Dell PowerSwitch S4048T-ON User Manual

Dell EMC Configuration Guide for the
S4048T–ON System

9.14.2.4

Notes, cautions, and warnings

NOTE: A NOTE indicates important information that helps you make better use of your product.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the

problem.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

© 2019 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries.

Other trademarks may be trademarks of their respective owners.

2019 - 11

Rev. A00

Contents

1 About this Guide......................................................................................................................... 33

Audience............................................................................................................................................................................... 33

Conventions......................................................................................................................................................................... 33

Related Documents.............................................................................................................................................................33

2 Configuration Fundamentals....................................................................................................... 34

Accessing the Command Line............................................................................................................................................34

CLI Modes............................................................................................................................................................................ 34

Navigating CLI Modes...................................................................................................................................................36

The do Command................................................................................................................................................................38

Undoing Commands............................................................................................................................................................39

Obtaining Help..................................................................................................................................................................... 39

Entering and Editing Commands....................................................................................................................................... 39

Command History................................................................................................................................................................40

Filtering show Command Outputs.................................................................................................................................... 40

Multiple Users in Configuration Mode............................................................................................................................... 41

3 Getting Started..........................................................................................................................42

Console Access....................................................................................................................................................................42

Serial Console.................................................................................................................................................................42

Accessing the CLI Interface and Running Scripts Using SSH....................................................................................... 43

Default Configuration..........................................................................................................................................................44

Configuring a Host Name................................................................................................................................................... 44

Accessing the System Remotely.......................................................................................................................................44

Configure the Management Port IP Address.............................................................................................................44

Configure a Management Route................................................................................................................................. 45

Configuring a Username and Password..................................................................................................................... 45

Configuring the Enable Password..................................................................................................................................... 46

Configuration File Management........................................................................................................................................ 46

Copy Files to and from the System.............................................................................................................................46

Mounting an NFS File System......................................................................................................................................47

Save the Running-Configuration................................................................................................................................. 48

Configure the Overload Bit for a Startup Scenario...................................................................................................49

Viewing Files...................................................................................................................................................................49

Compressing Configuration Files.................................................................................................................................50

Managing the File System..................................................................................................................................................52

Enabling Software Features on Devices Using a Command Option.............................................................................52

View Command History......................................................................................................................................................53

Upgrading Dell EMC Networking OS................................................................................................................................54

Verify Software Images Before Installation......................................................................................................................54

Using HTTP for File Transfers...........................................................................................................................................55

4 Management..............................................................................................................................57

Configuring Privilege Levels............................................................................................................................................... 57

Contents 3

Removing a Command from EXEC Mode..................................................................................................................58

Moving a Command from EXEC Privilege Mode to EXEC Mode........................................................................... 58

Allowing Access to CONFIGURATION Mode Commands....................................................................................... 58

Allowing Access to Different Modes...........................................................................................................................58

Applying a Privilege Level to a Username...................................................................................................................60

Applying a Privilege Level to a Terminal Line............................................................................................................. 60

Configuring Logging............................................................................................................................................................60

Audit and Security Logs................................................................................................................................................60

Configuring Logging Format ................................................................................................................................ 62

Display the Logging Buffer and the Logging Configuration.....................................................................................62

Setting Up a Secure Connection to a Syslog Server.......................................................................................63

Sending System Messages to a Syslog Server..........................................................................................................64

Track Login Activity............................................................................................................................................................ 64

Restrictions for Tracking Login Activity......................................................................................................................64

Configuring Login Activity Tracking............................................................................................................................ 64

Display Login Statistics................................................................................................................................................. 65

Limit Concurrent Login Sessions.......................................................................................................................................66

Restrictions for Limiting the Number of Concurrent Sessions................................................................................66

Configuring Concurrent Session Limit........................................................................................................................ 66

Enabling the System to Clear Existing Sessions........................................................................................................67

Enabling Secured CLI Mode...............................................................................................................................................67

Log Messages in the Internal Buffer.................................................................................................................................68

Disabling System Logging...................................................................................................................................................68

Sending System Messages to a Syslog Server............................................................................................................... 68

Configuring a UNIX System as a Syslog Server........................................................................................................ 68

Changing System Logging Settings..................................................................................................................................69

Display the Logging Buffer and the Logging Configuration...........................................................................................69

Configuring a UNIX Logging Facility Level....................................................................................................................... 70

Synchronizing Log Messages............................................................................................................................................. 71

Enabling Timestamp on Syslog Messages.........................................................................................................................71

File Transfer Services..........................................................................................................................................................74

Enabling the FTP Server...............................................................................................................................................74

Configuring FTP Server Parameters...........................................................................................................................74

Configuring FTP Client Parameters............................................................................................................................ 75

Terminal Lines...................................................................................................................................................................... 75

Denying and Permitting Access to a Terminal Line...................................................................................................75

Configuring Login Authentication for Terminal Lines................................................................................................76

Setting Timeout for EXEC Privilege Mode.......................................................................................................................77

Using Telnet to get to Another Network Device.............................................................................................................78

Lock CONFIGURATION Mode...........................................................................................................................................78

LPC Bus Quality Degradation.............................................................................................................................................79

Restoring the Factory Default Settings............................................................................................................................79

Restoring Factory Default Environment Variables.................................................................................................... 80

Viewing the Reason for Last System Reboot...................................................................................................................81

5 802.1X.......................................................................................................................................82

Port-Authentication Process............................................................................................................................................. 83

EAP over RADIUS..........................................................................................................................................................84

Configuring 802.1X..............................................................................................................................................................84

Important Points to Remember.........................................................................................................................................85

4

Contents

Enabling 802.1X................................................................................................................................................................... 85

Configuring Request Identity Re-Transmissions............................................................................................................. 86

Configuring a Quiet Period after a Failed Authentication.........................................................................................87

Forcibly Authorizing or Unauthorizing a Port...................................................................................................................88

Re-Authenticating a Port................................................................................................................................................... 88

Configuring Timeouts..........................................................................................................................................................89

Configuring Dynamic VLAN Assignment with Port Authentication..............................................................................90

Guest and Authentication-Fail VLANs...............................................................................................................................91

Configuring a Guest VLAN............................................................................................................................................91

Configuring an Authentication-Fail VLAN................................................................................................................... 91

6 Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM)..........................93

Optimizing CAM Utilization During the Attachment of ACLs to VLANs......................................................................93

Guidelines for Configuring ACL VLAN Groups................................................................................................................ 93

Configuring ACL VLAN Groups and Configuring FP Blocks for VLAN Parameters................................................... 94

Configuring ACL VLAN Groups................................................................................................................................... 94

Configuring FP Blocks for VLAN Parameters............................................................................................................95

Viewing CAM Usage........................................................................................................................................................... 95

Allocating FP Blocks for VLAN Processes....................................................................................................................... 97

Unified Forwarding Table (UFT) Modes...........................................................................................................................97

Configuring UFT Modes................................................................................................................................................97

7 Access Control Lists (ACLs)........................................................................................................98

IP Access Control Lists (ACLs)......................................................................................................................................... 99

CAM Usage.................................................................................................................................................................... 99

Implementing ACLs on Dell EMC Networking OS................................................................................................... 100

Important Points to Remember........................................................................................................................................ 101

Configuration Task List for Route Maps....................................................................................................................101

Configuring Match Routes..........................................................................................................................................103

Configuring Set Conditions.........................................................................................................................................104

Configure a Route Map for Route Redistribution....................................................................................................105

Configure a Route Map for Route Tagging.............................................................................................................. 106

Continue Clause........................................................................................................................................................... 106

IP Fragment Handling........................................................................................................................................................106

IP Fragments ACL Examples...................................................................................................................................... 106

Layer 4 ACL Rules Examples...................................................................................................................................... 107

Configure a Standard IP ACL........................................................................................................................................... 108

Configuring a Standard IP ACL Filter........................................................................................................................ 108

Configure an Extended IP ACL........................................................................................................................................ 109

Configuring Filters with a Sequence Number...........................................................................................................109

Configuring Filters Without a Sequence Number.....................................................................................................110

Configure Layer 2 and Layer 3 ACLs................................................................................................................................ 111

Assign an IP ACL to an Interface.......................................................................................................................................111

Applying an IP ACL............................................................................................................................................................. 112

Counting ACL Hits........................................................................................................................................................ 112

Configure Ingress ACLs..................................................................................................................................................... 112

Configure Egress ACLs...................................................................................................................................................... 113

Applying Egress Layer 3 ACLs (Control-Plane)........................................................................................................ 114

IP Prefix Lists.......................................................................................................................................................................114

Contents

5

Configuration Task List for Prefix Lists......................................................................................................................115

ACL Remarks.......................................................................................................................................................................118

Configuring a Remark...................................................................................................................................................118

Deleting a Remark.........................................................................................................................................................118

ACL Resequencing............................................................................................................................................................. 119

Resequencing an ACL or Prefix List...........................................................................................................................119

Route Maps........................................................................................................................................................................ 120

Logging of ACL Processes................................................................................................................................................ 121

Guidelines for Configuring ACL Logging.................................................................................................................... 121

Configuring ACL Logging............................................................................................................................................ 122

Flow-Based Monitoring..................................................................................................................................................... 122

Enabling Flow-Based Monitoring................................................................................................................................124

Configuring UDF ACL........................................................................................................................................................ 124

Configuring IP Mirror Access Group................................................................................................................................127

Sample Configuration...................................................................................................................................................127

Example of viewing IP mirror–access–group applied to an Interface...................................................................127

8 Bidirectional Forwarding Detection (BFD)................................................................................... 129

How BFD Works.................................................................................................................................................................129

BFD Packet Format..................................................................................................................................................... 130

BFD Sessions.................................................................................................................................................................131

BFD Three-Way Handshake....................................................................................................................................... 132

Session State Changes................................................................................................................................................133

Important Points to Remember........................................................................................................................................133

Configure BFD....................................................................................................................................................................133

Configure BFD for Physical Ports.............................................................................................................................. 134

Configure BFD for Static Routes...............................................................................................................................135

Configure BFD for IPv6 Static Routes...................................................................................................................... 138

Configure BFD for OSPF............................................................................................................................................ 140

Configure BFD for OSPFv3........................................................................................................................................ 145

Configure BFD for IS-IS...............................................................................................................................................147

Configure BFD for BGP...............................................................................................................................................149

Configure BFD for VRRP............................................................................................................................................ 156

Configuring Protocol Liveness....................................................................................................................................158

9 Border Gateway Protocol (BGP)................................................................................................ 159

BGP IP version 4 (BGPv4) Overview............................................................................................................................. 159

BGP Autonomous Systems........................................................................................................................................ 159

AS4 Number Representation.......................................................................................................................................161

Four-Byte AS Numbers...............................................................................................................................................163

BGP router ID............................................................................................................................................................... 163

Sessions and Peers...................................................................................................................................................... 163

Establish a Session.......................................................................................................................................................163

BGP Attributes for selecting Best Path.................................................................................................................... 164

Multiprotocol BGP....................................................................................................................................................... 169

BGP global and address family configuration........................................................................................................... 170

Implement BGP with Dell EMC Networking OS....................................................................................................... 171

Configuration Information........................................................................................................................................... 174

Basic BGP configuration tasks......................................................................................................................................... 174

6

Contents

Prerequisite for configuring a BGP network.............................................................................................................174

Restrictions................................................................................................................................................................... 174

Enabling BGP................................................................................................................................................................ 174

Enabling four-byte autonomous system numbers................................................................................................... 176

Changing a BGP router ID...........................................................................................................................................177

Configuring AS4 Number Representations............................................................................................................... 177

Configuring a BGP peer...............................................................................................................................................178

Example-Configuring BGP routing between peers..................................................................................................179

BGP peer group............................................................................................................................................................180

Advanced BGP configuration tasks................................................................................................................................. 187

Route-refresh and Soft-reconfiguration................................................................................................................... 187

Aggregating Routes..................................................................................................................................................... 189

Filtering BGP..................................................................................................................................................................191

Configuring BGP Fast Fall-Over.................................................................................................................................196

Configuring Passive Peering....................................................................................................................................... 197

Enabling Graceful Restart........................................................................................................................................... 198

Redistributing Routes.................................................................................................................................................. 199

Redistributing iBGP Routes into IGP......................................................................................................................... 199

Enabling Additional Paths........................................................................................................................................... 202

Configuring IP Community Lists................................................................................................................................202

Configuring an IP Extended Community List...........................................................................................................203

Configure BGP attributes...........................................................................................................................................204

Enabling Multipath.......................................................................................................................................................207

Route Reflectors......................................................................................................................................................... 208

Enabling Route Flap Dampening................................................................................................................................209

Changing BGP keepalive and hold timers.................................................................................................................. 211

Setting the extended timer.........................................................................................................................................212

Enabling or disabling BGP neighbors......................................................................................................................... 212

Route Map Continue....................................................................................................................................................213

Configuring BGP Confederations...............................................................................................................................214

Configuring a BGP VRF address family.....................................................................................................................214

Maintaining Existing AS Numbers During an AS Migration.....................................................................................215

Allowing an AS Number to Appear in its Own AS Path...........................................................................................216

Enabling MBGP Configurations.................................................................................................................................. 217

MBGP support for IPv6...............................................................................................................................................217

Configuring IPv6 MBGP between peers................................................................................................................... 217

Example-Configuring IPv4 and IPv6 neighbors........................................................................................................218

Configure IPv6 NH Automatically for IPv6 Prefix Advertised over IPv4 Neighbor............................................ 220

BGP Regular Expression Optimization......................................................................................................................222

Debugging BGP........................................................................................................................................................... 222

10 Content Addressable Memory (CAM)........................................................................................224

CAM Allocation.................................................................................................................................................................. 224

Test CAM Usage...............................................................................................................................................................225

View CAM-ACL Settings..................................................................................................................................................226

View CAM Usage...............................................................................................................................................................227

Configuring CAM Threshold and Silence Period........................................................................................................... 228

CAM Optimization.............................................................................................................................................................229

Troubleshoot CAM Profiling.............................................................................................................................................229

QoS CAM Region Limitation...................................................................................................................................... 229

Contents

7

11 Control Plane Policing (CoPP).................................................................................................. 230

Configure Control Plane Policing..................................................................................................................................... 231

Configuring CoPP for Protocols................................................................................................................................232

Configuring CoPP for CPU Queues..........................................................................................................................233

CoPP for OSPFv3 Packets........................................................................................................................................ 234

Configuring CoPP for OSPFv3..................................................................................................................................236

Displaying CoPP Configuration .................................................................................................................................237

12 Data Center Bridging (DCB)..................................................................................................... 239

Ethernet Enhancements in Data Center Bridging.........................................................................................................239

Priority-Based Flow Control.......................................................................................................................................240

Enhanced Transmission Selection..............................................................................................................................241

Data Center Bridging Exchange Protocol (DCBx)..................................................................................................242

Data Center Bridging in a Traffic Flow..................................................................................................................... 242

Enabling Data Center Bridging.........................................................................................................................................242

DCB Maps and its Attributes..................................................................................................................................... 243

Data Center Bridging: Default Configuration.................................................................................................................243

Configuring Priority-Based Flow Control....................................................................................................................... 244

Configuring Lossless Queues..................................................................................................................................... 244

Configuring PFC in a DCB Map.......................................................................................................................................246

Applying a DCB Map on a Port........................................................................................................................................247

Configuring PFC without a DCB Map.............................................................................................................................247

Priority-Based Flow Control Using Dynamic Buffer Method.......................................................................................249

Behavior of Tagged Packets............................................................................................................................................249

Configuration Example for DSCP and PFC Priorities...................................................................................................250

Using PFC to Manage Converged Ethernet Traffic......................................................................................................251

Configure Enhanced Transmission Selection................................................................................................................. 251

ETS Prerequisites and Restrictions........................................................................................................................... 251

Creating an ETS Priority Group..................................................................................................................................251

ETS Operation with DCBx..........................................................................................................................................252

Configuring Bandwidth Allocation for DCBx CIN.................................................................................................... 253

Configuring ETS in a DCB Map................................................................................................................................. 253

Hierarchical Scheduling in ETS Output Policies............................................................................................................ 254

Using ETS to Manage Converged Ethernet Traffic..................................................................................................... 255

Applying DCB Policies in a Switch Stack....................................................................................................................... 255

Configure a DCBx Operation...........................................................................................................................................255

DCBx Operation...........................................................................................................................................................255

DCBx Port Roles..........................................................................................................................................................255

DCB Configuration Exchange.................................................................................................................................... 257

Configuration Source Election................................................................................................................................... 257

Propagation of DCB Information............................................................................................................................... 257

Auto-Detection and Manual Configuration of the DCBx Version......................................................................... 258

DCBx Example............................................................................................................................................................. 258

DCBx Prerequisites and Restrictions........................................................................................................................259

Configuring DCBx........................................................................................................................................................259

Verifying the DCB Configuration.....................................................................................................................................262

QoS dot1p Traffic Classification and Queue Assignment.............................................................................................270

Configuring the Dynamic Buffer Method........................................................................................................................271

8

Contents

Sample DCB Configuration.............................................................................................................................................. 272

13 Dynamic Host Configuration Protocol (DHCP)........................................................................... 275

DHCP Packet Format and Options.................................................................................................................................275

Assign an IP Address using DHCP...................................................................................................................................276

Implementation Information............................................................................................................................................. 277

Configure the System to be a DHCP Server.................................................................................................................278

Configuring the Server for Automatic Address Allocation..................................................................................... 278

Specifying a Default Gateway....................................................................................................................................279

Configure a Method of Hostname Resolution......................................................................................................... 279

Using DNS for Address Resolution............................................................................................................................279

Using NetBIOS WINS for Address Resolution.........................................................................................................280

Creating Manual Binding Entries............................................................................................................................... 280

Debugging the DHCP Server.....................................................................................................................................280

Using DHCP Clear Commands.................................................................................................................................. 280

Configure the System to be a Relay Agent.................................................................................................................... 281

Configure the System to be a DHCP Client.................................................................................................................. 282

Configuring the DHCP Client System.......................................................................................................................282

DHCP Client on a Management Interface................................................................................................................283

DHCP Client Operation with Other Features.......................................................................................................... 284

DHCP Relay When DHCP Server and Client are in Different VRFs...........................................................................285

Configuring Route Leaking between VRFs on DHCP Relay Agent...................................................................... 285

Non-default VRF configuration for DHCPv6 helper address...................................................................................... 286

Configuring DHCP relay source interface......................................................................................................................286

Global DHCP relay source IPv4 or IPv6 configuration .......................................................................................... 286

Interface level DHCP relay source IPv4 or IPv6 configuration .............................................................................287

Configure the System for User Port Stacking (Option 230)...................................................................................... 288

Configure Secure DHCP.................................................................................................................................................. 288

Option 82 (DHCPv4 relay options)...........................................................................................................................288

DHCPv6 relay agent options..................................................................................................................................... 289

DHCP Snooping...........................................................................................................................................................289

Drop DHCP Packets on Snooped VLANs Only....................................................................................................... 293

Dynamic ARP Inspection............................................................................................................................................ 294

Configuring Dynamic ARP Inspection.......................................................................................................................294

Source Address Validation............................................................................................................................................... 295

Enabling IP Source Address Validation..................................................................................................................... 295

DHCP MAC Source Address Validation................................................................................................................... 296

Enabling IP+MAC Source Address Validation..........................................................................................................296

Viewing the Number of SAV Dropped Packets.......................................................................................................297

Clearing the Number of SAV Dropped Packets...................................................................................................... 297

14 Equal Cost Multi-Path (ECMP).................................................................................................298

ECMP for Flow-Based Affinity........................................................................................................................................298

Configuring the Hash Algorithm................................................................................................................................ 298

Enabling Deterministic ECMP Next Hop..................................................................................................................298

Configuring the Hash Algorithm Seed...................................................................................................................... 298

Link Bundle Monitoring.....................................................................................................................................................299

Managing ECMP Group Paths.................................................................................................................................. 299

Creating an ECMP Group Bundle............................................................................................................................. 300

Contents

9

Modifying the ECMP Group Threshold....................................................................................................................300

RTAG7................................................................................................................................................................................. 301

Flow-based Hashing for ECMP.......................................................................................................................................302

15 FIP Snooping.......................................................................................................................... 305

Fibre Channel over Ethernet........................................................................................................................................... 305

Ensure Robustness in a Converged Ethernet Network............................................................................................... 305

FIP Snooping on Ethernet Bridges..................................................................................................................................306

FIP Snooping in a Switch Stack...................................................................................................................................... 308

Using FIP Snooping...........................................................................................................................................................308

FIP Snooping Prerequisites........................................................................................................................................ 308

Important Points to Remember.................................................................................................................................308

Enabling the FCoE Transit Feature...........................................................................................................................309

Enable FIP Snooping on VLANs................................................................................................................................ 309

Configure the FC-MAP Value.....................................................................................................................................310

Configure a Port for a Bridge-to-Bridge Link...........................................................................................................310

Configure a Port for a Bridge-to-FCF Link...............................................................................................................310

Impact on Other Software Features......................................................................................................................... 310

FIP Snooping Restrictions...........................................................................................................................................310

Configuring FIP Snooping............................................................................................................................................ 311

Displaying FIP Snooping Information................................................................................................................................311

FCoE Transit Configuration Example.............................................................................................................................. 316

16 FIPS Cryptography.................................................................................................................. 318

Configuration Tasks...........................................................................................................................................................318

Preparing the System........................................................................................................................................................318

Enabling FIPS Mode...........................................................................................................................................................318

Generating Host-Keys.......................................................................................................................................................319

Monitoring FIPS Mode Status..........................................................................................................................................319

Disabling FIPS Mode..........................................................................................................................................................319

17 Force10 Resilient Ring Protocol (FRRP).....................................................................................321

Protocol Overview............................................................................................................................................................. 321

Ring Status...................................................................................................................................................................322

Multiple FRRP Rings................................................................................................................................................... 322

Important FRRP Points...............................................................................................................................................323

Important FRRP Concepts.........................................................................................................................................324

Implementing FRRP.......................................................................................................................................................... 324

FRRP Configuration..........................................................................................................................................................325

Creating the FRRP Group.......................................................................................................................................... 325

Configuring the Control VLAN...................................................................................................................................325

Configuring and Adding the Member VLANs.......................................................................................................... 326

Setting the FRRP Timers............................................................................................................................................327

Clearing the FRRP Counters......................................................................................................................................327

Viewing the FRRP Configuration...............................................................................................................................327

Viewing the FRRP Information.................................................................................................................................. 327

Troubleshooting FRRP......................................................................................................................................................328

Sample Configuration and Topology...............................................................................................................................328

FRRP Support on VLT......................................................................................................................................................329

10

Contents

18 GARP VLAN Registration Protocol (GVRP)................................................................................332

Configure GVRP................................................................................................................................................................333

Enabling GVRP Globally....................................................................................................................................................333

Enabling GVRP on a Layer 2 Interface........................................................................................................................... 334

Configure GVRP Registration..........................................................................................................................................334

Configure a GARP Timer..................................................................................................................................................335

RPM Redundancy............................................................................................................................................................. 335

19 High Availability (HA).............................................................................................................. 336

Component Redundancy..................................................................................................................................................336

Automatic and Manual Stack Unit Failover..............................................................................................................336

Synchronization between Management and Standby Units..................................................................................337

Forcing a Stack Unit Failover..................................................................................................................................... 337

Specifying an Auto-Failover Limit..............................................................................................................................337

Disabling Auto-Reboot................................................................................................................................................ 337

Pre-Configuring a Stack Unit Slot...................................................................................................................................338

Removing a Provisioned Logical Stack Unit.................................................................................................................. 338

Hitless Behavior.................................................................................................................................................................338

Graceful Restart................................................................................................................................................................ 338

Software Resiliency...........................................................................................................................................................339

Software Component Health Monitoring.................................................................................................................339

System Health Monitoring......................................................................................................................................... 339

Failure and Event Logging..........................................................................................................................................339

Hot-Lock Behavior............................................................................................................................................................340

20 Internet Group Management Protocol (IGMP)........................................................................... 341

IGMP Protocol Overview..................................................................................................................................................341

IGMP Version 2............................................................................................................................................................ 341

IGMP Version 3............................................................................................................................................................342

Configure IGMP.................................................................................................................................................................345

Viewing IGMP Enabled Interfaces...................................................................................................................................345

Selecting an IGMP Version.............................................................................................................................................. 346

Viewing IGMP Groups.......................................................................................................................................................347

Adjusting Timers................................................................................................................................................................ 347

Adjusting Query and Response Timers..................................................................................................................... 347

Preventing a Host from Joining a Group........................................................................................................................348

Enabling IGMP Immediate-Leave....................................................................................................................................350

IGMP Snooping.................................................................................................................................................................. 351

Configuring IGMP Snooping....................................................................................................................................... 351

Removing a Group-Port Association......................................................................................................................... 351

Disabling Multicast Flooding.......................................................................................................................................352

Specifying a Port as Connected to a Multicast Router..........................................................................................352

Configuring the Switch as Querier............................................................................................................................352

Fast Convergence after MSTP Topology Changes......................................................................................................353

Egress Interface Selection (EIS) for HTTP and IGMP Applications...........................................................................353

Designating a Multicast Router Interface...................................................................................................................... 359

21 Interfaces...............................................................................................................................360

Contents

11

Interface Types.................................................................................................................................................................. 361

View Basic Interface Information.....................................................................................................................................361

Resetting an Interface to its Factory Default State..................................................................................................... 363

Enabling a Physical Interface........................................................................................................................................... 363

Physical Interfaces............................................................................................................................................................ 363

Configuration Task List for Physical Interfaces.......................................................................................................364

Overview of Layer Modes..........................................................................................................................................364

Configuring Layer 2 (Data Link) Mode..................................................................................................................... 364

Configuring Layer 2 (Interface) Mode......................................................................................................................365

Configuring Layer 3 (Network) Mode...................................................................................................................... 365

Configuring Layer 3 (Interface) Mode......................................................................................................................365

Automatic recovery of an Err-disabled interface..........................................................................................................366

Configuring an automatic recovery for an Err-disabled interface.........................................................................366

Egress Interface Selection (EIS)..................................................................................................................................... 367

Configuring EIS............................................................................................................................................................ 367

Management Interfaces................................................................................................................................................... 368

Configuring Management Interfaces........................................................................................................................368

Configuring a Management Interface on an Ethernet Port...................................................................................369

VLAN Interfaces................................................................................................................................................................ 370

Loopback Interfaces......................................................................................................................................................... 370

Null Interfaces.....................................................................................................................................................................371

Configuring Port Delay...................................................................................................................................................... 371

Port Channel Interfaces.................................................................................................................................................... 371

Port Channel Definition and Standards..................................................................................................................... 371

Port Channel Benefits.................................................................................................................................................372

Port Channel Implementation.................................................................................................................................... 372

Interfaces in Port Channels........................................................................................................................................372

Configuration Tasks for Port Channel Interfaces....................................................................................................372

Creating a Port Channel............................................................................................................................................. 373

Adding a Physical Interface to a Port Channel........................................................................................................ 373

Reassigning an Interface to a New Port Channel................................................................................................... 375

Configuring the Minimum Oper Up Links in a Port Channel.................................................................................. 375

Adding or Removing a Port Channel from a VLAN.................................................................................................375

Assigning an IP Address to a Port Channel..............................................................................................................376

Deleting or Disabling a Port Channel......................................................................................................................... 377

Load Balancing Through Port Channels....................................................................................................................377

Changing the Hash Algorithm.................................................................................................................................... 377

Bulk Configuration.............................................................................................................................................................378

Interface Range........................................................................................................................................................... 378

Bulk Configuration Examples......................................................................................................................................378

Defining Interface Range Macros....................................................................................................................................379

Define the Interface Range........................................................................................................................................380

Choosing an Interface-Range Macro........................................................................................................................380

Monitoring and Maintaining Interfaces...........................................................................................................................380

Maintenance Using TDR..............................................................................................................................................381

Non Dell-Qualified Transceivers.......................................................................................................................................381

Splitting 40G Ports without Reload................................................................................................................................ 382

Splitting QSFP Ports to SFP+ Ports.............................................................................................................................. 383

Converting a QSFP or QSFP+ Port to an SFP or SFP+ Port..................................................................................... 384

Link Dampening................................................................................................................................................................. 386

12

Contents

Enabling Link Dampening............................................................................................................................................388

Link Bundle Monitoring.....................................................................................................................................................389

Using Ethernet Pause Frames for Flow Control........................................................................................................... 389

Enabling Pause Frames...............................................................................................................................................390

Configure the MTU Size on an Interface.......................................................................................................................390

Port-Pipes...........................................................................................................................................................................391

Auto-Negotiation on Ethernet Interfaces.......................................................................................................................391

Setting the Speed of Ethernet Interfaces................................................................................................................392

Set Auto-Negotiation Options................................................................................................................................... 393

View Advanced Interface Information............................................................................................................................393

Configuring the Interface Sampling Size..................................................................................................................394

Configuring the Traffic Sampling Size Globally............................................................................................................. 395

Dynamic Counters.............................................................................................................................................................396

Clearing Interface Counters....................................................................................................................................... 397

Discard Counters...............................................................................................................................................................397

Display discard counters.............................................................................................................................................397

22 Internet Protocol Security (IPSec)...........................................................................................399

Configuring IPSec ............................................................................................................................................................ 399

23 IPv4 Routing...........................................................................................................................401

IP Addresses...................................................................................................................................................................... 402

Configuration Tasks for IP Addresses............................................................................................................................ 402

Assigning IP Addresses to an Interface..........................................................................................................................402

Configuring Static Routes................................................................................................................................................403

Adding description for IPv4 and IPv6 static routes................................................................................................ 404

Configure Static Routes for the Management Interface.............................................................................................404

IPv4 Path MTU Discovery Overview..............................................................................................................................405

Using the Configured Source IP Address in ICMP Messages.....................................................................................405

Configuring the Duration to Establish a TCP Connection........................................................................................... 406

