Doro 7050 User Manual

Doro 7050

English (US)

3 4

5 6

14 15

1. Speaker

2. Left selection button

3. Four-way navigation keys

4. Camera shortcut

5. Call button

6. Voicemail Speed Dial

7. Microphone

8. International prefix /Symbols

9. Right selection button

10. Back key

11. OK key

12. End call / Power on/off

13. Input method/Silent

Note! All illustrations may not accurately depict the actual device.

The items supplied with your phone might vary depending on the software and accessories available in your region or offered by Consumer Cellular. You can obtain additional accessories from Consumer Cellular. The supplied accessories provide the best performance with your phone.

14. External screen

15. Green light = New message / missed call Red light = battery level low / charging

16. Camera flash and flashlight

17. Camera lens

18. Charging socket

19. Assistance button

20. Headset socket

21. Loudspeaker

22. Volume control

English (US)

Contents

Congratulations on your purchase ................................................................ 1

Getting started ............................................................................................... 1

Unbox your new phone ......................................................................... 1

Insert SIM card, memory card and the battery..................................... 2

Charge the phone................................................................................... 3

Save energy ............................................................................................ 4

Turn the phone on and off..................................................................... 5

Getting to know your phone.......................................................................... 5

External display ...................................................................................... 5

Phone indicators .................................................................................... 5

Notification panel and status bar .......................................................... 6

Descriptions in this document ............................................................... 6

Basic phone operations.......................................................................... 6

Enter text................................................................................................ 8

Calls ................................................................................................................ 9

Make a call ............................................................................................. 9

Call from the phonebook ..................................................................... 10

Receive a call ........................................................................................ 10

Call information.................................................................................... 10

Call options........................................................................................... 10

Emergency calls.................................................................................... 11

Call log .................................................................................................. 11

TTY mode.............................................................................................. 12

Contacts........................................................................................................ 13

Add contact .......................................................................................... 13

Manage phonebook contacts .............................................................. 13

Phonebook settings.............................................................................. 14

ICE (In Case of Emergency) .................................................................. 16

Assistance button......................................................................................... 17

Make an assistance call........................................................................ 17

Activation ............................................................................................. 17

Number ................................................................................................ 18

Messages...................................................................................................... 18

Create and send text message (SMS)/picture message (MMS).......... 18

Read and respond to messages ........................................................... 19

Wireless Emergency Alerts .................................................................. 20

English (US)

Message settings.................................................................................. 20

Camera ......................................................................................................... 22

Media ........................................................................................................... 22

Video .................................................................................................... 22

Recorder............................................................................................... 23

Gallery .................................................................................................. 23

Organizer...................................................................................................... 24

Alarm .................................................................................................... 24

Calendar ............................................................................................... 24

Calculator ............................................................................................. 25

Note...................................................................................................... 25

File manager......................................................................................... 26

FM Radio ...................................................................................................... 26

Connect the phone to a computer .............................................................. 27

Settings......................................................................................................... 28

Personalization..................................................................................... 28

Network & connectivity ....................................................................... 32

Call settings .......................................................................................... 37

Privacy & security................................................................................. 39

Assistance............................................................................................. 41

Storage ................................................................................................. 41

Device................................................................................................... 42

Additional functions ..................................................................................... 43

Display status symbols ......................................................................... 43

Display main symbols........................................................................... 44

Troubleshooting ........................................................................................... 44

Safety instructions........................................................................................ 46

Network services and costs ................................................................. 46

Operating environment ....................................................................... 46

Medical units........................................................................................ 46

Areas with explosion risk ..................................................................... 47

Protect your hearing ............................................................................ 47

Emergency calls.................................................................................... 47

Vehicles ................................................................................................ 47

Driving safely ........................................................................................ 48

Hearing aid compatibility ..................................................................... 49

TTY compatibility.................................................................................. 49

RF exposure information (SAR)............................................................ 49

English (US)

Disclaimer and Limitation of Liability .......................................................... 50

FCC notice..................................................................................................... 51

Care and maintenance ................................................................................. 51

Battery disposal and recycling information................................................. 52

Warranty ...................................................................................................... 53

Content copyright ................................................................................ 54

Support......................................................................................................... 55

Specifications ............................................................................................... 55

English (US)

Congratulations on your purchase

The Doro 7050 makes calling, messaging and sending photos or video messages all very easy thanks to widely separated, high contrast keys and a large 2.8 inch screen. It also has an assistance button for added safety. For more information about accessories or other Consumer Cellular products please visit ConsumerCellular.com/Products.

Getting started

When you first receive your phone, you will need to set it up before using it.

Tip: Remember to remove the plastic screen protector.

Unbox your new phone

The first step is to unbox the phone and assess the items and equipment included in the delivery. Make sure to read through the manual so you can familiarize yourself with the equipment and the basic functions.

