Precision 3440 Small Form Factor
Setup and specifications guide
Regulatory Model: D15S Regulatory Type: D15S003 May 2020 Rev. A00
Contents
Chapter 1: Set up your computer......................................................................................................4
Chapter 2: Chassis overview............................................................................................................ 9
Front view...............................................................................................................................................................................9
Back view.............................................................................................................................................................................. 10
System board layout.............................................................................................................................................................11
Chapter 3: Specifications of Precision 3440 Small Form Factor......................................................... 12
System specifications.......................................................................................................................................................... 12
Support policy...................................................................................................................................................................... 22
Energy Star and Trusted Platform Module (TPM)......................................................................................................... 22
Accessories...........................................................................................................................................................................22
Add-in cards......................................................................................................................................................................... 22
Chapter 4: Getting help................................................................................................................. 23
Contacting Dell.....................................................................................................................................................................23
2 Contents
Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2020 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
Steps
1. Connect the keyboard and mouse.
1

Set up your computer

2. Connect to your network using a cable, or connect to a wireless network.
4 Set up your computer
3. Connect the display.
4. Connect the power cable.
Set up your computer
5
5. Press the power button.
6
Set up your computer
6. Finish operating system setup.
For Ubuntu:
Follow the on-screen instructions to complete the setup. For more information about installing and configuring Ubuntu, see the knowledge base articles SLN151664 and SLN151748 at www.dell.com/support.
For Windows:Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you:
• Connect to a network for Windows updates.
NOTE:
If connecting to a secured wireless network, enter the password for the wireless network access when
prompted.
• If connected to the internet, sign in with or create a Microsoft account. If not connected to the internet, create an offline account.
• On the Support and Protection screen, enter your contact details.
7. Locate and use Dell apps from the Windows Start menu—Recommended
Table 1. Locate Dell apps
Dell apps Details
Dell Product Registration
Register your computer with Dell.
Dell Help & Support
Access help and support for your computer.
Set up your computer 7
Table 1. Locate Dell apps (continued)
Dell apps Details
SupportAssist
Proactively checks the health of your computer’s hardware and software.
Dell Update
Updates your computer with critical fixes and important device drivers as they become available.
Dell Digital Delivery
Download software applications including software that is purchased but not preinstalled on your computer.
NOTE: Renew or upgrade your warranty by clicking the
warranty expiry date in SupportAssist.
8 Set up your computer
Topics:
• Front view
• Back view
• System board layout

Front view

2

Chassis overview

1. Power button and power light
2. SD card reader (Optional)
3. Hard drive activity light
4. Universal audio jack port
5. USB 2.0 Type-A port with PowerShare
6. USB 2.0 Type-A port
7. USB 3.2 Gen 2 Type-C port with PowerDelivery
8. USB 3.2 Gen2 Type-A port
9. Optical disk drive
Chassis overview 9

Back view

1.
Line -in/out retasking
2. Two DisplayPort 1.4 ports
3. Serial Port
4. PS/2 Keyboard port
5. USB 3.2 Gen 2 Type-A port
6. Two USB 2.0 ports with Power On
7. Expansion card slots
8. Power connector port
9. Power supply diagnostic light
10. Padlock loop
11. Network port
12. Three USB 3.2 Gen 1 Type-A ports
13. Kensington security-cable slot
14. PS/2 Mouse port
15. Release latch
10
Chassis overview

System board layout

1. Video connector 2. Intrusion switch connector (Intruder)
3. CPU power connector (ATX_CPU) 4. CPU fan connector
5. Memory slots (DIMM1, DIMM2, DIMM3, DIMM4) 6. M.2 Solid-state drive connector
7. Power switch connector (PWR_SW) 8. Remote PWR switch connector
9. Media card reader connector (Card_reader) 10. M.2 WLAN connector
11. System fan connector 12. SATA 1 connector
13. M.2 Soild-state drive connector 14. SATA 2 connector
15. PSU connector 16. SATA 3 connector
17. Internal speaker connector 18. SATA power connector
19. PCI-e connectors 20. Coin cell battery
21. USB Type-C connector 22. Processor socket (CPU)
Chassis overview 11
Specifications of Precision 3440 Small Form
Factor
Topics:
• System specifications
• Support policy
• Energy Star and Trusted Platform Module (TPM)
• Accessories
• Add-in cards

System specifications

NOTE: Offerings may vary by region. The following specifications are only those required by law to ship with your
computer. For more information about the configuration of your computer, go to Help and Support in your Windows
operating system and select the option to view information about your computer.
3

Dimensions and weight

Table 2. Dimensions and weight
Description Values
Height:
Front
Rear
Width
Depth
Weight (maximum)
290 mm (11.42 in.)
290 mm (11.42 in.)
92.6 mm (3.65 in.)
292.8 mm (11.53 in.)
5.59 kg (12.32 lb)
NOTE: The weight of your computer depends on the
configuration ordered and the manufacturing variability.

