D-Link DES-1210-28/ME Reference Manual

CLI Reference Guide

DES-1210-28/ME

Metro Ethernet Managed Switch

V1.1

Information in this document is subject to change without notice.

© 2009 D-Link Computer Corporation. All rights reserved.

Reproduction in any manner whatsoever without the written permission of D-Link Computer Corporation
is strictly forbidden.

Trademarks used in this text: D-Link and the D-Link logo are trademarks of D-Link Computer
Corporation; Microsoft and Windows are registered trademarks of Microsoft Corporation.

Other trademarks and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. D-Link Computer Corporation disclaims any proprietary interest
in trademarks and trade names other than its own.

FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with this user’s guide, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at hisown expense.

CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause radio interference in

which case the user may be required to take adequate measures.

Warnung!

Dies ist ein Produkt der Klasse A. Im Wohnbereich kann dieses Produkt Funkstoerungen verursachen. In
diesem Fall kann vom Benutzer verlangt werden, angemessene Massnahmen zu ergreifen.

Precaución!

Este es un producto de Clase A. En un entorno doméstico, puede causar interferencias de radio, en
cuyo case, puede requerirse al usuario para que adopte las medidas adecuadas.

Attention!

Ceci est un produit de classe A. Dans un environnement domestique, ce produit pourrait causer des
interférences radio, auquel cas l`utilisateur devrait prendre les mesures adéquates.

Attenzione!

Il presente prodotto appartiene alla classe A. Se utilizzato in ambiente domestico il prodotto può causare
interferenze radio, nel cui caso è possibile che l`utente debba assumere provvedimenti adeguati.

VCCI Warning

January, 2012

Table of Contents

INTRODUCTION...................................................................................................................................................... 1

USING THE CONSOLE CLI.................................................................................................................................... 3

COMMAND SYNTAX .............................................................................................................................................. 7

BASIC SWITCH COMMANDS .............................................................................................................................. 10

enable password encryption................................................................................................................................................. 10

disable password encryption................................................................................................................................................ 11

create account ...................................................................................................................................................................... 11

config account ..................................................................................................................................................................... 12

show account ....................................................................................................................................................................... 13

delete account ...................................................................................................................................................................... 13

show session ........................................................................................................................................................................ 14

show switch ......................................................................................................................................................................... 14

enable web ........................................................................................................................................................................... 15

disable web .......................................................................................................................................................................... 16

enable autoconfig ................................................................................................................................................................ 16

disable autoconfig................................................................................................................................................................ 17

show autoconfig .................................................................................................................................................................. 17

save...................................................................................................................................................................................... 17

reboot................................................................................................................................................................................... 18

reset ..................................................................................................................................................................................... 19

logout................................................................................................................................................................................... 19

ping...................................................................................................................................................................................... 20

enable telnet......................................................................................................................................................................... 20

disable telnet........................................................................................................................................................................ 21

show tech support ................................................................................................................................................................ 21

SMTP SERVER COMMANDS............................................................................................................................... 23

enable smtp.......................................................................................................................................................................... 23

disable smtp ......................................................................................................................................................................... 23

config smtp .......................................................................................................................................................................... 24

show smtp............................................................................................................................................................................ 24

smtp sent_testmsg................................................................................................................................................................ 25

MODIFY BANNER AND PROMPT COMMANDS................................................................................................. 26

config command_prompt..................................................................................................................................................... 26

config greeting_message ..................................................................................................................................................... 27

show greeting_message ....................................................................................................................................................... 28

SWITCH PORT COMMANDS ............................................................................................................................... 29

config ports.......................................................................................................................................................................... 29

show ports............................................................................................................................................................................ 30

LOOPBACK DETECTION COMMANDS .............................................................................................................. 31

config loopdetect ................................................................................................................................................................. 31

config loopdetect mode ....................................................................................................................................................... 31

config loopdetect ports ........................................................................................................................................................ 32

config loopdetect ................................................................................................................................................................. 32

show loopdetect ................................................................................................................................................................... 33

DOS PREVENTION COMMANDS ........................................................................................................................ 34

config dos_prevention dos_type.......................................................................................................................................... 34

show dos_prevention ........................................................................................................................................................... 35

clear dos_prevention counters ............................................................................................................................................. 36

enable dos_prevention trap_log........................................................................................................................................... 36

disable dos_prevention trap_log.......................................................................................................................................... 37

PPPOE CIRCUIT ID INSERTION COMMANDS ................................................................................................... 38

config pppoe circuit_id_insertion state................................................................................................................................ 38

config pppoe circuit_id_insertion ports ............................................................................................................................... 39

show pppoe circuit_id_insertion.......................................................................................................................................... 39

show pppoe circuit_id_insertion ports................................................................................................................................. 40

DHCP SERVER SCREENING COMMANDS........................................................................................................ 41

config filter dhcp_server...................................................................................................................................................... 41

show filter dhcp_server ....................................................................................................................................................... 42

config dhcp_server screening ports ..................................................................................................................................... 43

show dhcp_server screening................................................................................................................................................ 43

IP-MAC-PORT BINDING COMMANDS ................................................................................................................ 45

create address_binding ip_mac ipaddress............................................................................................................................ 45

config address_binding ip_mac ports .................................................................................................................................. 46

config address_binding auto_scan....................................................................................................................................... 46

delete address_binding ........................................................................................................................................................ 47

show address_binding ......................................................................................................................................................... 48

show address_binding auto_scan list................................................................................................................................... 49

enable address_binding dhcp_snoop ................................................................................................................................... 49

disable address_binding dhcp_snoop .................................................................................................................................. 49

NETWORK MANAGEMENT (SNMP) COMMANDS............................................................................................. 51

create snmp user .................................................................................................................................................................. 53

delete snmp user .................................................................................................................................................................. 54

show snmp user ................................................................................................................................................................... 54

create snmp view ................................................................................................................................................................. 55

delete snmp view ................................................................................................................................................................. 56

show snmp view .................................................................................................................................................................. 56

create snmp community....................................................................................................................................................... 57

delete snmp community....................................................................................................................................................... 57

show snmp community ........................................................................................................................................................ 58

config snmp engineID ......................................................................................................................................................... 58

show snmp engineID ........................................................................................................................................................... 59

create snmp group ............................................................................................................................................................... 59

delete snmp group ............................................................................................................................................................... 61

show snmp global state........................................................................................................................................................ 61

show snmp groups ............................................................................................................................................................... 61

create snmp host .................................................................................................................................................................. 62

delete snmp host .................................................................................................................................................................. 63

show snmp host ................................................................................................................................................................... 64

enable trusted_host .............................................................................................................................................................. 64

disable trusted_host ............................................................................................................................................................. 65

create trusted_host ............................................................................................................................................................... 65

show trusted_host ................................................................................................................................................................ 65

delete trusted_host ............................................................................................................................................................... 66

enable snmp traps ................................................................................................................................................................ 67

disable snmp traps ............................................................................................................................................................... 67

enable snmp authenticate trap.............................................................................................................................................. 67

disable snmp authenticate trap............................................................................................................................................. 68

show snmp traps .................................................................................................................................................................. 68

config syslocation ................................................................................................................................................................ 69

config sysname .................................................................................................................................................................... 69

enable snmp ......................................................................................................................................................................... 69

disable snmp ........................................................................................................................................................................ 70

enable snmp DHCP_ screening traps .................................................................................................................................. 70

disable snmp DHCP_ screening traps ................................................................................................................................. 71

enable snmp IMPB_violation traps ..................................................................................................................................... 71

disable snmp IMPB_violation traps .................................................................................................................................... 71

enable snmp fiber_port_link traps ....................................................................................................................................... 72

disable snmp fiber_port_link traps ...................................................................................................................................... 72

enable snmp firmware_upgrade_state traps......................................................................................................................... 73

disable snmp firmware_upgrade_state traps........................................................................................................................ 73

enable snmp LBD traps ....................................................................................................................................................... 73

disable snmp LBD traps ...................................................................................................................................................... 74

enable snmp port_security_violation traps .......................................................................................................................... 74

disable snmp port_security_violation traps ......................................................................................................................... 75

enable snmp rstpport_state_change traps ............................................................................................................................ 75

disable snmp rstpport_state_change traps ........................................................................................................................... 76

enable snmp system_device_bootup traps ........................................................................................................................... 76

disable snmp system_device_bootup traps .......................................................................................................................... 76

enable snmp twistedpair_port_link traps ............................................................................................................................. 77

disable snmp twistedpair_port_link traps ............................................................................................................................ 77

enable snmp duplicate_IP_detected traps ............................................................................................................................ 78

disable snmp duplicate_IP_detected traps ........................................................................................................................... 78

DOWNLOAD/UPLOAD COMMANDS................................................................................................................... 79

download ............................................................................................................................................................................. 79

upload .................................................................................................................................................................................. 80

DHCP RELAY COMMANDS ................................................................................................................................. 82

enable dhcp_relay ................................................................................................................................................................ 82

disable dhcp_relay ............................................................................................................................................................... 83

config dhcp_relay add ipif system....................................................................................................................................... 83

config dhcp_relay delete ipif system ................................................................................................................................... 84

config dhcp_relay ................................................................................................................................................................ 84

config dhcp_relay option_82 ............................................................................................................................................... 85

show dhcp_relay .................................................................................................................................................................. 86

enable dhcp_local_relay ...................................................................................................................................................... 86

disable dhcp_local_relay ..................................................................................................................................................... 87

config dhcp_local_relay vlan............................................................................................................................................... 87

show dhcp_local_relay ........................................................................................................................................................ 88

GRATUITOUS ARP COMMANDS ........................................................................................................................ 89

config gratuitous_arp send ipif_status_up ........................................................................................................................... 89

config gratuitous_arp send dup_ip_detected ....................................................................................................................... 90

config gratuitous_arp learning............................................................................................................................................. 90

enable gratuitous_arp........................................................................................................................................................... 91

disable gratuitous_arp.......................................................................................................................................................... 91

show gratuitous_arp............................................................................................................................................................. 92

config gratuitous_arp send periodically interval ................................................................................................................. 92

NETWORK MONITORING COMMANDS ............................................................................................................. 94

show packet ports ................................................................................................................................................................ 94

show error ports ................................................................................................................................................................... 95

show utilization ................................................................................................................................................................... 96

clear counters....................................................................................................................................................................... 97

clear log ............................................................................................................................................................................... 97

show log .............................................................................................................................................................................. 97

enable syslog ....................................................................................................................................................................... 98

disable syslog ...................................................................................................................................................................... 98

show syslog ......................................................................................................................................................................... 99

create syslog host................................................................................................................................................................. 99

config syslog host .............................................................................................................................................................. 101

delete syslog host............................................................................................................................................................... 103

show syslog host................................................................................................................................................................ 104

cable diagnostic port .......................................................................................................................................................... 104

SPANNING TREE COMMANDS......................................................................................................................... 106

config stp ........................................................................................................................................................................... 106

config stp ports .................................................................................................................................................................. 107

config stp version .............................................................................................................................................................. 109

config stp fbpdu ................................................................................................................................................................. 109

config stp priority .............................................................................................................................................................. 110

enable stp........................................................................................................................................................................... 110

disable stp .......................................................................................................................................................................... 110

show stp............................................................................................................................................................................. 111

show stp ports .................................................................................................................................................................... 112

show stp instance ............................................................................................................................................................... 113

show stp mst_config_id ..................................................................................................................................................... 114

create stp instance_id......................................................................................................................................................... 114

delete stp instance_id......................................................................................................................................................... 115

config stp mst_config_id ................................................................................................................................................... 115

config stp mst_ports .......................................................................................................................................................... 116

FORWARDING DATABASE COMMANDS ........................................................................................................ 117

create fdb ........................................................................................................................................................................... 117

create multicast_fdb........................................................................................................................................................... 118

config multicast_fdb .......................................................................................................................................................... 118

config fdb aging_time........................................................................................................................................................ 119

delete fdb ........................................................................................................................................................................... 119

enable flood_fdb ................................................................................................................................................................ 120

disable flood_fdb ............................................................................................................................................................... 120

show flood_fdb.................................................................................................................................................................. 121

clear flood_fdb .................................................................................................................................................................. 121

show multicast_fdb............................................................................................................................................................ 121

show fdb ............................................................................................................................................................................ 122

config multicast filter ........................................................................................................................................................ 123

show multicast filter port_mode ........................................................................................................................................ 123

create auto_fdb .................................................................................................................................................................. 124

delete auto_fdb .................................................................................................................................................................. 124

BROADCAST STORM CONTROL COMMANDS .............................................................................................. 126

config traffic control .......................................................................................................................................................... 126

show traffic control............................................................................................................................................................ 127

config traffic trap ............................................................................................................................................................... 127

QOS COMMANDS............................................................................................................................................... 129

config scheduling .............................................................................................................................................................. 130

show scheduling ................................................................................................................................................................ 131

config bandwidth_control.................................................................................................................................................. 132

show bandwidth_control ................................................................................................................................................... 132

config cos mac_mapping ................................................................................................................................................... 133

show cos mac_mapping..................................................................................................................................................... 134

delete cos mac_mapping.................................................................................................................................................... 134

config cos ip_mapping ...................................................................................................................................................... 134

show cos ip_mapping ........................................................................................................................................................ 135

delete cos ip_mapping ....................................................................................................................................................... 135

config cos mapping............................................................................................................................................................ 136

show cos mapping ............................................................................................................................................................. 136

config cos protocol_mapping ............................................................................................................................................ 137

show cos protocol_mapping .............................................................................................................................................. 137

delete cos protocol_mapping ............................................................................................................................................. 138

config cos vlanid_mapping................................................................................................................................................ 138

show cos vlanid_mapping ................................................................................................................................................. 139

delete cos vlanid_mapping ................................................................................................................................................ 139

config cos tos..................................................................................................................................................................... 140

show cos tos....................................................................................................................................................................... 140

config cos tcp_port_mapping ............................................................................................................................................ 141

show cos tcp_port_mapping .............................................................................................................................................. 141

delete cos tcp_port_mapping ............................................................................................................................................. 142

config cos udp_port_mapping ........................................................................................................................................... 142

show cos udp _port_mapping ............................................................................................................................................ 142

delete cos udp_port_mapping............................................................................................................................................ 143

config 802.1p user_priority ............................................................................................................................................... 143

show 802.1p user_priority ................................................................................................................................................. 144

config 802.1p default_priority........................................................................................................................................... 145

show 802.1p default_priority............................................................................................................................................. 145

config scheduling_mechanism .......................................................................................................................................... 146

show scheduling_mechanism ............................................................................................................................................ 147

config dscp mode............................................................................................................................................................... 147

config dscp_mapping......................................................................................................................................................... 147

show dscp_mapping .......................................................................................................................................................... 148

RMON COMMANDS............................................................................................................................................ 149

enable rmon ....................................................................................................................................................................... 149

disable rmon ...................................................................................................................................................................... 150

create rmon alarm .............................................................................................................................................................. 150

delete rmon alarm .............................................................................................................................................................. 151

create rmon collection stats ............................................................................................................................................... 151

delete rmon collection stats ............................................................................................................................................... 152

create rmon collection history ........................................................................................................................................... 152

delete rmon collection history ........................................................................................................................................... 153

create rmon event .............................................................................................................................................................. 153

delete rmon event .............................................................................................................................................................. 154

show rmon ......................................................................................................................................................................... 154

PORT MIRRORING COMMANDS ...................................................................................................................... 156

enable mirror ..................................................................................................................................................................... 156

disable mirror .................................................................................................................................................................... 156

config mirror target............................................................................................................................................................ 157

show mirror ....................................................................................................................................................................... 158

VLAN COMMANDS............................................................................................................................................. 159

create vlan.......................................................................................................................................................................... 160

delete vlan.......................................................................................................................................................................... 160

config vlan ......................................................................................................................................................................... 160

config gvrp ........................................................................................................................................................................ 161

config pvid......................................................................................................................................................................... 162

config gvrp timer ............................................................................................................................................................... 162

enable gvrp ........................................................................................................................................................................ 163

disable gvrp ....................................................................................................................................................................... 163

show vlan........................................................................................................................................................................... 164

show gvrp .......................................................................................................................................................................... 164

show gvrp timer ................................................................................................................................................................. 165

enable vlan_trunk .............................................................................................................................................................. 165

disable vlan_trunk ............................................................................................................................................................. 166

show vlan_trunk ................................................................................................................................................................ 166

config vlan_trunk ports...................................................................................................................................................... 167

enable asymmetric_vlan .................................................................................................................................................... 167

disable asymmetric_vlan ................................................................................................................................................... 167

show asymmetric_vlan ...................................................................................................................................................... 168

enable management vlan ................................................................................................................................................... 168

disable management vlan .................................................................................................................................................. 168

config management vlan.................................................................................................................................................... 169

show management vlan ..................................................................................................................................................... 169

Q-IN-Q COMMANDS........................................................................................................................................... 171

enable qinq ........................................................................................................................................................................ 171

disable qinq........................................................................................................................................................................ 172

show qinq .......................................................................................................................................................................... 172

config qinq ports................................................................................................................................................................ 173

create vlan_translation ....................................................................................................................................................... 173

show vlan_translation ........................................................................................................................................................ 174

delete vlan_translation cvid ............................................................................................................................................... 174

LINK AGGREGATION COMMANDS.................................................................................................................. 176

create link_aggregation ..................................................................................................................................................... 176

delete link_aggregation ..................................................................................................................................................... 177

config link_aggregation ..................................................................................................................................................... 177

show link_aggregation....................................................................................................................................................... 178

BASIC IP COMMANDS....................................................................................................................................... 179

config ipif System ............................................................................................................................................................. 179

show ipif ............................................................................................................................................................................ 180