• The items supplied with the device and any available accessories may

vary depending on the region.

• The items supplied are designed only for this device and might not be

compatible with other devices.

• Appearances and specifications are subject to change without prior

notice.

• You can purchase additional accessories from Consumer Cellular.

• Make sure accessories are compatible with the device before

purchase.

• Only use batteries, chargers and accessories that have been approved

for use with this particular model. Connecting other accessories may

be dangerous and may invalidate the phone’s type approval and

warranty.

• Availability of all accessories is subject to change depending entirely

on manufacturing companies. For more information about available

accessories, refer to the Consumer Cellular website.

English (US)

Insert SIM card, memory card and the battery

The SIM card and the battery are normally pre-installed. Follow these instructions should you ever need to access them yourself. The SIM and memory card holder’s are located inside the battery compartment.

Tip: Take care not to scratch the metallic contacts on the cards when inserting them into the card holders.

Remove the battery cover

IMPORTANT!

Turn off the phone and disconnect the charger before removing the battery cover. Be careful not to damage your fingernails when you remove the battery cover. Do not bend or twist the battery cover excessively as it may get damaged.

Insert the SIM card

IMPORTANT!

Insert the micro-SIM (3FF) card by gently sliding it into the SIM card slot. Make sure that the SIM card’s contacts are facing inwards and that the cut off corner is down, as shown . Take care not to scratch or bend the contacts on the SIM card. Should you need, but have difficulty removing/replacing the SIM card, use adhesive tape on the exposed part of the SIM card to pull it out.

This device accepts a micro-SIM card or 3FF. Use of incompatible SIM cards may damage the card or the device, and may corrupt data stored on the card.

English (US)

Insert the memory card (optional):

IMPORTANT!

Use only compatible memory cards with this device. Compatible card types include microSD, microSDHC. Incompatible cards may damage the card itself, the device and corrupt any data stored on the card.

Tip: Take care not to scratch or bend the contacts on the memory or SIM card when inserting them into the card holders.

You may also optionally insert a memory card. Make sure that the memory card’s contacts are facing as shown. To remove the memory card: find the small ridge on the exposed end of the memory card. Put your fingernail into the ridge and gently pull the card out. See Storage, p.41 for additional info.

Insert the battery

Insert the battery by sliding it into the battery compartment with the contacts facing up to the right. Replace the back cover.

Charge the phone

While your phone may come partially charged so that it can be turned on right out of the box, we recommend charging the device fully before using it.

English (US)

CAUTION

Only use batteries, chargers and accessories that have been approved for use with this particular model. Using unapproved accessories may be dangerous and may invalidate the phone's type approval and warranty.

When the battery is running low, heard. When the charger is connected to the phone, briefly, and

when it is disconnected. The battery charge indicator is ani-

is displayed and a warning signal is

is displayed

mated while charging. It takes approximately 3 hours to fully charge the battery. If the phone is turned off when the charger is connected to the phone only the battery charge indicator will be shown on the display. When charging is completed,

is displayed on the screen.

Use a wall power outlet to charge

1. Connect the small head of the USB charging cable to the charging

socket y on the phone.

2. Plug the large head of the cable to the USB charger.

3. Plug the power adapter to a wall power outlet.

Use a charging cradle to charge

1. Connect the small head of the USB charging cable to the cradle. Place

the phone in the cradle.

2. Plug the large head of the cable to the power adapter.

3. Plug the power adapter to a wall power outlet.

Use a computer or other power source to charge

1. Connect the small head of the USB charging cable to the phone.

2. Plug the large head of the cable to the computer’s USB port.

Note! Generally charging is quicker if plugged directly into the wall.

If the phone is turned off during charging, the phone is still charging. Press

to view charging status.

Save energy

When the battery is fully charged, disconnect the charger from the device and unplug the charger from the wall outlet. To save power, the screen turns off after a while. Press any button to wake the screen up. Full battery capacity will not be reached until the battery has been charged 3–4 times. Batteries degrade over time, which means that call time and standby time

English (US)

will normally decrease with regular use. During extended operation, the device may feel warm. In most cases, this is normal. To avoid getting too warm, the device may switch off charging. If the device is not working properly, please contact Customer Service, see Support, p.55.

Turn the phone on and off

1. Press and hold on the phone to turn it on or off. Press Select to

Power off.

2. If the SIM card is valid but protected with a PIN code (Personal Identi-

fication Number), SIM PIN is displayed. Enter the PIN code and press

Done. Delete by pressing Clear (

Note! If PIN and PUK codes were not provided with your SIM card, please

contact Consumer Cellular.

# tries left shows the number of PIN attempts left. When no more attempts remain, SIM card is locked. is displayed. The SIM card must then be unlocked with the PUK code (Personal Unblocking Key).

