D-Link System, Inc.™

xStack Storage DSN-1000 / 2000 / 3000 / 4000 / 5000 series

Command Line Interface User’s Guide

Version 1.5

D-Link Systems, Inc. makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. D-Link Systems, Inc. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

This document contains proprietary information, which is protected by copyright. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of D-Link Systems, Inc.

The information is provided “as is” without warranty of any kind and is subject to change without notice. The only warranties for D-Link Systems products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. D-Link Systems shall not be liable for technical or editorial errors or omissions contained herein.

Trademarks

xStack is a registered trademark of D-Link, Inc. Adobe® and Acrobat® are trademarks of Adobe Systems, Incorporated. Java™ is a U.S. trademark of Sun Microsystems, Incorporated. Microsoft Windows is a U.S. registered trademarks of Microsoft Corporation. Oracle® is a registered U.S. trademark of Oracle Corporation, Redwood City, California. UNIX® is a registered trademark of The Open Group. All other brand or product names are or may be trademarks or service marks, and are used to identify products or services, of their respective owners.

D-Link Systems, Inc. 17595 Mount Herrmann Street Fountain Valley, CA 92708

www.DLink.com

Notice of Export Controls

Export of technical data contained in this document may require an export license from the United States government. Please contact D-Link, Inc. for any export compliance questions.

Document Revision Level

Date Description

July 2008 Version 1.0

September 2008 Version 1.1 – updated for software version 2.5.0 and redundant controllers

January 2009 Version 1.2 – minor technical and formatting updates

May 2009 Version 1.3 – updated for software version 2.6.0

December 2009

October 2010

Version 1.4 – updated for software version 2.7.0, including new commands for SNMP support, revised syntax for the IntegrityScanNow command, and several new Volume attributes

Version 1.5 – updated for software version 2.8.0, including several new commands in the AdvancedSettings context and removal of the IsBatteryFailed and IsBatteryCharging items from the System context

Command Line Interface User’s Guide iii

Preface

This document is intended for storage managers, administrators, and developers responsible for using the command-line interface (CLI) to configure, manage, or develop custom applications for the D-Link storage array from D-Link. This document assumes that the user is computer literate, familiar with storage array products, has a basic understanding of storage products and concepts, and has previous experience using a CLI.

Document Conventions

This document uses the following conventions to draw your attention to certain information.

The CLI is intended for users who have significant storage management expertise and previous experience using a CLI. Improper CLI use can cause undesired results.

Notes

Notes provide information that deserves special attention. They are preceded by:

Cautions

Cautions contain information, which if not followed, can cause damage to the DLink storage system. They are preceded by:

Warnings

Warnings contain information, which if not followed, can cause damage to the DLink storage system and to the person installing it. They are preceded by:

iv Preface

Typographic Conventions

The following typographic conventions are used in this document.



Bold text = indicates commands and keywords that you enter literally as shown. When appropriate, bold text is also used to call attention to text.



Italics = indicate arguments for which you supply values.



< > = angle brackets denote a descriptor to be specified.



[X] = square brackets enclose an optional item.



| = a vertical bar indicates a choice within an optional or required set of items.



[x|y] = square brackets enclosing items separated by a vertical bar indicate an optional choice.



{x|y} = braces enclosing items separated by a vertical bar indicate a required choice.



[x {y | z}] = nested sets of square brackets or braces indicate optional or required choices within optional or required items. Braces and a vertical bar within square brackets indicate a required choice within an optional item.



Courier typeface is used to represent commands and command prompts.

How to Use This Document

This CLI User’s Guide is intended as a general overview of the operation of the CLI. This User’s Guide also provides concepts and terminology specific to understanding the use of the CLI. It is intended that the reader can start to use the CLI with this understanding, and later refer to this User’s Guide as a reference for details on the commands.

Command Line Interface User’s Guide v

vi Preface

Contents

Chapter 1 Introduction ............................................................................................................................ 1

1.1 Contexts ............................................................................................. 2

1.2 Commands .......................................................................................... 3

1.3 Properties ........................................................................................... 4

1.4 Understanding the CLI Hierarchy ............................................................... 4

1.5 Members ............................................................................................ 6

1.6 Enumerators ........................................................................................ 6

1.7 Special Keywords .................................................................................. 6

Chapter 2 Installing the CLI..................................................................................................................... 7

2.1 Supported Operating Systems ................................................................... 8

2.2 Installing the CLI .................................................................................. 8

2.3 Starting the CLI ................................................................................... 14

2.3.1 Using the CLI Shortcut to Start the CLI ............................................. 14

2.3.2 Using the Run Command to Start the CLI ........................................... 15

2.4 Exiting the CLI .................................................................................... 18

2.5 Removing the CLI ................................................................................. 18

Chapter 3 Using the CLI ........................................................................................................................ 19

3.1 General Guidelines ............................................................................... 20

3.1.1 Understanding Commands ............................................................. 20

3.1.2 Global Action Commands .............................................................. 20

3.1.3 Context-Specific Commands .......................................................... 20

3.1.4 Abbreviating Commands ............................................................... 20

3.1.5 Editing Command Lines ................................................................ 21

3.1.6 Concatenating Commands ............................................................. 21

3.1.7 Referencing Root Items ................................................................ 21

3.2 Specifying Operating Modes .................................................................... 22

3.2.1 Output Mode ............................................................................. 23

3.2.2 Indication Mode ......................................................................... 24

3.2.3 Stream Mode ............................................................................. 25

3.2.4 Completion Code Mode ................................................................ 25

3.2.5 Echo Command Mode ................................................................... 26

3.2.6 Exit Script on Error Mode .............................................................. 26

3.3 Command Line Syntax ........................................................................... 27

3.4 Getting Help with CLI Commands ............................................................. 28

3.4.1 Help Summary ........................................................................... 28

3.4.2 Command Help .......................................................................... 30

3.4.3 Advanced Scripting Concepts ......................................................... 31

Chapter 4 Global Action Commands .................................................................................................... 33

4.1 List of Global Action Commands ............................................................... 34

4.2 Description of Global Action Commands ..................................................... 35

4.2.1 Do .......................................................................................... 35

4.2.2 Echo ....................................................................................... 36

4.2.3 Execute ................................................................................... 36

4.2.4 Exit ........................................................................................ 37

4.2.5 Help ....................................................................................... 37

4.2.6 List ......................................................................................... 38

Command Line Interface User’s Guide vii

4.2.7 Mode ...................................................................................... 38

4.2.8 Pop ........................................................................................ 40

4.2.9 Push ....................................................................................... 40

4.2.10 RequireArgs .............................................................................. 41

4.2.11 Select ..................................................................................... 42

4.2.12 Set ......................................................................................... 43

4.2.13 ShiftArgs .................................................................................. 43

4.2.14 Show....................................................................................... 44

4.2.15 System .................................................................................... 45

Chapter 5 Supported CLI Commands and Properties ........................................................................ 47

5.1 System Commands and Properties ............................................................ 48

5.2 Controller Commands and Properties ........................................................ 50

5.3 PhysicalPort Commands and Properties ...................................................... 52

5.4 PoolList Commands and Properties ........................................................... 53

5.5 DiskList Property ................................................................................. 53

5.6 Disk Commands ................................................................................... 54

5.7 VolumeList Property ............................................................................. 55

5.8 Volume Commands and Properties ............................................................ 55

5.9 VolumeComposition Properties ................................................................ 57

5.10 Extent Properties................................................................................. 57

5.11 TaskList Property ................................................................................. 58

5.12 Task Commands and Properties ............................................................... 59

5.13 iSCSI Commands and Properties ............................................................... 60

5.14 iSCSITarget Commands and Properties ....................................................... 61

5.15 iSCSISession Properties .......................................................................... 64

5.16 iSCSIConnection Properties ..................................................................... 65

5.17 Portal Commands and Properties ............................................................. 66

5.18 Initiator Commands and Properties ........................................................... 67

5.19 AdvancedSettings Commands and Properties ............................................... 68

5.20 SystemPolicy Properties ........................................................................ 69

5.21 ExternalConnectionsManager Properties ..................................................... 70

5.22 SystemStatistics Properties ..................................................................... 71

5.23 LAG Commands and Properties ................................................................ 72

5.24 ManagementPort Commands and Properties ................................................ 73

5.25 NetworkRoute Commands and Properties ................................................... 74

5.26 ServicePool Commands and Properties ....................................................... 75

Chapter 6 Application Examples .......................................................................................................... 77

6.1 Setting the Name of the System ............................................................... 78

6.2 Creating Volumes ................................................................................ 78

6.3 Obtaining the Maximum Size of a Volume ................................................... 79

6.4 Obtaining the Maximum Stripe Width of a Volume ......................................... 79

6.5 Adding an iSCSI Initiator ........................................................................ 80

6.6 Obtaining a Vector of All Controllers on a System ......................................... 80

6.7 Restarting the System ........................................................................... 81

6.8 Shutting Down the System ...................................................................... 81

6.9 Showing the Status of a Controller ............................................................ 81

6.10 Navigating and Displaying System, Volume, and Drive Information ..................... 82

Index ............................................................................................................................................... 85

viii Contents

List of Figures

Figure 1-1. Hierarchy of the System Context ........................................................... 5

Figure 2-1. Management Center Home Page ............................................................ 8

Figure 2-2. File Download Security Warning Message ................................................. 9

Figure 2-3. Secondary Warning Message ................................................................. 9

Figure 2-4. Welcome Page ................................................................................ 10

Figure 2-5. License Agreement ........................................................................... 10

Figure 2-6. Destination Folder Screen .................................................................. 11

Figure 2-7. Setup Type Screen ........................................................................... 11

Figure 2-8. Custom Setup Screen ........................................................................ 12

Figure 2-9. Ready to Install the Program Screen ...................................................... 12

Figure 2-10. Progress Bar .................................................................................. 13

Figure 2-11. InstallShield Wizard Complete Screen .................................................. 13

Figure 2-12. Run Dialog Box .............................................................................. 15

Figure 2-13. Example of Using the –g, -u, and –p Switches ......................................... 16

Figure 2-14. Example of Using the –x Switch .......................................................... 16

Figure 2-15. Example of Using the –x Switch with the –g, -u, and –p Switches .................. 17

Figure 2-16. Example of Using the –I Switch ........................................................... 17

Figure 3-1. Example of Viewing Operating Modes .................................................... 22

Figure 3-2. Example of Normal Output ................................................................. 23

Figure 3-3. Example of XML Output ..................................................................... 23

Figure 3-4. Example of Formatted XML Output (Excerpt Shown) .................................. 24

Figure 3-5. Examples of Errors Displayed in Completion Code Mode .............................. 25

Command Line Interface User’s Guide ix

List of Tables

Table 1-1. Members .......................................................................................... 6

Table 3-1. Items in a Command Line .................................................................... 27

Table 4-1. Global Action Commands .................................................................... 34

Table 5-1. System Context Commands ................................................................. 48

Table 5-2. System Context Properties .................................................................. 49

Table 5-3. Controller Commands ........................................................................ 50

Table 5-4. Controller Properties ......................................................................... 50

Table 5-5. PhysicalPort Command ....................................................................... 52

Table 5-6. PhysicalPort Properties ...................................................................... 52

Table 5-7. PoolList Commands ........................................................................... 53

Table 5-8. PoolList Properties ............................................................................ 53

Table 5-9. DiskList Property .............................................................................. 53

Table 5-10. Disk Commands .............................................................................. 54

Table 5-11. Disk Properties ............................................................................... 54

Table 5-12. Volume Property ............................................................................. 55

Table 5-13. Volume Commands .......................................................................... 55

Table 5-14. Volume Properties ........................................................................... 56

Table 5-15. VolumeComposition Properties ........................................................... 57

Table 5-16. Extent Properties ............................................................................ 57

Table 5-17. TaskList Properties .......................................................................... 58

Table 5-18. Task Commands .............................................................................. 59

Table 5-19. Task Properties .............................................................................. 59

Table 5-20. iSCSI Commands ............................................................................. 60

Table 5-21. iSCSI Properties .............................................................................. 60

Table 5-22. iSCSITarget Commands ..................................................................... 61

Table 5-23. iSCSITarget Properties ...................................................................... 61

Table 5-24. iSCSISession Properties ..................................................................... 64

Table 5-25. iSCSIConnection Properties ................................................................ 65

Table 5-26. Portal Commands ............................................................................ 66

Table 5-27. Portal Properties ............................................................................ 66

Table 5-28. Initiator Command .......................................................................... 67

Table 5-29. Initiator Properties .......................................................................... 67

Table 5-30. AdvancedSettings Commands ............................................................. 68

Table 5-31. AdvancedSettings Properties .............................................................. 68

Table 5-32. SystemPolicy Properties .................................................................... 69

Table 5-33. ExternalConnectionsManager Properties ................................................ 70

Table 5-34. SystemStatistics Properties ................................................................ 71

Table 5-35. LAG Commands .............................................................................. 72

Table 5-36. LAG Properties ............................................................................... 72

Table 5-37. ManagementPort Command ............................................................... 73

Table 5-38. ManagementPort Properties ............................................................... 73

Table 5-39. NetworkRoute Command ................................................................... 74

Table 5-40. NetworkRoute Properties .................................................................. 74

Table 5-41. ServicePool Commands ..................................................................... 75

Table 5-42. ServicePool Properties ...................................................................... 75

x Contents

Chapter 1 Introduction

The CLI is a line-oriented user interface that provides commands for configuring, managing, and monitoring an D-Link storage array. The CLI can be used as an alternative or supplement to the Management Center graphical user interface (GUI).

Using the CLI can be useful in the following scenarios:



Users who want to develop tools and applications that utilize D-Link functions.



Users that do not have access to a Web browser or the Internet.



Users who prefer to use a CLI rather than a graphical user interface (GUI).



Users that want to perform multiple tasks. CLI users can create a sequence of commands that are connected together to achieve a very flexible range of results. By comparison, there is no simple way to connect the output of one GUI program to the input of another.



Users who perform activities using scripts that contain one or more command lines.

For the latest information about the CLI, consult the Interoperability Matrix on the D-Link Web site: www.dlink.com.