BPDU ATTACK PROTECTION COMMANDS.................................................................................................... 181

config bpdu_protection ports............................................................................................................................................. 181

config bpdu_protection recovery_timer ............................................................................................................................ 182

config bpdu_protection...................................................................................................................................................... 183

enable bpdu_protection ..................................................................................................................................................... 183

disable bpdu_protection..................................................................................................................................................... 184

show bpdu_protection ....................................................................................................................................................... 184

MAC NOTIFICATION COMMANDS.................................................................................................................... 186

enable mac_notification..................................................................................................................................................... 186

disable mac_notification .................................................................................................................................................... 186

config mac_notification ..................................................................................................................................................... 187

config mac_notification ports............................................................................................................................................ 187

show mac_notification....................................................................................................................................................... 188

show mac_notification ports.............................................................................................................................................. 188

IGMP SNOOPING COMMANDS......................................................................................................................... 190

config igmp_snooping ....................................................................................................................................................... 191

config igmp_snooping querier........................................................................................................................................... 192

config igmp_snooping querier_selection........................................................................................................................... 192

config igmp_snooping querier_interval............................................................................................................................. 193

config igmp_snooping robustness_variable ...................................................................................................................... 193

create igmp_snooping multicast_vlan ............................................................................................................................... 194

config igmp_snooping multicast_vlan............................................................................................................................... 194

delete igmp_snooping multicast_vlan ............................................................................................................................... 195

config igmp_snooping multicast_vlan_group ................................................................................................................... 195

config igmp_snooping data_driven_learning .................................................................................................................... 196

config igmp_snooping data_driven_learning .................................................................................................................... 196

clear igmp_snooping data_driven_group .......................................................................................................................... 197

config igmp_snooping max_response_time ...................................................................................................................... 197

config router_ports ............................................................................................................................................................ 198

config router_ports_forbidden........................................................................................................................................... 198

config igmp access_authentication ports ........................................................................................................................... 199

show igmp access_authentication ports............................................................................................................................. 199

enable igmp_snooping ....................................................................................................................................................... 200

disable igmp_snooping ...................................................................................................................................................... 200

show igmp_snooping ......................................................................................................................................................... 201

show igmp_snooping group .............................................................................................................................................. 202

show igmp_snooping forwarding ...................................................................................................................................... 202

show igmp_snooping host ................................................................................................................................................. 203

show router_port................................................................................................................................................................ 203

LIMITED IP MULTICAST ADDRESS COMMANDS ........................................................................................... 205

create mcast_filter_profile................................................................................................................................................. 205

config mcast_filter_profile profile_id............................................................................................................................... 206

config mcast_filter_profile profile_name ......................................................................................................................... 206

delete mcast_filter_profile................................................................................................................................................. 207

show mcast_filter_profile.................................................................................................................................................. 207

config limited_multicast_addr ports .................................................................................................................................. 208

show limited_multicast_addr............................................................................................................................................. 208

config max_mcast_group ports ......................................................................................................................................... 209

show max_mcast_group ports ........................................................................................................................................... 209

802.1X COMMANDS ........................................................................................................................................... 211

enable 802.1x..................................................................................................................................................................... 212

disable 802.1x.................................................................................................................................................................... 212

show 802.1x....................................................................................................................................................................... 213

config 802.1x feap ............................................................................................................................................................. 213

show 802.1x auth_state ..................................................................................................................................................... 213

show 802.1x feap status..................................................................................................................................................... 214

show 802.1x auth_configuration ....................................................................................................................................... 215

config 802.1x auth_parameter ports .................................................................................................................................. 216

config 802.1x init .............................................................................................................................................................. 217

config 802.1x auth_protocol.............................................................................................................................................. 218

config 802.1x reauth .......................................................................................................................................................... 218

config radius add ............................................................................................................................................................... 218

config radius delete............................................................................................................................................................ 219

config radius ...................................................................................................................................................................... 219

show radius........................................................................................................................................................................ 220

config 802.1x auth_mode .................................................................................................................................................. 221

create 802.1x guest_vlan ................................................................................................................................................... 221

delete 802.1x guest_vlan ................................................................................................................................................... 222

config 802.1x guest_vlan ports.......................................................................................................................................... 222

show 802.1x guest_vlan .................................................................................................................................................... 223

create 802.1x user .............................................................................................................................................................. 223

show 802.1x user ............................................................................................................................................................... 224

delete 802.1x user .............................................................................................................................................................. 224

config 802.1x capability ports ........................................................................................................................................... 225

PORT SECURITY COMMANDS ......................................................................................................................... 226

config port_security ........................................................................................................................................................... 226

show port_security ............................................................................................................................................................ 227

TIME AND SNTP COMMANDS .......................................................................................................................... 228

config sntp ......................................................................................................................................................................... 228

show sntp........................................................................................................................................................................... 229

enable sntp ......................................................................................................................................................................... 229

disable sntp ........................................................................................................................................................................ 230

config time......................................................................................................................................................................... 230

config time_zone operator................................................................................................................................................. 231

config dst ........................................................................................................................................................................... 231

show time .......................................................................................................................................................................... 232

ARP COMMANDS ............................................................................................................................................... 234

create ArpSpoofing............................................................................................................................................................ 234

show ArpSpoofing............................................................................................................................................................. 235

delete ArpSpoofing............................................................................................................................................................ 235

config arp_aging time ........................................................................................................................................................ 236

clear arptable ..................................................................................................................................................................... 236

show arpentry .................................................................................................................................................................... 237

show arpentry aging_time ................................................................................................................................................. 237

BANNER COMMANDS ....................................................................................................................................... 238

config log_save_timing ..................................................................................................................................................... 238

show log_save_timing ....................................................................................................................................................... 239

show log ............................................................................................................................................................................ 239

COMMAND HISTORY LIST COMMANDS ......................................................................................................... 240

? ......................................................................................................................................................................................... 240

show command_history..................................................................................................................................................... 241

dir ...................................................................................................................................................................................... 242

SSH COMMANDS ............................................................................................................................................... 243

enable ssh .......................................................................................................................................................................... 243

disable ssh.......................................................................................................................................................................... 244

config ssh algorithm .......................................................................................................................................................... 244

config ssh authmode .......................................................................................................................................................... 245

show ssh authmode............................................................................................................................................................ 245

config ssh server ................................................................................................................................................................ 246

show ssh server.................................................................................................................................................................. 246

show ssh algorithm ............................................................................................................................................................ 247

config ssh user ................................................................................................................................................................... 248

show ssh user authmode .................................................................................................................................................... 248

SSL COMMANDS................................................................................................................................................ 249

enable ssl ........................................................................................................................................................................... 249

disable ssl .......................................................................................................................................................................... 249

show ssl ............................................................................................................................................................................. 250

download ssl certificate ..................................................................................................................................................... 250

ACCESS AUTHENTICATION CONTROL COMMANDS ................................................................................... 252

create authen_login method_list_name ............................................................................................................................. 253

config authen_login ........................................................................................................................................................... 253

delete authen_login method_list_name ............................................................................................................................. 255

show authen_login............................................................................................................................................................. 255

show authen_policy ........................................................................................................................................................... 256

create authen_enable method_list_name ........................................................................................................................... 256

config authen_enable ......................................................................................................................................................... 257

delete authen_enable method_list_name ........................................................................................................................... 258

show authen_enable........................................................................................................................................................... 259

enable authen_policy ......................................................................................................................................................... 259

disable authen_policy ........................................................................................................................................................ 260

config authen application .................................................................................................................................................. 260

show authen application .................................................................................................................................................... 261

config authen parameter .................................................................................................................................................... 262

show authen parameter ...................................................................................................................................................... 262

create authen server_host .................................................................................................................................................. 263

config authen server_host .................................................................................................................................................. 264

delete authen server_host .................................................................................................................................................. 265

show authen server_host.................................................................................................................................................... 265

create authen server_group................................................................................................................................................ 266

config authen server_group ............................................................................................................................................... 267

delete authen server_group................................................................................................................................................ 268

show authen server_host.................................................................................................................................................... 268

enable admin...................................................................................................................................................................... 269

config admin local_enable ................................................................................................................................................. 269

LACP COMMANDS............................................................................................................................................. 271

config lacp port_priority.................................................................................................................................................... 271

show lacp........................................................................................................................................................................... 271

LLDP COMMANDS ............................................................................................................................................. 273

enable lldp ......................................................................................................................................................................... 273

disable lldp ........................................................................................................................................................................ 274

config lldp message_tx_interval........................................................................................................................................ 274

config lldp message_tx_hold_multiplier ........................................................................................................................... 275

config lldp reinit_delay...................................................................................................................................................... 275

config lldp tx_delay ........................................................................................................................................................... 276

show lldp ........................................................................................................................................................................... 276

show lldp ports .................................................................................................................................................................. 277

show lldp local_ports......................................................................................................................................................... 278

show lldp remote_ports ..................................................................................................................................................... 279

config lldp ports................................................................................................................................................................. 279

show lldp mgt_addr ........................................................................................................................................................... 283

show lldp statistics............................................................................................................................................................. 283

ACCESS CONTROL LIST COMMANDS............................................................................................................ 285

create access_profile.......................................................................................................................................................... 286

config access_profile ......................................................................................................................................................... 287

delete access_profile.......................................................................................................................................................... 290

show access_profile ........................................................................................................................................................... 290

create cpu_access_profile.................................................................................................................................................. 291

config cpu_access_profile ................................................................................................................................................. 292

delete cpu_access_profile.................................................................................................................................................. 294

show cpu_access_profile ................................................................................................................................................... 295

TRAFFIC SEGMENTATION COMMANDS ......................................................................................................... 296

config traffic_segmentation ............................................................................................................................................... 296

show traffic_segmentation................................................................................................................................................. 296

SAFEGUARD COMMANDS................................................................................................................................ 298

config safeguard_engine .................................................................................................................................................... 298

show safeguard_engine ..................................................................................................................................................... 298

DEVICE SPECIFICATIONS ................................................................................................................................ 300

Technical Specifications .................................................................................................................................................... 300

Cable Lengths.................................................................................................................................................................... 302

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

1

1

11

1

INTRODUCTION

The DES-1210-28/ME consists of 24 10/100Mbps ports plus 2 combo 10/100/100/SFP ports and 2
dedicated SFP ports.

The Switch can be managed through the Switch’s serial port, Telnet, or the Web-based management
agent. The Command Line Interface (CLI) can be used to configure and manage the Switch via the serial
port or Telnet interfaces.

This manual provides a reference for all of the commands contained in the CLI. Configuration and
management of the Switch via the Web-based management agent is discussed in the Manual. For
detailed information on installing hardware please refer also to the Manual.

Accessing the Switch via the Serial Port
The Switch’s serial port’s default settings are as follows:

• 9600 bps

• No parity

• 8 data bits

• 1 stop bit

A computer running a terminal emulation program capable of emulating a VT-100 terminal and a serial
port configured as above then connected to the Switch’s serial port via an RJ-45 cable.

With the serial port properly connected to a management computer, the following screen should be
visible. If this screen does not appear, try pressing Ctrl+r to refresh the console screen.

Figure 1–1 Initial CLI screen

There is no initial username or password. Just press the Enter key twice to display the CLI input cursor

− DES-1210-28/ME:5#. This is the command line where all commands are input.
Setting the Switch’s IP Address
Each Switch must be assigned its own IP Address, which is used for communication with an SNMP

network manager or other TCP/IP application (for example BOOTP, TFTP). The Switch’s default IP
address is 10.90.90.90. You can change the default Switch IP address to meet the specification of your
networking address scheme.

The Switch is also assigned a unique MAC address by the factory. This MAC address cannot be changed,
but can be found on the initial boot console screen – shown below.

Figure 1–2 Boot Screen

The Switch’s MAC address can also be found in the Web management program on the Switch Information

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

2

(Basic Settings) window in the Configuration folder.
The IP address for the Switch must be set before it can be managed with the Web-based manager. The Switch
IP address can be automatically set using BOOTP or DHCP protocols, in which case the actual address
assigned to the Switch must be known.

The IP address may be set using the Command Line Interface (CLI) over the console serial port as follows:
Starting at the command line prompt, enter the command config ipif System ipaddress
xxx.xxx.xxx.xxx/yyy.yyy.yyy.yyy. Where the x’s represent the IP address to be assigned to the IP interface
named System and the y’s represent the corresponding subnet mask.

Alternatively, users can enter config ipif System ipaddress xxx.xxx.xxx.xxx/z. Where the x’s represent the IP
address to be assigned to the IP interface named System and the z represents the corresponding number of
subnets in CIDR notation.

The IP interface named System on the Switch can be assigned an IP address and subnet mask which
can then be used to connect a management station to the Switch’s Telnet or Web-based management
agent.

Figure 1–3 Assigning an IP Address

In the above example, the Switch was assigned an IP address of 10.73.21.11 with a subnet mask of

255.0.0.0. The system message Success indicates that the command was executed successfully. The
Switch can now be configured and managed via Telnet, SNMP MIB browser and the CLI or via the Web­based management agent using the above IP address to connect to the Switch.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

3

2

22

2

USING THE CONSOLE CLI

The Switch supports a console management interface that allows the user to connect to the Switch’s
management agent via a serial port and a terminal or a computer running a terminal emulation program.
The console can also be used over the network using the TCP/IP Telnet protocol. The console program
can be used to configure the Switch to use a SNMP-based network management software over the
network.

This chapter describes how to use the console interface to access the Switch, change its settings, and
monitor its operation.

NOTE: Switch configuration settings are saved to non-volatile RAM using the save command.

The current configuration will then be retained in the Switch’s NV-RAM, and reloaded when the
Switch is rebooted. If the Switch is rebooted without using the save command, the last
configuration saved to NV-RAM is loaded.

Connecting to the Switch
The console interface is used by connecting the Switch to a VT100-compatible terminal or a computer

running an ordinary terminal emulator program (for example, the HyperTerminal program included with
the Windows operating system) using an RJ-45 serial cable. Your terminal parameters will need to be set
to:

• VT-100 compatible

• 9600 bps

• 8 data bits

• No parity

• One stop bit

• No flow control

The same functions may also be accessed over a Telnet interface. Once an IP address for the Switch has
been set, A Telnet program can be used (in VT-100 compatible terminal mode) to access and control the
Switch. All of the screens are identical, whether accessed from the console port or from a Telnet
interface.

After the Switch reboots and you have to logged in, the console looks like this:

Figure 2–1 Initial Console Screen after Logging In

Commands are entered at the command prompt, DES-1210-28/ME:5#
There are a number of helpful features included in the CLI. Entering the ? command displays a list of all

of the top-level commands.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

4

Figure 2–2 The ? Command

When entering a command without its required parameters, the CLI displays the prompt: command:
config account message and the options listed below.

Figure 2–3 Example Command Parameter Help

In this case, the command config account was entered with the parameter <username>. The CLI will then
prompt to enter the <username> with the message, command: config account. Every command in the
CLI has this feature, and complex commands have several layers of parameter prompting.

In addition, after typing any given command plus one space, users can see all of the next possible sub­commands, in sequential order, by pressing the ? key.

To re-enter the previous command at the command prompt, press the up arrow cursor key. The previous
command appears at the command prompt.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

5

Figure 2–4 Using the Up Arrow to Re-enter a Command

In the above example, the command config account was entered without the required parameter
<username>, the CLI returned the command: config account prompt. The up arrow cursor control key
was pressed to re-enter the previous command (config account) at the command prompt. Now the
appropriate username can be entered and the config account command re-executed.

All commands in the CLI function in this way. In addition, the syntax of the help prompts are the same as
presented in this manual angle brackets < > indicate a numerical value or character string. The < > can
also indicate a word with a number for character allowed.

If a command is entered that is unrecognized by the CLI, the top-level commands are displayed under
the Available commands: prompt.

Figure 2–5 Available Commands

The top-level commands consist of commands such as show or config. Most of these commands
require one or more parameters to narrow the top-level command. This is equivalent to show what? or
config what? Where the what? is the next parameter.

For example, entering the show command with no additional parameters, the CLI will then display all of
the possible next parameters.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

6

Figure 2–6 Next possible completions: Show Command

In the above example, all of the possible next parameters for the show command are displayed. At the
next command prompt in the example, the up arrow was used to re-enter the show command, followed
by the account parameter. The CLI then displays the user accounts configured on the Switch.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

7

3

33

3

COMMAND SYNTAX

The following symbols are used to describe how command entries are made and values and arguments
are specified in this manual. The online help contained in the CLI and available through the console
interface uses the same syntax.

NOTE: All commands are case-sensitive. Be sure to disable Caps Lock or any other unwanted

function that changes text case.

<angle brackets>

Purpose Encloses a variable or value that must be specified.

Syntax

create account [admin | oper |user] <username 15>

Description In the above syntax example, supply a username in the

<username> space. Do not type the angle brackets.

Example
Command

create account admin newadmin1

[square brackets]

Purpose Encloses a required value or set of required arguments. One value

or argument can be specified.

Syntax

create account [admin | oper |user] <username 15>

Description

In the above syntax example, specify admin, oper or a user level
account to be created. Do not type the square brackets.

Example
Command

create account user newuser1

| vertical bar

Purpose Separates two or more mutually exclusive items in a list, one of

which must be entered.

Syntax

create account [admin | oper | user] <username 15>

Description

In the above syntax example, specify admin, oper, or user. Do not
type the vertical bar.

Example
Command

create account user newuser1

All commands are case-sensitive. Be sure to disable Caps Lock or any other unwanted function that
changes text case.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

8

{braces}

Purpose Encloses an optional value or set of optional arguments.

Syntax reset

Description execute “reset” will return the switch to its factory default setting.

Example
command

reset

Please be aware that all configuration will be reset to default value.

