Dell EMC Networking OS Configuration Guide
for the S5048F–ON System
9.14.2.4
Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2019 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries.
Other trademarks may be trademarks of their respective owners.
2019 - 11
Rev. A00
Contents
1 About this Guide..........................................................................................................................31
Audience................................................................................................................................................................................31
Conventions.......................................................................................................................................................................... 31
Related Documents..............................................................................................................................................................31
2 Configuration Fundamentals....................................................................................................... 32
Accessing the Command Line............................................................................................................................................32
CLI Modes............................................................................................................................................................................ 32
Navigating CLI Modes...................................................................................................................................................34
The do Command................................................................................................................................................................36
Undoing Commands............................................................................................................................................................ 37
Obtaining Help......................................................................................................................................................................37
Entering and Editing Commands....................................................................................................................................... 38
Command History................................................................................................................................................................38
Filtering show Command Outputs.................................................................................................................................... 39
Multiple Users in Configuration Mode.............................................................................................................................. 40
Configuring alias command................................................................................................................................................ 40
Viewing alias configuration............................................................................................................................................41
3 Getting Started..........................................................................................................................42
Console Access....................................................................................................................................................................42
Serial Console.................................................................................................................................................................42
Micro USB-B Access.....................................................................................................................................................43
Default Configuration..........................................................................................................................................................44
Configuring a Host Name................................................................................................................................................... 44
Accessing the System Remotely.......................................................................................................................................44
Configure the Management Port IP Address.............................................................................................................44
Configure a Management Route................................................................................................................................. 45
Configuring a Username and Password..................................................................................................................... 45
Configuring the Enable Password..................................................................................................................................... 45
Configuration File Management........................................................................................................................................ 46
Copy Files to and from the System.............................................................................................................................46
Mounting an NFS File System......................................................................................................................................47
Save the Running-Configuration................................................................................................................................. 49
Configure the Overload Bit for a Startup Scenario...................................................................................................49
Viewing Files...................................................................................................................................................................49
Managing the File System...................................................................................................................................................51
View Command History.......................................................................................................................................................51
Upgrading Dell EMC Networking OS................................................................................................................................52
Using HTTP for File Transfers........................................................................................................................................... 52
Verify Software Images Before Installation......................................................................................................................53
4 Management..............................................................................................................................54
Configuring Privilege Levels...............................................................................................................................................54
Contents 3
Removing a Command from EXEC Mode..................................................................................................................55
Moving a Command from EXEC Privilege Mode to EXEC Mode...........................................................................55
Allowing Access to CONFIGURATION Mode Commands....................................................................................... 55
Allowing Access to Different Modes...........................................................................................................................55
Applying a Privilege Level to a Username...................................................................................................................56
Applying a Privilege Level to a Terminal Line............................................................................................................. 56
Configuring Logging............................................................................................................................................................ 57
Audit and Security Logs................................................................................................................................................57
Configuring Logging Format ................................................................................................................................ 58
Setting Up a Secure Connection to a Syslog Server.......................................................................................59
Log Messages in the Internal Buffer.................................................................................................................................60
Disabling System Logging.................................................................................................................................................. 60
Sending System Messages to a Syslog Server............................................................................................................... 60
Configuring a UNIX System as a Syslog Server........................................................................................................ 60
Track Login Activity............................................................................................................................................................. 61
Restrictions for Tracking Login Activity...................................................................................................................... 61
Configuring Login Activity Tracking.............................................................................................................................61
Display Login Statistics..................................................................................................................................................61
Limit Concurrent Login Sessions.......................................................................................................................................63
Restrictions for Limiting the Number of Concurrent Sessions................................................................................63
Configuring Concurrent Session Limit........................................................................................................................ 63
Enabling the System to Clear Existing Sessions........................................................................................................63
Enabling Secured CLI Mode...............................................................................................................................................64
Changing System Logging Settings..................................................................................................................................64
Display the Logging Buffer and the Logging Configuration...........................................................................................65
Configuring a UNIX Logging Facility Level.......................................................................................................................68
Synchronizing Log Messages............................................................................................................................................ 68
Enabling Timestamp on Syslog Messages....................................................................................................................... 69
File Transfer Services..........................................................................................................................................................70
Enabling the FTP Server...............................................................................................................................................70
Configuring FTP Server Parameters............................................................................................................................71
Configuring FTP Client Parameters............................................................................................................................. 71
Terminal Lines...................................................................................................................................................................... 72
Denying and Permitting Access to a Terminal Line................................................................................................... 72
Configuring Login Authentication for Terminal Lines................................................................................................73
Setting Timeout for EXEC Privilege Mode.......................................................................................................................73
Using Telnet to get to Another Network Device.............................................................................................................74
Lock CONFIGURATION Mode...........................................................................................................................................74
Reloading the system..........................................................................................................................................................75
Restoring the Factory Default Settings............................................................................................................................76
Restoring Factory Default Environment Variables.................................................................................................... 76
5 802.1X....................................................................................................................................... 78
Port-Authentication Process............................................................................................................................................. 79
EAP over RADIUS..........................................................................................................................................................80
Configuring 802.1X..............................................................................................................................................................80
Important Points to Remember..........................................................................................................................................81
Enabling 802.1X.................................................................................................................................................................... 81
Configuring dot1x Profile ................................................................................................................................................... 82
Configuring the Static MAB and MAB Profile ................................................................................................................ 83
4
Contents
Configuring Critical VLAN ................................................................................................................................................. 84
Configuring MAC addresses for a do1x Profile................................................................................................................84
Configuring Request Identity Re-Transmissions............................................................................................................. 85
Configuring a Quiet Period after a Failed Authentication.........................................................................................85
Forcibly Authorizing or Unauthorizing a Port...................................................................................................................86
Re-Authenticating a Port................................................................................................................................................... 86
Configuring Timeouts..........................................................................................................................................................87
Configuring Dynamic VLAN Assignment with Port Authentication..............................................................................88
Guest and Authentication-Fail VLANs..............................................................................................................................89
Configuring a Guest VLAN...........................................................................................................................................90
Configuring an Authentication-Fail VLAN.................................................................................................................. 90
6 Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM)..........................92
Optimizing CAM Utilization During the Attachment of ACLs to VLANs......................................................................92
Guidelines for Configuring ACL VLAN Groups................................................................................................................ 92
Configuring ACL VLAN Groups and Configuring FP Blocks for VLAN Parameters................................................... 93
Configuring ACL VLAN Groups................................................................................................................................... 93
Configuring FP Blocks for VLAN Parameters............................................................................................................94
Viewing CAM Usage........................................................................................................................................................... 94
Allocating FP Blocks for VLAN Processes....................................................................................................................... 97
ACL Optimization to Increase Number of Supported IPv4 ACLs..................................................................................97
Optimizing ACL for More Number of IPv4 ACL Rules..............................................................................................97
7 Access Control Lists (ACLs)........................................................................................................99
IP Access Control Lists (ACLs)........................................................................................................................................100
CAM Usage...................................................................................................................................................................100
Implementing ACLs on Dell EMC Networking OS.................................................................................................... 101
Configure ACL Range Profiles..........................................................................................................................................102
Important Points to Remember....................................................................................................................................... 103
Configuration Task List for Route Maps...................................................................................................................103
Configuring Match Routes..........................................................................................................................................105
Configuring Set Conditions.........................................................................................................................................106
Configure a Route Map for Route Redistribution.................................................................................................... 107
Configure a Route Map for Route Tagging.............................................................................................................. 108
Continue Clause........................................................................................................................................................... 108
IP Fragment Handling........................................................................................................................................................108
IP Fragments ACL Examples...................................................................................................................................... 109
Layer 4 ACL Rules Examples...................................................................................................................................... 109
Configure a Standard IP ACL............................................................................................................................................110
Configuring a Standard IP ACL Filter.......................................................................................................................... 111
Configure an Extended IP ACL..........................................................................................................................................111
Configuring Filters with a Sequence Number............................................................................................................ 111
Configuring Filters Without a Sequence Number.....................................................................................................115
Configure Layer 2 and Layer 3 ACLs............................................................................................................................... 115
Assign an IP ACL to an Interface......................................................................................................................................116
Applying an IP ACL............................................................................................................................................................. 116
Counting ACL Hits........................................................................................................................................................ 117
Configure Ingress ACLs......................................................................................................................................................117
Configure Egress ACLs...................................................................................................................................................... 117
Contents
5
Applying Egress Layer 3 ACLs (Control-Plane)........................................................................................................ 118
Configuring UDF ACL.........................................................................................................................................................119
IP Prefix Lists......................................................................................................................................................................122
Configuration Task List for Prefix Lists.....................................................................................................................122
ACL Resequencing.............................................................................................................................................................125
Resequencing an ACL or Prefix List.......................................................................................................................... 126
Route Maps.........................................................................................................................................................................127
8 Bidirectional Forwarding Detection (BFD)................................................................................... 128
How BFD Works.................................................................................................................................................................128
BFD Packet Format..................................................................................................................................................... 129
BFD Sessions................................................................................................................................................................130
BFD Three-Way Handshake........................................................................................................................................131
Session State Changes................................................................................................................................................132
Important Points to Remember........................................................................................................................................132
Configure BFD....................................................................................................................................................................132
Configure BFD for Physical Ports.............................................................................................................................. 133
Configure BFD for Static Routes............................................................................................................................... 134
Configure BFD for OSPF............................................................................................................................................ 136
Configure BFD for OSPFv3.........................................................................................................................................141
Configure BFD for IS-IS...............................................................................................................................................144
Configure BFD for BGP...............................................................................................................................................145
Configure BFD for VRRP.............................................................................................................................................151
Configuring Protocol Liveness....................................................................................................................................154
Troubleshooting BFD...................................................................................................................................................154
9 Border Gateway Protocol (BGP)................................................................................................ 155
BGP IP version 4 (BGPv4) Overview............................................................................................................................. 155
BGP Autonomous Systems........................................................................................................................................ 155
AS4 Number Representation......................................................................................................................................157
Four-Byte AS Numbers...............................................................................................................................................159
BGP router ID............................................................................................................................................................... 159
Sessions and Peers...................................................................................................................................................... 159
Establish a Session.......................................................................................................................................................159
BGP Attributes for selecting Best Path....................................................................................................................160
Multiprotocol BGP....................................................................................................................................................... 165
BGP global and address family configuration........................................................................................................... 166
Implement BGP with Dell EMC Networking OS.......................................................................................................167
Configuration Information........................................................................................................................................... 170
Basic BGP configuration tasks......................................................................................................................................... 170
Prerequisite for configuring a BGP network.............................................................................................................170
Restrictions................................................................................................................................................................... 170
Enabling BGP................................................................................................................................................................ 170
Enabling four-byte autonomous system numbers................................................................................................... 172
Changing a BGP router ID...........................................................................................................................................173
Configuring AS4 Number Representations...............................................................................................................173
Configuring a BGP peer...............................................................................................................................................174
Example-Configuring BGP routing between peers..................................................................................................175
BGP peer group............................................................................................................................................................176
6
Contents
Advanced BGP configuration tasks.................................................................................................................................183
Route-refresh and Soft-reconfiguration...................................................................................................................183
Aggregating Routes.....................................................................................................................................................185
Filtering BGP.................................................................................................................................................................187
Configuring BGP Fast Fall-Over.................................................................................................................................192
Configuring Passive Peering.......................................................................................................................................193
Enabling Graceful Restart........................................................................................................................................... 194
Redistributing Routes.................................................................................................................................................. 195
Enabling Additional Paths............................................................................................................................................195
Configuring IP Community Lists.................................................................................................................................196
Configuring an IP Extended Community List............................................................................................................197
Configure BGP attributes........................................................................................................................................... 198
Enabling Multipath....................................................................................................................................................... 201
Route Reflectors......................................................................................................................................................... 202
Enabling Route Flap Dampening................................................................................................................................203
Changing BGP keepalive and hold timers................................................................................................................ 205
Setting the extended timer........................................................................................................................................205
Enabling or disabling BGP neighbors........................................................................................................................ 206
Route Map Continue...................................................................................................................................................207
Configuring BGP Confederations..............................................................................................................................207
Configuring a BGP VRF address family....................................................................................................................208
Maintaining Existing AS Numbers During an AS Migration....................................................................................209
Allowing an AS Number to Appear in its Own AS Path...........................................................................................210
Enabling MBGP Configurations...................................................................................................................................211
MBGP support for IPv6............................................................................................................................................... 211
Configuring IPv6 MBGP between peers....................................................................................................................211
Example-Configuring IPv4 and IPv6 neighbors........................................................................................................212
Configure IPv6 NH Automatically for IPv6 Prefix Advertised over IPv4 Neighbor............................................. 214
BGP Regular Expression Optimization...................................................................................................................... 215
Debugging BGP............................................................................................................................................................216
10 Content Addressable Memory (CAM)........................................................................................ 218
CAM Allocation...................................................................................................................................................................218
Test CAM Usage...............................................................................................................................................................220
View CAM-ACL Settings..................................................................................................................................................220
View CAM Usage............................................................................................................................................................... 221
CAM Optimization.............................................................................................................................................................222
Troubleshoot CAM Profiling.............................................................................................................................................222
QoS CAM Region Limitation...................................................................................................................................... 222
Syslog Error When the Table is Full.......................................................................................................................... 222
Syslog Warning Upon 90 Percent Utilization of CAM............................................................................................223
Syslog Warning for Discrepancies Between Configured Extended Prefixes.......................................................223
Unified Forwarding Table (UFT) Modes.........................................................................................................................223
Configuring UFT Modes............................................................................................................................................. 223
11 Control Plane Policing (CoPP).................................................................................................. 225
Configure Control Plane Policing.....................................................................................................................................226
Configuring CoPP for Protocols................................................................................................................................ 227
Configuring CoPP for CPU Queues..........................................................................................................................228
Contents
7
Protocol to CPU Queue Mapping............................................................................................................................. 229
Configuring Protocol to CPU Queue Mapping........................................................................................................ 230
Displaying CoPP Configuration .................................................................................................................................230
12 Data Center Bridging (DCB)..................................................................................................... 233
Ethernet Enhancements in Data Center Bridging.........................................................................................................233
Priority-Based Flow Control.......................................................................................................................................234
Enhanced Transmission Selection.............................................................................................................................235
Data Center Bridging Exchange Protocol (DCBx)..................................................................................................236
Data Center Bridging in a Traffic Flow..................................................................................................................... 237
Buffer Organization.....................................................................................................................................................237
Enabling Data Center Bridging........................................................................................................................................ 240
DCB Maps and its Attributes..................................................................................................................................... 240
Data Center Bridging: Default Configuration..................................................................................................................241
Configuring Priority-Based Flow Control........................................................................................................................ 241
Configuring Lossless Queues..................................................................................................................................... 242
Configuring PFC in a DCB Map.......................................................................................................................................243
Applying a DCB Map on a Port........................................................................................................................................244
Configuring PFC without a DCB Map............................................................................................................................ 245
Priority-Based Flow Control Using Dynamic Buffer Method.......................................................................................246
Shared headroom for lossless or PFC packets..............................................................................................................247
Configuring Shared Head Room Buffer....................................................................................................................249
Viewing Shared Head Room Usage.......................................................................................................................... 249
Monitoring Buffer Statistics for Tracking Purposes............................................................................................... 249
Behavior of Tagged Packets........................................................................................................................................... 250
Configuration Example for DSCP and PFC Priorities...................................................................................................250
SNMP Support for PFC and Buffer Statistics Tracking...............................................................................................251
Performing PFC Using DSCP Bits Instead of 802.1p Bits............................................................................................ 251
PFC and ETS Configuration Examples...........................................................................................................................253
Using PFC to Manage Converged Ethernet Traffic.....................................................................................................253
Operations on Untagged Packets...................................................................................................................................253
Generation of PFC for a Priority for Untagged Packets..............................................................................................253
Configure Enhanced Transmission Selection................................................................................................................ 253
Creating an ETS Priority Group.................................................................................................................................253
ETS Operation with DCBx..........................................................................................................................................254
Configuring ETS in a DCB Map................................................................................................................................. 255
Hierarchical Scheduling in ETS Output Policies............................................................................................................ 256
Using ETS to Manage Converged Ethernet Traffic..................................................................................................... 256
Applying DCB Policies in a Switch Stack....................................................................................................................... 256
Configure a DCBx Operation........................................................................................................................................... 257
DCBx Operation...........................................................................................................................................................257
DCBx Port Roles..........................................................................................................................................................257
DCB Configuration Exchange....................................................................................................................................258
Configuration Source Election...................................................................................................................................259
Propagation of DCB Information...............................................................................................................................259
Auto-Detection and Manual Configuration of the DCBx Version......................................................................... 259
DCBx Example............................................................................................................................................................. 260
DCBx Prerequisites and Restrictions........................................................................................................................260
Configuring DCBx........................................................................................................................................................260
Verifying the DCB Configuration.....................................................................................................................................263
8
Contents
QoS dot1p Traffic Classification and Queue Assignment..............................................................................................271
Configuring the Dynamic Buffer Method........................................................................................................................271
Sample DCB Configuration.............................................................................................................................................. 272
13 Dynamic Host Configuration Protocol (DHCP)........................................................................... 274
DHCP Packet Format and Options.................................................................................................................................274
Assign an IP Address using DHCP.................................................................................................................................. 275
Implementation Information............................................................................................................................................. 276
Configure the System to be a DHCP Server................................................................................................................. 277
Configuring the Server for Automatic Address Allocation..................................................................................... 277
Specifying a Default Gateway....................................................................................................................................278
Configure a Method of Hostname Resolution......................................................................................................... 278
Using DNS for Address Resolution............................................................................................................................278
Using NetBIOS WINS for Address Resolution......................................................................................................... 279
Creating Manual Binding Entries............................................................................................................................... 279
Debugging the DHCP Server.....................................................................................................................................279
Using DHCP Clear Commands.................................................................................................................................. 279
Configure the System to be a DHCP Client.................................................................................................................. 280
Configuring the DHCP Client System.......................................................................................................................280
DHCP Client on a Management Interface................................................................................................................ 281
DHCP Client Operation with Other Features.......................................................................................................... 282
Configuring DHCP relay source interface......................................................................................................................282
Global DHCP relay source IPv4 or IPv6 configuration ...........................................................................................282
Interface level DHCP relay source IPv4 or IPv6 configuration .............................................................................283
Configure Secure DHCP.................................................................................................................................................. 284
Option 82 (DHCPv4 relay options)...........................................................................................................................284
DHCPv6 relay agent options..................................................................................................................................... 285
DHCP Snooping...........................................................................................................................................................285
Drop DHCP Packets on Snooped VLANs Only....................................................................................................... 289
Dynamic ARP Inspection............................................................................................................................................ 289
Configuring Dynamic ARP Inspection.......................................................................................................................290
Source Address Validation................................................................................................................................................ 291
Enabling IP Source Address Validation......................................................................................................................291
DHCP MAC Source Address Validation................................................................................................................... 292
Enabling IP+MAC Source Address Validation..........................................................................................................292
Viewing the Number of SAV Dropped Packets.......................................................................................................292
Clearing the Number of SAV Dropped Packets...................................................................................................... 293
14 Equal Cost Multi-Path (ECMP).................................................................................................294
ECMP for Flow-Based Affinity........................................................................................................................................294
Configuring the Hash Algorithm................................................................................................................................ 294
Enabling Deterministic ECMP Next Hop..................................................................................................................294
Configuring the Hash Algorithm Seed...................................................................................................................... 294
Link Bundle Monitoring.....................................................................................................................................................295
Managing ECMP Group Paths.................................................................................................................................. 295
Creating an ECMP Group Bundle............................................................................................................................. 296
Modifying the ECMP Group Threshold.................................................................................................................... 296
Support for /128 IPv6 and /32 IPv4 Prefixes in Layer 3 Host Table and LPM Table........................................ 297
Support for ECMP in host table................................................................................................................................ 297
Contents
9
Support for moving /128 IPv6 Prefixes and /32 IPv4 Prefixes ............................................................................297
15 FIP Snooping.......................................................................................................................... 298
Fibre Channel over Ethernet............................................................................................................................................298
Ensure Robustness in a Converged Ethernet Network............................................................................................... 298
FIP Snooping on Ethernet Bridges..................................................................................................................................299
Using FIP Snooping............................................................................................................................................................301
FIP Snooping Prerequisites.........................................................................................................................................301
Important Points to Remember..................................................................................................................................301
Enabling the FCoE Transit Feature...........................................................................................................................303
Enable FIP Snooping on VLANs.................................................................................................................................303
Configure the FC-MAP Value....................................................................................................................................303
Configure a Port for a Bridge-to-Bridge Link.......................................................................................................... 303
Configure a Port for a Bridge-to-FCF Link.............................................................................................................. 303
Impact on Other Software Features.........................................................................................................................304
FIP Snooping Restrictions.......................................................................................................................................... 304
Configuring FIP Snooping...........................................................................................................................................304
Displaying FIP Snooping Information.............................................................................................................................. 305
FCoE Transit Configuration Example............................................................................................................................. 309
16 Flex Hash and Optimized Boot-Up..............................................................................................311
Flex Hash Capability Overview..........................................................................................................................................311
Configuring the Flex Hash Mechanism............................................................................................................................ 311
RDMA Over Converged Ethernet (RoCE) Overview....................................................................................................312
Preserving 802.1Q VLAN Tag Value for Lite Subinterfaces......................................................................................... 312
17 Force10 Resilient Ring Protocol (FRRP).....................................................................................314
Protocol Overview............................................................................................................................................................. 314
Ring Status....................................................................................................................................................................315
Multiple FRRP Rings....................................................................................................................................................315
Important FRRP Points............................................................................................................................................... 316
Important FRRP Concepts..........................................................................................................................................317
Implementing FRRP........................................................................................................................................................... 317
FRRP Configuration...........................................................................................................................................................318
Creating the FRRP Group...........................................................................................................................................318
Configuring the Control VLAN................................................................................................................................... 318
Configuring and Adding the Member VLANs........................................................................................................... 319
Setting the FRRP Timers........................................................................................................................................... 320
Clearing the FRRP Counters......................................................................................................................................320
Viewing the FRRP Configuration.............................................................................................................................. 320
Viewing the FRRP Information.................................................................................................................................. 320
Troubleshooting FRRP...................................................................................................................................................... 321
Sample Configuration and Topology................................................................................................................................321
FRRP Support on VLT......................................................................................................................................................322
18 GARP VLAN Registration Protocol (GVRP)................................................................................325
Configure GVRP................................................................................................................................................................325
Enabling GVRP Globally....................................................................................................................................................326
Enabling GVRP on a Layer 2 Interface........................................................................................................................... 327
10
Contents
Configure GVRP Registration..........................................................................................................................................327
Configure a GARP Timer.................................................................................................................................................. 327
19 Internet Group Management Protocol (IGMP)........................................................................... 329
IGMP Protocol Overview................................................................................................................................................. 329
IGMP Version 2............................................................................................................................................................329
IGMP Version 3............................................................................................................................................................330
Configure IGMP.................................................................................................................................................................333
Viewing IGMP Enabled Interfaces...................................................................................................................................333
Selecting an IGMP Version.............................................................................................................................................. 334
Viewing IGMP Groups...................................................................................................................................................... 334
Adjusting Timers................................................................................................................................................................335
Adjusting Query and Response Timers.....................................................................................................................335
Enabling IGMP Immediate-Leave....................................................................................................................................335
IGMP Snooping..................................................................................................................................................................336
Configuring IGMP Snooping...................................................................................................................................... 336
Removing a Group-Port Association.........................................................................................................................337
Disabling Multicast Flooding.......................................................................................................................................337
Specifying a Port as Connected to a Multicast Router..........................................................................................337
Configuring the Switch as Querier............................................................................................................................ 337
Fast Convergence after MSTP Topology Changes......................................................................................................338
Egress Interface Selection (EIS) for HTTP and IGMP Applications...........................................................................338
Designating a Multicast Router Interface...................................................................................................................... 344
20 Interfaces.............................................................................................................................. 345
Interface Types..................................................................................................................................................................346
View Basic Interface Information.................................................................................................................................... 346
Resetting an Interface to its Factory Default State..................................................................................................... 348
Enabling a Physical Interface........................................................................................................................................... 348
Physical Interfaces............................................................................................................................................................ 349
Configuration Task List for Physical Interfaces.......................................................................................................349
Overview of Layer Modes..........................................................................................................................................349
Configuring Layer 2 (Data Link) Mode..................................................................................................................... 349
Configuring Layer 2 (Interface) Mode......................................................................................................................350
Configuring Layer 3 (Network) Mode......................................................................................................................350
Configuring Layer 3 (Interface) Mode......................................................................................................................350
Egress Interface Selection (EIS)......................................................................................................................................351
Configuring EIS.............................................................................................................................................................351
Management Interfaces................................................................................................................................................... 352
Configuring Management Interfaces........................................................................................................................352
Configuring a Management Interface on an Ethernet Port...................................................................................352
VLAN Interfaces................................................................................................................................................................353
Loopback Interfaces......................................................................................................................................................... 353
Null Interfaces....................................................................................................................................................................354
Configuring Port Delay..................................................................................................................................................... 354
Port Channel Interfaces................................................................................................................................................... 354
Port Channel Definition and Standards.................................................................................................................... 355
Port Channel Benefits................................................................................................................................................ 355
Port Channel Implementation.................................................................................................................................... 355
Contents
11
Interfaces in Port Channels........................................................................................................................................355
Configuration Tasks for Port Channel Interfaces................................................................................................... 356
Creating a Port Channel.............................................................................................................................................356
Adding a Physical Interface to a Port Channel........................................................................................................356
Reassigning an Interface to a New Port Channel................................................................................................... 358
Configuring the Minimum Oper Up Links in a Port Channel..................................................................................358
Adding or Removing a Port Channel from a VLAN.................................................................................................359
Assigning an IP Address to a Port Channel..............................................................................................................359
Deleting or Disabling a Port Channel.........................................................................................................................360
Load Balancing Through Port Channels...................................................................................................................360
Load-Balancing Method............................................................................................................................................. 360
Changing the Hash Algorithm....................................................................................................................................360
Bulk Configuration..............................................................................................................................................................361
Interface Range............................................................................................................................................................361
Bulk Configuration Examples..................................................................................................................................... 362
Defining Interface Range Macros................................................................................................................................... 363
Define the Interface Range........................................................................................................................................363
Choosing an Interface-Range Macro........................................................................................................................364
Monitoring and Maintaining Interfaces...........................................................................................................................364
Maintenance Using TDR.............................................................................................................................................365
Non Dell-Qualified Transceivers...................................................................................................................................... 365
Splitting 100G Ports..........................................................................................................................................................366
Link Dampening................................................................................................................................................................. 366
Enabling Link Dampening............................................................................................................................................369
Link Bundle Monitoring.....................................................................................................................................................370
Using Ethernet Pause Frames for Flow Control............................................................................................................370
Enabling Pause Frames................................................................................................................................................371
Configure the MTU Size on an Interface........................................................................................................................ 371
