1
About this guide
This guide provides site preparation recommendations, step-by-step procedures for rack mounting and desk mounting, inserting
modules, and connecting to a power source.
CAUTION: To avoid electrostatic discharge (ESD) damage, wear grounding wrist straps when handling this
equipment.
NOTE: Only trained and qualified personnel can install this equipment. Read this guide before you install and power up this
equipment. This equipment contains two power cords. Disconnect both power cords before servicing.
NOTE: This equipment contains optical transceivers, which comply with the limits of Class 1 laser radiation.
Figure 1. Class 1 laser product tag
NOTE: When no cable is connected, visible and invisible laser radiation may be emitted from the aperture of the optical
transceiver ports. Avoid exposure to laser radiation and do not stare into open apertures.
Regulatory
● Marketing model S4248FB-ON is represented by the regulatory model E22W and the regulatory Type E22W001.
● Marketing model S4248FBL-ON is represented by the regulatory model E22W and the regulatory Type E22W002.
Topics:
• Related documents
• Information Symbols
Related documents
For more information about the S4200-ON Series (S4248FB-ON and S4248FBL-ON), see the following documents:
● OS10 Enterprise Edition Release Notes
● OS10 Enterprise Edition User Guide
● S4200-ON Series Set-up Guide
● Open Networking Hardware Diagnostic Guide
● S4200-ON Series Release Notes
NOTE: For the most recent documentation, visit Dell EMC support: www.dell.com/support.
About this guide 5
Information Symbols
This book uses the following information symbols:
NOTE: The Note icon signals important operational information.
CAUTION: The Caution icon signals information about situations that could result in equipment damage or loss
of data.
NOTE: The Warning icon signals information about hardware handling that could result in injury.
NOTE: The ESD Warning icon requires that you take electrostatic precautions when handling the device.
6 About this guide
S4200-ON series switch
The following sections describe the Dell EMC S4200-ON Series (S4248FB-ON and S4248FBL-ON).
Topics:
• Introduction
• Features
• Physical dimensions
• LED display
• Prerequisites
• S4200-ON configurations
• Luggage tag
Introduction
The S4200-ON Series (S4248FB-ON and S4248FBL-ON) is a one rack unit (RU) compact full-featured high-density
10/25/40/100GbE switch. The switch includes 40 small form-factor pluggable plus (SFP+) optics, six quad form-factor
pluggable 28 (QSFP28) optics (100GbE, 4x25GbE, 40GbE, and 4x10GbE), and two QSFP+ optics for 40/100GbE aggregation
and 1/10GbE top-of-rack (ToR) and end-of-row (EoR) applications.
The S4200-ON Series supports the following configurations:
● 48 x 10GbE + 6 x 100GbE
● 40 x 10GbE + 8 x 40GbE
● 48 x 10GbE + 12 x 50GbE
● 48 x 10GbE + 24 x 25GbE
● 72 x 10GbE
● 40 x 10GbE + 2 x 40GbE + 6 x 100GbE
2
Figure 2. S4200-ON Series I/O-side view
1.
RS-232 console port 2. 40 SFP+ optical ports
3. Two QSFP+ optical ports 4. Six QSFP28 optical ports
5. ESD Jack 6. USB Type A
7. Ethernet management port 8. Luggage tag
S4200-ON series switch 7
Figure 3. S4200-ON Series PSU-side view
1. Five hot-swappable fan units
2. Two hot-swappable PSUs with integrated fans
Features
The S4200-ON Series (S4248FB-ON and S4248FBL-ON) offers the following features:
● Forty 1/10GbE fixed SFP+ ports
● Two QSFP+ ports supporting 40GbE or 4x10GbE breakout
● Six QSFP28 ports
● One RJ-45 console port
● One USB Type-A 2.0 port for additional file storage
● One ESD Jack
● TCAM: on-board Rangeley central processing unit (CPU) system with 32GB DDR III RAM, 64GB iSLC mSATA SSD
● Non-TCAM: on-board Rangeley CPU system with 8GB DDR III RAM, 16GB iSLC mSATA SSD
● Two hot-swappable redundant power supplies
● Five hot-swappable fans modules
● Standard 1U switch
Physical dimensions
The S4200-ON Series (S4248FB-ON and S4248FBL-ON) has the following physical dimensions:
● 434 x 462 x 44 mm (W x D x H)
● 17.1 x 18.2 x 1.72 inches (W x D x H)
● PSU and fan module Handle: 1.57 inches (40 mm)
LED display
The S4200-ON Series (S4248FB-ON and S4248FBL-ON) includes LED displays on the I/O side of the switch.
For more LED information, see your third-party operating software documentation.
8
S4200-ON series switch
LED behavior
The following S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch LED behavior displays during open networking
installation environment (ONIE) operations:
Figure 4. S4200-ON Series LEDs
System LED 2. Locator LED
1.
3. Link Port LED 4. Activity Port LED
5. QSFP28 Port LED 6. RJ-45 Ethernet Port LED: Left is link; right is activity.
7. Fan LED 8. Power LED
Table 1. S4200-ON series LED behavior
LED Description
System Status/Health LED
Power LED
FAN LED
LOCATOR LED/System beacon
RJ-45 Ethernet LED
● Solid green—Normal Operation
● Blinking green—Booting
● Solid yellow—Critical system error
● Blinking yellow—Noncritical system error, fan failure, or
power supply failure
● Off—No power
● Solid green—Normal
● Solid yellow—POST is in process
● Blinking yellow—Power supply failed
● Solid green—Fan powered and running at the expected
RPM
● Blinking yellow—Fan failed, including incompatible airflow
direction when you insert the PSU or fan trays with
differing airflows
● Off—No power
● Off—Locator function is disabled
● Blinking blue—Locator function is enabled
● Off—no link and no activity detected
● On—Activity on the port
● Solid yellow—10MHz activity
● Solid green—100MHz activity
● Blinking green—1GHz activity
S4200-ON series switch 9
Table 2. Management Ethernet port LEDs
LED Description
Link LED
Activity LED
● Off—No Link
● Solid green—Link operating at a maximum speed,
autonegotiated/forced or 1G
● Solid yellow—Link operating at a lower speed,
autonegotiated/forced or 10/100M
● Off—No Link
● Flashing green—Port activity
Table 3. SFP+ port LEDs
LED Description
Link LED
Activity LED
NOTE: There are four LEDs for each QSFP+ and QSFP28 port. For each port, 100GbE or 40GbE uses only one LED,
2x50GbE uses two LEDs, and 4x25GbE or 4x10GbE uses all four LEDs.