Chipset

Table 3. Chipset
Description Values
Chipset
Processor
DRAM bus width
Flash EPROM

12 Specifications of Precision 3440 Small Form Factor

Intel W480
10th Generation Intel Core i3/i5/i7/i9/Xeon
Two channels, 128-bit
32 MB
Table 3. Chipset (continued)
Description Values
PCIe bus
Non-volatile memory Yes
BIOS Configuration Serial Peripheral Interface (SPI) 256 Mbit (32 MB) located at SPI_FLASH on chipset
Trusted Platform Module (Discrete TPM Enabled) 24 KB located at TPM 2.0 on chipset
Firmware TPM (Discrete TPM Disabled) By default the Platform Trust Technology feature is visible to the
NIC EEPROM LOM configuration contained within SPI flash ROM instead of
Upto Gen 3
OS
LOM e-fuse

Processors

NOTE: Global Standard Products (GSP) are a subset of Dell’s relationship products that are managed for availability and
synchronized transitions on a worldwide basis. They ensure the same platform is available for purchase globally. This
allows customers to reduce the number of configurations managed on a worldwide basis, thereby reducing their costs.
They also enable companies to implement global IT standards by locking in specific product configurations worldwide.
Device Guard (DG) and Credential Guard (CG) are the new security features that are only available on Windows 10 Enterprise today.
Device Guard is a combination of enterprise-related hardware and software security features that, when configured together, will lock a device down so that it can only run trusted applications. If it is not a trusted application, it cannot run.
Credential Guard uses virtualization-based security to isolate secrets (credentials) so that only privileged system software can access them. Unauthorized access to these secrets can lead to credential theft attacks. Credential Guard prevents these attacks by protecting NTLM password hashes and Kerberos Ticket Granting Tickets.
NOTE:
Processor numbers are not a measure of performance. Processor availability is subject to change and may vary
by region/country.
Table 4. Processors
Processors Wattage Core
10th Generation Intel Core i3-10100
10th Generation Intel Core i5-10500
10th Generation Intel Core i5-10600
10th Generation Intel Core i7-10700
65 W 4 8 3.6 GHz to 4.3
65 W 6 12 3.1 GHz to 4.5
65 W 6 12 3.3 GHz to 4.8
65 W 8 16 2.9 GHz to 4.7
count
Thre
Speed Cache Integrated graphics GSP DG/CG ad coun t
6 MB Intel UHD Graphics 630
GHz
12 MB Intel UHD Graphics 630
GHz
12 MB Intel UHD Graphics 630
GHz
16 MB Intel UHD Graphics 630
GHz
No Yes
Yes Yes
Yes Yes
Yes Yes
Ready
Specifications of Precision 3440 Small Form Factor 13
Table 4. Processors (continued)
Processors Wattage Core
10th Generation Intel Core i9-10900
Intel Xeon W-1250
Intel Xeon W-1270
Intel Xeon W-1290
65 W 10 20 2.8 GHz to 4.6
80 W 6 12 3.3 GHz to 4.4
80 W 8 16 3.2 GHz to 4.7
80 W 10 20 3.7 GHz to 4.9
count

Operating system

• Windows 10 Home (64-bit)
• Windows 10 Enterprise (64-bit)
• Windows 10 Professional (64-bit)
• Windows 10 Pro Education (64-bit)
• Windows 10 LTSC (64-bit)
• Ubuntu 18.04
Thre
Speed Cache Integrated graphics GSP DG/CG ad coun t
20 MB Intel UHD Graphics 630
GHz
12 MB Intel UHD Graphics 630
GHz
16 MB Intel UHD Graphics 630
GHz
20 MB Intel UHD Graphics 630
GHz
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Ready