Are you sure you want to proceed with system reset now? (Y/N)[N] N

Line Editing Key Usage

Delete Deletes the character under the cursor and then shifts the

remaining characters in the line to the left.

Backspace Deletes the character to the left of the cursor and then shifts the

remaining characters in the line to the left.

Insert or Ctrl+R Toggle on and off. When toggled on, inserts text and shifts previous

text to the right.

Left Arrow Moves the cursor to the left.

Right Arrow Moves the cursor to the right.

Up Arrow Repeats the previously entered command. Each time the up arrow

is pressed, the command previous to that displayed appears. This
way it is possible to review the command history for the current
session. Use the down arrow to progress sequentially forward
through the command history list.

Down Arrow The down arrow displays the next command in the command

history entered in the current session. This displays each command
sequentially as it was entered. Use the up arrow to review previous
commands.

Tab Shifts the cursor to the next field to the left.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

9

Multiple Page Display Control Keys

Space Displays the next page.

CTRL+c Stops the display of remaining pages when multiple pages are to be

displayed.

ESC Stops the display of remaining pages when multiple pages are to be

displayed.

n Displays the next page.

p Displays the previous page.

q Stops the display of remaining pages when multiple pages are to be

displayed.

r Refreshes the pages currently displayed.

a Displays the remaining pages without pausing between pages.

Enter Displays the next line or table entry.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

10

4

44

4

BASIC SWITCH COMMANDS

The Basic Switch commands in the Command Line Interface (CLI) are listed (along with the appropriate
parameters) in the following table.

Command Parameter

enable password
encryption

disable password
encryption

create account [admin | operator | user] <username 15>

config account <username 15>

show account

delete account <username 15>

show session

show switch

enable web <tcp_port_number 1-65535>

disable web

enable autoconfig

disable autoconfig

save {[config config_id <value 1-2> | log | account]}

reboot

reset {[config | system | account | password]} {force_agree}

logout

ping <ipaddr> {times <value 1-255>} {timeout <sec 1-99>}

enable telnet

disable telnet

show tech support

Each command is listed in detail, as follows:

enable password encryption

Purpose Used to enable password encryption on a user account.

Syntax

enable password encryption

Description The user account configuration information will be stored in the

configuration file, and can be applied to the system at a time in the
future. If the password encryption is enabled, the password will be in
encrypted form. If password encryption is disabled and the user
specifies the password in encrypted form, or if the password has

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

11

been converted to encrypted form by the last enabled password
encryption command, the password will still be in encrypted form. It
can not revert back to plain text.

Parameters None.

Restrictions Only Administrator level users can issue this command.

Example usage:

To enable password encryption on the Switch:

DES-1210-28/ME:5# enable password encryption
Command: enable password encryption

Success.

DES-1210-28/ME:5#

disable password encryption

Purpose Used to disable password encryption on a user account.

Syntax

disable password encryption

Description The user account configuration information will be stored in the

configuration file, and can be applied to the system at a time in the
future. If the password encryption is enabled, the password will be in
encrypted form. If password encryption is disabled and the user
specifies the password in encrypted form, or if the password has
been converted to encrypted form by the last enabled password
encryption command, the password will still be in encrypted form. It
can not revert back to plain text.

Parameters None.

Restrictions Only Administrat level users can issue this command.

Example usage:

To disable password encryption on the Switch:

DES-1210-28/ME:5# disable password encryption
Command: disable password encryption

Success.

DES-1210-28/ME:5#

create account

Purpose To create user accounts.

Syntax

create account [admin | operator | user] <username 15>

Description

The create account command creates an administrator, operator,
or user account that consists of a username and an optional

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

12

password. Up to 31 accounts can be created. You can enter
username and Enter. In this case, the system prompts for the
account’s password, which may be between 0 and 15 characters.
Alternatively, you can enter the username and password on the
same line.

Parameters

admin − Name of the administrator account.

oper − Specify an operator level account.
user − Specify a user account with read-only permissions.

<username 1-15> − The account username may be between 1 and

15 characters.
password <password_string> {encrypted} - the account password

can be included, and (optionally) can be encrypted.

Restrictions Only Administrator level users can issue this command.

Usernames can be between 1 and 15 characters.

Passwords can be between 0 and 15 characters.

NOTE: You are not required to enter a User Name. However, if you do not enter a User Name,
you cannot perform the following actions:

Create a monitor or operator (level 1 or level 14) users until an administrator user (level 15) is
defined.

Delete the last administrator user if there are monitor and/or operator users defined.

Example usage:

To create an administrator-level user account with the username ‘dlink’:

DES-1210-28/ME:5# create account admin dlink
Command: create account admin dlink

Enter a case-sensitive new password:*****
Enter the new password again for confirmation:*****

Success.

DES-1210-28/ME:5#

config account

Purpose To change the password for an existing user account.

Syntax

config account <username 15>

Description

The config account command changes the password for a user
account that has been created using the create account command.
The system prompts for the account’s new password, which may be
between 0 and 15 characters.

Parameters

<username 1-15> − the account username.

Restrictions Only Administrator-level users can issue this command.

Example usage:

To configure the user password of ‘dlink’ account:

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

13

DES-1210-28/ME:5# config account dlink
Enter a old password:****

Enter a case-sensitive new password:******
Enter the new password again for confirmation:******

Success.

DES-1210-28/ME:5#

show account

Purpose To display information about all user accounts on the Switch.

Syntax

show account

Description

The show account command displays all account usernames and
their access levels created on the Switch. Up to 31 user accounts
can exist on the Switch at one time.

Parameters None.

Restrictions None.

Example usage:

To display the account which have been created:

DES-1210-28/ME:5# show account
Command: show account

Username Access Level

------------------ -----------­dlink Admin

Total Entries : 1

DES-1210-28/ME:5#

delete account

Purpose To delete an existing user account.

Syntax

delete account <username 15>

Description

The delete account command deletes a user account that has been
created using the create account command.

Parameters

<username 15> − the account username.

Restrictions

Only Administrator-level users can issue this command.

Example usage:

To delete the user account ‘System’:

DES-1210-28/ME:5# delete account System
Command: delete account System

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

14

Success.

DES-1210-28/ME:5#

show session

Purpose To display information about currently logged-in users.

Syntax

show session

Description

The show session command displays a list of all the users that are
logged-in at the time the command is issued. The information
includes the session ID (0 for the first logged-in user, 1 for the next
logged-in user, etc.), the Protocol used to connect to the Switch, the
user’s IP address, the user’s access Level (1=user, 15=admin), and
the account name on the Switch.

Parameters None.

Restrictions None.

Example usage:

To display the way users logged in:

DES-1210-28/ME:5# show session
Command: show session

Total Entries: 1

ID Login Time Live Time From Level Name

-- -------------------- ------------ --------------- ----- --------------­0 Jan 1 01:04:08 2011 00:11:05 Serial Port 14 dorothy

Total Entries: 1

CTRL+C ESC q Quit SPACE n Next Page p Previous Page r Refresh

show switch

Purpose To display information about the Switch.

Syntax

show switch

Description

The show switch command displays information about the Switch
settings, including Device Type, MAC Address, IP configuration,
Hardware/Software version, System information, and Switch
Network configuration.

Parameters None.

Restrictions None.

Example usage:

To display the Switch information:

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

15

DES-1210-28/ME:5# show switch
Command: show switch

System name :
System Contact :
System Location :
System up time : 0 days, 1 hrs, 17 min, 19 secs
System Time : 01/01/2011 01:17:20
System hardware version :
System firmware version : 6.00.004
System boot version : 1.00.002
System Protocol version : 2.001.004
System serial number : 1MB1733K0000A
MAC Address : 00-B2-FD-DA-EE-EB
STP : Disabled
SNMP Status : Enabled
Port Mirroring : Disabled

802.1X Status : Disabled
Storm Control : Disabled

802.1Q Management VLAN : Disabled
Safeguard Engine : Enabled
IGMP Snooping : Disabled

DES-1210-28/ME:5#

enable web

Purpose To enable the HTTP-based management software on the Switch.

Syntax

enable web <tcp_port_number 1-65535>

Description

The enable web command enables the Web-based management
software on the Switch. The user can specify the TCP port number
the Switch uses to listen for Telnet requests.

Parameters

<tcp_port_number 1-65535> − The TCP port number. TCP ports are
numbered between 1 and 65535. The ‘well-known’ port for the Web­based management software is 80.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To enable HTTP and configure the TCP port number to listen for Telnet requests:

DES-1210-28/ME:5# enable web 80
Command: enable web 80

Success.

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

16

disable web

Purpose To disable the HTTP-based management software on the Switch.

Syntax

disable web

Description

The disable web command disables the Web-based management
software on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To disable HTTP-based management software on the Switch:

DES-1210-28/ME:5# disable web
Command: disable web

Success.

DES-1210-28/ME:5#

enable autoconfig

Purpose Used to activate the auto configuration function for the Switch. This

will load a previously saved configuration file for current use.

Syntax

enable autoconfig

Description When autoconfig is enabled on the Switch, the DHCP reply will

contain a configuration file and path name. It will then request the file
from the TFTP server specified in the reply. When autoconfig is
enabled, the ipif settings will automatically become DHCP client.

Parameters None.

Restrictions When autoconfig is enabled, the Switch becomes a DHCP client

automatically (same as: config ipif System dhcp). The DHCP server
must have the TFTP server IP address and configuration file name,
and be configured to deliver this information in the data field of the
DHCP reply packet. The TFTP server must be running and have the
requested configuration file in its base directory when the request is
received from the Switch. Consult the DHCP server and TFTP
server software instructions for information on loading a
configuration file.

If the Switch is unable to complete the auto configuration process
the previously saved local configuration file present in Switch
memory will be loaded.

Example usage:

To enable auto configuration on the Switch:

DES-1210-28/ME:5# enable autoconfig
Command: enable autoconfig

Success.
DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

17

disable autoconfig

Purpose Use this to deactivate auto configuration from DHCP.

Syntax

disable autoconfig

Description

The disable autoconfig command is used to instruct the Switch not
to accept auto configuration instruction from the DHCP server. This
does not change the IP settings of the Switch. The ipif settings will
continue as DHCP client until changed with the config ipif command.

Parameters None.

Restrictions Only Administrator-level users can issue this command. .

Example usage:

To stop the auto configuration function:

DES-1210-28/ME:5# disable autoconfig
Command: disable autoconfig

Success.
DES-1210-28/ME:5#

show autoconfig

Purpose Used to display the current autoconfig status of the Switch.

Syntax

show autoconfig

Description

The show autoconfig command is used to list the current status of
the auto configuration function.

Parameters None.

Restrictions None.

Example usage:

To display the autoconfig status:

DES-1210-28/ME:5# show autoconfig
Command: show autoconfig

Autoconfig State: Enabled

DES-1210-28/ME:5#

save

Purpose To save changes in the Switch’s configuration to non-volatile RAM.

Syntax

save {[config config_id <value 1-2> | log | account]}

Description

The save command used to enter the current switch configuration
into non-volatile RAM. The saved switch configuration will be loaded
into the Switch’s memory each time the Switch is restarted.

Parameters

config – Used to save the current configuration to a file.

config_id <value 1-2> - Specifies which cfg file ID. if cfg ID is not

specified, it refers to the boot_up CFG file.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

18

log – Used to save the current log to a file. The log file cannot be
deleted.

account – Used to save the account to a file.

Restrictions Only administrator-level users can issue this command.

Example usage:

To save the Switch’s current configuration to non-volatile RAM:

DES-1210-28/ME:5# save
Command: save

Building configuration ...
[OK]
DES-1210-28/ME:5#

reboot

Purpose To reboot the Switch. If the Switch is a member of a stack, it may be

rebooted individually, without affecting the other members of the
stack.

Syntax

reboot

Description

The reboot command restarts the Switch.

Parameters None.

Restrictions Only Administrator or operate-level users can issue this command.

Example usage:

To restart the Switch:

DES-1210-28/ME:5# reboot
Command: reboot

Are you sure you want to proceed with the system reboot?(y/n)y
% Please wait, the switch is rebooting...

DES-1210-28/ME:5# System will Reboot....



Boot Procedure

--------------------------------------------------------------------------------

Please wait, loading Runtime image ........................ 100%

MAC Address : 00-B2-FD-DA-EE-EB
H/W Version :
F/W Version : 6.00.004

--------------------------------------------------------------------------------

DES-1210-28/ME Fast Ethernet Switch
Command Line Interface

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

19

Firmware: Build 6.00.004
Copyright(C) 2010 D-Link Corporation. All rights reserved.

DES-1210-28/ME login:

reset

Purpose To reset the Switch to the factory default settings.

Syntax

reset {[config | system | account | password]} {force_agree}

Description

The reset command restores the Switch’s configuration to the
default settings assigned from the factory. Execution of the reset
command through the CLI retains the unit’s current stack
membership number.

Parameters

config - If the keyword ‘config’ is specified, all of the factory default
settings are restored on the Switch including the IP address, user
accounts, and the switch history log. The Switch will not save or
reboot.

system − If the keyword ‘system’ is specified all of the factory default
settings are restored on the Switch. The Switch will save and reboot
after the settings are changed to default. Rebooting will clear all
entries in the Forwarding Data Base.

account − If the keyword ‘account is specified, all of the factory
default account settings are restored on the Switch.

password − If the keyword ‘password is specified, all of the factory
default password settings are restored on the Switch.

{force_agree} - When force_agree is specified, the reset command
will be executed immediately without further confirmation.

If no parameter is specified, the Switch’s current IP address, user
accounts, and the switch history log are not changed. All other
parameters are restored to the factory default settings. The Switch
will not save or reboot.

Restrictions Only administrator-level users can issue this command.

Example usage:

To restore all of the Switch’s parameters to their default values:

DES-1210-28/ME:5# reset system
Command: reset system

Are you sure you want to proceed with the system reset?(y/n)y
% Success.

DES-1210-28/ME:5# System will Reboot....

logout

Purpose To log out a user from the Switch’s console.

Syntax

Logout

Description

The logout command terminates the current user’s session on the

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

20

Switch’s console.

Parameters None.

Restrictions None.

Example usage:

To terminate the current user’s console session:

DES-1210-28/ME:5# logout

ping

Purpose To test the connectivity between network devices.

Syntax

ping <ipaddr> {times <value 1-255>} {timeout <sec 1-99>}

Description

The ping command sends Internet Control Message Protocol
(ICMP) echo messages to a remote IP address. The remote IP
address then ‘echos’ or returns the message. This is used to confirm
connectivity between the Switch and the remote device.

Parameters

<ipaddr> - The IP address of the host.

times <value 1-255> - The number of individual ICMP echo

messages to be sent. The maximum value is 255. The default is 4.
timeout <sec 1-99> - The time-out period while waiting for a

response from the remote device. A value of 1 to 99 seconds can be
specified. The default is 1 second.

Restrictions None.

Example usage:

To ping the IP address 10.6.150.34 three times:

DES-1210-28/ME:5# ping 10.6.150.34 times 3
Command: ping 10.6.150.34 times 3

Reply Not Received From : 10.6.150.34, Timeout : 5 secs
Reply Not Received From : 10.6.150.34, Timeout : 5 secs
Reply Not Received From : 10.6.150.34, Timeout : 5 secs

--- 10.6.150.34 Ping Statistics --­3 Packets Transmitted, 0 Packets Received, 100% Packets Loss
DES-1210-28/ME:5#

enable telnet

Purpose To enable the telnet.

Syntax

enable telnet

Description

The enable telnet command enables telnet.

Parameters None.

Restrictions Only Administrator or operate-level users can issue this command

Example usage:

To enable telnet:

DES-1210-28/ME:5# enable telnet

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

21

Command: enable telnet

Success.
DES-1210-28/ME:5#

disable telnet

Purpose To disable telnet.

Syntax

disable telnet

Description

The disable telnet command disables telnet.

Parameters None.

Restrictions Only Administrator or operate-level users can issue this command

Example usage:

To disable telnet:

DES-1210-28/ME:5# disable telnet
Command: disable telnet

Success.

DES-1210-28/ME:5#

show tech support

Purpose To display system and configuration information. to provide to the

Technical Assistance Center when reporting a problem, use the
show tech-support command.

Syntax

show tech support

Description

The show tech support command displays system and
configuration information. to provide to the Technical Assistance
Center when reporting a problem.

By default, this command displays the output for technical-support­related show commands. Use keywords to specify the type of
information to be displayed. If you do not specify any parameters,
the system displays all configuration and memory data.

The show tech support command may time out if the configuration
file output takes longer to display than the configured session
timeout time. If this happens, enter a set logout timeout value of 0 to
disable automatic disconnection of idle sessions or enter a longer
timeout value.

The show tech support command output is continuous; it does not
display one screen at a time. To interrupt the output, press Esc.

Parameters None.

Restrictions Only Administrator-level users can issue this command..

Example usage:

To display technical support information on the Switch:

DES-1210-28/ME:5# show tech support

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

22

Command: show tech support

- System Info. -

System name :
System Contact :
System Location :
System up time : 0 days, 1 hrs, 28 min, 24 secs
System Time : 01/01/2011 01:28:22
System hardware version :
System firmware version : 6.00.004
System boot version : 1.00.002
System Protocol version : 2.001.004
System serial number : 1MB1733K0000A
MAC Address : 00-B2-FD-DA-EE-EB
STP : Disabled
SNMP Status : Enabled
Port Mirroring : Disabled

802.1X Status : Disabled
Storm Control : Disabled

802.1Q Management VLAN : Disabled
Safeguard Engine : Enabled
IGMP Snooping : Disabled
CTRL+C ESC q Quit SPACE n Next Page ENTER Next Entry a ALL

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

23

5

55

5

SMTP SERVER COMMANDS

The SMTP Server commands in the Command Line Interface (CLI) are listed (along with the appropriate
parameters) in the following table.