● Off—No Link
● Solid green—Link operating at maximum speed, 10G
● Solid yellow — Link operating at a lower speed, 1G
● Flashing yellow, 1 second on/off—Port beacon
● Off—No Link
● Flashing green—Port activity
Table 4. QSFP+ and QSFP28 port LEDs
LED Description
Link/Activity LED
Link/Activity LED—4x25G mode or 4x10G mode
Link/Activity LED—2x50G
● Off—No Link
● Flashing green—Port activity operating at maximum
speed, 100G for QSFP28 ports or 40G for QSFP+ ports
● Flashing yellow—Port activity operating at a lower speed
● Flashing yellow, 1 second on/off—Port beacon
● Off—No Link
● Flashing green—Port activity at 4x25G on a QSFP28 port
or 4x10G on a QSFP+ port
● Flashing yellow—Port activity at 4x10G on a QSFP28 port
● Flashing yellow, 1 second on/off—Port beacon
● Of —No Link
● Flashing yellow—Port activity at 2x50G on a QSFP28 port
● Flashing yellow, 1 second on/off—Port beacon
Prerequisites
The following is a list of required and optional components for the S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch:
Detailed installation instructions for the S42400-ON Series are provided in Site Preparations and Install the S4200-
NOTE:
ON Series.
● S4200-ON Series (S4248FB-ON or S4248FBL-ON) switch or multiple switches, if stacking
● AC country- and regional-specific cables to connect the AC power source to each of the switches’ AC power supplies
● Mounting brackets for rack installation, included
● Screws for rack installation
● #1 and #2 Phillips screw drivers, not included
10
S4200-ON series switch
● Torx screwdriver, not included
● Ground cable screws, included
● Copper or fiber cables
Other optional components are:
● Ground cable and lug for the frame-end of the ground cable
● Extra power supply unit
● Extra fan module
● Extra mounting brackets if installing in a four-post rack or cabinet
S4200-ON configurations
You can order the S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch in several different configurations.
● S4248FB–ON or S4248FBL-ON AC normal airflow: Forty 1/10GbE SFP+ ports, two 40GbE or 4x1/10GbE QSFP+, and six
100/40GbE or 4x25/10GbE or 2x50GbE QSFP28 ports, two AC power supplies, and five fan subsystems with airflow from
the I/O side to the power supply side
● S4248FB–ON or S4248FBL-ON AC reverse airflow: Forty 1/10GbE SFP+ ports, two 40GbE or 4x1/10GbE QSFP+, and six
100/40GbE or 4x25/10GbE or 2x50GbE QSFP28 ports, two AC power supplies, and five fan subsystems with airflow from
the power supply side to the I/O side
● Fan with airflow from the I/O side to the PSU side
● Fan with airflow from the PSU side to the I/O side
● AC Power supply with airflow from the I/O side to the PSU side—normal
● AC Power supply with airflow from the PSU side to the I/O side—reverse
● DC Power supply with airflow from the I/O side to the PSU side—normal
● DC Power supply with airflow from the PSU side to the I/O side—reverse
Luggage tag
The S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch has a pull-out tag, known as a luggage tag, on the I/O-side of
the switch. The front of the luggage tag includes switch ID information. The back of the luggage tag includes a QRL that takes
you to a Dell EMC How-To site where you can watch videos about racking the switch, replacing components, configuring port
channels, and so on.
S4200-ON series switch
11
Figure 5. S4200-ON Series luggage tag
SVC Tag 2. MAC Address
1.
3. PPID 4. Express Service Code
12 S4200-ON series switch
Site preparations
The S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch is suitable for installation as part of a common bond network
(CBN).
You can install the switch in:
● Network telecommunication facilities
● Data centers
● Other locations where the National Electric Code (NEC) applies
For more information about switch specifications, see Specifications.
NOTE: Install the S4200-ON Series switch in a rack or cabinet before installing any optional components.
Topics:
• Site selection
Cabinet placement
•
• Rack mounting
• Switch ground
• Fans and airflow
• Power
• Component storage
3
Site selection
Install Dell EMC equipment in restricted access areas.
A restricted access area is one in which service personnel can only gain access using a special tool, lock, key, or other means of
security. The authority responsible for the location controls access to the restricted area.
Ensure that the area where you install your S4200-ON Series switch meets the following safety requirements:
● Near an adequate power source. Connect the switch to the appropriate branch circuit protection according to your local
electrical codes.
● Switch environmental temperature range is from 0° to 45°C (32° to 113°F).
● Relative humidity is from 5 to 90 percent noncondensing.
● In a dry, clean, well-ventilated and temperature-controlled room, away from heat sources such as hot air vents or direct
sunlight.
● Away from sources of severe electromagnetic noise.
● Inside the restricted access area, positioned in a rack or cabinet, or on a desktop with adequate space in the front, back, and
sides for proper ventilation and access.
● Install the switch in Information Technology Rooms in accordance with Article 645 of the National Electrical Code and NFPA
75.
For more information about switch storage and environmental temperatures, see Specifications.
Cabinet placement
Install the S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch only in indoor cabinets designed for use in a controlled
environment.
Do not install the switch in outside cabinets. For cabinet placement requirements, see Site Selection.
The cabinet must meet minimum size requirements. Airflow must be in accordance with the Electronic Industries Alliance (EIA)
standard. Ensure that there is a minimum of 5 inches (12.7 cm) between the intake and exhaust vents and the cabinet wall.
Site preparations 13
Rack mounting
When you prepare your equipment rack, ensure that the rack is grounded.
Ground the equipment rack to the same ground point the power service in your area uses. The ground path must be permanent.
Switch ground
Dell EMC recommends grounding your switch. Use the S4200-ON Series switch in a CBN.
Connect the grounding cables as described in S4200–ON Series Installation.
Fans and airflow
The S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch fans support two airflow options: normal and reverse.
Fan combinations
Installation of the fans is done as part of the factory install based on stock keeping unit (SKU) type. The S4200-ON Series has
SKUs that support the following configurations:
● AC or DC PSU with fan airflow from the I/O to the PSU—the red indicator is the normal airflow.
● AC or DC PSU with fan airflow from the PSU to the I/O—the blue indicator is the reverse airflow.
Be sure to order the fans suitable to support your site’s ventilation. Use a single type of airflow fan in your switch. Do not mix
reverse and normal airflows in a single S4200-ON Series switch.
For proper ventilation, position the switch in an equipment rack (or cabinet) with a minimum of 5 inches (12.7 cm) of clearance
around the exhaust vents. When you install two S4200-ON Series switches near each other, to permit proper airflow, position
the two switches at least 5 inches (12.7 cm) apart. The fan speed varies based on internal temperature monitoring. The S4200ON Series never intentionally turns off the fans.
For more information, see Fans.
Power
Use the appropriate power cord with the S4200-ON Series (S4248FB-ON and S4248FBL-ON) when connecting the switch to
the power source. An AC power cord is included with each PSU.
When installing AC or DC switches, follow the requirements of the National Electrical Code ANSI/NFPA 70, where applicable.
The switch is powered-up when the power cord is connected between the switch and the power source. For more information,
see Power Supplies.
CAUTION:
multiple power cords. Before servicing, ensure all power cords are disconnected.
CAUTION: Use the power supply cord as the main disconnect device on the AC switch. Ensure that the socket-
outlet is located/installed near the equipment and is easily accessible.
NOTE: Module power is software controlled. You do not see module LEDs when the switch powers up in ONIE.
Always disconnect the power cable before you service the power supply slots. The switch has
Component storage
If you do not install your S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch and components immediately, properly
store the switch and all optional components by following these guidelines:
● Storage location temperature must remain constant. The storage range is from -40°C to 70°C (-40°F to 158°F).