Memory

Table 5. Memory specifications
Description Values
Slots
Type
Speed
Maximum memory
Minimum memory
Memory size per slot
Configurations supported
4 DIMM slots
DDR4
• 2666 MHz for Intel Core i3/i5/Xeon W-1250 processors, 2933
128 GB
4 GB
4 GB, 8 GB, 16 GB, 32 GB
• 4 GB, 1 x 4 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon
• 8 GB, 2 x 4 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon
• 8 GB, 1 x 8 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon
MHz for Intel Core i7/i9/Xeon W-1270/W-1290 processors
W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon W-1270/W-1290 processors
W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon W-1270/W-1290 processors
W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon W-1270/W-1290 processors
14 Specifications of Precision 3440 Small Form Factor
Table 5. Memory specifications (continued)
Description Values
• 16 GB, 2 x 8 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon W-1270/W-1290 processors
• 32 GB, 4 x 8 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon W-1270/W-1290 processors
• 32 GB, 2 x 16 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon W-1270/W-1290 processors
• 64 GB, 4 x 16 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon W-1270/W-1290 processors
• 128 GB, 4 x 32 GB, DDR4, 2666 MHz for Intel Core i3/i5/Xeon W-1250 processors, 2933 MHz for Intel Core i7/i9/Xeon W-1270/W-1290 processors

Storage

Your computer supports one of the following configurations:
• One 2.5-inch hard-disk drive
• Two 2.5-inch hard-disk drives
• One 3.5-inch hard-disk drive
• One 2.5-inch hard-disk drive and one 3.5-inch hard-disk drive
• One M.2 2230 or 2280 solid-state drive (class 40)
• One M.2 2230 or 2280 solid-state drive (class 40) and one 3.5-inch hard-disk drive
• One M.2 2230 or 2280 solid-state drive (class 40) and one 2.5-inch hard-disk drive
• One M.2 2230 or 2280 solid-state drive (class 40) and two 2.5-inch hard-disk drives
Table 6. Storage specifications
Storage type Interface type Capacity
2.5 in. hard-disk drive, 5400 RPM SATA Upto 2 TB
2.5 in. hard-disk drive, 7200 RPM SATA Upto 1 TB
2.5 in. hard-disk drive, 7200 RPM, FIPS Self Encrypting Opal 2.0
3.5 in, hard-disk drive, 5400 RPM SATA Upto 4 TB
3.5 in, hard-disk drive, 7200 RPM SATA Upto 2 TB
M.2 2280 solid-state drive Gen 3 PCIe x4 NVMe, Class 40 Upto 2 TB
M.2 2280 Opal Self-Encrypting solid-state drive Gen 3 PCIe x4 NVMe, Class 40 Upto 1 TB
SATA Upto 500 GB

Audio and Speaker

Table 7. Audio specifications
Description Values
Type
4 Channel High Definition Audio
Specifications of Precision 3440 Small Form Factor 15
Table 7. Audio specifications (continued)
Description Values
Controller
Stereo conversion
Internal interface
External interface
Speakers
Internal speaker amplifier
External volume controls
Speaker output average
Speaker output peak
Subwoofer output
Microphone

Video

Realtek ALC3246
Supported
High definition audio interface
Universal Audio Jack
2
Integrated in ALC3246 (Class-D 2 W)
Keyboard shortcut controls
2 W
2.5 W
Not Supported
Not Supported
Table 8. Discrete graphics specifications
Discrete graphics
Controller External display support Memory size Memory Type
AMD Radeon R5 430 • Two DisplayPort 1.2 2 GB DDR3
AMD Radeon Pro WX 2100 • One DisplayPort 1.4
• Two Mini DisplayPort 1.4
AMD Radeon Pro WX 3200 • Four Mini DisplayPort 1.4 4 GB GDDR5
NVIDIA Quadro P400 • Three Mini DisplayPort 1.4 2 GB GDDR5
NVIDIA Quadro P620 • Four Mini DisplayPort 1.4 2 GB GDDR5
2 GB GDDR5
Table 9. Integrated graphics specifications
Integrated graphics
Controller External display support Memory size Processor
Intel UHD Graphics 630 Two DisplayPort 1.4 Shared system memory 10th Generation Intel
Core i3/i5/i7/i9
16 Specifications of Precision 3440 Small Form Factor

Communications

Ethernet
Table 10. Ethernet specifications
Description Values
Model number
Transfer rate
Intel i219-LM
10/100/1000 Mbps
Wireless module
Table 11. Wireless module specifications
Description Values
Model number
Transfer rate
Frequency bands supported
Wireless standards
Encryption
Qualcomm QCA61x4a (DW1820) Intel AX201
Up to 867 Mbps Up to 2400 Mbps
2.4 GHz/5 GHz 2.4 GHz/5 GHz
• WiFi 802.11a/b/g
• Wi-Fi 4 (WiFi 802.11n)
• Wi-Fi 5 (WiFi 802.11ac)
• 64-bit/128-bit WEP
• AES-CCMP
• TKIP
• Wi-Fi 802.11a/b/g
• Wi-Fi 4 (Wi-Fi 802.11n)
• Wi-Fi 5 (Wi-Fi 802.11ac)
• Wi-Fi 6 (Wi-Fi 802.11ax)
• 64-bit/128-bit WEP
• AES-CCMP
• TKIP
Bluetooth
Bluetooth 5.0 Bluetooth 5.1