Enabling Directed Broadcast........................................................................................................................................... 406

Resolution of Host Names............................................................................................................................................... 406

Enabling Dynamic Resolution of Host Names................................................................................................................407

Specifying the Local System Domain and a List of Domains.......................................................................................407

Configuring DNS with Traceroute...................................................................................................................................407

ARP..................................................................................................................................................................................... 408

Configuration Tasks for ARP........................................................................................................................................... 408

Configuring Static ARP Entries....................................................................................................................................... 408

Enabling Proxy ARP.......................................................................................................................................................... 409

Clearing ARP Cache..........................................................................................................................................................409

ARP Learning via Gratuitous ARP...................................................................................................................................409

Enabling ARP Learning via Gratuitous ARP....................................................................................................................410

ARP Learning via ARP Request....................................................................................................................................... 410

Configuring ARP Retries....................................................................................................................................................411

ICMP.....................................................................................................................................................................................411

Configuration Tasks for ICMP...........................................................................................................................................411

Enabling ICMP Unreachable Messages........................................................................................................................... 411

ICMP Redirects.................................................................................................................................................................. 412

UDP Helper......................................................................................................................................................................... 412

Contents

13

Enabling UDP Helper......................................................................................................................................................... 413

Configuring a Broadcast Address.................................................................................................................................... 413

Configurations Using UDP Helper....................................................................................................................................414

UDP Helper with Broadcast-All Addresses.....................................................................................................................414

UDP Helper with Subnet Broadcast Addresses.............................................................................................................415

UDP Helper with Configured Broadcast Addresses......................................................................................................415

UDP Helper with No Configured Broadcast Addresses................................................................................................416

Troubleshooting UDP Helper............................................................................................................................................416

24 IPv6 Routing........................................................................................................................... 417

Protocol Overview............................................................................................................................................................. 417

Extended Address Space............................................................................................................................................ 417

Stateless Autoconfiguration........................................................................................................................................417

IPv6 Headers................................................................................................................................................................ 418

IPv6 Header Fields....................................................................................................................................................... 418

Extension Header Fields............................................................................................................................................. 420

Addressing.....................................................................................................................................................................421

Implementing IPv6 with Dell EMC Networking OS....................................................................................................... 421

ICMPv6...............................................................................................................................................................................423

Path MTU discovery......................................................................................................................................................... 423

IPv6 Neighbor Discovery..................................................................................................................................................424

IPv6 Neighbor Discovery of MTU Packets.............................................................................................................. 425

Configuration Task List for IPv6 RDNSS....................................................................................................................... 425

Configuring the IPv6 Recursive DNS Server...........................................................................................................425

Debugging IPv6 RDNSS Information Sent to the Host .........................................................................................426

Displaying IPv6 RDNSS Information......................................................................................................................... 426

Secure Shell (SSH) Over an IPv6 Transport................................................................................................................. 427

Configuration Tasks for IPv6........................................................................................................................................... 427

Adjusting Your CAM-Profile....................................................................................................................................... 427

Assigning an IPv6 Address to an Interface.............................................................................................................. 428

Assigning a Static IPv6 Route....................................................................................................................................428

Configuring Telnet with IPv6..................................................................................................................................... 429

SNMP over IPv6..........................................................................................................................................................429

Displaying IPv6 Information........................................................................................................................................429

Displaying an IPv6 Interface Information..................................................................................................................430

Showing IPv6 Routes..................................................................................................................................................430

Showing the Running-Configuration for an Interface............................................................................................. 431

Clearing IPv6 Routes...................................................................................................................................................432

Disabling ND Entry Timeout....................................................................................................................................... 432

Configuring IPv6 RA Guard..............................................................................................................................................432

Configuring IPv6 RA Guard on an Interface............................................................................................................ 434

Monitoring IPv6 RA Guard......................................................................................................................................... 434

14

25 iSCSI Optimization................................................................................................................. 435

iSCSI Optimization Overview...........................................................................................................................................435

Monitoring iSCSI Traffic Flows..................................................................................................................................436

Application of Quality of Service to iSCSI Traffic Flows........................................................................................ 436

Information Monitored in iSCSI Traffic Flows..........................................................................................................437

Detection and Auto-Configuration for Dell EqualLogic Arrays.............................................................................. 437

Contents

Configuring Detection and Ports for Dell Compellent Arrays................................................................................ 438

Synchronizing iSCSI Sessions Learned on VLT-Lags with VLT-Peer.................................................................. 438

Enable and Disable iSCSI Optimization.....................................................................................................................439

Default iSCSI Optimization Values.................................................................................................................................. 439

iSCSI Optimization Prerequisites.....................................................................................................................................439

Configuring iSCSI Optimization.......................................................................................................................................440

Displaying iSCSI Optimization Information......................................................................................................................441

26 Intermediate System to Intermediate System........................................................................... 443

IS-IS Protocol Overview...................................................................................................................................................443

IS-IS Addressing................................................................................................................................................................ 443

Multi-Topology IS-IS......................................................................................................................................................... 444

Transition Mode...........................................................................................................................................................444

Interface Support........................................................................................................................................................ 444

Adjacencies...................................................................................................................................................................444

Graceful Restart................................................................................................................................................................445

Timers........................................................................................................................................................................... 445

Implementation Information.............................................................................................................................................445

Configuration Information................................................................................................................................................ 446

Configuration Tasks for IS-IS.....................................................................................................................................446

Configuring the Distance of a Route........................................................................................................................ 453

Changing the IS-Type.................................................................................................................................................453

Redistributing IPv4 Routes........................................................................................................................................ 455

Redistributing IPv6 Routes........................................................................................................................................ 455

Configuring Authentication Passwords.................................................................................................................... 456

Setting the Overload Bit.............................................................................................................................................456

Debugging IS-IS........................................................................................................................................................... 457

IS-IS Metric Styles............................................................................................................................................................ 458

Configure Metric Values...................................................................................................................................................458

Maximum Values in the Routing Table..................................................................................................................... 458

Change the IS-IS Metric Style in One Level Only................................................................................................... 458

Leaks from One Level to Another.............................................................................................................................460

Sample Configurations..................................................................................................................................................... 460

27 Link Aggregation Control Protocol (LACP)................................................................................463

Introduction to Dynamic LAGs and LACP......................................................................................................................463

Important Points to Remember.................................................................................................................................463

LACP Modes................................................................................................................................................................463

Configuring LACP Commands...................................................................................................................................464

LACP Configuration Tasks...............................................................................................................................................464

Creating a LAG............................................................................................................................................................ 464

Configuring the LAG Interfaces as Dynamic............................................................................................................465

Setting the LACP Long Timeout............................................................................................................................... 465

Monitoring and Debugging LACP..............................................................................................................................466

Shared LAG State Tracking............................................................................................................................................. 466

Configuring Shared LAG State Tracking.................................................................................................................. 467

Important Points about Shared LAG State Tracking..............................................................................................468

LACP Basic Configuration Example................................................................................................................................468

Configure a LAG on ALPHA.......................................................................................................................................468

Contents

15

28 Layer 2...................................................................................................................................476

Manage the MAC Address Table.................................................................................................................................... 476

Clearing the MAC Address Table.............................................................................................................................. 476

Setting the Aging Time for Dynamic Entries............................................................................................................476

Configuring a Static MAC Address........................................................................................................................... 476

Displaying the MAC Address Table............................................................................................................................477

MAC Learning Limit...........................................................................................................................................................477

Setting the MAC Learning Limit................................................................................................................................ 477

mac learning-limit Dynamic.........................................................................................................................................478

mac learning-limit mac-address-sticky..................................................................................................................... 478

mac learning-limit station-move................................................................................................................................ 478

mac learning-limit no-station-move.......................................................................................................................... 478

Learning Limit Violation Actions.................................................................................................................................479

Setting Station Move Violation Actions....................................................................................................................479

Recovering from Learning Limit and Station Move Violations...............................................................................479

Enabling port security................................................................................................................................................. 480

NIC Teaming...................................................................................................................................................................... 480

Configure Redundant Pairs...............................................................................................................................................481

Far-End Failure Detection................................................................................................................................................ 484

FEFD State Changes.................................................................................................................................................. 484

Configuring FEFD........................................................................................................................................................485

Enabling FEFD on an Interface.................................................................................................................................. 486

Debugging FEFD..........................................................................................................................................................486

29 Link Layer Discovery Protocol (LLDP).......................................................................................488

802.1AB (LLDP) Overview...............................................................................................................................................488

Protocol Data Units.....................................................................................................................................................488

Optional TLVs.................................................................................................................................................................... 489

Management TLVs......................................................................................................................................................489

TIA-1057 (LLDP-MED) Overview...................................................................................................................................490

TIA Organizationally Specific TLVs............................................................................................................................ 491

Configure LLDP................................................................................................................................................................. 494

CONFIGURATION versus INTERFACE Configurations............................................................................................... 494

Enabling LLDP................................................................................................................................................................... 495

Disabling and Undoing LLDP......................................................................................................................................495

Enabling LLDP on Management Ports........................................................................................................................... 495

Disabling and Undoing LLDP on Management Ports..............................................................................................496

Advertising TLVs............................................................................................................................................................... 496

Storing and Viewing Unrecognized LLDP TLVs............................................................................................................ 497

Viewing the LLDP Configuration.....................................................................................................................................498

Viewing Information Advertised by Adjacent LLDP Neighbors...................................................................................498

Examples of Viewing Information Advertised by Neighbors..................................................................................498

Configuring LLDPDU Intervals......................................................................................................................................... 501

Configuring LLDP Notification Interval........................................................................................................................... 501

Configuring LLDP Notification Interval.......................................................................................................................... 502

Configuring Transmit and Receive Mode.......................................................................................................................502

Configuring the Time to Live Value................................................................................................................................ 503

Debugging LLDP............................................................................................................................................................... 503

16

Contents

Relevant Management Objects.......................................................................................................................................504

30 Microsoft Network Load Balancing...........................................................................................509

Configuring a Switch for NLB .........................................................................................................................................510

Enabling a Switch for Multicast NLB.........................................................................................................................510

31 Multicast Source Discovery Protocol (MSDP)............................................................................ 512

Anycast RP......................................................................................................................................................................... 513

Implementation Information..............................................................................................................................................514

Configure Multicast Source Discovery Protocol............................................................................................................514

Related Configuration Tasks.......................................................................................................................................514

Enable MSDP......................................................................................................................................................................518

Manage the Source-Active Cache.................................................................................................................................. 519

Viewing the Source-Active Cache.............................................................................................................................519

Limiting the Source-Active Cache.............................................................................................................................519

Clearing the Source-Active Cache............................................................................................................................ 519

Enabling the Rejected Source-Active Cache.......................................................................................................... 520

Accept Source-Active Messages that Fail the RFP Check.........................................................................................520

Specifying Source-Active Messages.............................................................................................................................. 522

Limiting the Source-Active Messages from a Peer......................................................................................................523

Preventing MSDP from Caching a Local Source..........................................................................................................523

Preventing MSDP from Caching a Remote Source..................................................................................................... 523

Preventing MSDP from Advertising a Local Source.....................................................................................................524

Logging Changes in Peership States..............................................................................................................................525

Terminating a Peership.....................................................................................................................................................525

Clearing Peer Statistics.................................................................................................................................................... 525

Debugging MSDP..............................................................................................................................................................526

MSDP with Anycast RP................................................................................................................................................... 526

Configuring Anycast RP................................................................................................................................................... 527

Reducing Source-Active Message Flooding............................................................................................................ 528

Specifying the RP Address Used in SA Messages..................................................................................................528

MSDP Sample Configurations.........................................................................................................................................530

32 Multicast Listener Discovery Protocol...................................................................................... 533

MLD timers........................................................................................................................................................................ 536

Reducing Host Response Burstiness........................................................................................................................536

Configuring MLD Version.................................................................................................................................................536

Clearing MLD groups........................................................................................................................................................ 537

Debugging MLD.................................................................................................................................................................537

Explicit Tracking.................................................................................................................................................................537

Reducing Leave Latency.................................................................................................................................................. 537

Displaying MLD groups table........................................................................................................................................... 537

Displaying MLD Interfaces............................................................................................................................................... 538

33 Multiple Spanning Tree Protocol (MSTP)................................................................................. 539

Spanning Tree Variations................................................................................................................................................. 540

Implementation Information.......................................................................................................................................540

Configure Multiple Spanning Tree Protocol...................................................................................................................540

Related Configuration Tasks......................................................................................................................................540

Contents

17

Enable Multiple Spanning Tree Globally.......................................................................................................................... 541

Adding and Removing Interfaces.....................................................................................................................................541

Creating Multiple Spanning Tree Instances....................................................................................................................541

Influencing MSTP Root Selection................................................................................................................................... 542

Interoperate with Non-Dell Bridges................................................................................................................................ 543

Changing the Region Name or Revision.........................................................................................................................543

Modifying Global Parameters.......................................................................................................................................... 543

Modifying the Interface Parameters...............................................................................................................................544

Setting STP path cost as constant................................................................................................................................ 545

Configuring an EdgePort..................................................................................................................................................545

Flush MAC Addresses after a Topology Change.......................................................................................................... 546

MSTP Sample Configurations......................................................................................................................................... 546

Debugging and Verifying MSTP Configurations........................................................................................................... 550

34 Multicast Features..................................................................................................................552

Enabling IP Multicast........................................................................................................................................................ 552

Implementation Information.............................................................................................................................................552

Multicast Policies...............................................................................................................................................................553

IPv4 Multicast Policies................................................................................................................................................553

Understanding Multicast Traceroute (mtrace).............................................................................................................559

Printing Multicast Traceroute (mtrace) Paths..............................................................................................................559

Supported Error Codes..................................................................................................................................................... 561

mtrace Scenarios............................................................................................................................................................... 561

35 Multicast Listener Discovery Protocol...................................................................................... 567

MLD timers........................................................................................................................................................................ 570

Reducing Host Response Burstiness........................................................................................................................570

Clearing MLD groups........................................................................................................................................................ 570

Debugging MLD..................................................................................................................................................................571

Explicit Tracking................................................................................................................................................................. 571

Reducing Leave Latency...................................................................................................................................................571

Displaying MLD groups table............................................................................................................................................ 571

Displaying MLD Interfaces................................................................................................................................................ 571

MLD Snooping................................................................................................................................................................... 572

Enable MLD Snooping.................................................................................................................................................572

Disable MLD Snooping................................................................................................................................................572

Configure the switch as a querier............................................................................................................................. 572

Specify port as connected to multicast router........................................................................................................573

Enable Snooping Explicit Tracking.............................................................................................................................573

Display the MLD Snooping Table...............................................................................................................................573

36 Object Tracking...................................................................................................................... 574

Object Tracking Overview................................................................................................................................................574

Track Layer 2 Interfaces.............................................................................................................................................575

Track Layer 3 Interfaces.............................................................................................................................................575

Track IPv4 and IPv6 Routes...................................................................................................................................... 575

Set Tracking Delays.....................................................................................................................................................576

VRRP Object Tracking................................................................................................................................................ 577

Object Tracking Configuration.........................................................................................................................................577

18

Contents

Tracking a Layer 2 Interface.......................................................................................................................................577

Tracking a Layer 3 Interface...................................................................................................................................... 578

Track an IPv4/IPv6 Route......................................................................................................................................... 579

Displaying Tracked Objects..............................................................................................................................................582

37 Open Shortest Path First (OSPFv2 and OSPFv3)...................................................................... 584

Protocol Overview............................................................................................................................................................ 584

Autonomous System (AS) Areas.............................................................................................................................. 584

Area Types................................................................................................................................................................... 585

Networks and Neighbors............................................................................................................................................586

Router Types............................................................................................................................................................... 586

Designated and Backup Designated Routers...........................................................................................................587

Link-State Advertisements (LSAs)........................................................................................................................... 587

Router Priority and Cost.............................................................................................................................................588

OSPF with Dell EMC Networking OS.............................................................................................................................589

Graceful Restart..........................................................................................................................................................589

Fast Convergence (OSPFv2, IPv4 Only).................................................................................................................590

Multi-Process OSPFv2 with VRF............................................................................................................................. 590

OSPF ACK Packing......................................................................................................................................................591

Setting OSPF Adjacency with Cisco Routers.......................................................................................................... 591

Configuration Information.................................................................................................................................................591

Configuration Task List for OSPFv2 (OSPF for IPv4)........................................................................................... 592

OSPFv3 NSSA.............................................................................................................................................................603

Configuration Task List for OSPFv3 (OSPF for IPv6)...........................................................................................604

MIB Support for OSPFv3................................................................................................................................................. 615

Viewing the OSPFv3 MIB........................................................................................................................................... 615

Configuration Task List for OSPFv3 (OSPF for IPv6)..................................................................................................616

Enabling IPv6 Unicast Routing................................................................................................................................... 616

Applying cost for OSPFv3.......................................................................................................................................... 616

Assigning IPv6 Addresses on an Interface................................................................................................................617

Assigning Area ID on an Interface.............................................................................................................................. 617

Assigning OSPFv3 Process ID and Router ID Globally............................................................................................ 617

Assigning OSPFv3 Process ID and Router ID to a VRF.......................................................................................... 618

Configuring Stub Areas............................................................................................................................................... 618

Configuring Passive-Interface....................................................................................................................................618

Redistributing Routes.................................................................................................................................................. 619

Configuring a Default Route....................................................................................................................................... 619

Enabling OSPFv3 Graceful Restart........................................................................................................................... 619

OSPFv3 Authentication Using IPsec......................................................................................................................... 621

Troubleshooting OSPFv3........................................................................................................................................... 627

38 Policy-based Routing (PBR).................................................................................................... 628

Overview............................................................................................................................................................................ 628

Implementing PBR.............................................................................................................................................................629

Configuration Task List for Policy-based Routing........................................................................................................ 629

Create a Redirect List.................................................................................................................................................630

Create a Rule for a Redirect-list................................................................................................................................630

Apply a Redirect-list to an Interface using a Redirect-group................................................................................. 631

Sample Configuration....................................................................................................................................................... 634

Contents

19

39 PIM Sparse-Mode (PIM-SM)................................................................................................... 638

Implementation Information.............................................................................................................................................638

Protocol Overview............................................................................................................................................................ 638

Requesting Multicast Traffic......................................................................................................................................638

Refuse Multicast Traffic.............................................................................................................................................638

Send Multicast Traffic................................................................................................................................................ 639

Configuring PIM-SM.........................................................................................................................................................639

Related Configuration Tasks......................................................................................................................................639

Enable PIM-SM................................................................................................................................................................. 639

Configuring S,G Expiry Timers......................................................................................................................................... 641

Configuring a Static Rendezvous Point......................................................................................................................... 642

Overriding Bootstrap Router Updates......................................................................................................................642

Configuring a Designated Router....................................................................................................................................643

Creating Multicast Boundaries and Domains.................................................................................................................644

Electing an RP using the BSR Mechanism.................................................................................................................... 644

40 PIM Source-Specific Mode (PIM-SSM).................................................................................... 646

Implementation Information.............................................................................................................................................646

Configure PIM-SSM......................................................................................................................................................... 646

Enabling PIM-SSM............................................................................................................................................................ 647

Use PIM-SSM with IGMP Version 2 Hosts................................................................................................................... 647

Electing an RP using the BSR Mechanism.................................................................................................................... 649

Enabling RP to Server Specific Multicast Groups.................................................................................................. 650

41 Port Monitoring.......................................................................................................................651

Important Points to Remember....................................................................................................................................... 651

Port Monitoring..................................................................................................................................................................651

Configuring Port Monitoring............................................................................................................................................654

Configuring Monitor Multicast Queue............................................................................................................................655

Enabling Flow-Based Monitoring.................................................................................................................................... 655

Remote Port Mirroring..................................................................................................................................................... 656

Remote Port Mirroring Example................................................................................................................................657

Configuring Remote Port Mirroring.......................................................................................................................... 657

Displaying Remote-Port Mirroring Configurations..................................................................................................659

Configuration procedure for Remote Port Mirroring..............................................................................................659

Encapsulated Remote Port Monitoring..........................................................................................................................663

ERPM Behavior on a typical Dell EMC Networking OS ..............................................................................................665

Port Monitoring on VLT................................................................................................................................................... 666

42 Private VLANs (PVLAN).......................................................................................................... 669

Private VLAN Concepts...................................................................................................................................................669

Using the Private VLAN Commands...............................................................................................................................670

Configuration Task List......................................................................................................................................................671

Creating PVLAN ports.................................................................................................................................................671

Creating a Primary VLAN............................................................................................................................................ 671

Creating a Community VLAN.....................................................................................................................................672

Creating an Isolated VLAN......................................................................................................................................... 673

Private VLAN Configuration Example.............................................................................................................................674

20

Contents

Inspecting the Private VLAN Configuration...................................................................................................................675

43 Per-VLAN Spanning Tree Plus (PVST+).................................................................................... 677

Protocol Overview.............................................................................................................................................................677

Implementation Information............................................................................................................................................. 678

Configure Per-VLAN Spanning Tree Plus...................................................................................................................... 678

Enabling PVST+.................................................................................................................................................................678

Disabling PVST+................................................................................................................................................................ 678

Influencing PVST+ Root Selection..................................................................................................................................679

Modifying Global PVST+ Parameters.............................................................................................................................680

Modifying Interface PVST+ Parameters.........................................................................................................................681

Configuring an EdgePort...................................................................................................................................................681

PVST+ in Multi-Vendor Networks.................................................................................................................................. 682

Enabling PVST+ Extend System ID................................................................................................................................ 682

PVST+ Sample Configurations........................................................................................................................................683

44 Quality of Service (QoS)......................................................................................................... 685

Implementation Information............................................................................................................................................. 687

Port-Based QoS Configurations......................................................................................................................................687

Setting dot1p Priorities for Incoming Traffic............................................................................................................687

Honoring dot1p Priorities on Ingress Traffic.............................................................................................................688

Configuring Port-Based Rate Policing......................................................................................................................688

Configuring Port-Based Rate Shaping..................................................................................................................... 688

Policy-Based QoS Configurations...................................................................................................................................689

Classify Traffic.............................................................................................................................................................689

Create a QoS Policy....................................................................................................................................................692

Create Policy Maps.....................................................................................................................................................694

DSCP Color Maps............................................................................................................................................................. 697

Creating a DSCP Color Map...................................................................................................................................... 697

Displaying DSCP Color Maps.....................................................................................................................................698

Displaying a DSCP Color Policy Configuration ....................................................................................................... 698

Enabling QoS Rate Adjustment.......................................................................................................................................699

Enabling Strict-Priority Queueing....................................................................................................................................699

Weighted Random Early Detection.................................................................................................................................699

Creating WRED Profiles............................................................................................................................................. 700

Applying a WRED Profile to Traffic...........................................................................................................................700

Displaying Default and Configured WRED Profiles.................................................................................................. 701

Displaying WRED Drop Statistics............................................................................................................................... 701

Displaying egress–queue Statistics............................................................................................................................701

Pre-Calculating Available QoS CAM Space....................................................................................................................701

Configuring Weights and ECN for WRED .....................................................................................................................702

Configuring WRED and ECN Attributes.........................................................................................................................704

Guidelines for Configuring ECN for Classifying and Color-Marking Packets............................................................ 704

Sample configuration to mark non-ecn packets as “yellow” with Multiple traffic class.................................... 705

Classifying Incoming Packets Using ECN and Color-Marking...............................................................................705

Sample configuration to mark non-ecn packets as “yellow” with single traffic class.........................................707

Applying Layer 2 Match Criteria on a Layer 3 Interface...............................................................................................708

Applying DSCP and VLAN Match Criteria on a Service Queue.................................................................................. 708

Classifying Incoming Packets Using ECN and Color-Marking.....................................................................................709

Contents

21

Guidelines for Configuring ECN for Classifying and Color-Marking Packets............................................................. 710

Sample configuration to mark non-ecn packets as “yellow” with Multiple traffic class............................................711

Sample configuration to mark non-ecn packets as “yellow” with single traffic class................................................711

Enabling Buffer Statistics Tracking .................................................................................................................................712

45 Routing Information Protocol (RIP).......................................................................................... 715

Protocol Overview............................................................................................................................................................. 715

RIPv1.............................................................................................................................................................................. 715

RIPv2............................................................................................................................................................................. 715

Implementation Information..............................................................................................................................................715

Configuration Information................................................................................................................................................. 716

Configuration Task List................................................................................................................................................716

RIP Configuration Example......................................................................................................................................... 721

46 Remote Monitoring (RMON)....................................................................................................726

Implementation Information............................................................................................................................................. 726

Fault Recovery...................................................................................................................................................................726

Setting the RMON Alarm........................................................................................................................................... 726

Configuring an RMON Event..................................................................................................................................... 727

Configuring RMON Collection Statistics.................................................................................................................. 728

Configuring the RMON Collection History...............................................................................................................728

47 Rapid Spanning Tree Protocol (RSTP)...................................................................................... 729

Protocol Overview............................................................................................................................................................ 729

Configuring Rapid Spanning Tree....................................................................................................................................729

Important Points to Remember.......................................................................................................................................729

RSTP and VLT............................................................................................................................................................. 730

Configuring Interfaces for Layer 2 Mode.......................................................................................................................730

Enabling Rapid Spanning Tree Protocol Globally...........................................................................................................730

Adding and Removing Interfaces.................................................................................................................................... 732

Modifying Global Parameters...........................................................................................................................................732

Enabling SNMP Traps for Root Elections and Topology Changes........................................................................733

Modifying Interface Parameters......................................................................................................................................734

Enabling SNMP Traps for Root Elections and Topology Changes............................................................................. 734

Influencing RSTP Root Selection.................................................................................................................................... 734

Configuring an EdgePort.................................................................................................................................................. 734

Configuring Fast Hellos for Link State Detection..........................................................................................................735

48 Software-Defined Networking (SDN)....................................................................................... 737

49 Security................................................................................................................................. 738

AAA Accounting.................................................................................................................................................................738

Configuration Task List for AAA Accounting........................................................................................................... 738

RADIUS Accounting.................................................................................................................................................... 740

AAA Authentication...........................................................................................................................................................745

Configuration Task List for AAA Authentication..................................................................................................... 745

Obscuring Passwords and Keys.......................................................................................................................................747

AAA Authorization............................................................................................................................................................. 748

Privilege Levels Overview...........................................................................................................................................748

22

Contents

Configuration Task List for Privilege Levels.............................................................................................................748

RADIUS...............................................................................................................................................................................752

RADIUS Authentication.............................................................................................................................................. 752

Configuration Task List for RADIUS..........................................................................................................................753

Support for Change of Authorization and Disconnect Messages packets..........................................................756

TACACS+...........................................................................................................................................................................765

Configuration Task List for TACACS+......................................................................................................................765

TACACS+ Remote Authentication............................................................................................................................766

Command Authorization............................................................................................................................................. 767

Protection from TCP Tiny and Overlapping Fragment Attacks..................................................................................768

Enabling SCP and SSH..................................................................................................................................................... 768

Using SCP with SSH to Copy a Software Image.................................................................................................... 768

Removing the RSA Host Keys and Zeroizing Storage ...........................................................................................769

Configuring When to Re-generate an SSH Key .....................................................................................................769

Configuring the SSH Server Key Exchange Algorithm...........................................................................................770

Configuring the HMAC Algorithm for the SSH Server...........................................................................................770

Configuring the SSH Server Cipher List....................................................................................................................771

Configuring DNS in the SSH Server.......................................................................................................................... 771

Secure Shell Authentication....................................................................................................................................... 772

Troubleshooting SSH.................................................................................................................................................. 774

Telnet.................................................................................................................................................................................. 774

VTY Line and Access-Class Configuration..................................................................................................................... 774

VTY Line Local Authentication and Authorization...................................................................................................775

VTY Line Remote Authentication and Authorization.............................................................................................. 775

VTY MAC-SA Filter Support...................................................................................................................................... 775

Role-Based Access Control..............................................................................................................................................776

Overview of RBAC...................................................................................................................................................... 776

User Roles.....................................................................................................................................................................778

AAA Authentication and Authorization for Roles..................................................................................................... 781

Role Accounting...........................................................................................................................................................783

Display Information About User Roles.......................................................................................................................784

Two Factor Authentication (2FA)...................................................................................................................................785

Handling Access-Challenge Message....................................................................................................................... 785

Configuring Challenge Response Authentication for SSHv2.................................................................................785

SMS-OTP Mechanism................................................................................................................................................786

Configuring the System to Drop Certain ICMP Reply Messages............................................................................... 786

Dell EMC Networking OS Security Hardening...............................................................................................................788

Dell EMC Networking OS Image Verification...........................................................................................................788

Startup Configuration Verification............................................................................................................................ 789

Configuring the root User Password........................................................................................................................ 790

Locking Access to GRUB Interface.......................................................................................................................... 790

Enabling User Lockout for Failed Login Attempts................................................................................................... 791

50 Service Provider Bridging........................................................................................................792

VLAN Stacking...................................................................................................................................................................792

Configure VLAN Stacking...........................................................................................................................................793

Creating Access and Trunk Ports..............................................................................................................................794

Enable VLAN-Stacking for a VLAN...........................................................................................................................794

Configuring the Protocol Type Value for the Outer VLAN Tag............................................................................ 795

Configuring Dell EMC Networking OS Options for Trunk Ports........................................................................... 795

Contents

23

Debugging VLAN Stacking.........................................................................................................................................796

VLAN Stacking in Multi-Vendor Networks.............................................................................................................. 796

VLAN Stacking Packet Drop Precedence..................................................................................................................... 800

Enabling Drop Eligibility...............................................................................................................................................800

Honoring the Incoming DEI Value............................................................................................................................. 800

Marking Egress Packets with a DEI Value................................................................................................................ 801

Dynamic Mode CoS for VLAN Stacking......................................................................................................................... 801

Mapping C-Tag to S-Tag dot1p Values.................................................................................................................... 803

Layer 2 Protocol Tunneling.............................................................................................................................................. 803