14
Site preparations
● Store on a dry surface or floor, away from direct sunlight, heat, and air conditioning ducts.
● Store in a dust-free environment.
NOTE: ESD damage can occur when components are mishandled. Always wear an ESD-preventive wrist or heel ground
strap when handling the S4200-ON Series switch and its accessories. After you remove the original packaging, place the
S4200-ON Series switch and its components on an anti-static surface.
Site preparations 15
NEBS compliance
For your switch to be network equipment building system (NEBS) compliant, you must follow the instructions detailed in this
section.
To be NEBS compliant, orient your switch in the rack so that the air inlet is from the front aisle and the air exhaust is to the
back aisle.
Topics:
• Important information
• NEBS-compliant ground installation
Important information
WARNING: The SFP+, QSFP, QSFP28, console, Ethernet management, and universal serial bus (USB) ports are
suitable for connection to intrabuilding or unexposed wiring or cabling only. You MUST NOT metallically connect
the ports to interfaces that connect to the out side plant (OSP) or its wiring. Use these interfaces as
intrabuilding interfaces only (Type-2 or Type-4 ports as described in GR-1089-CORE, Issue 6) and they require
isolation from the exposed OSP cabling. Adding primary protectors is not sufficient protection to connect these
interfaces metallically to OSP wiring.
4
WARNING: If you install and connect the S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch to a
commercial AC power source, you must connect the switch to an external special protection device (SPD).
To be NEBs compliant:
● Locate your switch in a restricted-access area were only trained personnel are allowed access.
● Install and connect your switch to the common bonding network (CBN).
● You can also install and connect your switch to the central office.
● Connect the battery returns of your switch as DC-I.
● Ground your switch using a copper ground conductor.
● Clean and coat all bare grounding connection points on your switch with an antioxidant solution before making connections.
● Bring all unplated ground connection surfaces on your switch to a bright finish and treat them with an antioxidant solution
before making connections.
● To ensure electrical continuity, remove any nonconductive surfaces on your switch from the ground connection points and
threaded holes used to secure the ground lugs.
● Use the two-hole, Listed, compression-type lug with an AWG 14 gauge wire for switch grounding.
NOTE: The S4200-ON Series can operate at -40.5 VDC to -60 VDC at a maximum current level of 15A.
NOTE: The S4200-ON Series is Earthquake Z4-compliant when you attach the ReadyRails to the frame using threaded
hardware. Do not use tool-less installation method.
NEBS-compliant ground installation
Before you install the switch into a rack, install the ground (GND) lug assembly.
Your switch includes an assembled UL-certified GND lug with bracket, packaged separately. If any parts are missing, contact
your Dell EMC sales representative.
16 NEBS compliance
Figure 6. GND lug assembly
1. Remove the two installed M3 screws from the lower-left side of your switch.
NOTE: Keep these screws.
2. Remove the bracket assembly from the shipping bag.
3. Clean the bracket and lug surfaces thoroughly and apply an anti-oxidant solution to the mating surfaces.
4. Attach the switch ground using the Ground cable instructions.
5. Using the two removed screws, attach the GND lug bracket assembly to your switch, as shown.
Torque the M3 screws to ±4-5 in-lbs.
Figure 7. Attach the GND lug assembly
NEBS compliance
17
Figure 8. GND lug assembly attached
6. Install your switch into your rack using the Switch installation instructions.
18 NEBS compliance
S4200-ON Series installation
To install the S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch, complete the installation procedures in the order
presented in this section.
Always handle the switch and its components with care. Avoid dropping the switch or its field replaceable units (FRUs).
NOTE: ESD damage can occur if components are mishandled. Always wear an ESD-preventive wrist or heel ground strap
when handling the S4200-ON Series and its components. As with all electrical devices of this type, take all the necessary
safety precautions to prevent injury when installing this switch.
Topics:
• Unpack the switch
• Rack or cabinet installation
• ReadyRails Installation
• S4200-ON Series switch installation
• Ground cable
• Optics installation
• Switch power-up
• After switch installation
• Switch replacement
5
Unpack the switch
NOTE: Before unpacking the switch, inspect the container and immediately report any evidence of damage.
When unpacking the S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch, make sure that the following items are
included:
● One S4200-ON Series (S4248FB-ON or S4248FBL-ON) switch
● One RJ-45 to DB-9 female cable
● Two sets of rail kits, no tools required
● Two PSUs and power cords
● Five fan units
● Two country- and region-specific AC power cords
● S4200-ON Series Set-up Guide
● Safety and Regulatory Information
● Warranty and Support Information
Unpack
1. Place the container on a clean, flat surface and cut all straps securing the container.
2. Open the container or remove the container top.
3. Carefully remove the switch from the container and place it on a secure and clean surface.
4. Remove all packing material.
5. Inspect the product and accessories for damage.
S4200-ON Series installation 19
Rack or cabinet installation
You may either place the switch on a rack shelf or mount the switch directly into a 19" wide, EIA-310- E-compliant rack. Rack
mounting includes four-post, two-post, round threaded holes, or square holes. The ReadyRails system is provided for 1U frontrack and two-post installations.
The ReadyRails system includes two separately packaged rail assemblies. To begin installation, separate each rail assembly by
sliding the inside rail out of the outside rail.
CAUTION: Your switch is not NEBS Earthquake Z4-compliant if you use the 1U tool-less square-hole or two-post
installation methods.
WARNING: This document is a condensed reference. Read the safety instructions in your
and Regulatory
NOTE: The illustrations in this section are not intended to represent a specific switch.
NOTE: Do not the use the mounted ReadyRails as a shelf or a workplace.
information booklet before you begin.
Safety, Environmental,
Rack mount safety considerations
● Rack loading—Overloading or uneven loading of racks may result in shelf or rack failure, possibly damaging the equipment
and causing personal injury. Stabilize racks in a permanent location before loading begins. Mount the components starting at
the bottom of the rack, then work to the top. Do not exceed your rack’s load rating.
● Power considerations—Connect only to the power source specified on the unit. When you install multiple electrical
components in a rack, ensure that the total component power ratings do not exceed the circuit capabilities. Overloaded
power sources and extension cords present fire and shock hazards.
● Elevated ambient temperature—If you install the switch in a closed rack assembly, the operating temperature of the rack
environment may be greater than the room ambient temperature. Use care not to exceed the 45°C maximum ambient
temperature of the switch.
● Reduced air flow—Do not compromise the amount of airflow required for safe operation of the equipment. Install the
equipment in the rack so that the equipment constantly has the correct amount of airflow surrounding it.
● Reliable earthing—Maintain reliable earthing of rack-mounted equipment. Pay particular attention to the supply connections
other than the direct connections to the branch circuit, for example: use of power strips.
● Do not mount the equipment with the fan panel facing downward.
ReadyRails Installation
To easily configure your rack for installation of your S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch, use the
ReadyRails rack mounting system provided.
You can install the ReadyRails system using the 1U tool-less square-hole method or one of three possible 1U threaded round-hole
methods—2-post flush mount, 2-post center mount, or 4-post mount.
CAUTION:
method.