Configuring wavelength for 10–Gigabit SFP+ optics................................................................................................... 372
Port-Pipes.......................................................................................................................................................................... 372
CR4 Auto-Negotiation...................................................................................................................................................... 372
Setting the Speed of Ethernet Interfaces......................................................................................................................373
Speed Setting on 25G Interfaces....................................................................................................................................374
Configuring 10G speed on 25G ports............................................................................................................................. 375
FEC Configuration.............................................................................................................................................................376
View Advanced Interface Information............................................................................................................................ 378
Configuring the Interface Sampling Size.................................................................................................................. 378
Configuring the Traffic Sampling Size Globally............................................................................................................. 379
Dynamic Counters..............................................................................................................................................................381
Clearing Interface Counters........................................................................................................................................381
Enhanced Validation of Interface Ranges...................................................................................................................... 382
Compressing Configuration Files.....................................................................................................................................382
OUI on 25G and 50G Interfaces......................................................................................................................................384
Configuring OUI on 25G and 50G Interfaces.......................................................................................................... 384
12
21 IPv4 Routing...........................................................................................................................385
IP Addresses...................................................................................................................................................................... 386
Configuration Tasks for IP Addresses............................................................................................................................ 386
Assigning IP Addresses to an Interface..........................................................................................................................386
Configuring Static Routes................................................................................................................................................ 387
Contents
Adding description for IPv4 and IPv6 static routes................................................................................................ 388
Configure Static Routes for the Management Interface.............................................................................................388
Using the Configured Source IP Address in ICMP Messages.....................................................................................389
Configuring the Duration to Establish a TCP Connection........................................................................................... 389
Enabling Directed Broadcast........................................................................................................................................... 390
Resolution of Host Names............................................................................................................................................... 390
Enabling Dynamic Resolution of Host Names............................................................................................................... 390
Specifying the Local System Domain and a List of Domains....................................................................................... 391
Configuring DNS with Traceroute................................................................................................................................... 391
ARP..................................................................................................................................................................................... 392
Configuration Tasks for ARP........................................................................................................................................... 392
Configuring Static ARP Entries....................................................................................................................................... 392
Enabling Proxy ARP.......................................................................................................................................................... 392
Clearing ARP Cache..........................................................................................................................................................393
ARP Learning via Gratuitous ARP...................................................................................................................................393
Enabling ARP Learning via Gratuitous ARP................................................................................................................... 393
ARP Learning via ARP Request.......................................................................................................................................393
Configuring ARP Retries.................................................................................................................................................. 394
ICMP...................................................................................................................................................................................395
Configuration Tasks for ICMP.........................................................................................................................................395
Enabling ICMP Unreachable Messages..........................................................................................................................395
ICMP Redirects................................................................................................................................................................. 395
UDP Helper........................................................................................................................................................................ 396
Enabling UDP Helper.........................................................................................................................................................397
Configuring a Broadcast Address....................................................................................................................................397
Configurations Using UDP Helper...................................................................................................................................398
UDP Helper with Broadcast-All Addresses....................................................................................................................398
UDP Helper with Subnet Broadcast Addresses............................................................................................................399
UDP Helper with Configured Broadcast Addresses..................................................................................................... 399
UDP Helper with No Configured Broadcast Addresses...............................................................................................400
Troubleshooting UDP Helper...........................................................................................................................................400
22 IPv6 Routing...........................................................................................................................401
Protocol Overview.............................................................................................................................................................401
Extended Address Space............................................................................................................................................ 401
Path MTU discovery....................................................................................................................................................401
Stateless Autoconfiguration.......................................................................................................................................402
IPv6 Headers................................................................................................................................................................403
Longest Prefix Match (LPM) Table and IPv6 /65 – /128 support...................................................................... 403
IPv6 Header Fields...................................................................................................................................................... 403
Extension Header Fields............................................................................................................................................. 404
Addressing....................................................................................................................................................................405
Implementing IPv6 with Dell EMC Networking OS...................................................................................................... 406
ICMPv6.............................................................................................................................................................................. 406
Path MTU discovery.........................................................................................................................................................406
IPv6 Neighbor Discovery..................................................................................................................................................407
IPv6 Neighbor Discovery of MTU Packets..............................................................................................................408
Configuring the IPv6 Recursive DNS Server...........................................................................................................408
Debugging IPv6 RDNSS Information Sent to the Host ........................................................................................ 409
Displaying IPv6 RDNSS Information......................................................................................................................... 409
Contents
13
Secure Shell (SSH) Over an IPv6 Transport..................................................................................................................410
Configuration Tasks for IPv6............................................................................................................................................410
Adjusting Your CAM-Profile........................................................................................................................................410
Assigning an IPv6 Address to an Interface................................................................................................................411
Assigning a Static IPv6 Route..................................................................................................................................... 411
Configuring Telnet with IPv6......................................................................................................................................412
SNMP over IPv6.......................................................................................................................................................... 412
Displaying IPv6 Information.........................................................................................................................................412
Displaying an IPv6 Interface Information.................................................................................................................. 412
Showing IPv6 Routes.................................................................................................................................................. 413
Showing the Running-Configuration for an Interface............................................................................................. 414
Clearing IPv6 Routes................................................................................................................................................... 415
Configuring IPv6 RA Guard.............................................................................................................................................. 415
23 iSCSI Optimization.................................................................................................................. 417
iSCSI Optimization Overview............................................................................................................................................417
Monitoring iSCSI Traffic Flows...................................................................................................................................418
Application of Quality of Service to iSCSI Traffic Flows.........................................................................................418
Information Monitored in iSCSI Traffic Flows.......................................................................................................... 419
Detection and Auto-Configuration for Dell EqualLogic Arrays...............................................................................419
Configuring Detection and Ports for Dell Compellent Arrays................................................................................ 420
Synchronizing iSCSI Sessions Learned on VLT-Lags with VLT-Peer.................................................................. 420
Enable and Disable iSCSI Optimization......................................................................................................................421
Default iSCSI Optimization Values...................................................................................................................................421
iSCSI Optimization Prerequisites..................................................................................................................................... 421
Configuring iSCSI Optimization....................................................................................................................................... 422
Displaying iSCSI Optimization Information.....................................................................................................................423
24 Intermediate System to Intermediate System........................................................................... 425
IS-IS Protocol Overview...................................................................................................................................................425
IS-IS Addressing................................................................................................................................................................ 425
Multi-Topology IS-IS......................................................................................................................................................... 426
Transition Mode...........................................................................................................................................................426
Interface Support........................................................................................................................................................ 426
Adjacencies...................................................................................................................................................................426
Graceful Restart................................................................................................................................................................ 427
Timers............................................................................................................................................................................427
Implementation Information............................................................................................................................................. 427
Configuration Information................................................................................................................................................ 428
Configuration Tasks for IS-IS.....................................................................................................................................428
Configuring the Distance of a Route........................................................................................................................ 435
Changing the IS-Type.................................................................................................................................................435
Redistributing IPv4 Routes.........................................................................................................................................437
Redistributing IPv6 Routes.........................................................................................................................................438
Configuring Authentication Passwords.................................................................................................................... 438
Setting the Overload Bit.............................................................................................................................................439
Debugging IS-IS...........................................................................................................................................................439
IS-IS Metric Styles............................................................................................................................................................ 440
Configure Metric Values...................................................................................................................................................440
14
Contents
Maximum Values in the Routing Table..................................................................................................................... 440
Change the IS-IS Metric Style in One Level Only................................................................................................... 440
Leaks from One Level to Another............................................................................................................................. 442
Sample Configurations......................................................................................................................................................442
25 Link Aggregation Control Protocol (LACP)................................................................................445
Introduction to Dynamic LAGs and LACP......................................................................................................................445
Important Points to Remember.................................................................................................................................445
LACP Modes................................................................................................................................................................445
Configuring LACP Commands...................................................................................................................................446
LACP Configuration Tasks...............................................................................................................................................446
Creating a LAG............................................................................................................................................................ 446
Configuring the LAG Interfaces as Dynamic............................................................................................................447
Setting the LACP Long Timeout............................................................................................................................... 447
Monitoring and Debugging LACP..............................................................................................................................448
Shared LAG State Tracking............................................................................................................................................. 448
Configuring Shared LAG State Tracking..................................................................................................................449
Important Points about Shared LAG State Tracking..............................................................................................450
LACP Basic Configuration Example................................................................................................................................450
Configure a LAG on ALPHA.......................................................................................................................................450
26 Layer 2.................................................................................................................................. 458
Manage the MAC Address Table.................................................................................................................................... 458
Clearing the MAC Address Table.............................................................................................................................. 458
Setting the Aging Time for Dynamic Entries........................................................................................................... 458
Configuring a Static MAC Address........................................................................................................................... 458
Displaying the MAC Address Table...........................................................................................................................459
MAC Learning Limit.......................................................................................................................................................... 459
Setting the MAC Learning Limit................................................................................................................................459
mac learning-limit Dynamic........................................................................................................................................ 460
mac learning-limit mac-address-sticky.....................................................................................................................460
mac learning-limit station-move................................................................................................................................460
mac learning-limit no-station-move.......................................................................................................................... 460
Learning Limit Violation Actions................................................................................................................................. 461
Setting Station Move Violation Actions.................................................................................................................... 461
Recovering from Learning Limit and Station Move Violations............................................................................... 461
Disabling MAC Address Learning on the System..........................................................................................................462
Enabling port security....................................................................................................................................................... 462
NIC Teaming...................................................................................................................................................................... 462
Configure Redundant Pairs..............................................................................................................................................463
Far-End Failure Detection................................................................................................................................................ 466
FEFD State Changes.................................................................................................................................................. 466
Configuring FEFD........................................................................................................................................................ 467
Enabling FEFD on an Interface.................................................................................................................................. 468
Debugging FEFD..........................................................................................................................................................468
27 Link Layer Discovery Protocol (LLDP).......................................................................................470
802.1AB (LLDP) Overview...............................................................................................................................................470
Protocol Data Units.....................................................................................................................................................470
Contents
15
Optional TLVs..................................................................................................................................................................... 471
Management TLVs.......................................................................................................................................................471
TIA-1057 (LLDP-MED) Overview................................................................................................................................... 472
TIA Organizationally Specific TLVs............................................................................................................................473
Configure LLDP................................................................................................................................................................. 475
CONFIGURATION versus INTERFACE Configurations............................................................................................... 476
Enabling LLDP....................................................................................................................................................................477
Disabling and Undoing LLDP...................................................................................................................................... 477
Enabling LLDP on Management Ports............................................................................................................................477
Disabling and Undoing LLDP on Management Ports.............................................................................................. 477
Advertising TLVs............................................................................................................................................................... 478
Viewing the LLDP Configuration..................................................................................................................................... 478
Viewing Information Advertised by Adjacent LLDP Neighbors................................................................................... 479
Examples of Viewing Information Advertised by Neighbors.................................................................................. 479
Configuring LLDPDU Intervals......................................................................................................................................... 481
Configuring Transmit and Receive Mode....................................................................................................................... 481
Configuring the Time to Live Value.................................................................................................................................482
Debugging LLDP................................................................................................................................................................483
Relevant Management Objects.......................................................................................................................................484
28 Microsoft Network Load Balancing...........................................................................................488
Configuring a Switch for NLB ........................................................................................................................................ 489
Enabling a Switch for Multicast NLB........................................................................................................................489
29 Multicast Source Discovery Protocol (MSDP)............................................................................491
Anycast RP.........................................................................................................................................................................492
Implementation Information.............................................................................................................................................493
Configure Multicast Source Discovery Protocol...........................................................................................................493
Related Configuration Tasks......................................................................................................................................493
Enable MSDP.....................................................................................................................................................................497
Manage the Source-Active Cache..................................................................................................................................498
Viewing the Source-Active Cache............................................................................................................................ 498
Limiting the Source-Active Cache............................................................................................................................ 498
Clearing the Source-Active Cache............................................................................................................................498
Enabling the Rejected Source-Active Cache...........................................................................................................499
Accept Source-Active Messages that Fail the RFP Check.........................................................................................499
Specifying Source-Active Messages...............................................................................................................................501
Limiting the Source-Active Messages from a Peer......................................................................................................502
Preventing MSDP from Caching a Local Source..........................................................................................................502
Preventing MSDP from Caching a Remote Source..................................................................................................... 502
Preventing MSDP from Advertising a Local Source.................................................................................................... 503
Logging Changes in Peership States..............................................................................................................................504
Terminating a Peership.....................................................................................................................................................504
Clearing Peer Statistics.................................................................................................................................................... 504
Debugging MSDP..............................................................................................................................................................505
MSDP with Anycast RP................................................................................................................................................... 505
Configuring Anycast RP...................................................................................................................................................506
Reducing Source-Active Message Flooding............................................................................................................ 507
Specifying the RP Address Used in SA Messages..................................................................................................507
16
Contents
MSDP Sample Configurations.........................................................................................................................................509
30 Multicast Listener Discovery Protocol.......................................................................................512
MLD timers......................................................................................................................................................................... 515
Reducing Host Response Burstiness.........................................................................................................................515
Configuring MLD Version..................................................................................................................................................516
Clearing MLD groups.........................................................................................................................................................516
Debugging MLD................................................................................................................................................................. 516
Explicit Tracking................................................................................................................................................................. 516
Reducing Leave Latency...................................................................................................................................................516
Displaying MLD groups table............................................................................................................................................516
Displaying MLD Interfaces................................................................................................................................................ 517
MLD Snooping....................................................................................................................................................................517
Enable MLD Snooping................................................................................................................................................. 517
Disable MLD Snooping.................................................................................................................................................517
Configure the switch as a querier..............................................................................................................................518
Specify port as connected to multicast router........................................................................................................ 518
Enable Snooping Explicit Tracking............................................................................................................................. 518
Display the MLD Snooping Table............................................................................................................................... 518
31 Multiple Spanning Tree Protocol (MSTP).................................................................................. 519
Spanning Tree Variations................................................................................................................................................. 520
Implementation Information.......................................................................................................................................520
Configure Multiple Spanning Tree Protocol...................................................................................................................520
Related Configuration Tasks......................................................................................................................................520
Enable Multiple Spanning Tree Globally.......................................................................................................................... 521
Adding and Removing Interfaces.....................................................................................................................................521
Creating Multiple Spanning Tree Instances....................................................................................................................521
Influencing MSTP Root Selection................................................................................................................................... 523
Interoperate with Non-Dell Bridges................................................................................................................................ 523
Changing the Region Name or Revision.........................................................................................................................523
Modifying Global Parameters.......................................................................................................................................... 524
Modifying the Interface Parameters...............................................................................................................................525
Setting STP path cost as constant................................................................................................................................ 525
Configuring an EdgePort..................................................................................................................................................526
Flush MAC Addresses after a Topology Change.......................................................................................................... 526
MSTP Sample Configurations..........................................................................................................................................527
Debugging and Verifying MSTP Configurations............................................................................................................ 531
32 Multicast Features..................................................................................................................533
Enabling IP Multicast........................................................................................................................................................ 533
Implementation Information.............................................................................................................................................533
Multicast Policies...............................................................................................................................................................534
IPv4 Multicast Policies................................................................................................................................................534
Understanding Multicast Traceroute (mtrace)..............................................................................................................541
Printing Multicast Traceroute (mtrace) Paths...............................................................................................................541
Supported Error Codes.................................................................................................................................................... 543
mtrace Scenarios.............................................................................................................................................................. 543
Contents
17
33 Object Tracking......................................................................................................................549
Object Tracking Overview............................................................................................................................................... 549
Track Layer 2 Interfaces............................................................................................................................................ 550
Track Layer 3 Interfaces............................................................................................................................................ 550
Track IPv4 and IPv6 Routes...................................................................................................................................... 550
Set Tracking Delays..................................................................................................................................................... 551
VRRP Object Tracking................................................................................................................................................552
Object Tracking Configuration........................................................................................................................................ 552
Tracking a Layer 2 Interface...................................................................................................................................... 552
Tracking a Layer 3 Interface...................................................................................................................................... 553
Track an IPv4/IPv6 Route......................................................................................................................................... 554
Displaying Tracked Objects..............................................................................................................................................557
34 Open Shortest Path First (OSPFv2 and OSPFv3)...................................................................... 559
Protocol Overview............................................................................................................................................................ 559
Autonomous System (AS) Areas.............................................................................................................................. 559
Area Types................................................................................................................................................................... 560
Networks and Neighbors............................................................................................................................................ 561
Router Types................................................................................................................................................................ 561
Designated and Backup Designated Routers.......................................................................................................... 562
Link-State Advertisements (LSAs)...........................................................................................................................562
Router Priority and Cost.............................................................................................................................................563
OSPF with Dell EMC Networking OS.............................................................................................................................564
Graceful Restart.......................................................................................................................................................... 564
Fast Convergence (OSPFv2, IPv4 Only).................................................................................................................565
Multi-Process OSPFv2 with VRF............................................................................................................................. 565
OSPF ACK Packing.....................................................................................................................................................566
Setting OSPF Adjacency with Cisco Routers..........................................................................................................566
Configuration Information................................................................................................................................................566
Configuration Task List for OSPFv2 (OSPF for IPv4)........................................................................................... 567
Configuration Task List for OSPFv3 (OSPF for IPv6)................................................................................................. 578
Enabling IPv6 Unicast Routing...................................................................................................................................579
Assigning IPv6 Addresses on an Interface............................................................................................................... 579
Assigning Area ID on an Interface............................................................................................................................. 579
Assigning OSPFv3 Process ID and Router ID Globally........................................................................................... 580
Assigning OSPFv3 Process ID and Router ID to a VRF......................................................................................... 580
Configuring Stub Areas.............................................................................................................................................. 580
Configuring Passive-Interface....................................................................................................................................581
Redistributing Routes.................................................................................................................................................. 581
Configuring a Default Route....................................................................................................................................... 581
Applying cost for OSPFv3..........................................................................................................................................582
Enabling OSPFv3 Graceful Restart...........................................................................................................................582
OSPFv3 Authentication Using IPsec........................................................................................................................ 584
Troubleshooting OSPFv3...........................................................................................................................................589
MIB Support for OSPFv3.................................................................................................................................................590
Viewing the OSPFv3 MIB........................................................................................................................................... 591
18
35 Policy-based Routing (PBR).................................................................................................... 592
Contents
Overview............................................................................................................................................................................ 592
Implementing PBR............................................................................................................................................................ 593
Configuration Task List for Policy-based Routing........................................................................................................ 593
Create a Redirect List.................................................................................................................................................594
Create a Rule for a Redirect-list................................................................................................................................594
Apply a Redirect-list to an Interface using a Redirect-group................................................................................ 595
Sample Configuration....................................................................................................................................................... 597
36 PIM Sparse-Mode (PIM-SM)................................................................................................... 602
Implementation Information.............................................................................................................................................602
Protocol Overview............................................................................................................................................................ 602
Requesting Multicast Traffic..................................................................................................................................... 602
Refuse Multicast Traffic.............................................................................................................................................602
Send Multicast Traffic................................................................................................................................................ 603
Configuring PIM-SM.........................................................................................................................................................603
Related Configuration Tasks......................................................................................................................................603
Enable PIM-SM................................................................................................................................................................. 603
Configuring S,G Expiry Timers........................................................................................................................................ 604
Configuring a Static Rendezvous Point......................................................................................................................... 605
Overriding Bootstrap Router Updates..................................................................................................................... 605
Configuring a Designated Router....................................................................................................................................605
Creating Multicast Boundaries and Domains.................................................................................................................606
Electing an RP using the BSR Mechanism.................................................................................................................... 606
37 PIM Source-Specific Mode (PIM-SSM).................................................................................... 608
Implementation Information.............................................................................................................................................608
Configure PIM-SSM......................................................................................................................................................... 608
Enabling PIM-SSM............................................................................................................................................................609
Use PIM-SSM with IGMP Version 2 Hosts................................................................................................................... 609
Electing an RP using the BSR Mechanism..................................................................................................................... 610
Enabling RP to Server Specific Multicast Groups.................................................................................................... 611
38 Port Monitoring...................................................................................................................... 613
Important Points to Remember....................................................................................................................................... 613
Port Monitoring..................................................................................................................................................................613
Configuring Port Monitoring.............................................................................................................................................615
Configuring Monitor Multicast Queue.............................................................................................................................616
Flow-Based Monitoring..................................................................................................................................................... 617
Enabling Flow-Based Monitoring............................................................................................................................... 618
Remote Port Mirroring..................................................................................................................................................... 620
Remote Port Mirroring Example................................................................................................................................620
Configuring Remote Port Mirroring...........................................................................................................................621
Displaying Remote-Port Mirroring Configurations..................................................................................................622
Configuration procedure for Remote Port Mirroring..............................................................................................622
Encapsulated Remote Port Monitoring..........................................................................................................................626
ERPM Behavior on a typical Dell EMC Networking OS ..............................................................................................628
Port Monitoring on VLT................................................................................................................................................... 629
39 Private VLANs (PVLAN).......................................................................................................... 632
Contents
19
Private VLAN Concepts................................................................................................................................................... 632
Using the Private VLAN Commands...............................................................................................................................633
Configuration Task List.....................................................................................................................................................634
Creating PVLAN ports................................................................................................................................................634
Creating a Primary VLAN........................................................................................................................................... 634
Creating a Community VLAN.................................................................................................................................... 635
Creating an Isolated VLAN.........................................................................................................................................636
Private VLAN Configuration Example.............................................................................................................................637
Inspecting the Private VLAN Configuration.................................................................................................................. 638
40 Per-VLAN Spanning Tree Plus (PVST+)....................................................................................640
Protocol Overview............................................................................................................................................................ 640
Implementation Information..............................................................................................................................................641
Configure Per-VLAN Spanning Tree Plus.......................................................................................................................641
Enabling PVST+................................................................................................................................................................. 641
Disabling PVST+.................................................................................................................................................................641
Influencing PVST+ Root Selection..................................................................................................................................642
Modifying Global PVST+ Parameters.............................................................................................................................643
Modifying Interface PVST+ Parameters........................................................................................................................644
Configuring an EdgePort..................................................................................................................................................644
PVST+ in Multi-Vendor Networks..................................................................................................................................645
Enabling PVST+ Extend System ID................................................................................................................................ 645
PVST+ Sample Configurations........................................................................................................................................646
41 Quality of Service (QoS).......................................................................................................... 648
Implementation Information.............................................................................................................................................650
Port-Based QoS Configurations..................................................................................................................................... 650
Setting dot1p Priorities for Incoming Traffic............................................................................................................650
Honoring dot1p Priorities on Ingress Traffic............................................................................................................. 651
Configuring Port-Based Rate Policing.......................................................................................................................651
Configuring Port-Based Rate Shaping......................................................................................................................651
Policy-Based QoS Configurations...................................................................................................................................652
Classify Traffic.............................................................................................................................................................652
Dot1p to Queue Mapping Requirement....................................................................................................................655
Create a QoS Policy....................................................................................................................................................656
DSCP Color Maps....................................................................................................................................................... 658
Create Policy Maps.....................................................................................................................................................659
Enabling QoS Rate Adjustment....................................................................................................................................... 662
Enabling Strict-Priority Queueing....................................................................................................................................662
Queue Classification Requirements for PFC Functionality.......................................................................................... 663
Support for marking dot1p value in L3 Input Qos Policy.............................................................................................. 663
Weighted Random Early Detection.................................................................................................................................664
Enabling and Disabling WRED Globally..................................................................................................................... 664
Creating WRED Profiles............................................................................................................................................. 665
Applying a WRED Profile to Traffic...........................................................................................................................665
Displaying Default and Configured WRED Profiles................................................................................................. 665
Displaying WRED Drop Statistics..............................................................................................................................665
Displaying egress–queue Statistics...........................................................................................................................666
Pre-Calculating Available QoS CAM Space...................................................................................................................666
20
Contents
Specifying Policy-Based Rate Shaping in Packets Per Second.................................................................................. 667
Configuring Policy-Based Rate Shaping.........................................................................................................................667
Configuring Weights and ECN for WRED .....................................................................................................................668
Configuring WRED and ECN Attributes.........................................................................................................................669
Guidelines for Configuring ECN for Classifying and Color-Marking Packets............................................................ 670
Sample configuration to mark non-ecn packets as “yellow” with Multiple traffic class.................................... 670
Classifying Incoming Packets Using ECN and Color-Marking................................................................................671
Sample configuration to mark non-ecn packets as “yellow” with single traffic class.........................................672
Applying Layer 2 Match Criteria on a Layer 3 Interface...............................................................................................673
Managing Hardware Buffer Statistics...................................................................................................................... 673
Enabling Buffer Statistics Tracking ................................................................................................................................674
42 Routing Information Protocol (RIP)..........................................................................................676
Protocol Overview............................................................................................................................................................ 676
RIPv1............................................................................................................................................................................. 676
RIPv2.............................................................................................................................................................................676
Implementation Information............................................................................................................................................. 676
Configuration Information.................................................................................................................................................677
Configuration Task List............................................................................................................................................... 677
RIP Configuration Example........................................................................................................................................ 682
43 Remote Monitoring (RMON)....................................................................................................687
Implementation Information............................................................................................................................................. 687
Fault Recovery...................................................................................................................................................................687
Setting the RMON Alarm........................................................................................................................................... 687
Configuring an RMON Event.....................................................................................................................................688
Configuring RMON Collection Statistics..................................................................................................................689
Configuring the RMON Collection History...............................................................................................................689
44 Rapid Spanning Tree Protocol (RSTP)......................................................................................690
Protocol Overview............................................................................................................................................................ 690
Configuring Rapid Spanning Tree................................................................................................................................... 690
Important Points to Remember.......................................................................................................................................690
RSTP and VLT..............................................................................................................................................................691
Configuring Interfaces for Layer 2 Mode....................................................................................................................... 691
Enabling Rapid Spanning Tree Protocol Globally........................................................................................................... 691
Adding and Removing Interfaces.................................................................................................................................... 693
Modifying Global Parameters.......................................................................................................................................... 693
Enabling SNMP Traps for Root Elections and Topology Changes....................................................................... 695
Modifying Interface Parameters..................................................................................................................................... 695
Enabling SNMP Traps for Root Elections and Topology Changes.............................................................................695
Influencing RSTP Root Selection....................................................................................................................................695
Configuring an EdgePort..................................................................................................................................................696
Configuring Fast Hellos for Link State Detection......................................................................................................... 696
45 Software-Defined Networking (SDN)....................................................................................... 698
46 Security.................................................................................................................................699
AAA Accounting................................................................................................................................................................ 699
Contents
21
Configuration Task List for AAA Accounting...........................................................................................................699
RADIUS Accounting.....................................................................................................................................................701
AAA Authentication...........................................................................................................................................................706
Configuration Task List for AAA Authentication..................................................................................................... 706
Obscuring Passwords and Keys...................................................................................................................................... 708
AAA Authorization.............................................................................................................................................................709
Privilege Levels Overview.......................................................................................................................................... 709
Configuration Task List for Privilege Levels.............................................................................................................709
RADIUS................................................................................................................................................................................712
RADIUS Authentication............................................................................................................................................... 713
