Doro 6040 User Manual
Doro 6040
English
3
4
5
6
14
20
13
11
10
7
1
8
12
9
19
21
22
23
18
17
16
2
15
24
25
The items supplied with your phone might
vary depending on the software and accessories available in your region or offered by your
service provider. You can obtain additional accessories from your local Doro dealer. The
supplied accessories provide the best performance with your phone.
1. Earpiece
2. Display
3. Left selection button
4. Call button
5. Top 10 shortcut
6. Voice mail
7.
International prefix/
*
Symbols
8. Microphone
9.
Input method/Silent
#
10. Camera shortcut
11. Message shortcut
12. End call / Power on/off
13. Arrow buttons
14. Right selection button
15. Camera flash/torch
16. Red light = Battery level low/
Charging
17. Green light = New message/
Missed call
18. Camera lens
19. Headset socket
20. Charging socket
21. Assistance button
22. Loudspeaker
23. Volume control
24. Lanyard hold (lanyard
optional)
25. Charging stand (optional)
English
Contents
Congratulations on your purchase ................................................................ 1
Get started ..................................................................................................... 1
Insert SIM card, memory card and battery ........................................... 1
Charge the phone................................................................................... 3
Get to know your phone ................................................................................ 5
Assistive functions.................................................................................. 5
Turn the phone on and off..................................................................... 5
Start-up wizard....................................................................................... 5
Phone indicators .................................................................................... 6
Navigate the phone
Enter text
Hearing aid compatible.......................................................................... 8
Phone settings........................................................................................ 9
Calls .............................................................................................................. 11
Make a call ........................................................................................... 11
Call from the phonebook ..................................................................... 11
Receive a call........................................................................................ 11
Volume control..................................................................................... 11
Call options........................................................................................... 12
SOS calls ............................................................................................... 13
Call log .................................................................................................. 13
Call settings .......................................................................................... 14
Phonebook ................................................................................................... 16
Add contact .......................................................................................... 16
Manage phonebook contacts .............................................................. 17
Phonebook settings.............................................................................. 18
ICE (In Case of Emergency)
........................................................................................ 7
........................................................................ 6
............................................................ 20
Assistance button
Make an assistance call........................................................................ 21
Activation ............................................................................................. 22
Number list........................................................................................... 22
Activate text messages (SMS) .............................................................. 23
Position SMS......................................................................................... 23
Confirm with "0" .................................................................................. 24
Signal type ............................................................................................ 24
................................................................................... 21
English
Messages...................................................................................................... 24
Create and send text message (SMS) .................................................. 24
Create and send picture message (MMS) ........................................... 25
Create and send voice message........................................................... 25
Inbox, Outbox and Sent ....................................................................... 26
Message settings.................................................................................. 27
Camera (take photos) .................................................................................. 32
Adjustments ......................................................................................... 32
Camera settings............................................................................................ 32
Image viewer................................................................................................ 33
Connectivity.................................................................................................. 34
Bluetooth
®
............................................................................................ 34
Network setup...................................................................................... 35
File manager......................................................................................... 35
Connect the phone to a computer ...................................................... 36
Sound & Display ........................................................................................... 37
Audio setup
..................................................................................... 37
Tone setup (ringtone) .......................................................................... 37
Ringtone volume
............................................................................. 38
Silent..................................................................................................... 38
Alert type.............................................................................................. 38
Extra tone............................................................................................. 38
Main menu ........................................................................................... 38
Wallpaper............................................................................................. 39
Text size
........................................................................................ 39
Idle display ........................................................................................... 39
LCD backlight........................................................................................ 39
Brightness
..................................................................................... 39
Additional functions..................................................................................... 40
Response by Doro ................................................................................ 40
Alarm .................................................................................................... 40
Organiser.............................................................................................. 40
Calculator ............................................................................................. 42
Torch..................................................................................................... 42
Display status symbols ......................................................................... 42
Display main symbols........................................................................... 43
Reset settings ....................................................................................... 44
English
Troubleshooting ........................................................................................... 44
Safety instructions........................................................................................ 46
Network services and costs ................................................................. 46
Operating environment ....................................................................... 47
Medical units........................................................................................ 47
Areas with explosion risk ..................................................................... 47
Li-Ion battery........................................................................................ 48
Protect your hearing ............................................................................ 48
Emergency calls.................................................................................... 48
GPS/Location based functions ............................................................. 48
Vehicles ................................................................................................ 49
Protect your personal data .................................................................. 49
Malware and viruses ............................................................................ 49
Care and maintenance ................................................................................. 50
Warranty ...................................................................................................... 51
Copyright and other notices ........................................................................ 51
Content copyright ................................................................................ 52
Specifications ............................................................................................... 52
Hearing aid compatibility ..................................................................... 52
Specific Absorption Rate (SAR) ............................................................ 53
Correct disposal of this product........................................................... 54
Correct disposal of batteries in this product ....................................... 54
Declaration of Conformity ................................................................... 54
English
Congratulations on your purchase
The Doro 6040 is a stylish clamshell phone that prevents accidental key
presses when folded, and lets you answer and end calls with a simple flip.
