D-Link warrants its hardware products to be free from defects in workmanship and materials, under normal
use and service, for the following lengths of time from the date of purchase from D-Link or its authorized
reseller:
Product TypeWarranty Period
Network adaptersLifetime
Unmanaged and managed hubs Lifetime *
Repeaters, MAUs, transceivers, media convertersOne year
* Power supply and fans in these devices One year
Spare parts and spare kits 90 days
If a product does not operate as warranted during the applicable warranty period, D-Link shall, at its option and
expense, (1) repair the defective product or part, (2) deliver to Customer an equivalent product or part to replace the
defective ite m. A ll product s t hat a re re placed will become the property of D-Link. Replacement products may be new
or reconditioned. Any replaced or repaired product or part has a ni net y (90) day w arrant y or the rema inder of the initial
warranty peri od, w hic hever i s l onger.
D-Link shall not be responsible for any software, firmware, information, or memory data of Customer contained in,
stored on, or inte grat ed wi th a ny products re turned t o D-L ink purs uant to any w arra nty.
All products with lifetime warranty have a standard five-year warranty. To qualify for lifetime warranty, the
enclosed Product Registration Card must be completed and returned to D-Link within ninety (90) days of
purchase.
Warranty service may be obtained by contacting a D-Link office for a Return Material Authorization (RMA)
number. If a Product Registration Card has not been previously sent, proof of purchase, such as a copy of the
dated purchase invoice, must be provided. Once an RMA number is issued, the defective product must be
shipped back to D-Link prepaid, insured and wrapped in the original or similar shipping package to ensure
that it will not be damaged during shipment. When returning the defective product to D-Link for service, the
RMA number must be marked on the outside of the shipping package. Any product returned without an
RMA number shall be rejected and sent back to the Customer, and D-Link reserves the right to have
Customer bear the cost of sending back such products. A service charge may or may not be levied to
Customer by D-Link. To find out if a service charge is levied or not, and the charged amount, read the RMA
that is returned to Customer, or ask the D-Link office when an RMA is requested.
WARRANTIES EXCLUSIVE
IF THE D-LINK PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, THE CUSTOMER'S SOLE REMEDY SHALL BE,
AT D-LINK'S OPTION, REPAIR OR REPLACEMENT. THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE
AND ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW,
STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. D-LINK NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER
LIABILITY IN CONNECTION WITH THE SALE, INSTAL LATION MAI NTENANCE OR USE OF D-LINK'S PRODUCTS.
D-LINK SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE
ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY THE CUSTOMER'S OR ANY THIRD
PERSON'S MISUSE, NEGLECT, IMPROPER INSTALLATION OR TES TING, UNAUTHORIZED ATTEMPTS TO REPAIR, OR
ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING OR OTHER
HAZARD.
LIMITATION OF LIABILITY
IN NO EVENT WILL D-LINK BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA, LOSS OF PROFITS, COS T OF
COVER OR OTHER INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES ARISING OUT THE INSTALLATION,
MAINTENANCE, USE, PERFORMANCE, FAILURE OR INTERRUPTION OF A D- LINK PRODUCT, HOWEVER CAUSED AND
ON ANY THEORY OF LIABILITY. THIS LIMITATION WILL APPLY EVEN IF D-LINK HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.
IF YOU PURCHASED A D-L I NK PRODUCT IN THE UNI T E D STAT E S, SOME STAT E S DO NOT AL L OW THE L I M I T AT I ON OR
EXCLUSION OF LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION MAY NOT
APPLY TO YOU.