Configuration Task List for RADIUS.......................................................................................................................... 714
TACACS+............................................................................................................................................................................716
Configuration Task List for TACACS+.......................................................................................................................716
TACACS+ Remote Authentication.............................................................................................................................718
Command Authorization..............................................................................................................................................719
Protection from TCP Tiny and Overlapping Fragment Attacks...................................................................................719
Enabling SCP and SSH......................................................................................................................................................719
Using SCP with SSH to Copy a Software Image.................................................................................................... 720
Removing the RSA Host Keys and Zeroizing Storage ............................................................................................721
Configuring When to Re-generate an SSH Key ......................................................................................................721
Configuring the SSH Server Key Exchange Algorithm............................................................................................721
Configuring the HMAC Algorithm for the SSH Server...........................................................................................722
Configuring the HMAC Algorithm for the SSH Client............................................................................................ 722
Configuring the SSH Server Cipher List...................................................................................................................723
Configuring the SSH Client Cipher List.................................................................................................................... 723
Secure Shell Authentication....................................................................................................................................... 723
Troubleshooting SSH.................................................................................................................................................. 725
Telnet.................................................................................................................................................................................. 726
VTY Line and Access-Class Configuration.....................................................................................................................726
VTY Line Local Authentication and Authorization...................................................................................................726
VTY Line Remote Authentication and Authorization...............................................................................................727
VTY MAC-SA Filter Support...................................................................................................................................... 727
Role-Based Access Control..............................................................................................................................................728
Overview of RBAC...................................................................................................................................................... 728
User Roles.................................................................................................................................................................... 730
AAA Authentication and Authorization for Roles.....................................................................................................733
Role Accounting...........................................................................................................................................................735
Display Information About User Roles.......................................................................................................................736
Two Factor Authentication (2FA)................................................................................................................................... 737
Handling Access-Challenge Message....................................................................................................................... 737
Configuring Challenge Response Authentication for SSHv2................................................................................. 737
SMS-OTP Mechanism................................................................................................................................................738
Configuring the System to Drop Certain ICMP Reply Messages............................................................................... 738
SSH Lockout Settings...................................................................................................................................................... 740
22
47 Service Provider Bridging.........................................................................................................741
VLAN Stacking................................................................................................................................................................... 741
Configure VLAN Stacking...........................................................................................................................................742
Creating Access and Trunk Ports..............................................................................................................................743
Enable VLAN-Stacking for a VLAN...........................................................................................................................743
Contents
Configuring the Protocol Type Value for the Outer VLAN Tag.............................................................................744
Configuring Dell EMC Networking OS Options for Trunk Ports........................................................................... 744
Debugging VLAN Stacking.........................................................................................................................................745
VLAN Stacking in Multi-Vendor Networks.............................................................................................................. 745
VLAN Stacking Packet Drop Precedence......................................................................................................................748
Enabling Drop Eligibility............................................................................................................................................... 748
Honoring the Incoming DEI Value..............................................................................................................................749
Marking Egress Packets with a DEI Value................................................................................................................749
Dynamic Mode CoS for VLAN Stacking.........................................................................................................................750
Mapping C-Tag to S-Tag dot1p Values.....................................................................................................................751
Layer 2 Protocol Tunneling............................................................................................................................................... 751
Enabling Layer 2 Protocol Tunneling.........................................................................................................................753
Specifying a Destination MAC Address for BPDUs................................................................................................ 754
Setting Rate-Limit BPDUs..........................................................................................................................................754
Debugging Layer 2 Protocol Tunneling.....................................................................................................................754
Provider Backbone Bridging.............................................................................................................................................754
48 sFlow.....................................................................................................................................756
Overview............................................................................................................................................................................ 756
Implementation Information.............................................................................................................................................756
Enabling Extended sFlow..................................................................................................................................................757
Important Points to Remember.................................................................................................................................758
Enabling and Disabling sFlow on an Interface................................................................................................................758
Enabling sFlow Max-Header Size Extended..................................................................................................................759
sFlow Show Commands...................................................................................................................................................759
Displaying Show sFlow Global....................................................................................................................................760
Displaying Show sFlow on an Interface.................................................................................................................... 760
Displaying Show sFlow on a .......................................................................................................................................761
Configuring Specify Collectors.........................................................................................................................................761
Changing the Polling Intervals.......................................................................................................................................... 761
Back-Off Mechanism.........................................................................................................................................................761
sFlow on LAG ports...........................................................................................................................................................762
49 Simple Network Management Protocol (SNMP)........................................................................ 763
Protocol Overview............................................................................................................................................................ 764
Implementation Information............................................................................................................................................. 764
SNMPv3 Compliance With FIPS..................................................................................................................................... 764
Configuration Task List for SNMP..................................................................................................................................765
Important Points to Remember.......................................................................................................................................765
Set up SNMP.....................................................................................................................................................................765
Creating a Community................................................................................................................................................ 766
Setting Up User-Based Security (SNMPv3)........................................................................................................... 766
Enable SNMPv3 traps.................................................................................................................................................767
Reading Managed Object Values.....................................................................................................................................767
Writing Managed Object Values......................................................................................................................................768
Configuring Contact and Location Information using SNMP...................................................................................... 768
Subscribing to Managed Object Value Updates using SNMP.....................................................................................769
Enabling a Subset of SNMP Traps..................................................................................................................................769
Enabling an SNMP Agent to Notify Syslog Server Failure...........................................................................................770
Contents
23
Copy Configuration Files Using SNMP............................................................................................................................771
Copying a Configuration File...................................................................................................................................... 772
Copying Configuration Files via SNMP..................................................................................................................... 773
Copying the Startup-Config Files to the Running-Config......................................................................................773
Copying the Startup-Config Files to the Server via FTP........................................................................................773
Copying the Startup-Config Files to the Server via TFTP..................................................................................... 774
Copy a Binary File to the Startup-Configuration..................................................................................................... 774
Additional MIB Objects to View Copy Statistics......................................................................................................774
Obtaining a Value for MIB Objects............................................................................................................................775
MIB Support for Power Monitoring................................................................................................................................ 775
MIB Support for 25G, 40G, 50G, 100G Optical Transceiver or DAC cable IDPROM user info.............................. 776
MIB Support to Display the Available Memory Size on Flash...................................................................................... 777
Viewing the Available Flash Memory Size.................................................................................................................777
MIB Support to Display the Software Core Files Generated by the System.............................................................778
Viewing the Software Core Files Generated by the System................................................................................. 778
MIB Support for PFC Storm Control.............................................................................................................................. 779
MIB Support for PFC no-drop-priority L2Dlf Drop....................................................................................................... 780
MIB Support for Monitoring the overall buffer usage for lossy and lossless traffic per XPE.................................. 781
SNMP Support for WRED Green/Yellow/Red Drop Counters...................................................................................782
MIB Support to Display the Available Partitions on Flash............................................................................................ 783
Viewing the Available Partitions on Flash................................................................................................................. 783
MIB Support to Display the ECN Marked Packets ...................................................................................................... 784
MIB Support to Display Egress Queue Statistics.......................................................................................................... 784
MIB Support to ECMP Group Count..............................................................................................................................784
Viewing the ECMP Group Count Information......................................................................................................... 785
............................................................................................................................................................................................. 787
Viewing the FEC BER Details.....................................................................................................................................788
MIB Support for entAliasMappingTable ........................................................................................................................ 790
Viewing the entAliasMappingTable MIB...................................................................................................................790
MIB Support for LAG.........................................................................................................................................................791
Viewing the LAG MIB..................................................................................................................................................792
MIB Support for CAM.......................................................................................................................................................792
Viewing the CAM MIB................................................................................................................................................ 793
MIB support for MAC notification traps.........................................................................................................................793
MIB support for Port Security......................................................................................................................................... 794
Global MIB objects for port security......................................................................................................................... 794
MIB support for interface level port security...........................................................................................................794
MIB objects for configuring MAC addresses...........................................................................................................795
MIB objects for configuring MAC addresses...........................................................................................................796
Configuring SNMP traps for new MAC learning or station–move.............................................................................796
Manage VLANs using SNMP........................................................................................................................................... 797
Creating a VLAN.......................................................................................................................................................... 797
Assigning a VLAN Alias................................................................................................................................................797
Displaying the Ports in a VLAN.................................................................................................................................. 797
Add Tagged and Untagged Ports to a VLAN...........................................................................................................797
Managing Overload on Startup....................................................................................................................................... 798
Enabling and Disabling a Port using SNMP....................................................................................................................799
Fetch Dynamic MAC Entries using SNMP.....................................................................................................................799
Example of Deriving the Interface Index Number.........................................................................................................800
MIB Objects for Viewing the System Image on Flash Partitions.......................................................................... 800
24
Contents
Monitor Port-Channels..................................................................................................................................................... 801
Troubleshooting SNMP Operation..................................................................................................................................802
Transceiver Monitoring.................................................................................................................................................... 802
Configuring SNMP context name...................................................................................................................................803
50 Storm Control........................................................................................................................ 804
Configure Storm Control..................................................................................................................................................804
Configuring Storm Control from INTERFACE Mode..............................................................................................804
Configuring Storm Control from CONFIGURATION Mode...................................................................................805
PFC Storm......................................................................................................................................................................... 805
Detect PFC Storm...................................................................................................................................................... 805
Restore Queue Drop State........................................................................................................................................ 806
View Details of Storm Control PFC.......................................................................................................................... 806
51 Spanning Tree Protocol (STP)................................................................................................. 808
Protocol Overview............................................................................................................................................................ 808
Configure Spanning Tree................................................................................................................................................. 808
Important Points to Remember.......................................................................................................................................809
Configuring Interfaces for Layer 2 Mode.......................................................................................................................809
Enabling Spanning Tree Protocol Globally...................................................................................................................... 810
Adding an Interface to the Spanning Tree Group..........................................................................................................812
Modifying Global Parameters........................................................................................................................................... 812
Modifying Interface STP Parameters..............................................................................................................................813
Enabling PortFast...............................................................................................................................................................813
Prevent Network Disruptions with BPDU Guard.....................................................................................................814
Selecting STP Root........................................................................................................................................................... 816
STP Root Guard.................................................................................................................................................................816
Root Guard Scenario................................................................................................................................................... 816
Configuring Root Guard...............................................................................................................................................817
Enabling SNMP Traps for Root Elections and Topology Changes..............................................................................818
Configuring Spanning Trees as Hitless............................................................................................................................818
STP Loop Guard.................................................................................................................................................................818
Configuring Loop Guard.............................................................................................................................................. 819
Displaying STP Guard Configuration.............................................................................................................................. 820
52 SupportAssist......................................................................................................................... 821
Configuring SupportAssist Using a Configuration Wizard............................................................................................ 821
Configuring SupportAssist Manually...............................................................................................................................822
Configuring SupportAssist Activity.................................................................................................................................823
Configuring SupportAssist Company..............................................................................................................................825
Configuring SupportAssist Person..................................................................................................................................825
Configuring SupportAssist Server...................................................................................................................................826
Viewing SupportAssist Configuration............................................................................................................................. 827
53 System Time and Date............................................................................................................ 829
Network Time Protocol.................................................................................................................................................... 829
Protocol Overview...................................................................................................................................................... 830
Configure the Network Time Protocol..................................................................................................................... 830
Enabling NTP............................................................................................................................................................... 830
Contents
25
Configuring NTP Broadcasts......................................................................................................................................831
Disabling NTP on an Interface....................................................................................................................................831
Configuring a Source IP Address for NTP Packets................................................................................................. 831
Configuring NTP Authentication............................................................................................................................... 832
Configuring NTP control key password....................................................................................................................834
Configuring the NTP Step-Threshold.......................................................................................................................834
Configuring a Custom-defined Period for NTP time Synchronization................................................................. 834
Dell EMC Networking OS Time and Date...................................................................................................................... 835
Configuration Task List ..............................................................................................................................................835
Setting the Time and Date for the Switch Software Clock...................................................................................835
Setting the Timezone................................................................................................................................................. 835
Set Daylight Saving Time........................................................................................................................................... 836
Setting Daylight Saving Time Once.......................................................................................................................... 836
Setting Recurring Daylight Saving Time...................................................................................................................836
54 Tunneling...............................................................................................................................838
Configuring a Tunnel.........................................................................................................................................................838
Configuring Tunnel Keepalive Settings...........................................................................................................................839
Configuring a Tunnel Interface........................................................................................................................................839
Configuring Tunnel Allow-Remote Decapsulation.........................................................................................................840
Configuring Tunnel source anylocal Decapsulation.......................................................................................................840
Guidelines for Configuring Multipoint Receive-Only Tunnels.......................................................................................841
Multipoint Receive-Only Tunnels..................................................................................................................................... 841
55 Uplink Failure Detection (UFD)................................................................................................ 842
Feature Description...........................................................................................................................................................842
How Uplink Failure Detection Works.............................................................................................................................. 843
UFD and NIC Teaming......................................................................................................................................................844
Important Points to Remember.......................................................................................................................................844
Configuring Uplink Failure Detection.............................................................................................................................. 845
Clearing a UFD-Disabled Interface..................................................................................................................................846
Displaying Uplink Failure Detection................................................................................................................................. 847
Sample Configuration: Uplink Failure Detection............................................................................................................848
56 Upgrade Procedures............................................................................................................... 850
57 Virtual LANs (VLANs).............................................................................................................. 851
Default VLAN......................................................................................................................................................................851
Port-Based VLANs............................................................................................................................................................852
VLANs and Port Tagging................................................................................................................................................. 852
Configuration Task List.....................................................................................................................................................853
Creating a Port-Based VLAN.....................................................................................................................................853
Assigning Interfaces to a VLAN.................................................................................................................................853
Moving Untagged Interfaces..................................................................................................................................... 854
Assigning an IP Address to a VLAN.......................................................................................................................... 855
Configuring Native VLANs...............................................................................................................................................856
Enabling Null VLAN as the Default VLAN...................................................................................................................... 856
26
58 Virtual Link Trunking (VLT)..................................................................................................... 857
Contents
Overview............................................................................................................................................................................ 857
VLT Terminology......................................................................................................................................................... 859
Layer-2 Traffic in VLT Domains.................................................................................................................................859
Interspersed VLANs....................................................................................................................................................860
VLT on Core Switches.................................................................................................................................................861
Enhanced VLT.............................................................................................................................................................. 861
Configure Virtual Link Trunking....................................................................................................................................... 862
Important Points to Remember.................................................................................................................................862
Configuration Notes....................................................................................................................................................863
Primary and Secondary VLT Peers........................................................................................................................... 866
RSTP and VLT............................................................................................................................................................. 866
VLT Bandwidth Monitoring........................................................................................................................................ 867
VLT and Stacking........................................................................................................................................................ 867
VLT and IGMP Snooping............................................................................................................................................ 867
VLT IPv6.......................................................................................................................................................................867
VLT Port Delayed Restoration................................................................................................................................... 867
PIM-Sparse Mode Support on VLT.......................................................................................................................... 868
VLT Routing ................................................................................................................................................................869
Non-VLT ARP Sync.....................................................................................................................................................872
RSTP Configuration.......................................................................................................................................................... 872
Preventing Forwarding Loops in a VLT Domain...................................................................................................... 872
Sample RSTP configuration....................................................................................................................................... 873
Configuring VLT...........................................................................................................................................................873
PVST+ Configuration........................................................................................................................................................ 881
Peer Routing Configuration Example..............................................................................................................................882
Dell-1 Switch Configuration........................................................................................................................................883
Dell-2 Switch Configuration....................................................................................................................................... 887
R1 Configuration.......................................................................................................................................................... 890
Access Switch A1 Configurations and Verification.................................................................................................. 891
eVLT Configuration Example............................................................................................................................................891
PIM-Sparse Mode Configuration Example.................................................................................................................... 894
Verifying a VLT Configuration......................................................................................................................................... 894
Additional VLT Sample Configurations........................................................................................................................... 897
Troubleshooting VLT........................................................................................................................................................ 899
Reconfiguring Stacked Switches as VLT.......................................................................................................................900
Specifying VLT Nodes in a PVLAN.................................................................................................................................900
Configuring a VLT VLAN or LAG in a PVLAN............................................................................................................... 903
Creating a VLT LAG or a VLT VLAN.........................................................................................................................903
Associating the VLT LAG or VLT VLAN in a PVLAN..............................................................................................904
Proxy ARP Capability on VLT Peer Nodes.................................................................................................................... 905
VLT Nodes as Rendezvous Points for Multicast Resiliency........................................................................................906
Configuring VLAN-Stack over VLT................................................................................................................................ 906
IPv6 Peer Routing in VLT Domains Overview...............................................................................................................909
Configure BFD in VLT Domain......................................................................................................................................... 913
Sample BFD configuration in VLT domain................................................................................................................ 913
59 VLT Proxy Gateway................................................................................................................. 918
Proxy Gateway in VLT Domains.......................................................................................................................................918
LLDP VLT Proxy Gateway in a Square VLT Topology............................................................................................ 921
Configuring a Static VLT Proxy Gateway...................................................................................................................... 922
Contents
27
Configuring an LLDP VLT Proxy Gateway.....................................................................................................................922
VLT Proxy Gateway Sample Topology...........................................................................................................................922
VLT Domain Configuration.........................................................................................................................................923
Dell-1 VLT Configuration.............................................................................................................................................923
Dell-2 VLT Configuration............................................................................................................................................924
Dell-3 VLT Configuration............................................................................................................................................925
Dell-4 VLT Configuration............................................................................................................................................926
60 Virtual Extensible LAN (VXLAN)...............................................................................................927
Components of VXLAN network.................................................................................................................................... 928
Functional Overview of VXLAN Gateway......................................................................................................................928
VXLAN Frame Format......................................................................................................................................................929
Configuring and Controlling VXLAN from the NSX Controller GUI............................................................................930
Configuring VxLAN Gateway...........................................................................................................................................934
Connecting to an NVP Controller............................................................................................................................. 934
Advertising VXLAN Access Ports to Controller...................................................................................................... 935
Displaying VXLAN Configurations...................................................................................................................................935
Static Virtual Extensible LAN (VXLAN)......................................................................................................................... 936
Configuring Static VXLAN......................................................................................................................................... 936
Limitations on VXLAN ................................................................................................................................................937
Displaying Static VXLAN Configurations..................................................................................................................937
Disabling MAC Address Learning on Static VXLAN Tunnels.................................................................................938
Preserving 802.1 p value across VXLAN tunnels.......................................................................................................... 939
RIOT....................................................................................................................................................................................939
61 Virtual Routing and Forwarding (VRF)...................................................................................... 940
VRF Overview................................................................................................................................................................... 940
VRF Configuration Notes..................................................................................................................................................941
DHCP............................................................................................................................................................................ 942
VRF Configuration.............................................................................................................................................................942
Loading VRF CAM.......................................................................................................................................................942
Creating a Non-Default VRF Instance......................................................................................................................942
Assigning an Interface to a VRF................................................................................................................................ 943
Assigning a Front-end Port to a Management VRF............................................................................................... 943
View VRF Instance Information.................................................................................................................................943
Assigning an OSPF Process to a VRF Instance.......................................................................................................943
Configuring VRRP on a VRF Instance...................................................................................................................... 944
Configuring Management VRF..................................................................................................................................944
Configuring a Static Route.........................................................................................................................................945
Sample VRF Configuration...............................................................................................................................................945
Route Leaking VRFs......................................................................................................................................................... 950
Dynamic Route Leaking....................................................................................................................................................950
Configuring Route Leaking without Filtering Criteria.............................................................................................. 951
Configuring Route Leaking with Filtering................................................................................................................. 953
62 Virtual Router Redundancy Protocol (VRRP)............................................................................ 956
VRRP Overview................................................................................................................................................................ 956
VRRP Benefits...................................................................................................................................................................957
VRRP Implementation...................................................................................................................................................... 957
28
Contents
VRRP Configuration......................................................................................................................................................... 958
Configuration Task List...............................................................................................................................................958
Setting VRRP Initialization Delay...............................................................................................................................965
Sample Configurations..................................................................................................................................................... 966
VRRP in a VRF Configuration.................................................................................................................................... 970
VRRP for IPv6 Configuration.....................................................................................................................................975
63 Debugging and Diagnostics......................................................................................................979
Offline Diagnostics............................................................................................................................................................ 979
Important Points to Remember.................................................................................................................................979
Running Offline Diagnostics....................................................................................................................................... 979
Trace Logs......................................................................................................................................................................... 980
Auto Save on Crash or Rollover...................................................................................................................................... 980
Hardware Watchdog Timer............................................................................................................................................. 980
Enabling Environmental Monitoring................................................................................................................................980
Recognize an Overtemperature Condition.............................................................................................................. 982
Troubleshoot an Over-temperature Condition........................................................................................................982
Recognize an Under-Voltage Condition................................................................................................................... 982
Troubleshoot an Under-Voltage Condition.............................................................................................................. 983
Buffer Tuning.....................................................................................................................................................................983
Troubleshooting Packet Loss.......................................................................................................................................... 984
Displaying Drop Counters...........................................................................................................................................984
Dataplane Statistics.................................................................................................................................................... 985
Display Stack Member Counters...............................................................................................................................986
Enabling Application Core Dumps................................................................................................................................... 988
Mini Core Dumps...............................................................................................................................................................988
Enabling TCP Dumps........................................................................................................................................................989
64 Standards Compliance.............................................................................................................991
IEEE Compliance................................................................................................................................................................ 991
RFC and I-D Compliance..................................................................................................................................................992
General Internet Protocols.........................................................................................................................................992
General IPv4 Protocols...............................................................................................................................................993
General IPv6 Protocols...............................................................................................................................................994
Border Gateway Protocol (BGP)..............................................................................................................................995
Open Shortest Path First (OSPF)............................................................................................................................ 996
Intermediate System to Intermediate System (IS-IS)............................................................................................996
Routing Information Protocol (RIP).......................................................................................................................... 997
Multicast.......................................................................................................................................................................997
Network Management................................................................................................................................................998
MIB Location.................................................................................................................................................................... 1002
65 X.509v3................................................................................................................................1004
Introduction to X.509v3 certificates.............................................................................................................................1004
X.509v3 support in .........................................................................................................................................................1005
Information about installing CA certificates................................................................................................................. 1006
Installing CA certificate............................................................................................................................................. 1007
Information about Creating Certificate Signing Requests (CSR)............................................................................. 1007
Creating Certificate Signing Requests (CSR)........................................................................................................1007
Contents
29
Information about installing trusted certificates..........................................................................................................1008
Installing trusted certificates....................................................................................................................................1008
Transport layer security (TLS).......................................................................................................................................1008
Syslog over TLS.........................................................................................................................................................1009
Online Certificate Status Protocol (OSCP)................................................................................................................. 1009
Configuring OCSP setting on CA............................................................................................................................ 1009
Configuring OCSP behavior..................................................................................................................................... 1009
Configuring Revocation Behavior.............................................................................................................................1010
Configuring OSCP responder preference............................................................................................................... 1010
Verifying certificates........................................................................................................................................................1010
Verifying Server certificates......................................................................................................................................1010
Verifying Client Certificates...................................................................................................................................... 1010
Event logging.................................................................................................................................................................... 1010
30 Contents
1
About this Guide
This guide describes the protocols and features the Dell EMC Networking Operating System (OS) supports and provides configuration
instructions and examples for implementing them. For complete information about all the CLI commands, see the Dell EMC Command Line
Reference Guide for your system.
The S5048F-ON platform is available with Dell EMC Networking OS version 9.12(1.0) and beyond.
Though this guide contains information about protocols, it is not intended to be a complete reference. This guide is a reference for
configuring protocols on Dell EMC Networking systems. For complete information about protocols, see the related documentation,
including Internet Engineering Task Force (IETF) requests for comments (RFCs). The instructions in this guide cite relevant RFCs. The
Standards Compliance chapter contains a complete list of the supported RFCs and management information base files (MIBs).
Topics:
• Audience
• Conventions
• Related Documents
Audience
This document is intended for system administrators who are responsible for configuring and maintaining networks and assumes
knowledge in Layer 2 (L2) and Layer 3 (L3) networking technologies.
Conventions
This guide uses the following conventions to describe command syntax.
Keyword
parameter
{X} Keywords and parameters within braces must be entered in the CLI.
[X] Keywords and parameters within brackets are optional.
x|y Keywords and parameters separated by a bar require you to choose one option.
x||y Keywords and parameters separated by a double bar allows you to choose any or all of the options.
Keywords are in Courier (a monospaced font) and must be entered in the CLI as listed.
Parameters are in italics and require a number or word to be entered in the CLI.
Related Documents
For more information about the Dell EMC Networking switches, see the following documents:
• Dell EMC Networking OS Command Line Reference Guide
• Dell EMC Networking OS Installation Guide
• Dell EMC Networking OS Quick Start Guide
• Dell EMC Networking OS Release Notes
About this Guide 31
2
Configuration Fundamentals
The Dell EMC Networking Operating System (OS) command line interface (CLI) is a text-based interface you can use to configure
interfaces and protocols.
The CLI is largely the same for each platform except for some commands and command outputs. The CLI is structured in modes for
security and management purposes. Different sets of commands are available in each mode, and you can limit user access to modes using
privilege levels.
In the Dell EMC Networking OS, after you enter a command, the command is added to the running configuration file. You can view the
current configuration for the whole system or for a particular CLI mode. To save the current configuration, copy the running configuration
to another location.
NOTE: Due to differences in hardware architecture and continued system development, features may occasionally differ
between the platforms. Differences are noted in each CLI description and related documentation.
Topics:
• Accessing the Command Line
• CLI Modes
• The do Command
• Undoing Commands
• Obtaining Help
• Entering and Editing Commands
• Command History
• Filtering show Command Outputs
• Multiple Users in Configuration Mode
• Configuring alias command
Accessing the Command Line
Access the CLI through a serial console port or a Telnet session.
When the system successfully boots, enter the command line in EXEC mode.
NOTE:
you must use a console connection when connecting to the system for the first time.
telnet 172.31.1.53
Trying 172.31.1.53...
Connected to 172.31.1.53.
Escape character is '^]'.
Login: username
Password:
DellEMC>
You must have a password configured on a virtual terminal line before you can Telnet into the system. Therefore,
CLI Modes
Different sets of commands are available in each mode.
A command found in one mode cannot be executed from another mode (except for EXEC mode commands with a preceding do
command (refer to the do Command section).
You can set user access rights to commands and command modes using privilege levels.
The Dell EMC Networking OS CLI is divided into three major mode levels:
• EXEC mode is the default mode and has a privilege level of 1, which is the most restricted level. Only a limited selection of commands
is available, notably the show commands, which allow you to view system information.
32 Configuration Fundamentals
• EXEC Privilege mode has commands to view configurations, clear counters, manage configuration files, run diagnostics, and enable or
disable debug operations. The privilege level is 15, which is unrestricted. You can configure a password for this mode; refer to the
Configure the Enable Password section in the Getting Started chapter.
• CONFIGURATION mode allows you to configure security features, time settings, set logging and SNMP functions, configure static
ARP and MAC addresses, and set line cards on the system.
Beneath CONFIGURATION mode are submodes that apply to interfaces, protocols, and features. The following example shows the
submode command structure. Two sub-CONFIGURATION modes are important when configuring the chassis for the first time:
• INTERFACE submode is the mode in which you configure Layer 2 and Layer 3 protocols and IP services specific to an interface. An
interface can be physical (Management interface, 1 Gigabit Ethernet, 10 Gigabit Ethernet, 25 Gigabit Ethernet, 40 Gigabit Ethernet, 50
Gigabit Ethernet, or 100 Gigabit Ethernet) or logical (Loopback, Null, port channel, or virtual local area network [VLAN]).
• LINE submode is the mode in which you to configure the console and virtual terminal lines.
NOTE: At any time, entering a question mark (?) displays the available command options. For example, when you are in
CONFIGURATION mode, entering the question mark first lists all available commands, including the possible submodes.
The CLI modes are:
EXEC
EXEC Privilege
CONFIGURATION
AS-PATH ACL
CONTROL-PLANE
CLASS-MAP
DCB POLICY
DHCP
DHCP POOL
ECMP-GROUP
EXTENDED COMMUNITY
FRRP
INTERFACE
GIGABIT ETHERNET
10 GIGABIT ETHERNET
40 GIGABIT ETHERNET
25 Gigabit Ethernet
50 Gigabit Ethernet
100 Gigabit Ethernet
INTERFACE RANGE
LOOPBACK
MANAGEMENT ETHERNET
NULL
PORT-CHANNEL
TUNNEL
VLAN
VRRP
IP
IPv6
IP COMMUNITY-LIST
IP ACCESS-LIST
STANDARD ACCESS-LIST
EXTENDED ACCESS-LIST
MAC ACCESS-LIST
LINE
AUXILLIARY
CONSOLE
VIRTUAL TERMINAL
LLDP
LLDP MANAGEMENT INTERFACE
MONITOR SESSION
MULTIPLE SPANNING TREE
OPENFLOW INSTANCE
PVST
PORT-CHANNEL FAILOVER-GROUP
PREFIX-LIST
PRIORITY-GROUP
PROTOCOL GVRP
QOS POLICY
RSTP
ROUTE-MAP
ROUTER BGP
BGP ADDRESS-FAMILY
Configuration Fundamentals
33
ROUTER ISIS
ISIS ADDRESS-FAMILY
ROUTER OSPF
ROUTER OSPFV3
ROUTER RIP
SPANNING TREE
TRACE-LIST
VLT DOMAIN
VRRP
UPLINK STATE GROUP
GRUB
Navigating CLI Modes
The Dell EMC Networking OS prompt changes to indicate the CLI mode.
The following table lists the CLI mode, its prompt, and information about how to access and exit the CLI mode. Move linearly through the
command modes, except for the end command which takes you directly to EXEC Privilege mode and the exit command which moves
you up one command mode level.
NOTE: Sub-CONFIGURATION modes all have the letters conf in the prompt with more modifiers to identify the mode
and slot/port/subport information.
Table 1. Dell EMC Networking OS Command Modes
CLI Command Mode Prompt Access Command
EXEC
EXEC Privilege
DellEMC>
DellEMC#
Access the router through the console or
terminal line.
• From EXEC mode, enter the enable
command.
• From any other mode, use the end
command.
CONFIGURATION
NOTE: Access all of the following
modes from CONFIGURATION
mode.
AS-PATH ACL
10 Gigabit Ethernet Interface
25 Gigabit Ethernet Interface
40 Gigabit Ethernet Interface
50 Gigabit Ethernet Interface
100 Gigabit Ethernet Interface
Interface Group
Interface Range
Loopback Interface
Management Ethernet Interface
Null Interface
Port-channel Interface
Tunnel Interface
DellEMC(conf)#
DellEMC(config-as-path)# ip as-path access-list
DellEMC(conf-if-te-1/49/1)#
DellEMC(conf-if-tf-1/1)#
DellEMC(conf-if-fo-1/49/1)#
DellEMC(conf-if-fi-1/49/1)#
DellEMC(conf-if-hu-1/49)#
DellEMC(conf-if-group)# interface(INTERFACE modes)
DellEMC(conf-if-range)#
DellEMC(conf-if-lo-0)#
DellEMC(conf-if-ma-1/1)#
DellEMC(conf-if-nu-0)#
DellEMC(conf-if-po-1)#
DellEMC(conf-if-tu-1)#
• From EXEC privilege mode, enter the
configure command.
• From every mode except EXEC and
EXEC Privilege, enter the exit
command.
interface (INTERFACE modes)
interface(INTERFACE modes)
interface (INTERFACE modes)
interface(INTERFACE modes)
interface(INTERFACE modes)
interface (INTERFACE modes)
interface (INTERFACE modes)
interface (INTERFACE modes)
interface (INTERFACE modes)
interface (INTERFACE modes)
interface (INTERFACE modes)
34 Configuration Fundamentals
CLI Command Mode Prompt Access Command
VLAN Interface
STANDARD ACCESS-LIST
EXTENDED ACCESS-LIST
IP COMMUNITY-LIST
AUXILIARY
CONSOLE
VIRTUAL TERMINAL
STANDARD ACCESS-LIST
EXTENDED ACCESS-LIST
MULTIPLE SPANNING TREE
Per-VLAN SPANNING TREE Plus
PREFIX-LIST
RAPID SPANNING TREE
REDIRECT
ROUTE-MAP
ROUTER BGP
BGP ADDRESS-FAMILY
DellEMC(conf-if-vl-1)#
DellEMC(config-std-nacl)#
DellEMC(config-ext-nacl)#
DellEMC(config-community-list)# ip community-list
DellEMC(config-line-aux)#
DellEMC(config-line-console)#
DellEMC(config-line-vty)#
DellEMC(config-std-macl)#
DellEMC(config-ext-macl)#
DellEMC(config-mstp)# protocol spanning-tree mstp
DellEMC(config-pvst)# protocol spanning-tree pvst
DellEMC(conf-nprefixl)# ip prefix-list
DellEMC(config-rstp)# protocol spanning-tree rstp
DellEMC(conf-redirect-list)# ip redirect-list
DellEMC(config-route-map)# route-map
DellEMC(conf-router_bgp)# router bgp
DellEMC(conf-router_bgp_af)#
(for IPv4)
DellEMC(conf-routerZ_bgpv6_af)#
(for IPv6)
interface (INTERFACE modes)
ip access-list standard (IP
ACCESS-LIST Modes)
ip access-list extended (IP
ACCESS-LIST Modes)
line (LINE Modes)
line (LINE Modes)
line (LINE Modes)
mac access-list standard (MAC
ACCESS-LIST Modes)
mac access-list extended (MAC
ACCESS-LIST Modes)
address-family {ipv4 multicast
| ipv6 unicast} (ROUTER BGP
Mode)
ROUTER ISIS
ISIS ADDRESS-FAMILY
ROUTER OSPF
ROUTER OSPFV3
ROUTER RIP
SPANNING TREE
TRACE-LIST
CLASS-MAP
CONTROL-PLANE
DHCP
DHCP POOL
ECMP
EIS
FRRP
LLDP DellEMC(conf-lldp)# or
DellEMC(conf-router_isis)# router isis
DellEMC(conf-router_isisaf_ipv6)#
DellEMC(conf-router_ospf)# router ospf
DellEMC(conf-ipv6router_ospf)# ipv6 router ospf
DellEMC(conf-router_rip)# router rip
DellEMC(config-span)# protocol spanning-tree 0
DellEMC(conf-trace-acl)# ip trace-list
DellEMC(config-class-map)# class-map
DellEMC(conf-control-cpuqos)# control-plane-cpuqos
DellEMC(config-dhcp)# ip dhcp server
DellEMC(config-dhcp-pool-name)#
DellEMC(conf-ecmp-group-ecmp-
group-id)#
DellEMC(conf-mgmt-eis)# management egress-interface-
DellEMC(conf-frrp-ring-id)# protocol frrp
DellEMC(conf-if—interfacelldp)#
address-family ipv6 unicast
(ROUTER ISIS Mode)
pool (DHCP Mode)
ecmp-group
selection
protocol lldp (CONFIGURATION or
INTERFACE Modes)
Configuration Fundamentals 35
CLI Command Mode Prompt Access Command
LLDP MANAGEMENT INTERFACE
DellEMC(conf-lldp-mgmtIf)#
management-interface (LLDP Mode)
LINE DellEMC(config-line-console) or
DellEMC(config-line-vty)
MONITOR SESSION
OPENFLOW INSTANCE
PORT-CHANNEL FAILOVER-GROUP
PRIORITY GROUP
PROTOCOL GVRP
QOS POLICY
SUPPORTASSIST
VLT DOMAIN
VRRP
UPLINK STATE GROUP
The following example shows how to change the command mode from CONFIGURATION mode to PROTOCOL SPANNING TREE.
