progressiv HDc
nano
Full HD Sat Receiver
User’s Guide
Page 2
Contents
.................................................................................................................................................................................1
► Important safety instructions................................................................................................................................ 4
► Description........................................................................................................................................................... 7
Switching off ........................................................................................................................................................7
Language Selection............................................................................................................................................. 8
► Features...............................................................................................................................................................8
► Information bar (InfoBar)......................................................................................................................................9
How to change the time for fading in the information bar:................................................................................... 9
Functions and settings: ....................................................................................................................................... 9
► EDIVISION - Your electronic program guide ..................................................................................................... 10
► Program list........................................................................................................................................................13
How to change the fading time of the information bar:...................................................................................... 13
► Menu program ...................................................................................................................................................15
Edit channel....................................................................................................................................................... 15
How to move a channel:.................................................................................................................................... 16
How to lock a channel: ......................................................................................................................................16
How to unlock a channel: .................................................................................................................................. 16
How to delete a channel:................................................................................................................................... 16
How to name a channel:.................................................................................................................................... 17
Skip channel...................................................................................................................................................... 17
How to select a channel to be skipped:............................................................................................................. 17
Edit favourites....................................................................................................................................................18
How to add a channel to a favourite list: ........................................................................................................... 19
How to remove a channel from a favourite list: ................................................................................................. 19
How to move a channel in a favourite list:......................................................................................................... 19
How to name a favourite list: .............................................................................................................................20
► Menu Conditional............................................................................................................................................... 21
Other settings ....................................................................................................................................................21
► Menu installation................................................................................................................................................ 23
Satellite installation............................................................................................................................................ 23
Auto installation .................................................................................................................................................25
Satellite guide....................................................................................................................................................25
► Menu system settings ........................................................................................................................................26
Languages......................................................................................................................................................... 26
Functions and settings in the menu:..................................................................................................................26
Minors protection...............................................................................................................................................27
Time setting .......................................................................................................................................................27
Timer ................................................................................................................................................................. 28
Audio + Video ....................................................................................................................................................29
► Menu system ..................................................................................................................................................... 30
Page 3
Information.........................................................................................................................................................30
Factory setting...................................................................................................................................................30
► Menu/Media/File List..........................................................................................................................................31
► Menu/Media/Memory Information ......................................................................................................................32
► Menu/Internet/Ethernet Settings........................................................................................................................33
► Setting up WLAN (Optional with external USB-WIFI STICK) ............................................................................ 34
► Menu/Miscellaneous/Software Update ..............................................................................................................35
Http Upgrade .....................................................................................................................................................35
Auto Upgrade ....................................................................................................................................................35
Update from USB/HDD......................................................................................................................................35
Backup to USB/HDD ......................................................................................................................................... 36
► Menu/Applications ............................................................................................................................................. 37
Weather Forecast.............................................................................................................................................. 37
RSS Reader ...................................................................................................................................................... 38
Page 4
► Important safety instructions
1) Please read these instructions carefully.
2)
Keep these instructions in a safe place for future reference.
3)
Pay extra attention to "warning" points.
4)
Follow all instructions.
5)
Do not use the device near water.
6)
Clean with a dry cloth only.
7)
Do not use near heat sources, such as radiators, heat accumulators, ovens or other devices (including
amplifiers) generating heat.
8)
Only operate this product with the type of power source indicated on the label. If you are unsure about the
type of power supply you use at home, ask your electricity supplier. Disconnect the device from the mains
before maintenance or installation procedure.
9)
Protect the mains cable from damage.
10)
Only use auxiliary devices/accessories specified by the manufacturer.
11)
Disconnect the device during thunderstorms or extended periods of non-use.
12)
All maintenance work should be carried out by qualified service personnel. Maintenance is required when
the device is damaged in any way, including damage to the mains cable or mains plug. Also in case the
device becomes exposed to liquids or moisture, was dropped or does not function properly.
13)
Make sure that the ventilation slots are always unobstructed.
14)
Attention should be paid to the environmental aspect of battery disposal.
15)
Only use the device in moderate climate.
WARNING: In order to avoid the risk of fire or electric shock, do not expose this device to rain or moisture.
WARNING: The batteries should not be exposed to excessive heat and heat sources such as direct sunlight, fire,
etc.
Page 5
This symbol indicates that there is risk of electric shock.
This symbol indicates that the operating instructions contain important operating and maintenance
information.
This symbol indicates that the product has a double insulation between voltage and user accessible parts.