SOFTWARE
D-Link warran ts that the so ftware pr ogra ms licensed f rom it will p erfor m in sub stantial con form ance to the
applicable published program specifications for a period of ninety(90) days from the date of purchase from
D-Link or its authorized reseller. D-Link warrants the magnetic media containing software against failure
during the warranty period. No updates are provided. D-Link
any defective software products with products which substantially conform to D-Link
specifications. Customer assumes responsibility for the selection o f th e a pp r op r iate ap p licatio n s pr og r am a nd
associa ted reference mat e rials. D -Link makes no warranty that its software produc t s will work in combination
with any hardware of applications software products provided by third party, that the operation of the
software products will be uninterrupted or error free, or that all defects in the software product will be
corrected. F or a ny third party products listed in the D-Link software product documentat ion or specifications
as being comp atible. D-Link will make reasona ble efforts to prov ide com patibility, e xcept wh ere the noncompatibility is caused by
bug or defect in the third party s product.
s sole obligation hereunder shall be to replace
s applicable pu blished
Warranty service for software products may be obtained by contacting a D-Link office within the warranty
period. Where no Product Registration Card has been sent by Customer, proof of purchase, such as a copy of
the dated purcha sed invoice , must be provide d.
D-Link Offices to Contact for Warranty Service:
To obtain an RM A number or a warranty service, c ontact one of the following regiona l D-Link offices:
In North, Ce ntral and South A me r ica:
D-Link Systems Inc.
5 Musick, Irvine CA 92718
Tel. (1) 714-455-1688, Fax. (1) 714-455-2521
In Europe and Israel:
D-Link (EUROPE) LTD.
D-Link House, 6 Garland R oa d, Stanmore,
London HA7 IDP U.K.
Tel. (44) 181-2355555, Fax. (44) 181-2355500
In the Middle East (except for Isreal), Asia, Oceania and Africa:
D-Link Corporat ion
No. 233-2, 2nd F. Pao Chiao Road, Hsin Tien, T a ipei, Taiwan
Tel. (886) 2-916-1600, Fax. (886) 2-914-6299
2-3
Trademarks
Copyright D-Link Cor poration / D- Link Systems , Inc.
All rights reserved, contents are subjected to revision without pr ior notice.
D-Link is a regist er ed trademark of D-L ink Corporation / D-Link Systems, Inc.
All other trademarks belong to t heir owners.
Copyright Statement
No part of this publication may
or used to make any derivative (such as translation,
transformation or adaptation) without express permission from
the D-Link Corporation / D-Link Systems Inc., as stipulated by
the United States Copyright Act of 1976.
be reproduced in any form or by any means
FCC Certifications
DE-528CT FC C C lass B ID : 528-KA2OPC 3200
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
Shielded interface cables must be used in order to comply with
emission limits.
You are cautioned that changes or modifications not expressly
approved by the party responsible for compliance could void your
authority to operate the equipment.
This device complies with Part 15 of ???
he FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference,
and (2) This device must accept any interference received,
including interference that may cause undesired operation.
DE-528CT Ethernet Adapter / User s Guide
TABLE OF CONTENTS
Introduction............................2-1
Features.................................... 2-1
General steps t o s et up/configure a DE-528CT c ar d
For a DE-528CT without Boot ROM......... 2-2
For a DE-528CT with Boot ROM............ 2-2
Hardware Installation...................3-1
Step 1 Inset the adapter into an expansion
slot........................................ 3-1
Step 2. Network Cable Connections.......... 3-2
Twisted-Pair Cable...................... 3-2
Thin Coaxial Cable...................... 3-3
..... 2-2
Software Installation...................4-1
Configuration and Diagnostics...........5-1
Starting the Setup and Diagnostic Program5-1
Configuring DE-528CT.................... 5-2
Run Diagnostics......................... 5-2
Boot ROM Installation...................6-1
Appendices
A. Trouble Shooting.......................A
B. LED Indicators.........................B
DE-528CT Ethernet Adapter / User s Guide
C. Specifications.........................C
D. Cable Specifications...................D
E. Device Drivers.........................E
2-2
Introduction
DE-528CT Ethernet Adapter / User s Guide
2
I
NTRODUCTION
The DE-528CT is a high performance PCI based Ethernet Adapter which i s
based upon Industry Standard PCI Local Bus Specification 2.0, that
features plug and play funct i on, ma ki ng it ful ly a ut o-confi gura ble .
The Ethernet Adapter offers the network medium selection of 10BASE-T(RJ-45)
or 10BASE2(BNC) connection. It also includes a built-in buffer RAM for
faster network transmission and reception, and two LEDs for trouble
shooting.