This chapter provides an introduction to the CLI. The topics covered in this chapter are:



Section 1.1, Contexts (page 2)



Section 1.2, Commands (page 3)



Section 1.3, Properties (page 4)



Section 1.4, Understanding the CLI Hierarchy (page 4)



Section 1.5, Members (page 6)



Section 1.6, Enumerators (page 6)



Section 1.7, Special Keywords (page 6)

Command Line Interface User’s Guide 1

1.1 Contexts

Controller[A] ::

Volume[Mynewvolume] ::

All actions performed with the CLI are done in a specific “context.” A context is a reference to a specific physical or logical object on the system. Examples of contexts are:



When you start the CLI, for example, you interact with the root context. There is one instance of the root context on an D-Link storage array. In this guide, the root context is referred to as System.

Every context has a unique ID. When you are in a context, the prompt indicates the specific object with which you are communicating. For example:



The system itself (referred to as the root context),

A disk drive in the system.

A volume that was created on the system.

An iSCSI Initiator object that has been registered with the system.

If you communicate with the root object, the prompt takes the form of the IP address of the root. For example:

192.168.59.25 ::



In the controller context, the prompt displays the unique ID in brackets. For example:



In the volume context, the unique ID is the volume name shown in brackets. For example:

2 Chapter 1 Introduction

1.2 Commands

Commands cause some action to happen or a state to change. For example, the command createVolume creates a new volume and the command addInitiator adds an iSCSI initiator to the list of known initiators for an array. For a complete list of the commands available in the CLI, see Chapter 5.

The CLI provides a special set of commands called global action commands. Global action commands indicate an action that you want to perform and precede other commands and properties on a command line. For example, the global action command Show can be used with the property Controllers to return information about an array’s controller(s) from the System context:

192.168.59.25 :: show controller[a] ID = A Status = OK IsActive = true SlotNumber = 0 SerialNumber = 00001 DriveSlots = 12 NumFrontPorts = 8 DisplayName = Blade A SoftwareVersion = 2.5.1.21 IsAlternateSoftwareVersionPresent = true AlternateSoftwareVersion = 2.5.1.21 BoardType = 0009 BoardTypeRevision = XC05 I8kHwVersion = 1.0.0.0 I8kSwVersion = 0.1.0.0 MpuSwVersion = 2.5.1.21 BindFailReason = Bind_OK BladeHealth = Healthy BladeState = Bound BladeType = SFF PersistenceSetting = Unchanged BatteryState = Failed BufferMemDimmCnt = 2 BufferMemSize = 2048 SystemMemDimmCnt = 2 SystemMemSize = 512 SystemTime = 13:18:27 Ports = 8 Ports LAGs = 8 LAGs ManagementPort = ManagementPort [192.168.59.25], Status=OK BasePool = [BaseA], 2 disks

You can also chain commands on a command line and have the CLI execute them in sequence by separating each command with a semicolon (;). The following command line, for example, tells the CLI to perform two Pop operations and then create a 30 GB volume named Engineering.

Command Line Interface User’s Guide 3

Pop; Pop; createVolume Engineering 30GB mirror

For a complete list of the global action commands available in the CLI, see Chapter 4.

1.3 Properties

Properties are items that you show using the global action command Show. For example, the command Show softwareVersion returns the current version of software running on the array. Some properties can also be set. For example, the property context lets you set the name of an array using the global action command Set.

Volume[Parity3] :: set name ThisIsMyParityVolume

For a complete list of the properties available in the CLI, see Chapter 5. This chapter includes the global action commands used with the properties.

1.4 Understanding the CLI Hierarchy

Name

in the Volume

The CLI consists of a hierarchy of contexts, commands, and properties. For example, Figure 1-1 shows the relationships between contexts, commands, and the properties in the root context. Navigation within the CLI hierarchy is achieved ether by using properties that are of type Context or ContextList, or by using commands that return Contexts (such as createVolume and addInitiator).

In Figure 1-1, the arrows represent command- and property-based navigation:



Single arrows show a link from one starting context to one resulting context (for example, from System to diskList).



Double arrows show a link from one starting context to one resulting context as a result of selecting from a ContextList (for example, from System to a specifically selected controller, from Controller to a specifically selected physical port, or from DiskList to a specifically selected Disk).

Some contexts have both single and double arrows. PhysicalPort, for example, has a single LAG associated with it (indicated by a single arrow from PhysicalPort to LAG). However a LAG can have many physical ports(indicated by a double arrow from LAG to PhysicalPort).

Navigating within the CLI hierarchy is achieved using the following commands:



Push moves down one level in the CLI hierarchy and adds the context to the push/pop stack.



Select changes to the specified context, without adding the context to the push/pop stack.



Pop moves up either one level in the CLI hierarchy (if you used the Push command to navigate down the hierarchy) or to the root level (if you used the Select command to navigate down the hierarchy).

4 Chapter 1 Introduction

For more information about these global action commands, see Chapter 4.

Command Line Interface User’s Guide 5

Figure 1-1. Hierarchy of the System Context

1.5 Members

Each context has one or more members associated with it. A member can be a value property, context property, context list, or command. Table 1-1 describes these types of members.

Table 1-1. Members

Member Description Examples of Data Types for This Member

Value properties Value properties can be read-only or read-write:

Context property

Context lists

Commands Commands support Do.

1.6 Enumerators

Enumerators are a data type, much like Number, String, Boolean, and Date/Time. Enumerators have a discrete list of possible values that can be used in a property or command argument . Examples include:



VolumeComposition (for example, JBOD, Stripe, Mirror, Parity, StripeMirror)



Read-only properties only support Show.



Read-write properties support Show and Set.

Context properties can be read-only or readwrite.

Types of entities that can be displayed or operated upon from the current context.



Number



String



Enumeration (see section 1.6)



Boolean



Date/Time



DiskList on the root context.



LAG on PhysicalPort



Controllers on the root context



Disks on DiskList



CreateVolume on the root context



Reconfigure on Volume



StripeDepth (for example, 32KB, 64KB, 128KB, 256KB, 512KB, 1024KB, 2048KB)

1.7 Special Keywords

When working in a context that can contain one or more members, the special keywords of $first and $last let you reference the first or last entry in the list of members, although the order of entries in the list may be random. This is useful if you use advanced scripts or perform a repetitive operation that should continue until the entire list is empty, without needing to indicate the names or index values for the specific members of the list. For example, you can delete all volumes on an array by specifying the following command repeatedly until an error occurs (when no more volumes exist):

do volumelist.volume[$last].delete

6 Chapter 1 Introduction

Chapter 2 Installing the CLI

This chapter describes how to install the CLI. The topics covered in this chapter are:



Section 2.1, Supported Operating Systems (page 8)



Section 2.2, Installing the CLI (page 8)



Section 2.3, Starting the CLI (page 14)



Section 2.4, Exiting the CLI (page 18)



Section 2.5, Removing the CLI (page 18)

Command Line Interface User’s Guide 7

2.1 Supported Operating Systems

The CLI supports the following operating systems:



Microsoft Windows XP Professional Service Pack 2



Microsoft Windows Server 2003 R2



Microsoft Windows Server 2008



Microsoft Windows Vista Business and above

2.2 Installing the CLI

To install the CLI, use the following procedure.

1. Start your Web browser.

In the browser address field, enter the IP address of the management port. The home page in Figure 2-1 appears.

2. From the home page, click Click here to install the Advanced Features for Windows.

The file download security warning message in Figure 2-2 appears.

8 Chapter 2 Installing the CLI

Figure 2-1. Management Center Home Page

Figure 2-2. File Download Security Warning Message

3. Click Run to run the installer.

4. If the security warning appears in Figure 2-3, click Run. A Welcome page appears (see

Figure 2-4).

Figure 2-3. Secondary Warning Message

Command Line Interface User’s Guide 9

Figure 2-4. Welcome Page

5. Click Next. The License Agreement appears (see Figure 2-5).

6. Read the License Agreement, then click I accept the terms in the license agreement and click Next. (You must accept the terms of the license agreement to proceed.) The Destination Folder screen appears (see Figure 2-6).

10 Chapter 2 Installing the CLI

Figure 2-5. License Agreement

To obtain a printed copy of the License Agreement, click Print.

Figure 2-6. Destination Folder Screen

7. Either accept the default destination folder shown, or click the Change button and

specify a different installation location.

8. Click Next. You are prompted to select a setup type (see Figure 2-7).

Command Line Interface User’s Guide 11

Figure 2-7. Setup Type Screen

9. Select whether you want to perform the complete or custom setup. The complete setup installs the Windows VDS Provider and the CLI, and displays the screen in Figure 2-9. If you only want to install the CLI, select Custom and make the appropriate selections in the screens that appear (see Figure 2-8); then click Next until the screen in Figure 2-9 appears.

Figure 2-8. Custom Setup Screen

Figure 2-9. Ready to Install the Program Screen

12 Chapter 2 Installing the CLI

10. With the Ready to Install the Program screen displayed, click Install. A progress bar

shows the progress of the installation (see Figure 2-10). As part of this process, a shortcut is placed on your Windows desktop for starting the CLI.

Figure 2-10. Progress Bar

11. When the installation is complete, the screen in Figure 2-11 appears. Click Finish to

close the screen.

Command Line Interface User’s Guide 13

Figure 2-11. InstallShield Wizard Complete Screen

2.3 Starting the CLI

The CLI can be started using either the CLI shortcut installed on your Windows desktop or the Run command. The following sections describe these methods for starting the CLI.

2.3.1 Using the CLI Shortcut to Start the CLI

When you installed the CLI, a desktop shortcut was automatically placed on your desktop. To start the CLI using the shortcut, use the following procedure.

1. Double-click the following shortcut on your Windows desktop:

A HOSTNAME IP address prompt similar to the one below appears.

2. Enter the IP address of the management port for the array with which you want to communicate (for example, 192.168.59.25).

3. Press the Enter key. You are prompted for a username.

4. Enter a username (the default username is admin) and press Enter. You are prompted for a password.

14 Chapter 2 Installing the CLI

5. Enter a case-sensitive password (the default password is admin) and press Enter. For

security, each typed password character appears as an asterisk (*). The following actions occur when you press Enter:



A series of numbers count down from 5 to zero.



When zero is reached, a Successful login message with the IP address of the array you logged in to appears if the login was successful. In the example below, the user has logged in to an array with an IP address of 192.168.59.25.



A prompt appears that consists of the IP address of the array to which you are logged in followed by two colons (for example, 192.168.59.25 ::).

You are now at the System level and can issue CLI command lines at the root context, or navigate to and issue commands from subcontexts (see section 1.1).

2.3.2 Using the Run Command to Start the CLI

The following procedure describes how to start the CLI using the Windows Run command. With this method, you enter the name of the CLI executable file in the Open field of the Windows Run dialog box. If you know the IP address of the array management port, username, and password, you can add them to the command line following the name of the CLI executable file. If desired, you can also specify the name of a script that you want the CLI to automatically run at login.

1. Click the Start button and click Run. The Run dialog box appears (see Figure 2-12).

Figure 2-12. Run Dialog Box

2. In the Open field, click the Browse button. Navigate to the location Program

Files/D-Link, Inc./Advanced Features for Windows (or the destination

location you specified during the installation). Double-click the name of the CLI executable (cli2.exe).

Command Line Interface User’s Guide 15

3. Optional: To add an IP address of the array management port, username, and password, or script file name after the CLI executable name, or to disable any real-time indications, type the option (which consists of a switch and an entry such as an IP address or hostname) after the name of the CLI executable, as shown in the following steps. Separate the CLI executable filename from these options with a space.



Adding a system IP address or host name: -g <IPAddressOrHostName> See the example in Figure 2-13. If -g is omitted, the environment variable ISA_HOSTNAME is used. If that environment variable is not defined, you are prompted for an IP address if none is found.



Adding a username: -u <username> Adding a password: -p <password> The default username and password are admin (see the example in Figure 2-13). If -u is omitted, the environment variable ISA_USERNAME is used. If -p is omitted, the ISA_PASSWORD environment variable is used. If these environment variables are not defined, you are prompted for a username and/or password if none is found.

Figure 2-13. Example of Using the –g, -u, and –p Switches



Running a script: -x <scriptFileName> See the examples in Figure 2-14 and Figure 2-15. The name of the script file referenced in the Open field should have the file name scriptFileName.cli. The file name entered in the Open field should not include the .cli extension. In Figure 2-14, for instance, the command line will have the CLI run a script called createJbodScript, which creates a JBOD on the array. The 10GB following the script name tells the CLI to create a 10 GB volume called myVolName on that JBOD. In Figure 2-15, the command line will provide the IP address, username, and password for logging in and run the same script as in Figure 2-14, without creating the 10 GB volume.

Figure 2-14. Example of Using the –x Switch

16 Chapter 2 Installing the CLI

Figure 2-15. Example of Using the –x Switch with the –g, -u, and –p Switches

Because the CLI uses a computer’s environment variables if the –g, -u, and/or –p switches are not specified on the command line, it is recommended that you set the environment variables as desired on the machine where the CLI is running. System environment variables are defined by Windows and apply to all computer users. However, you must be an administrator to modify a system environment variable. Changes to the system environment are written to the registry and usually require a restart to become effective.



Disabling real-time indications: -I See the example in Figure 2-16. Specify the -I switch to enable real-time indications while the CLI is running. This will allow the CLI to provide asynchronous reporting of changed services and may have performance impacts for heavily loaded systems. It is generally recommended that this option not be used unless there is a specific need for it. You can combine the -I switch with any other switches.

Figure 2-16. Example of Using the –I Switch

4. Click the OK button. The following actions occur:



A series of numbers count down from 5 to zero.



A prompt appears that consists of the IP address of the array to which you are logged in followed by two colons (for example, 192.168.59.25 ::).

Command Line Interface User’s Guide 17

You are now at the System level and can issue CLI command lines at the root context, or navigate to and issue commands from sub-contexts (see section 1.1).

2.4 Exiting the CLI

To exit a CLI session, type the Exit command from the CLI session and press Enter to terminate the CLI program. The Exit command is a “global action” command and can be issued from any context.

If you omitted the IP address, username, and password in step 2, you will be prompted for these before gaining access to the root context.

2.5 Removing the CLI

To remove the CLI from the computer on which it is installed, rerun the installer from the Advanced Features for Windows link. When the screen appears with links for repairing or uninstalling the CLI, click the un-installation link to remove the CLI.

You can also use Add/Remove Programs from the Windows control panel to remove the CLI as you would any other Windows application.

18 Chapter 2 Installing the CLI

Chapter 3 Using the CLI

This chapter describes how to use the CLI. The topics covered in this chapter are:



Section 3.1, General Guidelines (page 20)



Section 3.2, Specifying Operating Modes (page 22)



Section 3.3, Command Line Syntax (page 27)



Section 3.4, Getting Help with CLI Commands (page 28)

Command Line Interface User’s Guide 19

3.1 General Guidelines

The following sections describe general guidelines to follow when issuing CLI command lines.