Enabling Layer 2 Protocol Tunneling........................................................................................................................ 805

Specifying a Destination MAC Address for BPDUs................................................................................................806

Setting Rate-Limit BPDUs......................................................................................................................................... 806

Debugging Layer 2 Protocol Tunneling.................................................................................................................... 806

Provider Backbone Bridging............................................................................................................................................ 806

51 sFlow..................................................................................................................................... 808

Overview............................................................................................................................................................................ 808

Implementation Information.............................................................................................................................................808

Enabling Extended sFlow................................................................................................................................................. 809

Enabling and Disabling sFlow on an Interface................................................................................................................ 810

Enabling sFlow Max-Header Size Extended...................................................................................................................810

sFlow Show Commands.................................................................................................................................................... 811

Displaying Show sFlow Global..................................................................................................................................... 811

Displaying Show sFlow on an Interface......................................................................................................................811

Displaying Show sFlow on a Stack-unit.....................................................................................................................812

Configuring Specify Collectors.........................................................................................................................................812

Changing the Polling Intervals..........................................................................................................................................812

Back-Off Mechanism........................................................................................................................................................ 813

sFlow on LAG ports........................................................................................................................................................... 813

Enabling Extended sFlow.................................................................................................................................................. 813

Important Points to Remember..................................................................................................................................814

24

52 Simple Network Management Protocol (SNMP)........................................................................ 815

Protocol Overview.............................................................................................................................................................816

Implementation Information..............................................................................................................................................816

SNMPv3 Compliance With FIPS......................................................................................................................................816

Configuration Task List for SNMP...................................................................................................................................817

Important Points to Remember........................................................................................................................................817

Set up SNMP......................................................................................................................................................................817

Creating a Community.................................................................................................................................................818

Setting Up User-Based Security (SNMPv3)............................................................................................................818

Enable SNMPv3 traps................................................................................................................................................. 819

Reading Managed Object Values.....................................................................................................................................819

Writing Managed Object Values......................................................................................................................................820

Configuring Contact and Location Information using SNMP......................................................................................820

Subscribing to Managed Object Value Updates using SNMP..................................................................................... 821

Enabling a Subset of SNMP Traps.................................................................................................................................. 821

Enabling an SNMP Agent to Notify Syslog Server Failure...........................................................................................823

Copy Configuration Files Using SNMP...........................................................................................................................824

Contents

Copying a Configuration File......................................................................................................................................825

Copying Configuration Files via SNMP.....................................................................................................................826

Copying the Startup-Config Files to the Running-Config......................................................................................826

Copying the Startup-Config Files to the Server via FTP....................................................................................... 827

Copying the Startup-Config Files to the Server via TFTP.....................................................................................827

Copy a Binary File to the Startup-Configuration.....................................................................................................827

Additional MIB Objects to View Copy Statistics..................................................................................................... 828

Obtaining a Value for MIB Objects............................................................................................................................828

MIB Support to Display Reason for Last System Reboot............................................................................................829

Viewing the Reason for Last System Reboot Using SNMP.................................................................................. 829

MIB Support for Power Monitoring................................................................................................................................829

MIB Support to Display the Available Memory Size on Flash......................................................................................830

Viewing the Available Flash Memory Size................................................................................................................830

MIB Support to Display the Software Core Files Generated by the System............................................................ 830

Viewing the Software Core Files Generated by the System..................................................................................831

MIB Support to Display the Available Partitions on Flash.............................................................................................831

Viewing the Available Partitions on Flash.................................................................................................................832

MIB Support to Display Egress Queue Statistics..........................................................................................................833

MIB Support to ECMP Group Count..............................................................................................................................833

Viewing the ECMP Group Count Information......................................................................................................... 833

MIB Support for entAliasMappingTable ........................................................................................................................ 836

Viewing the entAliasMappingTable MIB...................................................................................................................836

MIB Support for LAG........................................................................................................................................................836

Viewing the LAG MIB..................................................................................................................................................837

MIB Support to Display Unrecognized LLDP TLVs...................................................................................................... 838

MIB Support to Display Reserved Unrecognized LLDP TLVs............................................................................... 838

MIB Support to Display Organizational Specific Unrecognized LLDP TLVs........................................................839

MIB Support for LLDP Notification Interval.................................................................................................................. 839

MIB support for Port Security.........................................................................................................................................840

Global MIB objects for port security.........................................................................................................................840

MIB support for interface level port security...........................................................................................................840

MIB objects for configuring MAC addresses............................................................................................................841

MIB objects for configuring MAC addresses...........................................................................................................842

Manage VLANs using SNMP...........................................................................................................................................843

Creating a VLAN..........................................................................................................................................................843

Assigning a VLAN Alias............................................................................................................................................... 843

Displaying the Ports in a VLAN..................................................................................................................................843

Add Tagged and Untagged Ports to a VLAN.......................................................................................................... 844

Managing Overload on Startup....................................................................................................................................... 845

Enabling and Disabling a Port using SNMP....................................................................................................................845

Fetch Dynamic MAC Entries using SNMP.....................................................................................................................846

Example of Deriving the Interface Index Number......................................................................................................... 847

MIB Objects for Viewing the System Image on Flash Partitions...........................................................................847

Monitoring BGP sessions via SNMP...............................................................................................................................847

Monitor Port-Channels.....................................................................................................................................................849

Enabling an SNMP Agent to Notify Syslog Server Failure.......................................................................................... 850

Troubleshooting SNMP Operation.................................................................................................................................. 851

Transceiver Monitoring..................................................................................................................................................... 851

Configuring SNMP context name...................................................................................................................................852

Contents

25

53 Stacking................................................................................................................................ 854

Stacking Overview............................................................................................................................................................854

Stack Management Roles.......................................................................................................................................... 854

Stack Master Election................................................................................................................................................ 855

Virtual IP....................................................................................................................................................................... 856

Failover Roles...............................................................................................................................................................857

MAC Addressing on Stacks........................................................................................................................................857

Stacking LAG............................................................................................................................................................... 858

Supported Stacking Topologies.................................................................................................................................858

High Availability on Stacks......................................................................................................................................... 858

Management Access on Stacks................................................................................................................................859

Mixed-mode Stacking.................................................................................................................................................860

Important Points to Remember....................................................................................................................................... 861

Stacking Installation Tasks................................................................................................................................................861

Create a Stack..............................................................................................................................................................861

Add Units to an Existing Stack.................................................................................................................................. 865

Split a Stack................................................................................................................................................................. 867

Stacking Configuration Tasks.......................................................................................................................................... 867

Assigning Unit Numbers to Units in an Stack.......................................................................................................... 867

Creating a Virtual Stack Unit on a Stack..................................................................................................................868

Displaying Information about a Stack....................................................................................................................... 868

Influencing Management Unit Selection on a Stack............................................................................................... 870

Managing Redundancy on a Stack.............................................................................................................................871

Resetting a Unit on a Stack........................................................................................................................................ 871

Enabling Mixed-mode Stacking.................................................................................................................................. 871

Verify a Stack Configuration............................................................................................................................................872

Displaying the Status of Stacking Ports................................................................................................................... 872

Remove Units or Front End Ports from a Stack........................................................................................................... 873

Removing a Unit from a Stack...................................................................................................................................873

Removing Front End Port Stacking.......................................................................................................................... 874

Troubleshoot a Stack........................................................................................................................................................874

Recover from Stack Link Flaps..................................................................................................................................875

Recover from a Card Problem State on a Stack.....................................................................................................875

26

54 Storm Control.........................................................................................................................877

Configure Storm Control.................................................................................................................................................. 877

Configuring Storm Control from INTERFACE Mode.............................................................................................. 877

Configuring Storm Control from CONFIGURATION Mode................................................................................... 878

55 Spanning Tree Protocol (STP)................................................................................................. 879

Protocol Overview............................................................................................................................................................ 879

Configure Spanning Tree..................................................................................................................................................879

Important Points to Remember.......................................................................................................................................880

Configuring Interfaces for Layer 2 Mode.......................................................................................................................880

Enabling Spanning Tree Protocol Globally...................................................................................................................... 881

Adding an Interface to the Spanning Tree Group.........................................................................................................883

Modifying Global Parameters.......................................................................................................................................... 883

Modifying Interface STP Parameters.............................................................................................................................884

Contents

Enabling PortFast..............................................................................................................................................................884

Prevent Network Disruptions with BPDU Guard....................................................................................................885

Selecting STP Root...........................................................................................................................................................887

STP Root Guard................................................................................................................................................................ 887

Root Guard Scenario...................................................................................................................................................887

Configuring Root Guard..............................................................................................................................................888

Enabling SNMP Traps for Root Elections and Topology Changes.............................................................................889

Configuring Spanning Trees as Hitless...........................................................................................................................889

STP Loop Guard................................................................................................................................................................889

Configuring Loop Guard............................................................................................................................................. 890

Displaying STP Guard Configuration............................................................................................................................... 891

56 SupportAssist........................................................................................................................ 892

Configuring SupportAssist Using a Configuration Wizard........................................................................................... 892

Configuring SupportAssist Manually...............................................................................................................................893

Configuring SupportAssist Activity.................................................................................................................................894

Configuring SupportAssist Company............................................................................................................................. 896

Configuring SupportAssist Person..................................................................................................................................896

Configuring SupportAssist Server...................................................................................................................................897

Viewing SupportAssist Configuration.............................................................................................................................898

57 System Time and Date............................................................................................................ 900

Network Time Protocol....................................................................................................................................................900

Protocol Overview....................................................................................................................................................... 901

Configure the Network Time Protocol......................................................................................................................901

Enabling NTP................................................................................................................................................................901

Configuring NTP Broadcasts.....................................................................................................................................902

Disabling NTP on an Interface................................................................................................................................... 902

Configuring a Source IP Address for NTP Packets................................................................................................ 902

Configuring NTP Authentication............................................................................................................................... 903

Configuring NTP control key password................................................................................................................... 905

Configuring the NTP Step-Threshold...................................................................................................................... 905

Dell EMC Networking OS Time and Date...................................................................................................................... 905

Configuration Task List ............................................................................................................................................. 905

Setting the Time and Date for the Switch Software Clock...................................................................................905

Setting the Timezone................................................................................................................................................. 906

Set Daylight Saving Time........................................................................................................................................... 906

Setting Daylight Saving Time Once.......................................................................................................................... 906

Setting Recurring Daylight Saving Time...................................................................................................................907

58 Tunneling...............................................................................................................................909

Configuring a Tunnel.........................................................................................................................................................909

Configuring Tunnel Keepalive Settings........................................................................................................................... 910

Configuring a Tunnel Interface.........................................................................................................................................910

Configuring Tunnel Allow-Remote Decapsulation.......................................................................................................... 911

Configuring the Tunnel Source Anylocal..........................................................................................................................911

59 Uplink Failure Detection (UFD).................................................................................................912

Feature Description........................................................................................................................................................... 912

Contents

27

How Uplink Failure Detection Works...............................................................................................................................913

UFD and NIC Teaming.......................................................................................................................................................914

Important Points to Remember....................................................................................................................................... 914

Configuring Uplink Failure Detection...............................................................................................................................915

Clearing a UFD-Disabled Interface.................................................................................................................................. 916

Displaying Uplink Failure Detection.................................................................................................................................. 917

Sample Configuration: Uplink Failure Detection.............................................................................................................918

60 Upgrade Procedures............................................................................................................... 920

61 Virtual LANs (VLANs)...............................................................................................................921

Default VLAN......................................................................................................................................................................921

Port-Based VLANs............................................................................................................................................................922

VLANs and Port Tagging..................................................................................................................................................922

Configuration Task List.....................................................................................................................................................923

Creating a Port-Based VLAN.....................................................................................................................................923

Assigning Interfaces to a VLAN.................................................................................................................................923

Moving Untagged Interfaces..................................................................................................................................... 924

Assigning an IP Address to a VLAN.......................................................................................................................... 925

Configuring Native VLANs...............................................................................................................................................926

Enabling Null VLAN as the Default VLAN...................................................................................................................... 926

62 Virtual Link Trunking (VLT)......................................................................................................927

Overview............................................................................................................................................................................ 927

VLT Terminology......................................................................................................................................................... 929

Layer-2 Traffic in VLT Domains.................................................................................................................................929

Interspersed VLANs....................................................................................................................................................930

VLT on Core Switches.................................................................................................................................................931

Enhanced VLT.............................................................................................................................................................. 931

Configure Virtual Link Trunking....................................................................................................................................... 932

Important Points to Remember.................................................................................................................................932

Configuration Notes....................................................................................................................................................933

Primary and Secondary VLT Peers........................................................................................................................... 936

RSTP and VLT............................................................................................................................................................. 936

VLT Bandwidth Monitoring........................................................................................................................................ 937

VLT and Stacking........................................................................................................................................................ 937

VLT and IGMP Snooping............................................................................................................................................ 937

VLT IPv6....................................................................................................................................................................... 937

VLT Port Delayed Restoration................................................................................................................................... 937

PIM-Sparse Mode Support on VLT.......................................................................................................................... 938

VLT Routing ................................................................................................................................................................ 939

Non-VLT ARP Sync.................................................................................................................................................... 942

RSTP Configuration.......................................................................................................................................................... 942

Preventing Forwarding Loops in a VLT Domain......................................................................................................942

Sample RSTP configuration....................................................................................................................................... 943

Configuring VLT...........................................................................................................................................................943

PVST+ Configuration........................................................................................................................................................952

Peer Routing Configuration Example............................................................................................................................. 953

Dell-1 Switch Configuration........................................................................................................................................953

28

Contents

Dell-2 Switch Configuration....................................................................................................................................... 957

R1 Configuration..........................................................................................................................................................960

Access Switch A1 Configurations and Verification.................................................................................................. 961

eVLT Configuration Example...........................................................................................................................................962

PIM-Sparse Mode Configuration Example.................................................................................................................... 964

Verifying a VLT Configuration......................................................................................................................................... 964

Additional VLT Sample Configurations........................................................................................................................... 967

Troubleshooting VLT........................................................................................................................................................ 969

Reconfiguring Stacked Switches as VLT.......................................................................................................................970

Specifying VLT Nodes in a PVLAN................................................................................................................................. 970

Configuring a VLT VLAN or LAG in a PVLAN................................................................................................................973

Creating a VLT LAG or a VLT VLAN.........................................................................................................................973

Associating the VLT LAG or VLT VLAN in a PVLAN.............................................................................................. 974

Proxy ARP Capability on VLT Peer Nodes.....................................................................................................................975

VLT Nodes as Rendezvous Points for Multicast Resiliency........................................................................................ 976

Configuring VLAN-Stack over VLT.................................................................................................................................976

IPv6 Peer Routing in VLT Domains Overview............................................................................................................... 979

Configure BFD in VLT Domain.........................................................................................................................................983

Sample BFD configuration in VLT domain................................................................................................................983

VXLAN on VLT.................................................................................................................................................................. 987

63 VLT Proxy Gateway.................................................................................................................989

Proxy Gateway in VLT Domains......................................................................................................................................989

LLDP VLT Proxy Gateway in a Square VLT Topology........................................................................................... 992

Configuring a Static VLT Proxy Gateway...................................................................................................................... 993

Configuring an LLDP VLT Proxy Gateway.....................................................................................................................993

VLT Proxy Gateway Sample Topology...........................................................................................................................993

VLT Domain Configuration.........................................................................................................................................994

Dell-1 VLT Configuration.............................................................................................................................................994

Dell-2 VLT Configuration............................................................................................................................................995

Dell-3 VLT Configuration............................................................................................................................................996

Dell-4 VLT Configuration............................................................................................................................................997

64 Virtual Extensible LAN (VXLAN)...............................................................................................998

advertise-local-mac.......................................................................................................................................................... 999

Components of VXLAN network.................................................................................................................................... 999

Functional Overview of VXLAN Gateway....................................................................................................................1000

VXLAN Frame Format.................................................................................................................................................... 1000

Limitations on VXLAN .....................................................................................................................................................1001

Configuring and Controlling VXLAN from the NSX Controller GUI.......................................................................... 1002

Configuring and Controling VXLAN from Nuage Controller GUI.............................................................................. 1006

Configuring VxLAN Gateway......................................................................................................................................... 1007

Connecting to an NVP Controller............................................................................................................................1007

Advertising VXLAN Access Ports to Controller.....................................................................................................1008

Displaying VXLAN Configurations................................................................................................................................. 1008

VXLAN Service nodes for BFD......................................................................................................................................1009

Static Virtual Extensible LAN (VXLAN).........................................................................................................................1010

Configuring Static VXLAN.........................................................................................................................................1010

Displaying Static VXLAN Configurations..................................................................................................................1011

Contents

29

Disabling MAC Address Learning on Static VXLAN Tunnels.................................................................................1011

Preserving 802.1 p value across VXLAN tunnels..........................................................................................................1012

VXLAN Scenario............................................................................................................................................................... 1012

Routing in and out of VXLAN tunnels............................................................................................................................1013

Configuring VXLAN RIOT.......................................................................................................................................... 1014

VLT Scenario...............................................................................................................................................................1015

NSX Controller-based VXLAN for VLT......................................................................................................................... 1016

Important Points to Remember................................................................................................................................ 1016

Configure NSX Controller-based VxLAN in VLT Setup.........................................................................................1017

Configuring BFD and UFD for VXLAN..................................................................................................................... 1017

Configuring NSX-based VxLAN on VLT Peer Devices.......................................................................................... 1017

Configuring VLT for NSX-based VxLAN................................................................................................................. 1018

Configuring and Controlling VXLAN from the NSX Controller GUI.....................................................................1022

65 Virtual Routing and Forwarding (VRF).....................................................................................1027

VRF Overview.................................................................................................................................................................. 1027

VRF Configuration Notes............................................................................................................................................... 1028

DHCP...........................................................................................................................................................................1029

VRF Configuration...........................................................................................................................................................1029

Loading VRF CAM..................................................................................................................................................... 1029

Creating a Non-Default VRF Instance.................................................................................................................... 1029

Assigning an Interface to a VRF.............................................................................................................................. 1030

Assigning a Front-end Port to a Management VRF..............................................................................................1030

View VRF Instance Information............................................................................................................................... 1030

Assigning an OSPF Process to a VRF Instance.....................................................................................................1030

Configuring VRRP on a VRF Instance......................................................................................................................1031

Configuring Management VRF................................................................................................................................. 1031

Configuring a Static Route....................................................................................................................................... 1032

Sample VRF Configuration............................................................................................................................................. 1032

Route Leaking VRFs........................................................................................................................................................1038

Dynamic Route Leaking.................................................................................................................................................. 1038

Configuring Route Leaking without Filtering Criteria............................................................................................1039

Configuring Route Leaking with Filtering................................................................................................................ 1041

30

66 Virtual Router Redundancy Protocol (VRRP)........................................................................... 1044

VRRP Overview............................................................................................................................................................... 1044

VRRP Benefits................................................................................................................................................................. 1045

VRRP Implementation.....................................................................................................................................................1045

VRRP Configuration........................................................................................................................................................ 1046

Configuration Task List............................................................................................................................................. 1046

Setting VRRP Initialization Delay............................................................................................................................. 1054

Sample Configurations....................................................................................................................................................1054

VRRP in a VRF Configuration.................................................................................................................................. 1058

VRRP for IPv6 Configuration................................................................................................................................... 1063

Proxy Gateway with VRRP............................................................................................................................................ 1066

67 Debugging and Diagnostics..................................................................................................... 1071

Offline Diagnostics............................................................................................................................................................1071

Important Points to Remember................................................................................................................................ 1071

Contents

Running Offline Diagnostics...................................................................................................................................... 1071

Trace Logs........................................................................................................................................................................ 1074

Auto Save on Crash or Rollover.....................................................................................................................................1074

Last Restart Reason........................................................................................................................................................1074

Hardware Watchdog Timer............................................................................................................................................ 1074

Using the Show Hardware Commands.........................................................................................................................1074

Enabling Environmental Monitoring...............................................................................................................................1075

Recognize an Overtemperature Condition.............................................................................................................1076

Troubleshoot an Over-temperature Condition.......................................................................................................1077

Recognize an Under-Voltage Condition..................................................................................................................1077

Troubleshoot an Under-Voltage Condition............................................................................................................. 1077

Troubleshooting Packet Loss.........................................................................................................................................1078

Displaying Drop Counters..........................................................................................................................................1078

Dataplane Statistics....................................................................................................................................................1081

Display Stack Port Statistics.................................................................................................................................... 1082

Display Stack Member Counters............................................................................................................................. 1083

Enabling Application Core Dumps..................................................................................................................................1085

Mini Core Dumps............................................................................................................................................................. 1086

Enabling TCP Dumps.......................................................................................................................................................1086

68 Standards Compliance........................................................................................................... 1088

IEEE Compliance..............................................................................................................................................................1088

RFC and I-D Compliance................................................................................................................................................ 1089

General Internet Protocols....................................................................................................................................... 1089

General IPv4 Protocols............................................................................................................................................. 1090

General IPv6 Protocols.............................................................................................................................................. 1091

Border Gateway Protocol (BGP).............................................................................................................................1092

Open Shortest Path First (OSPF)...........................................................................................................................1093

Intermediate System to Intermediate System (IS-IS)...........................................................................................1093

Routing Information Protocol (RIP)........................................................................................................................ 1094

Multicast..................................................................................................................................................................... 1094

Network Management..............................................................................................................................................1095

MIB Location.................................................................................................................................................................... 1099

69 X.509v3.................................................................................................................................1101

Introduction to X.509v3 certificates.............................................................................................................................. 1101

X.509v3 support in ..........................................................................................................................................................1102

Information about installing CA certificates.................................................................................................................. 1103

Installing CA certificate.............................................................................................................................................. 1104

Information about Creating Certificate Signing Requests (CSR).............................................................................. 1104

Creating Certificate Signing Requests (CSR)........................................................................................................ 1104

Information about installing trusted certificates...........................................................................................................1105

Installing trusted certificates.....................................................................................................................................1105

Transport layer security (TLS)....................................................................................................................................... 1105

Syslog over TLS..........................................................................................................................................................1106

Online Certificate Status Protocol (OSCP).................................................................................................................. 1106

Configuring OCSP setting on CA............................................................................................................................. 1106

Configuring OCSP behavior...................................................................................................................................... 1106

Configuring Revocation Behavior............................................................................................................................. 1107

Contents

31

Configuring OSCP responder preference................................................................................................................1107

Verifying certificates........................................................................................................................................................ 1107

Verifying Server certificates......................................................................................................................................1107

Verifying Client Certificates.......................................................................................................................................1107

Event logging.....................................................................................................................................................................1107

32 Contents

1

About this Guide

This guide describes the protocols and features the Dell EMC Networking Operating System (OS) supports and provides configuration
instructions and examples for implementing them. For complete information about all the CLI commands, see the Dell EMC Command Line
Reference Guide for your system.

The S4048–ON platform is available with Dell EMC Networking OS version 9.7.(0.1) and beyond.S4048–ON stacking is supported with
Dell EMC Networking OS version 9.7(0.1) and beyond.

Though this guide contains information about protocols, it is not intended to be a complete reference. This guide is a reference for
configuring protocols on Dell EMC Networking systems. For complete information about protocols, see the related documentation,
including Internet Engineering Task Force (IETF) requests for comments (RFCs). The instructions in this guide cite relevant RFCs. The

Standards Compliance chapter contains a complete list of the supported RFCs and management information base files (MIBs).

Topics:

• Audience

• Conventions

• Related Documents

Audience

This document is intended for system administrators who are responsible for configuring and maintaining networks and assumes
knowledge in Layer 2 (L2) and Layer 3 (L3) networking technologies.

Conventions

This guide uses the following conventions to describe command syntax.

Keyword

parameter

{X} Keywords and parameters within braces must be entered in the CLI.

[X] Keywords and parameters within brackets are optional.

x|y Keywords and parameters separated by a bar require you to choose one option.

x||y Keywords and parameters separated by a double bar allows you to choose any or all of the options.

Keywords are in Courier (a monospaced font) and must be entered in the CLI as listed.

Parameters are in italics and require a number or word to be entered in the CLI.

Related Documents

For more information about the Dell EMC Networking switches, see the following documents:

• Dell EMC Networking OS Command Line Reference Guide

• Dell EMC Networking OS Installation Guide

• Dell EMC Networking OS Quick Start Guide

• Dell EMC Networking OS Release Notes

About this Guide 33

2

Configuration Fundamentals

The Dell EMC Networking Operating System (OS) command line interface (CLI) is a text-based interface you can use to configure
interfaces and protocols.

The CLI is largely the same for each platform except for some commands and command outputs. The CLI is structured in modes for
security and management purposes. Different sets of commands are available in each mode, and you can limit user access to modes using
privilege levels.

In the Dell EMC Networking OS, after you enter a command, the command is added to the running configuration file. You can view the
current configuration for the whole system or for a particular CLI mode. To save the current configuration, copy the running configuration
to another location.

NOTE: Due to differences in hardware architecture and continued system development, features may occasionally differ

between the platforms. Differences are noted in each CLI description and related documentation.

Topics:

• Accessing the Command Line

• CLI Modes

• The do Command

• Undoing Commands

• Obtaining Help

• Entering and Editing Commands

• Command History

• Filtering show Command Outputs

• Multiple Users in Configuration Mode

Accessing the Command Line

Access the CLI through a serial console port or a Telnet session.

When the system successfully boots, enter the command line in EXEC mode.

NOTE:

you must use a console connection when connecting to the system for the first time.

telnet 172.31.1.53
Trying 172.31.1.53...
Connected to 172.31.1.53.
Escape character is '^]'.
Login: username
Password:
DellEMC>

You must have a password configured on a virtual terminal line before you can Telnet into the system. Therefore,

CLI Modes

Different sets of commands are available in each mode.

A command found in one mode cannot be executed from another mode (except for EXEC mode commands with a preceding do
command (refer to the do Command section).

You can set user access rights to commands and command modes using privilege levels.

For more information about privilege levels and security options, refer to the Privilege Levels Overview section in the Security chapter.

The Dell EMC Networking OS CLI is divided into three major mode levels:

• EXEC mode is the default mode and has a privilege level of 1, which is the most restricted level. Only a limited selection of commands
is available, notably the show commands, which allow you to view system information.

34 Configuration Fundamentals

• EXEC Privilege mode has commands to view configurations, clear counters, manage configuration files, run diagnostics, and enable or
disable debug operations. The privilege level is 15, which is unrestricted. You can configure a password for this mode; refer to the
Configure the Enable Password section in the Getting Started chapter.

• CONFIGURATION mode allows you to configure security features, time settings, set logging and SNMP functions, configure static
ARP and MAC addresses, and set line cards on the system.

Beneath CONFIGURATION mode are submodes that apply to interfaces, protocols, and features. The following example shows the
submode command structure. Two sub-CONFIGURATION modes are important when configuring the chassis for the first time:

• INTERFACE submode is the mode in which you configure Layer 2 and Layer 3 protocols and IP services specific to an interface. An
interface can be physical (Management interface, 1 Gigabit Ethernet, 10 Gigabit Ethernet, 25 Gigabit Ethernet, 40 Gigabit Ethernet, 50
Gigabit Ethernet, or 100 Gigabit Ethernet) or logical (Loopback, Null, port channel, or virtual local area network [VLAN]).

• LINE submode is the mode in which you to configure the console and virtual terminal lines.

NOTE: At any time, entering a question mark (?) displays the available command options. For example, when you are in

CONFIGURATION mode, entering the question mark first lists all available commands, including the possible submodes.

The CLI modes are:

EXEC
EXEC Privilege
CONFIGURATION
AS-PATH ACL
CONTROL-PLANE
CLASS-MAP
DCB POLICY
DHCP
DHCP POOL
ECMP-GROUP
EXTENDED COMMUNITY
FRRP
INTERFACE
GROUP
GIGABIT ETHERNET
10 GIGABIT ETHERNET
40 GIGABIT ETHERNET
INTERFACE RANGE
LOOPBACK
MANAGEMENT ETHERNET
NULL
PORT-CHANNEL
TUNNEL
VLAN
VRRP
IP
IPv6
IP COMMUNITY-LIST
IP ACCESS-LIST
STANDARD ACCESS-LIST
EXTENDED ACCESS-LIST
MAC ACCESS-LIST
LINE
AUXILLIARY
CONSOLE
VIRTUAL TERMINAL
LLDP
LLDP MANAGEMENT INTERFACE
MONITOR SESSION
MULTIPLE SPANNING TREE
OPENFLOW INSTANCE
PVST
PORT-CHANNEL FAILOVER-GROUP
PREFIX-LIST
PRIORITY-GROUP
PROTOCOL GVRP
QOS POLICY
RSTP
ROUTE-MAP
ROUTER BGP
BGP ADDRESS-FAMILY
ROUTER ISIS
ISIS ADDRESS-FAMILY

Configuration Fundamentals

35

ROUTER OSPF
ROUTER OSPFV3
ROUTER RIP
SPANNING TREE
SUPPORTASSIST
TRACE-LIST
VLT DOMAIN
VRRP
UPLINK STATE GROUP
uBoot

Navigating CLI Modes

The Dell EMC Networking OS prompt changes to indicate the CLI mode.

The following table lists the CLI mode, its prompt, and information about how to access and exit the CLI mode. Move linearly through the
command modes, except for the end command which takes you directly to EXEC Privilege mode and the exit command which moves
you up one command mode level.

NOTE: Sub-CONFIGURATION modes all have the letters conf in the prompt with more modifiers to identify the mode

and slot/port[/subport] information.

Table 1. Dell EMC Networking OS Command Modes

CLI Command Mode Prompt Access Command

EXEC

EXEC Privilege

DellEMC>

DellEMC#

Access the router through the console or
terminal line.

• From EXEC mode, enter the enable
command.

• From any other mode, use the end
command.

CONFIGURATION

NOTE: Access all of the following

modes from CONFIGURATION
mode.

