DENON DBP-2012UDC User Manual

Simple version

Version simpliﬁée

Versión sencilla

UNIVERSAL AUDIO/VIDEO PLAYER

DBP-2012UDCI

Owner’s Manual Manuel de l’Utilisateur Manual del usuario

Basic version

Advanced version

Version basique Versión básica

Version avancée

Versión avanzada

Information

“Part names and functions” (vpage44)

Informations

“Nomenclature et fonctions“ (vpage 44)

Información

“Nombres y funciones de las piezas“ (vpágina 44)

SAFETY PRECAUTIONS

IMPORTANT SAFETY

FRANCAISESPAÑOL ENGLISH

FCC INFORMATION (For US customers)

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning ﬂash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufﬁcient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION:

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. THIS PRODUCT SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE EXCEPT PROPERLY QUALIFIED SERVICE PERSONNEL

Laser Class (IEC 60825-1:2001)

CLASS 1

LASER

PRODUCT

INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not ﬁt into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories speciﬁed by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table speciﬁed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

Refer all servicing to qualiﬁed service personnel.

14. is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15. Batteries shall not be exposed to excessive heat such as sunshine, ﬁre or the like.

CAUTION:

To completely disconnect this product from the mains, disconnect the plug from the wall socket outlet. The mains plug is used to completely interrupt the power supply to the unit and must be within easy access by the user.

PRECAUTION:

Pour déconnecter complètement ce produit du courant secteur, débranchez la prise de la prise murale. La prise secteur est utilisée pour couper complètement l’alimentation de l’appareil et l’utilisateur doit pouvoir y accéder facilement.

PRECAUCIÓN:

Para desconectar completamente este producto de la alimentación eléctrica, desconecte el enchufe del enchufe de la pared. El enchufe de la alimentación eléctrica se utiliza para interrumpir por completo el suministro de alimentación eléctrica a la unidad y debe de encontrarse en un lugar al que el usuario tenga fácil acceso.

Servicing

1. COMPIANCE INFORMATION

Product Name: Universal Audio / Video player Model Number: DBP-2012UDCI This product complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) this product may not cause harmful interference, and (2) this product must accept any interference received,

including interference that may cause undesired operation. Denon Electronics (USA), LLC (a D & M Holdings Company) 100 Corporate Drive Mahwah, NJ 07430-2041 Tel. (800) 497-8921

2. IMPORTANT NOTICE: DO NOT MODIFY THIS PRODUCT

This product, when installed as indicated in the instructions contained

in this manual, meets FCC requirements. Modiﬁcation not expressly

approved by DENON may void your authority, granted by the FCC, to use

the product.

3. NOTE

This product has been tested and found to comply with the limits for

a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This product generates, uses and can radiate radio frequency energy and,

if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

product does cause harmful interference to radio or television reception,

which can be determined by turning the product OFF and ON, the user

is encouraged to try to correct the interference by one or more of the

following measures:

•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connect the product into an outlet on a circuit different from that to

which the receiver is connected.

•Consultthelocalretailerauthorizedtodistributethistypeofproductor

an experienced radio/TV technician for help.

For Canadian customers:

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

ENGLISH

FRANCAIS

ESPAÑOL

NOTES ON USE / OBSERVATIONS RELATIVES A L’UTILISATION / NOTAS SOBRE EL USO

WARNINGS AVERTISSEMENTS ADVERTENCIAS

•Avoid high temperatures. Allow for sufﬁcient heat dispersion when installed in a rack.

•Handle the power cord carefully. Hold the plug when unplugging the cord.

•Keep the unit free from moisture, water, and dust.

•Unplug the power cord when not using the unit for long periods of time.

•Do not obstruct the ventilation holes.

•Do not let foreign objects into the unit.

•Do not let insecticides, benzene, and thinner

come in contact with the unit.

•Never disassemble or modify the unit in any way.

•Ventilation should not be impeded by covering

the ventilation openings with items, such as newspapers, tablecloths or curtains.

•Naked ﬂame sources such as lighted candles should not be placed on the unit.

•Observe and follow local regulations regarding battery disposal.

•Do not expose the unit to dripping or splashing ﬂuids.

•Do not place objects ﬁlled with liquids, such as vases, on the unit.

•Do not handle the mains cord with wet hands.

•When the switch is in the OFF position, the

equipment is not completely switched off from MAINS.

•The equipment shall be installed near the power supply so that the power supply is easily accessible.

•Eviter des températures élevées. Tenir compte d’une dispersion de chaleur sufﬁsante lors de l’installation sur une étagère.

•Manipuler le cordon d’alimentation avec précaution. Tenir la prise lors du débranchement du cordon.

•Protéger l’appareil contre l’humidité, l’eau et la poussière.

•Débrancher le cordon d’alimentation lorsque l’appareil n’est pas utilisé pendant de longues périodes.

•Ne pas obstruer les trous d’aération.

•Ne pas laisser des objets étrangers dans

l’appareil.

•Ne pas mettre en contact des insecticides, du benzène et un diluant avec l’appareil.

