DSL-360T
ADSL Modem
User’s Manual
(December 2003)
DSL-360T DSL Modem User’s Guide
FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CE Mark Warning
This is a Class B product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures.
ii
DSL-360T ADSL Modem User’s Guide
LIMITATION OF LIABILITY
IN NO EVENT WILL D-LINK BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA, LOSS OF PROFITS, COST OF COVER OR OTHER INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES ARISING OUT THE INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE OR INTERRUPTION OF A D- LINK PRODUCT, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY. THIS LIMITATION WILL APPLY EVEN IF D-LINK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
IF YOU PURCHASED A D-LINK PRODUCT IN THE UNITED STATES, SOME STATES DO NOT ALLOW THE LIMITATION OR EXCLUSION OF LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
Limited Warranty
Hardware:
D-Link warrants each of its hardware produc ts to be fre e from defects in wo rkmans hip and material s unde r norma l use and se rv ice for a period commencing on the date of purchase from D-Link or its Authorized Reseller and extending for the length of time stipulated by the Authorized Reseller or D-Link Branch Office nearest to the place of purchase.
This Warranty applies on the condition that the product Registration Card is filled out and returned to a D-Link office within ninety (90) days of purchase. A list of D-Link offices is provided at the back of this manual, together with a copy of the Registration Card.
If the product proves defective within the applicable warranty period, D-Link will provide repair or replacement of the product. D-Link shall have the sole discretion whether to repair or replace, and replacement product may be new or reconditioned. Replacement product shall be of equivalent o r better sp ecifications , relative to the defective p roduct, b ut need no t be identic al. An y product or part repaired by D-Link pursuant to this warranty s hall have a warranty period of not less than 90 days, from date of such repair, irrespective of any ea rlier expiration of original warranty period. When D-Link provides re pla cement, then the defective product becomes the property of D-Link.
Warranty service may be obtained by contacting a D-Link office within the applicable warranty period, and requesting a Return Material Authorization (RMA) number. If a Registration Card for the product in question has not been returned to D- Link, then a proof of purchase (such as a copy of the dated purchase invoice) must be provided. If Purchaser's circumstances require special handling of warranty correction, then at the time of requesting RMA number, Purchaser may also propose special procedure as may be suitable to the case.
After an RMA number is issued, the defective product must be packaged securely in the original or other suitable shipping package to ensure that it will not be damaged in transit, and the RMA number must be prominently marked on the outside of the package. The package must be mailed or otherwise shipped to D -Link with all costs of mailing/shipping/insurance prepaid. D-Link shall never be responsible for any so ftware, firmware, information, or memory da ta of Purchaser contained in, stored o n, or integrated with any product returned to D-Link pursuant to this warranty.
Any package returned to D-Link without an RMA number will be rejected and shipped back to Purchaser at Purchaser's expense, and D-Link reserves the right in such a case to levy a reasonable handling charge in addition mailing or shipping costs.
Software:
Warranty service for software products may be ob tained by contacting a D-Link office within the applicable warranty period. A list of D-Link offices is provided at the back of this manual, together with a copy of the Registration Card. If a Registration Card for the product in question has not been returned to a D-Link office, then a proof of purchase (such as a copy of the dated purchase invoice) must be provided when requesting warranty service. The term "purchase" in this software warranty refers to the purchase transaction and resulting license to use such software.
D-Link warrants that its software products will perform in substantial conformance with the applicable product documentation provided by D-Link with such software product, for a period of ninety (90) days from the date of purchase from D-Link or its Authorized Reseller. D-Link warrants the magnetic media, on which D-Link provides its software product, against failure during the same warranty period. This warranty applies to purchased software, and to replacement software provided by D-Link pursuant to this warranty, but shall not apply to any update or replacement which may be provided for download via the Internet, or to any update which may otherwise be provided free of charge.