Example of Changing Command Modes
DellEMC(conf-mon-sesssessionID)#
DellEMC(conf-of-instance-of-
id)#
DellEMC(conf-po-failover-grp)# port-channel failover-group
DellEMC(conf-pg)# priority-group
DellEMC(config-gvrp)# protocol gvrp
DellEMC(conf-qos-policy-outets)#
DellEMC(support-assist)# support-assist
DellEMC(conf-vlt-domain)# vlt domain
DellEMC(conf-if-interface-typeslot/port-vrid-vrrp-group-id)#
DellEMC(conf-uplink-stategroup-groupID)#
line console orline vty
monitor session
openflow of-instance
qos-policy-output
vrrp-group
uplink-state-group
DellEMC(conf)#protocol spanning-tree 0
DellEMC(config-span)#
The do Command
You can enter an EXEC mode command from any CONFIGURATION mode (CONFIGURATION, INTERFACE, SPANNING TREE, and so
on.) without having to return to EXEC mode by preceding the EXEC mode command with the do command.
The following example shows the output of the do command.
DellEMC(conf)#do show system brief
Stack MAC : 34:17:eb:37:2d:00
Reload-Type : normal-reload [Next boot : normal-reload]
-- Stack Info -Unit UnitType Status ReqTyp CurTyp Version Ports
----------------------------------------------------------------------------------- 1 Management online S5048F-ON S5048F-ON 9-12(1-28) 72
2 Member not present
3 Member not present
4 Member not present
5 Member not present
6 Member not present
-- Power Supplies -Unit Bay Status Type FanStatus FanSpeed Power AvgPower AvgPowerStartTime
------------------------------------------------------------------------------------------- 1 1 up AC up 26144 119 119 10/08/2017-16:11
1 2 up AC up 26848 133 133 10/08/2017-16:11
-- Fan Status -Unit Bay TrayStatus Fan1 Speed Fan2 Speed
----------------------------------------------------------------------------------- 1 1 up up 21370 up 22341
36
Configuration Fundamentals
1 2 up up 21254 up 21967
1 3 up up 21605 up 22090
1 4 up up 21487 up 22090
Speed in RPM
Undoing Commands
When you enter a command, the command line is added to the running configuration file (running-config).
To disable a command and remove it from the running-config, enter the no command, then the original command. For example, to delete
an IP address configured on an interface, use the no ip address ip-address command.
NOTE: Use the help or ? command as described in Obtaining Help.
Example of Viewing Disabled Commands
DellEMC(conf)#interface twentyFiveGigE 1/17
DellEMC(conf-if-tf-1/17)#ip address 192.168.10.1/24
DellEMC(conf-if-tf-1/17)#show config
!
interface twentyFiveGigE 1/17
ip address 192.168.10.1/24
no shutdown
DellEMC(conf-if-tf-1/17)#no ip address
DellEMC(conf-if-tf-1/17)#show config
!
interface twentyFiveGigE 1/17
no ip address
no shutdown
Layer 2 protocols are disabled by default. To enable Layer 2 protocols, use the no disable command. For example, in PROTOCOL
SPANNING TREE mode, enter no disable to enable Spanning Tree.
Obtaining Help
Obtain a list of keywords and a brief functional description of those keywords at any CLI mode using the ? or help command:
• To list the keywords available in the current mode, enter ? at the prompt or after a keyword.
• Enter ? after a command prompt to list all of the available keywords. The output of this command is the same as the help command.
DellEMC#?
bmp BMP commands
cd Change current directory
clear Reset functions
clock Manage the system clock
• Enter ? after a partial keyword lists all of the keywords that begin with the specified letters.
DellEMC(conf)#cl?
class-map
clock
DellEMC(conf)#cl
• Enter [space]? after a keyword lists all of the keywords that can follow the specified keyword.
DellEMC(conf)#clock ?
summer-time Configure summer (daylight savings) time
timezone Configure time zone
DellEMC(conf)#clock
Configuration Fundamentals
37
Entering and Editing Commands
Notes for entering commands.
• The CLI is not case-sensitive.
• You can enter partial CLI keywords.
• Enter the minimum number of letters to uniquely identify a command. For example, you cannot enter cl as a partial keyword
because both the clock and class-map commands begin with the letters “cl.” You can enter clo, however, as a partial
keyword because only one command begins with those three letters.
• The TAB key auto-completes keywords in commands. Enter the minimum number of letters to uniquely identify a command.
• The UP and DOWN arrow keys display previously entered commands (refer to Command History).
• The BACKSPACE and DELETE keys erase the previous letter.
• Key combinations are available to move quickly across the command line. The following table describes these short-cut key
combinations.
Short-Cut Key
Action
Combination
CNTL-A Moves the cursor to the beginning of the command line.
CNTL-B Moves the cursor back one character.
CNTL-D Deletes character at cursor.
CNTL-E Moves the cursor to the end of the line.
CNTL-F Moves the cursor forward one character.
CNTL-I Completes a keyword.
CNTL-K Deletes all characters from the cursor to the end of the command line.
CNTL-L Re-enters the previous command.
CNTL-N Return to more recent commands in the history buffer after recalling commands with CTRL-P or the UP arrow
key.
CNTL-P Recalls commands, beginning with the last command.
CNTL-R Re-enters the previous command.
CNTL-U Deletes the line.
CNTL-W Deletes the previous word.
CNTL-X Deletes the line.
CNTL-Z Ends continuous scrolling of command outputs.
Esc B Moves the cursor back one word.
Esc F Moves the cursor forward one word.
Esc D Deletes all characters from the cursor to the end of the word.
Command History
The Dell EMC Networking OS maintains a history of previously-entered commands for each mode. For example:
• When you are in EXEC mode, the UP and DOWN arrow keys display the previously-entered EXEC mode commands.
• When you are in CONFIGURATION mode, the UP or DOWN arrows keys recall the previously-entered CONFIGURATION mode
commands.
38
Configuration Fundamentals
Filtering show Command Outputs
Filter the output of a show command to display specific information by adding | [except | find | grep | no-more | save]
specified_text after the command.
The variable specified_text is the text for which you are filtering and it IS case sensitive unless you use the ignore-case suboption.
Starting with Dell EMC Networking OS version 7.8.1.0, the grep command accepts an ignore-case sub-option that forces the search
to case-insensitive. For example, the commands:
show run | grep Ethernet returns a search result with instances containing a capitalized “Ethernet,” such as interface
•
TenGigabitEthernet 1/49/1.
• show run | grep ethernet does not return that search result because it only searches for instances containing a noncapitalized “ethernet.”
• show run | grep Ethernet ignore-case returns instances containing both “Ethernet” and “ethernet.”
The grep command displays only the lines containing specified text. The following example shows this command used in combination with
the show system brief command.
Example of the grep Keyword
DellEMC(conf)#do show system brief | grep 2
2 not present
DellEMC(conf)#do show system brief | grep 0
0 not present
DellEMC#show system brief | grep Management
1 Management online S5048F-ON S5048F-ON 9.12(1.0) 72
DellEMC#
NOTE:
underscores, or ranges, enclose the phrase with double quotation marks.
The except keyword displays text that does not match the specified text. The following example shows this command used in
combination with the show system brief command.
Example of the except Keyword
DellEMC#show system brief | except 1
Stack MAC : 4c:76:25:e5:49:40
Reload-Type : normal-reload [Next boot : normal-reload]
The find keyword displays the output of the show command beginning from the first occurrence of specified text. The following
example shows this command used in combination with the
Example of the find Keyword
DellEMC#show system brief | find Management
1 Management online S5048F-ON S5048F-ON 9-12(1-28) 72
2 Member not present
3 Member not present
4 Member not present
5 Member not present
6 Member not present
Dell EMC Networking OS accepts a space or no space before and after the pipe. To filter a phrase with spaces,
show system brief command.
-- Power Supplies -Unit Bay Status Type FanStatus FanSpeed Power AvgPower AvgPowerStartTime
------------------------------------------------------------------------------------------- 1 1 up AC up 26144 119 119 10/08/2017-16:11
1 2 up AC up 26816 133 133 10/08/2017-16:11
-- Fan Status --
Configuration Fundamentals
39
Unit Bay TrayStatus Fan1 Speed Fan2 Speed
----------------------------------------------------------------------------------- 1 1 up up 21370 up 22215
1 2 up up 21254 up 21967
1 3 up up 21605 up 22090
1 4 up up 21487 up 22215
Speed in RPM
The display command displays additional configuration information.
The no-more command displays the output all at once rather than one screen at a time. This is similar to the terminal length
command except that the no-more option affects the output of the specified command only.
The save command copies the output to a file for future reference.
NOTE: You can filter a single command output multiple times. The save option must be the last option entered. For
example: DellEMC# command | grep regular-expression | except regular-expression | grep other-
regular-expression | find regular-expression | save.
Multiple Users in Configuration Mode
Dell EMC Networking OS notifies all users when there are multiple users logged in to CONFIGURATION mode.
A warning message indicates the username, type of connection (console or VTY), and in the case of a VTY connection, the IP address of
the terminal on which the connection was established. For example:
• On the system that telnets into the switch, this message appears:
% Warning: The following users are currently configuring the system:
User "<username>" on line console0
• On the system that is connected over the console, this message appears:
% Warning: User "<username>" on line vty0 "10.11.130.2" is in configuration mode
If either of these messages appears, Dell EMC Networking recommends coordinating with the users listed in the message so that you do
not unintentionally overwrite each other’s configuration changes.
Configuring alias command
You can configure shorter alias names for single–line command input using the alias command.
To configure the alias name, perform the following steps:
1. Configure the terminal to enter the Global Configuration mode.
EXEC Privilege mode
DellEMC#configure terminal
2. Configure the system to enter the alias-definition mode.
CONFIGURATION mode
DellEMC(conf)#alias-definition
3. Create the alias name followed by the single–line CLI.
ALIAS DEFINITION CONFIGURATION mode
DellEMC(conf-alias-definition)#alias sr show running-config
4. Display the aliases and its definition.
EXEC Privilege mode
show alias
Example of the show alias Command
DellEMC# configure terminal
DellEMC(config)# alias-definition
DellEMC(conf-alias-definition)# alias ns no shutdown
DellEMC(conf-alias-definition)# alias 10gint interface wentyFiveGigE $1
40
Configuration Fundamentals
Viewing alias configuration
To view the Alias configurations, use the following commands:
1. Display the complete list of aliases and its definitions.
EXEC Privilege mode
DellEMC#show alias
DellEMC# show alias
----------------------------------------------------------------Alias Name Definition
----------------------------------------------------------------showipbr10 show ip interface brief | ….
showipbr40 show ip interface brief | ….
shboot show bootvar…
cr-vlan interface vlan $1 ..
----------------------------------------------------------------Total Alias Configured : 4
-----------------------------------------------------------------
NOTE: The alias definition displays upto 40 characters and you can view the detailed list of definitions using the
details option.
2. Display the details of all the aliases that are configured on the system.
EXEC Privilege mode
DellEMC#show alias details
DellEMC# show alias details
-----------------------------------------------------------------Name: showipbr10
Definition:
show ip interface brief | grep tengig ignore-case
------------------------------------------------------------------
-----------------------------------------------------------------Name: showipbr40
Definition:
show ip interface brief | grep fortygig ignore-case
-----------------------------------------------------------------DellEMC#
3. Display the details of a specific alias.
EXEC Privilege mode
DellEMC#show alias details showipbr10
DellEMC# show alias details showipbr10
-----------------------------------------------------------------Name: showipbr10
Definition:
show ip interface brief | grep tengig ignore-case
-----------------------------------------------------------------DellEMC#
Configuration Fundamentals
41
Getting Started
This chapter describes how you start configuring your system.
When you power up the chassis, the system performs a power-on self test (POST) and system then loads the Dell EMC Networking
Operating System. Boot messages scroll up the terminal window during this process. No user interaction is required if the boot process
proceeds without interruption.
When the boot process completes, the system status LEDs remain online (green) and the console monitor displays the EXEC mode
prompt.
For details about using the command line interface (CLI), refer to the Accessing the Command Line section in the Configuration
Fundamentals chapter.
Topics:
• Console Access
• Default Configuration
• Configuring a Host Name
• Accessing the System Remotely
• Configuring the Enable Password
• Configuration File Management
• Managing the File System
• View Command History
• Upgrading Dell EMC Networking OS
• Using HTTP for File Transfers
• Verify Software Images Before Installation
3
Console Access
The device has one RJ-45/RS-232 console port, an out-of-band (OOB) Ethernet port, and a micro USB-B console port.
Serial Console
The management ports are on the middle of the system as you face the I/O side of the chassis, as shown in the following illustration. The
upper port is the management ethernet port and the lower port is the RS-232 console port.
Figure 1. RJ-45 Console Port
1. RJ-45 management port.
Accessing the Console Port
To access the console port, follow these steps:
For the console port pinout, refer to Accessing the RJ-45 Console Port with a DB-9 Adapter.
42 Getting Started
1. Install an RJ-45 copper cable into the console port. Use a rollover (crossover) cable to connect the console port to a terminal server.
2. Connect the other end of the cable to the DTE terminal server.
3. Terminal settings on the console port cannot be changed in the software and are set as follows:
• 115200 baud rate
• No parity
• 8 data bits
• 1 stop bit
• No flow control
Pin Assignments
You can connect to the console using a RJ-45 to RJ-45 rollover cable and a RJ-45 to DB-9 female DTE adapter to a terminal server (for
example, a PC).
The pin assignments between the console and a DTE terminal server are as follows:
Table 2. Pin Assignments Between the Console and a DTE Terminal Server
Console Port RJ-45 to RJ-45
Rollover Cable
Signal RJ-45 Pinout RJ-45 Pinout DB-9 Pin Signal
RTS 1 8 8 CTS
NC 2 7 6 DSR
TxD 3 6 2 RxD
GND 4 5 5 GND
GND 5 4 5 GND
RxD 6 3 3 TxD
NC 7 2 4 DTR
CTS 8 1 7 RTS
RJ-45 to RJ-45
Rollover Cable
RJ-45 to DB-9 Adapter Terminal Server Device
Micro USB-B Access
The Micro USB type B console port is on the I/O side.
The terminal settings are the same for the serial console port and the RS-232/RJ-45 console port:
• 115200 baud rate
• No parity
• 8 data bits
• 1 stop bit
• No flow control
When you connect the micro USB-B port, it becomes the primary connection and, while connected, all messages are sent to the micro
USB-B port.
NOTE:
You need to install the appropriate drivers to support the micro USB-B port. For assistance, contact https://
www.dell.com/support to download the drivers.
To access the micro USB-B console port, follow these steps.
1. Power on the PC.
2. Connect the USB-A end of cable into an available USB port on the PC.
3. Connect the micro USB-B end of cable into the micro USB-B console port on the system.
4. Power on the system.
5. Install the necessary USB device drivers. (To download the drivers, go to https://www.dell.com/support.)
For assistance, contact Dell EMC Networking Technical Support.
6. Open your terminal software emulation program to access the system.
Before starting this procedure, be sure that you have a terminal emulation program already installed on your PC.
Getting Started
43
7. Confirm that the terminal settings on your terminal software emulation program are as follows:
• 115200 baud rate
• No parity
• 8 data bits
• 1 stop bit
• No flow control
Default Configuration
Although a version of Dell EMC Networking OS is pre-loaded onto the system, the system is not configured when you power up the
system first time (except for the default hostname, which is DellEMC). You must configure the system using the CLI.
Configuring a Host Name
The host name appears in the prompt. The default host name is DellEMC.
• Host names must start with a letter and end with a letter or digit.
• Characters within the string can be letters, digits, and hyphens.
To create a host name, use the hostname name command in Configuration mode.
DellEMC(conf)#hostname R1
R1(conf)#
Accessing the System Remotely
You can configure the system to access it remotely by Telnet or secure shell (SSH).
• The platform has a dedicated management port and a management routing table that is separate from the IP routing table.
• You can manage all Dell EMC Networking products in-band via the front-end data ports through interfaces assigned an IP address as
well.
Accessing the System Remotely
Configuring the system for remote access is a three-step process, as described in the following topics:
1. Configure an IP address for the management port. Configure the Management Port IP Address
2. Configure a management route with a default gateway. Configure a Management Route
3. Configure a username and password. Configure a Username and Password
Configure the Management Port IP Address
To access the system remotely, assign IP addresses to the management ports.
1. Enter INTERFACE mode for the Management port.
CONFIGURATION mode
interface ManagementEthernet slot/port
2. Assign an IP address to the interface.
INTERFACE mode
ip address ip-address/mask
• ip-address: an address in dotted-decimal format (A.B.C.D).
• mask: a subnet mask in /prefix-length format (/ xx).
3. Enable the interface.
INTERFACE mode
no shutdown
44
Getting Started
Configure a Management Route
Define a path from the system to the network from which you are accessing the system remotely. Management routes are separate from
IP routes and are only used to manage the system through the management port.
To configure a management route, use the following command.
• Configure a management route to the network from which you are accessing the system.
CONFIGURATION mode
management route ip-address/mask gateway
• ip-address: the network address in dotted-decimal format (A.B.C.D).
• mask: a subnet mask in /prefix-length format (/ xx).
• gateway: the next hop for network traffic originating from the management port.
Configuring a Username and Password
To access the system remotely, configure a system username and password.
To configure a system username and password, use the following command.
• Configure a username and password to access the system remotely.
CONFIGURATION mode
username name [access-class access-list-name] [nopassword | {password | secret | sha256–
password} [encryption-type] password [dynamic-salt]] [privilege level] [role role-name]
• name: Enter a text string upto 63 characters long.
• access-class access-list-name: Enter the name of a configured IP ACL.
• nopassword: Allows you to configure an user without the password.
• password: Allows you to configure an user with a password.
• secret: Specify a secret string for an user.
• sha256–password: Uses sha256–based encryption method for password.
• encryption-type: Enter the encryption type for securing an user password. There are four encryption types.
• 0 — input the password in clear text.
• 5 — input the password that is already encrypted using MD5 encryption method.
• 7 — input the password that is already encrypted using DES encryption method.
• 8 — input the password that is already encrypted using sha256–based encryption method.
• password: Enter the password string for the user.
• dynamic-salt: Generates an additional random input to password encryption process whenever the password is configured.
• privilege level: Assign a privilege levels to the user. The range is from 0 to 15.
• role role-name: Assign a role name for the user.
Dell EMC Networking OS encrypts type 5 secret and type 7 password based on dynamic-salt option such that the encrypted
password is different when an user is configured with the same password.
NOTE:
dynamic-salt option is shown only with secret and password options.
In dynamic-salt configuration, the length of type 5 secret and type 7 password is 32 and 16 characters more compared to the
secret and password length without dynamic-salt configuration. An error message appears if the
maximum length, which is 256 characters.
The dynamic-salt support for the user configuration is added in REST API. For more information on REST support, see Dell EMC
Networking Open Automation guide.
username command reaches the
Configuring the Enable Password
Access EXEC Privilege mode using the enable command. EXEC Privilege mode is unrestricted by default. Configure a password as a
basic security measure.
There are three types of enable passwords:
Getting Started
45
• enable password is stored in the running/startup configuration using a DES encryption method.
• enable secret is stored in the running/startup configuration using MD5 encryption method.
• enable sha256-password is stored in the running/startup configuration using sha256-based encryption method (PBKDF2).
Dell EMC Networking recommends using the enable sha256-password password.
To configure an enable password, use the following command.
• Create a password to access EXEC Privilege mode.
CONFIGURATION mode
enable [password | secret | sha256-password] [level level] [encryption-type] password
level: is the privilege level, is 15 by default, and is not required.
•
• encryption-type: specifies how you input the password, is 0 by default, and is not required.
• 0 is to input the password in clear text.
• 5 is to input a password that is already encrypted using MD5 encryption method. Obtain the encrypted password from the
configuration file of another device.
• 7 is to input a password that is already encrypted using DES encryption method. Obtain the encrypted password from the
configuration file of another device.
• 8 is to input a password that is already encrypted using sha256-based encryption method. Obtain the encrypted password
from the configuration file of another device.
Configuration File Management
Files can be stored on and accessed from various storage media. Rename, delete, and copy files on the system from EXEC Privilege mode.
Copy Files to and from the System
The command syntax for copying files is similar to UNIX. The copy command uses the format copy source-file-url
destination-file-url.
NOTE:
• To copy a local file to a remote system, combine the file-origin syntax for a local file location with the file-destination syntax for a
remote file location.
• To copy a remote file to Dell EMC Networking system, combine the file-origin syntax for a remote file location with the file-destination
syntax for a local file location.
Table 3. Forming a
Location
For a remote file location:
FTP server
For a remote file location:
TFTP server
For a remote file location:
SCP server
For a detailed description of the copy command, refer to the
copy Command
source-file-url
copy ftp://
username:password@{hostip |
hostname}/filepath/filename
copy tftp://{hostip |
hostname}/filepath/ filename
copy scp://{hostip | hostname}/
filepath/ filename
Syntax
Important Points to Remember
Dell EMC Networking OS Command Reference
destination-file-url
ftp://username:password@{hostip
| hostname}/ filepath/filename
tftp://{hostip | hostname}/
filepath/filename
scp://{hostip | hostname}/
filepath/filename
Syntax
.
• You may not copy a file from one remote system to another.
• You may not copy a file from one location to the same location.
• When copying to a server, you can only use a hostname if a domain name server (DNS) server is configured.
• The usbflash command is supported on the device. Refer to your system’s Release Notes for a list of approved USB vendors.
46
Getting Started
Example of Copying a File to an FTP Server
DellEMC#copy flash://FTOS-S5048F-ON-9.12.1.0.bin ftp://myusername:mypassword@10.10.10.10/
/Dell/FTOS-S5048F-ON-9.12.1.0.bin
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
27952672 bytes successfully copied
DellEMC#copy flash://Dell-EF-8.2.1.0.bin ftp://myusername:mypassword@10.10.10.10/
/Dell/Dell-EF-8.2.1.0
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
27952672 bytes successfully copied
DellEMC#copy flash://FTOS-S5048F-ON-9.12.1.0.bin ftp://myusername:mypassword@192.168.1.1/
file_path/FTOS-S5048F-ON-9.12.1.0.bin
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
54238335 bytes successfully copied
Example of Importing a File to the Local System
core1#$//copy ftp://myusername:mypassword@10.10.10.10//Dell/
FTOS-S5048F-ON-9.12.1.0.bin flash://
Destination file name [FTOS-S5048F-ON-9.12.1.0.bin]:
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
26292881 bytes successfully copied
core1#$//copy ftp://myusername:mypassword@10.10.10.10//Dell/
Dell-EF-8.2.1.0.bin flash://
Destination file name [Dell-EF-8.2.1.0.bin.bin]:
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
26292881 bytes successfully copied
DellEMC#copy ftp://myusername:mypassword@192.168.1.1/file_path/FTOS-Z9100-ON-9.8.1.0.bin
flash://FTOS-S5048F-ON-9.12.1.0.bin
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
54238335 bytes successfully copied
Mounting an NFS File System
This feature enables you to quickly access data on an NFS mounted file system. You can perform file operations on an NFS mounted file
system using supported file commands.
This feature allows an NFS mounted device to be recognized as a file system. This file system is visible on the device and you can execute
all file commands that are available on conventional file systems such as a Flash file system.
Before executing any CLI command to perform file operations, you must first mount the NFS file system to a mount-point on the device.
Since multiple mount-points exist on a device, it is mandatory to specify the mount-point to which you want to load the system.
/f10/mnt/nfs directory is the root of all mount-points.
The
To mount an NFS file system, perform the following steps:
Table 4. Mounting an NFS File System
File Operation Syntax
To mount an NFS file system:
The foreign file system remains mounted as long as the device is up and does not reboot. You can run the file system commands without
having to mount or un-mount the file system each time you run a command. When you save the configuration using the write command,
the
mount command is saved to the startup configuration. As a result, each time the device re-boots, the NFS file system is mounted
during start up.
mount nfs rhost:path mountpoint username password
Getting Started
47
Table 5. Forming a copy Command
Location
For a remote file location:
NFS File System
source-file-url
copy nfsmount://{<mountpoint>}/filepath/filename}
username:password
Syntax
destination-file-url
tftp://{hostip | hostname}/
filepath/filename
Syntax
Important Points to Remember
• You cannot copy a file from one remote system to another.
• You cannot copy a file from one location to the same location.
• When copying to a server, you can only use a hostname if a domain name server (DNS) server is configured.
Example of Copying a File to current File System
DellEMC#copy tftp://10.16.127.35/dv-maa-test nfsmount://
Destination file name [dv-maa-test]:
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!.!
44250499 bytes successfully copied
DellEMC#
DellEMC#copy ftp://10.16.127.35 nfsmount:
Source file name []: test.c
User name to login remote host: username
Example of Logging in to Copy from NFS Mount
DellEMC#copy nfsmount:///test flash:
Destination file name [test]: test2
!
5592 bytes successfully copied
DellEMC#
DellEMC#copy nfsmount:///test.txt ftp://10.16.127.35
Destination file name [test.txt]:
User name to login remote host: username
Password to login remote host:
!
Example of Copying to NFS Mount
DellEMC#copy flash://test.txt nfsmount:///
Destination file name [test.txt]:
!
15 bytes successfully copied
DellEMC#copy flash://test/capture.txt.pcap nfsmount:///
Destination file name [test.txt]:
!
15 bytes successfully copied
DellEMC#copy flash://test/capture.txt.pcap nfsmount:///username/snoop.pcap
!
24 bytes successfully copied
DellEMC#
DellEMC#copy tftp://10.16.127.35/username/dv-maa-test ?
flash: Copy to local file system ([flash://]filepath)
nfsmount: Copy to nfs mount file system (nfsmount:///filepath)
running-config remote host:
Destination file name [test.c]:
!
225 bytes successfully copied
DellEMC#
48
Getting Started
Save the Running-Configuration
The running-configuration contains the current system configuration. Dell EMC Networking recommends coping your runningconfiguration to the startup-configuration.
The commands in this section follow the same format as those commands in the Copy Files to and from the System section but use the
filenames startup-configuration and running-configuration. These commands assume that current directory is the internal flash, which is
the system default.
• Save the running-configuration to the startup-configuration on the internal flash of the primary RPM.
EXEC Privilege mode
copy running-config startup-config
• Save the running-configuration to an FTP server.
EXEC Privilege mode
copy running-config ftp:// username:password@{hostip | hostname}/filepath/ filename
• Save the running-configuration to a TFTP server.
EXEC Privilege mode
copy running-config tftp://{hostip | hostname}/ filepath/filename
• Save the running-configuration to an SCP server.
EXEC Privilege mode
copy running-config scp://{hostip | hostname}/ filepath/filename
NOTE:
NOTE: When you load the startup configuration or a configuration file from a network server such as TFTP to the
running configuration, the configuration is added to the running configuration. This does not replace the existing
running configuration. Commands in the configuration file has precedence over commands in the running configuration.
When copying to a server, a host name can only be used if a DNS server is configured.
Configure the Overload Bit for a Startup Scenario
For information about setting the router overload bit for a specific period of time after a switch reload is implemented, see the
Intermediate System to Intermediate System (IS-IS) section in the Dell Command Line Reference Guide for your system.
Viewing Files
You can only view file information and content on local file systems.
To view a list of files or the contents of a file, use the following commands.
• View a list of files on the internal flash.
EXEC Privilege mode
dir flash:
• View the running-configuration.
EXEC Privilege mode
show running-config
• View the startup-configuration.
EXEC Privilege mode
show startup-config
The output of the dir command also shows the read/write privileges, size (in bytes), and date of modification for each file.
DellEMC#dir
Directory of flash:
1 drw- 32768 Jan 01 1980 00:00:00 .
2 drwx 512 Jul 23 2007 00:38:44 ..
3 drw- 8192 Mar 30 1919 10:31:04 TRACE_LOG_DIR
4 drw- 8192 Mar 30 1919 10:31:04 CRASH_LOG_DIR
5 drw- 8192 Mar 30 1919 10:31:04 NVTRACE_LOG_DIR
6 drw- 8192 Mar 30 1919 10:31:04 CORE_DUMP_DIR
7 d--- 8192 Mar 30 1919 10:31:04 ADMIN_DIR
Getting Started
49
8 -rw- 33059550 Jul 11 2007 17:49:46 FTOS-EF-7.4.2.0.bin
9 -rw- 27674906 Jul 06 2007 00:20:24 FTOS-EF-4.7.4.302.bin
10 -rw- 27674906 Jul 06 2007 19:54:52 boot-image-FILE
11 drw- 8192 Jan 01 1980 00:18:28 diag
12 -rw- 7276 Jul 20 2007 01:52:40 startup-config.bak
13 -rw- 7341 Jul 20 2007 15:34:46 startup-config
14 -rw- 27674906 Jul 06 2007 19:52:22 boot-image
15 -rw- 27674906 Jul 06 2007 02:23:22 boot-flash
--More--
DellEMC#dir
Directory of flash:
1 drw- 32768 Jan 01 1980 00:00:00 .
2 drwx 512 Jul 23 2007 00:38:44 ..
3 drw- 8192 Mar 30 1919 10:31:04 TRACE_LOG_DIR
4 drw- 8192 Mar 30 1919 10:31:04 CRASH_LOG_DIR
5 drw- 8192 Mar 30 1919 10:31:04 NVTRACE_LOG_DIR
6 drw- 8192 Mar 30 1919 10:31:04 CORE_DUMP_DIR
7 d--- 8192 Mar 30 1919 10:31:04 ADMIN_DIR
8 -rw- 33059550 Jul 11 2007 17:49:46 FTOS-EF-7.4.2.0.bin
9 -rw- 27674906 Jul 06 2007 00:20:24 FTOS-EF-4.7.4.302.bin
10 -rw- 27674906 Jul 06 2007 19:54:52 boot-image-FILE
11 drw- 8192 Jan 01 1980 00:18:28 diag
12 -rw- 7276 Jul 20 2007 01:52:40 startup-config.bak
13 -rw- 7341 Jul 20 2007 15:34:46 startup-config
14 -rw- 27674906 Jul 06 2007 19:52:22 boot-image
15 -rw- 27674906 Jul 06 2007 02:23:22 boot-flash
--More--
DellEMC#dir flash:
Directory of flash:
1 drwx 4096 Jan 01 1980 00:00:00 +00:00 .