3.1.1 Understanding Commands

Commands are organized into two categories, global action commands and context-specific commands. All CLI commands are case-insensitive. For readability, the commands in this guide are shown with a mix of upper-case and lower-case characters.

3.1.2 Global Action Commands

Global action commands can be used within all contexts. For example, the help command is a global action command. Issuing this command displays all of the global action and contextspecific commands available in the CLI. For a list of all the global action commands, see Table 4-1 on page 34.

3.1.3 Context-Specific Commands

Context-specific commands can be used within the current context only. Context-specific commands are prefaced by the global action command Do, Show, or Set. The following example uses the global command Show and the context-specific command diskList to get the DiskList information.

192.168.59.25 :: Show diskList ← typed by user

ID = 0 ← returned by CLI Status = OK ← returned by CLI Disks = 4 Disks ← returned by CLI

For a list of all the context-specific commands, see Chapter 5.

3.1.4 Abbreviating Commands

The CLI lets you abbreviate context-specific command keywords to their fewest unique characters. For example, instead of entering the full command Show diskList, you can type Show d. If you type an abbreviated command that can match more than one command, an error message is returned and you must retype the command, entering additional characters to make the command unambiguous to the CLI.

192.168.59.25 :: Show d ← typed by user

ID = 0 ← returned by CLI Status = OK ← returned by CLI Disks = 4 Disks ← returned by CLI

20 Chapter 3 Using the CLI

3.1.5 Editing Command Lines

The CLI allows you to view all previously entered commands by pressing the up-arrow key on your keyboard. Once you have examined a previously entered command, you can move forward in the list by pressing the down-arrow key on your keyboard.

If you view a command you want to reuse, you can edit it or press the Enter key to execute it.

3.1.6 Concatenating Commands

The CLI is ideally suited to handling large batches of tasks by allowing you to chain (or concatenate) commands on a command line using a dot (period). The following command lines provide examples of concatenating commands on a single command line.

Example 1: This command line lists all volumes whose names begin with mynewvol. The square bracket selects a volume that starts with [mynewvol].

Show volumeList.Volumes[mynewvol]

Example 2: This command line lists all volumes.

Show volumeList.Volumes

Example 3: This command line grants all iSCSI initiators with access to the volume named mynewvol.

volumeList.Volumes[mynewvol].target.grantInitiatorAccess All

Example 4: This command line is similar to the one above. However, in this example, quotation marks are added to the grantInitiatorAccess argument because it consists of more than one word. The grantInitiatorAccess command accepts one argument. In this example, however, the argument consists of two words (All Initiators) separated by a space. Including the quotation marks tells the CLI to treat the items between the quotation marks as a single object instead of as two arguments (in which case, the command line would fail).

volumeList.Volumes[mynewvol].target.grantInitiatorAccess "All Initiators"

Example 5: This command line deletes the volume mynewvol.

volumeList.Volumes[mynewvol].delete

3.1.7 Referencing Root Items

There may be times when you are in a subcontext and want to execute commands that are only available at the top (root) context. One way to accomplish this is to use the Pop command to reach the root level and then type the command line. Alternatively, you can issue the command line without having to leave the current subcontext by prefacing the command line with the caret (^) character.

Command Line Interface User’s Guide 21

The caret character provides a shortcut for executing commands available at the top (root) context from any subcontext. Issuing this command leaves you in the current context. For example, createVolume is a command that is available at the root level. If you are in a subcontext and want to issue the CreateVolume command, type a caret followed by the command, as shown in the following example.

^createVolume Engineering 30GB mirror

3.2 Specifying Operating Modes

The CLI provides the following operating modes:



Output mode – see section 3.2.1.



Indication mode – see section 3.2.2.



Stream mode – see section 3.2.3.



Completion code – see section 3.2.4.



Echo Command mode – see section 3.2.5.



Exit Script on Error mode – see section 3.2.6.

Each operating mode operates independently of the other modes, and can be configured independently using the Mode command. The following sections describe these operating modes.

To see the status of these operating modes, type Mode and press Enter. The figure below shows an example of the status information returned.

Figure 3-1. Example of Viewing Operating Modes

22 Chapter 3 Using the CLI

3.2.1 Output Mode

Output mode allows you to configure the format of the output from the CLI as humanreadable, XML, or formatted XML output.



Normal - output is displayed in human-readable format. This is the default setting and is recommended if the CLI output will be read by people. Figure 3-2 shows an example of this mode when the Show command at the root (system) context is issued. If you change to another output mode, type the following command to return to this output mode:

Mode outputMode Normal

Figure 3-2. Example of Normal Output



XML - output is nested together as XML, with XML tags. This selection is useful when a computer program will be receiving and interpreting the output from the CLI. Figure 3-3 shows an example of this mode when the Show command is issued. To select the XML output mode, type the following command:

Mode outputMode XML

Figure 3-3. Example of XML Output

Command Line Interface User’s Guide 23



Formatted XML - output is similar to XML, but with indentations to enhance human readability and facilitate scripted interaction for parsing. This selection is useful when a computer program and possibly a person will be interpreting the output from the CLI. Figure 3-4 shows an example of this mode when the Show command is issued. To select the formatted XML output mode, type the following command:

Mode outputMode FormattedXML

Figure 3-4. Example of Formatted XML Output (Excerpt Shown)

3.2.2 Indication Mode

Enabling indication mode displays messages of changes made to the system as a result of commands executed by you and other CLI users. For example, if you or another user creates a volume with indication mode enabled, messages inform you that the volume list was modified to include the new volume.

By default, indication mode is disabled. To enable it, type:

Mode indicationMode Enabled

To disable indication mode, type:

Mode indicationMode Disabled

24 Chapter 3 Using the CLI

3.2.3 Stream Mode

By default, the CLI directs output to two destinations:



Error messages go to standard error (STDERR).



All other output goes to standard out (STDOUT).

This separation may be undesirable for some scripting methods. Therefore, you can enable stream mode to direct all output to STDOUT, obviating the need to read two streams at the same time.

To enable stream mode, type:

Mode streamMode Mixed_STDOUT_Only

To disable stream mode, type:

Mode streamMode Mixed_STDOUT_STDERR

If the CLI is invoked with redirection to a file using a standard redirection (greater-than) character, standard out will be directed to the file and error messages will be directed to the screen.

3.2.4 Completion Code Mode

Completion code mode determines whether the CLI returns a text code and text description each time it executes (or tries to execute) a command line, or only when the command line fails due to an error. Figure 3-5 shows examples of error messages returned due to errors in command lines.

192.168.55.224 :: create Zeus 3tb jbod

UA_E_REQUEST_FAILED = Error - CIM_ERR_FAILED: A general error occurred that is not covered by a more specific error code: "Not enough space available

192.168.55.224 :: addInitiator

UA_E_INVALIDARG = Error - Expected 1 arguments

192.168.55.224 :: addInitiator Windows3

UA_E_UNEXPECTED = Error - CIM_ERR_ALREADY_EXISTS: Operation cannot be carried out because an object already exists: "An Initiator with that name already exists"

Figure 3-5. Examples of Errors Displayed in Completion Code Mode

Command Line Interface User’s Guide 25

By default, completion code mode returns a message when the command line has one or more errors. To enable completion codes for all command lines, type:

Mode completionCodeMode Always

To display completion codes only when an error occurs, type:

Mode completionCodeMode ErrorsOnly

3.2.5 Echo Command Mode

Echo command mode repeats everything you type. In the following example, echo command mode repeated the command typed next to the IP address.

192.168.59.25 :: Mode EchoCommandMode Enabled ← typed by user

Mode EchoCommandMode Enabled ← returned by CLI

By default, echo command mode is disabled To enable it, type:

Mode echoCommand Enabled

To disable echo command mode, type:

Mode EchoCommand Disabled

3.2.6 Exit Script on Error Mode

Exit script on error mode allows the CLI to exit a script automatically if the CLI encounters an error in the script. This mode is useful when running the CLI from a shell script.

By default, exit script on error mode is enabled To disable it, type:

Mode ExitScriptonError Disabled

To enable exit script on error mode, type:

Mode ExitScriptonError Enabled

26 Chapter 3 Using the CLI

3.3 Command Line Syntax

[Action]

[Member]

[Action]

[Member]

[Argument]

[Action]

[Member]

[Arguments]

CLI input is case-insensitive, except when otherwise noted. The general CLI syntax format is as follows:

{Action} {Member} [Arguments]

Table 3-1 describes the items that can be included in a command line. The command Do can be omitted for action commands.

Item Description

Table 3-1. Items in a Command Line

{Action}

{Action} refers to the global action command Do, Show, or Set. Every member has a default

action that is assumed if an action is omitted from the beginning of a command line. One such default is Show. If you want to issue a Show Identity command, for example, you need only type ID at the CLI prompt because Show is assumed and ID is a sufficient number of characters to make this command unambiguous to the CLI (see section 3.1.4). Note, however, that if you want to issue a Set command, you must type Set; otherwise, the CLI defaults to Show.

{Member}

{Member} is a context member name, such as a property or command. Examples include Name on Volume and CreateVolume on the root.

[Arguments]

Arguments are extensions that provide extra information needed for the execution of a particular action. Whether or not an argument is required depends on the specific action being executed. For example, CreateVolume has arguments for defining characteristics such as the name, size, and composition of the volume to be created. If you omit an argument, the default action is assumed.

Example 1: The following example shows a command line that has no arguments. This command line restarts the system.

Do SystemRestart

Example 2: The following example shows a command line that has one argument. This command line sets the name of the system to Zeus.

Example 3: The following example shows a command line that has more than one argument. This command line creates a new volume called Venus that is 100 GB large and configured as a JBOD.

Command Line Interface User’s Guide 27

Set Name Zeus

Do createVolume Venus 100GB jbod

3.4 Getting Help with CLI Commands

The help subsystem consists of two levels: help summary and command help.

3.4.1 Help Summary

Typing the global command help as the sole command on a command line from any context lists all of the supported global and context-specific commands:

192.168.59.25 :: help Global Commands ----------------------------------------

Help This help

List Brief list of current context properties/methods

Exit To end the session

Echo Echo a line of text to STDOUT

Execute Execute a CLI script file (same as '@' prefix)

RequireArgs Requires at least # arguments, or exits

ShiftArgs Shifts off # arguments

Mode Sets some session options

Push Saves the current context on a LIFO stack and changes context

Pop Returns to the last pushed context

Select Changes context

Show Shows a property in the current context

Set Sets a property in the current context

Do Performs a command in current context

System Invokes a system shell command (same as '!' prefix)

Context Specific Commands ------------------------------

show ID - The service's ID Returns: ID

show Status - The service's Operational Status Returns: Status

show Name - Gets the user-settable system name Returns: name

set Name - Sets the user-settable system name > name (String) - Name of the system

show Identity - Gets the %productshortname% identity Returns: identity

show DurableName - Gets the Durable system name Returns: name

show ProductId - Gets the system ProductId Returns: productId

show RevisionLevel - Gets the system RevisionLevel

28 Chapter 3 Using the CLI

Returns: revisionLevel

show VendorId - Gets the system VendorId Returns: vendorId

show BindFailReason - Gets the bind failure/success state detail Returns: bindFailReason (Undefined,Bind_OK,Bind_Error,RCP_Determination,Bind_Not_Possible,Split_RG,Non_Co nfig_Params,insufficient_resources,system_class_data,pblade_info_unavailable,FW_V ersions,SM_Size,BM_Size,SM_Dimms,BM_Dimms,Controller_Type,Product_ID,Starting_i8k ,Merge_Bind,Slam_Dunk,Cache,Board_revision,SEP_module_error,Discovered_drives_mis match,Incorrect_enclosure_cabling,Loss_of_peer_while_binding,Loss_of_comm_chan_wh ile_binding,Loss_of_rmc_link_while_binding,Message_returned_failure_status,Fatal_ error_on_other,Controller_states_dont_allow_bind,Moved_controller_in_restart_reco very,Unable_to_determine_seq_to_execute,Controllers_dont_agree_on_seq)

show BladeType - Gets the BladeType Returns: bladeType (Unknown,EBlade,DBlade,xStack,SFF,I386)

show SerialNumber - Gets the system SerialNumber Returns: serialNumber

show SystemState - Gets the SystemState Returns: systemState (Undefined,Standalone,Bound,Survivor,Not_bound,Split,Failed)

show Controllers - Gets a vector of all controllers in the system Returns: controllers (Controller list)

show DiskList - Gets the DiskList service Returns: diskList (DiskList object)

show PoolList - Gets the PoolList. Returns: poolList (PoolList object)

show VolumeList - Gets the VolumeList Returns: volumeList (VolumeList object)

show TaskList - Gets the TaskList Returns: taskList (TaskList object)

show iSCSI - Returns the iSCSI Service Returns: iSCSI (iSCSI object)

show EventHD-Linky - Gets the EventHD-Linky Returns: eventHD-Linky (EventHD-Linky object)

show ExternalConnectionsManager - Gets the ExternalConnectionsManager. Returns: externalConnectionsManager (ExternalConnectionsManager object)

show AdvancedSettings - NO DOC Returns: advancedSettings (AdvancedSettings object)

show SystemStatistics - Gets the SystemStatistics object Returns: service (SystemStatistics object)

do SystemShutdown - Shuts down the system

do SystemRestart - Reboots the system

do CreateVolume - Creates a volume. > name (String) - Volume name > sizeInBytes (StorageSize) - Volume size in bytes > compositionName (UAEnum) - Volume composition (JBOD,Stripe,Mirror,StripeMirror,Parity) > disks (ServiceList) - List of disks to use (Disk) > stripeWidth (Integer) - Stripe width > stripeDepth (UAEnum) - Stripe depth (32KB,64KB,128KB,256KB,512KB,1024KB,2048KB) Returns: newVolume (Volume object)

Command Line Interface User’s Guide 29

do GetMaxVolumeStripeWidth - Gets the Maximum StripeWidth supported for a vo lume type > compositionName (UAEnum) - Volume composition (JBOD,Stripe,Mirror,StripeMirror,Parity) Returns: stripeWidth

do GetMaxVolumeSize - Gets maximum volume size > compositionName (UAEnum) - Volume composition to use (JBOD,Stripe,Mirror,StripeMirror,Parity) > disks (ServiceList) - List of disks to use (Disk) > stripeWidth (Integer) - Stripe width > stripeDepth (UAEnum) - Stripe depth (chunksize) (32KB,64KB,128KB,256KB,512KB,1024KB,2048KB) Returns: sizeInBytes

do AddInitiator - Adds an initiator > name (String) Returns: initiator (Initiator object)

3.4.2 Command Help

Typing help followed by a global or context-specific command displays help information about the command. The following example displays help for the global command do:

192.168.59.25 :: help do

Global Commands ----------------------------------------

Do Performs a command in current context

The following example displays help for the context-specific command createVolume:

192.168.59.25 :: help createvolume

Context Specific Commands ------------------------------

do CreateVolume - Creates a volume.