D-Link's sole obligation under this software warranty shall be to replace any defective software product with product which substantially conforms to D-Link's applicable product documentation. Purchaser assumes res ponsibility for the selection of appropriate application and system/platform software and associated reference materials. D-Link makes no warranty that its software products will work in combination with any hard ware, or any application or system/platform software product provided by any third p arty, excepting onl y such products as are expressly represented, in D-Link's applicable product documentation as being compatible. D-Link's obligation under this warranty shall be a reasonable effort to provide compatibility, but D-Link shall have no obligation to provide compatibility when there is fault in the third-party hardware or software. D-Link makes no warranty that operation of its software products will be uninterrupted or absolutely error-free, and no warranty that all defects in the software product, within or without the scope of D-Link's applicable product documentation, will be corrected.
iii
TABLE OF CONTENTS
About This User’s Guide .............................................................................................................................. vii
Before You Start ...........................................................................................................................................vii
Information Required for Installation ..........................................................................................................viii
INTRODUCTION........................................................................................................ 1
Modem Description and Operation................................................................................................................. 1
Modem Features.............................................................................................................................................. 3
Standards Compatibility and Compliance....................................................................................................... 4
Front Panel Display......................................................................................................................................... 5
Rear Panel Connections .................................................................................................................................. 6
HARDWARE INSTALLATION................................................................................... 7
Power on Modem............................................................................................................................................ 7
Factory Reset Button....................................................................................................................................... 7
Network Connections...................................................................................................................................... 8
CONFIGURING THE MODEM FOR THE FIRST TIME.............................................10
Configuring IP Settings on Your Computer.................................................................................................. 10
Access the Configuration Manager.................................................................................................. 15
Home..................................................................................................................................................... 16
Configure the Modem................................................................................................................................... 17
Setup..................................................................................................................................................... 18
Configure a New Connection........................................................................................................................ 19
WEB-BASED MANAGEMENT .................................................................................25
Accessing the Web Manager......................................................................................................................... 25
DHCP Configuration..................................................................................................................................... 26
Management IP............................................................................................................................................. 27
Tools.....................................................................................................................................................28
Changing the User Name and Password....................................................................................................... 28
User Management......................................................................................................................................... 29
System Commands........................................................................................................................................ 30
Remote Log................................................................................................................................................... 31
Update Gateway............................................................................................................................................ 32
Ping Test ....................................................................................................................................................... 33
Modem Test.................................................................................................................................................. 34
Status.................................................................................................................................................... 35
Network Statistics......................................................................................................................................... 36
Connection Status ......................................................................................................................................... 37
DHCP Clients................................................................................................................................................ 38
Modem Status ............................................................................................................................................... 39
Product Info................................................................................................................................................... 40
System Log ................................................................................................................................................... 41
Help....................................................................................................................................................... 42
TECHNICAL SPECIFICATIONS...............................................................................43
IP ADDRESS SETUP................................................................................................45
IP CONCEPTS..........................................................................................................47
MICROFILTERS AND SPLITTERS..........................................................................50
DSL-360T DSL Modem User’s Guide
About This User’s Guide
This user’s guide provides instructions on how to install the DSL-360T ADSL Modem and use it to connect a computer or Ethernet Local Area Network (LAN) to the Internet thus providing a gateway to the Wide Area Network (WAN).
If you are using a computer with a functioning Ethernet port, the quickest and easiest way to set up the DSL­360T is to follow the instructions provided in the Quick Installation Guide.
Before You Start
Please read and make sure you understand all the prerequisites for proper installation of your new Modem. Have all the necessary information and equipment on hand before beginning the installation.
Installation Overview
The procedure to install the Modem can be described in general terms in the following steps:
1. Gather information and equipment needed to install the device. Before you power on the device or connect it to your computer, make sure you have all the necessary information, cables, power adapter and any other required equipment listed.
2. Install the hardware, that is, connect the cables (Ethernet and telephone) to the d evice and connect the power adapter.
3. Check the IP settings on your computer and change them if necessary so the computer can access the web-based software built into the Modem.
