Dell OptiPlex
FX130 & FX170
VESA Mount
Manual
Notes, Cautions, and Warnings
NOTE:
A NOTE indicates important information that helps you make better use of your
thin client.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data
if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage, personal
injury, or death.
______________
Information in this document is subject to change without notice.
© 2011 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission
of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell™, the DELL logo, and OptiPlex™.
Other trademarks and trade names may be used in this publication to refer to either the
entities claiming the marks and names or their products. Dell Inc. disclaims any
proprietary interest in trademarks and trade names other than its own.
March 2011 Rev. A00
Dell OptiPlex FX130 & FX170
WARNING: Before beginning, turn off the thin client, disconnect the AC adapter
from the electrical outlet and the thin client, and remove any other external cables
from the thin client.
WARNING: Before installing your thin client in an enclosure, read the safety
instructions that shipped with your thin client.
1
VESA Mounting Plate
2
VESA Mounting Bracket
3
Screws
VESA Mount Manual
VESA Mounting Materials
| 3
VESA Bracket
NOTE:
Only one side plate has three mounting holes.
1
Remove the middle button on of the side plate on your thin client that has
three mounting holes.
| 4
2
Place the VESA mounting plate on the thin client’s side plate chassis and
insert the screws to secure the mounting plate to the thin client.
| 5
3
NOTE:
The VESA mount above is secured to the back of a monitor. Make sure
the mounting bracket is secured as shown above.
WARNING: Before beginning, turn off the thin client, disconnect the AC
adapter from the electrical outlet and the thin client, and remove any other
external cables from the thin client.
WARNING: Before installing your thin client in an enclosure, read the safety
instructions that shipped with your thin client.
CAUTION: Use a wall that supports at least 20 lbs. (9.1kg) of weight. Use
appropriate mounting hardware depending on wall material (hardware not
included).
WARNING: Before mounting the chassis to the wall bracket ensure that none
of the vents are blocked on the system.
Insert the screws to secure the VESA bracket.
4
Slide the VESA mounting plate attached to your thin client onto the
VESA mounting bracket.
Mounting the VESA Bracket to a Wall
1
Insert the screws to secure the VESA mounting bracket to the wall.
2
Slide the VESA mounting plate attached to your thin client onto the
VESA mounting bracket.
| 6
Getting Help
NOTE
: If you do not have an active Internet connection, you can find contact information
on your purchase invoice, packing slip, bill, or Dell product catalog.
Contacting Dell
For customers in the United States, call 800-WWW-DELL (800-999-3355).
Dell provides several online and telephone-based support and service options.
Availability varies by country and product, and some services may not be
available in your area. To contact Dell for sales, technical support, or customer
service issues:
1
Visit
support.dell.com
a Country/Region” drop down menu at the bottom of the page.
2
Click “Contact Us” on the left side of the page. Then select the
appropriate service or support link based on your needs.
3
Choose the method of contacting Dell that is convenient for you.
and verify your country or region in the “Choose