AS-PATH ACL

10 Gigabit Ethernet Interface

40 Gigabit Ethernet Interface

Interface Group

Interface Range

Loopback Interface

Management Ethernet Interface

Null Interface

Port-channel Interface

Tunnel Interface

VLAN Interface

STANDARD ACCESS-LIST

DellEMC(conf)#

DellEMC(config-as-path)# ip as-path access-list

DellEMC(conf-if-te-1/1)#

DellEMC(conf-if-fo-1/52)#

DellEMC(conf-if-group)# interface(INTERFACE modes)

DellEMC(conf-if-range)#

DellEMC(conf-if-lo-0)#

DellEMC(conf-if-ma-1/1)#

DellEMC(conf-if-nu-0)#

DellEMC(conf-if-po-1)#

DellEMC(conf-if-tu-1)#

DellEMC(conf-if-vl-1)#

DellEMC(config-std-nacl)#

• From EXEC privilege mode, enter the
configure command.

• From every mode except EXEC and
EXEC Privilege, enter the exit
command.

interface (INTERFACE modes)

interface (INTERFACE modes)

interface (INTERFACE modes)

interface (INTERFACE modes)

interface (INTERFACE modes)

interface (INTERFACE modes)

interface (INTERFACE modes)

interface (INTERFACE modes)

interface (INTERFACE modes)

ip access-list standard (IP

ACCESS-LIST Modes)

36 Configuration Fundamentals

CLI Command Mode Prompt Access Command

EXTENDED ACCESS-LIST

IP COMMUNITY-LIST

AUXILIARY

CONSOLE

VIRTUAL TERMINAL

STANDARD ACCESS-LIST

EXTENDED ACCESS-LIST

MULTIPLE SPANNING TREE

Per-VLAN SPANNING TREE Plus

PREFIX-LIST

RAPID SPANNING TREE

REDIRECT

ROUTE-MAP

ROUTER BGP

BGP ADDRESS-FAMILY

DellEMC(config-ext-nacl)#

DellEMC(config-community-list)# ip community-list

DellEMC(config-line-aux)#

DellEMC(config-line-console)#

DellEMC(config-line-vty)#

DellEMC(config-std-macl)#

DellEMC(config-ext-macl)#

DellEMC(config-mstp)# protocol spanning-tree mstp

DellEMC(config-pvst)# protocol spanning-tree pvst

DellEMC(conf-nprefixl)# ip prefix-list

DellEMC(config-rstp)# protocol spanning-tree rstp

DellEMC(conf-redirect-list)# ip redirect-list

DellEMC(config-route-map)# route-map

DellEMC(conf-router_bgp)# router bgp

DellEMC(conf-router_bgp_af)#

(for IPv4)

DellEMC(conf-routerZ_bgpv6_af)#

(for IPv6)

ip access-list extended (IP
ACCESS-LIST Modes)

line (LINE Modes)

line (LINE Modes)

line (LINE Modes)

mac access-list standard (MAC

ACCESS-LIST Modes)

mac access-list extended (MAC
ACCESS-LIST Modes)

address-family {ipv4 multicast
| ipv6 unicast} (ROUTER BGP

Mode)

ROUTER ISIS

ISIS ADDRESS-FAMILY

ROUTER OSPF

ROUTER OSPFV3

ROUTER RIP

SPANNING TREE

TRACE-LIST

CLASS-MAP

CONTROL-PLANE

DHCP

DHCP POOL

ECMP

EIS

FRRP

LLDP DellEMC(conf-lldp)# or

LLDP MANAGEMENT INTERFACE

DellEMC(conf-router_isis)# router isis

DellEMC(conf-router_isis­af_ipv6)#

DellEMC(conf-router_ospf)# router ospf

DellEMC(conf-ipv6router_ospf)# ipv6 router ospf

DellEMC(conf-router_rip)# router rip

DellEMC(config-span)# protocol spanning-tree 0

DellEMC(conf-trace-acl)# ip trace-list

DellEMC(config-class-map)# class-map

DellEMC(conf-control-cpuqos)# control-plane-cpuqos

DellEMC(config-dhcp)# ip dhcp server

DellEMC(config-dhcp-pool-name)#

DellEMC(conf-ecmp-group-ecmp-
group-id)#

DellEMC(conf-mgmt-eis)# management egress-interface-

DellEMC(conf-frrp-ring-id)# protocol frrp

DellEMC(conf-if—interface­lldp)#

DellEMC(conf-lldp-mgmtIf)#

address-family ipv6 unicast

(ROUTER ISIS Mode)

pool (DHCP Mode)

ecmp-group

selection

protocol lldp (CONFIGURATION or

INTERFACE Modes)

management-interface (LLDP Mode)

LINE DellEMC(config-line-console) or

DellEMC(config-line-vty)

line console orline vty

Configuration Fundamentals 37

CLI Command Mode Prompt Access Command

MONITOR SESSION

OPENFLOW INSTANCE

PORT-CHANNEL FAILOVER-GROUP

PRIORITY GROUP

PROTOCOL GVRP

QOS POLICY

SUPPORTASSIST

VLT DOMAIN

VRRP

u-Boot

UPLINK STATE GROUP

DellEMC(conf-mon-sess­sessionID)#

DellEMC(conf-of-instance-of-
id)#

DellEMC(conf-po-failover-grp)# port-channel failover-group

DellEMC(conf-pg)# priority-group

DellEMC(config-gvrp)# protocol gvrp

DellEMC(conf-qos-policy-out­ets)#

DellEMC(support-assist)# support-assist

DellEMC(conf-vlt-domain)# vlt domain

DellEMC(conf-if-interface-type­slot/port-vrid-vrrp-group-id)#

Dell=>

DellEMC(conf-uplink-state­group-groupID)#

monitor session

openflow of-instance

qos-policy-output

vrrp-group

Press any key when the following line
appears on the console during a system
boot: Hit any key to stop

autoboot:

uplink-state-group

The following example shows how to change the command mode from CONFIGURATION mode to PROTOCOL SPANNING TREE.

Example of Changing Command Modes

DellEMC(conf)#protocol spanning-tree 0
DellEMC(config-span)#

The do Command

You can enter an EXEC mode command from any CONFIGURATION mode (CONFIGURATION, INTERFACE, SPANNING TREE, and so
on.) without having to return to EXEC mode by preceding the EXEC mode command with the do command.

The following example shows the output of the do command.

DellEMC(conf)#do show system brief

Stack MAC : 34:17:eb:f2:c2:c4
Reload-Type : normal-reload [Next boot : normal-reload]

-- Stack Info -­Unit UnitType Status ReqTyp CurTyp Version Ports

-----------------------------------------------------------------------­ 1 Management online S4048-ON S4048-ON 1-0(0-3932) 72
2 Member not present
3 Member not present
4 Member not present
5 Member not present
6 Member not present

-- Power Supplies -­Unit Bay Status Type FanStatus FanSpeed(rpm)

--------------------------------------------------------------­ 1 1 up AC absent 0
1 2 absent absent 0

-- Fan Status -­Unit Bay TrayStatus Fan0 Speed Fan1 Speed

------------------------------------------------------------------­ 1 1 up up 0 up 0

38

Configuration Fundamentals

1 2 up up 0 up 0
1 3 up up 0 up 0

Speed in RPM

Undoing Commands

When you enter a command, the command line is added to the running configuration file (running-config).

To disable a command and remove it from the running-config, enter the no command, then the original command. For example, to delete
an IP address configured on an interface, use the no ip address ip-address command.

NOTE: Use the help or ? command as described in Obtaining Help.

Example of Viewing Disabled Commands

DellEMC(conf)#interface tengigabitethernet 2/17
DellEMC(conf-if-te-2/17)#ip address 192.168.10.1/24
DellEMC(conf-if-te-2/17)#show config
!
interface TenGigabitEthernet 2/17
ip address 192.168.10.1/24
no shutdown
DellEMC(conf-if-te-2/17)#no ip address
DellEMC(conf-if-te-2/17)#show config
!
interface TenGigabitEthernet 2/17
no ip address
no shutdown

Layer 2 protocols are disabled by default. To enable Layer 2 protocols, use the no disable command. For example, in PROTOCOL
SPANNING TREE mode, enter

no disable to enable Spanning Tree.

Obtaining Help

Obtain a list of keywords and a brief functional description of those keywords at any CLI mode using the ? or help command:

• To list the keywords available in the current mode, enter ? at the prompt or after a keyword.

• Enter ? after a command prompt to list all of the available keywords. The output of this command is the same as the help command.

DellEMC#?
bmp BMP commands
cd Change current directory
clear Reset functions
clock Manage the system clock

• Enter ? after a partial keyword lists all of the keywords that begin with the specified letters.

DellEMC(conf)#cl?
class-map
clock
DellEMC(conf)#cl

• Enter [space]? after a keyword lists all of the keywords that can follow the specified keyword.

DellEMC(conf)#clock ?
summer-time Configure summer (daylight savings) time
timezone Configure time zone
DellEMC(conf)#clock

Entering and Editing Commands

Notes for entering commands.

• The CLI is not case-sensitive.

• You can enter partial CLI keywords.

Configuration Fundamentals

39

• Enter the minimum number of letters to uniquely identify a command. For example, you cannot enter cl as a partial keyword
because both the clock and class-map commands begin with the letters “cl.” You can enter clo, however, as a partial
keyword because only one command begins with those three letters.

• The TAB key auto-completes keywords in commands. Enter the minimum number of letters to uniquely identify a command.

• The UP and DOWN arrow keys display previously entered commands (refer to Command History).

• The BACKSPACE and DELETE keys erase the previous letter.

• Key combinations are available to move quickly across the command line. The following table describes these short-cut key
combinations.

Short-Cut Key

Action

Combination

CNTL-A Moves the cursor to the beginning of the command line.

CNTL-B Moves the cursor back one character.

CNTL-D Deletes character at cursor.

CNTL-E Moves the cursor to the end of the line.

CNTL-F Moves the cursor forward one character.

CNTL-I Completes a keyword.

CNTL-K Deletes all characters from the cursor to the end of the command line.

CNTL-L Re-enters the previous command.

CNTL-N Return to more recent commands in the history buffer after recalling commands with CTRL-P or the UP arrow

key.

CNTL-P Recalls commands, beginning with the last command.

CNTL-R Re-enters the previous command.

CNTL-U Deletes the line.

CNTL-W Deletes the previous word.

CNTL-X Deletes the line.

CNTL-Z Ends continuous scrolling of command outputs.

Esc B Moves the cursor back one word.

Esc F Moves the cursor forward one word.

Esc D Deletes all characters from the cursor to the end of the word.

Command History

The Dell EMC Networking OS maintains a history of previously-entered commands for each mode. For example:

• When you are in EXEC mode, the UP and DOWN arrow keys display the previously-entered EXEC mode commands.

• When you are in CONFIGURATION mode, the UP or DOWN arrows keys recall the previously-entered CONFIGURATION mode
commands.

Filtering show Command Outputs

Filter the output of a show command to display specific information by adding | [except | find | grep | no-more | save]
specified_text after the command.

The variable specified_text is the text for which you are filtering and it IS case sensitive unless you use the ignore-case sub­option.

Starting with Dell EMC Networking OS version 7.8.1.0, the grep command accepts an ignore-case sub-option that forces the search
to case-insensitive. For example, the commands:

• show run | grep Ethernet returns a search result with instances containing a capitalized “Ethernet,” such as interface
TenGigabitEthernet.

40

Configuration Fundamentals

• show run | grep ethernet does not return that search result because it only searches for instances containing a non­capitalized “ethernet.”

• show run | grep Ethernet ignore-case returns instances containing both “Ethernet” and “ethernet.”

The grep command displays only the lines containing specified text. The following example shows this command used in combination with

show system brief command.

the

Example of the grep Keyword

DellEMC(conf)#do show system brief | grep 0
0 not present

NOTE: Dell EMC Networking OS accepts a space or no space before and after the pipe. To filter a phrase with spaces,

underscores, or ranges, enclose the phrase with double quotation marks.

The except keyword displays text that does not match the specified text. The following example shows this command used in
combination with the show system brief command.

Example of the except Keyword

DellEMC#show system brief | except 1

Stack MAC : 4c:76:25:e5:49:40
Reload-Type : normal-reload [Next boot : normal-reload]

The find keyword displays the output of the show command beginning from the first occurrence of specified text. The following
example shows this command used in combination with the

Example of the find Keyword

The display command displays additional configuration information.

The no-more command displays the output all at once rather than one screen at a time. This is similar to the terminal length
command except that the no-more option affects the output of the specified command only.

The save command copies the output to a file for future reference.

show system brief command.

NOTE:

example: DellEMC# command | grep regular-expression | except regular-expression | grep other-
regular-expression | find regular-expression | save.

You can filter a single command output multiple times. The save option must be the last option entered. For

Multiple Users in Configuration Mode

Dell EMC Networking OS notifies all users when there are multiple users logged in to CONFIGURATION mode.

A warning message indicates the username, type of connection (console or VTY), and in the case of a VTY connection, the IP address of
the terminal on which the connection was established. For example:

• On the system that telnets into the switch, this message appears:

% Warning: The following users are currently configuring the system:
User "<username>" on line console0

• On the system that is connected over the console, this message appears:

% Warning: User "<username>" on line vty0 "10.11.130.2" is in configuration mode

If either of these messages appears, Dell EMC Networking recommends coordinating with the users listed in the message so that you do
not unintentionally overwrite each other’s configuration changes.

Configuration Fundamentals

41

Getting Started

This chapter describes how you start configuring your system.

When you power up the chassis, the system performs a power-on self test (POST) and system then loads the Dell EMC Networking
Operating System. Boot messages scroll up the terminal window during this process. No user interaction is required if the boot process
proceeds without interruption.

When the boot process completes, the system status LEDs remain online (green) and the console monitor displays the EXEC mode
prompt.

For details about using the command line interface (CLI), refer to the Accessing the Command Line section in the Configuration

Fundamentals chapter.

Topics:

• Console Access

• Accessing the CLI Interface and Running Scripts Using SSH

• Default Configuration

• Configuring a Host Name

• Accessing the System Remotely

• Configuring the Enable Password

• Configuration File Management

• Managing the File System

• Enabling Software Features on Devices Using a Command Option

• View Command History

• Upgrading Dell EMC Networking OS

• Verify Software Images Before Installation

• Using HTTP for File Transfers

3

Console Access

The device has one RJ-45/RS-232 console port, an out-of-band (OOB) Ethernet port, and a micro USB-B console port.

Serial Console

The RJ-45/RS-232 console port is labeled on the upper right-hand side, as you face the PSU side of the chassis.

Figure 1. RJ-45 Console Port

1. RJ-45 management Ethernet port.

2. RS-232 console port.

42 Getting Started

Accessing the Console Port

To access the console port, follow these steps:

For the console port pinout, refer to Accessing the RJ-45 Console Port with a DB-9 Adapter.

1. Install an RJ-45 copper cable into the console port. Use a rollover (crossover) cable to connect the console port to a terminal server.

2. Connect the other end of the cable to the DTE terminal server.

3. Terminal settings on the console port cannot be changed in the software and are set as follows:

• 115200 baud rate

• No parity

• 8 data bits

• 1 stop bit

• No flow control

Pin Assignments

You can connect to the console using a RJ-45 to RJ-45 rollover cable and a RJ-45 to DB-9 female DTE adapter to a terminal server (for
example, a PC).

The pin assignments between the console and a DTE terminal server are as follows:

Table 2. Pin Assignments Between the Console and a DTE Terminal Server

Console Port RJ-45 to RJ-45

Rollover Cable

Signal RJ-45 Pinout RJ-45 Pinout DB-9 Pin Signal

RTS 1 8 8 CTS

NC 2 7 6 DSR

TxD 3 6 2 RxD

GND 4 5 5 GND

GND 5 4 5 GND

RxD 6 3 3 TxD

NC 7 2 4 DTR

CTS 8 1 7 RTS

RJ-45 to RJ-45
Rollover Cable

RJ-45 to DB-9 Adapter Terminal Server Device

Accessing the CLI Interface and Running Scripts Using SSH

In addition to the capability to access a device using a console connection or a Telnet session, you can also use SSH for secure, protected
communication with the device. You can open an SSH session and run commands or script files. This method of connectivity is supported
with S4810, S4048–ON, S3048–ON, S4820T, and Z9000 switches and provides a reliable, safe communication mechanism.

Entering CLI commands Using an SSH Connection

You can run CLI commands by entering any one of the following syntax to connect to a switch using the preconfigured user credentials
using SSH:

ssh username@hostname <CLI Command>

or

echo <CLI Command> | ssh admin@hostname

The SSH server transmits the terminal commands to the CLI shell and the results are displayed on the screen non-interactively.

Getting Started

43

Executing Local CLI Scripts Using an SSH Connection

You can execute CLI commands by entering a CLI script in one of the following ways:

ssh username@hostname <CLIscript.file>

or

cat < CLIscript.file > | ssh admin@hostname

The script is run and the actions contained in the script are performed.

Following are the points to remember, when you are trying to establish an SSH session to the device to run commands or script files:

• There is an upper limit of 10 concurrent sessions in SSH. Therefore, you might expect a failure in executing SSH-related scripts.

• To avoid denial of service (DoS) attacks, a rate-limit of 10 concurrent sessions per minute in SSH is devised. Therefore, you might
experience a failure in executing SSH-related scripts when multiple short SSH commands are executed.

• If you issue an interactive command in the SSH session, the behavior may not really be interactive.

• In some cases, when you use an SSH session, when certain show commands such as show tech-support produce large volumes
of output, sometimes few characters from the output display are truncated and not displayed. This may cause one of the commands
to fail for syntax error. In such cases, if you add few newline characters before the failed command, the output displays completely.

Execution of commands on CLI over SSH does not notice the errors that have occurred while executing the command. As a result, you
cannot identify, whether a command has failed to be processed. The console output though is redirected back over SSH.

Default Configuration

Although a version of Dell EMC Networking OS is pre-loaded onto the system, the system is not configured when you power up the
system first time (except for the default hostname, which is DellEMC). You must configure the system using the CLI.

Configuring a Host Name

The host name appears in the prompt. The default host name is DellEMC.

• Host names must start with a letter and end with a letter or digit.

• Characters within the string can be letters, digits, and hyphens.

To create a host name, use the hostname name command in Configuration mode.

DellEMC(conf)#hostname R1
R1(conf)#

Accessing the System Remotely

You can configure the system to access it remotely by Telnet or secure shell (SSH).

• The platform has a dedicated management port and a management routing table that is separate from the IP routing table.

• You can manage all Dell EMC Networking products in-band via the front-end data ports through interfaces assigned an IP address as
well.

Accessing the System Remotely

Configuring the system for remote access is a three-step process, as described in the following topics:

1. Configure an IP address for the management port. Configure the Management Port IP Address

2. Configure a management route with a default gateway. Configure a Management Route

3. Configure a username and password. Configure a Username and Password

Configure the Management Port IP Address

To access the system remotely, assign IP addresses to the management ports.

1. Enter INTERFACE mode for the Management port.

44

Getting Started

CONFIGURATION mode

interface ManagementEthernet slot/port

2. Assign an IP address to the interface.
INTERFACE mode

ip address ip-address/mask

• ip-address: an address in dotted-decimal format (A.B.C.D).

• mask: a subnet mask in /prefix-length format (/ xx).

3. Enable the interface.
INTERFACE mode

no shutdown

Configure a Management Route

Define a path from the system to the network from which you are accessing the system remotely. Management routes are separate from
IP routes and are only used to manage the system through the management port.

To configure a management route, use the following command.

• Configure a management route to the network from which you are accessing the system.
CONFIGURATION mode

management route ip-address/mask gateway

• ip-address: the network address in dotted-decimal format (A.B.C.D).

• mask: a subnet mask in /prefix-length format (/ xx).

• gateway: the next hop for network traffic originating from the management port.

Configuring a Username and Password

To access the system remotely, configure a system username and password.

To configure a system username and password, use the following command.

• Configure a username and password to access the system remotely.
CONFIGURATION mode

username name [access-class access-list-name] [nopassword | {password | secret | sha256–
password} [encryption-type] password [dynamic-salt]] [privilege level] [role role-name]

• name: Enter a text string upto 63 characters long.

• access-class access-list-name: Enter the name of a configured IP ACL.

• nopassword: Allows you to configure an user without the password.

• password: Allows you to configure an user with a password.

• secret: Specify a secret string for an user.

• sha256–password: Uses sha256–based encryption method for password.

• encryption-type: Enter the encryption type for securing an user password. There are four encryption types.

• 0 — input the password in clear text.

• 5 — input the password that is already encrypted using MD5 encryption method.

• 7 — input the password that is already encrypted using DES encryption method.

• 8 — input the password that is already encrypted using sha256–based encryption method.

• password: Enter the password string for the user.

• dynamic-salt: Generates an additional random input to password encryption process whenever the password is configured.

• privilege level: Assign a privilege levels to the user. The range is from 0 to 15.

• role role-name: Assign a role name for the user.

Dell EMC Networking OS encrypts type 5 secret and type 7 password based on dynamic-salt option such that the encrypted
password is different when an user is configured with the same password.

NOTE:

dynamic-salt option is shown only with secret and password options.

Getting Started 45

In dynamic-salt configuration, the length of type 5 secret and type 7 password is 32 and 16 characters more compared to the
secret and password length without dynamic-salt configuration. An error message appears if the username command reaches the
maximum length, which is 256 characters.

The dynamic-salt support for the user configuration is added in REST API. For more information on REST support, see Dell EMC
Networking Open Automation guide.

Configuring the Enable Password

Access EXEC Privilege mode using the enable command. EXEC Privilege mode is unrestricted by default. Configure a password as a
basic security measure.

There are three types of enable passwords:

• enable password is stored in the running/startup configuration using a DES encryption method.

• enable secret is stored in the running/startup configuration using MD5 encryption method.

• enable sha256-password is stored in the running/startup configuration using sha256-based encryption method (PBKDF2).

Dell EMC Networking recommends using the enable sha256-password password.

To configure an enable password, use the following command.

• Create a password to access EXEC Privilege mode.
CONFIGURATION mode

enable [password | secret | sha256-password] [level level] [encryption-type] password

• level: is the privilege level, is 15 by default, and is not required.

• encryption-type: specifies how you input the password, is 0 by default, and is not required.

• 0 is to input the password in clear text.

• 5 is to input a password that is already encrypted using MD5 encryption method. Obtain the encrypted password from the
configuration file of another device.

• 7 is to input a password that is already encrypted using DES encryption method. Obtain the encrypted password from the
configuration file of another device.

• 8 is to input a password that is already encrypted using sha256-based encryption method. Obtain the encrypted password
from the configuration file of another device.

Configuration File Management

Files can be stored on and accessed from various storage media. Rename, delete, and copy files on the system from EXEC Privilege mode.

Copy Files to and from the System

The command syntax for copying files is similar to UNIX. The copy command uses the format copy source-file-url
destination-file-url.

NOTE:

• To copy a local file to a remote system, combine the file-origin syntax for a local file location with the file-destination syntax for a
remote file location.

• To copy a remote file to Dell EMC Networking system, combine the file-origin syntax for a remote file location with the file-destination
syntax for a local file location.

Table 3. Forming a

Location

For a remote file location:

FTP server

For a remote file location:

TFTP server

For a detailed description of the copy command, refer to the

copy Command

source-file-url

copy ftp://
username:password@{hostip |
hostname}/filepath/filename

copy tftp://{hostip |
hostname}/filepath/ filename

Syntax

Dell EMC Networking OS Command Reference

destination-file-url

ftp://username:password@{hostip
| hostname}/ filepath/filename

tftp://{hostip | hostname}/
filepath/filename

Syntax

.

46 Getting Started

Location

For a remote file location:

SCP server

source-file-url

copy scp://{hostip | hostname}/
filepath/ filename

Syntax

destination-file-url

scp://{hostip | hostname}/
filepath/filename

Important Points to Remember

• You may not copy a file from one remote system to another.

• You may not copy a file from one location to the same location.

• When copying to a server, you can only use a hostname if a domain name server (DNS) server is configured.

Example of Copying a File to an FTP Server

DellEMC#copy flash://Dell-EF-8.2.1.0.bin ftp://myusername:mypassword@10.10.10.10/
/Dell/Dell-EF-8.2.1.0
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
27952672 bytes successfully copied

Example of Importing a File to the Local System

core1#$//copy ftp://myusername:mypassword@10.10.10.10//Dell/
Dell-EF-8.2.1.0.bin flash://
Destination file name [Dell-EF-8.2.1.0.bin.bin]:
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
26292881 bytes successfully copied

Syntax

Mounting an NFS File System

This feature enables you to quickly access data on an NFS mounted file system. You can perform file operations on an NFS mounted file
system using supported file commands.

This feature allows an NFS mounted device to be recognized as a file system. This file system is visible on the device and you can execute
all file commands that are available on conventional file systems such as a Flash file system.

Before executing any CLI command to perform file operations, you must first mount the NFS file system to a mount-point on the device.
Since multiple mount-points exist on a device, it is mandatory to specify the mount-point to which you want to load the system.
The /f10/mnt/nfs directory is the root of all mount-points.

To mount an NFS file system, perform the following steps:

Table 4. Mounting an NFS File System

File Operation Syntax

To mount an NFS file system:

The foreign file system remains mounted as long as the device is up and does not reboot. You can run the file system commands without
having to mount or un-mount the file system each time you run a command. When you save the configuration using the
the

mount command is saved to the startup configuration. As a result, each time the device re-boots, the NFS file system is mounted

during start up.

Table 5. Forming a

Location

For a remote file location:

NFS File System

copy Command

mount nfs rhost:path mount­point username password

source-file-url

copy nfsmount://{<mount­point>}/filepath/filename}
username:password

Syntax

write command,

destination-file-url

tftp://{hostip | hostname}/
filepath/filename

Syntax

Important Points to Remember

• You cannot copy a file from one remote system to another.

• You cannot copy a file from one location to the same location.

• When copying to a server, you can only use a hostname if a domain name server (DNS) server is configured.

Getting Started

47

Example of Copying a File to current File System

DellEMC#copy tftp://10.16.127.35/dv-maa-test nfsmount://
Destination file name [dv-maa-test]:
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!.!
44250499 bytes successfully copied
DellEMC#
DellEMC#copy ftp://10.16.127.35 nfsmount:
Source file name []: test.c
User name to login remote host: username

Example of Logging in to Copy from NFS Mount

DellEMC#copy nfsmount:///test flash:
Destination file name [test]: test2
!
5592 bytes successfully copied
DellEMC#
DellEMC#copy nfsmount:///test.txt ftp://10.16.127.35
Destination file name [test.txt]:
User name to login remote host: username
Password to login remote host:
!

Example of Copying to NFS Mount

DellEMC#copy flash://test.txt nfsmount:///
Destination file name [test.txt]:
!
15 bytes successfully copied
DellEMC#copy flash://test/capture.txt.pcap nfsmount:///
Destination file name [test.txt]:
!
15 bytes successfully copied
DellEMC#copy flash://test/capture.txt.pcap nfsmount:///username/snoop.pcap
!
24 bytes successfully copied
DellEMC#
DellEMC#copy tftp://10.16.127.35/username/dv-maa-test ?
flash: Copy to local file system ([flash://]filepath)
nfsmount: Copy to nfs mount file system (nfsmount:///filepath)
running-config remote host:
Destination file name [test.c]:
!
225 bytes successfully copied
DellEMC#

Save the Running-Configuration

The running-configuration contains the current system configuration. Dell EMC Networking recommends coping your running­configuration to the startup-configuration.

The commands in this section follow the same format as those commands in the Copy Files to and from the System section but use the
filenames startup-configuration and running-configuration. These commands assume that current directory is the internal flash, which is
the system default.

• Save the running-configuration to the startup-configuration on the internal flash of the primary RPM.
EXEC Privilege mode

copy running-config startup-config

• Save the running-configuration to an FTP server.
EXEC Privilege mode

copy running-config ftp:// username:password@{hostip | hostname}/filepath/ filename

• Save the running-configuration to a TFTP server.
EXEC Privilege mode

copy running-config tftp://{hostip | hostname}/ filepath/filename

48

Getting Started

• Save the running-configuration to an SCP server.
EXEC Privilege mode

copy running-config scp://{hostip | hostname}/ filepath/filename

NOTE: When copying to a server, a host name can only be used if a DNS server is configured.

NOTE: When you load the startup configuration or a configuration file from a network server such as TFTP to the

running configuration, the configuration is added to the running configuration. This does not replace the existing
running configuration. Commands in the configuration file has precedence over commands in the running configuration.

Configure the Overload Bit for a Startup Scenario

For information about setting the router overload bit for a specific period of time after a switch reload is implemented, see the
Intermediate System to Intermediate System (IS-IS) section in the Dell Command Line Reference Guide for your system.

Viewing Files

You can only view file information and content on local file systems.

To view a list of files or the contents of a file, use the following commands.

• View a list of files on the internal flash.
EXEC Privilege mode

dir flash:

• View the running-configuration.
EXEC Privilege mode

show running-config

• View the startup-configuration.
EXEC Privilege mode

show startup-config

The output of the dir command also shows the read/write privileges, size (in bytes), and date of modification for each file.

DellEMC#dir
Directory of flash:

1 drw- 32768 Jan 01 1980 00:00:00 .
2 drwx 512 Jul 23 2007 00:38:44 ..
3 drw- 8192 Mar 30 1919 10:31:04 TRACE_LOG_DIR
4 drw- 8192 Mar 30 1919 10:31:04 CRASH_LOG_DIR
5 drw- 8192 Mar 30 1919 10:31:04 NVTRACE_LOG_DIR
6 drw- 8192 Mar 30 1919 10:31:04 CORE_DUMP_DIR
7 d--- 8192 Mar 30 1919 10:31:04 ADMIN_DIR
8 -rw- 33059550 Jul 11 2007 17:49:46 FTOS-EF-7.4.2.0.bin
9 -rw- 27674906 Jul 06 2007 00:20:24 FTOS-EF-4.7.4.302.bin
10 -rw- 27674906 Jul 06 2007 19:54:52 boot-image-FILE
11 drw- 8192 Jan 01 1980 00:18:28 diag
12 -rw- 7276 Jul 20 2007 01:52:40 startup-config.bak
13 -rw- 7341 Jul 20 2007 15:34:46 startup-config
14 -rw- 27674906 Jul 06 2007 19:52:22 boot-image
15 -rw- 27674906 Jul 06 2007 02:23:22 boot-flash

--More--

View Configuration Files

Configuration files have three commented lines at the beginning of the file, as shown in the following example, to help you track the last
time any user made a change to the file, which user made the changes, and when the file was last saved to the startup-configuration.