4. Use the web-based management software to configure the device to suit the requirements of your ADSL account.
vii
DSL-360T DSL Modem User’s Guide
Information Required for Installation
Information you will need from your ADSL service provider:
Username
Password
Connection Protocol
Security Protocol
VPI
VCI
This is the Username used to log on to your ADSL service provider’s network. It is commonly in the form user@isp.com. Your ADSL service provider uses this to identify your account.
This is the Password used, in conjunction with the Username above, to log on to your ADSL service provider’s network. This is used to verify the identity of your account.
This is the method your ADSL service provider uses to send and receive data between the Internet and your computer. Your Modem supports the following connection protocols: PPPoE, PPPoA, CLIP (IPoA) and Bridge.
This is the method your ADSL service provider will use to verify your Username and Password when you log on to their network. Your Modem supports the PAP and CHAP protocols.
This is the Virtual Path Identifier (VPI). It is used in conjunction with the Virtual Channel Identifier (VCI) below, to identify the data path between your ADSL service provider’s network and your computer.
This is the Virtual Channel Identifier (VCI). It is used in conjunction with the VPI above to identify the data path between your ADSL service provider’s network and your computer.
Record info here
Information you will need to change settings on the DSL-360T Modem:
Record info here
Username
Password
LAN IP addresses for the DSL-360T
LAN Subnet Mask for the DSL-360T
This is the Username needed access the Modem’s management interface. When you attempt to connect to the device through a web browser you will be prompted to enter this Username. The default Username for the Modem is admin. This may be changed by the user.
This is the Password you will be prompted to enter when you access the Modem’s management interface. The default Password is admin. This may be changed by the user.
This is the IP address you will enter into the Address field of your web browser to access the Modem’s configuration graphical user interface (GUI) using a web browser. The default IP address is 192.168.1.1 and it is referred to as the “Management IP” address in this User’s Manual. This may be changed to suit any IP address scheme the user desires. This address will be the base IP address used for DHCP service on the LAN when DHCP is enabled.
This is the subnet mask used by the DSL-360T, and will be used throughout your LAN. The default subnet mask is 255.255.255.0. This can be changed later.
viii
DSL-360T DSL Modem User’s Guide
Information you will need about your Ethernet LAN or computer:
If your computer has an Ethernet NIC, you can
Record info here
connect the DSL-360T to this Ethernet port using an
Ethernet NIC
Ethernet cable. You can also use the Ethernet port on the DSL-360T to connect to other Ethernet devices, such as a Wireless Access Point.
Your DSL-360T ADSL Modem is configured, by default, to be a DHCP server. This means that it can assign an IP address, subnet mask, and a default gateway address to computers on your LAN. The
DHCP Client status
default range of IP addresses the DSL-360T will assign are from 192.168.1.2 to 192.168.1.254. Your computer (or computers) needs to be configured to Obtain an IP address automatically (that is, they need to be configured as DHCP clients.)
It is recommended that your collect and record this information here, or in some other secure place, in case you have to re-configure your ADSL connection in the future.
Once you have the above information, you are ready to setup and configure your DSL-360T ADSL Modem.
The Modem may be reset to its factory default settings by performing a Restore
Note
settings operation within the management interface (see System Commands below). If you cannot gain access to the management interface, you may opt to use the Reset button on the rear panel of the device (see Factory Reset Button below).
ix
DSL-360T ADSL Modem User’s Guide
1
Introduction
This section provides a brief description of the Modem, its associated technologies and a list of Modem features.
Modem Description and Operation
The DSL-360T ADSL Modem is designed to provide a simple and cost-effective ADSL Internet connection for a single computer through the Ethernet port; or use it to bridge your Ethern et LAN to the Internet. The DSL­360T combines the benefits of high-speed ADSL technology and LAN IP management in one compact and convenient package. ADSL technology enables many interactive multi-media applications such as video conferencing and collaborative computing.