The Ethernet Adapter includes a complete set of drivers for all popular
Network Operation Systems and is also Microsoft Windows 95 compatible.
The optional BOOT TOM device allows the diskless workstation to be
connected to the network.
Features
Designed for versatility and performance, the DE-528CT provides the
following features:
Simple Plug-and-Play installation.
Complies with IEEE 802.3 and 10 BASE-Tst andard.
Flexible cable support wi th RJ-45 and BNC connectors.
10 Mbps data tr ans fer rate.
Support ful l-duplex function for send and receive to double channel bandwidth.
Built-in FIFO buffers reduce overloadof memory transfers.
VLSI components provides high reliability, low power consumption and reduced card
size.
DE-528CT Ethernet Adapter / User s Guide
Two LED indicators: Active, Link.
Drivers for all popular operating systems.
FCC class B and CE Marking Certification.
General steps
to set up/configure a DE-528CT card
For a DE-528CT without Boot
ROM
1. Install DE-528CT card and connect it to a network cable.
2. Run HELP.EXE on the DE-528CT software diskette to view the related
installation instructions.
3. Run INSTALL.EXE on the DE-528CT software diskette to copy a
specific driver.
4. If necessary, modify files according to installation instructions.
5. Restart the computer [Optional].
6. If the DE-528CT doesn
t function properly, run SETUP.EXE on the DE-
528CT software diskette to locate the problem.
For a DE-528CT with Boot ROM
1. Install the DE-528CT card and connect it to a network cable.
2. Run HELP.EXE on the DE-528CT software diskette to view installation
instructions.
3. Run SETUP.EXE on the DE-528CT software diskette to configure the
card and the Boot ROM.
4. Restart the computer.
5. If the DE-528CT doesn
528CT software diskette to locate the problem.
t function properly, run SETUP.EXE on the DE-
New or confused users should refer back to these general steps if necessary
And since most customers use the DE-528CT ca rd wit hout Boot ROM, the
detailed instructions on how to install the DE-528CT card without Boot
ROM will be described in the following chapters..
2-2
Introduction
DE-528CT Ethernet Adapter / User s Guide
In order to run the Network Diagnostics program (SETUP.EXE)
Note
successfully, the network drivers and related files, copied from the
DE-528CT installation diskette, and the SETUP.EXE file must be
stored in the same directory.
2-3
DE-528CT Ethernet Adapter / User s Guide
H
ARDWARE INSTALLATION
3
CAUTION
Installation of a DE-528CT Ethernet adapter requires two steps:
:
Step 1
expansion slot
1. Shut down the computer, unplug its power cord, and remove the
chassis c o ver.
2. Insert the card into the connector of any open PCI Bus I/O expansion
slot. Ascertain that the card is fully seated in the expansion slot
connector.
3. Install the bracket screw which secures the card to the computer
chassis.
4.Replace the computer
To prevent the damage to the product due to
ESD, please use wrist straps during the
installation and maintenance.
Insert the adapter
s chassis c o ver.
into an
DE-528CT Ethernet Adapter / User s Guide
Step 2. Network Cable
Connections
Before connecting a network cable to the DE-528CT adapter, ascertain that
the network cable medium is
Twisted-Pair
1
Thin Coaxial
or
2
cable. Then refer to one of the two sections following, according to your
network cable type.
Twisted-Pair Cable
3
Ascertain that you have a straight
or EIA/TIA-568 non-standard 100-ohm STP cable, not more than 100 meters
(328 feet) in length for the network connection. The cable will have an RJ-45
plug on each end. The stations are connected in a star topology.
1
Twisted Pair (TP) cable features RJ-45 connectors, and is available with or without EM
shield. TP cable without EM shield is also known as 10BaseT cable or UTP (Unshielded
Twisted-Pair) cable. TP cable with EM shield is known as screened twisted-pair cable, and
the EM shield may be either an aluminum sheath or a copper braid enclosing the twisted-pair
bundle.
2
Thin Coaxial
including 10Base2 cabl e , BNC cable, and R G -58 cable.