Command Parameter

enable smtp

disable smtp

config smtp

[self_mail_addr <mail_addr 64> | server <ipaddr> | server_port
<tcp_port_number 1-65535>] [{add mail_receiver <mail_addr 64>| delete
mail_receiver <index 1-8>}]

show smtp

smtp sent_testmsg

Each command is listed in detail, as follows:

enable smtp

Purpose To enable the SMTP server feature on the Switch.

Syntax

enable smtp

Description

The enable smtp command enables the SMTP server feature on
the Switch.

Parameters None.

Restrictions Only Administrator-level users can issue this command..

Example usage:

To enable SMTP feature on the Switch:

DES-1210-28/ME:5# enable smtp
Command: enable smtp

Success!
DES-1210-28/ME:5#

disable smtp

Purpose To disable the SMTP server feature on the Switch.

Syntax

disable smtp

Description

The disable smtp command disables the SMTP server feature on
the Switch.

Parameters None.

Restrictions Only Administrator-level users can issue this command..

Example usage:

To disable STMP feature on the Switch:

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

24

DES-1210-28/ME:5# disable smtp
Command: disable smtp

Success!
DES-1210-28/ME:5#

config smtp

Purpose To configure the fields to set up the SMTP server for the switch,

along with setting e-mail addresses to which switch log files can be
sent when a problem arises on the Switch.

Syntax

config smtp [self_mail_addr <mail_addr 64> | server <ipaddr> |
server_port <tcp_port_number 1-65535>] [{add mail_receiver
<mail_addr 64>| delete mail_receiver <index 1-8>}]

Description

The config smtp command is used to configure the fields to set up
the SMTP server for the switch, along with setting e-mail addresses
to which switch log files can be sent when a problem arises on the
Switch.

Parameters

self_mail_addr <mail_addr 64> − Specifies the e-mail address from
which mail messages will be sent. Only one self mail address can be
configured on the Swtich.

server <ipaddr> − Specifies the IP address of the SMTP server. This
will be the device that sends out the mail for user. For example,

10.90.90.99.

<tcp_port_number 1-65535> − Specifies the port number that the
Switch will connect with on the SMTP server. The range is between
1 and 65535.

add mail_receiver <mail_addr 64> − Specifies a list of e-mail
addresses so recipients can receive e-mail messages regarding
Switch functions. Up to 8 e-mail address can be added per Switch.

delete mail_receiver <index 1-8> − Specifies the e-mail address
index to be deleted.

Restrictions Only Administrator-level users can issue this command..

Example usage:

To config SMTP with self mail address ‘[email protected]’ on the Switch:

DES-1210-28/ME:5# config smtp self_mail_addr [email protected]
Command: config smtp self_mail_addr [email protected]

Success!
DES-1210-28/ME:5#

show smtp

Purpose To display the SMTP server settings on the Switch.

Syntax

show smtp

Description

The show smtp command displays the SMTP server settings on the
Switch.

Parameters None.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

25

Restrictions None.

Example usage:

To display SMTP information on the Switch:

DES-1210-28/ME:5# show smtp
Command: show smtp

smtp status : Enable
smtp server address : 0.0.0.0
smtp server port : 25
self mail address : [email protected]

Index Mail Receiver Address

-------- -------------------------------------­1
2
3
4
5
6
7
8

DES-1210-28/ME:5#

smtp sent_testmsg

Purpose To send test messages to all mail recipients configured on the

Switch.

Syntax

smtp sent_testmsg

Description

The smtp sent_testmsg command is used to send test messages
to all mail recipients configured on the Switch.

Parameters None.

Restrictions Only Administrator-level users can issue this command..

Example usage:

To send SMTP test message to all mail receivers:

DES-1210-28/ME:5# smtp sent_testmsg
Command: smtp sent_testmsg

Subject: This is a SMTP test
Content: Hello everybody!!

Sending mail, please wait...

Success!

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

26

6

66

6

MODIFY BANNER AND PROMPT COMMANDS

The Modify Banner and Prompt commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.

Command Parameter

config
command_prompt

[<string 32> | default | username]

config
greeting_message

{default}

show
greeting_message

Each command is listed in detail, as follows:

config command_prompt

Purpose To configure the command prompt.

Syntax

config command_prompt [<string 32> | default | username]

Description

The config command_prompt command configures the command
prompt.

Parameters

<string 32> – The command prompt can be changed by entering a
new name of no more that 32 characters.

default – The command prompt will reset to factory default command
prompt. Default = the name of the Switch model, for example “DES­1210-28”.

username – The command prompt will be changed to the login
username.

Restrictions

Only Administrator-level users can issue this command. Other
restrictions include:

If the “reset” command is executed, the modified command prompt
will remain modified. However, the “reset config/reset system”
command will reset the command prompt to the original factory
banner.

Example usage:

To modify the command prompt to “AtYourService”:

DES-1210-28/ME:5# config command_prompt AtYourService
Command: config command_prompt AtYourService

Success.

AtYourService:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

27

config greeting_message

Purpose Used to configure the login banner (greeting message).

Syntax

config greeting_message {default}

Description

The config greeting_message command to modify the login
banner (greeting message).

Parameters

default – If the user enters default to the modify banner command,
then the banner will be reset to the original factory banner.
To open the Banner Editor, click Enter after typing the config
greeting_message command. Type the information to be displayed
on the banner by using the commands described on the Banner
Editor:
Quit without save: Ctrl+C
Save and quit: Ctrl+W
Move cursor: Left/Right/Up/Down
Delete line: Ctrl+D
Erase all setting: Ctrl+X

Reload original setting: Ctrl+L

Restrictions

Only Administrator-level users can issue this command. Other
restrictions include:
If the “reset” command is executed, the modified banner will remain
modified. However, the “reset config/reset system” command will
reset the modified banner to the original factory banner.
The capacity of the banner is 6*80. 6 Lines and 80 characters per
line.
Ctrl+W will only save the modified banner in the DRAM. Users need
to type the “save config/save all” command to save it into Flash.

Only valid in threshold level.

Example usage:

To the banner:

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

28

DES-1210-28/ME:5#
Command: config greeting_message

Greeting Messages Editor
===========================================================

DES-1210-28/ME Fast Ethernet Switch
Command Line Interface

Copyright(C) 2012 D-Link Corporation. All rights reserved.

============================================================

<Function Key> <Control Key>
Ctrl+C Quit without save left/right/
Ctrl+W Save and quit up/down Move cursor
Ctrl+D Delete line
Ctrl+X Erase all setting
Ctrl+L Reload original setting

show greeting_message

Purpose Used to view the currently configured greeting message configured

on the Switch.

Syntax

show greeting_message

Description

The show greeting_message command is used to view the
currently configured greeting message on the Switch.

Parameters None.

Restrictions None.

Example usage:

To view the currently configured greeting message:

DES-1210-28/ME:5# show greeting_message
Command: show greeting_message

DES-1210-28/ME Fast Ethernet Switch
Command Line Interface

Copyright(C) 2012 D-Link Corporation. All rights reserved.

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

29

7

77

7

SWITCH PORT COMMANDS

The Switch Port commands in the Command Line Interface (CLI) are listed (along with the appropriate
parameters) in the following table.

Command Parameter

config ports

config ports [all | <portlist>] medium_type [copper | fiber_100 | fiber_1G]
MDI/MDIX [MDI | MDIX | auto] {description <desc 32> | flow_control [enable |
disable] | learning [enable | disable] | state [enable | disable] | speed [auto |
10_half | 100_full | 100_half | 10_full | 10_half]}

show ports

{<portlist> | all} {description | err_disabled}

Each command is listed in detail, as follows:

config ports

Purpose To configure the Switch’s Ethernet port settings.

Syntax

config ports [all | <portlist>] medium_type [copper | fiber_100 |
fiber_1G] MDI/MDIX [MDI | MDIX | auto] {description <desc 32> |
flow_control [enable | disable] | learning [enable | disable] |
state [enable | disable] | speed [auto | 10_half | 100_full |
100_half | 10_full | 10_half]}

Description

The config ports command configures the Switch’s Ethernet port
settings. Only the ports listed in the <portlist> are affected.

Parameters

<portlist> − A port or range of ports to be configured.

all − Configures all ports on the Switch.

medium_type [copper | fiber_100 | fiber_1G ] − If configuring the
Combo ports, this defines the type of medium being configured.

MDI/MDIX [MDI | MDIX | j auto] − Specifies the MDI or MDIX setting

of the port. The MDIX setting can be auto, normal or cross.

If set to normal state, the port in MDIX mode, can be connected to
PC NIC using a straight cable. If set to cross state, the port in mdi
mode, can be connected to a port (in mdix mode) on another switch
through a straight cable.

description <desc 32> − Enter and alphanumeric string of no more
that 32 characters to describe a selected port interface.

flow_control [enable] – Enables flow control for the specified ports.

flow_control [disable] – Disables flow control for the specified ports.

learning [enable | disable] c Enables or disables the MAC address

learning on the specified range of ports.
state [enable | disable] − Enables or disables the specified range of

ports.
speed – Sets the speed of a port or range of ports, with the addition

of one of the following:

• auto − Enables auto-negotiation for the specified range of
ports.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

30

• [10 | 100 | 1000] − Configures the speed in Mbps for the
specified range of ports.

• [half | full] − Configures the specified range of ports as either
full or half-duplex.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To configure the speed of ports 1-3 to be 100 Mbps, full duplex, learning and state enabled:

DES-1210-28/ME:5# config ports 1-3 medium_type copper speed 100_full learning en
able state enable
Command: config ports 1-3 medium_type copper speed 100_full learning enable stat
e enable

Success

DES-1210-28/ME:5#

show ports

Purpose To display the current configuration of a range of ports.

Syntax

show ports {<portlist> | all} {description | err_disabled}

Description

The show ports command displays the current configuration of a
port or range of ports.

Parameters

<portlist> − A port or range of ports whose settings are to be
displayed.

all – Specifies all ports to be displayed.

Restrictions None.

Example usage:

To display the configuration of port 8 on the Switch:

DES-1210-28/ME:5# show ports 8
Command: show ports 8

Port State/ Settings Connection Address
Type MDI Speed/Duplex/FlowCtrl Speed/Duplex/FlowCtrl Learning

----- ------- -------------------------------- --------------------------------- -----------­8 Enabled Auto/Disabled Link Down Enabled
Auto

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

31

8

88

8

LOOPBACK DETECTION COMMANDS

The Loopback Detection commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.

Command Parameter

config loopdetect [enable | disable]

config loopdetect mode [portbase | vlanbase]

config loopdetect ports [<portlist> | all] [enable | disable]

config loopdetect interval_time <value 1-32767> lbd_recover_time [0 | <value 60-1000000>]

show loopdetect {ports [<portlist> | all]}

Each command is listed in detail, as follows:

config loopdetect

Purpose To enable the loop back detection to be enabled or disabled on the

Switch.

Syntax

config loopdetect [enable | disable]

Description

The config loopdetect command enables or disables the loop back
detection on the Switch.

Parameters

[enabled | disabled] − Specifies the loop back detection is enabled or
disabled on the Switch.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To enable the loopback detection feature on the Switch:

DES-1210-28/ME:5# config loopdetect enable
Command: config loopdetect enable

Success!
DES-1210-28/ME:5#

config loopdetect mode

Purpose To configure the loop back detection mode to be portbase or

vlanbase on the Switch.

Syntax

config loopdetect mode [portbase | vlanbase]

Description

The config loopdetect mode command configures loop back
detection mode to be portbase or vlanbase on the Switch.

Parameters

[portbase | vlanbase]] - Specifies the loopdetect mode to be
portbase or vlanbase.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

32

Restrictions None.

Example usage:

To configure the loopback detection mode to be portabse on the Switch:

DES-1210-28/ME:5# config loopdetect mode portbase
Command: config loopdetect mode portbase

Success!
DES-1210-28/ME:5#

config loopdetect ports

Purpose To configures the loop back detection to be enabled or disabled for

the specific ports on the Switch.

Syntax

config loopdetect ports [<portlist> | all] [enable | disable]

Description

The config loopdetect ports command configures the loop back
detection to be enabled or disabled for the specific ports on the
Switch.

Parameters

<portlist> − A port or range of ports to be configured.
all − All ports settings are to be configured.

[enabled | disabled] − Specifies the loop back detection is enabled or

disabled for the specified ports on the Switch.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To enable the loop back detection on the Switch:

DES-1210-28/ME:5# config loopdetect ports all enable
Command: config loopdetect ports all enable

Success!
DES-1210-28/ME:5#

config loopdetect

Purpose To configure the loop back detection interval time and recover time

on the Switch.

Syntax

config loopdetect interval_time <value 1-32767>
lbd_recover_time [0 | <value 60-1000000>]

Description

The config loopdetect command configures the loop back
detection interval time and recover time on the Switch.

Parameters

interval_time <value 1-32767> − Specifies the interval time of loop
back detection. The range is between 1 and 32767 seconds.

lbd_recover_time [0 | <value 60-10000>] − Specifies the recover
time of loop back detection on the switch. The range is between 60
and 10000 seconds.

Restrictions Only administrator or operate-level users can issue this command.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

33

Example usage:

To configure the loop back detection with interval time 500 on the Switch:

DES-1210-28/ME:5# config loopdetect interval_time 500
Command: config loopdetect interval_time 500

Success!
DES-1210-28/ME:5#

show loopdetect

Purpose To display the loop back detection information on the Switch.

Syntax

show loopdetect {ports [<portlist> | all]}

Description

The show loopdetect command displays the loop back detection
information on the Switch.

Parameters

<portlist> − A port or range of ports to be displayed.
all − All ports settings are to be displayed.

Restrictions None.

Example usage:

To display the loop back detection information on the Switch:

DES-1210-28/ME:5# show loopdetect
Command: show loopdetect

Loopdetect Global Settings

---------------------------------­Loopdetect Status : Enabled
Loopdetect Mode : Port-Base
Loopdetect Interval : 100
Recover Time : 60
DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

34

9

99

9

DOS PREVENTION COMMANDS

The DoS Prevention commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.

Command Parameter

config dos_prevention
dos_type

[ {land_attack | blat_attack | smurf_attack | tcp_null_scan | tcp_xmascan |
tcp_synfin | tcp_syn_srcport_less_1024} | all] {action [ drop | mirror <portlist>
{priority <value 0-7> | rx_rate [ no_limit | <value 64-1024000> ] } ] | enable |
disable ] }

show dos_prevention

{ land_attack | blat_attack | smurf_attack | tcp_null_scan | tcp_xmascan |
tcp_synfin | tcp_syn_srcport_less_1024 }

clear dos_prevention
counters

[land_attack | blat_attack | smurf_attack | tcp_null_scan | tcp_xmascan |
tcp_synfin | tcp_syn_srcport_less_1024]

enable dos_prevention
trap_log

disable dos_prevention
trap_log

Each command is listed in detail, as follows:

config dos_prevention dos_type

Purpose Used to discard the L3 control packets sent to CPU from specific

ports.

Syntax

config dos_prevention dos_type [ {land_attack | blat_attack |
smurf_attack | tcp_null_scan | tcp_xmascan | tcp_synfin |
tcp_syn_srcport_less_1024} | all] {action [ drop | mirror
<portlist> {priority <value 0-7> | rx_rate [ no_limit | <value 64­1024000> ] } ] | enable | disable ] }

Description

The create snmp user command is used to configure the
prevention of DoS attacks, and includes state and action. The
packets matching will be used by the hardware. For a specific type
of attack, the content of the packet, regardless of the receipt port or
destination port, will be matched against a specific pattern.

Parameters The type of DoS attack. Possible values are as follows:

land_attack, blat_attack, smurf_attack, tcp_null_scan, tcp_xmascan

tcp_synfin and tcp_syn_srcport_less_1024.
state - Enable or disable DoS prevention.

By default, prevention for all types of DoS are enabled except for
tcp_syn_srcport_less_1024.

action - When enabling DoS prevention, the following actions can be
taken.

drop – Drop the attack packets.

mirror – Mirror the packet to other port for further process.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

35

priority – Change packet priority by the Switch from 0 to 7.

If the priority is not specified, the original priority will be used.
rx_rate – controls the rate of the received DoS attack packets.

• If not specified, the default action is drop.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To configure a land attack and blat attack prevention:

DES-1210-28/ME:5# config dos_prevention dos_type blat_attack action
drop

Command: config dos_prevention dos_type blat_attack action drop

Success!

DES-1210-28/ME:5#

show dos_prevention

Purpose Used to display DoS prevention information.

Syntax

show dos_prevention { land_attack | blat_attack | smurf_attack |
tcp_null_scan | tcp_xmascan | tcp_synfin |
tcp_syn_srcport_less_1024 }

Description

The show dos_prevention command is used to display DoS
prevention information, including the type of DoS attack, the
prevention state, the corresponding action if the prevention is
enabled, and the counter information of the DoS packet.

Parameters The type of DoS attack. Possible values are as follows:

land_attack, blat_attack, smurf_attack, tcp_null_scan, tcp_xmascan

tcp_synfin and tcp_syn_srcport_less_1024.

Restrictions None.

Example usage:

To display DoS prevention information:

DES-1210-28/ME:5# show dos_prevention
Command: show dos_prevention

DosType State Action Frame Counts
Land Attack Disabled Mirror 0
Blat Attack Disabled Mirror 0
Smurf Attack Disabled Mirror 0
Tcp Null Scan Disabled Mirror 0
Tcp Xmascan Disabled Mirror 0
Tcp Synfin Disabled Mirror 0
Tcp Syn Srcport less 1024 Disabled Mirror 0

Success!