•Ne jamais démonter ou modiﬁer l’appareil d’une manière ou d’une autre.

•Ne pas recouvrir les oriﬁces de ventilation avec des objets tels que des journaux, nappes ou rideaux. Cela entraverait la ventilation.

•Ne jamais placer de ﬂamme nue sur l’appareil, notamment des bougies allumées.

•Veillez à respecter les lois en vigueur lorsque vous jetez les piles usagées.

•L’appareil ne doit pas être exposé à l’eau ou à l’humidité.

•Ne pas poser d’objet contenant du liquide, par exemple un vase, sur l’appareil.

•Ne pas manipuler le cordon d’alimentation avec les mains mouillées.

•Lorsque l’interrupteur est sur la position OFF, l’appareil n’est pas complètement déconnecté du SECTEUR (MAINS).

•L’appareil sera installé près de la source d’alimentation, de sorte que cette dernière soit facilement accessible.

•Evite altas temperaturas. Permite la suﬁciente dispersión del calor cuando está instalado en la consola.

•Maneje el cordón de energía con cuidado. Sostenga el enchufe cuando desconecte el cordón de energía.

•Mantenga el equipo libre de humedad, agua y polvo.

•Desconecte el cordón de energía cuando no utilice el equipo por mucho tiempo.

•No obstruya los oriﬁcios de ventilación.

•No deje objetos extraños dentro del equipo.

•No permita el contacto de insecticidas, gasolina

y diluyentes con el equipo.

•Nunca desarme o modiﬁque el equipo de ninguna manera.

•La ventilación no debe quedar obstruida por haberse cubierto las aperturas con objetos como periódicos, manteles o cortinas.

•No deberán colocarse sobre el aparato fuentes inﬂamables sin protección, como velas encendidas

•A la hora de deshacerse de las pilas, respete la normativa para el cuidado del medio ambiente.

•No exponer el aparato al goteo o salpicaduras cuando se utilice.

•No colocar sobre el aparato objetos llenos de líquido, como jarros.

•No maneje el cable de alimentación con las manos mojadas.

•Cuando el interruptor está en la posición OFF, el equipo no está completamente desconectado de la alimentación MAINS.

•El equipo se instalará cerca de la fuente de alimentación de manera que resulte fácil acceder a ella.

n CAUTIONS ON INSTALLATION PRÉCAUTIONS D’INSTALLATION EMPLAZAMIENTO DE LA INSTALACIÓN

z z

Wall Paroi Pared

z For proper heat dispersal, do not install this unit in a conﬁned

space, such as a bookcase or similar enclosure.

•More than 0.1 m (4 in.) is recommended.

•Do not place any other equipment on this unit.

z Pour permettre la dissipation de chaleur requise, n’installez

pas cette unité dans un espace conﬁné tel qu’une bibliothèque ou un endroit similaire.

•Une distance de plus de 0.1 m (4 po) est recommandée.

•Ne placez aucun matériel sur cet appareil.

z Para la dispersión del calor adecuadamente, no instale este

equipo en un lugar conﬁnado tal como una librería o unidad similar.

•Se recomienda dejar más de 0.1 m (4 pulg.) alrededor.

•No coloque ningún otro equipo sobre la unidad.

Getting started

Thank you for purchasing this DENON product. To ensure proper operation, please read these owner’s manual carefully before using the product. After reading them, be sure to keep them for future reference.

ENGLISH

Contents

Getting started ·············································································· 1

Accessories ··················································································1 About this manual ·········································································1 Features ························································································2 Cautions on handling ····································································3 Cautions on handling for 3D video ················································3

Simple version (Simple setup guide) ··························4

Basic version ············································································9

Basic connections ·······································································10

Important information ·································································10 Connecting an AV receiver ·························································10 Connecting a TV··········································································13 Connecting a 2-channel audio ampliﬁer ······································14 Connecting to a digital recording device ·····································15

Playback (Basic operation) ························································· 16

About playback information ························································ 16 Playing BD and DVD-Video ························································· 17 Playing Super Audio CD ······························································18 Playing CD ··················································································19 Playing DVD-Audio ······································································19 Operations enabled during playback ···········································20

Basic settings ·············································································24

Changing the brightness of the display (Dimmer control) ················24 Playing high-quality audio (Pure direct function) ························· 24 HDMI control functions ······························································24 Video resolution ··········································································25 Adjusting the picture quality (Picture control) ·····························26 Mode setting ··············································································27

Advanced version ·······························································28

Advanced connections ·······························································29

Connecting to a USB memory device ········································· 29 Connecting to a network ····························································29

Playback (Advanced operation) ················································· 31

Home menu screen ···································································31

How to make detailed settings ··················································35

Menu map ··················································································35 GUI menu operation ···································································36 General Setting ···········································································37 Video Setting ··············································································40 Audio Setting ·············································································· 41 System Information ···································································· 42

Information ·············································································43

Part names and functions···························································44