2 drwx 3072 Sep 06 2015 12:41:26 +00:00 ..
3 d--- 4096 Aug 09 2015 06:52:28 +00:00 ADMIN_DIR
4 drwx 4096 Sep 04 2015 18:58:20 +00:00 CONFIG_TEMPLATE
5 drwx 4096 Aug 09 2015 06:56:32 +00:00 TRACE_LOG_DIR
6 drwx 4096 Aug 09 2015 06:56:32 +00:00 CONFD_LOG_DIR
7 drwx 4096 Aug 09 2015 06:56:32 +00:00 CORE_DUMP_DIR
8 drwx 4096 Aug 09 2015 06:56:32 +00:00 RUNTIME_PATCH_DIR
9 -rwx 53285 Sep 01 2015 18:08:54 +00:00 TestReport-SU-1.txt
10 -rwx 630 Sep 02 2015 17:53:14 +00:00 TestReportIndividual-SU-1.txt
11 -rwx 2760 Sep 04 2015 18:51:26 +00:00 startup-config
12 -rwx 294418 Sep 04 2015 18:51:36 +00:00 confd_cdb.tar.gz
13 -rwx 54238335 Sep 06 2017 13:04:58 +00:00 FTOS-S5048F-ON-9.12.1.0.bin
flash: 4286574592 bytes total (4170424320 bytes free)
View Configuration Files
Configuration files have three commented lines at the beginning of the file, as shown in the following example, to help you track the last
time any user made a change to the file, which user made the changes, and when the file was last saved to the startup-configuration.
In the running-configuration file, if there is a difference between the timestamp on the “Last configuration change” and “Startup-config
last updated,” you have made changes that have not been saved and are preserved after a system reboot.
Example of the show running-config Command
DellEMC#show running-config
Current Configuration ...
! Version 9.12(1.0)
! Last configuration change at Tue Mar 11 21:33:56 2017 by admin
! Startup-config last updated at Tue Mar 11 12:11:00 2017 by default
!
<output truncated for brevity>
DellEMC#show running-config
Current Configuration ...
! Version 9.4(0.0)
50
Getting Started
! Last configuration change at Tue Mar 11 21:33:56 2014 by admin
! Startup-config last updated at Tue Mar 11 12:11:00 2014 by default
!
<output truncated for brevity>
Managing the File System
The Dell EMC Networking system can use the internal Flash, external Flash, or remote devices to store files.
The system stores files on the internal Flash by default but can be configured to store files elsewhere.
To view file system information, use the following command.
• View information about each file system.
EXEC Privilege mode
show file-systems
The output of the show file-systems command in the following example shows the total capacity, amount of free memory, file
structure, media type, read/write privileges for each storage device in use.
DellEMC#show file-systems
Size(b) Free(b) Feature Type Flags Prefixes
4286574592 4213125120 FAT32 USERFLASH rw flash:
- - unformatted USERFLASH rw fcmfs:
15345991680 15162228736 FAT32 USBFLASH rw usbflash:
283115520 53760000 Unknown NFSMOUNT rw nfsmount:
- - - network rw ftp:
- - - network rw tftp:
- - - network rw scp:
- - - network rw http:
- - - network rw https:
DellEMC#show file-systems
Size(b) Free(b) Feature Type Flags Prefixes
520962048 213778432 dosFs2.0 USERFLASH rw flash:
127772672 21936128 dosFs2.0 USERFLASH rw slot0:
- - - network rw ftp:
- - - network rw tftp:
- - - network rw scp:
You can change the default file system so that file management commands apply to a particular device or memory.
To change the default directory, use the following command.
• Change the default directory.
EXEC Privilege mode
cd directory
View Command History
The command-history trace feature captures all commands entered by all users of the system with a time stamp and writes these
messages to a dedicated trace log buffer.
The system generates a trace message for each executed command. No password information is saved to the file.
NOTE:
The timestamps display format of the show command history output changes based on the service timestamps
log datetime configuration. The time format can be in uptime, local time zone time or UTC time.
If timestamp is disabled (no service timestamps log) then command history time format is shown with timestamp
defaults (service timestamps log datetime localtime).
To view the command-history trace, use the show command-history command.
Getting Started
51
Example of the show command-history Command
Example 1: Default configuration service timestamps log datetime or service timestamps log datetime
localtime
DellEMC(conf)#service timestamps log datetime
Example 2: service timestamps log datetime utc
DellEMC(conf)#service timestamps log datetime utc
Example 3: service timestamps log uptime
DellEMC(conf)#service timestamps log uptime
Example 4: no service timestamps log
DellEMC(conf)#no service timestamps log
DellEMC# show command-history
- Repeated 1 time.
[1d0h26m]: CMD-(CLI):[configure]by default from console
- Repeated 1 time.
[May 17 15:53:10]: CMD-(CLI):[no service timestamps log]by default from console
[May 17 15:53:16]: CMD-(CLI):[write memory]by default from console
- Repeated 3 times.
[May 17 15:53:22]: CMD-(CLI):[show logging]by default from console
- Repeated 1 time.
[May 17 15:53:36]: CMD-(CLI):[write memory]by default from console
- Repeated 5 times.
[May 17 15:53:44]: CMD-(CLI):[show logging]by default from console
[May 17 15:53:53]: CMD-(CLI):[show command-history]by default from console
[May 17 15:54:54]: CMD-(CLI):[end]by default from console
[May 17 15:55:00]: CMD-(CLI):[show logging]by default from console
[May 17 15:55:12]: CMD-(CLI):[show clock]by default from console
[May 17 15:55:22]: CMD-(CLI):[show running-config]by default from console
[May 17 15:55:27]: CMD-(CLI):[show command-history]by default from console
Upgrading Dell EMC Networking OS
To upgrade Dell EMC Networking Operating System (OS), refer to the Release Notes for the version you want to load on the system.
You can download the release notes of your platform at https://www.force10networks.com. Use your login ID to log in to the website.
Using HTTP for File Transfers
Stating with Release 9.3(0.1), you can use HTTP to copy files or configuration details to a remote server. To transfer files to an external
server, use the copy source-file-url http://host[:port]/file-path command.
Enter the following source-file-url keywords and information:
• To copy a file from the internal FLASH, enter flash:// followed by the filename.
• To copy the running configuration, enter the keyword running-config.
• To copy the startup configuration, enter the keyword startup-config.
• To copy a file on the USB device, enter usbflash:// followed by the filename.
In the Dell EMC Networking OS release 9.8(0.0), HTTP services support the VRF-aware functionality. If you want the HTTP server to use
a VRF table that is attached to an interface, configure that HTTP server to use a specific routing table. You can use the
command to inform the HTTP server to use a specific routing table. After you configure this setting, the VRF table is used to look up the
destination address.
NOTE:
You can specify either the management VRF or a nondefault VRF to configure the VRF awareness setting.
When you specify the management VRF, the copy operation that is used to transfer files to and from an HTTP server utilizes the VRF
table corresponding to the Management VRF to look up the destination. When you specify a nondefault VRF, the VRF table corresponding
to that nondefault VRF is used to look up the HTTP server.
To enable HTTP to be VRF-aware, as a prerequisite you must first define the VRF.
ip http vrf
52
Getting Started
However, these changes are backward-compatible and do not affect existing behavior; meaning, you can still use the ip http
source- interface command to communicate with a particular interface even if no VRF is configured on that interface
NOTE: If the HTTP service is not VRF-aware, then it uses the global routing table to perform the look-up.
To enable an HTTP client to look up the VRF table corresponding to either management VRF or any nondefault VRF, use the ip http
vrf command in CONFIGURATION mode.
• Configure an HTTP client with a VRF that is used to connect to the HTTP server.
CONFIGURATION MODE
DellEMC(conf)#ip http vrf {management | <vrf-name>}
Verify Software Images Before Installation
To validate the software image on the flash drive, you can use the MD5 message-digest algorithm or SHA256 Secure Hash Algorithm,
after the image is transferred to the system but before the image is installed. The validation calculates a hash value of the downloaded
image file on system’s flash drive, and
The MD5 or SHA256 hash provides a method of validating that you have downloaded the original software. Calculating the hash on the
local image file and comparing the result to the hash published for that file on iSupport provides a high level of confidence that the local
copy is exactly the same as the published software image. This validation procedure, and the verify {md5 | sha256} command to
support it, prevents the installation of corrupted or modified images.
The verify {md5 | sha256} command calculates and displays the hash of any file on the specified local flash drive. You can
compare the displayed hash against the appropriate hash published on iSupport. Optionally, you can include the published hash in the
verify {md5 | sha256} command, which displays whether it matches the calculated hash of the indicated file.
To validate a software image:
1. Download Dell EMC Networking OS software image file from the iSupport page to the local (FTP or TFTP) server. The published hash
for that file displays next to the software image file on the iSupport page.
2. Go on to the Dell EMC Networking system and copy the software image to the flash drive, using the copy command.
3. Run the verify {md5 | sha256} [ flash://]img-file [hash-value] command. For example, verify sha256
flash://FTOS-SE-9.5.0.0.bin
4. Compare the generated hash value to the expected hash value published on the iSupport page.
To validate the software image on the flash drive after the image is transferred to the system, but before you install the image, use the
verify {md5 | sha256} [ flash://]img-file [hash-value] command in EXEC mode.
• md5: MD5 message-digest algorithm
• sha256: SHA256 Secure Hash Algorithm
• flash: (Optional) Specifies the flash drive. The default uses the flash drive. You can enter the image file name.
• hash-value: (Optional). Specify the relevant hash published on iSupport.
• img-file: Enter the name of the Dell EMC Networking software image file to validate
Examples: Without Entering the Hash Value for Verification
MD5
, optionally, compares it to a Dell EMC Networking published hash for that file.
DellEMC# verify md5 flash:file-name
SHA256
DellEMC# verify sha256 flash://file-name
Examples: Entering the Hash Value for Verification
MD5
DellEMC# verify md5 flash://file-name 275ceb73a4f3118e1d6bcf7d75753459
SHA256
DellEMC# verify sha256 flash://file-name
e6328c06faf814e6899ceead219afbf9360e986d692988023b749e6b2093e933
Getting Started
53
Management
This chapter describes the different protocols or services used to manage the Dell EMC Networking system.
Topics:
• Configuring Privilege Levels
• Configuring Logging
• Log Messages in the Internal Buffer
• Disabling System Logging
• Sending System Messages to a Syslog Server
• Track Login Activity
• Limit Concurrent Login Sessions
• Enabling Secured CLI Mode
• Changing System Logging Settings
• Display the Logging Buffer and the Logging Configuration
• Configuring a UNIX Logging Facility Level
• Synchronizing Log Messages
• Enabling Timestamp on Syslog Messages
• File Transfer Services
• Terminal Lines
• Setting Timeout for EXEC Privilege Mode
• Using Telnet to get to Another Network Device
• Lock CONFIGURATION Mode
• Reloading the system
• Restoring the Factory Default Settings
4
Configuring Privilege Levels
Privilege levels restrict access to commands based on user or terminal line.
There are 16 privilege levels, of which three are pre-defined. The default privilege level is 1.
Level
Level 0 Access to the system begins at EXEC mode, and EXEC mode commands are limited to enable, disable, and
Level 1 Access to the system begins at EXEC mode, and all commands are available.
Level 15 Access to the system begins at EXEC Privilege mode, and all commands are available.
For information about how access and authorization is controlled based on a user’s role, see Role-Based Access Control.
Creating a Custom Privilege Level
Custom privilege levels start with the default EXEC mode command set. You can then customize privilege levels 2-14 by:
• restricting access to an EXEC mode command
• moving commands from EXEC Privilege to EXEC mode
• restricting access
A user can access all commands at his privilege level and below.
Description
exit.
54 Management
Removing a Command from EXEC Mode
To remove a command from the list of available commands in EXEC mode for a specific privilege level, use the privilege exec
command from CONFIGURATION mode.
In the command, specify a level greater than the level given to a user or terminal line, then the first keyword of each command you wish to
restrict.
Moving a Command from EXEC Privilege Mode to EXEC Mode
To move a command from EXEC Privilege to EXEC mode for a privilege level, use the privilege exec command from
CONFIGURATION mode.
In the command, specify the privilege level of the user or terminal line and specify all keywords in the command to which you want to allow
access.
Allowing Access to CONFIGURATION Mode Commands
To allow access to CONFIGURATION mode, use the privilege exec level level configure command from
CONFIGURATION mode.
A user that enters CONFIGURATION mode remains at his privilege level and has access to only two commands, end and exit. You must
individually specify each CONFIGURATION mode command you want to allow access to using the privilege configure level
level command. In the command, specify the privilege level of the user or terminal line and specify all the keywords in the command to
which you want to allow access.
Allowing Access to Different Modes
This section describes how to allow access to the INTERFACE, LINE, ROUTE-MAP, and ROUTER modes.
Similar to allowing access to CONFIGURATION mode, to allow access to INTERFACE, LINE, ROUTE-MAP, and ROUTER modes, you
must first allow access to the command that enters you into the mode. For example, to allow a user to enter INTERFACE mode, use the
privilege configure level level interface tengigabitethernet command.
Next, individually identify the INTERFACE, LINE, ROUTE-MAP or ROUTER commands to which you want to allow access using the
privilege {interface | line | route-map | router} level level command. In the command, specify the privilege
level of the user or terminal line and specify all the keywords in the command to which you want to allow access.
To remove, move or allow access, use the following commands.
The configuration in the following example creates privilege level 3. This level:
• removes the resequence command from EXEC mode by requiring a minimum of privilege level 4
• moves the capture bgp-pdu max-buffer-size command from EXEC Privilege to EXEC mode by requiring a minimum
privilege level 3, which is the configured level for VTY 0
• allows access to CONFIGURATION mode with the banner command
• allows access to INTERFACE tengigabitethernet and LINE modes are allowed with no commands
• Remove a command from the list of available commands in EXEC mode.
CONFIGURATION mode
privilege exec level level {command ||...|| command}
• Move a command from EXEC Privilege to EXEC mode.
CONFIGURATION mode
privilege exec level level {command ||...|| command}
• Allow access to CONFIGURATION mode.
CONFIGURATION mode
privilege exec level level configure
• Allow access to INTERFACE, LINE, ROUTE-MAP, and/or ROUTER mode. Specify all the keywords in the command.
CONFIGURATION mode
Management
55
privilege configure level level {interface | line | route-map | router} {command-keyword
||...|| command-keyword}
• Allow access to a CONFIGURATION, INTERFACE, LINE, ROUTE-MAP, and/or ROUTER mode command.
CONFIGURATION mode
privilege {configure |interface | line | route-map | router} level level {command ||...||
command}
DellEMC#show running-config privilege
!
privilege exec level 3 configure
privilege exec level 4 resequence
privilege configure level 3 line
privilege configure level 3 interface tengigabitethernet
DellEMC#telnet 10.11.80.201
DellEMC#?
configure Configuring from terminal
disable Turn off privileged commands
enable Turn on privileged commands
ethernet Ethernet commands
exit Exit from the EXEC
ip Global IP subcommands
ipv6 Global IPv6 subcommands
monitor Monitoring feature
ping Send echo messages
quit Exit from the EXEC
show Show running system information
DellEMC#config
DellEMC(conf)#do show priv
Current privilege level is 3.
DellEMC(conf)#?
end Exit from configuration mode
exit Exit from configuration mode
interface Select an interface to configure
line Configure a terminal line
DellEMC(conf)#
DellEMC(conf)#interface ?
tengigabitethernet TenGigabit Ethernet interface
DellEMC(conf)#
DellEMC(conf)#interface twentyFiveGigE 1/26
DellEMC(conf-if-tf-1/26)#?
end Exit from configuration mode
exit Exit from interface configuration mode
DellEMC(conf-if-tf-1/26)#exit
DellEMC(conf)#
DellEMC(conf)#line ?
console Primary terminal line
vty Virtual terminal
DellEMC(conf)#line vty 0
DellEMC(config-line-vty)#exit
DellEMC(conf)#
Applying a Privilege Level to a Username
To set the user privilege level, use the following command.
• Configure a privilege level for a user.
CONFIGURATION mode
username username privilege level
Applying a Privilege Level to a Terminal Line
To set a privilege level for a terminal line, use the following command.
• Configure a privilege level for a user.
CONFIGURATION mode
56
Management
username username privilege level
NOTE: When you assign a privilege level between 2 and 15, access to the system begins at EXEC mode, but the prompt
is hostname#, rather than hostname>.
Configuring Logging
The Dell EMC Networking OS tracks changes in the system using event and error messages.
By default, Dell EMC Networking OS logs these messages on:
• the internal buffer
• console and terminal lines
• any configured syslog servers
To disable logging, use the following commands.
• Disable all logging except on the console.
CONFIGURATION mode
no logging on
• Disable logging to the logging buffer.
CONFIGURATION mode
no logging buffer
• Disable logging to terminal lines.
CONFIGURATION mode
no logging monitor
• Disable console logging.
CONFIGURATION mode
no logging console
Audit and Security Logs
This section describes how to configure, display, and clear audit and security logs.
The following is the configuration task list for audit and security logs:
• Enabling Audit and Security Logs
• Displaying Audit and Security Logs
• Clearing Audit Logs
Enabling Audit and Security Logs
You enable audit and security logs to monitor configuration changes or determine if these changes affect the operation of the system in
the network. You log audit and security events to a system log server, using the logging extended command in CONFIGURATION
mode.
Audit Logs
The audit log contains configuration events and information. The types of information in this log consist of the following:
• User logins to the switch.
• System events for network issues or system issues.
• Users making configuration changes. The switch logs who made the configuration changes and the date and time of the
change. However, each specific change on the configuration is not logged. Only that the configuration was modified is logged with the
user ID, date, and time of the change.
• Uncontrolled shutdown.
Security Logs
The security log contains security events and information. RBAC restricts access to audit and security logs based on the CLI sessions’ user
roles. The types of information in this log consist of the following:
• Establishment of secure traffic flows, such as SSH.
• Violations on secure flows or certificate issues.
• Adding and deleting of users.
Management
57
• User access and configuration changes to the security and crypto parameters (not the key information but the crypto configuration)
Important Points to Remember
When you enabled RBAC and extended logging:
• Only the system administrator user role can execute this command.
• The system administrator and system security administrator user roles can view security events and system events.
• The system administrator user roles can view audit, security, and system events.
• Only the system administrator and security administrator user roles can view security logs.
• The network administrator and network operator user roles can view system events.
NOTE: If extended logging is disabled, you can only view system events, regardless of RBAC user role.
Example of Enabling Audit and Security Logs
DellEMC(conf)#logging extended
Displaying Audit and Security Logs
To display audit logs, use the show logging auditlog command in Exec mode. To view these logs, you must first enable the logging
extended command. Only the RBAC system administrator user role can view the audit logs. Only the RBAC security administrator and
system administrator user role can view the security logs. If extended logging is disabled, you can only view system events, regardless of
RBAC user role. To view security logs, use the
For information about the logging extended command, see Enabling Audit and Security Logs
Example of the show logging auditlog Command
show logging command.
DellEMC#show logging auditlog
May 12 12:20:25: DellEMC#: %CLI-6-logging extended by admin from vty0 (10.14.1.98)
May 12 12:20:42: DellEMC#: %CLI-6-configure terminal by admin from vty0 (10.14.1.98)
May 12 12:20:42: DellEMC#: %CLI-6-service timestamps log datetime by admin from vty0
(10.14.1.98)
For information about the logging extended command, see Enabling Audit and Security Logs
Example of the show logging Command for Security
DellEMC#show logging
Jun 10 04:23:40: %STKUNIT0-M:CP
line vty0 ( 10.14.1.91 )
%SEC-5-LOGIN_SUCCESS: Login successful for user admin on
Clearing Audit Logs
To clear audit logs, use the clear logging auditlog command in Exec mode. When RBAC is enabled, only the system administrator
user role can issue this command.
Example of the clear logging auditlog Command
DellEMC# clear logging auditlog
Configuring Logging Format
To display syslog messages in a RFC 3164 or RFC 5424 format, use the logging version {0 | 1} command in CONFIGURATION
mode. By default, the system log version is set to 0.
The following describes the two log messages formats:
• 0 – Displays syslog messages format as described in RFC 3164, The BSD syslog Protocol
• 1 – Displays syslog message format as described in RFC 5424, The SYSLOG Protocol
58
Management
Example of Configuring the Logging Message Format
DellEMC(conf)#logging version ?
<0-1> Select syslog version (default = 0)
DellEMC(conf)#logging version 1
Setting Up a Secure Connection to a Syslog Server
You can use reverse tunneling with the port forwarding to securely connect to a syslog server.
Figure 2. Setting Up a Secure Connection to a Syslog Server
Pre-requisites
To configure a secure connection from the switch to the syslog server:
1. On the switch, enable the SSH server
DellEMC(conf)#ip ssh server enable
2. On the syslog server, create a reverse SSH tunnel from the syslog server to the Dell OS switch, using following syntax:
ssh -R <remote port>:<syslog server>:<syslog server listen port> user@remote_host -nNf
In the following example the syslog server IP address is 10.156.166.48 and the listening port is 5141. The switch IP address is
10.16.131.141 and the listening port is 5140
ssh -R 5140:10.156.166.48:5141 admin@10.16.131.141 -nNf
3. Configure logging to a local host. locahost is “127.0.0.1” or “::1”.
Management
59
If you do not, the system displays an error when you attempt to enable role-based only AAA authorization.
DellEMC(conf)# logging localhost tcp port
DellEMC(conf)#logging 127.0.0.1 tcp 5140
Log Messages in the Internal Buffer
All error messages, except those beginning with %BOOTUP (Message), are log in the internal buffer.
For example, %BOOTUP:RPM0:CP %PORTPIPE-INIT-SUCCESS: Portpipe 0 enabled
Configuration Task List for System Log Management
There are two configuration tasks for system log management:
• Disable System Logging
• Send System Messages to a Syslog Server
Disabling System Logging
By default, logging is enabled and log messages are sent to the logging buffer, all terminal lines, the console, and the syslog servers.
To disable system logging, use the following commands.
• Disable all logging except on the console.
CONFIGURATION mode
no logging on
• Disable logging to the logging buffer.
CONFIGURATION mode
no logging buffer
• Disable logging to terminal lines.
CONFIGURATION mode
no logging monitor
• Disable console logging.
CONFIGURATION mode
no logging console
Sending System Messages to a Syslog Server
To send system messages to a specified syslog server, use the following command. The following syslog standards are supported: RFC
5424 The SYSLOG Protocol, R.Gerhards and Adiscon GmbH, March 2009, obsoletes RFC 3164 and RFC 5426 Transmission of Syslog
Messages over UDP.
• Specify the server to which you want to send system messages. You can configure up to eight syslog servers.
CONFIGURATION mode
logging {ip-address | ipv6-address | hostname} {{udp {port}} | {tcp {port}}}
You can export system logs to an external server that is connected through a different VRF.
Configuring a UNIX System as a Syslog Server
To configure a UNIX System as a syslog server, use the following command.
• Configure a UNIX system as a syslog server by adding the following lines to /etc/syslog.conf on the UNIX system and assigning write
permissions to the file.
• Add line on a 4.1 BSD UNIX system. local7.debugging /var/log/ftos.log
• Add line on a 5.7 SunOS UNIX system. local7.debugging /var/adm/ftos.log
60
Management
In the previous lines, local7 is the logging facility level and debugging is the severity level.
Track Login Activity
Dell EMC Networking OS enables you to track the login activity of users and view the successful and unsuccessful login events.
When you log in using the console or VTY line, the system displays the last successful login details of the current user and the number of
unsuccessful login attempts since your last successful login to the system, and whether the current user’s permissions have changed since
the last login. The system stores the number of unsuccessful login attempts that have occurred in the last 30 days by default. You can
change the default value to any number of days from 1 to 30. By default, login activity tracking is disabled. You can enable it using the
login statistics enable command from the configuration mode.
Restrictions for Tracking Login Activity
These restrictions apply for tracking login activity:
• Only the system and security administrators can configure login activity tracking and view the login activity details of other users.
• Login statistics is not applicable for login sessions that do not use user names for authentication. For example, the system does not
report login activity for a telnet session that prompts only a password.
Configuring Login Activity Tracking
To enable and configure login activity tracking, follow these steps:
1. Enable login activity tracking.
CONFIGURATION mode
login statistics enable
After enabling login statistics, the system stores the login activity details for the last 30 days.
2. (Optional) Configure the number of days for which the system stores the user login statistics. The range is from 1 to 30.
CONFIGURATION mode
login statistics time-period days
The following example enables login activity tracking. The system stores the login activity details for the last 30 days.
DellEMC(config)#login statistics enable
The following example enables login activity tracking and configures the system to store the login activity details for 12 days.
DellEMC(config)#login statistics enable
DellEMC(config)#login statistics time-period 12
Display Login Statistics
To view the login statistics, use the show login statistics command.
Example of the show login statistics Command
The show login statistics command displays the successful and failed login details of the current user in the last 30 days or the
custom defined time period.
DellEMC#show login statistics
-----------------------------------------------------------------User: admin
Last login time: 12:52:01 UTC Tue Mar 22 2016
Last login location: Line vty0 ( 10.16.127.143 )
Unsuccessful login attempt(s) since the last successful login: 0
Unsuccessful login attempt(s) in last 30 day(s): 0
Successful login attempt(s) in last 30 day(s): 1
------------------------------------------------------------------
Management
61
Example of the show login statistics all command
The show login statistics all command displays the successful and failed login details of all users in the last 30 days or the
custom defined time period.
DellEMC#show login statistics all
-----------------------------------------------------------------User: admin
Last login time: 08:54:28 UTC Wed Mar 23 2016
Last login location: Line vty0 ( 10.16.127.145 )
Unsuccessful login attempt(s) since the last successful login: 0
Unsuccessful login attempt(s) in last 30 day(s): 3
Successful login attempt(s) in last 30 day(s): 4
------------------------------------------------------------------
-----------------------------------------------------------------User: admin1
Last login time: 12:49:19 UTC Tue Mar 22 2016
Last login location: Line vty0 ( 10.16.127.145 )
Unsuccessful login attempt(s) since the last successful login: 0
Unsuccessful login attempt(s) in last 30 day(s): 3
Successful login attempt(s) in last 30 day(s): 2
------------------------------------------------------------------
-----------------------------------------------------------------User: admin2
Last login time: 12:49:27 UTC Tue Mar 22 2016
Last login location: Line vty0 ( 10.16.127.145 )
Unsuccessful login attempt(s) since the last successful login: 0
Unsuccessful login attempt(s) in last 30 day(s): 3
Successful login attempt(s) in last 30 day(s): 2
------------------------------------------------------------------
-----------------------------------------------------------------User: admin3
Last login time: 13:18:42 UTC Tue Mar 22 2016
Last login location: Line vty0 ( 10.16.127.145 )
Unsuccessful login attempt(s) since the last successful login: 0
Unsuccessful login attempt(s) in last 30 day(s): 3
Successful login attempt(s) in last 30 day(s): 2
Example of the show login statistics user user-id command
The show login statistics user user-id command displays the successful and failed login details of a specific user in the last
30 days or the custom defined time period.
DellEMC# show login statistics user admin
-----------------------------------------------------------------User: admin
Last login time: 12:52:01 UTC Tue Mar 22 2016
Last login location: Line vty0 ( 10.16.127.143 )
Unsuccessful login attempt(s) since the last successful login: 0
Unsuccessful login attempt(s) in last 30 day(s): 0
Successful login attempt(s) in last 30 day(s): 1
------------------------------------------------------------------
The following is sample output of the show login statistics unsuccessful-attempts command.
DellEMC# show login statistics unsuccessful-attempts
There were 3 unsuccessful login attempt(s) for user admin in last 30 day(s).
The following is sample output of the show login statistics unsuccessful-attempts time-period days command.
DellEMC# show login statistics unsuccessful-attempts time-period 15
There were 0 unsuccessful login attempt(s) for user admin in last 15 day(s).
62
Management
The following is sample output of the show login statistics unsuccessful-attempts user login-id command.
DellEMC# show login statistics unsuccessful-attempts user admin
There were 3 unsuccessful login attempt(s) for user admin in last 12 day(s).
The following is sample output of the show login statistics successful-attempts command.
DellEMC#show login statistics successful-attempts
There were 4 successful login attempt(s) for user admin in last 30 day(s).
Limit Concurrent Login Sessions
Dell EMC Networking OS enables you to limit the number of concurrent login sessions of users on VTY, auxiliary, and console lines. You
can also clear any of your existing sessions when you reach the maximum permitted number of concurrent sessions.
By default, you can use all 10 VTY lines, one console line, and one auxiliary line. You can limit the number of available sessions using the
login concurrent-session limit command and so restrict each user to that specific number of sessions. You can optionally
configure the system to provide an option to the users to clear any of their existing sessions. To restrict the total amount of VTY lines
using ACL, see the
Restrictions for Limiting the Number of Concurrent Sessions
These restrictions apply for limiting the number of concurrent sessions:
• Only the system and security administrators can limit the number of concurrent sessions and enable the clear-line option.
• Users can clear their existing sessions only if the system is configured with the login concurrent-session clear-line
enable command.
Denying and Permitting Access to a Terminal Line section.
Configuring Concurrent Session Limit
To configure concurrent session limit, follow this procedure:
• Limit the number of concurrent sessions for each user.
CONFIGURATION mode
login concurrent-session limit number-of-sessions
The following example limits the permitted number of concurrent login sessions to 4.
DellEMC(config)#login concurrent-session limit 4
Enabling the System to Clear Existing Sessions
To enable the system to clear existing login sessions, follow this procedure:
• Use the following command.