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

36

To display DoS prevention information for Land Attack:

DES-1210-28/ME:5# show dos_prevention land_attack
Command: show dos_prevention land_attack

DoS Type: Land Attack
State: Disabled
Action: Mirror
Port: 7
Priority: 5
Rx Rate(Kbit/sec): 1024
Frame Counts: 0

Success!

DES-1210-28/ME:5#

clear dos_prevention counters

Purpose Used to clear the counters of the prevention of each DoS attack.

Syntax

clear dos_prevention counters [land_attack | blat_attack |
smurf_attack | tcp_null_scan | tcp_xmascan | tcp_synfin |
tcp_syn_srcport_less_1024]

Description

The clear dos_prevention counters command is used to clear the
counters of the prevention of each DoS attack.

Parameters The type of DoS attack. Possible values are as follows:

land_attack, blat_attack, smurf_attack, tcp_null_scan, tcp_xmascan

tcp_synfin and tcp_syn_srcport_less_1024.

Restrictions Only Administrator-level users can issue this command.

Example usage:

To clear all counters of the prevention of each smurf attack:

DES-1210-28/ME:5# clear dos_prevention counters smurf_attack
Command: clear dos_prevention counters smurf_attack

DES-1210-28/ME:5#

enable dos_prevention trap_log

Purpose Used to enable a DoS prevention trap/log.

Syntax

enable dos_prevention trap_log

Description

The enable dos_prevention trap_log command is used to send
traps and logs when a DoS attack event occurs. The event will be
logged only when the action is specified as drop.

Parameters None.

Restrictions Only Administrator-level users can issue this command.

Example usage:

To enable a DoS prevention trap/log:

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

37

DES-1210-28/ME:5# enable dos_prevention trap_log
Command: enable dos_prevention trap_log

DES-1210-28/ME:5#

disable dos_prevention trap_log

Purpose Used to disable a DoS prevention trap/log.

Syntax

disable dos_prevention trap_log

Description

The disable dos_prevention trap_log command is used to disable
a DoS prevention trap/log.

Parameters None.

Restrictions Only Administrator-level users can issue this command.

Example usage:

To disable a DoS prevention trap/log:

DES-1210-28/ME:5# disable dos_prevention trap_log
Command: disable dos_prevention trap_log

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

38

10

1010

10

PPPOE CIRCUIT ID INSERTION COMMANDS

PPPoE Circuit ID Insertion is used to produce the unique subscriber mapping capability that is possible
on ATM networks between ATM-DSL local loop and the PPPoE server. The PPPoE server will use the
inserted Circuit Identifier sub-tag of the received packet to provide AAA services (Authentication,
Authorization and Accounting). Through this method, Ethernet networks can be as the alternative of the
ATM networks.

The PPPoE Circuit ID Insertion commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.

Command Parameter

config pppoe circuit_id
_insertion state

[enable | disable]

config pppoe
circuit_id_insertion
ports

[ circuit_id [ mac | ip | udf <string 32> ] | state [enable | disable ] ]

show pppoe
circuit_id_insertion

show pppoe
circuit_id_insertion
ports

{<portlist>}

Each command is listed in detail, as follows:

config pppoe circuit_id_insertion state

Purpose Used to enable or disable the PPPoE circuit identifier insertion.

Syntax

config pppoe circuit_id_insertion state [enable | disable]

Description When PPPoE circuit identifier insertion is enabled, the system will

insert the circuit ID tag to the received PPPoE discover and request
packet if the tag is absent, and remove the circuit ID tag from the
received PPPoE offer and session confirmation packet.

The inserted circuit ID contains the following information:

Client MAC address

Device ID

Port number

By default, the Switch IP address is used as the device ID to encode
the circuit ID option.

Parameters

[enable | disable] – Enables or disable PPPoE circuit ID insertion
globally. The function is disabled by default.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To globally enable PPPoE circuit identifier insertion:

DES-1210-28/ME:5# config pppoe circuit_id_insertion state enable
Command: config pppoe circuit_id_insertion state enable

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

39

Success.

DES-1210-28/ME:5#

config pppoe circuit_id_insertion ports

Purpose Used to enable and disable PPPoE circuit identifier insertion on a

per port basis and specify how to encode the circuit ID option.

Syntax

config pppoe circuit_id_insertion ports <portlist> [ circuit_id
[ mac | ip | udf <string 32> ] | state [enable | disable ] ]

Description When the port’s state and the global state are enabled, the system

will insert the Circuit ID TAG to the received PPPoE discovery
initiation and request packet if the TAG is absent, and remove the
Circuit ID tag, inserted by the system, from the received PPPoE offer
and session confirmation packet.

Parameters

<portlist> – Specifies a list of ports to be configured.

The default settings are enabled for ID insertion per port, but
disabled globally.

circuit_id – Configures the device ID used for encoding of the circuit
ID option.

mac – Specifies that the Switch MAC address be used to encode the
circuit ID option.

ip – Specifies that the Switch IP address be used to encode the
circuit ID option.

udf – A user defined string to be used to encode the circuit ID option.
The maximum length is 32.

The default encoding for the device ID option is the Switch IP
address.

state – Specify to enable or disable PPPoE circuit ID insertion for the
ports listed.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To enable port 1~5 PPPoE circuit ID insertion function and use Host MAC:

DES-1210-28/ME:5# config pppoe circuit_id_insertion ports 1-5 circuit_id
mac state enable

Command: config pppoe circuit_id_insertion ports 1-5 circuit_id mac
state enable

Success.

DES-1210-28/ME:5#

show pppoe circuit_id_insertion

Purpose Used to display the PPPoE circuit identifier insertion status for the

Switch.

Syntax

show pppoe circuit_id_insertion

Description

The show pppoe circuit_id_insertion command is used to display

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

40

the global state configuration of the PPPoE circuit ID insertion
function.

Parameters None.

Restrictions None.

Example usage:

To view the global PPPoE ID insertion state:

DES-1210-28/ME:5# show pppoe circuit_id_insertion
Command: show pppoe circuit_id_insertion

Status: Enabled

DES-1210-28/ME:5#

show pppoe circuit_id_insertion ports

Purpose Used to display the PPPoE ID insertion configuration on a per

port basis.

Syntax

show pppoe circuit_id_insertion ports {<portlist>}

Description

The show pppoe circuit_id_insertion ports command allows
the user to view the configuration of PPPoE ID insertion for each
port.

Parameters

<portlist> - Specifies which ports to display. If no ports are
specified, all ports configuration will be listed.

Restrictions None.

Example usage:

To view the PPPoE circuit ID configuration for ports 2 to 5:

DES-1210-28/ME:5# show pppoe circuit_id_insertion ports 2-5
Command: show pppoe circuit_id_insertion ports 2-5

Port State Cirucit ID

---- -------- --------------------------------------------­2 Enabled Switch MAC
3 Enabled Switch MAC
4 Enabled Switch MAC
5 Enabled Switch MAC

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

41

11

1111

11

DHCP SERVER SCREENING COMMANDS

The DHCP server screenint commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.

Due to this function allow you not only to restrict all DHCP Server packets but also to receive any
specified DHCP server packet by any specified DHCP client, it is useful when one or more than one
DHCP servers are present on the network and both provide DHCP services to different distinct groups of
clients.

When DHCP Server Screening function is enabled, all DHCP Server packets will be filtere from a specif ic
port. Also, you are allow to create entries for specific Server IP address an d Client MAC address bi
nding by por t-based. Be aware th a tthe DHCP Ser ver Screen ing f uncti n must b e enabled first On ce
all sett ng is do ne, all DHC P Serve packe s wi ll be filtered fro m a speci fic port e cep t those tha meet
th e Se ver IP Ad dres s and Cli ent M AC Addres s binding .

Command Parameter

config filter
dhcp_server

[add permit server_ip <ipaddr> { client_mac <macaddr>} ports [ <portlist> | all ] |
delete permit server_ip <ipaddr> { client_mac <macaddr> } ports [ <portlist> | all ]
| ports [ <portlist> | all ] state [ enable | disable]]

show filter dhcp_server

config dhcp_server
screening ports

<portlist> state [enable | disable]

show dhcp_server
screening

Each command is listed in detail, as follows:

config filter dhcp_server

Purpose DHCP server packets except those that have been IP/client MAC

bound will be filtered. This command is used to configure the state of
the function for filtering of DHCP server packet and to add/delete the
DHCP server/client binding entry.

Syntax

config filter dhcp_server [add permit server_ip <ipaddr>
{ client_mac <macaddr>} ports [ <portlist> | all ] | delete permit
server_ip <ipaddr> { client_mac <macaddr> } ports [ <portlist> |
all ] | ports [ <portlist> | all ] state [ enable | disable]]

Description

The config filter dhcp_server command has two purposes: To filter
all DHCP server packets on the specified port(s) and to allow some
DHCP server packets to forwarded if they are on the pre-defined
server IP address/MAC address binding list. Thus the DHCP server
can be restricted to service a specified DHCP client. This is useful
when there are two or more DHCP servers present on f network.

Parameters

<ipaddr> – The IP address of the DHCP server to be filtered

<macaddr> – The MAC address of the DHCP client.

state – Enable/Disable the DHCP filter state

ports <portlist> – The port number to which the DHCP filter will be

applied.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

42

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To add an entry from the DHCP server/client filter list in the Switch’s database:

DES-1210-28/ME:5# config filter dhcp_server add permit server_ip

10.1.1.1 client_mac 00-00-00-00-00-01 ports all
Command: config filter dhcp_server add permit server_ip 10.1.1.1

client_mac 00-0

0-00-00-00-01 ports all

Success!
DES-1210-28/ME:5#

show filter dhcp_server

Purpose Used to display current DHCP server/client filter list created on the

switch.

Syntax

show filter dhcp_server

Description

The show filter dhcp_server command is used to display DHCP
server/client filter list created on the switch.

Parameters None.

Restrictions None.

Example usage:

To display the DHCP server filter list created on the switch:

DES-1210-28/ME:5# show filter dhcp_server
Command: show filter dhcp_server

IP Address MAC Address Ports

--------------- ----------------- ------------------------------

10.1.1.1 00-00-00-00-00-01 1-28

Total Entries: 1

Success!
DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

43

config dhcp_server screening ports

Purpose To configure a DHCP server screening from the DHCP Relay server

list.

Syntax

config dhcp_server screening ports <portlist> state [enable |
disable]

Description

The config dhcp_server screening ports command configures the
ports of DHCP servers screening on the Switch.

Parameters

<portlist> − Specifies a port or a range of ports to be configured.

state [enable | disable] − Enable/Disable the DHCP server

screening for the specified ports.

Restrictions Only Administrator or operate-level users can issue this command.

Example usage:

To configure the DHCP server screening of port 1~5 on the Switch:

DES-1210-28/ME:5# config dhcp_server screening ports 1-5 state enable
Command: config dhcp_server screening ports 1-5 state enable

Success.

DES-1210-28/ME:5#

show dhcp_server screening

Purpose To

display the DHCP server screening on the Switch

.

Syntax

show dhcp_server screening

Description

The show dhcp_server screening command displays the DHCP
server screening on the Switch.

Parameters None.

Restrictions None.

Example usage:

To display DHCP server screening settings:

DES-1210-28/ME:5# show dhcp_server screening
Command: show dhcp_server screening

DHCP server screening :
Port Admin state

---- ----------­1 disabled
2 disabled
3 disabled
4 disabled
5 disabled
6 disabled
7 disabled
8 disabled
9 disabled

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

44

10 disabled
11 disabled
12 disabled
13 disabled

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

45

12

1212

12

IP-MAC-PORT BINDING COMMANDS

The IP network layer uses a four-byte address. The Ethernet link layer uses a six-byte MAC address.
Binding these two address types together allows the transmission of data between the layers. The
primary purpose of IP-MAC-port binding is to restrict the access to a switch to a number of authorized
users. Only the authorized client can access the Switch’s port by checking the pair of IP-MAC addresses
with the pre-configured database. If an unauthorized user tries to access an IP-MAC-port binding
enabled port, the system will block the access by dropping its packet. The maximum number of IP-MAC­port binding entries is dependant on chip capability (e.g. the ARP table size) and storage size of the
device. For the Switch, the maximum value for the IP-MAC-port binding ARP mode is 500. The creation
of authorized users can be manually configured by CLI or Web. The function is port-based, meaning a
user can enable or disable the function on the individual port.

The IP-MAC-Port Binding commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table:

Command Parameter

create address_binding
ip_mac ipaddress

<ipaddr> mac_address <macaddr> ports <port 1-28>

config address_binding
ip_mac ports

[<portlist> | all] {state [disable | enable] | ip_inspection [disable | enable] |
arp_inspection [loose | strict]}

config address_binding
auto_scan

from_ip <ipaddr> to_ip <ipaddr>

delete address_binding

[ip_mac [ipaddress <ipaddr> mac_address <macaddr> | all] | blocked [all |
vlan_name <vlan_name> mac_address <macaddr> port <port 1-28>]]

show address_binding

{[ip_mac [all | {ipaddress <ipaddr> | mac_address <macaddr>}] | blocked [all |
vlan_name <vlan_name> mac_address <macaddr> port <port 1-28>] | ports]}

show address_binding
auto_scan list

enable
address_binding
dhcp_snoop

ports [<portlist> | all]

disable
address_binding
dhcp_snoop

ports [<portlist> | all]

Each command is listed in detail, as follows:

create address_binding ip_mac ipaddress

Purpose Used to create an IP-MAC-port binding entry.

Syntax

create address_binding ip_mac ipaddress <ipaddr>
mac_address <macaddr> ports <port 1-28>

Description

The create address_binding ip_mac ipaddress command is used to
create an IP-MAC-port binding entry.

Parameters

<ipaddr> – The IP address of the device where the IP-MAC-port
binding is made.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

46

<macaddr> – The MAC address of the device where the IP-MAC­port binding is made.

<port 1-28> – Specifies a port to be configured for address binding.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To create address binding on the Switch:

DES-1210-28/ME:5# create address_binding ip_mac ipaddress 10.0.0.21
mac_address 00-00-00-00-01-02 ports 3

Command: create address_binding ip_mac ipaddress 10.0.0.21
mac_address 00-00-00-00-01-02 ports 3

Success.
DES-1210-28/ME:5#

config address_binding ip_mac ports

Purpose Used to configure an IP-MAC-port binding state to enable or disable

for specified ports.

Syntax

config address_binding ip_mac ports [<portlist> | all] {state
[disable | enable] | ip_inspection [disable | enable] |
arp_inspection [loose | strict]}

Description

The config address_binding ip_mac ports command is used to
configure the IP-MAC-port binding state to enable or disable for
specified ports.

Parameters

<portlist> − Specifies a port or range of ports.

all – Specifies all ports on the switch.
[enable | disable] – Enables or disables the specified range of ports

for state and IP-inspection.
arp_inspection [loose | strict] – Specifies to check the ARP

inspection to be loose or stict for the specified ports.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To configure address binding on the Switch:

DES-1210-28/ME:5# config address_binding ip_mac ports 3 state disable
arp_inspection loose ip_inspection disable

Command: config address_binding ip_mac ports 3 state disable
arp_inspection loose ip_inspection disable

Success.
DES-1210-28/ME:5#

config address_binding auto_scan

Purpose Used to configure an IP-MAC-port binding auto scan for specified IP

addresses.

Syntax

config address_binding auto_scan from_ip <ipaddr> to_ip
<ipaddr>

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

47

Description

The config address_binding auto_scan command is used to
configure the IP-MAC-port binding auto scan for specified IP
addresses.

Parameters

<ipaddr> − Specifies a range of IP addresses for address binding
auto scan on the Switch.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To configure address binding auto scan on the Switch:

DES-1210-28/ME:5# config address_binding auto_scan from_ip 10.0.0.10
to_ip 10.0.0.12

Command: config address_binding auto_scan from_ip 10.0.0.10 to_ip

10.0.0.12

Success.
DES-1210-28/ME:5#

delete address_binding

Purpose Used to delete IP-MAC-port binding entries.

Syntax

delete address_binding [ip_mac [ipaddress <ipaddr>
mac_address <macaddr> | all] | blocked [all | vlan_name
<vlan_name> mac_address <macaddr> port <port 1-28>]]

Description

The delete address_binding command is used to delete IP-MAC­port binding entries. Two different kinds of information can be
deleted.

ip_mac – Individual address binding entries can be deleted by
entering the physical and IP addresses of the device. Toggling to all
will delete all the address binding entries.

blocked – Blocked address binding entries (bindings between VLAN
names and MAC addresses) can be deleted by entering the VLAN
name and the physical address of the device. To delete all the
blocked address binding entries, toggle all.

Parameters

<ipaddr> – The IP address of the device where the IP-MAC-port
binding is made.

<macaddr> – The MAC address of the device where the IP-MAC­port binding is made.

vlan_name <string 20> – The VLAN name of the VLAN that is bound
to a MAC address in order to block a specific device on a known
VLAN.

all – For IP-MAC-port binding all specifies all the IP-MAC-port
binding entries; for blocked address binding entries all specifies all
the blocked VLANs and their bound physical sddresses.

<port 1-28> – Specifies a port to be deleted for address binding.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To delete all address binding entries on the Switch:

DES-1210-28/ME:5# delete address_binding ip_mac all
Command: delete address_binding ip_mac all

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

48

Success.
DES-1210-28/ME:5#

show address_binding

Purpose Used to display IP-MAC-port binding entries.

