Digi-Star Diet Manager Set-up User Manual

SET-UP AND USER

GUIDE

D3651US-D

Set-up and User Guide

Digi - Star® LLC

SOFTWARE LICENSE AGREEMENT

IMPORTANT: The Digi-Star® software being installed by you or by our technical staff will be licensed to you, the licensee, on the
condition that you agree with DIGI-STAR® LLC ("Digi-Star") to the terms and conditions set forth in this legal agreement. PLEASE
READ THIS AGREEMENT CAREFULLY, YOU WILL BE BOUND BY THE TERMS OF THIS AGREEMENT IF YOU INSTALL, OR
IF YOU HAVE DIGI-STAR®'S TECHNICAL STAFF OR AUTHORIZED REPRESENTATIVE INSTALL SOFTWARE FOR YOU. If you
do not agree to the terms contained in this agreement, please return the disk package to your dealer for a full refund, or do not have
a Digi-Star® technician or authorized representative install this software. Once you have allowed the software to be installed, you are
bound by this agreement.

If you agree to these terms and conditions, Digi-Star® grants to you a nonexclusive license to use the accompanying software (the
"Software") and documentation. The Software and the documentation are referred to in this Agreement as the "Licensed Material".

1. Ownership

The Licensed Materials are the sole and exclusive property of Digi-Star® and are protected by U.S. Copy Right Law and
international Treaty Provisions. By paying the license fee and by installing, or by allowing a Digi-Star® technical or authorized
representative to install the software, you do not become the owner of the Licensed Material according to the terms of this
agreement.

2. License

The license granted to you by Digi-Star® in this agreement authorizes you to use the Software on any single computer, or any
replacement for that computer. The Software may not be used on a Network Server. A separate disk, licensed under an additional
software agreement, is required for any other computer on which you wish to load the Software. YOU MAY NOT USE, COPY, OR
MODIFY THE LICENSED MATERIAL IN WHOLE OR PART, EXCEPT AS EXPRESSLY PROVIDED IN THIS AGREEMENT.

3. Term

This Agreement is effective from the date on which you open the sealed disk package and installed the Software or have the
Software installed by Digi-Star®. This agreement may be terminated by you at any time by destroying the Licensed Material,
together with all copies, modifications and merged portions in any form. It will also terminate automatically if you fail to comply with
any term of condition of this agreement.

4. Restrictions and Transfer

You may not sublicense, assign, share, rent, lease, or otherwise transfer your right to use the Licensed Material, nor any other rights
granted to you under this agreement, except stated in this paragraph. You may permanently transfer the software to any other party
if the other party is purchasing your business operation, the other party agrees to the terms and conditions of this agreement, you
transfer all copies of the Licensed Material to that party, or destroy those which are not transferred and that new party pays a license
transfer fee of 25% of the original license fee. By such transfer, you terminate the license granted to you in this agreement.

5. Restrictions against copying or modifying the Licensed Material

The Licensed Materials are copyrighted by Digi-Star®. Except as expressly permitted in this agreement, you may not copy or
otherwise reproduce the Licensed Materials. In no event does the limited copying or reproduction permitted under this Agreement
include the right to decompile, disassemble, or electrically transfer the Software in any form, in whole or in part, or of any
modification of the Software, or any updated work containing the Software, or any part thereof. You also agree not to remove any
existing copyright notice of the License Materials.

6. Protection and Security

You agree to use your best efforts and take all reasonable steps to safeguard the License Materials to ensure that no unauthorized
person has access to them and that non authorized copying, publication, disclosure, or distribution of any of the Licensed Material is
made. You acknowledge that the Licensed Materials contain valuable, confidential, and trade secrets and that unauthorized use and
copying are harmful to Digi-Star® and its software suppliers, and that you have the confidential obligation on such valuable
information and trade secrets.

7. Limited Warranty

Digi-Star® warrants that the media on which the Software is recorded will be free from defects in workmanship and materials for a
period of 90 (ninety) days from the payment of the license fee, and if Digi-Star® determines the media to be defective and provided
the media was not subject to misuse, abuse, or use in defective equipment, Digi-Star® will replace the media. ALL IMPLIED
WARRANTIES ON THE MEDIA, INCLUDING IMPUTED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF OF THE EXPRESS WARRANTY SET FORTH ABOVE.

IN NO EVENT WILL DIGI-STAR® OR ANY OTHER PARTY WHO HAS BEEN INVOLVED IN THE CREATION, PRODUCTION, OR
DELIVERY AND INSTALLATION OF THE LICENSE MATERIALS BE LIABLE FOR SPECIAL, DIRECT, INDIRECT, OR
CONSEQUENTIAL DAMAGES, IN NO EVENT SHALL DIGI-STAR®'S OR SUCH OTHER PARTY'S LIABILITY FOR ANY DAMAGE,
OR LOSS TO YOU OR ANY OTHER PARTY EXCEED DIGI-STAR REPLACING THE MEDIA ON WHICH THE LICENSED
MATERIALS HAS SUPPLIED.

8. General

If any provision or of portion of a provision of this Agreement is determined to be invalid under any applicable law, it shall be
deemed omitted and the remaining provision and partial provisions of this Agreement shall continue in full force and effect.

This Agreement constitutes the entire agreement between the parties with respect to the subject matter hereof, and all prior
agreements, statements and undertakings are hereby expressly canceled.