> name (String) - Volume name

> sizeInBytes (_ERROR_) - Volume size in bytes

> compositionName (UAEnum) - Volume composition

(JBOD,Stripe,Mirror,StripeMirror,Parity)

> disks (ServiceList) - List of disks to use (Disk)

> stripeWidth (Integer) - Stripe width

> stripeDepth (UAEnum) - Stripe depth

(32KB,64KB,128KB,256KB,512KB,1024KB,2048KB)

Returns: newVolume (Volume object)

30 Chapter 3 Using the CLI

3.4.3 Advanced Scripting Concepts

The CLI provides the ability to perform environment variable substitution. Variable substitution is the process of replacing a reference to the name of a variable with its actual value. Variable substitution is useful in Python, Perl, Bash, or other scripts that invoke predefined CLI script files and perform substitution at runtime.

The substitution syntax is ${varName}, with the information typed between the curly brackets specifying the variable name. Any time you use this syntax in a command line, the CLI expects the variable name in curly brackets to be the name of a variable. If you want the dollar sign preceding the first curly bracket to be interpreted as just a simple dollar sign, precede it with the backslash (\) “escape” character.

Example 1: The following example shows how variable substitution might work with a bash script. In this example, assume that a bash script has the following lines:

#!/bin/bash export VolName="MyNewVolName" cli2 –x DeleteVolume export VolName="Zeus" cli2 –x DeleteVolume

Also, assume that DeleteVolume.cli contains the following line:

VolumeList.Volumes[${VolName}].Delete

In this example, ${VolName} will be replaced with the volume named Zeus, which will be deleted.

Example 2: The following example shows how the backslash character can be used to have the CLI interpret a dollar sign character as just a simple dollar sign. In this example, assume that an ENV variable called envvar equals ABC. In this case, abc\${envvar} becomes abc${envvar}, while abc${envvar} becomes abcABC.

Command Line Interface User’s Guide 31

This Page Left Intentionally Blank

32 Chapter 3 Using the CLI

Chapter 4 Global Action Commands

This chapter describes the global action commands in the CLI. The topics covered in this chapter are:



Section 4.1, List of Global Action Commands (page 34)



Section 4.2, Description of Global Action Commands (page 35)

Command Line Interface User’s Guide 33

4.1 List of Global Action Commands

Global action commands help you navigate through the set of contexts, and perform controland configuration-related activities, such as piping output, setting operating modes, navigating contexts, and executing operating system functions.

Table 4-1 lists the global action commands in alphabetical order, and includes a description of the command and a link to the section that describes each command. The global action commands are described in detail, with examples, in the sections shown in the See Section column.

Command Description See Section

Do Performs a command in the current context. 4.2

Echo Echoes command lines to Standard Out (STDOUT). 4.2.2

Execute Executes a CLI script file. 4.2.3

Exit Ends the current CLI session. 4.2.4

Table 4-1. Global Action Commands

Help Displays all of the global and context-specific commands that the CLI supports. 4.2.5

List Displays a brief list of current context properties and methods. 4.2.6

Mode Sets the session operating modes. 3.2 and 4.2.7

Pop Returns to the context that was last pushed. 4.2.8

Push Saves the current context on a last-in-first-out (LIFO) stack and changes context. 4.2.9

RequireArgs Advanced feature intended for script files. 4.2.10

Select Changes contexts. 4.2.11

Set Sets a property in the current context. 4.2.12

ShiftArgs Advanced feature intended for script files. 4.2.13

Show Shows a property in the current context. 4.1.14

System Invokes a system shell command (equivalent to typing the prefix !). 4.2.15

34 Chapter 4 Global Action Commands

4.2 Description of Global Action Commands

4.2.1 Do

Use the Do command to perform a command in the current context. The command Do is the default action and can be omitted from action commands. For this reason, Do is shown within brackets in the syntax below.

Syntax



[Do] addInitiator <String>



[Do] createVolume <String> <SizeinBytes> <CompositionName> <Disks> <StripeWidth> <StripeDepth>



[Do] getMaxVolumeSize <CompositionName> <Disks> <StripeWidth> <StripeDepth>



[Do] getMaxVolumeStripeWidth <CompositionName> <Disks> <StripeWidth> <StripeDepth>



[Do] SystemRestart



[Do] SystemShutdown

Examples



Do SystemRestart

Restarts the system.



Do createVolume Venus 100GB jbod

Creates a new volume called Venus that is 100 GB in size and configured as a JBOD.



createVolume Venus 100GB jbod

Functionally equivalent to the previous command line, but with Do omitted.



Help Do

Displays help for the Do command.

Command Line Interface User’s Guide 35

4.2.2 Echo

Use the Echo command to echo command lines to Standard Out (STDOUT). When enabled, a copy of each command line you issue is sent to STDOUT. By default, echo is disabled. Issuing this command enables echo. Issuing the command again disables echo.

Syntax

Echo

Examples



Because Echo writes to STDOUT, it can be redirected.

Echo

Enables echo to STDOUT (if echo was disabled) or disables echo to STDOUT (if echo was enabled).

Help Echo

Displays help for the Echo command.

4.2.3 Execute

Use the Execute command to execute a text file containing one or more CLI command lines. Adding command lines to a file is particularly convenient if you will be performing repetitive operations on several systems: just enter the commands into a text file and then execute the text file each time you want to perform those operations. The text file extension must be .cli.

Syntax

Execute <pathname>

Examples



Execute createVols

Executes a file called CreateVols.cli that contains the following two CreateVolume commands to be performed:

Do createVolume CAD 30000000 mirror Do createVolume Exchange 125829120 parity [0,1,2,3] 4 512kb

In the command line example above, the .cli extension in the file name is assumed and should be omitted from the command line.

The CLI ignores blank lines or lines beginning with two forward slashes (//) in a script file. Therefore, you can add comment (remark) lines to a script file and not have the CLI execute them by starting the lines with //.



Help Execute

Displays help for the Execute command.

36 Chapter 4 Global Action Commands

4.2.4 Exit

Use the Exit command to end the current CLI session.

Syntax

Exit

Examples



4.2.5 Help

Use the Help command to display a list of the global action commands and context-specific commands supported by the CLI. If a global action or context-specific command follows Help, only help for the command is displayed. For more information, see section 3.4.

Exit

Closes the current CLI session.

Help Exit

Displays help for the Exit command.

Syntax

Help

Help <Command> where <Command> is either a global action command or a context-specific command.

Examples



Help

Displays all the global action and context-specific commands supported by the CLI.



Help Echo

Displays help for the Echo command.



Help CreateVolume

Displays help for the CreateVolume command.

Command Line Interface User’s Guide 37

4.2.6 List

Use the List command to list the current contexts and their properties (see the example below).

Syntax

List

Examples



4.2.7 Mode

Use the Mode command to set the CLI operating modes. Operating modes that can be set with this command include:



List

Displays a list of current contexts and properties.

Help List

Displays help for the List command.

Output mode – configures the output format from the CLI as human-readable, XML, or formatted XML.

Indication mode – displays messages when changes made to the system as a result of commands executed by you and other CLI users.

Stream mode – configures the CLI to either output error messages to STDERR and all other output to STDOUT, or direct all output (including error messages) to STDOUT.

Completion code mode – configures the CLI to return a confirmation message each time it executes (or tries to execute) a command line.



Echo command mode – repeats every character you type.



Exit script on error mode - lets the CLI exit a script automatically if the CLI encounters an error in the script.

38 Chapter 4 Global Action Commands

For more information, see section 3.2.

Syntax

Examples



Mode outputMode Normal

CLI output is displayed in human-readable format.



Mode outputMode XML

CLI output is nested together as XML, with XML tags.



Mode outputMode FormattedXML CLI output is nested together as XML, with XML tags.



Mode indicationMode Enabled

Enables indication mode, which displays messages of changes made to the system as a result of commands executed by you and other CLI users.



Mode indicationMode Disabled

Disables indication mode.



Mode streamMode Mixed_STDOUT_Only

Enables stream mode, directing all output to STDOUT.



Mode streamMode Mixed_STDOUT_STDERR Disables stream mode, directing error messages to STDERR and all other output to STDOUT.



Mode completionCodeMode Always

Enable completion code mode – return a completion code with each command line.



Mode completionCodeMode ErrorsOnly

Disable completion code mode – return a completion code only when a command line has an error.



Mode echoCommandMode Enabled

Enable echo command mode – repeats every command line character you type.



Mode echoCommandMode Disabled

Disable echo command mode – do not repeat every command line character you type.



Mode exitScriptOnError Enabled

Enable exit script on error – the CLI exits the script if an error is encountered.



Mode exitScriptOnError Disabled

Disable exit script on error – the CLI doe not exit the script if an error is encountered.



Help Mode

Displays help for the Mode command.

Command Line Interface User’s Guide 39

4.2.8 Pop

As you execute command lines, you may navigate through various CLI context levels. For example, accessing diskList from the root level moves you down one level in the CLI hierarchy. From this level, you can access Disk (two levels down from the root) and Extent (three levels down from the root).

Using the Pop command, you can move up in the CLI hierarchy. The number of levels you move up depends on whether you used the Push or Select command to move down in the hierarchy.



Syntax

Pop

Examples



If you used the Push command, the Pop command moves you up one level.

If you used the Select command, the Pop command moves you to the top (root) level in the CLI hierarchy.

Pop

Moves you up one level in the CLI hierarchy (if you previously used a Push command) or to the root level (if you previously used a Select command). If you are at the root level, issuing this command displays the error message Content Stack empty.



4.2.9 Push

Use the Push command to move down one level in the CLI hierarchy. The context is added to the push/pop stack. Issuing a Pop command after a Push command moves you up one level at a time in the hierarchy.

Syntax

Push <context>

where <context> is a member of the current context that returns a context. From the root context, for example, you can issue the command Push diskList because diskList is a property in the root context.

Examples



Help Pop

Displays help for the Pop command.

Push volumeList.volumes[mynewvolume] Pushes a volume called mynewvolume.

192.168.56.125 :: push iscsi.targets[$first]

Changes the context to the first iSCSI target, which is accessible from the top-level system context, then the iSCSI context, and finally the targets context.

40 Chapter 4 Global Action Commands



Controller[A] :: push ^iscsi.targets[$first]

Changes the context to the first iSCSI target, even though the current context is Controller[A].



Help Push

Displays help for the Push command.

4.2.10 RequireArgs

The requireArgs command is an advanced feature intended for use with script files. This command lets you specify the required number of arguments for subsequent commands.

If a CLI script has this command and the number of arguments provided does not provide at least the number of required arguments specified with RequireArgs, the script is terminated.

Syntax

requireArgs <integer> [optionalDisplayStringOnError]

where <integer> is the required number of arguments for subsequent commands and [optionalDisplayStringOnError] is a string that is displayed to the user if the argument count is not satisfied.

Examples



requireArgs 8

Checks that at least 8 arguments are present for the current script, and terminates the script if not.



Help requireArgs

Displays help for the RequireArgs command.

Command Line Interface User’s Guide 41

4.2.11 Select

Use the Select command to change contexts to the argument specified. The context is not added to the push/pop stack. As a result, issuing a Pop command after a Select command moves you to the top (root) level context of the CLI hierarchy.

Syntax

Select <context>

where <context> is a member of the current context (or a concatenated member reference) that returns a context. From the root context, for example, you can issue the command Select diskList because diskList is a property in the root context.

Examples



Select Controller[a]

Displays the new context in the prompt.

In the following example, at the System context of machine 192.168.59.25, the command line jumps directly to the context Controller. Then a show command displays the properties of the Controller context.

192.168.59.25 :: Select Controller[a] Controller[A] :: show ID = A Status = OK IsActive = true SlotNumber = 0 SerialNumber = 00001 DriveSlots = 12 NumFrontPorts = 8 DisplayName = Blade A SoftwareVersion = 2.5.1.21 IsAlternateSoftwareVersionPresent = true AlternateSoftwareVersion = 2.5.1.21 BoardType = 0009 BoardTypeRevision = XC05 I8kHwVersion = 1.0.0.0 I8kSwVersion = 0.1.0.0 MpuSwVersion = 2.5.1.21 BindFailReason = Bind_OK BladeHealth = Healthy BladeState = Bound BladeType = SFF PersistenceSetting = Unchanged BatteryState = Failed BufferMemDimmCnt = 2 BufferMemSize = 2048 SystemMemDimmCnt = 2 SystemMemSize = 512 SystemTime = 13:18:27 Ports = 8 Ports LAGs = 8 LAGs ManagementPort = ManagementPort [192.168.56.138], Status=OK BasePool = [BaseA], 2 disks

42 Chapter 4 Global Action Commands



Help Select

Displays help for the Select command.

4.2.12 Set

Use the Set command to set a property in the current context.

Syntax

Set <memberName> <newvalue>

Examples



Set name Zeus

Sets the array name to Zeus.



Help Set

Displays help for the Set command.

4.2.13 ShiftArgs

The shiftArgs command is an advanced feature intended for use with script files. This command left-shifts off a minimum number of arguments.

This command is useful when working with an external text file containing command line parameters and arguments. It is particularly useful if you will be performing repetitive operations on several systems where argument shifting is required. If <integer> is omitted from the command line, 1 is assumed.

Syntax

shiftArgs <integer>

Examples



shiftArgs

If a script has arguments 0, 1, and 2, including this command strips the leftmost argument (0), resulting in arguments 1 and 2 being passed (as arguments #0 and #1).



shiftArgs 2

If a script has arguments 0, 1, and 2, including this command strips the two leftmost arguments (0,1), resulting in argument 2 being passed (as argument #0).



Help shiftArgs

Displays help for the ShiftArgs command.

Command Line Interface User’s Guide 43

4.2.14 Show

Use the Show command to show a property in the current context.