Syntax

show address_binding {[ip_mac [all | {ipaddress <ipaddr> |
mac_address <macaddr>}] | blocked [all | vlan_name
<vlan_name> mac_address <macaddr> port <port 1-28>] |
ports]}

Description This command is used to display IP-MAC-port binding entries. Four

different kinds of information can be viewed.
ip_mac – Address binding entries can be viewed by entering the

physical and IP addresses of the device.

blocked – Blocked address binding entries (bindings between VLAN
names and MAC addresses) can be viewed by entering the VLAN
name and the physical address of the device.

ports – The number of enabled ports on the device.

Parameters

ip_mac – The database the user creates for address binding.

all – For IP MAC binding all specifies all the IP-MAC-port binding

entries; for blocked address binding entries all specifies all the
blocked VLANs and their bound physical addresses.

blocked – The address database that the system auto learns and
blocks.

<ipaddr> – The IP address of the device where the IP-MAC-port
binding is made.

<macaddr> – The MAC address of the device where the IP-MAC­port binding is made.

vlan_name <string 20> – The VLAN name of the VLAN that is bound
to a MAC address in order to block a specific device on a known
VLAN.

port <port 1-28> – Specifies a port to be displayed for the address
binding on the Switch.

Restrictions None.

Example usage:

To display address binding entries on the Switch:

DES-1210-28/ME:5# show address_binding ip_mac all
Command: show address_binding ip_mac all

IP Address MAC Address Port

--------------- -------------------- ----

10.0.0.21 00-00-00-00-01-02 3

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

49

show address_binding auto_scan list

Purpose Used to display IP-MAC-port binding entries.

Syntax

show address_binding auto_scan list

Description This command is used to display auto scan list of address binding

on the Switch.

Parameters None.

Restrictions None.

Example usage:

To display the auto scan list of address binding on the Switch:

DES-1210-28/ME:5# show address_binding auto_scan list
Command: show address_binding auto_scan list

VLAN IP Address MAC Address Port Bound

---- --------------- ----------------- ---- -----

DES-1210-28/ME:5#

enable address_binding dhcp_snoop

Purpose Used to enable IP-MAC-port binding DHCP Snooping.

Syntax

enable address_binding dhcp_snoop ports [<portlist> | all]

Description This command is used to enable IP-MAC-port binding DHCP

snooping entries.

Parameters

[<portlist> | all] – Specifies a port, a range of ports or all ports to be
enabled of the address binding DHCP snooping on the Switch.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To enable the DHCP snooping of address binding for port 3~5 on the Switch:

DES-1210-28/ME:5# enable address_binding dhcp_snoop ports 3-5
Command: enable address_binding dhcp_snoop ports 3-5

Success.
DES-1210-28/ME:5#

disable address_binding dhcp_snoop

Purpose Used to disable IP-MAC-port binding DHCP Snooping.

Syntax

disable address_binding dhcp_snoop ports [<portlist> | all]

Description This command is used to disable IP-MAC-port binding DHCP

snooping entries.

Parameters

[<portlist> | all] – Specifies a port, a range of ports or all ports to be
enabled of the address binding DHCP snooping on the Switch.

Restrictions Only administrator or operate-level users can issue this command.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

50

Example usage:

To disable the DHCP snooping of address binding for port 3~5 on the Switch:

DES-1210-28/ME:5# disable address_binding dhcp_snoop ports 4
Command: disable address_binding dhcp_snoop ports 4

Success.
DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

51

13

1313

13

NETWORK MANAGEMENT (SNMP) COMMANDS

The Switch supports the Simple Network Management Protocol (SNMP) versions 1, 2c, and 3. Users can
specify which version of the SNMP users want to use to monitor and control the Switch. The three
versions of SNMP vary in the level of security provided between the management station and the
network device. The following table lists the security features of the three SNMP versions:

SNMP Version Authentication Method Description

v1 Community String Community String is used for authentication - NoAuthNoPriv

v2c Community String Community String is used for authentication - NoAuthNoPriv

v3 Username Username is used for authentication – NoAuthNoPriv

v3 MD5 or SHA Authentication is based on the HMAC-MD5 or HMAC-SHA

algorithms – AuthNoPriv

v3 MD5 DES or SHA DES Authentication is based on the HMAC-MD5 or HMAC-SHA

algorithms – AuthPriv. DES 56-bit encryption is added based
on the CBC-DES(DES-56) standard

The Network Management commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.

Command Parameter

create snmp user

<username 32> <groupname 32> [v1 | v2c | v3 [MD5 <auth_password 32> |
SHA <auth_password 32> | none ] [DES <priv_password 32> | none]

delete snmp user

<username 32> [v1 | v2c | v3]

show snmp user

create snmp view

<view_name 32> <oid 32> <oid_mask 32 view_type [included | excluded]

delete snmp view

<view_name 32> <oid 32>

show snmp view

{<view_name 32>}

create snmp community <community_string 32> <username 32>

delete snmp community <community_string 32>

show snmp community {<community_string 32>}

config snmp engineID

<snmp_engineID 64>

show snmp engineID

create snmp group

<groupname 32> [v1 | v2c | v3 [noauth_nopriv | auth_nopriv |
auth_priv]{notify_view <view_name 32>}] {read_view <view_name 32> |
write_view <view_name 32>}

delete snmp group

<groupname 32> [v1 | v2c | v3] [auth_nopriv | auth_priv | noauth_priv]

show snmp global state

show snmp groups

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

52

Command Parameter

create snmp host

<ipaddr> [v1 <username 32> | v2c <username 32> | v3 [noauth_nopriv |
auth_nopriv | auth_priv] <username 32>]

delete snmp host

<ipaddr>

show snmp host

{<ipaddr>}

enable trusted_host

disable trusted_host

create trusted_host

<ipaddr>{network <network_address>} {application [telnet | ssh | snmp | http |
https | ping | all}

show trusted_host

delete trusted_host

[<ipaddr> | all | network <network_address>]

enable snmp traps

disable snmp traps

enable snmp
authenticate trap

disable snmp
authenticate trap

show snmp traps

config syslocation <string 20>

config sysname <string 20>

enable snmp

disable snmp

enable snmp
DHCP_screening traps

diable snmp
DHCP_screening traps

enable snmp
IMPB_violation traps

disable snmp
IMPB_violation traps

enable snmp
fiber_port_link traps

disable snmp
fiber_port_link traps

enable snmp
firmware_upgrade_state
traps

disable snmp
firmware_upgrade_state
traps

enable snmp LBD traps

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

53

Command Parameter

disable snmp LBD traps

enable snmp
port_security_violation
traps

disable snmp
port_security_violation
traps

enable snmp
rstpport_state_change
traps

disable snmp
rstpport_state_change
traps

enable snmp
system_device_bootup
traps

disable snmp
system_device_bootup
traps

enable snmp
twistedpair_port_link
traps

disable snmp
twistedpair_port_link
traps

enable snmp
duplicate_IP_detected
traps

disable snmp
duplicate_IP_detected
traps

Each command is listed in detail, as follows:

create snmp user

Purpose To create a new SNMP user and add the user to an SNMP group.

Syntax

create snmp user <username 32> <groupname 32> [v1 | v2c | v3
[MD5 <auth_password 32> | SHA <auth_password 32> | none ]
[DES <priv_password 32> | none]]

Description

The create snmp user command creates a new SNMP user and
adds the user to an existing SNMP group.

Parameters

<username 32> − The new SNMP username, up to 32 alphanumeric
characters.

<groupname 32> − The SNMP groupname the new SNMP user is
associated with, up to 32 alphanumeric characters.

auth - The user may also choose the type of authentication

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

54

algorithms used to authenticate the snmp user. The choices are:

• MD5 − Specifies that the HMAC-MD5-96 authentication
level to be used. md5 may be utilized by entering one of the
following:

• <auth password 32> - A string of between 1 and 32
alphanumeric characters used to authorize the agent to
receive packets for the host.

• SHA − Specifies that the HMAC-SHA-96 authentication level
will be used.

• <priv_password 32> - A string of between 1 and 32
alphanumeric characters used to authorize the agent to
receive packets for the host.

• DES − Specifies that the DES authentication level will be
used.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To create an SNMP user on the Switch:

DES-1210-28/ME:5# create snmp user dlink SW22 v3 MD5 1234 DES jklj22
Command: create snmp user dlink SW22 v3 MD5 1234 DES jklj22

Success!

DES-1210-28/ME:5#

delete snmp user

Purpose To remove an SNMP user from an SNMP group and also to delete

the associated SNMP group.

Syntax

delete snmp user <username 32> [v1 | v2c | v3]

Description

The delete snmp user command removes an SNMP user from its
SNMP group and then deletes the associated SNMP group.

Parameters

<username 32> − A string of up to 32 alphanumeric characters that
identifies the SNMP user to be deleted.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To delete a previously created SNMP user on the Switch:

DES-1210-28/ME:5# delete snmp user dlink v3
Command: delete snmp user dlink v3

Success!

show snmp user

Purpose To display information about each SNMP username in the SNMP

group username table.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

55

Syntax

show snmp user

Description

The show snmp user command displays information about each
SNMP username in the SNMP group username table.

Parameters None.

Restrictions None.

Example usage:

To display the SNMP users currently configured on the Switch:

DES-1210-28/ME:5# show snmp user
Command: show snmp user

Username Group Name SNMP Version Auth-Protocol PrivProtocol

-------- ------------ ------------ ---------------- ----------------

ReadOnly ReadOnly V1 None None
ReadOnly ReadOnly V2 None None
ReadWrite ReadWrite V1 None None
ReadWrite ReadWrite V2 None None

Total Entries: 4

DES-1210-28/ME:5#

create snmp view

Purpose To assign views to community strings to limit which MIB objects an

SNMP manager can access.

Syntax

create snmp view <view_name 32> <oid 32> <oid_mask 32
view_type [included | excluded]

Description

The create snmp view command assigns views to community
strings to limit which MIB objects an SNMP manager can access.

Parameters

<view_name 32> − A string of up to 30 alphanumeric characters that
identifies the SNMP view to be created.

<oid 32> − The object ID that identifies an object tree (MIB tree) to
be included or excluded from access by an SNMP manager.

<oid_mask 32> − The object ID mask that identifies an object tree
(MIB tree) to be included or excluded from access by an SNMP
manager.

included − Includes this object in the list of objects that an SNMP
manager can access.

excluded − Excludes this object from the list of objects that an
SNMP manager can access.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To create an SNMP view:

DES-1210-28/ME:5# create snmp view dlink 1.3.6 1.1.1 view_type excluded
Command: create snmp view dlink 1.3.6 1.1.1 view_type excluded

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

56

Success!

DES-1210-28/ME:5#

delete snmp view

Purpose To remove an SNMP view entry previously created on the Switch.

Syntax

delete snmp view <view_name 32> <oid 32>

Description

The delete snmp view command removes an SNMP view
previously created on the Switch.

Parameters

<view_name 32> − A string of up to 32 alphanumeric characters that
identifies the SNMP view to be deleted.

<oid 32> − The object ID that identifies an object tree (MIB tree) that
is deleted from the Switch.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To delete a previously configured SNMP view from the Switch:

DES-1210-28/ME:5# delete snmp view dlink 1.3.6
Command: delete snmp view dlink 1.3.6

Success.

DES-1210-28/ME:5#

show snmp view

Purpose To display an SNMP view previously created on the Switch.

Syntax

show snmp view {<view_name 32>}

Description

The show snmp view command displays an SNMP view previously
created on the Switch.

Parameters

<view_name 32> − A string of up to 30 alphanumeric characters that
identifies the SNMP view to be displayed.

Restrictions None.

Example usage:

To display SNMP view configuration:

DES-1210-28/ME:5# show snmp view
Command: show snmp view

SNMP View Table Configuration
View Name Subtree OID OID Mask View Type

------------ ---------------------- ---------------------- --------­dlink 1.2.3.4 1.1.1.1 Excluded
ReadWrite 1 1 Included

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

57

Total Entries: 2

DES-1210-28/ME:5#

create snmp community

Purpose To create an SNMP community string to define the relationship

between the SNMP manager and an SNMP agent.

Syntax

create snmp community <community_string 32> <username
32>

Description

The create snmp community command creates an SNMP
community string and assigns access-limiting characteristics to this
community string. The community string acts like a password to
permit access to the agent on the Switch. One or more of the
following characteristics can be associated with the community
string:

An Access List of IP addresses of SNMP managers that are
permitted to use the community string to gain access to the Switch’s
SNMP agent.

An MIB view that defines the subset of all MIB objects to be
accessible to the SNMP community.

Read/write or read-only level permission for the MIB objects
accessible to the SNMP community.

Parameters

<community_string 32> − A string of up to 32 alphanumeric
characters that is used to identify members of an SNMP community.
This string is used like a password to give remote SNMP managers
access to MIB objects in the Switch’s SNMP agent.

<username 32> − A string of up to 32 alphanumeric characters that
is used to identify the group of MIB objects that a remote SNMP
manager is allowed to access on the Switch.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To create the SNMP community string ‘dlink:’

DES-1210-28/ME:5# create snmp community dlinkgroup dlink

Success.

DES-1210-28/ME:5#

delete snmp community

Purpose To remove a specific SNMP community string from the Switch.

Syntax

delete snmp community <community_string 32>

Description

The delete snmp community command removes a previously
defined SNMP community string from the Switch.

Parameters

<community_string 32> − A string of up to 32 alphanumeric
characters that is used to identify members of an SNMP community
to delete. This string is used like a password to give remote SNMP
managers access to MIB objects in the Switch’s SNMP agent.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

58

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To delete the SNMP community string ‘dlink’:

DES-1210-28/ME:5# delete snmp community dlink
Command: delete snmp community dlink

Success!

DES-1210-28/ME:5#

show snmp community

Purpose To display SNMP community strings configured on the Switch.

Syntax

show snmp community {<community_string 32>}

Description

The show snmp community command displays SNMP community
strings that are configured on the Switch.

Parameters

<community_string 32> − A string of up to 20 alphanumeric
characters that is used to identify members of an SNMP community.
This string is used like a password to give remote SNMP managers
access to MIB objects in the Switch’s SNMP agent.

Restrictions None.

Example usage:

To display the currently entered SNMP community strings:

DES-1210-28/ME:5# show snmp community
Command: show snmp community

SNMP Community Table
(Maximum Entries : 10)

Community Name User Name

------------------ -----------­public ReadOnly
private ReadWrite

Total Entries: 2

DES-1210-28/ME:5#

config snmp engineID

Purpose To configure a name for the SNMP engine on the Switch.

Syntax

config snmp engineID <snmp_engineID 64>

Description

The config snmp engineID command configures a name for the
SNMP engine on the Switch.

Parameters

<snmp_engineID 64> − A string, of between 10 and 64

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

59

alphanumeric characters, to be used to identify the SNMP engine on
the Switch.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To give the SNMP agent on the Switch:

DES-1210-28/ME:5# config snmp engineID 12345678900
Command: config snmp engineID 12345678900

Success!

DES-1210-28/ME:5#

show snmp engineID

Purpose To display the identification of the SNMP engine on the Switch.

Syntax

show snmp engineID

Description

The show snmp engineID command displays the identification of
the SNMP engine on the Switch.

Parameters None.

Restrictions None.

Example usage:

To display the current name of the SNMP engine on the Switch:

DES-1210-28/ME:5# show snmp engineID
Command: show snmp engineID

Default SNMP Engine ID : 4445532d313231

SNMP Engine ID : 012345678900

DES-1210-28/ME:5#

create snmp group

Purpose To create a new SNMP group, or a table that maps SNMP users to

SNMP views.

Syntax

create snmp group <groupname 32> [v1 | v2c | v3
[noauth_nopriv | auth_nopriv | auth_priv]{notify_view
<view_name 32>}] {read_view <view_name 32> | write_view
<view_name 32>}

Description

The create snmp group command creates a new SNMP group, or
a table that maps SNMP users to SNMP views.

Parameters

<groupname 32> − A name of up to 30 alphanumeric characters that
identifies the SNMP group the new SNMP user is to be associated
with.

v1 – Specifies that SNMP version 1 is to be used. The Simple
Network Management Protocol (SNMP), version 1, is a network
management protocol that provides a means to monitor and control

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

60

network devices.
v2c – Specifies that SNMP version 2c is to be used. The SNMP v2c

supports both centralized and distributed network management
strategies. It includes improvements in the Structure of Management
Information (SMI) and adds some security features.

v3 – Specifies that the SNMP version 3 is to be used. SNMP v3
provides secure access to devices through a combination of
authentication and encrypting packets over the network. SNMP v3
adds:

• Message integrity − Ensures that packets have not been
tampered with during transit.

• Authentication − Determines if an SNMP message is from a
valid source.

• Encryption − Scrambles the contents of messages to
prevent it from being viewed by an unauthorized source.

noauth_nopriv − Specifies that there is no authorization and no
encryption of packets sent between the Switch and a remote SNMP
manager.

auth_nopriv − Specifies that authorization is required, but there is no
encryption of packets sent between the Switch and a remote SNMP
manager.

auth_priv − Specifies that authorization is required, and that packets
sent between the Switch and a remote SNMP manger are
encrypted.

read_view – Specifies that the SNMP group being created can
request SNMP messages.

• <view_name 32> − A string of up to 32 objects that a remote
SNMP manager is allowed to access on the Switch.

write_view – Specifies that the SNMP group being created has write
privileges.

• <view_name 32 identifies the group of MIB objects that a
remote SNMP manager is allowed to access on the Switch.

notify_view − Specifies that the SNMP group being created can
receive SNMP trap messages generated by the Switch’s SNMP
agent.

• <view_name 32> − A string of up to 32 alphanumeric
characters that identifies the group of MIB objects that a
remote SNMP manager is allowed to access on the Switch.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To create an SNMP group named ‘sg1:’

DES-1210-28/ME:5# create snmp group sg1 v2c read_view sg1 write_view sg1
notify_view sg1

Command: create snmp group sg1 v2c read_view sg1 write_view sg1 notify_view
sg1

Success!
DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

61

delete snmp group

Purpose To remove an SNMP group from the Switch.