08/31/05

Table of Contents

Introduction..................................................................................................................................... 1

Minimum System Requirements......................................................................................... 1

System Setup................................................................................................................................... 2

Connect the DataKey™ Docking Station ............................................................................ 2

Install Diet Manager Software.......................................................................................... 2

Find Comm ......................................................................................................................... 3

Diet Manager Setup...................................................................................................................... 4

Enter/Update Commodities................................................................................................. 4

Enter/Update Recipes.......................................................................................................... 4

Enter/Update Corrals .......................................................................................................... 5

Enter/Update Wagons ......................................................................................................... 6

Entering/Updating Operators.............................................................................................. 7

Sending Feed Data .............................................................................................................. 7

Loads Mode ........................................................................................................................ 7

Send Loads to the DataKey™.............................................................................................. 8

List Mode............................................................................................................................ 8

Send Loads to the DataKey™.............................................................................................. 9

Datakey Docking Station Activity Light Formats .............................................................. 9

RF Datalink......................................................................................................................... 9

Auto Send (RF Datalink) .............................................................................................. 10

Feeding with the EZ3500 Indicator .................................................................................. 10

Receive Data from the DataKey™................................................................................. 10

Receive Data Options ................................................................................................... 11

Receive Data from RF Datalink.................................................................................... 11

View Data on DataKey™.............................................................................................. 12

Test DataKey™.............................................................................................................. 12

Authorize DataKey™..................................................................................................... 12

Reports .......................................................................................................................................... 13

Report Types/Definitions.................................................................................................. 13

Help Menu .................................................................................................................... 13

D3651US-D

Diet Manager

Introduction

Welcome to the Diet Manager Set-up and User Guide”. Diet Manager is a software program designed
to easily utilize the EZ3500 Indicator and DataKey™ to track and record recipe loading and feeding. Diet
Manager allows you to set up specific recipes and pen deliveries for your herd. The program tracks and
records each step in the process including tracking each individual operator. The program outputs the
completed loading and feeding data into over 10 easy to read reports with selectable date ranges. This
provides you with the valuable data required to optimize your feeding system on a cost/production basis.

The program is Windows based to allow you to get up and running quickly and start understanding and
controlling your feeding costs.

Diet Manager includes:

1. Software on Compact Disk

2. Data Key Docking Station with Cable

3. Manual and Documents

Minimum System Requirements

Make certain that your PC includes the following hardware and software. These are the minimum system

requirements to run Diet Manager.

• A Pentium 100 or better PC

• Microsoft Windows XP Service Pack 2 or greater

• Adobe Acrobat Reader

• 100 Meg Free disk space

• 32 Meg Ram

• CD Drive

• A mouse

• A serial port

• Printer

• 28.8 modem

• Internet Service Provider

A USB to Serial Port adapter can be used if your PC does not have a free serial port. The serial port must
be assigned to a port number 1 to 8. A higher comm. port setting will not work with the Diet Manager
program.

Note: Certain programs can interfere with the operation of the serial port / Diet Manager. These programs

include Palm Desktop and some auto ID systems and milk monitoring programs. If these programs are
installed and running on the PC you intend to use for the Diet Manager system, they must be shut off
when reading / writing to the DataKey™. Failure to shut these programs off during this sequence may
result in errors and lost data.

D3651US-D 1

Set-up and User Guide

System Setup

Connect the DataKey™ Docking Station

The DataKey™ Docking Station is the interface device for the DataKey™. This device must be connected to
the computer running the Diet Manager software.

Note: The DataKey™ is not need to operate the Diet Manager Software unless you are sending feeding data to the

DataKey™ or running the software for the first time.

To connect the device:

1. Connect the 9-pin connector to the serial 9-pin connector on the computer that will be running

the Diet Manager software.

2. Plug the power supply into an 115v/230v outlet. The power light on the DataKey™ Docking

Station should be ON.

3. Insert the DataKey™ into the slot on the front of the DataKey™ Docking Station.

Install Diet Manager

Read the Digi-Star License Agreement on the sheet accompanying the software and this manual. When
you break the seal on the CD, and install the software, you agree to the terms of the license agreement.
The Diet Manager software is shipped to you on a CD. To install the software, please close all other open
programs. Insert the CD into the drive. On Windows XPTM operating systems, you must log on as
administrator. If Auto Run is enabled on your computer, follow the installation instructions.
If the installation screen does not appear, go to Start and select Run. From the Run menu, browse the CD
and select setup.exe. The install screen will now appear. Follow the installation instructions.

Install, connect and power On the DataKey™ Docking Station and Insert the DataKey™ before attempting

to start the Diet Manager software. Failure to do so will result in an error during the initial phase of the
software setup.



Software

Select the program Language

After installation of the software, the first time that the Diet Manager™ program is
started, the Language Selection box will appear.

Note: The Language Selection can be changed at any time after initial setup.

To select a language from the list, click on the desired language
and click Ok to save your selection. The language selection can
be changed from within the Diet Manager™ program by selecting
System, Language from the main menu.

Data Transfer Type for the EZ3500 and EZ4300

Data sent to the EZ3500 and EZ4300 can be sent in three
formats:

Standard Batch Type: Each load is built by the PC
software. It assigns pens to a recipe and builds an exact
load for the pens.
Loads are built and delivered by pressing [Recipe] only.

List Feed Type: The PC software sends the recipe data and
the pen data in two different fields. The operator selects the
recipe to build and which pens will be delivered.

Press [Recipe] to select a recipe list or press [Pens] to select
the pens list.

08/31/05 2