In the running-configuration file, if there is a difference between the timestamp on the “Last configuration change” and “Startup-config
last updated,” you have made changes that have not been saved and are preserved after a system reboot.

Getting Started

49

Example of the show running-config Command

DellEMC#show running-config
Current Configuration ...
! Version 9.4(0.0)
! Last configuration change at Tue Mar 11 21:33:56 2014 by admin
! Startup-config last updated at Tue Mar 11 12:11:00 2014 by default
!
<output truncated for brevity>

Compressing Configuration Files

You can optimize and reduce the sizes of the configuration files.

You can compress the running configuration by grouping all the VLANs and the physical interfaces with the same property. Support to
store the operating configuration to the startup config in the compressed mode and to perform an image downgrade without any
configuration loss are provided.

You can create groups of VLANs using the interface group command. This command will create nonexistent VLANs specified in a
range. On successful command execution, the CLI switches to the interface group context. The configuration commands inside the group
context will be the similar to that of the existing range command.

Two existing exec mode CLIs are enhanced to display and store the running configuration in the compressed mode.

show running-config compressed and write memory compressed

The compressed configuration will group all the similar looking configuration thereby reducing the size of the configuration. For this
release, the compression will be done only for interface related configuration (VLAN & physical interfaces)

The following table describes how the standard and the compressed configuration differ:

Table 6. Standard and Compressed Configurations

Uncompressed Compressed

DellEMC# show running-config

<snip>

!

interface TenGigabitEthernet 1/1

no ip address

switchport

shutdown

!

interface TenGigabitEthernet 1/2

no ip address

shutdown

!

interface TenGigabitEthernet 1/3

no ip address

shutdown

!

interface TenGigabitEthernet 1/4

no ip address

shutdown

!

interface TenGigabitEthernet 1/10

no ip address

DellEMC# show running-config compressed

<snip>

!

interface TenGigabitEthernet 1/1

no ip address

switchport

shutdown

!

Interface group TenGigabitEthernet 1/2 – 4 , TenGigabitEthernet
1/10

no ip address

shutdown

!

interface TenGigabitEthernet 1/34

ip address 2.1.1.1/16

shutdown

!

interface group Vlan 2 , Vlan 100

no ip address

no shutdown

!

interface group Vlan 3 – 5

50

Getting Started

Uncompressed Compressed

shutdown

!

interface TenGigabitEthernet 1/34

ip address 2.1.1.1/16

shutdown

!

interface Vlan 2

no ip address

no shutdown

!

interface Vlan 3

tagged te 1/1

no ip address

shutdown

!

interface Vlan 4

tagged te 1/1

no ip address

shutdown

!

interface Vlan 5

tagged te 1/1

no ip address

shutdown

!

interface Vlan 100

no ip address

no shutdown

!

interface Vlan 1000

ip address 1.1.1.1/16

no shutdown

Uncompressed config size – 52 lines

tagged te 1/1

no ip address

shutdown

!

interface Vlan 1000

ip address 1.1.1.1/16

no shutdown

!

<snip>

Compressed config size – 27 lines.

write memory compressed

The write memory compressed CLI will write the operating configuration to the startup-config file in the compressed mode. In stacking
scenario, it will also take care of syncing it to all the standby and member units.

The following is the sample output:

DellEMC#write memory compressed
!
Jul 30 08:50:26: %STKUNIT0-M:CP %FILEMGR-5-FILESAVED: Copied running-config to startup-config
in flash by default

Getting Started

51

copy compressed-config

Copy one file, after optimizing and reducing the size of the configuration file, to another location. Dell EMC Networking OS supports IPv4
and IPv6 addressing for FTP, TFTP, and SCP (in the hostip field).

Managing the File System

The Dell EMC Networking system can use the internal Flash, external Flash, or remote devices to store files.

The system stores files on the internal Flash by default but can be configured to store files elsewhere.

To view file system information, use the following command.

• View information about each file system.

EXEC Privilege mode

show file-systems

The output of the show file-systems command in the following example shows the total capacity, amount of free memory, file
structure, media type, read/write privileges for each storage device in use.

DellEMC#show file-systems
Size(b) Free(b) Feature Type Flags Prefixes
520962048 213778432 dosFs2.0 USERFLASH rw flash:
127772672 21936128 dosFs2.0 USERFLASH rw slot0:

- - - network rw ftp:

- - - network rw tftp:

- - - network rw scp:

You can change the default file system so that file management commands apply to a particular device or memory.

To change the default directory, use the following command.

• Change the default directory.

EXEC Privilege mode

cd directory

Enabling Software Features on Devices Using a Command Option

The capability to activate software applications or components on a device using a command is supported on this platform.

Starting with Release 9.4(0.0), you can enable or disable specific software features or applications that need to run on a device by using a
command attribute in the CLI interface. This enables effective, streamlined management and administration of applications and utilities
that run on a device. You can employ this capability to perform an on-demand activation, or turn-off a software component or protocol. A
feature configuration file generated for each image contains feature names, and denotes if this enabling or disabling method is available.
You can enable or disable the VRF application globally across the system by using this capability.

Activate the VRF application on a device by using the feature vrf command in CONFIGURATION mode.

NOTE: The no feature vrf command is not supported on any of the platforms.

To enable the VRF feature and cause all VRF-related commands to be available or viewable in the CLI interface, use the following
command. You must enable the VRF feature before you can configure its related attributes.

DellEMC(conf)# feature vrf

Based on if the VRF feature is identified as supported in the Feature Configuration file, configuration command feature vrf becomes
available for usage. This command is stored in the running-configuration and precedes all other VRF-related configurations.

To display the state of Dell EMC Networking OS features:

DellEMC# show feature

Example of show feature output

52

Getting Started

For a particular target where VRF is enabled, the show output is similar to the following:

Feature State

-----------------------­VRF Enabled

View Command History

The command-history trace feature captures all commands entered by all users of the system with a time stamp and writes these
messages to a dedicated trace log buffer.

The system generates a trace message for each executed command. No password information is saved to the file.

NOTE:

The timestamps display format of the show command history output changes based on the service timestamps
log datetime configuration. The time format can be in uptime, local time zone time or UTC time.

If timestamp is disabled (no service timestamps log) then command history time format is shown with timestamp
defaults (service timestamps log datetime localtime).

To view the command-history trace, use the show command-history command.

Example of the show command-history Command

Example 1: Default configuration service timestamps log datetime or service timestamps log datetime

localtime

DellEMC(conf)#service timestamps log datetime

DellEMC# show command-history

- Repeated 1 time.
[May 17 15:38:55]: CMD-(CLI):[service timestamps log datetime]by default from console
[May 17 15:41:40]: CMD-(CLI):[write memory]by default from console

- Repeated 1 time.
[May 17 15:41:45]: CMD-(CLI):[interface tengigabitethernet 1/1]by default from console
[May 17 15:41:47]: CMD-(CLI):[shutdown]by default from console
[May 17 15:41:50]: CMD-(CLI):[no shutdown]by default from console
[May 17 15:42:42]: CMD-(CLI):[show clock]by default from console
[May 17 15:42:52]: CMD-(CLI):[write memory]by default from console

- Repeated 1 time.
[May 17 15:43:08]: CMD-(CLI):[end]by default from console
[May 17 15:43:16]: CMD-(CLI):[show logging]by default from console
[May 17 15:43:22]: CMD-(CLI):[show command-history]by default from console
DellEMC#

Example 2: service timestamps log datetime utc

DellEMC(conf)#service timestamps log datetime utc

DellEMC# show command-history

- Repeated 1 time.
[May 17 15:46:44]: CMD-(CLI):[configure]by default from console

- Repeated 1 time.
[May 17 10:16:53]: CMD-(CLI):[service timestamps log datetime utc]by default from console
[May 17 10:17:05]: CMD-(CLI):[show clock]by default from console
[May 17 10:17:20]: CMD-(CLI):[show running-config]by default from console
[May 17 10:17:30]: CMD-(CLI):[interface tengigabitethernet 1/2]by default from console
[May 17 10:17:32]: CMD-(CLI):[shutdown]by default from console
[May 17 10:17:34]: CMD-(CLI):[no shutdown]by default from console
[May 17 10:17:40]: CMD-(CLI):[write memory]by default from console

- Repeated 1 time.
[May 17 10:17:46]: CMD-(CLI):[end]by default from console
[May 17 10:17:50]: CMD-(CLI):[show logging]by default from console
[May 17 10:17:56]: CMD-(CLI):[show command-history]by default from console

Example 3: service timestamps log uptime

Getting Started

53

DellEMC(conf)#service timestamps log uptime

DellEMC# show command-history

- Repeated 1 time.
[May 17 10:20:37]: CMD-(CLI):[configure]by default from console

- Repeated 1 time.
[1d0h24m]: CMD-(CLI):[service timestamps log uptime]by default from console
[1d0h24m]: CMD-(CLI):[interface tengigabitethernet 1/1]by default from console
[1d0h24m]: CMD-(CLI):[shutdown]by default from console
[1d0h24m]: CMD-(CLI):[no shutdown]by default from console
[1d0h25m]: CMD-(CLI):[end]by default from console
[1d0h25m]: CMD-(CLI):[write memory]by default from console

- Repeated 1 time.
[1d0h25m]: CMD-(CLI):[show clock]by default from console
[1d0h25m]: CMD-(CLI):[show version]by default from console
[1d0h25m]: CMD-(CLI):[show logging]by default from console
[1d0h25m]: CMD-(CLI):[show command-history]by default from console

Example 4: no service timestamps log

DellEMC(conf)#no service timestamps log

DellEMC# show command-history

- Repeated 1 time.
[1d0h26m]: CMD-(CLI):[configure]by default from console

- Repeated 1 time.
[May 17 15:53:10]: CMD-(CLI):[no service timestamps log]by default from console
[May 17 15:53:16]: CMD-(CLI):[write memory]by default from console

- Repeated 3 times.
[May 17 15:53:22]: CMD-(CLI):[show logging]by default from console

- Repeated 1 time.
[May 17 15:53:36]: CMD-(CLI):[write memory]by default from console

- Repeated 5 times.
[May 17 15:53:44]: CMD-(CLI):[show logging]by default from console
[May 17 15:53:53]: CMD-(CLI):[show command-history]by default from console
[May 17 15:54:54]: CMD-(CLI):[end]by default from console
[May 17 15:55:00]: CMD-(CLI):[show logging]by default from console
[May 17 15:55:12]: CMD-(CLI):[show clock]by default from console
[May 17 15:55:22]: CMD-(CLI):[show running-config]by default from console
[May 17 15:55:27]: CMD-(CLI):[show command-history]by default from console

Upgrading Dell EMC Networking OS

To upgrade Dell EMC Networking Operating System (OS), refer to the Release Notes for the version you want to load on the system.

You can download the release notes of your platform at https://www.force10networks.com. Use your login ID to log in to the website.

Verify Software Images Before Installation

To validate the software image on the flash drive, you can use the MD5 message-digest algorithm or SHA256 Secure Hash Algorithm,
after the image is transferred to the system but before the image is installed. The validation calculates a hash value of the downloaded
image file on system’s flash drive, and, optionally, compares it to a Dell EMC Networking published hash for that file.

The MD5 or SHA256 hash provides a method of validating that you have downloaded the original software. Calculating the hash on the
local image file and comparing the result to the hash published for that file on iSupport provides a high level of confidence that the local
copy is exactly the same as the published software image. This validation procedure, and the verify {md5 | sha256} command to
support it, prevents the installation of corrupted or modified images.

The verify {md5 | sha256} command calculates and displays the hash of any file on the specified local flash drive. You can
compare the displayed hash against the appropriate hash published on iSupport. Optionally, you can include the published hash in the
verify {md5 | sha256} command, which displays whether it matches the calculated hash of the indicated file.

To validate a software image:

1. Download Dell EMC Networking OS software image file from the iSupport page to the local (FTP or TFTP) server. The published hash
for that file displays next to the software image file on the iSupport page.

2. Go on to the Dell EMC Networking system and copy the software image to the flash drive, using the copy command.

54

Getting Started

3. Run the verify {md5 | sha256} [ flash://]img-file [hash-value] command. For example, verify sha256
flash://FTOS-SE-9.5.0.0.bin

4. Compare the generated hash value to the expected hash value published on the iSupport page.

To validate the software image on the flash drive after the image is transferred to the system, but before you install the image, use the
verify {md5 | sha256} [ flash://]img-file [hash-value] command in EXEC mode.

• md5: MD5 message-digest algorithm

• sha256: SHA256 Secure Hash Algorithm

• flash: (Optional) Specifies the flash drive. The default uses the flash drive. You can enter the image file name.

• hash-value: (Optional). Specify the relevant hash published on iSupport.

• img-file: Enter the name of the Dell EMC Networking software image file to validate

Examples: Without Entering the Hash Value for Verification

MD5

DellEMC# verify md5 flash:file-name

SHA256

DellEMC# verify sha256 flash://file-name

Examples: Entering the Hash Value for Verification

MD5

DellEMC# verify md5 flash://file-name 275ceb73a4f3118e1d6bcf7d75753459

SHA256

DellEMC# verify sha256 flash://file-name
e6328c06faf814e6899ceead219afbf9360e986d692988023b749e6b2093e933

Using HTTP for File Transfers

Stating with Release 9.3(0.1), you can use HTTP to copy files or configuration details to a remote server. To transfer files to an external
server, use the copy source-file-url http://host[:port]/file-path command.

Enter the following source-file-url keywords and information:

• To copy a file from the internal FLASH, enter flash:// followed by the filename.

• To copy the running configuration, enter the keyword running-config.

• To copy the startup configuration, enter the keyword startup-config.

• To copy a file on the USB device, enter usbflash:// followed by the filename.

In the Dell EMC Networking OS release 9.8(0.0), HTTP services support the VRF-aware functionality. If you want the HTTP server to use
a VRF table that is attached to an interface, configure that HTTP server to use a specific routing table. You can use the
command to inform the HTTP server to use a specific routing table. After you configure this setting, the VRF table is used to look up the
destination address.

NOTE:

You can specify either the management VRF or a nondefault VRF to configure the VRF awareness setting.

When you specify the management VRF, the copy operation that is used to transfer files to and from an HTTP server utilizes the VRF
table corresponding to the Management VRF to look up the destination. When you specify a nondefault VRF, the VRF table corresponding
to that nondefault VRF is used to look up the HTTP server.

However, these changes are backward-compatible and do not affect existing behavior; meaning, you can still use the ip http
source- interface command to communicate with a particular interface even if no VRF is configured on that interface

To enable HTTP to be VRF-aware, as a prerequisite you must first define the VRF.

ip http vrf

NOTE:

To enable an HTTP client to look up the VRF table corresponding to either management VRF or any nondefault VRF, use the ip http
vrf command in CONFIGURATION mode.

If the HTTP service is not VRF-aware, then it uses the global routing table to perform the look-up.

Getting Started

55

• Configure an HTTP client with a VRF that is used to connect to the HTTP server.
CONFIGURATION MODE

DellEMC(conf)#ip http vrf {management | <vrf-name>}

56 Getting Started

Management

This chapter describes the different protocols or services used to manage the Dell EMC Networking system.

Topics:

• Configuring Privilege Levels

• Configuring Logging

• Track Login Activity

• Limit Concurrent Login Sessions

• Enabling Secured CLI Mode

• Log Messages in the Internal Buffer

• Disabling System Logging

• Sending System Messages to a Syslog Server

• Changing System Logging Settings

• Display the Logging Buffer and the Logging Configuration

• Configuring a UNIX Logging Facility Level

• Synchronizing Log Messages

• Enabling Timestamp on Syslog Messages

• File Transfer Services

• Terminal Lines

• Setting Timeout for EXEC Privilege Mode

• Using Telnet to get to Another Network Device

• Lock CONFIGURATION Mode

• LPC Bus Quality Degradation

• Restoring the Factory Default Settings

• Viewing the Reason for Last System Reboot

4

Configuring Privilege Levels

Privilege levels restrict access to commands based on user or terminal line.

There are 16 privilege levels, of which three are pre-defined. The default privilege level is 1.

Level

Level 0 Access to the system begins at EXEC mode, and EXEC mode commands are limited to enable, disable, and

Level 1 Access to the system begins at EXEC mode, and all commands are available.

Level 15 Access to the system begins at EXEC Privilege mode, and all commands are available.

For information about how access and authorization is controlled based on a user’s role, see Role-Based Access Control.

Creating a Custom Privilege Level

Custom privilege levels start with the default EXEC mode command set. You can then customize privilege levels 2-14 by:

• restricting access to an EXEC mode command

• moving commands from EXEC Privilege to EXEC mode

• restricting access

A user can access all commands at his privilege level and below.

Description

exit.

Management 57

Removing a Command from EXEC Mode

To remove a command from the list of available commands in EXEC mode for a specific privilege level, use the privilege exec
command from CONFIGURATION mode.

In the command, specify a level greater than the level given to a user or terminal line, then the first keyword of each command you wish to
restrict.

Moving a Command from EXEC Privilege Mode to EXEC Mode

To move a command from EXEC Privilege to EXEC mode for a privilege level, use the privilege exec command from
CONFIGURATION mode.

In the command, specify the privilege level of the user or terminal line and specify all keywords in the command to which you want to allow
access.

Allowing Access to CONFIGURATION Mode Commands

To allow access to CONFIGURATION mode, use the privilege exec level level configure command from
CONFIGURATION mode.

A user that enters CONFIGURATION mode remains at his privilege level and has access to only two commands, end and exit. You must
individually specify each CONFIGURATION mode command you want to allow access to using the privilege configure level
level command. In the command, specify the privilege level of the user or terminal line and specify all the keywords in the command to
which you want to allow access.

Allowing Access to Different Modes

This section describes how to allow access to the INTERFACE, LINE, ROUTE-MAP, and ROUTER modes.

Similar to allowing access to CONFIGURATION mode, to allow access to INTERFACE, LINE, ROUTE-MAP, and ROUTER modes, you
must first allow access to the command that enters you into the mode. For example, to allow a user to enter INTERFACE mode, use the
privilege configure level level interface tengigabitethernet command.

Next, individually identify the INTERFACE, LINE, ROUTE-MAP or ROUTER commands to which you want to allow access using the
privilege {interface | line | route-map | router} level level command. In the command, specify the privilege
level of the user or terminal line and specify all the keywords in the command to which you want to allow access.

To remove, move or allow access, use the following commands.

The configuration in the following example creates privilege level 3. This level:

• removes the resequence command from EXEC mode by requiring a minimum of privilege level 4

• moves the capture bgp-pdu max-buffer-size command from EXEC Privilege to EXEC mode by requiring a minimum
privilege level 3, which is the configured level for VTY 0

• allows access to CONFIGURATION mode with the banner command

• allows access to INTERFACE tengigabitethernet and LINE modes are allowed with no commands

• Remove a command from the list of available commands in EXEC mode.
CONFIGURATION mode

privilege exec level level {command ||...|| command}

• Move a command from EXEC Privilege to EXEC mode.
CONFIGURATION mode

privilege exec level level {command ||...|| command}

• Allow access to CONFIGURATION mode.
CONFIGURATION mode

privilege exec level level configure

• Allow access to INTERFACE, LINE, ROUTE-MAP, and/or ROUTER mode. Specify all the keywords in the command.
CONFIGURATION mode

58

Management

privilege configure level level {interface | line | route-map | router} {command-keyword
||...|| command-keyword}

• Allow access to a CONFIGURATION, INTERFACE, LINE, ROUTE-MAP, and/or ROUTER mode command.
CONFIGURATION mode

privilege {configure |interface | line | route-map | router} level level {command ||...||
command}

DellEMC(conf)#do show run priv
!
privilege exec level 3 capture
privilege exec level 3 configure
privilege exec level 4 resequence
privilege exec level 3 capture bgp-pdu
privilege exec level 3 capture bgp-pdu max-buffer-size
privilege configure level 3 line
privilege configure level 3 interface
DellEMC(conf)#do telnet 10.11.80.201
[telnet output omitted]
DellEMC#show priv
Current privilege level is 3.
DellEMC#?
capture Capture packet
configure Configuring from terminal
disable Turn off privileged commands
enable Turn on privileged commands
exit Exit from the EXEC
ip Global IP subcommands
monitor Monitoring feature
mtrace Trace reverse multicast path from destination to source
ping Send echo messages
quit Exit from the EXEC
show Show running system information
[output omitted]
DellEMC#config
[output omitted]
DellEMC(conf)#do show priv
Current privilege level is 3.
DellEMC(conf)#?
end Exit from configuration mode
exit Exit from configuration mode
interface Select an interface to configure
line Configure a terminal line
linecard Set line card type
DellEMC(conf)#interface ?
fastethernet Fast Ethernet interface
gigabitethernet Gigabit Ethernet interface
loopback Loopback interface
managementethernet Management Ethernet interface
null Null interface
port-channel Port-channel interface
range Configure interface range
sonet SONET interface
tengigabitethernet TenGigabit Ethernet interface
vlan VLAN interface
DellEMC(conf)#interface tengigabitethernet 1/1
DellEMC(conf-if-te-1/1)#?
end Exit from configuration mode
exit Exit from interface configuration mode
DellEMC(conf-if-te-1/1)#exit
DellEMC(conf)#line ?
aux Auxiliary line
console Primary terminal line
vty Virtual terminal
DellEMC(conf)#line vty 0
DellEMC(config-line-vty)#?
exit Exit from line configuration mode
DellEMC(config-line-vty)#
DellEMC(conf)#interface group ?
gigabitethernet GigabitEthernet interface IEEE 802.3z
tengigabitethernet TenGigabit Ethernet interface
vlan VLAN keyword

Management

59

DellEMC(conf)# interface group vlan 1 - 2 , tengigabitethernet 1/1
DellEMC(conf-if-group-vl-1-2,te-1/1)# no shutdown
DellEMC(conf-if-group-vl-1-2,te-1/1)# end

Applying a Privilege Level to a Username

To set the user privilege level, use the following command.

• Configure a privilege level for a user.
CONFIGURATION mode

username username privilege level

Applying a Privilege Level to a Terminal Line

To set a privilege level for a terminal line, use the following command.

• Configure a privilege level for a user.
CONFIGURATION mode

username username privilege level

NOTE: When you assign a privilege level between 2 and 15, access to the system begins at EXEC mode, but the prompt

is hostname#, rather than hostname>.

Configuring Logging

The Dell EMC Networking OS tracks changes in the system using event and error messages.

By default, Dell EMC Networking OS logs these messages on:

• the internal buffer

• console and terminal lines

• any configured syslog servers

To disable logging, use the following commands.

• Disable all logging except on the console.
CONFIGURATION mode

no logging on

• Disable logging to the logging buffer.
CONFIGURATION mode

no logging buffer

• Disable logging to terminal lines.
CONFIGURATION mode

no logging monitor

• Disable console logging.
CONFIGURATION mode

no logging console

Audit and Security Logs

This section describes how to configure, display, and clear audit and security logs.

The following is the configuration task list for audit and security logs:

• Enabling Audit and Security Logs

• Displaying Audit and Security Logs

• Clearing Audit Logs

60

Management

Enabling Audit and Security Logs

You enable audit and security logs to monitor configuration changes or determine if these changes affect the operation of the system in
the network. You log audit and security events to a system log server, using the logging extended command in CONFIGURATION
mode.

This command is available with or without RBAC enabled. For information about RBAC, see Role-Based Access Control.

Audit Logs

The audit log contains configuration events and information. The types of information in this log consist of the following:

• User logins to the switch.

• System events for network issues or system issues.

• Users making configuration changes. The switch logs who made the configuration changes and the date and time of the
change. However, each specific change on the configuration is not logged. Only that the configuration was modified is logged with the
user ID, date, and time of the change.

• Uncontrolled shutdown.

Security Logs

The security log contains security events and information. RBAC restricts access to audit and security logs based on the CLI sessions’ user
roles. The types of information in this log consist of the following:

• Establishment of secure traffic flows, such as SSH.

• Violations on secure flows or certificate issues.

• Adding and deleting of users.

• User access and configuration changes to the security and crypto parameters (not the key information but the crypto configuration)

Important Points to Remember

When you enabled RBAC and extended logging:

• Only the system administrator user role can execute this command.

• The system administrator and system security administrator user roles can view security events and system events.

• The system administrator user roles can view audit, security, and system events.

• Only the system administrator and security administrator user roles can view security logs.

• The network administrator and network operator user roles can view system events.

NOTE:

Example of Enabling Audit and Security Logs

DellEMC(conf)#logging extended

If extended logging is disabled, you can only view system events, regardless of RBAC user role.

Displaying Audit and Security Logs

To display audit logs, use the show logging auditlog command in Exec mode. To view these logs, you must first enable the logging
extended command. Only the RBAC system administrator user role can view the audit logs. Only the RBAC security administrator and
system administrator user role can view the security logs. If extended logging is disabled, you can only view system events, regardless of
RBAC user role. To view security logs, use the show logging command.

For information about the logging extended command, see Enabling Audit and Security Logs

Example of the show logging auditlog Command

DellEMC#show logging auditlog
May 12 12:20:25: DellEMC#: %CLI-6-logging extended by admin from vty0 (10.14.1.98)
May 12 12:20:42: DellEMC#: %CLI-6-configure terminal by admin from vty0 (10.14.1.98)
May 12 12:20:42: DellEMC#: %CLI-6-service timestamps log datetime by admin from vty0
(10.14.1.98)

For information about the logging extended command, see Enabling Audit and Security Logs

Example of the show logging Command for Security

DellEMC#show logging
Jun 10 04:23:40: %STKUNIT0-M:CP

%SEC-5-LOGIN_SUCCESS: Login successful for user admin on

Management

61

line vty0 ( 10.14.1.91 )

Clearing Audit Logs

To clear audit logs, use the clear logging auditlog command in Exec mode. When RBAC is enabled, only the system administrator
user role can issue this command.

Example of the clear logging auditlog Command

DellEMC# clear logging auditlog

Configuring Logging Format

To display syslog messages in a RFC 3164 or RFC 5424 format, use the logging version {0 | 1} command in CONFIGURATION
mode. By default, the system log version is set to 0.

The following describes the two log messages formats:

• 0 – Displays syslog messages format as described in RFC 3164, The BSD syslog Protocol

• 1 – Displays syslog message format as described in RFC 5424, The SYSLOG Protocol

Example of Configuring the Logging Message Format

DellEMC(conf)#logging version ?
<0-1> Select syslog version (default = 0)
DellEMC(conf)#logging version 1

Display the Logging Buffer and the Logging Configuration

To display the current contents of the logging buffer and the logging settings for the system, use the show logging command in EXEC
privilege mode. When RBAC is enabled, the security logs are filtered based on the user roles. Only the security administrator and system
administrator can view the security logs.

Example of the show logging Command

DellEMC#show logging
syslog logging: enabled
Console logging: level Debugging
Monitor logging: level Debugging
Buffer logging: level Debugging, 40 Messages Logged, Size (40960 bytes)
Trap logging: level Informational
%IRC-6-IRC_COMMUP: Link to peer RPM is up
%RAM-6-RAM_TASK: RPM1 is transitioning to Primary RPM.
%RPM-2-MSG:CP1 %POLLMGR-2-MMC_STATE: External flash disk missing in 'slot0:'
%CHMGR-5-CARDDETECTED: Line card 0 present
%CHMGR-5-CARDDETECTED: Line card 2 present
%CHMGR-5-CARDDETECTED: Line card 4 present
%CHMGR-5-CARDDETECTED: Line card 5 present
%CHMGR-5-CARDDETECTED: Line card 8 present
%CHMGR-5-CARDDETECTED: Line card 10 present
%CHMGR-5-CARDDETECTED: Line card 12 present
%TSM-6-SFM_DISCOVERY: Found SFM 0
%TSM-6-SFM_DISCOVERY: Found SFM 1
%TSM-6-SFM_DISCOVERY: Found SFM 2
%TSM-6-SFM_DISCOVERY: Found SFM 3
%TSM-6-SFM_DISCOVERY: Found SFM 4
%TSM-6-SFM_DISCOVERY: Found SFM 5
%TSM-6-SFM_DISCOVERY: Found SFM 6
%TSM-6-SFM_DISCOVERY: Found SFM 7
%TSM-6-SFM_SWITCHFAB_STATE: Switch Fabric: UP
%TSM-6-SFM_DISCOVERY: Found SFM 8
%TSM-6-SFM_DISCOVERY: Found 9 SFMs
%CHMGR-5-CHECKIN: Checkin from line card 5 (type EX1YB, 1 ports)
%TSM-6-PORT_CONFIG: Port link status for LC 5 => portpipe 0: OK portpipe 1: N/A
%CHMGR-5-LINECARDUP: Line card 5 is up
%CHMGR-5-CHECKIN: Checkin from line card 12 (type S12YC12, 12 ports)

62

Management

%TSM-6-PORT_CONFIG: Port link status for LC 12 => portpipe 0: OK portpipe 1: N/A
%CHMGR-5-LINECARDUP: Line card 12 is up
%IFMGR-5-CSTATE_UP: changed interface Physical state to up: So 12/8
%IFMGR-5-CSTATE_DN: changed interface Physical state to down: So 12/8

To view any changes made, use the show running-config logging command in EXEC privilege mode.

