ease
of maintenance.
•Front, side and rear panels in Stainless Steel with Scotch
Brite finish.
•Right-angled side edges to allow flush fitting joints
between units, eliminating gaps and possible dirt traps.
•Kit for installation of top units to neutral bases and
cupboards provided as standard.
•Included Accessories: propane converter kit, pressure
regulator.
•In compliance with ETL Certification (UL & NSF).
•Configured for Natural Gas, LP Conversion Kit Included.
Construction
•4 screws to install on the cupboard base are supplied
with the unit.
•Gas pressure regulator is supplied with the unit.
Short Form Specification
Item No.
EMPower unit to be Electrolux Compact Line Ribbed Gas Griddle
Top with four individually controlled high efficiency 26,000 BTU (7 ,6
kW) burners. Suitable for natural gas or propane. Thick 1" (25 mm)
highly polished mild steel griddle plate maintains selected
tEMPowerperatures and assures quick recovery . Stainless steel
grease trough, one piece rolled front. Two large 1 gal. (3.8 lt)
removable grease collector drawers. Insulated cooktop to conserve
energy. Front, side and top panels of EMPower unit in Stainless steel
with Scotch Brite finish. EMPower unit has right-angled side edges
to allow flush-fitting junction between EMPower units.
In North America, products are covered by Electrolux Platinum
Star Service Program two-year parts and one-year labor warr anty,
installation start-up and performance check-up after one year from
installation.
APPROV AL:
Optional Accessories
•Scraper for smooth griddlePNC 164255
•EMPower 4 pins kit for mounting unit
to refrigerated/freezer. 1 kit is
supplied with each EMPower
refrigerated base
•EMPower extension gas pipe for 48
" griddle
•EMPower back mounted rear shelf-
spacer, 48"unit
•Portioning Shelf 12" PNC 169173
•Portioning Shelf 16" PNC 16917 4
•Portioning Shelf 24" PNC 169175
•Portioning Shelf 36" PNC 169176
•Portioning Shelf 48" PNC 169177
•Scraper for ribbed griddlePNC 206420
❑
PNC 169048
❑
PNC 169049
❑
PNC 169100
❑
❑
❑
❑
❑
❑
❑
Mixed (1/3 Ribbed) Gas Griddle Top - 48"
EMPower
Electrolux Professional, Inc.
10200 David T aylor Drive, Charlotte, NC 28262 • Telephone Number: 866-449-4200 • Fax Number: 704-547-7401
www.electroluxusa.com/professional
EMPower
Mixed (1/3 Ribbed) Gas Griddle Top
- 48"
Front
Gas
Gas Power:
169118 (ARG48FR)104000 Btu/hr (30.4 kW)
Gas Type Option:Propane
Gas Inlet:3/4"
Key Information:
External dimensions, Width:48 1/32" (1220 mm)
External dimensions, Depth:31 1/2" (800 mm)
External dimensions, Height:16 1/2" (419 mm)
Net weight:313 lbs (142 kg)
Shipping width:35 7 /16" (900 mm)
Shipping depth:50 " (1270 mm)
Shipping height:27 1/16" (688 mm)
Top
Shipping weight:348 lbs (158 kg)
Shipping volume:27.77 ft³ (0.79 m³)
If appliance is set up or next to or against temperature
sensitive furniture or similar, a safety gap of
approximately 150 mm should be maintained or some
form of heat insulation fitted.
EQ=Equipotential screw
G=Gas connection
Side
Mixed (1/3 Ribbed) Gas Griddle Top - 48"
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
EMPower
2016.07 .21