The Modem is easy to install and use. The DSL-360T connects to single computer or an Ethernet LAN via a standard Ethernet interface. The ADSL connection is made using ordinary twisted-pair telephone line with standard connectors. Multiple PCs can be networked and connected to the Internet using a single Wide Area Network interface and single global IP address.
What is ADSL?
Asymmetric Digital Subscriber Line (ADSL) is an access technology that utilizes ordinary copper telephone lines to enable broadband high-speed digital data transmission and interactive multimedia applications for business and residential customers.
ADSL greatly increases the signal carrying capacity of copper telephone lines witho ut interfering with regular telephone services. For the ADSL user, this means faster downloads and more reliable connectivity. ADSL devices make it possible to enjoy benefits such as high-speed Internet access without experiencing any loss of quality or disruption of voice/fax telephone capabilities.
ADSL provides a dedicated service over a single telephone line operating at speeds of up to 8 Mbps downstream and up to 640 Kbps upstream, depending on local telephone line conditions. A secure point-to-point co nnection is established between the user and the central office of the service provider.
D-Link ADSL devices incorporate the recommendations of the ADSL Forum regarding framing, data format, and upper layer protocols.
Low Pass Filters
Since ADSL and telephone services share the same copper wiring to carry their respective signals, a filtering mechanism may be necessary to avoid mutual interference. A low pass filter device can be installed for each telephone that shares the line with the ADSL line. These filters are easy to install passive devices that connect to the ADSL device and/or telephone using standard telephone cable. Ask your service provider for more information about the use of low pass filters with your installation.
Operating Systems
The DSL-360T uses an HTML-based web interface for setup and management. The web configuration manager may be accessed using any operating system capable of running web browser software, including Windows 98 SE, Windows ME, Windows 2000, and Windows XP.
1
DSL-360T ADSL Modem User’s Guide
Web Browser
Any common web browser can be used to configure the Modem using the web configuration management software. The program is designed to work best with more recently released browsers such as Opera, Microsoft Internet Explorer® version 5.0, Netscape Navigator® version 4.7, or later versions. The web browser must have JavaScript enabled. JavaScript is enabled by default on many browsers. Make sure JavaScript has not been disabled by other software (such as virus protection or web user security packages) that may be running on your computer.
Ethernet Port (NIC Adapter)
Any computer that uses the Modem must be able to connect to it through the Ethernet port on the Modem. This connection is an Ethernet connection and therefore requires that your computer be equipped with an Ethernet port as well. Most notebook computers are now sold with an Ethernet port already installed. Likewise, most fully assembled desktop computers come with an Ethernet NIC adapter as standard equ ipment. If your computer does not have an Ethernet port, you must install an Ethernet NIC adapter before you can use the Modem. If you must install an adapter, follow the installation instructions that come with the Ethernet NIC ad apter.
Additional Software
It may be necessary to install software on your computer that enables the computer to access the Internet. Additional software must be installed if you are using the device a simple bridge. For a bridged connection, the information needed to make and maintain the Internet connection is stored on another computer or gateway device, not in the Modem itself.
If your ADSL service is delivered through a PPPoE, PPPoA or IPoA connection, the information needed to establish and maintain the Internet connection can be stored in the Mode m. In this case, it is not necessary to install software on your computer. It may however be necessary to change some settings in the device, including account information used to identify and verify the connection.
All connections to the Internet require a unique global IP address. For bridged co nnections, th e global IP settings must reside in a TCP/IP enabled device on the LAN side of the bridge, such as a PC, a server, a gateway device such as a router or similar firewall hardware. The IP address can be assigned in a number of ways. Your network service provider will give you instructions about any additional connection software or NIC configuration that may be required.
2
DSL-360T ADSL Modem User’s Guide
Modem Features
The DSL-360T ADSL Modem utilizes the latest ADSL enhancements to provide a reliable Internet portal suitable for most small to medium sized offices. DSL-360T advantages include:
PPP (Point-to-Point Protocol) Security – The DSL-360T ADSL Modem supports PAP (Password
Authentication Protocol) and CHAP (Challenge Handshake Authentication Protocol) for PPP connections.