Front panel ··················································································44 Display ························································································ 44 Rear panel ···················································································45 Remote control ···········································································46

About media ················································································ 48

Playable media ············································································48 Cautions on using media ····························································51

Other information ·······································································52

About digital signal audio output ················································· 52 Trademark information ································································ 53 Explanation of Terms ··································································54

Troubleshooting ··········································································56 Speciﬁcations ··············································································59

Accessories

Check that the following parts are supplied with the product.

q Owner’s manual ...................................................................... 1

w Warranty (for North America model only) ................................1

e Service station list ...................................................................1

r Power cord (Cord length: Approx. 6.6ft / 2.0 m) ..................... 1

t Remote control (RC-1151) ....................................................... 1

y R6/AA batteries .......................................................................2

u Audio and Video cable (Cord length: Approx. 4.9 ft / 1.5 m) ... 1

t ur

About this manual

n Operation buttons

The operations described in this manual are based mainly on use of the remote control buttons.

n Symbols

NOTE

This symbol indicates a reference page on which related information is described.

This symbol indicates a supplementary information and tips for operations.

This symbol indicates points to remember operations or function limitations.

Basic version Advanced versionSimple version Information

n Illustrations

Note that the illustrations in these instructions may differ from the actual unit for explanation purposes.

ENGLISH

Features

A Universal Audio/Video player that plays Super Audio CD and DVD-Audio formats

The unit supports a variety of media and enables video and audio playback of your disc libraries with high quality (vpage48 “Playable media”).

Supporting the Network operations

•When the unit is connected to the Internet, Netﬂix and YouTube service can be used.

•Music, photos, video ﬁles stored on the device connected via the network can be played.

•When the unit is connected to the Internet, privileged video can be downloaded from the Internet site to the built-in memory to enjoy BD-LIVE™ (vpage29 “Connecting to a network”).

3D video playback

When the unit is connected to a 3D enabled TV with a high speed HDMI cable, you can enjoy 3D video.

Direct Mechanical Ground Construction, supporting high-quality HD sound and video by suppressing vibration

The disc mechanism that causes vibration is arranged at the center of the unit to transmit vibration out through the base, enabling video and audio playback of high quality.

High-bit video processor to reproduce beautiful and colorful images

GUI equipped for good operability and visibility

This unit is equipped with an easy to see “Graphical User Interface” that uses menu displays and levels. The use of level displays increases operability of the this unit (vpage 36 “GUI menu operation”).

HDMI control

By connecting a television or AV receiver that supports the HDMI control function to this unit using an HDMI cable, and enabling the HDMI control settings on each device, you can control other devices from one device (vpage24 “HDMI control functions”).

Independent Block Construction for playing video and audio signals with high ﬁdelity

The electronic circuits are separated to prevent electronic and electromagnetic noise caused by various electronic signals in the unit.

A high-grade and high-bit i/p scaler for enjoying sensitive and colorful video

•The i/p scaler, which improves resolution of interlace materials, supports SD (Standard Deﬁnition) video as well as HD (High Deﬁnition) video. Sensitive and beautiful images are available when a BD or DVD is played.

ENGLISH

Cautions on handling

•Before turning the power switch on

Check once again that all connections are correct and that there are no problems with the connection cables.

•Power is supplied to some of the circuitry even when the unit is set to the standby mode. When leaving home for long periods of time, be sure to unplug the power cord from the power outlet.

•Image persistence (image burn-in)

Do not leave still images of the disc menu, the unit menu, etc., displayed on the TV screen for long periods. This can result in image persistence (image burn-in) on the screen.

•About condensation

If there is a major difference in temperature between the inside of the unit and the surroundings, condensation (dew) may form on the operating parts inside the unit, causing the unit not to operate properly. If this happens, let the unit sit for an hour or two with the power turned off and wait until there is little difference in temperature before using the unit.

•Cautions on using mobile phones

Using a mobile phone near this unit may result in noise. If that occurs, move the mobile phone away from the unit when it is in use.

•Moving the unit

Be sure to remove a disc, turn off the power and unplug the power cord from the power outlet. Next, disconnect the connection cables to other system equipment before moving the unit.

•About Care

•Wipe the cabinet and control panel clean with a soft cloth.

•Follow the instructions when using a chemical cleaner.

•Benzene, paint thinner or other organic solvents, as well as insecticide, may cause material changes

and discoloration if brought into contact with the unit, and should, therefore, not be used.

•Sufﬁciently ventilate the place of installation

If the unit is left in a room full of the smoke from cigarettes, etc., for long periods of time, the surface of the optical pickup could get dirty, in which case it will not be able to read the signals properly.

Cautions on handling for 3D video

Before viewing 3D video, refer to the considerations described in the instruction manuals and other documents for your 3D enabled TV and 3D compatible glasses together with this manual.

•Do not view 3D video if you have epilepsy or heart disease, if you have had photosensitivity reactions before, or when you do not feel well.

Doing so may aggravate the symptoms.

•When you view 3D movies, etc., take a break adequately, once per movie as a guide.