1. Press Enter PUK to:

• Enter PUK code.

• Create PIN (must contain 4 to 8 digits).

• Confirm new PIN.

2. Confirm with Done.

upper right corner of keypad).

Getting to know your phone

External display

The external display shows the time, a number of status indicators, and notifications for incoming calls. The external display can only display characters in black and white. If the external display times out, press and hold any of the side keys +/– to turn it back on.

Phone indicators

There are lights on the phone lid that indicate the following:

• The green light appears when you have a new message or a missed

call.

• The red light appears when the battery is running low and during

charging.

English (US)

Notification panel and status bar

At the top of the main screen to the left you can see if there are any notifications. The number will show how many notifications you have.

• To view the notifications, press the left selection button

• Press Dismiss to close each notification.

Note! You do not delete the item itself, just the notification.

At the top of the main screen to the right you can see the status symbols, such as network signal strength, battery level, Bluetooth activity and more.

Descriptions in this document

Descriptions in this document are based on your phone’s setup at the time of purchase. Instructions normally start from the start screen. Press to reach the start screen. Some descriptions are simplified.

The arrow (

) indicates next action in step-by-step instructions.

Basic phone operations

Call :

• Dial a number or answer incoming call.

• Enter the call log.

End call/Power on and off :

• End calls or return to the start screen.

• Long press to power on or off.

Assistance :

Press to make an assistance call.

Back :

Return to the previous screen.

Camera :

Press to initiate the camera app.

English (US)

Selection buttons :

The selection buttons have multiple functions. The current function is shown above the selection button on the screen. During a call the selection buttons give access to additional functions.

Navigation keys

• (A) Use the Four-way navigation keys to nav-

igate up, down, left and right.

• (B) Use the OK to open the

confirm actions.

Menu and to

Standby (idle mode)

When the phone is ready to use, and you have not keyed in any characters, the phone is in standby.

• Press

• Press left selection button

right selection button

to open the

Tip: You can always press

to return to standby mode.

( ) to access the notifications, the

( ) to access your saved contacts and OK

Menu.

to return to standby.

Quick settings

From the standby screen, press to reach some useful functions such as

Flashlight, Bluetooth or Vibrate.

Note! The flashlight drains the battery very quickly. Remember to turn off

the flashlight after you are done using it.

Volume keys + / –

• During a call the volume keys adjusts the call volume.

CAUTION

Press Options to Enable boost volume or Disable boost volume. Enable boost volume can be very loud, so please use the feature

with caution.

English (US)

• From standby you can set your device to vibrate mode: press and hold

until the device vibrates and

See also Volume, p.28 for more information.

Note! If you use a hearing aid or have hearing difficulties when using the telephone in a noisy environment, you can adjust the phone's audio settings, see Audio setup, p.28.

Vibrate

Vibrate is a fixed profile with Keypad tone, Message tone and Ringtones disabled, while calendar events and Alarm are unchanged.

• Press and hold the shortcut button#to activate or deactivate vibrate

mode.

Headset

When a headset is connected, the internal microphone in the phone is automatically disconnected. If available, use the answer key on the headset to answer and end calls.

CAUTION

Using a headset at high volume may damage your hearing. Adjust the volume level carefully when using a headset.

appears.

Enter text

Enter text manually

Select character

• Press a numerical key repeatedly until the desired character is shown.

Wait a few seconds before entering the next character. Press Clear to

erase characters.

Special characters

1. Press*for a list of special characters.

2. Select the desired character using the Four-way navigation keys and

press Select to enter it.

Move the cursor within text

• Use the Four-way navigation keys to move the cursor within the text

English (US)

Upper case, lower case, numerals and predictive text

• Press#to choose between upper case, lower case, numerals and

predictive text. See Input mode, p.9.

Change writing language

• Press and hold#to change language. See Writing language, p.31.

Enter text with predictive text

In some languages you can use predictive text input method which uses a dictionary to suggest words.

• Press each key once, even if the displayed character is not the one

you want. The dictionary will suggest words based on the keys you

have pressed.

Example

1. Press3,7,3,3to write the word “Fred”. Complete the word be-

fore looking at the suggestions.

2. Use the Four-way navigation keys to move the cursor to view the sug-

gested words.

3. Press OK and continue with the next word.

Alternatively, press0to continue with the next word.

4. If none of the suggested words are correct, use manual input mode.

Note! See Writing language, p.31 and Input methods, p.32 for more information.

Input mode

• Press#to change input mode. The icon on the top left of the display

indicates the input mode.

Predictive text

Abc

ABC

abc

123 Numerals

Sentence case UPPER CASE lower case

Calls

Make a call

1. Enter the phone number including the area code. Delete with Clear.

English (US)

2. Press to make a call.

3. Press

Tip: For international calls, always use + before the country code for best results. Press*twice for the international prefix +.

to end the call.