To begin installation, separate each rail assembly by sliding the inside rail out of the outside rail.
NOTE: For more installation instructions, see the installation labels attached to the rail assembly.
Your switch is not NEBS Earthquake Z4-compliant if you use the 1U tool-less square-hole installation
20 S4200-ON Series installation
Figure 9. Separate rails
Tool-less non-threaded mount installation
CAUTION: Your switch is not NEBS Earthquake Z4-compliant if you this installation method.
NOTE: For more installation instructions, see the installation labels attached to the rail assembly.
1. With the ReadyRails flange ears facing outward, place one rail between the left and right vertical posts. Align and seat the
back flange rail pegs in the back vertical post flange. In the following illustration, item 1 and its extractions show how the
pegs appear in both the square and nonthreaded round holes.
S4200-ON Series installation
21
Figure 10. 1U tool-less nonthreaded square hole installation
2. Align and seat the front flange pegs in the holes on the front side of the vertical post.
NOTE: Be sure that the rails click into place and are secure.
3. Repeat this procedure for the second rail.
To remove each rail, pull on the latch release on each flange ear and unseat each rail.
Two-post flush-mount installation
CAUTION: Your switch is not NEBS Earthquake Z4-compliant if you this installation method.
NOTE: For more installation instructions, see the installation labels attached to the rail assembly.
1. For this installation, remove the tool-less latch castings from the front side of each ReadyRails assembly, see item 1.
Use a Torx screwdriver to remove the two screws from each front latch on the switch side of the rail. Remove the tool-less
latch casting. Retain the castings for future rack requirements. Do not remove the back latch castings.
22
S4200-ON Series installation
Figure 11. Two-post center-mount threaded round-hole installation
2. Slide the back bracket towards the post. Secure it with two user-supplied screws, see item 2.
3. Slide the front bracket forward against the front of the vertical post and secure it to the post flange with two user-supplied
screws, see item 3.
4. Repeat this procedure for the second rail.
Two-post center-mount installation
CAUTION: Your switch is not NEBS Earthquake Z4-compliant if you this installation method.
NOTE: For more installation instructions, see the installation labels attached to the rail assembly.
1. Slide the bracket rearward until it clicks into place and secure the rail bracket to the front of the post flange with two usersupplied screws, item 1.
S4200-ON Series installation
23
Figure 12. Two-post center-mount threaded round-hole installation
2. Slide the back bracket towards the post. Secure it to the post flange with two user-supplied screws, see items 2 and 3.
3. Repeat this procedure for the second rail.
Four-post threaded installation
NOTE: To be NEBS Earthquake Z4-compliant, you must remove the tool-less latch castings described in Step 1.
NOTE: For more installation instructions, see the installation labels attached to the rail assembly.
1. For this installation, remove the tool-less latch castings from the front side of each ReadyRails assembly, see item 1.
Use a Torx screwdriver to remove the two screws from each front latch on the switch side of the rail. Remove the tool-less
latch casting. Retain the castings for future rack requirements.
24
S4200-ON Series installation
Figure 13. Four-post threaded round-hole installation
2. For each rail, attach the front and back flanges to the post flanges with two user-supplied screws at each end.
S4200-ON Series switch installation
You can mount the switch in the 1U front-rack or 1U two-post flush or center configurations. The following is an example of a
front-rack configuration:
For the 1U two-post configurations, slide the switch into the rails in the same manner as the four-post configurations.
1U front-rack installation
Configure the rails that are attached to the switch.
1.
NOTE: For more instructions, see the installation instruction labels on the rail.
Attach the inner switch rails to the S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch.
Line up the rail with the mounting heads and attach the rail to the switch. Slide the rail back until it locks into place. The
following shows the detail of the front standoff with the locking tab:
S4200-ON Series installation
25
Figure 14. Attach switch rail
2. After installing both switch rails, line them up on the previously mounted ReadyRails and slide the switch in until it is flush
with front of rack.
To keep the switch from inadvertently sliding out of the rack and falling, about three inches before you fully insert your
switch, the rail locking feature engages.
26
S4200-ON Series installation
Figure 15. Front rack installation
NOTE: Do not the use the mounted Ready-Rails as a shelf or a workplace.
3. Tighten the two thumb screws and rack screws.
To remove the switch from the rack or cabinet, press in the two side-release bars on the switch at the same time and slide the
switch forward.
Ground cable
NOTE:
For AC-powered switches, although the third conductor of the AC power cord provides a ground path, Dell EMC
recommends grounding your switch with a dedicated ground wire.
NOTE: For DC-powered switches, the only way to safely ground your switch is to attach a dedicated ground wire.
Depending on the type of switch, to attach a ground cable to the switch, you need M3 or M4 screws.
The switch ships with one of the following two configurations:
● One threaded hole using an M3 screw.
● Two threaded holes using one of the two M4 screws.
In both configurations, the ground cable is not included. To properly ground the switch, Dell EMC recommends a one- or twohole lug, M3 or M4 hole size. The ground lugs must be a UL-recognized, crimp-type lug.
must
CAUTION: Grounding conductors
NOTE: Coat the one-hole lug with an anti-oxidant compound before crimping. Also, bring any unplated mating surfaces to a
shiny finish and coat with an anti-oxidant before mating. Plated mating surfaces must be clean and free from contamination.
1. Cut the ground cable (not included) to the desired length. The cable length must facilitate proper operation of the fault
interrupt circuits. Use the shortest cable route allowable.
2. To attach the ground cable, use one of the following:
be made of copper. Do not use aluminum conductors.
S4200-ON Series installation
27
● Using one threaded M3 hole, attached the ground cable to the lug using an M3 screw with a captive internal tooth lock
washer. Torque the screw to ±4-5 in-lbs.
● Using one of the two M4 threaded holes, attach the ground cable to the lug. Use an M4 screw with a captive internal
tooth lock washer. Torque the screw to ±5-6 in-lbs.
3. Attach the other end of the ground cable to a suitable ground point such as the rack or cabinet.
The rack installation ears are not a suitable grounding point.
Optics installation
The S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch has 40 SFP+ optical ports, two QSFP+ optical ports, and six
QSFP28 optical ports.
For a list of supported optics, see the S4200-ON Series data sheet at www.dell.com/support or contact your Dell EMC
representative.
CAUTION: ESD damage can occur if components are mishandled. Always wear an ESD-preventive wrist or heel
ground strap when handling the S4200-ON Series and its components.
WARNING: When working with optical fibers, follow all warning labels and always wear eye protection. Never
look directly into the end of a terminated or unterminated fiber or connector as it may cause eye damage.
1. Position the optic so it is in the correct position.
The optic has a key that prevents it from being inserted incorrectly.
2. Insert the optic into the port until it gently snaps into place.
NOTE:
When you cable the ports, be sure not to interfere with the airflow from the small vent holes above and below
the ports.
Optics removal
Remove an optic by pushing the tab on the optic and sliding the optic from the port.
When removing optics with direct attach cables (DACs) from the port, pull the release tab firmly and steadily. Prior to pulling
the release tab, you may need to gently push the optic into the port to ensure that it is seated properly. Do not jerk or tug
repeatedly on the tab.