Prolonged viewing of 3D video may cause eye strain.

•Restrict viewing of 3D video to those aged six and over as a guide.

Children do not respond to tiredness and discomfort expressly, so they may suddenly get sick. When children view 3D video, parents should keep their eyes open for signs of eye strain in children.

•Stop viewing 3D video when you see double images or you can not see 3D effects.

Viewing 3D video continuously in these conditions may cause eye strain.

•Stop viewing 3D video when you feel something wrong, get tired, or get sick.

Viewing 3D video continuously in these conditions may cause poor physical condition. Take a proper break.

•Pay attention to nearby people and objects.

Reaching for something without a sense of distance due to 3D video or moving your body suddenly in response to a 3D video image when you take it for a real object may cause injury to nearby people or

cause damages to nearby objects resulting in injury. Keep fragile objects away from your viewing area.

•Wear your vision correction glasses or contact lens under the 3D glasses if you have nearsightedness, farsightedness, anisometropia, or astigmatism.

Viewing 3D video without correcting your vision may cause eye strain or decreased vision.

•Sit at a proper distance from the screen when you view 3D video.

Sitting too close to the screen may cause eye strain or decreased vision. Sit at a distance that is recommended in the instruction manual for your TV.

Basic version Advanced version InformationSimple version

ENGLISH

Simple version

This section brieﬂy describes the procedures from connecting this unit and a television or AV receiver, using an HDMI cable, to start playback after unpacking.

n Before connecting the unit, turn off the power to all devices. n For operation of the connected devices, refer to the user manuals for each device.

Simple version (Simple setup guide)

Connect

(vpage5)

Connect this unit and a television or an AV receiver using an HDMI cable.

Turn on power

(vpage6)

Set up the audio

Press MODE to set up audio.

(vpage7)

Play back disc

(vpage8)

Enjoy Blu-ray Disc and DVD.

ENGLISH

Connect

1 2 3 4

This section describes two methods for connecting this unit and a television, connecting directly or via an AV receiver. Use an appropriate method depending on the television to be used. For the connection, use an HDMI cable (sold separately).

•If the device to be connected to the unit does not support the HDMI connection, see “Basic connections” (vpage10), and make connections depending upon the conditions.

•Use only HDMI (High Deﬁnition Multimedia Interface) cable that bears the HDMI logo (genuine HDMI product). Using cable without the HDMI logo (non-genuine HDMI product) may result in abnormal playback.

•When outputting Deep Color or 1080p, etc., we recommend you use “High Speed HDMI cable” or “High Speed HDMI cable with Ethernet” for enhanced high-quality playback.

TV AV receiver and TV

This method is for connecting the unit and a television directly. This method is for connecting the unit to an AV receiver.

HDMI

AV receiver

HDMI

OUT

HDMI

Basic version Advanced version InformationSimple version

HDMI cable (sold separately)

FL FR

SBL SBR

FL Front speaker (L) FR Front speaker (R) C Center speaker SW Subwoofer SL Surround speaker (L) SR Surround speaker (R) SBL Surround back speaker (L) SBR Surround back speaker (R)

HDMI

HDMI cable (sold separately)

ENGLISH

Connect

Power cord

Connect the supplied power cord to the unit, and plug it into an AC outlet.

To household power outlet

(AC 120 V, 60 Hz)

Power cord (supplied)

NOTE

•Be sure to insert the power plug ﬁrmly. Incomplete connection results in noise.

•Do not plug in the power cord until all connections have been completed.

•Do not bundle power cords together with connection cables. Doing so can result in humming or noise.

Turn on power

Turn on the power of the TV and AV receiver.

Turn on power

Set the TV and AV receiver source to the unit input.

Press POWER ON to turn on power to the unit.

•The power indicator ﬂashes green and the power turns on.

•Then the power indicator remains lit in green.

Turn on power

•“LOADING” appears on the display, and disc information is read.

•The “NO DISC” message is displayed if a disc is not loaded.

1 2 3 4

Turn on power

Before using a remote control, insert the batteries (vpage47 “Inserting the batteries”).

ENGLISH

1 2 3 4

Set up the audio (HD Audio Setup)

An audio format recorded on a Blu-ray Disc is an HD Audio (High Deﬁnition Audio) format, such as Dolby TrueHD, Dolby Digital Plus, DTS-HD, etc. For playing back audio of an HD Audio format, the AV receiver to which the unit is to be connected must support HD Audio playback. This section describes the setting for audio output depending on the AV receiver to be connected, outputting the Audio format as-is or converting to normal digital audio.

Press 5.

The disc tray opens.

Place the disc on the disc tray with the label side up.

Press MODE.

Displays a menu of items that can be set.

BDMV

HD Audio Output

HDMI/Com ponent

Off

PIP

BD Audio Mode

Use u i to select “BD Audio Mode”, then press ENTER or p.

HD Audio Output

Use u i to select “HD Audio Output” or “Mix Audio Output”, then press ENTER.

Basic version Advanced version InformationSimple version

Press 5.

The disc tray closes, and playback of the disc begins.