Setting Up a Secure Connection to a Syslog Server

You can use reverse tunneling with the port forwarding to securely connect to a syslog server.

Figure 2. Setting Up a Secure Connection to a Syslog Server

Pre-requisites

To configure a secure connection from the switch to the syslog server:

1. On the switch, enable the SSH server

DellEMC(conf)#ip ssh server enable

2. On the syslog server, create a reverse SSH tunnel from the syslog server to the Dell OS switch, using following syntax:

ssh -R <remote port>:<syslog server>:<syslog server listen port> user@remote_host -nNf

In the following example the syslog server IP address is 10.156.166.48 and the listening port is 5141. The switch IP address is

10.16.131.141 and the listening port is 5140

ssh -R 5140:10.156.166.48:5141 admin@10.16.131.141 -nNf

3. Configure logging to a local host. locahost is “127.0.0.1” or “::1”.

Management

63

If you do not, the system displays an error when you attempt to enable role-based only AAA authorization.

DellEMC(conf)# logging localhost tcp port
DellEMC(conf)#logging 127.0.0.1 tcp 5140

Sending System Messages to a Syslog Server

To send system messages to a specified syslog server, use the following command. The following syslog standards are supported: RFC
5424 The SYSLOG Protocol, R.Gerhards and Adiscon GmbH, March 2009, obsoletes RFC 3164 and RFC 5426 Transmission of Syslog
Messages over UDP.

• Specify the server to which you want to send system messages. You can configure up to eight syslog servers.
CONFIGURATION mode

logging {ip-address | ipv6-address | hostname} {{udp {port}} | {tcp {port}}}

You can export system logs to an external server that is connected through a different VRF.

Track Login Activity

Dell EMC Networking OS enables you to track the login activity of users and view the successful and unsuccessful login events.

When you log in using the console or VTY line, the system displays the last successful login details of the current user and the number of
unsuccessful login attempts since your last successful login to the system, and whether the current user’s permissions have changed since
the last login. The system stores the number of unsuccessful login attempts that have occurred in the last 30 days by default. You can
change the default value to any number of days from 1 to 30. By default, login activity tracking is disabled. You can enable it using the
login statistics enable command from the configuration mode.

Restrictions for Tracking Login Activity

These restrictions apply for tracking login activity:

• Only the system and security administrators can configure login activity tracking and view the login activity details of other users.

• Login statistics is not applicable for login sessions that do not use user names for authentication. For example, the system does not
report login activity for a telnet session that prompts only a password.

Configuring Login Activity Tracking

To enable and configure login activity tracking, follow these steps:

1. Enable login activity tracking.
CONFIGURATION mode

login statistics enable

After enabling login statistics, the system stores the login activity details for the last 30 days.

2. (Optional) Configure the number of days for which the system stores the user login statistics. The range is from 1 to 30.
CONFIGURATION mode

login statistics time-period days

The following example enables login activity tracking. The system stores the login activity details for the last 30 days.

DellEMC(config)#login statistics enable

The following example enables login activity tracking and configures the system to store the login activity details for 12 days.

DellEMC(config)#login statistics enable
DellEMC(config)#login statistics time-period 12

64

Management

Display Login Statistics

To view the login statistics, use the show login statistics command.

Example of the show login statistics Command

The show login statistics command displays the successful and failed login details of the current user in the last 30 days or the
custom defined time period.

DellEMC#show login statistics

-----------------------------------------------------------------­User: admin
Last login time: 12:52:01 UTC Tue Mar 22 2016
Last login location: Line vty0 ( 10.16.127.143 )
Unsuccessful login attempt(s) since the last successful login: 0
Unsuccessful login attempt(s) in last 30 day(s): 0
Successful login attempt(s) in last 30 day(s): 1

------------------------------------------------------------------

Example of the show login statistics all command

The show login statistics all command displays the successful and failed login details of all users in the last 30 days or the
custom defined time period.

DellEMC#show login statistics all

-----------------------------------------------------------------­User: admin
Last login time: 08:54:28 UTC Wed Mar 23 2016
Last login location: Line vty0 ( 10.16.127.145 )
Unsuccessful login attempt(s) since the last successful login: 0
Unsuccessful login attempt(s) in last 30 day(s): 3
Successful login attempt(s) in last 30 day(s): 4

------------------------------------------------------------------

-----------------------------------------------------------------­User: admin1
Last login time: 12:49:19 UTC Tue Mar 22 2016
Last login location: Line vty0 ( 10.16.127.145 )
Unsuccessful login attempt(s) since the last successful login: 0
Unsuccessful login attempt(s) in last 30 day(s): 3
Successful login attempt(s) in last 30 day(s): 2

------------------------------------------------------------------

-----------------------------------------------------------------­User: admin2
Last login time: 12:49:27 UTC Tue Mar 22 2016
Last login location: Line vty0 ( 10.16.127.145 )
Unsuccessful login attempt(s) since the last successful login: 0
Unsuccessful login attempt(s) in last 30 day(s): 3
Successful login attempt(s) in last 30 day(s): 2

------------------------------------------------------------------

-----------------------------------------------------------------­User: admin3
Last login time: 13:18:42 UTC Tue Mar 22 2016
Last login location: Line vty0 ( 10.16.127.145 )
Unsuccessful login attempt(s) since the last successful login: 0
Unsuccessful login attempt(s) in last 30 day(s): 3
Successful login attempt(s) in last 30 day(s): 2

Example of the show login statistics user user-id command

The show login statistics user user-id command displays the successful and failed login details of a specific user in the last
30 days or the custom defined time period.

DellEMC# show login statistics user admin

-----------------------------------------------------------------­User: admin

Management

65

Last login time: 12:52:01 UTC Tue Mar 22 2016
Last login location: Line vty0 ( 10.16.127.143 )
Unsuccessful login attempt(s) since the last successful login: 0
Unsuccessful login attempt(s) in last 30 day(s): 0
Successful login attempt(s) in last 30 day(s): 1

------------------------------------------------------------------

The following is sample output of the show login statistics unsuccessful-attempts command.

DellEMC# show login statistics unsuccessful-attempts
There were 3 unsuccessful login attempt(s) for user admin in last 30 day(s).

The following is sample output of the show login statistics unsuccessful-attempts time-period days command.

DellEMC# show login statistics unsuccessful-attempts time-period 15
There were 0 unsuccessful login attempt(s) for user admin in last 15 day(s).

The following is sample output of the show login statistics unsuccessful-attempts user login-id command.

DellEMC# show login statistics unsuccessful-attempts user admin
There were 3 unsuccessful login attempt(s) for user admin in last 12 day(s).

The following is sample output of the show login statistics successful-attempts command.

DellEMC#show login statistics successful-attempts
There were 4 successful login attempt(s) for user admin in last 30 day(s).

Limit Concurrent Login Sessions

Dell EMC Networking OS enables you to limit the number of concurrent login sessions of users on VTY, auxiliary, and console lines. You
can also clear any of your existing sessions when you reach the maximum permitted number of concurrent sessions.

By default, you can use all 10 VTY lines, one console line, and one auxiliary line. You can limit the number of available sessions using the
login concurrent-session limit command and so restrict each user to that specific number of sessions. You can optionally
configure the system to provide an option to the users to clear any of their existing sessions. To restrict the total amount of VTY lines
using ACL, see the Denying and Permitting Access to a Terminal Line section.

Restrictions for Limiting the Number of Concurrent Sessions

These restrictions apply for limiting the number of concurrent sessions:

• Only the system and security administrators can limit the number of concurrent sessions and enable the clear-line option.

• Users can clear their existing sessions only if the system is configured with the login concurrent-session clear-line
enable command.

Configuring Concurrent Session Limit

To configure concurrent session limit, follow this procedure:

• Limit the number of concurrent sessions for each user.
CONFIGURATION mode

login concurrent-session limit number-of-sessions

The following example limits the permitted number of concurrent login sessions to 4.

DellEMC(config)#login concurrent-session limit 4

66

Management

Enabling the System to Clear Existing Sessions

To enable the system to clear existing login sessions, follow this procedure:

• Use the following command.
CONFIGURATION mode

login concurrent-session clear-line enable

NOTE: If both concurrent sessions and the maximum number of VTY lines used are the same, the next or the

following attempt will be unsuccessful and the system displays access denied message. It is not possible to attempt
after clearing one of the existing sessions as user authentication has to happen first and before clearing the existing
login sessions. During the next authentication attempt, the system does not allow any attempt to login since
maximum VTY sessions have reached and hence no clear-line option.

NOTE: If the maximum number of VTY lines are more than the concurrent sessions and the same user is attempting

to login second time or more, the system displays the Maximum concurrent sessions for the user reached
message. You are allowed to clear the existing session and login. If you do not want to clear any of the existing
session, the system does not allow any attempt to login since maximum concurrent sessions have reached even
though more VTY lines are available. You are allowed to login as a different user as more VTY lines are available.

The following example enables you to clear your existing login sessions.

DellEMC(config)#login concurrent-session clear-line enable

Example of Clearing Existing Sessions

When you try to log in, the following message appears with all your existing concurrent sessions, providing an option to close any one of
the existing sessions:

$ telnet 10.11.178.14
Trying 10.11.178.14...
Connected to 10.11.178.14.
Escape character is '^]'.
Login: admin
Password:
Current sessions for user admin:
Line Location
2 vty 0 10.14.1.97
3 vty 1 10.14.1.97
Clear existing session? [line number/Enter to cancel]:

When you try to create more than the permitted number of sessions, the following message appears, prompting you to close one of the
existing sessions. If you close any of the existing sessions, you are allowed to login.

$ telnet 10.11.178.17
Trying 10.11.178.17...
Connected to 10.11.178.17.
Escape character is '^]'.
Login: admin
Password:

Maximum concurrent sessions for the user reached.
Current sessions for user admin:
Line Location
2 vty 0 10.14.1.97
3 vty 1 10.14.1.97
4 vty 2 10.14.1.97
5 vty 3 10.14.1.97
Kill existing session? [line number/Enter to cancel]:

Enabling Secured CLI Mode

The secured CLI mode prevents the users from enhancing the permissions or promoting the privilege levels.

• Enter the following command to enable the secured CLI mode:
CONFIGURATION Mode

Management

67

secure-cli enable

After entering the command, save the running-configuration. Once you save the running-configuration, the secured CLI mode is enabled.

If you do not want to enter the secured mode, do not save the running-configuration. Once saved, to disable the secured CLI mode, you
need to manually edit the startup-configuration file and reboot the system.

Log Messages in the Internal Buffer

All error messages, except those beginning with %BOOTUP (Message), are log in the internal buffer.

For example, %BOOTUP:RPM0:CP %PORTPIPE-INIT-SUCCESS: Portpipe 0 enabled

Configuration Task List for System Log Management

There are two configuration tasks for system log management:

• Disable System Logging

• Send System Messages to a Syslog Server

Disabling System Logging

By default, logging is enabled and log messages are sent to the logging buffer, all terminal lines, the console, and the syslog servers.

To disable system logging, use the following commands.

• Disable all logging except on the console.
CONFIGURATION mode

no logging on

• Disable logging to the logging buffer.
CONFIGURATION mode

no logging buffer

• Disable logging to terminal lines.
CONFIGURATION mode

no logging monitor

• Disable console logging.
CONFIGURATION mode

no logging console

Sending System Messages to a Syslog Server

To send system messages to a specified syslog server, use the following command. The following syslog standards are supported: RFC
5424 The SYSLOG Protocol, R.Gerhards and Adiscon GmbH, March 2009, obsoletes RFC 3164 and RFC 5426 Transmission of Syslog
Messages over UDP.

• Specify the server to which you want to send system messages. You can configure up to eight syslog servers.
CONFIGURATION mode

logging {ip-address | ipv6-address | hostname} {{udp {port}} | {tcp {port}}}

You can export system logs to an external server that is connected through a different VRF.

Configuring a UNIX System as a Syslog Server

To configure a UNIX System as a syslog server, use the following command.

• Configure a UNIX system as a syslog server by adding the following lines to /etc/syslog.conf on the UNIX system and assigning write
permissions to the file.

• Add line on a 4.1 BSD UNIX system. local7.debugging /var/log/ftos.log

• Add line on a 5.7 SunOS UNIX system. local7.debugging /var/adm/ftos.log

68

Management

In the previous lines, local7 is the logging facility level and debugging is the severity level.

Changing System Logging Settings

You can change the default settings of the system logging by changing the severity level and the storage location.

The default is to log all messages up to debug level, that is, all system messages. By changing the severity level in the logging commands,
you control the number of system messages logged.

To specify the system logging settings, use the following commands.

• Specify the minimum severity level for logging to the logging buffer.
CONFIGURATION mode

logging buffered level

• Specify the minimum severity level for logging to the console.
CONFIGURATION mode

logging console level

• Specify the minimum severity level for logging to terminal lines.
CONFIGURATION mode

logging monitor level

• Specify the minimum severity level for logging to a syslog server.
CONFIGURATION mode

logging trap level

• Specify the minimum severity level for logging to the syslog history table.
CONFIGURATION mode

logging history level

• Specify the size of the logging buffer.
CONFIGURATION mode

logging buffered size

NOTE:

Increasing the buffer size does not affect messages in the buffer.

• Specify the number of messages that Dell EMC Networking OS saves to its logging history table.
CONFIGURATION mode

logging history size size

To view the logging buffer and configuration, use the show logging command in EXEC privilege mode, as shown in the example for

Display the Logging Buffer and the Logging Configuration.

To view the logging configuration, use the show running-config logging command in privilege mode, as shown in the example for

Configure a UNIX Logging Facility Level.

When you decrease the buffer size, Dell EMC Networking OS deletes all messages stored in the buffer.

Display the Logging Buffer and the Logging Configuration

To display the current contents of the logging buffer and the logging settings for the system, use the show logging command in EXEC
privilege mode. When RBAC is enabled, the security logs are filtered based on the user roles. Only the security administrator and system
administrator can view the security logs.

Example of the show logging Command

DellEMC#show logging
syslog logging: enabled
Console logging: level Debugging
Monitor logging: level Debugging
Buffer logging: level Debugging, 40 Messages Logged, Size (40960 bytes)
Trap logging: level Informational
%IRC-6-IRC_COMMUP: Link to peer RPM is up
%RAM-6-RAM_TASK: RPM1 is transitioning to Primary RPM.
%RPM-2-MSG:CP1 %POLLMGR-2-MMC_STATE: External flash disk missing in 'slot0:'
%CHMGR-5-CARDDETECTED: Line card 0 present

Management

69

%CHMGR-5-CARDDETECTED: Line card 2 present
%CHMGR-5-CARDDETECTED: Line card 4 present
%CHMGR-5-CARDDETECTED: Line card 5 present
%CHMGR-5-CARDDETECTED: Line card 8 present
%CHMGR-5-CARDDETECTED: Line card 10 present
%CHMGR-5-CARDDETECTED: Line card 12 present
%TSM-6-SFM_DISCOVERY: Found SFM 0
%TSM-6-SFM_DISCOVERY: Found SFM 1
%TSM-6-SFM_DISCOVERY: Found SFM 2
%TSM-6-SFM_DISCOVERY: Found SFM 3
%TSM-6-SFM_DISCOVERY: Found SFM 4
%TSM-6-SFM_DISCOVERY: Found SFM 5
%TSM-6-SFM_DISCOVERY: Found SFM 6
%TSM-6-SFM_DISCOVERY: Found SFM 7
%TSM-6-SFM_SWITCHFAB_STATE: Switch Fabric: UP
%TSM-6-SFM_DISCOVERY: Found SFM 8
%TSM-6-SFM_DISCOVERY: Found 9 SFMs
%CHMGR-5-CHECKIN: Checkin from line card 5 (type EX1YB, 1 ports)
%TSM-6-PORT_CONFIG: Port link status for LC 5 => portpipe 0: OK portpipe 1: N/A
%CHMGR-5-LINECARDUP: Line card 5 is up
%CHMGR-5-CHECKIN: Checkin from line card 12 (type S12YC12, 12 ports)
%TSM-6-PORT_CONFIG: Port link status for LC 12 => portpipe 0: OK portpipe 1: N/A
%CHMGR-5-LINECARDUP: Line card 12 is up
%IFMGR-5-CSTATE_UP: changed interface Physical state to up: So 12/8
%IFMGR-5-CSTATE_DN: changed interface Physical state to down: So 12/8

To view any changes made, use the show running-config logging command in EXEC privilege mode.

Configuring a UNIX Logging Facility Level

You can save system log messages with a UNIX system logging facility.

To configure a UNIX logging facility level, use the following command.

• Specify one of the following parameters.
CONFIGURATION mode

logging facility [facility-type]

• auth (for authorization messages)

• cron (for system scheduler messages)

• daemon (for system daemons)

• kern (for kernel messages)

• local0 (for local use)

• local1 (for local use)

• local2 (for local use)

• local3 (for local use)

• local4 (for local use)

• local5 (for local use)

• local6 (for local use)

• local7 (for local use)

• lpr (for line printer system messages)

• mail (for mail system messages)

• news (for USENET news messages)

• sys9 (system use)

• sys10 (system use)

• sys11 (system use)

• sys12 (system use)

• sys13 (system use)

• sys14 (system use)

• syslog (for syslog messages)

• user (for user programs)

• uucp (UNIX to UNIX copy protocol)

70

Management

To view nondefault settings, use the show running-config logging command in EXEC mode.

DellEMC#show running-config logging
!
logging buffered 524288 debugging
service timestamps log datetime msec
service timestamps debug datetime msec
!
logging trap debugging
logging facility user
logging source-interface Loopback 0
logging 10.10.10.4
DellEMC#

Synchronizing Log Messages

You can configure Dell EMC Networking OS to filter and consolidate the system messages for a specific line by synchronizing the message
output.

Only the messages with a severity at or below the set level appear. This feature works on the terminal and console connections available
on the system.

1. Enter LINE mode.
CONFIGURATION mode

line {console 0 | vty number [end-number] | aux 0}

Configure the following parameters for the virtual terminal lines:

• number: the range is from zero (0) to 8.

• end-number: the range is from 1 to 8.

You can configure multiple virtual terminals at one time by entering a number and an end-number.

2. Configure a level and set the maximum number of messages to print.
LINE mode

logging synchronous [level severity-level | all] [limit]

Configure the following optional parameters:

• level severity-level: the range is from 0 to 7. The default is 2. Use the all keyword to include all messages.

• limit: the range is from 20 to 300. The default is 20.

To view the logging synchronous configuration, use the show config command in LINE mode.

Enabling Timestamp on Syslog Messages

By default, syslog messages include a time/date stamp, taken from the datetime, stating when the error or message was created.

To enable timestamp, use the following command.

• Add timestamp to syslog messages.
CONFIGURATION mode

service timestamps [log | debug] [datetime [localtime] [msec] [show-timezone] [utc] | uptime]

Specify the following optional parameters:

• datetime: To view the timestamp in system local time that includes the local time zone.

• localtime: You can add the keyword localtime to view timestamp in system local time that includes the local time zone.

• show-timezone: Enter the keyword to include the time zone information in the timestamp.

• msec: Enter the keyword msec to include milliseconds in the timestamp.

• uptime: To view time since last boot.

• utc: Enter the keyword utc to view timestamp in UTC time that excludes the local time zone.

If you do not specify a parameter, Dell EMC Networking OS configures datetime as localtime by default.

To view the configuration, use the show running-config logging command in EXEC privilege mode.

To disable time stamping on syslog messages, use the no service timestamps [log | debug] command.

Management

71

Example 1: Default configuration service timestamps log datetime or service timestamps log datetime

localtime

DellEMC(conf)#service timestamps log datetime

DellEMC#show clock
15:42:42.804 IST Fri May 17 2019

DellEMC# show command-history
[May 17 15:38:55]: CMD-(CLI):[service timestamps log datetime]by default from console
[May 17 15:41:40]: CMD-(CLI):[write memory]by default from console

- Repeated 1 time.
[May 17 15:41:45]: CMD-(CLI):[interface tengigabitethernet 1/1]by default from console
[May 17 15:41:47]: CMD-(CLI):[shutdown]by default from console
[May 17 15:41:50]: CMD-(CLI):[no shutdown]by default from console
[May 17 15:42:42]: CMD-(CLI):[show clock]by default from console
[May 17 15:42:52]: CMD-(CLI):[write memory]by default from console

- Repeated 1 time.
[May 17 15:43:08]: CMD-(CLI):[end]by default from console
[May 17 15:43:16]: CMD-(CLI):[show logging]by default from console
[May 17 15:43:22]: CMD-(CLI):[show command-history]by default from console
DellEMC#

DellEMC#show logging
Syslog logging: enabled
Console logging: disabled
Monitor logging: level debugging
Buffer logging: level debugging, 7 Messages Logged, Size (40960 bytes)
Trap logging: level informational
Last logging buffer cleared: May 17 15:38:38
May 17 15:43:08 %STKUNIT1-M:CP %SYS-5-CONFIG_I: Configured from console
May 17 15:42:52 %STKUNIT1-M:CP %FILEMGR-5-FILESAVED: Copied running-config to startup-config
in flash by default
May 17 15:41:53 %STKUNIT1-M:CP %IFMGR-5-OSTATE_UP: Changed interface state to up: Te 1/1
May 17 15:41:50 %STKUNIT1-M:CP %IFMGR-5-ASTATE_UP: Changed interface Admin state to up: Te 1/1
May 17 15:41:47 %STKUNIT1-M:CP %IFMGR-5-OSTATE_DN: Changed interface state to down: Te 1/1
May 17 15:41:47 %STKUNIT1-M:CP %IFMGR-5-ASTATE_DN: Changed interface Admin state to down: Te
1/1
May 17 15:41:40 %STKUNIT1-M:CP %FILEMGR-5-FILESAVED: Copied running-config to startup-config
in flash by default

Example 2: service timestamps log datetime utc

DellEMC(conf)#service timestamps log datetime utc

DellEMC#show clock
15:47:05.661 IST Fri May 17 2019

DellEMC# show command-history
[May 17 10:16:53]: CMD-(CLI):[service timestamps log datetime utc]by default from console
[May 17 10:17:05]: CMD-(CLI):[show clock]by default from console
[May 17 10:17:20]: CMD-(CLI):[show running-config]by default from console
[May 17 10:17:30]: CMD-(CLI):[interface tengigabitethernet 1/2]by default from console
[May 17 10:17:32]: CMD-(CLI):[shutdown]by default from console
[May 17 10:17:34]: CMD-(CLI):[no shutdown]by default from console
[May 17 10:17:40]: CMD-(CLI):[write memory]by default from console

- Repeated 1 time.
[May 17 10:17:46]: CMD-(CLI):[end]by default from console
[May 17 10:17:50]: CMD-(CLI):[show logging]by default from console
[May 17 10:17:56]: CMD-(CLI):[show command-history]by default from console

DellEMC# show logging
Syslog logging: enabled
Console logging: disabled
Monitor logging: level debugging
Buffer logging: level debugging, 6 Messages Logged, Size (40960 bytes)
Trap logging: level informational
Last logging buffer cleared: May 17 15:46:36
May 17 10:17:46 %STKUNIT1-M:CP %SYS-5-CONFIG_I: Configured from console

72

Management

May 17 10:17:40 %STKUNIT1-M:CP %FILEMGR-5-FILESAVED: Copied running-config to startup-config
in flash by default
May 17 10:17:37 %STKUNIT1-M:CP %IFMGR-5-OSTATE_UP: Changed interface state to up: Te 1/2
May 17 10:17:34 %STKUNIT1-M:CP %IFMGR-5-ASTATE_UP: Changed interface Admin state to up: Te 1/2
May 17 10:17:32 %STKUNIT1-M:CP %IFMGR-5-OSTATE_DN: Changed interface state to down: Te 1/2
May 17 10:17:32 %STKUNIT1-M:CP %IFMGR-5-ASTATE_DN: Changed interface Admin state to down: Te
1/2

Example 3: service timestamps log uptime

DellEMC(conf)#service timestamps log uptime

DellEMC#show clock
15:51:47.534 IST Fri May 17 2019

DellEMC# show version |grep uptime
Dell EMC Networking OS uptime is 1 day(s), 0 hour(s), 25 minute(s)

DellEMC# show command-history
[1d0h24m]: CMD-(CLI):[service timestamps log uptime]by default from console
[1d0h24m]: CMD-(CLI):[interface tengigabitethernet 1/1]by default from console
[1d0h24m]: CMD-(CLI):[shutdown]by default from console
[1d0h24m]: CMD-(CLI):[no shutdown]by default from console
[1d0h25m]: CMD-(CLI):[end]by default from console
[1d0h25m]: CMD-(CLI):[write memory]by default from console

- Repeated 1 time.
[1d0h25m]: CMD-(CLI):[show clock]by default from console
[1d0h25m]: CMD-(CLI):[show version]by default from console
[1d0h25m]: CMD-(CLI):[show logging]by default from console
[1d0h25m]: CMD-(CLI):[show command-history]by default from console

DellEMC# show logging
Syslog logging: enabled
Console logging: disabled
Monitor logging: level debugging
Buffer logging: level debugging, 6 Messages Logged, Size (40960 bytes)
Trap logging: level informational
Last logging buffer cleared: May 17 15:50:31
1d0h25m %STKUNIT1-M:CP %FILEMGR-5-FILESAVED: Copied running-config to startup-config in flash
by default
1d0h25m %STKUNIT1-M:CP %SYS-5-CONFIG_I: Configured from console
1d0h24m %STKUNIT1-M:CP %IFMGR-5-OSTATE_UP: Changed interface state to up: Te 1/1
1d0h24m %STKUNIT1-M:CP %IFMGR-5-ASTATE_UP: Changed interface Admin state to up: Te 1/1
1d0h24m %STKUNIT1-M:CP %IFMGR-5-OSTATE_DN: Changed interface state to down: Te 1/1
1d0h24m %STKUNIT1-M:CP %IFMGR-5-ASTATE_DN: Changed interface Admin state to down: Te 1/1

Example 4: no service timestamps log

DellEMC(conf)#no service timestamps log

DellEMC#show clock
15:55:12.246 IST Fri May 17 2019

DellEMC# show command-history
[May 17 15:53:10]: CMD-(CLI):[no service timestamps log]by default from console
[May 17 15:53:16]: CMD-(CLI):[write memory]by default from console

- Repeated 3 times.
[May 17 15:53:22]: CMD-(CLI):[show logging]by default from console

- Repeated 1 time.
[May 17 15:53:36]: CMD-(CLI):[write memory]by default from console

- Repeated 5 times.
[May 17 15:53:44]: CMD-(CLI):[show logging]by default from console
[May 17 15:53:53]: CMD-(CLI):[show command-history]by default from console
[May 17 15:54:54]: CMD-(CLI):[end]by default from console
[May 17 15:55:00]: CMD-(CLI):[show logging]by default from console
[May 17 15:55:12]: CMD-(CLI):[show clock]by default from console

Management

73

[May 17 15:55:22]: CMD-(CLI):[show running-config]by default from console
[May 17 15:55:27]: CMD-(CLI):[show command-history]by default from console

DellEMC# show logging
Syslog logging: enabled
Console logging: disabled
Monitor logging: level debugging
Buffer logging: level debugging, 3 Messages Logged, Size (40960 bytes)
Trap logging: level informational
Last logging buffer cleared: May 17 15:52:54
%STKUNIT1-M:CP %SYS-5-CONFIG_I: Configured from console
%STKUNIT1-M:CP %FILEMGR-5-FILESAVED: Copied running-config to startup-config in flash by
default - repeated 3 times
%STKUNIT1-M:CP %FILEMGR-5-FILESAVED: Copied running-config to startup-config in flash by
default

File Transfer Services

With Dell EMC Networking OS, you can configure the system to transfer files over the network using the file transfer protocol (FTP).

One FTP application is copying the system image files over an interface on to the system; however, FTP is not supported on virtual local
area network (VLAN) interfaces.

If you want the FTP or TFTP server to use a VRF table that is attached to an interface, you must configure the FTP or TFTP server to use
a specific routing table. You can use the ip ftp vrf vrf-name or ip tftp vrf vrf-name command to inform the FTP or TFTP
server to use a specific routing table. After you configure this setting, the VRF table is used to look up the destination address. However,
these changes are backward-compatible and do not affect existing behavior; meaning, you can still use the source-interface
command to communicate with a particular interface even if no VRF is configured on that interface.

For more information about FTP, refer to RFC 959, File Transfer Protocol.

NOTE:

To transmit large files, Dell EMC Networking recommends configuring the switch as an FTP server.

Configuration Task List for File Transfer Services

The configuration tasks for file transfer services are:

• Enable FTP Server (mandatory)

• Configure FTP Server Parameters (optional)

• Configure FTP Client Parameters (optional)

Enabling the FTP Server

To enable the system as an FTP server, use the following command.

To view FTP configuration, use the show running-config ftp command in EXEC privilege mode.

• Enable FTP on the system.
CONFIGURATION mode

ftp-server enable

DellEMC#show running ftp
!
ftp-server enable
ftp-server username nairobi password 0 zanzibar
DellEMC#

Configuring FTP Server Parameters

After you enable the FTP server on the system, you can configure different parameters.

To specify the system logging settings, use the following commands.

• Specify the directory for users using FTP to reach the system.

74

Management

CONFIGURATION mode

ftp-server topdir dir

The default is the internal flash directory.

• Specify a user name for all FTP users and configure either a plain text or encrypted password.
CONFIGURATION mode

ftp-server username username password [encryption-type] password

Configure the following optional and required parameters:

username: enter a text string.

•

• encryption-type: enter 0 for plain text or 7 for encrypted text.

• password: enter a text string.

NOTE: You cannot use the change directory (cd) command until you have configured ftp-server topdir.

To view the FTP configuration, use the show running-config ftp command in EXEC privilege mode.

Configuring FTP Client Parameters

To configure FTP client parameters, use the following commands.

• Enter the following keywords and the interface information:

• For a 10-Gigabit Ethernet interface, enter the keyword TenGigabitEthernet then the slot/port/subport[/subport]

information.