DHCP SupportDynamic Host Configuration Protocol automatically and dynamically assigns al LAN IP
settings to each host on your n etwork. Th is eliminates the need to reconfigure ever y host when ever ch anges in network topology occur.
Network Address Translation (NAT) – For small office environments, the DSL-360T allows multiple
users on the LAN to access the Internet concurrently through a single Internet account. This provides Internet access to everyone in the office for the price of a single user.
NAT improves network security in effect by hiding the private network behind one global and visible IP address. NAT address mapping can also be used to link two IP domains via a LAN-to-LAN connection.
TCP/IP (Transfer Control Protocol/Internet Protocol) – The DSL-360T supports TCP/IP protocol, the
language used for the Internet. It is compatible with access servers manufactured by major vendors.
ATM (Asynchronous Transfer Mode) – The DSL-360T supports Bridged Ethernet over ATM (RFC1483),
IP over ATM (RFC1577) and PPP over ATM (RFC 2364).
Precise ATM Traffic Shaping – Traffic shaping is a method of controlling the flow rate of ATM data cells.
This function helps to establish the Quality of Service for ATM data transfer.
G.hs (Auto-handshake) – This allows the Modem to automatically choose either the G.lite or G.dmt ADSL
connection standards.
High Performance – Very high rates of data transfer are possible with the Modem. Up to eight Mbps
downstream bit rate using the G.dmt.
Easy InstallationThe DSL-360T uses a web-based graphical user interface program for convenient
management access and easy set up. Any common web browser software can be used to manage the Modem.
3
DSL-360T ADSL Modem User’s Guide
Standards Compatibility and Compliance
The DSL-360T complies with or is compatible with the following standards as recognized by their respective agencies.
ITU G.992.2 (G.lite “Splitterless ADSL”) compliant
ITU-T Rec. I.361 compliant
RFC 791 Internet Protocol compliant
RFC 792 UDP compliant
RFC 1334 PPP Authentication Protocol compliant
RFC 1483 IP over AAL5/ Bridged Ethernet over AAL5 compliant
RFC 1557 Classical IP over ATM (IPoA) compliant
RFC 1661 Point to Point Protocol (PPP) compliant
RFC 1877 Automatic IP assignment compliant
RFC 1994 Challenge Handshake Authentication Protocol compliant
Supports RFC 2131 and RFC 2132 DHCP functions including: automatic assignment of IP address, use of
subnet mask and default gateway and provision of DNS server address for all hosts
RFC 2364 PPP over ATM compliant (PPPoA) compliant
RFC 2516 PPP over Ethernet compliant (PPPoE) compliant
RFC 2684 Bridged/Routed Ethernet over ATM compliant
Embedded management agent accessed via web browser
Supports DHCP for up to 253 hot connections
Supports ATM Forum UNI 3.1/4.0
4
DSL-360T ADSL Modem User’s Guide
Packing List
Open the shipping carton and carefully remove all items. In addition to this User's Guide, ascertain that you have:
One DSL-360T ADSL Modem
One Quick Installation Guide
One twisted-pair telephone cable used for ADSL connection
One straight-through Ethernet cable
One AC power adapter suitable for your electric service
An Installation CD containing this User’s Manual
Front Panel Display
Place the Modem in a location that permits an easy view of the LED indicators on the front panel. The LED indicators on the front panel include the Power, Status, ADSL Link/Act, and Ethernet Link/Act.
The ADSL and Ethernet indicators monitor link status and activity (Link/Act).
Power
Status
ADSL: Link/Act
Ethernet: Link/Act
Steady green light indicates the unit is powered on. When the device is powered off this remains dark.
Lights steady green during power on self-test (POST). Once the connection status has been settled, the light will blink green. If the indicator lights steady green after the POST, the system has failed and the device should be rebooted.