Switch power-up
Supply power to the S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch after you mount it in a rack or cabinet.
Dell EMC recommends reinspecting your switch before powering up. Verify the following:
● The equipment is properly secured to the rack. Dell EMC recommends properly grounding the switch.
● The ambient temperature around the unit, which may be higher than the room temperature, is within the limits specified for
the S4200–ON, see Specifications.
● There is sufficient airflow around the unit.
● The input circuits are correctly sized for the loads and that you use sufficient overcurrent protection devices.
● All protective covers are in place.
● Blank panels are installed if you do not install optional modules.
CAUTION: Do not power up the switch if you did not install a fan module.
NOTE: A US AC power cable is included for powering up an AC power supply. You must order all other power cables
separately.
NOTE: ESD damage can occur if components are mishandled. Always wear an ESD-preventive wrist or heel ground strap
when handling the S4200-ON Series switch and its components.
28 S4200-ON Series installation
Power up sequence
When the switch powers up, the fans immediately come on at high speed. The fan speed slows as the switch continues to boot
up.
After switch installation
To configure your switch, after you have securely installed and powered on the S4200-ON Series switch, see your open network
installation environment (ONIE)-compatible operating system documentation at http://onie.org. For more information about
working with the ONIE environment, see your switch documentation at www.dell.com/support.
Switch replacement
The following steps describe removing and replacing a switch. For further assistance when replacing a switch, contact your Dell
EMC support representative.
NOTE: ESD damage can occur when components are mishandled. Always wear an ESD-preventive wrist or heel ground
strap when handling the switch and accessories. After you remove the original packaging, place the switch and components
on an anti-static surface.
1. Back up the switch configuration to your back-up computer or laptop TFTP server.
copy running-config tftp://hostip/filepath
To establish a console connection to the switch CLI, assign an IP address on the switch network.
2. Disconnect the power source.
3. Label and remove all cables.
4. Remove the switch from the rack.
At the same time, press in the two side-release bars on the switch and slide the switch forward.
If you are using the fan trays or PSUs in the replacement switch, remove them from the switch.
5. Unpack the new switch.
For more information, see Unpack.
6. Confirm that the software version of the replacement switch is the same as the previously installed switch.
show os-version
If the software versions do not match, upgrade the replacement switch software using the procedure included with the
firmware download.
7. Copy the backed-up switch configuration to the new switch.
copy tftp://hostip/filepath running-config
8. Install the new switch in your rack or cabinet.
For detailed installation instructions, see S4200-ON Series installation.
If you are using the fan trays or PSUs from the removed switch, reinsert them in the replacement switch.
9. Connect all the cables.
10. Power on the switch.
For more information, see Switch power up.
S4200-ON Series installation
29
6
Power supplies
The S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch ships with two AC or DC power supplies.
The S4200-ON Series switch supports AC or DC power supplies with two air-flow directions, normal and reverse. Normal is from
the I/O to the PSU side. Reverse is from the PSU side to the I/O side. Two PSUs are required for full redundancy, but the
switch can operate with a single PSU.
The PSUs are field replaceable. When running with full redundancy—two power supplies installed and running, you can remove
and replace one PSU without disrupting traffic.
CAUTION: To prevent electrical shock, ensure that the S4200-ON Series switch is grounded properly. If you do
not ground your equipment correctly, excessive emissions may result. Use a qualified electrician to ensure that
the power cables meet your local electrical requirements.
NOTE: Connect the power supply to the appropriate branch circuit protection as defined by your local electrical codes and
verify that the remote power source complies with the switch input power specifications.
NOTE: If you use a single PSU, install a blank plate in the other PSU slot. Use power supply 2 (PSU2) as the blank plate
slot. To install the blank plate, use a #1 Philips screw driver.
NOTE: ESD damage can occur if components are mishandled. Always wear an ESD-preventive wrist or heel ground strap
when handling the S4200-ON Series switch and its components.
Topics:
• Components
• AC or DC power supply installation
• Connect DC power supply to power source
Components
The following power supply options are available for the S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch:
● AC or DC power supply with integrated fan
● AC or DC power supply with integrated reverse flow fan
Power supply 1 (PSU1) is on the left side of the switch; power supply 2 (PSU2) is on the right side of the switch.
Figure 16. S4200-ON Series PSUs
1. PSUs
The PSUs have an integrated fan, which you cannot replace individually; if the fans integrated in a PSU fail, you must replace
the entire PSU. However, you can replace the fan trays individually. For fan tray replacement procedures, see Fans.
30 Power supplies
WARNING: Prevent exposure and contact with hazardous voltages. Do not attempt to operate this switch with
the safety cover removed.
CAUTION: Remove the power cable from the PSU before removing the PSU. Also, do not connect the power
cable before you insert the PSU in the switch.
NOTE: To comply with the GR-1089 Lightning Criteria for Equipment Interfacing with AC Power Ports, use an external
surge protection device (SPD) at the AC input of the router.
PSU LEDs
● Solid green—input is OK.
● Flashing yellow—there is a fault with the PSU.
● Flashing green, five times and off—there is a PSU mismatch.
● Flashing green—system update.
● Off—PSU is off.
AC or DC power supply installation
NOTE: The PSU slides into the slot smoothly. Do not force a PSU into a slot as this action may damage the PSU or the
S4200-ON Series switch.
NOTE: Ensure that you correctly install the PSU. When you install the PSU correctly, the power connector is on the right
side of the PSU.
NOTE: If you use a single PSU, install a blank plate in the other PSU slot. If you are only using one power supply, install the
power supply in the first slot, PSU1. Install a blank plate in the second slot, PSU2.
1. Remove the PSU slot cover using a small #1 Phillips screwdriver.
2. Remove the PSU from the electro-static bag.
3. Insert the PSU into the switch PSU slot.
Insert the exposed PCB edge connector first. The PSU slot is keyed so that the PSU can only be fully inserted in one
orientation.
When you install the PSU correctly, it snaps into place and is flushed with the back of the switch.
Figure 17. PSU installation
a. Orange release tab
4. Plug in the appropriate AC three-prongs cord from the switch PSU to the external power source.
5. Repeat steps 1 through 4 if you have a redundant PSU.
Power supplies
31
NOTE: The S4200-ON Series switch powers up when you connect the cables between the power supply and the power
source.
AC or DC power supply replacement
CAUTION: Disconnect the power cord before removing the power supplies. Also, disconnect all power cords
before servicing.
NOTE: The PSU slides into the slot smoothly. Do not force a PSU into a slot as this action may damage the PSU or the
S4200-ON Series switch.
NOTE: If a PSU fails, you must replace the entire unit. There are no field serviceable components in the PSU. To request a
hardware replacement, see Dell EMC support.
NOTE: If you use a single PSU, install a blank plate in the other PSU slot. If you are only using one power supply, install the
power supply in the first slot, PSU1. Install a blank plate in the second slot, PSU2.
1. Disconnect the power cable from the PSU.
2. Use the grab handle to slide the PSU out of the power supply bay.
3. Use the grab handle on the replacement PSU to slide it into the power supply bay.
4. Attach the power cord to the replacement PSU.
NOTE: The switch powers up when the cables are connected between the power supply and the power source.