Only use parts provided by the manufacturer during repair.
This symbol on the product or in the operating instructions indicates that the electrical or electronic device
must be disposed of separately from household waste at the end of the service life. Separate collection systems
exist for recycling.
For further information, please contact your local authorities or your dealer where you purchased the product.
Page 6
Remote control
WebTV
...
WebT V
On/Off button.
Mute On/Off.
Changes the screen TV standard.
Safe USB Removal
Displays the satellite lists.
Displays the favourite lists.
To search for programs in lists.
Scrolls up (+) or down (-) in
lists of channel lists.
Displays the main menu.
Displays the information bar.
Use the arrow buttons to scroll up
in lists. Below, scroll left or right or
menu inputs with the OK button
or call up the channel list.
Exits a Menu/Dialogue window
Selection of the electronic program
guide EDIVISION.
Selection of TV/Radio program.
Input of numbers or letters in
the menus.
Returns to the previous program.
Toggles between TV and Radio mode.
Allows fast backward.
Allows fast forward.
Skips to the beginning or previous
Recording/Image.
Skips to the beginning or previous
Recording/Image.
Starts recording manually.
Starts Playback/Pauses playback.
Finishes TimeShift, a recording
or a playback.
Allows you to set the time at which the Receiver
autom. switches to standby mode.
Calls up the Audio menu.
Option button.
Calls up the Subtitle/Teletext menu.
Web TV button.
Page 7
Description
Front
① /USB: Connection for USB1 memory
devices.
3
/USB: Connection for USB1 memory
devices.
②
Infrared sensor for the reception of remote
control commands.
Back
④ LNB IN: Connection for the coaxial cable to
the signal from the satellite system.
⑤ HD OUT : Connection to an HDTV quality TV.
⑥ IR IN: Infrared connection
⑦ AV OUT: For broadcasting video and sound
signals.
⑧ Connection for an adapter (DC 12V/2A)
Connecting and switching on
Note: For interference-free satellite TV
reception, a specialist technician must
calibrate your satellite TV system with a
digital TV level meter.
• Connect the receiver using HDMI cable
from the HD OUT output to your TV HDMI
input.
• Now connect the receiver to the satellite
antenna cable via the LNB IN input.
• Insert the batteries into the remote
control, with respect to polarity.
• Connect the receiver to the power
sup
ply.
• The receiver starts with the BOOT
process and is operational within a short
time.
Switching off
By pressing the Power button once on your remote control, a pop-up window opens.
You can choose any of these two types of Stand-by mode, according to your preferences. When pressing
and holding the Power button of your remote control for more than 2 sec., the device goes into OFF
mode. For mo
re settings please refer to page 21
DC-12VAVHD OUT
LNB IN 13/18V
400mA Max
IR
1
HDMI in
2
HDmi
kabel
HDMI
kabel
Antenna cable
Power socket
HD OUT: Output receiver
HDMI cable
TV set connection panel
Use an HDMI input!
LNB IN:
Connecting
the cable to the satellite
signal
USB1USB2
progressiv HD c
3
1
2
DC-12VAVHD OUT
LNB IN 13/18V
400mA Max
IR
4 5 6 7 8
Page 8
Language Selection.
Features
- Full HD Receiver for DVB-S/S2 satellite reception
- 720p, 1080i,1080p
- DiSEqC 1.2, 13/18V, 0/22K, LNB control
- 6000 TV and Radio program channels
- Station and favourites lists
- EDIVISION electronic program guide
- Easy-to-use menu system
- Manual/automatic channel search
- 1 x HD OUT Video/Audio output
- 2 x USB Port, USB Wi-Fi, USB 3G
- Software update possible via USB
- Software update possible via HTTP
Page 9
► Information bar (InfoBar)
When in the TV/Radio mode, the 'INFO' button displays an information bar (InfoBar) at the lower edge
of the screen. This bar is faded-in up to 10 seconds.
How to change the duration of fading of the information bar:
1. Press the 'MENU' button to open the main menu.
2. Use the left/right arrow buttons to navigate to the 'System' item.
3. Use the up/down arrow buttons to navigate to the 'Other settings' menu item and press the OK
button.
4. Use the left/right arrow buttons to select the value in seconds you want to set (max. 10s) in the
'OSD time exceeded' item.