Syntax

Show

Examples



Show

Displays the properties in the current context, as shown in the following example.

In the following example, the show command displays the properties of the

iSCSITarget context for the target named “myvol”.

iSCSITarget[two] :: show

ID = myvol

Status = OK

DurableName = iqn.2000-03.com.D-Link:myvol:6-001215-0200005d6-484f4348e87aea61

Name = myvol

Secret =

IsChapRequired = false

PrimaryAuthenticationMethod = NO_AUTHENTICATION

SecondaryAuthenticationMethod = CHAP

MaxReceiveDataSegmentLength = 32768

PrimaryHeaderDigestMethod = NO_DIGEST

PrimaryDataDigestMethod = NO_DIGEST

SecondaryHeaderDigestMethod = CRC32C

SecondaryDataDigestMethod = CRC32C

RequestingMarkersOnReceive = false

MaxConnectionsPerSession = 8

InitialR2TPreference = true

ImmediateDataPreference = false

MaxOutstandingR2T = 8

MaxUnsolicitedFirstDataBurstLength = 8192

MaxDataBurstLength = 262144

DataSequenceInOrderPreference = true

DataPDUInOrderPreference = true

DefaultTimeToWaitPreference = 2

DefaultTimeToRetainPreference = 20

ErrorRecoveryLevelPreference = 0

Initiators = 0 Initiators

Sessions = 0 Sessions

Volume = [myvol], State=Normal, Composition=JBOD, Size=10.00GB



Help Show

Displays help for the Show command.

44 Chapter 4 Global Action Commands

4.2.15 System

Use the System command to invoke a system shell command. (This command is equivalent to adding a ! prefix to a command line.)

Syntax

System <DOS command>

where <DOS command> is the name of the DOS command you want performed.

Examples



System "dir c:\\"

Displays the results of the DOS command (in this example, the contents of the root directory on the C drive are displayed).

!dir c:\

Displays the results of the DOS command (in this example, the contents of the root directory on the C drive are displayed).

Help System

Displays help for the System command.

Command Line Interface User’s Guide 45

This Page Left Intentionally Blank

46 Chapter 4 Global Action Commands

Chapter 5 Supported CLI Commands and Properties

This chapter describes the commands and properties supported by the CLI. Each section describes the commands and properties specific to that context.

The topics covered in this chapter are:



Section 5.1, System Commands and Properties (page 48)



Section 5.2, Controller Commands and Properties (page 49)



Section 5.3, PhysicalPort Commands and Properties (page 52)



Section 5.4, PoolList Commands and Properties (page 53)



Section 5.5, DiskList Property (page 53)



Section 5.6, Disk Commands (page 54)



Section 5.7, VolumeList Property (page 55)



Section 5.8, Volume Commands and Properties (page 55)



Section 5.9, VolumeComposition Properties (page 57)



Section 5.10, Extent Properties (page 57)



Section 5.11, TaskList Property (page 58)



Section 5.12, Task Commands and Properties (page 59)



Section 5.13, iSCSI Commands and Properties (page 59)



Section 5.14, iSCSITarget Commands and Properties (page 61)



Section 5.15, iSCSISession Properties (page 64)



Section 5.16, iSCSIConnection Properties (page 65)



Section 5.17, Portal Commands and Properties (page 66)



Section 5.18, Initiator Commands and Properties (page 67)



Section 5.19, AdvancedSettings Commands and Properties (page 68)



Section 5.20, SystemPolicy Properties (page 69)



Section 5.21, ExternalConnectionsManager Properties(page 70)



Section 5.22, SystemStatistics Properties(page 71)



Section 5.23, LAG Commands and Properties (page 72)



Section 5.24, ManagementPort Commands and Properties (page 73)



Section 5.25, NetworkRoute Commands and Properties (page 74)



Section 5.26, ServicePool Commands and Properties (page 75)

Command Line Interface User’s Guide 47

5.1 System Commands and Properties

System commands and properties let you perform system-related activities, such as creating volumes, configuring, restarting, or shutting down the array. System commands are issued at the System context.

Table 5-1 provides an alphabetical list of the commands in the System context and Table 5-2 provides an alphabetical list of the properties in the System context. Both tables include a description of the command or property, and the global action commands that can be used with the command or property, and the return parameter. For example, in Table 5-1, AddInitiator can be used with the global action commands Do, Push, and Select, and the command returns a context.

Table 5-1. System Context Commands

System Context Command Description Associated Global Action Commands Return Parameter

AddInitiator Adds an iSCSI initiator Do/Push/Select Context

CreateVolume Creates a volume Do/Push/Select Context

MaxVolumeSize Obtains the maximum volume size Do Value

MaxVolumeStripeWidth

SystemRestart Reboots the system Do No Return Value

SystemShutdown Shuts down the system Do No Return Value

Obtains the maximum stripe width supported for a volume type

Do Value

48 Chapter 5 Supported CLI Commands and Properties

Table 5-2. System Context Properties

System Context Property Description Associated Global Action Commands Return Parameter

AdvancedSettings

BindFailReason

BladeType Displays the controller type Show Value

Controllers

DiskList Lets you access the DiskList service Show/Push/Select Context

DurableName Displays the durable name of the controller Show Value

EventHD-Linky

ExternalConnectionsManager

Identity Returns the Product Short Name identity. Show Value

ID The IP Address of the Management Port Show Value

iSCSI Lets you access the iSCSI Service Show/Push/Select Context

Name Returns the name of the array Show Value

Lets you access the system’s advanced settings

Displays the reason for a Bind failure (defined for DSN-5000 systems only)

Lets you access a vector of all controllers in the system

Lets you access the Event HD-Linky information

Lets you access the External Connections Manager

Sets the name of the array Set Value

Show/Push/Select Context

Show/Show[ID]/Push[ID]/Select[ID] Context List

Show/Push/Select Context

PoolList Lets you access the poolList. Show/Push/Select Context

ProductID Displays the controller type Show Value

RevisionLevel Displays the controller software revision Show Value

SerialNumber Displays the system serial number Show Context

Status Displays the system status Show Value

SystemState

SystemStatistics Lets you access the SystemStatistics object Show/Push/Select Context

TaskList Lets you access the TaskList Show/Push/Select Context

VendorId Displays the vendor name of the SCSI Inquiry Show Value

VolumeList Lets you access the VolumeList Show/Push/Select Context

Displays the system state (e.g., Standalone, Bound, Survivor, etc.)

Show Value

Command Line Interface User’s Guide 49

5.2 Controller Commands and Properties

Controller commands and properties let you perform controller-related activities, such as creating Link Aggregation Groups (LAGs); returning the number of drive slots, serial number, or name of a controller; and restarting the controller. Table 5-3 provides an alphabetical list of the commands in the Controller context and

Table 5-4 provides an alphabetical list of the properties in the Controller context. Both tables include a description of the command or property, the global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-3, for example, CreateLAG is used with the global action commands Do, Push, and Select.

Table 5-3. Controller Commands

Command Description Associated Global Action Commands Return Parameter

CreateLAG Lets you create a LAG

ControllerRestart Restarts the controller

ControllerShutdown Shuts down the controller

Do/Push/Select Context

Do No Return Value

Table 5-4. Controller Properties

Property Description Associated Global Action Commands Return Parameter

AlternateSoftwareVersion Returns the software version

in the alternate partition of the controller

BasePool Lets you access the system’s

base pool

BatteryState Returns the battery state

BindFailReason Returns the results of the

attempted BIND operation (dual controller systems only)

BladeHealth Returns the health of the

controller

BladeState Returns the Bind status of the

controller (Standalone, Bound, Survivor, etc.)

BladeType Returns the controller

hardware type (“SFF” for DSN5000-series. or “ATX” for DSN1000/2000/3000 series controllers)

BoardType Returns the hardware type (a

numeric identifier to identify the product configuration)

BoardTypeRevision Returns the hardware revision

BufferMemDimmCnt Returns the number of Buffer

Memory DIMM modules

Show Value

Show/Push/Select Context

Show Value

50 Chapter 5 Supported CLI Commands and Properties

Property Description Associated Global Action Commands Return Parameter

BufferMemSize Returns the amount of Buffer

Memory measured in MB

ControllerStatusDescription Returns controller status

DisplayName Returns the display name of

the controller

DriveSlots Returns the number of drive

bays

I8kHwVersion Returns the hardware revision

of the iSNP8008 ASIC

I8kSwVersion Returns the software revision

of the iSNP8008 ASIC

ID Returns the controller ID (A or

IsActive Indicates whether a controller

in a bound pair is active

IsAlternateSoftwareVersionPresent Indicates whether an alternate

firmware version is present

LAGs Lets you access array LAGs

ManagementPort Lets you access the service

management port

MpuSwVersion Returns the software version

that is running in the controller

NumFrontPorts Returns the number of iSCSI

data ports

PersistenceSetting Returns the state of the

controller’s persistence data

Ports Lets you access array Ports

SerialNumber Returns the serial number of

controller

SlotNumber Returns the slot number of the

controller (0 or 1)

SoftwareVersion Returns the software version

in the active partition of the controller

Status Returns the overall status of

the controller

SystemMemDimmCnt Returns the number of System

Memory DIMM modules

SystemMemSize Returns the amount of System

Memory measured in MB

SystemTime Returns the system time

Sets the system time

Show Value

Show/Show[ID]/Push[ID]/Select[ID] ContextList

Show/Push/Select Context

Show Value

Show/Show[ID]/Push[ID]/Select[ID] ContextList

Show Value

Show Value (hh:mm:ss)

Set Value (hh:mm:ss)

Command Line Interface User’s Guide 51

5.3 PhysicalPort Commands and Properties

PhysicalPort commands and properties let you perform activities related to an array’s physical ports, such as returning a port number, port state, or port speed. Table 5-5 lists the command in the PhysicalPort context and Table 5-6 provides an alphabetical list of the properties in the PhysicalPort context. Both tables include a description of the command or property, the global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-5, for example, RemoveFromLAG is used with the global action command Do.

Table 5-5. PhysicalPort Command

Command Description

Enable Enables the port Do No Return Value

Disable Disables the port Do No Return Value

RemoveFromLAG Removes the port from its current LAG Do No Return Value

Associated Global

Action Commands

Return Parameter

Table 5-6. PhysicalPort Properties

Property Description Associated Global Action Commands Return Parameter

IsEnabled Returns the Is Enabled state Show Value

LAG Returns the LAG Show/Push/Select Context

Sets the LAG Set Context

Name Returns the port name Show Value

PortNumber Returns the port number Show Value

PortState Returns the port state Show Value

Speed

Returns the port link speed in

bits per second

Show Value

52 Chapter 5 Supported CLI Commands and Properties

5.4 PoolList Commands and Properties

PoolList commands and properties let you perform activities related to drive pools, such as accessing the global available pool or global unavailable pool, accessing disks, and accessing the global spare pool. Table 5-7 provides an alphabetical list of the commands in the PoolList context and Table 5-8 provides an alphabetical list of the properties in the PoolList context. Both tables include a description of the command or property, the global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-7, for example, CreateVolume is used with the global action commands Do, Push, and Select.

Command Description Associated Global Action Commands Return Parameter

CreateVolume Creates a volume. Do/Push/Select Context

MaxVolumeSize Returns the maximum volume size Do Value

Table 5-7. PoolList Commands

Table 5-8. PoolList Properties

Property Description Associated Global Action Commands Return Parameter

GlobalAvailablePool

GlobalSparePool

GlobalUnavailablePool

Disks Lets you access drives Show/Show[ID]/Push[ID]/Select[ID] ContextList

PoolName Returns the pool name Show

Pools Lets you access pools Show/Show[ID]/Push[ID]/Select[ID] ContextList

PoolType Returns the pool type Show Value

5.5 DiskList Property

The DiskList property lets you perform tasks related to arrays of disks. Table 5-9 describes the property in the DiskList context, the global action commands that can be used with the property, and the return parameter. In Table 5-9, for example, Disks is used with the global action commands Show, Push, and Select.

Lets you access the available pool of drives

Lets you access the spares for the system

Lets you access the unavailable pool of drives

Show/Push/Select Context

Property Description Associated Global Action Commands Return Parameter

Disks Lets you access the array of disks in this list Show/Show[ID]/Push[ID]/Select[ID] ContextList

Command Line Interface User’s Guide 53

Table 5-9. DiskList Property

5.6 Disk Commands

Disk commands and properties let you perform disk-related activities, such as viewing a drive’s capacity or free space, link speed, or a number of an enclosure containing a drive. Table 5-10 provides an alphabetical list of the commands in the Disk context and Table 5-11 provides an alphabetical list of the properties in the Disk context (although some properties may be unique to SAS or SATA drive types). Both tables include a description of the command or property, the global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-10, for example, DownDrive is used with the global action command Do.

Command Description Associated Global Action Commands Return Parameter

DownDrive Downs the drive Do No Return Value

InitDrive Initializes the drive Do No Return Value

Table 5-10. Disk Commands

Table 5-11. Disk Properties

Property Description

ActualLinkSpeed Returns the actual link speed Show Value

ATAVersion Returns the ATA version Show Value

DriveNumber Returns the drive number Show Value

DriveType Returns the type of drive Show Value

EnclosureNumber Returns the enclosure the disk is in Show Value

Extents Lets you access all the extents on the disk Show/Show[ID]/Push[ID]/Select[ID] ContextList

FreeSpaceSize Returns the amount of free space Show Value

PhysicalCapacity Returns the total drive capacity Show Value

Pool Lets you access the pool to which the disk belongs Show/Push/Select Context

Pool Sets the pool to which the disk belongs Set Context

SASChannelNumber Returns the channel number of the SAS drive Show Value

SATAQueueDepth Returns the SATA queue depth Show Value

SATAQueueingSupport Returns the SATA queuing support setting Show Value

SerialNumber Returns the serial number Show Value

SlotNumber Returns the slot number in which the disk is

installed

State Returns the drive state Show Value

Supports48BitAddress Returns TRUE if the drive supports 48-bit

addressing or FALSE if the drive does not support it

SupportedLinkSpeeds Returns supported link speeds Show Value

Tasks Returns an array of all the tasks for this disk Show/Show[ID]/Push[ID]/Select[ID] ContextList

Vendor Returns the drive manufacturer Show Value

VendorModel Returns the vendor model Show Value

Associated Global

Action Commands

Show Value

Return

Parameter

54 Chapter 5 Supported CLI Commands and Properties

5.7 VolumeList Property

The VolumeList property lets you access all volumes in a list. Table 5-12 describes the property in the VolumeList context, the global action commands that can be used with the property, and the return parameter. In Table 5-12, for example, Volumes is used with the global action commands Show, Push, and Select.