• For a 40-Gigabit Ethernet interface, enter the keyword fortyGigE then the slot/port information.

• For a Loopback interface, enter the keyword loopback then a number from 0 to 16383.

• For a port channel interface, enter the keywords port-channel then a number.

• For a VLAN interface, enter the keyword vlan then a number from 1 to 4094.

CONFIGURATION mode

ip ftp source-interface interface

• Configure a password.
CONFIGURATION mode

ip ftp password password

• Enter a username to use on the FTP client.
CONFIGURATION mode

ip ftp username name

To view the FTP configuration, use the show running-config ftp command in EXEC privilege mode, as shown in the example for

Enable FTP Server.

Terminal Lines

You can access the system remotely and restrict access to the system by creating user profiles.

Terminal lines on the system provide different means of accessing the system. The console line (console) connects you through the
console port in the route processor modules (RPMs). The virtual terminal lines (VTYs) connect you through Telnet to the system. The
auxiliary line (aux) connects secondary devices such as modems.

Denying and Permitting Access to a Terminal Line

Dell EMC Networking recommends applying only standard access control lists (ACLs) to deny and permit access to VTY lines.

• Layer 3 ACLs deny all traffic that is not explicitly permitted, but in the case of VTY lines, an ACL with no rules does not deny traffic.

• You cannot use the show ip accounting access-list command to display the contents of an ACL that is applied only to a
VTY line.

• When you use the access-class access-list-name command without specifying the ipv4 or ipv6 attribute, both IPv4 as
well as IPv6 rules that are defined in that ACL are applied to the terminal. This method is a generic way of configuring access
restrictions.

Management

75

• To be able to filter access exclusively using either IPv4 or IPv6 rules, use either the ipv4 or ipv6 attribute along with the access­class access-list-name command. Depending on the attribute that you specify (ipv4 or ipv6), the ACL processes either

IPv4 or IPv6 rules, but not both. Using this configuration, you can set up two different types of access classes with each class
processing either IPv4 or IPv6 rules separately.

To apply an IP ACL to a line, Use the following command.

• Apply an ACL to a VTY line.
LINE mode

access-class access-list-name [ipv4 | ipv6]

NOTE: If you already have configured generic IP ACL on a terminal line, then you cannot further apply IPv4 or IPv6

specific filtering on top of this configuration. Similarly, if you have configured either IPv4 or IPv6 specific filtering on
a terminal line, you cannot apply generic IP ACL on top of this configuration. Before applying any of these
configurations, you must first undo the existing configuration using the no access-class access-list-name
[ipv4 | ipv6] command.

To view the configuration, use the show config command in LINE mode.

DellEMC(config-std-nacl)#show config
!
ip access-list standard myvtyacl
seq 5 permit host 10.11.0.1
DellEMC(config-std-nacl)#line vty 0
DellEMC(config-line-vty)#show config
line vty 0
access-class myvtyacl

DellEMC(conf-ipv6-acl)#do show run acl
!
ip access-list extended testdeny
seq 10 deny ip 30.1.1.0/24 any
seq 15 permit ip any any
!
ip access-list extended testpermit
seq 15 permit ip any any
!
ipv6 access-list testv6deny
seq 10 deny ipv6 3001::/64 any
seq 15 permit ipv6 any any
!
DellEMC(conf)#
DellEMC(conf)#line vty 0 0
DellEMC(config-line-vty)#access-class testv6deny ipv6
DellEMC(config-line-vty)#access-class testvpermit ipv4
DellEMC(config-line-vty)#show c
line vty 0
exec-timeout 0 0
access-class testpermit ipv4
access-class testv6deny ipv6
!

Configuring Login Authentication for Terminal Lines

You can use any combination of up to six authentication methods to authenticate a user on a terminal line.

A combination of authentication methods is called a method list. If the user fails the first authentication method, Dell EMC Networking OS
prompts the next method until all methods are exhausted, at which point the connection is terminated. The available authentication
methods are:

enable

line

local

76 Management

Prompt for the enable password.

Prompt for the password you assigned to the terminal line. Configure a password for the terminal line to which
you assign a method list that contains the line authentication method. Configure a password using the password
command from LINE mode.

Prompt for the system username and password.

none

radius

tacacs+

1.

Configure an authentication method list. You may use a mnemonic name or use the keyword default. The default authentication
method for terminal lines is

CONFIGURATION mode

aaa authentication login {method-list-name | default} [method-1] [method-2] [method-3]
[method-4] [method-5] [method-6]

2. Apply the method list from Step 1 to a terminal line.
CONFIGURATION mode

login authentication {method-list-name | default}

3. If you used the line authentication method in the method list you applied to the terminal line, configure a password for the terminal line.
LINE mode

password

In the following example, VTY lines 0-2 use a single authentication method, line.

DellEMC(conf)#aaa authentication login myvtymethodlist line
DellEMC(conf)#line vty 0 2
DellEMC(config-line-vty)#login authentication myvtymethodlist
DellEMC(config-line-vty)#password myvtypassword
DellEMC(config-line-vty)#show config
line vty 0
password myvtypassword
login authentication myvtymethodlist
line vty 1
password myvtypassword
login authentication myvtymethodlist
line vty 2
password myvtypassword
login authentication myvtymethodlist
DellEMC(config-line-vty)#

Do not authenticate the user.

Prompt for a username and password and use a RADIUS server to authenticate.

Prompt for a username and password and use a TACACS+ server to authenticate.

local and the default method list is empty.

Setting Timeout for EXEC Privilege Mode

EXEC timeout is a basic security feature that returns Dell EMC Networking OS to EXEC mode after a period of inactivity on the terminal
lines.

To set timeout, use the following commands.

• Set the number of minutes and seconds. The default is 10 minutes on the console and 30 minutes on VTY. Disable EXEC time out
by setting the timeout period to 0.

LINE mode

exec-timeout minutes [seconds]

• Return to the default timeout values.
LINE mode

no exec-timeout

The following example shows how to set the timeout period and how to view the configuration using the show config command from
LINE mode.

DellEMC(conf)#line con 0
DellEMC(config-line-console)#exec-timeout 0
DellEMC(config-line-console)#show config
line console 0
exec-timeout 0 0
DellEMC(config-line-console)#

Management

77

Using Telnet to get to Another Network Device

To telnet to another device, use the following commands.

NOTE: The device allows 120 Telnet sessions per minute, allowing the login and logout of 10 Telnet sessions, 12 times in

a minute. If the system reaches this non-practical limit, the Telnet service is stopped for 10 minutes. You can use
console and SSH service to access the system during downtime.

Telnet to a device with an IPv4 or IPv6 address.

•
EXEC Privilege

telnet [ip-address]

If you do not enter an IP address, Dell EMC Networking OS enters a Telnet dialog that prompts you for one.
Enter an IPv4 address in dotted decimal format (A.B.C.D).
Enter an IPv6 address in the format 0000:0000:0000:0000:0000:0000:0000:0000. Elision of zeros is supported.

DellEMC# telnet 10.11.80.203
Trying 10.11.80.203...
Connected to 10.11.80.203.
Exit character is '^]'.
Login:
Login: admin
Password:
DellEMC>exit
DellEMC#telnet 2200:2200:2200:2200:2200::2201
Trying 2200:2200:2200:2200:2200::2201...
Connected to 2200:2200:2200:2200:2200::2201.
Exit character is '^]'.
FreeBSD/i386 (freebsd2.force10networks.com) (ttyp1)
login: admin
DellEMC#

Lock CONFIGURATION Mode

Dell EMC Networking OS allows multiple users to make configurations at the same time. You can lock CONFIGURATION mode so that
only one user can be in CONFIGURATION mode at any time (Message 2).

You can set two types of lockst: auto and manual.

• Set auto-lock using the configuration mode exclusive auto command from CONFIGURATION mode. When you set auto­lock, every time a user is in CONFIGURATION mode, all other users are denied access. This means that you can exit to EXEC Privilege
mode, and re-enter CONFIGURATION mode without having to set the lock again.

• Set manual lock using the configure terminal lock command from CONFIGURATION mode. When you configure a manual
lock, which is the default, you must enter this command each time you want to enter CONFIGURATION mode and deny access to
others.

Viewing the Configuration Lock Status

If you attempt to enter CONFIGURATION mode when another user has locked it, you may view which user has control of
CONFIGURATION mode using the show configuration lock command from EXEC Privilege mode.

You can then send any user a message using the send command from EXEC Privilege mode. Alternatively, you can clear any line using the
clear command from EXEC Privilege mode. If you clear a console session, the user is returned to EXEC mode.

Example of Locking CONFIGURATION Mode for Single-User Access

DellEMC(conf)#configuration mode exclusive auto
BATMAN(conf)#exit
3d23h35m: %RPM0-P:CP %SYS-5-CONFIG_I: Configured from console by console

DellEMC#config
! Locks configuration mode exclusively.
DellEMC(conf)#

78

Management

If another user attempts to enter CONFIGURATION mode while a lock is in place, the following appears on their terminal (message 1): %
Error: User "" on line console0 is in exclusive configuration mode.

If any user is already in CONFIGURATION mode when while a lock is in place, the following appears on their terminal (message 2): %
Error: Can't lock configuration mode exclusively since the following users are currently
configuring the system: User "admin" on line vty1 ( 10.1.1.1 ).

NOTE: The CONFIGURATION mode lock corresponds to a VTY session, not a user. Therefore, if you configure a lock and

then exit CONFIGURATION mode, and another user enters CONFIGURATION mode, when you attempt to re-enter
CONFIGURATION mode, you are denied access even though you are the one that configured the lock.

NOTE: If your session times out and you return to EXEC mode, the CONFIGURATION mode lock is unconfigured.

LPC Bus Quality Degradation

LPC Bus Quality Analyzer (LBQA) runs on the system that make use of the LPC bus. It constantly monitors the LPC bus and alerts or
warns the user using following methods when it detects signal degradation:

1. The system displays a high priority syslog message. The text of this syslog is CPU Clock signal has degraded below

acceptable threshold on stack-unit <stack-unit-number> with service tag <service tag>. Please
contact Technical Support. On chassis platforms, the text is CPU Clock signal has degraded below
acceptable threshold on Line card <line card number> with service tag <service tag>. Please
contact Technical Support. This syslog continues to show every 30 minutes. An SNMP trap with this information is also

generated every hour.

2. If SupportAssist is enabled - it sends the event message to the global SupportAssist server immediately and there after once in two
days, so Dell can assist in pro-actively notifying and assisting customers.

3. System Status LED changes to an alarm state, blinking amber for S3048–ON, S6100–ON and Z9100–ON, and solid amber for C9000.
It is not possible to suppress this LED pattern until the unit is switched off (for RMA).

4. The switch (control/management/data plane) continues to be active.

NOTE:

master or standby (as in case of S3048-ON).

This is true even if the unit is the master (in a HA chassis environment – as in the case of RPM) or a Stack

LBQA (LPC Bus Quality Analyzer) Failure Detection mode

The following functions are performed as a part of this mode:

1. The LBQA will be started as part of FTOS application init (typically as a poller in sysd).

2. The LBQA will run as a fast poller (typically 1 sec) in failure detection mode.

3. During every fast poll cycle, LBQA will be the first poller to run.

4. In failure detection mode, the LBQA will issue a single IOCTL for each poll interval, which may in-turn issue multiple LPC operations
(write & read-back) to check the sanity of the LPC bus using the scratch register.

5. The LBQA will use an extended walking 1s/0s test along with a pattern based test (0x00, 0x55, 0xAA, 0xFF) that is staggered across
several polls.

6. The LBQA will limit each sanity check to a maximum of 16 operations (read + write).

7. LBQA will use a variable number of sanity checks over time, it would perform at least 1 check during every poll interval but will perform
8 checks during a signal poll once in 5 seconds.

8. The LBQA can be disabled on a system wide basis (i.e all stack-units or line cards as applicable) through a CLI command.

Restoring the Factory Default Settings

Restoring the factory-default settings deletes the existing NVRAM settings, startup configuration, and all configured settings such as,
stacking or fanout.

To restore the factory default settings, use the restore factory-defaults stack-unit {stack—unit—number | all}
{clear-all | nvram | bootvar} command in EXEC Privilege mode.

CAUTION:

There is no undo for this command.

Management 79

Important Points to Remember

• When you restore all the units in a stack, these units are placed in standalone mode.

• When you restore a single unit in a stack, only that unit is placed in standalone mode. No other units in the stack are affected.

• When you restore the units in standalone mode, the units remain in standalone mode after the restoration.

• After the restore is complete, the units power cycle immediately.

The following example illustrates the restore factory-defaults command to restore the factory default settings.

DellEMC#restore factory-defaults stack-unit 1 nvram

***********************************************************************
* Warning - Restoring factory defaults will delete the existing *
* persistent settings (stacking, fanout, etc.) *
* After restoration the unit(s) will be powercycled immediately. *
* Proceed with caution ! *
***********************************************************************

Proceed with factory settings? Confirm [yes/no]:yes

-- Restore status -­Unit Nvram Config

-----------------------­ 1 Success

Power-cycling the unit(s).

....

Restoring Factory Default Environment Variables

The Boot line determines the location of the image that is used to boot up the chassis after restoring factory default settings. Ideally,
these locations contain valid images, using which the chassis boots up.

When you restore factory-default settings, you can either use a flash boot procedure or a network boot procedure to boot the switch.

When you use the flash boot procedure to boot the device, the boot loader checks if the primary or the secondary partition contains a
valid image. If the primary partition contains a valid image, then the primary boot line is set to A: and the secondary and default boot lines
are set to a Null String. If the secondary partition contains a valid image, then the primary boot line is set to B: and the secondary and
default boot lines are set to a Null String. If both the partitions contain invalid images, then primary, secondary, and default boot line values
are set to a Null string.

When you use the Network boot procedure to boot the device, the boot loader checks if the primary partition contains a valid image. If a
valid image exists on the primary partition and the secondary partition does not contain a valid image, then the primary boot line is set to A:
and the secondary and default boot lines are set to a Null string. If the secondary partition also contains a valid image, then the primary
boot line value is set to the partition that is configured to be used to boot the device in a network failure scenario. The secondary and
default boot line values are set to a Null string.

Important Points to Remember

• The Chassis remains in boot prompt if none of the partitions contain valid images.

• To enable TFTP boot after restoring factory default settings, you must stop the boot process in BLI.

In case the system fails to reload the image from the partition, perform the following steps:

1. Power-cycle the chassis (pull the power cord and reinsert it).

2. Hit any key to abort the boot process. You enter uBoot immediately, the => prompt indicates success.

(during bootup)

press any key

3. Assign the new location to the Dell EMC Networking OS image it uses when the system reloads.

uBoot mode

=> setenv primary_boot f10boot

Boot variable (f10boot) can take the following values:

• flash0 — to boot from flash partition A.

80

Management

• flash1 — to boot from flash partition B.

• tftp://server-ip/image-file-name — to boot from the network.

4. Assign an IP address to the Management Ethernet interface.

uBoot mode

=> setenv ipaddr ip_address

For example, 10.16.150.105.

=> setenv netmask mask

For example, 255.255.0.0.

5. Assign an IP address as the default gateway for the system.

uBoot mode

=> setenv gatewayip gateway_ip_address

For example, 10.16.150.254.

6. Save the modified environmental variables.

uBoot mode

=> saveenv

7. Reload the system.

uBoot mode

reset

Viewing the Reason for Last System Reboot

You can view the reason for the last system reboot. To view the reason for the last system reboot, follow this procedure:

• Use the following command to view the reason for the last system reboot:
EXEC or EXEC Privilege mode

show reset-reason [stack-unit {unit-number | all}]

Enter the stack-unit keyword and the stack unit number to view the reason for the last system reboot for that stack unit.

Enter the stack-unit keyword and the keyword all to view the reason for the last system reboot of all stack units in the stack.

DellEMC#show reset-reason
Cause : Reset by User through CLI command
Reset Time: 11/05/2017-08:36

DellEMC# show reset-reason stack-unit 1
Cause : Reset by User through CLI command
Reset Time: 11/05/2017-08:36

Management

81

5

802.1X

802.1X is a port-based Network Access Control (PNAC) that provides an authentication mechanism to devices wishing to attach to a LAN

or WLAN. A device connected to a port that is enabled with 802.1X is disallowed from sending or receiving packets on the network until its
identity is verified (through a username and password, for example).

802.1X employs Extensible Authentication Protocol (EAP) to transfer a device’s credentials to an authentication server (typically RADIUS)

using a mandatory intermediary network access device, in this case, a Dell EMC Networking switch. The network access device mediates
all communication between the end-user device and the authentication server so that the network remains secure. The network access
device uses EAP-over-Ethernet (EAPOL) to communicate with the end-user device and EAP-over-RADIUS to communicate with the
server.

NOTE: The Dell EMC Networking Operating System (OS) supports 802.1X with EAP-MD5, EAP-OTP, EAP-TLS, EAP-

TTLS, PEAPv0, PEAPv1, and MS-CHAPv2 with PEAP.

The following figures show how the EAP frames are encapsulated in Ethernet and RADIUS frames.

Figure 3. EAP Frames Encapsulated in Ethernet and RADUIS

Figure 4. EAP Frames Encapsulated in Ethernet and RADUIS

The authentication process involves three devices:

82 802.1X

• The device attempting to access the network is the supplicant. The supplicant is not allowed to communicate on the network until
the authenticator authorizes the port. It can only communicate with the authenticator in response to 802.1X requests.

• The device with which the supplicant communicates is the authenticator. The authenticator is the gate keeper of the network. It
translates and forwards requests and responses between the authentication server and the supplicant. The authenticator also changes
the status of the port based on the results of the authentication process. The Dell EMC Networking switch is the authenticator.

• The authentication-server selects the authentication method, verifies the information the supplicant provides, and grants it network
access privileges.

Ports can be in one of two states:

• Ports are in an unauthorized state by default. In this state, non-802.1X traffic cannot be forwarded in or out of the port.

• The authenticator changes the port state to authorized if the server can authenticate the supplicant. In this state, network traffic can
be forwarded normally.

NOTE: The Dell EMC Networking switches place 802.1X-enabled ports in the unauthorized state by default.

Topics:

• Port-Authentication Process

• Configuring 802.1X

• Important Points to Remember

• Enabling 802.1X

• Configuring Request Identity Re-Transmissions

• Forcibly Authorizing or Unauthorizing a Port

• Re-Authenticating a Port

• Configuring Timeouts

• Configuring Dynamic VLAN Assignment with Port Authentication

• Guest and Authentication-Fail VLANs

Port-Authentication Process

The authentication process begins when the authenticator senses that a link status has changed from down to up:

1. When the authenticator senses a link state change, it requests that the supplicant identify itself using an EAP Identity Request frame.

2. The supplicant responds with its identity in an EAP Response Identity frame.

3. The authenticator decapsulates the EAP response from the EAPOL frame, encapsulates it in a RADIUS Access-Request frame and
forwards the frame to the authentication server.

4. The authentication server replies with an Access-Challenge frame. The Access-Challenge frame requests the supplicant to prove that
it is who it claims to be, using a specified method (an EAP-Method). The challenge is translated and forwarded to the supplicant by
the authenticator.

5. The supplicant can negotiate the authentication method, but if it is acceptable, the supplicant provides the Requested Challenge
information in an EAP response, which is translated and forwarded to the authentication server as another Access-Request frame.

6. If the identity information provided by the supplicant is valid, the authentication server sends an Access-Accept frame in which
network privileges are specified. The authenticator changes the port state to authorized and forwards an EAP Success frame. If the
identity information is invalid, the server sends an Access-Reject frame. If the port state remains unauthorized, the authenticator
forwards an EAP Failure frame.

802.1X

83

Figure 5. EAP Port-Authentication

EAP over RADIUS

802.1X uses RADIUS to shuttle EAP packets between the authenticator and the authentication server, as defined in RFC 3579.

EAP messages are encapsulated in RADIUS packets as a type of attribute in Type, Length, Value (TLV) format. The Type value for EAP
messages is 79.

Figure 6. EAP Over RADIUS

RADIUS Attributes for 802.1X Support

Dell EMC Networking systems include the following RADIUS attributes in all 802.1X-triggered Access-Request messages:

Attribute 31

Attribute 41 NAS-Port-Type: NAS-port physical port type. 15 indicates Ethernet.

Attribute 61 NAS-Port: the physical port number by which the authenticator is connected to the supplicant.

Attribute 81 Tunnel-Private-Group-ID: associate a tunneled session with a particular group of users.

Calling-station-id: relays the supplicant MAC address to the authentication server.

Configuring 802.1X

Configuring 802.1X on a port is a one-step process.

For more information, refer to Enabling 802.1X.

84

802.1X

Related Configuration Tasks

• Configuring Request Identity Re-Transmissions

• Forcibly Authorizing or Unauthorizing a Port

• Re-Authenticating a Port

• Configuring Timeouts

• Configuring a Guest VLAN

• Configuring an Authentication-Fail VLAN

Important Points to Remember

• Dell EMC Networking OS supports 802.1X with EAP-MD5, EAP-OTP, EAP-TLS, EAP-TTLS, PEAPv0, PEAPv1, and MS-CHAPv2 with
PEAP.

• All platforms support only RADIUS as the authentication server.

• If the primary RADIUS server becomes unresponsive, the authenticator begins using a secondary RADIUS server, if configured.

• 802.1X is not supported on port-channels or port-channel members.

• The NAS-Port-Type attribute indicates the type of the physical port of the NAS which is authenticating the user. It is used in Access­Request packets. The value of this attribute is set as Ethernet (15) for both EAP and MAB supplicants.

Enabling 802.1X

Enable 802.1X globally.

Figure 7. 802.1X Enabled

802.1X

85

1. Enable 802.1X globally.
CONFIGURATION mode

dot1x authentication

2. Enter INTERFACE mode on an interface or a range of interfaces.
INTERFACE mode

interface [range]

3. Enable 802.1X on the supplicant interface only.
INTERFACE mode

dot1x authentication

Verify that 802.1X is enabled globally and at the interface level using the show running-config | find dot1x command from
EXEC Privilege mode.

In the following example, the bold lines show that 802.1X is enabled.

DellEMC#show running-config | find dot1x

dot1x authentication

!
[output omitted]
!
interface TenGigabitEthernet 2/1
no ip address

dot1x authentication

no shutdown
!
DellEMC#

To view 802.1X configuration information for an interface, use the show dot1x interface command.

In the following example, the bold lines show that 802.1X is enabled on all ports unauthorized by default.

DellEMC#show dot1x interface TenGigabitEthernet 2/1/

802.1x information on Te 2/1/:

-----------------------------

Dot1x Status: Enable

Port Control: AUTO

Port Auth Status: UNAUTHORIZED

Re-Authentication: Disable
Untagged VLAN id: None
Guest VLAN: Disable
Guest VLAN id: NONE
Auth-Fail VLAN: Disable
Auth-Fail VLAN id: NONE
Auth-Fail Max-Attempts: NONE
Mac-Auth-Bypass: Disable
Mac-Auth-Bypass Only: Disable
Tx Period: 30 seconds
Quiet Period: 60 seconds
ReAuth Max: 2
Supplicant Timeout: 30 seconds
Server Timeout: 30 seconds
Re-Auth Interval: 3600 seconds
Max-EAP-Req: 2
Host Mode: SINGLE_HOST
Auth PAE State: Initialize
Backend State: Initialize

Configuring Request Identity Re-Transmissions

When the authenticator sends a Request Identity frame and the supplicant does not respond, the authenticator waits for 30 seconds and
then re-transmits the frame.

The amount of time that the authenticator waits before re-transmitting and the maximum number of times that the authenticator re­transmits can be configured.

86

802.1X

NOTE: There are several reasons why the supplicant might fail to respond; for example, the supplicant might have been

booting when the request arrived or there might be a physical layer problem.

To configure re-transmissions, use the following commands.

• Configure the amount of time that the authenticator waits before re-transmitting an EAP Request Identity frame.
INTERFACE mode

dot1x tx-period number

The range is from 1 to 65535 (1 year)
The default is 30.

• Configure the maximum number of times the authenticator re-transmits a Request Identity frame.
INTERFACE mode

dot1x max-eap-req number

The range is from 1 to 10.
The default is 2.

The example in Configuring a Quiet Period after a Failed Authentication shows configuration information for a port for which the
authenticator re-transmits an EAP Request Identity frame after 90 seconds and re-transmits for 10 times.

Configuring a Quiet Period after a Failed Authentication

If the supplicant fails the authentication process, the authenticator sends another Request Identity frame after 30 seconds by default. You
can configure this period.

NOTE:

Identity Re-transmit interval (dot1x tx-period) is for an unresponsive supplicant.

To configure a quiet period, use the following command.

• Configure the amount of time that the authenticator waits to re-transmit a Request Identity frame after a failed authentication.
INTERFACE mode

dot1x quiet-period seconds

The range is from 1 to 65535.
The default is 60 seconds.

The following example shows configuration information for a port for which the authenticator re-transmits an EAP Request Identity frame:

• after 90 seconds and a maximum of 10 times for an unresponsive supplicant

• re-transmits an EAP Request Identity frame

The bold lines show the new re-transmit interval, new quiet period, and new maximum re-transmissions.

DellEMC(conf-if-range-Te-2/1)#dot1x tx-period 90
DellEMC(conf-if-range-Te-2/1)#dot1x max-eap-req 10
DellEMC(conf-if-range-Te-2/1)#dot1x quiet-period 120
DellEMC#show dot1x interface TenGigabitEthernet 2/1

802.1x information on Te 2/1:

----------------------------­Dot1x Status: Enable
Port Control: AUTO
Port Auth Status: UNAUTHORIZED

Re-Authentication: Disable

Untagged VLAN id: None
Tx Period: 90 seconds

Quiet Period: 120 seconds

ReAuth Max: 2
Supplicant Timeout: 30 seconds
Server Timeout: 30 seconds
Re-Auth Interval: 3600 seconds

Max-EAP-Req: 10

Auth Type: SINGLE_HOST
Auth PAE State: Initialize
Backend State: Initialize

The quiet period (dot1x quiet-period) is the transmit interval after a failed authentication; the Request

802.1X

87

Forcibly Authorizing or Unauthorizing a Port

The 802.1X ports can be placed into any of the three states:

• ForceAuthorized — an authorized state. A device connected to this port in this state is never subjected to the authentication
process, but is allowed to communicate on the network. Placing the port in this state is same as disabling 802.1X on the port.

• ForceUnauthorized — an unauthorized state. A device connected to a port in this state is never subjected to the authentication
process and is not allowed to communicate on the network. Placing the port in this state is the same as shutting down the port. Any
attempt by the supplicant to initiate authentication is ignored.

• Auto — an unauthorized state by default. A device connected to this port in this state is subjected to the authentication process. If
the process is successful, the port is authorized and the connected device can communicate on the network. All ports are placed in
the Auto state by default.

To set the port state, use the following command.

• Place a port in the ForceAuthorized, ForceUnauthorized, or Auto state.
INTERFACE mode

dot1x port-control {force-authorized | force-unauthorized | auto}

The default state is auto.

The example shows configuration information for a port that has been force-authorized.

The bold line shows the new port-control state.

DellEMC(conf-if-Te-1/1)#dot1x port-control force-authorized
DellEMC(conf-if-Te-1/1)#show dot1x interface TenGigabitEthernet 1/1

802.1x information on Te 1/1:

----------------------------­Dot1x Status: Enable

Port Control: FORCE_AUTHORIZED

Port Auth Status: UNAUTHORIZED
Re-Authentication: Disable
Untagged VLAN id: None
Tx Period: 90 seconds
Quiet Period: 120 seconds
ReAuth Max: 2
Supplicant Timeout: 30 seconds
Server Timeout: 30 seconds
Re-Auth Interval: 3600 seconds
Max-EAP-Req: 10
Auth Type: SINGLE_HOST
Auth PAE State: Initialize
Backend State: Initialize
Auth PAE State: Initialize
Backend State: Initialize

Re-Authenticating a Port

You can configure the authenticator for periodic re-authentication.

After the supplicant has been authenticated, and the port has been authorized, you can configure the authenticator to re-authenticate the
supplicant periodically. If you enable re-authentication, the supplicant is required to re-authenticate every 3600 seconds by default, and
you can configure this interval. You can configure the maximum number of re-authentications as well.

To configure re-authentication time settings, use the following commands:

• Configure the authenticator to periodically re-authenticate the supplicant.
INTERFACE mode

dot1x reauthentication [interval] seconds

The range is from 1 to 31536000.
The default is 3600.

• Configure the maximum number of times the supplicant can be re-authenticated.
INTERFACE mode

dot1x reauth-max number

88

802.1X

The range is from 1 to 10.
The default is 2.

The bold lines show that re-authentication is enabled and the new maximum and re-authentication time period.

DellEMC(conf-if-Te-1/1)#dot1x reauthentication interval 7200
DellEMC(conf-if-Te-1/1)#dot1x reauth-max 10
DellEMC(conf-if-Te-1/1)#do show dot1x interface TenGigabitEthernet 1/1

802.1x information on Te 1/1:

----------------------------­Dot1x Status: Enable
Port Control: FORCE_AUTHORIZED

Port Auth Status: UNAUTHORIZED

Re-Authentication: Enable
Untagged VLAN id: None
Tx Period: 90 seconds
Quiet Period: 120 seconds

ReAuth Max: 10

Supplicant Timeout: 30 seconds
Server Timeout: 30 seconds

Re-Auth Interval: 7200 seconds

Max-EAP-Req: 10
Auth Type: SINGLE_HOST
Auth PAE State: Initialize
Backend State: Initialize
Auth PAE State: Initialize
Backend State: Initialize

Configuring Timeouts

If the supplicant or the authentication server is unresponsive, the authenticator terminates the authentication process after 30 seconds by
default. You can configure the amount of time the authenticator waits for a response.