NOTE

•Do not push the disc tray in by hand. It may damage the player.

•Some discs require pressing 1 to start playback. In this case, press 1 to start playback.

Setting the audio during playback.

For listening to a BD disc with high quality

Set “BD Audio Mode” to “HD Audio Output”.

•HD audio of a BD disc is output from the unit.

•Only main audio of HD audio is output.

•Before connecting the unit to an AV receiver, check that the receiver supports HD audio playback. If it

does not, the unit outputs the signal converted to LPCM from the HDMI output terminal. HD audio is not output.

For listening to subaudio of a BD disc (interactive audio or secondary audio)

Set “BD Audio Mode” to ”Mix Audio Output”.

•When the unit plays a BD, HD Audio of the BD is converted to normal digital audio and output.

Speciﬁcations of interactive audio or secondary audio differ depending on the Blu-ray Disc. For details, refer to the package or operation manual supplied with the Blu-ray Disc.

ENGLISH

Play back disc

Press TOP MENU or MENU.

The menu stored on the disc is displayed.

Select the playback title or chapter from the top

menu for playback.

Playback

Top menu Pop up menu

Select Playback

GExampleH

n Disc menu

DiscMenus

Subtitle

AudioSetup

n Top menu

Title1 Topmenu

n Pop up menu

Popupmenu

Chapter2

Chapter3

Chapter4

Chapter5

Chapter6

Ifyouhaveso methingtosa y,seethispict urebeforeyou

Title1 Title2 Bonustitle

1 2 3 4

When power is switched to standby

Press either POWER OFF on the remote control, or ON/STANDBY on the unit.

•The power indicator ﬂashes in green. Then the indicator lights in red and the power is turned off.

GPower indicator status in standby modeH

•Power Saving Standby : Off

•Normal Standby : Red

When “Auto Power Mode” is “On” (vpage 37), the following states are maintained for about 30 minutes, and then the power is automatically turned to standby.

•Disc not loaded

•Playback has stopped

•Stopped due to resume function

NOTE

During power standby, a slight amount of power is consumed. To totally cut off the power, remove the power cord from the power outlet.

Angle

SubStory

TopMenu

Basic version

This section describes the operations for enjoying video and audio on a disc.

F Basic connections vpage10 F Playback (Basic operation) vpage16 F Basic settings vpage24

ENGLISH

Advanced version InformationBasic versionSimple version

n Refer to the pages indicated below for information on connecting and playing back the various

media and external devices.

Audio and video

BD / DVD-Video DVD-Audio

Super Audio CD CD

vpage 10 – 15 vpage 17 vpage 10 – 15 vpage 19

Audio

vpage 10 – 15 vpage 18 vpage 10 – 15 vpage 19

PlaybackConnection

ENGLISH

Basic connections

Important information

•Connect this unit as follows before using. Make connections according to the equipment you are connecting.

•Some settings of this unit may be necessary depending on the connection method. Check each connection item for more information.

•Select the cables (sold separately) according to the components being connected.

NOTE

•Do not plug in the power cord until all connections have been completed.

•When making connections, also refer to the operating instructions of the other components being

connected.

•Be sure to connect the left and right channels properly (left with left, right with right).

•Do not bundle power cords together with connection cables. Doing so can result in noise.

Connecting an AV receiver

For connecting using an HDMI cable, see “Connect” (vpage5). This section describes the connections not using an HDMI cable.

Connecting to an AV receiver with an analog multi-channel audio input terminal

•This connection is recommended when the speciﬁcations of an AV Receiver connected to the unit are as follows:

•Not supporting HDMI input

•Not supporting digital audio(coaxial) input

•This connection enables decoding a playback signal of HD Audio on a Blu-ray Disc to an analog multi-

channel signals with this unit and playing back of all channels on the Disc, including surround back channel signals, with high ﬁdelity.

Cables used for connections

AV Receiver

AUDIO

FRONT

SUBWOOFER

CENTER

SURROUND

L L

R R

SURROUND BACK

L L

R R

VIDEO

VIDEO IN

COMPONENT

VIDEO IN

L L

R R

In the case of a 5.1-channel connection, you do not need to connect the SBR/SBL terminals. Set “Speaker Setting“ – ”Conﬁguration” to “5.1ch“ (vpage42).

Audio and Video cable

Audio cable (center, subwoofer) (Sold separately)

Component video cable (Sold separately)

Audio and Video cable

(White)

(Red)

(Yellow)

Audio cable

Video cable

(Green)

(Blue)

(Red)

Connecting to an AV receiver with an analog 2-channel audio input terminal

•This connection is recommended when the speciﬁcations of an AV receiver connected to the unit are as follows:

•Not supporting HDMI input

•Not supporting digital audio(coaxial) input

•Select the connector to use and connect the device.