Property Description Associated Global Action Commands Return Parameter

Volumes Lets you access all the volumes in the list Show/Show[ID]/Push[ID]/Select[ID] ContextList

5.8 Volume Commands and Properties

Volume commands and properties let you perform volume-related activities, such a growing, deleting, or scanning a volume for integrity. Table 5-13 provides an alphabetical list of the commands in the Volume context and Table 5-14 provides an alphabetical list of the properties in the Volume context. Both tables include a description of the command or property, the global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-13, for example, Delete is used with the global action command Do. For a detailed description of the syntax and parameters of these commands, refer to the Help command.

Table 5-12. Volume Property

Table 5-13. Volume Commands

Command Description

Delete Deletes the volume Do No Return Value

GrowTo Grows the volume to the specified size Do No Return Value

IntegrityScanNow Scans the volume for integrity (media and possibly parity) Do No Return Value

IntegrityScanAt Scans the volume for integrity (media and possibly parity) Do No Return Value

MaxGrowSize Expands the maximum size to which a volume can grow Do Value

Reconfigure Reconfigures the volume Do No Return Value

Associated Global

Action Commands

Return Parameter

Command Line Interface User’s Guide 55

Table 5-14. Volume Properties

Property Description Associated Global

CompositionName Returns the name of the composition type Show Value

DurableName Returns the durable name Show Value

Initiators Returns all iSCSI initiators for an array Show/Show[ID]/Push[ID]/Select[ID] ContextList

IsReadOnly Returns a flag indicating read only (R/O) or

read/write (R/W)

IsReadOnly Sets the flag indicating R/O or R/W Set Value

IsReconfiguring Returns a Boolean value indicating whether

the volume is currently being reconfigured

IsSyncCacheDisabled Returns a flag indicating whether Sync Cache

is disabled (Sync Cache becomes NOP)

IsSyncCacheDisabled Sets the flag indicating whether Sync Cache

is disabled (Sync Cache becomes NOP)

Name Returns the volume name Show Value

Name Sets the volume name Set Value

NSPOF Returns the No Single Point of Failure flag Show Value

State Shows the volume state Show Value

Size Shows the volume size Show Value

Action Commands

Show Value

Set Value

Return Parameter

StripeDepth Shows the stripe depth Show Value

StripeWidth Shows the stripe width Show Value

Target Lets you access the associated iSCSI target Show/Push/Select Context

Tasks Lets you access all volume tasks for an array Show/Show[ID]/Push[ID]/Select[ID] ContextList

VolumeComposition Lets you access the VolumeComposition

object.

ReadAheadSizeIsAutomatic Returns a Boolean value to that indicates

whether the Read Ahead Cache Size should be determined automatically

ReadAheadSizeIsAutomatic Sets a flag indicating whether the Read

Ahead Cache Size should be determined determined

MaxReadAheadByteCount Returns the maximum size of the Read

Ahead Cache (in megabytes) for the volume

ReadAheadByteCount Sets the size of the Read Ahead Cache for

the volume ( “ReadAheadSizeIsAutomatic” must also be set to “FALSE”)

ReadAheadByteCount Returns a numeric value for the Read Ahead

Cache Size (in Kbytes) for the volume

IsOptimizedForMultiTrackAudio Sets the multi-track audio optimization mode Set (TRUE or FALSE) Value

IsOptimizedForMultiTrackAudio Shows the current mode Show Value

Show/Push/Select Context

Show Value

Set Value

Show Value

Set Value

Show Value

BlockSizeBytes Sets the size of the volume block size to

BlockSizeBytes Returns the volume block size Show Value

56 Chapter 5 Supported CLI Commands and Properties

either 512 bytes or 4096 bytes

Set Value

5.9 VolumeComposition Properties

VolumeComposition properties let you view a volume’s composition name and access extents. Table 5-15 provides an alphabetical list of the properties in the VolumeComposition context, a description of the property and the global action commands that can be used with the property, and the return parameter. In Table 5-15, for example, CompositionName is used with the global action command Show.

Property Description Associated Global Action Commands Return Parameter

CompositionName Returns the name of the composition Show Value

Table 5-15. VolumeComposition Properties

Extents

5.10 Extent Properties

Extent properties let you perform activities related to extents, such as returning the size, state, or composition name of an extent. Table 5-16 provides an alphabetical list of the properties in the Extent context, a description of the property and the global action commands that can be used with the command or property, and the return parameter. In Table 5-16, for example, CompositionName is used with the global action command Show.

Property Description

CompositionName Returns the volume composition Show Value

Disk Lets you access the disk containing the extent Show/Push/Select Context

ExtentMemberElementBlockNumber Returns the element block number Show Value

ExtentState Returns the current state Enum of the extent Show Value

MemberBlockNumber

Lets you access all the extents for this volume

Table 5-16. Extent Properties

Returns the member block number within the volume

Show/Show[ID]/Push[ID]/Select[ID] ContextList

Associated Global

Action Commands

Show Value

Return Parameter

MirrorElementNumber Returns the mirror element number Show Value

PhysicalBlockNumber Returns the physical block number on the disk Show Value

Size Returns the size of the extent Show Value

StripeElementNumber Returns the stripe element number Show Value

Volume

Command Line Interface User’s Guide 57

Lets you access the volume associated with the extent

Show/Push/Select Context

5.11 TaskList Property

The TaskList property lets you access the tasks available for an array. Table 5-17 lists the property in the TaskList context, the global action commands that can be used with the property, and the return parameter. In the table below, for example, Tasks is used with the global action commands Show, Push, and Select.

Property Description Associated Global Action Commands Return Parameter

Tasks Lets you access the array of tasks Show/Show[ID]/Push[ID]/Select[ID] ContextList

Table 5-17. TaskList Properties

58 Chapter 5 Supported CLI Commands and Properties

5.12 Task Commands and Properties

Task commands and properties let you perform task-related activities such as scheduling, modifying, and suspending tasks. Table 5-18 provides an alphabetical list of the commands in the Task context and Table 5-19 provides an alphabetical list of the properties in the Task context. Both tables include a description of the command or property, the global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-18, for example, Cancel is used with the global action command Do.

Command Description Associated Global Action Commands Return Parameter

Cancel Cancels a task Do No Return Value

Delete Deletes a task Do No Return Value

Modify Modifies a task Do No Return Value

Resume Resumes a suspended task Do No Return Value

Suspend Suspends the task Do No Return Value

Table 5-18. Task Commands

Table 5-19. Task Properties

Property Description Associated Global Action Commands Return Parameter

EstimatedCompletionTime Estimate completion time Show

ObjectName Returns the object name Show

PercentComplete Returns a task’s percent completion Show

PeriodicityType Returns the units of the periodicity interval Show

Priority Returns the task priority Show

Sets the task priority Set

ScheduledStartTime Returns the scheduled start time Show

StartTime Returns the task start time Show

State Returns the task state Show

StatusDescription Returns the status description Show

TaskID Returns the task ID Show

Value

Command Line Interface User’s Guide 59

5.13 iSCSI Commands and Properties

iSCSI commands and properties lets you perform iSCSI-related activities such as creating LAGs and accessing ports, portals, targets, and iSCSI initiators. Table 5-20 provides an alphabetical list of the commands in the iSCSI context and Table 5-21 provides an alphabetical list of the properties in the iSCSI context. Both tables include a description of the command or property, the global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-20, for example, CreateLAG is used with the global action commands Do, Push, and Select.

Command Description Associated Global Action Commands Return Parameter

CreateLAG Creates a LAG Do/Push/Select Context

CreateStaticRoute Creates a static route entry Do No Return Value

Property Description Associated Global Action Commands Return Parameter

Table 5-20. iSCSI Commands

Table 5-21. iSCSI Properties

Initiators

LAGs Lets you access the array LAGs Show/Show[ID]/Push[ID]/Select[ID] ContextList

Portals Lets you access the array portals Show/Show[ID]/Push[ID]/Select[ID] ContextList

Ports

StaticRoutes

Targets Lets you access the array targets Show/Show[ID]/Push[ID]/Select[ID] ContextList

Lets you access the array initiators

Lets you access the array physical ports

Lets you access the array static routing table entries

Show/Show[ID]/Push[ID]/Select[ID] ContextList

60 Chapter 5 Supported CLI Commands and Properties

5.14 iSCSITarget Commands and Properties

iSCSITarget commands and properties let you perform activities related to iSCSI targets such as setting and returning a CHAP secret, setting and viewing authentication and digest methods, and viewing durable names. Table 5-22 provides an alphabetical list of the commands in the iSCSITarget context and Table 5-23 provides an alphabetical list of the properties in the iSCSITarget context. Both tables include a description of the command or property, the global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-22, for example, GrantInitiatorAccess is used with the global action command Do.

Table 5-22. iSCSITarget Commands

Command Description Associated Global Action Commands Return Parameter

GrantInitiatorAccess Grants initiator access to this target Do No Return Value

RevokeInitiatorAccess Revokes initiator access to this target Do No Return Value

Table 5-23. iSCSITarget Properties

Property Description

DataPDUInOrderPreference

DataSequenceInOrderPreference

DefaultTimeToRetainPreference

DefaultTimeToWaitPreference

DurableName Returns the durable name Show

ErrorRecoveryLevelPreference

Returns the data PDU in order preference

Sets the data PDU in order preference

Returns the data sequence In order preference

Sets the data sequence in order preference

Returns the default time to retain preference

Sets the default time to retain preference

Returns the default time to wait preference

Sets the default time to wait preference

Returns the error recovery level preference

Show

Set

Show

Set

Show

Set

Show

Set

Show

Associated Global

Action Commands

Return

Parameter

Value

ImmediateDataPreference Returns immediate data preference Show

InitialR2TPreference Returns the initial R2T preference Show

Command Line Interface User’s Guide 61

Sets the error recovery level preference

Sets the immediate data preference Set

Set

Value

Property Description

Sets the initial R2T preference Set

Initiators Lets you access the array initiators Show/Show[ID]/Push[ID]/Select[ID] ContextList

IsChapRequired

MaxConnectionsPerSession

MaxDataBurstLength

MaxOutstandingR2T

MaxReceiveDataSegmentLength

Indicates whether the “CHAP is Required” setting is set

Returns the maximum connections per session

Sets the maximum connections per session

Returns the maximum data burst length

Sets the maximum data burst length Set

Returns the maximum outstanding R2T

Sets the maximum outstanding R2T Set

Returns the maximum receive data segment length

Sets the maximum receive data segment length

Associated Global

Action Commands

Show

Set

Show

Set

Return

Parameter

Value

MaxUnsolicitedFirstDataBurstLength

Name Returns the target name Show

PrimaryAuthenticationMethod

PrimaryDataDigestMethod

PrimaryHeaderDigestMethod

RequestingMarkersOnReceive

SecondaryAuthenticationMethod

Returns the maximum unsolicited first data burst length

Sets the maximum unsolicited first data burst length

Sets the target name Set

Returns the primary authentication method

Sets the primary authentication method

Returns the primary data digest method

Sets the primary data digest method Set

Returns the primary header digest method

Sets the primary header digest method

Returns the requesting markers on receive

Returns the secondary authentication method

Show

Set

Show

Set

Show

Set

Show

Value

62 Chapter 5 Supported CLI Commands and Properties

Sets the secondary authentication method.

Set

Value

Property Description

SecondaryDataDigestMethod

SecondaryHeaderDigestMethod

Secret Returns a secret Show

Sessions Lets you access all current sessions Show/Show[ID]/Push[ID]/Select[ID] ContextList

Volume

Returns the secondary data digest method

Sets the secondary data digest method

Returns the secondary header digest method

Sets the secondary header digest method

Sets the secret Set

Lets you access the associated volume

Associated Global

Action Commands

Show

Set

Show

Set

Show/Push/Select Context

Return

Parameter

Value

Command Line Interface User’s Guide 63

5.15 iSCSISession Properties

iSCSISession properties let you perform activities related to iSCSI sessions such as accessing current connections and viewing session types and error recovery levels. Table 5-24 provides an alphabetical list of the properties in the iSCSISession context, a description of the property and the global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-24, for example, Connections is used with the global action commands Show, Push, and Select.

Table 5-24. iSCSISession Properties

Property Description

Connections

CurrentConnections Returns the current connections count Show Value

DataPDUInOrder Returns the data PDU in order Show Value

DataSequenceInOrder Returns the data sequence in order Show Value

DefaultTimeToRetain Returns the default time to retain Show Value

DefaultTimeToWait Returns the default time to wait Show Value

EndPointName Returns the end point name Show Value

ErrorRecoveryLevel Returns the error recovery level Show Value

ImmediateData Returns the immediate data value Show Value

InitialR2T Returns the initial R2T value Show Value

Initiator Returns the initiator for this session Show/Push/Select Context

InitiatorGlobalID Returns the global initiator ID Show Value

MaxConnectionsPerSession

Lets you access all the current connections in this session

Returns the maximum number of connections per session

Associated Global Action

Commands

Show/Show[ID]/Push[ID]/Select[ID] ContextList

Show Value

Return

Parameter

MaxDataBurstLength Returns the maximum data burst length Show Value

MaxOutstandingR2T Returns the maxoutstandingr2t Show Value

MaxUnsolicitedFirstDataBurstLength

Name Returns the name Show Value

SessionType Returns the session type Show Value

Target Returns the target Show/Push/Select Context

TSIH

64 Chapter 5 Supported CLI Commands and Properties

Returns the maximum unsolicited first data burst length

Returns the Target Session Handle (TSIH)

Show Value

5.16 iSCSIConnection Properties

iSCSIConnection properties let you perform activities related to iSCSI connections such as accessing a portal and viewing TCP port numbers and connection IDs . Table 5-25 provides an alphabetical list of the properties in the iSCSIConnection context, a description of the property and the global action commands that can be used with the command or property, and the return parameter. In Table 5-25, for example, ActiveiSCSIVersion is used with the global action command Show.