Easily call, message and share photos with family and friends thanks to
widely separated, high contrast keys and a large, 2.8" screen. The easy to
use 3MP camera is great for taking and sharing photos, and there is an assistance button featuring support for Response by Doro™ with GPS positioning. Other features include HAC (Hearing Aid Compatibility) as well as
shortcut keys for the camera, favourite contacts and messages. For more
information about accessories or other Doro products please visit
www.doro.com.
IMPORTANT!
Your device may use data services and you may incur additional charges
for data services, such as messaging or using location services depending
on your data plan. We recommend that you check your data rates for
your subscription with your service provider.
Get started
Insert SIM card, memory card and battery
Remove the battery cover
IMPORTANT!
Be careful not to damage your fingernails
when you remove the battery cover. Do
not bend or twist the battery cover
excessively as it may be damaged.
1
English
B
A
Insert the SIM cards (required)
Remove the battery if it is already installed.
Locate the SIM card holder and gently slide
the card in the holder. See the label right next
to the holder for guidance on how to insert
the card.
A. Insert the first SIM card by gently sliding
it into the SIM1 card slot.
B. Insert the second SIM card by gently slid-
ing it into the SIM2 card slot.
IMPORTANT!
This device accepts micro SIM or 3FF SIM card. Use of incompatible SIM
cards may damage the card or the device, and may corrupt data stored
on the card.
Note! If you are using only one SIM card, we recommend using SIM1.
Insert the memory card (optional)
Locate the SD card holder and follow the instructions for the SIM card. The device works
with or without a SD card installed.
IMPORTANT!
Use only compatible memory cards with
this device. Compatible card type:
microSD, microSDHC.
Incompatible cards may damage the card
itself, the device and corrupt any data
stored on the card. Depending on the
market some phones may have a preinstalled memory card.
Note! Since the SIM card holder and the memory card holder are located
beneath the battery you need to turn off the phone to insert or remove
the cards.
2
English
Tip: Take care not to scratch or bend the contacts on the memory or on
the SIM card when inserting them into the card holders.
Insert the battery and replace the battery cover
Insert the battery by sliding it into the battery
compartment with the contacts facing downwards to the right. Replace the battery cover.
Tip: It is recommended to remove the protective plastic film from the
display to enhance the visibility.
Charge the phone
CAUTION
Only use batteries, chargers and accessories that have been approved for
use with this particular model. Connecting other accessories may be
dangerous and may invalidate the phone's type approval and warranty.
3
English
A
B
When the battery is running low, is displayed and a warning signal is
heard.
1. Connect the mains adapter to a wall socket and to the charging socket
y.
The battery charge indicator is animated while charging. It takes approximately 3 hours to fully charge the battery. When the charger is
connected to the phone,
disconnected.
2. When charging is completed,
If the phone is turned off when the charger is connected to the phone
only the battery charge indicator will be shown on the display.
Note! To save power the LCD backlight goes off after a while. Press any
button to illuminate the display. Full battery capacity will not be reached
until the battery has been charged 3–4 times. Batteries degrade over time,
which means that call time and standby time will normally decrease with
regular use.
is displayed briefly, and when it is
is displayed on the screen.
4
English
Save energy
When you have fully charged the battery and disconnected the charger
from the device, unplug the charger from the wall socket.
Get to know your phone
Assistive functions
Use the symbols below to guide you through supporting sections in the
manual.
Seeing
Hearing
Handling
Safety
Turn the phone on and off
1. Press and hold on the phone to turn it on or off. Confirm with
Yes to power off.
2. If the SIM card is valid but protected with a PIN code (Personal Identification Number), PIN is displayed. Enter the PIN code and press Ok (
upper left corner of keypad). Delete with Clear ( upper right
corner of keypad).
Note! If PIN and PUK codes were not provided with your SIM card, please
contact your service provider.
Attempts: # shows the number of PIN attempts left. When no more at-
tempts remain, PIN blocked is displayed. The SIM card must then be unlocked with the PUK code (Personal Unblocking Key).
1. Enter the PUK code and confirm with Ok.
2. Enter a new PIN code and confirm with Ok.
3. Re-enter new PIN code and confirm with Ok.
Start-up wizard
When starting the phone for the first time, you can use the Start-up wizard
to set some basic settings.
• Press Yes to change or No if you do not want to change.
The default language is determined by the SIM card. See Phone settings,
p.9 on how to change language, time and date.