Call from the phonebook

1. Press Contacts to open the phonebook.

2. Use

by pressing the key corresponding to the first letter of the entry.

3. Press Options

number.

Alternatively, press

4. Press

/ to scroll through the phonebook, or to do a quick search

Call to dial the selected entry. If needed, select the

to dial.

to cancel the call.

Receive a call

1. Open the phone to answer.

Tip: Press and hold +/– to temporarily switch off the ringer without

opening the phone.

To reject an incoming call by opening the phone, see Answer mode,

p.37.

Press

2. Press

/close the phone to reject a call.

to end the call.

Call information

During a call, the outgoing or incoming phone number and the elapsed call time is displayed. If the identity of the caller is withheld, Unknown is displayed.

Call options

During a call the selection buttons1( ) give access to additional functions.

1. Selection buttons have multiple functions. The current function is shown

above the selection button on the display.

English (US)

Mute

Press Mute to disable the microphone. Press Unmute to re-enable the microphone.

Options

• Enable boost volume / Disable boost volume. Enable boost volume

can be very loud, so be careful when using this feature.

• Enable speaker to activate loudspeaker mode. Speak clearly into the

phone microphone at a maximum distance of 3 feet.

Press Disable speaker to return to normal mode.

Note! Loud background noises (music, etc.) may interfere with the

sound quality.

• Add call to call another number. When the second party is connected you can Swap call and Merge call.

• Hold call/Unhold call to hold/retrieve the current call.

Note! For settings related to calling, see Call settings, p.37

Emergency calls

As long as the phone is switched on, it is possible to place an emergency call by entering the main local emergency number for your present location followed by

Some networks accept calls to emergency numbers without a valid SIM card. Contact Consumer Cellular for more information.

Call log

Received, missed and dialed calls are saved in a combined call log. For multiple calls related to the same number, only the most recent call is saved.

1. Press Alternatively, press

2. Calls are displayed as follows depending on call type:

3. Select a call and press to dial, or Options:

Menu Call log.

Incoming call

Outgoing call

Missed call

English (US)

• Call information to show details for the selected call.

• Send message to send a text message.

• Create new contact to save the number for a new contact.

• Add to existing contact to add the number for an existing con-

tact saved to the phone.

• Delete call log to delete entries in the the call log. Press Select for each entry you want to delete and confirm with

Delete.

TTY mode

TTY Mode, also known as Text Telephone, TDD or Teletypewriter for the Deaf, is designed to help people who are deaf, hard-of-hearing or speech impaired, or who have speech or language disabilities, communicate over a phone call. Your phone is compatible with TTY devices. Please check with the manufacturer of the TTY device to ensure that it supports digital wireless transmission. Your phone and the TTY device will connect using a special cable that plugs into your phone’s headset jack. If this cable was not provided with your TTY device, contact your TTY device manufacturer to purchase the connector cable.

Activate TTY

1. Press

Menu Settings Calls TTY.

2. Select your needed option:

• Off to disable all TTY settings.

• Full to enable all TTY settings.

• VCO (Voice Carry Over) to not hear but to talk.

• HCO (Hearing Carry Over) to hear but not to talk.

Start a call over TTY

When a phone uses TTY Mode, it behaves similarly to how it does when sending and receiving text messages, except it uses an actual phone call connection to transfer data.

1. Enter the phone number including the area code and press

2. Once the phone has established the connection with the other line, the TTY devices can begin communicating with each other.

Note! Both devices used in the phone call need to support TTY for the service to work.

English (US)

Contacts

Add contact

1. Press Menu Contacts New.

2. Enter First name, Last name and Mobile phone for the contact. Delete with Clear.

3. Press Options for more options.

4. Press Save.

Tip: For international calls, always use + before the country code for best results. Press*twice for the international prefix +.

Manage phonebook contacts

1. Press Menu Contacts.

2. Select a contact with Select, then press Options:

• Add as Favorite (Top 10) to set the entry as one of the first 10

contacts listed in the phonebook. See Top 10, p.14.

• Edit to edit the contact. When done, press Save.

• Share to send the selected contact as a vCard via selected

method.

• Delete to delete the selected contact. Press Delete again to

confirm.

3. Press

4. Select a contact, but don’t press Select

5. Press Options:

• Edit to edit the contact. Same as above.

• Call to call the contact.

• Send message to create a message. See Create and send text

• Share to send a contact. Same as above.

• Delete contacts to select one or multiple contacts to delete.

• Move contacts

when done.

message (SMS)/picture message (MMS), p.18.

Press Delete to confirm.

Move from:

• Phone memory

one or multiple contacts from the phone memory to the SIM card. Press Move to move.

To SIM memory to select and move

+ 43 hidden pages