Syntax

delete snmp group <groupname 32> [v1 | v2c | v3 [auth_priv |
noauth_nopriv]]

Description

The delete snmp group command removes an SNMP group from
the Switch.

Parameters

<groupname 32> − A string of that identifies the SNMP group the
new SNMP user will be associated with. Up to 32 alphanumeric
characters.

Restrictions Only administrator or operate-level users can issue this command.

Example usage:

To delete the SNMP group named ‘sg1’:

DES-1210-28/ME:5# delete snmp group sg1 v3 auth_priv
Command: delete snmp group sg1 v3 auth_priv

Success!

DES-1210-28/ME:5#

show snmp global state

Purpose To display the global state of SNMP currently configured on the

Switch.

Syntax

show snmp global state

Description

The show snmp global state command displays the global state of
SNMP groups currently configured on the Switch.

Parameters None.

Restrictions None.

Example usage:

To display the currently configured SNMP global state on the Switch:

DES-1210-28/ME:5# show snmp global state
Command: show snmp global state

SNMP Global State : Enable

DES-1210-28/ME:5#

show snmp groups

Purpose To display the group-names of SNMP groups currently configured

on the Switch. The security model, level, and status of each group
are also displayed.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

62

Syntax

show snmp groups

Description

The show snmp groups command displays the group-names of
SNMP groups currently configured on the Switch. The security
model, level, and status of each group are also displayed.

Parameters None.

Restrictions None.

Example usage:

To display the currently configured SNMP groups on the Switch:

DES-1210-28/ME:5# show snmp groups
Command: show snmp groups

SNMP Group Table

Group Name Read View Write View Notify View Security Model Security Level

------------------ -------------- ---------------- --------------- ---------------------- ----------------­sg1 df df d v3 AuthPriv
ReadOnly ReadWrite --- ReadWrite v1 NoAuthNoPriv
ReadOnly ReadWrite --- ReadWrite v2c NoAuthNoPriv
ReadWrite ReadWrite ReadWrite ReadWrite v1 NoAuthNoPriv
ReadWrite ReadWrite ReadWrite ReadWrite v2c NoAuthNoPriv

Total Entries: 5

DES-1210-28/ME:5#

create snmp host

Purpose To create a recipient of SNMP traps generated by the Switch’s

SNMP agent.

Syntax

create snmp host <ipaddr> [v1 <username 32> | v2c <username
32> | v3 [noauth_nopriv | auth_nopriv | auth_priv] <username
32>]

Description

The create snmp host command creates a recipient of SNMP traps
generated by the Switch’s SNMP agent.

Parameters

<ipaddr> − The IP address of the remote management station to
serve as the SNMP host for the Switch.

v1 – Specifies that SNMP version 1 is to be used. The Simple
Network Management Protocol (SNMP), version 1, is a network
management protocol that provides a means to monitor and control
network devices.

v2c – Specifies that SNMP version 2c is to be used. The SNMP v2c
supports both centralized and distributed network management
strategies. It includes improvements in the Structure of Management
Information (SMI) and adds some security features.

v3 – Specifies that the SNMP version 3 is to be used. SNMP v3
provides secure access to devices through a combination of
authentication and encrypting packets over the network. SNMP v3
adds:

• Message integrity − ensures that packets have not been

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

63

tampered with during transit.

• Authentication − determines if an SNMP message is from a
valid source.

• Encryption − scrambles the contents of messages to prevent
it being viewed by an unauthorized source.

<username 32> − A string of up to 32 alphanumeric characters that
identifies user name of an SNMP community. This string is used like
a password to give remote SNMP managers access to MIB objects
in the Switch’s SNMP agent.

noauth_nopriv − Specifies that there is no authorization and no
encryption of packets sent between the Switch and a remote SNMP
manager.

auth_nopriv − Specifies that authorization is required, but there is no
encryption of packets sent between the Switch and a remote SNMP
manager.

auth_priv − Specifies that authorization is required, and that packets
sent between the Switch and a remote SNMP manger are
encrypted.

Restrictions Only Administrator and oper-level users can issue this command

Example usage:

To create an SNMP host to receive SNMP messages:

DES-1210-28/ME:5# create snmp host 10.90.90.22 v3 noauth_nopriv
dlink

Command: create snmp host 10.90.90.22 v3 noauth_nopriv dlink

Success!

DES-1210-28/ME:5#

delete snmp host

Purpose To remove a recipient of SNMP traps generated by the Switch’s

SNMP agent.

Syntax

delete snmp host <ipaddr>

Description

The delete snmp host command deletes a recipient of SNMP traps
generated by the Switch’s SNMP agent.

Parameters

<ipaddr> − The IP address of a remote SNMP manager that
receives SNMP traps generated by the Switch’s SNMP agent.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To delete an SNMP host entry:

DES-1210-28/ME:5# delete snmp host 10.90.90.22
Command: delete snmp host 10.90.90.22

Success!

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

64

show snmp host

Purpose To display the recipient of SNMP traps generated by the Switch’s

SNMP agent.

Syntax

show snmp host {<ipaddr>}

Description

The show snmp host command is used to display the IP addresses
and configuration information of remote SNMP managers that are
designated as recipients of SNMP traps generated by the Switch’s
SNMP agent.

Parameters

<ipaddr> − The IP address of a remote SNMP manager that
receives SNMP traps generated by the Switch’s SNMP agent.

Restrictions None.

Example usage:

To display the currently configured SNMP hosts on the Switch:

DES-1210-28/ME:5# show snmp host
Command: show snmp host

SNMP Host Table
(Maximum Entries : 10)
Host IP Address SNMP Version Community Name/SNMPv3 User Name

------------------------ --------------------- -------------------------------------------------------

10.90.90.22 V3-NoAuthNoPriv dlink

Total Entries : 1

DES-1210-28/ME:5#

enable trusted_host

Purpose To enable the trusted host.

Syntax

enable trusted_host

Description

The enable trusted_host command enables the trusted host
feature.

Parameters None.

Restrictions Only administrator or operator level users can issue this command.

Example usage:

To enable the trusted host on the Swtich:

DES-1210-28/ME:5# enable trusted_host
Command: enable trusted_host

Success!

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

65

disable trusted_host

Purpose To enable the trusted host.

Syntax

disable trusted_host

Description

The disable trusted_host command disables the trusted host
feature.

Parameters None.

Restrictions Only administrator or operator level users can issue this command.

Example usage:

To disable the trusted host on the Swtich:

DES-1210-28/ME:5# disable trusted_host
Command: disable trusted_host

Success!

DES-1210-28/ME:5#

create trusted_host

Purpose To create a trusted host.

Syntax

create trusted_host <ipaddr>{network <network_address>}

Description

The create trusted_host command creates a trusted host. The
Switch allows specifying up to 30 IP addresses that are allowed to
manage the Switch via in-band based management software. These
IP addresses must be members of the Management VLAN. If no IP
addresses are specified, then there is nothing to prevent any IP
address from accessing the Switch, provided the user knows the
Username and Password.

Parameters

<ipaddr> − The IP address of the trusted host to be created.

<network_address> − The subnet mask of the trusted host to be
created. This parameter is optional. If not specified, the default
subnet mask is 255.255.255.0.

Restrictions Only administrator or operator level users can issue this command.

Example usage:

To create the trusted host:

DES-1210-28/ME:5# create trusted_host 10.90.90.91
Command: create trusted_host 10.90.90.91

Success.

DES-1210-28/ME:5#

show trusted_host

Purpose To display a list of trusted hosts entered on the Switch using the

create trusted_host command above.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

66

Syntax

show trusted_host

Description

The show trusted_host command displays a list of trusted hosts
entered on the Switch using the create trusted_host command
above.

Parameters

None.

Restrictions None.

Example usage:

To display the list of trusted hosts:

DES-1210-28/ME:5# show trusted_host
Command: show trusted_host

Trusted Host Status : Enable

Management Stations

IP Address Subnet Mask

----------------- ---------------

10.90.90.91 255.255.255.255

10.90.90.92 255.255.255.255

Total Entries: 2

DES-1210-28/ME:5#

delete trusted_host

Purpose

To delete a trusted host entry made using the create trusted_host
command above.

Syntax

delete trusted_host [<ipaddr> | all | network
<network_address>]

Description

The delete trusted_host command deletes a trusted host entry
made using the create trusted_host command above.

Parameters

<ipaddr> − The IP address of the trusted host.
all − The all IP address of the trusted host.

network <network_address> − The subnet mask of the trusted host

to be deleted. This parameter is optional.

Restrictions Only administrator or operator level users can issue this command.

Example usage:

To delete a trusted host with an IP address 10.90.90.91:

DES-1210-28/ME:5# delete trusted_host 10.90.90.91
Command: delete trusted_host 10.90.90.91

Success.

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

67

enable snmp traps

Purpose To enable SNMP trap support.

Syntax

enable snmp traps

Description

The enable snmp traps command enables SNMP trap support on
the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To enable SNMP trap support on the Switch:

DES-1210-28/ME:5# enable snmp traps
Command: enable snmp traps

Success!

DES-1210-28/ME:5#

disable snmp traps

Purpose To disable SNMP trap support on the Switch.

Syntax

disable snmp traps

Description

The disable snmp traps command disables SNMP trap support on
the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To prevent SNMP traps from being sent from the Switch:

DES-1210-28/ME:5# disable snmp traps
Command: disable snmp traps

Success!

DES-1210-28/ME:5#

enable snmp authenticate trap

Purpose To enable SNMP authentication trap support.

Syntax

enable snmp authenticate trap

Description

The enable snmp authenticate trap command enables SNMP
authentication trap support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To turn on SNMP authentication trap support:

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

68

DES-1210-28/ME:5# enable snmp authenticate traps
Command: enable snmp authenticate traps

Success!

DES-1210-28/ME:5#

disable snmp authenticate trap

Purpose To disable SNMP authentication trap support.

Syntax

disable snmp authenticate trap

Description

The disable snmp authenticate trap command disables SNMP
authentication trap support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To disable the SNMP authentication trap support:

DES-1210-28/ME:5# disable snmp authenticate traps
Command: disable snmp authenticate traps

Success!

DES-1210-28/ME:5#

show snmp traps

Purpose To display SNMP trap support status on the Switch.

Syntax

show snmp traps

Description

The show snmp traps command displays the SNMP trap support
status currently configured on the Switch.

Parameters None.

Restrictions None.

Example usage:

To view the current SNMP trap support:

DES-1210-28/ME:5# show snmp traps
Command: show snmp traps

SNMP Traps : Disable
SNMP Authentication Traps : Disable
System Device Bootup : Disable
Fiber Port Link Up / Link Down : Disable
Twisted Pair Port Link Up / Link Down : Disable
RSTP Port State Change : Disable
Firmware Upgrade State : Disable
Port Security State : Disable

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

69

IMPBv2 State : Disable
Loopback detection State : Disable
DHCP server screen State : Disable
Gratutious ARP State : Disable

DES-1210-28/ME:5#

config syslocation

Purpose To enter a description of the location of the Switch.

Syntax

config syslocation <string 20>

Description

The config syslocation command enters a description of the
location of the Switch. A maximum of 20 characters can be used.

Parameters

<string 20> - A maximum of 20 characters is allowed.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To configure the Switch location for ‘HQ5F’:

DES-1210-28/ME:5# config syslocation HQ5F
Command: config syslocation HQ5F

Success.
DES-1210-28/ME:5#

config sysname

Purpose To define the name for the Switch.

Syntax

config sysname <string 20>

Description

The config sysname command defines the name of the Switch.

Parameters

<string 20> - A maximum of 20 characters is allowed.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To configure the Switch name as ‘28ME’:

DES-1210-28/ME:5# config sysname 28ME
Command: config sysname 28ME

Success.
DES-1210-28/ME:5#

enable snmp

Purpose To enable SNMP support.

Syntax

enable snmp

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

70

Description

The enable snmp command enables SNMP support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To enable SNMP support on the Switch:

DES-1210-28/ME:5# enable snmp
Command: enable snmp

Success!

DES-1210-28/ME:5#

disable snmp

Purpose To disable SNMP support.

Syntax

disable snmp

Description

The disable snmp command enables SNMP support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To disable SNMP support on the Switch:

DES-1210-28/ME:5# disable snmp
Command: disable snmp

Success!

DES-1210-28/ME:5#

enable snmp DHCP_ screening traps

Purpose To enable SNMP DHCP screening traps.

Syntax

enable snmp DHCP_screening traps

Description

The enable snmp DHCP_screening traps command enables
SNMP DHCP screening traps support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To enable SNMP DHCP screening traps support on the Switch:

DES-1210-28/ME:5# enable snmp DHCP_screening traps
Command: enable snmp DHCP_screening traps

Success!

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

71

DES-1210-28/ME:5#

disable snmp DHCP_ screening traps

Purpose To disable SNMP DHCP screening traps.

Syntax

disable snmp DHCP_screening traps

Description

The disable snmp DHCP_screening traps command enables
SNMP DHCP screening traps support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To disable SNMP DHCP screening traps support on the Switch:

DES-1210-28/ME:5# disable snmp DHCP_screening traps
Command: disable snmp DHCP_screening traps

Success!

DES-1210-28/ME:5#

enable snmp IMPB_violation traps

Purpose To enable SNMP IMPB violation traps.

Syntax

enable snmp IMPB_violation traps

Description

The enable snmp IMPBv2 traps command enables SNMP IMPB
violation traps support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To enable SNMP IMPB violation traps support on the Switch:

DES-1210-28/ME:5# enable snmp IMPB_violation traps
Command: enable snmp IMPB_violation traps

Success!

DES-1210-28/ME:5#

disable snmp IMPB_violation traps

Purpose To disable SNMP IMPB violation traps.

Syntax

disable snmp IMPB_violation traps

Description

The disable snmp IMPB_violation traps command enables SNMP
IMPB violation traps support on the Switch.

Parameters None.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

72

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To disable SNMP IMPB violation traps support on the Switch:

DES-1210-28/ME:5# disable snmp IMPB_violation traps
Command: disable snmp IMPB_violation traps

Success!

DES-1210-28/ME:5#

enable snmp fiber_port_link traps

Purpose To enable SNMP fiber port link traps support on the Switch.

Syntax

enable snmp fiber_port_link traps

Description

The enable snmp fiber_port_link traps command enables SNMP
fiber port link traps support on the Switch. After enables the SNMP
fiber port link traps support, the Switch will send out a trap to the
SNMP manage host when the fiber port is link up or link down.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To enable SNMP fiber port link traps support on the Switch:

DES-1210-28/ME:5# enable snmp fiber_port_link traps
Command: enable snmp fiber_port_link traps

Success!

DES-1210-28/ME:5#

disable snmp fiber_port_link traps

Purpose To disable SNMP fiber port link traps.

Syntax

disable snmp fiber_port_link traps

Description

The disable snmp fiber_port_link traps command disables SNMP
fiber port link traps support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To disable SNMP fiber port link traps support on the Switch:

DES-1210-28/ME:5# disable snmp fiber_port_link traps
Command: disable snmp fiber_port_link traps

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

73

Success!

DES-1210-28/ME:5#

enable snmp firmware_upgrade_state traps

Purpose To enable SNMP firmware upgrade state traps.

Syntax

enable snmp firmware_upgrade_state traps

Description

The enable snmp firmware_upgrade_state traps command
enables SNMP firmware upgrade state traps support on the Switch.
After enables the SNMP firmware upgrade state traps support, the
Switch will send out a trap to the SNMP manage host when the
firmware upgrade is succeed or fail.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To enable SNMP firmware upgrade state traps support on the Switch:

DES-1210-28/ME:5# enable snmp firmware_upgrade_state traps
Command: enable snmp firmware_upgrade_state traps

Success!

DES-1210-28/ME:5#

disable snmp firmware_upgrade_state traps

Purpose To disable SNMP firmware upgrade state traps.

Syntax

disable snmp firmware_upgrade_state traps

Description

The disable snmp firmware_upgrade_state traps command
disables SNMP firmware upgrade state traps support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To disable SNMP firmware upgrade state traps support on the Switch:

DES-1210-28/ME:5# disable snmp firmware_upgrade_state traps
Command disable enable snmp firmware_upgrade_state traps

Success!

DES-1210-28/ME:5#

enable snmp LBD traps

Purpose To enable SNMP LBD traps.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

74

Syntax

enable snmp LBD traps

Description

The enable snmp LBD traps command enables SNMP LBD traps
support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To enable SNMP LBD traps support on the Switch:

DES-1210-28/ME:5# enable snmp LBD traps
Command: enable snmp LBD traps

Success!

DES-1210-28/ME:5#

disable snmp LBD traps

Purpose To disable SNMP LBD traps.

Syntax

disable snmp LBD traps

Description

The disable snmp LBD traps command disables SNMP LBD traps
support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

To disable SNMP LBD traps support on the Switch:

DES-1210-28/ME:5# disable snmp LBD traps
Command: disable snmp LBD traps

Success!

DES-1210-28/ME:5#

enable snmp port_security_violation traps

Purpose To enable SNMP port security violation traps.

Syntax

enable snmp port_security_violation traps

Description

The enable snmp port_security_violation traps command
enables SNMP port security violation traps on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To enable SNMP port security violation traps support on the Switch:

DES-1210-28/ME:5# enable snmp port_security_violation traps

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

75

Command: enable snmp port_security_violation traps

Success!

DES-1210-28/ME:5#

disable snmp port_security_violation traps

Purpose To disable SNMP port security violation traps.