CONFIGURATION mode
login concurrent-session clear-line enable
NOTE:
following attempt will be unsuccessful and the system displays access denied message. It is not possible to attempt
after clearing one of the existing sessions as user authentication has to happen first and before clearing the existing
login sessions. During the next authentication attempt, the system does not allow any attempt to login since
maximum VTY sessions have reached and hence no clear-line option.
NOTE: If the maximum number of VTY lines are more than the concurrent sessions and the same user is attempting
to login second time or more, the system displays the Maximum concurrent sessions for the user reached
message. You are allowed to clear the existing session and login. If you do not want to clear any of the existing
If both concurrent sessions and the maximum number of VTY lines used are the same, the next or the
Management 63
session, the system does not allow any attempt to login since maximum concurrent sessions have reached even
though more VTY lines are available. You are allowed to login as a different user as more VTY lines are available.
The following example enables you to clear your existing login sessions.
DellEMC(config)#login concurrent-session clear-line enable
Example of Clearing Existing Sessions
When you try to log in, the following message appears with all your existing concurrent sessions, providing an option to close any one of
the existing sessions:
$ telnet 10.11.178.14
Trying 10.11.178.14...
Connected to 10.11.178.14.
Escape character is '^]'.
Login: admin
Password:
Current sessions for user admin:
Line Location
2 vty 0 10.14.1.97
3 vty 1 10.14.1.97
Clear existing session? [line number/Enter to cancel]:
When you try to create more than the permitted number of sessions, the following message appears, prompting you to close one of the
existing sessions. If you close any of the existing sessions, you are allowed to login.
$ telnet 10.11.178.17
Trying 10.11.178.17...
Connected to 10.11.178.17.
Escape character is '^]'.
Login: admin
Password:
Maximum concurrent sessions for the user reached.
Current sessions for user admin:
Line Location
2 vty 0 10.14.1.97
3 vty 1 10.14.1.97
4 vty 2 10.14.1.97
5 vty 3 10.14.1.97
Kill existing session? [line number/Enter to cancel]:
Enabling Secured CLI Mode
The secured CLI mode prevents the users from enhancing the permissions or promoting the privilege levels.
• Enter the following command to enable the secured CLI mode:
CONFIGURATION Mode
secure-cli enable
After entering the command, save the running-configuration. Once you save the running-configuration, the secured CLI mode is enabled.
If you do not want to enter the secured mode, do not save the running-configuration. Once saved, to disable the secured CLI mode, you
need to manually edit the startup-configuration file and reboot the system.
Changing System Logging Settings
You can change the default settings of the system logging by changing the severity level and the storage location.
The default is to log all messages up to debug level, that is, all system messages. By changing the severity level in the logging commands,
you control the number of system messages logged.
To specify the system logging settings, use the following commands.
• Specify the minimum severity level for logging to the logging buffer.
CONFIGURATION mode
64
Management
logging buffered level
• Specify the minimum severity level for logging to the console.
CONFIGURATION mode
logging console level
• Specify the minimum severity level for logging to terminal lines.
CONFIGURATION mode
logging monitor level
• Specify the minimum severity level for logging to a syslog server.
CONFIGURATION mode
logging trap level
• Specify the minimum severity level for logging to the syslog history table.
CONFIGURATION mode
logging history level
• Specify the size of the logging buffer.
CONFIGURATION mode
logging buffered size
NOTE: When you decrease the buffer size, Dell EMC Networking OS deletes all messages stored in the buffer.
Increasing the buffer size does not affect messages in the buffer.
• Specify the number of messages that Dell EMC Networking OS saves to its logging history table.
CONFIGURATION mode
logging history size size
To view the logging buffer and configuration, use the show logging command in EXEC privilege mode, as shown in the example for
Display the Logging Buffer and the Logging Configuration.
To view the logging configuration, use the show running-config logging command in privilege mode, as shown in the example for
Configure a UNIX Logging Facility Level.
Display the Logging Buffer and the Logging Configuration
To display the current contents of the logging buffer and the logging settings for the system, use the show logging command in EXEC
privilege mode. When RBAC is enabled, the security logs are filtered based on the user roles. Only the security administrator and system
administrator can view the security logs.
Example of the show logging Command
DellEMC#show logging
Syslog logging: enabled
Console logging: level debugging
Monitor logging: level debugging
Buffer logging: level debugging, 75 Messages Logged, Size (40960 bytes)
Trap logging: level informational
Oct 10 10:43:47 %S5048F-ON:1 %POLLMGR-2-USER_FLASH_STATE: USB flash disk removed from
'usbflash:'
Oct 10 10:43:46 %S5048F-ON:1 %KERN-2-INT: umass0: detached
Oct 10 10:43:46 %S5048F-ON:1 %KERN-2-INT: scsibus0: detached
Oct 10 10:43:46 %S5048F-ON:1 %KERN-2-INT: sd0: detached
Oct 10 10:43:46 %S5048F-ON:1 %KERN-2-INT: sd0(umass0:0:0:0): generic HBA error
Oct 10 10:43:45 %S5048F-ON:1 %KERN-2-INT: umass0: at uhub1 port 1 (addr 3) disconnected
Oct 10 10:16:22 %STKUNIT1-M:CP %SYS-5-CONFIG_I: Configured from vty0 ( 10.16.127.143 )by admin
Oct 10 10:07:32 %STKUNIT1-M:CP %SEC-5-AUTHENTICATION_ENABLE_SUCCESS: Enable authentication
success on vty0 ( 10.16.127.143 ) for user admin
Oct 10 10:07:25 %STKUNIT1-M:CP %SEC-5-LOGIN_SUCCESS: Login successful for user admin on line
vty0 ( 10.16.127.143 )
Oct 9 22:40:50 %STKUNIT1-M:CP %SEC-5-LOGOUT: Exec session is terminated on console
(Reason : Idle TimeOut)
Oct 9 22:30:46 %STKUNIT1-M:CP %SEC-5-LOGIN_SUCCESS: Login successful on console
Oct 9 17:16:45 %S5048F-ON:1 %IFAGT-5-INSERT_OPTICS_PLUS: Optics SFP+ inserted in slot 1 port
1
Oct 9 17:16:41 %S5048F-ON:1 %IFAGT-5-INSERT_OPTICS_PLUS: Optics SFP+ inserted in slot 1 port
2
Management
65
Oct 9 17:14:56 %S5048F-ON:1 %IFAGT-5-REMOVED_OPTICS_PLUS: Optics SFP+ removed in slot 1 port
2
Oct 9 17:14:39 %S5048F-ON:1 %IFAGT-5-INSERT_OPTICS_PLUS: Optics SFP+ inserted in slot 1 port
2
Oct 9 17:10:47 %S5048F-ON:1 %IFAGT-5-REMOVED_OPTICS_PLUS: Optics SFP+ removed in slot 1 port
4
Oct 9 17:10:41 %S5048F-ON:1 %IFAGT-5-REMOVED_OPTICS_PLUS: Optics SFP+ removed in slot 1 port
2
Oct 9 17:09:33 %STKUNIT1-M:CP %SEC-5-LOGOUT: Exec session is terminated for user admin on
line vty0 ( 10.16.127.143 ) (Reason : Idle TimeOut)
Oct 9 16:44:33 %S5048F-ON:1 %IFAGT-5-REMOVED_OPTICS_SFP28: Optics SFP28 removed in slot 1
port 19
Oct 9 16:39:33 %STKUNIT1-M:CP %SEC-5-LOGOUT: Exec session is terminated on console
(Reason : Idle TimeOut)
Oct 9 16:29:32 %STKUNIT1-M:CP %SEC-5-AUTHENTICATION_ENABLE_SUCCESS: Enable authentication
success on console
Oct 9 16:29:28 %STKUNIT1-M:CP %SEC-5-LOGIN_SUCCESS: Login successful on console
Oct 9 16:19:50 %STKUNIT1-M:CP %SEC-5-AUTHENTICATION_ENABLE_SUCCESS: Enable authentication
success on vty0 ( 10.16.127.143 ) for user admin
Oct 9 16:19:46 %STKUNIT1-M:CP %SEC-5-LOGIN_SUCCESS: Login successful for user admin on line
vty0 ( 10.16.127.143 )
Oct 9 16:19:07 %STKUNIT1-M:CP %SEC-5-LOGOUT: Exec session is terminated for user admin on
line vty0 ( 10.16.127.143 ) (Reason : Idle TimeOut)
Oct 9 15:48:32 %STKUNIT1-M:CP %SEC-5-AUTHENTICATION_ENABLE_SUCCESS: Enable authentication
success on vty0 ( 10.16.127.143 ) for user admin
Oct 9 15:48:26 %STKUNIT1-M:CP %SEC-5-LOGIN_SUCCESS: Login successful for user admin on line
vty0 ( 10.16.127.143 )
Oct 9 15:02:06 %STKUNIT1-M:CP %SEC-5-LOGOUT: Exec session is terminated for user admin on
line vty0 ( 10.16.127.143 ) (Reason : Idle TimeOut)
Oct 9 14:31:27 %STKUNIT1-M:CP %SEC-5-AUTHENTICATION_ENABLE_SUCCESS: Enable authentication
success on vty0 ( 10.16.127.143 ) for user admin
Oct 9 14:31:24 %STKUNIT1-M:CP %SEC-5-LOGIN_SUCCESS: Login successful for user admin on line
vty0 ( 10.16.127.143 )
Oct 8 22:41:47 %STKUNIT1-M:CP %SEC-5-LOGOUT: Exec session is terminated on console
(Reason : Idle TimeOut)
Oct 8 22:31:44 %STKUNIT1-M:CP %SEC-5-LOGIN_SUCCESS: Login successful on console
Oct 8 16:57:39 %STKUNIT1-M:CP %SEC-5-LOGOUT: Exec session is terminated for user admin on
line vty0 ( 10.16.127.143 ) (Reason : Idle TimeOut)
Oct 8 16:24:09 %STKUNIT1-M:CP %SEC-5-LOGOUT: Exec session is terminated on console
(Reason : Idle TimeOut)
Oct 8 16:17:48 %STKUNIT1-M:CP %SEC-5-AUTHENTICATION_ENABLE_SUCCESS: Enable authentication
success on vty0 ( 10.16.127.143 ) for user admin
Oct 8 16:17:33 %STKUNIT1-M:CP %SEC-5-LOGIN_SUCCESS: Login successful for user admin on line
vty0 ( 10.16.127.143 )
Oct 8 16:12:14 %STKUNIT1-M:CP %SEC-5-AUTHENTICATION_ENABLE_SUCCESS: Enable authentication
success on console
Oct 8 16:12:01 %S5048F-ON:1 %CHMGR-2-FAN_SPEED_CHANGE: Fan speed changed to 90 % of the full
speed
Oct 8 16:11:57 %S5048F-ON:1 %CHMGR-2-PSU_FAN_SPEED_CHANGE: PSU_Fan speed changed to 100 % of
the full speed
Oct 8 16:11:56 %STKUNIT1-M:CP %CHMGR-5-PSU_FAN_STATUS: Fan 1 in PSU 2 of Unit 1 is up
Oct 8 16:11:56 %STKUNIT1-M:CP %CHMGR-5-PSU_FAN_STATUS: Fan 1 in PSU 1 of Unit 1 is up
Oct 8 16:11:56 %S5048F-ON:1 %CHMGR-2-FAN_SPEED_CHANGE: Fan speed changed to 72 % of the full
speed
Oct 8 16:11:53 %STKUNIT1-M:CP %SEC-5-LOGIN_SUCCESS: Login successful on console
Oct 8 16:11:53 %STKUNIT1-M:CP %SUPPORT_ASSIST-3-SUPASSIST_PKG_INSTALLATION_ERROR: Required
SMARTSCRIPTS Package(>= 9.7) not found, SupportAssist uninstalled.
Oct 8 16:11:52 %STKUNIT1-M:CP %CLI-6-SECURE_CLI_NOT_ENABLED: CLI security mode not enabled
Oct 8 16:11:52 %STKUNIT1-M:CP %SEC-5-USER_ACC_CREATION_SUCCESS: User account "admin" created
or modified by default from console successfully
Oct 8 16:11:52 %STKUNIT1-M:CP %CHMGR-5-FANTRAY_INSERTED: Fan tray 4 of Unit 1 is inserted
Oct 8 16:11:52 %STKUNIT1-M:CP %SYS-5-CONFIG_LOAD: Loading configuration file
Oct 8 16:11:52 %STKUNIT1-M:CP %CHMGR-5-FANTRAY_INSERTED: Fan tray 3 of Unit 1 is inserted
Oct 8 16:11:44 %STKUNIT1-M:CP %CHMGR-5-FANTRAY_INSERTED: Fan tray 2 of Unit 1 is inserted
Oct 8 16:11:42 %STKUNIT1-M:CP %IFMGR-5-OSTATE_UP: Changed interface state to up: Ma 1/1
Oct 8 16:11:42 %STKUNIT1-M:CP %CHMGR-5-FANTRAY_INSERTED: Fan tray 1 of Unit 1 is inserted
Oct 8 16:11:41 %S5048F-ON:1 %IFAGT-5-INSERT_OPTICS_PLUS: Optics SFP+ inserted in slot 1 port
47
Oct 8 16:11:41 %S5048F-ON:1 %IFAGT-5-INSERT_OPTICS_PLUS: Optics SFP+ inserted in slot 1 port
38
Oct 8 16:11:41 %S5048F-ON:1 %IFAGT-5-INSERT_OPTICS_PLUS: Optics SFP+ inserted in slot 1 port
36
Oct 8 16:11:41 %S5048F-ON:1 %IFAGT-5-INSERT_OPTICS_PLUS: Optics SFP+ inserted in slot 1 port
66
Management
35
Oct 8 16:11:41 %S5048F-ON:1 %IFAGT-5-INSERT_OPTICS_PLUS: Optics SFP+ inserted in slot 1 port
26
Oct 8 16:11:41 %S5048F-ON:1 %IFAGT-5-INSERT_OPTICS_SFP28: Optics SFP28 inserted in slot 1
port 19
Oct 8 16:11:40 %S5048F-ON:1 %IFAGT-5-INSERT_OPTICS_PLUS: Optics SFP+ inserted in slot 1 port
4
Oct 8 16:11:40 %S5048F-ON:1 %IFAGT-5-INSERT_OPTICS_PLUS: Optics SFP+ inserted in slot 1 port
2
Oct 8 16:11:40 %STKUNIT1-M:CP %CHMGR-2-SYSTEM_READY: System ready
Oct 8 16:11:40 %STKUNIT1-M:CP %CHMGR-0-PS_UP: Power supply 2 in unit 1 is up
Oct 8 16:11:40 %STKUNIT1-M:CP %CHMGR-5-PEM_INSERTED: Power entry module 2 of unit 1 is
inserted
Oct 8 16:11:40 %STKUNIT1-M:CP %CHMGR-0-PS_UP: Power supply 1 in unit 1 is up
Oct 8 16:11:40 %STKUNIT1-M:CP %CHMGR-5-PEM_INSERTED: Power entry module 1 of unit 1 is
inserted
Oct 8 16:11:38 %STKUNIT1-M:CP %IFMGR-5-OSTATE_DN: Changed interface state to down: Ma 1/1
Oct 8 16:11:38 %STKUNIT1-M:CP %IFMGR-5-OSTATE_UP: Changed interface state to up: Ma 1/1
Oct 8 16:11:38 %STKUNIT1-M:CP %CHMGR-5-STACKUNIT_UP: stack-unit 1 is up
Oct 8 16:11:37 %STKUNIT1-M:CP %RAM-5-STACKUNIT_STATE: Stack-unit 1 is in Active State.
Oct 8 16:11:32 %STKUNIT1-M:CP %CHMGR-5-CHECKIN: Checkin from stack-unit 1 (type S5048F-ON,
72 ports)
Oct 8 16:11:32 %STKUNIT1-M:CP %CHMGR-5-LPM_CONFIG: Applying the default IPv6 LPM partition
config
Oct 8 16:11:32 %STKUNIT1-M:CP %CHMGR-5-STACKUNIT_DETECTED: stack-unit 1 present
Oct 8 16:11:32 %STKUNIT1-M:CP %CRYPTO-5-FIPS_SELF_TEST_PASSED: [sysd] FIPS crypto module
self-test passed
Oct 8 16:11:31 %STKUNIT1-M:CP %RAM-6-ELECTION_ROLE: Stack-unit 1 is transitioning to
Management Stack-unit.
Oct 8 16:11:31 %S5048F-ON:1 %POLLMGR-6-USER_FLASH_INFO: model: SanDisk Ultra firmware: 1.00
serial no: 218891921
DellEMC#show logging
syslog logging: enabled
Console logging: level Debugging
Monitor logging: level Debugging
Buffer logging: level Debugging, 40 Messages Logged, Size (40960 bytes)
Trap logging: level Informational
%IRC-6-IRC_COMMUP: Link to peer RPM is up
%RAM-6-RAM_TASK: RPM1 is transitioning to Primary RPM.
%RPM-2-MSG:CP1 %POLLMGR-2-MMC_STATE: External flash disk missing in 'slot0:'
%CHMGR-5-CARDDETECTED: Line card 0 present
%CHMGR-5-CARDDETECTED: Line card 2 present
%CHMGR-5-CARDDETECTED: Line card 4 present
%CHMGR-5-CARDDETECTED: Line card 5 present
%CHMGR-5-CARDDETECTED: Line card 8 present
%CHMGR-5-CARDDETECTED: Line card 10 present
%CHMGR-5-CARDDETECTED: Line card 12 present
%TSM-6-SFM_DISCOVERY: Found SFM 0
%TSM-6-SFM_DISCOVERY: Found SFM 1
%TSM-6-SFM_DISCOVERY: Found SFM 2
%TSM-6-SFM_DISCOVERY: Found SFM 3
%TSM-6-SFM_DISCOVERY: Found SFM 4
%TSM-6-SFM_DISCOVERY: Found SFM 5
%TSM-6-SFM_DISCOVERY: Found SFM 6
%TSM-6-SFM_DISCOVERY: Found SFM 7
%TSM-6-SFM_SWITCHFAB_STATE: Switch Fabric: UP
%TSM-6-SFM_DISCOVERY: Found SFM 8
%TSM-6-SFM_DISCOVERY: Found 9 SFMs
%CHMGR-5-CHECKIN: Checkin from line card 5 (type EX1YB, 1 ports)
%TSM-6-PORT_CONFIG: Port link status for LC 5 => portpipe 0: OK portpipe 1: N/A
%CHMGR-5-LINECARDUP: Line card 5 is up
%CHMGR-5-CHECKIN: Checkin from line card 12 (type S12YC12, 12 ports)
%TSM-6-PORT_CONFIG: Port link status for LC 12 => portpipe 0: OK portpipe 1: N/A
%CHMGR-5-LINECARDUP: Line card 12 is up
%IFMGR-5-CSTATE_UP: changed interface Physical state to up: So 12/8
%IFMGR-5-CSTATE_DN: changed interface Physical state to down: So 12/8
To view any changes made, use the show running-config logging command in EXEC privilege mode.
Management
67
Configuring a UNIX Logging Facility Level
You can save system log messages with a UNIX system logging facility.
To configure a UNIX logging facility level, use the following command.
• Specify one of the following parameters.
CONFIGURATION mode
logging facility [facility-type]
auth (for authorization messages)
•
• cron (for system scheduler messages)
• daemon (for system daemons)
• kern (for kernel messages)
• local0 (for local use)
• local1 (for local use)
• local2 (for local use)
• local3 (for local use)
• local4 (for local use)
• local5 (for local use)
• local6 (for local use)
• local7 (for local use)
• lpr (for line printer system messages)
• mail (for mail system messages)
• news (for USENET news messages)
• sys9 (system use)
• sys10 (system use)
• sys11 (system use)
• sys12 (system use)
• sys13 (system use)
• sys14 (system use)
• syslog (for syslog messages)
• user (for user programs)
• uucp (UNIX to UNIX copy protocol)
To view nondefault settings, use the show running-config logging command in EXEC mode.
DellEMC#show running-config logging
!
logging buffered 524288 debugging
service timestamps log datetime msec
service timestamps debug datetime msec
!
logging trap debugging
logging facility user
logging source-interface Loopback 0
logging 10.10.10.4
DellEMC#
Synchronizing Log Messages
You can configure Dell EMC Networking OS to filter and consolidate the system messages for a specific line by synchronizing the message
output.
Only the messages with a severity at or below the set level appear. This feature works on the terminal and console connections available
on the system.
1. Enter LINE mode.
CONFIGURATION mode
line {console 0 | vty number [end-number] | aux 0}
68
Management
Configure the following parameters for the virtual terminal lines:
• number: the range is from zero (0) to 8.
• end-number: the range is from 1 to 8.
You can configure multiple virtual terminals at one time by entering a number and an end-number.
2. Configure a level and set the maximum number of messages to print.
LINE mode
logging synchronous [level severity-level | all] [limit]
Configure the following optional parameters:
• level severity-level: the range is from 0 to 7. The default is 2. Use the all keyword to include all messages.
• limit: the range is from 20 to 300. The default is 20.
To view the logging synchronous configuration, use the show config command in LINE mode.
Enabling Timestamp on Syslog Messages
By default, syslog messages include a time/date stamp, taken from the datetime, stating when the error or message was created.
To enable timestamp, use the following command.
• Add timestamp to syslog messages.
CONFIGURATION mode
service timestamps [log | debug] [datetime [localtime] [msec] [show-timezone] [utc] | uptime]
Specify the following optional parameters:
• datetime: To view the timestamp in system local time that includes the local time zone.
• localtime: You can add the keyword localtime to view timestamp in system local time that includes the local time zone.
• show-timezone: Enter the keyword to include the time zone information in the timestamp.
• msec: Enter the keyword msec to include milliseconds in the timestamp.
• uptime: To view time since last boot.
• utc: Enter the keyword utc to view timestamp in UTC time that excludes the local time zone.
If you do not specify a parameter, Dell EMC Networking OS configures datetime as localtime by default.
To view the configuration, use the show running-config logging command in EXEC privilege mode.
To disable time stamping on syslog messages, use the no service timestamps [log | debug] command.
Example 1: Default configuration service timestamps log datetime or service timestamps log datetime
localtime
DellEMC(conf)#service timestamps log datetime
DellEMC#show clock
15:42:42.804 IST Fri May 17 2019
Example 2: service timestamps log datetime utc
DellEMC(conf)#service timestamps log datetime utc
DellEMC#show clock
15:47:05.661 IST Fri May 17 2019
Example 3: service timestamps log uptime
DellEMC(conf)#service timestamps log uptime
DellEMC#show clock
15:51:47.534 IST Fri May 17 2019
DellEMC# show version |grep uptime
Dell EMC Networking OS uptime is 1 day(s), 0 hour(s), 25 minute(s)
Example 4: no service timestamps log
Management
69
DellEMC(conf)#no service timestamps log
DellEMC#show clock
15:55:12.246 IST Fri May 17 2019
DellEMC# show command-history
[May 17 15:53:10]: CMD-(CLI):[no service timestamps log]by default from console
[May 17 15:53:16]: CMD-(CLI):[write memory]by default from console
- Repeated 3 times.
[May 17 15:53:22]: CMD-(CLI):[show logging]by default from console
- Repeated 1 time.
[May 17 15:53:36]: CMD-(CLI):[write memory]by default from console
- Repeated 5 times.
[May 17 15:53:44]: CMD-(CLI):[show logging]by default from console
[May 17 15:53:53]: CMD-(CLI):[show command-history]by default from console
[May 17 15:54:54]: CMD-(CLI):[end]by default from console
[May 17 15:55:00]: CMD-(CLI):[show logging]by default from console
[May 17 15:55:12]: CMD-(CLI):[show clock]by default from console
[May 17 15:55:22]: CMD-(CLI):[show running-config]by default from console
[May 17 15:55:27]: CMD-(CLI):[show command-history]by default from console
DellEMC# show logging
Syslog logging: enabled
Console logging: disabled
Monitor logging: level debugging
Buffer logging: level debugging, 3 Messages Logged, Size (40960 bytes)
Trap logging: level informational
Last logging buffer cleared: May 17 15:52:54
%STKUNIT1-M:CP %SYS-5-CONFIG_I: Configured from console
%STKUNIT1-M:CP %FILEMGR-5-FILESAVED: Copied running-config to startup-config in flash by
default - repeated 3 times
%STKUNIT1-M:CP %FILEMGR-5-FILESAVED: Copied running-config to startup-config in flash by
default
File Transfer Services
With Dell EMC Networking OS, you can configure the system to transfer files over the network using the file transfer protocol (FTP).
One FTP application is copying the system image files over an interface on to the system; however, FTP is not supported on virtual local
area network (VLAN) interfaces.
If you want the FTP or TFTP server to use a VRF table that is attached to an interface, you must configure the FTP or TFTP server to use
a specific routing table. You can use the ip ftp vrf vrf-name or ip tftp vrf vrf-name command to inform the FTP or TFTP
server to use a specific routing table. After you configure this setting, the VRF table is used to look up the destination address. However,
these changes are backward-compatible and do not affect existing behavior; meaning, you can still use the source-interface
command to communicate with a particular interface even if no VRF is configured on that interface.
For more information about FTP, refer to RFC 959, File Transfer Protocol.
NOTE:
Configuration Task List for File Transfer Services
The configuration tasks for file transfer services are:
• Enable FTP Server (mandatory)
• Configure FTP Server Parameters (optional)
• Configure FTP Client Parameters (optional)
Enabling the FTP Server
To transmit large files, Dell EMC Networking recommends configuring the switch as an FTP server.
To enable the system as an FTP server, use the following command.
To view FTP configuration, use the show running-config ftp command in EXEC privilege mode.
70
Management
• Enable FTP on the system.
CONFIGURATION mode
ftp-server enable
DellEMC#show running ftp
!
ftp-server enable
ftp-server username nairobi password 0 zanzibar
DellEMC#
Configuring FTP Server Parameters
After you enable the FTP server on the system, you can configure different parameters.
To specify the system logging settings, use the following commands.
• Specify the directory for users using FTP to reach the system.
CONFIGURATION mode
ftp-server topdir dir
The default is the internal flash directory.
• Specify a user name for all FTP users and configure either a plain text or encrypted password.
CONFIGURATION mode
ftp-server username username password [encryption-type] password
Configure the following optional and required parameters:
• username: enter a text string.
• encryption-type: enter 0 for plain text or 7 for encrypted text.
• password: enter a text string.
NOTE: You cannot use the change directory (cd) command until you have configured ftp-server topdir.
To view the FTP configuration, use the show running-config ftp command in EXEC privilege mode.
Configuring FTP Client Parameters
To configure FTP client parameters, use the following commands.
• Enter the following keywords and the interface information:
• For a 10-Gigabit Ethernet interface, enter the keyword TenGigabitEthernet then the slot/port/subport information.
• For a 25-Gigabit Ethernet interface, enter the keyword twentyFiveGigE then the slot/port/subport information.
• For a 40-Gigabit Ethernet interface, enter the keyword fortyGigE then the slot/port/subport information.
• For a 50-Gigabit Ethernet interface, enter the keyword fiftyGigE then the slot/port/subport information.
• For a 100-Gigabit Ethernet interface, enter the keyword hundredGigE then the slot/port information.
• For a Loopback interface, enter the keyword loopback then a number from 0 to 16383.
• For a port channel interface, enter the keywords port-channel then a number.
• For a VLAN interface, enter the keyword vlan then a number from 1 to 4094.
CONFIGURATION mode
ip ftp source-interface interface
• Configure a password.
CONFIGURATION mode
ip ftp password password
• Enter a username to use on the FTP client.
CONFIGURATION mode
ip ftp username name
To view the FTP configuration, use the show running-config ftp command in EXEC privilege mode, as shown in the example for
Enable FTP Server.
Management
71
Terminal Lines
You can access the system remotely and restrict access to the system by creating user profiles.
Terminal lines on the system provide different means of accessing the system. The console line (console) connects you through the
console port in the route processor modules (RPMs). The virtual terminal lines (VTYs) connect you through Telnet to the system. The
auxiliary line (aux) connects secondary devices such as modems.
Denying and Permitting Access to a Terminal Line
Dell EMC Networking recommends applying only standard access control lists (ACLs) to deny and permit access to VTY lines.
• Layer 3 ACLs deny all traffic that is not explicitly permitted, but in the case of VTY lines, an ACL with no rules does not deny traffic.
• You cannot use the show ip accounting access-list command to display the contents of an ACL that is applied only to a
VTY line.
• When you use the access-class access-list-name command without specifying the ipv4 or ipv6 attribute, both IPv4 as
well as IPv6 rules that are defined in that ACL are applied to the terminal. This method is a generic way of configuring access
restrictions.
• To be able to filter access exclusively using either IPv4 or IPv6 rules, use either the ipv4 or ipv6 attribute along with the access-
class access-list-name command. Depending on the attribute that you specify (ipv4 or ipv6), the ACL processes either
IPv4 or IPv6 rules, but not both. Using this configuration, you can set up two different types of access classes with each class
processing either IPv4 or IPv6 rules separately.
To apply an IP ACL to a line, Use the following command.
• Apply an ACL to a VTY line.
LINE mode
access-class access-list-name [ipv4 | ipv6]
NOTE:
specific filtering on top of this configuration. Similarly, if you have configured either IPv4 or IPv6 specific filtering on
a terminal line, you cannot apply generic IP ACL on top of this configuration. Before applying any of these
configurations, you must first undo the existing configuration using the no access-class access-list-name
[ipv4 | ipv6] command.
If you already have configured generic IP ACL on a terminal line, then you cannot further apply IPv4 or IPv6
To view the configuration, use the show config command in LINE mode.