Table 5-25. iSCSIConnection Properties

Property Description

ActiveiSCSIVersion Returns the active iSCSI version Show Value

AuthenticationMethodUsed Returns the authentication method used Show Value

ConnectionID Returns the connection ID Show Value

DataDigestMethod Returns the data digest method Show Value

HeaderDigestMethod Returns the header digest method Show Value

InstanceID Returns the connection instance ID Show Value

IPv4Address Returns the ipv4address for the connection Show Value

MaxReceiveDataSegmentLength Returns the maximum receive data segment length Show Value

MaxTransmitDataSegmentLength Returns the maximum transmit data segment length Show Value

MutualAuthentication Returns the mutual authentication flag Show Value

Name Returns the connection name Show Value

Portal Lets you access the portal Show/Push/Select Context

ReceivingMarkers Returns the receiving markers Show Value

SendingMarkers Returns the sending markers Show Value

Session Returns the session Show/Push/Select Context

Associated Global

Action Commands

Return Parameter

TcpPortNumber Returns the TCP port number for the connection Show Value

Command Line Interface User’s Guide 65

5.17 Portal Commands and Properties

Portal commands and properties let you perform portal-related activities such as returning a portal’s IP address or ping a port . Table 5-26 provides an alphabetical list of the commands in the Portal context and Table 5-27 provides an alphabetical list of the properties in the Portal context. Both tables include a description of the command or property, the global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-26, for example, Delete is used with the global action command Do.

Command Description Associated Global Action Commands Return Parameter

Delete Deletes the portal Do No Return Value

PingRemoteIPAddress Pings another IP address Do Value

Table 5-26. Portal Commands

Table 5-27. Portal Properties

Property Description

Connections

DefaultGateway Lets you access the default gateway for this portal Show Value

DynamicRoutes

IPAddress Returns the IP address of this portal Show Value

LAG Lets you access a LAG Show/Push/Select Context

PortNumber Returns the port number of this portal Show Value

SubnetMask Returns the subnet mask of this portal Show Value

VLANID Returns the VLAN ID of this portal Show Value

Lets you access the array of connections currently associated with this portal

Lets you access the array of dynamic routing table entries scoped to this portal

Associated Global

Action Commands

Show/Show[ID]/Push[ID]/Select[ID] ContextList

Return Parameter

66 Chapter 5 Supported CLI Commands and Properties

5.18 Initiator Commands and Properties

Initiator commands and properties let you perform iSCSI initiator-elated activities such as setting passwords and viewing iSCSI initiator IDs, names, and passwords. Table 5-28 lists the command in the Initiator context and Table 5-29 provides an alphabetical list of the properties in the Initiator context. Both tables include a description of the command or property, the global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-28, for example, Delete is used with the global action command Do.

Command Description Associated Global Action Commands Return Parameter

Delete Deletes the Initiator entry in the storage system Do No Return Value

Property Description Associated Global Action Commands Return Parameter

Table 5-28. Initiator Command

Table 5-29. Initiator Properties

GlobalID Returns the global ID Show Value

InitiatorID Returns the initiator ID Show Value

IsAllInitiators

Name Returns the initiator name Show Value

Sessions Lets you access the array sessions Show/Show[ID]/Push[ID]/Select[ID] ContextList

Secret Returns the password for this initiator Show Value

Targets Lets you access the array of targets Show/Show[ID]/Push[ID]/Select[ID] ContextList

Returns the IsAllInitiators flag to identify the special all-access-allowed instance

Sets the password Set Value

Show Value

Command Line Interface User’s Guide 67

5.19 AdvancedSettings Commands and Properties

AdvancedSettings commands and properties let you set and view advanced settings . Table 5-30 provides an alphabetical list of the commands in the AdvancedSettings context and Table 5-31 provides an alphabetical list of the properties in the AdvancedSettings context. Both tables include a description of the command or property, the global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-30, for example, ResetTcpipUpperLayerCounter is used with the global action command Do.

Table 5-30. AdvancedSettings Commands

Command Description

ForceControllerFailover

ResetTcpipUpperLayerCounter

RestoreToFactoryDefaults

RestoreConfiguration

SaveConfiguration

ForceSystemRestart Forces an orderly system shutdown and restart Do No Return Value

Causes a controller failover to occur when a bound pair of controllers exists.

Lets you access the Reset TCP/IP Upper Layer counter

Restores the array to its factory default settings Paramter: Boolean to include or exclude the Management Port IP Address as one of the parameters to be reset to factory defaults

Restores the system configuration from a local file. Parameters:

filePath: String for the path to the file onlySameChassis: Boolean to replace the

configuration ONLY if the saved data originated from the same chassis

Saves the current system configuration to a local file. Parameters:

filePath: String for the path to the file

Associated Global

Action Commands

Do No Return Value

Return Parameter

Table 5-31. AdvancedSettings Properties

Property Description

DefaultBackgroundTaskPriority Returns the default background task priority Show Value

iScsiPortNumber Returns the iSCSI port number Show Value

IsVirginConfiguration

SystemPolicy Lets you access the current battery policy Show/Push/Select Context

68 Chapter 5 Supported CLI Commands and Properties

Associated Global

Action Commands

Sets the default background task priority Set Value

Sets the iSCSI port number Set Value

Indicates whether the configuration is a virgin configuration

Sets the configuration is a virgin configuration Set Value

Show Value

Return Parameter

Property Description

TcpipMaxIpSegmentation

TcpipPmtuEnabled Returns the TCP/IP PMTU Enabled status Show Value

TcpipTimestampEnabled Returns the TCP/IP Timestamp Enabled status Show Value

TcpipTimeToLive Returns the TCP/IP Time To Live status Show

TcpipWindowScale Returns the TCP/IP Window Scale status Show

UserList Lets you access the user list Show/Push/Select Context

DefaultVolumeBlockSizeBytes

Returns the TCP/IP Max IP Segmentation value

Sets the TCP/IP Max IP Segmentation value Set Value

Sets the TCP/IP PMTU Enabled value Set Value

Sets the TCP/IP Timestamp Enabled value Set Value

Sets the TCP/IP Time To Live value Set

Sets the TCP/IP Window Scale value Set

Sets the default volume blocksize of either 512 bytes or 4096 bytes

Returns the default volume blocksize Show Value

Associated Global

Action Commands

Show Value

Return Parameter

Value

Set Value

5.20 SystemPolicy Properties

SystemPolicy properties let you perform activities related to the array’s battery policy. Table 5-32 provides an alphabetical list of the properties in the SystemPolicy context, along with a description of the property the global action commands that can be used with the property, and the return parameter. In Table 5-32, for example, BatteryPolicy is used with the global action commands Show and Set.

Property Description Associated Global Action Commands Return Parameter

BatteryPolicy Returns the array battery policy Show Value

Table 5-32. SystemPolicy Properties

Sets the array battery policy Set Value

Command Line Interface User’s Guide 69

5.21 ExternalConnectionsManager Properties

ExternalConnectionsManager properties lets you perform management activities related to external connections such as setting or viewing information email notification settings and iSNS settings. Table 5-33 provides an alphabetical list of the properties in the ExternalConnectionsManager context, a description of the property and the global action commands that can be used with the property, and the return parameter. In Table 5-33, for example, EmailFromAddress is used with the global action commands Show and Set.

Table 5-33. ExternalConnectionsManager Properties

Property Description

EmailFromAddress Returns the Email From Address value Show Value

Sets the Email From Address value Set Value

EmailNotificationEnabled Returns whether email notification is enabled Show Value

Sets the email notification enabled setting Set Value

EmailPassword Returns the email password Show Value

Sets the email password Set Value

EmailServerIPAddress Returns the email server IP address Show Value

Sets the email server IP address Set Value

EmailServerPortNumber Returns the email port number Show Value

Sets the email port number Set Value

EmailToAddress Returns the address where emails are to be sent Show Value

Sets the address where emails are to be sent Set Value

EmailUsername Returns the username to whom emails are to be sent Show Value

Sets the username to whom emails are to be sent Set Value

iSNSHeartbeatIpAddress Returns the iSNS Heartbeat IP address Set Value

Sets the iSNS Heartbeat IP address Show Value

iSNSHeartbeatEnabled Returns the iSNS Heartbeat Enabled value Show Value

Sets the iSNS Heartbeat Enabled value Set Value

iSNSHeartbeatSubnetMask Returns the iSNS Heartbeat subnet mask Show Value

Sets the iSNS Heartbeat subnet mask Set Value

iSNSServerIpAddress Returns the iSNS server IP address Show Value

Sets the iSNS server IP address Set Value

iSNSServerPortNumber Returns the iSNS server port number Show Value

Sets the iSNS server port number Set Value

iSNSServerSubnetMask Returns the iSNS server subnet mask Show Value

Sets the iSNS server subnet mask Set Value

NTPServerIPAddress Returns the NTP server IP address Show Value

Sets the NTP server IP address Set Value

Associated Global

Action Commands

Return Parameter

70 Chapter 5 Supported CLI Commands and Properties

Property Description

SNMPNotificationEnabled Returns whether SNMP Trap notification is enabled Show Value

Sets the SNMP Trap notification enabled setting Set Value

SNMPClientCommunityString Returns the SNMP Client Community String Show Value

Sets the SNMP Client Community String Set Value

SNMPClientIPAddress Returns the SNMP Client IP Address Show Value

Sets the SNMP Client IP Address Set Value

SNMPClientPortNumber Returns the SNMP Client Port Number Show Value

Sets the SNMP Client Port Number Set Value

5.22 SystemStatistics Properties

SystemStatistics properties let you access the system statistics for an array. Table 5-34 provides an alphabetical list of the properties in the SystemStatistics context, a description of the property and the global action commands that can be used with the property, and the return parameter. In Table 5-34, for example, InitiatorsActiveCount is used with the global action command Show.

Associated Global

Action Commands

Return Parameter

Table 5-34. SystemStatistics Properties

Property Description

InitiatorsActiveCount Returns the number of active iSCSI initiators Show

InitiatorsCount Returns the number of iSCSI initiators Show

StoragePerformance Returns storage performance information Show

StorageRedundancy Returns storage redundancy information Show

StorageUtilization Returns storage utilization information Show

TotalStorageCapacity Returns the total storage capacity Show

TotalAvailableCapacity Returns the total available capacity Show

TargetsWithoutInitiatorsCount

VolumeCount Returns the number of volumes Show

VolumesWithoutAccessCount

Returns the number of targets that do not have iSCSI initiators

Returns the number of volumes that do not have access

Associated Global

Action Commands

Show

Return Parameter

Value

Command Line Interface User’s Guide 71

5.23 LAG Commands and Properties

LAG commands and properties let you perform LAG-related activities, such as creating, disabling, and deleting a portal. Table 5-35 provides an alphabetical list of the commands in the LAG context and Table 5-36 provides an alphabetical list of the properties in the LAG context. Both tables include a description of the command or property, global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-35, for example, CreatePortal is used with the global action commands Do, Push, and Select.

Table 5-35. LAG Commands

Command Description

CreatePortal Creates a portal Do/Push/Select Context

Delete Deletes the LAG Do No Return Value

Disable Disables the LAG Do No Return Value

Enable Enables the LAG Do No Return Value

ReplaceLAGandChangeVLAN

Changes the VLAN Enabled flag by delete and recreate

Associated Global

Action Commands

Do No Return Value

Return Parameter

Table 5-36. LAG Properties

Property Description

ActiveMTU Returns the Active Maximum Transmission Unit Show

Sets the Active Maximum Transmission Unit Set

AutoSense Returns the AutoSense value in Boolean notation Show

Sets the AutoSense value in Boolean notation Set

FrameType Returns the Frame Type Show

Associated Global

Action Commands

Return Parameter

Value

IsEnabled

MACAddress Returns the LAG’s MAC address Show

Portals Lets you access the array of portals Show/Show[ID]/Push[ID]/Select[ID] ContextList

Ports Lets you access the array physical ports in the LAG Show/Show[ID]/Push[ID]/Select[ID] ContextList

RequestedSpeed Returns the Requested Speed Show

VLANState Returns the VLAN state Show

Returns the administrative enabled/disabled state in Boolean notation

Sets the requested speed Set

72 Chapter 5 Supported CLI Commands and Properties

Show

Value

5.24 ManagementPort Commands and Properties

ManagementPort commands and properties let you perform activities related to an array’s management port, such as viewing or setting the management port’s IP address or hostname. Table 5-37 provides an alphabetical list of the command in the ManagementPort context and Table 5-38 provides an alphabetical list of the properties in the ManagementPort context. Both tables include a description of the command or property, the global action commands that can be used with the command or property, and the return parameter. In Table 5-37, for example, PingRemoteIPAddress is used with the global action command Do.

Table 5-37. ManagementPort Command

Command Description Associated Global Action Commands Return Parameter

PingRemoteIPAddress Pings another IP address Do Value

Table 5-38. ManagementPort Properties

Property Description

BroadcastIpAddress

DynamicRoutes

Gateway

HostName Returns the system’s hostname Show

HostName Sets the system hostname Set

IPAddress

SubnetMask

Returns the system’s management broadcast IP address

Lets you access the array dynamic routing table entries scoped to this port

Returns the system’s management gateway IP address

Sets the system’s management gateway IP address

Returns the system’s management IP address

Sets the system’s management IP address

Returns the system’s management subnet mask

Sets the system’s management subnet mask

Show Value

Show/Show[ID]/Push[ID]/Select[ID] ContextList

Show

Set

Show

Set

Show

Set

Associated Global

Action Commands

Return Parameter

Value

Command Line Interface User’s Guide 73

5.25 NetworkRoute Commands and Properties

NetworkRoute commands and properties let you perform tasks related to network routes, such as returning a route’s destination IP address or values that indicate whether a network route is dynamic or usable. Table 5-39 lists the command in the NetworkRoute context and Table 5-40 provides an alphabetical list of the properties in the NetworkRoute context. Both tables include a description of the command or property, the global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-39, for example, Delete is used with the global action command Do.