Connect DC power supply to power source
Each DC powered switch comes with a set containing a prewired, 3-inch 8 AWG, power supply connector and a four-screw
wiring block. One set is provided for each DC PSU.
Figure 18. DC power connector and wiring block
1.
DC wire RTN 2. DC power connector
3. Captive screws (2) 4. Orange tab
5. PSU status LED 6. DC power socket
7. DC wire –48V
1. Strip 0.5 inches of insulation from each of the power connector’s wires, RTN and –48V.
32
Power supplies
2. Insert each of the power connector’s bare wire lengths into the wiring block. Insert RTN into one hole and –48V into the
other hole.
3. Use a flat-blade screwdriver to tighten the screws that secures the bare wires into the wiring block.
4. Secure the site’s DC power source wires to the other side of the wiring block. See steps 1 and 3.
NOTE: Do not cross the wires. In the wiring block, RTN aligns with RTN and –48V aligns with –48V.
5. Insert the DC power connector into the power socket of the DC PSU. Ensure that the connector pins firmly seat and you
hear the click of the power connector’s left and right levered clamps lock into place.
NOTE: Never try to force the power connector into or out of the DC PSU power socket.
NOTE: To remove the power connector from a DC PSU, use the orange tab on the side of the connector. Doing so
disengages the power connector’s clamps. After engaging the orange tab, pull the power connector from the DC PSU
socket.
Power supplies 33
Fans
The S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch comes from the factory with two PSUs and five fan modules
installed in the switch. The fan modules and the power supplies, which have integrated fans, are hot-swappable.
In addition to the power supply modules, you can order and install fan modules separately.
The S4200-ON Series switch supports two airflow direction options—normal and reverse. All fans and PSUs MUST have the
same airflow direction. If you mix the airflow direction, to avoid heat damage to the switch components, you must correct the
mixed airflow direction.
● Airflow is from the I/O panel to the PSU—normal.
● Airflow is from the PSU to the I/O panel—reverse.
Environmental factors can decrease the amount of time required between fan replacements. Check the environmental factors
regularly. An increase in temperature and particulate matter in the air might affect performance—for example, new equipment
installation.
CAUTION: Check the fans at six-month intervals and replace them as necessary. Regularly monitor the speeds
of the fans to accurately determine replacement intervals.
Topics:
• Components
• Fan module installation
7
Components
The following are the S4200-ON Series (S4248FB-ON and S4248FBL-ON) fan components.
● S4200-ON Series Fan module
● S4200-ON Series Fan module—Reverse flow
Figure 19. S4200-ON Series fan modules
1. Fan modules
Fan LEDs
● Solid green—Fan function is normal.
● Flashing yellow—There is a fan fault.
● Off—Fan is off.
34 Fans
Fan module installation
The fan modules in the S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch are field replaceable.
There are five fans. Slot 3 is in the middle of the switch and slot 5 is on the right side of the switch.
CAUTION: DO NOT mix airflow directions. All fans must use the same airflow direction—reverse or normal. If
you mix the airflow direction, to avoid overheating your switch,
1. Take the fan module out of the shipping box.
2. Slide the module into the bay.
Figure 20. S4200-ON Series fan modules installation
a. Orange release tab
you must correct the mixed airflow
.
Fan module replacement
To request a hardware replacement, see Dell EMC support.
CAUTION:
thresholds and the switch could shut down:
1. Slide the fan module out of the bay.
2. Slide the replacement module into the bay.
Complete the following steps within one minute or the switch temperature could rise above safe
Fan air filter replacement
Environmental factors can decrease the amount of time required between air filter replacements. Check the environmental
factors regularly. An increase in temperature and/or particulate matter in the air might affect performance.
CAUTION:
determine air filter replacement intervals, regularly monitor the speeds of the cooling fans. An increase in
overall fan speed may indicate a clogged filter.
You must replace the fan air filters with new filters; you cannot clean and reuse the old fan air filters. Replacement filter media
must meet the requirements found in GR-63-CORE.
● Minimum dust arrestance of 65%, per ASHRAE Standard 52.1-1992. OR
● Minimum Efficiency Rating Value (MERV) of 2, per ANSI/ASHRAE Standard 52.2-2007.
CAUTION: For Network Equipment Building Systems (NEBS) compliance, use NEBS approved filters.
Check the fan air filters at six-month intervals and replace them as necessary. To accurately
Use fan air filters with reverse blue-banded air flow systems—PSUs and fans. You can replace the air filters individually on each
fan within the switch without powering down a PSU module or disrupting traffic.
The fan air filter media slides into the frame from the top. No tools are required.
1. Determine which filters to replace.
Fans
35
2. Unlatch and remove the first module that needs the filter replaced.
3. Slide the existing filter upwards to remove it from the module.
4. Replace the filter with a new filter of the same size.
5. Reinsert the fan module.
6. Repeat for the remaining modules that need the filter replaced.
36 Fans
8
Management ports
Besides the 10/100/1000Base-T RJ-45 ports, the S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch provides several
ports for management and storage.
NOTE: The output examples in this section are for reference only. Your output may vary.
Topics:
• RS-232 console port access
• USB storage mount
• Before you install an OS
• ONIE service discovery
RS-232 console port access
The RS-232 console port is on the I/O-side of the switch.
NOTE:
The S4200F-ON Series switches use the Silicon Labs CP2102 USB-B chip. To find the correct USB-B universal
asynchronous receiver-transmitter (UART) driver, see https://www.silabs.com/products/development-tools/software/
usb-to-uart-bridge-vcp-drivers.
Figure 21. S4200-ON series RS-232 console port
CAUTION: Ensure that any equipment attached to the serial port can support the required 115200 baud rate.
NOTE: When connecting the RJ45 console to the patch panel or terminal server using Cat5e or Cat6 Ethernet cables, the
maximum cable length is 100m. However, if the Ethernet cable is disconnected from the patch panel or terminal server but
connected to the RJ45 console, the maximum cable length is 6m. If the cable is longer than 6m when disconnected from
the panel or server, your switch may not boot.
NOTE: Before starting this procedure, ensure your PC has a 9-pin serial port. You must have a terminal emulation program
already installed and running on your PC.
NOTE: If your PC’s serial port cannot accept a female DB-9 connector, acquire a DB-9 male-to-male adaptor.
1. Install the provided RJ-45 connector side of the provided cable into the S4200-ON Series console port.
2. Install the DB-9 female side of the provided copper cable into your PC’s serial port. Or install the DB-9 cable into other data
terminal equipment (DTE) server hardware that you intend to use.