Ports and connectors

Table 12. Ports and connectors
Description Values
External:
Network
USB
Audio
1 RJ-45
• One USB 2.0 Type-A port (front)
• One USB 2.0 Type-A with PowerShare (front)
• One USB 3.2 Gen 2 Type-A (front)
• One USB 3.2 Gen 2 Type-C port with PowerDelivery (front)
• Two USB 2.0 ports with Power On (rear)
• One USB 2.0 header for Comon Access Card (CAC)
• Three USB 3.2 Gen 1 Type-A ports (rear)
• One USB 3.2 Gen 2 Type-A ports (rear)
• One Universal Audio Jack (front)
• One Line -in/out retasking (rear)
Specifications of Precision 3440 Small Form Factor 17
Table 12. Ports and connectors (continued)
Description Values
Video
Memory card reader
Power port

Security

Antenna
Internal:
SATA
M.2
• Two DisplayPort 1.4 port (rear)
• One HDMI 2.0 port (rear, optional)
• One VGA port (rear, optional)
• One Type-C w/DP-Alt mode (rear optional)
One SD-card 4.0 slot
AC-in
• One Wedge-shaped lock
• One Padlock Loop
• One Lockable Port Cover
• One Intrusion switch
Two SMA connectors (optional)
One SATA slots for 2.5-inch Hard-disk drive
• One half-height Gen3 PCIe x16 slot (discrete graphics)
• One half-height Gen3 PCIe x4 slot
• Three SATA 3.0 for Hard-disk drive/Solid-state drive
• One M.2 2230 slot for WiFi/Bluetooth card
• One M.2 2230/2280 slot for solid-state drive
• One M.2 2230 slot for PCIe solid-state drive
NOTE: To learn more about the features of different
types of M.2 cards, see the knowledge base article
SLN301626.

Power supply

Table 13. Power supply
Feature Specifications
Input voltage
Wattage • 200 W 100V-240V Full range
100–240 VAC, 50–60 Hz
• 260 W 100V-240V Full range
Security
Table 14. Security
Feature Description
Trusted Platform Module (TPM) 2.0 Integrated on the system board
Firmware TPM Optional
Windows Hello Support Optional via security input device
18 Specifications of Precision 3440 Small Form Factor
Table 14. Security (continued)
Feature Description
Cable cover Optional
Chassis intrusion switch Standard
Dell Smartcard Keyboard Optional
Chassis lock slot and loop support Standard

Security Software

Table 15. Security Software
Features Description
Dell Endpoint Security Suite Enterprise Optional
Dell Data Guardian Optional
Dell Encryption (Enterprise or Personal) Optional
Dell Threat Defense Optional
RSA SecurID Access Optional
RSA NetWitness Endpoint Optional
MozyPro or MozyEnterprise Optional
VMware Airwatch/WorkspaceONE Optional
Absolute Data & Device Security Optional

CAC/PIV Module

Table 16. CAC/PIV Module
Features Tower/Small Form Factor/Micro
Connector Type ISO 7816 compliant contact smart card NFC forum 2.0
PCB
Dimensions (W x L x T) 74.5 mm x 45.7 mm
Layer 6
Controller Details
Controller bus architecture (example PCIe 1.0a x1) USB 2.0
Data transfer mode (example Bus-Master DMA) USB 2.0
Power consumption (full operation per data rate connection speed)
288.08 mA x 3.3 V
Specifications of Precision 3440 Small Form Factor 19
Table 16. CAC/PIV Module (continued)
Features Tower/Small Form Factor/Micro
Power consumption (standby operation) 8.9 mA x 3.3 V
Standard compliance (example 802.1P) NFC Forum 2.0, ISO7816
Hardware Certifications (example FCC, B, GS mark…) FIPS201, FIPS140-2
Boot ROM Support Integrated inside Lynx SoC
Processor/Chipset
NFC Broadcom Cortex-M3 BC58102
Card reader driver NXP TDA8034HN/C2
USB 2.0 Hub GENESYS GL850G-OHY50
PROM WINBOND W25Q32JVSSIQ 32M/bit
Power IC RICHTEK RT5796AHGJ5
Power LDO (NFC VBAT) GMT G9141T11U
Environmental
Operating System Driver Support Dell ControlVault2 Driver
Manageability (examples WOL, PXE) No, this is not a LAN controller chipset.
Management Capabilities Alerting (example ASF 2.0) No, this is not a LAN controller chipset.
Add-in Slots
Card reader connector 1 (10 PIN)
USB 2.0 header 1 (5 PIN)
NFC header 1 (6 PIN)