Cables used for connections

AV receiver

AUDIO

VIDEO

VIDEO IN

L L

ENGLISH

Connecting an AV receiver

Audio and video cable (supplied)

Component video cable (sold separately)

Audio and video cable

(White)

(Red)

(Yellow)

Video cable

(Green)

(Blue)

(Red)

COMPONENT

VIDEO IN

Advanced versionSimple version InformationBasic version

ENGLISH

Connecting to an AV receiver with a digital audio input terminal

•This connection is recommended when the speciﬁcations of an AV receiver connected to the unit are as follows:

•Not supporting HDMI input

•Supporting digital audio(coaxial) input

•This connection enables faithfully playing a disc that supports 5.1-channel output.

•Select the connector to use and connect the device.

Cables used for connections

Audio cable

Coaxial digital cable (sold separately)

Audio and video cable (supplied)

Component video cable (sold separately)

(Black)

Audio and video cable

(White)

(Red)

(Yellow)

Video cable

(Green)

(Blue)

(Red)

AV receiver

AUDIO

COAXIAL

VIDEO

VIDEO IN

COMPONENT

VIDEO IN

Connecting an AV receiver

L L

R R

When playing back Dolby Digital Plus/Dolby TrueHD/DTS-HD audio recorded on a BD disc, this unit outputs Dolby Digital or DTS bitstream from its digital audio output terminal.

NOTE

•Dolby TrueHD/Dolby Digital Plus/DTS-HD audio signals are not output with this connection. When outputting Dolby TrueHD/Dolby Digital Plus/DTS-HD audio signals, do so with an HDMI connection (vpage5).

•Super Audio CD’s DSD signal cannot be output. Also, during CD layer playback, 44.1 kHz/16-bit Linear PCM is output.

•Do not output DTS audio signals to an AV receiver that does not support DTS. Playing back a BD/DVD disc with recorded DTS content can generate noise and even damage your speakers.

Connecting a TV

•This connection is to connect the unit and a television directly.

•Check the television’s audio and video terminals and connect to one of them.

Cables used for connections

Audio and video cable

HDMI cable (sold separately)

Audio and video cable (supplied)

Component video cable (sold separately)

(White)

(Red)

(Yellow)

(Green)

(Blue)

(Red)

Video cable

ENGLISH

NOTE

•Do not connect this unit’s video output via a VCR (Video Cassette Recorder). Some media contain copy prohibiting signals, which will disturb the screen image.

•The unit can play both NTSC and PAL discs.

n When connected to the television’s component video input terminal

Press

RESOLUTION

connected television

•This unit’s component video output supports 480i/576i/480p/576p/720p/1080i output .

•Images will not be projected normally if the television resolution and this unit’s output resolution do not match.

•Copyright protected DVD is output in 480i/576i or 480p/576p.

according to the resolution of the

(vpage 25).

TV TV

HDMI

COMPONENT VIDEO

Y P

VIDEO

B PR

VIDEO

AUDIO

R R

Advanced versionSimple version InformationBasic version

n Connecting to a device equipped with a DVI-D connector

Use an HDMI DVI-D conversion cable.

•The audio signal is not output. Make the appropriate audio connections for your devices.

•The video signal will be in RGB format.

•You cannot output to a DVI-D device that does not support HDCP (high-bandwidth digital content

•Video may not be output depending on the combination of devices.

ENGLISH

Connecting a 2-channel audio ampliﬁer

This connection is for playback of audio of this unit, using a 2-channel audio device. Connect to either the 2ch Audio Out terminals or 7.1ch Audio Out terminals of this unit.

For software recorded in multi-channel, an analog signal down-mixed to 2-channel is output.

Cables used for connections

Audio and video cable

Audio and video cable (supplied)

(White)

(Red)

(Yellow)

Ampliﬁer

AUDIO

L L

Connecting to a device with analog 2-channel audio input terminals (7.1ch Audio OUT)

If the analog 7.1ch audio output terminals are to be used as the 2-channel output terminals, make this connection.

Ampliﬁer

AUDIO

After connection, make settings for output of 2-channel audio from the 7.1ch Audio Output terminals. Set “Speaker Setting“ – ”Conﬁguration” to “2.1ch“ (vpage42).

Connecting to a digital recording device

This connection is for recording audio from this unit, using an audio device with coaxial digital audio input

terminals.

Cables used for connections

Audio cable

Coaxial digital cable (sold separately)

Recorder

AUDIO

COAXIAL

(Black)

ENGLISH

Advanced versionSimple version InformationBasic version

When multi-channel audio is to be converted to 2-channel audio and output, change the setting for a connected Coaxial digital output to PCM from Bitstream, then make the setting for the sampling rate for

digital audio output, depending on the device (vpage41 “Down Sampling”).

NOTE

If you play back BD/DVD or other media with an incorrect conﬁguration, a deafening noise occurs that may damage your speakers.

ENGLISH

Playback (Basic operation)

This section describes the display screen for each media and the procedures for playback.

The icons show the category of content applicable to each operation.