DellEMC(config-std-nacl)#show config
!
ip access-list standard myvtyacl
seq 5 permit host 10.11.0.1
DellEMC(config-std-nacl)#line vty 0
DellEMC(config-line-vty)#show config
line vty 0
access-class myvtyacl
DellEMC(conf-ipv6-acl)#do show run acl
!
ip access-list extended testdeny
seq 10 deny ip 30.1.1.0/24 any
seq 15 permit ip any any
!
ip access-list extended testpermit
seq 15 permit ip any any
!
ipv6 access-list testv6deny
seq 10 deny ipv6 3001::/64 any
seq 15 permit ipv6 any any
!
DellEMC(conf)#
DellEMC(conf)#line vty 0 0
DellEMC(config-line-vty)#access-class testv6deny ipv6
DellEMC(config-line-vty)#access-class testvpermit ipv4
DellEMC(config-line-vty)#show c
line vty 0
exec-timeout 0 0
72
Management
access-class testpermit ipv4
access-class testv6deny ipv6
!
Configuring Login Authentication for Terminal Lines
You can use any combination of up to six authentication methods to authenticate a user on a terminal line.
A combination of authentication methods is called a method list. If the user fails the first authentication method, Dell EMC Networking OS
prompts the next method until all methods are exhausted, at which point the connection is terminated. The available authentication
methods are:
enable
line
local
none
radius
tacacs+
1. Configure an authentication method list. You may use a mnemonic name or use the keyword default. The default authentication
method for terminal lines is
CONFIGURATION mode
aaa authentication login {method-list-name | default} [method-1] [method-2] [method-3]
[method-4] [method-5] [method-6]
2. Apply the method list from Step 1 to a terminal line.
CONFIGURATION mode
login authentication {method-list-name | default}
3. If you used the line authentication method in the method list you applied to the terminal line, configure a password for the terminal line.
LINE mode
password
In the following example, VTY lines 0-2 use a single authentication method, line.
Prompt for the enable password.
Prompt for the password you assigned to the terminal line. Configure a password for the terminal line to which
you assign a method list that contains the line authentication method. Configure a password using the password
command from LINE mode.
Prompt for the system username and password.
Do not authenticate the user.
Prompt for a username and password and use a RADIUS server to authenticate.
Prompt for a username and password and use a TACACS+ server to authenticate.
local and the default method list is empty.
DellEMC(conf)#aaa authentication login myvtymethodlist line
DellEMC(conf)#line vty 0 2
DellEMC(config-line-vty)#login authentication myvtymethodlist
DellEMC(config-line-vty)#password myvtypassword
DellEMC(config-line-vty)#show config
line vty 0
password myvtypassword
login authentication myvtymethodlist
line vty 1
password myvtypassword
login authentication myvtymethodlist
line vty 2
password myvtypassword
login authentication myvtymethodlist
DellEMC(config-line-vty)#
Setting Timeout for EXEC Privilege Mode
EXEC timeout is a basic security feature that returns Dell EMC Networking OS to EXEC mode after a period of inactivity on the terminal
lines.
To set timeout, use the following commands.
• Set the number of minutes and seconds. The default is 10 minutes on the console and 30 minutes on VTY. Disable EXEC time out
by setting the timeout period to 0.
LINE mode
Management
73
exec-timeout minutes [seconds]
• Return to the default timeout values.
LINE mode
no exec-timeout
The following example shows how to set the timeout period and how to view the configuration using the show config command from
LINE mode.
DellEMC(conf)#line con 0
DellEMC(config-line-console)#exec-timeout 0
DellEMC(config-line-console)#show config
line console 0
exec-timeout 0 0
DellEMC(config-line-console)#
Using Telnet to get to Another Network Device
To telnet to another device, use the following commands.
NOTE: The device allows 120 Telnet sessions per minute, allowing the login and logout of 10 Telnet sessions, 12 times in
a minute. If the system reaches this non-practical limit, the Telnet service is stopped for 10 minutes. You can use
console and SSH service to access the system during downtime.
• Telnet to a device with an IPv4 or IPv6 address.
EXEC Privilege
telnet [ip-address]
If you do not enter an IP address, Dell EMC Networking OS enters a Telnet dialog that prompts you for one.
Enter an IPv4 address in dotted decimal format (A.B.C.D).
Enter an IPv6 address in the format 0000:0000:0000:0000:0000:0000:0000:0000. Elision of zeros is supported.
DellEMC# telnet 10.11.80.203
Trying 10.11.80.203...
Connected to 10.11.80.203.
Exit character is '^]'.
Login:
Login: admin
Password:
DellEMC>exit
DellEMC#telnet 2200:2200:2200:2200:2200::2201
Trying 2200:2200:2200:2200:2200::2201...
Connected to 2200:2200:2200:2200:2200::2201.
Exit character is '^]'.
FreeBSD/i386 (freebsd2.force10networks.com) (ttyp1)
login: admin
DellEMC#
Lock CONFIGURATION Mode
Dell EMC Networking OS allows multiple users to make configurations at the same time. You can lock CONFIGURATION mode so that
only one user can be in CONFIGURATION mode at any time (Message 2).
You can set two types of lockst: auto and manual.
• Set auto-lock using the configuration mode exclusive auto command from CONFIGURATION mode. When you set autolock, every time a user is in CONFIGURATION mode, all other users are denied access. This means that you can exit to EXEC Privilege
mode, and re-enter CONFIGURATION mode without having to set the lock again.
• Set manual lock using the configure terminal lock command from CONFIGURATION mode. When you configure a manual
lock, which is the default, you must enter this command each time you want to enter CONFIGURATION mode and deny access to
others.
74
Management
Viewing the Configuration Lock Status
If you attempt to enter CONFIGURATION mode when another user has locked it, you may view which user has control of
CONFIGURATION mode using the show configuration lock command from EXEC Privilege mode.
You can then send any user a message using the send command from EXEC Privilege mode. Alternatively, you can clear any line using the
clear command from EXEC Privilege mode. If you clear a console session, the user is returned to EXEC mode.
Example of Locking CONFIGURATION Mode for Single-User Access
DellEMC(conf)#configuration mode exclusive auto
BATMAN(conf)#exit
3d23h35m: %RPM0-P:CP %SYS-5-CONFIG_I: Configured from console by console
DellEMC#config
! Locks configuration mode exclusively.
DellEMC(conf)#
If another user attempts to enter CONFIGURATION mode while a lock is in place, the following appears on their terminal (message 1): %
Error: User "" on line console0 is in exclusive configuration mode.
If any user is already in CONFIGURATION mode when while a lock is in place, the following appears on their terminal (message 2): %
Error: Can't lock configuration mode exclusively since the following users are currently
configuring the system: User "admin" on line vty1 ( 10.1.1.1 ).
NOTE: The CONFIGURATION mode lock corresponds to a VTY session, not a user. Therefore, if you configure a lock and
then exit CONFIGURATION mode, and another user enters CONFIGURATION mode, when you attempt to re-enter
CONFIGURATION mode, you are denied access even though you are the one that configured the lock.
NOTE: If your session times out and you return to EXEC mode, the CONFIGURATION mode lock is unconfigured.
Reloading the system
You can reload the system using the reload command. To reload the system, follow these steps:
• Reload the system into Dell EMC Networking OS.
EXEC Privilege mode
reload
• Reload the system if a configuration change to the NVRAM requires a device reload.
EXEC Privilege mode
reload conditional nvram-cfg-change
• Reload the system into the Dell diagnostics mode.
EXEC Privilege mode
reload dell-diag
• Reload the system into the ONIE mode.
EXEC Privilege mode
reload onie [install | uninstall | rescue]
Use the install parameter to reload the system and enter the Install mode to install a networking OS.
Use the uninstall parameter to reload the system and enter the Uninstall mode to uninstall a networking OS.
Use the rescue parameter to reload the system and enter the Rescue mode to access the file system.
The following example shows how to reload the system:
DellEMC# reload
Proceed with reload [confirm yes/no]: yes
The following example shows how to reload the system into Dell diagnostics mode:
DellEMC#reload dell-diag
Proceed with reload [confirm yes/no]: yes
Management
75
The following example shows how to reload the system into ONIE mode:
DellEMC#reload onie
Proceed with reload [confirm yes/no]: yes
The following example shows how to reload the system into ONIE prompt and enter the install mode directly:
DellEMC#reload onie install
Proceed with reload [confirm yes/no]: yes
Restoring the Factory Default Settings
Restoring the factory-default settings deletes the existing NVRAM settings, startup configuration, and all configured settings such as,
stacking or fanout.
To restore the factory default settings, use the restore factory-defaults stack-unit {stack—unit—number | all}
{clear-all | nvram | bootvar} command in EXEC Privilege mode.
CAUTION:
Important Points to Remember
• When you restore all the units in a stack, these units are placed in standalone mode.
• When you restore a single unit in a stack, only that unit is placed in standalone mode. No other units in the stack are affected.
• When you restore the units in standalone mode, the units remain in standalone mode after the restoration.
• After the restore is complete, the units power cycle immediately.
The following example illustrates the restore factory-defaults command to restore the factory default settings.
There is no undo for this command.
DellEMC#restore factory-defaults stack-unit 1 nvram
***********************************************************************
* Warning - Restoring factory defaults will delete the existing *
* persistent settings (stacking, fanout, etc.) *
* After restoration the unit(s) will be powercycled immediately. *
* Proceed with caution ! *
***********************************************************************
Proceed with factory settings? Confirm [yes/no]:yes
-- Restore status -Unit Nvram Config
----------------------- 1 Success
Power-cycling the unit(s).
....
Restoring Factory Default Environment Variables
The Boot line determines the location of the image that is used to boot up the chassis after restoring factory default settings. Ideally,
these locations contain valid images, using which the chassis boots up.
When you restore factory-default settings, you can either use a flash boot procedure or a network boot procedure to boot the switch.
When you use the flash boot procedure to boot the device, the boot loader checks if the primary or the secondary partition contains a
valid image. If the primary partition contains a valid image, then the primary boot line is set to A: and the secondary and default boot lines
are set to a Null String. If the secondary partition contains a valid image, then the primary boot line is set to B: and the secondary and
default boot lines are set to a Null String. If both the partitions contain invalid images, then primary, secondary, and default boot line values
are set to a Null string.
When you use the Network boot procedure to boot the device, the boot loader checks if the primary partition contains a valid image. If a
valid image exists on the primary partition and the secondary partition does not contain a valid image, then the primary boot line is set to A:
and the secondary and default boot lines are set to a Null string. If the secondary partition also contains a valid image, then the primary
76
Management
boot line value is set to the partition that is configured to be used to boot the device in a network failure scenario. The secondary and
default boot line values are set to a Null string.
Important Points to Remember
• The Chassis remains in boot prompt if none of the partitions contain valid images.
• To enable TFTP boot after restoring factory default settings, you must stop the boot process in BLI.
Management 77
5
802.1X
802.1X is a port-based Network Access Control (PNAC) that provides an authentication mechanism to devices wishing to attach to a LAN
or WLAN. A device connected to a port that is enabled with 802.1X is disallowed from sending or receiving packets on the network until its
identity is verified (through a username and password, for example).
802.1X employs Extensible Authentication Protocol (EAP) to transfer a device’s credentials to an authentication server (typically RADIUS)
using a mandatory intermediary network access device, in this case, a Dell EMC Networking switch. The network access device mediates
all communication between the end-user device and the authentication server so that the network remains secure. The network access
device uses EAP-over-Ethernet (EAPOL) to communicate with the end-user device and EAP-over-RADIUS to communicate with the
server.
NOTE: The Dell EMC Networking Operating System (OS) supports 802.1X with EAP-MD5, EAP-OTP, EAP-TLS, EAP-
TTLS, PEAPv0, PEAPv1, and MS-CHAPv2 with PEAP.
The following figures show how the EAP frames are encapsulated in Ethernet and RADIUS frames.
Figure 3. EAP Frames Encapsulated in Ethernet and RADUIS
Figure 4. EAP Frames Encapsulated in Ethernet and RADUIS
The authentication process involves three devices:
78 802.1X
• The device attempting to access the network is the supplicant. The supplicant is not allowed to communicate on the network until
the authenticator authorizes the port. It can only communicate with the authenticator in response to 802.1X requests.
• The device with which the supplicant communicates is the authenticator. The authenticator is the gate keeper of the network. It
translates and forwards requests and responses between the authentication server and the supplicant. The authenticator also changes
the status of the port based on the results of the authentication process. The Dell EMC Networking switch is the authenticator.
• The authentication-server selects the authentication method, verifies the information the supplicant provides, and grants it network
access privileges.
Ports can be in one of two states:
• Ports are in an unauthorized state by default. In this state, non-802.1X traffic cannot be forwarded in or out of the port.
• The authenticator changes the port state to authorized if the server can authenticate the supplicant. In this state, network traffic can
be forwarded normally.
NOTE: The Dell EMC Networking switches place 802.1X-enabled ports in the unauthorized state by default.
Topics:
• Port-Authentication Process
• Configuring 802.1X
• Important Points to Remember
• Enabling 802.1X
• Configuring dot1x Profile
• Configuring the Static MAB and MAB Profile
• Configuring Critical VLAN
• Configuring MAC addresses for a do1x Profile
• Configuring Request Identity Re-Transmissions
• Forcibly Authorizing or Unauthorizing a Port
• Re-Authenticating a Port
• Configuring Timeouts
• Configuring Dynamic VLAN Assignment with Port Authentication
• Guest and Authentication-Fail VLANs
Port-Authentication Process
The authentication process begins when the authenticator senses that a link status has changed from down to up:
1. When the authenticator senses a link state change, it requests that the supplicant identify itself using an EAP Identity Request frame.
2. The supplicant responds with its identity in an EAP Response Identity frame.
3. The authenticator decapsulates the EAP response from the EAPOL frame, encapsulates it in a RADIUS Access-Request frame and
forwards the frame to the authentication server.
4. The authentication server replies with an Access-Challenge frame. The Access-Challenge frame requests the supplicant to prove that
it is who it claims to be, using a specified method (an EAP-Method). The challenge is translated and forwarded to the supplicant by
the authenticator.
5. The supplicant can negotiate the authentication method, but if it is acceptable, the supplicant provides the Requested Challenge
information in an EAP response, which is translated and forwarded to the authentication server as another Access-Request frame.
6. If the identity information provided by the supplicant is valid, the authentication server sends an Access-Accept frame in which
network privileges are specified. The authenticator changes the port state to authorized and forwards an EAP Success frame. If the
identity information is invalid, the server sends an Access-Reject frame. If the port state remains unauthorized, the authenticator
forwards an EAP Failure frame.
802.1X
79
Figure 5. EAP Port-Authentication
EAP over RADIUS
802.1X uses RADIUS to shuttle EAP packets between the authenticator and the authentication server, as defined in RFC 3579.
EAP messages are encapsulated in RADIUS packets as a type of attribute in Type, Length, Value (TLV) format. The Type value for EAP
messages is 79.
Figure 6. EAP Over RADIUS
RADIUS Attributes for 802.1X Support
Dell EMC Networking systems include the following RADIUS attributes in all 802.1X-triggered Access-Request messages:
Attribute 31
Attribute 41 NAS-Port-Type: NAS-port physical port type. 15 indicates Ethernet.
Attribute 61 NAS-Port: the physical port number by which the authenticator is connected to the supplicant.
Attribute 81 Tunnel-Private-Group-ID: associate a tunneled session with a particular group of users.
Calling-station-id: relays the supplicant MAC address to the authentication server.
Configuring 802.1X
Configuring 802.1X on a port is a one-step process.
For more information, refer to Enabling 802.1X.
80
802.1X
Related Configuration Tasks
• Configuring Request Identity Re-Transmissions
• Forcibly Authorizing or Unauthorizing a Port
• Re-Authenticating a Port
• Configuring Timeouts
• Configuring a Guest VLAN
• Configuring an Authentication-Fail VLAN
Important Points to Remember
• Dell EMC Networking OS supports 802.1X with EAP-MD5, EAP-OTP, EAP-TLS, EAP-TTLS, PEAPv0, PEAPv1, and MS-CHAPv2 with
PEAP.
• All platforms support only RADIUS as the authentication server.
• If the primary RADIUS server becomes unresponsive, the authenticator begins using a secondary RADIUS server, if configured.
• 802.1X is not supported on port-channels or port-channel members.
• The NAS-Port-Type attribute indicates the type of the physical port of the NAS which is authenticating the user. It is used in AccessRequest packets. The value of this attribute is set as Ethernet (15) for both EAP and MAB supplicants.
Enabling 802.1X
Enable 802.1X globally.
Figure 7. 802.1X Enabled
802.1X
81
1. Enable 802.1X globally.
CONFIGURATION mode
dot1x authentication
2. Enter INTERFACE mode on an interface or a range of interfaces.
INTERFACE mode
interface [range]
3. Enable 802.1X on the supplicant interface only.
INTERFACE mode
dot1x authentication
Verify that 802.1X is enabled globally and at the interface level using the show running-config | find dot1x command from
EXEC Privilege mode.
In the following example, the bold lines show that 802.1X is enabled.
DellEMC#show running-config | find dot1x
dot1x authentication
!
[output omitted]
!
interface twentyFiveGigE 1/1
no ip address
dot1x authentication
no shutdown
!
DellEMC#
To view 802.1X configuration information for an interface, use the show dot1x interface command.
In the following example, the bold lines show that 802.1X is enabled on all ports unauthorized by default.
DellEMC#show dot1x interface twentyFiveGigE 1/1
802.1x information on Tf 1/1:
-----------------------------
Dot1x Status: Enable
Port Control: AUTO
Port Auth Status: UNAUTHORIZED
Re-Authentication: Disable
Untagged VLAN id: None
Guest VLAN: Disable
Guest VLAN id: NONE
Auth-Fail VLAN: Disable
Auth-Fail VLAN id: NONE
Auth-Fail Max-Attempts: NONE
Mac-Auth-Bypass: Disable
Mac-Auth-Bypass Only: Disable
Tx Period: 30 seconds
Quiet Period: 60 seconds
ReAuth Max: 2
Supplicant Timeout: 30 seconds
Server Timeout: 30 seconds
Re-Auth Interval: 3600 seconds
Max-EAP-Req: 2
Host Mode: SINGLE_HOST
Auth PAE State: Initialize
Backend State: Initialize
Configuring dot1x Profile
You can configure a dot1x profile for defining a list of trusted supplicant MAC addresses. A maximum of 10 dot1x profiles can be
configured. The profile name length is limited to 32 characters. Thedot1x profile {profile-name} command sets the dot1x
profile mode and you can enter profile-related commands, such as the
To configure a dot1x profile, use the following commands.
• Configure a dot1x profile.
82
802.1X
mac command.
CONFIGURATION mode
dot1x profile {profile-name}
profile—name — Enter the dot1x profile name. The profile name length is limited to 32 characters.
DellEMC(conf)#dot1x profile test
DellEMC(conf-dot1x-profile)#
DellEMC#show dot1x profile
802.1x profile information
----------------------------Dot1x Profile test
Profile MACs
00:00:00:00:01:11
Configuring the Static MAB and MAB Profile
Enable MAB (mac-auth-bypass) before using the dot1x static-mab command to enable static mab.
To enable static MAB and configure a static MAB profile, use the following commands.
• Configure static MAB and static MAB profile on dot1x interface.
INTERFACE mode
dot1x static-mab profile profile-name
Eenter a name to configure the static MAB profile name. The profile name length is limited to a maximum of 32 characters.
DellEMC(conf-if-Tf-1/1)#dot1x static-mab profile sample
DellEMC(conf-if-Tf-1/1))#show config
!
interface twentyFiveGigE 21
switchport
dot1x static-mab profile sample
no shutdown
DellEMC(conf-if-Tf-1/1))#show dot1x interface twentyFiveGigE 1/1
802.1x information on Tf 1/1:
-----------------------------
Dot1x Status: Enable
Port Control: Auto
Port Auth Status: AUTHORIZED(STATIC-MAB)
Re-Authentication: Disable
Untagged VLAN id: None
Guest VLAN: Enable
Guest VLAN id: 100
Auth-Fail VLAN: Enable
Auth-Fail VLAN id: 200
Auth-Fail Max-Attempts:3
Critical VLAN: Enable
Critical VLAN id: 300
Mac-Auth-Bypass Only: Disable
Static-MAB: Enable
Static-MAB Profile: Sample
Tx Period: 90 seconds
Quiet Period: 120 seconds
ReAuth Max: 10
Supplicant Timeout: 30 seconds
Server Timeout: 30 seconds
Re-Auth Interval: 7200 seconds
Max-EAP-Req: 10
Auth Type: SINGLE_HOST
Auth PAE State: Authenticated
Backend State: Idle
802.1X
83
Configuring Critical VLAN
By default, critical-VLAN is not configured. If authentication fails because of a server which is not reachable, user session is authenticated
under critical-VLAN.
To configure a critical-VLAN for users or devices when authenticating server is not reachable, use the following command.
• Enable critical VLAN for users or devices
INTERFACE mode
dot1x critical-vlan [{vlan-id}]
Specify a VLAN interface identifier to be configured as a critical VLAN. The VLAN ID range is 1– 4094.
DellEMC(conf-if-Tf-1/2)#dot1x critical-vlan 300
DellEMC(conf-if-Tf 1/2)#show config
!
interface twentyFiveGigE 1/2
switchport
dot1x critical-vlan 300
no shutdown
DellEMC#show dot1x interface twentyFiveGigE 1/2
802.1x information on Tf 1/2:
-----------------------------------------------------Dot1x Status: Enable
Port Control: AUTO
Port Auth Status: AUTHORIZD(MAC-AUTH-BYPASS)
Critical VLAN Enable
Critical VLAN id: 300
Re-Authentication: Disable
Untagged VLAN id: 400
Guest VLAN: Enable
Guest VLAN id: 100
Auth-Fail VLAN: Disable
Auth-Fail VLAN id: NONE
Auth-Fail Max-Attempts: NONE
Mac-Auth-Bypass: Enable
Mac-Auth-Bypass Only: Enable
Tx Period: 3 seconds
Quiet Period: 60 seconds
ReAuth Max: 2
Supplicant Timeout: 30 seconds
Server Timeout: 30 seconds
Re-Auth Interval: 3600 seconds
Max-EAP-Req: 2
Host Mode: SINGLE_HOST
Auth PAE State: Authenticated
Backend State: Idle
Configuring MAC addresses for a do1x Profile
To configure a list of MAC addresses for a dot1x profile, use the mac command. You can configure 1 to 6 MAC addresses.
• Configure a list of MAC addresses for a dot1x profile.
DOT1X PROFILE CONFIG (conf-dot1x-profile)
mac mac-address
mac-address — Enter the keyword mac and type up to the 48– bit MAC addresses using the nn:nn:nn:nn:nn:nn format. A
maximum of 6 MAC addresses are allowed.
The following example configures 2 MAC addresses and then displays these addresses.
DellEMC(conf-dot1x-profile)#mac 00:50:56:AA:01:10 00:50:56:AA:01:11
DellEMC(conf-dot1x-profile)#show config
dot1x profile sample
mac 00:50:56:aa:01:10
84
802.1X
mac 00:50:56:aa:01:11
DellEMC(conf-dot1x-profile)#
DellEMC(conf-dot1x-profile)#exit
DellEMC(conf)#
Configuring Request Identity Re-Transmissions
When the authenticator sends a Request Identity frame and the supplicant does not respond, the authenticator waits for 30 seconds and
then re-transmits the frame.
The amount of time that the authenticator waits before re-transmitting and the maximum number of times that the authenticator retransmits can be configured.
NOTE: There are several reasons why the supplicant might fail to respond; for example, the supplicant might have been
booting when the request arrived or there might be a physical layer problem.
To configure re-transmissions, use the following commands.
• Configure the amount of time that the authenticator waits before re-transmitting an EAP Request Identity frame.
INTERFACE mode
dot1x tx-period number
The range is from 1 to 65535 (1 year)
The default is 30.
• Configure the maximum number of times the authenticator re-transmits a Request Identity frame.
INTERFACE mode
dot1x max-eap-req number
The range is from 1 to 10.
The default is 2.
The example in Configuring a Quiet Period after a Failed Authentication shows configuration information for a port for which the
authenticator re-transmits an EAP Request Identity frame after 90 seconds and re-transmits for 10 times.
Configuring a Quiet Period after a Failed Authentication
If the supplicant fails the authentication process, the authenticator sends another Request Identity frame after 30 seconds by default. You
can configure this period.
NOTE:
Identity Re-transmit interval (dot1x tx-period) is for an unresponsive supplicant.
To configure a quiet period, use the following command.
• Configure the amount of time that the authenticator waits to re-transmit a Request Identity frame after a failed authentication.
INTERFACE mode
dot1x quiet-period seconds
The range is from 1 to 65535.
The default is 60 seconds.
The following example shows configuration information for a port for which the authenticator re-transmits an EAP Request Identity frame:
• after 90 seconds and a maximum of 10 times for an unresponsive supplicant
• re-transmits an EAP Request Identity frame
The bold lines show the new re-transmit interval, new quiet period, and new maximum re-transmissions.
DellEMC(conf-if-range-tf-1/1)#dot1x tx-period 90
DellEMC(conf-if-range-tf-1/1)#dot1x max-eap-req 10
DellEMC(conf-if-range-tf-1/1)#dot1x quiet-period 120
DellEMC#show dot1x interface twentyFiveGigE 1/1
802.1x information on Tf 1/1:
----------------------------Dot1x Status: Enable
Port Control: AUTO
Port Auth Status: UNAUTHORIZED
Re-Authentication: Disable
The quiet period (dot1x quiet-period) is the transmit interval after a failed authentication; the Request
802.1X
85
Untagged VLAN id: None
Tx Period: 90 seconds
Quiet Period: 120 seconds
ReAuth Max: 2
Supplicant Timeout: 30 seconds
Server Timeout: 30 seconds
Re-Auth Interval: 3600 seconds
Max-EAP-Req: 10
Auth Type: SINGLE_HOST
Auth PAE State: Initialize
Backend State: Initialize
Forcibly Authorizing or Unauthorizing a Port
The 802.1X ports can be placed into any of the three states:
• ForceAuthorized — an authorized state. A device connected to this port in this state is never subjected to the authentication
process, but is allowed to communicate on the network. Placing the port in this state is same as disabling 802.1X on the port.
• ForceUnauthorized — an unauthorized state. A device connected to a port in this state is never subjected to the authentication
process and is not allowed to communicate on the network. Placing the port in this state is the same as shutting down the port. Any
attempt by the supplicant to initiate authentication is ignored.
• Auto — an unauthorized state by default. A device connected to this port in this state is subjected to the authentication process. If
the process is successful, the port is authorized and the connected device can communicate on the network. All ports are placed in
the Auto state by default.
To set the port state, use the following command.
• Place a port in the ForceAuthorized, ForceUnauthorized, or Auto state.
INTERFACE mode
dot1x port-control {force-authorized | force-unauthorized | auto}
The default state is auto.
The example shows configuration information for a port that has been force-authorized.
The bold line shows the new port-control state.
DellEMC(conf-if-tf-1/1)#dot1x port-control force-authorized
DellEMC(conf-if-tf-1/1)#show dot1x interface twentyFiveGigE 1/1
802.1x information on Tf 1/1:
----------------------------Dot1x Status: Enable
Port Control: FORCE_AUTHORIZED
Port Auth Status: UNAUTHORIZED
Re-Authentication: Disable
Untagged VLAN id: None
Tx Period: 90 seconds
Quiet Period: 120 seconds
ReAuth Max: 2
Supplicant Timeout: 30 seconds
Server Timeout: 30 seconds
Re-Auth Interval: 3600 seconds
Max-EAP-Req: 10
Auth Type: SINGLE_HOST
Auth PAE State: Initialize
Backend State: Initialize
Auth PAE State: Initialize
Backend State: Initialize
Re-Authenticating a Port
You can configure the authenticator for periodic re-authentication.
After the supplicant has been authenticated, and the port has been authorized, you can configure the authenticator to re-authenticate the
supplicant periodically. If you enable re-authentication, the supplicant is required to re-authenticate every 3600 seconds by default, and
you can configure this interval. You can configure the maximum number of re-authentications as well.
86
802.1X
To configure re-authentication time settings, use the following commands:
• Configure the authenticator to periodically re-authenticate the supplicant.
INTERFACE mode
dot1x reauthentication [interval] seconds
The range is from 1 to 31536000.
The default is 3600.
• Configure the maximum number of times the supplicant can be re-authenticated.
INTERFACE mode
dot1x reauth-max number
The range is from 1 to 10.
The default is 2.
The bold lines show that re-authentication is enabled and the new maximum and re-authentication time period.
DellEMC(conf-if-tf-1/1)#dot1x reauthentication interval 7200
DellEMC(conf-if-tf-1/1)#dot1x reauth-max 10
DellEMC(conf-if-tf-1/1)#do show dot1x interface twentyFiveGigE 1/1
802.1x information on Tf 1/1:
----------------------------Dot1x Status: Enable
Port Control: FORCE_AUTHORIZED
Port Auth Status: UNAUTHORIZED
Re-Authentication: Enable
Untagged VLAN id: None
Tx Period: 90 seconds
Quiet Period: 120 seconds
ReAuth Max: 10
Supplicant Timeout: 30 seconds
Server Timeout: 30 seconds
Re-Auth Interval: 7200 seconds
Max-EAP-Req: 10
Auth Type: SINGLE_HOST
Auth PAE State: Initialize
Backend State: Initialize
Auth PAE State: Initialize
Backend State: Initialize
Configuring Timeouts
If the supplicant or the authentication server is unresponsive, the authenticator terminates the authentication process after 30 seconds by
default. You can configure the amount of time the authenticator waits for a response.
To terminate the authentication process, use the following commands:
• Terminate the authentication process due to an unresponsive supplicant.
INTERFACE mode
dot1x supplicant-timeout seconds
The range is from 1 to 300.
The default is 30.
• Terminate the authentication process due to an unresponsive authentication server.
INTERFACE mode
dot1x server-timeout seconds
The range is from 1 to 300.
The default is 30.
The example shows configuration information for a port for which the authenticator terminates the authentication process for an
unresponsive supplicant or server after 15 seconds.