5
English
Tip: You can run the start-up wizard later if you want. From standby mode,
press Menu � Settings � General � Start-up wizard.
Phone indicators
Lights on the phone will:
• Flash when you have a new message or a missed call. After reading
the new message or missed call, the flashing will stop.
• Flash when the battery is running low and during charging.
Navigate the phone
Standby (idle mode)
When the phone is ready to use, and you have not keyed in any characters,
the phone is in standby.
• Press
• Press left selection button
lection button
phonebook.
Tip: You can always press
to return to standby mode.
to access the phone Menu or right se-
Name to access your saved contacts in the
to return to standby.
Scroll
• Use the arrow buttons / to scroll in menus.
Step-by-step instructions
The arrow (�) indicates next action in step-by-step instructions. To confirm an action, press Ok. To select an item, scroll or highlight the item using
/ and then press Ok.
Example:
• Press Menu � Phonebook � -New contact- � Add.
To perform the example on your Doro 6040 you should do the following:
1. Press Menu, scroll to Phonebook and press Ok.
2. Select -New contact- and press Add.
6
English
Enter text
Enter text manually
Select character
• Press a numerical key repeatedly until the desired character is shown.
Wait a second before entering the next character from same numerical key.
Special characters
1. Press*for a list of special characters.
2. Select the desired character with
Move the cursor within text
• Use
Upper case, lower case and numerals
• Press#to choose between upper case, lower case and numerals.
See Input mode, p.8.
Change writing language
/ to move the cursor within the text.
/ and press Ok to confirm.
1. Press and hold#for a list of available languages.
2. Select language with
/ and press Ok to confirm.
Enter text with predictive text
In some languages you can use an input method which uses a dictionary to
suggest words.
• Press each key once, even if the displayed character is not the one
you want. The dictionary will suggest words based on the keys you
have pressed.
Example
1. Press3,7,3,3to write the word “Fred”. Complete the word before looking at the suggestions.
2. Use
3. Press Select and continue with the next word.
Alternatively, press0to continue with the next word.
4. If none of the suggested words are correct, use manual input mode.
To temporarily switch between predictive text and manual input
mode, press and hold*.
/ to view the suggested words.
7
English
Note! See Predictive text, p.27 for more information.
Input mode
• Press#to change input mode. The icon on the top left of the display
indicates the input mode.
Abc
ABC
abc
Abc
ABC
abc
123 Numerals
Sentence case with predictive text
UPPER CASE with predictive text
lower case with predictive text
Sentence case
UPPER CASE
lower case
Hearing aid compatible
This phone is hearing aid compatible. Hearing aid compatibility is not a
guarantee that a specific hearing aid will work with a specific phone. Mobile phones contain radio transmitters that may interfere with hearing aid
performance. This phone has been tested for use with hearing aids, for
some of the wireless technologies that it uses, but there may be some
newer wireless technologies that have not been tested yet for use with
hearing aids. To ensure that a specific hearing aid works well with this
phone, test them together before making a purchase.
The standard for hearing aid compatibility contains two types of ratings:
• M: To use your hearing aid in this mode, make sure that your hearing
aid is set to "M-mode" or acoustic coupling mode, and position the
phones receiver near the hearing aid’s built-in microphone. For the
best results, try using the phone in different positions relative to your
hearing aid—for example, placing the receiver slightly above the ear
may result in better performance for hearing aids with microphones
positioned behind the ear.
• T: To use your hearing aid in this mode, make sure that your hearing
aid is set to "T-mode" or telecoil coupling mode (not all hearing aids
have this mode). For the best results, try using the phone in different
positions relative to your hearing aid—for example, placing the receiver slightly below or in front of the ear may result in better
performance.
See also Audio setup
, p.37 on how you can adjust the audio settings.
8
English
Phone settings
Time & date
Set the time and date
1. Press Menu � Settings � General � Time & date:
• Set time to enter the time (HH:MM).
• Set date to enter the date (DD/MM/YYYY).
2. Press Ok to confirm.
Tip: You can also set the phone to automatically update the time and date
according to the current time zone. In Time & date select Auto time � On.
Automatic update of date and time does not change the time you have set
for the alarm clock or the calendar. They are in local time. Updating may
cause some alarms you have set to expire depending on network support
and subscription.
Set the time and date format
1. Press Menu � Settings � General � Time & date � Set format:
• Time format � 12 hours or 24 hours.
• Date format and select the desired date format.
2. Press Ok to confirm.
Language
The default language for the phone menus, messages, etc. is determined
by the SIM card. You can change this to any other language supported by
the phone.
1. Press Menu � Settings � General � Language.
2. Select the wanted language.
3. Press Ok to confirm.
Block function
1. Press Menu � Settings � General � Block function.
2. Select each function you want to disable and press Off.
3. Press Done to confirm.
PIN code options
1. Press Menu � Settings � Security � SIM lock:
9
English
• On to activate the PIN code. You need to enter the PIN code
every time the phone is started.