Video : Blu-ray Disc, DVD-Video, DivX plus HD,

MPEG, AVI, WMV, AVCHD

Audio : Super Audio CD, CD, DVD-Audio, MP3,

WMA, AAC, LPCM

Photo : JPEG

n About playback information (vpage16) n Playing BD and DVD-Video (vpage17) n Playing Super Audio CD (vpage18) n Playing CD (vpage19) n Playing DVD-Audio (vpage19)

Operations enabled during playback (vpage20)

Basic settings (vpage24)

NOTE

•The symbol (prohibited mark) may appear on the top left of the TV screen during an operation. This means that the operation being conducted is prohibited.

•Depending on the disc, certain operations may not be as described in this manual. Check each disc owner’s manual for more information.

•During playback of a 2-layered disc, pictures may stop momentarily. This happens when the 1st layer switches to the 2nd layer. This is not a malfunction.

About playback information

Press DISPLAY to display the information bar display or media player display.

•To close the display, press DISPLAY until it goes away.

•Displayed content differs depending on the media being played.

Also, the information displayed while playing and stopped differs.

Information bar display

This screen is displayed when video data such as on a Blu-ray Disc, DVD-Video, etc. are played.

q w e r t

HDMVHDMV

1/2 Englis h

VC-1

DTS-HD MA 7.1 YCbCr / 1080i

13 / 16 1 / 21

q Playback information

•Play (1)

•Stop (2)

•Pause (3)

•Reverse Skip (8) / Forward Skip (9)

•Fast Reverse (6) / Fast Forward (7)

•Slow Reverse (

) / Slow Forward (

w Video format display e Title / Group display r Chapter / Track display t Time display

•Title Elapsed / Remain time

•Chapter Elapsed / Remain time

•Group Elapsed / Remain time

•Track Elapsed / Remain time

y Audio format display u HDMI output signal display

(When the connected HDMI device)

2 1

00 : 00 : 16

)

Media player display

This screen is displayed when audio data is played.

q Playback information

•Play (1)

•Stop (2)

•Pause (3)

•Reverse Skip (8) / Forward Skip (9)

•Fast Reverse (6) / Fast Forward (7)

•Slow Reverse (

w Media information

•Type　

•Total Time

•Title

•Artist

•Album

•Genre

•Artwork

1 / 31

Type: Total Time: Title: Artist: Album: Genre:

) / Slow Forward (

MP3 04:10 ABACAB GENESIS

2 1

00 : 00 : 16

)

The icons show the category of

content applicable to each operation.

Video Audio Photo

For details of the media corresponding to each icon, see “Playable media” (vpage48).

Playing BD and DVD-Video

ENGLISH

Press POWER ON to turn on

power to the unit.

Press SOURCE on the unit to

select “DISC MODE”. Select “BD ” with DISC

•The Media changes each time DISC

LAYER

Multi

Video

LAYER

is pressed for 2 seconds.

Multi Video BD

Super Audio CD

DVD-Audio

Hybrid BD

Select “BD layer” or “DVD

layer” for DISC LAYER for playback of a hybrid BD disc (vpage 50).

Plays the BD layer of the BD hybrid disc.

DVD Plays the DVD layer of the BD hybrid disc.

•The above setting is necessary only for BD hybrid discs.

NOTE

Select the disc layer before a disc is inserted.

Make the settings shown below on the disc menu.

•Subtitle language

•Audio language

•Audio format etc.

GExampleH

n Disc menu

DiscMenus

Subtitle

AudioSetup

Angle

SubStory

TopMenu

n Top menu

Title1 Topmenu

Chapter2

Chapter3

Chapter4

Chapter5

Chapter6

n Pausing (vpage20) n Stopping (vpage20) n Skipping to a desired chapter/track/ﬁle (vpage20) n Fast-forward/fast-reverse (vpage20) n Finding speciﬁc sections with search modes (vpage21) n Memorizing locations to replay (Marker function)

(vpage21)

n Playing repeatedly (Repeat playback) (vpage22) n Playing repeatedly between speciﬁed points (A-B repeat)

(vpage22) n Playing images frame by frame (vpage22) n Slow-forward/slow-reverse (vpage22) n Switching primary audio (vpage22) n Changing the primary subtitle (vpage23) n Switching the angle (vpage23)

Advanced versionSimple version InformationBasic version

Insert a disc.

Press 5 to open/close the disc tray.

Press 1 .

Playback begins.

During DVD-Video playback, press TOP MENU or

POP UP MENU to display the menu.

•If the menu continues, press uio p to get to the next part.

•With BD, depending on the disc, you can select title and chapter

from the pop up menu.

The icons show the category of

content applicable to each operation.

Video Audio Photo

n Pop up menu

Popupmenu

Title1 Title2 Bonustitle

Ifyouhaveso methingtosa y,seethispict urebeforeyou

For details of the media corresponding to each icon, see “Playable media” (vpage48).

ENGLISH

Playing BD-Video compatible with Bonus View

With a disc that is compatible with bonus view (picture-in-picture), in addition to the main video (primary video) stored on the disc, you can play back the video director’s commentary and simultaneously ongoing sub-story, as well as sub-video such as alternative camera angles (secondary video).