3. Keep the default terminal settings on the console as follows:
● 115200 baud rate
● No parity
Management ports 37
● 8 data bits
● 1 stop bit
● No flow control
USB storage mount
USB storage does not automatically mount. The supported file system is FAT. To use USB storage, first mount the device using
the following steps:
1. Create a mount directory for the USB.
ONIE:/ # mkdir /mnt/usb
2. View the fixed disks using fdisk.
ONIE:/mnt # fdisk -l
For internal storage:
Disk /dev/sda: 15.8 GB, 15829303296 bytes
255 heads, 63 sectors/track, 1924 cylinders
Units = cylinders of 16065 * 512 = 8225280 bytes
Device Boot Start End Blocks Id System
/dev/sda1 1 1925 15458303+ ee EFI GPT
For USB storage:
Disk /dev/sdb: 30.9 GB, 30942946304 bytes
64 heads, 32 sectors/track, 29509 cylinders
Units = cylinders of 2048 * 512 = 1048576 bytes
Device Boot Start End Blocks Id System
3. Mount the device /dev/sdb to the /mnt/usb directory.
ONIE:/ # mount -t vfat /dev/sdb /mnt/usb
NOTE:
The following message displays if the /mnt/usb directory is missing: mount: mounting /dev/sdb
on /mnt/usb failed: No such file or directory.
NOTE: The following message displays if the USB device is not seen: mount: mounting /dev/sdb on /mnt/usb
failed: No such device or address.
4. OPTIONAL: Add a device to the file systems table using the fstab command and mount the file systems.
ONIE:/ # vi /etc/fstab
# FSTAB entry for the ONIE-BOOT partition mounted on /boot
LABEL=ONIE-BOOT /mnt/onie-boot ext4 defaults,rw,errors=remount-ro 0 1
/dev/sdb /mnt/usb vfat defaults 0 1
ONIE:/ # mount -a
The mount -a command mounts all the file systems as indicated in the /etc/fstab file.
Before you install an OS
After powering on the S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch, it goes through a power-on self-test
(POST).
POST runs every time the switch is initialized and checks the hardware components to determine if the switch is fully
operational before booting. After POST, the switch uses the Grub bootloader.
To select an entry, use the up and down arrow keys. Press Enter to select an operating software (OS) or enter e to edit the
commands before booting. Enter c for a command line. The selected entry runs automatically in the operating system.
38
Management ports
Example of the Grub Bootloader
GNU GRUB version 2.02~beta2+e4a1fe391
+-------------------------------------------------+
|*ONIE: Install OS |
| ONIE: Rescue |
| ONIE: Uninstall OS |
| ONIE: Update ONIE |
| ONIE: Embed ONIE |
| EDA-DIAG |
| |
| |
| |
| |
| |
| |
+-------------------------------------------------+
Your switch comes with ONIE installed.
NOTE: To access ONIE, use the RJ-45 console port.
Example of ONIE
ONIE: Install OS
For downloading and installing an OS from a URL
Starts ONIE with ONIE Discovery Service
(factory default boot)
ONIE: Rescue
Starts ONIE without ONIE Discovery Service
Useful for running Diagnostics manually
ONIE: Uninstall OS
Restore to factory defaults erases any installed OS
ONIE: Update ONIE
For downloading and updating ONIE from a URL
ONIE: Embed ONIE
For downloading and updating ONIE from a URL and erases any installed OS
During the initial setup, the switch boots to ONIE Install. ONIE Install boots with ONIE Discovery to the console (ONIE:).
ONIE service discovery
ONIE attempts to locate the installer through several discovery methods, as shown. To download and run an installer, the ONIE
Service Discovery feature uses the first successful method found.
1. Search locally attached storage devices for one of the ONIE default installer filenames—for example, the filename is: onie
self update from the USB.
2. Query to the IPv4 and IPv6 link-local neighbors using HTTP for an installer.
3. Discover TFTP-based image from the DHCP server.
If none of the ONIE Service Discovery methods are successful, you can disable this using the onie-discovery-stop
command.
You can install an operating system manually from HTTP, FTP, or TFTP using the onie-nos-install <URL> command.
If you have a recovery USB plugged into your switch, remove it before installing the DIAG-OS using the onie-
NOTE:
nos-install command.
The ONIE Install environment uses DHCP to assign an IP address to the management interface—eth0. If that fails, it uses the
default IP address 192.168.3.10/255.255.255.0.
Management ports
39
To display the IP address, use the ifconfig eth0 command, as shown in the following example.
ONIE:/ # ifconfig eth0
eth0 Link encap:Ethernet HWaddr 90:B1:1C:F4:9C:76
inet addr:10.11.53.33 Bcast:10.255.255.255 Mask:255.0.0.0
inet6 addr: fe80::92b1:1cff:fef4:9c76/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:18 errors:0 dropped:0 overruns:0 frame:0
TX packets:24 errors:0 dropped:0 overruns:0 carrier:0 collisions:0 txqueuelen:1000
RX bytes:1152 (1.1 KiB) TX bytes:6864 (6.7 KiB)
Interrupt:21 Memory:ff300000-ff320000
To assign an IP address to the management interface, eth0, and verify network connectivity, use the ifconfig eth0 <ip
address> command, as shown in the following example:
ONIE:/ # ifconfig eth0 10.11.53.33/16
Verify the network connection with ping.
ONIE:/ # ping 10.11.8.12
PING 10.11.8.12 (10.11.8.12): 56 data bytes
64 bytes from 10.11.8.12: seq=0 ttl=62 time=1.357 ms
64 bytes from 10.11.8.12: seq=1 ttl=62 time=0.577 ms
^C
40 Management ports
Specifications
This section lists the S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch specifications.
CAUTION: Operate the product at an ambient temperature not higher than 113°F—45°C.
CAUTION: Lithium Battery Caution: There is a danger of explosion if the battery is incorrectly replaced. Replace
only with same or equivalent type of battery. Dispose of the batteries according to the manufacturer's
instructions.
NOTE: For RoHS information, see Restricted Material Compliance.
Topics:
• Chassis physical design
• IEEE standards
• Agency compliance
• USA Federal Communications Commission statement
• European Union EMC directive conformance statement
• Japan VCCI compliance for class A equipment
• Korean certification of compliance
• Electromagnetic compatibility
• Safety standards and compliance agency certifications
• Product recycling and disposal
9
Chassis physical design
Table 5. Chassis physical design
Parameter Specifications
Height 1.72 inches (44 mm)
Width 17.1 inches (434 mm)
Depth
Chassis weight with factory-installed components
Rack clearance required
Table 6. Environmental parameters
Parameter Specifications
Operating temperature 0°C to 45°C (32°F to 113°F) continuously
18.2 inches (462 mm)
PSU/fan tray handle: 1.57 inches (40 mm)
22 lbs (2* PSUs)
9.98 kg (2* PSUs)
Front: 5 inches (12.7 cm)
Back: 5 inches (12.7 cm)
-5°C to 45°C (23°F to 113°F) short term
Short term is </= 1% of operational hours per year.
Specifications 41
Table 6. Environmental parameters (continued)
Parameter Specifications
NOTE: Reduce maximum temperature by 1°C/300 meters
(1°F/547 feet) above 950 meters (3,117 feet).
Operating humidity 5% to 85% (RH), non-condensing, continuously
5% to 90% (RH), non-condensing, short term
Short term is </= 1% of operational hours per year.