• Off to deactivate the PIN code.
IMPORTANT!
If enabling Off-mode and the SIM card is lost or stolen, it is
unprotected.
• Automatic to start the phone without the PIN code. The phone
remembers it automatically, but if the SIM card is moved to another phone (lost or stolen) the PIN code needs to be entered
when the phone is started.
2. Press Ok to confirm.
Change PIN code
1. Press Menu � Settings � Security � Passwords � PIN.
2. Enter current PIN code and press Ok.
3. Enter new PIN and press Ok. Repeat to confirm.
Blacklist
You can compile a blacklist of phone numbers so that any phone number
on your blacklist is blocked when calling or texting you.
Activate the function, add, remove or edit blacklist numbers
1. Press Menu � Settings � Phonebook � Blacklist.
2. Select Activation.
• On to activate the function.
• Off to deactivate the function.
3. Select Number list.
4. Select Add � Phonebook to add a contact from the phonebook.
Alternatively, press Manual to add names or numbers manually.
5. Select the phone number and press Edit or Unblock.
6. Press Ok to confirm.
Tip: When activated, you can add numbers directly from your call log, just
press Options � Block � Yes.
10
English
Whitelist
A whitelist works much like a spam filter, once activated, you can only receive incoming calls from contacts saved in the phonebook. People not
stored in the phonebook gets a busy signal when trying to call you.
1. Press Menu � Settings � Security � Whitelist.
2. Select On to enable, or Off to disable.
3. Press Ok to confirm.
Calls
Make a call
1. Enter the phone number including the area code. Delete with Clear.
2. Press
3. Press
Tip: For international calls, always use + before the country code for best
operation. Press*twice for the international prefix +.
to make a call. Press Abort to cancel the call.
to end the call.
Call from the phonebook
1. Press Name to open the phonebook.
2. Scroll through the phonebook, or quick search by pressing the key corresponding to the first letter of the entry, see Enter text
3. Press Options � Call to dial the selected entry. If needed, select the
number.
Alternatively, press
4. Press Abort or
to dial.
to cancel the call.
, p.7.
Receive a call
1. Press to answer.
Alternatively press Silent to switch off the ringtone or press
the flip to reject directly (busy signal).
2. Press
to end the call.
Volume control
During a call
• Use the buttons
el is indicated on the display.
/ to adjust the sound volume. The volume lev-
11
/close
English
If you use a hearing aid or have hearing difficulties when using the telephone in a noisy environment, you can adjust the phone's audio settings,
see Audio setup
, p.37.
Silent
Silent is a fixed profile with Keypad tone, Message tone and Ringtone disabled, while Tasks, Daily reminder and Alarm are unchanged.
• Press and hold shortcut button#to activate or deactivate silent
mode.
Headset
When a headset is connected, the internal microphone in the phone is automatically disconnected. If available, use the answer key on the headset
to answer and end calls.
CAUTION
Using a headset at high volume may damage your hearing. Adjust the
volume level carefully when using a headset.
Call options
During a call the selection buttons1( ) give access to additional functions.
Options (left selection button)
• Volume to adjust the volume.
• Hold single call/Retrieve single to hold/retrieve the current call.
• End single call to end the current call (same as
• New call to call another number (Conference).
• Phonebook to search the phonebook.
• Messages to write or read text messages.
• Mute to disable the microphone.
).
SPK on (right selection button)
The loudspeaker allows you to speak without holding the phone close to
the ear.
1. Selection buttons have multiple functions. The current function is shown
above the selection button on the display.
12
English
1. Press SPK on to activate. Speak clearly into the phone microphone at
a maximum distance of 1 m. Use
volume.
2. Press SPK off to return to normal mode.
Note! Loud background noises (music, etc.) may interfere with the sound
quality.
/ to adjust the loudspeaker
SOS calls
As long as the phone is switched on, it is always possible to place an SOS
call by entering the main local emergency number for your present location followed by
Some networks accept calls to emergency numbers without a valid SIM
card. Contact your service provider for more information.
.
Call log
Received, missed and made calls are saved in a combined call log. 20
calls of each type can be stored in the log. For multiple calls related to the
same number, only the most recent call is saved.
1. Press
Alternatively, press Menu � Call log.
2. Use
3. Press to call, or Options:
• Call to call the contact.
• View to show details for the selected call.
• Send SMS to send a text message.
• Send MMS to send a picture message.
• Delete to delete the call.
• Delete all to delete all calls in the call log.
• Save to save the number in the phonebook � Create new cre-
• Block to block this number from calling or texting you.
.
/ to select:
Received call
Dialled call
Missed call
ate new contact, or Update to update existing contact.
13
Loading...