Main video (primary video)

Sub video (secondary video)

GExampleH Bonus view

Press MODE (vpage 27).

Use ui to select “Secondary

Video”, and then press ENTER or p.

Use ui to select the desired secondary video.

Off 1/X 2/X X/X

Off Does not display Secondary Video.

1/X Displays the ﬁrst Secondary Video.

2/X Displays the second Secondary Video.

X/X Displays the X th Secondary Video.

•“X” is the number of Secondary Videos recorded and differs depending on the disc.

•For using Bonus View, some BD discs require built-in memory or external memory.

•The unit has a built-in memory. If capacity of more than 1 GB is required, using a USB memory device of 1 GB or more is recommended.

•The playback method, etc., is determined by the disc, and varies depending on the disc. Refer to the operation guide of the relevant disc.

Playing BD and DVD-Video

Enjoying BD-LIVE™

If the unit is connected to the Internet environment, you can enjoy a BD-LIVE™ function, using a disc that supports BD-LIVE™. For details on functions and operations of BD-LIVE™, see the information displayed on the screen after inserting a BD-LIVE™ disc.

Select “Internal” of “BD Data Utility” – “BD-Live

Memory” (vpage 37).

Check that the connection and settings for the

Internet are completed (vpage 38 “Connection Test”).

Insert a Blu-ray Disc that supports BD-LIVE™ into

the unit.

Select “BD-LIVE™” from the Disc menu.

•When BD-LIVE™ is used, the downloaded contents are stored in the built-in memory of the unit.

•The unit has a built-in memory. If capacity of more than 1 GB is required, using a USB memory device of 1 GB or more is recommended.

•Depending on your network environment, it may take time to connect to the network or connection may not be possible.

NOTE

•For using a USB memory device, set “BD Data Utility” – “BD-Live Memory” to “External” (vpage37).

•The USB memory device must have been initialized (vpage37 “BD Data Utility” – “BD Data Information”).

•Insert or remove a USB memory device while the power is in standby. If you insert a USB memory device while the power is ON, the USB memory device may not be access.

USB memory devices (vpage 29, 48)

Playing Super Audio CD

Press POWER ON to turn on

power to the unit.

Press SOURCE on the unit to

select “DISC MODE”.

Select “Multi” with DISC

•The Media changes each time DISC LAYER

is pressed for 2 seconds.

Multi Super Audio CD

Video DVD-Audio

BD Hybrid BD

Multi

Stereo

NOTE

Select the disc layer before a disc is inserted.

5 6

•To play a disc in multichannel mode, connect the unit to an AV receiver, using an HDMI cable.

•The area/layer selected with DISC LAYER remains in the memory even when the power is turned off.

LAYER

Multi Video BD

Select the playback area and layer with DISC LAYER (vpage 50).

Plays the multi-channel area of the HD layer.

Plays the 2-channel area of the HD layer.

Plays the CD layer.

Insert a disc.

Press 5 to open/close the disc tray.

Press 1 .

Playback of the selected area and layer begins.

The icons show the category of

content applicable to each operation.

Video Audio Photo

For details of the media corresponding to each icon, see “Playable media” (vpage48).

ENGLISH

Playing Super Audio CD

(vpage22)

n Switching primary audio (vpage22) n Playing in random order (Random playback) (vpage23) n Playing in your preferred order (Program playback)

(vpage23)

Playing CD

Press POWER ON to turn on

power to the unit.

Press SOURCE on the unit to

select “DISC MODE”.

Insert a disc.

Press 5 to open/close the disc tray.

Press 1 .

Playback begins.

(vpage22)

n Switching primary audio (vpage22) n Playing in random order (Random playback) (vpage23) n Playing in your preferred order (Program playback)

(vpage23)

Playing DVD-Audio

Press POWER ON to turn on

power to the unit.

Press SOURCE on the unit to

select “DISC MODE”.

Select “Video” with DISC

LAYER.

•The Media changes each time DISC LAYER

is pressed for 2 seconds.

Multi Video BD

Multi

Video

Audio

Video

NOTE

Select the disc layer before a disc is inserted.

5 6

Super Audio CD

DVD-Audio

Hybrid BD

Select the playback part with DISC LAYER (vpage 50).

Plays the audio part.

Plays the video part.

Insert a disc.

Press 5 to open/close the disc tray.

Press 1 .

Playback of the selected part begins.

n Playing bonus group

DVD-Audio discs may have a bonus group that can be played after entering a password.

If you enter the wrong password

Press CLEAR to erase the input number and then enter the correct number.

n Selecting still images

When a DVD-Audio disc has still images on it, you can choose the image to display.

Press PAGE + during playback.

The next still image is displayed.

(vpage22)

n Switching primary audio (vpage22) n Playing in random order (Random playback) (vpage23) n Playing in your preferred order (Program playback)

(vpage23)

Advanced versionSimple version InformationBasic version

The icons show the category of

content applicable to each operation.

Video Audio Photo

For details of the media corresponding to each icon, see “Playable media” (vpage48).

+ 51 hidden pages