Out of Band Systems Management Intel Standard Manageability

Intel Standard Manageability (ISM) must be configured in our factory at the time of purchase, as it is NOT field upgradable. ISM offers out-of-band management and DASH compliance https://registry.dmtf.org/registry/results/field_initiative_name%3A%22DASH
%201.0%22. ISM offers a limited set of out-of-band features like remote power on/off, Serial-over-LAN redirect, Wake-on-LAN, etc. ISM
leverages the same capabilities that were available with Intel’s Active Management Technology (AMT) version 5.0.
To learn more about Intel ISM, visit Intel’s website at: https://software.intel.com/en-us/blogs/2009/03/27/what-is-standard-
manageability

Computer environment

Airborne contaminant level: G1 as defined by ISA-S71.04-1985
20
Specifications of Precision 3440 Small Form Factor
Table 17. Computer environment
Description Operating Storage
Temperature range
Relative humidity (maximum)
Vibration (maximum)
Shock (maximum)
Altitude (maximum)
* Measured using a random vibration spectrum that simulates user environment.
† Measured using a 2 ms half-sine pulse when the hard drive is in use.
*
10°C–35°C (50°F–95°F) -40°C-65°C (-40°F-149°F)
20% to 85% (non-condensing) 5% to 95% (non-condensing)
0.52 GRMS random at 5 Hz to 350 Hz 2.0 GRMS random at 5 Hz to 350 Hz
Bottom half-sine pulse with a change in velocity of 50.8 cm/sec (20 in./sec)
3048 m (10,000 ft) 10,668 m (35,000 ft)
105G half-sine pulse with a change in velocity of 133 cm/sec (52.5 in./sec)

Service and support

NOTE: For more details on Dell Service Plans, see https://www.dell.com/learn/us/en/19/services/warranty-support-
services.
Table 18. Warranty
Warranty
1 Year Basic Warranty with Hardware Service on site service after remote diagnosis
2 Years Basic Warranty Extension
3 Years Basic Warranty Extension
4 Years Basic Warranty Extension
5 Years Basic Warranty Extension
1 Year ProSupport and Next Business Day on-site service
2 Years ProSupport and Next Business Day on-site service
3 Years ProSupport and Next Business Day on-site service
4 Years ProSupport and Next Business Day on-site service
5 Years ProSupport and Next Business Day on-site service
1 Year ProSupport Plus for Client with Next Business Day on-site service
2 Years ProSupport Plus for Client with Next Business Day on-site service
3 Years ProSupport Plus for Client with Next Business Day on-site service
4 Years ProSupport Plus for Client with Next Business Day on-site service
5 Years ProSupport Plus for Client with Next Business Day on-site service
Table 19. Accidental damage services
Accidental Damage Services
1 Year Accidental Damage Service
2 Years Accidental Damage Service
3 Years Accidental Damage Service
4 Years Accidental Damage Service
Specifications of Precision 3440 Small Form Factor 21
Table 19. Accidental damage services (continued)
Accidental Damage Services
5 Years Accidental Damage Service

Support policy

For more information on support policy, see the knowledge base articles PNP13290, PNP18925, and PNP18955.

Energy Star and Trusted Platform Module (TPM)

Table 20. Energy Star and TPM
Features Specifications
TPM (Optional) HW/FW Trusted Platform Module support

Accessories

Table 21. Accessories
Accessories
Audio
Keyboard and Mice
Monitors
Stands and Mounts

Add-in cards

Table 22. Add-in cards
Add-in cards
Serial and parallel port PCIe card
• Dell Pro Stereo Headset - UC350
• Dell Wireless Keyboard and Mouse, KM636, Black
• Dell 24 Monitor - E2420HS
• Dell Dual Monitor Arm - MDA20
• Dell Dual Monitor Stand - MDS19
• Dell Single Monitor Arm - MSA20
22 Specifications of Precision 3440 Small Form Factor
4

Getting help

Topics:
• Contacting Dell

Contacting Dell

Prerequisites
NOTE: If you do not have an active Internet connection, you can find contact information on your purchase invoice,
packing slip, bill, or Dell product catalog.
About this task
Dell provides several online and telephone-based support and service options. Availability varies by country and product, and some services may not be available in your area. To contact Dell for sales, technical support, or customer service issues:
Steps
1. Go to Dell.com/support.
2. Select your support category.
3. Verify your country or region in the Choose a Country/Region drop-down list at the bottom of the page.
4. Select the appropriate service or support link based on your need.
Getting help 23
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