Table 5-39. NetworkRoute Command

Command Description Associated Global Action Commands Return Parameter

Delete Deletes the route entry Do No Return Value

Table 5-40. NetworkRoute Properties

Property Description

DestinationIpAddress Returns the destination IP address for this route entry Show

DestinationIsGateway

DestinationSubnetMask

InterfaceName Returns the interface name for this route entry Show

IsDynamic

IsHost Returns the Is host Boolean value for this route entry Show

IsInitialRoundTripTime

IsModified

IsRouteUsable

IsSpecificMTU

IsWindowClamping

Returns the destination is gateway Boolean value for this route entry

Returns the destination subnet mask for this route entry

Returns the Is Dynamic Boolean value for this route entry

Returns the Is Initial Round Trip Time Boolean value for this route entry

Returns the Is Modified Boolean value for this route entry

Returns the Is Route Usable Boolean value for this route entry

Returns the Is Specific MTU Boolean value for this route entry

Returns the Is Window Clamping Boolean value for this route entry

Associated Global

Action Commands

Show

Return Parameter

Value

NextHopIpAddress Returns the Next Hop IP Address for this route entry Show

NumberOfHopsToDestination

Reinstate

RouteIsRejected

74 Chapter 5 Supported CLI Commands and Properties

Returns the Number of Hops to destination for this route entry

Returns the Reinstate Boolean value for this route entry

Returns the Route Is Rejected Boolean value for this route entry

Show

Value

Property Description

RouteIsStatic

Returns the Route Is Static Boolean value for this route entry

5.26 ServicePool Commands and Properties

ServicePool commands and properties let you perform tasks related to pools of disks, such as accessing disks in a pool or obtaining the name of a pool. Table 5-41 lists the command in the ServicePool context and Table 5-42 provides an alphabetical list of the properties in the ServicePool context. Both tables include a description of the command or property, the global action commands that can be used with the command or property, and the return parameter (if any). In Table 5-41, for example, CreateVolume is used with the global action commands Do, Push, and Select.

Table 5-41. ServicePool Commands

Command Description Associated Global Action Commands Return Parameter

CreateVolume Creates a volume Do/Push/Select No Return Value

GetMaxVolumeSize Obtains the maximum volume size Do

Associated Global

Action Commands

Show

Value

Return Parameter

Value

Table 5-42. ServicePool Properties

Property Description Associated Global Action Commands Return Parameter

Disks

PoolName Obtains the pool name Show

PoolType Obtains the pool type Show

Lets you access the disks in a pool

Show/Show[ID]/Push[ID]/Select[ID])

Value

Command Line Interface User’s Guide 75

This Page Left Intentionally Blank

76 Chapter 5 Supported CLI Commands and Properties

Chapter 6 Application Examples

This chapter provides examples of entering CLI commands on a command line. In these examples, bold text indicates commands typed by the user.

The topics covered in this chapter are:



Section 6.1, Setting the Name of the System (page 78)



Section 6.2, Creating Volumes (page 78)



Section 6.3, Obtaining the Maximum Size of a Volume (page 79)



Section 6.4, Obtaining the Maximum Stripe Width of a Volume (page 79)



Section 6.5, Adding an iSCSI Initiator (page 80)



Section 6.6, Obtaining a Vector of All Controllers on a System (page 80)



Section 6.7, Restarting the System (page 81)



Section 6.8, Shutting Down the System (page 81)



Section 6.9, Showing the Status of a Controller (page 81)



Section 6.10, Navigating and Displaying System, Volume, and Drive Information (page 82)

Command Line Interface User’s Guide 77

6.1 Setting the Name of the System

The following example sets the name of the system to Garnet. Systems are named from the System context.

192.168.59.25 :: Set Name Garnet

6.2 Creating Volumes

The following sections show examples of creating volumes. Volumes are created from the System context.

Example 1

The following examples are functionally identical. Both examples create a volume called CAD that is 30,000,000 bytes (30 MB) in size and whose volume composition is mirror.

Example 2

Example 3

192.168.59.25 :: Do CreateVolume CAD 30MB mirror

192.168.59.25 :: CreateVolume CAD 30MB mirror

The following example creates a volume named Exchange that is 150 GBytes in size; has a volume composition of parity; is created on disks 0, 1, 2, and 3; and has a stripe width of 4 and a stripe depth of 512 KB.

192.168.59.25 :: Do CreateVolume Exchange 150GB parity [0,1,2,3] 4 512KB

The following example creates a volume called resumes that is 500 GB in size and has a volume composition of jbod.

192.168.59.25 :: Do CreateVolume resumes 500GB jbod

78 Chapter 6 Application Examples

Example 4

The following command lines show examples of creating volumes. The first line creates one 4-wide Parity volume with a 512KB stripeDepth (chunk-size). The second command line creates one JBOD volume.

192.168.59.25 :: createVolume my_parity_volume 10GB parity [0,1,2,3] 4 512KB

192.168.59.25 :: createVolume myjbodvolume 5GB jbod

6.3 Obtaining the Maximum Size of a Volume

The following example displays the maximum size of a volume called Exchange that:



Has a volume composition of parity.



Is created on disks 0, 1, 2, and 3.



Has a stripe width of 4 and a stripe depth of 512 KB.

192.168.59.25 :: Do GetMaxVolumeSize parity [0,1,2,3] 4 512kb

6.4 Obtaining the Maximum Stripe Width of a Volume

Example 1

The following example displays the maximum stripe width supported for a JBOD.

192.168.59.25 :: Do GetMaxVolumeStripeWidth JBOD

Example 2

The following example displays the maximum stripe width supported for a mirror configuration.

192.168.59.25 :: Do GetMaxVolumeStripeWidth Mirror

Command Line Interface User’s Guide 79

Example 3

The following example displays the maximum stripe width supported for a stripe mirror configuration.

192.168.59.25 :: Do GetMaxVolumeStripeWidth StripeMirror

Example 4

The following example displays the maximum stripe width supported for a parity configuration.

192.168.59.25 :: Do GetMaxVolumeStripeWidth Parity

6.5 Adding an iSCSI Initiator

The following example adds the iSCSI initiator named below as a known iSCSI initiator to the system. iSCSI initiators are added from the System context.

192.168.59.25 :: Do AddInitiator iqn.1991-05.com.microsoft:hostname.domain.com

6.6 Obtaining a Vector of All Controllers on a System

The following example obtain a vector of all controllers in the system. This command is issued from the System context.

192.168.59.25 :: Show Controllers

Controllers:

controllers = Controller[A], Status=OK, SlotNumber=0 Summary = 1 Controllers

80 Chapter 6 Application Examples

6.7 Restarting the System

The following examples are functionally identical. Both examples restart the system. You restart a system from the System context.

192.168.59.25 :: Do SystemRestart

192.168.59.25 :: SystemRestart

6.8 Shutting Down the System

The following example shuts down the system. You shut down a system from the System context.

192.168.59.25 :: Do SystemShutdown

6.9 Showing the Status of a Controller

The following example shows how to display the status of a controller A. In addition to the controller’s name (ID) and status, the following information is returned:



The number of ports on the controller



The IP address and status of the controller’s management port



The number of lAGs (if any) configured on the controller



The slot number, serial number, number of drive slots, and display name for the controller



The current software version running on the controller and the version number of any alternate software version configured for the controller



The board type and controller status description (if any)



The number of disks that make up the base pool

Showing controller status is performed from the Controller context.

Command Line Interface User’s Guide 81

Controller[A] :: show

ID = A

Status = OK

IsActive = true

SlotNumber = 0

SerialNumber = 00001

DriveSlots = 12

NumFrontPorts = 8

DisplayName = Blade A

SoftwareVersion = 2.5.1.21

IsAlternateSoftwareVersionPresent = true

AlternateSoftwareVersion = 2.5.1.21

BoardType = 0009

BoardTypeRevision = XC05

I8kHwVersion = 1.0.0.0

I8kSwVersion = 0.1.0.0

MpuSwVersion = 2.5.1.21

BindFailReason = Bind_OK

BladeHealth = Healthy

BladeState = Bound

BladeType = SFF

PersistenceSetting = Unchanged

BatteryState = Failed

BufferMemDimmCnt = 2

BufferMemSize = 2048

SystemMemDimmCnt = 2

SystemMemSize = 512

SystemTime = 13:18:27

Ports = 8 Ports

LAGs = 8 LAGs

ManagementPort = ManagementPort [192.168.59.25], Status=OK

BasePool = [BaseA], 2 disks

The information shown to the left of the equals sign in the example above are themselves commands that can be issued from the Controller context if you want to view a particular setting only. For example, to return the number of drive slots for the current controller, type show driveSlots.

6.10 Navigating and Displaying System, Volume, and Drive Information

The following example shows how to display system, volume, and drive information while navigating through the CLI hierarchy.

192.168.59.25 :: show ID = 192.168.56.134 Status = OK Controllers = 1 Controllers DiskList = 4 disks PoolList = 4 pools VolumeList = 2 volumes TaskList = 9 tasks iSCSI = 1 initiators, 2 targets, 4 ports, 1 portals

82 Chapter 6 Application Examples

ExternalConnectionsManager = ExternalConnectionsManager Name = Identity = 192.168.56.134 AdvancedSettings = AdvancedSettings SystemStatistics = SystemStatistics [0], Status=OK IsHighAvailabilitySystem = false

192.168.59.25 :: select volumelist

VolumeList :: show ID = 0 Status = OK Volumes = 2 Volumes

VolumeList :: show volumes Volumes: volumes = [my_volume], State=Normal, Composition=Parity, Size=10.00GB volumes = [mark1], State=Normal, Composition=JBOD, Size=5.00GB Summary = 2 Volumes

VolumeList :: select volumes[my_volume]

Volume[my_volume] :: show ID = my_volume Status = OK VolumeComposition = 4 extents IsReconfiguring = false Target = [my_volume], durableName=iqn.2000-03.com.D-Link:mynewvolume:6-001215-

00c000006-484daa3e3a95a6c1, sessionCount=0 Initiators = 0 Initiators Tasks = 1 Tasks Name = my_volume State = Normal DurableName = 600121500C000006484DAA3E3A95A6C1 CompositionName = Parity NSPOF = true Size = 10,736,369,664 StripeWidth = 4 StripeDepth = 524288 IsReadOnly = false IsSyncCacheDisabled = false

Volume[my_volume] :: pop

192.168.59.25 :: show disklist ID = 0 Status = OK Disks = 4 Disks

192.168.59.25 :: select diskList

DiskList :: show disks Disks: disks = [0], Status=OK, State=Normal, Capacity=233.76GB, Free=230.09GB disks = [1], Status=OK, State=Normal, Capacity=233.76GB, Free=230.09GB disks = [2], Status=OK, State=Normal, Capacity=233.76GB, Free=230.09GB disks = [3], Status=OK, State=Normal, Capacity=233.76GB, Free=230.09GB Summary = 4 Disks

DiskList :: select disks[0]

Disk[0] :: show ID = 0 Status = OK Extents = 2 Extents Tasks = 0 Tasks FreeSpaceSize = 247,053,688,832 Pool = [BaseA], 4 disks State = Normal DriveType = SATA PhysicalCapacity = 251,000,193,024

Command Line Interface User’s Guide 83

SerialNumber = Y65N42TE SASChannelNumber = 0 EnclosureNumber = 0 SlotNumber = 0 DriveNumber = 0 Vendor = VendorModel = Maxtor 7Y250M0 ATAVersion = 7 ActualLinkSpeed = 0 SupportedLinkSpeeds = 0 SupportedLinkSpeeds SATAQueueingSupport = ENABLED SATAQueueDepth = 32 Supports48BitAddress = true SMARTData = SMARTData [0], Status=OK

84 Chapter 6 Application Examples

Index

Abbreviating commands · 20 AdvancedSettings commands and properties ·

Application examples · 77

CLI

context-specificcommands · 20 enumerators · 6 exiting · 18 getting help · 28 global action commands · 20, 34 installing · 8 members · 6 removing · 18 starting · 14 supported operating systems · 8 syntax · 27

CLI operating modes

completion code mode · 25 echo command mode · 26 exit script on error mode · 26 indication mode · 24 output mode · 23 overview · 22 stream mode · 25

Commands

abbreviating · 20 and properties · 47 concatenating · 21 context-specific · 20 editing · 21 global action · 20, 34

Commands and properties

AdvancedSettings · 68 Controller · 50 Disk · 54 DiskList · 53 Extent · 57 ExternalConnectionsManager · 70 Initiator · 67 iSCSI · 60 iSCSIConnection · 65 iSCSISession · 64 iSCSITarget · 61 LAG · 72

ManagementPort · 73 NetworkRoute · 74 PhysicalPort · 52 PoolList · 53 Portal · 66 ServicePool · 75 System · 48 SystemPolicy · 69 SystemStatistics · 71 Task · 59 TaskList · 58 Volume · 55 VolumeComposition · 57

VolumeList · 55 Completion code mode · 25 Concatenating commands · 21 Context-specific commands · 20 Controller commands and properties · 50

Disk commands and properties · 54 DiskList commands and properties · 53 Do command · 35

Echo command · 36 Echo command mode · 26 Editing commands · 21 Enumerators · 6 Environment variables, substituting · 31 Examples of applications · 77 Execute command · 36 Exit command · 37 Exit script on error mode · 26 Exiting the CLI · 18 Extent commands and properties · 57 ExternalConnectionsManager commands and

properties · 70

Global action commands · 20, 34

Do · 35

Echo · 36

Execute · 36

Exit · 37

Help · 37

List · 38

Mode · 38

Pop · 40

Command Line Interface User’s Guide 85

Push · 40 RequireArgs · 41 Select · 42 Set · 43 ShiftArgs · 43 Show · 44 System · 45

Help command · 37 Help with CLI · 28

Indication mode · 24, 25 Initiator commands and properties · 67 Installing the CLI · 8 iSCSI commands and properties · 60 iSCSIConnection commands and properties · 65 iSCSISession commands and properties · 64 iSCSITarget commands and properties · 61

Keywords · 6

LAG commands and properties · 72 List command · 38

PhysicalPort commands and properties · 52 PoolList commands and properties · 53 Pop command · 40 Portal commands and properties · 66 Push command · 40

Referencing root items · 21 Removing the CLI · 18 RequireArgs command · 41 Root items, referencing · 21

Select command · 42 ServicePool commands and properties · 75 Set command · 43 ShiftArgs command · 43 Show command · 44 Special keywords · 6 Starting the CLI · 14 Substituting environment variables · 31 Supported operating systems · 8 Syntax of CLI · 27 System command · 45 System commands and properties · 48 SystemPolicy commands and properties · 69 SystemStatistics commands and properties · 71

ManagementPort commands and properties · 73 Members · 6 Mode command · 38

NetworkRoute commands and properties · 74

Operating modes · 22

completion code · 25 eco command · 26 exit script on error · 26 indication · 24 output · 23

stream · 25 Operating systems · 8 Output mode · 23

Formatted XML · 24

normal · 23

XML · 23

Task commands and properties · 59 TaskList commands and properties · 58

Volume commands and properties · 55 VolumeComposition commands and properties ·

VolumeList commands and properties · 55

86 Index