The bold lines show the new supplicant and server timeouts.
DellEMC(conf-if-tf-1/1)#dot1x port-control force-authorized
DellEMC(conf-if-tf-1/1)#do show dot1x interface twentyFiveGigE 1/1
802.1X
87
802.1x information on Tf 1/1:
----------------------------Dot1x Status: Enable
Port Control: FORCE_AUTHORIZED
Port Auth Status: UNAUTHORIZED
Re-Authentication: Disable
Untagged VLAN id: None
Guest VLAN: Disable
Guest VLAN id: NONE
Auth-Fail VLAN: Disable
Auth-Fail VLAN id: NONE
Auth-Fail Max-Attempts: NONE
Tx Period: 90 seconds
Quiet Period: 120 seconds
ReAuth Max: 10
Supplicant Timeout: 15 seconds
Server Timeout: 15 seconds
Re-Auth Interval: 7200 seconds
Max-EAP-Req: 10
Auth Type: SINGLE_HOST
Auth PAE State: Initialize
Backend State: Initialize
Enter the tasks the user should do after finishing this task (optional).
Configuring Dynamic VLAN Assignment with Port Authentication
Dell EMC Networking OS supports dynamic VLAN assignment when using 802.1X.
The basis for VLAN assignment is RADIUS attribute 81, Tunnel-Private-Group-ID. Dynamic VLAN assignment uses the standard dot1x
procedure:
1. The host sends a dot1x packet to the Dell EMC Networking system
2. The system forwards a RADIUS REQEST packet containing the host MAC address and ingress port number
3. The RADIUS server authenticates the request and returns a RADIUS ACCEPT message with the VLAN assignment using TunnelPrivate-Group-ID
The illustration shows the configuration on the Dell EMC Networking system before connecting the end user device in black and blue text,
and after connecting the device in red text. The blue text corresponds to the preceding numbered steps on dynamic VLAN assignment
with 802.1X.
88
802.1X
Figure 8. Dynamic VLAN Assignment
1. Configure 8021.x globally (refer to Enabling 802.1X) along with relevant RADIUS server configurations (refer to the illustration
Dynamic VLAN Assignment with Port Authentication).
in
2. Make the interface a switchport so that it can be assigned to a VLAN.
3. Create the VLAN to which the interface will be assigned.
4. Connect the supplicant to the port configured for 802.1X.
5. Verify that the port has been authorized and placed in the desired VLAN (refer to the illustration in Dynamic VLAN Assignment with
Port Authentication).
Guest and Authentication-Fail VLANs
Typically, the authenticator (the Dell system) denies the supplicant access to the network until the supplicant is authenticated. If the
supplicant is authenticated, the authenticator enables the port and places it in either the VLAN for which the port is configured or the
VLAN that the authentication server indicates in the authentication data.
NOTE:
If the supplicant fails authentication, the authenticator typically does not enable the port. In some cases this behavior is not appropriate.
External users of an enterprise network, for example, might not be able to be authenticated, but still need access to the network. Also,
some dumb-terminals, such as network printers, do not have 802.1X capability and therefore cannot authenticate themselves. To be able
to connect such devices, they must be allowed access the network without compromising network security.
The Guest VLAN 802.1X extension addresses this limitation with regard to non-802.1X capable devices and the Authentication-fail VLAN
802.1X extension addresses this limitation with regard to external users.
• If the supplicant fails authentication a specified number of times, the authenticator places the port in the Authentication-fail VLAN.
• If a port is already forwarding on the Guest VLAN when 802.1X is enabled, the port is moved out of the Guest VLAN and the
authentication process begins.
Ports cannot be dynamically assigned to the default VLAN.
802.1X
89
Configuring a Guest VLAN
If the supplicant does not respond within a determined amount of time ([reauth-max + 1] * tx-period, the system assumes that the host
does not have 802.1X capability and the port is placed in the Guest VLAN.
NOTE: For more information about configuring timeouts, refer to Configuring Timeouts.
Configure a port to be placed in the Guest VLAN after failing to respond within the timeout period using the dot1x guest-vlan
command from INTERFACE mode. View your configuration using the show config command from INTERFACE mode or using the
show dot1x interface command from EXEC Privilege mode.
Example of Viewing Guest VLAN Configuration
DellEMC(conf-if-tf-1/1)#dot1x guest-vlan 200
DellEMC(conf-if-tf-1/1))#show config
!
interface twentyFiveGigE 1/1
switchport
dot1x guest-vlan 200
no shutdown
DellEMC(conf-if-tf-1/1))#
Configuring an Authentication-Fail VLAN
If the supplicant fails authentication, the authenticator re-attempts to authenticate after a specified amount of time.
NOTE:
Authentication.
You can configure the maximum number of times the authenticator re-attempts authentication after a failure (3 by default), after which
the port is placed in the Authentication-fail VLAN.
Configure a port to be placed in the VLAN after failing the authentication process as specified number of times using the dot1x auth-
fail-vlan command from INTERFACE mode. Configure the maximum number of authentication attempts by the authenticator using
the keyword max-attempts with this command.
Example of Configuring Maximum Authentication Attempts
DellEMC(conf-if-Tf-1/1)#dot1x guest-vlan 200
DellEMC(conf-if-Tf-1/1)#show config
!
interface twentyFiveGigE 1/1
switchport
dot1x authentication
dot1x guest-vlan 200
no shutdown
DellEMC(conf-if-Tf-1/1)#
DellEMC(conf-if-Tf-1/1)#dot1x auth-fail-vlan 100 max-attempts 5
DellEMC(conf-if-Tf-1/1)#show config
!
interface twentyFiveGigE 1/1
switchport
dot1x authentication
dot1x guest-vlan 200
dot1x auth-fail-vlan 100 max-attempts 5
no shutdown
DellEMC(conf-if-Tf-1/1)#
For more information about authenticator re-attempts, refer to Configuring a Quiet Period after a Failed
View your configuration using the show config command from INTERFACE mode, as shown in the example in Configuring a Guest
VLAN or using the show dot1x interface command from EXEC Privilege mode.
Example of Viewing Configured Authentication
802.1x information on Te 2/1/1:
----------------------------Dot1x Status: Enable
Port Control: FORCE_AUTHORIZED
Port Auth Status: UNAUTHORIZED
90
802.1X
Re-Authentication: Disable
Untagged VLAN id: None
Guest VLAN: Disabled
Guest VLAN id: 200
Auth-Fail VLAN: Disabled
Auth-Fail VLAN id: 100
Auth-Fail Max-Attempts: 5
Tx Period: 90 seconds
Quiet Period: 120 seconds
ReAuth Max: 10
Supplicant Timeout: 15 seconds
Server Timeout: 15 seconds
Re-Auth Interval: 7200 seconds
Max-EAP-Req: 10
Auth Type: SINGLE_HOST
Auth PAE State: Initialize
Backend State: Initialize
802.1X 91
6
Access Control List (ACL) VLAN Groups and
Content Addressable Memory (CAM)
Optimizing CAM Utilization During the Attachment of ACLs to VLANs
To minimize the number of entries in CAM, enable and configure the ACL CAM feature. Use this feature when you apply ACLs to a VLAN
(or a set of VLANs) and when you apply ACLs to a set of ports. The ACL CAM feature allows you to effectively use the Layer 3 CAM
space with VLANs and Layer 2 and Layer 3 CAM space with ports.
To avoid using too much CAM space, configure ACL VLAN groups into a single group. A class identifier (Class ID) is assigned for each of
the ACLs attached to the VLAN and this Class ID is used as an identifier or locator in the CAM space instead of the VLAN ID. This method
of processing reduces the number of entries in the CAM area and saves memory space by using the Class ID for filtering in CAM instead
of the VLAN ID.
When you apply an ACL separately on the VLAN interface, each ACL has a mapping with the VLAN and you use more CAM space. To
maximize CAM space, create an ACL VLAN group and attach the ACL with the VLAN members.
The ACL manager application on the router processor (RP1) contains all the state information about all the ACL VLAN groups that are
present. The ACL handler on the control processor (CP) and the ACL agent on the line cards do not contain any information about the
group. After you enter the acl-vlan-group command, the ACL manager application performs the validation. If the command is valid, it
is processed and sent to the agent, if required. If a configuration error is found or if the maximum limit has exceeded for the ACL VLAN
groups present on the system, an error message displays. After you enter the acl-vlan-group command, the ACL manager application
verifies the following parameters:
• Whether the CAM profile is set in virtual flow processing (VFP).
• Whether the maximum number of groups in the system is exceeded.
• Whether the maximum number of VLAN numbers permitted per ACL group is exceeded.
• When a VLAN member that is being added is already a part of another ACL group.
After these verification steps are performed, the ACL manager considers the command valid and sends the information to the ACL agent
on the line card. The ACL manager notifies the ACL agent in the following cases:
• A VLAN member is added or removed from a group and previously associated VLANs exist in the group.
• The egress ACL is applied or removed from the group and the group contains VLAN members.
• VLAN members are added or deleted from a VLAN, which itself is a group member.
• A line card returns to the active state after going down and this line card contains a VLAN that is a member of an ACL group.
• The ACL VLAN group is deleted and it contains VLAN members.
The ACL manager does not notify the ACL agent in the following cases:
• The ACL VLAN group is created.
• The ACL VLAN group is deleted and it does not contain VLAN members.
• The ACL is applied or removed from a group and the ACL group does not contain a VLAN member.
• The description of the ACL group is added or removed.
Guidelines for Configuring ACL VLAN Groups
Keep the following points in mind when you configure ACL VLAN groups:
• The interfaces where you apply the ACL VLAN group function as restricted interfaces. The ACL VLAN group name identifies the
group of VLANs that performs hierarchical filtering.
• You can add only one ACL to an interface at a time.
• When you attach an ACL VLAN group to the same interface, validation performs to determine whether the ACL is applied directly to
an interface. If you previously applied an ACL separately to the interface, an error occurs when you attempt to attach an ACL VLAN
group to the same interface.
92 Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM)
• The maximum number of members in an ACL VLAN group is determined by the type of switch and its hardware capabilities. This
scaling limit depends on the number of slices that are allocated for ACL CAM optimization. If one slice is allocated, the maximum
number of VLAN members is 256 for all ACL VLAN groups. If two slices are allocated, the maximum number of VLAN members is 512
for all ACL VLAN groups.
• The maximum number of VLAN groups that you can configure also depends on the hardware specifications of the switch. Each VLAN
group is mapped to a unique ID in the hardware. The maximum number of ACL VLAN groups supported is 31. Only a maximum of two
components (iSCSI counters, Open Flow, ACL optimization, and so on) can be allocated virtual flow processing slices at a time.
• Port ACL optimization is applicable only for ACLs that are applied without the VLAN range.
• If you enable the ACL VLAN group capability, you cannot view the statistical details of ACL rules per VLAN and per interface. You can
only view the counters per ACL only using the
• Within a port, you can apply Layer 2 ACLs on a VLAN or a set of VLANs. In this case, CAM optimization is not applied.
• To enable optimization of CAM space for Layer 2 or Layer 3 ACLs that are applied to ports, the port number is removed as a qualifier
for ACL application on ports, and port bits are used. When you apply the same ACL to a set of ports, the port bitmap is set when the
ACL flow processor (FP) entry is added. When you remove the ACL from a port, the port bitmap is removed.
• If you do not attach an ACL to any of the ports, the FP entries are deleted. Similarly, when the same ACL is applied on a set of ports,
only one set of entries is installed in the FP, thereby saving CAM space. Enable optimization using the optimized option in the
access-group command. This option is not valid for VLAN and link aggregation group (LAG) interfaces.
show ip accounting access list command.
ip
Configuring ACL VLAN Groups and Configuring FP Blocks for VLAN Parameters
This section describes how to optimize CAM blocks by configuring ACL VLAN groups that you can attach to VLAN interfaces. It also
describes how to configure FP blocks for different VLAN operations.
Configuring ACL VLAN Groups
You can create an ACL VLAN group and attach the ACL with the VLAN members. The optimization is applicable only when you create an
ACL VLAN group.
1. Create an ACL VLAN group.
CONFIGURATION mode
acl-vlan-group {group name}
2. Add a description to the ACL VLAN group.
CONFIGURATION (conf-acl-vl-grp) mode
description description
3. Add VLAN member(s) to an ACL VLAN group.
CONFIGURATION (conf-acl-vl-grp) mode
member vlan {VLAN-range}
4. Display all the ACL VLAN groups or display a specific ACL VLAN group, identified by name.
CONFIGURATION (conf-acl-vl-grp) mode
show acl-vlan-group {group name | detail}
DellEMC#show acl-vlan-group detail
Group Name :
TestGroupSeventeenTwenty
Vlan Members :
100,200,300
Group Name :
CustomerNumberIdentificationEleven
Vlan Members :
2-10,99
Group Name :
HostGroup
Vlan Members :
Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM)
93
1,1000
DellEMC#
Configuring FP Blocks for VLAN Parameters
To allocate the number of FP blocks for the various VLAN processes on the system, use the cam-acl-vlan command. To reset the
number of FP blocks to the default, use the no version of this command. By default, 0 groups are allocated for the ACL in VLAN
contentaware processor (VCAP). ACL VLAN groups or CAM optimization is not enabled by default. You also must allocate the slices for
CAM optimization.
1. Allocate the number of FP blocks for VLAN operations.
CONFIGURATION mode
cam-acl-vlan vlanopenflow <0-2>
2. Allocate the number of FP blocks for ACL VLAN optimization.
CONFIGURATION mode
cam-acl-vlan vlanaclopt <0-2>
3. View the number of FP blocks that is allocated for the different VLAN services.
EXEC Privilege mode
DellEMC#show cam-usage switch
Stackunit|Portpipe| CAM Partition | Total CAM | Used CAM |Available CAM
========|========|=================|============|============|=============
1 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | OUT-L2 ACL | 206 | 9 | 197
Codes: * - cam usage is above 90%.
Viewing CAM Usage
View the amount of CAM space available, used, and remaining in each partition (including IPv4Flow and Layer 2 ACL sub- partitions) using
the show cam-usage command in EXEC Privilege mode.
Display Layer 2, Layer 3, ACL, or all CAM usage statistics.
EXCE Privilege mode
show cam usage [acl | router | switch]
The following output shows CAM blocks usage for Layer 2 and Layer 3 ACLs and other processes that use CAM space:
In S5048F–ON, ACL filters support more than 200 egress ACL rules.
DellEMC#show cam-usage
Stackunit|Portpipe|Pipeline| CAM Partition | Total CAM | Used CAM |Available CAM
========|========|========|=================|=============|=============|==============
1 | 0 | 0 | IN-L2 ACL | 256 | 0 | 256
| | | IN-L3 ACL | 256 | 1 | 255
| | | IN-L3 ECMP GRP | 2048 | 0 | 2048
| | | IN-V6 ACL | 0 | 0 | 0
| | | IN-NLB ACL | 0 | 0 | 0
| | | IPMAC ACL | 256 | 0 | 256
| | | IN-L3-UDFMIRRACL | 0 | 0 | 0
| | | IN-L3-MIRR ACL | 0 | 0 | 0
| | | OUT-L2 ACL | 206 | 12 | 194
| | | OUT-L3 ACL | 172 | 8 | 164
| | | OUT-V6 ACL | 172 | 3 | 169
| | | IN-L3 QOS | 256 | 0 | 256
| | | IN-L3 FIB | 90112 | 3 | 90109
1 | 0 | 1 | IN-L2 ACL | 256 | 0 | 256
| | | IN-L3 ACL | 256 | 1 | 255
| | | IN-L3 ECMP GRP | 0 | 0 | 0
| | | IN-V6 ACL | 0 | 0 | 0
| | | IN-NLB ACL | 0 | 0 | 0
| | | IPMAC ACL | 256 | 0 | 256
| | | IN-L3-UDFMIRRACL | 0 | 0 | 0
| | | IN-L3-MIRR ACL | 0 | 0 | 0
| | | OUT-L2 ACL | 206 | 12 | 194
| | | OUT-L3 ACL | 172 | 8 | 164
94
Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM)
| | | OUT-V6 ACL | 172 | 3 | 169
| | | IN-L3 QOS | 256 | 0 | 256
1 | 0 | 2 | IN-L2 ACL | 256 | 0 | 256
| | | IN-L3 ACL | 256 | 1 | 255
| | | IN-L3 ECMP GRP | 0 | 0 | 0
| | | IN-V6 ACL | 0 | 0 | 0
| | | IN-NLB ACL | 0 | 0 | 0
| | | IPMAC ACL | 256 | 0 | 256
| | | IN-L3-UDFMIRRACL | 0 | 0 | 0
| | | IN-L3-MIRR ACL | 0 | 0 | 0
| | | OUT-L2 ACL | 206 | 12 | 194
| | | OUT-L3 ACL | 172 | 8 | 164
| | | OUT-V6 ACL | 172 | 3 | 169
| | | IN-L3 QOS | 256 | 0 | 256
1 | 0 | 3 | IN-L2 ACL | 256 | 0 | 256
| | | IN-L3 ACL | 256 | 1 | 255
| | | IN-L3 ECMP GRP | 0 | 0 | 0
| | | IN-V6 ACL | 0 | 0 | 0
| | | IN-NLB ACL | 0 | 0 | 0
| | | IPMAC ACL | 256 | 0 | 256
| | | IN-L3-UDFMIRRACL | 0 | 0 | 0
| | | IN-L3-MIRR ACL | 0 | 0 | 0
| | | OUT-L2 ACL | 206 | 12 | 194
| | | OUT-L3 ACL | 172 | 8 | 164
| | | OUT-V6 ACL | 172 | 3 | 169
| | | IN-L3 QOS | 256 | 0 | 256
Codes: * - cam usage is above 90%.
DellEMC#show cam-usage
Stackunit|Portpipe| CAM Partition | Total CAM | Used CAM |Available CAM
========|========|=================|=============|=============|==============
1 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-L3 ECMP GRP | 1024 | 0 | 1024
| | IN-L3 FIB | 49152 | 3 | 49149
| | IN-V6 ACL | 0 | 0 | 0
| | IN-NLB ACL | 0 | 0 | 0
| | IPMAC ACL | 0 | 0 | 0
| | OUT-L2 ACL | 206 | 9 | 197
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
2 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-L3 FIB | 49152 | 3 | 49149
| | IN-V6 ACL | 0 | 0 | 0
| | IN-NLB ACL | 0 | 0 | 0
| | IPMAC ACL | 0 | 0 | 0
| | OUT-L2 ACL | 206 | 9 | 197
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
3 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-L3 FIB | 49152 | 3 | 49149
| | IN-V6 ACL | 0 | 0 | 0
| | IN-NLB ACL | 0 | 0 | 0
| | IPMAC ACL | 0 | 0 | 0
| | OUT-L2 ACL | 206 | 9 | 197
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
Codes: * - cam usage is above 90%.
DellEMC#show cam-usage
Stackunit|Portpipe| CAM Partition | Total CAM | Used CAM |Available CAM
=========|========|=================|=============|=============|==============
0 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-L3 ECMP GRP | 1024 | 0 | 1024
| | IN-V6 ACL | 0 | 0 | 0
| | IN-NLB ACL | 0 | 0 | 0
| | IPMAC ACL | 0 | 0 | 0
| | IN-L3-MIRR ACL | 0 | 0 | 0
| | OUT-L2 ACL | 206 | 12 | 194
Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM)
95
| | OUT-L3 ACL | 236 | 8 | 228
| | OUT-V6 ACL | 236 | 3 | 203
| | IN-L3 FIB | 163840 | 3 | 163837
Codes: * - cam usage is above 90%.
DellEMC#
The following output displays CAM space usage when you configure Layer 2 and Layer 3 ACLs:
DellEMC#show cam-usage acl
Stackunit|Portpipe| CAM Partition | Total CAM | Used CAM |Available CAM
========|========|=================|=============|=============|==============
1 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-L3 ECMP GRP | 1024 | 0 | 1024
| | IN-V6 ACL | 0 | 0 | 0
| | OUT-L2 ACL | 206 | 9 | 197
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
2 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-V6 ACL | 0 | 0 | 0
| | OUT-L2 ACL | 206 | 9 | 197
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
3 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-V6 ACL | 0 | 0 | 0
| | OUT-L2 ACL | 206 | 9 | 197
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
Codes: * - cam usage is above 90%.
The following output displays CAM space usage for Layer 2 ACLs:
DellEMC#show cam-usage switch
Stackunit|Portpipe| CAM Partition | Total CAM | Used CAM |Available CAM
========|========|=================|=============|=============|==============
1 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | OUT-L2 ACL | 206 | 9 | 197
2 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | OUT-L2 ACL | 206 | 9 | 197
3 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | OUT-L2 ACL | 206 | 9 | 197
| | IN-L3 ECMP GRP | 1024 | 0 | 1024
Codes: * - cam usage is above 90%.
The following output displays CAM space usage for Layer 3 ACLs:
DellEMC#show cam-usage router
Stackunit|Portpipe| CAM Partition | Total CAM | Used CAM |Available CAM
========|========|=================|=============|=============|==============
1 | 0 | IN-L3 FIB | 49152 | 3 | 49149
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-L3 ECMP GRP | 1024 | 0 | 1024
| | IN-V6 ACL | 0 | 0 | 0
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
2 | 0 | IN-L3 FIB | 49152 | 3 | 49149
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-V6 ACL | 0 | 0 | 0
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
3 | 0 | IN-L3 FIB | 49152 | 3 | 49149
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-V6 ACL | 0 | 0 | 0
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
Codes: * - cam usage is above 90%.
96
Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM)
Allocating FP Blocks for VLAN Processes
The VLAN contentaware processor (VCAP) application is a pre-ingress CAP that modifies the VLAN settings before packets are
forwarded. To support ACL CAM optimization, the CAM carving feature is enhanced. A total of four VCAP groups are present: two fixed
groups and two dynamic groups. Of the two dynamic groups, you can allocate zero, one, or two FP blocks to iSCSI Counters, Open Flow,
and ACL Optimization.
You can configure only two of these features at a time.
• To allocate the number of FP blocks for VLAN open flow operations, use the cam-acl-vlan vlanopenflow <0-2> command.
• To allocate the number of FP blocks for VLAN iSCSI counters, use the cam-acl-vlan vlaniscsi <0-2> command.
• To allocate the number of FP blocks for ACL VLAN optimization, use the cam-acl-vlan vlanaclopt <0-2> command.
To reset the number of FP blocks to the default, use the no version of these commands. By default, zero groups are allocated for the ACL
in VCAP. ACL VLAN groups or CAM optimization is not enabled by default. You must also allocate the slices for CAM optimization.
To display the number of FP blocks that is allocated for the different VLAN services, use the show cam-acl-vlan command. After you
configure the ACL VLAN groups, reboot the system to store the settings in nonvolatile storage. During CAM initialization, the chassis
manager reads the NVRAM and allocates the dynamic VCAP regions.
ACL Optimization to Increase Number of Supported IPv4 ACLs
You can configure the Dell EMC Networking OS to support more number of IPv4 ACLs.
Restrictions for ACL Optimization
After you enable ACL optimization, the system does not support the following features:
• Mirroring dropped packets
• Ability to specify filtering for routed traffic only
• ACLs applied on physical ports with VRF ranges
• ACLs with filter parameters such as DSCP and ECN
• PIM VLT
• Filtering noninitial fragments of a datagram
If your ACL rules contain the following keywords, the system accepts the configuration and shows a message stating that these features
are not supported and ignores the configuration.
• ttl
• fragments
• no-drop
• dscp
• ecn
Optimizing ACL for More Number of IPv4 ACL Rules
To optimize ACL for more number of IPv4 ACL rules, follow these steps:
1. Carve the vlanaclopt CAM region.
CONFIGURATION mode
cam-acl-vlan vlanopenflow 0 vlaniscsi 0 vlanaclopt 2
2. Enable the ACL optimized feature.
CONFIGURATION mode
feature acloptimized
3. Reload the system
EXEC Privilege
reload
Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM)
97
After the system reloads, the Dell Networking OS enables the feature.
DellEMC(conf)#feature acloptimized
Configuration change will be in effect after save and reload. ACL config containing TTL,
layer3 and VRF conflicts with ACL Cam optimzation feature and these keywords would be
discarded while applying the ACL.
Dell#show feature
Feature State
------- ----VRF disabled
UDF disabled
Aclrange disabled
Acloptimized enabled
98 Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM)
7
Access Control Lists (ACLs)
This chapter describes access control lists (ACLs), prefix lists, and route-maps.
At their simplest, access control lists (ACLs), prefix lists, and route-maps permit or deny traffic based on MAC and/or IP addresses. This
chapter describes implementing IP ACLs, IP prefix lists and route-maps. For MAC ACLS, refer to Layer 2.
An ACL is essentially a filter containing some criteria to match (examine IP, transmission control protocol [TCP], or user datagram protocol
[UDP] packets) and an action to take (permit or deny). ACLs are processed in sequence so that if a packet does not match the criterion in
the first filter, the second filter (if configured) is applied. When a packet matches a filter, the switch drops or forwards the packet based
on the filter’s specified action. If the packet does not match any of the filters in the ACL, the packet is dropped (implicit deny).
The number of ACLs supported on a system depends on your content addressable memory (CAM) size. For more information, refer to
User Configurable CAM Allocation and CAM Optimization. For complete CAM profiling information, refer to Content Addressable Memory
(CAM).
You can configure ACLs on VRF instances. In addition to the existing qualifying parameters, Layer 3 ACLs also incorporate VRF ID as one
of the parameters. Using this new capability, you can also configure VRF based ACLs on interfaces.
NOTE:
You can apply VRF-aware ACLs on:
• VRF Instances
• Interfaces
In order to configure VRF-aware ACLs on VRF instances, you must carve out a separate CAM region. You can use the cam-acl
command for allocating CAM regions. As part of the enhancements to support VRF-aware ACLs, the cam-acl command now includes
the following new parameter that enables you to allocate a CAM region: vrfv4acl.
The order of priority for configuring user-defined ACL CAM regions is as follows:
• V4 ACL CAM
• VRF V4 ACL CAM
• L2 ACL CAM
With the inclusion of VRF based ACLs, the order of precedence of Layer 3 ACL rules is as follows:
• Port/VLAN based PERMIT/DENY Rules
• Port/VLAN based IMPLICIT DENY Rules
• VRF based PERMIT/DENY Rules
• VRF based IMPLICIT DENY Rules
NOTE:
permit option.
You can use the ip access-group command to configure VRF-aware ACLs on interfaces. Using the ip access-group command,
in addition to a range of VLANs, you can also specify a range of VRFs as input for configuring ACLs on interfaces. The VRF range is from 1
to 511. These ACLs use the existing V4 ACL CAM region to populate the entries in the hardware and do not require you to carve out a
separate CAM region.
You can apply Layer 3 VRF-aware ACLs only at the ingress level.
In order for the VRF ACLs to take effect, ACLs configured in the Layer 3 CAM region must have an implicit-
NOTE:
You can configure VRF-aware ACLs on interfaces either using a range of VLANs or a range of VRFs but not both.
Topics:
• IP Access Control Lists (ACLs)
• Configure ACL Range Profiles
• Important Points to Remember
• IP Fragment Handling
• Configure a Standard IP ACL
• Configure an Extended IP ACL
• Configure Layer 2 and Layer 3 ACLs
Access Control Lists (ACLs) 99
• Assign an IP ACL to an Interface
• Applying an IP ACL
• Configure Ingress ACLs
• Configure Egress ACLs
• Configuring UDF ACL
• IP Prefix Lists
• ACL Resequencing
• Route Maps
IP Access Control Lists (ACLs)
In Dell EMC Networking switch/routers, you can create two different types of IP ACLs: standard or extended.
A standard ACL filters packets based on the source IP packet. An extended ACL filters traffic based on the following criteria:
• IP protocol number
• Source IP address
• Destination IP address
• Source TCP port number
• Destination TCP port number
• Source UDP port number
• Destination UDP port number
For more information about ACL options, refer to the Dell EMC Networking OS Command Reference Guide.
For extended ACL, TCP, and UDP filters, you can match criteria on specific or ranges of TCP or UDP ports. For extended ACL TCP filters,
you can also match criteria on established TCP sessions.
When creating an access list, the sequence of the filters is important. You have a choice of assigning sequence numbers to the filters as
you enter them, or the Dell EMC Networking Operating System (OS) assigns numbers in the order the filters are created. The sequence
numbers are listed in the display output of the show config and show ip accounting access-list commands.
Ingress and egress Hot Lock ACLs allow you to append or delete new rules into an existing ACL (already written into CAM) without
disrupting traffic flow. Existing entries in the CAM are shuffled to accommodate the new entries. Hot lock ACLs are enabled by default
and support both standard and extended ACLs and on all platforms.
NOTE:
Hot lock ACLs are supported for Ingress ACLs only.
CAM Usage
The following section describes CAM allocation and CAM optimization.
• User Configurable CAM Allocation
• CAM Optimization
User Configurable CAM Allocation
Allocate space for IPV6 ACLs by using the cam-acl command in CONFIGURATION mode.
The CAM space is allotted in filter processor (FP) blocks. The total space allocated must equal 13 FP blocks. (There are 16 FP blocks, but
System Flow requires three blocks that cannot be reallocated.)
The CAM space is allotted in filter processor (FP) blocks. The total space allocated must equal 9 FP blocks. (There are 12 FP blocks, but
System Flow requires three blocks that cannot be reallocated.)
Enter the ipv6acl allocation as a factor of 2 (2, 4, 6, 8, 10). All other profile allocations can use either even or odd numbered ranges.
Enter the ipv6acl allocation as a factor of 3 (3, 6, 9). All other profile allocations can use either even or odd numbered ranges.
If you want to configure ACL's on VRF instances, you must allocate a CAM region using the vrfv4acl option in the cam-acl command.
Save the new CAM settings to the startup-config (use write-mem or copy run start) then reload the system for the new settings
to take effect.
100
Access Control Lists (ACLs)
Loading...