3
Pins 1 and 2 must be a pair (the connected wires must be a twisted pair in the cable makeup)
and pins 3 and 6 must be a pair. Each pin must connect straight through the cable (that is pin
1 through to pin 1 of the opposite connector, pin 2 to pin 2, pin 3 to pin 3, and pin 6 to pin 6;
pins 4, 5, 7, 8 are not used).
features BNC connectors and is known by a variety of other names,
twisted-pair cable, UTP cable (Cat. 3 ,4 ,5)
a star topology
3-2Hardware Installation
DE-528CT Ethernet Adapter / User s Guide
Plug one end into the RJ-45 receptacle of the DE-528CT adapter, and plug
the other end into an available port of a 10Base-T hub. Push each RJ-45
plug into its receptacle until its retainer snaps into place.
Thin Coaxial
Cable
Ascertain that you have 0.2 inch diameter RG-58A/U 50-ohm coaxial
cable, with BNC connectors at each end, not more than 185 meters (600
feet) in length for the network connection. The stations are connected in a
bus topology. Follow the steps:
1. Connect a BNC T-connector onto the BNC receptacle of the DE-
528CT card.
2. Connect the network cable onto either open end of the BNC
connector
.
T-
3a. If the cable continues on to an additional station or stations, then
connect the continuation cable onto the remaining open end of the
BNC T-connector.
3b. If the network cable does not continue to additional stations (your
computer is at the end of the cable), then connect a 50-ohm terminator
to the remaining open end of the BNC T-connector.
Hardware Installation
3-3
DE-528CT Ethernet Adapter / User s Guide
4
S
OFTWARE INSTALLATION
On account of the great variety of network environments in which the DE528CT may be installed and used, and the frequency of revisions in these
network systems, the instructions for software installation are given as
README files on the DE-528CT driver program diskette supplied in your
DE-528CT package.
Required software is provided on a diskette labeled the DE-528CT
Installation. The diskette contains drivers for various NOSs (Network
Operating System), and README files which provide instructions for
installing the driver specific to your NOS.
Insert the DE-528CT Installation program diskette in an available diskette
drive (here shown as drive A).
To view related installation instructions
and press
Instruction
details, choose the specific command which is appropriate to your network
operating system.
To get the rela ted driver from
in
A: INSTALL.
Program
Dos Client
Enter,
to view the overview information, then for full installation
dialog box appears, choose a command, such as
, then follow the
then the
When
Main Menu
the DE-528CT Installation diskette, type
D-Link DE-528CT Ethernet Adapter AUTOinstall
instructions
on your screen.
, type in
dialog box appears. Choose
HELP.EXE
A:
Novell Netware
DE-528CT Ethernet Adapter / User s Guide
5
C
ONFIGURATION AND
D
IAGNOSTICS
The DE-528CT adapter will be automatically configured when the
computer is powered on.
Run the SETUP.EXE configuration and diagnostics program to verify
configuration of the DE-528CT as set by the installation procedure, and
assist with isolation of any faults in operation. These procedures are
optional, and will only be useful in the unusual event that there is a fault,
such as an interrupt number conflict among your computer
cards. If your installation provides normal operation, you might choose to
skip these procedures.
s expansion
Starting the Setup and Diagnostic Program
Insert the DE-528CT Installation program diskette in an available diskette
drive (here shown as drive A). At the DOS prompt (here shown as
key in:
> A : SETUP
The
Main Menu
Then follow the instructions on the screen. Note that you can get hel p or
quit the Setup and Diagnostics program at any time by pressing F1 or Esc
respectively.
dialog box appears.
and press
Enter
>
),
DE-528CT Ethernet Adapter / User s Guide
Configuring DE-528CT
Choose
Set Up New Confi gura tion
the
Set Up New Confi g ur a tion Menu
from the
appears.
Main Menu
dialog box, then
Run Diagnostics
Choose
Run Diagnostic s
Diagnostics Menu
EEPROM Test
This test verifies the mode and the register information on the
EEPROM.
On Board Diagnostics
To run this test, choose
Diagnostics Menu
This is a series of tests designed to check Network Controller
Registers, on-board RAM, Internal Loopback and Interrupt Generation.