Syntax

disable snmp port_security_violation traps

Description

The disable snmp port_security_violation traps command
disables SNMP port security violation traps on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To disable SNMP port security violation traps support on the Switch:

DES-1210-28/ME:5# disable snmp port_security_violation traps
Command: disable snmp port_security_violation traps

Success!

DES-1210-28/ME:5#

enable snmp rstpport_state_change traps

Purpose To enable SNMP rstp port state change traps support on the Switch.

Syntax

enable snmp rstpport_state_change traps

Description

The enable snmp rstpport_state_change traps command enables
SNMP rstp port state change traps support on the Switch. After
enables the SNMP RSTP port state change traps support, the
Switch will send out a trap when the state of RSTP port is changed.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To enable SNMP RSTP port state change traps support on the Switch:

DES-1210-28/ME:5# enable snmp rstpport_state_change traps
Command: enable snmp rstpport_state_change traps

Success!

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

76

disable snmp rstpport_state_change traps

Purpose To disable SNMP RSTP port state change traps.

Syntax

disable snmp rstpport_state_change traps

Description

The disable snmp rstpport_state_change traps command
disables SNMP RSTP port state change traps on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To disable SNMP RSTP port state change traps support on the Switch:

DES-1210-28/ME:5# disable snmp rstpport_state_change traps
Command: disable snmp rstpport_state_change traps

Success!

DES-1210-28/ME:5#

enable snmp system_device_bootup traps

Purpose To enable SNMP system device bootup traps support on the Switch.

Syntax

enable snmp system_device_bootup traps

Description

The enable snmp system_device_bootup traps command
enables SNMP system device bootup traps support on the Switch.
After enables the SNMP system device bootup traps support, the
Switch will send out a trap to the SNMP manage host when the
device is power on.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To enable the SNMP system device bootup traps on the Switch:

DES-1210-28/ME:5# enable snmp system_device_bootup traps
Command: enable snmp system_device_bootup traps

Success!

DES-1210-28/ME:5#

disable snmp system_device_bootup traps

Purpose To disable SNMP system device bootup traps support on the Switch.

Syntax

disable snmp system_device_bootup traps

Description

The disable snmp system_device_bootup traps command
disables SNMP system device bootup traps support on the Switch.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

77

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To disable the SNMP system device bootup traps on the Switch:

DES-1210-28/ME:5# disable snmp system_device_bootup traps
Command: disable snmp system_device_bootup traps

Success!

DES-1210-28/ME:5#

enable snmp twistedpair_port_link traps

Purpose To enable SNMP twisted pair ports link traps support on the Switch.

Syntax

enable snmp twistedpair_port_link traps

Description

The enable snmp twistedpair_port_link traps command enables
SNMP twisted pair ports link traps support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To enable the SNMP twisted pair ports link traps on the Switch:

DES-1210-28/ME:5# enable snmp twistedpair_port_link traps
Command: enable snmp twistedpair_port_link traps

Success!

DES-1210-28/ME:5#

disable snmp twistedpair_port_link traps

Purpose To disable SNMP twisted pair ports link traps support on the Switch.

Syntax

disable snmp twistedpair_port_link traps

Description

The disable snmp twistedpair_port_link traps command enables
SNMP twisted pair ports link traps support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To disable the SNMP twisted pair ports link traps on the Switch:

DES-1210-28/ME:5# disable snmp twistedpair_port_link traps
Command: disable snmp twistedpair_port_link traps

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

78

Success!

DES-1210-28/ME:5#

enable snmp duplicate_IP_detected traps

Purpose To enable SNMP duplicate IP detected traps support on the Switch.

Syntax

enable snmp duplicate_IP_detected traps

Description

The enable snmp duplicate_IP_detected traps command enables
SNMP duplicate IP detected traps support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To enable the SNMP duplicate_IP_detected traps on the Switch:

DES-1210-28/ME:5# enable snmp duplicate_IP_detected traps
Command: enable snmp duplicate_IP_detected traps

Success!

DES-1210-28/ME:5#

disable snmp duplicate_IP_detected traps

Purpose To disable SNMP duplicate IP detected traps support on the Switch.

Syntax

disable snmp duplicate_IP_detected traps

Description

The disable snmp duplicate_IP_detected traps command
disables SNMP duplicate IP detected traps support on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To disable the SNMP duplicate_IP_detected traps on the Switch:

DES-1210-28/ME:5# disable snmp duplicate_IP_detected traps
Command: disable snmp duplicate_IP_detected traps

Success!

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

79

14

1414

14

DOWNLOAD/UPLOAD COMMANDS

The Download/Upload commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.

Command Parameter

download

[configuration <ipaddr> <path_filename 64> startup] | [firmware <ipaddr> <string
64>]

upload

[[firmware <ipaddr> <path_filename 64>] | [cfg_toTFTP <ipaddr> <path_filename
64> config_id <value 1-2>] | [log_toTFTP <ipaddr> <path_filename 64>]]

Each command is listed in detail, as follows:

download

Purpose To download and install a firmware, boot, or switch configuration file

from a TFTP server.

Syntax

download [configuration <ipaddr> <path_filename 64> startup] |
[firmware <ipaddr> <string 64>]

Description

The download command downloads a firmware, boot, or switch
configuration file from a TFTP server.

Parameters

configuration − Downloads a switch configuration file from a TFTP
server.

<ipaddr> − The IP address of the TFTP server.

<path_filename 64> − The DOS path and filename of the switch

configuration file, up to 64 characters, on the TFTP server. For
example, C:\31xx.had.

startup − Indicates the Configuration file is to be downloaded to the
startup config.

firmware − Downloads and installs firmware on the Switch from a
TFTP server.

<string 64> − The DOS path and filename of the firmware file, up to
64 characters, on the TFTP server. For example, C:\31xx.had.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To download a firmware file:

DES-1210-28/ME:5# download firmware 1.1.1.23 1\des_1210-28me.ros
Command: download firmware 1.1.1.23 1\des_1210-28me.ros
01–Jan–2000 01:19:48 %COPY–I–FILECPY: Files Copy – source URL tftp://1.1.1.23 /1\

des_1210-28me.ros destination URL Unit all flash://image
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

80

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!01–Jan–2000 01:22:49 %COPY–W–TRAP:
The copy operation was completed successfully
!
3920460 bytes copied in 00:03:01 [hh:mm:ss]

DES-1210-28/ME:5#

To download a configuration file:

DES-1210-28/ME:5# download configuration 10.48.74.121 c:\cfg\setting.txt

Overwrite file [startup-config] ?[Yes/press any key for no]....

01-Jan-200003:19:46%COPY-I-FILECPY:FilesCopy-source URL tftp://10.48.74.121/1.txt
destination

URL flash://startup-config
Success.

Success.

.....01-Jan-2000 03:18:40 %COPY-N-TRAP: The copy operation was completed

successfully!
Copy: 267 bytes copied in 00:00:08 [hh:mm:ss]
DES-1210-28/ME:5#

upload

Purpose To upload the current switch settings to a TFTP server.

Syntax

upload [[firmware <ipaddr> <path_filename 64>] | [cfg_toTFTP
<ipaddr> <path_filename 64> config_id <value 1-2>] |
[log_toTFTP <ipaddr> <path_filename 64>]]

Description

The upload command uploads the Switch’s current settings to a
TFTP server.

Parameters

firmware − Specifies that the Switch’s current firmware are to be
uploaded to the TFTP server.

<ipaddr> − The IP address of the TFTP server. The TFTP server
must be on the same IP subnet as the Switch.

<path_filename 64> − The location of the Switch configuration file on
the TFTP server.

config_id <value 1-2> − Specifies the config id which to be
uploaded.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

DES-1210-28/ME:5# upload log_toTFTP 1.1.1.23 des-1210-28me.ros
Command: upload log_toTFTP 1.1.1.23 des-1210-28me.ros
01–Jan–2000 01:26:11 %COPY–I–FILECPY: Files Copy – source

URL running–config destination URL tftp://1.1.1.23/1\running–

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

81

config
… ..01–Jan–2000 01:26:16 %COPY–W–TRAP: The copy operation

was completed success fully!
158 bytes copied in 00:00:05 [hh:mm:ss]

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

82

15

1515

15

DHCP RELAY COMMANDS

The DHCP Relay commands in the Command Line Interface (CLI) are listed (along with the appropriate
parameters) in the following table.

Command Parameter

enable dhcp_relay

disable dhcp_relay

config dhcp_relay add
ipif system

<ipaddr>

config dhcp_relay
delete ipif system

<ipaddr>

config dhcp_relay hops <value 1-16>

config dhcp_relay
option_82

[check [enable | disable] | policy [drop | keep | replace] | remote_id [default |
user_define <string 32>] | state [enable | disable]]

show dhcp_relay {ipif}

enable
dhcp_local_relay

disable
dhcp_local_relay

config dhcp_local_relay
vlan

<vlan_name> | vlanid <vidlist>] state[enable | disable]

show dhcp_local_relay

Each command is listed in detail, as follows:

enable dhcp_relay

Purpose To enable DHCP Relay server on the Switch

Syntax

enable dhcp_relay

Description

The enable dhcp_relay command sets the DHCP Relay to be
globally enabled on the Switch and on all existing VLANs.

Parameters None.

Restrictions Only Administrator or operate-level users can issue this command.

Example usage:

To enable DCHP Relay on the Switch:

DES-1210-28/ME:5# enable dhcp_relay
Command: enable dhcp_relay

Success!

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

83

DES-1210-28/ME:5#

disable dhcp_relay

Purpose To disable DHCP Relay server on the Switch

Syntax

disable dhcp_relay

Description

The disable dhcp_relay command sets the DHCP Relay to be
globally disabled on the Switch and on all existing VLANs.

Parameters None.

Restrictions Only Administrator or operate-level users can issue this command.

Example usage:

To disable DHCP Relay on the Switch:

DES-1210-28/ME:5# disable dhcp_relay
Command: disable dhcp_relay

Success!

DES-1210-28/ME:5#

config dhcp_relay add ipif system

Purpose

To define a DHCP server as a DHCP Relay server

Syntax

config dhcp_relay add ipif system <ipaddr>

Description

The config dhcp_relay add ipif system command adds DHCP
servers as DHCP Relay servers.

Parameters

<ipaddr> − The IP address of the DHCP server. Up to 4 servers can
be defined.

Restrictions Only Administrator or operate-level users can issue this command.

Example usage:

To add a DHCP server as a DHCP Relay server:

DES-1210-28/ME:5# config dhcp_relay add ipif System 10.6.150.49
Command: config dhcp_relay add ipif System 10.6.150.49

Success!

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

84

config dhcp_relay delete ipif system

Purpose To delete a DHCP server from the DHCP Relay server list.

Syntax

config dhcp_relay delete ipif system <ipaddr>

Description

The config dhcp_relay delete ipif system command deletes a
DHCP servers defined as a DHCP Relay server.

Parameters

<ipaddr> − The IP address of the DHCP server.

Restrictions Only Administrator or operate-level users can issue this command.

Example usage:

To remove a DHCP server from the DHCP Relay server list:

DES-1210-28/ME:5# config dhcp_relay delete ipif System 10.6.150.49
Command: config dhcp_relay delete ipif System 10.6.150.49

Success!

DES-1210-28/ME:5#

config dhcp_relay

Purpose To delete a DHCP server from the DHCP Relay server list.

Syntax

config dhcp_relay hops <value 1-16>

Description

The config dhcp_relay hops command configures the
DHCP/BOOTP relay feature.

Parameters

hops <value 1-16> − Specifies the maximum number of relay agent
hops that the DHCP packets can cross.

Restrictions Only Administrator or operate-level users can issue this command.

Example usage:

To configure the DHCP relay on the Switch:

DES-1210-28/ME:5# config dhcp_relay hops 12
Command: config dhcp_relay hops 12

Success!

DES-1210-28/ME:5#

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

85

config dhcp_relay option_82

Purpose To configure the check, policy and state of DHCP relay agent

information option 82 of the Switch.

Syntax

config dhcp_relay option_82 [check [enable | disable] | policy
[drop | keep | replace] | remote_id [default | user_define <string
32>] | state [enable | disable]]

Description

The config dhcp_relay option_82 is used to configure the check,
policy and state of DHCP relay agent information option 82 of the
Switch

Parameters

check: used to configure the check of DHCP relay agent information
option 82 of the Switch.

enable – When the field is toggled to enable, the relay agent will
check the validity of the packet’s option 82 field. If the switch
receives a packet that contains the option 82 field from a DHCP
client, the switch drops the packet because it is invalid. In packets
received from DHCP servers, the relay agent will drop invalid
messages.

disable – When the field is toggled to disable, the relay agent will not
check the validity of the packet’s option 82 field.

policy: used to configure the re-forwarding policy of DHCP relay
agent information option 82 of the Switch.

replace − The option 82 field will be replaced if the option 82 field
already exists in the packet received from the DHCP client.

drop − The packet will be dropped if the option 82 field already
exists in the packet received from the DHCP client.

keep − The option 82 field will be retained if the option 82 field
already exists in the packet received from the DHCP client.

state: used to configure the state of DHCP relay agent information
option 82 of the Switch.

enable − W hen this field is toggled to Enabled the relay agent will
insert and remove DHCP relay information (option 82 field) in
messages between DHCP server and client. When the relay agent
receives the DHCP request, it adds the option 82 information, and
the IP address of the relay agent (if the relay agent is configured), to
the packet. Once the option 82 information has been added to the
packet it is sent on to the DHCP server. When the DHCP server
receives the packet, if the server is capable of option 82, it can
implement policies like restricting the number of IP addresses that
can be assigned to a single remote ID or circuit ID. Then the DHCP
server echoes the option 82 field in the DHCP reply. The DHCP
server unicasts the reply to the back to the relay agent if the request
was relayed to the server by the relay agent. The switch verifies that
it originally inserted the option 82 data. Finally, the relay agent
removes the option 82 field and forwards the packet to the switch
port that connects to the DHCP client that sent the DHCP request.

disable − If the field is toggled to disable the relay agent will not
insert and remove DHCP relay information (option 82 field) in
messages between DHCP servers and clients, and the check and
policy settings will have no effect.

Restrictions Only Administrator or operate-level users can issue this command.

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

86

Example usage:

To disable the DHCP relay option 82 on the Switch:

DES-1210-28/ME:5# config dhcp_relay option_82 state disable
Command: config dhcp_relay option_82 state disable

Success!

DES-1210-28/ME:5#

show dhcp_relay

Purpose To

display the DHCP Relay settings on the Switch

.

Syntax

show dhcp_relay {ipif}

Description

The show dhcp_relay command displays the DHCP Relay status
and list of servers defined as DHCP Relay servers on the Switch.

Parameters None.

Restrictions None.

Example usage:

To display DHCP Relay settings:

DES-1210-28/ME:5# show dhcp_relay
Command: show dhcp_relay

DHCP/BOOTP Relay Status : Disabled
DHCP/BOOTP Hops Count Limit : 4
DHCP/BOOTP Relay Time Threshold : 0
DHCP Relay Agent Information Option 82 State : Disabled
DHCP Relay Agent Information Option 82 Check : Disabled
DHCP Relay Agent Information Option 82 Policy : Replace
DHCP Relay Agent Information Option 82 ID : 00-B2-FD-DA-EE-EB

Interface Server 1 Server 2 Server 3 Server 4

--------- --------------- --------------- -------------- --------------­DES-1210-28/ME:5#

enable dhcp_local_relay

Purpose To enable the DHCP local relay feature globally

Syntax

enable dhcp_local_relay

Description

The enable dhcp_local_relay command enables the DHCP local
relay feature on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command

Example usage:

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

87

To enable the DHCP Local Relay:

DES-1210-28/ME:5# enable dhcp_local_relay
Command: enable dhcp_local_relay

Success
DES-1210-28/ME:5#

disable dhcp_local_relay

Purpose To disable the DHCP local relay feature globally

Syntax

disable dhcp_local_relay

Description

The disable dhcp_local_relay command disables the DHCP local
relay feature on the Switch.

Parameters None.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To disable the DHCP Local Relay:

DES-1210-28/ME:5# disable dhcp_local_relay
Command: disable dhcp_local_relay

Success
DES-1210-28/ME:5#

config dhcp_local_relay vlan

Purpose To specify which VLAN’s the feature works on.

Syntax

config dhcp_local_relay vlan <vlan_name> | vlanid <vidlist>]
state[enable | disable]

Description Each VLAN which was added to the DHCP Local Relay list

participates in the DHCP Local Relay process – Option 82 is added
to DHCP requests on this VLAN, and Removed from DHCP Replies
on this VLAN.

Parameters

vlan_name – the VLAN name identifier

vlanid <vidlist> – The VLAN tag identifier

state [enable | disable] – enable or disable of the DHCP Local Relay

status by VLAN name or VLAN ID.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To disable the VLAN ID10 from VLAN of DHCP Local Relay:

DES-1210-28/ME:5# config dhcp_local_relay vlan vlanid 10 state disable
Command: config dhcp_local_relay vlan vlanid 10 state disable

DES-1210-28/ME Metro Ethernet Managed Switch CLI Reference Guide

88

Success
DES-1210-28/ME:5#

show dhcp_local_relay

Purpose To display which VLAN’s the feature works on.

Syntax

show dhcp_local_relay

Description Each VLAN which was added to the DHCP Local Relay list

participates in the DHCP Local Relay process – Option 82 is added
to DHCP requests on this VLAN, and Removed from DHCP Replies
on this VLAN.

Parameters None.

Restrictions None.

Example usage:

To display the DHCP local relay information on the Switch:

DES-1210-28/ME:5# show dhcp_local_relay
Command: show dhcp_local_relay

DHCP/BOOTP Local Relay Status : Disabled
DHCP/BOOTP Local Relay VID List :

DES-1210-28/ME:5#