To terminate the authentication process, use the following commands:

• Terminate the authentication process due to an unresponsive supplicant.
INTERFACE mode

dot1x supplicant-timeout seconds

The range is from 1 to 300.
The default is 30.

• Terminate the authentication process due to an unresponsive authentication server.
INTERFACE mode

dot1x server-timeout seconds

The range is from 1 to 300.
The default is 30.

The example shows configuration information for a port for which the authenticator terminates the authentication process for an
unresponsive supplicant or server after 15 seconds.

The bold lines show the new supplicant and server timeouts.

DellEMC(conf-if-Te-1/1)#dot1x port-control force-authorized
DellEMC(conf-if-Te-1/1)#do show dot1x interface TenGigabitEthernet 1/1

802.1x information on Te 1/1:

----------------------------­Dot1x Status: Enable
Port Control: FORCE_AUTHORIZED
Port Auth Status: UNAUTHORIZED
Re-Authentication: Disable
Untagged VLAN id: None
Guest VLAN: Disable
Guest VLAN id: NONE
Auth-Fail VLAN: Disable
Auth-Fail VLAN id: NONE
Auth-Fail Max-Attempts: NONE

802.1X

89

Tx Period: 90 seconds
Quiet Period: 120 seconds
ReAuth Max: 10

Supplicant Timeout: 15 seconds
Server Timeout: 15 seconds

Re-Auth Interval: 7200 seconds
Max-EAP-Req: 10

Auth Type: SINGLE_HOST
Auth PAE State: Initialize
Backend State: Initialize

Enter the tasks the user should do after finishing this task (optional).

Configuring Dynamic VLAN Assignment with Port Authentication

Dell EMC Networking OS supports dynamic VLAN assignment when using 802.1X.

The basis for VLAN assignment is RADIUS attribute 81, Tunnel-Private-Group-ID. Dynamic VLAN assignment uses the standard dot1x
procedure:

1. The host sends a dot1x packet to the Dell EMC Networking system

2. The system forwards a RADIUS REQEST packet containing the host MAC address and ingress port number

3. The RADIUS server authenticates the request and returns a RADIUS ACCEPT message with the VLAN assignment using Tunnel­Private-Group-ID

The illustration shows the configuration on the Dell EMC Networking system before connecting the end user device in black and blue text,
and after connecting the device in red text. The blue text corresponds to the preceding numbered steps on dynamic VLAN assignment
with 802.1X.

Figure 8. Dynamic VLAN Assignment

90

802.1X

1. Configure 8021.x globally (refer to Enabling 802.1X) along with relevant RADIUS server configurations (refer to the illustration
inDynamic VLAN Assignment with Port Authentication).

2. Make the interface a switchport so that it can be assigned to a VLAN.

3. Create the VLAN to which the interface will be assigned.

4. Connect the supplicant to the port configured for 802.1X.

5. Verify that the port has been authorized and placed in the desired VLAN (refer to the illustration in Dynamic VLAN Assignment with

Port Authentication).

Guest and Authentication-Fail VLANs

Typically, the authenticator (the Dell system) denies the supplicant access to the network until the supplicant is authenticated. If the
supplicant is authenticated, the authenticator enables the port and places it in either the VLAN for which the port is configured or the
VLAN that the authentication server indicates in the authentication data.

NOTE:

If the supplicant fails authentication, the authenticator typically does not enable the port. In some cases this behavior is not appropriate.
External users of an enterprise network, for example, might not be able to be authenticated, but still need access to the network. Also,
some dumb-terminals, such as network printers, do not have 802.1X capability and therefore cannot authenticate themselves. To be able
to connect such devices, they must be allowed access the network without compromising network security.

The Guest VLAN 802.1X extension addresses this limitation with regard to non-802.1X capable devices and the Authentication-fail VLAN

802.1X extension addresses this limitation with regard to external users.

• If the supplicant fails authentication a specified number of times, the authenticator places the port in the Authentication-fail VLAN.

• If a port is already forwarding on the Guest VLAN when 802.1X is enabled, the port is moved out of the Guest VLAN and the
authentication process begins.

Ports cannot be dynamically assigned to the default VLAN.

Configuring a Guest VLAN

If the supplicant does not respond within a determined amount of time ([reauth-max + 1] * tx-period, the system assumes that the host
does not have 802.1X capability and the port is placed in the Guest VLAN.

NOTE:

Configure a port to be placed in the Guest VLAN after failing to respond within the timeout period using the dot1x guest-vlan
command from INTERFACE mode. View your configuration using the show config command from INTERFACE mode or using the
show dot1x interface command from EXEC Privilege mode.

Example of Viewing Guest VLAN Configuration

DellEMC(conf-if-Te-2/1)#dot1x guest-vlan 200
DellEMC(conf-if-Te 2/1))#show config
!
interface TenGigabitEthernet 2/1
switchport
dot1x guest-vlan 200
no shutdown
DellEMC(conf-if-Te 2/1))#

For more information about configuring timeouts, refer to Configuring Timeouts.

Configuring an Authentication-Fail VLAN

If the supplicant fails authentication, the authenticator re-attempts to authenticate after a specified amount of time.

NOTE:

Authentication.

For more information about authenticator re-attempts, refer to Configuring a Quiet Period after a Failed

You can configure the maximum number of times the authenticator re-attempts authentication after a failure (3 by default), after which
the port is placed in the Authentication-fail VLAN.

Configure a port to be placed in the VLAN after failing the authentication process as specified number of times using the dot1x auth-
fail-vlan command from INTERFACE mode. Configure the maximum number of authentication attempts by the authenticator using
the keyword

max-attempts with this command.

802.1X

91

Example of Configuring Maximum Authentication Attempts

DellEMC(conf-if-Te-2/1)#dot1x guest-vlan 200
DellEMC(conf-if-Te 2/1)#show config
!
interface TenGigabitEthernet 2/1
switchport
dot1x authentication
dot1x guest-vlan 200
no shutdown
DellEMC(conf-if-Te-2/1)#

DellEMC(conf-if-Te-2/1)#dot1x auth-fail-vlan 100 max-attempts 5
DellEMC(conf-if-Te-2/1)#show config
!
interface TenGigabitEthernet 2/1
switchport
dot1x authentication
dot1x guest-vlan 200
dot1x auth-fail-vlan 100 max-attempts 5
no shutdown
DellEMC(conf-if-Te-2/1)#

View your configuration using the show config command from INTERFACE mode, as shown in the example in Configuring a Guest

VLAN or using the show dot1x interface command from EXEC Privilege mode.

Example of Viewing Configured Authentication

802.1x information on Te 2/1:

----------------------------­Dot1x Status: Enable
Port Control: FORCE_AUTHORIZED
Port Auth Status: UNAUTHORIZED
Re-Authentication: Disable
Untagged VLAN id: None

Guest VLAN: Disabled
Guest VLAN id: 200
Auth-Fail VLAN: Disabled
Auth-Fail VLAN id: 100
Auth-Fail Max-Attempts: 5

Tx Period: 90 seconds
Quiet Period: 120 seconds
ReAuth Max: 10
Supplicant Timeout: 15 seconds
Server Timeout: 15 seconds
Re-Auth Interval: 7200 seconds
Max-EAP-Req: 10
Auth Type: SINGLE_HOST

Auth PAE State: Initialize
Backend State: Initialize

92

802.1X

6

Access Control List (ACL) VLAN Groups and

Content Addressable Memory (CAM)

Optimizing CAM Utilization During the Attachment of ACLs to VLANs

To minimize the number of entries in CAM, enable and configure the ACL CAM feature. Use this feature when you apply ACLs to a VLAN
(or a set of VLANs) and when you apply ACLs to a set of ports. The ACL CAM feature allows you to effectively use the Layer 3 CAM
space with VLANs and Layer 2 and Layer 3 CAM space with ports.

To avoid using too much CAM space, configure ACL VLAN groups into a single group. A class identifier (Class ID) is assigned for each of
the ACLs attached to the VLAN and this Class ID is used as an identifier or locator in the CAM space instead of the VLAN ID. This method
of processing reduces the number of entries in the CAM area and saves memory space by using the Class ID for filtering in CAM instead
of the VLAN ID.

When you apply an ACL separately on the VLAN interface, each ACL has a mapping with the VLAN and you use more CAM space. To
maximize CAM space, create an ACL VLAN group and attach the ACL with the VLAN members.

The ACL manager application on the router processor (RP1) contains all the state information about all the ACL VLAN groups that are
present. The ACL handler on the control processor (CP) and the ACL agent on the line cards do not contain any information about the
group. After you enter the acl-vlan-group command, the ACL manager application performs the validation. If the command is valid, it
is processed and sent to the agent, if required. If a configuration error is found or if the maximum limit has exceeded for the ACL VLAN
groups present on the system, an error message displays. After you enter the acl-vlan-group command, the ACL manager application
verifies the following parameters:

• Whether the CAM profile is set in virtual flow processing (VFP).

• Whether the maximum number of groups in the system is exceeded.

• Whether the maximum number of VLAN numbers permitted per ACL group is exceeded.

• When a VLAN member that is being added is already a part of another ACL group.

After these verification steps are performed, the ACL manager considers the command valid and sends the information to the ACL agent
on the line card. The ACL manager notifies the ACL agent in the following cases:

• A VLAN member is added or removed from a group and previously associated VLANs exist in the group.

• The egress ACL is applied or removed from the group and the group contains VLAN members.

• VLAN members are added or deleted from a VLAN, which itself is a group member.

• A line card returns to the active state after going down and this line card contains a VLAN that is a member of an ACL group.

• The ACL VLAN group is deleted and it contains VLAN members.

The ACL manager does not notify the ACL agent in the following cases:

• The ACL VLAN group is created.

• The ACL VLAN group is deleted and it does not contain VLAN members.

• The ACL is applied or removed from a group and the ACL group does not contain a VLAN member.

• The description of the ACL group is added or removed.

Guidelines for Configuring ACL VLAN Groups

Keep the following points in mind when you configure ACL VLAN groups:

• The interfaces where you apply the ACL VLAN group function as restricted interfaces. The ACL VLAN group name identifies the
group of VLANs that performs hierarchical filtering.

• You can add only one ACL to an interface at a time.

• When you attach an ACL VLAN group to the same interface, validation performs to determine whether the ACL is applied directly to
an interface. If you previously applied an ACL separately to the interface, an error occurs when you attempt to attach an ACL VLAN
group to the same interface.

Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM) 93

• The maximum number of members in an ACL VLAN group is determined by the type of switch and its hardware capabilities. This
scaling limit depends on the number of slices that are allocated for ACL CAM optimization. If one slice is allocated, the maximum
number of VLAN members is 256 for all ACL VLAN groups. If two slices are allocated, the maximum number of VLAN members is 512
for all ACL VLAN groups.

• The maximum number of VLAN groups that you can configure also depends on the hardware specifications of the switch. Each VLAN
group is mapped to a unique ID in the hardware. The maximum number of ACL VLAN groups supported is 31. Only a maximum of two
components (iSCSI counters, Open Flow, ACL optimization, and so on) can be allocated virtual flow processing slices at a time.

• Port ACL optimization is applicable only for ACLs that are applied without the VLAN range.

• If you enable the ACL VLAN group capability, you cannot view the statistical details of ACL rules per VLAN and per interface. You can
only view the counters per ACL only using the

• Within a port, you can apply Layer 2 ACLs on a VLAN or a set of VLANs. In this case, CAM optimization is not applied.

• To enable optimization of CAM space for Layer 2 or Layer 3 ACLs that are applied to ports, the port number is removed as a qualifier
for ACL application on ports, and port bits are used. When you apply the same ACL to a set of ports, the port bitmap is set when the
ACL flow processor (FP) entry is added. When you remove the ACL from a port, the port bitmap is removed.

• If you do not attach an ACL to any of the ports, the FP entries are deleted. Similarly, when the same ACL is applied on a set of ports,
only one set of entries is installed in the FP, thereby saving CAM space. Enable optimization using the optimized option in the

access-group command. This option is not valid for VLAN and link aggregation group (LAG) interfaces.

show ip accounting access list command.

ip

Configuring ACL VLAN Groups and Configuring FP Blocks for VLAN Parameters

This section describes how to optimize CAM blocks by configuring ACL VLAN groups that you can attach to VLAN interfaces. It also
describes how to configure FP blocks for different VLAN operations.

Configuring ACL VLAN Groups

You can create an ACL VLAN group and attach the ACL with the VLAN members. The optimization is applicable only when you create an
ACL VLAN group.

1. Create an ACL VLAN group.
CONFIGURATION mode

acl-vlan-group {group name}

2. Add a description to the ACL VLAN group.
CONFIGURATION (conf-acl-vl-grp) mode

description description

3. Add VLAN member(s) to an ACL VLAN group.
CONFIGURATION (conf-acl-vl-grp) mode

member vlan {VLAN-range}

4. Display all the ACL VLAN groups or display a specific ACL VLAN group, identified by name.
CONFIGURATION (conf-acl-vl-grp) mode

show acl-vlan-group {group name | detail}

DellEMC#show acl-vlan-group detail

Group Name :
TestGroupSeventeenTwenty

Vlan Members :
100,200,300

Group Name :
CustomerNumberIdentificationEleven

Vlan Members :
2-10,99

Group Name :
HostGroup

Vlan Members :

94

Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM)

1,1000
DellEMC#

Configuring FP Blocks for VLAN Parameters

To allocate the number of FP blocks for the various VLAN processes on the system, use the cam-acl-vlan command. To reset the
number of FP blocks to the default, use the no version of this command. By default, 0 groups are allocated for the ACL in VLAN
contentaware processor (VCAP). ACL VLAN groups or CAM optimization is not enabled by default. You also must allocate the slices for
CAM optimization.

1. Allocate the number of FP blocks for VLAN operations.
CONFIGURATION mode

cam-acl-vlan vlanopenflow <0-2>

2. Allocate the number of FP blocks for VLAN iSCSI counters.
CONFIGURATION mode

cam-acl-vlan vlaniscsi <0-2>

3. Allocate the number of FP blocks for ACL VLAN optimization.
CONFIGURATION mode

cam-acl-vlan vlanaclopt <0-2>

4. View the number of FP blocks that is allocated for the different VLAN services.
EXEC Privilege mode

DellEMC#show cam-usage switch
Stackunit|Portpipe| CAM Partition | Total CAM | Used CAM |Available CAM
========|========|=================|============|============|=============
1 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | OUT-L2 ACL | 206 | 9 | 197
Codes: * - cam usage is above 90%.

Viewing CAM Usage

View the amount of CAM space available, used, and remaining in each partition (including IPv4Flow and Layer 2 ACL sub- partitions) using

show cam-usage command in EXEC Privilege mode.

the

Display Layer 2, Layer 3, ACL, or all CAM usage statistics.
EXCE Privilege mode

show cam usage [acl | router | switch]

The following output shows CAM blocks usage for Layer 2 and Layer 3 ACLs and other processes that use CAM space:

DellEMC#show cam-usage
Stackunit|Portpipe| CAM Partition | Total CAM | Used CAM |Available CAM
========|========|=================|=============|=============|==============
1 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-L3 ECMP GRP | 1024 | 0 | 1024
| | IN-L3 FIB | 49152 | 3 | 49149
| | IN-V6 ACL | 0 | 0 | 0
| | IN-NLB ACL | 0 | 0 | 0
| | IPMAC ACL | 0 | 0 | 0
| | OUT-L2 ACL | 206 | 9 | 197
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
2 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-L3 FIB | 49152 | 3 | 49149
| | IN-V6 ACL | 0 | 0 | 0
| | IN-NLB ACL | 0 | 0 | 0
| | IPMAC ACL | 0 | 0 | 0
| | OUT-L2 ACL | 206 | 9 | 197
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
3 | 0 | IN-L2 ACL | 1536 | 0 | 1536

Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM)

95

| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-L3 FIB | 49152 | 3 | 49149
| | IN-V6 ACL | 0 | 0 | 0
| | IN-NLB ACL | 0 | 0 | 0
| | IPMAC ACL | 0 | 0 | 0
| | OUT-L2 ACL | 206 | 9 | 197
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
Codes: * - cam usage is above 90%.

The following output displays CAM space usage when you configure Layer 2 and Layer 3 ACLs:

DellEMC#show cam-usage acl
Stackunit|Portpipe| CAM Partition | Total CAM | Used CAM |Available CAM
========|========|=================|=============|=============|==============
1 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-L3 ECMP GRP | 1024 | 0 | 1024
| | IN-V6 ACL | 0 | 0 | 0
| | OUT-L2 ACL | 206 | 9 | 197
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
2 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-V6 ACL | 0 | 0 | 0
| | OUT-L2 ACL | 206 | 9 | 197
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
3 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-V6 ACL | 0 | 0 | 0
| | OUT-L2 ACL | 206 | 9 | 197
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
Codes: * - cam usage is above 90%.

The following output displays CAM space usage for Layer 2 ACLs:

DellEMC#show cam-usage switch
Stackunit|Portpipe| CAM Partition | Total CAM | Used CAM |Available CAM
========|========|=================|=============|=============|==============
1 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | OUT-L2 ACL | 206 | 9 | 197
2 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | OUT-L2 ACL | 206 | 9 | 197
3 | 0 | IN-L2 ACL | 1536 | 0 | 1536
| | OUT-L2 ACL | 206 | 9 | 197
| | IN-L3 ECMP GRP | 1024 | 0 | 1024
Codes: * - cam usage is above 90%.

The following output displays CAM space usage for Layer 3 ACLs:

DellEMC#show cam-usage router
Stackunit|Portpipe| CAM Partition | Total CAM | Used CAM |Available CAM
========|========|=================|=============|=============|==============
1 | 0 | IN-L3 FIB | 49152 | 3 | 49149
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-L3 ECMP GRP | 1024 | 0 | 1024
| | IN-V6 ACL | 0 | 0 | 0
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
2 | 0 | IN-L3 FIB | 49152 | 3 | 49149
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-V6 ACL | 0 | 0 | 0
| | OUT-L3 ACL | 178 | 9 | 169
| | OUT-V6 ACL | 178 | 4 | 174
3 | 0 | IN-L3 FIB | 49152 | 3 | 49149
| | IN-L3 ACL | 1024 | 1 | 1023
| | IN-V6 ACL | 0 | 0 | 0
| | OUT-L3 ACL | 178 | 9 | 169

96

Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM)

| | OUT-V6 ACL | 178 | 4 | 174
Codes: * - cam usage is above 90%.

Allocating FP Blocks for VLAN Processes

The VLAN contentaware processor (VCAP) application is a pre-ingress CAP that modifies the VLAN settings before packets are
forwarded. To support ACL CAM optimization, the CAM carving feature is enhanced. A total of four VCAP groups are present: two fixed
groups and two dynamic groups. Of the two dynamic groups, you can allocate zero, one, or two FP blocks to
and ACL Optimization.

You can configure only two of these features at a time.

• To allocate the number of FP blocks for VLAN open flow operations, use the cam-acl-vlan vlanopenflow <0-2> command.

• To allocate the number of FP blocks for VLAN iSCSI counters, use the cam-acl-vlan vlaniscsi <0-2> command.

• To allocate the number of FP blocks for ACL VLAN optimization, use the cam-acl-vlan vlanaclopt <0-2> command.

To reset the number of FP blocks to the default, use the no version of these commands. By default, zero groups are allocated for the ACL
in VCAP. ACL VLAN groups or CAM optimization is not enabled by default. You must also allocate the slices for CAM optimization.

To display the number of FP blocks that is allocated for the different VLAN services, use the show cam-acl-vlan command. After you
configure the ACL VLAN groups, reboot the system to store the settings in nonvolatile storage. During CAM initialization, the chassis
manager reads the NVRAM and allocates the dynamic VCAP regions.

iSCSI Counters, Open Flow,

Unified Forwarding Table (UFT) Modes

Unified Forwarding Table (UFT) consolidates the resources of several search tables (Layer 2, Layer 3 Hosts, and Layer 3 Route [Longest
Prefix Match — LPM]) into a single flexible resource. Dell EMC Networking OS supports several UFT modes to extract the forwarding
tables, as required. By default, Dell EMC Networking OS initializes the table sizes to UFT mode 2 profile, since it provides a reasonable
shared memory for all the tables. The other supported UFT modes are scaled-l3–hosts (UFT mode 3) and scaled-l3–routes (UFT mode

4).

Configuring UFT Modes

To configure the Unified Forwarding Table (UFT) modes, follow these steps.

1. Select a mode to initialize the maximum scalability size for L2 MAC table or L3 Host table or L3 Route table.
CONFIGURATION

hardware forwarding-table mode

DellEMC(conf)#hardware forwarding-table mode ?
scaled-l3-hosts Forwarding table mode for scaling L3 host entries
scaled-l3-routes Forwarding table mode for scaling L3 route entries
DellEMC(conf)#
DellEMC(conf)#hardware forwarding-table mode scaled-l3-hosts
Hardware forwarding-table mode is changed. Save the configuration and reload to take
effect.
DellEMC(conf)#end
DellEMC#write mem
!
01:13:36: %STKUNIT0-M:CP %FILEMGR-5-FILESAVED: Copied running-config to startup-config in
flash by default

DellEMC(conf)#
DellEMC(conf)#end
DellEMC#01:13:44: %STKUNIT0-M:CP %SYS-5-CONFIG_I: Configured from console

DellEMC#

2. Display the hardware forwarding table mode in the current boot and in the next boot.
EXEC Privilege

show hardware forwarding-table mode

Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM)

97

7

Access Control Lists (ACLs)

This chapter describes access control lists (ACLs), prefix lists, and route-maps.

At their simplest, access control lists (ACLs), prefix lists, and route-maps permit or deny traffic based on MAC and/or IP addresses. This
chapter describes implementing IP ACLs, IP prefix lists and route-maps. For MAC ACLS, refer to Layer 2.

An ACL is essentially a filter containing some criteria to match (examine IP, transmission control protocol [TCP], or user datagram protocol
[UDP] packets) and an action to take (permit or deny). ACLs are processed in sequence so that if a packet does not match the criterion in
the first filter, the second filter (if configured) is applied. When a packet matches a filter, the switch drops or forwards the packet based
on the filter’s specified action. If the packet does not match any of the filters in the ACL, the packet is dropped (implicit deny).

The number of ACLs supported on a system depends on your content addressable memory (CAM) size. For more information, refer to

User Configurable CAM Allocation and CAM Optimization. For complete CAM profiling information, refer to Content Addressable Memory
(CAM).

You can configure ACLs on VRF instances. In addition to the existing qualifying parameters, Layer 3 ACLs also incorporate VRF ID as one
of the parameters. Using this new capability, you can also configure VRF based ACLs on interfaces.

NOTE:

You can apply VRF-aware ACLs on:

• VRF Instances

• Interfaces

In order to configure VRF-aware ACLs on VRF instances, you must carve out a separate CAM region. You can use the cam-acl
command for allocating CAM regions. As part of the enhancements to support VRF-aware ACLs, the cam-acl command now includes
the following new parameter that enables you to allocate a CAM region: vrfv4acl.

The order of priority for configuring user-defined ACL CAM regions is as follows:

• V4 ACL CAM

• VRF V4 ACL CAM

• L2 ACL CAM

With the inclusion of VRF based ACLs, the order of precedence of Layer 3 ACL rules is as follows:

• Port/VLAN based PERMIT/DENY Rules

• Port/VLAN based IMPLICIT DENY Rules

• VRF based PERMIT/DENY Rules

• VRF based IMPLICIT DENY Rules

NOTE:

permit option.

You can use the ip access-group command to configure VRF-aware ACLs on interfaces. Using the ip access-group command,
in addition to a range of VLANs, you can also specify a range of VRFs as input for configuring ACLs on interfaces. The VRF range is from 1
to 511. These ACLs use the existing V4 ACL CAM region to populate the entries in the hardware and do not require you to carve out a
separate CAM region.

You can apply Layer 3 VRF-aware ACLs only at the ingress level.

In order for the VRF ACLs to take effect, ACLs configured in the Layer 3 CAM region must have an implicit-

NOTE:

You can configure VRF-aware ACLs on interfaces either using a range of VLANs or a range of VRFs but not both.

Topics:

• IP Access Control Lists (ACLs)

• Important Points to Remember

• IP Fragment Handling

• Configure a Standard IP ACL

• Configure an Extended IP ACL

• Configure Layer 2 and Layer 3 ACLs

• Assign an IP ACL to an Interface

98 Access Control Lists (ACLs)

• Applying an IP ACL

• Configure Ingress ACLs

• Configure Egress ACLs

• IP Prefix Lists

• ACL Remarks

• ACL Resequencing

• Route Maps

• Logging of ACL Processes

• Flow-Based Monitoring

• Configuring UDF ACL

• Configuring IP Mirror Access Group

IP Access Control Lists (ACLs)

In Dell EMC Networking switch/routers, you can create two different types of IP ACLs: standard or extended.

A standard ACL filters packets based on the source IP packet. An extended ACL filters traffic based on the following criteria:

• IP protocol number

• Source IP address

• Destination IP address

• Source TCP port number

• Destination TCP port number

• Source UDP port number

• Destination UDP port number

For more information about ACL options, refer to the Dell EMC Networking OS Command Reference Guide.

For extended ACL, TCP, and UDP filters, you can match criteria on specific or ranges of TCP or UDP ports. For extended ACL TCP filters,
you can also match criteria on established TCP sessions.

When creating an access list, the sequence of the filters is important. You have a choice of assigning sequence numbers to the filters as
you enter them, or the Dell EMC Networking Operating System (OS) assigns numbers in the order the filters are created. The sequence
numbers are listed in the display output of the

Ingress and egress Hot Lock ACLs allow you to append or delete new rules into an existing ACL (already written into CAM) without
disrupting traffic flow. Existing entries in the CAM are shuffled to accommodate the new entries. Hot lock ACLs are enabled by default
and support both standard and extended ACLs and on all platforms.

show config and show ip accounting access-list commands.

NOTE:

Hot lock ACLs are supported for Ingress ACLs only.

CAM Usage

The following section describes CAM allocation and CAM optimization.

• User Configurable CAM Allocation

• CAM Optimization

User Configurable CAM Allocation

Allocate space for IPV6 ACLs by using the cam-acl command in CONFIGURATION mode.

The CAM space is allotted in filter processor (FP) blocks. The total space allocated must equal 13 FP blocks. (There are 16 FP blocks, but
System Flow requires three blocks that cannot be reallocated.)

Enter the ipv6acl allocation as a factor of 2 (2, 4, 6, 8, 10). All other profile allocations can use either even or odd numbered ranges.

If you want to configure ACL's on VRF instances, you must allocate a CAM region using the vrfv4acl option in the cam-acl command.

Save the new CAM settings to the startup-config (use write-mem or copy run start) then reload the system for the new settings
to take effect.

Access Control Lists (ACLs)

99

CAM Optimization

When you enable this command, if a policy map containing classification rules (ACL and/or dscp/ ip-precedence rules) is applied to more
than one physical interface on the same port-pipe, only a single copy of the policy is written (only one FP entry is used). When you disable
this command, the system behaves as described in this chapter.

Test CAM Usage

This command applies to both IPv4 and IPv6 CAM profiles, but is best used when verifying QoS optimization for IPv6 ACLs.

To determine whether sufficient ACL CAM space is available to enable a service-policy, use this command. To verify the actual CAM
space required, create a class map with all the required ACL rules, then execute the test cam-usage command in Privilege mode. The
following example shows the output when executing this command. The status column indicates whether you can enable the policy.

Example of the test cam-usage Command

DellEMC#test cam-usage service-policy input asd stack-unit 1 port-set 0

Stack-unit|Portpipe|CAM Partition|Available CAM|Estimated CAM per Port|Status

-------------------------------------------------------------------------­ 1| 1| IPv4Flow| 232| 0|Allowed
DellEMC#

Implementing ACLs on Dell EMC Networking OS

You can assign one IP ACL per interface. If you do not assign an IP ACL to an interface, it is not used by the software.

The number of entries allowed per ACL is hardware-dependent.

If counters are enabled on ACL rules that are already configured, those counters are reset when a new rule which is inserted or prepended
or appended requires a hardware shift in the flow table. Resetting the counters to 0 is transient as the proginal counter values are retained
after a few seconds. If there is no need to shift the flow in the hardware, the counters are not affected. This is applicable to the following
features:

• L2 Ingress Access list

• L2 Egress Access list

In the Dell EMC Networking OS versions prior to 9.13(0.0), the system does not install any of your ACL rules if the available CAM space is
lesser than what is required for your set of ACL rules. Effective with the Dell EMC Networking OS version 9.13(0.0), the system installs
your ACL rules until all the allocated CAM memory is used. If there is no implicit permit in your rule, the Dell EMC Networking OS ensures
that an implicit deny is installed at the end of your rule. This behavior is applicable for IPv4 and IPv6 ingress and egress ACLs.

NOTE:

packets destined for the local device which the CPU needs to process. The system access lists always override the user
configured access lists. Even if you configure ACL to block certain hosts, control plane protocols such as, ARP, BGP,
LACP, VLT, VRRP and so on, associated with such hosts cannot be blocked.

System access lists (system-flow entries) are pre-programmed in the system for lifting the control-plane

Assigning ACLs to VLANs

When you apply an ACL to a VLAN using single port-pipe, a copy of the ACL entries gets installed in the ACL CAM on the port-pipe. The
entry looks for the incoming VLAN in the packet. When you apply an ACL on individual ports of a VLAN, separate copies of the ACL
entries are installed for each port belonging to a port-pipe.

You can use the log keyword to log the details about the packets that match. The control processor becomes busy based on the number
of packets that match the log entry and the rate at which the details are logged in. However, the route processor (RP) is unaffected. You
can use this option for debugging issues related to control traffic.

ACL Optimization

If an access list contains duplicate entries, Dell EMC Networking OS deletes one entry to conserve CAM space.

Standard and extended ACLs take up the same amount of CAM space. A single ACL rule uses two CAM entries to identify whether the
access list is a standard or extended ACL.

100

Access Control Lists (ACLs)