Network Diagnostics
To run this test, choose
Diagnostics Menu
from the
Main Menu
dialog box, then the
appears which provides three te sti ng le ve ls:
4
Run Diagnostics On Board
dialog box
.
Run Diagnostic s On Network
dialog box
.
from the
from the
Run
Run
Run
This test verifies that the network cable is connected properly, sothat
the adapter can send and receive data successfully.
This test requires two computers, the master computer and a second
computer. The master computer, configured as the a data generator,
generates and transmit packets. The second computer, configured as
the data receiver, receives packets and transmits them back to the data
generator.
4
The On Board Diagnostics test must be run before the Network Diagnostics test is run, in order to ensure
the adapter
5-2Configuration and Diagnostics
s basic functions are working properly.
DE-528CT Ethernet Adapter / User s Guide
6
B
OOT
The optional
the network. Follow the steps to i nst al l your
1. Insert the Boot ROM into the socket on t he a da pte r.
2. Run the SETUP.EXE program. Choose
choose
3. Restart the computer.
Note: Also refer to the Boot ROM installation procedures provided by
your Network Operating System.
ROM I
Boot ROM
Boot ROM Size , then choose the Boot ROM Enable d.
device allows you to connect a di skless workstation t o
NSTALLATION
Boot ROM
.
Set Up New Configuration ,
DE-528CT Ethernet Adapter / User s Guide
Appendices
A
T
ROUBLE SHOOTING
This section describes reasons for some adapter s failures and the actions to
be taken to resolve the problems.
Connection failure, and unshielded twisted pair(UTP) cable was used.
Action: Verify the
Connection failure, and coaxial cable was used.
Action: Verify the
UTP cable
coaxial cable
is firmly a attached.
is properly terminated..
LED I
ACTIVE
Flashing green indicates that the adapter is transmitting or receiving.
LINK
Steady green indicates good linkage between the DE-528CT and its
supporting hub.
NDICATORS
B
DE-528CT Ethernet Adapter / User s Guide
C
S
PECIFICATIONS
IEEE 802.3 Standard10BASE-T and 10-BASE2
Wiring ConnectorRJ-45 and BNC
Bus Characteristics32 bits; PCI Local Bus
Specification 2.0
I/O addressbeing assigned by the BIOS to
a free I/O address block
IRQ lineINTA; being assigned by the
BIOS to a free IRQ(interrupt)
number
SRAM buffer16 KB
FCC ComplianceFCC Class B
Power Consumption2.5W
Operating Temperature0 to 55 °C
Operating Humidity10% to 90%, non-condensing
PCB layertwo layers
DE-528CT Ethernet Adapter / User s Guide
D
C
ABLE SPECIFICATIONS
The DE-528CT Ethernet adapter has three connector alternatives. Each
connector requires a different cable. This section describes the various
cable
s specifications:
Cable for RJ-45 connector for 10BASE-T network
Cable typeSTP/UTP with 2 twisted pairs of 22,
24 or 26 AWG
Twists per foot2 to 3(min.)
Nominal impedance100 ohms
Maximum cable length328 feet( 100 m)
Cable for thin coaxial BNC connector for 10BASE2 network
Cable typeRG-58 A/U or RE-58C/U
Minimum distance0.5m(between two nodes.)
Maximum segment length600feet(185m)
Maximum
nodes per segment
30
DE-528CT Ethernet Adapter / User s Guide
D
EVICE DRIVERS
The DE-528CT installation diskette contains the following drivers:
DE-528CT drivers:
NDIS driver
Novell Netware 3.x and 4.x ODI driver
Packet driver
Drivers available for the following system s/p rot ocol s:
MS LAN Manager
Win/TCP Pathway Access for DOS
FTP PC/TCP
IBM PC LAN Support Program
SUN PC-NFS
IBM LAN Server
DEC Pathworks 4.0
Banyan VINES
Windows for Workgroups
3 COM 3+ Open
Windows NT
Windows 95
Windows NT Advanced Server
SCO UNIX
E
DE-528CT Ethernet Adapter / User s Guide
DE-528CT Ethernet Adapter / User s Guide
