Dnp Q8 User Manual
Copal Printer Manual
Acknowledgements
ACKNOWLEDGEMENTS
The information contained in this document represents the current view of DNP Photo Imaging America Corp. on the issues discussed as of the date of
publication. Because DNP Photo Imaging America Corp. must respond to changing market conditions, it should not be interpreted to be a commitment on
the part of DNP Photo Imaging America Corp., and DNP Photo Imaging America Corp. cannot guarantee the accuracy of any information presented after
the date of publication.
This document is for informational purposes only. DNP Photo Imaging America Corp. MAKES NO WARRANTIES, EXPRESSED OR IMPLIED, AS TO
THE INFORMATION IN THIS DOCUMENT.
Complying with all applicable copyright laws is the responsibility of the user. Without limiting the rights under copyright, no part of this document may be
reproduced, stored in or introduced into a retrieval system, or transmitted in any form or by any means (electronic, mechanical, photocopying, recording,
or otherwise), or for any purpose, without the express written permission of DNP Photo Imaging America Corp..
DNP Photo Imaging America Corp. may have patents, patent applications, trademarks, copyrights, or other intellectual property rights covering subject
matter in this document. Except as expressly provided in any written license agreement from DNP Photo Imaging America Corp., the furnishing of this
document does not give you any license to these patents, trademarks, copyrights, or other intellectual property.
ScanStation™, PrintMaster™, iStation™, PicViewer™, Photo Theater™, MyPhotoLab™, NexLab™, PixelWare™, LabServer™, One Touch Digital
Prints™ and One Touch Digital Printing™ are trademarks of DNP Photo Imaging America Corp.. The names of actual companies and products mentioned
herein may be the trademarks of their respective owners.
PrintRush™ is a trademark of Dai Nippon Printing Company LTD.
Dell® is a registered trademark of Dell Inc., pcAnywhere® is a registered trademark of Symantec Corporation, Kodak™ is a trademark of Eastman Kodak
Company, Epson Stylus® is a registered trademark of Seiko Epson Corporation, and Sony® is a registered trademark of Sony Electronics Corporation.
GO Software™, PC-Charge™, Win-Charge™ are trademarks of GO Software, Inc. IrDA® is a registered trademark of Infrared Data Association.
Bluetooth® is a registered trademark of the Bluetooth SIG, and Macromedia® and Flash® are registered trademarks of Macromedia, Inc. All other
trademarks are the property of their respective owners.
DNP Photo Imaging America Corp. • PO Box 767 • San Marcos, TX 78667 • USA
© 2000-2006 DNP Photo Imaging America Corp.. All rights reserved.
DNP Photo Imaging America Corp.
Acknowledgements
DNP Photo Imaging America Corp.
Before You Begin Basic Maintenance
Note
Attention
Q8 PRINTER
BEFORE YOU BEGIN
Figure 36. Q8 Printer
Attach the Q8 printer to the USB port on the computer designated for the Q8 or 8x10 printer. See the Installation and
Setup Guide for more information.
It is recommended that there be at least 50 mm (1.97 in) of space above and on either side of the M8C printer to allow
for proper airflow.
REMOVING AND REPLACING THE Q8 MEDIA
Prior to performing this procedure, you must remove the ribbon from the printer.
Installing the Printer Paper
Touching the paper surface leads to smudges on exposed paper. Only touch the ends of the paper roll.
1. Orient the paper roll with the leading edge of the paper going over the top of the paper roll (with the label arrow
pointing down).
2. Open the plastic covering on the right side of the roll.
3. Insert the paper spool with the metal spindle on the right side of the paper roll.
4. Remove the plastic from the new paper roll.
5. Locate the other endcap with the release buttons.
6. While squeezing the buttons, align the endcap on the left side of the paper roll so that the metal bar goes through the
hole in the center of the endcap.
7. Press firmly on the endcaps to make sure the roll is seated against both endcaps and no space remains.
8. Attention:If the endcaps are not properly seated on the roll, the printer can jam.
32 DNP Photo Imaging America Corp.
