Flash ROM
NA
Size
16 Mbit
Type [e.g. Flash PROM, EEPROM]
Serial flash memory
Volatility
Non-volatile
Can user programs or operating
system write data to it during
normal operation?
No
Purpose
To store firmware
How is data input to this
memory?
Loading flash memory requires a vendor-provided
firmware file
How is this memory write
protected?
Software write protected
DDR SDRAM
NA
Size
8x16 Mbit
Type [e.g. Flash PROM, EEPROM]
DDR SDRAM
Volatility
Volatile
Can user programs or operating
system write data to it during
normal operation?
No
Purpose
Buffer of video decoder
How is data input to this
memory?
Video is received by video decoder chip(CVBS processor)
and processed in SDRAM.
How is this memory write
protected?
No write protect mechanism
DDR2 SDRAM
NA
Size
32x16 Mbit
Statement of Volatility – Dell 1708FPf, 1908FPf Monitor
The purpose of this document is to certify that Dell’s XXXX monitor will not save, retain or reproduce a
signal to any internal or external component after power has been removed and reapplied to the unit.
The Dell XXXX monitor contains both volatile and non-volatile (NV) memory ICs. Volatile memory(s) lose
their data immediately upon removal of power. Non-volatile memory ICs continue to retain their data
even after the power has been removed. However, no input video data is written into these memory ICs
during operation.
List below contains volatile and non volatile memory ICs used in Dell XXXX monitor.
Type [e.g. Flash PROM, EEPROM]
DDR2 SDRAM
Volatility
Volatile
Can user programs or operating
system write data to it during
normal operation?
No
Purpose
Buffer for video processing
How is data input to this
memory?
Video is received by monitor core chip and processed in
SDRAM.
How is this memory write
protected?
No write protect mechanism
System EEPROM
AT24C04N
Size
4Kbit
Type [e.g. Flash PROM, EEPROM]
EEPROM
Volatility
Non-volatile
Can user programs or operating
system write data to it during
normal operation?
Yes
Purpose
Storage of system setting(OSD)
How is data input to this
memory?
Control the OSD menu and change OSD setting(ex.
Brightness,contrast,color setting) and the setting will be
stored into system EEPROM
How is this memory write
protected?
Software write protected
VGA EDID EEPROM
AT24C02AN
Size
2Kbit
Type [e.g. Flash PROM, EEPROM]
EEPROM
Volatility
Non-volatile
Can user programs or operating
system write data to it during
normal operation?
No
Purpose
To store VGA EDID
How is data input to this
memory?
Writing EDID requires a vendor-provided tool and an
specific VGA cable.
How is this memory write
protected?
Hardware and software write protected
DVI EDID EEPROM
AT24C02AN
Size
2Kbit