5. Press the EXIT button to exit the menu.
The InfoBar in TV or Radio mode shows the following information about the current program and
selected station:
- the place in the program list
- the name of the station
- the current program (as far as information is available) including start time
- the following program (as far as information is available) including start time
- the name of the favourite list
- the time
- indicates the availability of Teletext for the current program
- indicates if the transmitted program is encrypted
- indicates if subtitles are available
- indicates if the sound broadcasted is in stereo or mono format, left or right balance
- indicates if the program is blocked (child protection)
- indicates that the station is present in a favourite list
- indicates if the program is transmitted in HD
- indicates if Wi-Fi network connection exists
Functions and settings:
If the InfoBar is displayed, detailed information about the current program can be displayed (if
available) by (repeated) pressing the 'INFO' button. If multiple information pages are available, scroll
through these pages by using the 'PAGE+'/'PAGE-' buttons. Use the left/right arrow buttons to
switch between the information of the current and next program. Use the red button to display further
(technical) information. Use the EXIT button to exit the menu with the detailed information.
Use the EXIT button again to switch off the InfoBar.
Page 10
► EDIVISION - Your electronic program guide
Standard: EDIVISION is an electronic program guide with its own OSD menu. EDIVISION presents
the information provided by the service provider in detailed views. In addition, up to 8 time-controlled
recordings (Timer) can be programmed from here. Note that not all channels/program providers
provide program-related information.
Use the EDIVISION button on the remote control to start your program guide.
Functions and settings:
The window of 'EDIVISION' is structured differently, depending on in which mode you are. The mode
(now, next, more, timetable) can be changed with the green button.
Information can be found at the top left in the modes 'Now' and 'Next' on the current or next program
and on the channel in text format, at the top right, the current TV picture (in TV mode). In the lower
area, the current program list can be found which can be navigated with the up/down arrow buttons
and another channel can be chosen with the OK button. If the channel provides program-related
information, it will be displayed in the list (e.g. duration of the program in form of bars, program title).
Press the OK button to display detailed information about the program, if available. Use the left/right
arrow buttons to switch between 'Now' and 'Next EDIVISION modes.
Page 11
The 'More' mode displays program information in chart form and chronological order. Use the left/right
arrow buttons to navigate between a channel's temporal program information and use the up/down
arrow buttons to move the cursor (yellow marking) in the channel list. The OK button may possibly
has to be pressed if another channel was selected and the program-related information should be
displayed (if available). If the cursor is located on the right-hand side of a program title, detailed
information about this program can be displayed by pressing the OK button .
The 'Timetable' mode displays the currently selected program list in chart form on the left and program
information in weekly format on the right. Use the left/right arrow buttons
EDIVISION window in 'Timetable' mode
To navigate between the channel list and the PREV/NEXT buttons to navigate daily overview.
Page 12
Use the up/down arrow buttons to navigate between the weekdays in the respective list. If the cursor
is located on the right-hand column side of a program title, even more detailed information about this
program can be displayed (if available) by pressing the OK button .
The following functions and buttons can be used in all modes:
The red button displays an overview of the existing channel lists (groups). Use the arrow buttons to
navigate through this overview and the OK button to set the channel list to be used by EDIVISION.
The green button calls up a menu allowing to switch between the different views of EDIVISION by
using the up/down arrow buttons and the OK button.
The yellow button calls up a Popup Timer Menu. Select the 'VCR' item to program time-based events
(e.g. recordings). Select the item Timer List to see the programmed events.
If you want to make a recording on a certain date in the future, select the item 'USB/HDD Recorder'.
Use the up/down arrow buttons in the following window to navigate between the menu items and the
left/right arrow buttons and OK button to set the values. The following settings can be made in the
menu 'Timer'.
Timer number: Calling up the timer menu automatically switches to the next (available) programmable
timer. Use the left/right arrow buttons the OK button and the up/down arrow buttons to switch between
timers. Up to 8 different events can be programmed.
Timer mode: Set the recording mode here. Choose whether the recording is carried out once,
daily, weekly or monthly.
Timer service: Set the service entry 'Recording TV channel' here for a TV recording and 'Recording
Radio channel' for a radio recording.
Station: Set the channel here.
Date: Set the start date of the recording here.
Start time: Set the start time here.
Duration: Set the duration of the recording here (recording length).
After making changes and in order to keep them, confirm with 'Yes' in the appearing dialogue window.
Exit the timer menu with the EXIT button.
Note: An error message appears under certain circumstances. As a rule, an incorrect start time or start
date was given. Check the information!
Also note that a recording is only possible if a corresponding USB memory device is already connected
to the receiver.
Exit 'EDIVISION' by pressing the EXIT button.
Loading...
