Page 1
GE
Sensing
g
PTX/PDCR 1280/
1880 Series
Druck Submersible
Depth/Level Pressure
Transmitters/Transducers
Features
PTX/PDCR 1280/1880 is a Druck
product. Druck has joined other
GE high-technology sensing
businesses under a new name
__
GE Industrial, Sensing.
• All-welded titanium construction backed by five-year
corrosion warranty
• Accuracy:
_
1880: < ±0.1% full scale (FS) best fit straight line (BSL)
_
1280: < ±0.25% FS BSL
• Ideally suited for underground fuel tanks
• FM, CSA intrinsically safe, CE marked
• Flouropolymer
TM
cable
The PTX/PDCR 1280/1880 Series submersible/depth
pressure transducers are specifically designed for
depth/level measurements in the groundwater, well
water, canals, rivers and other similar applications. The
all-titanium construction ensures excellent life in the most
hostile environments, including corrosive and hazardous
chemical applications. GE backs its titanium construction
with a five year corrosion warranty. standard vented
cable is flouropolymer. Polyurethane cable is available on
the Series 1230 or 1830.
The PTX/PDCR 1280/1880 Series sensors are ideal for use
in applications where smaller size is an advantage, such
as municipal water supply wells, leachate wells, irrigation
projects, etc. The titanium construction also makes the
devices suitable for seawater and chemical tank
measurement applications.
An advanced micromachined silicon piezoresistive
pressure sensor provides excellent performance and
resistance to shock and vibration. A tough, flouropolymer
cable is attached to the transducer body, providing a
high integrity, waterproof assembly. The cable is
strengthened with Kevlar
®
so that there is no measurable
elongation when the cable is lowered into deep wells.
The fully isolated, all titanium design ensures long term
reliable measurements in water and wastewater
management, industrial, process and marine
applications.
Page 2
PTX/PDCR
1280/1880
Specifications
General
Standard Operating Ranges
• 1, 2.5 psi (0.75, 1.5 mH2O) gauge
• 5, 10, 15, 20, 30, 50, 75, 100, 150, 200, 300, 500,
900 psi (3.5, 7, 10, 15, 20, 35, 50, 70, 100, 150, 200, 350,
600 mH2O) gauge or absolute
Other ranges and pressure units may be specified.
Overpressure
• 10X for range 1 psig (0.75 mH
2
O)
• 8X for 2.5 psi (1.5 mH2O)
• 6X for 5 psi (1.5 to 3.5mH
2
O)
• 4X for ranges above 5 psi (3.5 mH2O)
• 2000 psi (1400 mH
2
O) maximum
Pressure Media
Fluids compatible with titanium and Flouropolymer
Transduction Principal
Piezoresistive micromachined silicon strain gauge
Combined Error (Non-Linearity, Hysteresis and
Repeatability)
Series 1880
±0.1% FS BSL; ±0.06% FS BSL available (consult factory)
Series 1280
±0.25% FS BSL
Temperature Effects Over Compensated Range of
30°F to 86°F (-1°C to 30°C)
Series 1880
±0.3% FS TEB; ±0.6% for ranges below 5 psi (3.5 mH
2
O)
Series 1280
±1% FS TEB; ±2% FS for ranges below 5 psi (3.5 mH
2
O)
Resolution
Infinite
Insulation Resistance
100 MS @ 50 VDC
Relative Humidity
0 to 100%
Compensated Temperature Range
30 to 86°F (-2°C to 30°C)
Operating Temperature Range
-5°F to 140°F (-20°C to 60°C)
Electrical Characteristics
Output
PDCR 1880/1280 Series
• 2.5 mV/V for range 1 psi (0.75 mH2O)
• 5 mV/V for range 2.5 psi (1.5 and 3.5 mH2O)
• 10 mV/V for ranges 10 psi and above (7 mH2O)
PTX 1880/1280 Series
Two-wire, 4 to 20 mA
Output is ratiometric to power supply (2.5 VDC minimum)
Installation Drawings
Electrical Connection
Vented polyurethans cable
Red
_
Positive supply
White
_
Negative supply
Yellow
_
Positive output
Blue
_
Negative output
Shield
_
connected to case
Any other conductors not connected.
Optional monitor leads: Orange and Black.
Electrical Connection
Vented polyurethane cable
Red
_
Positive supply
Black
_
Negative supply
Shield
_
connected to case
Any other conductors not connected.
7.8 in (198 mm) approximately
Length to order
0.224 in
(5.69 mm)
nominal
M 14 x 1.5 (38 mm) exposed
thread with nose cone removed
PDCR 1280
PTX 1280
Ø 0.69 in
(17.5 mm)
3.8 in (96.5 mm)
approximately
Length to order
0.224 in
(5.69 mm)
nominal
M 14 x 1.5 (38 mm) exposed
thread with nose cone removed
Ø 0.69 in
(17.5 mm)
GE
Sensing
Page 3
PTX/PDCR
1280/1880
Specifications
Mechanical Characteristics
Sensor Body
Titanium
Measurement Diaphragm
Titanium
Pressure Connection
Open face with protective titanium and flouropolymer
Electrical Connection
Vented flouropolymer cable (specify length)
Diameter
0.69 inches (17.5 mm)
Weight
5 oz (142 g) nominally (excluding cable)
Compatible Fluids
Any fluid compatible with titanium and flouropolymer
Safety
• FM, CSA Intrinsically safe
• Class I, Division 1, Groups A,B,C,&D
• EMC Emmissions EN50081-1
• EMC Immunity EN50082-2
• Certification CE marked
Ingress Protection
Type 6/IP68
Options
• Sink-weight (P/N: DA2608-1-01)
• Monitor leads (PDCR version only)
• FM, CSA or ATEX intrinsically safe certification
• ABS certification
• Threaded pressure port (welded)
_
1/4 in NPT male
_
1/8 in NPT male
_
7/16 UNF male
_
G 1/4 male
_
G 1/8 male
Accessories
• STE 110 terminal enclosure with desiccant and
waterproof vent
• SCU 220 terminal enclosure with desiccant and
waterproof vent with 4-20mA signal conditioning
(for all millivolt sensors)
• Cable clamp (P/N: 192-373-01)
• Two-wire lightning arrestor (P/N TAS 140-1);
Four-wire lightning arrestor (P/N: TAS 140-4)
• Descaling kit (P/N: DA2906-1-01)
• DPI 280 digital indicator
• DPI 610 portable field calibrator (specify range)
Ordering Information
Please State the Following:
(1) Type number
(2) Pressure range
(3) Cable length
(4) Options required
For non-standard requirements please specify in detail.
Shipping, Storage and Handling
Each transmitter is purged with clean dry nitrogen and
shipped with desiccant to prevent moisture ingress
during transit.
GE
Sensing
Page 4
g
©2008 GE. All rights reserved.
920-119B
All specifications are subject to change for product improvement without notice.
GE
®
is a registered trademark of General Electric Co. Other company or product
names mentioned in this document may be trademarks or registered trademarks
of their respective companies, which are not affiliated with GE.
GE
Sensing
www.gesensing.com