Steady green light indicates a valid ADSL connection. This will light after the ADSL negotiation process has been settled. A blinking green light indicates activity on the WAN (ADSL) interface.
A solid green light indicates a valid link on startup. This light will blink when there is activity currently passing through the Ethernet port.
5
DSL-360T ADSL Modem User’s Guide
Rear Panel Connections
All cable connections to the Modem are made at the rear panel. Connect the power adapter here to power on the Modem. Use the Reset button to restore the settings to the factory default values (see Factory Reset Button in the next chapter for instructions on using the reset button).
ADSL port,
connect ADSL
cable here
Ethernet
port,
connect
Ethernet
cable here
Factory
Reset
button
Power cord
connects
here
Note
The Modem may be rebooted by disconnecting and then reconnecting the power.
6
DSL-360T ADSL Modem User’s Guide
2
Hardware Installation
The DSL-360T maintains two interfaces and provides a bridge between two networks. An Ethernet port connects to a computer or Ethern et LAN and an ADSL port provides the connectio n to the Internet and the Wide Area Network. Place the Modem in a location where it can be connected to the various devices as well as to a power source. The Modem should not be located where it will be exposed to moisture or excessive heat. Mak e sure the cables and power cord are placed safely out of the way so they do not create a tripping hazard. As with any electrical appliance, observe common sense safety procedures.
The access point can be placed on a shelf or desktop, ideally you should be able to see the LED indicators on the front if you need to view them for troubleshooting.
Power on Modem
CAUTION: The Modem must be used with the power adapter included with the
device.
To power on the Modem:
1. Insert the AC Power Adapter cord into the power receptacle located on the rear panel of the Modem and plug the adapter into a suitable nearby power source.
2. You should see the Power LED indicator light up and remain lit. The Status LED should light solid green and begin to blink after a few seconds.
3. If the Ethernet port is connected to a working device, check the Ethernet Link/Act LED indicators to make sure the connection is valid. The Modem will attempt to establish the ADSL connection, if the ADSL line is connected and the Modem is properly configured this should light up after several seconds. If this is the first time installing the device, some settings may need to be changed before the Modem can establish a connection.
Factory Reset Button
The Modem may be reset to the original factory default settings by depressing the reset button for a few second s while the device is powered on. Use a ballpoint or paperclip to gently push down the reset button. Remember that this will wipe out any settings stored in flash memory including user account information and LAN IP settings. The factory default IP address of the Modem is 192.168.1 .1 and the subnet mask is 255.255.255.0 , the default management Username is admin and the default Password is admin.
7
DSL-360T ADSL Modem User’s Guide
Network Connections
Network connections are provided through the ADSL port and the Ethernet port on the back of the Modem. See the Rear Panel diagram above and the illustrations below for examples.
Connect ADSL Line
Use the ADSL cable included with the Modem to connect it to a telephone wall socket or receptacle. Plug one end of the cable into the ADSL port (RJ-11 receptacle) on the rear panel of the Modem and insert the other end into the RJ-11 wall socket. If you are using a low pass filter device, follow the instructions included with the device or given to you by your service provider. The ADSL connection represents the WAN interface, the connection to the Internet. It is the physical link to the service provider’s network backbone and ulti mately to the Internet.
Connect Modem to Ethernet
The Modem may be connected to a single computer or Ethernet device through the 10BASE-TX Ethernet port on the rear panel. Any connection to an Ethernet concentrating device such as a switch or hub must operate at a speed of 10/100 Mbps only. When connecting the Modem to any Ethernet device that is capable of operating at speeds higher than 10Mbps, be sure that the device has auto-negotiation (NWay) enabled for the connecting port.