Storage temperature –40° to 70°C (–40° to 158°F )
Storage humidity 5% to 95%, non-condensing
Maximum thermal output 600 W = 2047 BTU/Hr
Maximum operational altitude 10,000 feet (3,048 meters)
Maximum non-operational altitude 39,370 feet (12,000 meters)
Shock Dell EMC Spec SV0115
Table 7. AC power requirements
Parameter Specifications
Power supply 100–240 VAC 50/60 Hz
Maximum current draw per system 6A/5A at 100/120V AC 3A/2.5A at 200/240V AC
Maximum power consumption 600 Watts
Typical power consumption 300 Watts
Table 8. DC power requirements
Parameter Specifications
Minimum and maximum input voltage range −40.5, –60V DC, 15A Max
Maximum power consumption 600 Watts
Start up VDC 39.0 ± 1.5 V
Start off VDC 37.5 ± 1.5 v
IEEE standards
The S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch complies with the following IEEE standards:
● 802.1ab (LLDP)
● 802.1ax (Layer 2)
● 802.1d, 802.1w, 802.1s, 802.1x (Mgmt/Security), 802.3x (Layer 2)
● 802.3 (1000BASE-KX)
● 802.3ba (40GbE and 100GbE ports)
42
Specifications
Agency compliance
The S4200-ON Series (S4248FB-ON and S4248FBL-ON) switch complies with the following safety and agency requirements:
USA Federal Communications Commission statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
rules. These limits are designated to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy. If it is not installed and
used in accordance to the instructions, it may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference, in which case users will be required to take whatever measures
necessary to correct the interference at their own expense.
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Dell EMC is not
responsible for any radio or television interference caused by using other than recommended cables and connectors or by
unauthorized changes or modifications in the equipment. Unauthorized changes or modification could void the user’s authority
to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Figure 22. Canadian department of communication statement
European Union EMC directive conformance statement
This product is in conformity with the protection requirements of EU Council Directive 2004/30/EC on the approximation of the
laws of the Member States relating to electromagnetic compatibility. Dell EMC cannot accept responsibility for any failure to
satisfy the protection requirements resulting from a non-recommended modification of this product, including the fitting of nonDell EMC option cards.
This product has been tested and found to comply with the limits for Class A Information Technology Equipment according to
CISPR 32/CISPR34 and EN55032 / EN55034 The limits for Class A equipment were derived for commercial and industrial
environments to provide reasonable protection against interference with licensed communication equipment.
NOTE:
This is a Class A product. In a domestic environment, this device may cause radio interference, in which case, you
may be required to take adequate measures.
European Community Contact
Dell EMC, EMEA - Central
Dahlienweg 19
66265 Heusweiler
Germany
Tel: +49 172 6802630
Email: EMEA Central Sales
Specifications
43
Japan VCCI compliance for class A equipment
Figure 23. Japan: VCCI compliance for class A equipment
This is Class A product based on the standard of the Voluntary Control Council For Interference by Information Technology
Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs,
the user may be required to take corrective actions.
NOTE: Use the AC power cords with Dell EMC equipment only. Do not use Dell EMC AC power cords with any
unauthorized hardware.
Figure 24. Japan: warning label
Korean certification of compliance
Figure 25. Korean certification of compliance
Figure 26. Korean package label
44
Specifications
Electromagnetic compatibility
Emissions
● International: CISPR 32 Class A
● Australia/New Zealand: AS/NZS CISPR 32, Class A
● Canada: ICES-003, Issue-4, Class A
● Europe: EN55032, CISPR 32, Class A
● EN55032, Class A
● Japan: VCCI Class A
● Korea:KN32, Class A
● Taiwan, CNS13438, Class A
● USA: FCC CFR47 Part 15, Subpart B, Class A
Immunity
● EN 300 386 EMC for Network Equipment
EN 55024
●
● EN 61000-3-2 Harmonic Current Emissions
● EN 61000-3-3 Voltage Fluctuations and Flicker
● EN 61000-4-2 ESD
● EN 61000-4-3 Radiated Immunity
● EN 61000-4-4 EFT
● EN 61000-4-5 Surge
● EN 61000-4-6 Low Frequency Conducted Immunity
Safety standards and compliance agency certifications
● CUS UL 60950-1, 2nd Edition
○ Meets or exceeds Hi Pot and Ground Continuity testing per UL 60950-1.
● CSA 60950-1-03, 2nd Edition
● EN 60950-1, 2nd Edition
● EN 60825-1, 1st Edition
● EN 60825-1 Safety of Laser Products—Part 1: Equipment Classification Requirements and User’s Guide
● EN 60825-2 Safety of Laser Products—Part 2: Safety of Optical Fibre Communication Systems
● FDA Regulation 21CFR 1040.10 and 1040.11
● IEC 60950-1, 2nd Ed, including all National Deviations and Group Differences
● IEC 62368-1
Product recycling and disposal
You must recycle or discard this switch according to applicable local and national regulations. Dell EMC encourages owners of
information technology (IT) equipment to responsibly recycle their equipment when it is no longer needed. Dell EMC offers a
variety of product return programs and services in several countries to assist equipment owners in recycling their IT products.
Specifications
45
Waste Electrical and Electronic Equipment (WEEE) directive for recovery,
recycle, and reuse of IT and telecommunications products
Dell EMC switches are labeled in accordance with European Directive 2002/96/EC concerning waste electrical and electronic
equipment (WEEE). The Directive determines the framework for the return and recycling of used appliances as applicable
throughout the European Union. This label is applied to various products to indicate that the product is not to be thrown away,
but rather reclaimed upon end of life per this Directive.
Figure 27. The European WEEE symbol
In accordance with the European WEEE Directive, electrical and electronic equipment (EEE) is to be collected separately and to
be reused, recycled, or recovered at end of life. Users of EEE with the WEEE marking per Annex IV of the WEEE Directive, as
shown above, must not dispose of end of life EEE as unsorted municipal waste, but use the collection framework available to
customers for the return, recycling and recovery of WEEE. Customer participation is important to minimize any potential effects
of EEE on the environment and human health due to the potential presence of hazardous substances in EEE.
Dell EMC products, which fall within the scope of the WEEE, are labeled with the crossed-out wheelie-bin symbol, as shown
above, as required by WEEE.
For information on Dell EMC product recycling offerings, see the WEEE Recycling instructions on the Support page. For more
information, contact the Dell EMC Technical Assistance Center.
46
Specifications
10
Dell EMC support
The Dell EMC support site provides documents and tools to help you effectively use Dell equipment and mitigate network
outages. Through the support site you can obtain technical information, access software upgrades and patches, download
available management software, and manage your open cases. The Dell EMC support site provides integrated, secure access to
these services.
To access the Dell EMC support site, go to www.dell.com/support/. To display information in your language, scroll down to the
bottom of the web page and select your country from the drop-down menu.
● To obtain product-specific information, enter the 7-character service tag or 11-digit express service code of your switch and
click Submit.
To view the chassis service tag or express service code, pull out the luggage tag or enter the show chassis command
from the CLI.
● To receive more technical support, click Contact Us. On the Contact Information web page, click Technical Support.
To access switch documentation, go to www.dell.com/manuals/.
To search for drivers and downloads, go to www.dell.com/drivers/.
To participate in Dell EMC community blogs and forums, go to www.dell.com/community.
Dell EMC support 47
Loading...