Note
Use standard twisted-pair cable with RJ-45 connectors. The RJ-45 port on the Modem is a crossed port (MDI-X). Follow standard Ethernet guidelines when deciding what type of cable to use to make this connection. When connecting the Modem directly to a PC or server use a normal straight-through cable. You should use a crossed cable when connecting the Modem to a normal (MDI-X) port on a switch or hub. Use a normal straight-through cable when connecting it to an uplink (MDI-II) port on a hub or switch.
The rules governing Ethernet cable lengths apply to the LAN to Modem connection. Be sure that the cable connecting the LAN to the Modem does not exceed 100 meters.
In order to connect the Modem to an Ethernet LAN, it is necessary to install 3rd-party PPP connection software on any system used to access the Internet.
Computer to Modem Connection
Connect the Modem directly to a 10/100BASE-TX Ethernet port on a PC or notebook computer using the Ethernet cable provided as shown in this diagram.
8
DSL-360T ADSL Modem User’s Guide
r
r
Hub or Switch to Modem Connection
Connect the Modem to an uplink port (MDI-II) on an Ethern et hub or switch with a straight-through cable as shown in the diagram below:
If you wish to reserve the uplink port on the switch o hub for another device, connect to any on the othe MDI-X ports (1x, 2x, etc.) with a crossed cable.
9
DSL-360T ADSL Modem User’s Guide
3
Configuring the Modem for the First Time
The first time you setup the Modem, configure the WAN connection using a single computer connected directly to the Modem. Once the WAN connection is functioning properly, you may continue to make changes to Modem configuration including IP settings and DHCP setup. This chapter is concerned with using your computer to configure the WAN connection. The following chapter describes the various menus used to configure and monitor the Modem including how to change IP settings and DHCP server setup.
Wan Configuration Summary
1. Connect to the Modem To configure the WAN connection used by the Modem it is first necessary to
communicate with the Modem through its management interface, which is HTML-based and can be accessed using a web browser. To access the management software your computer must be able to “see” the Modem. Your computer can see the Modem if it is in the same “neighborhood” or subnet as the Modem. This is accomplished by making sure your computer has IP settings that place it in the same subnet as the Modem. The easiest way to make sure your computer has the correct IP settings is to configure it to use the embedded DHCP server in the Modem. The next section describes how to change the IP configuration for a computer running a Windows operating system to be a DHCP client.
2. Configure the WAN Connection Once your are able to access the configuration software you can
proceed to change the settings required to establish th e ADSL connection and connect to the service provider’s network. There are different methods used to establish the connection to the service provider’s network and ultimately to the Internet. You shou ld know what Encapsulation and conn ection type you are required to use for your ADSL service. For some users, it may be necessary to change the PVC settings used for the ADSL connection. Your service provider should provide all the information you need to successfully configure the WAN connection.
Configuring IP Settings on Your Computer
In order to configure your system to receive IP settings from the Modem it must first have the TCP/IP protocol installed. If you have an Ethernet port on your computer, it probably already has TCP/IP protocol installed. If you are using Windows XP the TCP/IP is enabled by default for standard installations. Below is an illustrated example of how to configure a Windows XP system to automatically obtain IP settings from the Modem. Following this example is a step-by-step description of the procedures used on the other Windows operating systems to first check if the TCP/IP protocol has been installed; if it is not, instructions are provided for installing it. Once the protocol has been installed you can configure the system to receive IP settings from the Modem.
For computers running non-Windows operating systems, follow the instructions for your OS that configure the system to receive an IP address from the Modem, that is, configure the system to be a DHCP client.
If you are using this Modem to provide Internet access for more than one
computer, you can use these instructions later to change the IP settings for the
Note
other computers. However, you cannot use the same IP address since every computer must have its own IP address that is unique on the local network.
10
DSL-360T ADSL Modem User’s Guide
Configure Windows XP for DHCP
Use the following steps to configure a computer running Windows XP to be a DHCP client.
1. From the Start menu on your desktop, go to Settings, then click on Network Connections.
2. In the Network Connections window, right-click on LAN (Local Area Connection), then click Properties.
11
Loading...
+ 46 hidden pages
